INSTRUCTION MANUAL
BIOMEDICAL FREEZER
MDF-U730M
CONTENTS
INTRODUCTION P. 2
PRECAUTIONS FOR SAFE OPERATION P. 3
ENVIRONMENTAL CONDITIONS P. 7
FREEZER COMPONENTS P. 8
Control panel P. 10
INSTALLATION SITE P. 11
INSTALLATION P. 12
START-UP OF UNIT P. 12
TEMPERATURE SETTING P. 13
KEY LOCK FUNCTION P. 13
REMOTE ALARM TERMINAL P. 14
ALARM TEMPERATURE SETTING P. 15
ALARMS & SAFETY FUNCTIONS P. 16
DEFROSTING P. 17
MAINTENANCE P. 17
REPLACEMENT OF BATTERY P. 18
TROUBLESHOOTING P. 19
DISPOSAL OF UNIT P. 20
TEMPERATURE RECORDER (OPTION) P. 25
SPECIFICATIONS P. 28
PERFORMANCE P. 29
SAFETY CHECK SHEET P. 30
1
INTRODUCTION
■ Read this manual carefully before using the appliance and follow the instructions for safety operation.
■ Sanyo never guarantee any safety if the appliance is used for any objects other than intended use or
used by any procedures other than those mentioned in this manual.
■ Keep this manual in an adequate place to refer to it as necessary.
■ The contents of the manual will be subjected to change without notice due to the improvement of
performance or functions.
■ Contact Sanyo sales representative or agent if any page of the manual is lost or page order is incorrect.
■ Contact Sanyo sales representative or agent if any point in this manual is unclear or if there are any
inaccuracies.
■ No part of this manual may be reproduced in any form without the expressed written permission of
Sanyo.
2
PRECAUTIONS FOR SAFE OPERATION
It is imperative that the user complies with this manual as it contains
important safety advice.
Items and procedures are described so that you can use this unit correctly and safely.
If the precautions advised are followed, this will prevent possible injury to the user and
any other person.
Precautions are illustrated in the following way:
WARNING
Failure to observe WARNING signs could result in a hazard to personnel
possibly resulting in serious injury or death.
CAUTION
Failure to observe CAUTION signs could result in injury to personnel and
damage to the unit and associated property.
Symbol shows;
Be sure to keep this manual in a place accessible to users of this unit.
< Label on the unit >
this symbol means caution.
this symbol means an action is prohibited.
this symbol means an instruction must be followed.
This mark is labeled on the cover in which the electrical components of high voltage
are enclosed to prevent the electric shock.
The cover should be removed by a qualified engineer or a service personnel only.
3
PRECAUTIONS FOR SAFE OPERATION
Do not use the unit outdoors. Current leakage or electric shock may result if the unit is exposed to
rain water.
Only qualified engineers or service personnel should install the unit. The installation by
unqualified personnel may cause electric shock or fire.
Install the unit on a sturdy floor and take an adequate precaution to prevent the unit from
turning over. If the floor is not strong enough or the installation site is not adequate, this may result
in injury from the unit falling or tipping over.
Never install the unit in a humid place or a place where it is likely to be splashed by water.
Deterioration of the insulation may result which could cause current leakage or electric shock.
Never install the unit in a flammable or volatile location. This may cause explosion or fire.
Never install the unit where acid or corrosive gases are present as current leakage or electric
shock may result due to corrosion.
Always ground (earth) the unit to prevent electric shock. If the power supply outlet is not
grounded, it will be necessary to install a ground by qualified engineers.
Never ground the unit through a gas pipe, water main, telephone line or lightning rod. Such
grounding may cause electric shock in the case of an incomplete circuit.
Connect the unit to a power source as indicated on the rating label attached to the unit. Use
of any other voltage or frequency other than that on the rating label may cause fire or electric shock.
Never store volatile or flammable substances in this unit if the container cannot be sealed. These
may cause explosion or fire.
Do not insert metal objects such as a pin or a wire into any vent, gap or any outlet on the unit.
This may cause electric shock or injury by accidental contact with moving parts.
Use this unit in safe area when treating the poison, harmful or radiate articles. Improper use
may cause bad effect on your health or environment.
Turn off the power switch (if provided) and disconnect the power supply to the unit prior to any
repair or maintenance of the unit in order to prevent electric shock or injury.
Do not touch any electrical parts (such as power supply plug) or operate switches with a wet
hand. This may cause electric shock.
WARNING
4
PRECAUTIONS FOR SAFE OPERATION
Ensure you do not inhale or consume medication or aerosols from around the unit at the time of
maintenance. These may be harmful to your health.
Never splash water directly onto the unit as this may cause electri c sho ck or short circuit.
Never put containers with liquid on the unit as this may cause electric shock or short circu it when
the liquid is spilled.
Never bind, process, or step on the power supply cord, or never damage or break the power
supply plug. A broken supply cord or plug may cause fire or electric shock.
Do not use the supply cord if its plug is loose. Such supply cord may cause fire or electric shock.
Never disassemble, repair, or modify the unit yourself. Any such work carried out by an
unauthorized person may result in fire, or electric shock or injury due to a malfunction.
Disconnect the power supply plug if there is something wrong with the unit. Continued
abnormal operation may cause electric shock or fire.
When removing the plug from the power supply outlet, grip the power supply plug, not the cord.
Pulling the cord may result in electric shock or fire by short circuit.
Disconnect the power supply plug before moving the unit. Take care not to damage the power
cord. A damaged cord may cause electric shock or fire.
Disconnect the power plug when the unit is not used for long periods. Keeping the connection
may cause electric shock, current leakage, or fire due to the deterioration of insulation.
If the unit is to be stored unused in an unsupervised area for an extended period, ensure that
children do not have access and that doors cannot be closed completely.
The disposal of the unit should be accomplished by appropriate personnel. Remove doors to
prevent accidents such as suffocation.
Do not put the packing plastic bag within reach of children as suffocation may result.
WARNING
5
PRECAUTIONS FOR SAFE OPERATION
Use a dedicated power source (a dedicated circuit with a breaker) as indicated on the rating label
attached to the unit. A branched circuit may cause fire resulting from abnormal h eating.
Connect the power supply plug to the power source firmly after removing the dust on the plug.
A dusty plug or improper insertion may cause a heat or ignition.
Never store corrosive substances such as acid or alkali in this unit if the container cannot be
sealed. These may cause corrosion of inner components or electric parts.
Check the setting when starting up of operation after power failure or turning off of power
switch. The stored items may be damaged due to the change of setting.
Be careful not to tip over the unit during movement to prevent damage or injury.
Prepare a safety check sheet when you request any repair or maintenance for the safety of service
personnel.
CAUTION
6
ENVIRONMENTAL CONDITIONS
This equipment is designed to be safe at least under the following conditions (based on the IEC-61010-1):
■ Indoor use;
■ Altitude up to 2000 m;
■ Ambient temperature 5
■ Maximum relative humidity 80% for temperature up to 31
o
at 40
C;
■ Mains supply voltage fluctuations not to exceed ±10% of the nominal voltage;
■ Other supply voltage fluctuations as stated by the manufacturer;
■ Transient overvoltages according to Installation Categories (Overvoltage Categories) II; For mains
supply the minimum and normal category is II;
■ Pollution degree 2 in accordance with IEC 60664.
o
C to 40oC
o
C decreasing linearly to 50% relative humidity
7
FREEZER COMPONENTS
11
10
9
8
7
6
5
17
12 14
18
13
1
2
3
4
15
16
<Inside of the front cover>
8
FREEZER COMPONENTS
1. Lock: Turn clockwise to 180
2. Magnetic door gasket: This prevent the cold air from escaping. Always keep clean.
3. Handle: Always grip this handle to open and close the outer door.
4. Drain hose: The drain hose can be used to collect the defrosted water. See page 17 for usage.
5. Leveling foot: The height of the freezer can be adjusted by this screw type foot. Keep the unit in
level at the installation.
6. Caster: 4 casters are provided to facilitate moving of the cabinet. For the installation, adjust the
leveling foot so that the front 2 casters cannot contact with the floor.
7. Drain cap: These are drain in defrosting and drain cap. See page 17 for usage.
8. Shelf: Items to be stored in the chamber must be placed on the shelves. The maximum storage
weight for each shelf is 50kg.
9. Access port: This is used for leading the measuring cable from the freezing chamber to the outside.
A total of two(2) are provided. ; left side and top of the freezer.
10. Door latch: The lock the door, turn this latch downward. A padlock is also available.
11. Temperature sensor: Located on the rear of the chamber.
12. Control panel: The operation status is displayed on this panel. And the temperature setting is
available through this panel. Refer to page 10 for details.
13. Front cover: Open this cover when connecting the remote alarm.
14. Space for temperature recorder: Space for an automatic temperature recorder (optional
component) is available separately. See page 25 “TEMPERATURE RECORDER (OPTION)”.
15. Battery switch: Switch for battery used for power failure alarm. Always keep ON. Turn the
switch OFF when the unit is in no use for a long period (more than 1 month).
16. Remote alarm terminal: Used to notify an alarm condition of the unit to remote location. See
page 14 for details.
17. Power switch (back side): This is for turning ON/OFF the power to the unit. ON – “I” OFF – “○”
18. Fixture (back side): These keep the adequate apace between the unit and wall, and also can be
used for fixing the unit.
o
with a key and the outer door is securely locked.
9
