Sansui SLEDVD329, SLEDVD329A User Manual

OWNER’S MANUAL GUIDE D’UTILISATION

32” CLASS LED-LCD TV WITH DVD PLAYER LED-LCD TV CATÉGORIE 32 PO ET LECTEUR DVD

SLEDVD329 SLEDVD329A

ATTENTION

If you purchase a universal remote control from your local retailer, please contact the remote manufacturer for the required programming code. Si vous utilisez avec cet appareil une télécommande universelle (autre que celle vendue avec ce téléviseur), consultez la documentation accompagnant la télécommande universelle afin de connaître le code numérique correspondant au téléviseur.

ATTENTION

FRANÇAIS ENGLISH

AIR/CABLE MODE SELECTION

When shipped from the factory, the Signal Type option is set to the “Cable” (Cable Television) mode. If not using Cable TV, set this menu option to the “Air” position. Lorsque l’appareil sort de l’usine, l’option Signal Type est en mode « Cable » (câblodistribution). Si vous n’utilisez pas la câblodistribution, sélectionnez l’option « Air ».

PLEASE HAVE THE MODEL NUMBER READY PRIOR TO THE CALL.

SI VOUS DEVEZ COMMUNIQUER AVEC LE SERVICE CLIENTÈLE, PRENEZ NOTE

FOR INFORMATION ON OUR OTHER PRODUCTS, TO ORDER ACCESSORIES ONLINE,

POUR OBTENIR DES INFORMATIONS SUR NOS AUTRES PRODUITS, POUR COMMANDER DES ACCESSOIRES,

Avant de faire fonctionner l’appareil, veuillez lire le présent guide attentivement.

OR FOR RECYCLING INFORMATION, PLEASE VISIT OUR WEBSITE AT

Before operating the unit, please read this manual thoroughly.

SÉLECTION DU MODE AIR/CABLE

IF CONTACT WITH CUSTOMER SERVICE IS REQUIRED

DU NUMÉRO DE MODÈLE AVANT D’APPELER.

CUSTOMER SERVICE: 1-800-289-0980

SERVICE/SERVICE CLIENTÈLE: 1-800-289-0980

ORION WEBSITE

SITE WEB ORION

OU LE RECYCLAGE, VEUILLEZ VISITER NOTRE SITE WEB:

www.sansuiproducts.com

ENGLISH

The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock.

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN

TO PREVENT THE SPREAD OF FIRE, KEEP CANDLES OR OPEN FLAMES AWAY

OR MOISTURE.

FROM THIS PRODUCT AT TIMES.

CAUTION: TO PREVENT ELECTRIC SHOCK, DO NOT USE THIS POLARIZED PLUG WITH AN

EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.

WARNING: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

CAUTION: Changes or modifications not expressly approved by the partly responsible for compliance with the FCC Rules

CAUTION:

THIS DIGITAL VIDEO PLAYER EMPLOYS A LASER SYSTEM. TO ENSURE PROPER USE OF THIS PRODUCT, PLEASE

READ THIS OWNER'S MANUAL CAREFULLY AND RETAIN FOR FUTURE REFERENCE. SHOULD THE UNIT REQUIRE MAINTENANCE, CONTACT AN AUTHORIZED SERVICE LOCATION-SEE SERVICE PROCEDURE.

USE OF CONTROLS, ADJUSTMENTS OR THE PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

TO PREVENT DIRECT EXPOSURE TO THE LASER BEAM, DO NOT TRY TO OPEN THE ENCLOSURE. RADIATION MAY BE PRESENT WHEN THE ENCLOSURE IS OPENED. DO NOT STARE INTO THE BEAM.

to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

could void the user’s authority to operate this equipment.

CLASS 1 LASER PRODUCT

Location of the required Marking

The rating sheet and the safety caution are on the rear of the unit.

CERTIFICATION: COMPLIES WITH FDA RADIATION PERFORMANCE STANDARDS, 21 CFR SUBCHAPTER J.

Complies with FDA performance standards for laser products except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007.

Record the model number and serial number.

Serial number _______________________________ Model number ______________________________

EN 2

NEC-NATIONAL

IMPORTANT SAFETY INSTRUCTIONS

15) Apparatus should not be exposed to dripping or splashing, and objects filled with liquids, such as vases, should not be placed on the apparatus.

16) An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits, as contact with them might be fatal.

17) Do not overload wall outlets and extension cords, as this can result in a risk of fire or electric shock.

18) Do not push objects through any openings in this unit, as they may touch dangerous voltage points or short out parts that could result in fire or electric shock. Never spill or spray any type of liquid into the unit.

19) If an outside antenna or cable system is connected to the unit, be sure the antenna or cable system is grounded to provide some protection against voltage surges and built-up static charges, Section 810 of the National Electrical Code, ANSI/NFPA 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to

ELECTRICAL CODE S2898A

grounding electrodes, and requirements for the grounding electrode.

20) When replacement parts are required, be sure the service technician uses replacement parts specified by the manufacturer or those that have the same characteristics as the original part.

Unauthorized substitutions may result in fire, electric shock or other hazards.

21) Upon completion of any service or repairs to this unit, ask the service technician to perform safety checks to determine that the unit is in proper operating condition.

22) Keep your fingers clear of the disc slot as it is closing. It may cause injury.

EXAMPLE OF ANTENNA GROUNDING AS PER THE

NATIONAL ELECTRICAL CODE

GROUND

CLAMP

ELECTRIC SERVICE

EQUIPMENT

ANTENNA LEAD IN WIRE

ANTENNA DISCHARGE UNIT (NEC SECTION 810-20) GROUNDING CONDUCTORS (NEC SECTION 810-21)

GROUND CLAMPS POWER SERVICE GROUNDING

ELECTRODE SYSTEM (NEC ART 250, PART H)

3 EN

IMPORTANT SAFETY INSTRUCTIONS

23) When you connect the product to other equipment, turn off the power and unplug all of the equipment from the wall outlet. Failure to do so may cause an electric shock and serious personal injury. Read the owner's manual of the other equipment carefully and follow the instructions when making any connections.

24) Reduce the volume to the minimum level before you turn on the product. Otherwise, sudden high volume sound may cause hearing or speaker damage.

25) Do not allow the product to output distorted sound for an extended period of time. It may cause speaker overheating and fire.

26) When you use the headphones, keep the volume at a moderate level. If you use the headphones continuously with high volume sound, it may cause hearing damage.

27) Do not look into the opening of the disc slot or ventilation opening of the product to see the source of the laser beam. It may cause eye damage.

28) Do not use a cracked, deformed, or repaired disc. These discs are easily broken and may cause serious personal injury and product malfunction.

29) This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.

30) The socket-outlet must be installed near the unit and easily accessible.

CONDENSATION

Moisture will form in the operating section of the player if the player is brought from cool surroundings into a warm room or if the temperature of the room rises suddenly. When this happens, player's performance will be impaired. To prevent this, let the player stand in its new surroundings for about an hour before switching it on, or make sure that the room temperature rises gradually. Condensation may also form during the summer if the player is exposed to the breeze from an air conditioner. In such cases, change the location of the player.

HOW TO HANDLE THE LCD PANEL

Do not press hard or jolt the LCD panel. It may cause the LCD panel glass to break and injury may occur.

•

If the LCD panel is broken, make absolutely sure that you do not touch the liquid in the panel. This may cause skin inflammation. If the liquid gets in your mouth, immediately gargle and consult with your doctor. Also, if the liquid gets in your eyes or touches your skin, consult with your doctor after rinsing for at least 15 minutes or longer in clean water.

CHILD SAFETY: It Makes A Difference How and Where You Use Your Flat Panel Display

Congratulations on your purchase! As you enjoy your new product, please keep these safety tips in mind:

THE ISSUE

The home theater entertainment experience is a growing trend and larger flat panel displays are popular purchases. However, flat panel displays are not always supported on the proper stands or installed according to the manufacturer’s recommendations. Flat panel displays that are inappropriately situated on dressers, bookcases, shelves, desks, speakers, chests or carts may fall over and cause injury.

THIS MANUFACTURER CARES!

The consumer electronics industry is committed to making home entertainment enjoyable and safe.

TUNE INTO SAFETY

One size does NOT fit all. Follow the manufacturer’s recommendations for the safe installation and use of your flat panel display. Carefully read and understand all enclosed instructions for proper use of this product. Don’t allow children to climb on or play with furniture and television sets. Don’t place flat panel displays on furniture that can easily be used as steps, such as a chest of drawers. Remember that children can become excited while watching a program, especially on a “larger than life” flat panel display. Care should be taken to place or install the display where it cannot be pushed, pulled over, or knocked down. Care should be taken to route all cords and cables connected to the flat panel display so that they cannot be pulled or grabbed by curious children.

WALL MOUNTING: IF YOU DECIDE TO WALL MOUNT YOUR FLAT PANEL DISPLAY, ALWAYS:

Use a mount that has been recommended by the display manufacturer and/or listed by an independent laboratory (such as UL, CSA, ETL). Follow all instructions supplied by the display and wall mount manufacturers. If you have any doubts about your ability to safely install your flat panel display, contact your retailer about professional installation. Make sure that the wall where you are mounting the display is appropriate to support the weight of the unit/ product and wall mount. If you are unsure, contact a professional installer. A minimum of two people are required for installation. Flat panel displays can be heavy.

EN 4

SAFETY PRECAUTIONS

The unit emits heat when in operation. Do not place any covers or blankets on the unit, this may cause overheating. Do not block ventilation holes, or set up near radiators. Do not place in direct sunshine. When placing on a shelf leave 4 inches (10 cm) free space around the entire unit.

4 inches

Y(VIDEO)

Notes when mounting the TV/DVD on a wall

•

If the unit is to be mounted on the wall, contact the retailer where you purchased the TV/DVD for advice, and have the equipment professionally installed. Incomplete or improper installation may cause injury to you, and/or damage to the TV/DVD.

•

To hang the television on a wall, remove these screws and then remove a stand. Before performing work spread cushioning over the base area to lay the TV on.

•

Before wall-mounting, please check carefully the location of the TV’s mounting-holes.

Screws

IMPORTANT NOTICE

Possible Adverse Effects on LCD Panel: If a fixed (non-moving) pattern remains on the LCD Panel for

long periods of time, the image can become permanently engrained in the LCD Panel and cause subtle but permanent ghost images. This type of damage is NOT COVERED BY YOUR WARRANTY. Never leave your LCD Panel on for long periods of time while it is displaying the following formats or images:

•

Fixed Images, such as stock tickers, video game patterns, TV station logos, and websites.

•

Special Formats that do not use the entire screen. For example, viewing letterbox style (16:9) media on a normal (4:3) display (black bars at top and bottom of screen); or viewing normal style (4:3) media on a widescreen (16:9) display (black bars on left and right sides of screen).

The following symptoms are not signs of malfunction but technical limitation. Therefore we disclaim any responsibility for these symptoms.

•

LCD Panels are manufactured using an extremely high level of precision technology, however sometimes parts of the screen may be missing picture elements or have luminous spots.

This is not a sign of a malfunction.

•

Do not install the LCD Panel near electronic equipment that produces electromagnetic waves. Some equipment placed too near this unit may cause interference.

•

Effect on infrared devices – There may be interference while using infrared devices such as infrared cordless headphones.

5 EN

How to attach the stand

NOTE:

• Unplug the AC cord.

• Before beginning this process, assure that the TV is laid on a clean, safe, and cushioned surface to avoid

any damage to the unit.

• Do not touch or press the TV-screen, glass might break under pressure.

Place the TV on its front onto a table. Align the stand’s bottom-plate (supplied) as seen here. It will ﬁ t in only one direction. Hold the unit and attach the stand slowly, as shown in Figure 1.

LCD PANEL SIDE

Figure 2

Figure 1

Finally secure the bottom-plate with 3 screws (supplied) (4x16mm(5/32x5/8 inches)) as indicated by the arrows in Figure 2.

Be sure to follow the instructions. Insufficient tightening or incorrect installation of the stand will not support

•

your unit correctly, and could result in damage or injury from tip-over.

How to remove the stand

When you transport this product, remove the stand and pack ﬂ at against the back of the unit in the carton. To remove the stand, perform these steps in reverse order.

For wall mounting, the base must be removed. To disconnect the base/stand remove the 3 screws from the back (see page 5).

EN 6

Features

LED color TV With DVD/CD player

Unique space saving design combines a 32” LED-LCD color TV and a DVD/CD player. A DVD disc has much more capacity, but is the same size as an audio CD disc. The Picture/Audio quality of a DVD exceeds other software. The picture quality is higher than Super VHS video cassettes. The audio quality is higher than an audio CD. The DVD also has special options; audio language selection, subtitle language selection, or multi-angle, etc. The DVD PLAYER can playback both audio CDs and MP3/WMA/JPEG CDs.

Compatible with a wide range of DVD audio outputs

Digital Audio Jack (Coaxial)

•

When a component with a built-in Dolby Digital decoder is connected, Dolby Digital sound can produce the effect of being in a movie theater or a concert hall.

•

Surround standard is different from Dolby Digital. This format is already in use in many theaters. By connecting this unit to a DTS decoder or an AV amplifier with a built-in DTS decoder, the DTS audio of DVD discs recorded in this format can be enjoyed. However, audio will not be output from the analog audio output jacks.

•

By connecting this unit to an AV amplifier with a built-in MPEG decoder, the MPEG audio of DVD discs recorded in this format can be enjoyed.

•

The Linear PCM sound of a 48 kHz/24 bit through 96 kHz/24 bit exceeds audio CD sound.

Convenience Features

Direct selection of your desired scenes using Title/Chapter/Time/Track - You can playback from the

desired scene.

Recalling Up to 12 Scenes Frame Advance - The PAUSE/STILL and SEARCH moves one frame at a time. Slow Motion - The SLOW moves you back and forth through the program by 4 steps of 1/16-1/2 times. Repeat Playback - You can repeat chapter, track, title, sides or material between two selected points. Program Playback (Audio CD/MP3/WMA CD) - You can playback tracks in programmed sequences. Zoom - You can zoom in the selected subject on the screen during playback.

Note: Make sure that discs are suitable for the following functions. Multi-Language - Maximum 32 language subtitles and maximum 8 language soundtracks can be played back

for movies or programs. Multi-Angle - Pictures of Sports or a Live Concert are recorded with many cameras. When you play such a disc, you can change the angles during playback. Parental Control - You can limit the playback of scenes or sounds of DVD discs that have a rating level encoded on the disc. Video Aspect Ratio - You can change the aspect ratio of the screen for your monitor.

You can program up to 12 scenes in memory and recall the marked scenes.

TV Features

LED Backlight System - It realize thin profile, low power consumption, eco-friendly Hg-less design and high

contrast picture.

Integrated Digital Tuner - You can view digital broadcasts without using a Digital TV Set-Top Box. Closed Caption Decoder With Full Text Mode - Displays text captions or full screen text on the screen for

hearing impaired viewers. Picture Adjustments Using The Remote Control - The On-Screen display allows precise remote control adjustment of BRIGHTNESS, CONTRAST, COLOR, TINT and SHARPNESS. Programmable TV Sleep Timer - Operable from the remote control, the TV can be programmed for up to 240 minutes to turn off automatically. On-Screen 3 Languages Display - You can select one of 3 languages, English, French or Spanish for onscreen programming. V-Chip - The V-Chip function can read the rating of a TV program or movie content if the program is encoded with this information. V-chip will allow you to set a restriction level.

* This item incorporates copy protection technology that is protected by U.S. patents and other intellectual

property rights of Rovi Corporation. Reverse engineering and disassembly are prohibited.

is a trademark of DVD Format/Logo Licensing Corporation.

* Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of

Dolby Laboratories.

* The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or

registered trademarks of HDMI Licensing LLC in the United States and other countries.

7 EN

Contents

Before using your unit

IMPORTANT SAFETY INSTRUCTIONS ...........3

SAFETY PRECAUTIONS .................................5

IMPORTANT NOTICE .......................................5

How to attach the stand ....................................6

How to remove the stand ..................................6

Features ............................................................7

Contents ...........................................................8

Disc...................................................................9

Parts and functions .........................................11

Remote control ...............................................12

Power source ..................................................13

Antenna connections ......................................14

Cable TV connections .....................................14

TV operation

Starting setup .................................................15

TV operation ...................................................15

Quick guide for menu operation ...................... 16

Convenience functions ...................................17

Channel setup.................................................20

Labeling channels ...........................................21

Setting the Lock ..............................................21

Closed Caption ...............................................23

CC options ......................................................23

Aspect Ratio ...................................................24

Media Playback ..............................................25

DVD Operation

DVD Operation ...............................................27

Status display of disc ......................................27

Playback procedure ........................................ 27

Special playback ............................................. 28

Zoom ..............................................................28

Locating desired scene ...................................28

A-B Repeat playback ......................................28

Marking desired scenes ..................................29

Changing angles .............................................29

Changing soundtrack language ......................29

Subtitles .......................................................... 29

Using HOME MENU .......................................30

Play mode .......................................................30

Audio Settings menu .......................................31

Video Adjust menu ..........................................32

Quick guide for DVD menu operation ..............32

Function Setup ................................................ 33

Parental Control .............................................. 34

Additional information

Language Code List ........................................ 35

Country/Area Code List ..................................35

Connections to other equipment .....................36

Reception disturbances ..................................39

Problems and troubleshooting ........................40

Specifications ................................................42

limited WARRANTY .......................................43

EN 8

Disc

Playable discs

Disc type and logo mark content

Audio

DVD Video

CD-DA

The following discs are also available.

DVD-ROM/-R/-RW/-R DL discs of DVD video format.

• CD-ROM/-R/RW discs of MP3/WMA/JPEG.

•

Video

(moving

pictures)

Audio

CAUTION:

•

Only the left types of discs can be played on this unit. DVD-ROM (for PC), CD-ROM (for PC), SVCD, CVD, VCD, etc. cannot be played.

•

This unit cannot play an 8 cm disc. It cannot also be played even using a disc adapter.

•

If you insert an irregular shaped disc, it may get stuck and cause a malfunction.

•

The use of a ring protector or other disc accessories will cause errors.

•

This unit is to be used exclusively with the NTSC color system. PAL and SECAM system discs cannot be used with this unit.

•

Some discs cannot be played back depending on the recording conditions.

Region Number

Region number (Regional restriction code) is built-in to the unit and DVD video discs. Region number “1” or “ALL” of DVD video discs can be used on this unit.

Title

When two or more movies are recorded on a disc, the disc is divided into two or more sections. Each section is called a “TITLE”.

TITLE 1 TITLE 2

CHAPTER 1

DVD DISC

CHAPTER 2 CHAPTER 2 CHAPTER 3CHAPTER 1

Chapter

The titles can be subdivided into many sections. Each section is called a “CHAPTER”.

Track

An Audio CD can contain several items. These are assigned to the tracks.

TRACK 1 TRACK 2 TRACK 3 TRACK 4 TRACK 5

Audio CD

ALL

Removing Disc from Case

Be sure to hold the edge of disc. Do not touch the surface of the disc. Pick up the disc gently from the case.

•

Do not scratch the disc.

•

Do not get dirt on the surface of the disc.

•

Do not stick a label or adhesive tape on the disc.

•

Do not drop or bend the disc.

Storing Disc

•

Store the disc in the case to avoid risk of scratches, dirt or damage.

•

Do not leave disc exposed to direct sunlight or in hot or humid places.

Cleaning Disc

Wipe the disc with a clean, dry cloth from center to edge.

•

Do not wipe the disc in a circular motion.

•

Do not use liquid or aerosol cleaners.

9 EN

Disc

■ Title/Chapter/Track PC-created disc

• You may not be able to play discs recorded using a personal computer or recorder for disc compatibilities, scratches or marks on the disc, dirty lenses of the unit or condensation and so on.

• Discs recorded using a personal computer may not be playable in this unit due to the setting of the application software used to create the disc. In these particular instances, check with the software publisher for more detailed information.

■ Playable files

• ISO 9660 Level 1 or 2 compliant.

Romeo and Joliet file systems are both compatible

with this player.

• DRM (Digital Rights Management) protected files will not play in this player.

For detailed information, please see the instruction

manuals or help files that came with your PC and/or software.

• File structure (may differ): Up to 299 folders on a disc; up to 648 files within each folder.

• Folder and file names can be displayed as long as they are typed in alphabets and numbers. If folder and file names are other than alphabets and numbers, they may be replaced and displayed like as “_”. Garbled characters may also be displayed in this case.

■ Playing image files

JPEG files recorded in DVD-R/-RW/-R DL and CD-R/RW can be played.

■ JPEG file compatibility

• Image files should be saved in JPEG format.

• Files recorded in Fuji Color CD, Kodak Picture CD or CD-R/-RW can be played.

• Compatible formats: Baseline JPEG and EXIF 2.2* still image files up to a resolution of 3072 x 2048.

*File format used by digital still cameras.

• Files with extensions .jpg or .JPG can be played.

• Progressive JPEG formatted files do not work.

• It may take some more time to start to play larger files than usual.

• JPEG files with different aspect ratio may be displayed with black bands (either vertical or horizontal).

■ Windows Media Audio (WMA) compatibility

• WMA is an acronym for Windows Media Audio and refers to an audio compression technology developed by Microsoft Corporation.

• You can encode your files by using Windows Media Player Ver.7, 7.1, Windows Media Player for Windows XP or Windows Media Player 9 Series.

• When encoding your files, use only applications approved by Microsoft Corporation. If you use a non-approved application, it may not work properly.

• This unit is compatible with audio files recorded with the following sampling frequency: 32 kHz, 44.1 kHz and 48 kHz.

• It is not compatible with loss-less encoding.

• Files with extensions .wma or .WMA can be played.

■ Playing MP3 (MPEG-1 Audio Layer-3) files

• This unit is compatible with audio files recorded with the following sampling frequency: 32 kHz, 44.1 kHz and 48 kHz.

• Files with extensions .mp3 or .MP3 can be played.

• For the best quality of sound, 128 kbps or higher bit rate is recommended.

■ Copy Control CD (CCCD)

This product is designed to conform to CD-DA (Compact Disc Digital Audio). Any other discs than CD-DA are not guaranteed with their operation and performance in this product.

Note on copyright

• Unauthorized recording of copyrighted television programs, films, video cassettes and other materials may infringe the rights of copyright owners and be contrary to copyright laws.

■ Playing Audio files

WMA and MP3 files recoded in DVD-R/-RW, CD-R/RW can be played.

EN 10

Parts and functions

Right sideFront

Remote sensor

Power indicator Red: Stanby Green: On

To display the menu screen. Press and hold both VOL (VOLUME) +/– at the same time for 1 second to display the menu screen. CH (CHANNEL)

/ buttons,

VOL (VOLUME)

+/– buttons and INPUT/ENTER button can be used

to select the desired setting during the menu screen operations.

Rear

Right side

USB INPUT

Y(VIDEO)

PC MONITOR IN jack

INPUT/ENTER button CH (CHANNEL) /STOP (7) button/MENU 5 CH (CHANNEL) / EJECT (0) button/MENU ∞ VOL (VOLUME) +/– buttons /MENU 2/3

POWER button

/PLAY (£)

HDMI1/2/DVI IN jack

VIDEO IN jacks

(AUDIO (L/R))

COMPONENT IN jacks

DIGITAL AUDIO

COAXIAL OUT jack

AUDIO OUT jack

ANT. (RF) IN jack

Y(VIDEO)

11 EN

Remote control

POWER Power On/Off DISPLAY Call TV information

TV/DVD Switch between TV and DVD

(EJECT) Eject a disc

0-9/– Direct channel selection of TV

SLEEP Sleep timer SETUP/

TV MENU PICTURE SIZE Display Picture size menu ▲▼◀▶ Cursor buttons ENTER Enter information in the menu MUTE Switch off the sound EXIT/

CANCEL VOL +/– Adjust volume of TV INPUT SELECT Display source selection menu RECALL/

ZOOM

CH DVD MENU Display DVD menu TOP MENU Select title CCD/

JUMP RETURN Remove DVD setup menu AUDIO Change soundtrack language SUBTITLE Set subtitle ANGLE Change playback angle PLAY MODE Select playback mode SLOW Forward/Reverse- slow motion MARKER Index REPEAT A-B Repeat playback between A and B SEARCH Fast Forward/Review playback PLAY Playback SKIP Skip chapter to forward or reverse direction PAUSE Pause CD sound

STOP Stop

Call DVD information

Input setting Enter a password Input “–” for digital channels

DVD mode - Call up initial setup mode TV mode - Display menu of TV

Exit from On-Screen menu Reset information in the menu

Switch between present/last channel Zoom

Select channel of TV

Closed Caption Locating desired scene

Still picture of DVD

EN 12

Remote control

Inserting Batteries

Open the battery compartment

cover in the direction of the arrow.

Operation

Aim the remote control at the remote sensor and press control

• buttons to operate. Operate the remote control within a 30° angle on either side of

• the remote sensor, up to a distance of approximately 15 feet.

NOTE:

•

Do not leave the remote control unit exposed to direct sunlight or in hot or humid places.

•

The remote control unit uses infrared beams to transmit signals, so sunlight or fluorescent light on the remote sensor may shorten operating distance.

•

Incorrect use of batteries may cause them to leak or burst. Read the battery warnings and use the batteries properly.

•

Do not mix old and new batteries.

•

Do not mix alkaline, standard (carbon-zinc), or rechargeable, (ni-cad, ni-mh, etc) batteries.

•

Remove batteries if the remote control will not be operated for an extended period of time.

Install two “AA” batteries

(supplied), paying attention to the polarity diagram in the battery compartment.

Replace the compartment cover.

Approximately 15 feet

Power source

TO USE AC POWER SOURCE

Use the AC polarized line cord provided for operation on AC. Insert the AC cord plug into a standard 120V 60Hz polarized AC outlet.

AC Outlet

Wider Hole and Blade

Polarized AC Cord Plug (One blade is wider than the other.)

NOTE:

•

Never connect the AC line cord plug to other than the specified voltage (120V 60Hz). Use the attached power cord only.

•

If the polarized AC cord does not fit into a non-polarized AC outlet, do not attempt to file or cut the blade. It is the user’s responsibility to have an electrician replace the obsolete outlet.

•

If you cause a static discharge when touching the unit and the unit fails to function, simply unplug the unit from the AC outlet and plug it back in. The unit should return to normal operation.

13 EN

Antenna connections

If you are using an indoor or outdoor antenna, follow the instructions below that correspond to your antenna system. If you are using a Cable TV service, see “Cable TV connections”.

Combination VHF/UHF Antenna (Single 75 ohm cable)

Antenna

Jack

75 ohm Coaxial Cable

Connect the 75 ohm cable from the combination VHF/UHF antenna to the Antenna Jack.

Cable TV connections

This TV has an extended tuning range and can tune most cable channels without using a Cable TV Converter box. Some cable companies offer “premium pay channels” where the signal is scrambled. Descrambling these signals for normal viewing requires the use of a descrambler device which is generally provided by the Cable TV company.

For subscribers to basic Cable TV service

75 ohm

Antenna

Jack

Coaxial Cable

For subscribers to scrambled Cable TV service

If you subscribe to a Cable TV service which requires the use of a Converter/Descrambler box, connect the incoming 75 ohm Coaxial Cable to the Converter/Descrambler box. Using another 75 ohm Coaxial Cable, connect the output jack of the Converter/Descrambler box to the Antenna Jack on the TV. Follow the connections shown below. Set the TV to the output channel of the Converter/Descrambler box (usually channel 3 or 4) and use the Converter/Descrambler box to select channels.

Incoming 75 ohm Cable TV Cable

Converter/

Descrambler

For basic Cable TV service not requiring a Converter/ Descrambler box, connect the 75 ohm Coaxial Cable directly to the Antenna Jack on the back of the TV.

Antenna

Jack

75 ohm Cable to TV

For subscribers to unscrambled Cable TV service with scrambled premium channels

If you subscribe to a Cable TV service in which basic channels are unscrambled and premium channels require the use of a Converter/Descrambler box, you may wish to use a signal Splitter and an A/B Switch box (available from the Cable TV company or an electronics supply store). Follow the connections shown below. With the switch in the “B” position, you can directly tune any nonscrambled channels on your TV. With the switch in the “A” position, tune your TV to the output of the Converter/Descrambler box (usually channel 3 or 4) and use the Converter/Descrambler box to tune scrambled channels.

Incoming 75 ohm Cable TV Cable

Splitter

Converter/

Descrambler

A/B Switch

75 ohm Cable to TV

Antenna

Jack

EN 14

Starting setup

TV operation

The Setup Wizard menu appears the first time you turn on the TV, and assists you to specify the Air/Cable setting, and program your channels automatically.

IMPORTANT: Make sure that the antenna or cable TV system connection is made!

To turn on the TV, press POWER. (POWER

indicator on the front of the unit changes green. It may take approx. 10 seconds for a picture to appear on screen.) The Setup Wizard function begins.

Setup Wizard

TV Location Store

Go to next step

Press ▲ or ▼ to select “TV Location”, then press

◀ or ▶ to select “Store” or “Home”. This product qualifies for ENERGY STAR In Home mode default setting. Then press ▼ or ENTER.

NOTE:

This unit has been preset to STORE

• brightness. This setting does not qualify under ENERGY STAR. To reduce brightness and energy consumption, change setting to ‘HOME’. This setting does qualify under ENERGY STAR.

Press ▶ or ENTER to go to next step.

Press ◀ or ▶ to select your time zone, then

press ▼ or ENTER.

In the rare event that you live within broadcast

• range of two stations in two different time zones, the TV may recognize the wrong station for the auto clock set.

Press ◀ or ▶ to select daylight saving time on

or off, then press ▼ or ENTER. Press ◀ or ▶ to select desired time format, then

press ▼ or ENTER. Press ▶ or ENTER to go to next step.

Press ▲ or ▼ to select “Air/Cable”, then press

◀ or ▶ to select signal type that you using, then press ▼ or ENTER.

Press ▶ or ENTER to go to next step.

Auto Scan will begin. After tuning is completed,

the TV channel appears on the screen.

Depending on the reception condition, it

• may take up to 30 minutes to complete memorizing digital cable channels. Please allow the process to complete without interruption.

NOTE:

If you press MENU or EXIT in the process of “Auto Scan”,

• the Auto Scan stops and changes to normal screen. When you make a menu selection, your changes occur

• immediately. You do not have to press MENU to see your changes.

To turn on the TV, press POWER. (POWER

indicator on the front of the unit changes green. It may take approx. 10 seconds for a picture to appear on screen.)

Adjust the volume level by pressing VOL + or – .

The volume level will be indicated on the screen by brown bars. As the volume level increases, so do the number of bars. If the volume decreases, the number of brown bars also decreases.

Set the signal type option to the appropriate

position (see “Air/Cable selection” on page 20). Press the Direct Channel Selection (0-9, –)

buttons to select the channel. (If you press only channel number, channel selection will be delayed for a few seconds.)

TO SELECT ANALOG CHANNELS

1-9: Press 1-9 as needed. Example, to

10-99: Press the 2 digits in order. Example,

100-135: Press the 3 digits in order. Example, to

TO SELECT DIGITAL CHANNELS

Press the first 1-3 digits, then press the – button, followed by the remaining number. Example, to select channel 15-1, press 1, 5, –, 1, then press ENTER.

•

The same program may be available on either

VHF/UHF/CABLE CHANNELS

VHF 2-13

UHF

14-69

NOTE:

If a channel with no broadcast is selected, the sound will

• automatically be muted. It may take a few seconds for a digital channel picture to

• appear on screen after being selected.

To select the video input source

To view a signal from another device connected to your TV, such as a VCR player, press INPUT SELECT, then press ▲ or ▼, then press ENTER.

select channel 2, press 2, then press ENTER.

to select channel 12, press 1, 2, then press ENTER.

select channel 120, press 1, 2, 0, then press ENTER.

If a channel is selected with only audio content, “Audio Only” will be displayed on the screen. If a channel is selected with a weak digital signal, “No Signal” will be displayed on the screen.

an analog channel or a digital channel. You may choose to watch either format.

Air Cable

VHF 2-13

STD/HRC/IRC 14-36 (A) (W) 37-59 (AA) (WW) 60-85 (AAA) (ZZZ) 86-94 (86) (94) 95-99 (A-5) (A-1) 100-135 (100) (135) 01 (4A)

15 EN

CH /

Press and release CH / . The channel automatically stops at the next channel set into memory. For proper operation, before selecting channels, they should be set into the memory. See “Channel setup” on page 20.

DISPLAY

Press DISPLAY to display the current information on the screen.

When the TV receives a digital signal, the digital information will appear.

15-1

CH-1

3_ARTE_Monosco_0820_0000_0030_Audio6_ABCDEFGHIJKLMNOPQ RSTUVWXYZabcdefghijklmnopqrstuvwxyz_ABCDEFGHIJKLMNOPQR STUVWXYZabcdefghijklmnopqrs tuvwxyz_ABCDEFGHIJKLMNOPQRS TUVWXYZabcdefghijklmnopqrs

Service1

480i Audio 2/3

2013/01/01 17:10 17:00-17:30

Monoscope_480i_1

Digital Air

TV-14-D

Good

Channel number• DTV Signal condition•

Broadcast program name

Channel label (if preset)•

• V-Chip rating• Current date and time• Program guide• Audio language• Resolution• Closed Caption•

Press DISPLAY again to clear the call display.

NOTE:

•

After a few seconds, DISPLAY screen will return to normal TV operation automatically.

SLEEP

To set the TV to turn off after a preset amount of time, press SLEEP on the remote control. The clock will change for each press of the SLEEP button (Off, 5 min, 10 min, ..., 240 min).To confirm the sleep timer setting, press SLEEP and the remaining time will be displayed for a few seconds. To cancel the sleep timer, press SLEEP repeatedly until the display turns to Off.

Quick guide for menu operation

Call menu and for example: Select Menu Language.

Press INPUT SELECT to select TV mode.

Press MENU. The TV menu screen will appear.

Picture Sound Time Setup Lock Channel

Picture Mode

Brightness

Contrast

Color

Tint

Sharpness

Color Temperature

Advanced Settings

Press ◀ or ▶ to select “Setup”, then press ▼.

Press ▲ or ▼ to select “Menu Language”, then

press ◀ or ▶ to select the desired language. …on the following pages the menu can be called in the same way as here.

Press MENU to return to the previous screen.

NOTE:

•

If no buttons are pressed for more than about 30 (depending on your setting) seconds, the menu screen will return to normal operation automatically.

•

During TV or external input mode (except PC input mode), if there is no signal reception, the TV will change to standby after approx. 15 minutes (in PC input mode: 5 minutes).

Standard

Normal

EN 16

Convenience functions

You can change the default settings by pressing the MENU button on your remote, then select the one of the icons at the top of the menu - follow the On-Screen prompts to set your preferences.

Icon Selected Items Setup hint


Picture Mode

Power Saving The darker the brightness for power-saving Standard Standard picture quality Dynamic Bright and dynamic picture Soft Soft edge picture setting User Your personal preferences

Brightness You can adjust the picture quality to your preference. Contrast Color Tint

Sharpness Color Temperature Cool (Bluish) / Normal (Neutral) / Warm (Reddish) Advanced Settings

Aspect Ratio See page 24. Noise Reduction To set the level of decreasing noises included in the video

Medium / High / Off /

Low

DBC Use this feature to change the Black level automatically

Off / ECO / On

DLC DLC (Dynamic Luminance Contrast) function would adjust

Off / On

Film Mode A smoother motion may be obtained by setting the Film

Off / On

HDMI Mode Select the HDMI input signal as Video (for video) or Graphic

Video / Graphic

Available only when you selected “User”.

• “Tint” is available only in Analog TV and AV mode.

•

signal.

according to the brightness of an image. The Black level will become dark in a dark scene. If “ECO” is selected, the power consumption is reduced.

DBC is not available in Media mode.•

the luminance follow the average brightness automatically

Mode to “On”.

(for PC).

17 EN

Convenience functions

Icon Selected Items Setup hint

Sound

Equalizer Settings

Equalizer Mode

Standard / Music / Movie / Sports

User

150 / 500 / 1K / 5K / 10K Hz

Balance Adjust the left and right sound channel volume.

MTS The multi-channel TV sound (MTS) feature provides high-

Stereo / SAP / Mono

Audio Language When two or more audio languages are included in a digital

English / French / Spanish

Digital Audio Output Select the format for your digital audio output If you have

Raw / Off / PCM

Surround Sound

Off / On

AVL Volume level can be adjusted automatically by the sound

Off / On

Time

Sleep Timer Sleep timer switches the TV to standby after a defined period

Off / 5 / 10 / 15 / 30 / 60 / 90 / 120 / 180 / 240 min

Auto Power Off When the Set and Remote button operation are not operated

Off / 1 / 2 / 4 Hour

Time Zone Select your local time zone for auto clock feature.

Daylight Saving Time If you want to activate the daylight saving time, select “On”.

Off / On

Time Format Select the time format.

12-hour / 24-hour

Auto Clock The Auto Clock function will automatically set the built-in

Off / On

Clock Using the ▲/▼/◀/▶, the setting value is changed.

You can choose a basic equalizer mode. Depending on this setting, the following detail setting is set to default value of each mode.

The setting of this item adjusts the audio level of its frequency corresponding to each setting.

Available only when you selected “User”.•

fidelity stereo sound. MTS also can transmit a second audio program (SAP) containing a second language or other audio information. This item is valid only when the analog broadcast.

signal, you can select one of the audio language. (This function is available only for digital broadcast.)

connected an amplifier / receiver to the digital audio jack on your TV.

The dynamic presence and sound created offers a thoroughly enjoyable listening experience.

level.

of time. To cancel the Sleep Timer, set to “Off”.

with specified period by this setting (1/2/4 Hours), the power status is changed to stand by mode automatically.

You can select Newfoundland, Atlantic, Eastern, Central, Mountain, Pacific, Alaska, Hawaii and Samoa.

clock (Year, Month, Day and Time) when the TV is connected to an antenna or cable TV system and it is turned off. As the TV searches for a receivable station in your area and it receives a broadcast signal for Auto Clock, the Auto Clock needs several minutes to set itself.

Available only when you selected “Auto Clock” to “Off”.•

EN 18

Convenience functions

Icon Selected Items Setup hint

Setup

Menu Language

English / Français / Español You can choose from three different languages (English,

OSD Timeout

5 / 15 / 30 / 45 / 60 Sec. You can set the display time of OSD Menu. Closed Caption See page 23. Over Scan To adjust the size of the display by removing excess or

Off / On Input Label The Input Label feature allows you to label each input source

Default / Antenna / Cable /

Satellite / DTV / DVD / Blu-ray /

HD-DVD / XBOX / Wii / PS3 /

Game / Computer / VCR / DV /

Custom (10 characters) PC Settings (available only for PC mode)

H-Pos To adjust the horizontal placing of the image.

V-Pos To adjust the vertical placing of the image.

Clock Eliminates the vertical (CLOCK) interfering lines.

Phase Eliminates the horizontal (PHASE) interfering lines.

Auto To adjust the all PC settings automatically. Other Settings

Audio Only You can turn off the picture on your TV and listen to the pro-

Off / On

TV Location Select location of TV. Usually, select “Home”.

Store / Home

Restore Default Select “Yes”, then press ENTER. Restore Picture, Sound and

No / Yes

Setup Wizard See page 15. (TV mode only)

Lock See page 21. Channel See page 20.

Français (French) and Español (Spanish)) for the on-screen displays. Select the language you prefer first, then proceed with the other menu options.

unattractive when set it to”On”.

for your TV. You can select label from default value or input by yourself with ▲/▼ (alphabet select) / ◀/▶ (select character / position).

gram audio only. To exit audio only mode, press any buttons (except VOL +/-, MUTE) on your remote control or unit.

Time (Sleep Timer and Time Format only) (except “Menu Language”) settings to the default factory settings.

19 EN

Channel setup

This TV is equipped with a channel memory feature which allows channels to skip up or down to the next channel set into memory, skipping over unwanted channels. Before selecting channels, they must be programmed into the TV’s memory. To use this TV with an antenna, set the signal type option to the Air mode. When shipped from the factory, this menu option is in the Cable mode.

Air/Cable selection

Select “Channel ⇒ Air/Cable”.

Press ◀ or ▶ to select “Air” or “Cable”.

Air - VHF/UHF channels Cable - CABLE TV channels

Picture Sound Time Setup Lock Channel

Air/Cable

Auto Scan

Channel List

Show/Hide

Channel Number

Channel Label

NOTE:

It may take a few seconds for a digital channel

• picture to appear on screen after being selected.

Auto Scan

Select “Channel ⇒

ENTER.

Cable

CH-2

Auto Scan

”, then press ▶ or

receive a list based on your address or zip code. Should you require further assistance you may call our toll-free customer service line at 1-800-289-0980.

•

New digital channels may be added to your area periodically, it is recommended to perform the “Auto Scan” procedure regularly.

The new channel will be added into the channel

memory.

Show/Hide channel

You can select the channel that you want to skip.

Select “Channel ⇒ Show/Hide”, then press ▶ or

ENTER. Press ▲ or ▼ to select the channel that you want

to skip.

Picture Sound Time Setup Lock Channel

Channel Channel Label Hide

4-0

7-0

12-0

23-2

23-3

23-77

23-999

Prev Next

Press ENTER to assign P mark for unwanted

channel. Repeat steps 2 - 3 for other channels you want to

show/hide.

CH-2

CH-3

CH-77

CH-999

1/1

Picture Sound Time Setup Lock Channel

Are you sure to Auto

Scan?

No Yes

In confirmation window, Press ▶ to select “Yes”,

then press ENTER. The TV will begin memorizing all the channels available in your area.

•

It may take from 15 minutes to 30 minutes to complete memorizing digital cable channels.

Depending on the reception condition, a bar

display may not advance for several minutes, please be patient. If you press MENU during search, digital

• channel search will stop.

NOTE:

Memorizing channels is best accomplished during

• evening “PRIMETIME” hours, as more stations are broadcasting digital signals. Memorizing channels can only be accomplished while a station is broadcasting a digital signal to set that channel into memory. If you are unsure of the digital channels available

• in your area, you may visit www.antennaweb.org to

EN 20

Labeling channels

Setting the Lock

Channel label appear with the channel number display each time you turn on the TV, select a channel, or press DISPLAY. You can choose any 7 characters to identify a channel.

To create channel labels

Select “Channel ⇒ Channel Number”.

Press ◀ or ▶ to select a channel you want to

label, then press ▼ to select “Channel Label”. Then press ▶ or ENTER.

Picture Sound Time Setup Lock Channel

Air/Cable

Auto Scan

Channel List

Show/Hide

Channel Number

Channel Label

Press ▲ or ▼ repeatedly until the character you

want appears in the first space.

Picture Sound Time Setup Lock Channel

CH 3

If the character which you desire appears, press ▶. You can also change the position which input character by pressing Repeat this step to enter the rest of the characters.

Repeat steps 1-3 for other channel. You can

assign a label to each channel. When you finish inputting the label name, press

EXIT to return to the normal screen.

NOTE:

•

The channel labels will be reset after “Auto Scan” on page 20.

Cable

CH-2

◀ or ▶

An age limitation can be set to restrict children from viewing or hearing violent scenes or pictures that you may choose to exclude. The restriction applies to “TV” and “MPAA” if this data is transmitted. You may set this restriction separately. To use the Lock function, you must register a password.

To register a password

Select “Lock”, then press ▼.

Press 0000 using Number buttons(0-9). (This is

default password.)

Picture Sound Time Setup Lock Channel

Enter Password

“ ” appears instead of the number.

NOTE:

•

If you forget the password, contact Customer Service at 1-800-289-0980 for assistance. Your original remote control will be required.

•

To avoid forgetting the password, write it down and keep in a safe place.

How to enter the Lock menu

Select “Lock” menu, then press ▼.

Use Number buttons (0-9) to enter your

password.

To Lock connected devices

In the Lock menu, press ◀ or ▶ to set “System

Lock” to “On”.

Press ▲ or ▼ to select “Input Block”, then press ▶

or ENTER.

Picture Sound Time Setup Lock Channel

Component

HDMI1

HDMI2

Media

UnBlock

Press ▲ or ▼ to select which device will be

blocked, then press ◀ or ▶ to select “Block”.

NOTE:

Blocked device will appear in Source Select

• window. Enter your password before watching. If you want to use such a device again, you should setting “UnBlock” in step 3.

21 EN

To set the Lock

In the Lock menu, press ◀ or ▶ to set “System

Lock” to “On”.

Press ▲ or ▼ to select “US Rating”, then press ▶

or ENTER. Press ▲ or ▼ to select which rating will be used,

then press ▶ or ENTER. Each rating below will appear.

TV Rating

Picture Sound Time Setup Lock Channel

TV Rating

ALL FV V

TV-Y

TV-Y7

TV-G

TV-PG

TV-14

TV-MA

Press Enter to Lock or Unlock: Block

You can set the rating using age level and genre.

Age: TV-Y : All children TV-Y7 : 7 years old and above TV-G : General audience TV-PG : Parental guidance TV-14 : 14 years old and above TV-MA : 17 years old and above

Genre: All : General FV : Fantasy Violence V : Violence S : Sex L : Language D : Dialogue

Press ▲/▼/◀/▶ to select the desired rating, then press ENTER.

MPAA Rating Off : None

G : All ages PG : Parental guidance PG-13 : Parental guidance R : Under 17 years old parental guidance

suggested

NC-17 : 17 years old and above X : Adult only

Press ◀/▶ to select the desired rating.

Press EXIT to return to the normal screen.

Lock function is activated now.

NOTE:

•

The Lock function is activated only on programs and input sources that include a rating signal.

SLD

less than 13 years old

To change the password

In the Lock menu, press ▲ or ▼ to select “Change

Password”, then press ▶ or ENTER.

Enter a current password using Number buttons

(0-9).

Enter a new password using Number buttons

(0-9).

Enter the same password again to confirm.

The password is now registered.

Downloading the additional Lock rating system

As a supplement to the standard Lock rating system, your television will be able to download an additional rating system, if such a system becomes available in the future.

To download the additional Lock rating system (when available)

In the Lock menu, press ◀ or ▶ to set “System

Lock” to “On”. Press ▲ or ▼ to select “RRT Setting”, then press

▶ or ENTER. If the TV is not storing the additional rating

system, the TV will begin downloading it, which may take some time to be completed.

Set your preferred content rating limits for the

additional rating system.

NOTE:

•

You can only download the additional Lock rating system when your TV is receiving a digital signal.

•

When you download the additional rating system, it may take some time for the download to occur.

•

The Lock rating information and system are not determined or controlled by the TV.

•

The standard Lock rating system is available whether your TV is receiving a digital signal or not, and will block both analog and digital programs. To set the restriction level using the standard Lock rating system, select “US Rating” in step 2.

•

The downloadable Lock rating system is an evolving technology, and availability, content, and format may vary.

To clear the RRT Setting

In the Lock menu, press ◀ or ▶ to set “System

Lock” to “On”. Press ▲ or ▼ to select “Reset RRT”, then press

▶ or ENTER. The confirmation window will appear.

Press ▶ to select “Yes”, then press ENTER.

Your RRT Setting will clear.

EN 22

Closed Caption

WHAT IS CLOSED CAPTIONING?

This television has the capability to decode and display Closed Captioned television programs. Closed Captioning will display text on the screen for hearing impaired viewers or it will translate and display text in another language.

Captions: This Closed Caption mode will display text on the screen in English or another language. Generally, Closed Captions in English are transmitted on CC1 and Closed Captions in other languages are transmitted on CC2. Text: The Text Closed Caption mode will usually fill 1/2 of the screen with a programming schedule or other information.

Select “Setup ⇒ Closed Caption”, then press ▶ or

ENTER.

Press ◀ or ▶ to set “CC Mode” to “CC On” or “CC

on Mute”.

CC On: Captions will be displayed on the screen. CC on Mute: Only when you press MUTE,

captions will be displayed. CC Off: Captions will not be displayed on the screen.

Press ▲ or ▼ to select “Analog CC” or “Digital

CC”. When you select “Analog CC”, you can choose

from CC1~4, Text1~4. When you select “Digital CC”, you can choose

from Service1~6 and Off. Press ◀ or ▶ to select the desired Closed

mode for both Digital and Analog Captions.

NOTE:

Depending on the broadcast signal, some

• Analog Captions will function with a Digital broadcast signal. This step prevent that two kind of captions are overlapping.

NOTE:

If the program or video you selected is not closed-

• captioned, no captions will display on-screen. If text is not available in your viewing area, a black

• rectangle may appear on-screen. If this happens, set the CC Mode to “CC Off”. When selecting Closed Captions, the captioning

• will be delayed approx. 10 seconds. If no caption signal is received, no captions will

• appear, but the television will remain in the Caption mode. Misspellings or unusual characters may

• occasionally appear during Closed Captioning. This is normal with Closed Captioning, especially with live programs. This is because during live programs, captions are also entered live. These transmissions do not allow time for editing. When Captions are being displayed, on-screen

• displays, such as volume and mute may be seen but may interfere with Closed Captions. Some cable systems and copy protection systems

• may interfere with the Closed Captioned signal. If using an indoor antenna or if TV reception is

• very poor, the closed caption decoder may not appear or may appear with strange characters or misspelled words. In this case, adjust the antenna for better reception or use an outdoor antenna.

Caption

•

CC Mode will be change to”CC Off”,”CC On” or “CC on Mute” by each pressing CCD on the remote control.

CC options

When you have selected “Custom” as the display method, you can adjust the various setting listed below as follows:

This feature is designed to customize Digital Caption only.

Select “Setup ⇒ Closed Caption”, then press ▶ or

ENTER. Press ◀ or ▶ to set “CC Mode” to “CC On” or “CC

on Mute”. Press ▲ or ▼ to select “Option”, then press ▶ or

ENTER. Press ▲ or ▼ to select “Mode”, then press ◀ or ▶

to select “Custom”. Press ▲ or ▼ to select the desired item, then

press ◀ or ▶ to change the setting.

Picture Sound Time Setup Lock Channel

Mode

Font Style

Font Size

Font Edge Style

Font Edge Color

FG Color

BG Color

FG Opacity

BG Opacity Default

You can select from among the following items and parameters.

Font Style:

Select display font style.

Font Size:

Select display font size.

Font Edge Style:

Select display font edge style.

Font Edge Color:

Select display font edge color.

FG Color:

Select foreground color.

BG Color:

Select background color.

FG Opacity:

Select foreground opacity level.

BG Opacity:

Select background opacity level.

NOTE:

You cannot set both “FG Color” and “BG Color” as a

• same color.

Default

23 EN

Aspect Ratio

You can change to a variety of picture sizes— Wide, Zoom, Cinema, Normal, Full 100% (for PC) and Point to Point (for PC).

Selecting the picture size

Select “Picture ⇒

Ratio

”.

Press

NOTE:

•

◀ or ▶

described below.

Selectable picture sizes may vary depending on the input source or broadcast signal. You can be select desired size of picture by pressing PICTURE SIZE on the remote control.

Normal

In some cases, this image will display the size of standard 4:3 with a black side bar.

Wide (for 4:3 format programs)

To fill the screen, the right and left edges are extended, however; the center of the picture remains near its former ratio. The top and bottom edges of the picture may be hidden.

Advanced Settings ⇒ Aspect

to select the desired picture size, as

Full 100% (for PC mode only)

Full will display the picture at the maximum size.

Point to Point (for PC mode only)

Detects the resolution of the signal of the image and it will be shown on the screen with same amount of pixels.

Zoom (for letter box programs with subtitles)

To fill the width of the screen, it is extended horizontally. However; it is only slightly extended at the top and the bottom.

The top and bottom edges of the picture may be hidden.

A B C D E F G - - - - - - - - - - - - - - - - A B C D E F G - - - - - - - - - - - - - - - -

Cinema (for letter box programs)

The entire picture is uniformly enlarged—it is stretched the same amount both wider and taller (retains its original proportion).

The top and bottom edges of the picture may be hidden.

A B C D E F G - - - - - - - - - - - - - - - -

EN 24

Media Playback

You can enjoy viewing pictures and movies from your USB storage device.

Connect the USB storage device into the USB

Input terminal. Press INPUT SELECT then press

“Media”, then press ENTER.

NOTE:

•

Do not disconnect a USB storage device while it is being accessed. Doing so can damage the device or the files stored on the device. You can safely connect or disconnect the USB storage device when the TV is not in media mode.

•

Back up all the data in the USB storage device in case if data was lost due to unexpected accident. We do not assume any liability for the losses by misuse or malfunction.

•

Not all USB storage devices are compatible with this TV.

•

The character that exceeds the display area is not displayed.

•

Do not use USB extension cable.

•

Playable files are JPEG (.jpg/.jpeg) and Motion JPEG (.avi (MJPEG format)).

Media Browser

Media Selection

Movie


▲ or ▼

to select

Playback files

Press

◀ or ▶

Selection and press ENTER.

Press ◀ or ▶ to select “C”, then press ENTER.

Select folder or file with ▲/▼/◀/▶, and then start

the playback with ENTER.

to select Photo or Movie

You can playback the files with the following remote control buttons.

Button Action

Press to start the playback.

ENTER

Press to open the folder. Press to open the operation window.

▌▌

Press to pause the playback.

Press to start the playback or slideshow.

▶

Press to stop the playback.

■

During the playback, press to select the next file.

During the playback, press to select the previous file.

at Media

File Selection

C:\ 1 / 1

Return Up Folder Folder 1 Photo1.mpg

Photo2.jpg Photo3.jpg Photo4.jpg Photo5.mpg


Photo6.jpg Photo7.jpg Photo8.jpg Photo9.jpg

Resolution:

Size:

Date:

Time:

1920 x 1080

2000Kbytes

---- / -- / --

--: -- : --

Information window

NOTE:

The content will change in accordance with each

• media setting screen.

25 EN

Details of operation commands

Icon Operation

Play / Resume playback.

▐▐

▶

Pause.

Skip file to reverse / forward direction.

Stop.

■

Repeat playback. Press ENTER repeatedly to select desired repeat option.

Show the playlist. Press ▲ or ▼ and ENTER to select the playback

Show the file information.

Rotate the image.

Zoom in / out.

Move the frame from the center position.

Review / Fast playback.

Select start point, then select end point. Repeat material between two selected points.

Slow-motion Playback.

One frame is advanced each time select this command.

Direct jump by desired time.

EN 26

DVD Operation

The following pages describe the setup/ operation in DVD mode.

Preparation

Before DVD/CD operation, please make the following preparations.

Insert the AC cord plug into a standard 120V

60Hz polarized AC outlet.

•

If the AC cord plug is plugged in for the first time, wait for about 5 seconds before pressing

POWER.

NOTE:

•

When connecting to other equipment, unplug the unit from the AC outlet.

Press POWER on the unit or on the remote

control to turn on the unit. The POWER indicator will change to green.

When using an amplifier, switch on the amplifier.

• Press TV/DVD to select DVD mode.

The DVD startup screen will appear on the screen.

If the DVD is not operated, the unit will

• automatically shut itself after 15 minutes.

NOTE:

•

If the unit does not operate properly:

Static electricity, etc., may affect the player’s operation. Disconnect the AC power cord once, then connect it again.

•

About inserting disc:

If the unit is slanted or moved while inserting a disc, the disc may be damaged.

Status display of disc

Press DISPLAY. The status display of the disc will appear on the screen.

Display messages may change each time you press

•

DISPLAY for some discs or files.

To make the status display screen disappear, press

DISPLAY again.

Playback procedure

On the screen, “ ” changes to “Loading” and then

playback will commence.

A menu screen may appear on the TV screen,

• if the disc has a menu feature. In this case, press ▲, ▼, ◀, ▶ or ENTER to operate a menu feature.

(

Press STOP

The unit can record where you stop a video, but it

• depends on the disc you are using. Press PLAY

()

store the stopped points of the last five discs that you have played. When one of these discs is reloaded, you can resume playback from where you stopped playing last time. If you press STOP

• appears on the screen) the unit will clear the stopped point. You cannot save a stopped point for some discs.

• If a number of discs played and stored in the unit exceeds five, a new memory will overwrite the oldest stored memory.

Press (EJECT).

Remove the disc and then press POWER. The unit turns off.

When you eject the disc, you may hear some

• mechanism noise, but it is not a malfunction.

NOTE:

If a non-compatible disc is loaded, “Can’t play disc”

• or “Incompatible disc region number Can’t play disc” will appear on the TV screen according to the type of loaded disc. In this case, check your disc again (see page 9). Some discs may take a minute or so to start

• playback. A prohibition message “Depending on the disc, this

• operation may be prohibited” or “This operation can’t be performed” may appear on the screen. This message means either the feature you tried is not available on the disc, or the unit cannot access the feature at this time. This does not indicate a problem with the unit. When you insert a single-faced disc label backwards

• (i.e. the wrong way) “Loading” will appear on the display and then “Can’t play disc” will be displayed. Some playback operations of DVDs may be

• intentionally fixed by software producers. Since this unit plays DVDs according to the disc content recorded, some playback features may not be available. Also refer to the instructions supplied with the DVDs.

)

to end playback.

to resume a playback point. The unit can

() again (“Resume off”

Press TV/DVD to select DVD mode.

Place the disc in the

disc slot with the label side facing forward. (If the disc has a label.) Hold the disc without touching either of its surfaces, align it with the guides, and place it in position.

27 EN

Special playback

Fast Forward Playback

Press SEARCH (uu) during normal playback. Each press of SEARCH (uu) will increase the speed of the search.

• To resume normal playback, press PLAY

Review Playback

Press SEARCH (tt) during normal playback. Each press of SEARCH (tt) will increase the speed of the search.

• To resume normal playback, press PLAY

Still Playback

Press PAUSE/STILL pause playback.

• To resume normal playback, press PLAY () or

PAUSE/STILL

Frame Advance

Press PAUSE/STILL One frame is advanced each time you press SEARCH (tt) or SEARCH (uu).

• To resume normal playback, press PLAY ().

Slow-motion Playback

Press SLOW ( playback or still playback. Each press of SLOW will change the speed of the slow.

• To resume normal playback, press PLAY ().

•

To resume the still playback, press PAUSE/STILL

Locating a chapter or track

Press SKIP during playback to locate a chapter/track that you want to watch. Each time you press the button, a chapter or track is skipped.

NOTE:

•

The TV/DVD is capable of holding a still video image or On screen display image on your television screen indefinitely. If you leave the still video image or On screen display image displayed on your TV for an extended period of time, you risk permanent damage to your television screen.

(

(8)

during normal playback to

(8)

during normal playback.

) or SLOW ( ) during normal

)

Forward or SKIP

( )

(

)

(

)

Reverse

)

(

Zoom

This TV/DVD will allow you to zoom in on the frame image. You can then make selections by switching the position of the frame.

Press ZOOM during playback.

The center part of the image will be zoomed in. Each press of ZOOM will change the ZOOM magnification Zoom 2× and Zoom 4×.

Press ▲/▼/◀/▶ to view a different part of the

frame. You may move the frame from the center position UP, DOWN, LEFT or RIGHT.

In the zoom mode, press ZOOM repeatedly to

return to a 1:1 view.

NOTE:

•

You can select the Still Playback or Fast Forward (Review) Playback in the zoom mode.

•

Some discs may not respond to the zoom feature.

Locating desired scene

Use the title, chapter and time recorded on the disc to locate the desired point to play back.

Press JUMP during playback.

Press ▲/▼ to select the “Title Search”, “Chapter

Search”, “Time Search” or “Track Search”. Then press ▶ or ENTER.

Press Number buttons (0–9) to input the number.

If you input a wrong number, press CANCEL.

• Refer to the package supplied with the disc to

• check the numbers.

Press ENTER.

Playback starts.

• When you change the title, playback starts from

• Chapter 1 of the selected title. Some discs may not work in the above

• operation.

A-B Repeat playback

A-B repeat playback allows you to repeat material between two selected points.

Press REPEAT A-B during playback.

The start point is selected.

Press REPEAT A-B again.

The end point is selected. Playback starts at the point that you selected. Playback stops at the end point, returns to Point A automatically, then starts again.

To resume normal playback press REPEAT A-B

• again.

NOTE:

•

In A-B Repeat mode, subtitles near the A or B locations may not be displayed.

•

You may not be able to set A-B Repeat during certain scenes of the DVD.

•

A-B Repeat does not work with an interactive DVD, MP3/WMA/JPEG-CD.

EN 28

Marking desired scenes

The TV/DVD stores the points that you want to watch again up to 12 points. You can resume playback from each scene.

Marking the scenes

Press MARKER during playback.

Select the blank Marker using ▲/▼/◀/▶, then

press ENTER at the desired scene.

• Up to 12 scenes can be selected.

• Repeat this procedure to set the other 11 scenes.

Press MARKER to return to the normal screen.

Returning to the scenes

Press MARKER during playback or stop mode.

Press ▲/▼/◀/▶ to select the Marker 1-12.

Press ENTER.

Playback starts from the marked scene.

To cancel the Marker Follow the above steps 1~2, then press CANCEL.

NOTE:

Some discs may not work with the marking

• operation. The marking is cancelled when you eject the disc or

• turn the power off. Some subtitles recorded around the marker may fail

• to appear.

Changing angles

When playing back a disc recorded with multi-angle facility, you can change the view angle.

Press ANGLE during playback.

The current angle will appear.

Current/Total

Angle 1/2

Changing soundtrack language

You can select the language when you play a multilingual disc.

Press AUDIO during playback.

The current soundtrack language will appear.

Current/Total

Audio 1/2 English Dolby Digital 2/0CH

Press AUDIO repeatedly until the desired

language is selected. The on-screen display will disappear after a few seconds.

Current/Total

Audio 2/2 French Dolby Digital 2/0CH

NOTE:

•

If the desired language is not heard after pressing AUDIO several times, the language is not recorded on the disc.

•

Changing soundtrack language is cancelled after “Resume off” has been selected.

•

The initial default language or available language will be heard if the disc is played back again.

Subtitles

Changing the subtitle language

You can select the language when playing back a disc recorded with multilingual subtitles.

Press SUBTITLE repeatedly during playback until

your desired language appears. The on-screen display will disappear after a few seconds.

Current/Total

Subtitle 1/2 English

Press ANGLE repeatedly until the desired angle is

selected.

NOTE:

In case of JPEG-playback, the JPEG-image is

• rotated 90 degrees to the right. Depending on the DVD, you may not be able

• to change the angles even if multi-angles are recorded on the DVD.

Turning the subtitles off Press SUBTITLE during playback until “Off” appears.

NOTE:

• Changing subtitle language is cancelled after “Resume off” has been selected.

• Some functions may not work on some DVDs. You may not be able to turn subtitles on or off or change subtitles.

While playing the DVD, the subtitle may change

when:

- you eject or insert the disc.

- you change the title.

• In some cases, the subtitle language is not changed to the selected one immediately.

29 EN

Using HOME MENU

Playing a disc

Press SETUP during stop mode.

HOME MENU will appear.

HOME MENU

Press ▲/▼/◀/▶

to select “Disc Navigator”, then press ENTER

Press

desired option, then press ENTER.

Disc Navigator may not work with some discs.

• Depending on a disc, you can select Title,

• Chapter, or both.

Press

select Title or Chapter then press ENTER.

Press SKIP (

• previous/next page. Press RETURN to return to the previous screen.

•

▲/▼

to select

▲/▼/◀/▶

or Number Buttons (0–9) to

) or SKIP ( ) to move to the

DVD

Audio Settings Video Adjust

Play Mode

Initial Settings

Disc Navigator Title Chapter

Disc Navigator

Playing a file

Press SETUP during stop mode.

HOME MENU will appear.

Press

▲/▼/◀/▶

press ENTER.

Press

folder, then press ENTER.

Press

If you select a JPEG file, the unit shows the

• pictures one after another automatically. Press RETURN to go to the previous step.

•

NOTE:

When music files and JPEG files are recorded

• on one disc, you can play them simultaneously. Please select the music file then select the JPEG file.

to select “Disc Navigator”, then

▲/▼

to select

▲/▼

to select file, then press ENTER.

00:00/ 00:00 0kbps

Folder1 Folder2 Folder3 Folder4

Play mode

A-B repeat playback

A-B repeat playback allows you to repeat a selection between two selected points.

Press PLAY MODE

during playback. Play Mode screen will appear.

Play Mode

A-B Repeat

Repeat

Random

Program

Search Mode

A(Start Point)

B(End Point)

Off

Press ▲/▼ to select “A-B Repeat”, then press ▶ or

ENTER.

Press

▲/▼

ENTER. The start point is selected.

Press

ENTER. The end point is selected. Playback starts at the point that you selected. Playback stops at the end point and returns to Point A automatically, then starts again.

To resume normal playback

Select “Off” in step 3.

NOTE:

Some discs may not work wth the Play Mode function.

• A-B Repeat playback does not work with MP3/WMA

• CD’s.

Repeat playback

Press PLAY MODE during playback.

Play Mode screen will appear.

Press

ENTER

Press

press ENTER. The unit automatically starts repeat playback after finishing the current title or chapter.

To resume normal playback

Select “Repeat Off” in step 3.

Random playback

Press PLAY MODE during playback.

Play Mode screen will appear.

Press

ENTER

Press

option, then press ENTER. The unit automatically starts random playback.

To resume normal playback

Select “Random Off” in step 3.

NOTE:

You cannot play Random playback for programmed

• contents (Random play is not permitted during Program playback). During Random playback, the same title, chapter or

• track may be repeated. Random playback does not work with MP3/WMA CD.

•

to select “A(Start Point)”, then press

▲/▼

to select “B(End Point)”, then press

▲/▼

to select “Repeat”, then press ▶ or

▲/▼

to select desired repeat option, then

▲/▼

to select “Random”, then press ▶ or

▲/▼

to select desired random playback

EN 30

Program playback

Press PLAY MODE during playback or stop mode.

Play Mode screen will appear.

Press

▲/▼

to select “Program”, then press or

ENTER. Press

▲/▼

“Create/Edit”, then press ENTER. “Create/Edit” display differs, depending on discs or files.

Press

to select

▲/▼/◀/▶

to select Title, Chapter, Track or

Program

Program Step

01. 01

02.

03.

04.

05.

06.

07.

08.

Current Title:02 Chapter:001

Title 1-38

Title 01 Title 02 Title 03 Title 04 Title 05 Title 06 Title 07 Title 08

File, then press ENTER.

•

When you add a program, find where you want to add it (Program Step) and select Title, Chapter or Track then press ENTER. (It will be added to the left if file is added.)

•

To go to previous step, press RETURN.

•

If RETURN is pressed while programming, the content will be deleted.

•

To delete a program, select Program Step that you want to delete and press CANCEL.

Press PLAY ( ).

To play existing programmed contents, select

• “Playback Start” from Play Mode screen and press ENTER. To resume normal playback, select “Playback

• Stop” in Play Mode screen and press ENTER. Your programmed contents are saved. To delete all programmed contents, select

• “Program Delete” in Play Mode screen and press ENTER.

NOTE:

You can repeat the programmed contents. Select

• “Program Repeat” from “Repeat” in the Play Mode screen during Program playback. You cannot play Random playback for programmed

• contents (Random play is not permitted during Program playback). In stop mode, you can also enter Play Mode

• screen by selecting “Play Mode” in HOME MENU.

Locating desired scene

Press PLAY MODE during playback or stop mode.

Play Mode screen will appear. Press ▲/▼ to select “Search Mode”, then press ▶

or ENTER. Press ▲/▼ to select desired search mode option,

then press ▶ or ENTER.

Search Mode options differs, depending on

• discs or files.

Chapter 1-004

Chapter 001 Chapter 002 Chapter 003 Chapter 004

Input Title, Chapter,

Track or Folder number or Time by using

Number buttons

Play Mode

A-B Repeat

Repeat

Random

Program

Search Mode

Title Search

Chapter Search

Time Search

Input Chapter

0 0 1

(0–9) and press ENTER.

For instance, if you want to enter 1hr 4min

• (64:00), input 6, 4, 0, 0.

NOTE:

You can locate a desired scene in the Menu

• screen for some DVD videos. In stop mode, you can also enter the Play Mode

• screen by selecting “Play Mode” in HOME MENU.

Audio Settings menu

The Audio Settings menu offers features for adjusting the way discs sound.

Press SETUP during stop mode.

HOME MENU will appear.

HOME MENU

Press ▲/▼/◀/▶

to select “Audio Settings”, then press ENTER.

Press

▲/▼/◀/▶

setting the option, then press ENTER.

Press SETUP to save the setting.

Audio Settings

Equalizer Audio DRC Dialog

Equalizer

Select the most suitable setting to match a category of music that you are listening to.

Audio DRC

•

Adjusts loud sound levels down and quiet sound levels up while playing. This is useful, for instance, when you watch a film in the late night.

•

Audio DRC only works with Dolby Digital Sound.

•

The effect depends on your AV amplifier and speaker volume. Adjust the sound as you wish and find the most effective setting.

Dialog

Adjusts the audio setting when you cannot hear dialogs very well.

NOTE:

•

It may not be very effective for some discs or files.

DVD

Audio Settings Video Adjust

Play Mode

Initial Settings

Off Rock Pop Live Dance Techno Classic Soft

Disc Navigator

31 EN

Video Adjust menu

From the Video Adjust menu you can adjust various settings that affect how the picture is presented.

Press SETUP during stop mode.

HOME MENU will appear.

HOME MENU

Press

▲/▼/◀/▶

select “Video Adjust”, then press ENTER.

Press

▲/▼/◀/▶

setting the option, then press ENTER.

Press SETUP to save the setting.

Video Adjust

Sharpness Brightness Contrast Gamma Hue Chroma Level

Sharpness

Adjust sharpness of images.

Brightness

Adjust brightness of images.

Contrast

Adjust a ratio of brightness between the brightest part and the darkest part.

Gamma

Emphasizes the dark part of images.

Hue

Adjusts the balance between green and red.

Chroma Level

Adjusts color density. It is effective with animation or something with high color density.

DVD

Audio Settings Video Adjust

Play Mode

Initial Settings

Fine Standard Soft

Disc Navigator

Quick guide for DVD menu operation

You can change the default settings to customize performance to your preference.

Setting procedure

Press SETUP in stop mode.

HOME MENU will appear.

HOME MENU

Press

▲/▼/◀/▶

select “Initial Settings”, then press ENTER.

Press

▲/▼/◀/▶

to select the desired option, then

press ENTER.

Change the selection using

by referring to the corresponding page 33.

Repeat steps 3 and 4 to change other options.•

To clear HOME MENU screen, press SETUP.

DVD

Audio Settings Video Adjust

Play Mode

Initial Settings

▲/▼/◀/▶

Disc Navigator

or ENTER,

EN 32

NOTE:

It may not be very effective for some discs or files.•

Function Setup

Setting Option

Digital Audio Out settings

Digital Out On Digital audio is output when playing a disc.

Off Digital audio is not output when playing a disc.

Dolby Digital Out Dolby Digital Dolby Digital encoded digital audio is output when playing a

Dolby Digital > PCM Dolby Digital audio is converted to PCM audio before being

DTS Out DTS DTS encoded digital audio is output when playing a DTS disc.

Off DTS encoded digital audio is not output when playing a DTS

96kHz PCM Out 96kHz > 48kHz 96 kHz digital audio is converted to 48 kHz for digital output.

96kHz 96 kHz digital audio is output as is at 96 kHz.

MPEG Out MPEG MPEG encoded digital audio is output as is.

MPEG > PCM MPEG encoded digital audio is converted to PCM audio for

Video Output settings

TV Screen 4:3 (Letter Box) Set Picture Size to Natural. Widescreen movies are shown with

4:3 (Pan & Scan) Set Picture Size to Natural. Widescreen movies are shown with

16:9 (Wide) Set if you have a widescreen TV.

Language settings

Audio Language English/French/Spanish If there is an English, French or Spanish soundtrack on the

Other Language Select to choose a language other than the ones displayed.

Subtitle Language English/French/Spanish If there is an English, French or Spanish subtitle on the disc,

Other Language Select to choose a language other than the ones displayed. (see

DVD Menu Lang. w/Subtitle Lang. DVD disc menus will be displayed in the same language as

English/French/Spanish If there is an English, French or Spanish DVD menu language

Other Language Select to choose a language other than the ones displayed. (see

Subtitle Display On Subtitles are displayed according to your selected subtitle

Off Subtitles are always off by default when you play a DVD disc

Display settings

Angle Indicator On A camera icon is displayed on-screen during multi-angle

Off No multi-angle indication is shown.

Options settings

Parental Lock See page 34.

Dolby Digital DVD disc.

output.

(Noise will be output if your amplifier/receiver is not compatible with DTS audio.)

disc.

digital output.

black bars top and bottom.

the sides cropped so that the image fills the screen.

disc, then it will be played.

(See “Language Code List” on page 35.)

then it will be displayed.

“Language Code List” on page 35.)

your selected subtitle language, if possible.

on the disc, then it will be displayed.

“Language Code List” on page 35.)

language (see above).

(note that some discs override this setting).

scenes on a DVD disc.

33 EN

Parental Control

Some discs are specified as not suitable for children. Such discs can be limited not to playback with the unit.

How to into the Parental Lock menu

Press SETUP in stop mode.

HOME MENU will appear.

HOME MENU

Press

▲/▼/◀/▶ to select “Initial Settings”, then press ENTER.

Press

▲/▼

ENTER

Then press

to select “Options”, then press

▶ or ENTER

Lock menu.

Set Password

Press ▲ or ▼ to

select “Password”, then press ENTER.

Press Number

buttons (0–9) to input the password, then press ENTER.

Change Password

Press ▲ or ▼ to

select “Password Change”, then press ENTER.

Press Number

buttons (0–9) to input the current password, then press ENTER.

Press Number

buttons (0–9) to input the new password. Press ENTER. Now your new password has been set. Be sure to

remember this

number!

to enter the Parental

Initial Settings

Video Output

Language

Display

Options

Initial Settings

Digital Audio Out Video Output Language Display Options

Initial Settings

Video Output

Language

Display

Options

Initial Settings

Digital Audio Out

Video Output

Language

Display

Options

Initial Settings

Digital Audio Out

Video Output

Language

Display

Options

DVD

Audio Settings Video Adjust

Play Mode

Initial Settings

Disc Navigator

▶ or

Password

Parental LockDigital Audio Out

Level Change

Country Code

Parental Lock: Register Code Number

Parental LockDigital Audio Out

Password Change

Level Change

Country Code

Parental Lock: Password Change

Password

New Password

Parental Lock: Password Change

Password

New Password

Level Change

Press ▲ or ▼ to select

“Level Change”, then press ENTER.

Press Number

buttons (0–9) to input the current password, then press

Initial Settings

Video Output

Language

Display

Options

Initial Settings

Digital Audio Out

Video Output

Language

Display

Options

Parental LockDigital Audio Out

Parental Lock: Level Change

Password

12345678Off

ENTER.

Initial Settings

Digital Audio Out

Video Output

Language

Display

Options

Parental Lock: Level Change

Password

1234 678Off

Press ◀ or ▶ to

select from the level 1 to level 8. The limitation will more severe as the level number is lower. Then press ENTER.

Level 1: DVD software for adults cannot be

played back.

Level 8: Virtually all DVD software can be

played back.

Level Off: The parental control setting does not

function.

Country Code

Press ▲ or ▼ to select

“Country Code”, then press ENTER.

Press Number

buttons (0–9) to input the current password, then press

Initial Settings

Video Output

Language

Display

Options

Initial Settings

Digital Audio Out

Video Output

Language

Display

Options

Parental LockDigital Audio Out

Parental Lock: Change Country Code

Password

Country Code List Code

ENTER.

Press ▲ or ▼ to

select the input mode from “Country Code List” or “Code”.

•

When you selected “Country Code List”: Press

Initial Settings

Digital Audio Out

Video Output

Language

Display

Options

Parental Lock: Change Country Code

Password

Country Code List Code

▲ or ▼ to select Country Code, then press

ENTER.

•

When you selected “Code”: Press ▶ then use the Number buttons (0-9) to enter the 4-digit Country Code, then press ENTER. (see Country/Area Code List on page 35)

NOTE:

•

Depending on the discs, the unit cannot limit playback.

•

Some discs may not be encoded with specific rating level information though its disc jacket says “adult.” For those discs, the age restriction will not work.

•

If you input a wrong number, press ◀, then input correct number.

Password Change

Level Change

Country Code

Password Change

Level Change

Country Code

1 1 9

EN 34

Language Code List

Language (Language code letter), Language code

Japanese (ja), 1001 English (en), 0514 French (fr), 0618 German (de), 0405 Italian (it), 0920 Spanish (es), 0519 Chinese (zh), 2608 Dutch (nl), 1412 Portuguese (pt), 1620 Swedish (sv), 1922 Russian (ru), 1821 Korean (ko), 1115 Greek (el), 0512 Afar (aa), 0101 Abkhazian (ab), 0102 Afrikaans (af), 0106 Amharic (am), 0113 Arabic (ar), 0118 Assamese (as), 0119 Aymara (ay), 0125 Azerbaijani (az), 0126 Bashkir (ba), 0201 Byelorussian (be), 0205 Bulgarian (bg), 0207 Bihari (bh), 0208 Bislama (bi), 0209 Bengali (bn), 0214 Tibetan (bo), 0215 Breton (br), 0218 Catalan (ca), 0301 Corsican (co), 0315 Czech (cs), 0319 Welsh (cy), 0325 Danish (da), 0401

Bhutani (dz), 0426 Esperanto (eo), 0515 Estonian (et), 0520 Basque (eu), 0521 Persian (fa), 0601 Finnish (fi), 0609 Fiji (fj), 0610 Faroese (fo), 0615 Frisian (fy), 0625 Irish (ga), 0701 Scots-Gaelic (gd), 0704 Galician (gl), 0712 Guarani (gn), 0714 Gujarati (gu), 0721 Hausa (ha), 0801 Hindi (hi), 0809 Croatian (hr), Hungarian (hu), 0821 Armenian (hy), 0825 Interlingua (ia), 0901 Interlingue (ie), 0905 Inupiak (ik), 0911 Indonesian (in), 0914 Icelandic (is), 0919 Hebrew (iw), 0923 Yiddish (ji), 1009 Javanese (jw), 1023 Georgian (ka), 1101 Kazakh (kk), 1111 Greenlandic (kl), 1112 Cambodian (km), 1113 Kannada (kn), 1114 Kashmiri (ks), 1119 Kurdish (ku), 1121

0818

Kirghiz (ky), 1125 Latin (la), 1201 Lingala (ln), 1214 Laothian (lo), 1215 Lithuanian (lt), 1220 Latvian (lv), 1222 Malagasy (mg), 1307 Maori (mi), 1309 Macedonian (mk), 1311 Malayalam (ml), 1312 Mongolian (mn), 1314 Moldavian (mo), 1315 Marathi (mr), 1318 Malay (ms), 1319 Maltese (mt), 1320 Burmese (my), 1325 Nauru (na), 1401 Nepali (ne), 1405 Norwegian (no), 1415 Occitan (oc), 1503 Oromo (om), 1513 Oriya (or), 1518 Panjabi (pa), 1601 Polish (pl), 1612 Pashto, Pushto (ps), Quechua (qu), 1721 Rhaeto-Romance (rm), Kirundi (rn), 1814 Romanian (ro), 1815 Kinyarwanda (rw), 1823 Sanskrit (sa), 1901 Sindhi (sd), 1904 Sangho (sg), 1907 Serbo-Croatian (sh),

1619

1813

1908

Sinhalese (si), 1909 Slovak (sk), 1911 Slovenian (sl), 1912 Samoan (sm), 1913 Shona (sn), 1914 Somali (so), 1915 Albanian (sq), 1917 Serbian (sr), 1918 Siswati (ss), 1919 Sesotho (st), 1920 Sundanese (su), 1921 Swahili (sw), 1923 Tamil (ta), 2001 Telugu (te), 2005 Tajik (tg), 2007 Thai (th), 2008 Tigrinya (ti), 2009 Turkmen (tk), 2011 Tagalog (tl), 2012 Setswana (tn), 2014 Tonga (to), 2015 Turkish (tr), 2018 Tsonga (ts), 2019 Tatar (tt), 2020 Twi (tw), 2023 Ukrainian (uk), 2111 Urdu (ur), 2118 Uzbek (uz), 2126 Vietnamese (vi), 2209 Volapük (vo), 2215 Wolof (wo), 2315 Xhosa (xh), 2408 Yoruba (yo), 2515 Zulu (zu), 2621

Country/Area Code List

Country/Area, Country/Area code, Country/Area code letter

Argentina, 0118, ar Australia, 0121, au Austria, 0120, at Belgium, 0205, be Brazil, 0218, br Canada, 0301, ca Chile, 0312, cl China, 0314, cn Denmark, 0411, dk

Finland, 0609, fi France, 0618, fr Germany, 0405, de Hong Kong, 0811, hk India, 0914, in Indonesia, 0904, id Italy, 0920, it Japan, 1016, jp Republic of Korea,

1118, kr

Malaysia, 1325, my Mexico, 1324, mx Netherlands, 1412, nl New Zealand, 1426, nz Norway, 1415, no Pakistan, 1611, pk Philippines, 1608, ph Portugal, 1620, pt Russian Federation, 1821, ru

Singapore, 1907, sg Spain, 0519, es Sweden, 1905, se Switzerland, 0308, ch Taiwan, 2023, tw Thailand, 2008, th United Kingdom, 0702, gb USA, 2119, us

35 EN

Connections to other equipment

The exact arrangement you use to interconnect various video and audio components to this unit is dependent on the model and features of each component. Check the Owner’s Manual provided with each component for the location of video and audio inputs and outputs.

To connect the TV to a VCR

Right of the unit

To Video/Audio OUT

Y(VIDEO)

To VIDEO/AUDIO IN

Video/Audio cord (not supplied)

To connect the TV to a DVD player with Component Video Input

You can enjoy a high quality picture by connecting the unit’s COMPONENT VIDEO OUT jacks of your DVD player with the component video cables (not supplied).

Right of the unit

To COMPONENT IN

Y(VIDEO)

NOTE:

Component Video input of the unit are for use with a device which output 480i/1080i interlaced signals and

• 480p/720p progressive signals.

To AUDIO IN

Audio cord

(not supplied)

Component video cord

(not supplied)

To Audio OUT

To Component OUT

VCR

DVD

To connect the TV to a camcorder, or a game console

To playback from a camcorder, connect the camcorder to the unit as shown. This unit can also be used as a display device for many video games. However, due to the wide variety of signals generated by these devices and subsequent hook-up variations required, they have not all been included in the suggested connection diagrams. You’ll need to consult each component’s Owner’s Manual for additional information.

Right of the unit

To VIDEO/AUDIO IN To Video/Audio OUT

Y(VIDEO)

Video/Audio cord (not supplied)

EN 36

GAME CONSOLE

Connections to other equipment

Using an AV Amplifier with built-in digital surround

If you are using an AV Amplifier with built-in digital surround sound, you can enjoy various audio systems including Dolby Digital Surround audio that sounds just like the movie.

Connect an AV Amplifier with built-in Dolby Digital decoder, etc. as shown below.

Right of the unit

To DIGITAL AUDIO

COAXIAL OUT

Coaxial digital cable

(not supplied)

To Coaxial

Digital Audio Input

Front

Speaker

(Left)

TV/DVD

Subwoofer

Center Speaker

Front Speaker (Right)

Surround

AV Amplifier with built-in digital surround decoder

NOTE:

When you are viewing digital broadcast, this unit will not work in conjunction with DTS audio or MPEG audio.

•

There will be no sound output if connected to an AV Amplifier with a built-in DTS decoder or MPEG decoder.

To connect an audio system

This connection allows you to use an audio amplifier and external speakers, and adjust the audio level using the TV’s remote control.

Speaker (Left)

Surround Speaker (Right)

Right of the unit

Amplifier

To AUDIO (L/R) OUT

Audio cord (not supplied)

To Audio (L) Input To Audio (R) Input

NOTE:

To hear sound when using an external audio amplifier, the volume of both the TV and the amplifier must be set

•

above 0 (zero).

37 EN

Connections to other equipment

To connect the TV to a PC (Personal Computer)

BEFORE YOU CONNECT THIS TV TO YOUR PC, CHANGE THE ADJUSTMENT OF YOUR PC’S RESOLUTION AND REFRESH RATE (60 HZ).

Connect one end of a (male to male) VGA cable to the video cord of the computer and the other end to the connector PC MONITOR IN on the rear of the case of a Multimedia computer, connect the audio cord to the audio output of your Multimedia computer and to the AUDIO IN connector of the PC/DVI AUDIO IN jack of the TV. You can also connect the PC with HDMI cable. If you use HDMI cable, you don’t have to connect the audio cord. If you use DVI-to-HDMI cable, please connect audio cord as same way as VGA cable. Press INPUT SELECT on the remote control to select PC mode. Switch on the computer. The TV can operate as the computer monitor.

. Attach the connectors firmly with the screws on the plug.

VGA

Rear and right of the unit

Y(VIDEO)

To HDMI/DVI IN

To AUDIO IN

NOTE:

•

The on-screen displays will have a different appearance in PC mode than in TV mode.

•

If there is no video signal from the PC when the unit is in PC mode, “No signal” will appear on the TV-screen.

•

When the PC connected to the HDMI terminal and 1920x1080 resolution (FHD) is selected, the top and bottom, right and left edges of the picture may be hidden on all picture sizes. In this case, use the PC MONITOR IN jack (VGA cable) is recommended to connect.

•

When the PC’s resolution is set to 1920 x 1080/60 Hz (FHD mode), a signal that differs from the FHD signal, which has been confirmed operational on this TV, may appear depending on the PC used. In this case, “Auto Adjust” or other Position Adjustment functions may fail to correct the image position. To solve this problem, change the PC settings to select another resolution.

To PC MONITOR IN

HDMI cable (not supplied)

VGA cable (not supplied)

Audio cord (not supplied)

Monitor Display modes

Mode Resolution Refresh rate VGA 640x480 60/ 75 Hz

VGA 720x400 70Hz SVGA 800x600 60/ 75 Hz XGA 1024x768 60/ 70/ 75 Hz WXGA 1360x768 60Hz SXGA 1280x1024 60Hz WXGA+ 1440x900 60Hz WSXGA+ 1680x1050 60Hz FHD 1920x1080 60Hz

To return to normal mode Press INPUT SELECT again.

To connect a HDMI or a DVI device to the unit

The HDMI/DVI input receives digital audio and uncompressed video from a HDMI device or uncompressed digital video from a DVI device. When you connect to a DVI device with a HDMI-to-DVI adapter cable, it transfers only video signal. Separate analog audio cords required.

Rear and right of the unit

To HDMI IN

Y(VIDEO)

HDMI cable (type A connector)

(not supplied)

HDMI - to - DVI adapter cable

(HDMI type A connector)

(not supplied)

To HDMI output

HDMI device

DVI device

EN 38

Audio cord (not supplied)

To AUDIO IN To DVI output

Reception disturbances

Most types of television interference can be remedied by adjusting the height and position of the VHF/UHF antenna. Outdoor antennas are recommended for best results. The most common types of television interference are shown below. If one of these symptoms appear when the TV is connected to a Cable TV system, the disturbance may be caused by the local Cable TV company broadcast.

IGNITION

Black spots or horizontal streaks may appear, the picture may flutter or drift. Usually caused by interference from automobile ignition systems, neon lamps or AC powered tools and appliances such as drills or hair dryers.

GHOSTS

Ghosts are caused by the television signal following two paths. One is the direct path and the other is reflected by tall buildings, hills or other large objects. Changing the direction or position of the antenna may improve the reception.

SNOW

If the TV is located far from the TV station, in a fringe reception area where the signal is weak, small dots may appear in the picture. If the signal is extremely weak, the installation of a larger external antenna may be necessary.

RADIO FREQUENCY INTERFERENCE (RFI)

Caused by two-way radios, this type of interference produces moving ripples or diagonal streaks in the picture. Some cases may cause a loss of contrast in the picture. Changing the direction and position of the antenna or installing an RFI filter may improve the picture.

PICTURE SIZE VARIATION

A slight picture size variation is normal when you adjust the CONTRAST or BRIGHTNESS settings.

CARE AND MAINTENANCE

To prevent fire or shock hazard, disconnect the TV from the power source before cleaning. The finish on the cabinet may be cleaned with mild soap and a soft, damp cloth and cared for as other furniture. Use caution when cleaning or wiping the plastic parts.

39 EN

Problems and troubleshooting

Use the following check list for troubleshooting when you have problems with your TV/DVD. Consult your local dealer or service outlet if problems persist. Be sure all connections are properly made when using with other units.

SYMPTOMS POSSIBLE SOLUTIONS PAGE

POWER

Make sure the power cord is plugged in.

TV/DVD does not operate.

TV BROADCAST RECEPTION

Poor sound or no sound.

Poor picture or no picture.

Poor reception on some channels.

Poor color or no color.

Picture wobbles or drifts.

No Cable TV reception.

Horizontal or diagonal bars on screen.

No reception above channel 13.

TV shuts off.

Closed Caption is not activated.

Display is not shown in your language.

REMOTE CONTROL

The remote control does not function.

The LCD panel is a very high technology product, giving you fine picture details. Occasionally, a few non-

• active pixels may appear on the screen as a fixed point of blue, green or red. Please note that this does not affect the performance of your product.

• Power is off, check fuse or circuit breaker.

• Unplug unit, then plug it back in.

•

Station or Cable TV experiencing problems, tune to another station.

• Check Volume adjustments or muting.

• Check for sources of possible interference.

• Station or

• Check antenna or Cable TV connections, reorient antenna.

• Check for sources of possible interference.

• Check picture control adjustments.

• Station or Cable TV experiencing problems, tune to another station.

• Station signal is weak, reorient antenna to receive stronger station.

• Check for sources of possible interference.

• Station or

• Make sure channels are set into memory.

• Check picture control adjustments.

• Check antenna or Cable TV connections, reorient antenna.

• Check for sources of possible interference.

• Station or Cable TV experiencing problems, tune to another station.

• Make sure channels are set into memory.

• Cable TV company is scrambling signal.

• Check antenna orientation.

• Check all Cable TV connections.

• Set Signal Type option to the “Cable” mode.

• Station or Cable TV system problems, try another station.

• Check antenna connections, reorient antenna.

• Check for sources of possible interference.

• Make sure Signal Type option is in the appropriate mode.

• If using antenna, check UHF antenna connections.

• No broadcast on station tuned.

• Sleep Timer is set.

• Power interrupted.

• TV station experiencing problems or program tuned is not closed

• captioned. Try another channel. Check Cable TV connection or VHF/UHF antenna, reposition or

• rotate antenna. Set Closed Caption in the menu.

•

Select proper language in the menu options.• 19

Aim at the remote control at the remote sensor.

• Operate within approx. 15 feet or reduce the light in the room.

• Clear the path of the beam.

• The batteries are weak. Replace the batteries.

• Check the batteries are inserted correctly.

•

Cable TV

experiencing problems, tune to another station.

15 15 39

15 14 39 17

15 14 39

15 20 17 14 39

15 20

–

14 14

20 15

14 39

20 14

15 16

–

EN 40

Problems and troubleshooting

SYMPTOMS POSSIBLE SOLUTIONS PAGE

DVD

No disc is inserted. Playback doesn’t start or disc ejects automatically.

No picture. TV/DVD selector is not set correctly.• 27

No sound.

Picture is distorted during CUE or REVIEW.

Stopping playback, search, slow-motion play, repeat play, or program play, etc. cannot be performed.

No surround sound. The setup does not match your stereo system.• 37 The unit or remote

operation key is not functioning.

Playback does not start when the title is selected.

Audio soundtrack and/or subtitle language is not changed when you play back a DVD.

No subtitle.

Angle cannot be changed. Multi-angles are not recorded on the DVD disc.• 29 “This operation can’t be

performed” appears on the screen.

• The disc may be dirty. Clean up the disc.

• The disc is scratched or warped.

• The unit cannot play CD-ROMs, etc.

•

Check the input selector of the amplifier is set properly.

• The unit is in the Special playback mode.

• Select the correct Audio Output position on AV amplifier.

•

The picture will be distorted occasionally.• –

Some discs may not allow some functions.• –

Turn off the unit and unplug the AC power cord for several minutes,

• then replug it.

Check the Parental Lock setup.• 34

Multilingual language is not recorded on the DVD disc.• 29

Some discs have no subtitles.

• Subtitles are cleared. Press SUBTITLE.

•

The function is prohibited with the unit or the disc.• 27

28 37

9 9 9

–

FCC Declaration of Conformity Compliance Statement (Part 15):

The Sansui SLEDVD329 and SLEDVD329A LED-LCD TV with DVD player complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The party responsible for compliance to these rules is: ORION AMERICA,INC. 1105 SOUTH MAIN STREET PRINCETON, INDIANA 47670,U.S.A Ph: 1-800-289-0980

FOR CUSTOMER SERVICE, ADDITIONAL SET-UP AND OPERATING ASSISTANCE, OR TO ORDER ACCESSORIES PLEASE CALL:

1-800-289-0980

WHEN CALLING CUSTOMER SERVICE – PLEASE HAVE YOUR MODEL NUMBER READY

OR WRITE TO:

ORION SALES, INC.

3471 N. UNION DR.

OLNEY, ILLINOIS 62450

FOR INFORMATION ON OUR OTHER PRODUCTS, TO ORDER ACCESSORIES ONLINE, OR FOR RECYCLING INFORMATION,

PLEASE VISIT OUR WEBSITE AT

www.sansuiproducts.com

41 EN

Specifications

GENERAL

Power supply: AC 120V, 60Hz Power consumption: Operation: 63W

Weight: 6.5 kg (14.3 lbs) Dimensions: Width: 732.9 mm (28-55/64 inches)

Operating temperature: 5˚C - 40˚C Operating humidity: Less than 80% RH

TELEVISION

Type: 800.4mmV (32”class/31.51” digonal) Display method: Transmission TFT color LCD panel Number of Pixels: 1366 (H) x 768 (V) Tuner type: US System M

Receiving channels: VHF 2-13

Inputs: Video: (RCA) 1 V (p-p), 75 ohms

Outputs: Digital audio out: 0.5 V (p-p), 75 ohms terminated

Speakers: 40.6 mm x 121.9 mm (1-5/8 inches x 4-13/16 inches), 8 ohms x 2 Audio output power: 5.0W + 5.0W

DVD/CD player

Signal system: NTSC Applicable disc: 1.DVD (12 cm)

Pickup: CD: Wavelength: 790 nm

ACCESSORIES Remote control

Stand by: 0.5W

Height: 470.9 mm (18-35/64 inches) Depth: 170.0 mm (6-45/64 inches)

ATSC standard (8VSB), QAM

UHF 14-69 CATV 14-36 (A)-(W) 37-59 (AA)-(WW) 60-85 (AAA)-(ZZZ) 86-94 (86)-(94) 95-99 (A-5)-(A-1) 100-135 (100)-(135) 01 (4A)

Audio: (RCA) –8 dBm/50k ohms Component video: (Y) 1 V (p-p), 75 ohms (Pb)/(Pr) 0.7 V (p-p), 75 ohms HDMI: HDMI compliant (type A connector) HDCP compliant E-EDID compliant Suggested scan rates: 480i, 480p, 720p,1080i,1080p HDMI Audio: 2-channel PCM 32/44.1/48 kHz sampling frequency 16/20/24 bits per sample PC Monitor: Mini-Dsub 15pin Antenna: VHF/UHF In 75 ohms coaxial

Audio: 0-600 mV rms/1k ohm

2.CD (12 cm)

Maximum output power: 7 mW DVD: Wavelength: 655 nm Maximum output power: 5 mW

Batteries (AA) x 2 Stand Screws (4x16mm(5/32x5/8 inches)) x 3

Designs and specifications are subject to change without notice.

EN 42

limited

WARRANTY

ORION warrants this product to be free from manufacturing defects in material and workmanship under normal use and conditions for a period of 1 year from date of original purchase in the United States.

Should service be necessary under this warranty for any reason due to a manufacturing defect or malfunction during the first 12 months from date of original purchase, ORION will provide carry-in service only by an ORION authorized Independent Service Center at no charge. Also, if an original part fails due to manufacturing defect in material and workmanship within one year from date of original purchase we will replace the defective part, provided the defect or malfunction is verified along with dated proof of purchase.

There are ORION authorized Independent Service Centers located throughout the country. For the one nearest you, DIAL TOLL FREE: 1-800-289-0980 or visit our website at www.sansuiproducts.com. ORION will not be liable for damages incurred in shipment of the unit. If there are no ORION authorized Independent Service Centers in your area please call - 1-888-296-7466 for assistance.

Note: This warranty is void if the product is: (a) Damaged through negligence, misuse, abuse, or accident. (b) Used in a commercial application or rentals. (c) Modified or repaired by anyone other than an Independent Service Center authorized by ORION to effect warranty repairs to the class of product or by the ORION Factory Service Center. (d) Damaged because it is improperly connected to the equipment of other manufacturers.

This warranty does not cover: (a) Damage to video disc. (b) Damage to equipment not properly connected to the product. (c) Costs incurred in the shipping of the product to an ORION authorized Independent Service Center or ORION Factory Service Center. (d) Damage or improper operation of unit caused by customer abuse, misuse, negligence, or failure to follow operating instructions provided with the product. (e) Ordinary adjustments to the product which can be performed by customer as outlined in the owner’s manual. (f) Signal reception problems caused by external antenna or cable systems.

32” CLASS LED-LCD TV WITH DVD PLAYER

THIS WARRANTY IS NON TRANSFERABLE AND APPLIES ONLY TO THE ORIGINAL PURCHASER AND DOES NOT EXTEND TO SUBSEQUENT OWNERS OF THE PRODUCT. ANY APPLICABLE IMPLIED WARRANTIES, INCLUDING THE WARRANTY OF MERCHANTABILITY, ARE LIMITED IN DURATION TO A PERIOD OF THE EXPRESS WARRANTY AS PROVIDED HEREIN BEGINNING WITH THE DATE OF ORIGINAL PURCHASE AT RETAIL AND NO WARRANTIES, WHETHER EXPRESS OR IMPLIED SHALL APPLY TO THIS PRODUCT THEREAFTER. ORION MAKES NO WARRANTY AS TO THE FITNESS OF THE PRODUCT FOR ANY PARTICULAR PURPOSE AND USE.

UNDER NO CIRCUMSTANCES SHALL ORION BE LIABLE FOR ANY LOSS, DIRECT, INDIRECT, INCIDENTAL, SPECIAL, OR CONSEQUENTIAL DAMAGE ARISING OUT OF OR IN CONNECTION WITH THE USE OF THIS PRODUCT.

THIS WARRANTY IS VALID ONLY IN THE UNITED STATES OF AMERICA. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, HOWEVER, YOU MAY HAVE OTHER RIGHTS WHICH MAY VARY FROM STATE TO STATE. SOME STATES DO NOT ALLOW LIMITATION ON IMPLIED WARRANTIES OR EXCLUSION OF CONSEQUENTIAL DAMAGE, THEREFORE THESE RESTRICTIONS MAY NOT APPLY TO YOU.

ORION SALES, INC.

3471 N. UNION DR.

OLNEY, ILLINOIS 62450

43 EN

Sansui SLEDVD329, SLEDVD329A User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
