Page 1

SPH-m530

PORTABLE Dual-Mode

TELEPHONE

User Guide

Please read this manual before operating your phone, and keep it for

future reference.

BMC_m530_UG_EN_06032008_F8

Page 2

Intellectual Property

All Intellectual Property, as defined below, owned by or which is otherwise the property of Samsung or its respective suppliers relating to the SAMSUNG Phone, including but not limited to, accessories, parts, or software relating thereto (the “Phone System”), is proprietary to Samsung and protected under federal laws, provincial laws, and international treaty provisions. Intellectual Property includes, but is not limited to, inventions (patentable or unpatentable), patents, trade secrets, copyrights, software, computer programs, and related documentation and other works of authorship. You may not infringe or otherwise violate the rights secured by the Intellectual Property. Moreover, you agree that you will not (and will not attempt to) modify, prepare derivative works of, reverse engineer, decompile, disassemble, or otherwise attempt to create source code from the software. No title to or ownership in the Intellectual Property is transferred to you. All applicable rights of the Intellectual Property shall remain with SAMSUNG and its suppliers.

© 2008 Samsung Electronics Canada, Inc.. SAMSUNG is a registered trademark of Samsung Electronics Co., Ltd. and its related entities. Licensed by Qualcomm Incorporated under one or more of the following patents: U.S. Patent No. 4, 901, 307; 5, 056, 109; 5, 099, 204; 5, 101, 501; 5, 103, 459; 5, 107, 225; 5, 109, 390.

Openwave RSA® is a registered Trademark of RSA Security, Inc. Post-it®is a registered Trademark of Minnesota Mining and Manufacturing Company aka 3M CORPORATION DELAWARE. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Samsung Electronics Canada, Inc. is under license. Other trademarks and trade names are those of their respective owners.

is a registered Trademark of Openwave, Inc.

Page 3

Disclaimer of Warranties; Exclusion of Liability

Except as set forth in the express warranty contained on the warranty page enclosed with the product, the purchaser takes the product "as is", and Samsung makes no express or implied warranty of any kind whatsoever with respect to the product, including but not limited to the merchantability of the product or its fitness for any particular purpose or use; the design, condition or quality of the product; the performance of the product; the workmanship of the product or the components contained therein; or compliance of the product with the requirements of any law, rule, specification or contract pertaining thereto. Nothing contained in the instruction manual shall be construed to create an express or implied warranty of any kind whatsoever with respect to the product. In addition, Samsung shall not be liable for any damages of any kind resulting from the purchase or use of the product or arising from the breach of the express warranty, including incidental, special or consequential damages, or loss of anticipated profits or benefits.

Privacy

The privacy and copyright laws of Canada govern the disclosure, reproduction and distribution of data, media and other content, including music and video content. Certain activities, including downloads or transfer by any means (including, via cable, Bluetooth® or otherwise) of such content may be an infringement of privacy or copyright law. Neither Samsung Electronics Canada Inc. nor any of its affiliates shall be liable or responsible for any data or content disclosed, reproduced, downloaded or distributed by the user of this equipment.

Warning

Depending on the user interface used in the handset, you may experience slow keypad response when performing tasks in the background. This can impact making phone calls. When there is no activity or change in the icons at the top of the main LCD display, the handset will resume normal operations.

Page 4

Table of Contents

Getting Started ................................................................................... 1

Closed View of Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Open View of Phone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Viewing the Display Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Turning Your Phone On and Off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Using Your Phone’s Battery and Charger. . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Using the Travel Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Using a microSD Memory Card in Your Phone . . . . . . . . . . . . . . . . . . . . . . 11

Phone Basics.................................................................................... 13

Accessing Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Displaying Your Phone Number. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Making and Answering Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Using Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Responding to Call Waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Making a Three-Way Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

TTY Use With Handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Entering Text .................................................................................... 21

T9 Text Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Alpha Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Numbers, Symbols, Emoticons and Preset Messages . . . . . . . . . . . . . . . . 23

Roaming........................................................................................... 24

Setting Your Roaming Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Update PRL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Voice Service.................................................................................... 26

Customizing Voice Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Main Menu ....................................................................................... 33

User Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Menu Styles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Changing the Phone’s Menu Style . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Menu Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Web.................................................................................................. 36

Calls ................................................................................................. 38

Calls Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Making a Call From the Calls Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Page 5

Entertainment................................................................................... 39

TV & Radio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Bluetooth.......................................................................................... 45

Enable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Visibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Device Name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Device Info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

FTP Contents Folder. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Pairing Bluetooth Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Missed Alerts ................................................................................... 49

My Downloads ................................................................................. 50

Downloading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Playing Games . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Assigning Ringers and Screen Savers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Launching Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Messaging........................................................................................ 53

Text Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Web Alert . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Tools ................................................................................................ 62

GPS Nav . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Alarm Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

World Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Memo Pad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Voice Memo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Camera............................................................................................. 71

Photo Album . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Send Pic/Video. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Print . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Contacts ........................................................................................... 80

Finding Contacts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Adding a New Contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Editing an Existing Contact. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Page 6

Speed Dial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

My Name Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Backup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Settings............................................................................................ 84

Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Sounds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Voice Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Phone Info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Others. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Phone Support ................................................................................. 96

Phone Info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Live Assistance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Account Info. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Add New Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Text Assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Phone Security................................................................................ 98

Accessing the Security Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Using Your Phone’s Lock Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Special #s. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

Erase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

Reset Pic/Video Account . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

Reset Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

Safety ............................................................................................. 101

Getting the Most Out of Your Reception . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Maintaining Safe Use of and Access to Your Phone . . . . . . . . . . . . . . . . . 102

Caring for the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104

Owner’s Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106

User Guide Proprietary Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

Manufacturer’s Warranty................................................................ 108

Index .............................................................................................. 111

Page 7

Getting Started

Closed View of Phone

9. Camera Lens

8. Hold Key

7. Volume Keys

6. Front LCD

5. microSD Card Slot

1. Hole: The Hole is used to hang an accessory, such as a keychain.

2. Power/Accessory Connector: The power/accessory interface connector

is used to plug in the charging accessories and also connect any available accessory cables to your phone. This connector also allows you to plug in an optional headset for safe, convenient conversations.

3. Camera/Camcorder Key: This key is used to launch the integrated

digital camera.

4. Front Navigation Pad: Use the front keypad to launch the Music Player

and navigate tracks.

5. microSD™ Card Slot: This expansion slot allows you to insert a

microSD™ memory card to add additional memory and storage capacity.

6. Front LCD: The Front LCD shows signal and battery strength, time, day,

and date. It also displays incoming calls or messages.

7. Volume Keys: Allows you to adjust the ringer volume in idle mode (with

the phone open) or adjust the voice volume during a call. To mute the ringer during an incoming call, press the volume key up or down.

8. Hold Key: Allows you to lock the front keypad.

1. Hole

2. Power/Accessory Connector

3. Camera/ Camcorder Key

4. Front Navigation Pad

Getting Started

Getting Started 1

Page 8

9. Camera Lens: Allows you to take photos or shoot video.

Open View of Phone

1. Menu/OK Key

2. Left Softkey

3. Music Store 9. Speakerphone

4. TALK Key

5. Alpha-numeric Keypad

11. Navigation Keys

10. Right Softkey

8. END Key

7. BACK Key

6. Microphone

1. Menu/OK Key: Pressing when navigating through a menu accepts the

highlighted choice in a menu.

2. Left Softkey: This key is used to navigate through menus and

applications by selecting the choice available in the Left Softkey Option.

3. Music Store: This key is used to launch the Music Store application.

4. TALK Key: Allows you to place or receive a call. In idle mode, press the

key once to access the recent call log.

5. Alpha-numeric Keypad: Use these keys to enter numbers, letters, and

characters.

6. Microphone: The Microphone allows the other caller to hear you clearly

when you are speaking to them.

7. BACK Key: Deletes characters from the display when you are in text

entry mode. Press to return to the previous menu or screen when navigating features on your phone.

2 Getting Started

Page 9

8. END Key: Ends a call. If you press and hold the END key, the power goes

On or Off. When you receive an incoming call, press to ignore the call and send the call to voicemail.

9. Speakerphone Key: When pressed during a call, this key is used to

turn the speakerphone on or off. When pressed outside the duration of a call, this key launches the Voice Service functionality.

10. Right Softkey: This key is used to navigate menus and applications by

selecting the choice available in the Right Softkey Option.

11. Navigation Keys: These keys allow you to scroll through the phone

menu options.

Viewing the Display Screen

The following list identifies the icons you’ll see on your phone’s display screens:

indicates that your 1X connection is active. Incoming voice calls go directly to Voicemail; outgoing voice calls can be made, but the connection will terminate.



indicates that data is being transferred over the 1X network. The arrow direction indicates whether the handset is sending or receiving data.

indicates that your 1X connection is dormant.

indicates that you are in a high-speed EV-DO coverage area.

indicates that you have an active EV-DO connection. When the arrows are moving, data is being transferred over the EV-DO network.

indicates that the EV-DO connection is dormant.

indicates that position location is active.

indicates that position location is inactive.

indicates that your phone is in web security mode.

indicates that your phone is roaming.

indicates that you have a new Text Message.

indicates that you have a new Picture Message.

indicates that you have a new Voice Mail.

Getting Started

Getting Started 3

Page 10

indicates that there is an unread message in your inbox.

indicates that the message has been read.

indicates that there is an unread urgent message in your inbox.

indicates that you have read the urgent message.

indicates that the message was sent.

indicates that the message failed to send.

indicates that you have a pending message to be sent.

indicates that the message is a draft.

indicates that there is URL contained in the text message.

indicates that the text message is locked. A locked message cannot be deleted without confirmation.

indicates that your phone is in vibrate all mode.

indicates that your phone is set to ringer plus vibrate mode.

indicates that the ringer is turned off and the vibrate option is enabled.

indicates that the TTY option is On. This icon is displayed only when earphones or a Bluetooth headset is in use.

indicates that the ringer is set at a level between 1-8 or that 1-Beep is selected.

indicates that the ringer is turned off.

indicates that an alarm is set on your phone.

tells you a call is in progress.

means there is no service, as your phone cannot find a signal.

4 Getting Started

Page 11

displays your current signal strength. When you are receiving maximum

signal strength, five bars are shown.

displays your current battery strength at full.

displays your current battery strength at empty.

indicates that the handset is in Mute mode.

indicates that the handset is in Key Mute mode.

indicates that the handset is in Speaker mode.

indicates that the Camera is enabled.

indicates that the Camcorder is enabled.

indicates that the self-timer function is enabled. With the self timer enabled, a set amount of time is required prior to taking a picture.

indicates that the white balance has been set to Automatic.

indicates that the white balance has been set to Sunny. This is used for taking pictures outdoors on bright sunny days.

indicates that the white balance has been set to Cloudy. This is used for taking pictures outdoors under cloudy conditions.

indicates that the white balance has been set to Tungsten. This is used for taking pictures indoors under normal lighting conditions.

indicates that the white balance has been set to Fluorescent. This is used for taking pictures indoors under fluorescent lighting conditions.

indicates that the white balance has been set to Manual. This is used for taking pictures indoors or outdoors using your own custom settings.

indicates that a voice memo or video is being recorded.

Getting Started

indicates the key you must press to pause playback.

indicates the key you must press to play.

indicates that media has been uploaded to an online album or folder.

indicates that media is pending upload to an online album or folder.

Getting Started 5

Page 12

indicates that there is a voice caption attached to an image.

indicates that Bluetooth technology is enabled.

indicates that Bluetooth technology is active and hidden.

indicates that Bluetooth technology is connected.

indicates that Bluetooth technology is active and visible.

indicates that Bluetooth technology is connected but idle.

indicates that a that Memory Card is inserted.



Your phone can also display a handy glossary of icons:

1. Press , select the Phone Support menu, and press .

MENU MENU

2. Select Phone Info.

3. Select Icon Glossary.

4. Use the navigation keys to scroll through the list of icons.

Turning Your Phone On and Off

To turn your phone on:

• Press and hold to turn your phone on.

Once your phone is On, it displays “Looking for Service” which indicates that your phone is searching for a signal. When your phone finds a signal, it automatically enters standby mode – the phone’s idle state. At this point, you are ready to begin making and receiving calls.

If your phone is unable to find a signal after 15 minutes of searching, a Power Save feature is automatically activated. When a signal is found, your phone automatically returns to standby mode.

In Power Save mode, your phone searches for a signal periodically without your intervention. You can also initiate a search for service by pressing any key (when your phone is turned On).

END

6 Getting Started

Page 13

Tip: The Power Save feature helps to conserve your battery power when you are in an area where there is no signal.

To turn your phone off:

• Press for two or more seconds until you see the powering down

Your screen remains blank while your phone is off (unless the battery is charging).

END

animation on the display screen.

Using Your Phone’s Battery and Charger

Battery Capacity

Your phone is equipped with a Lithium Ion (LiIon) battery. It allows you to recharge your battery before it is fully drained.

When the battery runs low, the battery icon will blink to remind you to recharge the battery. When the battery capacity is close to completely drained, the phone sounds an audible alert and then powers down.

Note: Long backlight settings, low signal strength, searching for service, vibrate mode, playing games, or browser use affect the battery’s talk and standby times.

Tip: Be sure to watch your phone’s battery level indicator and charge the battery before it runs out of power.

Getting Started

Getting Started 7

Page 14

Installing the Battery

To install the LiIon battery:

1. Press the top of the battery cover and slide the battery cover down to

release it. Lift the cover up by the bottom corners to remove it.

2. Insert the bottom end of the battery into the phone housing by using the

direction of the arrow printed on the battery. The gold contacts on the bottom of the battery should match up with those on the phone.

3. Push the top end of the battery down until it snaps into place.

8 Getting Started

Page 15

4. Insert the top end of the battery cover into the grooves of the phone.

Snap the lid into place.

Removing the Battery

Note: Make sure the power is off so that you don’t lose any stored numbers or

messages.

To remove your battery:

• Use your finger to lift the battery (top end first) up and away from the

phone.

Charging the Battery

Your phone’s LiIon battery is rechargeable and should be charged as soon as possible so you can begin using your phone.

Keeping track of your battery’s charge is important. If your battery level becomes too low, your phone automatically turns off and you will lose all the information you were just working on. For a quick check of your phone’s battery level, glance at the battery charge indicator located in the upper-right corner of either of your phone’s display screens. indicates that the battery is full. If the battery charge is getting too low, the battery icon blinks and the phone sounds a warning tone.

Always use a Samsung-approved desktop charger, travel adapter, or vehicle power adapter to charge your battery.

Getting Started

Getting Started 9

Page 16

WARNING! FOR CONNECTION TO AN ELECTRICAL SUPPLY NOT LOCATED IN NORTH AMERICA, YOU MUST USE AN ADAPTER OF THE PROPER CONFIGURATION FOR THE POWER OUTLET. USE OF THE WRONG ADAPTER COULD DAMAGE YOUR PHONE AND VOID YOUR WARRANTY. IMPORTANT SAFETY INSTRUCTIONS - TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, CAREFULLY FOLLOW THESE INSTRUCTIONS. THIS POWER UNIT IS INTENDED TO BE CORRECTLY ORIENTED IN A VERTICAL OR HORIZONTAL OR FLOOR MOUNT POSITION.

Note: You must unplug the adapter before removing the battery from the phone during charging to avoid damage.

Using the Travel Adapter

1. Locate the interface connector on the side of the phone and pull out and

turn the plastic cover.

2. Plug the terminal end of the adapter into the phone’s interface

connector, orienting the adapter’s gold contact pin upward.

Incorrect

Correct

3. Plug the other end into an electrical outlet.

4. An animated battery icon is displayed on the main screen. The icon

provides an indication of whether the battery is being charged or is fully charged.

10 Getting Started

Page 17

Note: It takes approximately 4 hours to fully recharge a completely drained standard battery. With the Samsung approved LiIon battery, you can recharge the battery before it drains completely.

Using a microSD Memory Card in Your Phone

Your phone is capable of supporting a memory storage media known as a microSDTM memory card. This card is the newest standard of flash memory specifically designed for use with ultra-small mobile phones and other devices. It is ideal for storing media-rich files such as music, videos, and photographs in your phone.

The maximum storage size for this media card is 4 GB.

Note: Compatibility with all high capacity microSDTM memory cards is not guaranteed.

Installing the microSDTM Memory Card

Your phone has a memory card slot on the lower left side. You can install a microSDTM card to provide additional memory for storing files (such as sound files and photos) in your phone.

To install the card:

1. Locate the memory slot on the left side of the phone and pull out and

turn the plastic cover.

2. Insert the microSD

pointing toward the phone—into the memory card slot.

card—pin side facing you and smaller end

Correct

Getting Started

Incorrect

Getting Started 11

Page 18

3. Carefully insert the microSD

card into the opening and firmly push it in until you hear a click, which indicates that the card is now securely installed.

Note: To remove the card once it has been inserted, firmly push the end of the card further into the phone and release—the card should pop out of the memory card slot. If this does not work, repeat the process again.

4. With the card now securely installed, resecure the plastic cover over the

microSD slot on the phone.

12 Getting Started

Page 19

Phone Basics

Your handset supports a flexible user interface that allows you to modify the user interface via downloadable themes. The availability of a custom user interface is subject to your carrier. The following description of the basic capabilities of the phone is a general description and not specific to a particular user interface.

However, there are some general principles that govern the handset's user interface. For each user interface, there will be a mechanism to access a main menu that provides access and control for most of the phone's capability.

Accessing Menus

1. Select the user interface's main focus button or press to activate

the main menu.

2. Select menu items by highlighting them with the navigation key and

pressing .

Displaying Your Phone Number

1. Press , highlight the Phone Support menu, and press .

2. Select Phone Info.

3. Select Phone Number.

MENU MENU

Making and Answering Calls

To make a call:

1. Make sure your phone is on.

2. Enter a phone number. (If you make a mistake while dialing, press

to erase one digit at a time. Press and hold to erase the entire number.)

3. Press to call.

4. Press or close the phone when you are finished.

TALK

END

BACK

Phone Basics

Tip: To redial your last recent call, press twice.

TALK

Phone Basics 13

Page 20

Tip: Some networks support + dialing. + dialing automatically indicates to the network that you are dialing an international call and adds the international dialing prefix (typically ‘001’) to the call automatically. To use + dialing, press and hold the 0 key (until the + appears) before entering the phone number.

To answer an incoming call:

1. Make sure your phone is on. (If your phone is off, incoming calls go to

Voicemail.)

2. Flip open the phone to answer an incoming call.

Your phone notifies you of incoming calls in the following ways:

• The phone rings or vibrates (unless set to Silence All).

• The screen displays an incoming call message.

If the incoming call is from a number stored in your Contacts, the Contacts entry’s name is displayed. The caller’s phone number may also be displayed, if available.

The following options are also available to handle an incoming call:

• Press or the volume key on the side of the phone to quiet the ringer.

END

• Press the right softkey for Ignore or press and hold the volume key to

send the incoming call to your Voicemail box immediately.

To disconnect a call when you are finished:

• Flip the phone closed or press .

Missed Call Notification

When an incoming call is not answered, a Missed Call message is displayed on your screen.

To dial a missed call back press .

Calling Emergency Numbers

You can place calls to 911 (dial 911 and press ), even if your phone is locked or your account is restricted.

END

TALK

Warning: After initiating a 911 call, you must end the call by pressing * and # on your keypad. This notifies the phone that the 911 call was terminated intentionally by the user. No other calls can be made prior to terminating the emergency call.

14 Phone Basics

Page 21

In-Call Options

During a call, use the left softkey to Mute or UnMute your phone’s microphone. Additional actions are available by pressing the right softkey for Options during a call. (To select an option, press the corresponding keypad number or highlight the option and press .)

• (1) Key Mute or Key Unmute allows you to mute the key tones on your

phone so the other caller cannot hear you pressing any keys on your phone.

• (2) Whisper Mode On or Whisper Mode Off allows you to whisper (such as

when you are in a public area) and your voice will be amplified so that the other caller can hear you.

• (3) Save allows you to save the new number in your Contacts.

• (4) Contacts accesses the Contacts menu options.

• (5) Messaging allows you to check notifications and access the contents of

voice or text messages.

• (6) 3-Way Call allows you to talk to two different people at the same time.

(For more information, see "Making a Three-Way Call" on page 19.)

• (7) Call History checks your call log for Missed, Outgoing, Incoming and

Recent calls. You can also erase the logs from this menu.

• (8) Voice Memo allows you to record the current conversation. (For more

information on recording a voice memo, see "Voice Memo" on page 68.)

• (9) Tools accesses the Tools menu options.

• (10) Phone Info displays the phone number, icon glossary, the hardware/

software version, the system and the technology being used.

During a call, you can to route the device’s audio through the speaker or through the earpiece by pressing the Speakerphone button on the keypad. You will see the message “Speaker Mode ON”. To turn off the speaker phone, press the Speakerphone button again. You will see the message “Speaker Mode OFF”.

Phone Basics

WARNING: Because of higher volume levels, do not place the device near your ear during speakerphone use.

End-of-Call Options

After receiving a call from or making a call to a phone number that is not in your Contacts, the phone number and the duration of the call are displayed. Press the left softkey to Save the new number in your Contacts. (See “"Saving a Phone Number" on page 16” below for more information.)

Phone Basics 15

Page 22

Note: The End-of-Call options are not displayed for calls identified as Unknown ID or Restricted Number.

Saving a Phone Number

You can store up to 1000 phone numbers in the Contacts list. (For more information, see "Adding a New Contact" on page 80.)

1. Enter a phone number from standby mode.

2. Press the right softkey for Options.

3. Select Save.

4. Select New Entry and press .

Note: Step 4 does not appear when your Contacts list is empty.

5. Select the Type using the navigation key and press .

• Mobile • Home • Work

• Pager • Others

6. Enter the name using the keypad and press .

7. Press the left softkey for Done.

Finding a Phone Number

From the Idle screen, press the right softkey for Contacts.

2. Scroll down through your list of contacts to highlight the name and

TALK

press to make the call.

Tip: To search through your list more quickly, enter the first few letters in the Name box. The display will move down the list to the first entry that matches the text in the Name box.

Tip: If the entry contains more than one phone number, scroll left or right to display the number you wish to call and press to make the call.

16 Phone Basics

TALK

Page 23

Dialing and Saving Phone Numbers With Pauses

TALK

You can dial or save phone numbers with pauses for use with automated systems, such as Voicemail or credit card billing numbers.

There are two types of pauses available on your phone:

• Hard Pause sends the next set of numbers when you press .

• 2-Second Pause automatically sends the next set of numbers after two

seconds.

Note: You can have multiple pauses in a phone number and combine 2-second and hard pauses.

To dial or save phone numbers with pauses:

1. Enter a phone number from standby mode.

2. Press the right softkey for Options and select Hard Pause or 2sec

Pause. Hard pauses are displayed as a “P” and 2-second pauses as a “T”.

3. Enter additional numbers.

4. Press to dial the number.

When dialing a number with a hard pause, press to send the next set of numbers.

Abbrev. Dial

Abbreviated dialing allows you to program a five or six digit prefix for commonly used phone numbers. When abbreviated dialing is on, you can enter the last four or five digits of any phone number that matches the five or six digit prefix, and the number is dialed.

To set up abbreviated dialing:

1. Press , highlight the Settings menu, and press .

2. Select Others.

3. Select Call Setup.

4. Select Abbrev. Dial.

TALK

— or— Press the right softkey for Options and select Save to save the number in your Contacts.

TALK

MENU MENU

Phone Basics

Phone Basics 17

Page 24

5. Select On or Off and press .

6. Input the five or six digit prefix (for example, area code and prefix) and

press .

Making an Abbreviated Dial Call

1. Enter the last four or five digits of the prefix phone number. Abbrev. Dial

is displayed in the lower left corner with the prefix digits displayed.

Note: If there is more than one Contact entry that matches the last four or five digits, a list is displayed which allows you to select the desired number to call.

2. Press to make the call.

TALK

Using Speed Dialing

You can store up to 98 numbers in your phone’s speed dial memory to make contacting friends and family as easy as pressing a few buttons. With this feature, you can dial Speed Dial entries using one key press for locations 2-9, or two key presses for locations 10-99.

To use One-Touch Dialing for Speed Dial locations 2-9:

• Press and hold the appropriate key for approximately two seconds.

To use Two-Touch Dialing for Speed Dial locations 10-99:

1. Press the first digit.

2. Press and hold the second digit for approximately two seconds.

Using Caller ID

To block your phone number from being displayed for a specific outgoing call:

1. Dial *67 on your keypad.

2. Enter the number you want to call.

3. Press .

To permanently block your number, call the Customer Service department of your network service provider.

Responding to Call Waiting

When you’re on a call, Call Waiting alerts you of incoming calls by sounding two beeps. Your phone’s screen informs you that another call is coming in and displays the caller’s phone number (if it is available and you are in digital mode).

18 Phone Basics

TALK

Page 25

To respond to an incoming call while you’re on a call:

TALK

• Press . (This puts the first caller on hold and answers the second

call.)

To switch back to the first caller:

TALK

• Press again.

Making a Three-Way Call

With Three-Way Calling, you can talk to two people at the same time. When using this feature, the normal airtime rates will be charged for each of the two calls.

To make a Three-Way Call:

1. Enter a number you wish to call and press .

2. Once you have established the connection, press the right softkey

for Options and select 3-way Call.

3. Select Contacts, Recent List, or Enter Phone # to dial the second

number and press the left softkey .

4. When you’re connected to the second party, press again to begin

your three-way call.

If one of the people you called hangs up during your call, you and the remaining caller stay connected. If you initiated the call and are the first to hang up, all three callers are disconnected.

Tip: You can also begin a Three-Way Call by displaying a phone number stored in your Contacts, Call History, or Messaging. To call the third party, press .

Note: Call Waiting and Three-Way Calling are not available while roaming off the network.

TALK

Phone Basics

TTY Use With Handset

A TTY (also known as a TDD or Text Telephone), is a telecommunications device that allows people who are deaf or hard of hearing, or who have speech or language disabilities, to communicate by telephone.

Phone Basics 19

Page 26

Your phone is compatible with selected TTY devices. Please check with the manufacturer of your TTY device to ensure that it supports digital wireless transmission. Your phone and TTY device will connect via a special cable that plugs into your phone's headset jack. If this cable was not provided with your TTY device, contact your TTY device manufacturer to purchase the connector cable.

Note: Not all service providers support TTY. Consult your service provider for more information.

To turn TTY Mode on or off:

1. Dial ##889 on your keypad and press . (A brief explanation of TTY

Mode will display.)

2. Press again to continue.

3. Press the navigation key up or down to select TTY On or TTY Off and

press to save and exit.

Note: In TTY Mode when your headset is plugged in, your phone will display the TTY access icon. If TTY mode is enabled, the headset cannot be used.

IMPORTANT 911 Emergency Calling: We recommend that TTY users make emergency calls by other means, including Telecommunications Relay Services (TRS), analog cellular, and land line communications. Wireless TTY calls to 911 may be corrupted when received by public safety answering points (PSAPs) rendering some communications unintelligible. The problem encountered appears related to TTY equipment or software used by PSAPs. The wireless industry and PSAP community are currently working to resolve this.

20 Phone Basics

Page 27

Entering Text

To change the character input mode:

1. When you display a screen where you can enter text, press the right

softkey for Options. Softkey options are not displayed when viewing existing messages.

2. Select a character input mode:

• T9 (English): To enter characters using predictive T9 Text Input (see

page 21).

• Alpha: To enter characters by tapping the keypad (see page 22).

• Symbol: To enter symbols (see page 23).

• Number: To enter numbers (see page 23).

• Preset Msg: To enter a pre-set message, chosen from a list of

common phrases.

• Recent Msg: To reuse the text from a recent message.

• Emoticons: To enter emoticon symbols.

• Text Options: To customize your character input mode.

T9 Text Input

T9 Text Input analyzes the letters you enter using an intuitive word database and creates a suitable word. (The word may change as you type.) Other possible words appear in a list below your text.

• To choose a word displayed in the list, scroll up and down using the up and

down navigation keys.

• To accept a word, press .

• To accept a word and insert a space, press the key.

BACK

• Press to erase a single character. Press and hold to delete an

entire entry.

BACK

Entering Text

Entering Text 21

Page 28

• To enter a period, press . To enter other special characters, press

and then repeatedly press to cycle through other special

characters until the desired character is displayed. If the desired character

does not display, press the right softkey for Options and select Symbol.

• To insert a number, press and hold the corresponding number key.

To enter text using T9:

1. From the text entry screen (for example, a new event in scheduler),

press the right softkey for Options and select T9 (English).

2. Use your keypad to enter the new event.

Alpha Mode

To enter characters by tapping the keypad, select the Alpha mode. Press the corresponding key repeatedly until the desired character appears.

Use the key to switch between uppercase, lowercase, and mixed case.

To enter text using Alpha:

1. From a text entry screen, press the right softkey for Options and

select Alpha.

2. Use your keypad to enter the contact's name. Characters scroll in the

following order:

. , @ 1 ? ! * # / P Q R S p q r s 7

ABC

A B C a b c 2 T U V t u v 8

D E F d e f 3 W X Y Z w x y z 9

DEF

G H I g h i 4 0

GHI

J K L j k l 5 Space

JKL

M N O m n o 6 Change case

MNO

After a character is entered, the cursor automatically advances to the next space after two seconds or when you enter a character on a different key.

PQRS

TUV

WXYZ

Note: When the Dual Language text option is enabled, accented characters are also displayed.

22 Entering Text

Page 29

Numbers, Symbols, Emoticons and Preset Messages

See "To change the character input mode:" on page 21 to enter the following types of input.

To enter symbols:

• Select the Symbol mode. To enter a symbol, press the corresponding

number key indicated on the display. Use the navigation keys to scroll up or down to see additional symbols.

To enter numbers:

• Select the Number mode and press the appropriate key.

To enter preset messages:

1. Select the Preset Msg mode.

2. Scroll to the desired pre-programmed message and press .

For more information on preset messages, see "Preset Messages" on page 57.

To enter “emoticons” (smileys):

• Select the Emoticons mode. To enter an emoticon, press the corresponding

number key indicated on the display. Use the navigation keys to scroll up or down to see additional emoticons. Emoticons are also referred to as “smileys”, which are icons that express an emotion through a facial expression.

Entering Text

Entering Text 23

Page 30

Roaming

Recognizing Icons on the Display Screen

Your phone’s display screen always lets you know when you’re off the network.

Roaming Indicator

Other Digital Networks

Note: You may pay a higher per-minute rate for roaming calls.

Roaming on Other Digital Networks

When you’re roaming, you may not be able to access certain features, such as web services.

Note: If you’re on a call when you leave the network and enter an area where roaming is available, your call is dropped. If your call is dropped in an area where you think service is available, turn your phone Off and On again to reconnect to the network.

Setting Your Roaming Mode

By using the Roaming menu option, you can determine which signals your phone accepts. Choose from three different settings on your phone to control your roaming experience:

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Others.

3. Select Roaming.

4. Select Set Mode.

5. To select an option, highlight it and press .

• Automatic: This setting seeks service. When service is unavailable,

the phone searches for an alternate system.

• 1X-Only Mode: This setting allows you to access 1X networks. No

EVDO service is available.

• Home Only Mode: This setting allows you to access the home

network only and prevents roaming on other networks.

24 Roaming

Page 31

Update PRL

You can manually update your PRL (Preferred Roaming List) to access additional networks provided by new roaming partners of your service provider, or by new systems that have been enabled. This typically results in either a better signal or expanded coverage. This is not a frequent activity and does not require constant checking. Access this feature if you know you will be traveling outside of your carrier's network to ensure that you always have the best coverage possible.

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Others.

3. Select Roaming.

4. Select Update PRL.

Roaming

1.This sub-menu may not be available depending on the UI version configured for your phone.

Roaming 25

Page 32

Voice Service

Voice recognition allows you to say commands to perform common functions supported by your phone.

To activate voice recognition:

1. Press and hold . (The phone prompts you to say a voice

command.)

2. Wait for the beep and then say one of the following commands:

TALK

• Call <Name or #> • Lookup <Name>

• Send Text <Name or #> • Go To <App>

• Send Email <Name> • Check <Item>

Note: If you want to use another button to activate voice recognition, in addition to

TALK

menu. Through this menu, you can change button assignments, including the button used to launch "Voice Service", which is the voice recognition application.

Call <Name or #>

You can dial any valid 7, 10 or 11 digit North American phone number. You can also dial by pronouncing a name stored in your Contacts.

Tips for using Call <Name or #>:

, press to activate the main menu, press the key for the Settings

• Voice Service works best in quieter environments.

• When saying a number, speak at a normal speed and say each digit clearly.

There is no need to pause between digits.

• The phone recognizes the digits one, two, three, four, five, six, seven, eight,

nine, zero, and oh. The phone does not recognize numbers such as "one eight hundred" for "1-800." Instead, say "one-eight-zero-zero."

• The phone recognizes only valid 7, 10 or 11 digit North American phone

numbers.

• If your phone does not usually recognize you correctly when you are using

Voice Service, try adapting Voice Service to your voice, which can significantly improve accuracy for some speakers. (See "Sensitivity" on page 29 for details.)

26 Voice Service

Page 33

To place a call using Call <Name or #>:

1. Activate voice recognition. (See page 26.)

2. Say “Call” followed by either a name stored in your Contacts or a valid

7, 10 or 11 digit North American phone number naturally and clearly.

• If the phone asks you, "Did You Say," followed by the correct number,

say Yes . (You can also select the correct number from those displayed on the screen by pressing on the correct number. The phone will then dial the number.)

• If the phone asks you, "Did You Say," followed by an incorrect

number, say No. (If there are other alternatives, the phone will prompt you with the next one. You can also press the navigation key up or down to select the correct number from the Choice List, and then press to dial.)

3. Alternatively, you can call a person in your Contacts by saying the

name of the person, exactly as it is entered in your Contacts. (The phone plays the name through the earpiece and displays it on the screen.)

If you said a name listed in your Contacts that has more than one number associated with it, the phone displays the different locations (Home, Work, Mobile, Pager, Others) and asks you which one to dial. Say one of the location names and the phone will dial the number for the location you specified.

Send Text <Name or #>

To compose a text message using Voice Service:

1. Activate voice recognition. (See page 26.)

2. Say “Send Text” followed by either a name stored in your Contacts or a

valid 7, 10 or 11 digit North American phone number.

• If the phone asks you, "Did You Say," followed by the correct number,

say Yes . (You can also select the correct number from those displayed on the screen by pressing on the correct number.)

• If the phone asks you, "Did You Say," followed by an incorrect

number, say No. (If there are other alternatives, the phone will prompt you with the next one. You can also press the navigation key up or down to select the correct number from the Choice List.)

3. Compose your text message. For more information, see "To send a text

message:" on page 53, beginning at step 6.

Voice Service

Voice Service 27

Page 34

Send Email <Name>

To compose email using Voice Service:

1. Activate voice recognition. (See page 26.)

2. Say “Send Email” followed by a name stored in your Contacts.

• If the phone asks you, "Did You Say," followed by the correct name,

say Yes . (You can also select the correct address from those displayed on the screen by pressing on the correct number.)

• If the phone asks you, "Did You Say," followed by an incorrect name,

say No. (If there are other alternatives, the phone will prompt you with the next one. You can also press the navigation key up or down to select the correct address from the Choice List.)

3. Compose your email message using the keypad. For more information,

see "To send a text message:" on page 53, beginning at step 6.

Lookup <Name>

You can retrieve contact information for any person in your Contacts by saying the full name of the person.

To retrieve information using Lookup <Name>:

1. Activate voice recognition. (See page 26.)

2. Say “Lookup” followed by the name of the person, exactly as it is

entered in your Contacts. (The phone will play the name it recognized through the speaker, and then open the contact information for that name.)

If the phone says, "Did You Say," followed by an incorrect name, say No. The phone then prompts you with the next name, if there is one. If there are no more names, the phone will say "Sorry, No Match Found."

Go To <App>

You can open an application or access a menu by saying “Go To” followed immediately by the “destination,” either an application or menu.

To see a list of possible destinations:

1. Activate voice recognition. (See page 26.)

2. Say “Go To” by itself. A list of valid destinations is displayed and

prompts you with “Please Choose.” If the list is too long to fit on one screen, the screen displays “Next Menu.” You can say the name of a destination, or say “Next Menu” to view the next screen.

28 Voice Service

Page 35

Check <Item>

The voice recognition Status option gives you an update on your phone's service, signal strength, and battery level.

To retrieve your phone's status information:

1. Activate voice recognition. (See page 26.)

2. Say “Check” followed immediately by one of the following items:

• Status plays back and displays ALL status information.

• Battery plays back and displays the current level of battery charge.

• Signal plays back and displays current signal strength.

• Network plays back and displays the type of network coverage.

• My phone # plays back and displays your phone number.

Customizing Voice Service

Choice Lists

You can customize whether the Voice Service feature displays the list of top voice recognition choices or automatically dials the first number, without displaying a choice list.

To enable or disable choice lists for Voice Service:

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Voice Service.

3. Select Choice Lists.

4. Press the navigation key up or down to select Automatic, Always On or

Always Off and press .

Sensitivity

You can adjust your phone’s sensitivity to sounds when listening for voice commands or names, making it require a more exact or less exact sound match before responding to your command.

To adjust your phone’s Voice Service sensitivity:

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Voice Service.

3. Select Sensitivity.

Voice Service

Voice Service 29

Page 36

4. Press the navigation key up or down to select Reject The Most, Reject

More 2, Reject More 1, Recommended, Reject Less 1, Reject Less 2, or Reject The Least and press .

If you select Reject More, your phone will require a more exact sound match and if you select Reject Less, your phone will require a less exact sound match.

Digit Dialing

Some users with heavy accents or unusual voice characteristics may encounter difficulty in achieving high accuracy with speaker independent Voice Dialing. The Adapt Digits feature allows users to dramatically improve the digit accuracy through adaptation.

To adapt Voice Service to your voice:

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Voice Service.

3. Select Digit Dialing.

4. Select Adapt Digits. (The phone displays the first digit sequence.)

5. When you are ready to start recording, press . (The phone prompts

you to say the first sequence of digits.)

6. Wait for the beep, and then repeat the digits using a normal tone of

voice. (The phone plays back your recording and asks you if the recording sounds "OK.")

• If the recording sounds OK (no mistakes and no background noises),

say Yes .

• If you need to re-record the digits to fix any problems, say No. (The

phone then prompts you to say the digits again.)

7. After confirming that the recording sounds OK, repeat the recording

process with the next set of digits. In total, there are 10 sets of numbers. When you are finished with a full session, you will reach a screen that reads, “Adaptation Complete.”

To erase any adaptation and reset Voice Service to its original state:

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Voice Service.

3. Select Digit Dialing.

30 Voice Service

Page 37

4. Select Reset Digits.

5. Press the left softkey for OK.

Sound

By default, your phone provides audio prompts such as “Please say a command”. You can turn these prompts on or off.

To turn Voice Service prompts On or Off:

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Voice Service.

3. Select Sound.

4. Select Prompts, Digits, Names, or Name Settings.

5. Press the navigation key up or down to select the appropriate setting

and press .

To modify your Voice Service prompts:

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Voice Service.

3. Select Sound.

4. Select Name Settings.

5. Select Speed or Volume.

6. Press the navigation key up or down to select the appropriate setting

and press .

Voice Launch

You can change your phone’s settings to activate Voice Dialing whenever you open your phone.

To change your Voice Launch method:

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Voice Service.

3. Select Voice Launch.

4. Press the navigation key up or down to select Talk Key or Talk Key &

Flip Open and press .

Voice Service

Voice Service 31

Page 38

About

You can view information about the version of your Voice Service application.

To view Voice Service information:

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Voice Service.

3. Select About.

32 Voice Service

Page 39

Main Menu

User Interface

The SPH-m530 is equipped with the capability to provide multiple user interfaces that can provide a different look and feel, and be customized to user preference. The availability of a customized user interface is subject to your service provider.

Below the idle screen, all user interfaces provide a main menu to support the operation and configuration of the handset's feature. This will be accessible via either a special soft "button" (softkey) or pressing the key. This user guide focuses on describing the functions and features of the main menu. For other ways to access the main menu, please see the additional printed material that comes with your phone or talk to your service provider's customer support.

Menu Styles

Your phone can display the various features and options in one of two different menu styles: grid and list. By default, your handset is set to the grid menu style.

Grid style

The grid style displays the first level menu choices with graphical icons arranged in a grid pattern. In other menu levels, choices are arranged in a vertical list.

• To navigate through a first level menu, simply press the navigation key in

the direction towards your desired menu choice. The currently highlighted menu choice is enlarged and the text label appears at the top of the screen. Once the desired menu option is highlighted, press .

List style

The list style displays all the various menu choices in a vertical list. As you navigate through the menu, menu options are highlighted. You can use your navigation keys to scroll through menus quickly and easily. The scroll bar at the right of the menu keeps track of your position in the menu at all times.

• To navigate through a menu, simply press the navigation key up or down. If

you are in a first-level menu, such as Settings, you may also navigate to the next menu by pressing the navigation key left or right.

• You can also press the number on the keypad that corresponds to the menu

choice to immediately access the menu.

Main Menu

Main Menu 33

Page 40

Changing the Phone’s Menu Style

Your phone allows you to choose how the menu appears on your display screen. To select the display’s menu style:

1. Activate the main menu.

2. Press the right soft key for List View.

Menu Layout

The grid menu consists of the following menus:

1: Web 2: Ringers 3: Entertainment

4: Calls 5: Missed Alerts 6: My Downloads

7: Camera 8: Messaging 9: Contacts

*: Settings 0: Tools #: Phone Support

The list menu consists of the same menus in the following order:

1: Web

2: Ringers

3: Entertainment

4: Calls

5: Missed Alerts

6: My Downloads

7: Camera

8: Messaging

#: Phone Support

34 Main Menu

9: Contacts

*: Settings

0: Tools

Page 41

Each menu (in alphabetical order) provides the following group of functions and features:

• Calls: Manage incoming, outgoing, missed, and recent calls. Please see

"Calls" on page 38 for more information.

• Contacts: Manage your phone book. Please see "Contacts" on page 80 for

detail description.

• Camera: Use the Camera and Camcorder features. Please see "Camera" on

page 71 for more information.

• Entertainment: Play live and pre-packaged video and audio. Please see

"Entertainment" on page 39 for more information. Purchase and listen to downloaded music. Please see "Music" on page 41 for more information.

• Messaging: Stay in touch with others via messaging. Please see

"Messaging" on page 53 for more information.

• Missed Alerts: Display list of missed alerts to catch up with events. Please

see "Missed Alerts" on page 49 for more information.

• My Downloads: Download contents like screen savers, themes, ringers,

games, and applications to personalize your phone. Please see "My Downloads" on page 50 for more information.

• Phone Support: Access a directory of useful customer service and

assistance. Please see "Phone Support" on page 96 for more information.

• Ringers: Access and configure settings for the ringer, voice calls,

messaging, and the scheduler. Please see "Sounds" on page 87 for more information.

• Settings: Configure the phone to your preferences and network

environment. Please see "Settings" on page 84 for more information.

• Too ls : Access productivity tools to help manage your daily work. Please see

"Tools" on page 62 for more information.

• Web: Access the internet to browse pages customized for mobile devices.

Please see "Web" on page 36 for more information.

Main Menu

Main Menu 35

Page 42

Web

When you launch the browser, the phone will connect to the Internet and the service indicator icon will display.

Launching the Web Browser

• Activate the main menu, highlight the Web menu, and press .

The first time you use the Web Browser, you will be prompted to go through a setup process that takes approximately three minutes. If you had a previous web connection, the last page you visited will be displayed.

Navigating the Wireless Web

Use the following keys to navigate the Web:

Softkeys Select an item

Navigation key Scroll up and down on a web page

Volume keys Scroll one page at a time

Use the following tips when navigating the Web:

• Select on-screen items by using the navigation key to highlight the desired

item, then press the desired softkey button (or press ).

You'll find that the left softkey is used primarily for selecting items. This softkey is often labeled OK or Go.

• If the items on a page are numbered, you can use your keypad (number

keys) to select an item.

• Select links by highlighting the link and then selecting the appropriate

softkey.

Tip: The tenth item in a numbered list may be selected by pressing the 0 key on your phone’s keypad, even though the number 0 doesn’t appear on the screen.

• To go back one page, press on your phone. (Note that is also used

like a BACKSPACE key to delete text.)

36 Web

BACK

Page 43

Using the Menu to Navigate

By pressing the Menu softkey, you can navigate between web pages. Press the Menu softkey and select one of the following options:

1. Home to return to the carrier’s home page.

2. Forward one web page (if you have not returned from a previous web

page, this option is greyed out).

3. Mark this Page to create a Bookmark.

4. View Bookmarks to see your list of Bookmarks.

5. Search takes you to a search engine.

6. Send page to embeds the current URL in a picture or video message

that can be sent to others.

7. Go to URL to directly jump to a specific web page.

8. History to see a list of web pages you have browsed this session.

9. Refresh this page reloads the current web page.

0. More displays the following options:

• Show URL to view the URL of your current webpage.

• Restart Browser to reload your Browser and return to your home

page.

• Script Log shows any scripting errors that have occurred on the

page.

• About Browser to view information about your Mobile Browser.

• Preferences to change your Mobile Browser preferences.

Web

Web 37

Page 44

Calls

Your phone will display calls you have missed. You can also access your list of recent calls from the idle screen by pressing the key.

Calls Options

When in a call history menu (Incoming, Outgoing, Missed, or Recent), press the right softkey for Options to select one of the following options for a call:

TALK

• Save to create a new Contact for this phone number. (Appears only if this

number is not already stored as a Contact.)

• Prepend to add a dialing prefix to the phone number prior to calling.

(Appears only if this number is not already stored as a Contact.)

• Erase to erase this number from your call history.

• Erase All to erase all entries.

Note: To view additional information about a call, highlight the call and press . The hour and date of the call are displayed.

Making a Call From the Calls Menu

Activate the main menu, highlight the Calls menu, and press .

2. Select Incoming Calls, Outgoing Calls, Missed Calls, or Recent Calls.

3. Highlight the entry you want to call and press to dial the number.

TALK

Voicemail

Please see "Voicemail" on page 55 for more information.

Settings

Please see "Settings" on page 57 for more information.

38 Calls

Page 45

Entertainment

The Entertainment menu allows you to listen, view, and download media content onto your phone. The content can be streamed to your phone from your network provider's server, which allows you to stay up to date, or from your memory card. After you access the Entertainment menu, you will see the following options:

• TV & Radio displays television and radio clips that are available on the network or

your memory card.

• Music

displays music files that are available for purchase and download.

• Memory Card displays all the media content that is saved on your memory card,

if installed.

TV & Radio

Activate the main menu, highlight the Entertainment menu, and press

2. Highlight TV & Radio and press . Please note that additional

charges may apply for accessing this service.

3. Once the application launches, navigate through the media content

offered by your service provider using the navigation keys. Press or the left softkey to make your selections.

4. Follow the on-screen instructions to purchase and play the desired

media clip.

Memory Card

You can also play media clips that you have stored on your memory card.

To play media from your memory card:

1. Activate the main menu, highlight the Entertainment menu, and press

2. Highlight TV & Radio and press .

3. Highlight Memory Card and press .

4. Navigate through the media content using the navigation keys. Press

or the left softkey to make your selections.

Entertainment

1.The Music and Movies sub-menus may not be available depending on the UI version configured for your phone.

Entertainment 39

Page 46

My Play List

You can create and use playlists to organize the media clips that you have stored on your memory card.

When you attempt to open a newly created playlist for the first time, you will receive the following prompt: “There is no content in My Play List. Copy from Media Listing?” Select Yes if you have media clips in the Media folder on your memory card that you want to add to the playlist. To add files to the playlist again at a later date, select the playlist and press the right softkey for Options, and select Add New.

To create a playlist:

1. Activate the main menu, highlight the Entertainment menu, and press

2. Highlight TV & Radio and press . Please note that additional charges

may apply for accessing this service.

3. Highlight Play List and press .

4. Press the right softkey for Options and select New Play List.

5. Enter a name for your playlist and press the left softkey for Done.

6. Highlight the new playlist name and press .

7. Select Yes to copy media clips from the Media folder on your memory

card.

8. Highlight a media clip that you wish to add and press to check/

uncheck it. When you are finished, press the left softkey for Done.

To start a playlist:

1. Activate the main menu, highlight the Entertainment menu, and press

2. Highlight TV & Radio and press . Please note that additional charges

may apply for accessing this service.

3. Highlight Play List and press . A list of playlists appears.

4. Select a playlist and press .

5. Select a media clip and press to begin playing.

40 Entertainment

Page 47

Music

Activate the main menu, highlight the Entertainment menu, and press

2. Highlight Music and press . The Music Store is displayed.

3. Follow the onscreen instructions to download songs or other audio

tracks. A service charge may apply.

Music Player

To start the music player:

1. Activate the main menu, highlight the Entertainment menu, and press

. The Music Store is displayed.

2. Highlight Music and press . The Music Store is displayed.

3. Select either All My Music or a desired playlist and press .

4. Select a song track and press to begin playing.

Note: You can also access the music player when the phone is flipped closed by pressing the up navigation key and selecting Music.

To exit the music player:

• Press . When the phone prompts you to confirm, highlight Exit

END

and press .

Music Player Controls

• Press to play or pause the current track.

• Press the right navigation key to skip to the next song in the current playlist.

• Press the left navigation key to skip to the previous song in the current

playlist.

• Press the up or down navigation key to display all the tracks in the current

playlist. Press up or down using the music player or navigation keys to move through the list and press to select a song.

• Use the side volume keys to adjust song volume.

• While the Media Player is running, you can flip open the phone and press

the right softkey for Menu to access one of the following options:

• Pause to pause the song.

• Repeat Song to repeat the current song.

Entertainment 41

Entertainment

Page 48

• Shuffle Order to randomize the current playlist.

• Go to Store to view and purchase new music.

• Go to Player to return to the main player menu.

Note: Flip the phone closed to access controls on the front to navigate tracks.

Memory Card

Connect to PC

You must insert a memory card into the phone in order to connect the phone to a computer. The memory card is the destination for all file transfer.

To transfer files between your phone and your computer:

1. Connect your phone to the data cable.

2. Connect the data cable to your computer.

3. Activate the main menu, highlight the Entertainment menu, and press

4. Highlight Memory Card and press .

5. Select Connect to PC. The phone now appears as a removable disk on

your computer.

Warning: Call is disabled when the device is connected as a mass storage device.

6. Using your computer’s navigation systems, transfer your files between

the computer and the phone.

Warning: Do not disconnect the phone from the data cable while transferring files! Please follow proper shutdown procedure for removable storage device to avoid file corruption.

42 Entertainment

7. When you are finished transferring files, press the left softkey for

Done. Highlight Yes and press to confirm.

8. It is now safe to remove the phone from the data cable.

Page 49

File Manager

You can view and manage the files stored on your phone. Your phone can include any of the following folders that are used by different applications:

• DCIM stores your photos and videos.

• MEDIA is used by the Media Player application. If you transfer music or

video files from your computer to your phone to be played by the Media Player application, you should place them here.

• music is used by the Music application. If you transfer music files from your

computer to your phone to be played by the Music application, you should place them here. The Music application can access both the MEDIA and Music folders but the Media Player will only access the MEDIA folder. It is advisable to put all music and video files in the MEDIA folder.

• filestore stores other types of files.

• OTHERS stores files received via a Bluetooth connection.

Note: There is no moving of files from one folder to another folder via the phone UI. If you need to move files, connect the phone to your computer via the data cable and use the Connect to PC application.

1. Activate the main menu, highlight the Entertainment menu, and press

2. Select Memory Card.

3. Select File Manager.

4. Using the navigation keys, highlight Phone or Memory Card and

5. Navigate through your phone’s menu tree to the desired file.

press .

• To erase a file, highlight the file to be deleted, and press the right

softkey for Options, followed by Erase.

• If the file is viewable or playable on your phone, press to view/

play. Not all files can be viewed or played.

Memory Info.

To view the amount of storage space used on your phone:

1. Activate the main menu, highlight the Entertainment menu, and press

Entertainment

Entertainment 43

Page 50

2. Select Memory Card.

3. Select Memory Info..

4. Using the navigation keys, highlight ALL, Phone or Card and

press .The amount of storage space used and available is displayed on-screen.

5. When you are finished, press the left softkey for Done.

44 Entertainment

Page 51

Bluetooth

Bluetooth is a short-range communications technology that allows you to connect wirelessly to a number of Bluetooth devices, such as mono or stereo headsets, hands-free car kits, and Bluetooth-enabled handhelds, PCs, printers, and wireless phones. The Bluetooth communication range is usually up to approximately 10 meters (30 feet).

Note: There are many Bluetooth devices in the market whose compatibility with the SPH-m530 cannot be guaranteed.

Enable

By default, your device’s Bluetooth functionality is turned off.

To turn Bluetooth on or off:

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Bluetooth.

3. Select Enable.

4. Select On or Off and press .

Bluetooth Status Indicators

The following icons show your Bluetooth connection status at a glance:

• Bluetooth is active and visible.

• Bluetooth is connected to a device.

• Bluetooth is active and hidden.

Visibility

The Visibility setting allows you to manage your availability to other Bluetooth devices.

To configure your phone’s visibility (discoverability) to other Bluetooth devices:

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Bluetooth.

3. Select Visibility.

4. Select your desired Visibility setting and press :

• Always visible allows other Bluetooth devices to detect and identify

your phone.

Bluetooth

Bluetooth 45

Page 52

• Visible for 3Min allows other devices three minutes before changing

your status to hidden.

• Hidden prevents other Bluetooth devices from detecting and

identifying your phone.

Device Name

Your phone’s Bluetooth name will appear to other in-range Bluetooth devices, depending on your Visibility settings.

To change your Bluetooth name for your phone:

1. Activate the main menu, highlight the Settings menu, and press .

Select Bluetooth.

3. Select Device Name.

4. Press and hold to clear the current name.

5. Use your keypad to enter a new name and press to save and exit.

Tip: Give your handset an easily recognized name so other people can select your handset quickly in environments where multiple Bluetooth devices are visible.

BACK

Device Info

To view the device information for your phone:

1. Activate the main menu, highlight the Settings menu, and press .

Select Bluetooth.

3. Select Device Info.

FTP Contents Folder

To set how the device receives contact information:

1. Activate the main menu, highlight the Settings menu, and press .

Select Bluetooth.

3. Select FTP Contents Folder.

4. Select Phone or Memory Card.

46 Bluetooth

Page 53

Pairing Bluetooth Devices

Paired Devices

The Bluetooth pairing process allows you to establish trusted connections between your phone and another Bluetooth device. When devices are paired, a passkey is shared between devices, allowing for fast, secure connections while bypassing the discovery and authentication process.

To pair your phone with another Bluetooth device:

1. Activate the main menu, highlight the Tool s menu, and press .

2. Select Bluetooth.

3. If no devices are currently listed, press the left softkey for Add New.

4. Select Search and press . Your phone displays a list of discovered

in-range Bluetooth devices.

5. Select the device you wish to pair with and press the left softkey

for Add to list.

6. Enter the passkey and press .

7. The name of the Bluetooth device is displayed. Press the left

softkey for Done. Pairing between the devices is complete at this point. To establish a working connection, please perform the next step.

8. Highlight the device and press the left softkey for Browse.

Connection Successful will display if the device is connected properly.

Note: When pairing your phone to a headset, press the the left softkey for Connect.

Waiting for Pairing

If you are going to be using a Dial-Up Network (DUN) profile to pair with a PC or PDA, you will want to allow the other device to initiate pairing with your phone.

To allow your phone to be paired with another Bluetooth device:

1. Activate the main menu, highlight the Tool s menu, and press .

2. Select Bluetooth.

3. If no devices are currently listed, press the left softkey for Add New.

4. Select Wait for request and press .

Bluetooth

Bluetooth 47

Page 54

5. Enter the passkey and press .

6. On the other device, initiate the search process. Follow the prompt and

enter any relevant information to complete the pairing.

Options

After a device is added to your list of Trusted Devices, press the right softkey to select from the following options (the list may change depending on the device type):

• Add New adds another device to your Trusted Devices list.

• Send Contact allows you to send one or more name cards from your

Contacts to the trusted device.

• Get Contact allows you to get the name card of the trusted device.

• Get Files allows you to receive a data file (Contacts, pictures, video, text,

etc.) from another Bluetooth® device.

• Send Files allows you to send a data file (Contacts, pictures, video, text,

etc.) to another Bluetooth® device.

• Edit Name shows the name given to your phone for Bluetooth® purposes.

You can edit the name if needed.

• Erase allows you to delete the highlighted trusted device.

• Erase All allows you to delete all the trusted devices.

• Auto-Accept allows you to accept requests from the trusted device without

being prompted for confirmation.

• Info allows you to view information about the highlighted trusted device.

• Settings allows you to set up many of the characteristics of your device’s

Bluetooth service.

48 Bluetooth

Page 55

Missed Alerts

The Missed Alerts menu serves as a centralized location so you don’t have to go through different menus to check for missed calls, unheard voice mail or unread messages, etc. This menu is only a reminder. The actual information is still saved in the various locations even when the missed alert has been viewed.

The Missed Alerts screen appears whenever you flip open your phone and you have unviewed Missed Alerts. You can also view your alerts by going to the Missed Alerts menu.

To view your Missed Alerts:

• Activate the main menu, highlight the Missed Alerts menu, and press .

Missed Alerts options

Using the navigation keys, highlight the desired alert and select one of the following:

• To view more details about the alert, press . Viewing the alert will delete

it from the Missed Alerts list.

• If the alert is a call, press the left softkey to Call the person back.

• If the alert is a voicemail message, press the left softkey to Listen to

the message. Follow the normal procedure you use to access the voice mail server.

• If the alert is a text or picture or video message, press the left softkey

to View the message.

• To delete an alert without viewing it, press the right softkey for

Dismiss.

Missed Alerts

Missed Alerts 49

Page 56

My Downloads

END

You can download the following types of items to your phone:

• Games allows you to download and play games. You can also play pre-

installed demo games.

• Ringers allows you to download and assign ringer types to voice calls.

• Screen Savers allows you to download and assign screen savers to your

phone.

• Tools allows you to download and run applications on your phone.

Downloading

To download items to your phone:

Activate the main menu, highlight the My Downloads menu, and press

2. Select Games, Ringers, Screen Savers, or Too ls .

3. Highlight the Get More option and press . The browser will launch

and take you to the specified download menu.

4. Use your navigation key to highlight and select an item you wish to

download. (For more information on navigating the Web, see “Navigating the Wireless Web” on page 36.)

5. Follow the web page instructions to complete your purchase.

Note: You may store a limited number of downloaded applications, ringers, screen savers, games, and themes on your phone, depending on the file sizes. When in the My Downloads menu, you can check the Memory Status by pressing the right softkey for Options, then highlighting Memory Status and pressing .

Playing Games

1. Activate the main menu, highlight the My Downloads menu, and press

2. Highlight Games and press .

3. Select the game you wish to play and press .

4. Follow the on-screen instructions to play the game. When you are

finished, select Exit (or Quit) or press .

50 My Downloads

Page 57

Assigning Ringers and Screen Savers

Assigning Downloaded Ringers

You may assign a ringer to more than one type of call.

1. Activate the main menu, highlight the My Downloads menu, and press

2. Highlight Ringers and press .

If you wish to hear the ringer, highlight the desired ringer and press . When you are finished, press to return to the Ringers menu.

3. Press the right softkey and select Set As....

4. Select Voice Calls.

5. Select With Caller ID or No Caller ID.

6. Press to exit.

END

Note: Downloaded ringers are also available through the Settings menu (see "To select Ringer Types for Voice Calls, Messaging and Scheduler:" on page 88).

BACK

Assigning Downloaded Screen Savers

You may assign a Screen Saver to more than one task.

1. Activate the main menu, highlight the My Downloads menu, and press

2. Highlight Screen Savers and press .

If you wish to see the screen saver, highlight the desired screen saver and press . When you are finished, press to return to the

BACK

Screen Savers menu.

3. Press the right softkey and select Set As....

4. Select Screen Saver.

5. Press to exit.

END

Note: Downloaded Screen Savers are also available through the Settings menu (see "Screen Saver" on page 84).

My Downloads 51

My Downloads

Page 58

Launching Applications

1. Activate the main menu, highlight the My Downloads menu, and press

2. Highlight To ol s and press .

3. Select the application you wish to launch and press .

4. Follow the on-screen instructions to launch the application. When you

are finished, select Exit (or Quit) or press .

Note: Your phone comes equipped with preloaded applications such as Backup Manager, GPS Nav, Media Player, and Windows Live. To activate these services,

please contact your service provider.

END

52 My Downloads

Page 59

Messaging

After you access the Messaging menu, you will see the following options:

• Inbox allows you to view text messages that you have received.

• Outbox allows you to view text messages that you have sent.

• Send Text allows you to send text messages.

• Drafts allows you to view saved text messages that you have not sent.

• IM & Email allows you to send instant and email messages.

• Voicemail allows you to listen to any voice messages saved in the voice

mail server.

• Web Alert allows you to review web alerts received from the network.

• Settings allows you to configure the messaging options.

Text Messaging

To send a text message:

1. Activate the main menu, highlight the Messaging menu, and press .

2. Select Send Text and press .

3. Using the navigation keys, select either the Contacts, Mobile #, or

Email box and press .

• if you selected Contacts, scroll through your Contacts list and press

to check/uncheck desired recipients. When you are finished,

press the left softkey for Done.

• if you selected Mobile # or Email, enter the recipient’s phone

number or email address and press .

Tip: The recipients of the message appear in the lower half of the screen. If you wish to send your text message to multiple numbers or addresses, repeat step 3. You can send a text message to a maximum of 10 numbers.

Messaging

4. Press the left softkey for Next.

5. Enter your message using the keypad. If you wish to change your text

message options, press the right softkey for Options and select one of the following:

1.The IM & Email sub-menu may not be available depending on the UI version configured for your phone.

Messaging 53

Page 60

• T9 (English) changes the text entry mode to T9. For more

information, see page 21.

• Alpha changes the text entry mode to Alphabet. For more

information, see page 22.

• Symbol changes the text entry mode to Symbol. For more

information, see page 23.

• Number changes the text entry mode to Numbers.

• Preset Msg allows you to choose from a list of Preset messages.

• Recent Msg allows you to choose a recent text message as a

template.

• Emoticons allows you to add emoticons such as : ) to your message.

• Text Options allows you to access the following options:

• Auto Capital: When on, capitalizes the first word of a sentence.

• Used Word Dic.: When on, adds the words used to the phone’s

dictionary.

• Display Cand.: When on and you are in T9 Mode, displays

possible word choices on the screen.

• Prediction Start: Sets the number of letters required to activate

the Display Candidate feature.

• Dual Language: When on and you are in T9 Mode, displays

choices from both the English and French dictionaries.

• Auto-Space: When on, adds a space after you select a word in T9

Mode.

6. Press the left softkey for Next when finished.

7. Press the left softkey to Send. If you wish to change your text

message options, press the right softkey for Options and select one of the following:

• Edit allows you to reenter the message recipients and the message.

• Priority allows you to set the priority level between Normal and

Urgent.

• Call Back # allows you to enter or omit a call back number in your

message.

54 Messaging

Page 61

• Save to Drafts stores a copy of the text message in your Drafts

folder.

To reply to the text message:

1. While the message is open, select the left softkey for Reply.

2. Compose your reply, or use a pre-composed messages.

• To type a message, use your keypad to enter text. Use the right

softkey to select a character input mode.

• To use pre-written messages, press the right softkey for Options

and select Preset Msg. Press the corresponding number on the keypad to enter the preset message response.

3. Press the left softkey for Next when finished.

4. Press the left softkey to Send.

To erase messages:

1. Activate the main menu, highlight the Messaging menu, and press .

2. Select Inbox.

3. Press the right softkey , followed by:

• Erase. Using the navigation keys select Erase This to delete the

currently highlighted message, Erase Read to delete all read messages, or Erase All to delete all messages in your Inbox and

press .

• Erase Multiple. Scroll through your list of messages and press

to check or uncheck messages you want to erase. When you are finished, press the left softkey for Erase.

Voicemail

All unanswered calls to your phone are automatically transferred to your Voicemail, even if your phone is in use or turned off. However, you are only notified of new messages when your phone is turned on and you are in a Service Area.

To set up your Voicemail:

1. Press and hold on your phone’s keypad.

2. Follow the system prompts to create your passcode, record your

greeting, and record your name announcement.

Messaging

Messaging 55

Page 62

To call your Voicemail:

• Press and hold on your phone’s keypad.

To display your Missed Calls:

MENU MENU

• Press , highlight the Calls menu, press , and select Missed Calls.

Important: When you are roaming off the network, you may not receive notification

of new Voicemail messages. It is recommended that you periodically check your Voicemail by dialing 1 + area code + your Phone Number. When your Voicemail answers, press the key and enter your passcode. You will be charged roaming rates when accessing Voicemail while roaming off the network.

Retrieving Your Voicemail Messages

You can review your messages directly from your phone or from any other touchtone phone. To dial from your phone, you can either speed dial your Voicemail or use the menu keys.

Using One-Touch Message Access

• Press and hold on your phone’s keypad. Follow the system prompts.

Using the Menu Keys on Your Phone to Access Your Messages

1. Activate the main menu, highlight the Messaging menu, and press .

2. Select Voicemail.

3. Select Call Voicemail to call the Voicemail server.

Clearing the Message Icon

Your phone may temporarily continue to display the message icon after you have checked your voice and text messages.

To clear the icon from the display screen:

1. Activate the main menu, highlight the Messaging menu, and press .

2. Select Voicemail.

3. Select Clear Envelope.

4. Press the navigation key up to select Yes and press .

Web Alert

Your phone is capable of receiving web alerts from online providers. Consult with your Service Provider for more details.

56 Messaging

Page 63

To access your web alerts:

1. Activate the main menu, highlight the Messaging menu, and press .

2. Select Web Alert.

3. Follow the on-screen instructions.

Settings

There are several options associated with voice mail, text and pic/video messaging. The Settings menu allows you to customize the options to fit your preferences.

To access the Settings menu:

1. Activate the main menu, highlight the Messaging menu, and press .

2. Select Settings.

General

General settings affect voice mail, text and picture/video messages.

• Notification allows you to configure whether new messages will appear

with a pop-up message or with an icon.

• Preset Messages allows you to edit, delete or add pre-written messages.

• Message Alert allows you to configure the Volume, Type, and Reminder

settings for Message Alerts.

• Auto-Erase sets the phone to automatically delete old messages from the

mail boxes when they become full. This allows new messages to be added to a full mail box without having to manually delete old messages to free up space first.

Notification

To change the display pop-up option:

1. In the Settings menu, select General.

2. Select Notification.

3. Select Message & Icon or Icon Only using the navigation key and press

to select.

Preset Messages

A preset message can be selected and automatically entered into the message.

To edit a preset message:

1. In the Settings menu, select General.

2. Select Preset Messages.

Messaging

Messaging 57

Page 64

3. Press the navigation key up or down to highlight the desired message or

available entry and press to edit.

4. Press and hold to erase the message. Enter your new message or

edit the existing one and press to save.

BACK

To delete a preset message:

1. In the Settings menu, select General.

2. Select Preset Messages.

3. Press the navigation key up or down to highlight the desired message.

4. Press the right softkey for Options.

5. Select Erase.

6. Select Yes .

To add a preset message:

1. In the Settings menu, select General.

2. Select Preset Messages.

3. Press the right softkey for Options.

4. Select Add New.

5. Enter your message using the keypad.

6. Press the left softkey for Done when finished to add your message

to the list.

Note: When you send a message using Preset Messages, the last message selected automatically displays as the first choice when sending a new message.

Message Alert

The Message Alert menu allows you to configure the volume and message reminder default settings for your messages.

To set the volume:

1. In the Settings menu, select General.

2. Select Message Alert.

3. Select Volume.

58 Messaging

Page 65

4. Select one of the following options:

• Voicemail

• Text Message

• Pic/Video Msg

5. Use the navigation keys to select the desired volume level and press

to save.

6. When you are finished, press the left softkey for Done.

To set the ringer type:

1. In the Settings menu, select General.

2. Select Message Alert.

3. Select Typ e.

4. Select one of the following options:

• Voicemail

• Text Message

• Pic/Video Msg

5. Press the navigation key left or right to select between Single Tones,

Ring Tones, Melodies, or Downloads and press .

6. Press the navigation key down to preview the first ringer. Press left or

right to preview the other ringers associated with the ringer group selected. When finished, press to save the desired ringer.

To set the message reminder option:

1. In the Settings menu, select General.

2. Select Message Alert.

3. Select Reminder.

4. Press the navigation key up or down to select the desired duration and

press to select.

Messaging

Messaging 59

Page 66

Auto-Erase

This option allows you to automatically delete old messages when the memory becomes full. This prevents new messages from being rejected due to the Inbox being full.

To turn this option On or Off:

1. In the Settings menu, select General.

2. Select Auto-Erase.

3. Press the navigation key up or down to select Yes or No and press

to select.

Text Message

Text Message settings only affect text messages.

• Save In Outbox allows you to save a copy of the outgoing text message in

the outbox.

• Priority allows you to configure the default Priority level for your text

message.

• Call Back # allows you to change the default call back number for your text

message.

• Edit Signature allows you to create a signature of up to 15 characters that is

automatically appended to all your text messages.

To turn the Save in Outbox option On or Off:

1. In the Settings menu, select Text Message.

2. Select Save in Outbox.

3. Press the navigation key up or down to select Yes or No and press

to select.

To select the priority level:

1. In the Settings menu, select Text Message.

2. Select Priority.

3. Select Normal or Urgent using the navigation key and press to

select.

To change the call back number:

1. In the Settings menu, select Text Message.

2. Select Call Back #.

60 Messaging

Page 67

3. Use the navigation key to highlight None, your mobile directory number,

or Other for a different phone number and press .

4. For the Other call back #, enter the number using the keypad and press

to save.

To edit your signature, or to turn signatures on or off:

1. In the Settings menu, select Text Message.

2. Select Edit Signature.

3. Press the navigation key up or down to highlight On or Off and

press .

4. If signatures are on, your current signature is now displayed. Press and

BACK

hold to erase the signature. Enter your new signature or edit the existing one using the keypad and press the left softkey or to

save.

Alerts setup

This menu allows you to set your phone to automatically connect to the Internet to receive Web Alerts.

1. In the Settings menu, select Alerts setup.

2. Press the navigation key up or down to select Yes or No and press

to select.

Voicemail #

This menu allows you to change your voice mail number.

To change your voice mail number:

1. In the Settings menu, select Voice Mail #.

2. Use the navigation key to highlight Other and press .

3. Enter the new voice mail # and press the left softkey for Done.

To change your voice mail back to the default voice mail:

1. In the Settings menu, select Voice Mail #.

2. Use the navigation key to highlight the default number and press .

Messaging

Messaging 61

Page 68

Tools

After you access Too ls menu, you will see the following options:

• GPS Nav allows you to launch the GPS Navigation system application on

your phone.

• Alarm Clock allows you to set multiple alarm times on your phone.

• Calendar helps organize your time and reminds you of important events.

• Calculator allows you to use your phone’s built-in calculator.

• Bluetooth allows you to connect wirelessly to other Bluetooth devices.

• World Clock displays the time in different time zones around the world

together with one or more major cities, states, regions, or countries in a time zone.

• Memo Pad allows you to compose and store reminders and notes to help

keep you organized.

• Voice Memo allows you to record brief memos to remind you of important

events, phone numbers, or other items.

• Update phone allows you to download and update the software in your

phone automatically. Only the internal software is updated; no contact entries or other information saved to your phone will be deleted.

GPS Nav

To use GPS Nav:

1. Activate the main menu, highlight the Tool s menu, and press .

2. Select GPS Nav. This launches the Telenav GPS Navigator application,

where you can enter your origin and destination and then receive voice and onscreen directions.

Alarm Clock

To use the alarm clock:

1. Activate the main menu, highlight the Tool s menu, and press .

2. Select Alarm Clock.

3. Select Alarm #1, Alarm #2, or Alarm #3.

4. Press the navigation key left or right and select On or Off.

5. Press the navigation key down once and enter the alarm time.

1.The GPS Nav sub-menu may not be available depending on the UI version configured for your phone.

62 Tools

Page 69

6. Press the navigation key down once to select the desired ringer. (Cycle

through the ringers by pressing the navigation key left or right.)

7. Press the navigation key down once to select the alarm frequency.

8. Press the navigation key left or right and select one of the following

options:

• Daily • Mon to Fri

• Once • Sat & Sun

9. Press the navigation key down once to select Snooze Interval. Press the

navigation key left or right and select the desired interval.

10. Press the left softkey for Done.

Calendar

There are four options available in the Calendar:

• Tod ay shows events that are scheduled for today. You can create new

events for later in the day.

• Scheduler shows a monthly calendar, highlighting days with scheduled

events. You can create new events for future dates.

• Task List shows a to-do list, with optional priority settings and due dates.

• Countdown allows you to enter a future date and time into the phone and

then see the amount of days, hours, and minutes until that time is reached.

Today

To add an event to today’s schedule:

1. Activate the main menu, highlight the Tool s menu, and press .

2. Select Calendar.

3. Select To day .

4. Press the left softkey for Add New.

5. Enter the event description using the keypad and press the left softkey

for Next.

Tools

Tools 63

Page 70

6. Set the event details using the navigation keys. Press up and down to

move between options and press left and right to change the currentlyhighlighted options: Event Type, Reminder, Recurrence, Alarm Ringer, Start (starting time), End (end time), and go to Contact. (When the scheduled event occurs, this entry will be displayed onscreen, making the person convenient to contact.)

7. When you are finished with the event details, press the left softkey

for Done.

Scheduler

To add an event for a specific calendar date:

1. Activate the main menu, highlight the Tool s menu, and press .

2. Select Calendar and then select Scheduler.

3. Using the navigation keys, scroll to the desired date.

4. Press the left softkey for View.

5. Press the left softkey for Add New.

6. Enter the event description using the keypad and press the left softkey

for Next.

7. Set the event details using the navigation keys. Press up and down to

move between options and press left and right to change the currently highlighted options: Event Type, Reminder, Recurrence, Alarm Ringer, Start (starting time), End (end time), and go to Contact. (When the scheduled event occurs, this entry will be displayed onscreen, making the person convenient to contact.)

8. When you are finished with the event details, press the left softkey

for Done.

Task List

To add a task:

1. Activate the main menu, highlight the Tool s menu, and press .

2. Select Calendar.

3. Select Task List.

• If you have no events currently scheduled for today, then the New

Tas k menu is automatically displayed.

64 Tools

Page 71

• If you have one or more events scheduled for today, they are

displayed. Press the left softkey for Add New.

4. Enter the task description using the keypad and press the left softkey

for Next.

5. Press the navigation keys left or right to select a Low or High priority.

6. Enter the Due Time and Date using the keypad. (Press the right

softkey to toggle between AM and PM.)

7. Press the left softkey for Done.

To view a task:

1. Activate the main menu, highlight the Tool s menu, and press .

2. Select Calendar.

3. Select Task List.

4. Use the navigation keys to scroll to the desired task and press to

view the task details.

To delete one or more tasks:

1. Activate the main menu, highlight the Tool s menu, and press .

2. Select Calendar.

3. Select Task List. If you wish to delete a specific task, highlight it using

the navigation keys.

4. When you press the right softkey for Options key, the following

options appear:

• Add New

• Set State

• Erase

• Erase All

5. Select Erase to erase the highlighted task or Erase All to erase all

tasks.

6. Highlight Ye s with the navigation key and press to confirm.

Countdown

To set up a new countdown:

1. Activate the main menu, highlight the Tool s menu, and press .

Tools

Tools 65

Page 72

2. Select Calendar.

3. Select Countdown.

• If there are no existing countdowns, the No Countdown Entered

screen is automatically displayed.

• If you have one or more composed memos, they are displayed. Press

the left softkey for Add New.

4. Enter a name using the keypad and press .

5. Enter the time and date values and press the left softkey for Done.

To view a countdown:

1. Activate the main menu, highlight the Tool s menu, and press .

2. Select Calendar.

3. Select Countdown.

4. Press the navigation key up or down to highlight the desired countdown

and press to view.

Tip: When viewing an existing countdown, press the navigation key left or right to cycle between the other countdown entries.

Viewing Events

To view your scheduled events:

1. Activate the main menu, highlight the Tool s menu, and press .

2. Select Calendar.

3. Select To day or Scheduler.

4. If you selected Scheduler, use the navigation keys to scroll to the

desired date and press the left softkey for View.

Erasing Events

To delete an individual event:

1. View the day from which you wish to erase the event.

2. Press the right softkey for Options.

3. Select Erase to erase the current event.

4. Highlight Ye s using the navigation key and press to confirm.

66 Tools

Page 73

To delete all scheduled events:

1. Activate the main menu, highlight the Tool s menu, and press .

2. Select Calendar.

3. Select Scheduler.

4. Press the right softkey for Options.

5. Select Erase All.

6. Highlight Ye s with the navigation key and press to confirm.

Calculator

To use the calculator:

1. Activate the main menu, highlight the Tool s menu, and press .

2. Select Calculator.

3. Enter a number with the keypad. (Use to insert a decimal point

and/or to make the number negative or positive.)

4. Use your navigation key to select a mathematical function:

• Left to Subtract

• Right to Add

• Up to Multiply

• Down to Divide

5. Enter the next number using the keypad. Repeat steps 4 and 5 as

necessary.

6. Press to view the results.

Bluetooth

For information on pairing Bluetooth devices, see "Pairing Bluetooth Devices" on page 47.

World Clock

To access the World Clock:

1. Activate the main menu, highlight the Tool s menu, and press .

2. Select World Clock.

3. Press the navigation key left, right, up, or down to display the different

time zones.

Tools

Tools 67

Page 74

4. Press the left softkey for DST Setting to turn Daylight Savings Time

(DST) On or Off. The DST setting is intended to show the time if DST is on or off. It is not intended to show if DST is in use for a particular region/country/city.

Memo Pad

To compose a memo:

1. Activate the main menu, highlight the Tool s menu, and press .

2. Select Memo Pad.

• If you have no memos composed, then the New Memo menu is

automatically displayed.

• If you have one or more composed memos, they are displayed. Press

the left softkey for Add New.

3. Enter up to 160 characters in the memo using the keypad and press the

left softkey for Save.

To view a memo:

1. Activate the main menu, highlight the Tool s menu, and press .

2. Select Memo Pad.

3. Use the navigation keys to scroll to the desired memo and press to

view the memo details.

To delete saved memos:

1. Activate the main menu, highlight the Tool s menu, and press .

2. Select Memo Pad.

3. Highlight the memo you wish to delete using the navigation keys.

4. Press the right softkey for Options.

5. Select Erase to erase the highlighted memo or Erase All to erase all

memos.

6. Highlight Ye s with the navigation key and press to confirm.

Voice Memo

A total of 10 minutes in 10 separate memos can be recorded and saved. Individual memos can record up to 60 seconds of audio.

68 Tools

Page 75

Recording Voice Memos

To record a voice memo:

1. Activate the main menu, highlight the Tool s menu, and press .

2. Select Voice Memo.

3. Select Record. (The phone prompts you to start recording after the

beep.)

4. Wait for the beep and then start speaking.

Press the left softkey to Pause the memo. (When a memo is paused, press the left softkey again to Resume recording.)

5. To finish recording, press or the right softkey for Finish.

To record a conversation during a phone call:

1. During a call, press the right softkey for Options.

2. Select Voice Memo.

Press the left softkey to Pause the memo. (When a memo is paused, press the left softkey again to Resume recording.)

3. Press the right softkey for Done to end the recording prior to the

countdown completion.

Note: When recording a conversation during a call, only the other speaker's audio is recorded.

Reviewing and Erasing Memos

To play the voice memos you have recorded:

1. Activate the main menu, highlight the Tool s menu, and press .

2. Select Voice Memo.

3. Select Review. (The phone displays a list of saved memos, with the

first one selected.)

4. Select a memo and press .

— or —

Press the number corresponding to the memo you want to review. (The phone replays the memo.)

Tools

Tools 69

Page 76

Press the left softkey to Pause the memo. (When a memo is

paused, press the left softkey again to Resume playing.)

To erase an individual memo:

1. Activate the main menu, highlight the Tool s menu, and press .

2. Select Voice Memo.

3. Select Review. (The phone displays a list of saved memos, with the first

one selected.)

4. Highlight the memo to erase.

5. Press the right softkey for Options and select Erase.

6. Press the navigation key up to select Yes and press .

To erase all voice memos:

1. Activate the main menu, highlight the Tool s menu, and press .

2. Select Voice Memo.

3. Select Erase All.

4. Press the navigation key up to select Yes and press .

70 Tools

Page 77

Camera

You can activate the camera and take pictures when the phone is open. In addition to taking pictures, you can also record, view, and send videos to your friends and family with your phone’s built-in video camera.

To take a picture:

1. Activate the main menu, highlight the Camera menu, and press .

2. Select Camera.

Shortcut: To activate Camera mode, you can also press and hold the side camera

button (see illustration on page 1).

3. Using the phone’s front LCD as a viewfinder, aim the camera lens at

your subject.

• To zoom in or out, press the left and right navigation keys. The levels

of zooming available depends on the resolution selected.

• To adjust the brightness, press the up and down navigation keys.

4. Press either the left softkey for Capture, or the side camera

button until the shutter sounds. (Make sure the camera is steady.)

The picture taken appears on-screen and is saved in your default file location. For more information, see "Status Bar" on page 79.

To record a video:

1. Activate the main menu, highlight the Camera menu, and press .

2. Select Camcorder.

3. Select either:

• Video Mail to take a short video up to 30 seconds that is suitable for

transfer via Pic/Video messaging.

• Long Video to take a longer video. Videos over 512 KB cannot be

sent via messaging. The length of the video depends on how much free memory remains in your handset.

4. Using the phone’s main LCD as a viewfinder, aim the camera lens at

your subject. To zoom in or out, press the right and left navigation keys.

5. Press the left softkey for Record. Make sure the camera is steady.

Camera

Camera 71

Page 78

6. When you are finished recording, press the left softkey again for

Done.

Camera and Camcorder Options

Once you have captured the picture or video, you can press the right softkey for Options (Next if you are in Camcorder mode) and select one of the following options:

• Send Msg to send your picture to someone using Pic/Video Msg. For more

information. See "Send Pic/Video" on page 76.

• Play to view your video (Camcorder Mode).

• Camera Mode to take another picture (Camera Mode).

• Upload to upload the picture/video to your online folder. See "Creating an

Online Album" on page 76.

• Assign to assign the picture/video to a Picture ID or Video Ringer, or Voice

Calls. See "Display" on page 84.

• Erase to erase this picture/video.

• Send to Other to send the picture/video to an online service provider.

• Camcorder to take another video (Camcorder mode).

• Review Albums to review the pictures/videos stored in your camera.

• To exit Camera or Camcorder Mode, press .

Camera Settings

The settings associated with the full-color digital camera allow you to customize how the camera operates when taking pictures.

To set a camera option:

1. Start the camera. For more information, see "To take a picture:" on page

71.

2. Press the right softkey for Options.

3. Press the number key corresponding to the desired option.

END

• Self-Timer allows you to configure a timer to be Off, 5 Sec or 10 Sec.

• Fun Tools allows you to select either Fun Frames or Color Tones.

• Controls allows you to set the Brightness, White Balance, and Night

Shot for your pictures.

• Brightness allows you to set the brightness level. Press the

navigation key up or down to increase or decrease the desired brightness.

72 Camera

Page 79

• White Balance allows you to set up the white balance of the

camera automatically or manually using the different preset modes. The modes available are Auto, Sunny, Cloudy, Tungsten, Fluorescent, Manual.

• Night Shot allows you to take a picture in low light levels. Set it to

be Off (default) or On.

• Settings allows you to change the following camera settings:

• Resolution allows you to change the resolution of images. Images

taken at a higher resolution require more memory to save. The available sizes are 1.3 M (1280x960), High (640x480), Med

(320x240), Low (176x220).

Tip: While in Capture mode, the zoom feature is available using the navigation keys.

As the resolution increases, zooming capability is reduced. At the highest resolution (1.3MP), the zoom feature is not available.

• Quality allows you to select between Fine, Normal,and Economy.

These settings reflect the image quality settings for the pictures.

• Shutter Sound allows you to select between different shutter

sounds. The shutter sound is heard when you take a picture.

• Status Bar allows you to switch the Status Bar On or Off.

• Storage allows you to switch the saved file location between

Phone or Memory Card.

• Review Pictures allows you to review pictures currently stored in

your camera’s internal or external memory.

• Camcorder switches the phone to Camcorder mode. For more

information, see "To record a video:" on page 71.

Setting the Self-timer

To activate the Self-timer and get yourself in the picture:

1. With the phone open and in Camera mode, press the right softkey

for Options.

2. Select Self-Timer.

3. Using the navigation key, highlight the length of delay you want the

timer to use (5 or 10 seconds) and press .

4. Press the left softkey for Capture. (A timer is displayed in the upper

right portion of the main LCD during the Self Timer countdown)

Camera

Camera 73

Page 80

5. Prepare for the picture. At 3 seconds, the timer icon turns red.

To cancel the Self Timer after it has started:

BACK

• Press .

Camcorder Options

The settings associated with the full-color digital camcorder allow you to customize how the camcorder operates when taking videos.

To set a camcorder option:

1. Start the camera. For more information, see "To record a video:" on page

71.

2. Press the right softkey for Options.

3. Press the number key corresponding to the desired option.

• Self-Timer allows you to configure a timer to be Off, 5 Seconds or 10

Seconds.

• Color Tones allows you to select between several different color

tones by pressing the navigation key left or right. When you find the desired tone, press .

• Controls allows you to set the Brightness, White Balance, and Night

Shot for your videos.

• Brightness allows you to set the brightness level. Press the

navigation key left or right to increase or decrease the desired brightness.

• White Balance allows you to set up the white balance of the

camcorder automatically or manually using the different preset modes. The modes available are Auto, Sunny, Cloudy, Tungsten, Fluorescent, Manual.

• Night Shot allows you to record a video in low light levels. Set it to

be On or Off.

• Settings allows you to change the following camcorder settings:

• Quality allows you to select between Fine, Normal,and Economy.

These settings reflect the image quality settings for the videos.

• Save Video To allows you to change the saved file location

between Phone and Memory Card.

• Review Albums allows you to review pictures and videos currently

stored in your phone’s memory.

• Take a Picture switches the phone to Camera Mode. For more

information, see "Camera" on page 71.

74 Camera

Page 81

Photo Album

Your media can be stored in the phone, on your memory card, or in an Online Album.

To view media stored in an Album:

1. Activate the main menu, highlight the Camera menu, and press .

2. Select My Albums.

3. Select either In Phone, Memory Card or Online Albums and press .

4. Use the navigation keys to scroll though your media. The media type is

indicated by either a camera or a camcorder icon in the top right corner.

• To select/unselect the currently-highlighted picture or video,

press to check/uncheck the box beside the item.

• To view the currently-highlighted picture or video, press the left

softkey for Expand.

• To access the video or picture options, press the right softkey for

Options.

Photo Album Options

Some of the options described below are available only for videos or still pictures:

• Play (video only) the current video.

• Send the picture or video to another user using Pic/Video Msg.

• Upload the picture or video to an online album.

• Print (picture only) to print selected pictures.

• Assign to assign the current picture as a Picture ID, Screen Saver, or Voice

Calls.

• Erase to erase the selected pictures and videos.

• Copy/Move to copy or move the files to the memory card.

• Detail/Edit to attach a text message or view the media information

associated with the picture or video.

• Album list to display the list of albums saved in your phone.

• Media Filter to filter just pictures, just videos or to display all media types.

• Camera Mode (picture only) switches back to the camera.

• Make a Video (video only) switches back to the camcorder.

Camera

Camera 75

Page 82

Creating an Online Album

The first time you access Online Albums you will need to establish a Picture Messaging password. This password will also allow you to log in to the Picture Messaging Web site. Please contact your service provider for the web site details to access and manage your uploaded pictures and albums.

To create your Picture Messaging password:

1. Activate the main menu, highlight the Camera menu, and press .

2. Select My Albums.

3. Select Online Albums and press .

4. Follow the on-screen instructions.

Once you have received confirmation that your account has been successfully registered, you may upload and share pictures and access the Picture Messaging Web site.

To access the Picture Messaging Web site:

1. From your computer’s web browser, go to the Picture messaging web

site provided by your service provider.

2. Enter your Phone Number and Picture Messaging password to log in.

Send Pic/Video

To send Pic/Video messages from your phone:

1. Activate the main menu, highlight the Camera menu, and press .

2. Select Send Pic/Video.

3. Press the left softkey for Compose.

Note: If you have not registered and configured this feature, you will be prompted to do so. Follow the instructions on screen, then continue with this procedure.

4. Using the navigation keys, select either the Contacts, Mobile #, or

Email box and press .

• if you selected Contacts, scroll through your Contacts list and press

to check/uncheck desired recipients. When you are finished,

press the left softkey for Done.

76 Camera

Page 83

• if you selected Mobile # or Email, enter the recipient’s phone number

or email address and press .

Tip: The recipients of the message appear in the lower half of the screen. If you wish to send your text message to multiple numbers or addresses, repeat step 4. You can send a text message to a maximum of 10 numbers.

5. Press the left softkey for Next.

6. Using the navigation keys select:

• In Phone, Memory Card or Online Albums to send a picture or video

that is already saved. Use the navigation keys to highlight an item and

press .  A checkmark appears beside the picture or video. You can select more than one. Once you have finished selecting all the pictures or videos you wish to send press the left softkey for Next.

• Select Take New Picture to take a new picture prior to sending your

message. For more information on taking a picture, see "To take a picture:" on page 71.

• Select Take New Video to take a new video prior to sending your

message.

• Select Text Only to make your message text only. Although this

message is text only, it is not sent as a simple text message (SMS), and the receiver will receive the message differently depending on his or her phone's capability.

7. When you have finished entering all the desired destinations, press the

left softkey for Next.

• If you wish to add a subject or text to your picture message,

highlight Subj: or Tex t: and press the right softkey for Add. Enter your text and press the left softkey for Next.

• If you wish to add an audio clip, highlight Audio: and press the right

softkey for Record. From the Add Voice Memo screen, press the left softkey for Record to record your message. When finished, press the left softkey for Done.

8. Press the left softkey for Send.

Camera

Camera 77

Page 84

A USB data cable must be connected between the printer and the phone before any printing can occur.

To print pictures from your phone:

1. Insert one end of the data cable into the USB slot on the printer.

2. Activate the main menu, highlight the Camera menu, and press .

3. Select Print.

4. Insert the data cable into your phone.

5. Read the onscreen “Connect Printer” message and press the left

softkey for Next.

6. Highlight the desired image and press the left softkey for Next. (To

select multiple images, press to place a check mark next to each image selected.)

7. Highlight Copies and press the navigation key left or right to select the

desired number of copies to print.

8. Press the navigation key down to select Size. Press the navigation key

left or right to select one of the following sizes:

• 4x6

• Default

Note: These sizes may vary and are dependent on the printer’s capabilities.

9. Press the navigation key up to select Type . Press the navigation key left

or right to select one of the following:

• Standard prints the standard image.

• Index prints the index information.

Note: These options may vary and are dependent on the printer’s capabilities.

10. Press the navigation key down to select Border. Press the navigation

key left or right to select on or off.

11. Press the navigation key up to select Date Print. Press the navigation

key left or right to select on or off.

78 Camera

Page 85

12. Press the right softkey to Preview the image or press the left

softkey to Print the image.

13. Select Yes to confirm printing and press .

Settings

Auto Save To

You can change the default saved file location for your pictures and videos. Select

Phone or Memory Card and press .

Note: Even when this setting is set to Memory Card, photos and videos will be

saved to the phone if the memory card is not in the phone. The File Manager can be used to move the media files to the memory card later.

Status Bar

You can set whether the status bar icons are displayed onscreen while taking pictures or recording videos. Select On or Off and press .

Account Info

The Account Info screen allows you to check the details of your online album(s), such as your account number, the number of pictures you have loaded, and comments. Contact your service provider for more details.

Camera

Camera 79

Page 86

Contacts

TALK

Finding Contacts

1. Activate the main menu, highlight the Contacts menu, and press .

2. Select Find.

3. Scroll down through your list of contacts to highlight the name and

press to make the call.

Adding a New Contact

Your phone can store up to 1000 phone numbers. Each contact entry can store up to a total of five phone numbers (plus one email address), and each entry’s name can contain up to 20 characters.

1. Enter a new phone number and press the right softkey for Options.

2. Press Save and select New Entry.

3. Select the Label using the navigation keys (Mobile, Home, Work, Pager,

or Others) and press .

4. Enter the name using the keypad and press .

5. Press the left softkey for Done.

Editing an Existing Contact

To add a number to an existing entry:

1. Activate the main menu, highlight the Contacts menu, and press .

2. Select Find.

3. Select the desired entry and press .

4. Press the right softkey to Edit the entry.

5. Scroll down to the Add Number box. Enter the phone number using the

keypad and press .

6. Select a label (Mobile, Home, etc.) for this number and press .

7. When you are finished, press the left softkey for Done.

To edit an entry’s phone number:

1. Activate the main menu, highlight the Contacts menu, and press .

2. Select Find.

3. Select the desired entry and press .

4. Press the right softkey to Edit the entry.

80 Contacts

Page 87

5. Select the phone number (Home, Work, etc.) to be edited, and

6. Press and hold to erase the entire number or press once to erase

press .

BACK

just the last digit.

7. Enter the phone number and press .

8. If you want to change the label (Mobile, Home, Work, etc.) of the

selected number, press the right softkey for Options and select Change Label. Select the new label and press .

9. Press the left softkey for Done.

To select a ringer type for an entry:

1. Activate the main menu, highlight the Contacts menu, and press .

2. Select Find.

3. Select the desired entry and press .

4. Press the right softkey to Edit the entry.

5. Press the navigation key down until Ring is selected and press .

6. Press the navigation key up or down and highlight the desired Ringer

Category and press .

7. Press the navigation key up or down to highlight and listen to the

desired Ringer and press to save.

8. Press the left softkey for Done.

Speed Dial

You can assign a speed dial number (1 or 2 digits) to up to 98 phone numbers from your Contacts.

Note: ‘1’ is reserved for your voicemail and is not assignable as a speed dial number.

Contacts

To assign a speed dial #:

1. Activate the main menu, highlight the Contacts menu, and press .

2. Select Speed Dial.

3. Using the navigation keys, highlight the number that you wish to assign

and press the left softkey for Assign.

Contacts 81

Page 88

4. Highlight the Contact that you wish to assign to the speed dial # and

press .

• To call a Contact using a 1 digit speed dial, from the Idle screen, press

and hold the # key assigned to the Contact.

• To call a Contact using a 2 digit speed dial, from the Idle screen, enter

the first digit, and then press and hold the # key for the second digit of the speed dial # assigned to the Contact.

Groups

You can associate a preset group name to your entries to help you sort them easier in the Contacts. Four preset group names are already programmed into your phone.

To change the name of a group:

1. Activate the main menu, highlight the Contacts menu, and press .

2. Select Groups.

3. Highlight the group that you want to change the name for.

4. Press the right softkey for Options and select Rename group.

5. Enter the new name for the group and press .

To associate an existing number located in your Contacts:

1. Activate the main menu, highlight the Contacts menu, and press .

2. Select Find.

3. Select the desired entry and press .

4. Press the right softkey to Edit the entry.

5. Press the navigation key down until Group is highlighted. Press .

6. Press the navigation key up or down to select the desired group name

and press .

7. Press the left softkey for Done.

Memory

You can display how many phone numbers are stored on your phone and how many spaces are available.

1. Activate the main menu, highlight the Contacts menu, and press .

2. Select Memory.

82 Contacts

Page 89

My Name Card

This function is similar to an entry in the Phone Book, except that it contains your contact information, like a business card. You can send the name card to others via Bluetooth.

To send your Name Card via Bluetooth:

1. Activate the main menu, highlight the Contacts menu, and press .

2. Select My Name Card.

3. Press the left softkey for Send Contact.

Note: If Bluetooth is not activated, you will be prompted to enable it. Select Yes and

press .

4. Highlight the device you wish to send the name card to and press .

Note: If the device is not visible, you will be prompted to search for the device. Select Yes and press . For more information, see ‘Bluetooth” on page 45.

To edit your Name Card:

1. Activate the main menu, highlight the Contacts menu, and press .

2. Select My Name Card.

3. Press the right softkey for Edit.

4. Edit your card details.

5. When you are finished, press the left softkey for Done.

Backup

This function allows you to launch the browser, where you can download applications to your phone, as well as back up your address book, allowing you to safeguard and migrate your contacts list. You can also launch the browser from the My Downloads menu. See "My Downloads" on page 50 for more information.

1. Activate the main menu, highlight the Contacts menu, and press .

2. Select Backup. The browser will launch and take you to the download

menu.

1.The Backup sub-menu may not be available depending on the UI version configured for your phone.

Contacts 83

Contacts

Page 90

Settings

Display

Screen Saver

You can set what image appears on the display screen when in standby mode.

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Display.

3. Select Screen Saver.

4. Select Main LCD or Sub LCD.

5. Press the navigation keys up or down to select the type of Screen Saver:

Preset Images, Downloads or My Albums and press . If you selected Sub LCD, select Preset Images or Main LCD Image and press

Press the navigation key up and down to select the desired image.

7. Press to save and exit.

Phone Interface

You can set which interface to use to navigate menus on your phone.

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Phone Interface.

3. Select Bell or Samsung and press .

Dialing Font

You can adjust the display format of your dialing font.

To change the dialing font color:

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Display.

3. Select Dialing Font.

4. Select Color.

5. Press the navigation keys up or down to select one of the following and

press :

• Basic displays entered digits all in black.

• Rainbow displays each digit in a different color.

• Monochrome displays entered digits as a single color of your choice.

84 Settings

Page 91

• Hyphenate displays each block of digits separated by hyphens in a

different color.

A sample of the new Dialing Font color appears onscreen.

• If you selected Monochrome, press the navigation keys left or right to

select your desired color and press .

• If you selected any other option, press to save your changes.

To change the dialing font size:

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Display.

3. Select Dialing Font.

4. Select Size.

5. Press the navigation keys up or down to select Large, Normal or Small

and press to save your changes.

Incoming Call

You can change the image shown on your display screen when receiving a call.

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Display.

3. Select Incoming Call.

4. Select With Caller ID or No Caller ID.

5. Press the navigation keys up or down to select one of Preset

Animation, Downloads or My Albums and press .

6. Use the navigation keys to select the desired image and press .

Backlight

The backlight setting lets you select how long the display screen and keypad are backlit after any key press is made.

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Display.

3. Select Backlight.

4. Select Main Display, Keypad, or Pwr Save Mode.

5. Use the navigation key to select:

• Flip open, 30 seconds, 15 seconds, or 8 seconds for the Main

Display.

Settings

Settings 85

Page 92

• Flip open, 30 seconds, 15 seconds, 8 seconds or Off for Keypad.

• On or Off for Pwr Save Mode. Turning on the power save mode will

slow down the user interface response in order to conserve power.

6. Press to save and exit.

Note: Long backlight settings reduce the battery’s talk and standby times.

You can change the brightness of the LCD screens, making them brighter or dimmer.

To change the brightness setting:

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Display.

3. Select Backlight.

4. Select Brightness.

5. Using the navigation keys, select a brightness level and press .

You can change the contrast settings for the front LCD display to suit your needs.

To change the sub contrast setting:

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Display.

3. Select Backlight.

4. Select Sub Contrast.

5. Using the navigation keys, select a contrast level and press .

Text Entry

The Text Entry menu allows you to customize how T9 text entry mode functions on your handset. For more information, see "T9 Text Input" on page 21.

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Display.

3. Select Text Entry.

4. Using the navigation keys, select one of the options and press : See

"Text Messaging" on page 53 for more information on these options.

86 Settings

Page 93

Note: The Help option provides additional information on using T9 text entry mode.

Scroll up or down using the navigation keys. When you are finished, press the left softkey for OK.

Sounds

Volume

To adjust the volume of the ringer and voice:

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Sounds.

3. Select Volume.

4. Select Ringer, Voice Volume, Headset Voice, Speaker Voice, or

Advanced.

• For Ringer, press the navigation key left or right until the desired

volume level is selected. Press to select or deselect Always Vibrate. Press the left softkey for Done to save and exit.

• For Voice Volume, Headset Voice, Speaker Voice, select a Level (1-

8).

• For Advanced, select Text Message, Pic/Video Msg, Voice Mail,

Alarms,or App. Volume.

• For Text Message, Pic/Video Msg, Voice Mail or Alarms, use the

navigation keys to select Use Ringer volume or Separate Volume.

Press to select/deselect Always Vibrate. Press the left softkey for Done to save and exit.

• For App. Volume, select Sound. Use the navigation keys to select

Use Ringer volume or Separate Volume. Press the left softkey

for Done to save and exit. To enable game vibration, select

Game Vibrate, select On, and press .

Silence All

There may be times when you need to silence your phone entirely. The phone’s Silence All option allows you to mute all sounds without turning your phone off.

• With the phone open, press and hold the down volume key in standby

mode. (The screen will display “Silence All.”) To deactivate Silence All, press the up volume key repeatedly to select a desired volume level.

Settings

Settings 87

Page 94

Ringer Type

You can assign ringer types to individual Contacts entries, types of calls, Scheduler entries, and types of messages.

• Single Tones are non-polyphonic traditional style ring tones.

• Ring Tones include a variety of standard ringer types.

• Melodies include a variety of musical melodies.

• Downloads include all the ringtones you have previously downloaded.

• My Videos includes videos you have recorded and can be used for

playback.

To select Ringer Types for Voice Calls, Messaging and Scheduler:

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Sounds.

3. Select Ringer Type.

4. Select Voice Calls, Messaging, or Scheduler.

• If you selected Voice Calls, select With Caller ID or No Caller ID.

• If you selected Messaging, select Voicemail, Text Message or Pic/

Video Msg.

5. Use the navigation keys to select Single Tones, Ring Tones, Melodies,

or Downloads.

6. Use the navigation keys to select the desired Ringer.

7. Press to save and exit.

Selecting Ringer Type for Roam Ringer

2. Select Sounds.

3. Select Ringer Type.

4. Select Roam Ringer.

5. Select Normal or Distinctive and press to save and exit.

Activate the main menu, highlight the Settings menu, and press .

88 Settings

Page 95

Alerts

Your phone can alert you with an audible tone when you change service areas, once a minute during a voice call, when a call has been connected, and when turning your phone on and off. The different options available are:

• Minute Beep: An alert tone is sounded every minute that you are

connected.

• Service: An alert tone is sounded when you come in or out of your coverage

area.

• Connect: An alert tone is sounded when you are initially connected.

• Sig. Fade Tone: An alert tone is sounded when your phone partially loses

signal due to network conditions or leaving network coverage area.

• Roam: An alert tone is sounded when your phone enters a roaming area.

To enable or disable alert sounds:

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Sounds.

3. Select Alerts.

4. Press the navigation key up or down to select the desired alert.

5. Select On or Off using the navigation key and press to save and exit.

Key Tone

You can select the audible tones accompanying a key press. There are three different tones available:

• DTMF: Normal, touch-tone beeps are heard when a button is pressed.

• Xylophone: Polyphonic ‘xylophone’ tones are heard when a key is pressed.

• Voice: The number or symbol of the key is heard when you press a key.

To select a key tone:

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Sounds.

3. Select Key Tone.

4. Select Tone Type.

5. Press the navigation key up or down to select the desired tone type.

6. Press to save and exit.

Settings

Settings 89

Page 96

You can change the tone level and tone duration of a key press. Voicemail or other automated systems may require long or short time lengths to activate different features.

To select a tone level:

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Sounds.

3. Select Key Tone.

4. Select Key Tone Level.

5. Select Key Tone Off or Level 1-8 and press to save and exit.

To select a tone length:

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Sounds.

3. Select Key Tone.

4. Select Tone Length.

5. Select Short or Long and press to save and exit.

Vibrates

You can select the level of vibration for voice calls.

To select a vibration level:

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Sounds.

3. Select Vibrates.

4. Select Intensity.

5. Press the navigation key up or down to select the desired vibration level.

6. Press to save and exit.

To enable/disable the vibration setting:

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Sounds.

3. Select Vibrates.

4. Select Enable Vib.

90 Settings

Page 97

5. Press to place a check mark beside Power On and/or Power Off to

6. Press to save and exit.

enable or disable vibration on any of these functions.

Messages

See "Settings" on page 57 for information on messaging settings.

Voice Service

See "Voice Service" on page 26 for information on voice service settings.

Camera

See "Camera" on page 71 for information on camera settings.

Bluetooth

See "Bluetooth" on page 45 for information on Bluetooth settings.

Phone Info

The Phone Info screen displays information about your handset’s current hardware and software. The Icon Glossary option can help you identify a display icon whose function you have forgotten.

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Phone Info.

3. Select Phone Number, Icon Glossary, Version, or Advanced.

Security

See "Phone Security" on page 98 for information on security settings.

Others

Call Setup

Call Setup options allow you to set up the following options:

Abbrev. Dial

Abbreviated dialing allows you to program a five or six digit prefix for commonly used phone numbers. When abbreviated dialing is on, you can enter the last four or five digits and the handset will prepend the six or five digit prefix to the sequence you have entered to complete the dialing number.

To set up abbreviated dialing:

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Others and then Call Setup.

3. Select Abbrev. Dial.

Settings

Settings 91

Page 98

4. Select On or Off and press .

5. If you selected On, input the five or six digit prefix (for example, area

code and prefix) and press .

To make an Abbreviated Dial call:

1. Enter the last four or five digits of the prefix phone number. Abbrev. Dial

is displayed in the lower left corner with the prefix digits displayed.

2. Press to make the call.

TALK

Contacts Match

With the Contacts Match feature on, you can dial the last few digits and press

TALK

To set up Contacts Match:

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Others and then Call Setup.

3. Select Contacts Match.

4. Select On or Off and press .

Making a call using Contacts Match:

1. Dial the last few digits of the desired number and press . A list of

TALK

Contacts entries appear whose last few digits match the sequence you dialed.

2. Use the up or down navigation key to select the Contact you want to call

and press .

TALK

Restriction

To set up call restriction:

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Others and then Call Setup.

3. Select Restriction.

4. Enter your lock code. (The security menu is displayed.)

92 Settings

Page 99

Tip: If you can’t recall your lock code, try using the last four digits of either your

Social Insurance Number or Mobile Directory Number or try 0000. If none of these work, call Customer Service at 1-800-Samsung.

5. Select Outgoing Call.

6. Select Allow All, Contacts Only, or Special# Only and press .

Call Answer

To set the actions required to answer an incoming call:

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Others and then Call Setup.

3. Select Call Answer and select one of the following:

• Any Key • Talk Key • Flip Open

4. Press to save and exit.

Auto Answer

To answer calls when your phone is connected to an optional hands-free car kit or head set:

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Others and then Call Setup.

3. Select Auto Answer.

4. Press the navigation key up or down to select Yes or No.

5. Press to save and exit.

Language

Language selection changes all menus and voice message settings.

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Others.

3. Select Language.

4. Press the navigation key up or down to select English or French.

5. Press to save and exit.

Settings

Settings 93

Page 100

Airplane Mode

When your phone is in Airplane Mode, it cannot send or receive any calls or access online information. All incoming calls will be sent directly to your Voicemail box. The Bluetooth interface will be disabled when Airplane Mode is on.

To set your phone to Airplane Mode:

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Others.

3. Select Airplane Mode. (A brief explanation of Airplane Mode will

display.)

4. Press to continue.

5. Press the navigation key up or down to select On, Off or On Power-Up

and press to save and exit.

While in Airplane Mode, your phone’s standby screen will display “PhoneOff.”

Location

The Location feature allows the network to detect your position. Turning Location off will hide your location from everyone except 911.

Note: Even if the Location feature is enabled, no service may use your location

information without your expressed permission.

To enable your phone’s Location feature:

1. Activate the main menu, highlight the Settings menu, and press .

2. Select Others.

3. Select Location. (A brief explanation will display. Use your navigation

key to scroll through to read the entire text.)

4. Press to continue.

5. Press the navigation key up or down to select On or Off.

6. Press to save and exit.

When the Location feature is on, your phone’s standby screen will display the icon. When Location is turned off, the icon will display.

94 Settings

Samsung SPH-M530 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
