Sanyo CE19LD95-B Instruction Manual

INSTRUCTION MANUAL

Colour television

CE19LD95-B

Please read this Instruction book before using your television. We wish you many hours of pleasure from your new television.

Problems with set-up?

Call 0870 240 7475

Contents

Features ............................................................... 3

Accessories ......................................................... 3

Introduction ........................................................... 4

Preparation ........................................................... 4

Safety Precautions ............................................... 4

Power Source .................................................. 4

Power Cord ...................................................... 4

Moisture and Water .......................................... 4

Cleaning ............................................................ 4

Ventilation ......................................................... 4

Heat and Flames ............................................... 4

Lightning ........................................................... 5

Replacement Parts ............................................ 5

Servicing ........................................................... 5

Waste Disposal ................................................. 5

Information for Users in European Union

Countries .......................................................... 5

Disconnecting the Device ................................. 5

Headphone Volume ........................................... 5

Installation ......................................................... 5

LCD Screen ...................................................... 5

Warning ............................................................ 5

Overview of the Remote Control .......................... 6

LCD TV and Operating Buttons ............................ 7

Viewing the Connections ..................................... 8

Power Connection .............................................. 10

Aerial Connection ............................................... 10

Connecting the LCD TV to a PC .......................... 11

Connecting to a DVD Player ............................... 12

Using Other Connectors ..................................... 13

Connecting Other Equipment via Scart ............... 14

Inserting Batteries in the Remote Control Handset.... 15

Operating Range for the Remote Control ............ 15

Switching the TV On/Off .................................... 16

To Switch the TV On ...................................... 16

To Switch the TV Off ...................................... 16

Input Selection .................................................... 16

Basic Operations ................................................ 17

Operation with the Buttons on the TV ............ 17

Volume Setting ............................................ 17

Programme Selection .................................. 17

Entering Main Menu ..................................... 17

AV Mode ..................................................... 17

Operation with the Remote Control ................. 17

Volume Setting ............................................ 17

Programme Selection (Previous or Next

Programme)................................................. 17

Programme Selection (Direct Access) ........ 17

Initial Settings ...................................................... 18

General Operation .............................................. 18

Information Banner ......................................... 18

Electronic Programme Guide (EPG)................. 19

Displaying the Subtitles ................................... 20

Digital Teletext ................................................. 20

Over Air Download ......................................... 21

Widescreen .................................................... 21

English - 1 -

IDTV Menu System ............................................. 21

Channel List .................................................... 21

Navigating the Entire Channel List ............... 22

Deleting the Channels in the Channel List ... 22

Renaming Channels .................................... 22

Adding Locks to Channels .......................... 22

Setting Favourites ....................................... 23

On Screen Help ........................................... 23

Installation ....................................................... 23

Add New Channels ..................................... 24

Automatic Search ................................. 24

Manual Search ...................................... 24

Configuration .................................................. 25

Audio Language .......................................... 25

Subtitle ........................................................ 25

Favourite Mode ........................................... 25

EPG Preference .......................................... 26

Receiver Upgrade ....................................... 26

Automatic Download (Automatic Upgrade) 26 Search for New Version (Manual

Upgrade) ............................................... 26

Parental Settings ......................................... 26

Timers ............................................................. 27

Language ........................................................ 28

TV Setup ......................................................... 29

Common Interface ........................................... 29

Analogue TV Menu Map ..................................... 30

Navigating the Analogue TV Menu System ......... 31

Analogue TV Menu System ................................ 31

Sound Menu.................................................... 31

Volume ........................................................ 31

Balance ....................................................... 31

Sound Mode ................................................ 31

AVL ............................................................. 31

Effect .......................................................... 31

Equalizer ..................................................... 32

HP Volume ................................................... 32

Store ........................................................... 32

Picture Menu ................................................... 32

Picture Mode ............................................... 32

Brightness/Contrast/Colour/ ........................ 32

Sharpness/Tint ............................................ 32

Colour Temp ................................................ 32

Room Lighting.............................................. 32

Picture Zoom ............................................... 32

Store ........................................................... 32

Features Menu ................................................ 33

Sleep Timer ................................................. 33

Language .................................................... 33

Child Lock ................................................... 33

Menu Colour ................................................ 33

Favourite Mode ........................................... 33

Install Menu ..................................................... 33

Programming ............................................... 33

Programme............................................ 33

Band ..................................................... 33

Channel ................................................. 34

Standard ............................................... 34

Colour System ...................................... 34

Search .................................................. 34

VCR Mode ............................................. 34

Decoder ................................................ 34

Store ..................................................... 34

A.P.S. .......................................................... 34

A.P.S. Country ............................................. 34

Teletext Region............................................ 35

Install Menu in AV modes ............................ 35

Programming ......................................... 35

Colour System ...................................... 35

Program Table ............................................. 35

Name .................................................... 35

Move ..................................................... 35

Delete.................................................... 36

APS (Auto Programming System) ......... 36

Favourite Mode ..................................... 36

Program Lock........................................ 36

Enter PIN ............................................... 36

PC Mode Menu System ....................................... 37

Displaying TV Information ................................... 38

Mute Function ..................................................... 38

Personal Preference .......................................... 38

Zoom Modes ....................................................... 38

Teletext ............................................................... 39

Tips .................................................................... 40

Appendix A: PC Input Typical Display Modes ...... 41

Specifications ..................................................... 42

Pin Specifications ............................................... 43

Important Instructions ......................................... 44

Change PIN ........................................... 36

Sound Menu.................................................... 37

Feature Menu.................................................. 37

PC Picture Menu.............................................. 37

Geometry Menu........................................... 37

H. (Horizontal) Position .......................... 37

V. (Vertical) Position ............................. 37

Clock ..................................................... 37

Phase.................................................... 37

Auto Adjustment ................................... 37

Auto ............................................................ 38

4:3 ............................................................... 38

16:9 ............................................................. 38

Cinema ........................................................ 38

Subtitle ........................................................ 38

Screen Care ................................................... 40

No Power ........................................................ 40

Poor Picture .................................................... 40

Input Sources ................................................. 40

CI Module ........................................................ 40

English - 2 -

Features

INFO

-/--

EXIT

I-II

GUIDE

WIDE

SELECT

P+

• Remote controlled colour television.

• Fully integrated digital TV (DVB-T).

• 100 programmes from VHF, UHF bands or

cable channels can be preset.

• It can tune cable channels.

• Controlling the TV is very easy by its menu

driven system.

• It has a scart socket for external devices

(such as video, video games, audio set, etc.)

• Stereo sound system (Nicam).

• Fully functional teletext .

• Fastext (10 pages), top text.

• Favourite channel.

• Channel lock.

• Headphone connection.

• A.P.S. (Automatic Programming System).

• All programmes can be named.

• Forward or backward automatic tuning.

• Sleep timer.

• Child lock.

•Automatic sound mute when no transmission.

• NTSC playback.

• It has an HDMI connector for digital video

and audio. This connection is also designed

to accept high definition signals.

• AVL (automatic volume limiting).

• When no valid signal is detected, after 5

minutes the TV switches itself automatically

to standby mode.

• PLL (frequency search).

• PC input.

• Plug & Play for Windows 9X, ME, 2000, XP, Vista.

• Audio Line Out.

Accessories

Remote Controller

Instruction Book

ABC DEF GHI

1 2 3

JKL MNO

5 6

VWX

STU

7 8 9

P -

P<P

Batteries

2 X AAA

PQR

English - 3 -

Introduction

Th a n k yo u fo r choosing this

product. This manual will guide

you for the proper operation of your

TV. Before operating the TV, please

read this manual throughly.

Please do keep this manual in a safe place

for future references.

Preparation

For ventilation, leave a free space of at least

10 cm all around the set. To prevent any fault

and unsafe situations, please do not place

any objects on top of the set.

Use this device in moderate climates.

Safety Precautions

Please read the following recommended

safety precautions carefully for your safety.

Power Source

The TV set should be operated only from a

220-240 V AC, 50 Hz outlet. Ensure that you

select the correct voltage setting for your

convenience.

Power Cord

Do not place the set, a piece of furniture, etc.

on the power cord (mains lead) or pinch the

cord. Handle the power cord by the plug. Do

not unplug the appliance by pulling from the

power cord and never touch the power cord

with wet hands as this could cause a short

circuit or electric shock. Never make a knot in

the cord or tie it with other cords. The power

cords should be placed in such a way that

English - 4 -

they are not likely to be stepped on. A damaged

powe r cord can cause fire or give you an

electric shock. When it is damaged and needs

to be replaced, it should be done by qualified

personnel.

Moisture and Water

Do not use this device in a

humid and damp place

(avoid the bathroom, the sink

in the kitchen, and near the

washing machine). Do not

expose this device to rain or

water, as this may be dangerous and do not

place objects filled with liquids, such as flower

va s e s , on to p . Avoi d from drippi n g or

splashing.

If any solid object or liquid falls into the cabinet,

unplug the TV and have it checked by qualified

personnel before operating it any further.

Cleaning

Before cleaning, unplug the

TV set from the wall outlet.

Do not use liquid or aerosol

cleaners. Use soft and dry

cloth.

Ventilation

The slots and openings on the TV set are

intended for ventilation and to ensure reliable

oper ation. To pr event overhea ting, these

openings must not be blocked or covered in

anyway.

Heat and Flames

The set should not be placed

near to op e n flames and

sources of intense heat such

as an electric heater. Ensure

that no open flame sources, such as lighted

candles, are placed on top of the TV. Batteries

should not be exposed to excessive heat such

as sunshine, fire or the like.

Lightning

In case of storm and lightning

or wh e n go i ng on ho l iday,

di sconnect the powe r cord

from the wall outlet.

Replacement Parts

When replacement parts are required, make

sure that the service technic ian has used

replacement parts, which are specified by the

manufacturer or have the same specifications

as th e o r i g i n a l one. Unauthor i z e d

substitutions may result in fire, electrical shock

or other hazards.

Servicing

Please refer all servicing to

qualified personnel. Do not

remove the cover yourself as

this may result in an electric

shock.

Waste Disposal

Instructions for Waste Disposal

• Packaging and packaging aids are recyclable

and should principally be recyc l e d .

Packaging materials, such as foil bag, must

be kept away from children.

• Batteries, including those which are heavy

metal-free, should not be disposed of with

household waste. Please dispose of used

battery in an environment friendly manner.

Find out about the legal regulations which

apply in your area.

• Cold cat hode fluoresce nt lamp in LCD

PANEL contains a small amount of mercury;

please follow the local laws or regulations

for disposal.

Disconnecting the Device

The mains plug is used to disconnect TV set

from the mains and therefore it must remain

readily operable.

Headphone Volume

Excessive sound pressure from

ea r p hones an d headph o nes

can cause hearing loss.

Installation

To prevent injury, this device must be securely

attached to the wall in accordance with the

installation instructions when mounted to the

wall (if the option is available).

LCD Screen

The LCD panel is a very high technology

produ c t with ab o u t a mi l l i o n thin fi l m

transistors, giving you fine picture details.

Occasionally, a few non-active pixels may

appear on the screen as a fixed blue, green

or red point. Please note that this does not

affect the performance of your product.

Warning

Do not leave your TV in standby or operating

mode when you leave your house.

English - 5 -

Overview of the Remote Control

DTV

INFO

-/--

EXIT

SWAP

I-II

SOURCE

GUIDE

WIDE

SELECT

10111213141516

P+

Standby

Cursor up

Cursor right

Info

Direct programme

Double digit/ No function

Programme up

Volume up

TV/Digital TV Mode

External source

Feature

Instal

Hold/No function

Update/No function

Index page

Reveal/Switch from TV to PC

Expand/Image size

Mix/No function

Teletext

Time/Subtitle on-off

Sound


Previous programme

Mono-Stereo/Dual I-II

Programme down

Volume down

Personal preference

Okay (Store)

Cursor down

Cursor left

Mute

21 20 19

18 17

ABC DEF GHI

1 2 3

JKL MNO

STU

5 6

VWX

7 8 9

P -

P<P

2 3

PQR

English - 6 -

LCD TV and Operating Buttons

TV/AV

STAND BY

PROGRAMME UP/DOWN

(MENU NAVIGATION)

MENUP/CHVOLUME

VOLUME UP/DOWN (MENU NAVIGATION)

REAR VIEW

English - 7 -

Viewing the Connections

Headphone jack is used for connecting an external headphone to the system.

Connect to the HEADPHONE jack to listen to the TV from headphones (optional).

Power Cable

PC Input is for connecting a personal computer to the TV set.

Connect the PC cable between the

HDMI Inputs are for connecting a device that has an HDMI socket.

Your LCD Television is capable of displaying High Definition pictures from devices such as a

High Definition Satellite Receiver or DVD Player. These devices must be connected via the

HDMI sockets or Component Socket. These sockets can accept either 720p or 1080i signals.

No sound connection is needed for an HDMI to HDMI connection.

Audio Line Out outputs audio signals to an external device such as an optional sound

system.

To connect the external speakers to your TV, use AUDIO LINE OUTof the TV with an audio

cable.

Component Audio Inputs are used for connecting component audio.

Connect the audio cable between COMPONENT AUDIO INPUTS on the TV and audio outputs

of your device.

PC INPUT on the TV and the PC output on your PC.

English - 8 -

Component Video Inputs (YPbPr) are used for connecting component video.

You can connect the component video and audio sockets with a device that has component

output. Connect the component video cables between the

on the TV and the component video outputs of your device.

letters on your TV, “

Use an appropriate RCA cable to connect the set to a subwoofer unit.

SCART 1 inputs or outputs for external devices.

RF Input connects to an antenna or a cable.

Note that if you use a decoder or a media recorder, you should connect the aerial cable

through the device to the television with an appropriate antenna cable, as shown in the

illustration below.

CI Slot .

CI Slot

is used for inserting a CI card. A CI card allows you to view all the channels that you

subscribe to. For more information, see “Common Interface” section.

Y”, “Pb”, “Pr” correspond with your device’s connectors.

COMPONENT VIDEO INPUTS on

While connecting, be sure that the

English - 9 -

Power Connection

Aerial Input

IMPORTANT: The TV set is designed to operate on 220-240V AC, 50 Hz.

• After unpacking, allow the TV set to reach the ambient room temperature before you

connect the set to the mains.

• Plug the power cable to the mains socket outlet.

Aerial Connection

• Connect the aerial or cable TV plug to the AERIAL INPUT socket located at the rear of the TV.

REAR VIEW

English - 10 -

Connecting the LCD TV to a PC

PC audio cable

(not supplied)

For displaying your computer’s screen image on your LCD TV, you can connect your computer

to the TV set.

• Power off both computer and display before making any connections.

• Use 15-pin D-sub display cable to connect a PC to the LCD TV.

• When done, switch to PC source. See, “

• Set the resolution that suits your viewing requirements.

Input selection” section.

PC RGB cable

(not supplied)

to PC RGB output

to component

audio input

English - 11 -

Connecting to a DVD Player

SCART

cable

If you want to connect a DVD player to your LCD TV, you can use connectors of the TV set. DVD

players may have different connectors. Please refer to your DVD player’s instruction book for

additional information. Power off both the TV and the device before making any connections.

Note: Cables shown in the illustration are not supplied.

• If your DVD player has an HDMI socket, you can connect via HDMI. When you connect to DVD

player as illustrated below, switch to HDMI source. See, “

• Most DVD players are connected through

COMPONENT SOCKETS. Use a component video

cable to connect video input. For enabling audio, use a component audio cable as illustrated

below. When done, switch to YPbPr source. See, “Input selection” section.

• You may also connect through the

SCART 1 . Use a SCART cable as shown below.

Input selection” section.

REAR VIEW

Component

video cable

HDMI cable

Component

audio cable

Note: These three methods of connection perform the same function but in different levels of

quality. It is not necessary to connect by all three methods.

English - 12 -

Using Other Connectors

You can connect a range of optional equipment to your LCD TV. Possible connections are

shown below.

• To connect external speakers, use an audio cable. Do not reverse the AUDIO LEFT and

AUDIO RIGHT jacks. Turn on the LCD TV and external speaker set after all connections are

made. Refer to your speaker set’s manual for further queries.

• To listen the sound from headphones, connect to the HEADPHONE jack of theTV.

Note that cables shown in the illustration are not supplied.

Headphone

external speaker

English - 13 -

Connecting Other Equipment via Scart

VCR

DVD Recorder

Decoder

Most devices support SCART connection. You can connect a; DVD recorder, a VCR or a

decoder to your LCD TV by using the SCART sockets. Note that cables shown in the illustration

are not supplied.

• Power off both the TV and the devices before making any connections.

• For more information, refer to your device’s own instruction book.

REAR VIEW

scart

sockets

English - 14 -

Inserting Batteries in the

INFO

-/--

EXIT

I-II

GUIDE

WIDE

SELECT

P+

Remote Control Handset

IMPORTANT : The TV set is designed to operate on

• Remove the battery cover located on the back

of the handset by gently pulling backwards

from the indicated part.

• Ins ert two

batteries inside. Place the batteries in the

right directions and replace the battery cover.

Note: Remove the battery from remote control

220-240V AC ,50Hz.

AAA/R03 or equivale nt type

handset when it is not to be used for a

lo n g perio d . Other w ise, it ca n be

dama g e d d u e t o a n y l e a k a g e o f

batteries.

Operating Range for the Remote Control

• Point the top of the remote control toward

the LCD TV's remote sen sor LED while

pressing a button.

ABC DEF GHI

1 2 3

JKL MNO PQR

4 5 6

VWX

STU

7 8 9

P -

P<P

Remote range is approximately 7m/23ft.

English - 15 -

Switching the TV On/Off

Source

YPBPR

To Switch the TV On

• Your TV will switch on in two steps.

• Connect the power cord to 220-240V AC 50

Hz. Press stand-by button. Then the TV

switches itself to stand-by mode (Optional).

• To switch on the TV from stand-by mode

either:

• Press a digit button on the remote control so

that a channel number is selected, or press

the -P/CH or P/CH+ button on the TV or press

the

P/CH+ or P/CH- button on the remote

control, so that last mode switched off is

selected. By either method the TV will switch

on.

To Switch the TV Off

• Press the “ (stand-by)” button on the

remote control or stand-by button on the TV,

so the TV will switch to stand-by mode.

• To power down the TV completely, unplug

the power cord from the mains socket.

Input Selection

Once you have connected external systems

to your TV, you can switch to different input

sources.

• Press the

until the desired source is highlighted. The

TV will then switch to the selected source

after a short while.

button on your remote control

EXT1 PC

DTV

HDMI

English - 16 -

Basic Operations

You can operate your TV using both the

remote control and onset buttons.

Operation with the Buttons on the TV

Volume Setting

• Press - button to decrease volume or

+ button to increase volume, so a volume

level scale (slider) will be displayed on the

screen.

Programme Selection

• Press P/CH + button to select the next

programme or

previous programme.

Entering Main Menu

• Press the MENU button to enter main menu.

In the Main menu select sub-menu using

CH -

or P/CH + buttons and enter the sub-

menu using

the usage of the menus, refer to the menu

system sections.

AV Mode

• Press the TV/AV button at the control panel

on the the TV to switch your TV to AV modes.

Operation with the Remote Control

• The remote control of your TV is designed to

control all the functions of the model you

selected. The functions will be described in

accordance with the menu system of your

TV.

• Functions of the menu system are described

in the following sections.

P/CH - button to select the

- or + buttons. To learn

Volume Setting

Press V + button to increase the volume.

Press

V - button to decrease the volume. A

volume level scale (slider) will be displayed

on the screen.

Programme Selection (Previous or Next Programme)

• Press P - button to select the previous programme.

P + button to select the next programme.

• Press

Programme Selection (Direct Access)

•Press numeric buttons on the remote control

to select programmes between 0 and 9. The

TV will switch to the selected programme.

To select programmes between 10 - 999 (for

IDTV) or 10-99 (for analogue), press the

numeric butt ons con secutivel y (e.g. for

programme 27, first press 2 and then 7).

When the pressing time is due for the second

numeric button, only the first digit programme

will be displayed. The limit of the delay time

is 3 seconds.

• Press directly the programme number to

reselect single digit programmes.

English - 17 -

Initial Settings

Auto. Programming System

West Europe









DTV

When the TV set is operated for the first time,

the IDTV turns on first.

Because this is the first time the TV is used, there

are no channels stored in the memory and the

following message appears on the screen:

Please ensure aerial is plugged in. Do you want to start first time installation?

Yes

• To start installation process, select “Yes”,

to cancel select “No”.

• To select the “Yes” or “No” option, highlight

the item by using

the

OK button.

or buttons and press

The IDTV will automatically tune to the UHF

transmision channels 21 to 68, searching for

digital terrestrial TV broadcasts and displaying

the names of channels found. This process

wi l l take ab out five minu t e s . To cancel

searching, you can press the M button at any

time during the process.

AUTOMATIC SEARCH

Channels:

BBC ONE BBC TWO BBC CHOICE

Searching UHF channels 30. Please wait. This will take a few minutes

12 %

Cancel search

After Automatic Search is completed, the

following message asking for analogue channel

search appears on the screen:

Do you want to search for analogue channels?

Yes

To seach for analogue channels, select “Yes”.

TV switches to the analogue TV mode. The

menu below is displaye d to search for

analogue channels:

Language

Country Txt. Region

Check the antenna cable

Start : Ok

English

U.K.

Exit : TV

Set Language item by pressing  or  button.

Press

and then use

or  button to highlight Country item

or  to set. Press  or

button to highlight Txt. Region. Select a region

by using

or  button. When finished, press

OK button to continue. To cancel, press the

button.

For more information on this proces s, see

“Install Menu” section.

NOTE: For proper functioning of digital teletext

in DTV mode, you should set

country

as UK in analogue APS.

General Operation

Pressing the

while watching television programmes will

switch the TV set between displaying the

digital terrestrial television broadcasting and

its normal analogue broadcasting.

Information Banner

• Whenever you change channel, using the P-

/ P+ button or the numeric buttons, the TV

displays the broadcast picture along with an

information banner at the bottom of the

screen. This will remain on the screen for

approximately three seconds.

• The in f o r m a t i o n banner can a l so b e

displayed at any time while watching TV by

press ing the

button at any time

but ton on th e remote

English - 18 -

control:

Chuckle Vision 13:00-14:00

Change

Change Time

Now: 50/50 Next: Ace Lighting

1. BBC ONE

Signal Level:

09:25 - 11:00 11:00 - 11:25

13:15

• The information banner gives information

on the channel selected and the

programmes on it. The name of the channel

is displayed, along with its chann el list

number and an indication of the strength of

the signal received.

Hint : Not all c h a n n e l s broadcast the

programme data. If the name and time

of the programme are not available,

then “

No Information Available” will be

displayed in the information banner.

• Icons are also displayed in the information

banner and if this channel is a favourite

channel, favourite channel icon “ ” will

also be displayed.

If the selected channel is locked, you must

enter the correct four numeric code to view

the channel. “Enter Lock Key” wi l l be

displayed on the screen in such a case:

Enter Lock Key

Electronic Programme Guide (EPG)

• Some, but not all, channels send information

about the current and next events.

• Please note that event information is updated

automatically. If there is no event information

data available in channels, only channel

names with

banner is displayed.

• Press

• In EPG menu, you can easily see the extended

help information by pressing

• Press this button again to close this window.

“No Information Available”

GUIDE button to view the EPG menu.

button.

• In the EPG menu, all channels are displayed.

Current channel is highlighted. Use

buttons to change channels. Also pr ess

GREEN/RED buttons to scroll up/down the

pages for the channels.

• If yo u highlig h t an even t ; short ev e nt

description, extended event description, start

and end times of the event will be displayed

on the screen.

• When the current programme is highlighted,

the box is switched to the highlighted channel

by pressing the

• If you press the

OK button.

OK button when a next event

is high light ed, a reminder is set for the

highlighted programme and a clock appears

across the highlighted channel line.

Programme reminders can be set to signal

that a programme is about to start when you

are watchin g an other chan nel. If you set

reminder for a programme, then you will be

asked for switching to that channel when the

reminder time is reached.

• Press the M button to view the 7 day EPG.

• Press

or button to navigate in Channels

or Programmes.

• Press or button to navigate through the

channel and programme list.

ELECTRONIC PROGRAMME GUIDE(7 Day) Saturday 21/8 13:49

Triple bill. In the Ring/Romany Days/On the Radio: Paul and Barry grapple with the world of wrestling; hunt for a mysterious Emperor's underpants; and record their first pop song.

Channels Programmes on Saturday 21/8, 13:00 - 15:00

30. CBBC Channel 13:00 Chuckle Vision (Now)

40. BBC NEWS 24 14:00 Tracy Beaker

41. ITV News 14:55 Newsround

50. Four Text

800. BLUE/LEFT 1k...

801. CCIR17/1kHz...

Navigate

Day

• With RED/GREEN buttons, you can change

the schedule time. By pressing

BLU E

you ca n adva n c e the schedule

YELLOW/

English - 19 -

backward/forward of a day.

Change

Change Time

Interactive services cannot be used

while subtitles are on. Would you like

• If you press

button you can see the

detailed help information easily. Press

button again to exit help menu.

• The starting time for

EPG is the current time.

You can see the event information for the

next two hours. By pressing or button,

you can go to the next/previous hours while

Programmes list is highlighted.

• lf you press the

OK button when a next event

is highlight ed, a reminder is set for the

highlighted programme and a clock appears

on the screen.

• Programme reminders can be set to signal

that a programme is about to start when you

are watching another channel. If you set

reminder to a programme, then you will be

asked for switching to that channel when the

reminder time is due.

ELECTRONIC PROGRAMME GUIDE(7 Day) Saturday 21/8 13:51

Newsround 16:55-17:00

CBBC joins the Newsround team, keeping you up to date on the latest stories and events happening at home and abroad.

Channels Programmes on Saturday 21/8, 15:00 - 17:00

30. CBBC Channel 15:00 Even Stevens

40. BBC NEWS 24 15:50 Newsround Showbiz

41. ITV News 16:00 Basil Brush

50. Four Tex t 16:55 Newsround

51. BBCI

800. BLUE/LEFT 1k...

801. CCIR17/1kHz...

DayNavigate

Displaying the Subtitles

With digital terrestrial broadcasting (DVB-T),

some programmes a re br o a d c a s t wi t h

subtitles. Subtitles can be displayed while

watching these programmes.

Press the M button to display the main menu,

highlight the

button and press the OK button to display the

configuration menu.

Configuration line using or

Highlight the

menu and use

“Subtitle” item in configuration

or button to set Subtitle to

Off or a language.

“Subtitle” is on and a language option is

se t, press ing the

bu tto n ca uses the

following warning message display on the

screen:

to turn subtitles off now?

NoYes

Digital Teletext

With digital terrestrial broadcasting (DVB-T),

in addition to pictures and sound, you can also

view digital teletext.

Digital teletext is sometimes broadcast at the

same time with the normal broadcasting.

• Press the

• The digital teletext information appears.

• Operate it with the coloured buttons,

buttons and OK button.

The operation method may differ depending

on the contents of the digital teletext.

Follow the instructions displayed on digital

teletext screen.

• When “

message appears on the screen, press the

OK button.

• When the

TV returns to television broadcasting.

• With digital terrestrial broadcasting (DVB-

T), in addition to digital teletext broadcasting

at t h e same time wi t h the n o r m a l

broadcasting, there are also channels with

just digital teletext broadcasting.

button.

/ / /

Press SELECT” button or similar

(Text) button is pressed, the

English - 20 -

• The aspect ratio when watching a channel

DTV

Configuration

SELECT

CHANNEL LIST 1 BBC ONE

with just digital teletext broadcasting is the

same as the aspect ratio of the picture

watched previously.

• When you press the

(Text) button again,

the digital teletext screen will be displayed.

Over Air Download

To ensure that your IDTV always has the most

up-to-date information, please ensure that,

after use, it is set to standby mode. At 3 A.M.

each day, the IDTV automatically searches for

any new information which may be broadcast

and will download t h i s to yo u r ID TV

automatically. This operation will normally

take approximately 30 seconds.

If you want to perform this, you need to set

Automatic Download to

“Enabled” in Receiver

Upgrade setting.

Widescreen

Depending on the type of the broadcast being

transmitted, programmes can be viewed in a

number of formats. Press the WIDE button

repeatedly to select between

Cinema

or Subtitle.

When Auto is selected, the format being

displayed is determined by the picture being

broadcast.

PLEA S E NOTE : Menu s i ze changes

depen d i n g on the

chosen image size.

Auto, 4:3, 16:9,

IDTV Menu System

The IDTV menu can only be viewed when

watching digital terr estrial broa dcas tin g.

Press the

while the TV is in analogue mode.

Press the

on the screen:

Channel List

Using the or button on the remote control,

make sure that the first item, Channel List, is

highlighted and press the OK button to display

the

Channel List.

The following operations can be performed

in this menu:

• Navigating the entire list of channels

• Deleting channels

• Renaming channels

• Adding locks to channels

• Setting favourites

Channel List is the place where the channels

are managed.

button to turn IDTV on

M button. The menu below appears

Main Menu

Channel List

Installation

Timers

Language

TV Setup

Common Interface

English - 21 -

1. BBC ONE

2. BBC TWO

3. ITV 8

4. Channel 4

5. BBC THREE

6. Teletext

7. BBC FOUR

8. Sky Travel

9. UKHistory

10. RTL

Select

Function

Delete Edit Name Lock Favourites

Select Channel Watch More

Navigating the Entire Channel List

SELECT

CHANNEL LIST 1 BBC ONE

SELECT

CHANNEL LIST 1 BBC ONE

Press or button for selecting the previous

or next channel. You can press

RED or GREEN

button to move page up or page down.

To watch a specific channel, highlight it using

or button and then press OK button, while

the “

Select” item on Channel List menu is

highlighted by using

or button.

Then the name and number of the selected

channel will be displayed in the top-left and

top-right of the channel display at the top-right

of the screen, respectively.

Deleting the Channels in the Channel List

Press or button to select the channel

that will be deleted.

Press or button to select the “Delete’’

item on Cha nne l List menu. As seen on

Channel List menu, SELECT is displayed next

Delete item at the bottom of the screen to

indicate that you must press the

delete the highlighted channel in the channel

list.

1. BBC ONE

2. BBC TWO

3. ITV 8

4. Channel 4

5. BBC THREE

6. Teletext

7. BBC FOUR

8. Sky Travel

9. UKHistory

10. RTL

Select

Delete Edit Name Lock Favourites

Function

Select Channel Delete More

Press the OK button to delete the highlighted

channel in the channel list. Then the message

below appears on the screen:

The selected service will be permanently deleted. Are you sure?

Yes No

OK button to

Press or button to highlight the desired

option. If

OK button is pressed while “Yes” is

highl i g h t e d , the hi g h l i g h t ed ch a n n e l is

deleted. Selecting “No” cancels the deletion.

Renaming Channels

To rename a specific channel, the channel

must be hig hlighted by pressing

button. Then highlight the Edit Name item by

pressing

Press the

or button as illustrated below..

OK button to activate the rename

feature.

1. BBC ONE

2. BBC TWO

3. ITV 8

4. Channel 4

5. BBC THREE

6. Teletext

7. BBC FOUR

8. Sky Travel

9. UKHistory

10. RTL

Select

Delete Edit Name Lock Favourites

Function

Select Channel Edit Name More

Now pressing or button moves to the

previous/next character. Pressing

button toggles the current character, i.e., ‘b’

character becomes ‘a’ by and ‘c’ by .

Pressing the numeric buttons ‘

0...9’ replaces

the highlighted character with the characters

printed above the button one by one as the

button is pressed.

Press the M button to cancel the editing or OK

button to save the new name.

Adding Locks to Channels

Chann e l l o c k i n g provi d e s a password-

protected access to channels selected by

parents. In order to lock a channel you should

know the parental lock password (default

value is set to 0000 in the factory and can only

be changed from the

Select the channel to be locked by highlighting

it and select the Lock option by pressing or

Configuration menu).

English - 22 -

button. When the OK button is pressed, a

SELECT

CHANNEL LIST 1 BBC ONE

SELECT

CHANNEL LIST 1 BBC ONE

Press the SELECT button on your remote control to tune to the

Configuration

dialog OSD asking for the password will be

displayed.

1. BBC ONE

2. BBC TWO

3. ITV 8

4. Channel 4

5. BBC THREE

6. Teletext

7. BBC FOUR

8. Sky Travel

9. UKHistory

10. RTL

Select

Delete Edit Name Lock Favourites

Function

Select Channel Lock/Unlock More

Enter Lock Key

1. BBC ONE

2. BBC TWO

3. ITV 8

4. Channel 4

5. BBC THREE

6. Teletext

7. BBC FOUR

8. Sky Travel

9. UKHistory

10. RTL

Select

Delete Edit Name Lock Favourites

Function

Select Channel Add/Remove... More

On Screen Help

For all menus, press the button to display

the help information about the menu functions.

For Channel L i s t menu th e following

message is displayed on the screen:

Enter the password by using the numeric

buttons on the remote control. The lock icon

“ ” will now be displayed next to the selected

channel. Repeat the same operation to cancel

the lock.

Setting Favourites

You can set various channels as favourites

so th a t only th e fa vour i te chann e ls are

navi gated. To se t a favouri te you shoul d

highlight the

the Channel List menu.

Us e the

“Favourites” item at the base of the screen

and then, in turn, highlight each channel you

want to add to the favourites list, using the

and buttons (or red/green buttons), and

press the

A channel selected as a favourite appears in

the main channel list with a favourites icon

(

) against the channel name as illustrated

below:

Favourites item at the bottom of

or butt o n to hig h ligh t the

OK button.

highlighted channel. Press MENU to exit this screen.

Installation

The Installation menu is mainly intended to

help you for creating a

Channel Table in the

most efficient way.

Main Menu

Channel List

Installation

Timers

Language

TV Setup

Common Interface

This menu includes the following items:

• Add New Channels.

• First Time Installation.

English - 23 -

Add New Channels

First Time Installation

Auto. Programming System

West Europe









This tuning menu consists of two parts:

• Automatic Search

• Manual Search

Installation

Add New Channels

First Time Installation

Automatic Search

Automatic search is started by pressing the

OK button in the auto-search pop up menu.

All the services will be searched and a channel

table will be created automatically.

All channels found are stored in a sorted form

with respect to their channel numbers. Some

services may not appear with the correct

channel number. If the broadcaster has no

channel information, this may happen due to

missing info.

Manual Search

In manual search, the number of the multiplex

is entered manually and only that multiplex is

searched for the channels. For every valid

channel number, signal level, signal quality

and network name are shown at the bottom

of the screen.

In both manual and auto search, any existing

channel in the database is not re-stored to

avoid redundant duplicates of that channel.

First Time Installation

The user can use this item to load default

settings, which were loaded to the receiver at

the factory.

To install factory settings, highlight

Installation”

menu and press the OK button.

Installation

Add New Channels

Then you will be asked to confirm for deleting

all channels and settings:

Automatic Search

Manual Search

“First Time

English - 24 -

Your previous digital channel list will be destroyed. Are you sure you want to delete all digital channels and settings for first time installation?

Yes

By selecting Yes and pressing the OK button,

the existing channel table will be deleted.

After factory settings are loaded, “First Time

Installation

” menu will be displayed:

Please ensure aerial is plugged in. Do you want to start first time installation?

Yes

Press the OK button to start installation. After

search is co mpleted for digita l channels, a

message asking whether to se a rc h fo r

analogue channels appears on the screen:

Do you want to search for analogue channels?

Yes

Press the OK button to search for analogue

channels.The following menu appears on the

screen for analogue channel search:

Language

Country Txt. Region

Check the antenna cable

Start : Ok

English

U.K.

Exit : TV

Set Language item by pressing  or  button.

Press

and then use

or  button to highlight Country item

or  to set. Press  or

button to highlight Txt. Region. Select a region

by using

or  button. When finished, press

OK button to continue. To cancel, press the

DTV

Auto. Programming System

Automatic tuning runs at: 78 %

Configuration

CONFIGURATION

Parental Settings

Change Default Audio Language

button. The following menu will be

displayed during the APS process:

can se lect a func tio n by highl ighting th e

corresponding menu line using the

button. Configuration menu will look like this:

State: Fine scanning ...

Exit : TV

After APS is finalized, the programme table

will appear on the screen. In the programme

table you will see the programme numbers

and names assigned to the programmes.

If you do not accept the locations and/or the

programme names, you can change them in

the programme table.

Configuration

Press the M button to display the main menu

and press the

Configuration. Then press the

display the configuration menu. Press the

button to leave the menu screen.

Th e vari ous confi g urati on funct i ons are

displayed in a list, along with a quarter-screen

image of the currently selected channel. You

button twice to highlight

OK button to

Main Menu

Channel List

Installation

Timers

Language

TV Setup

Common Interface

Audio Language Subtitle Favourite Mode EPG Preference Receiver Upgrade

English Off Off Now&Next V.1.5

Audio Language

Digita l terrestrial televis ion channels can

broadcast simultaneous soundtracks in more

than one lan guage. This function selects

which language soundtrack you will hear

when switching to a channel broadcasting with

the multiple soundtracks.

Highlight the Audio Language line in the

Configuration menu and use the or

button to cycle through the language options.

Subtitle

Digita l terrestrial televis ion channels can

broadcast subtitles displayed on the screen

for hard-of-hea ring people. This functio n

selects the desired subtitle language and

enables the automatic display of subtitles

whenever subtitle information is broadcast.

Highlight the Subtitle line in the Configuration

menu and use the

through

“Off” and language options.

or button to cycle

Favourite Mode

This function enables or disables the favourite

channel list mode.

Use

or button to turn on/off favourite

mode. If the

normal operating mode, pressing

but t o n s will only naviga t e throug h th e

“Favourite Mode” is on; while in

P+ and P-

English - 25 -

channels that were previously defined as

CONFIGURATION

Parental Settings

favourites in the channel list.

EPG Preference

Digita l terrestrial televis ion channels can

broadcast simultaneous Next&Now and 7-

Day electronic programme.

Highlight the EP G Preference line in the

Configuration menu and use the or

button to select Next&Now or 7-Day.

Receiver Upgrade

Th e IDT V c a n be upgraded via the

configuration menu, entered from the main

menu.

In the con figur ati on menu , hig hlig h t the

“Receiver Upgrade” item by pressing or

button and press the OK button to start

upgrade process.

Th e r e are two poss i b i l ities for receiv e r

software to be upgraded:

manual.

Audio Language Subtitle Favourite Mode EPG Preference Receiver Upgrade

Automatic Download Search for New Version

Exit

English Off Off Now&Next V.1.5

Enabled

Automatic Download (Automatic Upgrade)

Au tomat ic Downloa d can be enab led or

disabled by pressing

enabl e d , then t h e re ar e two wa y s for

automatic upgrade:

• The first one is checking the existence of a

new software every time the IDTV goes to

standby.

• The second one is being activated at 03:00

A.M. every night, provided that the IDTV is left

in standby mode.

automatic and

or button. If it is

English - 26 -

• Both automatic upgrade methods result in

standby mode either the upgraded or not.

If the automatic upgrade is set to “Disabled”

then this function will not work.

Search for New Version (Manual Upgrade)

Manual upgrade starts if the “Search for New

Version”

item is highlighted by using or

button and activated via pressing the OK

button.

After

“Search for New Version” is activated,

the IDTV tunes to each frequency that have

been stored in its database and looks for the

new so f t ware. Du r i n g th is process , the

following OSD is displayed:

Software Upgrade

Searching for upgrade. Please wait, or press MENU to cancel.

Search Progress:

Parental Settings

Some channels broadcast material which you

do not want younger members of the family to

watch. Any channel can be ‘locked’ so that it

cannot be selected for viewing unless a four-

digit PIN code is entered. In this way, any

channel not suitable for younger viewers can

be prohibited.

This function enables or disables the menu

protection system and allows the PIN code to

be changed.

Use or button to highlight Parental

Settings

Parental Settings menu. A dialog box asking

for the lock key is displayed:

option. Press the OK button to enter

Enter Lock Key

There is only one key which is set to “0000”

Wrong Lock Key

Installation

Configuration

SELECT

No Channel Name Start End Date Mode

1. ITV 1 20:00 21:00 12/05/2005 Active

initially. Enter lock key. If wrong lock key is

entered, the following message is displayed

and the TV then returns to the previous menu:

If it is correct, the Parental Settings menu will

be displayed including the following items:

Menu Lock

Set Lock Key

Display the main menu by pressing the

button. Highlight the Timers line by pressing

or button and press the OK button to

display the Timer menu:

Main Menu

Channel List

Installation

Timers

There you can set/reset locking for the main

menu or the installa tion menu to restrict

access. If the menu lock is disabled, there

will be free access to the menu system. Also

in this menu you can change the lock key and

set/change parental lock mode.

Disabled: All menus are unlocked.

Main Menu: Main menu is accessible only with

the correct lock key. So the user

ca n n ot add, delet e , re name,

move ch a nnels, cannot set

timers.

Installation: Installation menu is locked, so

the user cannot add channels.

Note: Changes will be updated after exiting

configuration menu.

Timers

You can set a timer to switch the TV to any

channel without your intervention. This is also

for making video recordings of programmes

when you are out.

Language

TV Setup

Common Interface

Up to five separate timer events can be set

and each is displayed in the Timer screen,

showing the event number, the channel to be

selected, the start time, end time, date and

the mode - whether that event is active (and

will be acted on) or not.

TIMER MENU

2. BBC ONE 00:00 00:00 01/01/2005 Inactive

3. BBC ONE 00:00 00:00 01/01/2005 Inactive

4. BBC ONE 00:00 00:00 01/01/2005 Inactive

5. BBC ONE 00:00 00:00 01/01/2005 Inactive

6. BBC ONE 00:00 00:00 01/01/2005 Inactive

Toggle Mode

Edit Timer More

Exit

• To set an event, highlight its mode button

using the

or button and press the OK

button to display the timer entry window.

English - 27 -

Name:

3. ITV 1

Configuration

Start: End: Date: Mode:

00:00 00:00 03/06/2005 Once

• Here the five settings consistin g of the

channel name, start time, end time, date and

frequency mode can be set. You can move

freely between each setting using the

buttons.

• The channel name is set using the

butto n t o display th e channel which

broadcasts the programme.

• The start time, end time and date are each

set with the numeric buttons on the remote

control in 24-hour format.

• The frequency mode determines how often

the receiver operates this event and is set

with the

or button to be either Once,

Daily, or Weekly.

If an invalid number for the start or end times

or the date is entered, “Entered time is not

messa g e a p p e ars on the m e n u

va l i d ”

screen.

If timer action occurs while the TV is being

watched, the TV switches to the selected

channel. When timer expires, the TV switches

back to the channel which it is switched from.

Language

Some programmes are broadcast in two or

more la n g u ages simultaneo u s l y. The

language thus can be selected fr om the

Language menu.

• Press the

and use

Language line and press the

M button to display the main menu

or b utton to highlig ht the

OK button:

Main Menu

Channel List

Installation

Timers

Language

TV Setup

Common Interface

• Use the or button to highlight the

soundtrack language required and press the

OK button. Normal viewing, with the required

language soundtrack, can be resumed by

pressing the M button.

Languages

English

English - 28 -

TV Setup

Configuration

You can use this ite m to display the TV

functions.

Th e digital TV Setup m e nu screen i s

accessed from the main menu. Press the

button to display the main menu and use

or button to highlight “TV Setup”, press the

OK button to display TV Setup menu screen.

Main Menu

Channel List

Installation

Timers

Language

TV Setup

Common Interface

You can find detailed information for all menu

items in “Analogue TV Menu System” section.

Common Interface

• Press the M button to display the main menu

and use the

“Common Interface” line and press the OK

button:

or button to highlight the

Main Menu

Channel List

Installation

Timers

Language

TV Setup

Common Interface

Obtain the Conditional Access Module (CAM)

and the viewing card by subscribing to a pay

channel company, then insert those to the TV

using the following procedure.

• Switch off the TV and unplug from the mains.

• Insert the CAM, then viewing card to the slot

that is located in the terminal cover at the

left-hand side of the TV (from front view).

• The CAM should be correctly inserted, it is

impossible to insert fully if reversed. The

CAM or the TV terminal may be damaged if

the CAM is forcefully inserted.

• Connect the TV to the mains supply, switch

on and then wait for few moments until the

card is activated.

• Some CAMs may require the following set

up. Please set the CAM by entering the IDTV

menu, Common Interface then pressing the

OK button . (CAM set up menu is no t

displayed when it is not required.)

• To see the viewing contract information: enter

IDTV; press the

M button, then highlight

Common Interface and press the OK button.

• When no module is inserted, “

Interfa ce mo dul e detec ted

No Common

” message

appears on the screen.

• Refer to the module instruction manual for

details of the settings.

NOTE: Insert or remove the CI module only

when the TV is in

STAND-BY mode or

SWITCHED OFF.

It is required to subscribe to a pay channel

company to view the pay channels of the digital

terrestrial broadcasting.

English - 29 -

Analogue TV Menu Map

INSTALL

Program Table

Favorite mode

-Auto Programming System

SOUND

Volume

Balance 0

Sound Mode Stereo

AVL On Effect Off

Back : Menu Exit : TV


Picture Mode Bright

Brightness

Contrast

Colour

Sharpness

Back : Menu Exit : TV

FEATURES

Sleep Timer Off

Language English

Child Lock Off

Menu Colour Gray

Back : Menu Exit : TV

Programming

A.P.S.

Txt. region West Europe

Back : Menu Exit : TV

SOUND MENU PICTURE MENU

-Volume

-Balance

-Sound Mode

-AVL

-Effect

-Equalizer

-Mode

-HP Volume

-Store

-Picture Mode

-Brightness

-Contrast

-Colour

-Sharpness

-Colour Temp

-Room Lightning

-Picture zoom

-Store

FEATURES MENU INSTALL MENU

-Sleep Timer

-Language

-Childlock

-Menu Colour

-Favorite Mode

-Programming

-Programme

-Band

-Channel

-Standard

-Colour System

-Search

-VCR Mode

-Decoder

-Store

-APS

A menu map is provided above. For details of the items,

refer to relevant explanations in the “MENU SYSTEM”.

-Txt. Region

-Program Table

English - 30 -

Navigating the Analogue TV

INFO

For displaying

SOUND

Back : Menu





Menu System

For navigation

To confirm choices

SELECT

• Press M to display the main menu.

• Press or button to select an icon. Press

or OK button for more options.

• Use or button to highlight.

• Press or buttons to change the settings.

OK to set as default.

Press

• To exit the menu or return from sub-menu

screen, press

Note: These explana tions are valid for the

navigation of the whole menu system.

To select options that are explained in

the following parts, refer to “Navigating

the Analogue TV Menu System”.

menu options

Analogue TV Menu System

Sound Menu

Volume

Balance 0 Sound Mode Stereo AVL On Effect Off

Exit : TV

Volume

When you enter the sound menu, Volume will

be the first selected option. Press

to change the level of the Volume.

Balance

This setting is used for emphasizing the left

or right speaker balance.

Press or button to select Balance. Press

/  button to change the level of the balance.

Balance level can be adjusted between

and + 32.

Sound Mode

Press or button to select Sound Mode.

Using

/  button, you can select Mono,

Stereo, Dual I or Dual II mode, only if the

selected channel supports that mode.

AVL

Automatic Volume Limiting (AVL) function adjusts

the sound to obtain fixed output level between

programmes (For instance, volume level of

advertisement s tends to be louder than

programmes).

Press

or button to select AVLVL. Press  /

button to set the AVL as On or Off.

Effect

If you are watching a mono broadcast, set

Effect on to obtain a better sound effect which

/  button

-32

English - 31 -

will be more stereo-like. If the current sound

/ 










system is stereo, switching this effect on will

give a more spatial effect.

Press

or button to select Effect. Press

button to set Effect as On or Off.

Equalizer

Press or button to select Equalizer. Press

/  button to change the Equalizer setting. In

equalizer menu, the mode can be changed to

Flat, Speech, Music, Personal and Jazz.

Select the desired frequency by pressing /

button and increase or decrease the frequency

gain by pressing

Note: Equalizer menu settings can be changed only

when the mode is in Personal.

/  button.

HP Volume

To adjust headphone volume level, press

or button to select HP Volume. Press  /

button to change the level of the HP Volume.

Store

Select Store by pressing  /  button. Press

or OK button to store the settings. “Stored”

will be displayed on the screen.

Picture Menu

Picture Mode Bright

Brightness Contrast Colour Sharpness

Back : Menu Exit : TV

Brightness/Contrast/Colour/

Sharpness/Tint

Press or button to select the desi red

option. Press

Hint: Tint (Hue) is displayed in picture menu when

the TV receives an NTSC signal.

/  button to set the level.

Colour Temp

Press or button to select Colour Temp.

Press

options:

/  to choose from one of thes e

Cool, Normal and Warm.

Note:

• Setting

Cool option gives white colours a

slight blue stress.

• Setting

Warm option gives white colours a

slight red stress.

• For normal colours, select Normal option.

Room Lighting

Select Room Lighting by pressing the /

button. Press / button to set Room

Lighting as

Normal, Bright or Movie.

Picture Zoom

Picture Zoom setting enables you to select

the aspect ratio of the broadcast.

Select Picture Zoom by pressing / button.

Use

/  buttons to change Picture Zoom to

Auto, 4:3, 16:9, Cinema or Subtitle.

Store

Select Store by pressing  /  button. Press

or OK button to store the settings. “Stored”

will be displayed on the screen.

Picture Mode

For your viewing requirements, you can set

the related

Press

options:

mode option.

or button to select Picture Mode.

or button to choose from one of these

Bright, Standard, Soft and Manual.

English - 32 -

Features Menu

Sleep Timer

Back : Menu



Programming

Txt. region

West Europe

Program Table

PROGRAMMING

Colour System

Use

/  button to set Favourite mode On or Off

(See the “Program Table” section for details).

Install Menu

FEATURES

Language Engli sh Child Lock Off

Menu Colo ur Favourite Mode

Gray

Exit : TV

Off

Sleep Timer

Press or button to select Sleep Timer.

Use

/  button to set the Sleep Timer.

The timer can be programmed between

Off

and 120 minutes in steps of 10 minutes.

Sleep Timer is activated, at the end of the

selected time, the TV goes automatically to

standby mode.

Language

Press or button to select Language. Use

/  button to select the Language.

Child Lock

Press or button to select Child Lock.

Use

/  button to set the Child Lock On or

Off. When On is selected, the TV can only be

controlled by the remote control handset. In

this case the control panel buttons (except for

the

STANDBY button) will not work.

Hence, if one of those buttons is pressed,

“Child Lock On” will be displayed on the

screen when the menu screen is not visible.

Menu Colour

Press or button to select Menu Colour.

/  button to change menu background

Use

Transparent or Gray.

Favourite Mode

Press or button to select Favourite Mode.

INSTALL

A.P.S.

Back : Menu Exit : TV

Programming

Select Programming by pressing / button.

Then press

menu:

Programme

Select Programme by pressing / button.

Press

number. You can also enter a number via the

numeric buttons on the remote control. There

are 100 programme storage between 0 and 99.

Band

Band can be selected either C or S. Press

/ button to select Band.

button to display Programming

Programme 4

Band S

Channel 30 Standard BG

Back : Menu Exit : TV

PAL

/ button to select the programme

English - 33 -

Channel





DTV

Auto. Programming System

Automatic tuning runs at: 78 %

DTV

Select Channel by pressing / button.

Channel can be changed by pressing

button or the numeric buttons.

Standard

Select Standard by pressing / button. Use

/ button to change the standard to B/G,

D/K, I or L/L'.

Colour System

Select Colour System by pressing / button.

Use

/  button to change the colour system

PAL, SECAM or AUTO.

Select Search by pressing / button. Press

/  button to start search. The search will

stop when a signal is found.

Note: If you press the buttons with one-step moves,

a frequency of 0.25 Mhz will be advanced. However if you press the buttons all at once, it will advance automatically. To stop searching at a certain time, you may press

/ buttons.

VCR Mode

Select VCR Mode by pressing / button.

Use

/  buttons to set VCR Mode as On or Off.

Hint: If you want to watch a DVD , then you

have to set this item as

Off.

Decoder

You can use this mode to connect any decoder to your TV.

Select Decoder by pressing / button. Press

the

/  buttons to turn it On or Off.

When you switch the Decoder setting to

Off,

EXT-1 output will be muted. In this case, EXT-

output will not be available to display video.

If it is switched on, the

EXT-1 output will be the

selected video source. Any decoder can be

connected to EXT-1 to unscramble required

video signals.

Hint: Decoder setting should be stored separately

for each programme.

Store

Select Store by pressing  /  button. Press

or OK button to store the settings. “Stored”

will be displayed on the screen.

A.P.S.

Select A.P.S. by pressing  /  button. Press

button to enter the A.P.S. submenu:

Auto. Programming System

Country

Warning! All prestored programs will be deleted

Start : Ok Back : Menu

U.K.

Exit : TV

A.P.S. Country

Press / button to set your country..

If you want to exit from A.P.S. function, press

the

When you press

all stored programs will be erased and the

following screen will be displayed:

Whenever you press the

function stops and program table appears on

the screen.

button. For going back, press M.

OK button for starting APS,

State: Fine scanning ...

Exit : TV

button, A.P.S.

English - 34 -

If you wait until the end of A.P.S., Program Table





PROGRAMMING

Colour System



Program Table



is displayed with the programmes found and

located.

Teletext Region

Select Txt. region by pressing  /  button.

Using

There are five options to select:

East Europe, Turk/Gre, Cyrillic

Hebrew

/  buttons, select your teletext region.

West Europe,

and Arabic/

Install Menu in AV modes

The following screen appears in the install

menu:

INSTALL

Programming

Txt. Region

Back : Menu Exit : TV

Programming

Select Programming by pres sing  /

button. After pressing button, programming

menu appears on the screen:

VCR Mode Store

Back : Menu Exit : TV

Colour System

Select Colour System by pressing  /

button. Press / button to change the colour

system to

PAL, SECAM or AUTO.

West Europe

PAL

Off

Program Table

P01

P01 BBC 1

P02 C 04 P03 P13 P04 P14 P05 P15 P06 P16 P07 P17 P08 P18 P09 P19 P10 P20

Delete Name

Program Table lists the channels that are

stored in the memory. By moving the cursor in

four directions, you can reach 20 programmes

in the same page. You can scroll up or scroll

down to see all the programmes while in TV

mode by pressing the navigation buttons. By

cursor action, programme selection is done

automatically.

Name

To change the name of a programme, select

the de s i r e d p r o g ramme a nd p ress the

YELLOW button.

The first letter of the selected name starts to

blink. Press  /  button to change that letter

and

/  button to select the other letters. By

pressing the

YELLOW button, you can store

the name.

Move

Select the programme that you want to insert

by using the navigation buttons. Press the

GREEN button. Using navigation buttons, move

th e selec ted pro g ramm e to the de c ided

programme space and press the GREEN

button again.

P11 P12

Move A.P.S

Exit: TV

English - 35 -

Delete

You May Unlock this Program

Enter old PIN

Enter new PIN

To delete a programme, press the RED button.

Pressing the

RED button again erases the

selected programme from the programme list

and the programmes below shift one line up.

APS (Auto Programming System)

When you press the BLUE button for APS, Auto

Programming System

menu will appear on

the screen.

Favourite Mode

You can set various channels as favourites

so th a t only th e fa vour i te chann e ls are

navigated. To set a favourite, use the navigation

buttons to select a channel and then press

the

item. The channel selected as a

favourite appears in the Program Table with a

favo urites icon ( ) against the channel

name. For removing a favourite, carry out the

same operation. To exit, press M.

Program Lock

Enter PIN

Change PIN

Back : Menu Exit : TV

Pr o gram Locking pr o vides a pas s word-

protected access to channels selected by

parents. In order to lock a channel you should

know the Program Lock password (default

value is set to 0000 in the factory and can only

be changed from the

Program Lock menu).

Enter PIN

Select the channel that you desire to lock by

highlighting it and then press the

When the

button is pressed, Program Lock

button.

menu will be displayed on the screen. After

entering the pin code, desired channel will be

locked. The program lock icon will appear next

to the channe l name. W hen the lo c k ed

channel is selected through

P+ or P- buttons,

the fo l l o wing wa r ning sc r e e n will b e

displayed:

Program Is Locked!

from Program Table.

Change PIN

Select Change PIN by pressing / button.

Use

button to change the PIN code. After

pressing

button, the following message

appears on the screen:

Program Lock

Back : Menu Exit : TV

Enter old PIN code through the numeric

buttons and then enter your new PIN code.

Program Lock menu will be displayed on the

screen when you enter the new PIN code:

Program Lock

Back : Menu Exit : TV

Program Lock Menu will again be displayed

after a short while of the identification of new

PIN.

Hint: If you forget your Program Lock password, you

can deactivate the Program Lock by using the code 7910 and be able to set new password for future use. Thus, do keep this code in a safe place for future reference.

English - 36 -

PC Mode Menu System

GEOMETRY

H Position

V Position



See the “Connecting the LCD TV to a PC”

section for connecting a PC to the TV set.

For switching to

PC source, press the

button on your remote control and select PC

input.

Note that PC mode m e nu se t t i n g s are

available only while the TV is in PC source.

Sound Menu

The items in this menu are described at

“Sound Menu” section explained in the “Menu

System” section.

Feature Menu

Feature menu settings are identical to the

settings explained in “

Feature Menu” section

in the “Menu System” section.

PC Picture Menu

Select PC Picture menu by pressing  / button

and then press

appears on the screen.

button. PC Picture menu

Brightness, Contrast and

Colour Temperature adjustments in this menu

are identical to adjustments defined in TV picture

menu in “Menu System” part.

Geometry Menu

Select the fourth icon by pressing  / button

and then press

appears on the screen:

button. Geometry menu

H. (Horizontal) Position

This item shifts the image horizontally to right

hand side or left hand side of the screen.

Select H. position by pressing / button.

Use

/  button to adjust the value.

V. (Vertical) Position

This item shifts the image vertically towards

the top or bottom of the screen.

V. position by pressing / button.

Select

Use

/  button to adjust the value.

Clock

adjustments correct interference that

Clock

appear as vertical banding in dot inten sive

prese n t a t i o n s li k e spread s h e e t s or

paragraphs or text in smaller fonts.

Select Clock by pressing / button. Use

/  button to adjust the value.

Phase

Depen d i n g on th e re s o l u t ion and scan

frequency that you input to the TV set, you may

see a hazy or noisy picture on the screen. In

such a case, you can use this item to get a

clear picture by trial and error method.

Phase by pressing / button. Use

Select

/  button to adjust the value.

Auto Adjustment

If you shift the picture horizontally or vertically

to an unwanted position, use this item to put

the picture into correct place automatically.

Select

Auto Adjustment item by using /

buttons. Press  or OK button.

Warning: Auto position adjustment recommended

to be done with the full screen image for the proper adjustment.

Clock

Phase Auto Adjustment

Back : Menu Exit : TV

English - 37 -

Displaying TV Information

Programme Number, Programme Name,

Sound Indicator

are displayed on the screen when a new

programme is entered or button is pressed.

and Zoom Mode information

4:3

Use to view a normal picture (4:3 aspect ratio)

as this is its original size.

Mute Function

Pr ess b utton to disa ble sou nd. Mute

indicator will be displayed in the upper side

of the screen.

To cancel mute, there are two alternatives; the

first one is pressing the

second one is increasing the volume level.

button and the

Personal Preference

Press PP button to adopt the previous settings

that you had stored before.

Zoom Modes

You can change the aspect ratio of the TV for

viewing the picture in different zoom modes.

Press /WIDE button to directly change the

zoom mode. Available zoom modes are listed

below:

Auto

Whe n a WSS (Wide Screen Signal ling)

signal, which shows the aspect ratio of the

picture, is included in the broadcast signal or

the signal from an external device, the TV

au tomat icall y chan g es the

according to the

• When the

correctly due to poor

when you want to change the

change to another

WSS signal.

AUTO mode does not function

WSS signal quality or

ZOOM mode manually.

ZOOM mod e

ZOOM mode,

16:9

This uniformly stretches the left and right sides

of a normal picture (4:3 aspect ratio) to fill the

wide TV screen.

• For 16:9 aspect ratio pictures that have been

squeezed into a normal picture (4:3 aspect

ratio), use the 16:9 mode to restore the

picture to its original shape.

Cinema

This zooms up the wide picture (16:9 aspect

ratio) to the full screen.

Subtitle

This zooms up the wide picture (16:9 aspect

ratio) with subtitles to the full screen.

English - 38 -

Teletext

Teletext system transmits information such

as news, sports and weather on your TV. Note

that if the signal becomes insufficient, some

text errors may occur or the teletext mode may

be quitted.

Teletext function buttons are listed below:

Teletext On-Off / PAT mode

Activates teletext mode when pressed once.

Pressing this button again will split the screen

into two windows, one displaying the teletext

and the other displaying the current channel.

Pressing again will quit the teletext mode.

Index

Selects the teletext index page.

Mix

Places the teletext screen over the programme.

Expand

Press once to enlarge top half of the page,

press again to enlarge the bottom half of the

page. Press again to revert back to normal

size.

Reveal

Shows hidden information (e.g. solutions of

games).

Hold

Holds a text page when convenient. Press again to

resume.

Subcode Pages / Time

Selects subcode pages if available when the

teletext is activated. When the teletext is not

activated, displays time info if the programme

has teletext transmission.

P+ / P- and numbers (0-9)

Press to select a page.

Note: Most TV stations use code 100 for their

index pages.

Coloured Buttons

(RED/GREEN/YELLOW/BLUE)

Your TV supports both FASTEXT and TOP text

systems. W hen these systems are available,

the pages are divided into groups or topics.

When FASTEXT system is available, sections

in a teletext page will become colour-coded

and can be selected by pressing the coloured

butt o n s . Press a coloured button that

corresponds to with your needs.

The coloured writings will appear, showing

you, which coloured buttons to use when

transmission is present. Pressing P - or

text

P + co m mands will requ e st the ne xt or

previous page respectively.

TOP

English - 39 -

Tips

Screen Care

Clean the screen with a slightly damp, soft

cloth. Do not use abrasive solvents as they

may damage the coat ing la yer of the TV

screen.

For your safety, unplug the mains plug when

cleaning the set. When moving the TV, hold it

properly from the bottom part.

Image Persistence

Please note that ghosting may occur while

displaying a pe rsistent image. LCD TVs’

image persistence may disappear after a short

time. Try turning off the TV for a while.

To avoid this, do not leave the screen in still

picture for extended periods.

No Power

If your TV system has no power, please check

the main power cable and connection to the

mains socket outlet.

Poor Picture

Have you selected the correct TV system? Is

your TV set or house aerial located too close

to a non-earthed audio equipme nt or neon

lights, etc.?

Mountains or high buildings can cause double

pictures or ghost images. Sometimes you can

improve the picture quality by changing the

direction of the aerial.

Is the picture or teletext unrecognis able?

Check if yo u have entered the co r r e c t

frequency.

The picture quality may degrade when two

peripherals are connected to the TV at the

same time. In such a case, disconnect one of

the peripherals.

No Picture

Is the aerial connected properly? Are the plugs

connected tightly to the aerial socket? Is the

aerial cable damaged? Are suitable plugs

used to connect the aerial? If you are in doubt,

consult your dealer.

No Picture means that your TV is not receiving

a transmission. Have you selected the correct

button on the remote control? Try once more.

Sound

You cannot hear any sound. Did you perhaps

interrupt the sound, pressing the

Sound is com i n g from on l y on e of th e

speakers. Is the balance set to one extreme?

See

Sound menu.

button?

Remote Control

Your TV no longer responds to the remote

control. Perhaps the batteries are exhausted.

If so you can still use the local buttons at the

bottom of the TV.

Input Sources

If you cannot select an input source, it is

possible that no device is connected.

Check the AV cables and connections if you

have tried to connect a device.

CI Module

If you are experiencing a problem with the CI

module, it is possible that CI module is not

properly inserted. Remove the CI card and

then reinsert.

If the problem persists, it is possible that your

CI module is not recognized. Try inserting a

different CI module.

English - 40 -

Appendix A: PC Input Typical Display Modes

Resolution

Frequency

The display has a maximum PC resolution of 1360 x 768, frequency range of 56-75 Hz.

The following table is an illustration of some of the typical video display modes.

Your TV may not support different resolutions. Supported resolution modes are listed below.

If you switch your PC to an unsupported mode, a warning OSD will appear on the screen.

Mode

Horizontal Vertical Hor.(kHz) Ver.(Hz)

1 2 3 4 5 6 7 8

9 10 11 12 13

640 480 31.5 60 640 480 37.9 72 640 480 37.5 75 800 600 35.2 56 800 600 37.9 60 800 600 48.1 72

800 600 46.9 75 1024 768 48.4 60 1024 768 56.5 70 1024 768 60 75

1280 1024 64 60 1280 768 47.8 60

1360 768 47.7 60

Note : Your PC may not work correctly with some resolution modes which are listed above

because of unexpected causes. W hen you confront with such a problem, please try switching

your PC to different resolution modes.

English - 41 -

Specifications

With foot

Without foot

TV BROADCASTING

PAL/SECAM B/G D/K K' I/I' L/L'

POWER CONSUMPTION (W)

60W

<1 W (Standby)

RECEIVING CHANNELS

VHF (BAND I/III) UHF (BAND U) HYPERBAND CABLE TV (S1-S20/ S21-S41)

NUMBER OF PRESET CHANNELS

100

CHANNEL INDICATOR

On Screen Display

RF AERIAL INPUT

75 Ohm (unbalanced)

OPERATING VOLTAGE

220 - 240V AC, 50 Hz

AUDIO

Nicam

AUDIO OUTPUT POWER (W

) (%10 THD)

RMS.

2 x 3 W

PANEL

16:10 display, 19” screen size

DIMENSIONS

140

L H

480 480

398 357 5,1

(mm)

5,4

Your SANYO product is designed and manufactured with high quality materials and components

which can be recycled and reused.

This symbol means that electrical and electronic equipment, at their end-of-life,

should be disposed of separately from your household waste.

Please dispose of this equipment at your local community waste collection/

recycling centre.

In the European Union there are separate collection systems for used electrical

and electronic products.

Please help us to conserve the environment we live in!

English - 42 -

Pin Specifications

Signal Input

PC RGB Terminal (D-sub 15-pin connector)

Pin Input signal

1 R 2 G or sync on green 3 B 4 No connection 5 No connection 6 R.GND 7 G.GND 8 B.GND

9 No connection 10 GND 11 No connection 12 [SDA] 13 H.s ync or H/V composite sync 14 V.sync. [V.CLK] 15 [SCL]

• When different kinds of input signals are

simultaneously input to the monitor via a graphics

board or the like, the monitor will automatically

select the signals in the following priority order:

Sync signal type Priority

H/V s eparate sync. 1

H/V composite s ync. 2

sync.on Green * 3

• Even in the case of the recommended

signals shown on the following page,

there may be instances when correct

display is not possible. In this case, use

H/V separate sync, H/V composite sync.

HDMI connector pin specifications

Pin Input signal Pin Input signal

1 TMDS Data2+ 11 TMDS Clock Shield 2 TMDS Data2 Shield 12 TMDS Clock 3 TMDS Data 2- 13 CEC 4 TMDS Data 1+ 14 Reserved (N.C. on device) 5 TMDS Data1 Shield 15 SCL 6 TMDS Data1- 16 SDA 7 TMDS Data0+ 17 DDC/CED Ground 8 TMDS Data0 Shield 18 +5V Power 9 TMDS Data0- 19 Hot Plug Detect

10 TMDS Clock+

SCART connector pin specifications

Pin I nput signal Pin Input signal

1 A UDIO OUT (RIGHT) 12 Not used 2 AUDIO IN (RIGHT) 13 RGB-R GND 3 AUDIO OUT (LEFT/MONO) 14 GND 4 AUDIO GND 15 RGB-R / S.VHS CHROMINANCE IN 5 RGB-B GND 16 BLANKING SIGNAL 6 AUDIO IN (LEFT/MONO) 17 COMPOSITE VIDEO GND 7 RGB-B IN 18 BLANKING SIGNAL GND 8 AUDIO / RGB SWITCH / 16:9 19 COMPOSITE VIDEO OUT

9 RGB-G GND 20 COMPOSITE VIDEO / S.VHS LUMINANCE IN 10 Not used 21 GND / SHIELD (CHASSIS) 11 RGB-G IN

English - 43 -

Important Instructions

For your own safety read following instruction carefully before attempting to connect this unit to

the mains supply.

MAINS (AC) OPERATION

The wires in the mains lead are coloured in accordance with the following code :

GREEN

YELLOW

(Earth)

(if there is

earth cable)

BLUE

(Neutral)

IMPORTANT

As the colours of the wires in the mains lead of this appliance may not correspond with

the coloured markings identifying the terminals in your plug, proceed as follows:

The wire which is coloured green and yellow must be connected to the terminal which

is marked with the letter E, or by the earth symbol, or coloured green or green and

yellow.

The wire which is coloured blue or black must be connected to the terminal which is

marked with the letter N or coloured Black.

The wire which is coloured brown or red must be connected to the terminal which is

marked with the letter L or coloured Red.

For continued protection against risk of fire, replace only with same type and rating of

fuse (ASTA approved 5A 250VAC fuse).

FUSE

BROWN

(Live)

CAUTION

TO PREVENT ELECTRIC SHOCK DISCONNECT FROM THE MAINS BEFORE

REMOVING COVER. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING

TO QUALIFIED SERVICE PERSONNEL.

SAFETY PRECAUTION

THIS EQUIPMENT MUST BE DISCONNECTED FROM THE MAINS WHEN NOT IN

USE. DO NOT ALLOW THIS UNIT TO BE EXPOSED TO RAIN OR MOISTURE.

English - 44 -

THE GUARANTEE

The seller of this equipment (the vendor) warrants to the initial retail purchaser that if the equipment becomes defective, and the defect is shown to be due to faulty materials or workmanship within a period of 12 Months from the date of sale to the original purchaser it will be repaired (or at the vendors sole option) replaced free of charge, always providing that: The equipment has at all times been used in accordance with the operating instructions issued by the manufacturer, and has not been connected to an electrical supply for which it has not been properly adjusted. Unauthorised repairs or modifications, which have not been expressly approved by the manufacturer, shall render this guarantee null and void.

This guarantee is not transferable and is only applicable in the UK.

Nothing in this express warranty affects the statutory rights available to the purchaser of this equipment

EXCLUSIONS

SANYO shall not be liable for any removal or installation or re-installation of the equipment. The warranty does not coverFailure due to fair wear and tear of any item. Cosmetic items, remote controls or parts and consumable items such as lamps, filters, batteries, tapes, cables or connectors. Accidental damage or damage caused by negligence or misuse by the user. Failure caused by lightning strike, storage or operation outside the specified environment, incorrect installation, lack of routine maintenance outlined in the operating instructions supplied with the unit, incorrect fitting of lamps, filters, batteries or other consumables or parts. Units not originally supplied by SANYO Europe Ltd through a UK Reseller.

Dear Customer.

Thank you for buying SANYO. This equipment should give you many years of pleasure and faithful service but in the event that a fault occurs, the following notes for you guidance may be helpful:-

1: PLEASE RETAIN YOUR PURCHASE RECEIPT

WHICH WILL BE REQUIRED FOR SERVICE DURING WARRANTY.

2: If your SANYO equipment proves faulty during the

period of guarantee, take it or send it back to the dealer who originally supplied it together with this guarantee and the proof of purchase. We have made arrangements with our approved dealers under which they will carry out in guarantee service repairs on our behalf. In this way, we hope to reduce to a minimum the amount of time you will be without your equipment.

3: If for some reason it is impossible to return the

equipment to the original supplier, please contact our Customer Relations Department at the address below for further advice.

4: Should the equipment require servicing after the

expiry of the guarantee period, take or send it to the original supplier or any other Sanyo dealer. He will be pleased to give you a quotation for the repair.

Customer Relations Department, SANYO Europe Ltd. SANYO House, 18, COLONIAL WAY, Watford, Hertfordshire, WD24 4PT. Tel: 01923 246363

Manufacturer and Address

SANYO Electric Co., Ltd. 5-5, Keihan-hondori, 2-chome, Moriguchi City, Osaka, Japan

Authorized Representative and Address

SANYO FISHER Sales (Europe) GmbH Stahlgruberring 4, D-81829 Munich, Germany

042-02514/1.5

50125235

SANYO Electric Co., Ltd.

Sanyo CE19LD95-B Instruction Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
