Schlage Utility Soware

For Android Devices, Ver. 1.0 User’s Guide

Important Information

Customer Service

U.S.A.: 877-671-7011

us.allegion.com

electronic_lock_techprodsupport@allegion.com

Revision

This document has been updated for Schlage Utility Soware for Android (SUS-A) Rev 1.0.

Got to www.schlage.com/support, search “AD ﬁrmware” or “CO ﬁrmware” for latest SUS-A versions.

ii • Schlage • Schlage Utility Soware for Android User's Guide

WarrantyImportant Information

Warranty

SCHLAGE LIMITED PRODUCT WARRANTY

(COMMERCIAL APPLICATIONS ONLY)

Schlage Lock Company, LLC (the “Company”) extends a warranty against defects in material and workmanship to the original user of the products manufactured by the Company (the “Products”) beginning from the date of purchase by the original user. Certain Products contain restrictions to this limited warranty, additional warranties, or different warranty periods. Please see below for speciﬁc Product warranty periods and details.

PRODUCT WARRANTY PERIOD

47282796 SUS-A KIT 1 year

What The Company Will do: Upon return of the defective Product to the Company or its authorized distributor for inspection, free and clear of all liens and encumbrances and accompanied by the statement of defects and proof of purchase, the company will, at its option, repair or replace the Product (with new or remanufactured product (as applicable), or refund the purchase price.

Original User: These warranties only apply to the original end user of the Products (“Original User”). These warranties are not transferable.

What is not Covered: The following costs, expense and damages are not covered by the provisions of these limited warranties: (i) back charges or labor costs including, but not limited to, such costs as the removal and reinstallation of the Product or for normal maintenance; (ii) shipping and freight expenses required to return the Product to Schlage; (iii) failures, defects, or damage (including, but not limited to, any security failure or loss of data) caused by any third party product, service, or system connected or used in conjunction with the Product; (iv) loss of use of control panel or video recorder; (v) any other incidental, consequential, indirect, special and/or punitive damages, whether based on contract, warranty, tort (including, but not limited to, strict liability or negligence), patent infringement, or otherwise, even if advised of the possibility of such damages; or (vi) normal wear and tear.

The provisions of these limited warranties do not apply to Products: (i) used for purposes for which they are not designed or intended by the Company; (ii) which have been subjected to alteration, misuse, abuse, negligence, or accident; (iii) which have been improperly stored, installed, maintained, repaired or operated; (iv) which are not the proper size for the application, have been used in violation of written instructions provided by the Company, or have been installed with improper or incorrect parts; (v) which have been subjected to improper temperature, humidity, or other environmental conditions (i.e., corrosion); or (vi) which, based on the Company’s examination, do not disclose to the Company satisfactory non-conformance to these warranties. Company will not warrant ANSI A156.2 Grade 1 lever Product installed in educational facilities and student housing. Additionally, these warranties do not cover scratches, abrasions, or deterioration due to the use of paints, solvents, or other chemicals.

Additional Terms: The Company does not authorize any person to create for it any obligation or liability in connection with the Products. No other warranties, express or implied, are made to the Original User with respect to the Products including, but not limited to, any implied warranty of merchantability or ﬁtness for a particular purpose. No agent, representative, dealer, or distributor of Company has the authority to increase or alter the obligations under this limited warranty. No action arising out of a claimed breach of this warranty by Company may be brought by the Original User more than one (1) year aer the cause of action has arisen.

Claims Process: If you have a claim under this limited warranty, please contact Company’s Customer Service for repair, replacement or refund of the original purchase price in exchange for the return of the Product to Company. Contact Company’s Customer Service at 1-877-671-7011.

iii • Schlage • Schlage Utility Soware for Android User's Guide

Contents

ii Important Information

ii Customer Service ii Copyright ii Revision iii Warranty

5 Overview

5 Supported Devices 6 SUS-A Functions by Device

7 Getting Started and Daily Operations

7 System Components and Compatibility

Requirements

8 Install/Update Schlage Utility Soware for

Android 8 Logging In 9 Connecting the Mobile Device 10 Transferring Door and Audit Files 11 Updating Firmware 12 Interface Reference

13 SUS-A Settings

13 Connection Examples 13 Audit Retrieval Mode 13 SUS Password 14 Coupling Password 14 Language 14 Import/Export Conﬁguration Feature 14 Diagnostic Data Log Feature

49 CO-Series Locks

49 Couple mobile device to Lock 49 Program a Lock 50 Collect Audits 50 View Properties 51 Edit Properties 51 View Reader Properties 51 Edit Reader Properties 51 Update Firmware 52 Lock Properties

54 Legacy Locks

54 Program a Lock or Controller 54 Supported Legacy Locks 55 Collect Audits and Update a Lock 55 View Properties 56 Edit Properties 56 Update Firmware 57 Demo mode

58 Troubleshooting

58 General Troubleshooting 58 Error Codes 62 Enable File Transfer

63 Glossary

66 Change Lock Class

66 AD-Series Locks

15 AD-Series Locks and Controllers

15 Couple mobile device to Lock 16 Couple mobile device to PIM400 or PIB300 16 Couple mobile device to WRI400/CT5000 17 Program a Lock or Controller 17 Collect Audits and Update Lock 18 Device Information 18 Lock Conﬁguration 18 Reader Conﬁguration 19 Put PIM400 into Link Mode 19 Put PIM400 into Demo/Diagnostic Mode 19 Update Firmware 19 Diagnostic Data Log Feature 20 AD-Series Readers 22 Lock Properties 35 Controller Properties

67 Import/Export Conﬁguration

67 About Import/Export Conﬁguration Feature 67 Supported Locks and Accessories 67 Prerequisites 68 Create an Import/Export Conﬁguration 68 Copy a Saved Import/Export Conﬁguration

69 Diagnostic Data Log

69 About Diagnostic Data Log Feature 69 Prerequisites 69 Diagnostic Data Log Menu

71 Index

iv • Schlage • Schlage Utility Soware for Android User's Guide

Overview

The Schlage Utility Soware for Android is an application that runs on the Android operating system. It is used to conﬁgure, edit and program all supported devices.

Supported Devices

Supported for version 1.0

AD-Series Locks

AD-300

AD-301

AD-302

AD-400

AD-401

AD-402

Legacy Locks

BE367

FE210

Support planned for future versions

AD-Series Locks

AD-200

AD-201

AD-250

CO-Series Locks

CO-200

CO-220

CO-250

Legacy Locks

KC2-5100

KC2-5500

KC2-9000

CM5100

CM5500

CM5200

CM5600

CM5700

CM993

CL5100

CL5500

CL5200

CL5600

CL993

AD-Series Accessories and Legacy Controllers

PIM400

WPR400

PIB300

AD-Series Readers

AD-Series Accessories and Legacy Controllers

CT5000 Controller

CT500 Controller

CT1000 Controller

WRI400

5 • Schlage • Schlage Utility Soware for Android User's Guide

SUS-A Functions by Device

SUS-A Functions by DeviceOverview

AD-Series Devices

AD-2002AD-250

1 2

AD-3002AD-400

CT5000

PIB300

PIM400

WPR400

WRI400

Collect Audits • • •

Edit Lock Properties • • • • • • •

Edit PIB300 properties •

Edit PIM400 properties •

Edit Door Properties • • • •

Update Firmware • • • • • • • • •

Couple mobile device to Device • • • • • • • • •

Set Date/Time • • • • • •

Demo mode •

Change Lock Class • • • •

1. AD-Series wireless device properties may also be viewed or edited through the PIM400.

2. These devices work with the FIPS201 standard. AD-200 will become AD-201, AD-300 will become AD-301, and AD400 will become AD-401 when a FMK reader is attached. If the FMK reader is attached to the WPR400, it will become WPR401.

CO-Series Devices

CO-200

CO-220

CO-250

Collect Audits • • •

Edit Lock Properties • • •

Update Firmware • • •

Couple mobile device to Device • • •

Set Date/Time • • •

Legacy Devices

KC2

BE367

FE210

CT500/1000

CL Controller

Legacy PIM

WA1WPR21WSM1WRI

Collect Audits • • • • • • •

Edit Lock Properties • • • • • • •

Update Firmware Update • • • • • • • •

Edit Legacy PIM properties •

Edit WAPM Properties • • • • •

Demo mode •

1. Legacy wireless access point devices cannot be conﬁgured directly. They are conﬁgured through the legacy PIM.

6 • Schlage • Schlage Utility Soware for Android User's Guide

Getting Started and Daily Operations

System Components and Compatibility Requirements

The Schlage Utility Soware for Android (SUS-A) is a soware application that runs on Android OS, version 9 or higher, with a type C connection. It is used to transfer data ﬁles between the access control soware and locks and controllers.

USB Connector

2-PIN Connector

C-Connector

System Components

ID Description

SUS-A Cable Cable used to connect an Android device to AD- and CO-Series products. The legacy

products BE367 and FE210 are also supported.

Mobile Device The Android OS device, version 9 or higher with a type C connection, upon which the

SUS-A application has been installed.

CAUTION

• Do not hang the mobile device or the lock from the cable connection.

• Carefully plug and unplug the mobile device and USB/2-PIN device connectors to prevent damage.

• Do not expose the cable to high heat (like the dash board of your work truck).

7 • Schlage • Schlage Utility Soware for Android User's Guide

Install/Update Schlage Utility Soware for AndroidGetting Started and Daily Operations

Install/Update Schlage Utility Soware for Android

Download Schlage Utility Soware for Android from the Google Play Store.

Logging In

Logging in for the ﬁrst time

Once the application is downloaded, you must change default password.

1 Select User Type: Manager or Operator.

1 Enter Default Password: 123456

2 You will be prompted to enter a new password and conﬁrm the new password.

Î New password must not be a default password, subset or super set of default password.

3 You must log in again with User Type: Manager or Operator and new password.

You can log in to the Schlage Utility Soware for Android (SUS-A) as either a Manager or an Operator. The Manager role has access to all commands. The Operator role has access only to limited commands.

Manager Operator

Lock Properties • •

Program Lock • •

Firmware Update •

Change Lock Class •

Couple mobile device to Device •

Set Date/Time •

Diagnostic Data Log • •

Door Properties • •

PIM properties • •

Demo Mode •

SUS Password • •

Coupling Password •

Language • •

Auto/Manual Update • •

List All/Pending Doors • •

8 • Schlage • Schlage Utility Soware for Android User's Guide

Connecting the Mobile DeviceGetting Started and Daily Operations

Connecting the Mobile Device

Î The mobile device must have ﬁle transfer via USB enabled to function properly. See Enable File

Transfer on page 62 for more information.

The Schlage button will ﬂash green while the lock is waiting to communicate with the mobile device. The Schlage button will begin to ﬂash red when communication between the lock the mobile device is established.

When communication is established, the device name will be displayed on the SUS-A main screen.

AD-Series and CO-Series Locks

1 Start the Schlage Utility Soware for Android (SUS-A).

2 Connect the SUS-A Cable to the mobile device. A

pop-up will appear, “Allow Schlage Utility Software to

access SUS A-CABLE?” Click OK to continue.

3 Plug the SUS-A Cable into the lock’s USB port located

in the bottom of the exterior housing.

4 Press the Schlage button twice to begin

communication.

AD-Series Controllers

1 Start the Schlage Utility Soware for Android (SUS-A).

2 Connect the SUS-A Cable to the mobile device. A pop-

up will appear, “Allow Schlage Utility Software to access

SUS A-CABLE?” Click OK to continue.

3 Plug the SUS-A Cable into the controllers’s USB port.

Communication will begin automatically.

USB Connection

Legacy CM and CL Locks

1 Start the Schlage Utility Soware for Android (SUS-A).

2 Connect the SUS-A Cable to the mobile device. A pop-

up will appear, “Allow Schlage Utility Software to access

SUS A-CABLE?” Click OK to continue.

3 Plug the SUS-A Cable into the lock’s 2-Pin connector.

4 Press the Schlage button twice to begin

communication.

When you present the red programming fob, if the Schlage button lights red and then green one time, the cam is in the wrong position. See

alle.co/BE367IS.

Legacy BE367 and FE210

Allow Access to SUS-A Cable

1 Start the Schlage Utility Soware for Android (SUS-A).

2 The deadbolt must be retracted if this is the ﬁrst time

programming the lock.

3 Connect the SUS-A Cable to the mobile device. A pop-

up will appear, “Allow Schlage Utility Software to access

SUS A-CABLE?” Click OK to continue.

4 Present the Red programming iButton to the lock.

5 Plug the SUS-A Cable into the lock’s 2-Pin connector.

Î If the lock does not connect and begin

communication, the lock may have timed out. Present the red programming button again.

2-PIN Connections

9 • Schlage • Schlage Utility Soware for Android User's Guide

Transferring Door and Audit FilesGetting Started and Daily Operations

Before attempting to transfer ﬁles, Schlage Express must be set up and running on a PC.

The xx in the extension of a door ﬁle or audit ﬁle is the number of the door that represents the order in which the door was originally entered into Schlage Express.

Transferring Door and Audit Files

Schlage Express is used in conjunction with SUS-A. It is the application for PC that is used to set up users and access for a site, and then create door ﬁles for programming. Audit ﬁles are collected from the locks and devices using SUS-A or another legacy device, prior to SUS-A.

Types of Files

File type Extension Purpose

Door ﬁles .dxx Transfers user and access information from Schlage Express to a lock or

device via SUS-A.

capindex .ndx Transfers the door names to the locks so they can be displayed for easy

reference during programming.

Audit ﬁles .axx Transfers door audits to Schlage Express from a lock or device via

SUS-A. The numbers in the extension correspond to the door ﬁle with the same numbers. Only doors that were programmed will return an audit ﬁle.

uplink .log Tells Schlage Express which doors have been successfully updated.

Device Template .dte Used to save device settings from one device and then copy them to

another device of the same type. Ensures each device has the same settings applied.

Device Data Log .ddl AD-Series devices only: Captures the settings and status of the last 50

devices that the SUS has connected with. Used to check status and settings while oine and not connected with the device..

n/a .kxx These are system ﬁles that do not need to be transferred during

updates; they can be ignored.

The mobile device must have ﬁle transfer via USB enabled to function properly. See

Enable File Transfer

on page 62 for more information.

* The SUS-A cable cannot be used to transfer ﬁles between the PC and the mobile device. A high-quality data transfer cable should be used.

To ﬁnd the export folder on PC, go to Settings >

Program Settings > Programming Tab. The

option that is checked will show where the ﬁles generate.

Transfer Files from the PC to the Mobile Device for Programming

1 Navigate to the Export folder (usually

C:\SchlageExpress\Export) on the PC. Copy the

door les (*.dxx) and capindex.ndx ﬁle.

2 Connect the mobile device to the computer’s

USB port using a data transfer cable*.

3 Once the mobile device drive appears on the PC,

locate the folder named Schlage Utility Software.

4 Paste the copied ﬁles to the folder on your

mobile device.

Transfer Files from the Mobile Device to the PC aer Programming

1 Connect the mobile device to the PC’s USB port

Programming Files on PC

using a data transfer cable*.

2 Once the mobile device drive appears on the

PC, navigate to the folder named Schlage Utility

Software.

3 Copy the audit les (*.axx), uplink.log and

capindex.ndx from Schlage Utility Software.

Î There should be one audit ﬁle for each door

that was programmed.

4 Navigate to the Export folder (usually

C:\SchlageExpress\Export) on the PC. Paste the

copied ﬁles into the folder.

10 • Schlage • Schlage Utility Soware for Android User's Guide

Programming Files on Mobile Device

Updating FirmwareGetting Started and Daily Operations

Transferring Device Template Export (.DTE) and Device Data log(.DDL) Files to PC

1 Connect the mobile device to computer’s USB port using a data transfer cable*.

2 Once the mobile device drive appears on the PC, locate the folder named Schlage Utility Software.

3 Copy DTE/DDL ﬁles and paste it to a desired folder on the PC.

Updating Firmware

Firmware ﬁles can be downloaded and transferring to SUS-A using a PC, or by downloading them directly to the SUS-A

Download Firmware Files to SUS-A Using PC

Î Choose this process or Download Firmware Files Directly to SUS-A. You do not need to do both.

1 Navigate to www.schlage.com/support.

2 Search for AD rmware.

3 Click on the latest ﬁrmware package in the list. The ﬁle will download to your PC. Note the

location.

4 Extract the .zip ﬁle and note the location.

5 Connect the mobile device to computer’s USB port using a data transfer cable*. Once the mobile

device drive appears on PC, locate the folder named Schlage Utility Software.

6 Locate the extracted ﬁle (AD.A.xxx.ffp) and move it to the mobile device folder called Schlage

Utility Software.

Download Firmware Files Directly to SUS-A

Î Choose this process or Download Firmware Files to SUS-A Using PC. You do not need to do

both.

1 Navigate to www.schlage.com/support.

2 Search for AD rmware.

3 Click on the latest ﬁrmware package in the list. The ﬁle will download to the mobile device.

4 Extract the .zip ﬁle and note the location.

5 Locate the extracted ﬁle (AD.A.xxx.ffp) and move it to the mobile device folder called Schlage

Utility Software.

11 • Schlage • Schlage Utility Soware for Android User's Guide

Interface Reference

Interface ReferenceGetting Started and Daily Operations

Main menu

Save

Action menu

Back

Forward

Lock

Show

Hide

Success

Failure

Warning

No ﬁles

Sort

Export

Import

Grant access

No matches found

12 • Schlage • Schlage Utility Soware for Android User's Guide

SUS-A Settings

Connection Examples

2-pin Connection

USB Connection

Audit Retrieval Mode

When Auto Update is selected, the SUS will automatically set the date and time in the lock to which it is connected, retrieve the audit and program the lock. When Manual Update is selected, the functions must be independently performed by the user.

Î Manual Update is recommended when managing Legacy Locks.

1 Select .

2 Select Settings.

3 Use the toggle button next to Audit Retrieval Mode to choose Auto or Manual.

SUS Password

You must be logged in to a role to change the password for that role.

1 Select .

2 Select Settings.

3 Select SUS Password.

4 Enter the old password into the Old Password box.

5 Enter the new password into the New Password box.

Î The new password must be between four (4) and eight (8) characters long and can include

capital and lowercase characters, numbers, and symbols. It must not be a default password, subset or super set of default password at any point of time

6 Enter the new password again into the Conrm New Password box.

7 Select the Update button.

13 • Schlage • Schlage Utility Soware for Android User's Guide

Coupling PasswordSUS-A Settings

This function is available only when logged into the mobile device as a manager.

The default Coupling Password is 123456.

Coupling Password

1 Select .

2 Select Settings.

3 Select Coupling Password.

4 Enter the old password into the Old Password box.

5 Enter the new password into the New Password box.

Î The new password must be between four (4) and eight (8) characters long and can include

capital and lowercase characters, numbers, and symbols. It must not be a default password, subset or super set of default password at any point of time

6 Enter the new password again into the Conrm New Password box.

7 Select Update.

Language

1 Select .

2 Select Language.

3 Select the desired language.

Import/Export Conﬁguration Feature

The Import/Export Conﬁguration feature facilitates creation, modiﬁcation and duplication of Device Properties settings across multiple devices. In addition, the Import/Export Conﬁguration will also report additional device status parameters for a complete summary of the device’s health.

Locating the Import/Export Conﬁguration Feature:

1 Select Device Options.

2 Select Lock Properties for the connected device.

3 Select the Edit or Reader tab

4 The Import/Export Conﬁguration is at the bottom of the screen

Î For details on the Import/Export Conﬁguration feature, see Import/Export Conﬁguration on

page 67.

Diagnostic Data Log Feature

This new feature provides a simple method for AD-Series customers to quickly gather and save important lock-status information in a ﬁle.

Î For details see Diagnostic Data Log on page 69.

14 • Schlage • Schlage Utility Soware for Android User's Guide

AD-Series Locks and Controllers

This function works with AD-Series devices only.

The mobile device will use a default Coupling Password (123456) when coupling with a device. The Coupling Password should be changed to provide increased security for your locks. See

Coupling Password

on page 14 for more information.

If a device is not in Coupling mode, SUS-A will display a device speciﬁc message with instructions for placing the device into Coupling mode.

Supported Locks

All chassis for the following models are supported.

AD-Series Oine

AD-200

AD-250

Supported Controllers

PIM400 (Panel Interface Module) WRI400 (Wireless Reader Interface) WPR400 (Wireless Portable Reader) PIB300 (Panel Interface Board) CT5000 Controller

AD-201

AD-Series Networked

AD-300

AD-301

AD-302

AD-400

AD-401

AD-402

Couple mobile device to Lock

AD-Series locks can be coupled, or authenticated, with the mobile device. This provides enhanced security by ensuring that the lock will only communicate with mobile device(s) to which it has been coupled. Once the lock has been coupled, the Coupling Password is passed to the device from the mobile device during programming.

Î mobile devices with the same coupling password can program the same devices. Once the mobile

device and lock are coupled, the coupling password is disabled in the lock and any mobile device with the correct coupling password will automatically couple with the lock.

1 Connect the mobile device to the lock using the SUS-A cable.

2 Press the Schlage button twice. The lock will be displayed on the screen.

3 On the mobile device, select Device Options.

4 Remove the top inside lock cover.

5 Press and hold the Inside Push button. Then press and release the tamper switch three times.

6 Release the Inside Push button. On the lock, the Inside Push button LED will illuminate.

7 On the mobile device, select Couple mobile device to Device.

8 When Coupling is successful, a message will be displayed on the screen.

15 • Schlage • Schlage Utility Soware for Android User's Guide

Couple mobile device to PIM400 or PIB300AD-Series Locks and Controllers

This function works with AD-Series devices only.

The mobile device will use a default Coupling Password (123456) when coupling with a device. The Coupling Password should be changed to provide increased security for your locks. See

Coupling Password

on page 14 for more information.

If a device is not in Coupling mode, SUS-A will display a device speciﬁc message with instructions for placing the device into Coupling mode.

This function works with AD-Series devices only.

The mobile device will use a default Coupling Password (123456) when coupling with a device. The Coupling Password should be changed to provide increased security for your locks. See

Coupling Password

on page 14 for more information.

If a device is not in Coupling mode, SUS-A will display a device speciﬁc message with instructions for placing the device into Coupling mode.

Couple mobile device to PIM400 or PIB300

AD-Series devices can be coupled, or authenticated, with the mobile device. This provides enhanced security by ensuring that the device will only communicate with mobile device(s) to which it has been coupled. Once the device has been coupled, the coupling password is passed to the device from the mobile device during programming.

Î mobile devices with the same coupling password can

program the same devices. Once the mobile device and the device are coupled, the coupling password is disabled in the PIM400 or PIB300 and any mobile device with the correct coupling password will automatically couple with the PIM400 (or PIB300).

1 Remove the PIM400 or PIB300 cover.

2 Connect the mobile device to the PIM400 or PIB300

Link 1 Button Link 2 Button

using the SUS-A cable. The PIM400 or PIB300 will be displayed on the mobile device screen.

3 On the mobile device, select Device Options.

4 On the PIM400 or PIB300, press and hold the LINK 1

button. Then press the LINK 2 button three times.

5 On the mobile device, select Couple mobile device to

Device.

6 When Coupling is successful, a message will be displayed on the mobile device screen.

Couple mobile device to WRI400/CT5000

The WRI400/CT5000 can be coupled, or authenticated, with the mobile device. This provides enhanced security by ensuring that the device will only communicate with mobile device(s) to which it has been coupled. Once the device has been coupled, the programming password is passed to the device from the mobile device during programming.

Î mobile devices with the same programming password can program the same devices. Once the

mobile device and the device are coupled, the coupling password is disabled in the WRI400/ CT5000 and any mobile device with the correct coupling password will automatically couple with the WRI400/CT5000.

1 Remove the device cover.

2 Connect the mobile device to the device using the SUS-A

cable. The name of the device will be displayed on the mobile device screen.

3 On the mobile device, select Device Options.

4 On the WRI400/CT5000, press and hold the Schlage

button. Then press the LINK button three times within ﬁve (5) seconds. Then release both buttons.

5 On the mobile device, select Couple mobile device to

Device.

6 When Coupling is successful, a message will be displayed on the mobile device screen.

Link Button Schlage Button

16 • Schlage • Schlage Utility Soware for Android User's Guide

Program a Lock or ControllerAD-Series Locks and Controllers

Program a Lock or Controller

Oine Locks

1 Connect the mobile device to the lock or controller and establish communication between the

mobile device and the device.

2 Select Device Options.

3 Select Program Lock.

4 Select the door ﬁle that should be associated with the lock or controller.

Î Door ﬁles are downloaded to the mobile device when synchronized with the access control

soware.

5 Select OK.

Online Locks

Î NOTE: This function is not applicable to online locks.

Collect Audits and Update Lock

Collecting audits on the mobile device does not delete the audits from a lock.

Collected audits will be transferred from mobile device to your Access Control Soware the next time they are synchronized.

When Auto Update is enabled, as soon as the Schlage button is pressed twice and the communication with the Schlage Utility Soware starts, the lock will automatically:

• update lock’s date/time

• collect audits

• update access rights

When Manual Update is enabled, follow the steps below to collect audits and update the lock access rights.

Î See Audit Retrieval Mode on page 13 for more information.

Collect Audits when Date/Time and Lock Access Rights are Up-to-Date

1 Conﬁrm mobile device is connected to lock.

Î See Connecting the Mobile Device on page 9 for more information.

2 Double-click the displayed name of the connected lock.

3 The audit collection will begin.

Î If no previous audit exists, skip to step 7.

4 If a previous audit exists, a message will appear asking to overwrite previous audit. Click YES to

override audits and skip to step 7.

5 Click NO if you do not want to override the audit.

6 Acknowledge the message advising to synchronize the lock with system soware. Audit collection

will be stopped.

7 A progress indicator will be displayed while the audit is being collected. A message will be

displayed once the process is complete.

17 • Schlage • Schlage Utility Soware for Android User's Guide

Device InformationAD-Series Locks and Controllers

Collect Audits when Date/Time and Lock Access Rights are Not Up-to-Date

1 Conﬁrm mobile device is connected to lock.

Î See Connecting the Mobile Device on page 9 for more information.

2 Double-click the displayed name of the connected lock.

3 When asked to update date and time of the device, click YES. A progress indicator will be

displayed while date and time is being updated.

4 A message will appear to conﬁrm the successful update.

5 The audit collection will begin. A progress indicator will be displayed while the audit is being

collected.

6 The access rights update will begin. A progress indicator will be displayed while lock is being

updated.

7 A message will be displayed once the process is complete.

Device Information

1 Connect the mobile device to the lock or controller.

2 Select Device Settings.

3 Select Device Information for the connected device.

4 The View tab will be displayed.

Î See Lock Properties on page 22 for more information.

Lock Conﬁguration

1 Connect the mobile device to the device.

2 Select Device Settings.

3 Select Device Conguration for the connected device.

4 Select the Lock tab.

5 Edit the properties as desired.

Î See Lock Properties on page 22 for more information.

6 Select Save to update and save the changes.

Reader Conﬁguration

1 Connect the mobile device to the device.

2 Select Device Settings.

3 Select Device Conguration for the connected device.

4 Select the Reder tab.

5 Edit the properties as desired.

Î See Lock Properties on page 22 for more information.

6 Select Save to update and save the changes.

18 • Schlage • Schlage Utility Soware for Android User's Guide

Put PIM400 into Link ModeAD-Series Locks and Controllers

Put PIM400 into Link Mode

1 Connect the mobile device to the PIM400.

2 Select Device Options.

3 Select PIM Properties for the connected device.

4 Select the Link tab.

5 Select the door number from the drop-down box.

Î See the system administrator for the proper door number selection.

6 The PIM400 will stay in link mode for up to 30 minutes.

7 Put the lock (door) into link mode.

Î See the user guide that came with the lock for more information.

8 The PIM400 will automatically exit link mode once linking is complete.

Put PIM400 into Demo/Diagnostic Mode

1 Connect the mobile device to the PIM400 and select Device Options.

2 Select Demo mode and then select the door number from the drop-down box.

• Card Data box: shows card data from credential when card presented to reader.

• Unlock on Read: if enabled allows the door to be unlocked upon the reading of a card: the OEM has the ability to disable this feature (grayed out).

Update Firmware

Î See Updating Firmware on page 11 for more information.

Diagnostic Data Log Feature

This new feature provides a simple method for AD-Series customers to quickly gather and save important lock-status information in a ﬁle. See Diagnostic Data Log on page 69 for more information.

19 • Schlage • Schlage Utility Soware for Android User's Guide

AD-Series ReadersAD-Series Locks and Controllers

AD-Series Readers

Î Note: (Multi-Tech, Multi-Tech + Keypad) and (iClass + Multi-Tech, iClass + Multi-Tech + Keypad)

and (FIPS + Multi-Tech +Keypad) and (Keypad) readers are being discontinued (1st half 2016) and replaced by the (Multi-Tech 2, Multi-Tech + Keypad 2) and (FIPS + Multi-Tech +Keypad 2) and (Keypad 2) readers that provide all the same functionality as the original readers

The Multi-Tech and Multi-Tech + Keypad readers will read both proximity and smart cards. The Proximity, Proximity + Keypad ONLY and Smart Card, Smart Card + Keypad ONLY readers have been discontinued and replaced by the MultiTech, Multi-Tech + Keypad readers that provide all the same functionality as the original Proximity and Smart card readers in a single credential reader.

The MiK and SiK2 readers are both a solution for applications using the HID iClass smart card credential.

iCLASS® is a proprietary smart card technology developed by HID that operates on ISO 15693. In order to support these requirements, iClass + Multi-Tech + Keypad reader were integrated to create the (MiK) and (SiK2). (SiK2) is not capable of reading Proximity credentials.

The FMK reader module is for applications which require approval by the U.S. Federal Government under HSPD-12 for FIPS 201 compliance. In order to meet these requirements, FIPS + Multi-Technology + Keypad reader were integrated to create the (FMK).

Multi-Tech Multi-Tech + Keypad

iClass + Multi-Tech iClass + Multi-Tech + Keypad

FIPS + Multi-Tech + Keypad

20 • Schlage • Schlage Utility Soware for Android User's Guide

AD-Series ReadersAD-Series Locks and Controllers

MagInsert MagInsert +

Keypad

Reader Types

Reader Description Reader Type Shown in SUS-A

Mag Insert with Keypad MagInsert + Keypad

Mag Insert without Keypad MagInsert

Mag Swipe with Keypad MagSwipe + Keypad

Mag Swipe without Keypad MagSwipe

Keypad Only Keypad

Prox with Keypad Proximity + Keypad

Prox without Keypad Proximity

Smart with Keypad Smart Card + Keypad

Smart without Keypad Smart Card

FMK Reader FIPS + Multi-Tech + Keypad

MT Multi-Tech

MTK Multi-Tech + Keypad

Mi iClass + Multi-Tech

MiK iClass + Multi-Tech + Keypad

MT2 Multi-Tech 2

MTK2 Multi-Tech 2 + Keypad

FMK2 FIPS + Multi-Tech 2 + Keypad

KP2 Keypad 2

Si2 iClass + Smart Only 2

SiK2 iClass + Smart Only 2 + Keypad

MagSwipe MagSwipe +

Keypad

21 • Schlage • Schlage Utility Soware for Android User's Guide

Lock PropertiesAD-Series Locks and Controllers

Lock Properties

• AD-200/250 (Oine Locks): pg 22

• AD-300/AD301/AD-302 (Networked Locks): pg 26

• AD-400/AD-401/AD-402 (Networked Locks): pg 30

AD-200/250 (Oine Locks)

Property Description

Lock Name The name of the Lock. Set by the door ﬁle programmed into the lock.

Date & Time Current date and time. Initialized/set by the mobile device.

General Properties

Model Model number of the device connected to the mobile device.

Max Users Number of Users supported by the lock (AD-200).

Max Void List Number of void users supported by the lock (AD-250).

Power Status Current voltage level of the AA and Coin Cell batteries. Number of AA batteries connected to the lock.

Max One Time User Number of one time use PIN codes supported by the lock (AD-250).

Main Lock

Serial Number Serial number that uniquely identiﬁes the lock.

Manufacture Date Date the lock was manufactured.

Days Since Installed Used for warranty purposes; it marks the beginning of the lock’s functional life.

Firmware Version Version of the current ﬁrmware ﬁle. Automatically updated when a new ﬁrmware version is loaded.

Hardware Version Current version of the printed circuit main board.

Bootloader Version Version of the current bootloader. Allows new ﬁrmware to be loaded.

Credential Reader

VIEW Tab

Serial Number Serial number that uniquely identiﬁes the reader.

Manufacture Date Date the reader was manufactured.

Firmware Version Version of the current ﬁrmware ﬁle. Automatically updated when a new ﬁrmware version is loaded.

Card Detection Firmware Version

Hardware Version Current version of the printed circuit credential board.

Bootloader Version Version of the current bootloader. Allows new ﬁrmware to be loaded.

Reader Type Type of Reader installed:

Custom Key If the reader supports reporting the status of custom conﬁguration then SUS-A displays “Custom Key:

Applicable only for MTK2, FMK2 and SIK2. Current ﬁrmware version of the card detection module.

• MagInsert

• MagInsert + Keypad

• MagSwipe

• MagSwipe + Keypad

• Keypad

• Proximity

• Proximity + Keypad

• Smart Card

Installed” or “Custom Key: Not Installed”

• Smart Card + Keypad

• Multi-Tech

• Multi-Tech + Keypad

• FIPS + Multi-Tech + Keypad

• iClass + Multi-Tech

• iClass + Multi-Tech + Keypad

• Multi-Tech 2

• Multi-Tech 2 + Keypad

• FIPS + Multi-Tech 2 + Keypad

• Keypad 2

• iClass + Smart Only 2

• iClass + Smart Only 2 + Keypad

22 • Schlage • Schlage Utility Soware for Android User's Guide

AD-200/250 (Oine Locks)

Property Description Default

Lock Type Classroom: Unlocks when a credential is presented and then automatically locks

aer the relock delay has expired. Oce: Unlocks when a credential is presented and then automatically locks aer the

relock delay has expired. To keep the door unlocked, push the button on the inside. The button will momentarily illuminate green. To return the lock to the locked state, push the button again or present a credential to the outside.

Privacy: To initiate the Privacy function, with the door closed, push the button on the inside of the door. This prevents normal credentials from opening the door from the outside.

• The lock will go back to its normal state when the button is pushed again or when the door position switch indicates that the door has opened.

• When using a Mortise Deadbolt, extending the deadbolt from the inside lights a red LED on the inside trim and initiates the Privacy function which prevents normal credentials from opening the door from the outside. The lock can always be opened using a Pass-Through credential or mechanical key in case of emergency.

Apartment: The apartment function lock is normally locked and never relocks automatically, which prevents users from being locked out.

• To unlock the door from the outside, present a credential.

• To unlock the door from the inside, push the inside button or, if using the MD chassis, retract the deadbolt. Egress always available from inside.

• When lever is rotated and door is opened, the request-to-exit switch is used in conjunction with the door position switch to cause the door to return to unlocked condition.

• To lock the door from the outside, present a credential.

• To lock the door from the inside, push the inside button or, for MD chassis, extend the deadbolt.

EDIT Tab

PIN Length

Maximum number of digits in the user PIN. Range of 3 to 6 digits. 6

(AD-200 only)

Allow Privacy Mode Override (AD-250 only)

When enabled, allows cards to override a lock that has been placed in privacy mode. When disabled, only cards speciﬁcally assigned to this door will have access.

Ignore Keypad If checked, key entry codes are ignored. Disabled

Record Lock/Unlock If checked and supported by the system soware, will record an audit event when the

Inside Push button is pressed.

IPB Control User can select any one IPB functionality from the options:

Normal Operation: This option is used to disable all other IPB Control conﬁgurations. This is the default option for IPB control conﬁgurations. This conﬁguration is available on AD-200 and AD-250.

Disable Interior LED Status Blinking: This will disable the interior LED’s status blinking. This conﬁguration is available on AD-200 and AD-250.

Blink Interior Button LED when locked: The IPB will ﬂash every 15 seconds for the ﬁrst 10 minutes; it will then ﬂash every 30 seconds for the next 50 minutes; and it will then ﬂash every minute aer 1 hour. If a door actuation occurs, then the process is restarted. This conﬁguration is available on AD-200 and AD-250.

Blink Interior LED Rapidly when in Privacy Mode: Interior LED will ﬂash rapidly while privacy mode is enabled. This conﬁguration is available on AD-200 and AD-250.

Occupancy Indicator Fast Blink: If selected, Occupancy Indicator Fast Blink is enabled on the lock. This conﬁguration is only available on AD-200.

Occupancy Indicator Slow Blink: If selected, Occupancy Indicator Slow Blink is enabled on the lock. This conﬁguration is only available on AD-200.

Oine Lockdown Mode: If selected, Oine Lockdown Mode is enabled on the lock. This conﬁguration is only available on AD-200.

Lock PropertiesAD-Series Locks and Controllers

Set by the Factory

Disabled

Normal Operation

23 • Schlage • Schlage Utility Soware for Android User's Guide

AD-200/250 (Oine Locks)

Battery Fail Mode Lock state set when battery fails. As-Is, Secure/Locked, Unsecure/Unlocked As-Is

Relock Delay Amount of time before the lock relocks aer being unlocked by a user presenting a

valid credential.

ADA Delay Amount of time before the lock relocks aer being unlocked by a user who is ﬂagged

EDIT Tab

as handicapped and presenting a valid credential. Can be changed in the access control system.

Property Description Default

Prox in Use (AD-200 only)

Proximity credential card types allowed. Selections:

• HID/Kantech ioProx*

• GE/CASI

• GE4001

• AWID*

• GE4002*

Mag Track in Use Magnetic card track that access data is to be read from. Track 1, 2 or 3.

Track 1 not conﬁgurable for AD-200.

Enable Low Power Wake-Up

Smart Cards in Use (AD-200 only)

Active when Mag Track 1 or 3 is selected in "Mag Track in Use". By enabling Low Power Wake-Up and recording data on track 2, this option will allow longer battery life.

Smart card(s) to be used with the card reader.

• 14443 UID(CSN) (when selected, disables all other 14443 selections and PIV format)

• 14443 Secure MiFare Plus*

• 14443 EV1 (NOC)*

• 15693 UID (CSN)*

• 14443 Secure MiFare Classic*

MTK1

• iClass credential formats for Reader Types which support Smart Cards

• iClass 40-bit UID (CSN)

• iClass 64-bit UID (CSN)*

• HID iClass Classic* (only appears with Mi/MiK reader attached)

• PIV credential formats for AD200 reader types which support Smart Cards. Range is 1 to 15.

READER Tab

1. 75 Bit PIV*

2. 58 Bit TWIC/CAC

3. 200 Bit FASC–N

4. 64 Bit (BCD) TWIC/CAC

5. 83 Bit TWIC/CAC

6. 66 Bit (58 Bit Format + TSM) TWIC/CAC

7. 64 Bit (58 Bit Format (no parity) + TSM) TWIC/CAC

8. 91 Bit (83 Bit Format + TSM) TWIC/ CAC

9. 40 Bit BCD

10. 40 Bit Reversed BCD

11. 64 Bit BCD

12. 64 Bit Reversed BCD

13. 128 Bit BCD

14. 128 Bit Reversed BCD

15. 58 Bit HSE

Lock PropertiesAD-Series Locks and Controllers

* Default formats

Track 2

Enabled

* Default formats

MTK2

• iClass/Felica credential formats for Reader Types which support Smart Cards

• iClass/Felica 40-bit UID (CSN)

• iClass/Felica 64-bit UID (CSN)*

• HID iClass/iClass SE/iClass SEOS (only appears with Si2/SiK2 reader attached). Enabled by default.

• PIV credential formats for AD200 reader types which support Smart Cards. Range is 1 to 15.

1. 75 Bit PIV*

2. 58 Bit TWIC/CAC

3. 200 Bit FASC–N

4. 64 Bit (BCD) TWIC/CAC

5. 83 Bit TWIC/CAC

6. 66 Bit (58 Bit Format + TSM) TWIC/CAC

7. 64 Bit (58 Bit Format (no parity) + TSM) TWIC/CAC

24 • Schlage • Schlage Utility Soware for Android User's Guide

8. 91 Bit (83 Bit Format + TSM) TWIC/ CAC

9. 40 Bit BCD

10. 40 Bit Reversed BCD

11. 64 Bit BCD

12. 64 Bit Reversed BCD

13. 128 Bit BCD

14. 128 Bit Reversed BCD

15. 58 Bit HSE

AD-200/250 (Oine Locks)

Beeper Indicates if the Beeper is on or off. ON

Apple NFC MTK2, FMK2 and SIK2 only Disabled

TRA Security

Increased Card Read

READER Tab

Attempts

Lock PropertiesAD-Series Locks and Controllers

(unchecked)

25 • Schlage • Schlage Utility Soware for Android User's Guide

AD-300/AD301/AD-302 (Networked Locks)

Property Description

General Properties

Model Model number of the device connected to the mobile device.

Power Status Shows current auxiliary power status of OFF/ON.

FIPS201-2 Capable (AD-302 only)

The Yes or No value for this ﬁeld indicates whether the device (i.e. Lock/Reader combination) is FIPS201-2 Capable or not.

Main Lock

RS485 Partner ID Identiﬁes the participating OEM soware partner.

Serial Number Serial number that uniquely identiﬁes the lock.

Manufacture Date Date the lock was manufactured.

Days Since Installed Used for warranty purposes; it marks the beginning of the lock’s functional life.

Firmware Version Version of the current ﬁrmware ﬁle. Automatically updated when new ﬁrmware ﬁle is loaded.

Hardware Version Current version of the printed circuit main board.

Bootloader Version Version of the current bootloader. Allows new ﬁrmware to be loaded.

Credential Reader

Serial Number Serial number that uniquely identiﬁes the reader.

Manufacture Date Date the reader was manufactured

Firmware Version Version of the current ﬁrmware ﬁle. Automatically updated when new ﬁrmware ﬁle is loaded.

VIEW Tab

Card Detection

Applicable only for MTK2, FMK2 and SIK2. Current ﬁrmware version of the card detection module.

Firmware Version

Hardware Version Current version of the printed circuit main board.

Bootloader Version Version of the current bootloader. Allows new ﬁrmware to be loaded.

Reader Type Type of Reader installed:

• MagInsert

• MagInsert + Keypad

• MagSwipe

• MagSwipe + Keypad

• Keypad

• Proximity

• Proximity + Keypad

• iClass + Multi-Tech + Keypad

• Multi-Tech 2

• Multi-Tech 2 + Keypad

• FIPS + Multi-Tech 2 + Keypad

• Keypad 2

• iClass + Smart Only 2

• iClass + Smart Only 2 + Keypad

• Smart Card

• Smart Card + Keypad

• Multi-Tech

• Multi-Tech + Keypad

• FIPS + Multi-Tech + Keypad

• iClass + Multi-Tech

Lock PropertiesAD-Series Locks and Controllers

Custom Key If the reader supports reporting the status of custom conﬁguration then SUS-A displays “Custom

Key: Installed” or “Custom Key: Not Installed”

26 • Schlage • Schlage Utility Soware for Android User's Guide

AD-300/AD301/AD-302 (Networked Locks)

Property Description Default

RS485 Address Set the RS-485 network address of the lock. 0-255 0

ACP Timeout Time (in seconds) to wait before determining communication from the ACP has

failed.

Comm Loss Fail Mode Lock state set when communication from the ACP fails. As-Is, Secure/Locked,

Unsecure/Unlocked

Power Fail Mode Lock state set when power to the lock fails. As-Is, Secure/Locked, Unsecure/

Unlocked

Degraded (Cache) Mode: Card Bit Format*

Degraded (Cache) Mode: Full Card Number or Facility Code*

Degraded (Cache) Mode: Purge unused

Enter the number of bits on the cards being used to enable degraded mode. abilities. 0= cache mode disabled

Use the full card number or the facility codes of previously approved credentials in the Degraded (Cache) mode. Granting access is determined by “Full Card” content or just “Facility Code”.

When enabled, deletes the cache entry aer 5 days of non-use. If enabled, cards that have not accessed the lock within 5 days will be removed.

aer 5 days*

Degraded (Cache) Mode: Clear Cache*

Deletes all valid user credentials from the Degraded (cache) memory. Allows you to manually clear cache memory.

Max Entries Stored* Number of credential cards or facility codes maintained in the cache. Minimum of

5, Maximum of 1000.

EDIT Tab

Disable Interior Button

If checked, interior button LED blinking is disabled. LED is

LED

Relock Delay Amount of time before the lock relocks aer being unlocked by a user presenting a

valid credential.

Relatch Aer: Timer/ Door Status

Re-latch on:

• Timer Only (Lock when timer expires regardless of Door status or Position)

• On Door Open or Timer (Lock when the Door opens or Timer expires)

• On Door Close or Timer (Lock when the Door closes or Timer expires)

Card + PIN LED mode Disabled

Mode 1: 2 alternating blinks Mode 2: Solid Green/2 red blinks

Communication Link Direct to Host: Sets RS-485 communication protocol to work directly with an ACP.

Through PIB300: Sets RS-485 communication protocol through the PIB300.

FIPS201-2 Authentication

This checkbox will allow the user to choose whether to perform the full FIPS201-2 authentication for PIV credentials. Also, since this operation is not applicable on all lock types, it appears Grayed out (un-editable) for the following lock types:

AD-300, AD-301.

* AD-302 does not support Cache mode; these options will be grayed out.

Lock PropertiesAD-Series Locks and Controllers

3 seconds

As-Is

Full Card

Disabled

n/a

125

Enabled (unchecked)

3 seconds

Timer only

Direct to Host

unchecked

27 • Schlage • Schlage Utility Soware for Android User's Guide

AD-300/AD301/AD-302 (Networked Locks)

Property Description Default

Prox in Use Proximity credential card types allowed. Selections:

• HID/Kantech ioProx*

• GE/CASI

• GE4001

• AWID*

• GE4002*

Mag Track in Use Magnetic card track that access data is to be read from. Track 1, 2 or 3 Track 2

Enable Low Power Wake-Up

Active when Mag Track 1 or 3 is selected in "Mag Track in Use". By enabling Low Power Wake-Up and having data on track 2, this option will allow longer battery life. (Available only on battery-powered locks.)

Smart Cards in Use Smart card(s) to be used with the card reader.

• 14443 UID(CSN) (when selected, disables all other 14443 selections and PIV format)

• 14443 Secure MiFare Classic*

• 14443 Secure MiFare Plus*

• 14443 EV1 (NOC)*

• 15693 UID (CSN)*

MTK1

• iClass credential formats for Reader Types which support Smart Cards

• iClass 40-bit UID (CSN)

• iClass 64-bit UID (CSN)*

• HID iClass Classic* (only appears with Mi/MiK reader attached)

• PIV credential formats for AD200 reader types which support Smart Cards. Range is 1 to 15.

READER Tab

1. 75 Bit PIV*

2. 58 Bit TWIC/CAC

3. 200 Bit FASC–N

4. 64 Bit (BCD) TWIC/CAC

5. 83 Bit TWIC/CAC

6. 66 Bit (58 Bit Format + TSM) TWIC/CAC

7. 64 Bit (58 Bit Format (no parity) + TSM) TWIC/CAC

8. 91 Bit (83 Bit Format + TSM) TWIC/CAC

9. 40 Bit BCD

10. 40 Bit Reversed BCD

11. 64 Bit BCD

12. 64 Bit Reversed BCD

13. 128 Bit BCD

14. 128 Bit Reversed BCD

15. 58 Bit HSE

Lock PropertiesAD-Series Locks and Controllers

* Default formats

Enabled

* Default formats

MTK2

• iClass/Felica credential formats for Reader Types which support Smart Cards

• iClass/Felica 40-bit UID (CSN)

• iClass/Felica 64-bit UID (CSN)*

• HID iClass/iClass SE/iClass SEOS (only appears with Si2/SiK2 reader attached). Enabled by default.

• PIV credential formats for AD200 reader types which support Smart Cards. Range is 1 to 15.

1. 75 Bit PIV*

2. 58 Bit TWIC/CAC

3. 200 Bit FASC–N

4. 64 Bit (BCD) TWIC/CAC

5. 83 Bit TWIC/CAC

6. 66 Bit (58 Bit Format + TSM) TWIC/CAC

7. 64 Bit (58 Bit Format (no parity) + TSM) TWIC/CAC

28 • Schlage • Schlage Utility Soware for Android User's Guide

8. 91 Bit (83 Bit Format + TSM) TWIC/CAC

9. 40 Bit BCD

10. 40 Bit Reversed BCD

11. 64 Bit BCD

12. 64 Bit Reversed BCD

13. 128 Bit BCD

14. 128 Bit Reversed BCD

15. 58 Bit HSE

AD-300/AD301/AD-302 (Networked Locks)

Beeper Indicates if the Beeper is On or Off. ON

Apple NFC MTK2, FMK2 and SIK2 only Disabled

TRA Security

Increased Card Read Attempts

Keypad: Output Type Wiegand or Magnetic output type. Wiegand

Keypad: Facility Code A facility or site code is encoded into each card to increase security.

A number from 0 to 255 on a 26-bit format card.

Keypad: Keys Buffered Fixed number of key presses to buffer. Range in 1 to 11. Active only in keypad output

modes that support buffered key presses. See Output formats 4, 6, 9 and 10 below.

Keypad: Output Format Sets the keypad data length and format mode. Range is 0 to 12.

0. Disable Keypad output

1. Mode 1: 4 Data Bits per Key without Parity (high nibble)

READER Tab

2. Mode 2: 4 Data Bits per Key with Parity

3. Mode 3: 8 Data Bits per Key without Parity

4. Mode 4: 8 Data Bits per Key with Parity

5. Mode 5: 4 Data Bits per Key, Buffered Key Presses without Parity

6. Mode 6: 4 Data Bits per Key, Buffered Key Presses with Parity

7. Mode 7: 26 Bit Wiegand Emulation

8. Mode 8: 4 Data Bits per Key without Parity (low nibble)

9. Mode 9: IR, 4 Data Bits per Key, Buffered Key Presses without Parity

10. Mode 10: IR, 4 Data Bits per Key, Buffered Key Presses with Parity

11. Mode 11: 8 Data Bits per Key, ASCII with parity

12. Mode 12: 32 Bit Wiegand Emulation

Lock PropertiesAD-Series Locks and Controllers

(unchecked)

29 • Schlage • Schlage Utility Soware for Android User's Guide

AD-400/AD-401/AD-402 (Networked Locks)

Property Description

General Properties

Model Model number of the device connected to the mobile device.

Power Status Current voltage level and number of AA batteries.

FIPS201-2 Capable (AD-402 only)

The Yes or No value for this ﬁeld indicates whether the device (i.e. Lock/Reader combination) is FIPS201-2 Capable or not.

Main Lock

RS485 Partner ID Identiﬁes the participating OEM soware partner.

Serial Number Serial number that uniquely identiﬁes the lock.

Manufacture Date Date the lock was manufactured.

Days Since Installed Used for warranty purposes; it marks the beginning of the lock’s functional life.

Firmware Version Version of the current ﬁrmware ﬁle. Automatically updated when new ﬁrmware ﬁle is loaded.

Hardware Version Current version of the printed circuit main board.

Bootloader Version Version of the current bootloader. Allows new ﬁrmware to be loaded.

Credential Reader

Serial Number Serial number that uniquely identiﬁes the reader.

Manufacture Date Date the reader was manufactured.

Firmware Version Version of the current ﬁrmware ﬁle. Automatically updated when new ﬁrmware ﬁle is loaded.

Hardware Version Current version of the printed circuit credential board.

VIEW Tab

Card Detection

Applicable only for MTK2, FMK2 and SIK2. Current ﬁrmware version of the card detection module.

Firmware Version

Bootloader Version Version of the current bootloader. Allows new ﬁrmware to be loaded.

Reader Type Type of Reader installed:

• MagInsert

• MagInsert + Keypad

• MagSwipe

• MagSwipe + Keypad

• Keypad

• Proximity

• Proximity + Keypad

• Smart Card

• Smart Card + Keypad

• FIPS + Multi-Tech + Keypad

• iClass + Multi-Tech

• iClass + Multi-Tech + Keypad

• Multi-Tech 2

• Multi-Tech 2 + Keypad

• FIPS + Multi-Tech 2 + Keypad

• Keypad 2

• iClass + Smart Only 2

• iClass + Smart Only 2 + Keypad

• Multi-Tech

• Multi-Tech + Keypad

Lock PropertiesAD-Series Locks and Controllers

Custom Key If the reader supports reporting the status of custom conﬁguration then SUS-A displays “Custom

Key: Installed” or “Custom Key: Not Installed”

Communication

Serial Number Serial number that uniquely identiﬁes the communication module.

Firmware Version Version of the communication module ﬁrmware.

1. These properties are view-only when the mobile device is connected to the lock. Connect the mobile device to the PIM400 to make changes.

30 • Schlage • Schlage Utility Soware for Android User's Guide

AD-400/AD-401/AD-402 (Networked Locks)

Property Description Default

Heartbeat The heartbeat is a brief communication from the lock to the PIM400. It allows an

idle lock to check for messages. Range: 15 seconds - many hours. The value indicates the time between the heartbeats. Set to a shorter time (lower

number) for more frequent communication. Set to a longer time (higher number) for less frequent communication. A smaller value will decrease battery life. A larger value will increase battery life.

Comm Loss Fail Mode Lock state set when RF communication with the linked PIM400 fails.

States: As-Is, Secure/Lock, Unsecure/Unlock

Allow Extended Unlocks (Locks linked to

PIM400-TD2 only)

Report RTX for Host to

unlock

Extended unlock permits the lock to stay in an indeﬁnite unlock state. Enabling the Extended Unlock feature is required to implement a scheduled unlock

period from an ACP.

Determines how an AD-400 will handle a request to exit. If disabled, the AD-400 will only report that a request to exit has occurred. Disable

if the access point does not need to be electronically unlocked to provide egress (if equipped with a crash bar) but the access control panel needs to be notiﬁed so that a forced door does not occur.

If enabled, the AD-400 will report that a request to exit has occurred, and also will query the PIM400 to determine if the AD-400 should be electronically unlocked. Use this mode if the AD-400 needs to be electronically unlocked in order to provide egress.

Relatch Aer: Timer/ Door Status

EDIT Tab

Re-latch on:

• Timer Only (Lock when Timer expires (default 3 seconds) regardless of Door status or Position)

• On Door Open or Timer (Lock when the Door opens or Timer expires)

• On Door Close or Timer (Lock when the Door closes or Timer expires)

High Low Output (Locks linked to

PIM400-TD2 only)

Polarity of the Request-to-Exit (RTX) signal. Low: RTX

Polarity of the Request-to-Enter (RTE) signal. Low: RTE

Polarity of the On Door Open, (Door Position Switch (DPS)) signal. High: open

Polarity of Trouble signal. Low: trouble

First, Delay, Retry First: First query a Lock makes to a PIM400 occurs immediately following

presentation of a credential. First is the amount of time, in milliseconds, an AD400 should wait before making its second query to a PIM400. This setting should be slightly greater than the fastest response time from the access control panel or host. This optimizes battery life and system performance.

Delay: The idle time between subsequent queries. Shorter delays may reduce latency. Longer delays may enhance battery life.

Retry: The maximum number of times an access point queries a PIM400 before the Lock goes back to sleep. The number of retries should be slightly greater than the longest response time from the access control panel or host. Retrys = [{Max Response Time of Panel- First}/ Delay] +1

Degraded (Cache) Mode: Card Bit Format

1. These properties are view-only when the mobile device is connected to the lock. Connect the mobile device to the PIM400 to make changes.

Enter the number of bits on the cards being used to enable degraded mode. abilities. 0= cache mode disabled

Lock PropertiesAD-Series Locks and Controllers

10 minutes

As-Is

Enabled

Disabled

Timer only

First: 300 msec.

Delay: 200 msec.

Retry: 5

31 • Schlage • Schlage Utility Soware for Android User's Guide

AD-400/AD-401/AD-402 (Networked Locks)

Property Description Default

Degraded (Cache) Mode: Full Card Number or Facility Code*

Degraded (Cache) Mode: Purge unused

Use the full card number or the facility codes of previously approved credentials in the Degraded (Cache) mode. Granting access is determined by “Full Card” content or just “Facility Code”.

When enabled, deletes the cache entry aer 5 days of non-use. If enabled, cards that have not accessed the lock within 5 days will be removed.

aer 5 days*

Degraded (Cache) Mode: Clear Cache*

Deletes all valid user credentials from the Degraded (cache) memory. Allows you to manually clear cache memory.

Card + PIN LED Mode Disabled

Mode 1: 5 le green and right red alternating blinks Mode 2: 5 le green and right red alternating blinks, plus two beeps

Request to Enter Report Request to Enter signal state to PIM400/401. Always

Wakeup status

Displays the time, in seconds, the lock listens for Wake on Radio broadcasts from its linked PIM400/401.

Disable Interior Button

Edit Tab (Cont.)

If checked, interior button LED blinking is disabled. Disabled

LED

Max Entries Stored* Number of credential cards or facility codes maintained in the cache. Minimum of 5,

Maximum of 1000.

ACP Timeout Time (in seconds) to wait before determining communication from the ACP has

failed.

Battery Fail Mode Lock state set when battery fails. As-Is, Secure/Lock, Unsecure/Unlock As-Is

FIPS201-2 Authentication

AD-400, AD-401.

* AD-402 does not support Cache mode; these options will be grayed out.

1. These properties are view-only when the mobile device is connected to the lock. Connect the mobile device to the PIM400 to make changes.

Lock PropertiesAD-Series Locks and Controllers

Full Card

Disabled

n/a

Enabled

Disabled

(unchecked)

125

10 seconds

unchecked

32 • Schlage • Schlage Utility Soware for Android User's Guide

AD-400/AD-401/AD-402 (Networked Locks)

Property Description Default

Prox in Use Proximity credential card types allowed. Selections:

• HID/Kantech ioProx*

• GE/CASI

• GE4001

• AWID*

• GE4002*

Mag Track in Use Magnetic card track that access data is to be read from. Track 1, 2 or 3 Track 2

Enable Low Power Wake-Up

Active when Mag Track 1 or 3 is selected in "Mag Track in Use". By enabling Low Power Wake-Up and recording data on track 2, this option will allow longer battery life.

Smart Cards in Use Smart card(s) to be used with the card reader.

• 14443 UID(CSN) (when selected, disables all other 14443 selections and PIV format)

• 14443 Secure MiFare Classic*

• 14443 Secure MiFare Plus*

• 14443 EV1 (NOC)*

• 15693 UID (CSN)*

MTK1

• iClass credential formats for Reader Types which support Smart Cards

• iClass 40-bit UID (CSN)

• iClass 64-bit UID (CSN)*

• HID iClass Classic* (only appears with Mi/MiK reader attached)

• PIV credential formats for AD200 reader types which support Smart Cards. Range is 1 to 15.

READER Tab

1. 75 Bit PIV*

2. 58 Bit TWIC/CAC

3. 200 Bit FASC–N

4. 64 Bit (BCD) TWIC/CAC

5. 83 Bit TWIC/CAC

6. 66 Bit (58 Bit Format + TSM) TWIC/CAC

7. 64 Bit (58 Bit Format (no parity) + TSM) TWIC/CAC

8. 91 Bit (83 Bit Format + TSM) TWIC/CAC

9. 40 Bit BCD

10. 40 Bit Reversed BCD

11. 64 Bit BCD

12. 64 Bit Reversed BCD

13. 128 Bit BCD

14. 128 Bit Reversed BCD

15. 58 Bit HSE

Lock PropertiesAD-Series Locks and Controllers

* Default formats

Enabled

* Default formats

MTK2

• iClass/Felica credential formats for Reader Types which support Smart Cards

• iClass/Felica 40-bit UID (CSN)

• iClass/Felica 64-bit UID (CSN)*

• HID iClass/iClass SE/iClass SEOS (only appears with Si2/SiK2 reader attached). Enabled by default.

• PIV credential formats for AD200 reader types which support Smart Cards. Range is 1 to 15.

1. 75 Bit PIV*

2. 58 Bit TWIC/CAC

3. 200 Bit FASC–N

4. 64 Bit (BCD) TWIC/CAC

5. 83 Bit TWIC/CAC

6. 66 Bit (58 Bit Format + TSM) TWIC/CAC

7. 64 Bit (58 Bit Format (no parity) + TSM) TWIC/CAC

1. These properties are view-only when the mobile device is connected to the lock. Connect the mobile device to the PIM400 to make changes.

33 • Schlage • Schlage Utility Soware for Android User's Guide

8. 91 Bit (83 Bit Format + TSM) TWIC/CAC

9. 40 Bit BCD

10. 40 Bit Reversed BCD

11. 64 Bit BCD

12. 64 Bit Reversed BCD

13. 128 Bit BCD

14. 128 Bit Reversed BCD

15. 58 Bit HSE

AD-400/AD-401/AD-402 (Networked Locks)

Beeper Indicates if the Beeper is On or Off. ON

Apple NFC MTK2, FMK2 and SIK2 only Disabled

TRA Security

Increased Card Read Attempts

Keypad: Output Type Wiegand or Magnetic output type. Wiegand

Keypad: Facility Code A facility or site code is encoded into each card to increase security. A number from

0 to 255 on a 26-bit format card.

Keypad: Keys Buffered Fixed number of key presses to buffer. Range is 1 to 11. Active only in keypad output

modes that support buffered key presses. See Output formats 4, 6, 9 and 10 below.

Keypad: Output Format Sets the keypad data length and format mode. Range is 0 to 12.

0. Disable Keypad output

READER Tab

1. Mode 1: 4 Data Bits per Key without Parity (high nibble)

2. Mode 2: 4 Data Bits per Key with Parity

3. Mode 3: 8 Data Bits per Key without Parity

4. Mode 4: 8 Data Bits per Key with Parity

5. Mode 5: 4 Data Bits per Key, Buffered Key Presses without Parity

6. Mode 6: 4 Data Bits per Key, Buffered Key Presses with Parity

7. Mode 7: 26 Bit Wiegand Emulation

8. Mode 8: 4 Data Bits per Key without Parity (low nibble)

9. Mode 9: IR, 4 Data Bits per Key, Buffered Key Presses without Parity

10. Mode 10: IR, 4 Data Bits per Key, Buffered Key Presses with Parity

11. Mode 11: 8 Data Bits per Key, ASCII with parity

12. Mode 12: 32 Bit Wiegand Emulation

1. These properties are view-only when the mobile device is connected to the lock. Connect the mobile device to the PIM400 to make changes.

Lock PropertiesAD-Series Locks and Controllers

(unchecked)

34 • Schlage • Schlage Utility Soware for Android User's Guide

Controller Properties

Controller PropertiesAD-Series Locks and Controllers

• WPR400: pg 35

• PIM400 -TD2, -485, -VBB (PIM PROPERTIES): pg 38

• PIM400 -TD2, -485, -VBB (LOCK

WPR400

Property Description

General Properties

Model Model of the device connected to the mobile device.

Power Status Current voltage level and number of AA batteries.

MAIN LOCK

RS485 Partner ID Identiﬁes the participating OEM soware partner.

Serial Number Serial number that uniquely identiﬁes the lock.

Manufacture Date Date the lock was manufactured

Days Since Installed Used for warranty purposes; it marks the beginning of the lock’s functional life.

Firmware Version Current version of the ﬁrmware

Bootloader Version Version of the current bootloader. Allows new ﬁrmware to be loaded.

Hardware Version Current version of the printed circuit board.

Credential Reader

Serial Number Serial number that uniquely identiﬁes the reader.

Manufacture Date Date the reader was manufactured.

Firmware Version Current version of the ﬁrmware

Card Detection

VIEW Tab

Firmware Version

Bootloader Version Version of the current bootloader. Allows new ﬁrmware to be loaded.

Hardware Version Current version of the printed circuit board.

Reader Type Type of Reader installed:

Applicable only for MTK2, FMK2 and SIK2. Current ﬁrmware version of the card detection module.

• MagInsert

• MagInsert + Keypad

• MagSwipe

• MagSwipe + Keypad

• Keypad

• Proximity

• Proximity + Keypad

• Smart Card

PROPERTIES): pg 39

• PIB300: pg 43

• WRI400: pg. (page 45)

• CT5000: pg. (page 47)

• Smart Card + Keypad

• Multi-Tech

• Multi-Tech + Keypad

• FIPS + Multi-Tech + Keypad

• iClass + Multi-Tech

• iClass + Multi-Tech + Keypad

• Multi-Tech 2

• Multi-Tech 2 + Keypad

• FIPS + Multi-Tech 2 + Keypad

• Keypad 2

• iClass + Smart Only 2

• iClass + Smart Only 2 + Keypad

Custom Key If the reader supports reporting the status of custom conﬁguration then SUS-A displays “Custom

Key: Installed” or “Custom Key: Not Installed”

Communication

Serial Number Serial number that uniquely identiﬁes the communication module.

Firmware Version Version of the communication module ﬁrmware.

35 • Schlage • Schlage Utility Soware for Android User's Guide

Controller PropertiesAD-Series Locks and Controllers

WPR400

Property Description Default

Relatch Aer: Timer Length

Amount of time before the lock re-locks aer being unlocked by a user presenting a valid credential.

First, Delay, Retry First: First query a Lock makes to a PIM400 occurs immediately following

presentation of a credential. First is the amount of time, in milliseconds, the WPR400 should wait before making its second query to a PIM400. This setting should be slightly greater than the fastest response time from the access control panel or host. This optimizes battery life and system performance.

Delay: The idle time between subsequent queries. Shorter delays may reduce latency. Longer delays may enhance battery life.

Retry: The maximum number of times the WPR400 queries a PIM400 before the Lock goes back to sleep. The number of retries should be slightly greater than the longest response time from the access control panel or host. Retrys = [{Max Response Time of Panel- First}/Delay] +1

Degraded (Cache) Mode: Full Card Number or Facility Code

EDIT Tab

Degraded (Cache) Mode: Purge unused

Use the full card number or the facility codes of previously approved credentials in the Degraded (Cache) mode. Granting access is determined by “Full Card” content or just “Facility Code”.

When enabled, deletes the cache entry aer 5 days of non-use. If enabled, cards that have not accessed the lock within 5 days will be removed.

aer 5 days

Degraded (Cache) Mode: Clear Cache

Deletes all valid user credentials from the Degraded (cache) memory. Allows you to manually clear cache memory.

Card + PIN LED mode Disabled

Mode 1: 2 alternating blinks Mode 2: Solid Green/ 2 red right blinks

Wakeup Status Displays the time, in seconds, the lock listens for Wake on Radio broadcasts from its

linked PIM400.

Max Entries Stored Number of credential cards or facility codes maintained in the cache. Minimum of 5,

Maximum of 1000.

ACP Timeout Time (in seconds) to wait before determining communication from the ACP has

failed.

3 seconds

First: 300 msec.

Delay: 200 msec.

Retry: 5

Full Card

Disabled

n/a

Disabled

125

10 seconds

36 • Schlage • Schlage Utility Soware for Android User's Guide

Controller PropertiesAD-Series Locks and Controllers

WPR400

Property Description Default

Prox in Use Proximity credential card types allowed. Selections:

• HID/Kantech ioProx*

• GE/CASI

• GE4001

• AWID*

• GE4002*

Mag Track in Use Magnetic card track that access data is to be read from. Select Track 1, 2 or 3 Track 2

Enable Low Power Wake-Up

Active when Mag Track 1 or 3 is selected in "Mag Track in Use". By enabling Low Power Wake-Up and recording data on track 2, this option will allow longer battery life.

Smart Cards in Use Smart card(s) to be used with the card reader.

• 14443 UID(CSN) (when selected, disables all other 14443 selections and PIV format)

• 14443 Secure MiFare Classic*

• 14443 Secure MiFare Plus*

• 14443 EV1 (NOC)*

• 15693 UID (CSN)*

MTK1

• iClass credential formats for Reader Types which support Smart Cards

• iClass 40-bit UID (CSN)

• iClass 64-bit UID (CSN)*

• HID iClass Classic* (only appears with Mi/MiK reader attached)

• PIV credential formats for AD200 reader types which support Smart Cards. Range is 1 to 15.

READER Tab

1. 75 Bit PIV*

2. 58 Bit TWIC/CAC

3. 200 Bit FASC–N

4. 64 Bit (BCD) TWIC/CAC

5. 83 Bit TWIC/CAC

6. 66 Bit (58 Bit Format + TSM) TWIC/CAC

7. 64 Bit (58 Bit Format (no parity) + TSM) TWIC/CAC

8. 91 Bit (83 Bit Format + TSM) TWIC/CAC

9. 40 Bit BCD

10. 40 Bit Reversed BCD

11. 64 Bit BCD

12. 64 Bit Reversed BCD

13. 128 Bit BCD

14. 128 Bit Reversed BCD

15. 58 Bit HSE

* Default formats

Enabled

* Default formats

MTK2

• iClass/Felica credential formats for Reader Types which support Smart Cards

• iClass/Felica 40-bit UID (CSN)

• iClass/Felica 64-bit UID (CSN)*

• HID iClass/iClass SE/iClass SEOS (only appears with Si2/SiK2 reader attached). Enabled by default.

• PIV credential formats for AD200 reader types which support Smart Cards. Range is 1 to 15.

1. 75 Bit PIV*

2. 58 Bit TWIC/CAC

3. 200 Bit FASC–N

4. 64 Bit (BCD) TWIC/CAC

5. 83 Bit TWIC/CAC

6. 66 Bit (58 Bit Format + TSM) TWIC/CAC

7. 64 Bit (58 Bit Format (no parity) + TSM) TWIC/CAC

37 • Schlage • Schlage Utility Soware for Android User's Guide

8. 91 Bit (83 Bit Format + TSM) TWIC/CAC

9. 40 Bit BCD

10. 40 Bit Reversed BCD

11. 64 Bit BCD

12. 64 Bit Reversed BCD

13. 128 Bit BCD

14. 128 Bit Reversed BCD

15. 58 Bit HSE

Controller PropertiesAD-Series Locks and Controllers

WPR400

Beeper Indicates if the Beeper is On or Off. ON

Apple NFC MTK2, FMK2 and SIK2 only Disabled

TRA Security

Increased Card Read Attempts

Keypad: Output Type Wiegand or Magnetic output type. Wiegand

Keypad: Facility Code A facility or site code is encoded into each card to increase security.

A number from 0 to 255 on a 26-bit format card.

Keypad: Keys Buffered Fixed number of key presses to buffer. Range in 1 to 11. Active only in keypad output

modes that support buffered key presses. See Output formats 4, 6, 9 and 10 below.

Keypad: Output Format Sets the keypad data length and format mode. Range is 0 to 12.

0. Disable Keypad output

READER Tab

1. Mode 1: 4 Data Bits per Key without Parity (high nibble)

2. Mode 2: 4 Data Bits per Key with Parity

3. Mode 3: 8 Data Bits per Key without Parity

4. Mode 4: 8 Data Bits per Key with Parity

5. Mode 5: 4 Data Bits per Key, Buffered Key Presses without Parity

6. Mode 6: 4 Data Bits per Key, Buffered Key Presses with Parity

7. Mode 7: 26 Bit Wiegand Emulation

8. Mode 8: 4 Data Bits per Key without Parity (low nibble)

9. Mode 9: IR, 4 Data Bits per Key, Buffered Key Presses without Parity

10. Mode 10: IR, 4 Data Bits per Key, Buffered Key Presses with Parity

11. Mode 11: 8 Data Bits per Key, ASCII with parity

12. Mode 12: 32 Bit Wiegand Emulation

(unchecked)

PIM400 -TD2, -485, -VBB (PIM PROPERTIES)

Property Description

General Properties

Model Model number of the device connected to the mobile device.

Source ID Unique identiﬁer for the PIM400.

FIPS 201-2 Capable (PIM-485 & PIM-VBB

The Yes or No value for this ﬁeld indicates whether the device (i.e. Lock/Reader/PIM combination) is FIPS201-2 Capable or not.

ONLY)

PIM

RS485 Partner ID Identiﬁes the participating OEM soware partner.

Firmware Version Version of the current ﬁrmware ﬁle. Automatically updated when a new ﬁrmware version is

VIEW Tab

loaded.

Bootloader version Version of the current bootloader. Allows new ﬁrmware to be loaded.

Serial No. Serial number that uniquely identiﬁes the device.

Manufacture Date Date the device was manufactured.

Days since Installed Used for warranty purposes; marks the beginning of the lock’s functional life.

Hardware Version Current version of the printed circuit main board.

Communication

Firmware Version Version of the communication module ﬁrmware.

38 • Schlage • Schlage Utility Soware for Android User's Guide

PIM400 -TD2, -485, -VBB (PIM PROPERTIES)

Property Description Default

Unique ID Set the Unique Identiﬁcation number of the PIM400. Range: 1 to 65534.

Freq Channel Radio Frequency Channel used for communication with wireless devices. One of

ten RF channels can be set.

RS-485 Address PIM400 -485 and PIM400-VBB ONLY. Set the RS-485 network address of the

PIM400/401. Address range 0-254

Low Door PIM400 -485, -VBB ONLY. Set the Low address for the range of door addresses

available for linking. Range: 0 to 255

High Door PIM400 -485, -VBB ONLY. Set the High address for the range of door addresses

available for linking. Range: 0 to 255

Channel Switching Dynamic Channel Switching is used to improve immunity to RF channel

EDIT Tab

interference. One of three RF channel groups can be set.

Wakeup When enabled, this feature causes wireless devices linked to the PIM400/401 to

respond within seconds to a centralized command from the access control panel. When disabled, the wireless devices will respond only during their heartbeat, which could result in a delay. Range 0 to 10 seconds. 0= disabled

Output Type (PIM400TD2 only)

Magnetic, Wiegand or Automatic. Outputs the Credential Card and Keypad data in either Magnetic or Wiegand format.

When Automatic is selected, the PIM400-TD2 will detect the Credential Card and Keypad data format and then send the received data in its original data format.

Property Description Default

Select Door Select the door address desired to be linked to the PIM400 -485.

Controller PropertiesAD-Series Locks and Controllers

Disabled

Automatic

LINK Tab

(PIM400/401, -485, -VBB only)

PIM400 -TD2, -485, -VBB (LOCK PROPERTIES)

Property Description

General Properties

Model Model of the device connected to the mobile device.

Door Number Allows the selection of a door connected to the PIM400 to display its properties.

Power Status Current voltage level of the AA batteries.

FIPS 201-2 capable Applicable if AD401/AD402 is linked at this door address.

VIEW Tab

PIM

Firmware Version Version of the ﬁrmware.

Communication

Firmware Version Version of the communication module ﬁrmware.

39 • Schlage • Schlage Utility Soware for Android User's Guide

Controller PropertiesAD-Series Locks and Controllers

PIM400 -TD2, -485, -VBB (LOCK PROPERTIES)

Property Description Default

Heartbeat The heartbeat is a brief communication from the lock to the PIM400.

The heartbeat allows an idle lock to check for messages from the PIM400. By default, this occurs every 10 minutes, but can be adjusted in the range of 15 seconds to many hours.

The value indicates the time between the heartbeats. Set the value to a shorter time (lower number) to achieve more frequent communication while the lock is idle. Set the value to a longer time (higher number) to achieve less frequent communication. A smaller value will decrease battery life. A larger value will increase battery life.

Comm Loss Fail Mode Lock state set when RF communication with the linked PIM400 fails.

Selections: As-Is, Secure/Lock, Unsecure/Unlock

Allow Extended Unlocks (PIM400-TD2 only)

Extended unlock is a feature that permits the lock to stay in an indeﬁnite unlock state.

Enabling the Extended Unlock feature is required to implement a scheduled unlock period from an ACP.

Report RTX for Host to Unlock

This feature determines how a Wireless Access Point (Door) will handle a request to exit.

If not checked (disabled), then the access point will only report that a request to exit has occurred. Use this mode if the access point does not need to be electronically unlocked in order to provide egress (for instance, the access point has a crash bar) but the access control panel needs to be notiﬁed so that a forced door does not occur.

If checked (enabled), then the access point will not only report that a request to exit has occurred, but will query the PIM400 (as in a card swipe) to determine if the access point should be electronically unlocked. Use this mode if the access point needs to be electronically unlocked in order to provide egress.

Relatch Aer: Timer

EDIT Tab

Length

Relatch Aer : Timer/ Door Status

Amount of time, in seconds, before the lock re-locks aer being unlocked by a user presenting a valid credential.

Re-latch on:

• Timer Only: Lock when timer expires regardless of Door status or Position

• On Door Open or Timer: Lock when the Door opens or Timer expires

• On Door Close or Timer: Lock when the Door closes or Timer expires

High Low Output (PIM400-TD2 only)

Polarity of the Request-to-Exit (RTX) signal. Low: RTX

Polarity of the Request-to-Enter (RTE) signal. Low: RTE

Polarity of the On Door Open, (Door Position Switch (DPS)) signal. High: open

Polarity of Trouble signal. Low: trouble

First, Delay, Retry First: First query a lock makes to a PIM400 occurs immediately following

presentation of a credential. First is the amount of time, in milliseconds, an access point should wait before making its second query to a PIM400. This setting should be slightly greater than the fastest response time from the access control panel or host. This optimizes battery life and system performance.

Delay: The idle time between subsequent queries. Shorter delays may reduce latency. Longer delays may enhance battery life.

Retry: The maximum number of times and access point queries a PIM400 before the lock goes back to sleep. The number of retires shoudl be slightly greater than the longest response time from the access control panel or host. Retry=[{ Max Response Time of Panel - First} /Delay] + 1.

Degraded (Cache) Mode: Card Bit Format

Enter the number of bits on the cards being used to enable degraded mode.abilities. 0 = cache mode disabled

10 minutes

As-Is

enabled

Enabled

3 seconds

Timer only

First: 300 Delay: 200 Retry: 5

40 • Schlage • Schlage Utility Soware for Android User's Guide

PIM400 -TD2, -485, -VBB (LOCK PROPERTIES)

Controller PropertiesAD-Series Locks and Controllers

Degraded (Cache) Mode: Purge unused

When enabled, deletes the cache entry aer 5 days of non-use. If enabled, cards that have not accessed the lock within 5 days will be removed.

Disabled

aer 5 days*

Degraded (Cache) Mode: PIM485 Card Removal*

PIM400 -485, -VBB ONLY. Only displayed when a Legacy PIM is connected. If disabled only time or a full cache

will remove an entry from the cache. If enabled only a full cache or receiving a

Disabled

RS−485 Deny Access command will remove an entry from the cache.

Degraded (Cache) Mode: Full Card Number or Facility Code*

Degraded (Cache) Mode: Clear Cache*

Card + PIN LED mode Disabled

Use the full card number or the facility codes of previously approved credentials in the Degraded (Cache) mode. Granting access is determined by “Full Card” content or just “Facility Code”.

Deletes all valid user credentials from the Degraded (cache) memory. Allows you to manually clear cache memory.

Full Card

n/a

1 Mode 1: 5 le green and right red alternating blinks Mode 2: 5 le green and right red alternating blinks, plus two beeps

Request to Enter Report Request to Enter signal state to PIM400 Disabled

Wakeup Displays the time, in seconds, the Wireless Access Point Device listens for Wake on

Disabled Radio broadcasts from its linked PIM400.

EDIT Tab (Cont.)

Max Entries Stored Number of credential cards or facility codes maintained in the cache. Minimum of 5,

125 Maximum of 1000.

ACP timeout Time (in seconds) to wait before determining communication from the ACP has

10 seconds failed.

Power Fail Mode Lock state set when battery fails. As-Is, Secure/Lock, Unsecure/Unlock As-Is

Pin Required TD2 Only Disabled

(unchecked)

Disable Interior Button LED

FIPS 201-2

TD2 and 485 Enabled

(unchecked)

Checkbox will be displayed only if AD402 is connected. unchecked

Authentication

* Not applicable for AD-302 & AD-402

41 • Schlage • Schlage Utility Soware for Android User's Guide

Controller PropertiesAD-Series Locks and Controllers

PIM400 -TD2, -485, -VBB (LOCK PROPERTIES)

Property Description Default

Prox in Use Proximity credential card types allowed. Selections:

• HID/Kantech

ioProx*

• GE/CASI

• GE4001

• AWID*

• GE4002*

Mag Track in Use Magnetic card track that access data is to be read from. Select Track 1, 2 or 3 Track 2

Enable Low Power Wake-Up

Active when Mag Track 1 or 3 is selected in "Mag Track in Use". By enabling Low Power Wake-Up and recording data on track 2, this option will allow longer battery life.

Smart Cards in Use Smart card(s) to be used with the card reader.

• 14443 UID(CSN) (when selected, disables all other 14443 selections and PIV

format)

• 14443 Secure MiFare Classic*

• 14443 Secure MiFare Plus*

• 14443 EV1 (NOC)*

• 15693 UID (CSN)*

MTK1

• iClass credential formats for Reader Types which support Smart Cards

• iClass 40-bit UID (CSN)

• iClass 64-bit UID (CSN)*

• HID iClass Classic* (only appears with Mi/MiK reader attached)

• PIV credential formats for AD200 reader types which support Smart Cards. Range

is 1 to 15.

READER Tab

1. 75 Bit PIV*

2. 58 Bit TWIC/CAC

3. 200 Bit FASC–N

4. 64 Bit (BCD) TWIC/CAC

5. 83 Bit TWIC/CAC

6. 66 Bit (58 Bit Format + TSM) TWIC/CAC

7. 64 Bit (58 Bit Format (no parity) + TSM) TWIC/CAC

8. 91 Bit (83 Bit Format + TSM) TWIC/CAC

9. 40 Bit BCD

10. 40 Bit Reversed BCD

11. 64 Bit BCD

12. 64 Bit Reversed BCD

13. 128 Bit BCD

14. 128 Bit Reversed BCD

15. 58 Bit HSE

* Default formats

Enabled

* Default formats

MTK2

• iClass/Felica credential formats for Reader Types which support Smart Cards

• iClass/Felica 40-bit UID (CSN)

• iClass/Felica 64-bit UID (CSN)*

• HID iClass/iClass SE/iClass SEOS (only appears with Si2/SiK2 reader attached). Enabled by default.

• PIV credential formats for AD200 reader types which support Smart Cards. Range is 1 to 15.

1. 75 Bit PIV*

2. 58 Bit TWIC/CAC

3. 200 Bit FASC–N

4. 64 Bit (BCD) TWIC/CAC

5. 83 Bit TWIC/CAC

6. 66 Bit (58 Bit Format + TSM) TWIC/CAC

7. 64 Bit (58 Bit Format (no parity) + TSM) TWIC/CAC

42 • Schlage • Schlage Utility Soware for Android User's Guide

8. 91 Bit (83 Bit Format + TSM) TWIC/CAC

9. 40 Bit BCD

10. 40 Bit Reversed BCD

11. 64 Bit BCD

12. 64 Bit Reversed BCD

13. 128 Bit BCD

14. 128 Bit Reversed BCD

15. 58 Bit HSE

Controller PropertiesAD-Series Locks and Controllers

PIM400 -TD2, -485, -VBB (LOCK PROPERTIES)

Beeper Indicates if the Beeper is On or Off. ON

Apple NFC MTK2, FMK2 and SIK2 only Disabled

TRA Security

Increased Card Read Attempts

Keypad: Output Type Wiegand or Magnetic output type. Wiegand

Keypad: Facility Code A facility or site code is encoded into each card to increase security. A number from 0

to 255 on a 26-bit format card.

Keypad: Keys Buffered Fixed number of key presses to buffer. Range in 1 to 11. Active only in keypad output

modes that support buffered key presses. See Output formats 4, 6, 9 and 10 below.

Keypad: Output Format Sets the keypad data length and format mode. Range is 0 to 12.

0. Disable Keypad output

1. Mode 1: 4 Data Bits per Key without Parity (high nibble)

READER Tab

2. Mode 2: 4 Data Bits per Key with Parity

3. Mode 3: 8 Data Bits per Key without Parity

4. Mode 4: 8 Data Bits per Key with Parity

5. Mode 5: 4 Data Bits per Key, Buffered Key Presses without Parity

6. Mode 6: 4 Data Bits per Key, Buffered Key Presses with Parity

7. Mode 7: 26 Bit Wiegand Emulation

8. Mode 8: 4 Data Bits per Key without Parity (low nibble)

9. Mode 9: IR, 4 Data Bits per Key, Buffered Key Presses without Parity

10. Mode 10: IR, 4 Data Bits per Key, Buffered Key Presses with Parity

11. Mode 11: 8 Data Bits per Key, ASCII with parity

12. Mode 12: 32 Bit Wiegand Emulation

(unchecked)

PIB300

Property Description

General Properties

Model Model of the device connected to the mobile device.

PIB

Firmware Version Version of the ﬁrmware ﬁle. Automatically updated when a new ﬁrmware ﬁle is loaded.

Bootloader Version Version of the current bootloader. Allows new ﬁrmware to be loaded.

VIEW Tab

Serial No. Serial number that uniquely identiﬁes the device.

Manufacture Date Date the device was manufactured.

Days since Installed Used for warranty purposes; marks the beginning of the lock’s functional life.

Hardware Version Current version of the printed circuit main board.

43 • Schlage • Schlage Utility Soware for Android User's Guide

Controller PropertiesAD-Series Locks and Controllers

PIB300

Property Description Default

Standard/ Legacy VIP RS-485 network communication format: Standard (Schlage RSI RS-485 protocol)

or Legacy VIP Protocol.

Number of doors Number of doors connected to the RS-485 network. 2

Lock 1 Address RS-485 address for Lock 1, Range: 0 to 254 0

Lock 2 Address RS-485 address for Lock 2, Range: 0 to 254 1

Output Type Magnetic, Wiegand or Automatic. Outputs the Credential Card and Keypad data in

either Magnetic or Wiegand format. When Automatic is selected, the PIB300 will detect the Credential Card and Keypad

data format and then send the received data in its original data format.

Host Control: LED Control

Host Control: LED Standard

Off= two-line led control of lock led indication On=single-line led control of lock led indication

Off=led standard (active low signal from access control panel) On=led invert (active high signal from access control panel.)

Host Control: LED Style Off=led style std. (For use on two led system.)

On=special case. If panel tries to light both leds (at the same time) neither of them lights. Beeper is not controlled by panel with this switch on. S1-1 must be set to off when

EDIT Tab

Host Control: Lock Control from ACP

Host Control: Beep Std/ Inverted

Output Reporting: Door Status

Output Reporting: Request to Exit (RTX)

this switch is set to on.

Off=normally open lock control from panel On=normally closed lock control from panel

Off=beep standard (active low signal from access control panel) On=beep inverted (active high signal from access control panel)

Off=normally open door status output (when door closed) On=normally closed door status output (when door closed)

Off=normally open RTX output when lever not depressed On=normally closed RTX output when lever not depressed

Output Reporting: Spare Off=normally open spare output (normal = key not used/latch extended, locked

position) On=normally closed spare output (normal = key not used/latch extended, locked position)

Output Reporting: Spare Status

Off=spare output provides status of key use (rta) - if lock is equipped w/option On=spare output provides status of latch bolt monitor (lbm) - if lock is equipped w/ option

Output Reporting: Spare Provides

Off=spare output does not provide troubles status. Selection on 9 is used On=spare output provides troubles status. Selection on 9 is ignored

Standard

Automatic

Unchecked

44 • Schlage • Schlage Utility Soware for Android User's Guide

Controller PropertiesAD-Series Locks and Controllers

WRI400

Property Description

General Properties

Model Model number of the device connected to the mobile device.

Main Lock

RS485 Partner ID Identiﬁes the participating OEM soware partner.

Serial Number Serial number that uniquely identiﬁes the WRI400.

Manufacture Date Date the WRI400 was manufactured.

Days Since Installed Used for warranty purposes; marks the beginning of the WRI400 functional life.

VIEW Tab

Firmware Version Version of the current ﬁrmware ﬁle. Automatically updated when new ﬁrmware ﬁle is loaded.

Hardware Version Current version of the printed circuit main board.

Bootloader Version Version of the current bootloader. Allows new ﬁrmware to be loaded.

Communication

Serial Number Serial number that uniquely identiﬁes the communication module.

Firmware Version Version of the communication module ﬁrmware.

Property Description Default

Heartbeat The heartbeat is a brief communication from the WRI400 to the PIM400.

It allows the WRI400 to check for messages. Range: 1 s. – 65535 s. The value indicates the time between the heartbeats. Set to a shorter time (lower

number) for more frequent communication. Set to a longer time (higher number) for less frequent communication.

A smaller value will decrease battery life. A larger value will increase battery life.

Comm Loss Fail Mode WRI400 state set when the RF communication with the linked PIM400 fails. States:

As-Is, Secure/Lock, Unsecure/Unlock

Allow Extended Unlocks

Extended unlock permits the WRI400 to stay in an indeﬁnite unlock state (available only in a PIM400-TD2).

Enabling the Extended Unlock feature is required to implement a scheduled unlock period from an Access Control Panel.

Report RTX for Host to unlock

EDIT Tab

Determines how the WRI400 handles a request to exit. If disabled, the WRI400 will only report that a request to exit has occurred. Disable

if the WRI400 does not need to be electronically unlocked to provide egress (if equipped with a crash bar) but the access control panel needs to be notiﬁed so that a forced door does not occur.

If enabled, the WRI400 will report that a request to exit has occurred, and also will query the PIM400 to determine if it should be electronically unlocked. Use this mode if the WRI400 needs to be electronically unlocked in order to provide egress.

Relatch Aer Amount of time before the WRI400 re-locks aer being unlocked by a user presenting

a valid credential. The value set in the mobile device is only used if the Access Control Panel (ACP)

responds with a “Momentary Unlock” command. When the Access Control Panel sends the number of seconds to unlock the WRI400 then the relatch aer value set in the mobile device is ignored.

Relatch Aer: Timer/ Door Status

Timer Only: Locks the WRI400 when timer expires regardless of its status or position. On Door Open or Timer: Locks WRI400 when it opens or Timer expires. On Door Close or Timer: Locks WRI400 when it closes or Timer expires.

10 minutes

As-Is

Enabled

3 seconds

Timer Only

45 • Schlage • Schlage Utility Soware for Android User's Guide

WRI400

Controller PropertiesAD-Series Locks and Controllers

Output (PIM400TD2)

Signaled through the PIM400-TD2 to the Access Control Panel, it sets the polarity of the Request to Enter (RTE) signal.

On Door Open

Output (PIM400TD2)

Signaled through the PIM400-TD2 to the Access Control Panel, it sets the polarity of the Request to Exit (RTX) signal.

On Request to Exit: Active High/Active Low

Output (PIM400TD2)

Signaled through the PIM400-TD2 to the Access Control Panel, this sets the polarity of the Trouble signal.

On Trouble: Active High/Active Low

WRI400 - Input Request to Enter:

This sets the polarity of the Request To Enter signal into the WRI400. Default is when the switch is closed and the WRI400 reads and reports a Request to Enter.

Active Open/Active Close

WRI400 - Input Request to Exit: Active

This sets the polarity of the Request To Exit signal into the WRI400. Default is when the switch is closed and the WRI400 reads and reports a Request to Exit.

Open/Active Close

Reader 1 Tamper: Active Open/Active

This sets the polarity of the Reader 1 Tamper signal into the WRI400. Default is when the switch is closed and the WRI400 reads and reports a Reader 1 Tamper.

Closed

Reader 2 Tamper: Active Open/Active

This sets the polarity of the Reader 2 Tamper signal into the WRI400. Default is when the switch is closed and the WRI400 reads and reports a Reader 2 Tamper.

Closed

Door Position Switch (DPS): Active Open/

EDIT Tab (cont.)

Active Closed

This sets the polarity of the Door Position Switch (DPS) signal into the WRI400. Default is when the switch is closed and the WRI400 reads and reports the door closed.

First, Delay, Retry First: First query the WRI400 makes to a PIM400 occurs immediately following

presentation of a credential. This parameter is the amount of time, in milliseconds a WRI400 should wait before making its second query to a PIM400. This setting should be slightly greater than the fastest response time from the access control panel or host to any message originated by the WRI400. This optimizes battery life and system performance.

Delay: The idle time between subsequent queries. Shorter delays may reduce latency, but also decrease battery life. Longer delays may enhance battery life.

Retry: The maximum number of times the WRI400 queries a PIM400 before it goes back to sleep. The number of retries should be slightly greater than the longest response time from the access control panel or host. Retries = [{Max Response Time of Panel - First} / Delay] +1

Degraded (Cache) Mode: Card Bit

Enter the number of bits on the cards being used to enable degraded mode.abilities. 0 = cache mode disabled

Format

Degraded (Cache) Mode: Full Card Number or Facility

Use the full card number or the facility codes of previously approved credentials in the Degraded (Cache) mode. Granting access is determined by “Full Card” content or just “Facility Code”.

Code

Degraded (Cache) Mode: Purge unused

When enabled, deletes the cache entry aer 5 days of non-use. If enabled, cards that have not accessed the lock within 5 days will be removed.

aer 5 days

Active High

Active Low

Active Close

Active close

First: 300 msec.

Delay: 200 msec.

Retry: 5 times

Full Card

Disabled

46 • Schlage • Schlage Utility Soware for Android User's Guide

WRI400

Controller PropertiesAD-Series Locks and Controllers

Degraded (Cache) Mode: PIM485 Card Removal

PIM400 -485, -VBB ONLY Only displayed when a PIM400−485 is connected. If disabled, both ACP’s refusing access (no access grant) and ACP’s explicit deny

access (Deny Access Command) will remove an entry. If enabled, only ACP’s explicit deny access command will remove an entry from the cache.

Degraded (Cache) Mode: Clear Cache

Deletes all valid user credentials from the Degraded (cache) memory. Allows you to manually clear cache memory.

Max Entries Stored Number of credential cards or facility codes maintained in the cache. Minimum of 5,

Maximum of 1000

ACP Timeout Time (in seconds) to wait before determining communication from the access control

panel has failed.

Wakeup Status Displays the time, in seconds, the WRI400 listens for Wakeup on Radio broadcasts

from its linked PIM400.

Strike Relay: Normally Open

(Secure)

EDIT Tab (cont.)

Normally Closed

When Normally-closed (Secure), the normally-closed side of the relay is the secure side. (Needs to read a valid credential before changing the relay polarity.)

(Secure)

Aux Relay: Normally Open

(Secure)

When Normally-closed (Secure), the normally-closed side of the relay is the secure side. (The auxiliary relay polarity will change as soon as saved, a credential is not required.)

Normally Closed (Secure)

Keys Buffered 4

Reader 1 Facility Code 1

Reader2 Facility Code 1

Disabled

n/a

125

10 seconds

Disabled

Normally Closed (Secure)

CT5000

Property Description

Lock Name The name of the CT5000. Set by the door ﬁle programmed into the CT5000.

Date & Time Current date and time. Initialized/set by the mobile device.

General Properties

Model Model number of the CT5000 connected to the mobile device.

Max Users Number of Users supported by the CT5000.

Max Audits Number of audits supported by the CT5000.

Power Status Current voltage level of the Coin Cell battery.

CT5000

VIEW Tab

Serial Number Serial number that uniquely identiﬁes the CT5000.

Manufacture Date Date the CT5000 was manufactured.

Days Since Installed Used for warranty purposes; marks the beginning of the CT5000 functional life.

Firmware Version Version of the current ﬁrmware ﬁle. Automatically updated when new ﬁrmware ﬁle is loaded.

Hardware Version Current version of the printed circuit main board.

Bootloader Version Version of the current bootloader. Allows new ﬁrmware to be loaded.

47 • Schlage • Schlage Utility Soware for Android User's Guide

Controller PropertiesAD-Series Locks and Controllers

CT5000

Property Description Default

Lock Type Classroom: Unlocks when a credential is presented and then automatically locks aer

the relock delay has expired. The CT5000 can only be Classroom Type.

PIN Length Maximum number of digits in the user PIN. Range of 3 to 6 digits. 6

Ignore Keypad If checked, key entry codes are ignored. Disabled

Relock Delay Amount of time before the CT5000 relocks aer being unlocked by a user presenting

a valid credential or the Request to Exit being released.

CT5000-Input Request to Exit: Active

This sets the polarity of the Request To Exit signal into the CT5000. Default is when the switch is closed and the CT5000 reads and reports a Request to Exit.

Open/Active Closed

CT5000-Input Reader Tamper 1:

This sets the polarity of the Reader 1 Tamper signal into the CT5000. Default is when the switch is closed and the CT5000 reads and reports a Reader 1 Tamper.

Active Open/Active Closed

CT5000-Input Reader Tamper 2:

This sets the polarity of the Reader 2 Tamper signal into the CT5000. Default is when the switch is closed and the CT5000 reads and reports a Reader 2 Tamper.

Active Open/Active Closed

Door Position Switch (DPS): Installed

If unchecked, the Door Position Switch (DPS) is disabled and the Door Prop Delay, Anti-Tailgate, Request to Exit Clears Alarm, and Alarm are also disabled.

By default, the CT5000 assumes there is no Door Position Switch (DPS) connected.

Door Position Switch (DPS): Active Open/ Active Closed

Door Prop Delay The Prop Delay setting is the time to allow the door to be held open before the alarm

EDIT Tab

This sets the polarity of the Door Position Switch (DPS) signal into the CT5000 (Open or Closed). Default is when the switch is closed and the CT5000 reads and reports the door closed.

relay triggers the alarm.

Door Prop Delay: Enabled/Disabled

When enabled, the alarm relay will activate aer the door has been open more time than the number of seconds speciﬁed in the Door Prop Delay time.

Anti-Tailgate Anti-Tailgate is designed to automatically relock the door when the door re-closes, no

matter how much time is le on the relock delay (requires a Door Position Switch).

Request to Exit Clears

During an alarm event, enabling request to exit disables the alarm. Disabled

Alarm

Alarm Relay: Normally Open

(Secure)

When Normally-closed (Secure), the normally-closed side of the relay is the secure side. (The alarm relay polarity will change as soon as saved, a credential is not required.)

Normally Closed (Secure)

Aux Relay: Normally Open

(Secure) Normally

When Normally-closed (Secure), the normally-closed side of the relay is the secure side. (The auxiliary relay polarity will change as soon as saved, a credential is not required.)

Closed (Secure)

Strike Relay: Normally Open

When Normally-closed (Secure), the normally-closed side of the relay is the secure

side. (Needs to read a valid credential before changing the relay polarity.) (Secure) Normally Closed (Secure)

Coin Cell Nuisance Delay

Classroom

3 seconds

Active close

Disabled

Active Open

30 seconds

Disabled

Normally Closed (Secure)

Enabled (checked)

48 • Schlage • Schlage Utility Soware for Android User's Guide

CO-Series Locks

Supported Locks

Î Not supported in version 1.0. Support is planned in future versions.

All chassis for the following models are supported.

CO-Series Locks

CO-200 CO-220 CO-250

This function works with CO-Series devices only.

The mobile device will use a default Coupling Password (123456) when coupling with a device. The Coupling Password should be changed to provide increased security for your locks. See

Coupling Password

on page 14 for more information.

If a device is not in Coupling mode, SUS-A will display a device speciﬁc message with instructions for placing the device into Coupling mode.

Couple mobile device to Lock

CO-Series locks can be coupled, or authenticated, with the mobile device. This provides enhanced security by ensuring that the lock will only communicate with mobile device to which it has been coupled. Once the lock has been coupled, the coupling password is passed to the device from the mobile device during programming. Each lock will retain only one coupling password; therefore, only one mobile device can be coupled with the lock.

Î mobile devices with the same coupling password can program the same devices. Each mobile

device with a different coupling password must be coupled with each device it will program.

1 Connect the mobile device to the lock using the SUS-A cable.

2 Insert the mechanical key into the lock. Then rotate and hold the key.

3 Continue holding the key and press the Schlage button three (3) times. Then release the key.

4 On the mobile device, select Device Options.

5 On the mobile device, select Couple mobile device to Device.

6 When Coupling is successful, a message will be displayed on the screen.

Program a Lock

1 Connect the mobile device to the lock or controller and establish communication between the

mobile device and the device.

2 Select Device Options.

3 Select Program Lock.

4 Select the door ﬁle that should be associated with the lock or controller.

Î Door ﬁles are downloaded to the mobile device when synchronized with the access control

soware.

5 Select OK.

49 • Schlage • Schlage Utility Soware for Android User's Guide

Collect Audits

Collect AuditsCO-Series Locks

Collecting audits on the mobile device does not delete the audits from a lock.

Collected audits will be transferred from mobile device to your Access Control Soware the next time they are synchronized.

When Auto Update is enabled, as soon as the Schlage button is pressed twice and the communication with the Schlage Utility Soware starts, the lock will automatically:

• update lock’s date/time

• collect audits

• update access rights

When Manual Update is enabled, follow the steps below to collect audits and update the lock access rights.

Î See Audit Retrieval Mode on page 13 for more information.

Collect Audits when Date/Time and Lock Access Rights are Up-to-Date

1 Conﬁrm mobile device is connected to lock.

Î See Transferring Door and Audit Files on page 10 for more information.

2 Double-click the displayed name of the connected lock.

3 The audit collection will begin.

Î If no previous audit exists, skip to step 7.

4 If a previous audit exists, a message will appear asking to overwrite previous audit. Click YES to

override audits and skip to step 7.

5 Click NO if you do not want to override the audit.

6 Acknowledge the message advising to synchronize the lock with system soware. Audit collection

will be stopped.

7 A progress indicator will be displayed while the audit is being collected.

A message will be displayed once the process is complete.

Collect Audits when Date/Time and Lock Access Rights are Not Up-to-Date

1 Conﬁrm mobile device is connected to lock.

Î See Connecting the Mobile Device on page 9 for more information.

2 Double-click the displayed name of the connected lock.

3 When asked to update date and time of the device, click YES. A progress indicator will be

displayed while date and time is being updated.

4 A message will appear to conﬁrm the successful update.

5 The audit collection will begin. A progress indicator will be displayed while the audit is being

collected.

6 The access rights update will begin. A progress indicator will be displayed while lock is being

updated.

7 A message will be displayed once the process is complete.

View Properties

1 Connect the mobile device to the lock or controller.

2 Select Device Options.

3 Select Properties for the connected device.

4 The View tab will be displayed.

Î See Lock Properties on page 52 for more information.

50 • Schlage • Schlage Utility Soware for Android User's Guide

Edit Properties

1 Connect the mobile device to the device.

2 Select Device Options.

3 Select Properties for the connected device.

4 Select the Edit tab.

5 Edit the properties as desired.

Î See Lock Properties on page 52 for more information.

6 Select Save before exiting the tab.

View Reader Properties

1 Connect the mobile device to the device.

2 Select Device Options.

3 Select Properties for the connected device.

4 Select the Reader tab.

Î See Lock Properties on page 52 for more information.

Edit PropertiesCO-Series Locks

Edit Reader Properties

1 Connect the mobile device to the device.

2 Select Device Options.

3 Select Properties for the connected device.

4 Select the Reader tab.

5 Edit the properties as desired.

6 Select Save before exiting the tab.

Î See Lock Properties on page 52 for more information.

Update Firmware

Î See Updating Firmware on page 11 for more information.

51 • Schlage • Schlage Utility Soware for Android User's Guide

Lock Properties

CO-200/220/250

Property Description

Lock Name The name of the Lock. Set by the door ﬁle programmed into the lock.

Date & Time Current date and time. Initialized/set by the mobile device.

General Properties

Model Model number of the device connected to the mobile device.

Max Users Number of Users supported by the lock (CO-200/220)

Max Void List Number of void users supported by the lock (CO-250)

Max Audits Number of Audits supported by the lock.

Power Status Current voltage level of the AA and Coin Cell batteries.

Main Lock

VIEW Tab

Serial Number Serial number that uniquely identiﬁes the lock.

Manufacture Date Date the lock was manufactured.

Days since Installed Used for warranty purposes; marks the beginning of the lock’s functional life.

Firmware Version Version of the current ﬁrmware ﬁle. Automatically updated when new ﬁrmware ﬁle is loaded.

Hardware Version Current version of the printed circuit main board.

Bootloader Version Version of the current bootloader. Allows new ﬁrmware to be loaded.

Credential Reader

Reader Type Type of Reader installed: Keypad, MagInsert, MagSwipe, Proximity, and Keypad Variations

Property Description Default

Lock Type Classroom Security (CO-220 Only): Allows lock to be placed into secure lockdown

by the a paired fob. Once in lockdown, only a Passthrough credential can be used to

gain access.

Oce: Unlocks when a credential is presented and then automatically locks aer the

relock delay has expired. To keep the door unlocked, push the button on the inside.

The button will momentarily illuminate green. To return the lock to the locked state,

push the button again or present a credential to the outside.

Privacy: To initiate the Privacy function, with the door closed, push the button on the

inside of the door. This prevents normal credentials from opening the door from the

outside.

The lock will go back to its normal state when the button is pushed again or when the

door position switch indicates that the door has opened.

When using a Mortise Deadbolt, extending the deadbolt from the inside lights a

red LED on the inside trim and initiates the Privacy function which prevents normal

credentials from opening the door from the outside. The lock can always be opened

EDIT Tab

PIN Length (CO-200/220 only)

Allow Privacy Mode Override (CO-250 only)

Ignore Keypad If checked, key entry codes are ignored. Disabled

Record Lock/Unlock1If checked and supported by the system soware, will record an audit event when the

using a Pass-Through credential or mechanical key in case of emergency.

Storeroom: Lockset is normally secure. Inside lever always allows free egress. Valid

Toggle credentials may be used to alternate (toggle) the state of the lock between

passage (unlocked) and secured (locked). Unlocks when a normal credential is

presented and then automatically locks aer the relock delay has expired.

Maximum number of digits in the user PIN. Range of 3 to 6 digits. 6

When enabled, allows cards override a lock that has been placed in privacy mode.

When disabled, only cards speciﬁcally assigned to this door will have access.

Inside Push button is pressed.

Lock PropertiesCO-Series Locks

Set by the Factory

Disabled

52 • Schlage • Schlage Utility Soware for Android User's Guide

Lock PropertiesCO-Series Locks

CO-200/220/250

Battery Fail Mode Lock state set when battery fails. As-Is, Secure/Locked, Unsecure/Unlocked As-Is

Coin Cell Battery Nuisance Delay

Lock state set aer coin cell battery replacement. If unchecked, nuisance delay is

disabled.

Relock Delay Amount of time before the lock relocks aer being unlocked by a user presenting a

valid credential.

ADA Delay (CO-250) Amount of time before the lock relocks aer being unlocked by a user who is ﬂagged

as handicapped and presenting a valid credential. Can be changed in the access

control system.

IPB Control User can select any one IPB functionality from the options:

Normal Operation: This option is used to disable all other IPB Control conﬁgurations.

This is the default option for IPB control conﬁgurations. This conﬁguration is available

on CO-200 and CO-250.

Blink Interior Button LED when locked: The IPB will ﬂash every 15 seconds for the

EDIT Tab (Cont.)

ﬁrst 10 minutes; it will then ﬂash every 30 seconds for the next 50 minutes; and it will

then ﬂash every minute aer 1 hour. If a door actuation occurs, then the process is

restarted. This conﬁguration is available on CO-200 and CO-250.

Occupancy Indicator Fast Blink: If selected, Occupancy Indicator Fast Blink is

enabled on the lock. This conﬁguration is only available on CO-200.

Occupancy Indicator Slow Blink: If selected, Occupancy Indicator Slow Blink is

enabled on the lock. This conﬁguration is only available on CO-200.

Oine Lockdown Mode: If selected, Oine Lockdown Mode is enabled on the lock.

This conﬁguration is only available on CO-200.

Property Description Default

Prox in Use Proximity credential card types allowed. Selections: HID/KantechIO, GE/CACY, AWID ALL selected

Mag Track in Use Magnetic card track that access data is to be read from. Track 1, 2 or 3 (Track 1 not

conﬁgurable for CO-200)

Enable Low Power

READER Tab

Wake-Up

Active when Mag Track 1 or 3 is selected in "Mag Track in Use". By enabling Low Power

Wake-Up and recording data on track 2, this option will allow longer battery life.

Beeper Indicates if the Beeper is on or off. ON

Disabled (unchecked)

Normal Operation

Track 2

Enabled

53 • Schlage • Schlage Utility Soware for Android User's Guide

Legacy Locks

Supported Legacy Locks

KC2

Program a Lock or Controller

1 Connect the mobile device to the lock using the HH-Serial Cable and CIP if using the BM150. Both

2 Select Device Options.

3 Select Program Lock.

4 Select the door ﬁle that should be associated with the lock.

5 Select OK.

6 Wait for the screen asking for the programming credential. Then present the programming

7 Select OK. Lock programming will begin.

Î Only BE367 and FE210 are supported in version 1.0.

BE367

FE210

the BM-150 and BM-170 can also use the HH-2PIN Serial Cable.

Î See Connecting the Mobile Device on page 9 for more information.

Î Door ﬁles are downloaded to the mobile device when synchronized with the access control

soware.

credential to the lock.

Î The lock will ﬂash red and green alternating several times, indicating it has entered

programming mode.

Î Consult the lock user guide that came with your lock for more information about

programming mode.

54 • Schlage • Schlage Utility Soware for Android User's Guide

Collect Audits and Update a Lock

Collect Audits and Update a LockLegacy Locks

Collecting audits on the mobile device does not delete the audits from a lock.

Collected audits will be transferred from mobile device to your Access Control Soware the next time they are synchronized.

All non-lock legacy controllers require the null converter (PIMWA-CV). See

Connecting the Mobile Device on

page 9 for more information.

When Auto Update is enabled, as soon as the Schlage button is pressed twice and the communication with the Schlage Utility Soware starts, the lock will automatically update lock’s date/time, collect audits and update access rights.

When Manual Update is enabled, follow the steps below to collect audits and update the lock access rights.

Î See Connecting the Mobile Device on page 9 for more information.

Collect Audits when Date/Time and Lock Access Rights are Up-to-Date

1 Conﬁrm mobile device is connected to lock.

Î See Connecting the Mobile Device on page 9 for more information.

2 Double-click the displayed name of the connected lock.

3 The audit collection will begin.

Î If no previous audit exists, skip to step 7.

4 If a previous audit exists, a message will appear asking to overwrite previous audit. Click YES to

override audits and skip to step 7.

5 Click NO if you do not want to override the audit.

6 Acknowledge the message advising to synchronize the lock with system soware. Audit collection

will be stopped.

7 A progress indicator will be displayed while the audit is being collected.

A message will be displayed once the process is complete.

Collect Audits when Date/Time and Lock Access Rights are Not Up-to-Date

1 Conﬁrm mobile device is connected to lock.

Î See Connecting the Mobile Device on page 9 for more information.

2 Double-click the displayed name of the connected lock.

3 When asked to update date and time of the device, click YES.

4 When asked for a valid programming credential, present the credential and then click OK. A

progress indicator will be displayed while date and time is being updated.

5 A message will appear to conﬁrm the successful update.

6 When asked for a valid programming credential (second time), present the credential and then

click OK. The audit collection will begin. A progress indicator will be displayed while the audit is

being collected.

7 The access rights update will begin. A progress indicator will be displayed while lock is being

updated.

8 A message will be displayed once the process is complete.

View Properties

1 Connect the mobile device to the lock or controller.

2 Select Device Options.

3 Select Properties for the connected device.

4 The View tab will be displayed.

Î See Lock Properties on page 57 for more information.

55 • Schlage • Schlage Utility Soware for Android User's Guide

Edit PropertiesLegacy Locks

Edit Properties

1 Connect the mobile device to the lock or controller.

Î See Connecting the Mobile Device on page 9 for more information.

2 Select Device Options.

3 Select Properties for the connected device.

4 Select the Edit tab.

5 Edit the properties as desired.

Î See Lock Properties on page 57 for more information.

6 Select Save.

7 Wait for the screen asking for the programming credential. Then present the programming

credential to the lock.

Î The lock will ﬂash red and green alternating several times, indicating it has entered

programming mode.

Î Consult the lock user guide that came with your lock for more information about

programming mode.

8 Select OK. Lock properties will be saved.

Update Firmware

Consult the directions that came with your lock for information about entering programming mode.

1 Connect the mobile device to the device you want to update.

Î See Connecting the Mobile Device on page 9 for more information.

2 Select Device Options.

3 Select Firmware Update.

4 Select the desired ﬁrmware ﬁle from the list.

Î Firmware updates are available at www.schlage.com/support to be downloaded to the

computer that synchronizes with the mobile device. See Transferring Door and Audit Files

on page 10 for details on how to obtain ﬁrmware ﬁles online and update to the mobile

device.

5 Select OK at the bottom of the screen.

6 Wait for the screen asking for the programming credential. Then present the programming

credential to the device.

Î The lock will ﬂash red and green alternating several times, indicating it has entered

programming mode.

Î Consult the lock user guide that came with your lock for more information about

programming mode.

7 Select OK to proceed when prompted.

8 A progress indicator will be displayed during the ﬁrmware update. A message will be displayed

brieﬂy once the ﬁrmware update is complete.

Î Updating Lock ﬁrmware will require the user to reset the lock before proceeding. See Change

Lock Class on page 66 for more information.

56 • Schlage • Schlage Utility Soware for Android User's Guide

Demo modeLegacy Locks

Demo mode

Test Mode can be used for troubleshooting.

1 Connect the mobile device to the controller.

Î See Connecting the Mobile Device on page 9 for more information.

2 Select Device Options.

3 Select Demo mode.

Lock Properties

Property Description Editable?

Lock Name Name of the Lock

Can be edited in the access control system.

Firmware Version Version of the current ﬁrmware ﬁle

Automatically updated when a new ﬁrmware version is loaded.

Date & Time Current date and time Lock setting Yes

Relock Delay Amount of time before the lock relocks aer being unlocked

by a user presenting a valid credential

Prop Delay Amount of time a door can be open before the prop delay

alarm is activated

Yes

57 • Schlage • Schlage Utility Soware for Android User's Guide

Troubleshooting

General Troubleshooting

If you are having trouble with the SUS-A and/or the mobile device, please check the following before contacting customer support:

Component Problem Solution

Cable SUS-A is not communicating with

PC and mobile device

System PIM400 and Access Control

the lock/component.

Firmware ﬁles are not available in the Update Firmware menu.

SUS-A is not running properly or is intermittent.

The mobile device will not transfer ﬁles.

Panel are not communicating.

mobile device goes to sleep while connected to a CO Lock.

The SUS-A cable must be properly connected to the lock and the mobile device. See Connection

Examples on page 13 for more information.

Make sure the ﬁles have been copied to the Schlage

Utility Software folder in the mobile device.

Make sure the mobile device has adequate memory available.

Enable ﬁle tranfer on the mobile device. See Enable

File Transfer on page 62 for more information.

mobile device must not be connected to either the AD-400 or the PIM400. Disconnect the mobile device from hardware prior to testing system.

Wake the device up and press the Schlage button four (4) times to resume communication.

Error Codes

No. Error Solution

E100 Enter a valid password No password was entered. Enter the correct password.

E101 Incorrect password The password entered was incorrect. Enter the correct

password.

E102 Incorrect password entered three

times. Wait for 30 seconds before next retry

E103 The old password is incorrect When attempting to change the password, the old

E104 Password ﬁeld cannot be le blank When attempting to change the password, no

E105 Password must be at least 4 characters When attempting to change the password, the

E106 Passwords do not match When attempting to change the password, the second

E107 Old password and new password are

identical

No Device Connected The Options menu was tapped when no lock was

E201 This device is not connected A device name, other than the device to which the

An incorrect password was entered three times. Wait thirty (30) seconds. Then enter the correct password.

password entered was incorrect.

password was entered.

password entered was too short.

password entered did not match the ﬁrst password entered.

When attempting to change the password, both passwords are the same. The new password must be different.

connected to the mobile device. Connect the mobile device to a device and try again.

mobile device is currently connected, was selected and then the Options menu item was tapped. Options can be viewed only for the lock that is currently connected.

58 • Schlage • Schlage Utility Soware for Android User's Guide

Error CodesTroubleshooting

Error Codes

No. Error Solution

E202 Unrecognized device connected or

incompatible SUS version. Please visit www.schlage.com/support to download the latest SUS version and try again

E300 Collecting audit failed The mobile device was disconnected from the lock

E301 Synchronizing lock data failed The mobile device was disconnected from the lock

E302 Updating lock’s date and time failed The mobile device was disconnected from the lock

E303 Your mobile device is not authenticated

to perform this action. Couple mobile device with the device to authenticate

E304 Retrieving lock properties failed The mobile device was disconnected from the lock

E305 Retrieving PIB properties failed The mobile device was disconnected from the PIB300

E306 Retrieving PIM properties failed The mobile device was disconnected from the

E307 Retrieving door properties failed The mobile device was disconnected from the Door

E400 Data ﬁles for French language are

missing

E401 Data ﬁles for Spanish language are

missing

E500 Please set the Relock delay and Prop

delay

SUS is unable to recognize this device. The version of SUS on the handheld is currently incompatible with this device. Please visit www.schlage.com/support to download the latest SUS version and try again.

before audit collection was complete. The mobile device must remain connected to the lock until collection is complete.

before synchronization was complete. The mobile device must remain connected to the device until synchronization is complete. OR

No valid programming credential was presented to the lock. A valid programming credential must be presented before the device can be programmed.

before date/time update was complete. The mobile device must remain connected to the device until date/ time update is complete. OR

No valid programming credential was presented to the lock. A valid programming credential must be presented before the date/time can be updated.

This message appears when the device is not coupled with the mobile device and an action requiring authentication was performed (feature change, ﬁrmware update, lock synchronization, etc.).

before the Retrieving Properties process was complete. The mobile device must remain connected to the lock until the process is complete.

before the Retrieving Properties process was complete. The mobile device must remain connected to the PIB300 until the process is complete.

PIM400/401 or Legacy PIM before the Retrieving Properties process was complete. The mobile device must remain connected to the PIM400/401 or Legacy PIM until the process is complete.

before the Retrieving Properties process was complete. The mobile device must remain connected to the Door until the process is complete.

When attempting to change the language to French, the French language ﬁles cannot be found. Contact customer support.

When attempting to change the language to Spanish, the Spanish language ﬁles cannot be found. Contact customer support.

The relock delay and prop delay must be greater than zero (0). Change the delay(s) to a value greater than zero (0).

59 • Schlage • Schlage Utility Soware for Android User's Guide

Error CodesTroubleshooting

Error Codes

No. Error Solution

Lock1 and Lock2 address cannot be identical

E502 Saving properties failed The mobile device was disconnected from the lock

E503 The Unique ID should be in range 0 -

65535

E504 The Unique ID should be in range

1-65534

E505 The RS485 address should be in range

0- 254

E506 The Relock Delay value should be in

range 0- 255

E507 Reserved address 170 cannot not be

used for RS485 address

E508 Difference between high door and low

door cannot be equal or greater than 16

E509 High door cannot be lesser than low

address

E510 The ADA Delay value should be in range

0- 255

E600 Please select the ﬁrmware ﬁle No ﬁrmware ﬁle was selected before the OK menu

E601 Updating ﬁrmware failed The mobile device was disconnected from the lock

E602 No ﬁles to select The mobile device does not have any ﬁles to select

E603 File integrity check failed While updating Firmware or Programming a lock,

E604 Cannot open ﬁle

E605 Cannot read ﬁle

E606 Invalid ﬁle

The Save menu item was tapped but no values were changed. Change at least one value, or tap back to cancel.

before the saving properties function was complete. The mobile device must remain connected to the lock until the saving properties process is complete. OR

No valid programming credential was presented to the lock. A valid programming credential must be presented before the properties can be saved.

The PIM400 or Legacy PIM address entered was greater than 65535. Enter a value less than 65535 and try again.

The PIM400 or Legacy PIM address is incorrect. Enter a value less than 65535 and try again.

The RS485 address entered was greater than 254. Enter a value less than 254 and try again.

The Relock Delay entered was greater than 255. Enter a value less than 255 and try again.

The RS485 address entered is incorrect. Enter a value less than 254 and different than 170.

While setting the addresses of the Low and High doors make sure that the difference between both is less than 16.

The address of the High door MUST be greater than the Low door.

The ADA Delay entered was greater than 255. Enter a value less than 255 and try again.

item was tapped when attempting to update the lock’s ﬁrmware. Select a ﬁrmware ﬁle and try again.

before the ﬁrmware update was complete. The mobile device must remain connected to the lock until the ﬁrmware update is complete.

No valid programming credential was presented to the lock. A valid programming credential must be presented before the ﬁrmware update can be done.

SUS may need to be updated in order to perform ﬁrmware updates to this device. Please check

www.schlage.com/support for the latest version.

from or they were put in the incorrect folder.

the SUS soware detected that the ﬁle being used is corrupted. Download/Create the ﬁle again and upload it into the mobile device.

60 • Schlage • Schlage Utility Soware for Android User's Guide

Error CodesTroubleshooting

Error Codes

No. Error Solution

E607 Please select the lock class ﬁle While attempting to change a lock class, inside the

Firmware Package Screen – no selections were made. Select a lock class and try again.

E700 Please select the door While attempting to program a lock, no door was

selected. Select a door and try again.

E701 Programming lock failed The mobile device was disconnected from the lock

before the lock setup was complete. The mobile device must remain connected to the lock until the lock setup is complete.

No valid programming credential was presented to the lock. A valid programming credential must be presented before the lock can be set up.

E702 The door ﬁle is invalid due to incorrect

data present; for example, blank lines. This can occur for multiple reasons, including manually editing the door ﬁle.

E703 Door ﬁle contains invalid data for the

AD200 lock model. Verify the correct lock and door ﬁles are selected or regenerate the door ﬁle and try again. Click OK to continue.

E704 The selected Door ﬁle contains format

errors. Click OK to Continue or Cancel to exit and try again using a new door ﬁle.

E800 Device is not in coupling mode AD series: Hold down the Interior Push Button and

E801 Lock not responding correctly Verify cable is properly connected to lock.

E802 Device does not support this action

E810 Saving from device failed. Please try again.

Use SMS to regenerate the door ﬁle & load the new door ﬁle into the SUS. Then retry programming.

The Doorﬁle used contains IButton Data. This data is not valid for an AD200 Lock. Ensure the correct door/ doorﬁle is selected or regenerate the doorﬁle.

The doorﬁle contains errors that may interfere with normal operation. Programming is allowed to proceed if OK is selected. It is recommended that the doorﬁle be generated again by the access soware in order to ensure the expected function of the lock.

press the Tamper switch (sw1) 3 times. PIM400/PIB300 devices: Hold down LINK1 switch (s2)

and press LINK2 switch (s3) 3 times. CO Series: Rotate mechanical key and hold while

pressing Schlage button 3 times. WRI400/CT5000 devices: Hold down the SCHLAGE

switch (s1) and press the LINK switch (s2) 3 times. WPR400: Hold down the IPB switch (s2) and press the

TMP switch (s3) 3 times. While trying to couple the mobile device with the

device, the message pops up when the connected device was not in coupling mode. Follow the instructions to put the connected device in coupling mode and try again.

If trying to program, verify Program Mode has been entered properly.

If programming a KC-2 Deadbolt for the ﬁrst time be sure the latch bolt is retracted.

While communicating with the lock, the SUS has detected some problems, follow the presented instructions to correct the problem.

61 • Schlage • Schlage Utility Soware for Android User's Guide

Enable File TransferTroubleshooting

Error Codes

No. Error Solution

E900 Cannot open or read ﬁle SUS was not able to read this ﬁle. If this was a ﬁrmware

package, SUS is currently incompatible with this ﬁrmware package. Please visit www.schlage.com/

support to download the latest SUS version and try

again.

Enable File Transfer

Some mobile devices are set to allow charging only via USB by default. If you connect your device to your PC and do not see any ﬁles in the ﬁle explorer, then your device is set for charging only. This must be changed to allow ﬁle transfer. You will likely have to perform these steps each time you reconnect your device.

1 Pull down from the top of

the screen to access the

notiﬁcation menu. You will

see a notiﬁcation for Android

System. If USB charging is

displayed, you must change

it to allow ﬁle transfer.

Tap on the notiﬁcation to

expand the item.

2 Tap the expanded item to

open the Settings menu.

3 Choose Transferring les

under Use USB for to allow for ﬁle transfer.

62 • Schlage • Schlage Utility Soware for Android User's Guide

Glossary

BCD

Acronym for Binary Coded Decimal, an encoding method for representing decimal numbers where each digit is represented by four bits.

CAC

Acronym for Common Access Card, a U.S. Department of Defense smart card issued as standard identiﬁcation, and for access to computers, networks and some facilities.

Cache Mode

How the reader will handle stored card information if there is loss of communication to its controller.

Card Conversion

Card data ﬁlters and converters that provide data that can be accepted by the access control system.

CM Lock

A Computer Managed oine lock, for example the Schlage CM 5500 series.

CSN

Acronym for the Card Serial Number, a unique, unencrypted identiﬁcation number contained on the integrated chip in each smart card.

DCS

Acronym for Dynamic channel switching - can be selected to decrease the chance of interference but will decrease battery life.

Delay

The idle time between subsequent queries. - Shorter delays may reduce latency. - Longer delays may enhance battery life.

Door Prop Delay

The time allowed between opening a Door and closing it. If the Door is open longer then the Door prop delay an alarm is released. The delay can be set individually for each Door and is programmed through the program ﬁles.

Extend Unlock

This setting is required to respond to scheduled unlocks from an access control panel.

Fail Safe/Secure

The condition of a lock or latch when a loss of RF communications occurs between the PIM400/401 or Legacy and an access point.

FASC-N

Acronym for Federal Agency Smart Credential Number, an identiﬁer used on all government issued credentials.

63 • Schlage • Schlage Utility Soware for Android User's Guide

FC Mode

Allows access by Facility (Site) code.

First

The ﬁrst query an access point makes to a PIM400/401 or Legacy PIM occurs immediately following a card swipe. - “First” is the amount of time, in milliseconds, an access point should wait before making its second query to a PIM400/401 or Legacy. This setting should be slightly greater than the fastest response time from the access control panel or host. This optimizes battery life and system performance.

GUI

Acronym for Graphical User Interface.

Heartbeat

The time interval that access points communicate to PIM400/401 or Legacy PIM when there is no activity. The Heartbeat is displayed in the format days, hours, minutes, seconds. Affects battery life.

Hi Lo Output

These settings control the PIM400/401-TD2 open collector outputs sent to an access control panel on detection of Request-to-Exit (RTX), Door Position Switch (DPS), and Trouble. The WPIM switches these signals between an open collector and ground state.

Glossary

Latch Type

Conﬁguration of an access point depending on lock or latch type issued or used.

Mode

Conﬁguration of an access point for standard operation or for factory testing.

No Purge

Reader will remember the ﬁrst 20 cards swiped for degraded mode access.

PIM

Acronym for Panel Interface Module.

PIV

Acronym for Personal Identiﬁcation Veriﬁcation, refers to control and security standards set by the National Institute of Standards and Technology (NIST) for Federal employees and long-term contractors.

Relatch Time

The interval between the unlocking and relocking of an access point. Controlled by the access point, not the host system.

Relock delay

The time span from unlocking a lock aer presenting a Credential until relocking. The relock delay can be set for each Door individually between 1 and 254 seconds. The relock delay setting is transferred to the lock through the program ﬁle.

TSA

Acronym for Transportation Security Administration.

64 • Schlage • Schlage Utility Soware for Android User's Guide

TSM

Acronym for Transaction Status Message.

TWIC

Acronym for Transportation Worker Indentiﬁcation Credential.

Request to Exit

Whenever a Door is opened from the safe side a request to exit is required. In the simplest version this means operating a mechanism that unlocks the door (for example turning the doorknob). Most electronic locks use a switch to detect a request to exit. This can be a passive infrared sensor, a push button, an electronic exit bar, or the doorknob contact itself. This switch has either a normally open or a normally closed contact. Based on this conﬁguration the system has to be set up correctly, otherwise a request is permanently reported unless someone activates the switch.

Retry

The maximum number of times an access point queries a PIM400/401 or Legacy PIM before the access point goes back to sleep The number of retries should be slightly greater than the longest response time from the access control panel or host.

Rxt

Determines whether the access point module queries for unlock authorization on a Request to Exit activation.

Glossary

Rxt Sift

Determines whether a WA56XX or WA993 reports Request to Exit activations in unlocked state.

UID

Acronym for the Unique Identiﬁer, a unique, unencrypted identiﬁcation number contained on the integrated chip in each smart card. (May also be referred to as CSN.)

WAPM

Acronym for Wireless Access Point Module.

65 • Schlage • Schlage Utility Soware for Android User's Guide

Change Lock Class

AD-Series Locks

66 • Schlage • Schlage Utility Soware for Android User's Guide

Import/Export Conﬁguration

About Import/Export Conﬁguration Feature

The Schlage Utility Soware for Android (SUS-A) includes the Import/Export Conﬁguration feature.

Users may quickly change and copy “Device Properties” settings across multiple devices so that a group of devices may have the exact same settings applied.

An Import/Export Conﬁguration ﬁle may be initiated from and copied to locks and devices, saved on the mobile device, transferred to another mobile device, and saved to a computer or network drive.

Supported Locks and Accessories

AD-200

AD-250

AD-300

AD-400

WRI400

WPR400

CT5000

PIB300

PIM400-TD2

PIM400-485

CO-200

CO-220

CO-250

Prerequisites

• The mobile device used must be coupled before the Import/Export Conﬁguration ﬁle may be saved or retrieved. See Connecting the Mobile Device on page 9 for more information.

• The “source” lock or device must be installed and working as desired with all property settings conﬁgured as required by the user.

• The Import/Export Conﬁguration ﬁle can be saved and restored for a speciﬁc hardware class only. For example:

Î A Import/Export Conﬁguration created from an AD-200 Mag Swipe lock will not be

available when the SUS-A is communicating with an AD-200 Prox lock.

Î A Import/Export Conﬁguration created from an AD-200 Prox lock will not be available with

an AD-300 Prox lock.

Saving a Import/Export Conﬁguration will also capture the following device status parameters:

• Lock Firmware Version

• Reader Firmware Version

• Lock Serial number

• Reader Serial number

• Card Detection Firmware Version

• Boot Loader Version

• Days Since Installed

• AA Battery Pack Type

• AA Battery Voltage

• Coin Cell Voltage

This information is saved within the Import/Export Conﬁguration ﬁle, and can be viewed with any text viewer by the user.

67 • Schlage • Schlage Utility Soware for Android User's Guide

Create an Import/Export ConﬁgurationImport/Export Conﬁguration

When naming the Import/Export Conﬁguration, use normal Windows OS naming conventions.

Before copying, a Import/Export Conﬁguration ﬁle must be saved to the SUS-A /My Documents/ and must be a hardware conﬁguration match with the receiving device.

See Transferring

Device Template Export (.DTE) and Device Data log(. DDL) Files to PC on

page 11 for more information.

Create an Import/Export Conﬁguration

1 Connect the mobile device to the device with desired properties.

Î If the device properties have not been programmed, conﬁgure the device properties as

desired. Refer to AD-Series Lock Properties on page 22, or CO-Series Lock Properties on page 52.

2 Select Device Options.

3 Select Lock Properties for the connected device.

4 Select the Edit or Reader tab.

5 Select Import/Export Conguration at the bottom of the screen.

6 Select Save From Device to create a Import/Export Conﬁguration ﬁle from the properties of this

device.

7 Enter a name for the Import/Export Conﬁguration ﬁle.

Î The name should describe the device conﬁguration this Template is intended to work with

and clearly identify the hardware conﬁguration. (Example: AD200-PRK main entrances.)

8 Tap OK to save. The SUS-A will display the location of the saved Template ﬁle.

Copy a Saved Import/Export Conﬁguration

1 Connect the mobile device to the device that will receive the saved properties settings.

Î Be sure that the receiving device is of the same hardware conﬁguration as that of the source

of the Import/Export Conﬁguration. (See Prerequisites on page 67 for more information.)

2 Select Device Options.

3 Select Lock Properties for the connected device.

4 Select the Edit or Reader tab.

5 Select Import/Export Conguration at the bottom of the screen.

6 Select Save To Device to copy and save a Import/Export Conﬁguration ﬁle to the connected

device.

7 Select the Import/Export Conﬁguration ﬁle name.

Î If the Import/Export Conﬁguration name is not available, check to be sure that the receiving

device is of the same hardware conﬁguration as that of the source of the Import/Export Conﬁguration. (See Prerequisites on page 67 for more information.)

8 Tap OK to save.

9 Tap YES on the conﬁrmation window, then tap OK again to ﬁnish.

Î Saving an Import/Export Conﬁguration ﬁle to a PIM or PIB will require re-linking of all previously

linked devices

68 • Schlage • Schlage Utility Soware for Android User's Guide

Diagnostic Data Log

About Diagnostic Data Log Feature

This new feature provides a simple method for AD-Series customers to quickly gather and save important lockset information in a ﬁle. This Diagnostic Data ﬁle can then be shared with Technical Services for setup and conﬁguration review and for analysis of issues from the ﬁeld.

The Diagnostic Data ﬁle will store the device settings and status of the last 50 devices that were successfully connected. All information is then available for review while not actually connected with the device and can be saved off-line and sent to Technical Services for further analysis.

Prerequisites

• The mobile device used must be coupled before the Diagnostic Data Log ﬁle may be saved. See

Connecting the Mobile Device on page 9 for more information.

Diagnostic Data Log Menu

Î NOTE: CO-Series products and non-lock AD-Series products do not support the Diagnostic Data

Log feature

1 Schlage Utility Soware for Android (SUS-A) provides

a Device Options menu. This Diagnostic Data Log menu will be available when the SUS-A is connected and communicating with AD-Series locksets.

2 When the Diagnostic Data log menu is selected, the

customer must then provide a name for the ﬁle and then select “OK” to continue.

Î NOTE: Be sure to provide a suciently descriptive

name for the ﬁle so that you and others will know

which AD-Series device and location the ﬁle pertains to.

69 • Schlage • Schlage Utility Soware for Android User's Guide

Device Settings Menu

Enter a descriptive name

3 Next, the SUS-A will request all data from the

AD-Series device and save the ﬁle.

4 Once the ﬁle is generated, the customer should

copy and forward the Diagnostic Data ﬁle to Technical Services for detailed analysis.

Î See Transferring Device Template Export

(.DTE) and Device Data log(.DDL) Files to PC

on page 11 for more information.

Diagnostic Data Log MenuDiagnostic Data Log

Retrieving device data

70 • Schlage • Schlage Utility Soware for Android User's Guide

File ready for analysis

Index

AD-200 5, 6, 14, 21, 66 AD-201 5, 14 AD-250 5, 6, 14, 21, 66 AD-300 5, 6, 14, 25, 66 AD-301 14 AD-302 5, 14, 29, 31, 40 AD-400 5, 14, 29, 66 AD-401 14 AD-402 5, 14, 29, 31, 40 AD-Series Controllers 14

Edit Properties 50 Functions 6 PIM400 Link Mode 18 Program 16, 48 Properties 34 Supported 5, 14 View Properties 49

AD-Series Locks 14

Collect Audits 16 Edit Properties 50 Edit Reader Properties 50 Functions 6 Program 16, 48 Properties 21, 51 Supported 5, 14 View Properties 49 View Reader Properties 50

BE367 5, 6, 7, 9, 53

Cache Mode 62 Card Conversion 62 CIP 53 CL 6, 53 CL993 5 CL5100 5 CL5200 5 CL5500 5 CL5600 5 CM 6, 53, 62 CM993 5 CM5100 5 CM5200 5 CM5500 5 CM5600 5 CM5700 5 CM Lock 62 CO-200 5, 6, 48, 66 CO-220 5, 6, 48, 66 CO-250 5, 6, 48, 66 Copy

Device Template 67

Create

Device Template 67 CT500 5, 6 CT1000 5 CT5000 5, 6, 14, 66 Customer Service ii

DCS 62 Delay 62 Device Template

Copy 67

Create 67 Diagnostic Data Log 18, 68 Door Prop Delay 62

Fail Safe 62 Fail Secure 62 FC Mode 62 FE210 5, 6, 7, 9, 53 Files 10

Transfer and update 10 FIPS 5, 14, 29, 31, 40 FIPS201 5, 14, 29, 31, 40 FIPS201-1 5, 14, 29, 31, 40 FIPS201-2 5, 14, 29, 31, 40 Firmware 10

Update using mobile device 10

Update using PC 10 First 63

Glossary 62 GUI 63

Heartbeat 63 Hi Lo Output 63

Install

SUS-A 8

KC2 5, 6, 53 KC2-5100 5 KC2-5500 5 KC2-9000 5

Extend Unlock 62

71 • Schlage • Schlage Utility Soware for Android User's Guide

Index

Latch Type 63 Legacy Controllers

Demo Mode 56 Edit Properties 55 Functions 6 Program 53 Supported 5, 53 Update Firmware 55 View Properties 54

Legacy Locks

Collect Audits 54 Demo Mode 56 Edit Properties 55 Functions 6 Program 53 Properties 56 Supported 5, 53 Update Firmware 55 View Properties 54

Manager 8

Mobile device 9

AD-Series controllers 9 Connecting 9

AD-Series 9 CO-Series 9 Legacy BE367 9 Legacy CM and CL Locks 9 Legacy FE210 9

Update 10

Mode 63

Schlage Utility Soware

Language 13 Options 12 Programming Password 13 SUS Password 12

Schlage Utility Soware for Android

Install 8 Update 8

SUS-A

Install 8

Update 8 SUS Password 8, 12 Synchronization Soware 66

Transfer

Device conﬁguration 10

Diagnostic data log 10

Files 10 Troubleshooting 57

Update

Mobile Device 10

SUS-A 8

WAPM 6, 64 Warranty iii WPR400 5, 14, 34, 66 WRI400 5, 14, 66

No Purge 62

PIB300 5, 6, 14, 42, 66 PIM 6, 8, 15, 18, 29, 30, 37, 38, 62, 63, 64 PIM400 5, 6, 14, 15, 18, 30, 31, 35, 38, 39,

40 PIM400-485 66 PIM400-TD2 66 PIMWA-CV 54 Programming Password 8, 13, 14, 15, 48

Relatch Time 63 Relock delay 63 Request to Exit 64 Retry 64 Rxt 64 Rxt Si 64

72 • Schlage • Schlage Utility Soware for Android User's Guide

About Allegion

Allegion (NYSE: ALLE) creates peace of mind by pioneering safety and security. As a $2 billion provider of security solutions for homes and businesses, Allegion employs more than 7,800 people and sells products in more than 120 countries across the world. Allegion comprises 23 global brands, including strategic brands CISA®, Interﬂex®, LCN®, Schlage® and Von Duprin®.

For more, visit www.allegion.com.

www.allegion.com

Schlage Utility Software For Android Devices Ver. 1.0 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
