Page 1
Direct Coupled
Actuators
SmartX Actuators
For the full range of HVAC applications
Make the most of your energy
Page 2
2
SmartX Spring-Return Direct Coupled Actuators
We offer a complete line of direct coupled actuators for all your spring return actuator needs.
Direct coupled easy to install, spring return SmartX actuators are available with torques that range from 30
to 150 lb-in for two position, floating or proportional control.
Value-Driven General Purpose Applications
30 lb-in Mx4D series
30 lb-in Mx4D series direct coupled for up to ½” shafts, NEMA 2, 10’ plenum rated cable
standard, accepts ½” conduit connector, convenient manual override, two position, floating or
proportional control.
High Performance HVAC Applications
35 lb-in Mx40 series
35 lb-in Mx40-704x series direct coupled standard mounting to ½” shafts with optional mounting to
¾” shafts. NEMA 2, optional built in auxiliary switches, CW or CCW spring return mounting, 3’ cable,
accepts ½” conduit connector, two position, floating or proportional control.
60 lb-in/133 lb-in Mx41-7xxx series
60 lb-in/133 lb-in Mx41-7xxx series direct coupled standard mounting to ¾” shafts with optional
mounting to 1”. NEMA 2, optional built in auxiliary switches, CW or CCW spring return mounting, 3’
cable, accepts ½” conduit connector, convenient manual override, multiple accessories available,
two position, floating or proportional control.
Damp and Harsh Environment Applications
150 lb-in Mx40-71xx series
150 lb-in Mx40-71xx series direct coupled standard mounting to ½” shafts with optional mounting to
1”. A premier oil immersed gear train actuator for long dependable service with a heavy duty NEMA 4
housing, 3’ cable, accepts ½” conduit connector, CW or CCW spring return mounting.
Schneider Electric
F-27272- 4 November 2014
Page 3
Spring Return Damper Actuators
Mx4D-703x and Mx4D-803x Series 30 lb-in Direct Coupled
Designed for controlling air dampers in building systems that require fail safe return, with two
position, floating or proportional control.
Features
• NEMA 2 and Plenum rated
• 10’ plenum cable (24V Models), 3’ appliance wires for 120/230 vac models
• ½” conduit connection or seal tight
• Overload protected throughout stroke
• 93° nominal rotation
• Automatically adjust input span to match damper travel
• Manual override
• UL-873, cUL C22-2, CE, C-Tick
• Operating Temperature –22 to 140°F (–30 to 60°C)
• Humidity 15 to 95% non-condensing
Value-Driven General Purpose Applications
Part Number Torque
lb-in
(NM)
MA4D-7033-100 30 (3.4) CCW 2 Position 24 vac/dc 5.1 — No 56 23
MA4D-7030-000 30 (3.4) CCW 2 Position 120 vac 7.8 — No 56 23
MA4D-8033-100 30 (3.4) CW 2 Position 24 vac/dc 5.1 — No 56 23
MA4D-8030-000 30 (3.4) CW 2 Position 120 vac 7.8 — No 56 23
MF4D-7033-100 30 (3.4) CCW Floating 24 vac/dc 6.8 2-10 vdc No 85 21
MF4D-8033-100 30 (3.4) CW Floating 24 vac/dc 6.8 2-10 vdc No 85 21
MS4D-7033-100 30 (3.4) CCW 2-10 vdc 24 vac/dc 6.1 2-10 vdc No 85 21
MS4D-7033-130 30 (3.4) CCW 6-9 vdc 24 vac/dc 6.1 6-9 vdc No 85 21
MS4D-7033-150 30 (3.4) CCW 0-10 vdc 24 vac/dc 6.1 0-10 vdc No 85 21
MS4D-7033-160 30 (3.4) CCW 4-20 ma 24 vac/dc 6.1 2-10 vdc No 85 21
MS4D-8033-100 30 (3.4) CW 2-10 vdc 24 vac/dc 6.1 2-10 vdc No 85 21
MS4D-8033-130 30 (3.4) CW 6-9 vdc 24 vac/dc 6.1 6-9 vdc No 85 21
MS4D-8033-150 30 (3.4) CW 0-10 vdc 24 vac/dc 6.1 0-10 vdc No 85 21
MS4D-8033-160 30 (3.4) CW 4-20 ma 24 vac/dc 6.1 2-10 vdc No 85 21
Spring
Return
Actuator Inputs Outputs Approximate Timing in seconds @ 70°F
Control Voltage VA @
Feedback Auxiliary
60Hz
Powered Spring Return
Switch
3
Schneider Electric
F-27272- 4 November 2014
Page 4
4
Spring Return Damper Actuators
Mx40-704x Series 35 lb-in Direct Coupled
Designed for controlling air dampers in building systems that require fail safe return, with two
position, floating or proportional control.
Features
• NEMA 2 and Plenum rated
• ½” conduit connection or seal tight
• 3’ plenum cable (24V models), 3’ appliance wires for 120/230 vac models
• Overload protected throughout stroke
• 95° nominal rotation
• Automatically adjust input span to match damper travel
• UL-873, cUL C22-2, CE, C-Tick
• Operating Temperature –22 to 140°F (–30 to 60°C)
• Humidity 15 to 95% non-condensing
High Performance HVAC Applications
Part Number Torque
lb-in
(NM)
MA40-7040 35 (4) CW/CCW 2 Position 120 vac 4.3 — — <50 <28
MA40-7040-501 35 (4) CW/CCW 2 Position 120 vac 4.3 — 1-SPDT <50 <28
MA40-7041 35 (4) CW/CCW 2 Position 230 vac 4.6 — — <50 <28
MA40-7041-501 35 (4) CW/CCW 2 Position 230 vac 4.6 — 1-SPDT <50 <28
MA40-7043 35 (4) CW/CCW 2 Position 24 vac/dc 4.4 — — <50 <28
MA40-7043-501 35 (4) CW/CCW 2 Position 24 vac/dc 4.4 — 1-SPDT <50 <28
MF40-7043 35 (4) CW/CCW Floating 24 vac/dc 5.9 — — <130 <25
MF40-7043-501 35 (4) CW/CCW Floating 24 vac/dc 5.9 — 1-SPDT <130 <25
MS40-7043 35 (4) CW/CCW 2-10 vdc 24 vac/dc 5.9 2-10 vdc — <130 <25
MS40-7043-501 35 (4) CW/CCW 2-10 vdc 24 vac/dc 5.9 2-10 vdc 1-SPDT <130 <25
Spring
Return
Actuator Inputs Outputs Approximate Timing in seconds @ 70°F
Control Voltage VA @
Feedback Auxiliary
60Hz
Powered Spring Return
Switch
Schneider Electric
F-27272- 4 November 2014
Page 5
Spring Return Damper Actuators
Mx41-7xxx Series 60 lb-in and 133 lb-in Direct Coupled
Designed for controlling air dampers in building systems that require fail safe return, with two
position, floating or proportional control.
Features
• NEMA 1 and 2 rated models
• ½” conduit connection or seal tight
• 3’ plenum cable (24V models), 3’ appliance wires for 120/230 vac models
• Overload protected throughout stroke
• 95° nominal rotation
• Automatically adjust input span to match damper travel
• Tandem mounting
• Manual override
• Reverse action switch (MS41 models)
• UL-873, cUL C22-2, CE, C-Tick
• Operating Temperature –40 to 160°F (–40 to 71°C)
• Humidity 15 to 95% non-condensing
5
High Performance HVAC Applications
Part Number Torque
lb-in
(NM)
MA41-7070 60 (7) CW/CCW 2 Position 120 vac 5.6 — — <80 <40
MA41-7070-502 60 (7) CW/CCW 2 Position 120 vac 5.6 — 2-SPDT <80 <40
MA41-7071 60 (7) CW/CCW 2 Position 230 vac 8.0 — — <80 <40
MA41-7071-502 60 (7) CW/CCW 2 Position 230 vac 8.0 — 2-SPDT <80 <40
MA41-7073 60 (7) CW/CCW 2 Position 24 vac/dc 4.8 — — <80 <40
MA41-7073-502 60 (7) CW/CCW 2 Position 24 vac/dc 4.8 — 2-SPDT <80 <40
MA41-7150 133 (15) CW/CCW 2 Position 120 vac 10.0 — — <190 <30
MA41-7150-502 133 (15) CW/CCW 2 Position 120 vac 10.0 — 2-SPDT <190 <30
MA41-7151 133 (15) CW/CCW 2 Position 230 vac 10.6 — — <190 <30
MA41-7151-502 133 (15) CW/CCW 2 Position 230 vac 10.6 — 2-SPDT <190 <30
MA41-7153 133 (15) CW/CCW 2 Position 24 vac/dc 9.7 — — <190 <30
MA41-7153-502 133 (15) CW/CCW 2 Position 24 vac/dc 9.7 — 2-SPDT <190 <30
MF41-7073 60 (7) CW/CCW Floating 24 vac/dc 6.2 — — <195 <30
MF41-7073-502 60 (7) CW/CCW Floating 24 vac/dc 6.2 — 2-SPDT <195 <30
MF41-7153 133 (15) CW/CCW Floating 24 vac/dc 9.7 — — <190 <30
MF41-7153-502 133 (15) CW/CCW Floating 24 vac/dc 9.7 — 2-SPDT <190 <30
MS41-7073 60 (7) CW/CCW 2-10vdc 24 vac/dc 5.8 2-10 vdc — <195 <30
MS41-7073-502 60 (7) CW/CCW 2-10vdc 24 vac/dc 5.8 2-10 vdc 2-SPDT <195 <30
MS41-7153 133 (15) CW/CCW 2-10vdc 24 vac/dc 9.7 2-10 vdc <190 <30
MS41-7153-502 133 (15) CW/CCW 2-10vdc 24 vac/dc 9.7 2-10 vdc <190 <30
Spring
Return
Actuator Inputs Outputs Approximate Timing in seconds @ 70°F
Control Voltage VA @
Feedback Auxiliary
60Hz
Powered Spring Return
Switch
Schneider Electric
F-27272- 4 November 2014
Page 6
6
Spring Return Damper Actuators
Mx40-717x Series 150 lb-in Direct Coupled
Designed for controlling air dampers in building systems that require fail safe position. With two
position, floating or proportional control.
Features
• Premier oil immersed gear train construction
• NEMA 4 capable
• ½” conduit connections
• 3’ plenum cable (24V models), 3’ appliance wires for 120/230 vac models
• Tandem mounting
• Overload protected throughout stroke
• 93° nominal rotation
• UL-873, cUL C22-2, CE, C-Tick
• Operating Temperature –25 to 140°F ( –32 to 60°C)
• Humidity 15 to 95% non-condensing
Damp & Harsh Environment Applications
Part Number Torque
lb-in
(NM)
MA40-7170 150 (17) 120 vac 8.4 —
MA40-7171 150 (17) CW/CCW 2 Position 240 vac 9.8 — No 162 82
MA40-7173 150 (17) 24 vac/dc 7.4 —
MF40-7173 150 (17) CW/CCW Floating 24 vac/dc 8.1 — No 162 82
MS40-7170 150 (17) CW/CCW 2-10 vdc 240 vac 8.5 2-10 vdc No 147 65
MS40-7171 150 (17) CW/CCW 2-10 vdc 240 vac 10.8 2-10 vdc No 147 65
MS40-7173 150 (17) CW/CCW 2-10 vdc 24 vac/dc 7.8 2-10 vdc No 147 65
Spring
Return
Actuator Inputs Outputs Approximate Timing in seconds @ 70°F
Control Voltage VA @
Feedback Auxiliary
60Hz
Powered Spring Return
Switch
Schneider Electric
F-27272- 4 November 2014
Page 7
SmartX Non Spring Return Direct Coupled Actuators
We offer a complete line of direct coupled actuators for all your non spring return actuator needs.
Direct coupled easy to install, non spring return SmartX actuators are available with torque ranges from 35
to 300 lb-in for floating or proportional control.
Value-Driven General Purpose Applications
35 lb-in or 70 lb-in Mx4D-60xx series
35 lb-in or 70 lb-in Mx4D-60xx series direct coupled up to ½” shafts, NEMA 2, 10’ plenum rated cable,
accepts ½” conduit connector, convenient manual override, two position, floating or proportional
control models.
High Performance HVAC Applications
44 lb-in or 88 lb-in Mx41-60xx series
44 lb-in or 88 lb-in Mx41-60xx series direct coupled standard mounting to 5/8” shafts, NEMA 2,
manual override, 3’ plemun rated cable, optional ½” conduit connection, optional built in auxiliary
switches, two position, floating or proportional control.
7
133 lb-in Mx41-61xx series
133 lb-in Mx41-61xx series direct coupled up to ¾” shafts, NEMA 1, manual override, 3’ cable,
accepts ½” conduit connector, optional auxiliary switch, two position, floating or proportional control.
Damp and Harsh Environment Applications
300 lb-in Mx41-63xx series
300 lb-in Mx41-63xx series direct couple standard mounting to ½” shafts with optional mounting
to 1”, manual override, premier oil immersed gear train actuator for long dependable service with
a heavy duty NEMA 4 housing, 3’ cable, accepts ½” conduit connector, two position, floating or
proportional control.
Schneider Electric
F-27272- 4 November 2014
Page 8
8
Non Spring Return Damper Actuators
Mx4D-60x3 Series 35 lb-in and 70 lb-in Direct Coupled
Designed for controlling air dampers in building systems with floating or proportional control.
Features
• NEMA 2 and Plenum rated
• 10’ plenum cable
• ½” conduit connection or seal tight
• Overload protected throughout stroke
• 93° nominal rotation
• Automatically adjust input span to match damper travel
• Manual override
• UL-873, cUL C22-2, CE, C-Tick
• Operating Temperature –22 to 140°F (–30 to 60°C)
• Humidity 15 to 95% non-condensing
Value-Driven General Purpose Applications
Part Number Torque
lb-in (NM)
MF4D-6043-100 35 (4) Floating 24 vac/dc 4.4 2-10 vdc No 85
MF4D-6083-100 70 (8) Floating 24 vac/dc 5.9 2-10 vdc No 85
MS4D-6043-100 35 (4) 2-10 vdc 24 vac/dc 4.2 2-10 vdc No 85
MS4D-6043-130 35 (4) 6-9 vdc 24 vac/dc 4.2 6-9 vdc No 85
MS4D-6043-150 35 (4) 0-10 vdc 24 vac/dc 4.2 0-10 vdc No 85
MS4D-6043-160 35 (4) 4-20 ma 24 vac/dc 4.2 2-10 vdc No 85
MS4D-6083-100 70 (8) 2-10 vdc 24 vac/dc 5.2 2-10 vdc No 85
MS4D-6083-130 70 (8) 6-9 vdc 24 vac/dc 5.2 6-9 vdc No 85
MS4D-6083-150 70 (8) 0-10 vdc 24 vac/dc 5.2 0-10 vdc No 85
MS4D-6083-160 70 (8) 4-20 ma 24 vac/dc 5.2 2-10 vdc No 85
Actuator Inputs Outputs Approximate Timing in sec. @ 70°F
Control Voltage VA @ 60Hz Feedback Auxiliary Switch Spring Return
Schneider Electric
F-27272- 4 November 2014
Page 9
Non Spring Return Damper Actuators
Mx41-60x3 Series 44 lb-in and 88 lb-in Direct Coupled
Designed for controlling air dampers in building systems with floating or proportional control.
Features
• Compact Design
• NEMA 2 and Plenum rated
• Automatically adjust input span to match damper travel
• 3’ plenum cable
• Overload protected throughout stroke
• 95° nominal rotation
• Manual override
• Auxiliary Switches Optional
• Adjustable zero and span model available
• UL-873, cUL C22-2, CE
• Operating Temperature –25 to 130°F ( –32 to 55°C)
• Humidity 15 to 95% non-condensing
High Performance HVAC Applications
Part Number Torque
lb-in (NM)
MF41-6043 44 (5) Floating 24 vac 2.3 — — 90
MF41-6083 88 (10) Floating 24 vac 2.3 — — 125
MF41-6083-510 88 (10) Floating 24 vac 2.3 1000 ohm — 125
MF41-6083-502 88 (10) Floating 24 vac 2.3 — 2-SPDT 125
MS41-6043 44 (5) 0-10 vdc 24 vac 3.3 0-10 vdc — 90
MS41-6083 88 (10) 0-10 vdc 24 vac 3.3 0-10 vdc — 125
MS41-6083-520 88 (10) 0-10 vdc* 24 vac 3.3 0-10 vdc — 125
MS41-6083-502 88 (10) 0-10 vdc 24 vac 3.3 0-10 vdc 2-SPDT 125
* Adjustable
Actuator Inputs Outputs Approximate Timing in sec. @ 70°F
Control Voltage VA @ 60Hz Feedback Auxiliary Switch Spring Return
9
Schneider Electric
F-27272- 4 November 2014
Page 10
10
Non Spring Return Damper Actuators
Mx41-6153 Series 133 lb-in Direct Coupled
Designed for controlling air dampers in building systems with floating or proportional control.
Features
• NEMA 1
• Span adjust Function Switch
• 0-10 vdc (factory set), 2-10 input switch or floating control
• 3’ plenum cable
• Overload protected throughout stroke
• Tandem mounting
• 95° nominal rotation
• Manual override
• ½” conduit connection
• Auxiliary Switches Optional
• UL-873, cUL C22-2, CE
• Operating Temperature –25 to 130°F ( –32 to 55°C)
• Humidity 15 to 95% non-condensing
High Performance HVAC Applications
Part Number Torque
lb-in (NM)
MF41-6153 133 (15) Floating 24 vac 3 — — 125
MS41-6153 133 (15) 0-10 vdc 24 vac 5 0-10 vdc — 125
MS41-6153-502 133 (15) 0-10 vdc 24 vac 5 0-10 vdc 2-SPDT 125
Actuator Inputs Outputs Approximate Timing in sec. @ 70°F
Control Voltage VA @ 60Hz Feedback Auxiliary Switch Spring Return
Schneider Electric
F-27272- 4 November 2014
Page 11
Non Spring Return Damper Actuators
Mx41-634x Series 300 lb-in Direct Coupled
Designed for controlling air dampers in building systems with floating or proportional control.
Features
• Premier oil immersed gear train construction
• NEMA 4 capable
• ½” conduit connections
• 3’ plenum cable (24V models), 3’ appliance wires for 120/230 vac models
• Overload protected throughout stroke
• 93° nominal rotation
• Manual override
• Tandem Mounting
• UL-873, cUL C22-2, CE, C-Tick
• Operating Temperature –25 to 140°F ( –32 to 60°C)
• Humidity 15 to 95% non-condensing
Damp & Harsh Environment Applications
Part Number Torque
lb-in (NM)
MF41-6343 300 (34) Floating 24 vac/dc 5.7 — No 162
MS41-6343 300 (34) 2-10 vdc 24 vac/dc 5.6 2-10 vdc No 148
MS41-6340 300 (34) 2-10 vdc 120 vac 7.5 2-10 vdc No 148
MS41-6341 300 (34) 2-10 vdc 240 vac 9.0 2-10 vdc No 148
Actuator Inputs Outputs Approximate Timing in sec. @ 70°F
Control Voltage VA @ 60Hz Feedback Auxiliary Switch Spring Return
11
Schneider Electric
F-27272- 4 November 2014
Page 12
12
Damper Actuators
Accessories Chart
Spring Return Actuators Non Spring Return Actuators
Part
Number
AM-620 Actuator
AM-621 Round Shaft
AM-671
AM-673
AM-674
AM-675 X X X X X X
Description
Remote Mount
Extension
abc
Mounting
abc
Bracket
b
Weather
Shield & Base
MF40-7043
MA40-7043
MF41-7073
MS40-7043
MA41-7073
MF41-7153
MA41-7153
MS41-7073
MF40-7173
MS41-7153
MA40-717x
MS40-7173
MS4D-x033
MF41-6043
MS41-6043
MF41-6083
MS41-6083
MF41-6153
MS41-6153
MF41-6343
X X X X X X F-27484
X X X X X X F-27481
X X X X X X
X X X X X X
X X X X X X
X X X X X X X X X X
AM-676 Shaft Extension X X X X X X X X X X
AM-686 Position
Indicator
d
AM-687
V-clamp X X X X
AM-688 Relacement
Universal Clamp
X X X X
X X X X
AM-689 Rotation Limiter X X X X
AM-690
AM-691 X X X X
AM-692
AM-693
Crank Arm
e
V-bolt X X X X
fg
Crank Arm Kit X X X X
a AM-693 crank arm kit required.
b Drill appropriate mounting holes where needed.
c The large “C”-shaped clamps included in AM-693 crank arm kit are required
for mounting the actuator. Drill appropriate mounting holes where needed.
d For shafts to 1.05” (26.7 mm) diameter or ⁵⁄⁵” (15.9 mm) square.
X X X X
e For shafts to ¾” and 1.05” (19 to 26.7 mm) diameter
(with AM-690 and AM-691, respectively).
f Use the self-tapping screws and flat washers provided
in kit to mount actuator.
g AM-692 V-bolt kit required.
General
Instructions
Document
MS41-6343
MS4D-60x3-1xx
F-25096AM-672
F-25097
F-25098
Schneider Electric
F-27272- 4 November 2014
Page 13
Damper Actuators
13
Accessories Chart
Spring Return Actuators Non Spring Return Actuators
Part
Number
Description
MF40-7043
MA40-7043
MF41-7073
MS40-7043
MA41-7073
MF41-7153
MA41-7153
MS41-7073
MF40-7173
MS41-7153
MA40-717x
MS40-7173
MS4D-x033
MF41-6043
MS41-6043
MF41-6083
MS41-6083
MF41-6153
MS41-6153
MF41-6343
General
Instructions
Document
MS41-6343
MS4D-60x3-1xx
AM-703 Span
Adjustment
AM-704 Modulation
Interface
AM-705
Positioner
X X X X X X X X
F-26895
X X X X X X X X
X X X X X X X X X
F-26895AM-706 X X X X X X X X X
AM-708 500 Ω Resistor X X X X X X X
AM-709 Position Indicator
& Stroke Limiter
a
AM-710
AM-711
AM-712 X X
V-clamp X X
Crank Arm
Adaptor Kit
X X
X X
F-26896
AM-713 Bracket X X X
AM-714 Weather Shield X X X X X X X F-25097
AM-715 Crank Arm
Adaptor Kit
AM-717 Replacement
Universal Clamp
AM-726
Crank Arm
Adaptor
b
AM-728
AM-751
AM-752 X X X X
Conduit Adaptor X X X X
Anti-rotation
Bracket
X X F-26896
X X F-26896
X X X X
F-26802AM-727 X X X X
X X X X
F-26898
a For shafts up to ¾” (19 mm) diameter round up to ½” (13 mm) square.
b Cannot be used when creating a linked valve/actuator assembly.
Schneider Electric
F-27272- 4 November 2014
Page 14
14
Damper Actuators
Accessories Chart
Spring Return Actuators Non Spring Return Actuators
Part
Number
Description
MF40-7043
MA40-7043
MF41-7073
MS40-7043
MA41-7073
MF41-7153
MA41-7153
MS41-7073
MF40-7173
MS41-7153
MA40-717x
MS40-7173
MS4D-x033
MF41-6043
MS41-6043
MF41-6083
MS41-6083
MF41-6153
MS41-6153
MF41-6343
General
Instructions
Document
MS41-6343
MS4D-60x3-1xx
AM-735 Crank Arm Kit X X F-27246
AM-736 Crank Arm Kit
with Bracket
AM-737 Universal Crank
Arm
a
X X F-27247
X X F-27248
AM-470 Replacement Kit X X F-27249
AM-741 Weather Shield X X X X X F-27250
b
AM-753
AM-754
Mounting Clamp
c
AM-755 Manual Override
Crank
AM-756 Metric Conduit
Adaptor
AM-758 Short “U”
Mounting Bracket
AM-759 Tall “U” Mounting
Bracket
AM-760 Slotted “L”
Mounting Bracket
AM-761 7-inch Anti-
rotation Bracket
AM-762 9-inch Anti-
rotation Bracket
AM-763 Manual Override
Crank
TF-711-02
TF-713-02 X X X X
Seallight Conduit
Connector
X X X X X X X X X X X X F-26899
X X X X
X X X X
X X X X
X X F-26986
X X X X X X X X X X F-25098
dXdXdXd
X
X X X X
X X X X
X X
X X X X
F-26898
F-25096
X F-25098
TF-5521 Pipe Plug X X X X
a For Honeywell Floor Mount Mod. Motor.
b For shafts ¾” (19 mm) round and ⁵⁄⁵” (15.9 mm) square.
c For shafts ³⁄⁵” to ½” (10 to 13 mm) round and square.
d Only used on Mx41-707x-xxx, Mx41-715x-xxx.
Schneider Electric
F-27272- 4 November 2014
Page 15
15
Schneider Electric
F-27272- 4 November 2014
Page 16
Schneider Electric
F-27272- 4
© 2014 Schneider Electric. All rights reserved.
November 2014
Loading...
