DPX I865 CS

Scott DPX I865 CS User Manual

CONTENTS
CONTENTS ............................................................................................................................................. 1
ACCESSORIES ....................................................................................................................................... 1
IMPORTANT ............................................................................................................................................ 2
SAFETY ............................................................................................................................................... 2-5
INSTALLATION ....................................................................................................................................... 5
CONNECTIONS .................................................................................................................................... 6-7
MAIN UNIT ............................................................................................................................................... 8
REMOTE CONTROL ................................................................................................................................9
BASIC SETUP .................................................................................................................................. 10-13
SYSTEM SETUP .............................................................................................................................. 13-15
PLAYING BACK A DISC ........................................................................................................................ 16
PLAYING BACK A KODAK PICTURE CD/JPEG .................................................................................... 17
PLAYING BACK A MP3 CD ................................................................................................................... 17
LOCATING A SPECIFIC TITLE, CHAPTER OR TRACK ......................................................................... 18
PLAYING REPEATEDLY........................................................................................................................ 18
PLAYING IN FAVORITE ORDER ........................................................................................................... 19
DVD BOOKMARK ................................................................................................................................. 20
USING THE GOTO FEATURE ........................................................................................................... 20-21
ZOOMING A PICTURE ........................................................................................................................... 22
USB OR CARD PLAYBACK ................................................................................................................. 23
CARRYING BAG INSTALLATION ......................................................................................................... 24
DISC NOTES .................................................................................................................................... 24-25
TROUBLE SHOOTING GUIDE .......................................................................................................... 25-26
TECHNICAL SPECIFICATIONS . ............................................................................................................. 27
ACCESSORIES
Supplied Accessories
Remote Control .......................................................... X 1
Rechargeable Battery Pack ..................................... X 1
AC adaptor ................................................................ X 1
Cigarette adaptor ...................................................... X 1
Carry bag ................................................................. X 1
Earphone ................................................................... X 1
AV cable................................................................... X 1
GB–1
IMPORTANT
Since CD circuitry may cause interference to other radio tuners nearby, switch this unit off when not in use or move it away from the affected radio tuner.
NOTE :
This equipment generates uses and can radiate radio frequency energy and if not installed and used in accordance with the instruction, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television, which can be determined by turning the equipment off and the user is encouraged to try to correct the interference by one or more of the following measures :
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio / TV technician for help.
Caution When Using
Be careful of ambient temperature
• Using the DVD player in a place where the temperature is over 40 deg C or under 0 deg C will result in abnormal function.
• Never expose this unit to prolonged periods of high temperature or leave the unit situated where high temperatures can occur (such as the dash panels of vehicles on very hot days). This could cause malfunctions or damage to the product.
SAFETY
WARNING :
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE CABINET. REFER SERVICING TO QUALIFIED PERSONNEL ONLY.
– The AC/DC adaptor and DVD player shall not be exposed to dripping or splashing and that no
objects filled with liquids, such as vases, shall be placed on apparatus or other equivalent.
– Minimum distances around the apparatus for sufficient ventilations. – The ventilation should not be impeded by covering the ventilation openings with items such as
newspaper, tablecloths, curtains etc.
– No open flame sources such as lighted candles should be placed on the apparatus. – Attention should be drawn to the environmental aspects of battery disposal. – The use of apparatus in moderate climates.
LASER :
This Digital Video Disc Player employs a Laser System. To ensure proper use of this product, please read this owner’s manual carefully and retain for
future reference. Should the unit require maintenance, contact the qualified service personnel. Use of controls, adjustments or the performance of procedures other than those specified may
result in hazardous radiation exposure. To prevent direct exposure to laser beam, do not try to open the enclosure. Visible and invisible laser radiation when open and interlocks defeated.
GB–2
DO NOT ST ARE INTO BEAM
WARNING :
To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.
CAUTION :
Use of controls or adjustments or performance of procedures other than those specified may result in hazardous radiation exposure.
RISK OF ELECTRIC SHOCK DO NOT OPEN
T
o reduce the risk of electric shock, do not remove cover ( or back ).
No user serviceable parts inside. Refer servicing to qualified service personnel.
The lightning flash witjh arrowhead symbol, with in an equilateral triangle, is intended to alert user to the presence of uninsulated “ dangerous voltage “ within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the pesence of important operating and maintenance ( servicing ) instruction in the literature accompanying the appliance.
CAUTION
INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK FAILED OR DEFEATED
AVOID DIRECT EXPOSURE TO LASER BEAM.
SAFETY
CAUTION
CAUTION :
PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS OWNER’S MANUAL AND THOSE MARKED ON THE UNIT. KEEP THESE INSTRUCTIONS. RETAIN THIS BOOKLET FOR FUTURE REFERENCE.
This set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. The safeguards incorporated in this unit will protect you if you observe the following procedures for installation, use and servicing. This unit does not contain any parts that can be repaired by the user.
DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO DANGEROUS VOLTAGE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL ONLY.
1. Read these instructions.
After unpacking this product, read the owner manual carefully.
2. Keep these instructions.
Retain this booklet for future reference.
3. Heed all warnings.
4. Follow all the operating and other instructions.
5. Do not use this apparatus near water.
6. Clean only with a damp cloth.
GB–3
SAFETY
7. Do not block any of the ventilation openings. Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9. Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles and the point where they exit from the apparatus.
10. Only use attachments/accessories specified by the manufacturer.
11. Use only with a cart, stand, tripod, bracket or table specified by the manufacturer, or sold
with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
12. Unplug this apparatus during lightning storms or when unused for long periods of time.
13. Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as when the power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
14. Burden
Do not place a heavy object on, or step on the product. The object may fall, causing serious personal injury and serious damage to the product.
15. Disc
Do not use a cracked, deformed, or repaired disc. These discs are easily broken and may cause serious personal injury and product malfunction.
16. Damage Requiring Service
Unplug this product from the wall refer servicing to qualified service personnel under the
following conditions: a) When the power-supply cord or plug is damaged. b) If liquid has been spilled, or objects have fallen into the product. c) If the product has been exposed to rain or water. d) If the product does not operate normally by following the operating instructions. Adjust only
those controls that are covered by the operating instructions. Improper adjustment of other
controls may result in damage and will often require extensive work by a qualified technician
to restore the product to its normal operation. e) If the product has been dropped or damaged in any way. f ) When the product exhibits a distinct change in performance - this indicates a need for
service.
17. Servicing
Do not attempt to service this product yourself as opening or removing covers may expose
you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
18. Replacement Parts
When replacement parts are required, be sure the service technician has used replacement
parts specified by the manufacturer or have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock, or other hazards.
19. Safety Check
Upon completion of any service or repairs to this product, ask the service technician to
perform safety checks to determine that the product is in proper operating condition.
GB–4
SAFETY
20. AC Power disconnect
The AC/DC adaptor is used as the disconnection device and it shall remain readily operable. To
be completely disconnected the power input, the AC/DC adaptor of the apparatus shall be
disconnected from the mains completely. Since the AC/DC adaptor is used as the
disconnection device and the signal lamp of the unit would be used as an indication of Power
On, if the signal lamp is turned Off, the apparatus is completely disconnected from the mains.
NOTE : See the marking on the bottom of cabinet
Batteries
1. Battery pack
• Use this unit to recharge the battery pack.
• Do not use the battery pack with equipment other than the specified player.
• Do not use the player outside if it is snowing or raining. (The battery pack is not waterproof.)
• Do not get dirt, sand, liquids, or other foreign matter on the terminals.
• Do not touch the plug terminals with metal objects.
• Do not disassemble, remodel, heat or throw into fire.
2. Disposing of the batteries
Check and follow your local regulations before disposal.
CAUTION:
The batteries used in this device may present a risk of fire or chemical burn if mistreated.
Do not heat the batteries pack above 60°C.
Remove the battery pack when you are not using the appliance. In addition, the battery pack has to be recharged every 3 months in order to ensure a longer battery life.
PLAYER ZONES
For the purpose of distribution of DVD Discs, the world has been separated into 6 zones. The zone your player is intended for is indicated on the “Zone Label”. This should be the same as the label on discs available in your region. If you have any difficulties in playing a disc, make sure that the disc is for the same zone as your player.
INSTALLATION
Install your DVD player on a stable flat surface. The unit should be situated with enough space around it so that proper heat ventilation is assured. Allow 20cm clearance from the rear and the top of the unit, and 10cm from each side.
Caution: Do not install this equipment in confined space with poor ventilation.
This product incorporates copyright protection technology that is protected by U.S.patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision, Reverse engineering or disassembly is prohibited.
Apparatus Claims of U.S. Patent Nos. 4,631,603; 4,819,098; 4,907,093; 5,315,448; and 6,516,132. Licensed for limited viewing uses only.
GB–5
CONNECTIONS
1. Connecting to TV
Connect the Audio ( Black ) and Video ( Yellow ) cable to Audio/Video Out jacks on your DVD Player, and to the corresponding Audio/Video Input jacks on your TV.
NOTE : AV switch must be switched to “OUT” position
Remarks : To prevent EMI interference with other electronic equipment, we recommend you
use an A/V cable (included).
2. Connecting for in car use
Use the Car Power Adaptor (included) for power when using the DVD player in a car.
1. Plug the adaptor into the car cigarette lighter.
2. Plug the pin into the DC IN jack on the main unit.
GB–6
CONNECTIONS
3. Connect to external analog Video / Audio source (using the appliance as a monitor)
Connect the Audio (Red/White) and Video (Yellow) cable to Audio/Video Out jacks on your external VCD/DVD Player as shown:
NOTE : AV switch must be switched to “ IN ” position.
4. Connect to S-Video
Connect S-Video cable (not included) to S-Video jack on your DVD player, and to the correspond­ing S-Video jack on your TV.
GB–7
MAIN UNIT
1. ON/OFF – Turn the player on or off.
2. PUSH OPEN – Open the disc door.
3. PLAY – Start disc playback or pause the playback.
4. STOP – Stops disc playback.
5. SKIP + – Skip to the next track, and next chapter ( only while playing )
6. SKIP - – Skip to the beginning / previous track (only while playing)
7. MENU – In DVD mode, press for Menu setup for DVD ( if available ). Switch PBC ON/OFF (For
VCD/SVCD)
8. SCREEN MODE – Press to select the screen display format between 16:9 and 4:3.
9. NAVIGATION ( / / / ) – Select Menu items
10. OK – Press to confirm the selected function.
11. SETUP – Accesses the DVD player setup menu.
12. DISPLAY – Press for detailed information on the disc playing.
13. VOLUME – Adjust the volume to the desired level using the dial.
14. HEADPHONE JACK – Listen to stereo sound with headphones (included)
15. VIDEO
Video out – Connects to the Video input to your TV. ( A/V Switch set at “ OUT ” ) Video in – Connects to the Video from external video source. ( A/V Switch set at “ IN ” )
16. AUDIO
Audio Out – Connects to the Audio input to your TV/External amplifier system. ( A/V Switch set at “ OUT ” )
Audio In – Connects to the Line OUT from external audio source. ( A/V Switch set at “ IN ” )
17. A/V IN/OUT – Switch between analog Audio and Video IN / OUT function.
18. DC IN – Connects to DC power source in
19. IR – Infrared sensor for remote control.
20. POWER LED – Led lights up when the player turns on.
21. CHARGE LED – Led blinks in red when the battery is being charged; LED lights in red when
the battery is charged full.
22. SPEAKERS
23. MODE – Select disc or media (USB or SD/MMC card).
24. S-VIDEO – S-Video output to your TV.
25. USB – USB socket.
26. CARD – SD/MMC card slot.
