SAMSUNG YP-T6HB User Manual
- MP3, WMA , ASF and Ogg Playback
- Removable Storage Device
- Direct MP3 Recording
- FM Reception
- 3D Sound
- USB 2.0 Support
- Upgradable
- 20 Hours of Continuous Play
- Voice Recording Function
AH68-01633L(Rev 0.0)
Samsung Electronics America, Inc.
400 Valley Road, Suite 201 Mount Arlington, NJ 07856
1-800-SAMSUNG (1-800-726-7864)
www.samsung.com
3
ContentsContents
2
Safety Instructions................................................................................................................................................4
Features ..............................................................................................................................................................6
Components ........................................................................................................................................................8
Location of Controls ............................................................................................................................................9
I Preparations
Playing Music and Turning Off the Device ........................................................................................................28
Hold Function ....................................................................................................................................................29
Recording Voice ................................................................................................................................................29
MP3 Encoding ....................................................................................................................................................30
Searching for Music/Voice Files ........................................................................................................................31
Listening to FM Radio ........................................................................................................................................32
FM Encoding ......................................................................................................................................................34
I Basic Usage
Loop Repeating ..................................................................................................................................................34
MENU Options ..................................................................................................................................................35
I Additional Usage
Connecting the player to PC ..............................................................................................................................11
Manual Installation of USB Driver ......................................................................................................................15
Using the removable storage(PC)......................................................................................................................18
● Formatting on your PC ..................................................................................................................................18
● Downloading/Uploading files ........................................................................................................................18
● Disconnecting the USB cable........................................................................................................................19
● Downloading Secure WMA Files ..................................................................................................................20
Installing Music Studio........................................................................................................................................22
Using Music Studio ............................................................................................................................................23
To V iew Help on Music Studio ..........................................................................................................................27
I Connection to Computer
Using Navigation ................................................................................................................................................36
Setting Playlist....................................................................................................................................................39
Setting the Advanced Functions ........................................................................................................................40
Selecting the Play mode ....................................................................................................................................41
Setting the EQ mode..........................................................................................................................................42
● Preset EQ......................................................................................................................................................42
● Bass Booster ................................................................................................................................................42
● WOW Set ......................................................................................................................................................43
● User EQ Set ..................................................................................................................................................44
Display Settings..................................................................................................................................................45
● Scroll Speed ..................................................................................................................................................45
● Display Time..................................................................................................................................................45
● Backlight........................................................................................................................................................46
● Contrast ........................................................................................................................................................46
● Tag ................................................................................................................................................................47
● Language ......................................................................................................................................................47
Setting the System ............................................................................................................................................48
Record Settings..................................................................................................................................................50
Time Settings......................................................................................................................................................51
Managing Files ..................................................................................................................................................52
I Additional Usage
Troubleshooting..................................................................................................................................................54
Specifications ....................................................................................................................................................56
Safety Information ..............................................................................................................................................58
Warranty ............................................................................................................................................................60
I Customer Support
MENU Table ......................................................................................................................................................53
I Appendix
5
Safety InstructionsSafety Instructions
4
Read and understand all the instructions to avoid injury to yourself and damage to the equipment.
Do not expose to extreme temperatures (above 95°F or below 23°F).
Do not expose to moisture.
Do not subject the unit to severe
impact, or place heavy objects
on it.
Do not let any foreign matter spill
into the device.
Be careful not to subject the
player to excessive pressure
when wearing it round your neck.
Do not expose to chemicals such
as benzene and thinners.
Remove batteries when the
device is left unused for a long
period of time.
Do not expose to direct sunlight
or heat sources.
Do not store in dusty areas. Do not try to disassemble and
repair the device yourself.
I Earphones
Follow Traffic Safety Instructions
● Do not use the earphones while driving an automobile or riding a bicycle.
It’s not only dangerous, but also against the law.
● To avoid an accident, do not turn up the volume of the earphones too high while walking.
Protect your ears
● Do not turn up the volume too high. Doctors warn against prolonged exposure to high volume.
● Stop using the device or turn the volume down if you have ringing in your ears.
I Ambient operating conditions
● Ambient temperature : 5°C ~ 35°C (41°F ~ 95°F)
Humidity : 10 ~ 75%
I Environmental Information
● Follow local guidelines for waste disposal when discarding packages, batteries,
and old electronic appliances.
● Your player is packaged with cardboard, polyethylene etc., and does not use any unnecessary materials.
✽
Please be aware that we claim no responsibility for damage from data loss
due to breakdown, repair or other causes.
7
FeaturesFeatures
6
MP3, WMA, ASF, Secure WMA and Ogg Playback
● The player supports playback of MP3, WMA, ASF, Secure WMA and Ogg(Ogg Vorbis)
❉ OGG is a new audio compression format that is free, open and unpatented.
For more info, see www.vorbis.com
Removable Storage Device
● You can easily copy and paste files to the player using Windows Explorer.
Direct MP3 Recording
● You can convert music from CDs, cassettes, and radio into
MP3 files without a PC.
FM Reception
● Listening to an FM program is made easy with Auto Search and
Frequency Memory functions.
3D Sound
● The 3D surround(SRS) feature adds spaciousness to the sound.
USB 2.0 Support
● Maximum data speed transfer of 18 Mbps.
Upgradable
● You can upgrade the built-in programs when available.
Add functions, CODEC, etc. Please check the home page
(www.samsung.com) for upgrades.
20 Hours of Continuous Play
● This player uses one AAA/LR03 alkaline battery. Operation can last up to 20hours.
Actual playing time may vary according to the type and capacity of the battery.
Voice Recording Function
● You can make high quality voice recordings.
9
Location of ControlsComponents
8
● The capacity of the useable built-in memory is less than indicated as the internal firmware
uses part of the memory as well.
● The accessories' design is subject to change for the purpose of improvement, without notice.
Model
Built-in memory
YP-T6 H
128MB
YP-T6 V
256MB
YP-T6 X
512MB
YP-T6 Z
1GB
Continued...
Recording Button
Play/Pause Button
Hold Switch
Loop Repeating Button
USB Cable
Connection Port
ENC Jack
Microphone
Neck strap Hook
MENU, Navigation button/
Move to Track/Speed Search/
Volume Button
Display
Battery Cover
Earphone Jack
Player
Earphone
AH30-00069D
One Battery
(1.5V AAA/LR03 type)
4301-000115
USB Cable
AH39-00692A
User manual
AH68-01633L
Line In Cable
AH39-00488B
Installation CD
AH80-00078C
Neck Strap
AH61-01414B
Carrying case
AH61-01618A
Direct Connect
USB Adapter
AH39-00590B
11
Connecting the player to PCLocation of Controls
10
The PC system must meet the
following specifications:
● Pentium 200MHz or greater
● Windows 98 SE/ME/2000/XP
● 40MB of available hard disc space
● CD-ROM drive
(double speed or greater)
● USB port (2.0) supported
● VGA graphic
System Requirements.
I Installing software
I Display
I Inserting the Battery
1 Slide the cover in the direction of
the arrow to open.
2 Insert a battery to the right poles
+ , – and push-close the cover in
the direction of the arrow as indicated.
1Insert the Installation CD into the
CD-ROM drive.
Select [Install Player USB Driver].
NNNNoooottttee
ee
- Do not place heavy objects on the cover.
✍
Before connecting the player to PC, make sure to install USB driver. If “Add New Hardware
Wizard” appears, press the [Cancel] button and install the USB driver.
NNNNoooottttee
ee
- Install the operating system in Administrator Account
(main user) for Windows 2000 or XP.
Otherwise, installation will not be completed.
- Windows ME, 2000 and XP can recognize the driver
without installing the provided program. However,
you must install the program in order to format the player
and upgrade firmware.
- If the YP-T6 program has not been installed in Windows
98, then it will not communicate with your removable disc.
You must install the USB driver file first.
✍
Continued...
Title (track & artist) indicator
Play/Stop/Pause indicator
Track Number indicator
Remaining Battery Power indicator
Play mode indicator
Equalizer, SRS indicator
Playtime indicator
13
Connecting the player to PC
12
2 Follow the instructions in the window to complete the installation.
1 Connect the USB cable or Direct Connect USB adapter to the USB port on
the computer.
2 Connect the other end of the USB cable or adapter to the USB cable connection
port on the bottom of the player.
● If you disconnect the USB cable from your PC while implementing a
command or initializing during USB driver installation, your PC may not
function correctly.
3 The USB driver is installed with a message saying that it is searching for a new
device. You may not see the display screen during installation.
Go to the device manager (see next page) to check that installation has been
successfully completed.
4 Upon installation of the USB driver "Samsung YP-T6 USB Device" will appear in
the [System Properties] ➝ [Device Manager].
I Connecting the player to PC with the USB cable
Continued...
Connecting the player to PC
Direct Connect USB adapter
USB cable
15
Manual Installation of USB DriverConnecting the player to PC
14
How to check USB driver
How to check USB driver
Windows 98:
Control Panel ➝ System ➝ Device Manager ➝ Disc Drives ➝ Samsung YP-T6
Windows 2000/Windows XP:
Control Panel ➝ System ➝ Hardware ➝ Device Manager ➝ Disc Drives ➝
Samsung YP-T6 USB Device
5 When the USB driver is not installed automatically, refer to the next page.
NNNNoooottttee
ee
- If you are using Windows 2000 and your version of Windows does not recognize the USB driver
please download and install the latest service pack from windowsupdate.microsoft.com
- The installation method may vary depending on the type of PC or operating system.
Contact your PC dealer or service center for installation information.
- If errors occur continuously when you install the USB driver, reconnect the USB cable after
rebooting your system.
✍
I
When an error occurs during installation of the USB driver
1Check the device manager.
Windows 98,ME:
Control Panel ➝ System ➝ Device Manager
Windows 2000:
Control Panel ➝ System ➝ Hardware ➝
Device Manager
Windows XP:
Control Panel ➝ System ➝ Hardware ➝
Device Manager
2Check if there is a device listed with an exclamation point or a question mark
(displayed as unknown device or USB device).
3Double click on the device listed with an exclamation point or a question mark.
Go to “Downloading/Uploading files”(p18) if the USB driver is installed.
Follow these steps if the USB driver is not in installed :
17
Manual Installation of USB DriverManual Installation of USB Driver
16
I In Windows 98
Follow the instructions in the window to complete the installation.
USB driver location
[CD ROM]\setup\Drivers
: You must reboot your computer to complete the installation.
NNNNoooottttee
ee
- You cannot use the player as a removable disc in Windows 98 if the YP-T6 program is not installed.
Make sure to install the USB driver file first.
✍
4After selecting the driver,
click [Update Driver].
5Click [Next].
6Select [Search for a suitable driver
for my device] and then click [Next].
7Click [Next] to finish.
19
Using the removable storage(PC)Using the removable storage(PC)
18
I Downloading/Uploading files
I Formatting on your PC
1Connect the player to your PC with the supplied USB cable.
2Open Windows Explorer on your PC.
● Removable Disc is displayed in Windows Explorer.
3Select the file to save and drag-and-drop it into the removable disc icon.
(Files will appear In numerical, alphabetical order)
● If you change the name of music files in Windows Explorer to 001* * * , 002* * *...,
music files will be played in the order of number indicated.
2When the
[Stop a Hardware device]
message appears, press
the [OK] button and
disconnect the USB cable.
1Select the removable disc icon
and click the right mouse button
to select [Format].
2Press the [Start] button.
● All saved files will be formatted.
● You can change the name of removable disc
by selecting [Volume label].
I Disconnecting the USB cable
1Double-click on the green arrow in the taskbar on the
bottom right of the window.
NNNNoooottttiiiiccccee
ee
- The “WRITING/READING” message will
appear during file download or upload.
Disconnecting the USB cable while
“WRITING/READING” is displayed may
cause malfunction of the unit.
- The music file order displayed in Windows
Explorer may differ from the play order on
your device.
✍
NNNNoooottttee
ee
- By formatting, all previously preset menus will be reset,
and any pre-existing song or data files will be erased.
- Care must be taken as formatted files can not be recovered.
✍
Continued...
After completing the file transfer, you must disconnect the cable in the following way:
Loading...
