110
Securitron® DM62
®
Electromagnetic Locks
Magnalock
The ultimate 1,200 lbs holding
force Magnalock double magnet for
indoor/outdoor high security
The versatile
Securitron DM62
electromagnetic lock
offers strength and
ease of maintenance
for interior, perimeter
and exterior
access control—
in a compact
double magnet.
This all-in-one unit is designed for double
doors with no mullion. With unsurpassed
durability, the Securitron DM62 will last
long after most buildings wear out.
Features
Standard Features
• Ultra-secure collapsing blind
nuts mount to door frame for
strength and reliability
• Fully sealed for weatherproof
operations
• 3' [1 m] of jacketed, stranded
conductor cable for each lock
• Automatic dual-voltage
—no field adjustment required
• Instant release circuit
—no residual magnetism
• Noise suppression with built-in MOV
• Efficient, low power usage
• Rust resistant — all ferrous metal
surfaces plated for durability
• MagnaCare
no-fault, no questions asked warranty
®
lifetime replacement,
Optional Features
• B Patented BondSTAT
magnetic bond sensor
• D Integrated door
position switch (DPS)
• OS Offset strike plates
US assaabloyesh.com | 800.626.7590 | customerservice.esh@assaabloy.com
Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com
Copyr ight © 2019, Hanche tt Entr y Systems , Inc., an A SSA ABLOY Group c ompany. All r ights re served . Reproduc tion
in whol e or in part w ithout the e xpress w ritten p ermissio n of Hanchet t Entry Sy stems, Inc . is prohibi ted.
Updated5/31/19 Patent pending and/or patent www.assaabloydss.com/patents
Page 3
Securitron DM62 Magnalock
Dimensions
Magnalock
3"
[76m m]
1-3/4"
[44 mm]
Strike
22"
[559 mm]
1/2 "
[12m m]
111
Electromagnetic Locks
2-3/4"
[70 mm]
6"
[152mm]
Strike
Specifications
Certifications
• UL 10C Listed
• CAN4-S104, CAN/ ULC-S533 Listed
• ANSI/BHMA A156.23, Grade 2;
E08511-1000 Compliant
• CSFM- California State Fire Marshal Approved
Electrical (Per Lock)
• 250 mA at 12 VDC
• 150 mA at 24 VDC
Holding Force (Per Lock)
• 1,200 lbs [544kg]
Operating Temperature
• -40˚ to 140˚F [-40˚ to 60˚C]
• Indoor or Outdoor use
Shipping Weight
• 16 lbs [7.26kg]
How to Order
2-1/2" [63.5 mm]
The Securitron DM62 with
Strike fits in 2-1/2" [63.5mm]
of flat mounting space
Model Series Monitoring Options Strike Plate Options
DM62 BD – OS
DM62 (blank) N o M o n i t o r i n g (blank) Standard Strike
B BondSTAT Monitor OS Offset Strike
D Door Position Switch
