Samsung SM-R735AZKAATT User Manual

User Manual

SM-R735A

Legal

WARNING! This product contains chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information, please call 1-800-SAMSUNG (726-7864).

Notice: Water-resistant and dustproof based on IP68 rating, which tests submersion up to 5.0 feet for up to 30 minutes.

Intellectual Property

All Intellectual Property, as defined below, owned by or which is otherwise the property of Samsung or its respective suppliers relating to the SAMSUNG mobile device, including but not limited to, accessories, parts, or software relating thereto (the “mobile device”), is proprietary to Samsung and protected under federal laws, state laws, and international treaty provisions. Intellectual Property includes, but is not limited to, inventions (patentable or unpatentable), patents, trade secrets, copyrights, software, computer programs, and related documentation and other works of authorship. You may not infringe or otherwise violate the rights secured by the Intellectual Property. Moreover, you agree that you will not (and will not attempt to) modify, prepare derivative works of, reverse engineer, decompile, disassemble, or otherwise attempt to create source code from the software. No title to or ownership in the Intellectual Property is transferred to you. All applicable rights of the Intellectual Property shall remain with SAMSUNG and its suppliers.

ATT_R735A_EN_UM_TN_PB3_051116_FINAL

Open Source Software

Some software components of this product incorporate source code covered under GNU General Public License (GPL), GNU Lesser GeneralPublic License (LGPL), OpenSSL License, BSD License and other open source licenses. Toobtain the source code covered under the opensource licenses, please visit: opensource.samsung.com

Disclaimer of Warranties; Exclusion of Liability

EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY CONTAINED ON THE WARRANTY PAGE ENCLOSED WITH THE PRODUCT, THE PURCHASER TAKES THE PRODUCT “AS IS”, AND SAMSUNG MAKES NO EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT, INCLUDING BUT NOT LIMITED TO THE MERCHANTABILITY OF THE PRODUCT OR ITS FITNESS FOR ANY PARTICULAR PURPOSE OR USE; THE DESIGN, CONDITION OR QUALITY OF THE PRODUCT; THE PERFORMANCE OF THE PRODUCT; THE WORKMANSHIP OF THE PRODUCT OR THE COMPONENTS CONTAINED THEREIN; OR COMPLIANCE OF THE PRODUCT WITH THE REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION OR CONTRACT PERTAINING THERETO. NOTHING CONTAINED IN THE INSTRUCTION MANUAL SHALL BE CONSTRUED TO CREATE AN EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT. IN ADDITION, SAMSUNG SHALL NOT BE LIABLE FOR ANY DAMAGES OF ANY KIND RESULTING FROM THE PURCHASE OR USE OF THE PRODUCT OR ARISING FROM THE BREACH OF THE EXPRESS WARRANTY, INCLUDING INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, OR LOSS OF ANTICIPATED PROFITS OR BENEFITS.

Modification of Software

SAMSUNG IS NOT LIABLE FOR PERFORMANCE ISSUES OR INCOMPATIBILITIES CAUSED BY YOUR EDITING OF REGISTRY SETTINGS, OR YOUR MODIFICATION OF OPERATING SYSTEM SOFTWARE.

USING CUSTOM OPERATING SYSTEM SOFTWARE MAY CAUSE YOUR DEVICE AND APPLICATIONS TO WORK IMPROPERLY. YOUR CARRIER MAY NOT PERMIT USERS TO DOWNLOAD CERTAIN SOFTWARE, SUCH AS CUSTOM OS.

IF YOUR CARRIER PROHIBITS THIS, IF YOU ATTEMPT TO DOWNLOAD SOFTWARE ONTO THE DEVICE WITHOUT AUTHORIZATION, YOU WILL BE NOTIFIED ON THE SCREEN THAT UNAUTHORIZED SOFTWARE HAS BEEN DETECTED. YOU SHOULD THEN POWER DOWN THE DEVICE AND CONTACT YOUR CARRIER TO RESTORE THE DEVICE TO THE CARRIER AUTHORIZED SETTINGS.

Diagnostic Software

This device is equipped with diagnostic software reporting usage and performance information used solely to deliver improved network quality and overall device experience to AT&T customers. Please refer to your AT&T Wireless Customer Agreement and/or the AT&T Privacy Policy (att.com/privacy) for more information.

Samsung KNOX

Samsung KNOX™ is Samsung’s security platform and is a mark for a Samsung device tested for security with enterprise use in mind. Additional licensing fee may be required. For more information about KNOX, please refer to: samsung.com/us/knox [041516]

iii

Samsung Electronics America (SEA), Inc.

Address

85 Challenger Road Ridgefield Park, New Jersey 07660

Phone

1-800-SAMSUNG (726-7864)

Internet Address

samsung.com

Other marks are the property of their respective owners.

Notice: Screen images are simulated. Appearance of device may vary.

Do you have questions about your Samsung Mobile Device?

For 24 hour information and assistance, we offer a new FAQ/ARS System (Automated Response System) at: samsung.com/us/support

The actual available capacity of the internal memory is less than the specified capacity because the operating system and default applications occupy part of the memory. The available capacity may change when you upgrade the device.

Legal Information

Important legal information can be accessed at samsung.com

READ THIS INFORMATION BEFORE USING YOUR MOBILE DEVICE.

Samsung Limited Warranty

Samsung Limited Warranty - This product is covered under the applicable Samsung Limited Warranty INCLUDING ITS DISPUTE RESOLUTION PROCEDURE and your right to opt out of arbitration within 30 calendar days of the first consumer purchase. You may opt out by either sending an email to optout@sea.samsung.com with the subject line “Arbitration Opt-Out” or by calling 1-800-SAMSUNG (726-7864). For more detailed procedures, please refer to the “Dispute Resolution Procedures and Arbitration and

Opt-Out” section of the Limited Warranty.

The EULA for this device is found in the Gear Manager application, which is required for operation of your device.

You may also access this EULA at: samsung.com/us/Legal/SamsungLegal-EULAGEAR

Basics

2 Device layout

6 Battery

11 Wearing the Gear

15 Replacing the strap

18 Connecting the Gear to a Smartphone

21 Activating the device

22 Remote connection

22 Turning the screen on and off

23 Using the bezel

26 Touchscreen

30 Navigating the screen

32 Home screen

40 Status panel

47 Setting the screen lock

48 Entering text

53 Screen capture

54 Updating the Gear

Applications

55 Messages

57 Phone

60 S Health

75 Nike+ Running

77 Schedule

78 S Voice

81 Weather

82 Alarm

83 Timer

84 Stopwatch

85 World Clock

86 Bloomberg

87 CNN

87 ESPN

88 News Briefing

88 Music Player

91 Samsung Milk Music

92 Gallery

96 Buddy

97 Email

vii

98 Find My Phone

110 Connections

99 Maps

100 Voice Memo

Settings

103 Introduction

104 Display

105 Sound

107 Device

108 Call

109 Messages

116 Screen lock

117 Accessibility

118 Input

120 Power saving

121 Gear info

Samsung Gear App

122 Introduction

124 Watch faces

125 Notifications

viii

126 Apps layout

127 Send content to Gear

128 Settings

135 Find My Gear

137 Samsung Gear Apps

Basics

Instructional icons

Warning: Situations that could cause injury to yourself or others.

Caution: Situations that could cause damage to your device or other equipment.

Notice: Notes, usage tips, or additional information.

Basics

Touchscreen

Microphone (behind)

Device layout

Front

Bezel

Back button

Home/Power button

Light sensor

Basics

Heart rate sensor

Back

Speaker

Basics

Buttons

Button Function

Home/Power

Back • Press to return to the previous screen.

Make sure the Gear’s microphone is not obstructed when you are speaking into it while charging.

Do not allow children or animals to chew or suck the device. Do not disassemble, modify, or repair your device. Magnetic stripe cards, including credit cards, phone cards, passbooks, and boarding passes, may be damaged by magnetic fields.

• Press and hold to turn the Gear on or off.

• Press to turn on the screen.

• Press and hold for more than 7 seconds to restart the Gear.

• Press to open the Apps screen when you are on the Watch screen.

• Press to open the Watch screen when you are on any other screen.

Basics

Wireless charger dock

Wireless

charging

surface

LED indicator

Make sure the Gear’s microphone is not obstructed when you are speaking into it while charging.

USB charger port

Basics

Battery

Charging the battery

Charge the battery before using it for the first time or when it sits unused for extended periods.

Use only charging devices and batteries approved by Samsung. Samsung accessories are designed for your device to maximize battery life. Using other accessories may invalidate your warranty and may cause damage.

1 Connect the USB cable to the USB charger head.

Then, connect the other end of the USB cable to the wireless charger dock.

Prevent the USB charger port and the small

end of the charger from coming into contact with conductive materials, such as liquids, dust, metal powders, and pencil leads.

Basics

2 Plug the USB charger head into an electric socket.

3 Place the Gear into the wireless charger dock.

4 After fully charging your Gear, disconnect it from the wireless charger dock. Unplug the charger from the wireless charger dock,

and then unplug the charger from the electric socket.

Basics

Checking the charging status

When you connect the Gear and the wireless charger dock, the wireless charger dock’s LED indicator flashes certain colors to indicate the battery level.

Color Charging status

Red > Green > Yellow Standby mode

Red Charging

Green Fully charged

Orange Connected to a low-charger head

When a wireless charger dock error occurs, the LED indicator flashes red. Disconnect the Gear from the wireless charger dock and reconnect them. If the error occurs again, contact a Samsung Service Center for service support.

The LED indicator may work differently depending on the Gear.

Basics

Reducing the battery consumption

Your Gear provides various options that help you conserve battery power.

• When you are not using the Gear, switch to sleep mode by covering the screen with yourpalm.

• Activate power saving mode.

• Close unnecessary apps.

• Deactivate the Bluetooth feature when not in use.

• Deactivate the Wi-Fi feature when not in use.

• Decrease the screen brightness.

• Deactivate the watch always on feature.

• Deactivate the voice wake-up feature in S Voice

• Customize the notification settings in the Samsung Gear app on the connected smartphone.

™

Basics

Battery charging tips and precautions

• If there are obstructions between the Gear and the wireless charger dock, the Gear may not charge properly.

• Prevent the Gear and the wireless charger from coming into contact with sweat, liquids, or dust.

• If the battery is completely discharged, the Gear cannot be turned on immediately after being connected to the charger.

Allow a depleted battery to charge for a few minutes before turning on the Gear.

• If you use multiple apps at once, the battery will drain quickly. To avoid losing power during a data transfer, always use these apps

after fully charging the battery.

• Using a power source other than the charger, such as a computer, may result in a slower charging speed due to a lower electric

current.

• If the Gear is being charged with other devices using a multi-charger, charging may takelonger.

• The Gear can be used while it is charging, but it may take longer to fully charge the battery.

• If the Gear receives an unstable power supply while charging, the touchscreen may not function. If this happens, immediately

disconnect the Gear from the wireless charger dock and leave the device aside until another power connection can be found.

• While charging, the Gear may heat up. This is normal and should not affect the Gear’s lifespan or performance. If the battery feels

hot to the touch during this charging process, remove the Gear from the charger and allow it to cool down before restarting the charging process, or call 1-800-SAMSUNG (726-7864) to receive technical support.

• If the Gear is not charging properly, take the Gear to a Samsung Service Center.

• Avoid using a bent or damaged USB cable.

Basics

Wearing the Gear

Putting on the Gear

1 Open the buckle and place the strap around your wrist.

2 Fit the strap to your wrist, insert the pin into an adjustment hole, and then secure the buckle to close it.

Basics

The information gathered from this device, S Health, or related software is not intended for use in the diagnosis of disease or other conditions, or in the cure, mitigation, treatment or prevention of disease.

The accuracy of the information and data provided by this device and its related software, including heart rate readings, may be affected by factors such as environmental conditions, skin condition, specific activity performed while using/wearing the device, settings of the device, user configuration/user-provided information, placement of the sensor on the body, and other end-user interactions. For more information on proper wear and use, see samsung.com/us/heartratesensor.

If you feel discomfort while using the device, stop using it and remove it from your wrist. If your device becomes hot to the touch, please remove it until it cools.

To measure your heart rate more accurately with the Gear, wear the Gear firmly around your lower arm just above the wrist. Refer to Wearing the Gear fordetails.

Basics

Maintaining Water and DustResistance

Water-resistant and dustproof based on IP68rating, which tests submersion up to

5.0 feet for up to 30 minutes.

This device is rated IP68 using the Ingress Protection rating system.

Your device has been tested in a controlled environment and shown to be water and dust resistant in certain circumstances (meets requirements of classification IP68 as described by the international standard IEC 60529 - Degrees of Protection provided by Enclosures [IP Code]; test conditions: 15-35°C, 86-106 kPa, 5.0 feet, for 30minutes). Despite this classification, your device is not impervious to water damage in any situation. It is important that all compartments are closed tightly.

Follow these tips carefully to prevent damage to the device.

• Whenever your device gets wet, dry it thoroughly with a clean, soft cloth.

• Do not expose the device to salt water or ionized water, or to water over 5.0 feet deep for more than 30 minutes. If your device is

exposed to fresh water, dry it thoroughly with a clean, soft cloth. If the device is exposed to any liquid other than fresh water, rinse the device with fresh water immediately and dry it thoroughly with a clean, soft cloth. Failure to rinse the device in fresh water and dry it as instructed may cause the device to suffer from operability or cosmetic issues.

• Do not expose the device to water at high pressure.

• If the device is dropped or receives an impact, the water and dust resistant features of the device may be damaged.

• The touchscreen and other features may not work properly if the device is used in water or in other liquids.

Basics

Strap tips and precautions

• Be cautious when wearing the Gear. If you have sensitive skin or fasten the Gear too tightly, you may feel some discomfort.

• Some people may experience discomfort when wearing the Gear for prolonged periods.

• Do not expose the straps to very wet conditions. Wet straps can cause skin irritations. Dry the straps first. If you experience skin

irritation when wearing the device, stop wearing the device and consult a physician.

• The Gear and the strap have passed the hazardous materials test and meet international safety standards.

Basics

Replacing the strap

Detach the strap from the Gear to replace it with a new one.

1 Slide the strap’s spring bar inwards.

Basics

2 Insert one end of the spring bar into the lug, slide the spring bar inwards, and connect the strap.

Basics

Turning the Gear on and off

1 Press and hold the

• When you turn on the Gear for the first time or reset it, a pop-up window displays. Follow the prompts to download and install the Samsung Gear app on your smartphone.

2 To turn off the Gear, press and hold the

Power

button for a few seconds to turn on the Gear.

Power

button, and then tap

Power off

Basics

Connecting the Gear to a Smartphone

You should connect your Gear to your smartphone once before using the Gear. To connect your Gear to a smartphone, install the Samsung Gear app on the smartphone. Launch For non-Samsung devices, download the Samsung Gear app from the Google Play store.

Compatible with Android 4.4 and later with 1.5GB RAM. Some features may not be available. For best compatibility, connect with compatible Samsung Galaxy devices.

1 Turn on the Gear.

Galaxy Apps

or visit apps.samsung.com/gear from your smartphone to downloadit.

2 On the smartphone Apps screen, tap

• If necessary, update the Samsung Gear app to the latest version.

3 Tap

Connect to gear

4 When the

then tap OK.

5 Follow the prompts to complete the connection.

Bluetooth pairing request

Samsung Gear

window displays, confirm the passkeys displayed on your Gear and smartphone match, and

Basics

When the devices are connected, a tutorial displays on the Gear’s screen. Follow the prompts to learn the Gear’s basic controls.

• Connection methods and screenshots may vary depending on your device and software version.

• You cannot install the Samsung Gear app on smartphones that do not support Gear syncing. Ensure that your

smartphone is compatible with a Gear.

• Supported smartphones and features may vary depending on your region, service provider, and device manufacturer.

Visit samsung.com and search for your Gear device’s support page to view a list of compatible smartphones.

Basics

Connecting the Gear to a new smartphone

When you connect the Gear to another smartphone, the Gear automatically resets and all data is removed from its memory. Make sure you back up any important data stored on yourGear.

1 Back up your Gear’s data on your smartphone.

• On your smartphone, open the Apps screen and tap

2 End the connection between your Gear and smartphone. Refer to Disconnecting the Gear for more information.

3 Connect your Gear to another smartphone.

A new Gear device cannot connect to a target smartphone that is already paired with another Gear.

Samsung Gear

Settings

Back up and restore

Back up data

+ 117 hidden pages
