E-MANUAL

Thank you for purchasing this Samsung product.
To receive more complete service, please register

your product at

www.samsung.com/register

Model______________ Serial No.______________

Contents

Channel Menu

• Connecting the TV 1

• Using the INFO button

(Now & Next guide) 20

• Managing Channels

and Channel Functions 22

• Memorizing Channels 66

• Other Features 80

Basic Feature

• Changing the Preset Picture Mode 96

• Adjusting Picture Settings 99

• Changing the Picture Size 105

• Changing the Picture Options 116

• Using the TV with Your PC 134

• Changing the Preset Sound Mode 138

Preference Features

• Connecting to the Network 156

• Setting up a Wired Network 167

• Setting up the Wireless Network 180

• Managing the Network Devices 206

• Setting the Time 218

• Blocking Programmes 231

• Economical Solutions 236

• Picture In Picture (PIP) 240

• Using the TV with

a Keyboard and a Mouse 245

• Other Features 253

• Support Menu 276

• Adjusting Sound Settings 140

Advanced Features

• Specification for SMART Interaction 566

• Using the 3D function 301

• Smart Hub 319

• Customizing the Home Screen 343

• Using Samsung Apps 375

• Search 385

• Your Video 393

• Family Story 410

• Fitness 465

• Kids 477

• Web Browser 493

• Skype 522

• SMART Interaction 525

• AllShare Play 577

• Using the AllShare Play 602

• My list (In AllShare Play) 606

• Videos (In AllShare Play) 619

• Photos (In AllShare Play) 638

• Music (In AllShare Play) 655

• Recorded TV (In AllShare Play) 669

• Timeshift 684

• Using the DLNA Function 694

• Using the MHL function 705

• Anynet+ (HDMI-CEC) 711

Other Information

• AllShare Play (Troubleshooting) 783

• Troubleshooting 728

• Picture Quality (Troubleshooting) 732

• Sound Quality (Troubleshooting) 740

• No Picture, No Video (Troubleshooting) 744

• RF (Cable / Aerial) Connection

(Troubleshooting) 748

• PC Connection (Troubleshooting) 750

• Network Connection (Troubleshooting) 751

• Recording / Timeshift (Troubleshooting) 752

• Others (Troubleshooting) 761

• Anynet+ (HDMI-CEC) (Troubleshooting) 775

• Smart Hub (Troubleshooting) 784

• Web Browser (Troubleshooting) 786

• Using the Smart Touch Control 794

• Supported Subtitle

and AllShare Play file formats 822

• Data Service 831

• HbbTV 839

• Connecting to a TV Viewing Card slot 843

• Teletext Feature 849

• Anti-theft Kensington Lock 856

• Licence 861

Connecting the TV

Connecting to an Aerial and / or Satellite

TV rear panel

or

The displayed image may differ depending on the model.

Connecting to an AV Device

Using a HDMI (up to 1080p)

The displayed image may differ depending on the model.

TV side panel

Using an HDMI cable (up to 1080p)

N

HDMI IN 1(DVI), HDMI IN 2(ARC),

HDMI IN 3(MHL)

●

For better picture and audio quality,

connect to a digital device using an

HDMI cable.

●

An HDMI cable supports digital video

and audio signals, and does not require

an audio cable.

–To connect the TV to a digital device

that does not support HDMI output,

use an HDMI/DVI and audio cables.

●

The picture may not display normally

(if at all) or the audio may not work if

an external device that uses an older

version of HDMI mode is connected to

the TV. If such a problem occurs, ask

the manufacturer of the external device

about the HDMI version and, if out of

date, request an upgrade.

●

Be sure to use an HDMI cable with a

thickness of 14 mm or less.

●

Be sure to purchase a certified HDMI

cable. Otherwise, the picture may not

display or a connection error may

occur.

●

A basic high-speed HDMI cable or one

with Ethernet is recommended. This

product does not support the Ethernet

function via HDMI.

●

This product supports the 3D and ARC

(Audio Return Channel) functions via an

HDMI cable. Note that the ARC function

is supported by the HDMI IN 2(ARC)

port only.

–If 3D Auto View is set to On, some

functions such as SMART HUB may

be disabled. In this case, set 3D Auto

View or 3D Mode to Off.

●

The ARC function allows digital audio

to output via the HDMI IN 2(ARC) port.

It can be enabled only when the TV is

connected with an audio receiver that

supports the ARC function.

●

This product supports the Mobile High-

Definition Link (MHL) function via an

HDMI-MHL cable. Note that the MHL

function is supported by the HDMI IN

3(MHL) port only.

●

The MHL function allows to display

mobile device's screen via the HDMI

IN 3(MHL) port. It can be enabled

only when the TV is connected with a

mobile device that supports the MHL

function. For more detailed information,

see "Using the MHL function" in

e-Manual.

Using a Scart Cable

The displayed image may differ depending on the model.

TV side panel

Using a Component (up to 1080i)

TV rear panel

The displayed image may differ depending on the model.

Using a Component (up to 1080i) or an

Audio/Video (480i only) and a Scart Cable

N

In Ext. mode, DTV Out supports

MPEG SD Video and Audio only.

N

When connecting to AV IN, connect

the AV connector (yellow) to the TV

jack (Green).

N

To obtain the better picture quality,

the Component connection or Scart

connection are recommended over

the A/V connection.

Connecting to an Audio device

Using an Optical (Digital) Connection

TV side panel

The displayed image may differ depending on the model.

DIGITAL AUDIO OUT (OPTICAL)

●

When you connect a Digital Audio

System to the DIGITAL AUDIO OUT

(OPTICAL) jack, decrease the volume

of both the TV and the system.

●

Use the System speakers for audio.

●

5.1 CH (channel) audio is available when

the TV is connected to an external

device supporting 5.1 CH.

●

When the receiver (home theatre) is set

to on, you can hear sound output from

the TV’s optical jack. When the TV

is receiving a DTV signal, the TV will

send 5.1 CH sound to the home theatre

receiver. When the source is a digital

component such as a DVD / Blu-ray

player / cable box / STB (Set-Top-Box)

satellite receiver and is connected to the

TV via HDMI, only 2 CH audio will be

heard from the home theatre receiver. If

you want to hear 5.1 CH audio, connect

the digital audio out jack from your

DVD / Blu-ray player / cable box / STB

satellite receiver directly to an amplifier

or home theatre.

Headphones

TV rear panel

The displayed image may differ depending on the model.

H

You can connect your headphones to

the headphones output on your set.

While the headphones are connected,

the sound from the built-in speakers

will be disabled.

●

Sound function may be restricted

when connecting headphones to the

TV.

●

Headphone volume and TV volume

are adjusted separately.

●

The headphones jack supports only

the 3 conductor tip-ring-sleeve (TRS)

type.

Connecting to a PC

Using an HDMI cable or an HDMI to DVI

cable

TV side panel

The displayed image may differ depending on the model.

N

Connecting through the HDMI cable

may not be supported depending on

the PC.

Optimal resolution is 1920 X 1080 @ 60

Hz.

N

For HDMI/DVI cable connection, you

must use the HDMI IN 1(DVI) jack.

●

The interlace mode is not supported.

●

The set might operate abnormally

if a non-standard video format is

selected.

●

Separate and Composite modes are

supported. SOG (Sync On Green) is

not supported.

●

PC (D-Sub) input is not supported.

Using the INFO button (Now & Next guide)

The display identifies the current

channel and the status of certain audio-

video settings.

The Now & Next guide shows daily

TV programme information for each

channel according to the broadcasting

time.

●

Scroll l, r to view information for a

desired programme while watching the

current channel.

●

Scroll

u, d

to view information for

other channels. If you want to move to

the currently selected channel, select

using your remote.

E

Managing Channels and Channel Functions

Press the ™ button to select the menu

you want to use. Each screen will be

displayed.

Guide

Guide

→

™

The EPG (Electronic Programme Guide)

information is provided by broadcasters.

Using programme schedules provided

by broadcasters, you can specify

programmes you want to watch

in advance so that the channel

automatically changes to the selected

programme channel at the specified

time. Programme entries may appear

blank or out of date depending on a

channel status.

Using Channel View

●

(Sche. Mgr): Displays the Schedule

a

Manager.

●

(-24 Hours): Viewing the list of

b

programmes to be broadcasted before

24 hours.

●

(+24 Hours): Viewing the list of

{

programmes to be broadcasted after 24

hours.

●

(Ch. Mode): Select the type of

}

channels you want to display on the

Channel View window.

●

Information: Displays details of the

`

selected programme.

●

●

Page: Move to next or previous page.

k

Watch / Schedule: When selecting

E

the current programme, you can watch

the selected programme. / When

selecting the future programme, you

can reserve to watch the selected

programme.

Channel

Channel

→

™

Using this function, you can delete

channels from the different Category

channel lists on the Channel screen,

set favourite channels, view and access

recently viewed and most viewed

channels, and edit the channel names

of analogue channels.

N

The available items may differ

depending on the selected aerial

source.

Category Options (on the left side of the

Channel screen)

●

All

Shows all channels.

●

TV

Shows TV channels.

●

Radio

Shows radio channels.

●

Data/Other

Shows data channels and other

channels.

●

Analogue

Shows analogue channels.

●

Favourites 1 – Favourites 5

Lets you arrange and display favourite

channels in up to five groups. Each

group is independent of the other

groups and can contain the same

channels as other groups, different

channels, or a combination of both.

N

The TV displays favourites only if

you have added favourites using Edit

Favourites in the Tools menu.

N

If the highlight located in the

Favourites 1 – Favourites 5 category,

you can change the name of

category by selecting b using your

remote.

●

Recently Viewed

Shows the most recently viewed

channels.

●

Most Viewed

Shows the most frequently viewed

channels.

Using the coloured and function buttons

with Channel

●

Air / Cable / Satellite

a

Select the desired aerial source.

The option may differ depending on

country.

●

Delete

b

Deletes the selected channel(s) from a

category list.

●

Information

`

Displays details of the selected channel.

●

Page

k

Scrolls the channel list to the next or

previous page.

N

These correspond to the CH buttons

on the remote.

●

Select / Deselect

E

Selects or deselects a channel.

●

T

Tools

Displays the option menu.

●

Return

R

Return to the previous menu.

Using the Tools menu with the Channel

●

Edit Favourites

Lets you assign channels you watch

frequently to a favourites group and

remove channels from a favourites

group. You access Edit Favourites on

the Tools menu.

Select Edit Favourites. The Edit

1.

Favourites screen appears.

Select

2.

using your remote. The

a

selected channel will be added to the

favourite group.

N

Also, you can select a channel in

the Edit Favourites screen.

N

You can add a favourite channel

to any one of the groups. To

change favourites group, select }

using your remote. Each time you

select }, a favourites group will

be changed.

When done, select OK on the right

3.

side. The channel is made a favourite

and is assigned to the favourites

group you selected.

Edit completed. appears on the

4.

screen. Select OK.

N

On the Channel screen, the TV

displays the “

to the channel, indicating it is a

favourite.

●

Lock / Unlock

” symbol next

Lock a channel so that the channel

cannot be selected and viewed.

N

This function is available only when

the Channel Lock is set to On.

●

Rename channels

(Appears only if you have selected an

analogue channel.)

Lets you assign a name of up to five

characters to an analogue channel. For

example, Food, Golf, etc. This makes it

easier to find and select the channel.

●

Edit Channel Number

Edit the channel number by select the

numbers.

N

This function may not be supported

depending on the region.

●

Sorting (digital channels only)

Change the list ordered by name or

number.

●

Channel Info

Displays information of channel signal.

The item may differ depending on

channel.

●

Search (when the Aerial was set to

Satellite)

Channel scan is started.

●

Delete

Delete a channel to display the

channels you want.

●

Select All / Deselect All

Select all channels in the list. / Deselect

all channels you selected.

To delete a channel from a Category

list on the Channel screen, follow these

steps:

If you want to delete a channel,

1.

select a category of the channel.

Select a channel in the category list.

2.

A

mark appears to the left of the

c

channel.

N

You can select more than one

channel.

N

If you re-select a channel you

selected, the

Open the Tools menu using your

3.

mark disappears.

c

remote.

Select Delete. The message Delete

4.

the selected channels? appears.

Select OK.

N

You can delete the selected channel

immediately by selecting b using

your remote.

N

When you delete a channel in the

Recently Viewed or Most Viewed

category, the channel will disappear

from that category list. But, the

channel is not deleted.

To set channels as favourites, follow

these steps:

Select the All category.

1.

Select a channel in the category. A

2.

mark appears to the left of the

c

channel.

N

You can select more than one

channel.

N

If you re-select a channel you

selected, the

Open the Tools menu using your

3.

c

mark disappears.

remote.

Select the Edit Favourites. The Edit

4.

Favourites screen appears.

Select

5.

using your remote. The

a

selected channel will be moved to

the favourite group.

N

Also, you can select a channel in

the Edit Favourites screen.

N

You can add a favourite channel

to any one of the groups. To

change favourites group, select }

using your remote. Each time you

select }, a favourites group will

be changed.

When done, select OK. The channel is

6.

made as a favourite and is assigned

to the favourite group you selected.

N

The TV displays the “ ” symbol

next to the channel, indicating it

is a favourite.

Using the coloured and function

buttons with Edit Favourites

●

When the highlight located in the All,

you can use these options:

–

Add

a

Add selected channels to the

favourites group.

–

Change Fav.

}

Change the favourites group.

Each time you select } using

your remote, the favourites group

changes.

–

Ÿ

Go To

You can enter a channel number

immediately using your remote.

–

Return

R

Return to the previous menu.

●

When you highlight a favourite

channel in a favourites group on the

Edit Favourites screen, you can use

these options:

–

–

–

Delete

a

Delete the selected channel.

Change order

b

Change the favourite group list

order.

Copy

{

Copy a selected channel to other

favourites groups.

–

Change Fav.

}

Change the favourites group.

Each time you select } using

your remote, the favourites group

changes.

–

–

–

Done

E

Finish the Change order function.

Ÿ

R

Go To

You can enter a channel number

immediately using your remote.

Return

Return to the previous menu.

To remove a channel from a favourites

group, follow these steps:

Select the favourite’s group category.

1.

Select a channel in the selected

2.

favourites group. A

mark appears

c

to the left of the channel.

N

You can select more than one

channel.

N

If you re-select a selected channel,

the

mark disappears.

c

Open the Tools menu using your

3.

remote.

Select the Delete. The message

4.

Do you want to delete the selected

item(s)? appears.

Select OK. The message Deleted the

5.

selected item(s). appears.

Display Icons Used in the Channel screens

: An analogue channel.

: A channel selected.

c

: A favourite channel.

: A locked channel.

Schedule Manager

Schedule Manager

→

™

Using this function, you can set

the TV to display a desired channel

automatically on a day and at a time of

your choice.

N

You must set the current time first

using the Time

Clock function

→

in the System menu to use this

function.

To use Schedule Viewing, follow these

steps:

On the Schedule Manager screen,

1.

select a using your remote.

A pop up screen will appear. Select

2.

Schedule Viewing.

Set Aerial, Channel, Repeat, and

3.

Start Time.

●

Aerial

Select the desired aerial source.

●

Channel

Select Channel to view the channel

numbers. Select the desired channel.

N

You can only select memorised

channels.

●

Repeat

Select Once, Manual, Sat~Sun,

Mon~Fri or Everyday. If you select

Manual, you can set the day you

want.

N

The

mark indicates a day you’

c

ve selected.

Date: You can set a desired date.

N

The Date is available only when

you select Once in Repeat.

●

Start Time

You can set the start time you want.

When done, select OK, The selected

4.

channel is scheduled for viewing.

N

On the Schedule Manager screen,

you can view a list of Schedule

Viewing.

N

If you select Information

function using your remote

after highlighting an item, the

Information screen appears. On

the Information screen, you can

change or cancel the Schedule

Viewing.

Cancel schedule: Cancel the Schedule

Viewing.

Edit Schedule: Change the Schedule

Viewing.

Return: Return to the previous

screen.

To delete an item in a list of scheduled,

follow these steps:

On the Schedule Manager screen,

1.

highlight an item you want to delete.

Open the Tools menu using your

2.

remote.

Select the Cancel schedule. The

3.

Cancel selected list(s)? message

appears.

Select Yes. The selected schedule is

4.

cancelled.

To use Schedule Recording, follow these

steps (Digital channels only):

Allows you to make a reservation to

record a programme scheduled for

broadcast.

Set the current time first to use this

function.

Select Schedule Manager. The

1.

Schedule Manager screen will be

displayed.

Select

2.

using your remote. A pop

a

up screen will appear.

Select the Schedule Recording.

3.

N

We recommend using a USB

HDD with at least 5,400 rpm, but

a USB HDD of RAID type is not

supported.

N

More than 3TB USB HDD is not

supported.

N

A USB storage device cannot

record until it completes the

Device Performance Test.

N

USB memory stick is not

compatible.

Set the Aerial, Channel, Repeat, Date,

4.

Start / End Time.

N

If you want to play a recorded

programme, refer to Recorded TV

in the e-Manual.

Channel List

Using this function, you can view the

channel list, programme information,

and favourite channels, select channels

to watch, and use Schedule Viewing on

digital channels.

Press the CH LIST button

1.

Remote Control

or select CH List

for Standard

for

Smart Touch Control

. The Channel List

screen is displayed immediately.

Change a channel or channel list

2.

mode.

Using the coloured and function buttons

with the Channel List

●

N

If you select Info using your remote,

the TV displays details of the

selected programme.

Aerial

a

Select the desired aerial source.

The option may differ depending on

country.

●

Programme View / Channel View

{

For digital channels, switches the

display between Programme View and

Channel View.

When you select a digital channel in

Channel List, select { once to display

a list of programmes on that channel.

Select again to re-display the Channel

View.

●

Ch. Mode / Channel

lr

Move to the type of channels you want

to display on the Channel List screen.

/ On the Programme View screen,

displays the programmes for the next

or previous channel.

●

Watch / Information

E

Watches the channel you select. /

Displays details of the selected channel.

●

Page

k

Scrolls the Channel List to the next or

previous page.

Using the Schedule Viewing in Channel List

(Digital channels only)

You can use Schedule Viewing in

Channel List to schedule a digital

channel programme for viewing.

The TV will turn on and display the

digital channel programme when the

programme begins.

Select CH LIST function using your

1.

remote. The Channel List screen

appears.

Select a desired digital channel.

2.

Select

3.

displays the programme list of the

selected channel.

Select a desired programme in the

4.

programme view, and then select

Information using your remote.

using your remote. The TV

{

On the Information screen, select

5.

Schedule Viewing. The selected

programme is scheduled.

N

If you want to cancel the Schedule

Viewing, follow Steps 1 through 4,

and then select Cancel schedule.

Channel Status Display Icons

: An analogue channel.

: A reserved programme.

: A reserved recording programme.

: A locked channel.

Memorizing Channels

Aerial

Menu

Before your television can begin

memorizing the available channels, you

must specify the type of signal source

that is connected to the TV.

N

Channel

→

The option may differ depending on

Aerial

→

country.

Country

Menu

Select your country so that the TV can

correctly auto-tune the broadcasting

channels.

N

●

Channel

→

The PIN input screen appears. Enter

Country

→

your 4 digit PIN number.

Digital Channel: Change the country

for digital channels.

●

Analogue Channel: Change the

country for analogue channels.

Auto Tuning

Menu

Scans for a channel automatically and

stores in the TV.

N

Channel

→

Automatically allocated programme

Auto Tuning

→

numbers may not correspond

to actual or desired programme

numbers. If a channel is locked using

the Channel Lock function, the PIN

input window appears.

●

Auto Tuning: Scans for channels

automatically and stores them in the

TV’s memory.

●

Cable Search Option

(Depending on the country)

N

When the Aerial was set to Cable.

Sets additional search options such

as the frequency and symbol rate for

a cable network search.

When Aerial Source is set to Air or Cable

●

Digital & Analogue / Digital / Analogue:

Select the channel source to memorise.

When selecting Cable

Digital &

→

Analogue or Digital: Provide a value to

scan for cable channels.

●

Operator Selection (Depending on the

country): Selects a provider of cable

services.

●

Search Mode: If you selected the Cable,

the Search Mode screen appears.

Scans for all channels with active

broadcast stations and stores them in

the TV.

N

If you select Quick, you can set up

the Network, Network ID, Frequency,

Modulation, and Symbol Rate

manually by the remote control.

Network: Selects the Network ID setting

mode among Auto or Manual.

Network ID: When Network is Manual,

you can set up Network ID.

Frequency: Displays the frequency for

the channel. (Differs in each country)

Modulation: Displays available

modulation values.

Symbol Rate: Displays available symbol

rates.

When Aerial Source is set to Satellite

(Depending on the country)

●

Channel Type: Select the Channel Type

to memorise.

●

Satellite: Selects the satellite to scan.

The option may differ depending on

country.

●

Scan Mode: Selects the scanning mode

of the selected satellite.

●

Re-initialise: Selects the scanning

mode of the selected satellite.

●

Search Mode: Sets search mode using

up/down functions.

Manual Tuning

Menu

Channel

→

Manual Tuning

→

Scans for a channel manually and

stores in the TV.

N

If a channel is locked using the

Channel Lock function, the PIN input

window appears.

N

This function may not be supported

depending on the region.

When Aerial Source is set to Air or Cable

●

Digital Channel Tuning: Scans for a

digital channel.

Select the New.

1.

N

When selecting Aerial

Air:

→

Channel, Frequency, Bandwidth

N

When selecting Aerial

Cable:

→

Frequency, Modulation, Symbol

Rate

Select the Search. When scanning

2.

has finished, a channel is updated in

the channel list.

●

Analogue Channel Tuning: Scans for a

analogue channel.

Select the New.

1.

Set the Programme, Colour System,

2.

Sound System, Channel and Search.

Select the Store. When scanning has

3.

finished, a channel is updated in the

channel list.

Channel mode

●

P (programme mode): When tuning is

complete, the broadcasting stations

in your area have been assigned to

position numbers from P0 to P99.

You can select a channel by entering

the position number in this mode.

●

C (aerial channel mode) / S (cable

channel mode): These two modes

allow you to select a channel by

entering the assigned number for

each aerial broadcasting station or

cable channel.

When Aerial Source is set to Satellite

●

Transponder: Selects the transponder.

●

Scan Mode: Selects either free or all

channels to store.

●

Network Search: Enable / Disable

network search.

●

Signal Quality: Display the current

status of broadcasting signal.

N

Information on a satellite and its

transponder is subject to change

depending on the broadcasting

conditions.

N

When setting is completed, move to

Search. Channel scan is started.

Other Features

Guide Type

Menu

(Depending on the country)

You can select a different type of

Guide.

●

Samsung: Uses the guide programme

by provided Samsung.

●

Rovi On Screen: Uses the guide

Channel

→

Guide Type

→

programme provided by Rovi

International Solutions.

N

ROVI EPG initial setting time can

take a while depending on the region

or broadcast environment.

Genre Selection

Menu

Channel

→

Genre Selection is available when Aerial

is set to Freesat.

●

Genre Selection: Turn the channel-

genre selection feature on or off

for U.K

Genre Selection

→

when using the guide.

Transfer Channel List

Menu

Imports or exports the channel map.

You should connect USB storage to use

this function.

N

●

Import from USB: Import channel list

Channel

→

The PIN input screen appears. Enter

Transfer Channel List

→

the PIN using your remote.

from USB.

●

Export to USB: Export channel list to

USB. This function is available when

USB is connected.

Fine Tune

Menu

(Analogue channels only)

If the reception is clear, you do not

have to fine tune the channel, as this is

done automatically during the search

and store operation. If the signal is

Channel

→

Fine Tune

→

weak or distorted, fine tune the channel

manually. Scroll to the left or right until

the image is clear.

N

Settings are applied to the channel

you’re currently watching.

N

Fine tuned channels that have been

saved are marked with an asterisk “*”

on the right-hand side of the channel

number in the channel banner.

N

To reset the fine-tuning, select the

Reset.

Crosstalk noise reduction

Menu

reduction

(Analogue channels only)

This function reduces diagonal noise in

the picture caused by signal crosstalk

(interference). If your TV picture

displays diagonal noise or distortion

Channel

→

Crosstalk noise

→

when you watch, turn on this function.

(Depending on the country)

Satellite System

Satellite System is available when

Aerial is set to Satellite. Before running

Auto Store, set Satellite System. Then

channel scan is run normally.

N

The PIN input screen appears. Enter

your 4 digit PIN number.

●

Satellite Selection: You can choose the

satellites for this TV.

●

LNB Power: Enables or disables the

power supply for the LNB.

●

LNB Settings: Configures the outdoor

equipment.

Satellite: Selects the satellite for

receiving digital broadcasts.

Transponder: Selects a transponder

from the list or adds a new transponder.

DiSEqC Mode: Selects DiSEqC mode

for the selected LNB.

Lower LNB Oscillators: Sets the LNB

oscillators to a lower frequency.

Upper LNB Oscillators: Sets the LNB

oscillators to a higher frequency.

Tone 22 kHz: Selects the Tone 22 kHz

depending on the LNB type. For a

universal LNB it should be Auto.

Signal Quality: Display the current

status of broadcasting signal.

●

SatCR/Unicable Settings: Configure

single cable installation.

N

This function may not support

depending on the region.

–SatCR/Unicable: Enables or disable

single cable installation support.

–Slot Number: Select the SatCR user

slot number for this receiver.

–Slot Frequency: Enter the appropriate

frequency to receive the signal from

SatCR.

–Detect Slot Frequency: Auto-detect

the signal frequency for the selected

slot number.

–Verify Slot Frequency: Verify that the

frequency entered corresponds to the

selected slot.

●

Positioner Settings: Configures the

aerial positioner.

Positioner: Enables or disables the

positioned control.

Positioner Type: Sets the positioned

type between DiSEqC 1.2 and USALS

(Universal Satellite Automatic Location

System).

–My Longitude: Sets the longitude for

my location.

–My Latitude: Sets the latitude for my

location.

–Satellite Longitude Settings: Sets the

longitude of user defined satellites.

User Mode: Sets the position of satellite

aerial according to each satellite.

If you store the current position of

satellite aerial according to a certain

satellite, when the signal of that

satellite is needed, the satellite aerial

can be moved to pre-populated

position.

–Satellite: Selects the satellite to set

the position for.

–Transponder: Selects a transponder

from the list for signal reception.

–Moving Mode: Selects the movement

mode between discrete and

continuous movement.

–Step Size: Adjusts the step size

degrees for the aerial rotation. Step

Size is available when Moving Mode

is set to Step.

–Go To Stored Position: Rotates the

aerial to the stored satellite position.

–Aerial Position: Adjusts and stores

the aerial position for the selected

satellite.

–Store Current Position: Stores current

position as the selected positioner

limit.

–Signal Quality: Display the current

status of broadcasting signal.

Installer Mode: Sets limits to the scope

of movement of satellite aerial or reset

the position. Generally, installation

guide uses this function.

–Limit Position: Selects the direction

of the positioner Limit.

–Aerial Position: Adjusts and stores

the aerial position for the selected

satellite.

–Store Current Position: Stores the

current position as the selected

positioner Limit.

–Go To Zero: Moves the aerial to the

reference position.

–Reset Positioner Limit: Allows the

aerial to rotate over the full arc.

●

Reset All Settings: All satellite settings

will be reset to the initial values.

Changing the Preset Picture Mode

Picture Mode

Menu

Picture modes apply preset adjustments

to the picture.

N

●

Dynamic


→

When your TV is connected to a PC

Picture Mode

→

via an HDMI to DVI cable, you can

only select Entertain and Standard.

Suitable for a bright room.
