If you purchase a universal remote control from your local retailer, please contact the remote
manufacturer for the required programming code.
TV/CABLE MODE SELECTION
When shipped from the factory, the TV/CABLE menu option is set to the “CABLE” (Cable Television)
mode. If not using Cable TV, set this menu option to the “TV” position.
IF CONTACT WITH CUSTOMER SERVICE IS REQUIRED
PLEASE HAVE THE MODEL NUMBER READY PRIOR TO THE CALL
CUSTOMER SERVICE – 1-800-289-0980
ORION WEBSITE
FOR INFORMATION ON OUR OTHER PRODUCTS, PLEASE VISIT OUR WEBSITE AT
www.orionsalesinc.com
Before operating the unit, please read this manual thoroughly.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead
symbol, within an equilateral triangle
is intended to alert the user to the
presence of uninsulated dangerous
voltage within the product's enclosure
that may be of sufficient magnitude to
constitute a risk of electric shock.
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
WARNING : TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN
OR MOISTURE.
CAUTION: TO PREVENT ELECTRIC SHOCK DO NOT USE THIS POLARIZED PLUG WITH AN
FCC Declaration of Conformity Compliance Statement (Part 15):
The Sansui HDPDP4250, WIDE PLASMA TELEVISION WITH DIGITAL TUNER complies with Part
The party responsible for compliance to these rules is:
ORION SALES, INC
HIGHWAY 41 ORION PLACE, PRINCE, PRINCETON, INDIANA 47670
Ph: 1-800-289-0980
WARNING: This equipment has been tested and found to comply with the limits for a Class B digital device,
However, there is no guarantee that interference will not occur in a particular installation. If
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-
- Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modifications not expressly approved by the partly responsible for compliance with
EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE
FULLY INSERTED TO PREVENT BLADE EXPOSURE.
15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
the FCC Rules could void the user's authority to operate this equipment.
2
Location of the required Marking
The rating sheet and the safety caution are on the rear of the unit.
IMPORTANT SAFETY INSTRUCTIONS
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and
the point where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods
of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
15) Apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such a vases,
shall be placed on the apparatus.
16) An outside antenna system should not be located in the vicinity of overhead power lines or other electric light
or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna
system, extreme care should be taken to keep from touching such power lines or circuits, as contact with
them might be fatal.
17) Do not overload wall outlets and extension cords, as this can result in a risk of fire or electric shock.
18) Do not push objects through any openings in this unit, as they may touch dangerous voltage points or short
out parts that could result in fire or electric shock. Never spill or spray any type of liquid into the unit.
PORTABLE CART WARNING
(symbol provided by RETAC)
S3126A
3
IMPORTANT SAFETY INSTRUCTIONS
19) If an outside antenna or cable system is connected to the unit, be sure the antenna or cable system is
grounded to provide some protection against voltage surges and built-up static charges, Section 810 of
the National Electrical Code, ANSI/NFPA 70, provides information with respect to proper grounding of the
mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding
conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements for the
grounding electrode.
EXAMPLE OF ANTENNA GROUNDING AS PER THE
NATIONAL ELECTRICAL CODE
ANTENNA LEAD
IN WIRE
GROUND
CLAMP
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
ELECTRIC SERVICE
EQUIPMENT
GROUND CLAMPS
NEC-NATIONAL ELECTRICAL CODE
S2898A
20) When replacement parts are required, be sure the service technician uses replacement parts specified by
the manufacturer or those that have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock or other hazards.
21) Upon completion of any service or repairs to this unit, ask the service technician to perform safety checks to
determine that the unit is in proper operating condition.
22) When you connect the product to other equipment, turn off the power and unplug all of the equipment from
the wall outlet. Failure to do so may cause an electric shock and serious personal injury. Read the owner's
manual of the other equipment carefully and follow the instructions when making any connections.
23) Reduce the volume to the minimum level before you turn on the product. Otherwise, sudden high volume
sound may cause hearing or speaker damage.
24) Do not allow the product to output distorted sound for an extended period of time. It may cause speaker
overheating and fire.
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
25) This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the NEC
that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be
connected to the grounding system of the building, as close to the point of cable entry as practical.
4
IMPORTANT SAFETY INSTRUCTIONS
Cleaning instructions for your Plasma TV.
Safety note:
Before you begin to clean, turn the unit power off, and disconnect from the power source.
Be careful not to scratch the plastic coated front panel - it is highly vulnerable to accidental scratching (e.g. by
fingernails or other sharp items).
While cleaning, do not wear jewelry that could cause surface scratching (such as rings, wrist-watch, etc.).
Use a moist lint-free cloth and pure water to clean the Plasma TV, assure the cloth is only damp and not wet - and
that the cloth is free from any dirt particles that could cause scratches to the surface.
Wipe the set clean using minimal pressure.
DO NOT USE STANDARD WINDOW CLEANER! ITS ALCOHOL / AMMONIA WILL DISSOLVE THE FRONT
WINDOW'S COATING!! NEVER USE SOLVENT OR THINNER. NEVER USE SPECIAL CLEANERS WHICH
ARE DESIGNED FOR CLEANING PC MONITORS OR CRT TV’S.
Carefully dry with a clean dry lint-free cloth.
Do not use paper towels or tissues to clean the set - paper can disintegrate when wet or may leave a trail of dust
behind. Some paper is abrasive and may scratch your screen.
5
SAFETY PRECAUTIONS
The unit emits heat when in operation. Do not place any covers or blankets on the unit, this may cause
overheating. Do not block ventilation holes, or set up near radiators. Do not place in direct sunshine. When
placing on a shelf leave 10 cm (4 inches) free space around the entire unit.
10cm
Notes when mounting the Plasma TV on a wall
•
When installing the unit on a wall, allow at least 6 cm (2 1/2 inches) clearance between the rear of the Plasma
TV and the wall. Clearance of less than 6 cm (2 1/2 inches) will obstruct the vents and may cause the interior of
the unit to overheat, resulting in damage to the unit.
•
If the unit is to be mounted on the wall, contact the retailer where you purchased the Plasma TV for advice, and
have the equipment professionally installed. Incomplete or improper installation may cause injury to you and/or
the Plasma TV.
•
Bracket holes: To attach a wall mounting bracket (not supplied) here, remove the screws.
Bracket holes
IMPORTANT NOTICE
Possible Adverse Effects on Plasma Screen: If a fixed (non-moving) pattern remains on the plasma screen
for long periods of time, the image can become permanently engrained in the plasma TV panel and cause subtle
but permanent ghost images. This type of damage is NOT COVERED BY YOUR WARRANTY. Never leave your
plasma TV on for long periods of time while it is displaying the following formats or images:
Fixed Images, such as stock tickers, video game patterns, TV station logos, and websites.
•
Special Formats that do not use the entire screen. For example, viewing letterbox style (16:9) media on
•
a normal (4:3) display (gray bars at top and bottom of screen); or viewing normal style (4:3) media on a
widescreen (16:9) display (gray bars on left and right sides of screen).
To avoid the engraining, we recommend that you use the screen saver function (see page 41).
The following symptoms are not signs of malfunction but technical limitation. Therefore we disclaim
any responsibility for these symptoms.
Plasma TV panels are manufactured using an extremely high level of precision technology, however
•
sometimes parts of the screen may be missing picture elements or have luminous spots. This is not a sign
of a malfunction.
Do not install the Plasma TV near electronic equipment that is susceptible to electromagnetic waves. Some
•
equipment placed too near this unit may cause interference.
Effect on infrared devices – There may be interference while using infrared devices such as infrared
•
cordless headphones.
6
Contents
PREPARATIONS
IMPORTANT SAFETY INSTRUCTIONS ........................................ 3
Integrated Digital Tuner - You can view digital broadcasting without using a Digital TV Set-Top Box.
•
Closed Caption Decoder With Full Text Mode - Displays text captions or full screen text on the screen for
hearing impaired viewers.
•
Picture Adjustments Using The Remote Control - The On-Screen display allows precise remote control
adjustment of BRIGHTNESS, CONTRAST, COLOR, TINT and SHARPNESS.
•
Programmable TV Sleep Timer - Operable from the remote control, the Plasma TV can be programmed up to
120 minutes to turn off automatically.
•
V-Chip - The V-Chip function can read the rating of a broadcast program or movie content if the program is
encoded with this information. V-chip will allow you to set a restriction level.
•
Digital Audio Jack (Coaxial/Optical) - When a component with a built-in Dolby Digital decoder is connected,
Dolby Digital sound can produce the effect of being in a movie theater or a concert hall.
•
S-Video/Component Video Jacks - A VCR, DVD player, satellite receiver or other audio/video component can
be connected to this unit.
•
Video Input Jacks - This unit is equipped 3 types of video input jacks. The component video in jacks and
S-video in jack enable you to watch the DVD player or the video devices with high quality picture.
•
On-Screen 3 Language Display - You can select one of 3 languages, English, Spanish or French for on-
screen programming.
* Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby
Laboratories.
Power source
TO USE AC POWER
1. Connect the AC cord plug into this unit’s AC IN jack.
2. Connect the AC cord into an AC outlet.
AC 120V, 60Hz
AC cord (supplied)
NOTES:
•
Please make sure to insert the cord securely at both the Plasma TV and the wall outlet.
•
The AC cord has a grounding-type AC line plug. If the supplied AC cord does not match you AC outlet, contact
a qualified electrician, do not defeat the purpose of a grounding plug.
WARNING:
•
DO NOT CONNECT THIS UNIT TO THE POWER USING ANY DEVICE OTHER THAN THE SUPPLIED AC
CORD. THIS COULD CAUSE FIRE, ELECTRICAL SHOCK, OR DAMAGE.
•
DO NOT USE WITH A VOLTAGE OTHER THAN THE POWER VOLTAGE DISPLAYED. THIS COULD CAUSE
FIRE, ELECTRICAL SHOCK, OR DAMAGE.
CAUTION:
•
WHEN THIS UNIT IS NOT USED FOR A LONG TIME, (E.G., AWAY ON A TRIP) IN THE INTEREST OF
SAFETY, BE SURE TO UNPLUG IT FROM THE AC OUTLET.
•
DO NOT PLUG/UNPLUG THE PLUG WHEN YOUR HANDS ARE WET. THIS MAY CAUSE ELECTRICAL
SHOCK.
IF YOU NEED TO REPLACE THE SUPPLIED AC ADAPTER OR AC CORD, THE SPECIFIED ONE IS
•
RECOMMENDED. CONTACT CUSTOMER SERVICE AT 1-800-289-0980.
8
Parts and functions
Left side
VIDEO-3 IN
* To display the menu screen.
Press both VOLUME ▲/▼ buttons at the same time to display the menu screen.
CHANNEL ▲/▼ buttons and VOLUME ▲/▼ buttons can be used to select the desired setting during the menu
screen operations.
Front
*CHANNEL ▲/▼ buttons
*VOLUME ▲/▼ buttons
INPUT button
Remote sensor
STANDBY/ON indicator
POWER button
Rear
PC IN jack
RF (ANT) IN jack
PC AUDIO/HDMI-1
COAXIAL DIGITAL AUDIO OUT jack
AUDIO IN jack
HDMI-2 IN jacks
HDMI-1 IN jack
OPTICAL DIGITAL AUDIO OUT jack
AUDIO (L/R)/VIDEO OUT jacks
VIDEO-2 IN jacks
VIDEO-1 IN jacks
COMPONENT-2 IN jacks
COMPONENT-1 IN jacks
AC power cord socket
9
Remote control
1
2
3
4
5
6
7
8
9
* You can use these buttons to operate
your VCR, Cable/Satellite box or DVD
after you have programmed the remote
control for the code that operates your
VCR, Cable/Satellite box or DVD (see
page 12 and 13).
1. PLASMA TV, VCR, CBL (Cable/Satellite box), DVD
POWER Button* - Used to turn the Plasma TV, VCR,
Cable/Satellite box or DVD on or off after you select
the operating mode.
2. SLEEP Button - To set the Plasma TV to turn off after
a preset amount of time, use the SLEEP button on the
remote control.
3. Direct Channel Selection Buttons (0-9)* - Allows
direct access to any channel of the Plasma TV, VCR,
Cable/Satellite box or DVD.
4. MUTE Button - To turn off the sound, press this
button once. The Plasma TV will be silenced and the
symbol “MUTE” will appear on the screen. The muting
feature can be released by pressing the MUTE button
again or one of the VOL (VOLUME) + or – buttons.
5. RESET Button - Press to reset the On-Screen picture
adjustments to their factory preset positions.
6. CH (CHANNEL)/CURSOR ▲ / ▼
to operate the menu functions of the Plasma TV, and
to change the channels of the Plasma TV or Cable/
Satellite box.
7. MENU Button - Use to display the On-Screen menu
function.
8. 16:9 Button - Press to display PICTURE SIZE menu.
9. VCR Operation Buttons* - Press to operate your
VCR if programmed properly using a code listed on
page 12.
10. TV, VCR, CBL (Cable/Satellite box), DVD Selector
Switch - Slide to select the Plasma TV, VCR, Cable/
Satellite box or DVD to be operated.
11. CODE SET Button - Used to register the 3-digit
codes to operate your VCR or Cable/Satellite box (see
page 12 and 13).
Buttons* - Used
10
11
12
13
14
15
16
17
18
19
20
12. DISPLAY Button - When the TV is receiving an
analog signal pressing this button will display the
current information on-screen. When the TV is
receiving a digital, pressing this button once will
display the digital information on-screen; pressing it
a second time will display the analog information onscreen. To remove the display from the screen, press
this button again.
13. QUICK VIEW Button - This button allows you to go
back to the previous channel selected by just pressing
the QUICK VIEW button. Press this button again to
return to the channel you were watching.
15. CH ENTER/– Button* - Some connected equipment
such as a Cable/Satellite box, VCR, or DVD may
require this button to input selected channels. This
button is also the “–” button used when selecting
digital channels.
16. CLOSED CAPTION Button - Displays text captions
or full screen text on the screen for hearing impaired
viewers.
17. ENTER Button - Use to enter or select information for
On-Screen operations.
18. VOL (VOLUME) + / – / CURSOR ◀ / ▶ Buttons -
Used to operate the menu functions of the Plasma
TV. Press the ▶ button to increase, or the ◀ button to
decrease the sound level.
19. EXIT Button - Press to remove setup menu.
20. DVD Operation Buttons* - Press to operate your
DVD if programmed properly using a code listed on
page 13.
10
Before using the remote control, batteries must first be installed.
HOW TO INSTALL BATTERIES
1. Open the battery compartment cover.
Use two “AA” size batteries. The batteries may last approximately
one year depending on how much the remote control is used. For
best performance, it is recommended that batteries should be
replaced on a yearly basis, or when the remote operation becomes
erratic. Do not mix old and new batteries or different types.
BATTERY PRECAUTIONS
These precautions should be followed when using batteries
in this device:
Use only the size and type of batteries specified.
•
Be sure to follow the correct polarity when installing the
2. Install two “AA” batteries (supplied).
3. Replace the battery compartment cover.
HOW TO USE THE REMOTE CONTROL
You may be able to use the remote control to operate
your VCR, Cable/Satellite box and DVD along with the
Plasma TV after the batteries are installed and you have
registered the codes that operate your products.
Some buttons are used exclusively for each product and
some buttons are used in common with each product.
To operate your products correctly using this universal
remote control follow each step below.
A
A, B, C, D
•
batteries as indicated in the battery compartment. Reversed
batteries may cause damage to the device.
Do not mix different types of batteries together (e.g. Alkaline
•
and Carbon-zinc) or old batteries with fresh ones.
If the device is not to be used for a long period of time,
•
remove the batteries to prevent damage or injury from
possible battery leakage.
Do not try to recharge batteries not intended to be recharged;
•
they can overheat and rupture. (Follow battery manufacturer’s
directions.)
A. For PLASMA TV
1
2
3
4
B. For VCR
1
2
3
A,B,C,D
A
4
Remote control
Slide the selector switch to select “TV” first.
Aim remote at Plasma TV.
Press the POWER button.
Press other buttons to operate the features of your
Plasma TV. You can use the VOL + and – buttons, the
0-9 buttons, the – button.
Slide the selector switch to select “VCR” first.
Aim remote at VCR.
Press the POWER button to turn on VCR.
Press other buttons to operate the features of your VCR.
You can use the VCR CH ▲ and ▼ buttons, the 0-9
buttons, the CH ENTER button.
A,C
A
A
B,D
D
C. For CABLE/SATELLITE box
Slide the selector switch to select “CBL” first.
1
Aim remote at CABLE/SATELLITE box.
2
Press the POWER button to turn on your CABLE/
3
SATELLITE box.
Press other buttons to operate the features of your
4
CABLE/SATELLITE box. You can use the CH ▲ and ▼
buttons, the 0-9 buttons, the CH ENTER button.
D. For DVD
Slide the selector switch to select “DVD” first.
1
Aim remote at DVD.
2
Press the POWER button to turn on DVD.
3
Press other buttons to operate the features of your DVD.
4
You can use the DVD SKIP
TOP MENU button, the DVD MENU button, the 0-9
buttons, the CH ENTER button.
NOTES:
•
Some buttons that have same functions are called different
names according to the brand and model of the product.
For example, RESET may be called “CANCEL”.
•
The buttons A, B, C and D are used exclusively for each
product. You can use these buttons whenever you
want.
and buttons, the
11
Remote control
TO REGISTER YOUR VCR, CABLE/SATELLITE BOX OR DVD WITH THE REMOTE CONTROL
1
Slide theselector switch to select the product you want to register (VCR, CBL or DVD).
Press and hold the CODE SET button while inputting a 3-digit code from the following lists using the Direct
If you are using an indoor or outdoor antenna, follow the instructions below that correspond to your
antenna system. If you are using a Cable TV service, see page 15 for Cable TV connections.
If your combination VHF/UHF antenna has a 300 ohm
twin-lead wire, the use of the 300-75 ohm matching
transformer may be necessary.
Connect the UHF 300 ohm twin-lead wire to the
Combiner (not supplied). Connect the VHF 300 ohm
twin-lead wire to the 300-75 ohm Matching Transformer. Attach the Transformer to the Combiner, then
attach the Combiner to the Antenna Jack.
Combiner
UHF 300 ohm
300-75 ohm Matching Transformer
VHF 300 ohm
Separate VHF/UHF Antennas (75 ohm VHF cable and 300 ohm UHF twin-lead wires)
Connect the VHF 75 ohm cable and UHF 300 ohm
Antenna
Jack
Combiner
UHF 300 ohm
VHF 75 ohm
twin-lead wire to the Combiner (not supplied). Attach
the Combiner to the Antenna Jack.
14
Cable TV connections
This TV has an extended tuning range and can tune most cable channels without using a Cable TV
Converter box. Some cable companies offer “premium pay channels” where the signal is scrambled.
Descrambling these signals for normal viewing requires the use of a descrambler device which is
generally provided by the Cable TV company.
FOR SUBSCRIBERS TO BASIC CABLE TV SERVICE
Antenna
Jack
75 ohm
Coaxial Cable
FOR SUBSCRIBERS TO SCRAMBLED CABLE TV SERVICE
If you subscribe to a Cable TV service which requires the use of a Converter/Descrambler box, connect the
incoming 75 ohm Coaxial Cable to the Converter/Descrambler box. Using another 75 ohm Coaxial Cable,
connect the output jack of the Converter/Descrambler box to the Antenna Jack on the TV. Follow the
connections shown below. Set the TV to the output channel of the Converter/Descrambler box (usually channel 3
or 4) and use the Converter/Descrambler box to select channels.
For basic Cable TV service not requiring a Converter/
Descrambler box, connect the 75 ohm Coaxial Cable directly to
the Antenna Jack on the back of the TV.
Incoming
75 ohm
Cable TV
Cable
Converter/
Descrambler
75 ohm Cable to TV
Antenna
Jack
FOR SUBSCRIBERS TO UNSCRAMBLED BASIC CABLE TV SERVICE WITH
SCRAMBLED PREMIUM CHANNELS
If you subscribe to a Cable TV service in which basic channels are unscrambled and premium channels require the
use of a Converter/Descrambler box, you may wish to use a signal Splitter and an A/B Switch box (available from
the Cable TV company or an electronics supply store). Follow the connections shown below. With the switch in the
“B” position, you can directly tune any nonscrambled channels on your TV. With the switch in the “A” position, tune
your TV to the output of the Converter/Descrambler box (usually channel 3 or 4) and use the Converter/Descrambler
box to tune scrambled channels.
Incoming
75 ohm
Cable TV
Cable
Splitter
Converter/
Descrambler
A/B Switch
75 ohm Cable to TV
A
B
Antenna
Jack
15
Connections to other equipment
The exact arrangement you use to interconnect various video and audio components to the Plasma TV is
dependent on the model and features of each component. Check the Owner’s Manual provided with each
component for the location of video and audio inputs and outputs.
The connection diagrams below are offered as suggestions. You may need to modify them to accommodate
your particular assortment of components. The diagrams are intended to show component video and audio
interconnections only.
To connect the Plasma TV to a VCR
Rear lower of the Plasma TV
To AUDIO/VIDEO IN 1 (or 2)
Audio/Video cord
(not supplied)
To Audio/Video OUT
To connect the Plasma TV to a VCR with an S-Video cord
If you connect a VCR with a S-VIDEO cord to the S-VIDEO IN jack on the rear of the
connect
video signal. The audio signal is separate.
NOTE:
When the S-video cord and the video cord are connected to each jack at the same time, the S-video cord takes
precedence over the video cord.
the audio cords to the AUDIO IN jacks on the rear of the Plasma TV. The S-VIDEO cord only carries the
Rear lower of the Plasma TV
To S-VIDEO IN 1 (or 2)
To AUDIO IN 1 (or 2)
To Audio OUT
Audio cord
(not supplied)
S-Video cord (not supplied)
To S-Video OUT
Plasma TV
, you must also
16
Connections to other equipment
To connect the Plasma TV to a DVD player /Satellite receiver
If your DVD player or Satellite receiver has a S-Video out jack, connect cords as shown.
Rear lower of the Plasma TV
To S-VIDEO IN 1 (or 2)
S-Video cord (not supplied)
To AUDIO IN 1 (or 2)
Audio cord
(not supplied)
To Audio OUT
To S-Video OUT
To connect the Plasma TV to a DVD player with component video
If your DVD player has component video out jacks, connect your Plasma TV to a DVD player using a component
video cord. It can greatly enhance picture quality and performance.
Rear lower of the Plasma TV
To COMPONENT IN 1 (or 2)
B
P
Y
PR
Audio cord
(not supplied)
Video cord
(not supplied)
To Audio OUT
To Component OUT
NOTE:
Component Video input of this unit are for use of device which output 480i/1080i interlaced signals and
480p/720p progressive signals.
17
Loading...
+ 39 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
