Sanyo VPC-AZ3 EX User Manual

INSTRUCTION MANUAL

VPC-AZ3EX VPC-AZ3

Digital Camera

Important note

This manual explains how to safely operate the VPC-AZ3EX and VPC-AZ3. Any information regarding only one of these products will be labeled as such.

Please read these instructions carefully before using the digital camera. Make sure to read and understand the section “USING YOUR DIGITAL CAMERA SAFELY AND CORRECTLY” on pages 7 to 23. Keep this manual in a safe place for later reference.

Warning

TO PREVENT THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE

FOR AMERICAN USERS

œ This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

œ Changes or modifications not expressly approved by the party responsible

for compliance could void the user’s authority to operate the equipment.

Tested to Comply with FCC Standards

FOR HOME OR OFFICE USE

Declaration of Conformity

Model Number : VPC-AZ3 Trade Name : SANYO Responsible party : SANYO FISHER COMPANY Address : 21605 Plummer Street, Chatsworth, California 91311 Telephone No. : (818) 998-7322

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation.

English

FOR CANADIAN USERS

œ This Class B digital apparatus complies with Canadian ICES-003.

English

OUTLINE OF OPERATION

To help you get started enjoying using your digital camera right away, given below is an outline of the fundamental operation, from setup to shooting to playback.

SETUP

Charge the battery pack (see pages 27 and 33).

Install the battery pack (see page 28).

3 Install the CompactFlash 4 Format the CompactFlash (see page 35).

NOTE

œ This camera uses a CompactFlash memory card

instead of photographic film to record images. Be sure to install the CompactFlash before operating the camera. A 16MB CompactFlash is supplied with this

camera

. A 32MB CompactFlash is also available as a

separately sold accessory.

SHOOTING

1 Take photos in the BASIC operation mode

œ See “Shooting in the BASIC mode” on page 42. œ See “BASIC MODE” on page 76.

(see page 28).

English

PLAYBACK

1 Set the playback mode (see page 83). 2 Play back the images.

œ See “PLAYING BACK STILL IMAGES” on page 85. œ See “PLAYING BACK SEQUENTIAL SHOTS” on page 87. œ See “PLAYING BACK VIDEO CLIPS” on page 88.

*1: About the CompactFlash

This digital camera can use both CompactFlash and Microdrive cards for data storage. This manual is written with the premise that CompactFlash cards are used. In this manual, CompactFlash and Microdrive cards are both referred to as “card”.

*2: Shooting in the BASIC mode

In the BASIC mode, the Scene Select function—whereby simply by selecting one from a short list of shooting conditions, the suitable settings are automatically completed—is available. Also, only the necessary shooting settings are displayed, making it easy even for the novice photographer to enjoy using this digital camera.

Symbols used in this manual

HINT Points that may prove useful when using the digital camera. NOTE Points giving some extended instructions or special points to

CAUTION Points that require special attention (see page xx) Refer to the page indicated for detailed information.

pay attention to.

English

CONTENTS

OUTLINE OF OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

USING YOUR DIGITAL CAMERA SAFELY AND CORRECTLY . . . . . . . 7

CAUTIONS CONCERNING HIGH TEMPERATURES . . . . . . . . . . . . . . 24

CHECKING THE INCLUDED ACCESSORIES . . . . . . . . . . . . . . . . . . . . 25

QUICK START FOR CAPTURING IMAGES. . . . . . . . . . . . . . . . . . . . . . 27

B PREPARATION

PARTS NAMES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

RECHARGING THE BATTERY PACK . . . . . . . . . . . . . . . . . . . . . . . . . . 33

FORMATTING A CARD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

TURNING THE POWER ON/OFF. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

SETTING SCREENS AND OPTION SETTING SCREENS . . . . . . . . . . 39

B CAPTURING IMAGES AND RECORDING SOUNDS

BEFORE TAKING PICTURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

SHOOTING/RECORDING MODE SETTINGS . . . . . . . . . . . . . . . . . . . . 59

CAPTURING STILL IMAGES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

SEQUENTIAL SHOTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

VIDEO CLIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

AUDIO RECORDINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

BASIC SHOOTING FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

BASIC MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

English

B PLAYBACK

PLAYBACK MODE SETTINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

PLAYING BACK STILL IMAGES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

PLAYING BACK SEQUENTIAL SHOTS . . . . . . . . . . . . . . . . . . . . . . . . . 87

PLAYING BACK VIDEO CLIPS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

LISTENING TO AUDIO RECORDINGS . . . . . . . . . . . . . . . . . . . . . . . . . 91

USING THE VARIOUS PLAYBACK FUNCTIONS . . . . . . . . . . . . . . . . . 93

DISPLAYING IMAGE INFORMATION (PLAYBACK INFO

SCREEN). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

B EXPERT MODE

ADDING A VOICE MEMO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

SETTING THE FOCUS MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102

LIGHT-MEASURING MODE SETTING. . . . . . . . . . . . . . . . . . . . . . . . . 103

WHITE BALANCE SETTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104

ISO SENSITIVITY SETTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106

SETTING THE EXPOSURE CONTROL . . . . . . . . . . . . . . . . . . . . . . . . 107

SETTING THE NOISE REDUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . 110

ADJUSTING THE COLOR TONES (REAL-COLOR EQUALIZER). . . . 111

DIGITAL ZOOM SETTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

QUICK SHOT SETTING (STILL IMAGE SHOOTING MODE

ONLY) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

EXPOSURE CORRECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122

FLICKER-REDUCTION SETTING (VIDEO CLIP SHOOTING

ONLY) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

SHOOTING SETTING INFORMATION DISPLAY (SHOOTING

INFO SCREEN). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124

English

CONTENTS

B OTHER FUNCTIONS

COPYING IMAGES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126

CHANGING IMAGE SIZE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127

ADDING TEXT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

ADDING A VOICE MEMO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133

PRINT SETTINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135

IMAGE PROTECT MODE (PREVENTING ACCIDENTAL

ERASURE) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143

ERASING DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145

IMAGE AND AUDIO DATA STORAGE . . . . . . . . . . . . . . . . . . . . . . . . . 148

USING THE CAMERA WITH A COMPUTER . . . . . . . . . . . . . . . . . . . . 150

USB DIRECT-PRINT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152

SETTING THE TV SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157

English

B CAMERA SETTINGS AND DISPLAYS

SETTING THE DATE AND TIME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158

SETTING THE OPERATIONAL SOUNDS . . . . . . . . . . . . . . . . . . . . . . 162

HELP FUNCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165

DISPLAY LANGUAGE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166

POWER SAVE MODE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167

ASSIGNING FILE NAMES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169

CHECKING THE REMAINING BATTERY PACK CHARGE . . . . . . . . . 171

CHECKING THE REMAINING CARD MEMORY . . . . . . . . . . . . . . . . . 173

B APPENDICES

TROUBLESHOOTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176

SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193

English

USING YOUR DIGITAL CAMERA SAFELY AND CORRECTLY

CONCERNING THE DIGITAL CAMERA

WARNING

B If the digital camera makes a strange noise, emits a strange

odor, or if smoke comes out from it, immediately turn off the power and remove the battery pack.

œ If the digital camera is used under these conditions, it may

cause a fire or electric shock. Immediately turn off the digital camera, remove the battery pack, and wait to make sure no more smoke comes from the digital camera. Then take it to the dealer for service. Do not try to repair or open the digital camera yourself.

B Do not modify or open the cabinet

œ High voltage circuits are inside, and there is a high risk of

fire or electric shock if they are touched. Any internal check, setting, or repair should be performed by the dealer.

B Do not use while driving

œ Do not capture images, play back images, or watch the

LCD monitor while driving a vehicle. Doing so may cause an accident.

œ Be careful where you put down the digital camera inside an

automobile. During sudden stops or turns it may fall behind the brake pedal and prevent braking.

œ When using the digital camera while walking, be very

careful of your surroundings and especially the traffic to avoid accidents.

B Be aware of your surroundings when using the digital

camera

œ Pay close attention to your surroundings when using the

digital camera. Failure to do so may lead to an accident or injury.

œ Do not use the digital camera inside an airplane or

elsewhere where its use may be restricted.

English

B Do not get the digital camera wet

œ This digital camera is not water-resistant. Do not allow it to

get wet, as doing so may cause a fire or electric shock.

œ Do not use the digital camera in a bathroom œ If the digital camera gets wet, immediately turn it off and

remove the battery pack. Then take it to a dealer for repair. Using the digital camera after it has been become wet may cause a fire, electric shock, or other accident.

B Do not use during a storm

œ To avoid the risk of being struck by lightning, do not use the

digital camera during a thunderstorm. In particular, if used in an open field, you have an increased chance of being struck by lightning. Quickly seek refuge in a place that will protect you from lightning.

B Do not place on an unstable surface

œ The digital camera may fall, resulting in damage to the

digital camera or injury.

œ If the digital camera has fallen and its body is damaged,

turn it off, remove the battery pack, and take it to the dealer for repair. Using the digital camera after its body has been damaged may cause a fire or electric shock.

B Do not look through the digital camera into the sun

œ Do not look through the digital camera at the sun or any

other strong source of light. Doing so may seriously injure your eyes.

B Do not use the flash close to a person’s face

œ To prevent possible eye injury, do not use the flash near a

person’s face (especially young children or babies). If the flash is used close to a person’s opened eyes, there is a risk that it may damage that person’s eyesight.

English

USING YOUR DIGITAL CAMERA SAFELY AND CORRECTLY

(CONCERNING THE DIGITAL CAMERA)

WARNING

B Do not use where there is risk of explosion

œ Do not use the digital camera in a location where there is

explosive gas, or any other flammable material in the air. Doing so may cause a fire or an explosion.

B Keep the digital camera out of the reach of children

œ The following may happen if children play with the digital

camera:

They may wrap the strap around their neck and suffocate.

They may swallow the battery pack or other small parts. In such a case, consult a physician immediately.

They may damage their eyesight if the flash goes off too close to their eyes.

They may get hurt by the digital camera.

CAUTION

B Cautions when carrying the digital camera

œ Do not walk around holding the digital camera by the

handstrap. It may hit other objects and get damaged. When walking around, hold the digital camera in your hand or place it in a pocket.

œ Be careful not to drop the digital camera or subject it to

strong shocks.

œ Make sure direct sunlight does not hit the digital camera

lens, as that may damage the internal parts. When not using the digital camera, be sure to always turn it off and retract the lens.

B If the digital camera is not going to be used for a long

period of time

œ For safety’s sake, remove the battery pack from the

camera. This will prevent any possible excess heat or leakage of battery fluid that may result in injuries or damage to nearby objects. (Note that when the battery pack is removed for a long period, the time and date settings will be cleared.)

English

B Cautions during use and storage

œ This digital camera is a precision instrument. When using or storing the

digital camera, make sure to avoid the following locations to avoid damage.

Places in direct sunlight

Places where humidity and temperature are high

Places that may get wet

Places close to an air conditioner or heater

Inside a car

Places where there is dust and dirt

Places where there is a fire burning

Places where volatile products are stored

Places subject to vibration

Operating environment

œ Temperature 0 to 40°C (operation)

œ Humidity 30 to 90% (operation, no condensation)

–20 to 60°C (storage)

10 to 90% (storage, no condensation)

English

USING YOUR DIGITAL CAMERA SAFELY AND CORRECTLY

Concerning the supplied battery pack charger (Model VAR-L10)

DANGER

B Risk of electric shock. Dry location use only. B Do not recharge battery packs that are not Lithium-ion

battery packs (Model DB-L10)

œ Do not use the supplied battery pack charger to recharge a

battery pack other than the supplied Lithium-ion battery pack (DB-L10). Recharging a dry-cell battery or other type of rechargeable battery may cause excess heat, combustion, or leakage, and cause a fire, injuries, burns, or damage to nearby objects.

B Use a 100 to 240 V AC power supply

œ If used with a power supply other than the one specified, it

may cause a fire or electric shock.

B Do not disassemble or modify the battery pack charger

œ It is dangerous to touch the inside of the battery pack

charger. Doing so may cause a fire or electric shock.

œ Do not use the battery pack charger as a direct current

generator.

B Do not get the battery pack charger wet

œ Make sure the battery pack charger does not get wet, as

doing so may cause a fire or electric shock.

œ Do not use the battery pack charger in a bathroom. œ If the battery pack charger gets wet, immediately unplug it

from the power outlet and remove the battery pack. Then contact the place of purchase. If used while wet, it may cause a fire, electric shock, or an accident.

English

B Cautions when plugging in the battery pack charger

œ Securely plug the power cord all the way into the power

outlet when using the battery pack charger. If the battery pack charger is used with the power cord not fully plugged in, heat may be generated and cause a fire.

œ If the power cord is damaged, or cannot be correctly

plugged into the power outlet, do not use the battery pack charger. Using the battery pack charger in this condition may cause a fire or electric shock.

œ Do not allow dust, etc., to build up on the power cord or

power outlet. A build-up of dust may cause a short circuit or generate heat and cause a fire.

œ When unplugging the power cord, be sure to hold the

power plug and slowly pull it out of the power outlet. Pulling the cord portion may damage the power cord and cause a fire or electric shock.

B Do not pull on the power cord to unplug it

œ Do not leave the power cord plugged into the power outlet

while the other end is not plugged into the battery pack charger. The loose end can cause electrocution if touched with wet hands or if handled by children.

œ Use only the power cord supplied with the battery pack

charger. If a different power cord is used, it may be rated for a different current load, and that may cause a fire.

œ The supplied power cord is for exclusive use with the

supplied battery pack charger. Do not use it with other devices, as doing so may cause a fire or electric shock.

œ Do not use a bundled power cord, as the heat generated

may cause a fire.

œ When using an extension cord, make sure that the total

wattage of the connected devices does not exceed the rated value of the extension cord. If the power load exceeds the rated value, it may cause a fire.

English

USING YOUR DIGITAL CAMERA SAFELY AND CORRECTLY

Concerning the supplied battery pack charger (Model VAR-L10) (continued)

DANGER

B Keep the battery pack charger out of the reach of children

œ Children may place the battery pack or other small

components in their mouth or perform some other such unforeseeable action. If swallowed, consult a physician immediately.

B If smoke or a strange odor is emitted, or if strange noises

are heard, immediately unplug the power cord from the power outlet

œ If the battery pack charger is used under these conditions, it

make cause a fire or electric shock.

œ If strange conditions such as these occur, immediately

unplug the battery pack charger, remove the battery pack, and wait to make sure no more smoke is emitted. Then contact the place of purchase. Do not try to repair or open the battery pack charger yourself.

B Do not handle with wet hands

œ Handling the battery pack charger with wet hands may

cause an electric shock.

B Do not use during a storm

œ Do not touch the battery pack charger or power cord while it

is plugged into a power outlet during a thunderstorm. Doing so may cause an electric shock.

B Unplug the power cord from the power outlet when finished

œ If the battery pack charger is left plugged into the power

outlet for a long period of time, there is a risk of fire.

English

CAUTION

B Do not connect to a voltage converter

œ Doing so may cause a fire or other trouble.

B Do not damage the power cord

œ Do not place heavy objects on the power cord. Do not place

the power cord near a heat source. Do not excessively bend the power cord, modify it, or secure it with staples. Doing so may damage the power cord and cause a fire or electric shock.

œ If the power cord is damaged, or if it does not plug properly

into the battery pack charger or wall outlet, contact the place of purchase.

B Do not place on an unstable surface

œ The battery pack charger may fall, causing injury or

damage.

œ If the battery pack charger falls and the charger body is

damaged, remove the battery pack and contact the place of purchase. If used while damaged, it may cause a fire, electric shock, or other damages.

B Operating and storage conditions

œ Do not use close to a heat source (close to a stove or

heater) or leave it exposed to direct sunlight.

Operating environment

œ Temperature 0 to 40°C (charging)

œ Humidity 10 to 85% (charging and storage)

–20 to 60°C (storage)

English

USING YOUR DIGITAL CAMERA SAFELY AND CORRECTLY

Concerning the Lithium-ion battery pack (Model DB-L10)

DANGER

This camera uses a Lithium-ion battery pack (Model DB-L10).

B If there is leaking, discoloration, change of shape, rise in

temperature, damaged exterior, strange odor or any other abnormal condition, immediately discontinue use and remove the battery pack from the camera, taking care to keep it well away from fire.

œ Continued use of the battery pack under any of these

conditions may result in fire, injury, explosion or other serious damage.

œ If battery fluid is leaking, placing the battery pack in close

proximity to a fire or other heat source may ignite the battery fluid and result in fire, damage, eruption of battery fluid, or smoke fumes.

B Do not transform, take apart, or modify.

œ Safety mechanisms and protective devices have been in

incorporation in the battery pack for the purpose of preventing danger. Any modification, by transforming, disassembling, or directly soldering to it, etc., will defeat these safety devices and possibly cause the battery pack to catch fire, explode, or leak or spew battery fluid.

B Do not connect the (+) and (–) terminals with a wire or other

metal implement. Do not carry loose or keep with necklaces, hairpins, etc.

œ Doing so may result in a short circuit, high voltage flow, fire,

explosion, leaking or spewing battery fluid, or heat generation. Metal such as a wire or necklace, etc. may cause heat to be generated.

B Do not throw the battery pack in the fire or subject it to heat

œ Doing so may cause the insulation to melt, damage the gas

discharge valve and safety mechanisms, or ignite the battery fluid, resulting in fire or explosion.

Batterij niet

weggooien, maar

inleveren als KCA.

English

B Do not drop, hit, or submit the battery pack to strong shocks

œ If the safety mechanisms and protective devices are

broken, an abnormal chemical reaction may occur inside the battery pack, or cause the battery pack to catch fire, explode, leak or spew battery fluid, or generate heat.

B Do not allow the battery pack to come into contact with

fresh or salt water, or allow the terminals to become wet.

œ If the safety mechanisms and protective devices are

damaged by corrosion, an abnormal chemical reaction may occur inside the battery pack, or cause the battery pack to catch fire, explode, leak or spew battery fluid, or generate heat.

B Cautions regarding the correct environment for using and

storing the battery pack

œ Temperature when using or recharging: 0 to 40°C

Do not use, recharge, store or leave the battery pack near fire or inside a car exposed to the hot sun, etc. (locations in which the temperature reaches 60°C or higher). At high temperatures, the safety mechanisms and protective devices inside the battery pack may be damaged by corrosion, causing an abnormal chemical reaction to occur, or cause the battery pack to catch fire, explode, leak or spew battery fluid, or generate heat. If the safety mechanisms and protective devices are damaged, the battery pack will become unusable. An environment with extremely high or low temperatures will cause the battery capacity to deteriorate and shorten the usable time, and may even shorten the battery life. Avoid storing the battery pack with it near full charge. It is recommended to store the battery pack when it is near fully discharged. If the battery pack is completely discharged, it may become unable to be recharged again. To avoid this, charge the battery pack for at least five minutes every six months.

œ Storage temperature: –10°C to 30°C

When not using the battery pack, remove it from the camera and store at –10°C to 30°C in a place with no condensation.

œ Humidity: 10% to 90% (no condensation)

English

USING YOUR DIGITAL CAMERA SAFELY AND CORRECTLY

Concerning the Lithium-ion battery pack (Model DB-L10) (continued)

DANGER

B Use only the supplied battery pack charger (Model VAR-L10)

œ If another charger is used, the battery pack may be

overcharged, or recharged with an abnormal voltage, causing an abnormal chemical reaction to occur, or cause the battery pack to catch fire, explode, leak or spew battery fluid, or generate heat.

B Use the battery pack only in the specified device

œ If the battery pack is used in a device other than that

specified, it may cause an abnormal voltage flow, or cause the battery pack to catch fire, explode, leak or spew battery fluid, or generate heat.

B Do not peel or damage the outer case

œ Damaging the outer case, inserting nails, hitting with a

hammer, stepping on the battery pack, etc. may cause a short circuit inside the battery pack or cause the battery pack to catch fire, explode, leak or spew battery fluid, or generate heat.

B If the battery pack is leaking and the electrolyte gets on

your skin or clothing, immediately rinse with clean water.

œ If the electrolyte gets into your eyes, you risk losing your

eyesight. Immediately rinse your eyes with clean, running water, and seek medical attention right away. Any electrolyte that comes into contact with your skin or clothing may harm your skin. Immediately rinse the area with clean, running water.

B Insert the battery pack correctly, as specified

œ When installing the battery pack in the charger or camera,

pay attention to the indicated polarity ((+) and (–)), and insert it correctly.

œ If the battery pack is installed with the wrong orientation, it

may cause an abnormal chemical reaction while in the charger, an abnormal voltage flow when it is used, or cause the battery pack to catch fire, explode, leak or spew battery fluid, or generate heat.

English

WARNING

B Always stop the recharging after the prescribed recharge

time, even if the battery pack is not fully charged.

œ If you continue to recharge the battery pack, it may cause

the battery pack to catch fire, explode, leak or spew battery fluid, or generate heat.

B Keep out of the reach of children.

œ They may handle the battery pack in an unforeseeable

manner that results in damage.

CAUTION

B Charge the battery pack before using it

œ Always recharge the battery pack before using it for the first

time, or when using it after it has been kept in storage for a long time. During recharging, the battery pack may be warm. This is normal and does not indicate a malfunction.

B Note concerning the battery pack after use

œ The battery pack may be warm immediately after the digital

camera is used. If removing the battery pack, turn off the digital camera and allow the battery pack to cool down before removing it.

B Recycling the battery pack

œ To conserve the environment and for efficient use of natural

resources, please discharge the used battery pack, cover the (+) and (–) terminals with tape and recycle the insulated battery pack.

œ If disposing of the battery pack as unburnable trash, please

follow all applicable regulations of your area.

English

USING YOUR DIGITAL CAMERA SAFELY AND CORRECTLY

Concerning the accessories

CAUTION

B Cautions concerning the use of the AC adapter

œ Use only the separately sold AC adapter (model VAR-G6EX for the

VPC-AZ3EX, model VAR-G6E for the VPC-AZ3EX [for U.K.] and model VAR-G6U for the VPC-AZ3) with your digital camera. Do not use an AC adapter other than the one indicted here, designed for specific use with your digital camera.

œ If an AC adapter other that the specified one is used, it may damage the

digital camera and cause a fire or electric shock.

œ Normally when using an AC adapter, remove the battery pack. Otherwise

the battery pack may cause excess heat, leakage, injury or damage to nearby objects.

œ For complete information on how to use the AC adapter, refer to the

instructions accompanying it.

B Cautions concerning the CompactFlash and Microdrive

œ Immediately after use, the CompactFlash and Microdrive will be very hot.

Before removing the CompactFlash or Microdrive, turn off the digital camera and wait for the temperature to cool down.

œ Keep out of the reach of children. Young children may put the media in their

mouth and choke or cause some other unexpected injury or accident.

FOR CORRECT USE OF YOUR CAMERA

B Cautions before capturing important images

œ Before capturing important images, make sure that the digital camera is

operating properly and in condition to capture the image properly.

œ Sanyo Electric shall not be held responsible for any losses that result

from images that could not be recorded, are erased, destroyed, or damaged in any way due to a problem with the digital camera, any of its accessories, or its software.

B Cautions concerning copyrights

œ The images you capture with your digital camera are for your own

private use, any other use may violate the rights of copyrights owners.

English

B Cautions when cleaning the digital camera

Cleaning procedure 1 Turn off the digital camera and remove the battery pack. 2 Remove the dirt with a soft cloth. 3 If the digital camera is extremely dirty, wipe with a soft cloth

moistened with a mild detergent diluted with water and wrung dry.

Caution

œ Do not use benzene or thinner products to clean the digital camera. Doing

so may cause deformation, discoloration, or paint peeling. When using a chemically treated cloth, carefully read its instructions and warnings.

œ Do not spray insecticides or volatile sprays on the digital camera. Do not let

rubber or vinyl objects contact the digital camera for a long period. They may cause deformation, discoloration, or paint peeling.

B Cautions when cleaning the lens

œ If the lens gets dirty, use a commercially available air blower or a cleaning

cloth for photographic equipment to clean it.

English

USING YOUR DIGITAL CAMERA SAFELY AND CORRECTLY

FOR CORRECT USE OF YOUR CAMERA (continued)

CAUTION

B When not using the digital camera for a long period

œ Remove the battery pack. However, when the battery pack is removed for

a long time, the digital camera functions may begin to not work properly. Periodically reinstall the battery pack and check the digital camera functions.

œ If the battery pack is left in the digital camera, a small amount of power is

still used even if the digital camera is turned off. If the battery pack is left in the digital camera for a long period, it may become completely discharged and lose its ability to be recharged again.

B Cautions concerning condensation

œ Using the digital camera with condensation inside it may damage the digital

camera.

If condensation seems likely to form

œ Place the digital camera in a plastic bag and seal it, and then wait until the

digital camera has reached the ambient temperature.

Be careful of condensation under the following conditions

œ When moving the digital camera suddenly from a cold place to a warm

place.

œ When the ambient temperature changes drastically, such as when a heater

is turned on to quickly heat the room.

œ When the digital camera is placed in the path of cool air from an air

conditioner.

œ When the digital camera is placed in a location of high humidity.

B Cautions concerning undesired interference

œ The digital camera may create undesired interference if used close to a

television or radio. To avoid this type of interference, make sure the cores on the supplied AV cable and USB interface cable are not removed.

Core Core

Dedicated AV cable Dedicated USB interface cable

English

B Cautions concerning magnetism

œ Do not place credit cards, bank cards, floppy disks, or other items that may

be damaged by magnetic fields near the speaker. Data may be lost or the magnetic strips on cards may be damaged.

Speaker

B Cautions concerning data storage

œ It is recommended that any important data be copied onto a separate

media (such as a hard disk, MO disk, or CD-R disk).

œ Stored data may be lost (or corrupted) in cases such as those listed below.

Sanyo Electric will not be held responsible for any damage or lost profits arising from the loss of data.

œ If the card is used incorrectly.

If the card is not inserted correctly into the digital camera.

œ œ If the card is subjected to electrical or mechanical shocks or other forces. œ If the card is removed from the digital camera or if the digital camera is

turned off during reading or writing operations.

œ If the card has reached the end of its usable life.

English

USING YOUR DIGITAL CAMERA SAFELY AND CORRECTLY

FOR CORRECT USE OF YOUR CAMERA (continued)

CAUTION

B Cautions when handling the cards

œ The cards are precision devices. Do not bend, drop, or subject them to

strong forces or shocks. Be especially careful with the Microdrive, for it is easily damaged by vibrations.

œ Avoid using or storing the cards in places with extremely high or low

temperatures, subject to direct sunlight, in a completely closed vehicle, near air conditioners or heaters, or in humid or dusty locations.

œ Avoid using or storing the cards in locations where strong static electrical

charges or electrical noise can be easily generated.

œ Do not allow the edges of the cards to become contaminated with foreign

materials. Gently wipe away any contamination with a soft, dry cloth.

œ When not using the cards, put them back into their protective covers to

protect them from damage due to static electricity.

œ Do not carry the cards in trouser pockets, as the cards may become

damaged when you sit down or make other movements that may apply forces.

œ Before using a new card, be sure to format it using the digital camera (see

“FORMATTING A CARD” on page 35).

œ When buying separately sold or commercially available products, carefully

read the instructions and warnings that come with them.

English

CAUTIONS CONCERNING HIGH TEMPERATURES

B S icon

œ The S icon indicates that the temperature inside the camera is high. If the

S icon appears, it is still possible to use the camera for a short while, but

eventually the S icon will flash and the camera will become inoperable. If the power is left on after this happens, the High Temperature Warning Screen will appear. In the event that the S icon flashes, the High Temperature Warning Screen appears and the camera becomes inoperable, discontinue using the camera as soon as possible, and wait until the internal temperature falls before using it again. Note that especially when shooting video clips, soon after the S icon lights, the remaining shooting time will appear, and when that figure becomes 0, further shooting is impossible.

00:46

HIGH TEMP TURN OFF THE POWER

English

CHECKING THE INCLUDED ACCESSORIES

œ Handstrap œ Software: 1 CD-ROM

œ CompactFlash (16MB): 1 œ Lithium-ion battery pack

œ Lithium-ion hydride battery pack

charger and power cord

œ Dedicated USB interface cable: 1 œ Soft case

(battery pack): 1

œ Dedicated AV cable: 1

ATTACHING THE HANDSTRAP

English

SOFT CASE

When not using the digital camera, keep it in the soft case for protection.

Media cards that can be used with this digital camera

The types of card that can be inserted into and used with this digital camera are:

œ CompactFlash œ Microdrive

There are special precautions that must be followed when using Microdrive cards. Before using Microdrive cards, carefully read “Cautions when using the Microdrive” (see page 199).

What “card” means in this manual

œ In this manual, CompactFlash and Microdrive cards that can be used in this

digital camera are referred to as “card”.

œ The cards in the illustrations in this manual are CompactFlash cards, but all

installation, removal, and formatting procedures are the same for both the CompactFlash and Microdrive cards.

English

QUICK START FOR CAPTURING IMAGES

Charge the battery pack

œ Before using the supplied battery

pack in the camera, insert it into the charger.

œ Insert it in the direction indicated by

the [j] mark on the battery pack.

Connect the supplied power cord

to the battery pack charger.

œ Insert the connector straight and

securely.

Plug the power plug into a power

outlet (AC 100 to 240V).

œ Recharging begins. œ During recharge, the CHARGE

indicator is lit red.

When the CHARGE indicator lights

green, unplug the power cord from the power outlet, and remove the battery pack from the charger.

HINT

œ Please read the safety precautions regarding the battery pack (see page

15) and the supplied battery pack charger (VAR-L10) (see page 11).

œ The recharge time is approx. 120 minutes.

Battery pack [j] mark

CHARGE indicator

To power outlet

English

Install the battery pack and card

The card can be used after it has been formatted with the camera (see FORMATTING A CARD on page 35). Be sure to turn off the power before installing or removing the card.

Use the battery pack recharged in step 1 above. Make sure that the battery pack polarity ((+) and (–)) and the card orientation

are correct.

Insert the battery pack.

Open battery compartment cover

on the digital camera side.

Close the battery compartment

cover.

Insert the card.

Push the card cover lever.

Close the card cover.

Push in

Insert the battery pack.

œ When removing the battery pack...

2Push in

Insert the card all the way.

œ When removing the card...

Push in

[j] mark

1Open

3Pull out

Push

Pull out

English

QUICK START FOR CAPTURING IMAGES

Capture an image

Now that preparation is completed, your digital camera is ready to capture images. Shown here is how to capture a still image.

Set the main switch to [á].

Turn the selector dial to [W].

Press the power button.

œ The power turns on. œ The lens extends. œ When the standby indicator lights

green, the camera is ready to capture an image.

Point the camera lens at the

subject.

œ Compose the picture by viewing

the LCD monitor.

(details on page 60)

Lens

Power button

Standby indicator

Main switch

Selector dial

Shutter release button

LCD monitor

English

Press the shutter release button

halfway (focus-lock).

œ The autofocus locks on the subject,

and the image in the LCD monitor appears clearly.

Continue to gently press the

shutter release button all the way.

œ The image is captured.

(Press halfway)

(Press fully)

View the image

Now let’s take a look at the image you captured.

Set the main switch to [Ô].

œ The image you captured appears in

the LCD monitor.

œ Press [d] or [c] on the arrow

button to display the images stored before or after the current image.

When you are finished, press the

power button to turn off the digital camera.

HINT

œ For still images, you can view the captured image on the LCD monitor by

keeping the shutter release button depressed when you capture the image.

œ When the standby indicator is flashing red, the next image cannot be

captured. When the standby indicator lights green again, it is possible to capture the next image.

(details on page 85)

Main switch

Power button

Arrow button

English

PARTS NAMES

12345 6

Front

Shutter release button

2 Selector dial 3 Flash button 4

Focus button

5 Viewfinder 6 Speaker

789F

Lens (closed when the lens is stowed)

8 Microphone 9 Flash F

Self-timer indicator

English

Rear

3567

1 Viewfinder 2

Standby indicator (red/green) Red flashing:

œ When capturing an image,

recording sound, charging the flash, storing an image or sound recording, when no card is installed (indicates that image or sound cannot be recorded), or recording using the self-timer

Red steady:

œ When the memory is full

(indicates that image or sound cannot be recorded), or recording using the self-timer

Green flashing:

œ When using the exposure

correction or digital zoom functions (indicates that image and sound can be recorded)

Green steady:

œ Image and sound can be

recorded, or when connected to a PC or Printer

3 Accessing indicator 4 5 SET button 6 Zoom switch 7 8 DIGITAL/AV terminal

9 DC IN (external DC power

F Battery compartment cover G Card cover H Arrow button I MENU button J Card cover lever K Main switch L LCD monitor

F G

HIJKL

Power button

Handstrap holder

œ Used as both the USB

connector and AV output terminal.

input) terminal

œ For connecting a separately

sold AC adapter

English

RECHARGING THE BATTERY PACK

Be sure to fully charge the supplied or separately sold battery pack before using it in your camera. For charging the battery pack, use the supplied charger.

Charge the battery pack if it is being used for the first time, and recharge it whenever the remaining charge is low (see “CHECKING THE REMAINING BATTERY PACK CHARGE” on page 171). œ During recharging, the charger and battery pack will be warm. This is

normal and does not indicate a malfunction.

If there is interference to your TV or radio during recharging...

œ Move the battery pack and charger further away from the TV or radio.

Ambient temperature during recharging

œ It is recommended that the ambient temperature during recharging be

between about 10°C and 35°C. Due to the characteristics of the battery pack, at temperatures below 10°C, it may not be possible to sufficiently recharge it.

Recharge a battery pack in the following cases

œ A battery pack which has not been used for a long time œ Newly purchased battery pack

English

About the CHARGE indicator

The CHARGE indicator shows the status of the battery pack and the charger. Please refer to the following table if the indicator flashes abnormally.

CHARGE indicator

Not lit Not connected properly

œ To recharge the battery pack, the power cord of the

charger must be connected to a power outlet, and the plug at one end inserted in the charger’s power socket (see page 27).

œ The battery pack is not installed, or it is not installed

correctly (see page 27). Lit red Recharging Lit green Recharging finished Red flashing Problem with the battery pack

œ Immediately remove the battery pack from the

charger.

œ Do not use an abnormal battery pack. (The usable

life of the battery pack has probably expired.)

English

FORMATTING A CARD

Before using a card, it must be formatted with this camera:

œ After purchasing, when used for the first time œ If it was formatted using a personal computer or another digital camera.

For more information on handling the cards, see “Cautions when handling the cards” on page 23 and “Cautions when using the Microdrive” on page 199.

Display the Shooting Option Setting

Screen (see page 39).

œ Set the main switch to [á], and

turn the selector dial to [P].

Press [l] on the arrow button to

select the reformat icon ã.

Press the SET button.

œ The Reformat Screen appears.

Press [j] on the arrow button to

select “YES”.

Press the SET button.

œ Reformatting begins. œ During reformatting, “REFORMATTING” and “DO NOT POWER OFF”

are shown on the LCD monitor.

œ When reformatting is finished, you are returned to the Shooting Option

Setting Screen.

AUDIO REC COLOR ADJUSTMENT CLOCK SET BEEP LANGUAGE

TV SYSTEM REFORMAT

REFORMAT

YES

English

CAUTION Cautions during reformatting

œ Do not turn off the power to the camera or eject the card during

reformatting.

Reformatting erases the data

œ When a card is reformatted, all data recorded on the card is erased.

Protected data (see page 143) is also erased, so before reformatting a card, any data you wish to keep should be copied to your personal computer’s hard disk or other storage medium.

HINT To cancel reformatting

œ In step 4, select “NO”, and press the SET button. You are returned to the

Shooting Option Setting Screen.

Reformatting is also possible in the playback mode

œ Reformatting can also be executed if the main switch is set to [Ô] in step

1 above to display the Playback Option Setting Screen.

NOTE

œ By using the card together with a commercially available PC card adapter

for CompactFlash cards, the card can be used as a PC card conforming to PC Card Standard-ATA.

English

TURNING THE POWER ON/OFF

Turning the power on

When capturing images

Set the main switch to [á] or

[à].

[á]: The LCD monitor is used. [à]: The LCD monitor is not used.

Turn the selector dial to [W], [Y]

or [X].

Press the power button.

œ The power turns on, the lens

extends and the standby indicator next to the viewfinder lights.

œ If the main switch is set to [á], an

image appears on the LCD monitor.

When playing back images

Set the main switch to [Ô].

Press the power button.

œ The power turns on, and an image

appears on the LCD monitor.

Power button

Main switch

Standby indicator

Selector dial

Powe r button

Lens

English

Turning the power off

Press the power button.

œ The power turns off.

When capturing images

œ The lens automatically retracts and

closes.

œ The standby indicator turns off. œ The LCD monitor turns off. œ The power turns off.

When playing back images

œ The LCD monitor turns off.

Standby indicator

LCD monitor

Power button

Lens (automatically stowed)

Turning the power on when the power save function is active

In order to save the battery pack power, the power save function will automatically turn off the power after one minute of no use during shooting, or five minutes of no use during playback (factory-preset setting).

Press the MENU button, the power button or the shutter release

button once.

HINT

œ When using the separately sold AC adapter (model VAR-G6EX for the

VPC-AZ3EX, model VAR-G6E for the VPC-AZ3EX [for U.K.] and model VAR-G6U for the VPC-AZ3), the power save function will become active after about 10 minutes of inactivity (factory-preset setting).

œ The user can specify the time elapsed before the power save function is

activated (see page 167).

œ In the PC/USB DIRECT-PRINT connection mode and PC camera mode,

while the camera is connected to a personal computer with the dedicated USB interface cable, the power save function is disabled.

English

SETTING SCREENS AND OPTION SETTING SCREENS

For both shooting and playback, there are Setting Screens and Option Setting Screens.

Displaying and exiting the Shooting/Playback Setting Screens and Option Setting Screens

Displaying a Setting Screen

Set the main switch.

[á]: To display the Shooting Setting

Screen or Shooting Option Setting Screen.

[Ô]: To display the Playback Setting

Screen or the Playback Option Setting Screen.

Turn the selector dial to the mark

for the desired setting screen.

W Still Image Shooting

Setting Screen (page 45)

Y Sequential shots Shooting

Setting Screen (page 47)

X Video Clip Shooting Setting

Screen (page 49)

P Shooting Option Setting

Screen (page 54)

Ü PC/USB DIRECT-PRINT

connection mode (page

150)

â PC camera mode (page

151)

English

Main switch

Power button

Shooting Playback

Still Image Playback Setting Screen (page 53)

Sequential shots Playback Setting Screen (page 53)

Video Clip Playback Setting Screen (page 53)

Playback Option Setting Screen (page 54)

PC/USB DIRECT-PRINT connection mode (page

150) PC camera mode (page

151)

Selector dial

Turn on the power.

œ In step 2, if the selector dial is set to [P], the Shooting Option

Setting Screen or Playback Option Setting Screen appears.

Press the MENU button.

œ The setting screen selected in step

3 appears.

E 12

SCENE SELECT FULL AUTO

Example: Still Image Shooting

Mode Setting Screen

(BASIC mode)

Exiting the Shooting/Playback Setting Screen

Press the MENU button.

œ The Shooting/Playback Setting Screen is exited.

Exiting the Shooting/Playback Option Setting Screen

Turn the selector dial to a mark other than [P].

œ The Option Setting Screen is exited and either a Shooting Screen or

Playback Screen appears.

HINT

œ For more information on using the setting screens, see “Switching between

the operation modes” on page 41 and “Setting screen basic operation” on page 43.

œ In the PC connection mode and PC camera mode, the LCD monitor turns

off.

English

SETTING SCREENS AND OPTION SETTING SCREENS

Switching between the operation modes (BASIC mode and EXPERT mode)

This camera allows you to choose between two operation modes: with the BASIC mode, you can enjoy taking photos while letting the camera do all the work; in the EXPERT mode, you have control of all the camera settings. Select the operation mode for the type of photography you enjoy.

Display the Shooting Setting

Screen.

œ The BASIC Mode Shooting Setting

Screen or the EXPERT Mode Shooting Setting Screen appears.

Press [d] on the arrow button twice.

œ The operation mode is switched. œ To return to the initial operation

mode, again press [d] on the arrow button twice.

BASIC mode

E 12 E 12

SCENE SELECT FULL AUTO

Shooting Setting Screen

EXPERT mode

B 12

EXPERT

FOR EXPERT FOR BASIC

B 12

EXPERT

English

FOR BASIC FOR EXPERT

RESOLUTION 2288¶1712

Shooting Setting Screen

Shooting in the BASIC mode

In the BASIC mode the number of settings the user has to deal with are few, making it easy for the novice digital camera operator to enjoy taking photos. It is recommended that the user who is new to digital camera operation or not familiar with the various settings take photos using the basic settings of this mode. In addition, if you change the settings and find that the resulting images are not satisfactory, try returning to the basic settings to take the photos.

BASIC mode settings

E 12

SCENE SELECT FULL AUTO

E 12

SCENE SELECT FULL AUTO

E 00:46

SCENE SELECT FULL AUTO

B : Scene select setting

C : Resolution setting

D : Compression rate setting V : Self-timer setting

B : Scene select setting

Ä : Sequential shots mode setting

C : Resolution setting

D : Compression rate setting

B : Scene select setting 2 : Resolution setting

English

SETTING SCREENS AND OPTION SETTING SCREENS

Setting screen basic operation

When a setting screen is displayed, the arrow button and the SET button are used to make the desired settings.

SET button

Arrow button

B Shooting Setting Screen

œ When selecting a menu

Press [j] or [l] on the arrow button.

E 12 E

EXPERT

SCENE SELECT FULL AUTO

RESOLUTION

RESOLUTION 1600 1200

2288¶1712

œ When selecting a setting (icon)

Press [d] or [c] on the arrow button.

To make a setting, select the desired icon, and press the SET button. When the setting is established, the selected icon moves to the left end of the line-up.

English

SET button

COMPRESSION FINE

B Playback Setting Screen

œ When selecting a setting (icon)

Press [j] or [l] on the arrow button.

9-IMAGE DISPLAY

ZOOM PROTECT ERASE EDIT PHOTO PRINT SETTING SLIDESHOW VOLUME

9-IMAGE DISPLAY

ZOOM

PROTECT ERASE EDIT PHOTO PRINT SETTING SLIDESHOW VOLUME

B Other operations

œ To change a numerical value

Press [j] or [l] on the arrow button to change the number.

œ To return to the previous operation

Press the MENU button.

Select “EXIT” or the C icon, and press the SET button.

LOCK?

YES EXIT

Exit C icon

9-IMAGE DISPLAY ZOOM

PROTECT

ERASE EDIT PHOTO PRINT SETTING SLIDESHOW VOLUME

ADD AUDIO ADD TEXT RESIZE ROTATE

EXIT

English

SETTING SCREENS AND OPTION SETTING SCREENS

Shooting Setting Screens

Still Image Shooting Setting Screen

* All the icons never appear at the same time.

Main switch

E 12

SCENE SELECT FULL AUTO

BASIC mode

B 12

EXPERT

RESOLUTION 2288¶1712

EXPERT mode

Selector dial

1 Scene Select menu (page 76)

c B: Full auto icon

F: Sports scene icon x: Portrait icon G: Night scene icon

English

2 Resolution menu (page 78)

A: 3264 x 2448-pixel

resolution icon

B: 2880 x 2160-pixel

resolution icon

c C: 2288 x 1712-pixel

resolution icon

D: 1600 x 1200-pixel

resolution icon

E: 640 x 480-pixel resolution

icon

Compression menu (page 81)

c D: FINE icon (low compression)

a: SFINE icon (super-low

compression)

G: NORM (NORMAL) icon

(moderate compression)

L: TIFF icon (no compression)

Self-timer menu (page 80)

c V: Self-timer off icon

U: Self-timer on icon

Voice Memo menu (page 101)

c b: Voice memo off icon

a: Voice memo on icon

6 Spot focus menu (page 102)

c j: Spot focus off icon

i: Spot focus on icon

7 Light-measuring mode (EXP

MEASURE) menu (page 103)

c V: Multi-section

light-measuring icon

X: Center-weighted

light-measuring icon

W: Spot light-measuring icon

8 White Balance menu (page 104)

c H: Auto white balance icon

g: Fair icon h: Overcast icon e: Fluorescent lighting icon i: White (incandescent) light

icon

S: Color fill icon

9 ISO sensitivity menu (page 106)

c Ä: Auto sensitivity icon

(ISO100 to 400)

+: ISO100 icon 1: ISO200 icon %: ISO400 icon

Exposure control menu (page 107)

c Ï: Program AE icon

Î: Aperture priority AE icon Ì: Shutter speed priority AE

icon

Í: Manual exposure control

icon

Color correction menu (page 119)

ú, ô to m: Color

correction icons

(ú is the factory-set initial

setting)

H Noise reduction menu (page 110)

c h: Noise reduction off icon

g: Noise reduction on icon

I Digital Zoom menu (page 120)

c Z: Digital zoom off icon

Y: Digital zoom on icon

Quick Shot menu (page 121)

c ä: Quick Shot off icon

R: Quick Shot on icon

K Exposure correction icon (page 122) L

Number of remaining images that can be captured (page 173)

M Still image shooting mode icon

(page 51)

N Help display (page 165) O Remaining battery pack charge

(page 171)

Not displayed when the remaining battery pack charge is near full or when the AC adapter (sold separately) is used.

c indicates the factory-preset setting.

English

SETTING SCREENS AND OPTION SETTING SCREENS

Sequential Shots Shooting Setting Screen

* All the icons never appear at the same time.

Selector dial

Main switch

E 12

SCENE SELECT FULL AUTO

BASIC mode

B 12

EXPERT

METHOD BEST

EXPERT mode

1 Scene Select menu (page 76)

c B: Full auto icon

F: Sports scene icon x: Portrait icon

2 Sequential shots mode (METHOD)

menu (page 61)

c Ä: Best select shot icon

Ö: Standard sequential shots

icon

A: AE shift sequential shots

icon

English

Resolution menu (page 78)

c C: 2288 x 1712-pixel

resolution icon

D: 1600 x 1200-pixel

resolution icon

E: 640 x 480-pixel resolution

icon

4 Compression menu (page 81)

a: SFINE icon (super-low

compression)

c D: FINE icon (low compression)

G: NORM (NORMAL) icon

(moderate compression)

Spot focus menu (page 102)

c j: Spot focus off icon

i: Spot focus on icon

6 Light-measuring mode (EXP

MEASURE) menu (page 103)

c V: Multi-section

light-measuring icon

X: Center-weighted

light-measuring icon

W: Spot light-measuring icon

7 White Balance menu (page 104)

c H: Auto white balance icon

g: Fair icon h: Overcast icon e: Fluorescent lighting icon i: White (incandescent) light

icon

S: Color fill icon

c indicates the factory-preset setting.

ISO sensitivity menu (page 106)

c Ä: Auto sensitivity icon

(ISO100 to 400)

+: ISO100 icon 1: ISO200 icon %: ISO400 icon

9 Exposure Control menu (page 107)

c Ï: Program AE icon

Î: Aperture priority AE icon Ì: Shutter speed priority AE

icon

Í: Manual exposure control

icon

F Color correction menu (page 119)

ú, ô to m: Color

correction icons

(ú is the factory-set initial

setting)

G Digital Zoom menu (page 120)

c Z: Digital zoom off icon

Y: Digital zoom on icon

H Exposure correction icon (page 122) I Number of remaining images that

can be captured (page 173)

J Sequential shots shooting mode icon

(page 51)

K Help display (page 165) L Remaining battery pack charge

(page 171)

Not displayed when the remaining battery pack charge is near full or when the AC adapter (sold separately) is used.

English

SETTING SCREENS AND OPTION SETTING SCREENS

Video Clip Shooting Setting Screen

* All the icons never appear at the same time.

Main switch

E 00:46

SCENE SELECT FULL AUTO

BASIC mode

B 00:46

EXPERT

RESOLUTION 320¶240

EXPERT mode

Selector dial

1 Scene Select menu (page 76)

c B: Full auto icon

F: Sports scene icon x: Portrait icon

English

2 Resolution menu (page 78)

c 2: 320 x 240-pixel resolution

icon

0: 160 x 120-pixel resolution

icon

Digital Zoom menu (page 120)

c Z: Digital zoom off icon

Y: Digital zoom on icon

Flicker-reduction (FLICKER REDUCT) menu (page 123)

c l: Flicker-reduction function

off icon

k: Flicker-reduction function

on icon

5 Spot focus menu (page 102)

c j: Spot focus off icon

i: Spot focus on icon

6 Light-measuring mode (EXP

MEASURE) menu (page 103)

c V: Multi-section

light-measuring icon

X: Center-weighted

light-measuring icon

W: Spot light-measuring icon

7 White Balance menu (page 104)

c H: Auto white balance icon

g: Fair icon h: Overcast icon e: Fluorescent lighting icon i: White (incandescent) light

icon

S: Color fill icon

c indicates the factory-preset setting.

ISO sensitivity menu (page 106)

c Ä: Auto sensitivity icon

(ISO100 to 400)

+: ISO100 icon 1: ISO200 icon %: ISO400 icon

9 Color correction menu (page 119)

ú, ô to m: Color

correction icons

(ú is the factory-set initial

setting)

F Exposure correction icon (page 122) G Remaining recording time available

(page 165)

H Video clip shooting mode icon (page

52)

I Help display (page 165) J Remaining battery pack charge

(page 171)

Not displayed when the remaining battery pack charge is near full or when the AC adapter (sold separately) is used.

English

SETTING SCREENS AND OPTION SETTING SCREENS

Shooting status display

After you exit the Shooting Setting Screen, icons on the LCD monitor indicate the status of the digital camera and card. The icons and their positions differ depending on the selected shooting mode.

* All the icons never appear at the same time.

Operation mode indicator

2 Scene select indicator 3 Light-measuring mode

indicator

White balance indicator

ISO sensitivity indicator

6 Exposure control indicator 7

Aperture indicator

8 Shutter speed indicator 9 Quick Shot indicator F Spot focus indicator G Noise reduction indicator H Focus mark I Light-measuring spot mark J Number of images remaining K Shooting mode indicator L Flash mode indicator M Focus mode indicator N Self-timer indicator O Voice memo indicator P Color correction indicator R Exposure correction indicator R Remaining battery pack charge

2 3 4 5 6 7

2.7

1/100

2 3 4 5 6 7

2.7

1/100

<Sequential shots shooting status

display>

J9 F G

K L M N O P Q R

K T M

P Q R

English

Zoom bar

Sequential shots mode indicator

Flicker-reduction indicator

V Remaining shooting time

00:46

EXPERT

2 3 4 5

200

+0.3

P Q R

English

SETTING SCREENS AND OPTION SETTING SCREENS

Playback Setting Screens

Still Image Playback Setting Screen

9-IMAGE DISPLAY

ZOOM

PROTECT

ERASE

EDIT PHOTO

PRINT SETTING

SLIDESHOW

VOLUME

Sequential Shots Playback Setting Screen

9-IMAGE DISPLAY

ZOOM

PROTECT

ERASE

EDIT PHOTO

COPY

VOLUME

Video Clip Playback Setting Screen

Main switchMain switchMain switch

Selector dialSelector dialSelector dial

9-IMAGE DISPLAY

ZOOM

PROTECT

ERASE

COPY

VOLUME

1 9-image display playback 2 Playback zoom 3 Protect 4 Erase icon 5 Edit still image icon 6 Print settings 7

Slideshow playback

8 Volume control 9 Image copy

English

F Playback mode indicator

v: Still image playback x: Sequential shots playback w: Video clip playback

G Remaining battery pack charge

Not displayed when the remaining battery pack charge is near full or when the AC adapter (sold separately) is used.

Shooting/Playback Option Setting Screens

Shooting Option Setting Screen

Selector dial Selector dial

Playback Option Setting Screen

AUDIO REC

COLOR ADJUSTMENT

CLOCK SET

BEEP

LANGUAGE

TV SYSTEM

REFORMAT

FILE NUMBER RESET

POWER SAVE

HELP

1 Audio recording

On the Playback Option Setting Screen, the audio playback icon

M is shown.

Color correction setting (real color equalizer)

Cannot be selected from the Playback Option Setting Screen.

3 Date and time setting

Icons 8 to G are displayed when you press [j] or [l] on the arrow button to scroll down the screen.

AUDIO

COLOR ADJUSTMENT

CLOCK SET

BEEP

LANGUAGE

TV SYSTEM

REFORMAT

FILE NUMBER RESET

POWER SAVE

HELP

4 Operational sound (beep)

settings

Display language selection

6 TV system selection 7 Card reformat 8 File number reset setting 9 Power save function F Help display

English

BEFORE TAKING PICTURES

For best results

Holding the camera

Hold the camera securely with both hands, keeping your elbows close to your body and making sure the camera is stable.

Correct hold Incorrect hold

A finger is blocking the lens.

Make sure that the lens and flash are not blocked by your fingers or the handstrap.

HINT

œ When a picture is taken with the camera held vertically, the image played

back on the LCD monitor screen or on a TV set will be shown on its side. However, images captured in the still image shooting mode or sequential shots shooting mode can be rotated when they are played back (see page

96). Note that video clips cannot be rotated when they are played back.

English

USING THE AUTOFOCUS

The autofocus will work in almost all situations; however, there are certain conditions that may cause the autofocus function to not work properly. If the autofocus function is not working properly, use the manual focus mode to capture images (see page 69).

B Conditions that may cause incorrect focus

The following examples are some of the situations where the autofocus function may not work.

œ Subjects with low contrast, very bright

subjects at the center of the image, or dark subjects or locations

Use the focus-lock function (see page

60) to lock the focus on an object with contrast at the same distance as the desired subject.

œ Subjects without vertical lines

Use the focus-lock function to lock the focus on the subject while holding the digital camera vertically.

The following examples are some of the situations where the autofocus function may work, but not as desired.

œ When both near and far objects are

present

Use the focus-lock function to lock the focus on an object at the same distance as the desired subject.

English

BEFORE TAKING PICTURES

œ Fast-moving subjects

Use the focus-lock function to lock the focus on an object at the same distance as the desired subject.

Hints for taking pictures

Operational sound

œ The camera can be set so that a sound is heard, for example, when the

shutter release button, SET button, or MENU button is pressed (see page

162).

Saving battery pack power

œ When you take pictures without using the LCD monitor, you can slow down

the rate of battery pack consumption (see page 74).

Immediate viewing of captured images

œ After taking a picture, you can move the main switch to [Ô] to view the

last image captured.

Quick exposure correction setting (EXPERT mode only)

œ When a Shooting Setting Screen or Shooting Information Screen is not

shown, press [d] or [c] on the arrow button to immediately access the exposure correction icon and exposure correction bar, and adjust the setting. (The icon will not appear in cases where the setting cannot be adjusted.) The exposure correction icon and exposure correction bar are canceled when the MENU button is pressed (see page 122).

Where is the image and audio data saved?

œ All the image and sound data is recorded on the card installed in the

camera (see page 148).

Taking pictures in backlight conditions...

œ When taking pictures with the light coming from behind the subject, due to

the characteristics of the lens, light lines or patterns (flare phenomenon) may appear in the captured image. In this situation, it is recommended that you avoid taking pictures with the subject lit from behind.

English

NOTE About sequential shots shooting

œ In sequential shots shooting, the autofocus function is activated when the

shutter release button is pressed and remains fixed at the same focus until the sequential shots are finished.

If the motion alert icon appears...

œ During still image shooting, if the shutter speed is slow and the possibility

that the image may be blurred due to camera movement becomes high, the motion alert icon T may appear on the LCD monitor. In this case, use a tripod to stabilize the camera when shooting, set the exposure control (see page 107) to Ï, or set the flash operation mode to automatic (see page

71).

œ When the shutter release button is pressed halfway, the image in the LCD

monitor may waver vertically. This is the result of internal image processing and is not a malfunction. This wavering is not recorded and will not affect your images in any way.

Motion alert icon

8.0 1S

NOTE Did you snap a picture without a card installed?

œ When you press the shutter release button, it may sound and feel as

though the camera is actually operating to capture the shot. However, this function has been incorporated in the camera to enable you to experience what the actual operation feels like while you try out the camera before purchasing. Without a card installed in the camera, it is impossible to capture images, so please be sure to install the card before operating your camera.

English

SHOOTING/RECORDING MODE SETTINGS

Before using the digital camera, you must first set the desired recording mode (still image, sequential shots, video clip, or audio recording).

œ Still image shooting mode: For capturing still images. œ Sequential shots shooting mode: For capturing several images in

succession.

œ Video clip shooting mode: For capturing video clips. œ Audio recording mode: For recording sound only. œ PC camera mode: When using the camera as a PC camera.

Set the main switch to [á] or [à].

[á] : To use the LCD monitor. [à] : To turn off the LCD monitor.

Set the selector dial to the desired

shooting mode.

For the still image mode, set to [W]. For the sequential shots mode, set to [Y]. For the video clip shooting mode, set to

[X]. For the audio recording mode, set to [P]

(the Shooting Option Setting Screen will appear).

For the PC camera mode, set to [â].

Press the power button.

œ The camera turns on and the selected

shooting mode is active.

Main switch

Selector dial

English

CAPTURING STILL IMAGES

Set the camera to the still image

shooting mode (see page 59).

Take a picture.

1 Point the camera lens at the

subject. Slowly press and hold the shutter release button halfway.

œ The area in the center of the LCD

monitor comes clearly into focus, and the focus icon ë appears in the upper left corner (focus-lock).

œ If the Shooting Setting Screen

(see page 45) or Shooting Information Screen (see page

124) was displayed, it is exited.

œ The focus icon does not appear if

the focus is set to telephoto å or manual !, or during quick shot shooting (see page 121).

2 Press the shutter release button all

the way.

œ The image is captured.

NOTE

œ You can view the image captured on the LCD monitor by holding the

shutter release button down.

œ The stand-by indicator will flash red while the image is being written to the

memory. Another image can only be captured when the stand-by indicator lights green again.

œ The camera is ready for capturing the next image after about 1 second.

(Press halfway)

3.1 1/50

(Press fully)

English

SEQUENTIAL SHOTS

This digital camera provides three types of sequential shots.

Standard sequential shots Ö:

A normal sequential shot. (For the number of images captured, please see “Maximum number of sequential shots”.)

AE shift sequential shot A: Sequential images are captured while the exposure

Dark image (under exposed) (Standard exposure) Bright image (over exposed)

Best select shot Ä:

Four sequential images are captured from which you can select one to save.

(or shutter speed) is changed automatically.

Select one to save. The other three are deleted.

Maximum number of sequential shots

The maximum possible number of sequential shots depends on the resolution and compression rate settings.

Compression rate

Resolution

abc

C 4 images 6 images 9 images D 8 images 13 images 20 images E 56 images 84 images 99 images

English

Standard sequential shots Ö

3.5 1/90

Set the camera to the sequential

shots shooting mode (see page 39).

Select the standard sequential

shots icon Öfrom the sequential

shots mode menu, and press the SET button.

Press the shutter release button to

capture the sequential shots.

œ Images are captured as long as the

shutter release button is pressed.

œ During shooting, K appears in the

LCD monitor.

Finish capturing images.

œ Release the shutter release button

to end recording.

E 12

3.5

1/90

METHOD STANDARD

REC (recording) indicator

Shutter release button

English

SEQUENTIAL SHOTS

AE shift sequential (auto bracket) shots A

Set the camera to the sequential

shots shooting mode (see page 39).

Select the AE shift sequential shots

icon A from the sequential shots

mode menu, and press the SET button.

Press the shutter release button to capture the sequential shots.

œ When the shutter release button is pressed, sequential shots shooting

begins.

œ It is not necessary to keep the shutter release button depressed.

œ During shooting, K appears in the LCD monitor.

œ Shooting will end automatically if all the remaining number of images

have been shot.

NOTE

œ The number of images that can be captured in one AE shift sequential

shots sequence differs depending on the resolution and compression rate settings.

Resolution

C 3 images 5 images 7 images D 7 images 7 images 7 images E 7 images 7 images 7 images

œ In the AE sequential shots mode, the order in which images are played

back is different from the order in which they were photographed.

Photographed order

abc

Compression rate

E 12

METHOD BRACKET

Playback order

English

Best select shot Ä

Set the camera to the sequential

shots shooting mode (see page 39).

Select the best select shot icon Ä

from the sequential shots mode menu, and press the SET button.

Press the shutter release button to

capture the sequential shots.

œ When the shutter release button is

pressed, sequential shots shooting begins.

œ It is not necessary to keep the

shutter release button depressed.

œ During shooting, K appears in the

LCD monitor.

œ After a few moments, the 4-image

display appears showing the images captured.

Select the image that you want to

save.

1 Press the arrow button to move the

orange frame to the image you want to save.

2 Press the SET button.

œ The Best Shot Confirmation

Screen appears with the selected image displayed full screen. You can press [d] or [c] to select a different image.

E 12

METHOD BEST

Orange frame

English

SEQUENTIAL SHOTS

Save the selected image and erase

the others. 1 Select “YES”, and press the SET

button.

œ “PROCESSING” appears for a

few moments, and then the sequential shots shooting mode returns.

œ The selected image is saved in

the still image folder; the other three images are deleted (nothing is saved in the sequential shots folder). The saved image can be played back in the still image playback mode.

HINT Capturing images without using the LCD monitor

œ When taking pictures without using the LCD monitor, after the images are

captured, the 4-image display (step 3) does not appear. All four images are saved in the sequential shots folder.

To save all four images

œ While the 4-image display is shown in step 3, press the MENU button, or

select “NO” and press the SET button in step 4 above. All four images are saved in the sequential shots folder.

Folder number and file name (image number)

100-0101

SAVE IMAGE ERASE OTHERS

YES

<Confirmation Screen for

erasing the other images>

English

VIDEO CLIPS

When you shoot video clips, the sound is also recorded.

Set the camera to the video clip

shooting mode (see page 59).

Press the shutter release button to

record the video clip.

œ It is not necessary to keep the

shutter release button pressed while shooting.

œ During recording K appears on

the LCD monitor.

œ When the remaining recording time

available for the currently recording clip becomes little, a countdown of the remaining recording time appears on the display.

End the recording.

œ Press the shutter release button to

stop recording.

NOTE

œ Each single recording can consist of up to 10 minutes. œ The data for a video clip is very large. Therefore, be aware that if the video

clip is uploaded to a computer to be played back, the computer may not be able to play back the video fast enough, making it appear jerky. (The video will always be displayed properly on the LCD monitor or a television.)

REC (recording) indicator

Recording time (min:sec)

Remaining recording time

00:07 13

(sec)

English

AUDIO RECORDINGS

Your digital camera can record sound, just like a normal tape recorder.

Display the Shooting Option Setting

Screen (see page 39).

œ The audio recording icon a is

highlighted.

Press the SET button.

œ The Audio Recording Screen

appears.

Press [j] or [l] on the arrow button

to select the recording icon æ,

and press the SET button.

œ Recording begins. Point the

microphone toward the sound you wish to record.

œ K (recording) appears on the LCD

monitor during recording.

AUDIO REC

COLOR ADJUSTMENT CLOCK SET BEEP LANGUAGE TV SYSTEM REFORMAT

AUDIO REC 33:35

REC EXIT

Microphone

English

End the audio recording.

œ Press the SET button once more to

end the recording. You are returned to the Audio Recording Screen.

œ When the remaining recording time

becomes little, a countdown of the remaining recording time is shown.

œ To return to the Shooting Option

Setting Screen, in the Audio Recording Screen mode, press the

MENU button, or select the C

icon and press the SET button.

HINT

œ Each single recording can consist of up to 7 minutes of recording time.

You can perform an audio recording even after turning off the Audio Recording Screen

œ After displaying the Audio Recording Screen and æ is selected (step 4),

you can set the main switch to [à] to put the digital camera into the audio recording standby mode. In this condition, just press the SET button to start recording. Or, after turning on the power to the digital camera, if you set the

selector dial to [P], even when the LCD monitor is off, you can press the

SET button to start recording.

REC (recording) indicator

Recording time (min:sec)

AUDIO REC 00:08 4

RECORDING

STOP

Remaining recording time

English

BASIC SHOOTING FUNCTIONS

Setting the focus

The focus setting can be changed depending on the distance to the subject.

Select the desired shooting mode

(see page 59).

œ If the Shooting Information Screen

appears, press the MENU button to exit it.

Press the focus button.

œ The currently set focus setting is

shown on the LCD monitor. No icon: For photography at normal

focus.

c: For close-up photography (10 to 50 cm) å: For photography at distant focus (7 meters or more). Select this

setting when you know the distance to your subject beforehand or when photographing a subject that is difficult to get into focus.

!: The focus can be set to any distance from 10 cm to ∞ (manual

focus). When manual focus is selected, the set distance is shown to the left of the ! icon.

Press the focus button to set the

desired focus mode.

œ Each time the focus button is

pressed, the focus mode changes.

œ If ! is selected, press [j] or [l]

on the arrow button to set the desired focus distance.

3.1 1/50

<Example: Still image shooting mode>

Focus setting

Focus button

LCD monitor

English

Take the picture.

<Shooting without using the LCD monitor> 1 Press the focus button.

The LCD monitor turns on briefly to show the currently set focus

mode.

2 Press the focus button within 5 seconds to set the desired focus

mode.

HINT

œ The shortest distance for macro photography is 10 cm if [W] (Wide) on the

zoom switch is pressed, and 40 cm if [T] (Tele) is pressed.

œ In the manual focus mode, the shortest distance for taking pictures is 10

cm when [W] (Wide) on the zoom switch is pressed until it stops (wide angle), and 40 cm when [T] (Tele) is pressed until it stops (telephoto).

œ The focus distance indication shows the distance between the lens surface

and the subject.

œ The focus distance indication shows the distance between the lens surface

and the subject, but in some cases there may be a slight variance from the actual distance.

œ When shooting a close-up subject with the manual focus or macro

photography, use the LCD monitor to confirm the focus and compose the photo.

English

BASIC SHOOTING FUNCTIONS

Using the flash

The flash is used not only for taking pictures where there is insufficient light, but also when the subject is in shade or in backlight conditions. Your camera has four modes of operation (automatic flash mode, forced flash mode, flash off mode, and red-eye reduction mode). Flash photography is possible only in the still image shooting mode.

Set the camera to the still image

shooting mode (see page 59).

Press the flash button.

œ The current flash mode is shown on

the LCD monitor.

Flash button

Flash

English

Press the flash button to select the

flash mode.

œ Each time the flash button is

pressed, the flash mode icon changes.

No icon: The digital camera will

detect the subject brightness and use the flash only when required. In a backlight situation, if only the center of the image is very dark, the flash will operate to compensate (auto flash).

d: The flash will operate with every image captured regardless of

the conditions. Use this setting under backlight conditions, when the subject is in shade, under fluorescent lighting conditions, etc. (forced flash).

j: The flash will not operate even in dark situations. Use this setting

when capturing an image in a location where flash photography is prohibited, or when shooting a night landscape scene (flash off).

È: The digital camera will detect the subject brightness and use the

flash only when required. At this time the flash will operate in a manner that reduces the red reflection (“red-eye”) in the subject’s eyes.

BASIC

3.1 1/50

Flash mode

English

BASIC SHOOTING FUNCTIONS

Press the shutter release button.

œ The image is captured in the desired flash mode.

<Shooting without using the LCD monitor> 1Press the flash button.

œ The LCD monitor turns on briefly to show the currently set flash

mode.

2Press the flash button within 5 seconds to set the desired flash

mode.

HINT

œ At normal focus, the effective flash range is 0.5 to 3.1 meters (widest lens

setting) and 0.5 to 1.7 meters (telephoto lens setting). At macro focus, the effective flash range is 0.15 to 0.5 meters (widest lens setting) and 0.4 to

0.5 meters (telephoto lens setting).

NOTE In the automatic flash mode...

œ In the automatic flash mode using the LCD monitor, when the shutter

release button is depressed halfway, a f icon appearing in the upper

right area of the LCD monitor indicates that the flash will operate.

English

Shooting without using the LCD monitor

Compose the desired image by looking through the viewfinder. Compared to capturing images using the LCD monitor, this method uses less battery pack power.

Set the shooting mode (see page

59).

Set the main switch to [à].

Look through the viewfinder and

position the subject in the center.

Press the shutter release button.

Main switch

Viewfinder

English

BASIC SHOOTING FUNCTIONS

Using the zoom

There are two zoom functions: optical zoom and digital zoom. You can specify whether or not the digital zoom can be activated when shooting.

The digital zoom can be used when the resolution is set to D or less.

Make the zoom setting (see page

120), and point the camera lens at the subject.

Press [T] or [W] on the zoom switch

to compose the desired image.

[T] : Zoom in on the subject. [W] : Zoom out. œ When the zoom switch is pressed,

the zoom bar appears on the LCD monitor.

œ When the optical zoom factor

becomes 3x, zooming stops temporarily. When [T] on the zoom switch is pressed again, the mode changes to the digital zoom mode and zooming continues (if digital zooming is enabled).

Press the shutter release button.

NOTE

œ During video clip shooting, the optical zoom is disabled. œ The digital zoom cannot be used when you are shooting without using the

LCD monitor.

When optical zoom only is enabled

When both optical and digital zoom are enabled

Zoom switch

Zoom bar

Pointer

Optical zoom

Digital zoom (Yellow)

English

BASIC MODE

Master the shooting functions in the basic mode.

Select the preset setting that matches your shooting conditions (Scene Select function)

You can select from various preset settings (aperture, shutter speed, etc.) for specific shooting conditions.

Preset settings

Still image

shooting

Night scene

Sequential

shots

mode

Set to a shooting mode (see page

59), and display the Shooting Setting Screen (see page 39).

Select the scene select menu.

shooting

mode

Sports F

Portrait x

Full auto B

Video clip

shooting

mode

For shooting running and jumping, fast-moving subjects.

Perfect for shots with the subject at the center. For amusement park and fireworks displays at

——

night, produces a good balance between the bright lights and the dark background.

The camera makes settings suitable for conditions.

Features

E 12

SCENE SELECT FULL AUTO

<Example: Still image shooting

mode>

English

BASIC MODE

Select the desired icon, and press the SET button.

F: Sports x: Portrait G: Night scene

B: The camera makes settings suitable for conditions (full auto).

NOTE About other settings

œ When setting a scene selection function, the following settings are fixed.

Exposure control: Ï Suitable program AE for each preset setting

ISO sensitivity: Ä

œ When capturing images using the night scene G setting, use a tripod or

other method to stabilize the camera.

To return to normal shooting

œ Select B from the scene select menu, and press the SET button.

English

Setting the resolution

If the resolution is increased, the image quality will improve, but the remaining number of images that can be taken will decrease. Select the resolution according to the desired image quality and purpose.

Display a Shooting Setting Screen

(see page 39).

Select the desired resolution from

the resolution menu.

A: 3,264 x 2,448 pixels B: 2,880 x 2,160 pixels C: 2,288 x 1,712 pixels

Ò: 1,600 x 1,200 pixels 4: 640 x 480 pixels 2: 320 x 240 pixels 0: 160 x 120 pixels

œ The possible resolution settings for each shooting mode are as follows:

Resolution (units: pixels)

[Icon displayed on LCD monitor]

3,264 x

2,880 x

2,160

Not

available

Not

available

2,288 x

1,712

Yes Yes Yes

Not

available

Shooting

mode

2,448

Still image

Sequential shot

Video clip Not

Yes Yes Yes Yes Yes

Not

available

E 12

RESOLUTION 2288¶1712

<Example: Still image shooting

1,600 x 1,200 Ò

Not

available

640 x

480

Not

available

mode>

320 x

240

Not

available

Not

available

Yes Yes

160 x

120

Not

available

Not

available

Press the SET button.

œ The selected resolution is set.

English

BASIC MODE

HINT

œ At A and B resolutions, the camera processes the image internally to

produce a 3,264 x 2,448-pixel or 2,880 x 2,160-pixel image.

œ When capturing images at A B resolution, it takes 5 seconds after the

shutter release button is pressed before the data is recorded.

NOTE About the resolution and compression settings (see page 81)

œ The image captured by a digital camera consists of a collection of small

dots. The resolution refers to the number of these dots, and the greater the number, the higher the image quality. As the resolution increases, the size of the resulting data also increases, and the number of images that can be captured decreases. To compensate for this, this digital camera is able to compress the data. This digital camera uses JPEG compression. If JPEG compression is used, when the image is played back, an extremely small portion of it is lost. The higher the compression rate, the more of the original image is lost. Therefore, this digital camera also allows you to store image data without any compression to ensure that none of the original image is lost. This is the d mode. Since the image data is large when the d mode is used, compared to JPEG compression, the digital camera requires more time both to store the data after the shutter release button is pressed and to display the image in the playback mode.

English

Using the self-timer

Display the Still Image Shooting

Setting Screen (see page 39).

Select the self-timer on icon U

from the self-timer menu.

V: Turns off the self-timer function. U: Turns on the self-timer function.

Press the SET button.

œ This completes the self-timer setting.

Press the shutter release button.

œ When the shutter release button is

pressed, the self-timer indicator and standby indicator will light for about 7 seconds, flash for about 3 seconds, and then the image is captured.

HINT

œ If the shutter release button is pressed again before the image is captured,

the self-timer mode is stopped temporarily. Press the shutter release button one more time to restart the self-timer.

œ To cancel the self-timer mode, select the self-timer off icon V and press

the SET button.

œ If the SHUTTER operational sound is set to on (see page 162), a warning

tone (beep-beep-beep) sounds 3 seconds before the image is captured.

E 12

SELF-TIMER OFF

Shutter release button

Self-timer indicator

Tripod stand hole

NOTE

œ When using the self-timer function, be sure to use a tripod or place the

digital camera on a level, stable surface.

English

BASIC MODE

Setting the compression rate

Use the procedure below to set the compression rate. Even if the same resolution is used, you can change the compression setting to decrease the image data size so that you can capture more images, or increase the image data size for no loss in image quality.

Display a Shooting Setting Screen

(see page 39).

Select the desired compression rate

from the compression menu.

b: Stores the data with a low

compression (high quality).

a: Stores the data with an

extremely low compression (super high quality).

c: Stores the data with moderate

compression (normal quality).

d: Stores the data in TIFF format

(no compression for highest quality).

E 12

COMPRESSION FINE

<Example: Still image shooting

mode>

English

œ The possible compression rate settings for each shooting mode are

shown in the following table.

Resolution (units: pixels)

[Icon displayed on LCD monitor]

3,264 x

2,880 x

2,288 x

1,600 x

1,200

Not

available

640 x

480

Not

available

Still image

Shooting

mode

Sequential

shots

Press the SET button.

2,448

2,160

Not

available

Not

available

Not

available

Not

available

1,712

Yes

Yes Yes Yes

a Yes Yes Yes Yes Yes

b Yes Yes Yes Yes Yes

c Yes Yes Yes Yes Yes

Not

available

Not

available

Not

available

Not

available

œ The selected compression rate is set.

320 x

240

Not

available

Not

available

Not

available

Not

available

Not

available

Not

available

Not

available

160 x

120

Not

available

Not

available

Not

available

Not

available

Not

available

Not

available

Not

available

English

PLAYBACK MODE SETTINGS

This camera has playback modes for still images, sequential shots, video clips and audio recordings.

Still image playback mode:

For playing back still images and voice memos. Saved enlarged images (with the playback zoom) (see page 94) and copied images (see page 126) can also be viewed in the still image playback mode.

Sequential shots playback mode:

For viewing sequential shots images.

Video clip playback mode:

For viewing video clips.

Audio recording playback mode:

For listening to audio recordings.

Set the main switch to [Ô].

Turn the selector dial to the desired

playback mode.

[W]: Still image playback mode [Y]: Sequential shots playback mode [X]: Video clip playback mode [P]: Audio playback mode

(The Playback Option Setting Screen appears.)

Main switch

Selector dial

English

Playing back audio recordings

Turn the selector dial to [P].

œ The Playback Option Setting Screen

appears.

Select the audio playback icon M,

and press the SET button.

œ The audio recording playback mode

screen appears.

œ To continue the procedure, please

see page 91.

AUDIO 0001 5:40 0006 2:34 0002 1:20 0007 5:06 0003 3:45 0008 1:20 0004 6:01 0005 0:23 SELECT BACK TO MENU

AUDIO

COLOR ADJUSTMENT CLOCK SET BEEP LANGUAGE TV SYSTEM REFORMAT

English

PLAYING BACK STILL IMAGES

Play back still images one by one

Select the still image playback mode (see page 83).

Press [d] or [c] on the arrow button.

To play back the previous image : Press [d] To play back the next image : Press [c]

Play back a voice memo

œ Display an image, and press the SET

button. The voice memo is played back.

œ Display the Still Image Playback Setting

Screen (see page 39), select the volume

icon N, and press [d] or [c] on the

arrow button to adjust the playback volume.

9-image display playback

Select the still image playback

mode (see page 83).

Press [W] ([z]) on the zoom

switch.

œ The 9-image display appears. œ The number displayed on each

image is its file name (image number).

9-IMAGE DISPLAY ZOOM PROTECT ERASE EDIT PHOTO PRINT SETTING SLIDESHOW

Softer Louder

Volume bar

File name (image number)

0001 0002 0003

0004 0005 0006

0007 0008

Orange frame

0009

English

Use the arrow button to move the orange frame to the desired

image, and press [T] ([v]) on the zoom switch.

œ The selected image is displayed full screen. œ Instead of pressing [T] ([v]) on the zoom switch, you can also press

the SET button to show the image full screen.

HINT To jump forward or backward 100 images (if there are more than 100 images)

Display the 9-image display playback screen.

1 2 Press the flash button.

œ The frame around the images turns dark blue. Press either [d] or [c] on the arrow button.

œ Press [d] to move back 100 images. œ Press [c] to move forward 100 images. œ The frame around the images returns to black. œ To jump another 100 images, repeat steps 2 and 3.

4 Use the arrow button to move the orange frame to the desired image, and

press [T] ([v]) on the zoom switch or the SET button. œ The selected image is displayed full screen.

To access the 9-image display from the Playback Setting Screen...

Display the Playback Setting Screen (see page 39).

Select the 9-image display icon ;, and press the SET button.

English

PLAYING BACK SEQUENTIAL SHOTS

Select the sequential shots playback mode (see page 83).

Press [d] or [c] on the arrow button.

To play back the previous image : Press [d] To play back the next image : Press [c]

Press [W] ([z]) on the zoom

switch.

œ The 9-image display appears. œ The procedure from this point is the

same as step 3 on page 86.

œ When a voice memo has been

added to an image, you can play it back by displaying the image and then pressing the SET button.

œ To adjust the playback volume,

display the Sequential Shots Playback Setting Screen (see page

39), select the volume icon N,

and press [d] or [c] on the arrow button.

HINT To change to a different sequential shots folder œ Perform step 3 above, and step 3 on page 86. If the 9-image display appears in step 1 œ Perform step 3 on page 86, and then return to step 2 above. To quickly change to a different sequential shots folder

œ In step 2, with the Playback Setting Screen or Playback Information Screen

not displayed, press [j] or [l] to change to the previous or following sequential shots folder respectively.

To jump forward or backward 100 folders

œ The procedure is the same as when playing back still images.

Sequential shots folder number

Orange frame

0001 0002 0003

0004 0005 0006

0007 0008 0009

English

PLAYING BACK VIDEO CLIPS

Select the video clip playback mode (see page 83).

Play back the video clip.

Normal playback

œ Press the SET button. If the Playback Setup Screen appears, press

the SET button again to start playback.

œ Pressing [d] during a video clip playback will start reverse playback

(the audio will not be heard).

To pause playback

œ Press the SET button to pause playback; press the SET button again

to continue playback.

To play back one image at a time

œ While video clip playback is paused, you can press [c] on the arrow

button to view the frames in order, or [d] to view them in reverse order.

To accelerate playback

œ 2x fast forward playback: During normal speed playback, press [c]. œ 20x fast forward playback: During 2x playback, press [c]. œ Return to normal speed playback: During 20x playback, press [c].

* Pressing [d] will start reverse playback. The audio will not be heard.

To return to the beginning of the video clip

œ To jump to the beginning of the video clip during playback: Press [j]. œ To jump to the end of the video clip during playback: Press [l]. œ To jump to the beginning of the next video clip: Pause playback, then

press [l].

œ To jump to the beginning of the previous video clip: Pause playback,

then press [j].

To adjust the volume

œ Display the Playback Setting Screen, select the volume icon N, and

press [d] or [c].

œ To change to a different video clip, select a different video clip from

the 9-image display.

English

PLAYING BACK VIDEO CLIPS

Video clip 0001

Video clip start Video clip end

Video clip 0002 Video clip 0003

SET button: Play

[j]: Display start of video clip [l]: Display end of video clip

Press [W] ([z]) on the zoom

switch.

œ The 9-image display appears. œ The procedure from this point is the

same as step 3 on page 86.

SET button: Play

[l]: Display start of video clip 0002 SET button: Play from start of video clip 0001

[j]: Display start of

video clip 0002

Orange frame

0001 0002 0003

0004 0005 0006

0007 0008 0009

To jump forward or backward 100 video clips (if there are more than 100 video clips)

œ With the 9-image display showing, follow these steps.

1 Press the flash button. 2 Press either [d] or [c].

œ To jump another 100 video clips, repeat steps 1 and 2.

English

HINT To view video clips on your computer

œ You can view video clips taken with this camera on your computer using

QuickTime Ver. 3.0 or later from Apple.

œ By using the QuickTime Plug-in included with QuickTime, you can also play

back your video clips on your Internet browser.

œ QuickTime5 for Windows and Macintosh is supplied with the included

CD-ROM (Sanyo Software Pack).

œ Online information about QuickTime can be found at

http://www.apple.com/quicktime/.

English

LISTENING TO AUDIO RECORDINGS

Set the digital camera to the audio recording playback mode (see

page 83).

Press [j] or [l] on the arrow button

to select the desired audio recording, and press the SET button.

œ The Audio Recording Playback

Screen for the selected audio recording appears.

Select the audio playback icon Ô,

and press the SET button.

œ Playback starts.

To pause playback

œ Press the SET button to interrupt

playback; press it again to continue playback.

AUDIO

0001 5:40 0006 2:34

0002 1:20 0007 5:06 0003 3:45 0008 1:20 0004 6:01 0005 0:23 SELECT BACK TO MENU

AUDIO 1:20 100-0008 617KB

2003.01.23 PLAY

PROTECT ERASE VOLUME EXIT

To fast forward or rewind

œ Fast forward: During playback,

press [c].

œ Rewind: During playback, press [d].

* The audio will not be heard.

œ If [c] is pressed during fast forward

or rewind, playback will start.

English

AUDIO 01:15 100-0008 617KB

2003.01.23

PLAYBACK

STOP

To adjust the volume

1 On the Audio Recording Playback Screen, select the volume icon

2 Press [d] or [c] to adjust the volume.

To select a different audio recording

œ On the Audio Recording Playback Screen, press the MENU button.

The Audio Recording Select Screen appears; select the desired audio recording and play it back.

To stop playback

œ During playback, press the SET button. Playback will stop, and you

are returned to the Audio Recording Playback Screen.

English

USING THE VARIOUS PLAYBACK FUNCTIONS

Automatic playback (slideshow)

Still images can be automatically played back in a slideshow fashion. If voice memos are attached, they are also played back at the same time.

Display the Still Image Playback

Setting Screen (see page 39).

Select the slideshow icon ã, and

press the SET button.

œ The Slideshow Screen appears.

[Slide time]

1 Select “TIME”, and press the SET

button.

2 Press [j] or [l] on the arrow button

to select the time that each image is displayed.

3 Press the SET button.

[Slide effect]

1 Select “EFFECT”, and press the

SET button.

2 Press [j] or [l] on the arrow button

to select the desired wipe effect.

3 Press the SET button.

Select “START”, and press the SET button.

œ Slideshow playback begins. œ The still images or video clips are played back in the order in which

they were recorded.

œ To interrupt the slideshow, press the MENU button, the SET button, or

an arrow button.

œ After all the images have been played back, the slideshow ends. œ For continuous (loop) slideshow playback (up to 12 hours), in step 3

press the shutter release button instead of the SET button.

9-IMAGE DISPLAY ZOOM PROTECT ERASE EDIT PHOTO PRINT SETTING

SLIDESHOW

VOLUME

SLIDESHOW

TIME 4S

EFFECT OFF

START

EXIT

English

Magnifying (zooming in) the image

The saved images can be magnified for viewing during playback.

Display the image that you want to

magnify.

œ For a video clip, pause playback at

the place you wish to magnify.

Press [T] ([v]) on the zoom

switch.

œ Magnification is enabled. œ The image is magnified, and the

central portion of the image is displayed.

œ You can use the arrow button to

view different parts of the magnified image.

Magnify the image further.

To magnify:

Press [T] ([v]) on the zoom switch.

To return to normal size:

Press [W] ([z]) part on zoom switch.

ZOOM

MOVE ZOOM I/O SHUTTER FOR SAVE

English

USING THE VARIOUS PLAYBACK FUNCTIONS

HINT

œ The maximum degree of magnification will depend on the resolution of the

original image.

œ The maximum magnification for A resolution is about 51 times. œ If the image has been rotated, it will be returned to its original orientation

and then enlarged.

œ One scene (still image) of a paused video clip can be enlarged; however, a

video clip cannot be played while enlarged.

HINT The magnified portion of the image can be saved as a separate image.

œ Press the shutter release button. The magnified portion is saved as a new

still image.

To magnify the image from the Playback Setting Screen

Display the Playback Setting Screen (see page 39).

2 Select the zoom icon O, and press the SET button.

œ After the screen in step 2 on page 94 appears, you can magnify the

image further by pressing [T] ([v]) on the zoom switch.

English

Rotating an image

Captured images can be rotated to the correct orientation for viewing.

Display the still or sequential shots image you wish to rotate.

Display the Playback Setting

Screen (see page 39).

Select the edit photo icon r (or

ú), and press the SET button.

œ The Edit Photo Screen appears.

Select the rotate image icon Ç,

and press the SET button.

œ The Rotate Image Screen appears.

t: Rotates image clockwise 90

degrees

s: Rotates image

counterclockwise 90 degrees

Select the rotate right icon t or

rotate left icon s, and press the SET button.

œ Each time the SET button is

pressed, the image is rotated 90 degrees.

EDIT PHOTO

ADD AUDIO ADD TEXT RESIZE

ROTATE

EXIT

<Example: Still Image Playback

ROTATE

RIGHT

LEFT EXIT

Mode>

English

USING THE VARIOUS PLAYBACK FUNCTIONS

Playing back images on a TV set

By connecting the digital camera to a television set, you can view the captured images on the TV screen.

Connections

Connect the supplied AV cable from the DIGITAL/AV terminal on the digital camera to the AUDIO and VIDEO input terminals on the TV.

To the VIDEO

Yellow plug

AV cable (supplied)

input terminal

Plug

To the DIGITAL/ AV terminal

* If the dedicated AV cable is unplugged/plugged in, the Playback Setting

Screen is canceled.

White plug

To the AUDIO input terminal

Switch input to VIDEO

Playback

œ After connecting the digital camera to the television, set the TV input switch

to VIDEO input.

œ The playback method is the same as when viewing images on the LCD

monitor.

œ When an AV cable is connected, the LCD monitor display appears smaller

than usual.

œ If the TV system setting is set to PAL, no image appears on the camera’s

LCD monitor.

œ The same playback procedure as when playing back with the camera is

used to play back voice memos and audio recordings as well.

œ The sound output from the digital camera is monaural.

Voice memo playback: see page 87 Audio recording playback: see page 91

English

Sanyo VPC-AZ3 EX User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
