Samsung T27B350, T24B350, T19B300, T22B350 User Manual

Download

Page 1

LED TV MONITOR

(MFM TV)

user manual

TB300 TB350

If you have any questions, please call us at 1-800-SAMSUNG

✎

(1-800-726-7864) for assistance.

Page 2

Figures and illustrations in this User Manual are provided for reference only and may differ from actual product appearance. Product design and speciﬁcations may be changed without notice.

Important Warranty Information Regarding Television Format Viewing

See the warranty card for more information on warranty terms.

✎

Wide screen format TVs (with 16:9 aspect ratios, the ratio of the screen width to height) are primarily designed to view wide screen format full-motion video. The images displayed on them should primarily be in the wide screen 16:9 ratio format, or expanded to ﬁll the screen if your model offers this feature, with the images constantly in motion. Displaying stationary graphics and images on the screen, such as the dark sidebars on non-expanded standard format television video and programming, should be limited to no more than 5% of the total television viewing per week. Additionally, viewing other stationary images and text such as stock market crawls, video game displays, station logos, web sites or computer graphics and patterns, should be limited as described above for all televisions. Displaying stationary images for more than 5% of total viewing time can cause uneven aging of your TV and leave subtle, but permanent burned-in ghost images in the LED picture. To avoid this, vary the programming and images, and primarily display full screen moving images, not stationary patterns or dark bars. On LED models that offer picture sizing features, use these controls to view different formats as a full screen picture. Be careful in the selection of television formats you use for viewing and the amount of time you view them. Uneven LED aging as a result of format selection and use, as well as burned in images, are not covered by your Samsung limited warranty.

Still image warning

Avoid displaying still images (such as jpeg picture ﬁles), still image elements (such as TV channel logos, stock or news bars at the screen bottom etc.), or programs in panorama or 4:3 image format on the screen. Constantly displaying still pictures can cause image burn-in on the screen, which will affect image quality. To reduce risk of this effect, please follow the recommendations below:

• Avoid displaying the same TV channel for long periods.

• Always try to display a full screen image.

• Reduce brightness and contrast to avoid the appearance of after-images.

• Use all TV features designed to reduce image retention and screen burn. Refer to proper user manual section for details.

Securing the Installation Space

Keep the required distances between the product and other objects (e.g. walls) to ensure proper ventilation. Failing to do so may result in ﬁre or a problem with the product due to an increase in the internal temperature of the product.

Installation with a stand. Installation with a wall-mount.

4 inches

Other Warnings

The actual appearance of the TV may differ from the images in this manual, depending on the model. Be careful when you touch the TV. Some parts can be somewhat hot.

4 inches

English

Page 3

Contents

Getting Started

y Safety Precautions .................................................... 4

y List of Features ....................................................... 11

y Accessories ............................................................ 11

y Viewing the Control Panel ....................................... 12

y Viewing the Remote Control .................................... 13

y How to Navigate Menus ..........................................14

y Connecting to an Antenna ...................................... 14

y Plug & Play (Initial Setup) ......................................... 15

Connections

y Connecting to an AV Device .................................... 16

y Connecting to an Audio Device ............................... 17

y Connecting to a PC ................................................ 17

y Changing the Input Source ..................................... 19

Basic Features

y Channel Menu ........................................................ 20

Seeing Channels 20 Using Favorite Channels 20 Memorizing Channels 20 Editing Channels 21 Other Features 21

y Picture Menu .......................................................... 22

Changing the Preset Picture Mode 22 Adjusting Picture Settings 22 Changing the Picture Options 23

y Sound Menu ........................................................... 25

Changing the Preset Sound Mode 25 Adjusting sound settings 25 Sound Settings 25

y Setup Menu ............................................................ 26

Setting the Time 26 Using the Sleep Timer 26 Setting the On/Off Timer 26 Locking Programs 27 Other Features 28

y Support Menu .........................................................30

Advanced Features

y Media Play (USB) .................................................... 31

Connecting a USB Device 31

Other Information

y Attaching a Wall Mount/Desktop Stand ................... 37

y Anti-theft Kensington Lock ...................................... 38

y Troubleshooting ......................................................39

y Storage and Maintenance ....................................... 41

y License ................................................................... 41

y Speciﬁcations ......................................................... 42

TOOLS

Check the Symbol!

This function can be used by pressing the TOOLS

button on the remote control.

Note

Indicates additional information.

English

Page 4

Getting Started

Icons used for safety precautions

Safety Precautions

WARNING

CAUTION

Do not perform.

Must be followed.

CAUTION

RISK OF ELECTRIC SHOCK DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE

COVER (OR BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE.

REFER ALL SERVICING TO QUALIFIED PERSONNEL.

Failing to follow the precautions marked with this sign may result in a serious injury or even a fatality.

Failing to follow the precautions marked with this sign may result in a personal injury or property damage.

This symbol indicates that high voltage is present inside. It is dangerous to make any kind of contact with any internal part of this product.

This symbol alerts you that important literature concerning operation and maintenance has been included with this product.

¦ Power Related

✎

The following images are for your reference and may differ depending on models and countries.

Warning

Avoid using a damaged power cord or plug or a loose power outlet.

y Otherwise, it may result in

electric shock or ﬁre.

Avoid connecting multiple electric appliances to a single wall outlet.

y Otherwise, it may result in ﬁre

due to overheating of the wall outlet.

Avoid plugging in or unplugging the power supply with wet hands.

y Otherwise, it may result in

electric shock.

Make sure to connect the power cord to a grounded wall outlet (for insulation class 1 equipment only).

y Otherwise, it may result in

electric shock or injury.

Plug the power plug in ﬁrmly.

y Otherwise, it may result in ﬁre.

Avoid bending or twisting the power cord excessively and avoid placing heavy objects on the cord.

y Otherwise, it may result in

electric shock or ﬁre due to a damaged power cord.

English

Page 5

Getting Started

Keep the power cord and the product away from a heater.

y Otherwise, it may result in

Caution

Avoid unplugging the power plug while the product is operating.

y Otherwise, it may damage the

When unplugging the power plug from the wall outlet, make sure to hold it by the plug and not by the cord.

y Otherwise, it may result in

¦ Installation Related

electric shock or ﬁ re.

product due to electric shock.

electric shock or ﬁ re.

If the pins of the power plug or the wall outlet are covered in dust, clean it using a dry cloth.

y Otherwise, it may result in ﬁ re.

Make sure to use only the power cord supplied by our company. In addition, do not use the power cord of another electric appliance.

y Otherwise, it may result in

electric shock or ﬁ re.

Connect the power plug to a wall outlet that can be easily reached.

y When a problem occurs

with the product, you must unplug the power plug to cut the power off completely. You cannot cut the power off completely using only the power button on the product.

Warning

Avoid placing burning candles, mosquitorepellentor cigarettes on the product.

y Otherwise, it may result in ﬁ re.

Avoid installing the product in a badly-ventilated location such as inside a bookshelf or closet.

y Otherwise, it may result in ﬁ re

due to internal over-heating.

Avoid installing the product in a location that is unstable or exposed to excessive vibration such as on an unstable or slanted shelf.

y The product may fall and this

may result in damage to the product or injury.

y If you use the product in a

location exposed to excessive vibrations, it may result in a problem with the product or ﬁ re.

Ask an installation engineer or relevant company to install the product onto the wall.

y Otherwise, it may result in

injury.

y Make sure to use the speciﬁ ed

wall mount.

Keep the plastic bags used to pack the product away from children.

y If children place the plastic

bags over their heads, they may suffocate.

Avoid installing the product in a location exposed to dust, moisture (sauna), oil, smoke or water (rain drops) and installing it within a vehicle.

y This may result in electric shock

or ﬁ re.

English

Page 6

Getting Started

SAMSUNG

Caution

Avoid installing the product in a location exposed to direct sunlight and installing the product near a heat source such as a ﬁ replace or heater.

y This may shorten the product

life cycle or cause ﬁ re.

Bend the outdoor antenna cable downwards at the location where it comes in the house so that rainwater does not ﬂ ow in.

y If rainwater enters the product,

it may result in electric shock or ﬁ re.

Do not let the product drop while moving it.

y This may result in a problem

with the product or injury.

When installing the product on a console or shelf, make sure that the front of the product does not protrude out of the console or shelf.

y Otherwise, this may cause the

product to fall off and result in a malfunction or injury.

y Make sure to use a cabinet or

shelf suitable to the size of the product.

If the product is installed in a location where the operating conditions vary considerably, a serious quality problem may occur due to the surrounding environment. In this case, install the product only after consulting one of our service engineers about the matter.

y Places exposed to

microscopic dust, chemicals, too high or low temperature, high humidity, airports or stations where the product is continuously used.

Avoid installing the product where children may reach it.

y If a child touches the product,

the product may fall and this may result in injury.

y Since the front part is heavier,

install the product on a ﬂ at and stable surface.

Install the antenna far away from any high voltage cables.

y If the antenna touches or falls

onto a high voltage cable, it may result in electric shock or ﬁ re.

Do not place the product face down on the ﬂ oor.

y This may damage the panel of

the product.

When putting the product down, handle it gently.

y Otherwise, it may result in a

problem with the product or injury.

English

Page 7

Getting Started

¦ Cleaning Related

Warning

Before cleaning the product, unplug the power cord.

y Otherwise, it may result in

electric shock or ﬁ re.

Caution

Avoid spraying cleansing agent directly onto the product.

y This may result in discoloration

or cracking of the exterior of the product or the panel coming off.

When cleaning the product, do not spray water directly over the product parts.

y Make sure that water does not

enter the product.

y Otherwise, it may result in ﬁ re,

electric shock or a problem with the product.

When cleaning the product, disconnect the power cord and clean the product with the supplied cleaning cloth.

y Avoid using chemicals such as

wax, benzene, alcohol, thinner, mosquitorepellent, fragrance, lubrication or cleansing agent when cleaning the product.

This may result in the exterior being deformed or the print being removed.

¦ Usage Related

Warning

If you can't get the product clean with just the supplied cloth, use a soft, damp cloth with a "monitorexclusive cleansing agent" and wipe the product with it.

y If no monitor-exclusive

cleansing agent is available, dilute a cleansing agent with water at a ratio of 1:10 before cleaning the product.

Since a high voltage runs through the product, never disassemble, repair or modify the product yourself.

y Otherwise, it may result in ﬁ re

or electric shock.

y If the product needs to be

ﬁ xed, contact a service center.

Since the exterior of the product is easily scratched, be sure to use the supplied cleansing cloth.

To move the product, turn the power off and unplug the power cord, the antenna cable and any other wires connected to the product.

y Otherwise, it may result in

electric shock or ﬁ re due to the damaged power cord.

English

Page 8

Getting Started

GAS

100

If the product generates a strange noise, a burning smell, or smoke, unplug the power plug immediately and contact a service center.

y Otherwise, it may result in

electric shock or ﬁre.

If you drop the product or the case is damaged, turn the power off and unplug the power cord. Contact a service center.

y Otherwise, it may result in ﬁre

or electric shock.

When thunder or lighting occurs, unplug the power cord and under no circumstance touch the antenna cable as this is dangerous.

y Otherwise, it may result in

electric shock or ﬁre.

Avoid moving the product by pulling the power cord or antenna cable.

y Otherwise, it may result

in electric shock, ﬁre or a problem with the product due to damage to the cable.

Avoid letting children hang or climb onto the product.

y Otherwise, it may result in the

product falling and this may result in injury or death.

Avoid placing objects such as toys and cookies on top of the product.

y If a child hangs over the

product to grab an object, the object or the product may fall and this may result in injury or even death.

Avoid dropping an object over the product or cause impact to the product.

y Otherwise, it may result in

electric shock or ﬁre.

When a gas leak occurs, do not touch the product or the power plug and ventilate immediately.

y A spark may result in an

explosion or ﬁre.

y During a thunder or lighting

storm, do not touch the power cord or antenna cable.

Avoid lifting up or moving the product by holding only the power cord or signal cable.

y Otherwise, it may result

in electric shock, ﬁre or a problem with the product due to damage to the cable.

Take care not to block the vent by a table cloth or curtain.

y Otherwise, it may result in ﬁre

due to internal overheating.

Avoid using or placing inﬂammable spray or objects near the product.

y This may result in an explosion

or ﬁre.

Avoid inserting metal objects such as a chopsticks, coins or hairpins, or inﬂammable objects into the product (the vents, ports, etc).

y If water or substances enters

the product, turn the power off, unplug the power cord and contact a service center.

y Otherwise, it may result in a

problem with the product, electric shock or ﬁre.

English

Page 9

Getting Started

-_-

Caution

Avoid placing a liquid container such as a vase, ﬂ owerpot, beverage, cosmetics or drugs, or a metal object over the product.

y If water or substances enter

the product, turn the power off, unplug the power cord and contact a service center.

y Otherwise, it may result in a

problem with the product, electric shock or ﬁ re.

Displaying a still image for a long time may create a persistent image or stain on the screen.

y If you do not use the product

for a long time, use the power-saving mode or set the screensaver to the moving picture mode.

Set the appropriate resolution and frequency for the product.

y Otherwise, it may result in eye

strain.

Do not press down hard on the product. The product may become deformed or damaged.

When not using the product for a long time such as leaving your home, unplug the power cord from the wall outlet.

y Otherwise, it may cause dust

accumulation and result in ﬁ re caused by overheating or short circuit or result in an electric shock.

Avoid turning the product upside down or move the product holding only the stand.

y This may cause the product to

fall, resulting in damage to the product or injury.

Watching the product from too close a distance continuously may damage your eyesight.

It is important to give your eyes some rest (5 minutes every hour) when viewing the product screen for long periods of time.

y This will alleviate any eye

strain.

Avoid using a humidiﬁ er or cooker near the product.

y Otherwise, it may result in

electric shock or ﬁ re.

Since the display panel is hot after using it for a long time, do not touch the product.

English

Page 10

Getting Started

Keep the small accessories in a location out of the reach of children.

Avoid placing a heavy object over the product.

y Otherwise, it may result in a

problem with the product or injury.

Be careful that children do not place the batteries in their mouths when removed from the remote control. Place the battery in a location that children or infants cannot reach.

y If children have had the battery

in their mouths, consult your doctor immediately.

Take care when adjusting the angle of the product or the height of the stand.

y If your hand or ﬁnger is caught,

you may be injured.

y If the product is tilted

excessively, the product may fall and this may result in injury.

When using headphones or earphones, do not turn the volume too high.

y Having the sound too loud may

damage your hearing.

When replacing the batteries, insert them with right polarity (+, -).

y Otherwise, the battery may

become damaged or it may cause ﬁre, personal injury or damage due to leakage of the internal liquid.

Use only speciﬁed standard batteries. Do not use new and used batteries together.

y This may cause a battery to

break or leak and may cause ﬁre, injury, or contamination (damage).

The batteries (and rechargeable batteries) are not ordinary refuse and must be returned for recycling purposes. The customer is responsible for returning the used or rechargeable batteries for recycling.

y The customer can return used

or rechargeable batteries to a nearby public recycling center or to a store selling the same type of the battery or rechargeable battery.

English

Page 11

Getting Started

List of Features

y Media Play (USB)

Allows you to play video ﬁles, music ﬁles and pictures saved on a USB device.

Accessories

✎

Please make sure the following items are included with your TV. If any items are missing, contact your dealer.

✎

The items’ colors and shapes may vary depending on the model.

✎

Check that there is no accessory hidden behind packing materials when you open the box.

y Remote Control (AA59-00600A) & Batteries (AAA x 2) y Warranty Card / Safety Guide / Quick Setup Guide y Cleaning Cloth

y Power Cord y User Manual (CD)

D-Sub Cable

(BN39-00244H)

Input Cables (Sold Separately)

HDMI Component Composite (AV) Coaxial (RF)

✎

Check the cable before plug-in

Cable Ports

HDMI

USB

Do not plug cable upside down. Be sure to check before plug-in.

Stereo Cable

(BN39-01286A)

Stand Base Stand Connector

HDMI-DVI

English

Page 12

Getting Started

Viewing the Control Panel

✎

The product color and shape may vary depending on the model.

Control Panel

SOURCE

MENU Displays an on-screen menu, the OSD (on screen display) of your TV’s features.

(Power)

Remote control sensor Aim the remote control towards this spot on the TV.

Power Indicator Blinks and turns off when the power is on and lights up in standby mode.

Standby mode

Your TV enters Standby mode when you turn it off and continues to consume a small amount of electric power. To be safe and to decrease power consumption, do not leave your TV in standby mode for long periods of time (when you are away on a holiday, for example). It is best to unplug the power cord.

Useful Information

]

Caution

Do not press down hard on the product.

y The product may become deformed and damaged.

Toggles between all the available input sources. In the on-screen menu, use this button as you would use the ENTERE button on the remote control.

Adjusts the volume. In the OSD, use the

and r buttons on the remote control.

Changes the channels. In the OSD, use the

and u buttons on the remote control.

Turns the TV on or off.

buttons as you would use the

English

Page 13

Getting Started

Viewing the Remote Control

✎

This is a special remote control for the visually impaired and has Braille points on the Channel and Number "5" button.

Displays and selects the available video sources.

Turns the remote control light on or off. When on, the buttons become illuminated for a moment when pressed. (Using the remote control with this button set to on will reduce the battery usage time.)

Returns to the previous channel.

Cuts off the sound temporarily.

Change channels.

Displays the channel list on the screen.

Turns the TV on and off.

Press to directly access to channels.

Press to select additional channels

(digital) being broadcast by the same

station. For example, to select channel

‘54-3’, press ‘54’, then press ‘-’ and ‘3’.

Adjusts the volume.

Displays the main on-screen menu

SOURCE

MUTE

View the Media Play.

Quickly select frequently used functions.

Selects the on-screen menu items and changes the values seen on the menu.

Returns to the previous menu.

Use these buttons according to the

direction on screen.

P.SIZE: Choose the picture size.

MTS: Press to choose stereo, mono or

Separate Audio Program

(SAP broadcast).

CC: Controls the caption decoder.

Installing batteries (Battery size: AAA)

AA59-00600A

Automatically shuts off the TV at a preset time.

Displays information on the TV screen.

Exits the menu.

Using these buttons in Media Play mode.

✎

NOTE

Use the remote control within

23 feet from the TV.

Bright light may affect the

performance of the remote control. Avoid use when nearby fluorescent lights or neon signs.

The color and shape may vary

depending on the model.

English

Page 14

Getting Started

MEDIA.P

INFO

How to Navigate Menus

Before using the TV, follow the steps below to learn how to navigate the menu and select and adjust different functions.

SLEEP

MEDIA.P

LEEP

TOOLS

TOOL

RETURN

How to Operate the OSD (On Screen Display)

The access steps may differ depending on the selected menu.

MENU The main menu options appear on the screen:

1 2

3 4 5

6 7

ENTER

EXIT

Picture, Sound, Channel, Setup, Input, Application, Support. Select an icon or option with the u or d button.

Press ENTERE to access the sub-menu.

Select the desired submenu with the u or d button.

Adjust the value of an item with the l or r button. The adjustment in the OSD may differ depending on the selected menu.

Press ENTERE to conﬁrm the selection.

Press EXIT.

INFO

EXIT

Connecting to an Antenna

1 MENU button: Displays the main on-screen menu. 2 ENTER

3 RETURN button: Returns to the previous menu. 4 EXIT button: Exits the on-screen menu.

select an item. Conﬁrm the setting.

/ Direction button: Move the cursor and

Connecting the power cord and an antenna or cable connection

✎

When you move or swivel the TV with Antenna cable tightly connected, there is high risk antenna jack on T V will be broken off.

VHF/UHF Antenna

Antenna Cable (Not Supplied)

Power Input

Cable

ANT OUT

English

Page 15

Getting Started

Plug & Play (Initial Setup)

When you turn the TV on for the ﬁrst time, a sequence of on-screen prompts will assist in conﬁguring basic settings. To turn on the TV, press the POWERP button.

✎

Plug & Play is available only when the Source List is set to TV.

✎

Before turning on the TV, make sure you have connected the TV to an antenna or cable connection (p. 14).

Selecting a language

Selecting Store Demo

or Home Use

Selecting search

options for auto tuning

Setting the Clock

Mode

View the HDTV

Connection Guide Enjoy your TV.

Press the the desired OSD (On Screen Display) language.

Press the

Set the Clock Mode automatically or manually.

The connection method for the best HD screen quality is displayed.

Press the ENTER

or d button, then press the ENTERE button. Select

or r button, then press the ENTERE button.

y Select the Home Use mode. Store Demo Mode is for retail

environments.

y To return the unit’s settings from Store Demo to Home Use

(standard): Press the volume button on the TV. When you see the volume OSD, press and hold MENU for 5 sec.

or d button, then press the ENTERE button. Select Air, Cable or Auto.

✎

If you selected Cable, you’ll go to the cable system screen. Use the u or d button to select the correct cable signal format - STD, HRC, or IRC - and then press

ENTERE. Most cable systems use STD. Select the correct cable signal format for

both the Digital and Analog systems.

✎

When done, select Star t, and the press ENTERE.

y Auto: Allows you to select DST (Daylight Saving Time) mode and time zone. y Manual: Allows you to manually set the current date and time (p.26).

button.

If You Want to Rerun Plug & Play...

→ Setup → Plug & Play → ENTER

✎

NOTE

To change the TV’s setting from Store Demo to Home Use when not in Plug & Play, press the volume button on the TV. When you see the volume in the OSD, press and hold MENU for 5 sec.

English

Page 16

Connections

Connecting to an AV Device

Using an HDMI or HDMI/DVI Cable: HD connection (up to 1080p)

We recommend using the HDMI connection for the best quality HD picture. Available devices: DVD, Blu-ray player, HD cable box, HD STB (Set-Top-Box) satellite receiver

HDMI Cable (Not Supplied)

HDMI to DVI Cable

(Not Supplied)

Audio Cable

✎

HDMI IN 1 (DVI), HDMI IN 2, PC/DVI AUDIO IN

TB300 series have only HDMI IN 1 (DVI).

When using an HDMI/DVI cable connection, you must use the HDMI IN 1 (DVI) jack for video. A DVD, Blu-ray

player, HD cable box, or HD STB satellite receiver may require a DVI-HDMI (DVI to HDMI) cable or DVI-HDMI (DVI to HDMI) adapter.

The picture may not display normally (if at all) or the audio may not work if an external device that uses an older

version of HDMI mode is connected to the TV. If such a problem occurs, ask the manufacturer of the external device about the HDMI version and, if out of date, request an upgrade.

Be sure to purchase a cer tified HDMI cable. Otherwise, the picture may not display or a connection error may occur.

For better picture and audio quality, connect to a digital device using an HDMI cable.

An HDMI cable supports digital video and audio signals, and does not require an audio cable.

– To connect the TV to a digital device that does not support HDMI output, use an HDMI/DVI and audio cables.

(Not Supplied)

Device

HDMI OUT

Device

DVI OUT

AUDIO OUT

Using a Component (up to 1080p) or Audio/Video (480i only) Cable

Available devices: DVD, Blu-ray player, cable box, STB satellite receiver, VCR

Audio Cable

(Not Supplied)

R GB

Audio Cable

(Not Supplied)

Green

AUDIO OUT

R-AUDIO-L

✎

When connecting to AV IN, the color of the AV IN [Y/VIDEO] jack (green) will not match the video cable (yellow).

✎

For better picture quality, the Component connection is recommended over the A /V connection.

R GB

RedRed

BlueWhite

COMPONENT OUT

PR PB Y

Component Cable

B G

(Not Supplied)

Device

Video Cable

(Not Supplied)

VIDEO OUT

R W

Red

AUDIO OUT

R-AUDIO-L

Device

White Yellow

English

Page 17

Connections

Connecting to an Audio Device

Using an Optical (Digital) or a Headphone Connection

Only TB350 series have Headphone and Optical interface. Available devices: Digital Audio System, Ampliﬁer, DVD home theater

OPTICAL

✎

DIGITAL AUDIO OUT (OPTICAL)

When you connect a Digital Audio System to the DIGITAL AUDIO OUT (OPTICAL) jack, decrease the volume

of both the TV and the system.

5.1 CH (channel) audio is available when you connect the TV to an external device supporting 5.1 CH.

When the receiver (home theater) is set to on, you can hear sound output from the TV’s optical jack. When the

TV is receiving a DTV signal, the TV will send 5.1 CH sound to the home theater receiver. When the source is a digital component such as a DVD player / Blu-ray player / cable box / STB (Set-Top-Box) satellite receiver and you connected it to the TV via HDMI, you will only hear 2 CH audio from the home theater receiver. If you want to hear 5.1 CH audio, connect the digital audio out jack from your DVD / Blu-ray player / cable box / STB satellite receiver directly to an amplifier or home theater.

✎

HeadphonesH : You can connect your headphones to the headphones output on your set. While the

headphones are connected, the sound from the built-in speakers will be disabled.

Sound function may be restricted when connecting headphones to the TV.

Headphone volume and TV volume are adjusted at the same time.

Connecting to a PC

Using an HDMI cable or an HDMI to DVI cable or a D-sub cable

✎

Your PC may not suppor t an HDMI connection.

HDMI Cable (Not Supplied)

HDMI OUT

HDMI to DVI Cable (Not Supplied)

DVI OUT

AUDIO OUT

D-Sub Cable

Stereo Cable

Display Modes (D-Sub and HDMI/DVI Input)

If the signal from the PC is one of the following standard signal modes, the screen is set automatically. However, if the signal from the PC is not one of the following signal modes, a blank screen may be displayed or only the Power LED may be turned on. Therefore, conﬁgure it as follows referring to the User Manual of the graphics card.

PC OUT

AUDIO OUT

English

Page 18

Connections

1366 X 768 (T19B300 model only)

Display Mode Horizontal

Mode Resolution

IBM

VESA DMT

MAC VESA DMT VESA DMT VESA DMT VESA DMT VESA DMT

1920 X 1080

Mode Resolution

IBM

VESA DMT

MAC VESA DMT VESA DMT VESA DMT VESA DMT VESA DMT

MAC VESA DMT VESA DMT VESA DMT VESA DMT

MAC VESA DMT VESA DMT VESA DMT VESA DMT VESA DMT VESA DMT VESA DMT VESA DMT VESA DMT

✎✎

NOTE

The interlace mode is not supported.

The set may operate abnormally if you select a non-standard video format.

Separate and Composite modes are supported. SOG(Sync On Green) is not suppor ted.

✎

If there is no power cut-off switch, the power consumption is “0” only when the power cord is disconnected.

✎

DPM(Display Power Management) Function does not work if you used in connection with the HDMI port of this product.

720 x 400 70Hz 31.469 70.087 28.322 -/+

640 x 480 60Hz 31.469 59.940 25.175 -/-

640 x 480 67Hz 35.000 66.667 30.240 -/-

640 x 480 72Hz 37.861 72.809 31.500 -/-

640 x 480 75Hz 37.500 75.000 31.500 -/-

800 x 600 60Hz 37.879 60.317 40.000 +/+

800 x 600 72Hz 48.077 72.188 50.000 +/+

800 x 600 75Hz 46.875 75.000 49.500 +/+

832 x 624 75Hz 49.726 74.551 57.284 -/-

1024 x 768 60Hz 48.363 60.004 65.000 -/-

1024 x 768 70Hz 56.476 70.069 75.000 -/-

1024 x 768 75Hz 60.023 75.029 78.750 +/+

1280 x 720 60Hz 45.000 60.000 74.250 +/+

1366 x 768 60Hz 47.712 59.790 85.500 +/+

Display Mode Horizontal

720 x 400 70Hz 31.469 70.087 28.322 -/+

640 x 480 60Hz 31.469 59.940 25.175 -/-

640 x 480 67Hz 35.000 66.667 30.240 -/-

640 x 480 72Hz 37.861 72.809 31.500 -/-

640 x 480 75Hz 37.500 75.000 31.500 -/-

800 x 600 60Hz 37.879 60.317 40.000 +/+

800 x 600 72Hz 48.077 72.188 50.000 +/+

800 x 600 75Hz 46.875 75.000 49.500 +/+

832 x 624 75Hz 49.726 74.551 57.284 -/-

1024 x 768 60Hz 48.363 60.004 65.000 -/-

1024 x 768 70Hz 56.476 70.069 75.000 -/-

1024 x 768 75Hz 60.023 75.029 78.750 +/+

1152 x 864 75Hz 67.500 75.000 108.000 +/+

1152 x 870 75Hz 68.681 75.062 100.000 -/-

1280 x 720 60Hz 45.000 60.000 74.250 +/+

1280 x 800 60Hz 49.702 59.810 83.500 -/+

1280 x 1024 60Hz 63.981 60.020 108.000 +/+

1280 x 1024 75Hz 79.976 75.025 135.000 +/+

1366 x 768 60Hz 47.712 59.790 85.500 +/+

1440 x 900 60Hz 55.935 59.887 106.500 -/+

1600 x 900RB 60Hz 60.000 60.000 108.000 +/+

1680 x 1050 60Hz 65.290 59.954 146.250 -/+

1920 x 1080 60Hz 67.500 60.000 148.500 +/+

Frequency (kHz)

Vertical

Frequency (Hz)

Vertical

Frequency(Hz)

Pixel Clock

(MHz)

Pixel Clock

(MHz)

Sync Polarity

(H/V)

English

Page 19

Connections

Changing the Input Source

Source List

Use to select TV or an external input sources such as a DVD / Blu-ray player / cable box / STB satellite receiver.

ENTER

1. Press the SOURCE button on your remote.

2. Select a desired external input source.

→ Input → Source List →

✎■ TV / PC / AV / Component / HDMI1/DVI / HDMI2

✎

TB300 series have only HDMI IN 1 (DVI).

✎

You can only choose external devices that are connected to the set. In the Source List,

connected inputs will be highlighted.

SOURCE

Edit Name

MENUm → Input → Edit Name → ENTER

In the Source List, press the TOOLST button, and then you can set an external input sources name you want.

✎■ VCR / DVD / Cable STB / Satellite STB / PVR STB

/ AV Receiver / Game / Camcorder / PC / DVI PC / DVI / TV / IPTV / Blu-ray / HD DVD / DMA: Name the

device connected to the input jacks to make your input source selection easier.

✎

If you have connected a PC to the HDMI IN 1 (DVI) port with an HDMI cable, select PC under Edit Name to enter a device name.

✎

If you have connected a PC to the HDMI IN 1 (DVI) port with an HDMI to DVI cable, select DVI PC under Edit Name to enter a device name.

✎

If you connected an AV device to the HDMI IN 1 (DVI) port with an HDMI to DVI cable, select DVI under Edit Name to enter a device name.

Information

You can see detailed information about the selected external device.

English

Page 20

Basic FeaturesBasic Features

Channel Menu

¦ Seeing Channels

Channel List

MENUm → Channel → Channel List → ENTER

Select a channel in the All Channels, Added Channels, Favorite or Programmed screen by

pressing the ▲ / ▼ and ENTERE buttons. Then you can watch the selected channel.

Added Channels

6 Air 6-1 * TV #6

7 Air

8 Air 9 Air

9-1 * TV #9 10 Air

10-1 * TV #10 11-1 * TV #11

Air B Zoom Select

■ All Channels: Shows all currently available

channels.

Added Channels: Shows all added channels.

■

Favorite: Shows all favorite channels.

■

Programmed: Shows all currently reserved

programs.

✎

Using the color buttons with the Channel List

Green (Zoom): Enlarges or shrinks a channel

number.

Yellow (Select): Selects multiple channel lists.

Select desired channels and press the Yellow button to set all the selected channels at the same time. The

mark appears to the left of the selected channels.

(Tools): Displays the Channel List option menu.

(The options menus may dif fer depending on the situation.)

Channel Status Display Icons

Icons Operations

A channel selected.

A channel set as a Favorite.

A reserved Program.

Tools

¦ Using Favorite Channels

MENUm → Channel → Channel List → ENTER

Add to Favorite / Delete from Favorite

Set channels you watch frequently as Favorites.

1. Select a channel and press the TOOLS button.

2. Add or delete a the channel using the Add to Favorite or Delete from Favorite menu respectively.

6 Air

Added Channels

To show all Favorite channels, click on the button shown on the right.

6-1 * TV #6

7 Air

8 Air 9 Air

9-1 * TV #9 10 Air

10-1 * TV #10 11-1 * TV #11

Air B Zoom Select

Delete

Add to Favorite Timer Viewing Channel Name Edit Select All Auto Program

Tools

¦ Memorizing Channels

MENUm → Channel → ENTER

Antenna (Air / Cable)

Before your television can begin memorizing the available channels, you must specify the type of signal source that is connected to the TV (i.e. an Air or a Cable system).

Auto Program

Automatically registers available Air / Cable channels to the TV.

■ Air: Air antenna signal.

■ Cable: Cable antenna signal.

■ Auto: Air and Cable antenna.

English

Page 21

Basic Features

✎

NOTE

When selecting the Cable T V system: STD, HRC

and IRC identify various types of cable T V systems. Contact your local cable company to identify the type of cable system that exists in your particular area. At this point, the signal source has been selected.

After all the available channels are stored, it starts

to remove scrambled channels. The Auto program menu then reappears.

How to Stop Auto Programming

1. Press the ENTER

2. A message will ask Stop Auto Program?. Select Yes by

pressing the ◄ or ► button.

3. Press the ENTER

¦ Editing Channels

MENUm → Channel → Channel List → ENTER

Channel Name Edit

1. Select a channel and press the TOOLS button.

2. Edit the channel name using the Channel Name Edit

menu.

■ Channel Name Edit (analog channels only): Assign your

own channel name.

¦ Other Features

MENUm → Channel → ENTER

Clear Scrambled Channel

This function is used to ﬁlter out scrambled channels after Auto Program is completed. This process may take up to 20~30 minutes.

How to Stop Searching Scrambled Channels

1. Press the ENTER

2. Press the ◄ button to select Yes.

3. Press the ENTER

✎

This function is only available in Cable mode.

button.

button to select Stop.

button.

Channel List

MENUm → Channel → Channel List → ENTER

Channel List Option Menu

Set each channel using the Channel List menu options (Add / Delete, Timer Viewing, Select All / Deselect All). Option

menu items may differ depending on the channel status.

1. Select a channel and press the TOOLS button.

2. Select a function and change its settings.

■ Add / Delete: Delete or add a channel to display the

channels you want.

✎

NOTE

All deleted channels will be shown on the

All Channels menu.

A gray-colored channel indicates the channel

has been deleted.

The Add menu only appears for deleted

channels.

Delete a channel from the Added Channels or

Favorite menu in the same manner.

■ Timer Viewing: You can set a desired channel to be

displayed automatically at the reserved time. Set the current time ﬁrst to use this function.

1. Press the ◄ / ► / ▲ / ▼ buttons to select the

desired channel in Channel List.

2. Press the TOOLS button, then select Timer

Viewing.

3. Scroll up or down to adjust the settings in the box,

or use the numeric buttons on your remote to enter the date and time.

✎

If you selected Once, Every Week or Everyday in Repeat, you can enter the date you want.

4. Press the ENTER

✎

NOTE

Only memorized channels can be reserved.

Reserved programs will be displayed in the

Programmed menu.

When a digital channel is selected, press the ►

button to view the digital program.

■ Select All: Select all the channels in the channel list.

■ Deselect All: Deselect all the selected channels.

✎

You can only select Deselect All when one or more channels are selected.

button.

English

Page 22

Basic Features

Programmed

(in Channel List) You can view, modify or delete a show you have reserved

to watch. Programmed timer viewing is displayed here. Highlight a program and press the TOOLS button to display Options.

■ Change Info: Change a show you have reserved to

watch. Begin with step 3 of “Timer Viewing” above.

■ Cancel Schedules: Cancel a show you have reserved

to watch.

✎

This deletes the highlighted or selected program(s).

■ Information: Display a show you have reserved

to watch. (You can also change the reservation Information.)

✎

Alternatively, you can view Information by highlighting a program and pressing the

ENTERE button.

■ Select All / Deselect All: Select or deselect all reserved

programs.

Channel Mode

Change the channel mode directly between Added Channels and Favorite Channels.

✎

The Favorite Channels is enabled only when you set

Add to Favorite.

Fine Tune

(analog channels only) If the reception is clear, you do not have to ﬁne tune the

channel, as this is done automatically during the search and store operation. If the signal is weak or distorted, ﬁne tune the channel manually. Scroll to the left or right until the image is clear.

✎

Settings are applied to the channel you're currently watching.

✎

Fine tuned channels that have been saved are marked with an asterisk “*” on the right-hand side of the channel number in the channel banner.

✎

To reset the fine-tuning, select Reset.

Picture Menu

¦ Changing the Preset Picture Mode

MENUm → Picture → Mode → ENTER

Mode

Picture modes apply preset adjustments to the picture. Select a mode using the up and down arrow keys, and then press the ENTER

✎

When connecting a PC, you can only make changes to the Enter tain or Standard.

■ Dynamic: Suitable for a bright room.

■ Standard: Suitable for a normal environment.

■ Movie: Suitable for watching movies in a dark room.

■ Entertain: Suitable for watching movies and games.

✎

It is only available in PC mode.

button.

¦ Adjusting Picture Settings

MENUm → Picture → ENTER

Samsung MagicAngle

This feature allows you to see optimal screen quality according to your viewing position. When viewing the screen at an angle from below, above or the side of the product, by setting the appropriate mode for each position you can obtain a similar picture quality as viewing the screen directly from the front.

y Off: Select when viewing from the front position. y Lean back mode: Select when viewing from a slightly

lower position.

y Standing Mode: Select when viewing from the upper

position.

y Mode (1-10): Determines the amount of adjustment.

Numbers closer to 10 are best for lower viewing positions.

✎

When Samsung MagicAngle is set to Lean back

mode or Standing Mode, Gamma is not available.

Backlight / Contrast / Brightness / Sharpness / Color / Tint (G/R)

Your television has several setting options for picture quality control.

✎

NOTE

When you make changes to Backlight, Contrast,

Brightness, Sharpness, Color or Tint (G/R), the OSD will be adjusted accordingly.

When connecting a PC, you can only make

changes to Backlight, Contrast, Brightness and Sharpness.

English

Page 23

Basic Features

Settings can be adjusted and stored for each

external device connected to the set.

Lowering picture brightness reduces power

consumption.

Auto Adjustment

Frequency values/ position and ﬁne tune are adjusted automatically.

✎

It's only available in PC mode.

Screen

You can increase the picture quality by adjusting the frequency and performing ﬁne-tuning

✎

It's only available in PC mode.

y Coarse: Adjusts the frequency when vertical noise

appears on the screen(0-100).

y Fine: Adjusts the screen to be clearer(0-100). y PC Position: Optimizes the horizontal and vertical

picture position of the TV.

y Image Reset: Resets the PC settings to the default

values.

¦ Changing the Picture Options

Advanced Settings

MENUm → Picture → Advanced Settings → ENTER

Advance Settings are available in the Standard and Movie

modes. When connecting a PC, you can only make changes to Gamma and White Balance. They are not available when you are watching a digital channel.

To use, select an option using the up and down arrow keys, and then press ENTER value or setting, and then press ENTERE.

. Use the arrow keys to change a

Advanced Settings

Color Space : Native ►

White Balance

Gamma : 0

Dynamic Contrast : High

Black Tone : Off

Flesh Tone : 0

Motion Lighting : On

Move

Enter

■ Color Space (Auto / Native): Adjusts the range of

colors (the color gamut) available to create images.

■ White Balance: Adjusts the red, green, and blue

brightness so that the brightest point of a picture becomes white.

Return

R-Offset / G-Offset / B-Offset: Adjust each color's (red, green, blue) darkness.

R-Gain / G-Gain / B-Gain: Adjust each color's (red, green, blue) brightness.

Reset: Resets the White Balance to it's default settings.

■ Gamma: Adjust the primary color intensity.

■ Dynamic Contrast (Off / Low / Medium / High): Adjust

the screen contrast.

■ Black Tone (Off / Dark / Darker / Darkest): Select the

black level to adjust the screen depth.

■ Flesh Tone: Emphasize pink “Flesh Tone.”

■ Motion Lighting (Off / On): Reduces power

consumption by reducing screen brightness when the picture on the screen is in motion.

Picture Options

MENUm → Picture → Picture Options → ENTER

Select an option using the up and down arrow keys, and then press ENTERE. Use the arrow keys to change the setting, and then press ENTERE.

✎

When connecting a PC, you can only make changes to the Color Tone, Size.

Picture Options

Color Tone : Standard ►

Size : 16:9

Digital Noise Filter : Auto

HDMI Black Level : Normal

Film Mode : Off

Move

Enter

■ Color Tone (Cool / Standard / Warm1 / Warm2)

✎

Warm1 or Warm2 will be deactivated when the picture mode is Dynamic.

✎

You can adjust and store settings for each ex ternal device you have connected to an input on the TV.

■ Size: If you have a cable box or satellite

receiver, it may have its own set of screen sizes as well. However, we highly recommend you use your set's 16:9 mode most of the time.

16:9 : Sets the picture to 16:9 wide mode. Zoom1: Use for moderate magniﬁcation.

Cuts off the top and sides. Zoom2: Use for a stronger magniﬁcation.

Return

P.SIZE

English

Page 24

Basic Features

Wide Fit: Enlarges the aspect ratio of the picture to ﬁt the entire screen.

✎

Available with HD 1080i / 720p signals in 16:9 mode.

4:3 : Sets the picture to basic (4:3) mode.

✎

Do not watch in 4:3 format for a long time. Traces of borders displayed on the left, right and center of the screen may cause image retention(screen burn) which are not covered by the warranty.

Screen Fit: Displays the full image without any cut-off when HDMI (720p / 1080i / 1080p) or Component (1080i / 1080p) signals are inputted.

✎

NOTE

After selecting Zoom1, Zoom2 or Wide Fit:

1. Press the ► button to select Position.

2. Press the ENTER

3. Press the ▲ or ▼ button to move the picture up

or down.

4. Press the ENTER

✎

If you want to reset the pictures to its original position, select Reset, and then press

ENTERE. The picture will be reset to its

default position.

After selecting Screen Fit in HDMI (1080i/1080p) or

Component (1080i/1080p) mode, you may need to center the picture:

1. Press the ◄ or ► button to select Position.

2. Press the ENTER

3. Press the ▲, ▼, ◄ or ► button to move the

picture.

4. Press the ENTER

✎

If you want to reset the pictures to its original position, select Reset, and then press

ENTERE. The picture will be reset to its

default position.

HD (High Definition): 16:9 - 1080i/1080p (1920x1080),

720p (1280x720)

Settings can be adjusted and stored for each

external device you have connected to an input on the TV.

Input Source Picture Size

ATV, AV, Component (480i, 480p) DTV(1080i), Component (1080i, 1080p), HDMI (720p, 1080i, 1080p)

button.

16:9, Zoom1, Zoom2, 4:3

16:9, 4:3, Wide Fit, Screen Fit

Maintaining the Correct Posture when Using this Product

Maintain the correct posture when using this product.

y Straighten your back. y Keep a distance of 45~50 cm (15~19 inches) from your

eyes to the screen. Look down at the screen and face the screen forwards.

y Adjust the angle of the product so that light is not

reﬂected onto the screen.

y Keep your elbow at a right angle and keep your arm

level with the back of your hand.

y Keep your elbow at a right angle. y Place your heels ﬂat on the ground while keeping your

knees at an angle of 90 degrees or higher and maintain the position of your arm so that your arm is below your heart.

■ Digital Noise Filter (Off / Low / Medium / High / Auto): If the broadcast signal received by your set is weak, you can activate the Digital Noise Filter feature to reduce any static and ghosting that may appear on the screen.

✎

When the signal is weak, try other options until the best picture is displayed.

■ HDMI Black Level (Low / Normal): Lets you select the black level on the screen to adjust the screen depth.

✎

Available only in HDMI mode (RGB signal).

■ Film Mode (Off / Auto): Sets the TV to automatically sense and process ﬁlm signals from all sources and adjusts the picture for optimum quality.

✎

Available in TV, AV, COMPONENT (480i / 1080i) and HDMI (1080i).

Picture Reset (Reset Picture Mode / Cancel)

Resets your current picture mode to its default settings.

English

Page 25

Basic Features

Sound Menu

¦ Changing the Preset Sound Mode

MENUm → Sound → Mode → ENTER

Mode

■ Standard: Selects the normal sound mode.

■ Music: Emphasizes music over voices.

■ Movie: Provides the best sound for movies.

■ Clear Voice: Emphasizes voices over other sounds.

■ Amplify: Increase the intensity of high-frequency sound

to allow a better listening experience for the hearing impaired.

¦ Adjusting sound settings

MENUm → Sound → Equalizer → ENTER

Equalizer

Adjusts the sound mode.

■ Balance L/R: Adjusts the balance between the right and

left speaker.

■ 100Hz / 300Hz / 1kHz / 3kHz / 10kHz (Bandwidth

Adjustment): Adjusts the level of speciﬁc bandwidth frequencies.

■ Reset: Resets the equalizer to its default settings.

¦ Sound Settings

MENUm → Sound → ENTER

SRS TruSurround HD (Off / On)

(standard sound mode only) This function provides a virtual 5.1 channel surround sound

experience through a pair of speakers using HRTF (Head Related Transfer Function) technology.

Preferred Language

(digital channels only) Digital-TV broadcasts are capable of simultaneous

transmission of many audio tracks (for example, simultaneous translations of the program into foreign languages).

✎

You can only select a language among the ones being broadcasted.

Multi-Track Sound (MTS)

(analog channels only)

■ Mono: Choose for channels that are broadcasting in mono or if you are having difﬁculty receiving a stereo signal.

■ Stereo: Choose for channels that are broadcasting in stereo.

■ SAP: Choose to listen to the Separate Audio Program, which is usually a foreign-language translation.

✎

Depending on the particular program being broadcast, you can listen to Mono, Stereo or SAP.

MTS

Auto Volume (Off / On)

To equalize the volume level on each channel, set to On.

SPDIF Output

✎

Only for TB350 series.

SPDIF (Sony Philips Digital InterFace) is used to provide digital sound, reducing interference going to speakers and various digital devices such as a DVD player.

Speaker Select

✎

Only for TB350 series.

y Speaker Select (External Speaker / TV Speaker): A

sound echo may occur due to a difference in decoding speed between the main speaker and the audio receiver. In this case, set the TV to External Speaker.

✎

When Speaker Select is set to External Speaker, the volume and MUTE buttons will not operate and the sound settings will be limited.

✎

When Speaker Select is set to External

Speaker.

TV Speaker: Off, External Speaker: On

✎

When Speaker Select is set to TV Speaker.

TV Speaker: On, External Speaker: On

✎

If there is no video signal, both speakers will be mute.

Sound Reset (Reset All / Cancel)

Reset all sound settings to the factory defaults.

English

Page 26

Basic Features

Setup Menu

¦ Setting the Time

MENUm → Setup → Time → ENTER

Time

■ Clock: Setting the clock is for using various timer

features of the TV.

✎

The current time will appear every time you press the INFO button.

✎

If you disconnect the power cord, you have to set the clock again.

Clock Mode (Auto / Manual)

– Auto: Set the current time automatically using the

time from a digital channel.

✎

The antenna must be connected in order to set the time automatically.

– Manual: Set the current time manually.

✎

Depending on the broadcast station and signal, the auto time set up may not be correct. In this case, set the time manually.

Clock Set: Set the Month, Day, Year, Hour, Minute and am/pm manually.

✎

Available only when Clock Mode is set to Manual.

✎

You can set the Month, Day, Year, Hour and Minute directly by pressing the number buttons on the remote control.

Time Zone: Select your time zone.

✎

This function is only available when the

Clock Mode is set to Auto.

DST (Off / On / Auto): Switches the Daylight Saving

Time function on or off.

✎

This function is only available when the

Clock Mode is set to Auto.

¦ Using the Sleep Timer

MENUm → Setup → Time → Sleep Timer → ENTER

■ Sleep Timer after a preset period of time. (30, 60, 90, 120, 150 and 180 minutes).

✎

To cancel the Sleep Timer, select Off.

: Automatically shuts off the TV

¦ Setting the On/Off Timer

MENUm → Setup → Time → Timer 1 → ENTER

You can set the TV to turn on automatically at a preset time.

■ Timer 1 / Timer 2 / Timer 3: Three different on / off timer settings can be made. You must set the clock ﬁrst.

On Time

▲

12 00 am Inactivate

▼

Off Time

12 00 am Inactivate

Volume Contents

10 TV Air 3

Repeat

Once

On Time / Off Time: Set the hour, minute, and activate / inactivate. (To activate the timer with the setting you’ve chosen, set to Activate.)

Volume: Set the desired volume level. Contents: Select a content to be played when the TV

is turned on automatically. (USB can be selected only when a USB device is connected to the TV.)

– TV/USB: Select TV or USB. (Make sure that an USB

device is connected to your TV.)

– Antenna: You can view an antenna source. – Channel: Select the desired channel. – Music: Select the folder containing MP3 ﬁles on the

USB device.

– Photo: Select the folder containing JPEG ﬁles on the

USB device.

Timer 1

Sun Mon Tue Wed Thu Fri Sat

L Move

Adjust

Enter

Return

English

Page 27

Basic Features

✎

NOTE

If there is no music file on the USB device or the

folder containing a music file is not selected, the Timer function does not operate correctly.

When there is only one photo file in the USB,

the Slide Show will not play.

If a folder name is too long, the folder cannot be

selected.

Each USB you use is assigned its own folder.

When using more than one of the same type of USB, make sure the folders assigned to each USB have different names.

Repeat: Select Once, Everyday, Mon~Fri, Mon~Sat, Sat~Sun or Manual to set at you convenience. If you

select Manual, you can set up the day you want to activate the timer.

✎

The c mark indicates the day is selected.

✎

Auto Power Off (available only when the TV is turned on by the Timer): The TV will be automatically turned off after 3 hours of being left idle to prevent overheating.

¦ Locking Programs

MENUm → Setup → Program Rating Lock → ENTER

Program Rating Lock

The PIN input screen appears, Enter your 4 digit PIN number. The Program Rating Lock feature automatically locks out

programs that are deemed inappropriate for children. The user must enter a PIN (personal identiﬁcation number) before any of the Program Rating Lock restrictions are set up or changed.

✎

NOTE

Program Rating Lock is not available in HDMI,

Component, PC.

The default PIN number of a new TV set is “0-0-0-0”.

Allow All: Press to unlock all TV ratings.

Block All: Press to lock all TV ratings.

■ Program Rating Lock (Off / On): You can block rated TV Programs.

TV Parental Guidelines: You can block TV programs depending on their rating. This function allows you to control what your children are watching.

– TV-Y: Young children / TV-Y7: Children 7 and over /

TV-G: General audience / TV-PG: Parental guidance / TV-14: Viewers 14 and over / TV-MA: Mature audience

– ALL: Lock all TV ratings. / FV: Fantasy violence /

V: Violence / S: Sexual situation / L: Adult Language / D: Sexually Suggestive Dialog

✎

The Program Rating Lock will automatically block certain categories dealing with more sensitive material. For example, if you block the TV-Y category, then TV-Y7 will automatically be blocked. Similarly, if you block the TV-G category, then all the categories in the young adult group will be blocked (TV-G, TV-PG, TV-14 and TV-MA). The sub-ratings (D, L, S, V) work similarly. So, if you block the L sub-rating in TV-PG, then the L sub-ratings in TV-14 and

TV-MA will automatically be blocked.

MPAA Rating: You can block movies depending on

their MPAA rating. The Motion Picture Association of America(MPAA) has implemented a rating system that provides parents or guardians with advanced information on which ﬁlms are appropriate for children.

– G: General audience (no restrictions). / PG: Parental

guidance suggested. / PG-13: Parents strongly cautioned. / R: Restricted. Children under 17 should be accompanied by an adult. / NC-17: No children under age 17. / X: Adults only. / NR: Not rated.

✎

The Program Rating Lock will automatically block any category that deals with more sensitive material. For example, if you block the PG-13 category, then R, NC-17 and X will automatically be blocked.

Canadian English: You can block TV programs depending on their Anglophone Canadian ratings.

– C: Programming intended for children under age 8. /

C8+: Programming generally considered acceptable for children 8 years and over to watch on their own. / G: General programming, suitable for all audiences. / PG: Parental Guidance. / 14+: Programming contains themes or content which may not be suitable for viewers under the age of 14. / 18+: Adult programming.

✎

The Program Rating Lock will automatically block any category that deals with more sensitive material. For example, if you block the G category, then PG, 14+ and 18+ will automatically be blocked.

English

Page 28

Basic Features

Canadian French: You can block TV programs depending on their French Canadian rating.

– G: General / 8 ans+: Programming generally

considered acceptable for children 8 years and over to watch on their own. / 13 ans+: Programming may not be suitable for children under the age of 13. / 16 ans+: Programming is not suitable for children under the age of 16. / 18 ans+: Programming restricted to adults.

✎

The Program Rating Lock will automatically block any category that deals with more sensitive material. For example, if you block the

8 ans+ category, then 13 ans+, 16 ans+ and 18 ans+ will automatically be blocked also.

Downloadable U.S. Rating: Parental restriction

information can be used while watching DTV channels.

✎

NOTE

If information is not downloaded from the

broadcasting station, the Downloadable U.S. Rating menu is deactivated.

Parental restriction information is automatically

downloaded while watching DTV channels. It may take several seconds.

The Downloadable U.S. Rating menu

is available for use af ter information is downloaded from the broadcasting station. However, depending on the information from the broadcasting station, it may not be available for use.

Parental restriction levels differ depending on

the broadcasting station. The default menu name and Downloadable US Rating change depending on the downloaded information.

Even if you set the on-screen display to another

language, the Downloadable U.S. Rating menu will appear in English only.

The rating will automatically block certain

categories that deal with more sensitive material.

The rating titles (For example: Humor Level..etc)

and TV ratings (For example: DH, MH, H..etc) may differ depending on the broadcasting station.

■ Change PIN: The Change PIN screen will appear. Choose any 4 digits for your PIN and enter it in Enter

New PIN. Re-enter the same 4 digits in Conﬁrm New PIN. When the Conﬁrm screen disappears, select the OK. The TV has memorized your new PIN.

How to watch a restricted channel

If the TV is tuned to a restricted channel, the Program Rating Lock will block it. The screen will go blank and the

following message will appear: "This channel is blocked by a Parental Lock. Please enter the

PIN to unblock."

✎

If you forget the PIN code, press the remote control buttons in the following sequence in Standby mode, which resets the PIN to “0-0-0-0”: POWER (off) →

MUTE → 8 → 2 → 4 → POWER(on).

¦ Other Features

MENUm → Setup → ENTER

Language

Set the menu language.

1. Select Language and press the ENTER

2. Choose desired language and press the ENTER

button.

✎

Choose between English, Español and Français.

button.

Caption

(On-Screen Text Messages)

■ Caption (Off / On): You can switch the

caption function on or off. If captions are not available, they will not be displayed on the screen.

✎

The Caption feature doesn’t work in Component, HDMI and PC modes.

■ Caption Mode: You can select the

desired caption mode.

✎

The availability of captions depends on the program being broadcast.

Default / CC1~CC4 / Text1~Text4: (analog channels only) The Analog Caption function operates in either analog TV channel mode or when a signal is supplied from an external device to the TV. (Depending on the broadcasting signal, the Analog Caption function may or may not work with digital channels.)

Default / Service1~Service6 / CC1~CC4 / Text1~Text4: (digital channels only) The Digital Captions

function works with digital channels.

✎

Service1~6 may not be available in digital caption mode depending on the broadcast.

English

Page 29

Basic Features

■ Digital Caption Options: (digital channels only)

Size: Options include Default, Small, Standard and

Large. The default is Standard. Font Style: Options include Default and Styles 0 to 7.

The default is Style 0. Foreground Color: Options include Default, White,

Black, Red, Green, Blue, Yellow, Magenta and Cyan. You can change the color of the letter. The default is White.

Background Color: Options include Default, White, Black, Red, Green, Blue, Yellow, Magenta and Cyan. You can change the background color of the caption. The default is Black.

Foreground Opacity: This adjusts the opacity of text. Options include Default, Transparent, Translucent, Solid and Flashing.

Background Opacity: This adjusts the opacity of the caption background. Options include Default, Transparent, Translucent, Solid and Flashing.

Return to Default: This option sets each Size, Font Style, Foreground Color, Background Color, Foreground Opacity and Background Opacity to its default.

✎

NOTE

Digital Caption Options are available only

when Default and Service1 ~ Service6 can be selected in Caption Mode.

The availability of captions depends on the

program being broadcasted.

The Default setting follows the standards set by

the broadcaster.

The Foreground and Background cannot be set

to have the same color.

You cannot set both the Foreground Opacity

and the Background Opacity to Transparent.

Game Mode (Off / On)

When connecting to a game console such as PlayStation™ or Xbox™, you can enjoy a more realistic gaming experience by selecting the game mode.

✎

NOTE

Precautions and limitations for game mode.

– To disconnect the game console and connect

another external device, set Game Mode to Off in the setup menu.

– If you display the TV menu in Game Mode, the

screen shakes slightly.

Game Mode is not available when the input source

is set to TV or PC.

After connecting the game console, set Game Mode

to On. Unfortunately, you may notice reduced picture quality.

If Game Mode is On:

– Picture Mode is set to Standard and Sound

Mode is set to Movie.

– Equalizer is not available.

Melody (Off / Low / Medium / High)

Set so that a melody plays when the TV is turned on or off.

Auto Protection Time

y Off / 2 hours / 4 hours / 8 hours / 10 hours: If the

screen remains idle with a still image for a certain period of time deﬁned by the user, the screen saver is activated to prevent the formation of ghost images on

Eco Solution

y Energy Saving (Off / Low / Medium / High / Picture

Off) : This adjusts the brightness of the TV in order to

reduce power consumption. If you select Picture Off, the screen is turned off, but the sound remains on.Press any button except volume button to turn on the screen.

y No-Signal Power Off (Off / 15 min / 30 min / 60 min):

To avoid unnecessary energy consumption, set how long you want the TV to remain on if it’s not receiving a signal.

✎

Disabled when a PC connected to the HDMI1/ DVI port is in power-saving mode.

y Auto Power Off (Off / On): Saves power by turning TV

off automatically when no user operation is received for 4 hours.

English

Page 30

Basic Features

Support Menu

MENUm → Support → ENTER

Self Diagnosis

✎

Self Diagnostic might take few seconds, this is par t of the normal operation of the TV.

■ Picture Test: Use to check for picture problems.

Yes: If the test pattern does not appear or there is noise in the test pattern, select Yes. There may be a problem with the set. Contact Samsung’s Call Center for assistance (1-800-SAMSUNG).

No: If the test pattern is properly displayed, select No. There may be a problem with your external equipment. Please check your connections. If the problem persists, refer to the external device’s user manual.

■ Sound Test: Use the built-in melody sound to check for sound problems.

Yes: If you can hear sound only from one speaker or not at all during the sound test, select Yes. There may be a problem with the set. Contact Samsung’s Call Center for assistance (1-800-SAMSUNG).

No: If you can hear sound from the speakers, select No. There may be a problem with your external equipment. Please check your connections. If the problem persists, refer to the external device’s user manual.

■ Signal Strength: (Digital channels only) An HD channel’s reception quality is either perfect or the channels are unavailable. Adjust your antenna to increase signal strength.

■ Reset: All the settings will return to factory defaults.

Software Upgrade

Samsung may offer upgrades for your TV’s ﬁrmware in the future. Please visit Samsung.com or contact the Samsung call center at 1-800-SAMSUNG (726-7864) to receive information about downloading upgrades and using a USB drive. Upgrades will be possible by connecting a USB drive to the USB port.

✎

When software is upgraded, video and audio settings you have made will return to their default (factory) settings.

✎

We recommend you write down your settings so that you can easily reset them after the upgrade.

Side Panel

USB Drive

HD Connection Guide

Refer to this information when connecting external devices to the TV.

Contact Samsung

View this information when your TV does not work properly or when you want to upgrade the software. You can ﬁnd information regarding our call centers and how to download products and software.

English

Page 31

Advanced FeaturesAdvanced Features

SUM

Media Play (USB)

Enjoy video, music and/or photos ﬁ les saved on a USB Mass

Media Play

Storage Class (MSC) device.

Videos

→ Application → Media Play (USB) → ENTER

Change Device

• The displayed image may differ depending on the model.

¦ Connecting a USB Device

1. Turn on your TV.

2. Connect a USB device containing video, music and/or photos ﬁ les to the USB jack on the

rear of the TV.

3. When the Application selection screen is displayed, press the ► button to select Media Play (USB), then press the ENTER

button.

Using the Media Play Menu

1. Press the MENU button. Press the ▲ or ▼ button to select Application, and then press the ENTERE button.

2. Select Media Play (USB), then press the ENTER

button.

3. The USB Memory Device name is displayed in the left corner.

✎

The Media Play menu differs depending on the USB Memory Device connected to TV.

✎

Some devices may not be suppor ted due to compatibility problems.

4. Press the ◄ or ► button to select an icon (Videos , Music, Photos, Settings), then press the ENTER

button.

Media Play

Videos

Change Device

• The displayed image may differ depending on the model.

Side Panel

Enter

USB Drive

Enter

Return

✎

The USB function might not work properly with unlicensed multimedia files.

✎

Read this information before using Media Play (USB) with a USB device:

Only alphanumeric characters must be used as a folder name or file name (photo, music).

The file system supports FAT16, FAT32 and NTFS.

Certain types of USB Digital camera and audio devices may not be compatible with this TV.

Media Play (USB) only supports the USB Mass Storage Class device (MSC). MSC is a Mass Storage Class Bulk-

Only Transport device. Examples of MSC are Thumb drives and Flash Card Readers (Both USB and HUB are not supported.)

USB HDD is not supported. A USB device that requires high power(more than 0.5A) may not be supported.

English

Page 32

Advanced Features

Before connecting your device to the TV, please back up your files to prevent them from damage or loss of data.

SAMSUNG is not responsible for any data file damage or data loss.

Please connect directly to the USB port of your TV. If you are using a separate cable connection, there may be a USB

Compatibility problem.

The Media Play (USB) mp3 format only supports music files with a high sampling frequency (32 kHz, 44.1 kHz, or 48

kHz).

Photos only suppor ts sequential jpeg format.

Do not disconnect the USB device while it is loading.

MSC supports MP3 and JPEG files, and the PTP device supports JPEG files only.

MTP (Media Transfer Protocol) is not supported.

The playing duration of an mp3 file may be displayed as “00:00:00” if its playing time information is not found at the

start of the file.

The higher the resolution of the image, the longer it takes to display on the screen.

The Photo or Music List displays up to 300 folders or files.

Loading may take some time depending on the size of the file.

MP3 files with DRM that have been downloaded from a non-free site cannot be played.

Digital Rights Management (DRM) is a technology that supports the creation, distribution and management of the

content in an integrated and comprehensive way, including the protection of the rights and interests of the content providers, the prevention of the illegal copying of contents, as well as managing billings and settlements.

The power-saving mode of some external hard disk drives may be released automatically when connected to the TV.

If a USB extension cable is used, the USB device may not be recognized or the files on the device may not be read.

If a USB device connected to the TV is not recognized, the list of files on the device is corrupted or a file in the list is

not played, connect the USB device to a PC, format the device and check the connection.

Videos

Playing Video

1. Press the ◄ or ► button to select Videos, then press the

ENTER

button in the Media Play menu.

2. Press the ◄/►/▲/▼ button to select the desired ﬁ le in the ﬁ le list.

3. Press the ENTER

– The selected ﬁ le is displayed on the top with its playing time. – If video time information is unknown, play time and progress

bar are not displayed.

button.

E Pause L Jump T Tools R Returm

• The displayed image may differ depending on the model.

English

Page 33

Advanced Features

Supported Subtitle Formats

– External

Name Extension

MPEG-4 Timed text .ttxt

SAMI .smi

SubRip .srt

SubViewer .sub

Micro DVD .sub or .txt

SubStation Alpha .ssa

Advanced SubStation Alpha .ass

– Internal

Name File extension Format

Xsub AVI Picture format

SubStation Alpha MKV Text Format

Advanced SubStation Alpha MKV Text Format

SubRip MKV Text Format

MPEG-4 Timed text MP4 Text Format

English

Page 34

Advanced Features

Supported Video Formats

File

Extension

*.mp4 MP4

*.avi

*.mkv

*.asf

*.wmv

*.ts

*.trp

*.tp

*.m2ts

*.dat

*.mpg

*.mpeg

*.vob

*.3gp 3GPP

*.ﬂv

*.swf

Container Video Codec Resolution

Divx3.11/4.x/5.1/6.0 1920x1080 6~30 30Mbps

H264 1920x1080 6~30 30Mbps

AVC 1920x1080 6~30 30Mbps

MJPEG 640x480 6~30 10Mbps

Divx3.11/4.x/5.1/6.0 1920x1080 6~30 30Mbps

AVI

MKV

ASF

ﬂash formats

MPEG4 SP / ASP 1920x1080 6~30 30Mbps

H264 1920x1080 6~30 30Mbps

MJPEG 640x480 6~30 10Mbps

Divx 3.11/4.x/5.1/6.0 1920x1080 6~30 30Mbps

MPEG4 SP / ASP 1920x1080 6~30 30Mbps

H.264 1920x1080 6~30 30Mbps

MPEG2 1920x1080 6~30 30Mbps

H. 264 BP/MP/HP 1920x1080 6~30 30Mbps

MPEG1 1920x1080 24/25/30 30Mbps

MPEG2 1920x1080 24/25/30 30Mbps

H. 264 BP/MP/HP 1920x1080 6~30 30Mbps

MPEG4 SP / ASP 1920x1080 6~30 30Mbps

H.264 1920x1080 6~30 30Mbps

Sorenson H.263 1920x1080 6~30 30Mbps

Frame

rate(fps)

Bit

rate(Mbps)

Audio Codec

MP3 / ADPCM / AAC

MP3 / AC3 / LPCM /

ADPCM / DTS Core

MP3 / AC3 / LPCM /

ADPCM / WMA / WMA Pro

AC3 / AAC / MP3 / DD+ / HE-AAC

AC3 / MPEG / LPCM / AAC

Other Restrictions

✎

NOTE

Video content will not play, or not play correctly, if there is an error in the content or the container.

Sound or video may not work if the contents have a standard bit rate/ frame rate above the compatible Frame/sec

listed in the table above.

If the Index Table is in error, the Seek (Jump) function is not suppor ted.

The menu may take longer to appear if the video’s bit rate exceeds 10Mbps.

Video content can not be played, if there are many contents in one file.

Video Decoder Audio Decoder

• Supports up to H.264, Level 4.1

• H.264 FMO / ASO / RS, VC1 SP / MP / AP L4 and AVCHD are not

supported.

• MPEG4 SP, ASP :

– Below 1280 x 720: 60 frame max – Above 1280 x 720: 30 frame max

• H.263 is not supported.

• GMC is not support.

• Supports up to WMA7, 8, 9 STD, 9 PRO, 10 PRO

• WMA 9 PRO and WMA 10 PRO support 5.1 channel .

• WMA Lossless is not supported.

MP3

English

Page 35

Advanced Features

3/15

I Love you

Jhon

Music 1

Music 2

Music 3

Music 4

Music 5

I Love You

Jhon

01:10 / 04:02

Image1024.jpg 1024x768 3/15

Music

Playing Music

1. Press the ◄ or ► button to select Music, then press the

ENTER

button in the Media Play menu.

2. Press the ◄/►/▲/▼ button to select the desired ﬁle in the ﬁle list.

3. Press the ENTER

– During playing the music, you can search using the ◄ and ►

button.

–

�

(REW) and μ (FF) buttons do not function during play.

Photos

Viewing a Photo (or Slide Show)

1. Press the Tools button to display the option Slide Show, Detailed Information, Device Information.

2. Press the ▲ or ▼ button to select Start Slide Show then press

the ENTER

✎

During the slide show, files are displayed in order from the currently shown file.

✎

MP3 files can be automatically played during the slide show

if the Default Background Music is set to On.

✎

Press the Tools button during the photo view to set the following options Stop Slide Show, Slide Show Speed, Background

Music, Zoom, Rotate, Picture Mode, Sound Mode, Information. Press the ▲ or ▼ button to select the option, then

press the ENTER

– After setting the option press the ENTER

Supported Photo Formats

button or � (Play) button.

button.

button to make a change.

Playlist

1st Album Pop 2010

4.2MB

Device Name

• The displayed image may differ depending on the model.

Normal 11/14/2011

• The displayed image may differ depending on the model.

Pause

No Singer

E Pause

Previous/Next

Jump

Tools

Returm

Return

Image Photo Resolution

JPEG

Other Restrictions

CMYK, YCCK Color space JPEG are not supported.

Base-line 15360x8704

Progressive 1024x768

English

Page 36

Advanced Features

Videos/Music/Photos Play Option menu

During playing a ﬁle, press the TOOLS button.

Category Operations Videos Music Photos

Title

Repeat Mode

Picture Size

Picture Mode

Sound Mode

Stop Slide Show / Start Slide Show

Slide Show Speed

Background Music

Zoom

Rotate

Information

Settings

Using the Setting Menu

✎■ DivX® Video On Demand: DivX® Video On Demand Shows the registration code authorized for the set. If you connect

to the DivX web site and register, you can download the VOD registration ﬁle. If you play the VOD registration using Media contents, the registration is completed.

✎

For more information on DivX® VOD, visit “http://vod.divx.com”.

✎■ Information: Select to view information about the connected device.

You can move the other ﬁle directly.

You can play movie and music ﬁles repeatedly.

You can adjust the picture size for preference.

You can adjust the picture setting. (p.22)

You can adjust the sound setting. (p.25)

You can start or stop a slide show.

You can select the slide show speed during the slide show.

You can set and select background music when watching a slide show.

You can zoom into images in full screen mode.

You can rotate images in full screen mode.

You can see detailed information about the played ﬁle.

c c

c c c

English

Page 37

Other Information

Attaching a Wall Mount/Desktop Stand

Preparing before installing Wall-Mount/Desktop Stand

1. Turn the product off and unplug the power cord from the wall outlet.

2. Place a soft cloth or cushion on a ﬂat surface to protect the panel and place the product face down.

3. Hold the main body of the product with your hand. Pull the stand in the direction of the arrow as shown in the ﬁgure to

separate it.

Attaching a Wall Mount/Desktop Stand

Wall/Desktop Stand Mount

Wall mount kit/desktop stand (not supplied)

Caution

Important

For the installation of Wall-mount, please don't use screws longer than 14mm(L14) of longitude.

4. Align wall mount/desktop stand to the Monitor/TV and ﬁrmly ﬁx the wall mount/desktop stand by fastening the screw.

5. Align the groove of the part of the product that is to be connected to the stand with the groove in the stand (desk-top

stand, wall mount stand or another stand) and ﬁrmly ﬁx the stand by fastening the screw.

Do not install your Wall Mount Kit while your TV is turned on. It may result in personal injury due to electric shock.

English

Page 38

Other Information

✎

NOTE

If you use screws that are longer than the standard specifications, the inside of the product may be damaged.

For wall mounts that are not compatible with the standard VESA specifications, the length of the screw may differ

depending on the corresponding specifications.

Avoid using screws that are incompatible with the standard VESA specifications and avoid assembling them using

excessive force. This may result in damage to the product or injury due to the product falling. Samsung shall not be held liable for any damage or injury.

Samsung shall not be held liable for any damage to the product or injury caused by using a wall mount/desktop stand

that is not compatible with the specifications or due to an installation not performed by an authorized installation engineer.

When installing the product using a wall mount, purchase a wall mount that provides at least 10 cm (3.93 inches) of

space from the wall.

Use the wall mount according to the international speciﬁcations.

Anti-theft Kensington Lock

A Kensington Lock is a device you can use to physically ﬁx your set in place when using it in a public place. You wrap the Kensington Lock’s cable around a large, immobile object and then attach the lock to the Kensington slot on the back of the set.

The appearance and locking method may differ from the illustration below depending on the manufacturer. Refer to the manual provided with the Kensington Lock for additional information on proper use. The Kensington Lock is not supplied by Samsung.

✎

Please find a “K” icon on the rear of the set. A kensington slot is beside the

” icon.

“

To lock the product, follow these steps:

1. Wrap the Kensington lock cable around a large, stationary object such as desk or chair.

2. Slide the end of the cable with the lock attached through the looped end of the Kensington Lock cable.

3. Insert the locking device into the Kensington slot on the product 1.

4. Lock the lock.

✎

These are general instructions. For exact instructions, see the User manual supplied with the locking device.

✎

The locking device has to be purchased separately.

✎

The location of the Kensington slot may be different depending on the TV model.

English

Page 39

Other Information

Troubleshooting

If the TV seems to have a problem, ﬁrst review this list of possible problems and solution. If none of the troubleshooting tips apply, visit www.samsung.com/support or call Samsung customer Service at 1-800-SAMSUNG(1-800-726-7864).

Issues Solutions and Explanations

PC Connection

A Mode Not Supported message appears.

The video is OK but there is no audio. • If you are using an HDMI connection, check the audio output setting on your PC.

Poor picture First of all, please perform the Picture Test and conﬁrm that your TV is properly displaying the test image.

The TV image does not look as good as it did in the store.

The picture is distorted: macro block error, small block, dots, pixelization.

Color is wrong or missing. • If you’re using Component connection, make sure the component cables are connected to the

There is poor color or brightness. • Adjust the Picture options in the TV menu. (go to Picture mode / Color / Brightness / Sharpness)

There is a dotted line on the edge of the screen.

The picture is black and white. • If you are using an AV composite input, connect the video cable (yellow) to the Green jack of

When changing channels, the picture freezes or is distorted or delayed.

Sound Problem First of all, please perform the Sound Test to conﬁrm that your TV audio is properly operating.

There is no sound or the sound is too low at maximum volume.

The speakers are making an inappropriate noise.

No Picture, No Video

The TV won’t turn on. • Make sure the AC power cord is securely plugged in to the wall outlet and the TV.

• Set your PC’s output resolution so it matches the resolutions supported by the TV (p. 18).

(go to MENU - Support - Self Diagnosis - Picture Test) (p. 30) If the test image is properly displayed, the poor picture may be caused by the source or signal.

• If you have an analog cable/satellite box, upgrade to an HD digital set top box. Use HDMI or Component cables to deliver HD (high deﬁnition) picture quality.

• Cable/Satellite subscribers: Try HD stations from the channel line up.

• Antenna connection: Try HD stations after performing Auto program.

Many HD channels are up scaled from SD(Standard Deﬁnition) contents.

✎

• Adjust the Cable/Sat box video output resolution to 1080i or 720p.

• Make sure you are watching the TV at the minimum recommended distance based on the size and

deﬁnition of the signal.

• Compression of video contents may cause picture distortion, especially in fast moving pictures such as sports and action movies.

• Low signal level can cause picture distortion. This is not a TV problem.

• Mobile phones used close to the TV (within 3.3ft) may cause noise in picture on analog and digital

channels.

correct jacks. Incorrect or loose connections may cause color problems or a blank screen.

(p. 22)

• Adjust Energy Saving option in the TV menu. (go to MENU – Setup) (p. 29)

• Try resetting the picture to view the default picture settings. (go to MENU - Picture - Picture Reset)

(p. 24)

• If the picture size is set to Screen Fit, change it to 16:9 (p. 23).

• Change cable/satellite box resolution.

component input 1 on the TV.

• If connected to a cable box, please try to reset it. (reconnect the AC cord and wait until the cable box reboots. It may take up to 20 minutes)

• Set the output resolution of the cable box to 1080i or 720p.

(go to MENU - Support - Self Diagnosis - Sound Test) (p. 30) If the audio is OK, the sound problem may caused by the source or signal.

• Please check the volume of the device (Cable/Sat Box, DVD, Blu-ray etc) connected to your TV.

• Check cable connections. Make sure a video cable is not connected to an audio input.

• For antenna or Cable connections, check the signal strength. Low signal level may cause sound

distortion.

• Perform the Sound Test as explained above.

• Make sure the wall outlet is working.

• Try pressing the POWER button on the TV to make sure the problem is not the remote. If the TV turns

on, refer to “The remote control does not work” below.

English

Page 40

Other Information

Issues Solutions and Explanations

The TV turns off automatically. • Ensure the Sleep Timer is set to Off in the Setup menu (p. 26).

There is no picture/video. • Check cable connections (remove and reconnect all cables connected to the TV and external

RF(Cable/Antenna) Connection

The TV is not receiving all channels. • Make sure the coaxial cable is connected securely.

The picture is distorted: macro block error, small block, dots, pixelization.

Others

Purple/green rolling horizontal bars and buzzing noise from the TV speakers with Component cable connection.

A “Mode Not Supported” message appears.

Caption on TV menu is greyed out. • Caption can not be selected in the TV menu when connected via HDMI or Component or PC (p. 28).

There is a plastic smell from the TV. • This smell is normal and will dissipate over time.

The TV Signal Strength is unavailable in the Self Diagnostic Test menu.

The TV is tilted to the side. • Remove the base stand from the TV and reassemble it.

The channel menu is greyed out (unavailable).

Your settings are lost after 30 minutes or every time the TV is turned off.

You have intermittent loss of audio or video.

You see small particles when you look closely at the edge of the frame of the TV.

POP (TV’s internal banner ad) appears on the screen.

The remote control does not work. • Replace the remote control batteries with correct polarity (+/-).

• If your PC is connected to the TV, check your PC power settings.

• Make sure the AC power cord is plugged in securely to the wall outlet and the TV.

• When watching TV from an antenna or cable connection, the TV will turn off after 10 - 15 minutes if

there is no signal.

devices).

• Set your external device’s (Cable/Sat Box, DVD, Blu-ray etc) video outputs to match the connections to the TV input. For example, if an external device’s output is HDMI, it should be connected to an HDMI input on the TV.

• Make sure your connected devices are powered on.

• Be sure to select the TV’s correct source by pressing the SOURCE button on the remote control.

• Reboot the connected device by reconnecting the device’s power cable.

• Please try Auto Program to add available channels to the channel list. Go to MENU - Channel -

Auto Program then select Auto and make sure the correct Cable TV signal type is set in the menu. There are 3 options (STD, HRC and IRC) (p. 20).

• Verify the Antenna is positioned correctly.

• Compression of video contents may cause picture distortion, especially with fast moving pictures

such as sports and action movies.

• A low signal can cause picture distortion. This is not a TV problem.

• Remove the left and right audio connections from the set-top-box. If the buzzing stops, this indicates

that the set-top-box has a grounding issue. Replace the Component video cables with an HDMI connection.

• Check the supported resolution of the TV, and adjust the external device’s output resolution accordingly. Refer to the resolution settings on page 18 of this manual.

• Caption must be activated on the external device (p. 28).

• This function is only available with digital channels from an Antenna / RF/Coax connection (p. 30).

• The Channel menu is only available when the TV source is selected.

f the TV is in the Store Demo mode, it will reset audio and picture settings every 30 minutes. Change

• I the settings from Store Demo mode to Home Use mode in the Plug & Play procedure. Press the

SOURCE button to select TV mode, and go to MENU → Setup → Plug & Play → ENTERE (p. 15).

• Check the cable connections and reconnect them.

• Loss of audio or video can be caused by using overly rigid or thick cables. Make sure the cables are

ﬂexible enough for long term use. If mounting the TV to a wall, we recommend using cables with 90 degree connectors.

• This is part of the product’s design and is not a defect.

p. 15

• Select Home Use under Plug & Play mode. For details, refer to Plug & Play Feature (

• Clean the transmission window located on the top of the remote control.

• Try pointing the remote directly at the TV from 5~6 feet away.

✎

This panel uses a panel consisting of sub pixels which require sophisticated technology to produce. However, there may be a few bright or dark pixels on the screen. These pixels will have no impact on the performance of the product.

English

Page 41

Other Information

Storage and Maintenance

✎

If you attached some stickers on the TV screen, it remains some debris af ter removing the sticker. Please clean it to watch TV.

✎

The exterior and screen of the product can get scratched during cleaning. Be sure to wipe the ex terior and screen carefully using the cloth provided or a sof t cloth to prevent scratches.

Do not spray water or a cleaning agent directly onto the product. Any liquid that goes into the product may cause a failure, ﬁre, or electric shock.

License

TheaterSound HD, SRS and the symbol are trademarks of SRS Labs, Inc. TheaterSound HD technology is incorporated under license form SRS Lab, Inc.

Manufactured under licence from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,487,535 & other U.S. and worldwide patents issued & pending. DTS, the Symbol, & DTS and the Symbol together are registered trademarks & DTS 2.0 Channel is a trademarks of DTS, Inc. Product includes software. © DTS, Inc. All Rights Reserved.

Manufactured under license under U.S. Patent #’s: 5,451,942; 5,956,674; 5,974,380; 5,978,762; 6,487,535 & other U.S. and worldwide patents issued & pending. DTS and the Symbol are registered trademarks. & DTS 2.0+ Digital Out and the DTS logos are trademarks of DTS, Inc. Product Includes software. © DTS, Inc. All Rights Reserved.

Clean the product with a soft cloth dampened with amount of water.

TB300 series support dts 2.0 Channel,TB350 series support dts 2.0+Digital Out.

English

Page 42

Other Information

Speciﬁcations

Environmental

considerations

Screen Size (Diagonal) 18.5 inches (47 cm) 21.5 inches (54 cm) 23.5 inches (59 cm) 27 inches (68 cm)

VESA Mounting Interface 75 mm x 75 mm 100 mm x 100 mm

Display Resolution 1366 x 768@60Hz 1920x1080@60Hz

Sound (Output) 5W × 2

Dimensions (W x H x D)

Weight

✎

Design and specifications are subject to change without prior notice.

✎

This device is a Class B digital apparatus.

✎

For information about power supply, and more about power consumption, refer to the label attached to the product.

✎

Some models may not be available for purchase depending on the region.

Operating

Storage

Tilt -1° (±2°) ~ 20°(±2°)

Model Name T19B300 T22B350 T24B350 T27B350

(Without Stand)

(With Stand)

(Without Stand) 2.95 kg (6.5 lbs) 3.7 kg (8.2 lbs) 4.25 kg (9.4 lbs) 5.1 kg (11.2 lbs)

(With Stand) 3.2 kg (7.1 lbs) 3.95 kg (8.7 lbs) 4.5 kg (9.9 lbs) 5.6 kg (12.3 lbs)

444.7 x 278.2 x 52.9 mm (17.5 x 10.9 x 2.0 inches)

444.7 x 356.4 x 187 mm (17.5 x 14.0 x 7.4 inches)

Temperature : 32°F ~ 122°F (0°C ~ 50°C) Humidity : 10 % ~ 80 %, non-condensing

Temperature : -4°F ~ 113°F (-20°C ~ 45°C)

Humidity : 5 % ~ 95 %, non-condensing

509.7 x 318.2 x 51.5 mm (20.1 x 12.5 x 2.0 inches)

509.7 x 396.6 x 195 mm

(20.1 x 15.6 x 7.7 inches)

569.2 x 349.4 x 53.4 mm (22.4 x 13.8 x 2.1 inches)

569.2 x 428 x 195 mm

(22.4 x 16.9 x 7.7 inches)

643.3 x 397.9 x 53.4 mm (25.3 x 15.7 x 2.1 inches)

643.3 x 476.5 x 252 mm (25.3 x 18.8 x 9.9 inches)

English

Page 43

Contact SAMSUNG WORLDWIDE

If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center.

Country

Customer Care Center

Samsung T27B350, T24B350, T19B300, T22B350 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
