FEATURES
Continuous Tuning permits reception of Cancel Button allows you to instantly
more stations than ever before without change incorrect information keyed into
any break on LW, MW or SW bands. the microprocessor.
Fast response, Three Color LCD Band Select Buttons offer instant
indicates station frequency in large easy- selection of any desired frequency
to- read numbers, including dual time, bandwidth on SW.
Memory location, signal strength and
battery life. Tuning Speed Selector Switch permits
you to tune stations at either a fast or
Direct Access Keypad permits instant slow speed.
tuning of any desired frequency from
87.5 to 108MHz on the FM band and Adjustable Sleep Timer allows
from 150 to 29,999 KHz on the AM band. you to fall asleep to music or other
programming.
Fifty-Four Memory Pre-sets offer
instant access to your favorite stations on Standby Mode turns on the radio
LW,MW,FM and SW. automatically at a pre-set time either by
buzzer or radio program.
Supplemental Tuning Controls allow
for maximum clarity of the selected Stereo Headphone Jack permits
frequency. reception of FM multiplex stereo broad casts.
Dual Time Setting allows you to pre-set
your local time and UTC wORLD Time, or Folding Stand allows you to position the
any two time zones with instant recall. radio either vertically or at an angle while
maintaining stability.
Scanning Circuit permits you to check
various frequencies on a certain band width and lock on to it at random.
2
CONTROL LOCATIONS
1. Telescopic antenna 12. Meter Select Button
2. Sleep Timer 13. Band Selectors
3. Time Set 14. Numeric & Bandwidth Buttons
4. Dual Time Button 15. Cancel Button
5. Dual Time Set 16. Enter Command Button
6. LCD Display 17. Memory Entry Button
7. Power On/Off Button 18. External Antenna Jack
8. Rotary Tuning Knob 19. DX/Local Switch [AM Sensitivity]
9. Manual Tuning/Auto Scan Buttons [ ] 20. FM Stereo/Mono Mode Selector
[V] AM Narrow/Wide Mode Selector
10. Standby Button 21. Stereo Headphone Jack
11. Frequency Select Button 22. DC input Jack/6 Volts
18
19
20
21
22
1
5
2
4
3
LW
FM
MW
6
SW
MANUL/AUTO
POWER
7
8
9
TUNIGN
FM/LW/MW PLL SYNTHESIED RECEIVER
16
15
14
17
STANDBY
BUZZER
FREQ
DIRECT ACCESS
METER
RADIO
STANDBY
13
10
11
12
3
23. 9KHz/10KHz Step Switch
24. High/Low Tone Switch
25. Volume Control
26. Tuning Speed Control
27. Lock Switch
28. Alarm Set Selector
UP
DOWN
26
27
28
29. Folding Stand
30. Back-up Battery Compartment
31. Main Radio Battery Compartment
ROTARY
TUNING
9K
10K
MW STEP
HIGH
LOW
LUNE
10
5
0
VOL
23
24
25
29
30
31
4
CHOOSING A POWER SUPPLY
You can operate the receiver using:
Six Alkaline AA Batteries.
Household AC [With optional AC adaptor]
12 Volt DC Automobile Battery [With
optional DC adaptor]
USING BATTERIES
1. Press latch marked OPEN on both
battery ompartment covers in he
direction of the arrow and lift off cover.
2
1
2. Insert 4 AA batteries in the Radio
compartment and 2 AA batteries in
the Back-up compartment. Be sure
to position them as illustrated on the
back of the radio, and on top of the lift-out
ribbons for easy removal.
3. Replace both battery compartment
covers over their respective compartments
and press down until you hear it snap closed
3
4
1
2
NOTE
Whenever the radio is turned off, the battery
indiator will flash for about five seconds to
show battery condition.
If the indicator falls below #2, the 4 "MAIN
AA" batteries should be replaced.
When the "MAIN" batteries become exhausted, the micro-processor will automatically be powered bythe "BACK-UP"
batteries.
When the display on the micro-processor
begins to fade, replace the 2 "AA" batteries
in the "BACK -UP" circuit. Before you
replace these batteries, be sure to install the
4 "AA" batteries in the "MAIN" circuit to
prevent total memory loss.
5
USING HOUSE CURRENT [AC]
The receive may be power by AC
current using the AC adaptor (not included).
Insert the small barrel shaped plug into the
jack on the side of the radio marked DC
IN 6V .Plug the other end of the adaptor
into a standard household outlet. Whenever
AC is used, the batteries are automatically
disconnected.
AM SENS
AM
EXT
ANT
DX
LOCAL
FM
FTEREO
NARR
MONO
WIDE
6
PRELIMINARY SETTINGS
SETTING THE CLOCK
The time is displayed in the 24 hour mode
since most shortwave stations operate
according to Greenwich Mean Time. This
is the standard that is used throughout the
world.
The clock will start when 4 AA batteries are
installed. The display shows "0:00"
1. Press "TIME SET". "0:00" disappears
& for 12 seconds "TIME SET" flashes.
2. While "FLASHING" set the correct time
by pressing the numbered buttons. As
you press the corresponding button the
number shows up on the LCD display
3. If you press the wrong number, press the
"C" [CANCEL] button which deletes
one number at a time. Repeat step
#2 again.
NOTE
Time can only be adjusted when "TIME
SET" is in flashing mode.
TIME SET
7
4. Now press button marked ENTER .
Display shows hours and minutes.
8
SETTING DUAL TIME
A second time zone can be programmed
into this unit such as your home time if
you are traveling, or Greenwich Mean
Time for instant access to short-wave
broadcasts or the local time where ever
you may be.
1. Press lower "DUAL TIME" button and
the display will show "DUAL".
2. Press "TIME SET" button. Clock time
will disappear & "TIME SET" will flash
for 12 seconds.
3. While "FLASHING" set the correct time
by pressing the numbered buttons. As
you press the corresponding button the
number shows up on the LCD display.
4. If you press the wrong number, press the
"C" [CANCEL] button which deletes
one number at a time. Repeat step #3
again.
TIME SET
9
5. Now press button marked "ENTER",
Display shows hours and minutes.
6. By pressing the lower "DUAL TIME"
button now, the LCD display will once
again show the clock time.
7. To verify "DUAL TIME", press the upper
"DUAL TIME" button to display your
"OTHER" time zone. When you release
the button the clock will show your
current local time.
10
BAND SELECTION
There are four band selector buttons
located just beneath the LCD display.
LW
MW
FM
BAND FREQUENCY RANGE PROGRAM TYPE
FM 87.5~108 Mhz Standard FM
LW 150~519 Khz Longwave
MW 520~1710 KHz Standard AM
SW 1.711~29.999 Mhz SW/13 Sub-Bands
1. Turn radio on by pressing "POWER"
button. Display will show last band and
frequency selected.
SW
POWER
2. By pressing any one of the four band
selector buttons the display shows the
band selected and a random frequency
within that band.
NOTE
When you select SW you only have to press
the button marked "METER", and then any
one of the numbered buttons depending
upon what band you wand to listen to. The
display will show the band you selected and
a random frequency within that band.
11
FM
LW
LW
FM
MW
MW
SW
SW
MANUL/AUTO
TUNIGN
STANDBY
FREQ
DIRECT ACCESS
METER
TUNING MODE
ADJUSTING THE ANTENNA
Locate the band you want to listen to in the
following chart and adjust the antenna as
indicated.
BAND ANTENNA TYPES ILLUSTRATION
BAND ANTENNA TYPES ILLUSTRATION
FREQUENCY
RANGE
INTERNAL
Rotate radio
POWER
MW 520-1710 Khz for best reception
LW
MW
SW
FM
MANUL/AUTO
TUNIGN
STANDBY
BUZZER
FREQ
RADIO
DIRECT ACCESS
STANDBY
METER
FM/LW/MW PLL SYNTHESIED RECEIVER
INTERNAL
Rotate radio
LW 150-519 Khz for best reception
FM
FM/LW/MW PLL SYNTHESIED RECEIVER
POWER
LW
MW
SW
MANUL/AUTO
TUNIGN
STANDBY
BUZZER
FREQ
RADIO
DIRECT ACCESS
STANDBY
METER
TELESCOPIC
Extend antenna all
the way & rotate it
FM 87.5-108 Mhz for best reception
FM
FM/LW/MW PLL SYNTHESIED RECEIVER
POWER
LW
MW
SW
MANUL/AUTO
TUNIGN
STANDBY
BUZZER
FREQ
RADIO
DIRECT ACCESS
STANDBY
METER
TELESCOPIC
Extend antenna all
the way for best
SW 1.711e~29.999 Mhz reception & do not
rotate
12
You may select any frequency using four different turning methods:
Direct turning
Manual Tuning
Scan Turning
Memory Tuning
DIRECT TUNING
You may "KEY IN" a specific band (120m,
49m,16m) by pressing the appropriate
button. The exact station is then selected
by pressing the buttons corresponding to
the station frequency.
Example: To tune 100.70 Mhz on the FM band, follow this procedure:
1. Press the POWER button to turn on the
radio.
2. Press the button marked, FREQ
("Frequency")
3. Press the corresponding buttons,
marked [1], [0], [0], [ ], [7], [0]. That
exact frequency will now show up in the
display.
POWER
13
4. Press the button marked ENTER
within twelve seconds. The frequency
and band will now show up in the display.
The SIGNAL STRENGTH will also show.
NOTE: Be sure to press the decimal
point [ ] in100.70MHz, otherwise the
display will show SW , [10.070 MHz]
automatically.
5. Extend the antenna all the way and
rotate for best FM reception.
6. Adjust the VOLUME and TONE controls
for the desired sound.
LW
FM
FM/LW/MW PLL SYNTHESIED RECEIVER
ROTARY
TUNING
UP
9K
10K
DOWN
MW STEP
HIGH
LOW
LUNE
10
5
0
VOL
POWER
MW
SW
MANUL/AUTO
TUNIGN
STANDBY
BUZZER
FREQ
RADIO
DIRECT ACCESS
STANDBY
METER
7. When selecting a stereo FM station
make sure the FM mode switch is in the
STEREO position.
14
EXT
ANT
AM SENS
DX
LOCAL
AM
FM
FTEREO
NARR
MONO
WIDE
MANUAL TUNING
To select a station you do not know the
frequency of, use the MANUAL TUNING
[ ] [V] buttons or the ROTARY TUNING
control on the side of the radio.
1. Press the POWER button to turn on
radio.
2. Select a band.
3. Press repeatedly the [ ] or [V] buttons
to reach a desired frequency. Press and
hold the [ ] or [V] buttons for at least a
half second or more to change frequencies
rapidly.
MANUL/AUTO
TUNIGN
FM
LW
MANUL/AUTO
MW
POWER
SW
OR Rotate the TUNING knob until the
desired frequency or station is tuned
in using the SIGNAL STRENGTH
INDICATOR in the display for the best
reception.
15
TUNIGN
NOTE
When you repeatedly press the [ ] or [V]
buttons, the frequencies change in increments
of:
FM : 50 KHz (or 100 KHz)
LW : 9 KHz
MW : 9 KHz or 10 KHz
SW : 5 Khz
4. Adjust the VOLUME and TONE controls
as you like.
Turning the ROTARY TUNING knob with
the TUNING SPEED CONTROL set on
FAST will change each band as follows:
FM : 100 KHz
LW : 9 KH z
MW : 9 KHz/10 KHz
SW : 5 KHz
When set on slow, the frequencies
change as follows:
FM : 50 KHz
LW : 1 KHz
MW : 1 KHz
SW : 1 KHz
With the TUNING SPEED CONTROL set on
LOCK, ROTARY TUNING will not function.
ROTARY
TUNING
UP
16
DOWN
9K
10K
MW STEP
HIGH
LOW
LUNE
10
5
0
VOL
SCAN TUNING
Use scan tuning to quickly locate a station
or to monitor several stations within a
specific band.
1. Turn on radio by pressing POWER
button.
2. Select a band.
3. Adjust antenna or radio position de pending on selected band.
FM
LW
MW
SW
FM
FM/LW/MW PLL SYNTHESIED RECEIVER
LW
POWER
MANUL/AUTO
TUNIGN
STANDBY
BUZZER
FREQ
DIRECT ACCESS
METER
POWER
MW
RADIO
STANDBY
SW
17
LW
MW
FM
FM/LW/MW PLL SYNTHESIED RECEIVER
SW
POWER
MANUL/AUTO
TUNIGN
STANDBY
BUZZER
FREQ
DIRECT ACCESS
METER
RADIO
STANDBY
4. Press and hold the ( ) or (V) buttons for at least
a half second or more and the radio will scan
all the frequencies in that band, and will stop
automatically each time it lands on an active
station. Signal strength is recorded on the
SIGNAL STRENGTH INDICATOR.
5. Press and hold the ( ) or (V) buttons again to
resume scanning. When you reach the upper
or lower limits of the band, the scanning starts
all over again as long as the button is
depresseden once more.
MANUL/AUTO
TUNIGN
1 2 3 4 5 6 7
MANUL/AUTO
TUNIGN
6. Adjust the VOLUME and TONE controls
as you like.
18
UP
DOWN
ROTARY
TUNING
9K
10K
MW STEP
HIGH
LOW
LUNE
10
5
0
VOL
MEMORY TUNING
You may store up to eighteen different
frequencies on the SW/FM bands and up
to nine different frequencies on each of
the other bands for instant selection of
your favorite stations.
Storing a Frequency
1. Press POWER button to turn on radio
.
2. Turn to any frequency using any of the
previously mentioned tuning methods.
3. Press the button marked M for
MEMORY it will start flashing in the
display for 15 seconds during which time
press any of the buttons marked 1 - 9
on the keyboard and your station will be
stored in that memory position. For the
SW/FM bands frequencies press 1-9 and
then 01- 09 for a total of 18
memory positions. The display will show
the memory position the station is now
stored in. You may store your stations
in any sequence you want. You do not
have to start with #1.
POWER
19
RECALLING A FREQUENCY
1. Press POWER button to turn on radio.
2. Select a band in which a station is stored
that you want to recall.
3. Press any of the NUMBERED buttons for
a desired station and the radio will
instantly tune to it and display that
frequency and the MEMORY position
number. If you want to change to
another stored station, just press any
other numbered button for access.
FM
LW
MW
POWER
SW
20
CLOCK RADIO OPERATION
With this receiver you can fall asleep to
your favorite station by pressing the SLEEP
button, or wake you to the morning news,
or an alarm buzzer. Make the following
settings with the POWER off!
Setting the Alarm
1. Press STANDBY button so display
shows 0:00. STANDBY will flash for
15 seconds.
TUNIGN
2. Press the numbered buttons to activate
turn-on time using 24 hour time, in hours
and minutes. For example, to set the
radio to turn on at 1:30 PM each day,
press the buttons until the display shows
13:30. If the wrong number was
keyed-in, delete it by pressing the
CANCEL button marked C . One
time for each number. Then press the
correct number for the time you want.
.
3. When you reach your desired turn-on time,
press ENTER, STANDBY stops flashing,
your turn-on time is locked in. For 2 to 3
seconds, the clock returns to the current
time automatically.
21
4. To verify STANDBY button again.
Press STANDBY once more and the
clock returns to the current time.
5. You may select radio or buzzer alarm
to wake you by setting STANDBY:
BUZZER/RADIO selector switch on the
side of the radio.
BUZZER
BADIO
STANDBY
6. To cancel the ALARM time, press
STANDBY and C [CANCEL] button.
Setting the sleep Timer
1. The sleep timer allows the user to set the
auto-shut off in 30 or 15 minutes decrements
from 90 minutes to 15 minutes.
To set auto-shut off, press SLEEP button 2,
LCD will show frequency read-out, 60 (auto shut off time) and the icon.
Press SLEEP button to change the required
auto-shut off time, release the button when
shut of time desired is reached.
2. TO turn off the radio before it automati cally turns itself off, press the POWER
button.
LW
MW
FM
SW
MANUL/AUTO
TUNIGN
STANDBY
FREQ
DIRECT ACCESS
METER
POWER
22
MISCELLANEOUS CONTROLS
In addition to standard tuning methods
described previously, use the following
controls for special operations.
AM SENSITIVITY: DISTANCE/
LOCAL SELECTTIVITY SWITCH
This switch adjusts the receiver's sensitivity.
When you listen to a strong station and the
signal is slightly distorted, set the switch to
the LOCAL position for best reception. For
normal or weak stations, set the switch to
the DX position for maximum sensitivity.
AM SENS
DX
LOCAL
AM: NARROW/WIDE
SELECTIVITY SWITCH
To reduce interference from adjacent
stations, set this switch to the NARROW
position and the interference will be
suppressed. For maximum selectivity, leave
the switch in the WIDE position.
HEADPHONE USE
While not a control, you may consider using
HEADPHONES to obtain the best audio
clarity when listening to SW. Since many
SW stations broadcast only marginal
signals, using HEADPHONES will enable
you to distinguish between the signal and
the noise usually encountered at night. Be
sure that the HEADPHONES terminate in
a 1/8 inch plug, which is inserted into the
HEADPHONE jack located on the left side
of the radio, marked with the symbol .
When the HEADPHONES are plugged in,
the speaker is muted.
EXT
ANT
AM SENS
DX
LOCAL
AM
FM
FTEREO
NARR
MONO
WIDE
AM
NARR
WIDE
Because the radio is capable of receiving
FM multiplex stereo, the HEADPHONES
should be stereo capable so that your
listening enjoyment will be enhanced. When
listening to stereo FM, be sure that the
FM: STEREO/MONO switch is set to the
STEREO position. This switch is located on
the lift-hand side of the radio, just above
the HEADPHONE jack.
23
LOCK SWITCH USE
EXTERNAL ANTENNA USE
Using the LOCK switch prevents
unauthorized operation of the radio and will
also prevent the station you are listening to
from being changed. When the LOCK
switch is moved to its up position,
the POWER button ant TUNING controls
are completely disabled. If the radio is on
when the LOCK switch is moved to its up
position, you will not be able to turn it
off. If the radio is off, with the LOCK
switch in its up position, you will
not be able to turn it on. This will also
prevent it from being turned on by
accident, when packed in a suitcase
or attache case. To release the LOCK
switch, simply move the switch down.
To obtain optimum performance from this unit,
especially when listening to SW an external
antenna should be used to the EXTERNAL ANTENNA ADAPTER and then plugged into
the EXTERNAL ANTENNA jack located on
the left side of the radio.
EXT
AM SENS
DX
LOCAL
AM
NARR
WIDE
ANT
MW STEP SELECTOR SWITCH
Located on the right side of the unit, just
beneath the ROTARY TUNING knob is a
switch marked, MW STEP: 9K/10K. This
switch selects the incremental frequency
STEPS for the MW band, depending upon
your geographic location. In the USA, 10K
STEPS are used, so the switch should be
set to its lowest position. In other parts of
the world where they use 9K STEPS, move
the switch to the uppermost position.
24
9K
10K
MW STEP
CAR E AN DMAINTENANCE
Thisreceiverisanexampleofsuperior
designandcraftsmanship.Thefollowing
suggestionswillhelpyoucareforthe
receiverso
Keeptheproductdry.I fitdoesgetwet,wipe
itdryimmediately.Liquidsmightcontain
mineralsthatcan
circuits.
tha
tyoucanenjoyitforyears
theelectronic
corrod
e
Useandstoretheproduc
temperatur
turescanshortenthelifeofelectronic
devices,
meltplasticparts.
Handletheproduct
Droppingitcandamagecircuitboardsand
casesandcancausetheproducttowork
improperly.
Keeptheproductawayfromdustanddirt,
whichcancauseprematurewearofparts.
e
environments
damag
e
batteries,anddistortor
gentlyandcarefully.
onlyinnormal
t
.
High
tempera-
25
Wipetheproductwithadampenedcloth
occasionallytokeepitlookingnew.Donot
useharshchemicals,cleaningsolvents,or
strongdetergentstocleamtoproduct.
Useonlyfreshbatteriesoftherecommendedsizeandtype.Alwaysremoveoldor
weakbatteries.Theycanleakchemicals
thatdestroyelectroniccircuits.
Modifyingortamperingwiththeproduct's
internalcomponentscancauseamalfunctionandmightinvalidatetheproduct's
warranty.
26
SPECIFICATIONS
Semi conductors: 1 LSI, 9 IC,
8FET. 42 Transistors
41 Diodes.
Circuit:
FM : Heterodyne
AM (LW, MW, SW) Double-conversion heterodyne
Frequency range:
FM: 87.5-108 MHz
LW: 150-519 Khz
MW: 520-1710 KHz
SW: 1.711~29.999 Mhz
in which divided into 13 shortwave bands
120M 2.300 - 2.495 MHz
90M 3.200 - 3.400 MHz
75M 3.900 - 4.000 MHz
60M 4.750 - 5.060 MHz
49M 5.900 - 6.200 MHz
41M 7.100 - 7.350 MHz
31M 9.400 - 9.990 MHz
25M 11.600 - 12.100 MHz
21M 13.570 - 13.870 MHz
19M 15.100 - 15.800 MHz
16M 17.480 - 17.900 MHz
13M 21.450 - 21.750 Mhz
11M 25.600 - 26.100 MHz
Antennas:
LW/MW built-in Ferrite bar Antenna
SW Telescopic Antenna or External Antenna (not included)
FM Telescopic Antenna
Output: Nominal 440 mW at 10% T.H.D.
Jacks: 1. DC jack for external power (6V)
2. Headphone jack - 3.5 for mini stereo headphones
3. AM Ext. Ant. Jack.
27
Power sources: 1. For Power when not playing radio
UM 3 (AA size) battery x 2pcs
for memory/clock back-up (3V)
2. For Power to play radio:
1. UM 3 (AA size) battery 4pcs
2. AC adaptor 6V/300 mA center negative
Dimension: 196(L) x 125(H) x 36(T) mm
Weight: 600 g
Accessories: Stereo earphones, Carrying pouch.
STATION LOG
For those of you who would like to log your
favorite stations, a convenient card is
provided with your receiver which is simply
inserted under the folding stand on the
back of the radio. Please see illustration for
complete detail.
28
Loading...
