About the Gear VR

The Samsung Gear VR allows you to enjoy 2D, 3D, and 360-degree content by connecting it with your mobile device.

You can also view webpages and your own 360-degree images or videos. Connect other devices, such as game controllers or Bluetooth headsets (sold separately), to the mobile device for a more immersive experience.

Table of Contents

About the Gear VR

Read me first

Getting started

7 Package contents 8 Device layout 13 Connecting the mobile

device and wearing the Gear VR

27 Installing the Gear VR app

(Oculus)

Basics

30 Using the touchpad 32 Moving the pointer or the

screen 33 Selecting items 33 Using the Universal menu 36 Downloading apps and

content 37 Viewing notifications

received on the mobile

device

Table of Contents

Viewing content

39 Viewing content on the

Oculus Home screen

43 Viewing content on the

mobile device

44 Viewing online content

Health and safety warnings

Safety information

Appendix

65 Troubleshooting

Read me first

•

Please read this manual before using the Samsung Gear VR (also referred to as Gear VR) to ensure safe and proper use.

•

To prevent injury or damage to your devices, read the health and safety warnings and information before using the Gear VR.

•

Use the Gear VR for its intended purpose only. Using the Gear VR for other purposes may result in injury.

•

The Gear VR cannot be operated by itself. To use the Gear VR, connect a mobile device to it. Visit list of compatible mobile devices.

•

To use a mobile device with the Gear VR, upgrade the mobile device's software to the latest version.

•

Some languages or content may not be available depending on the region or network.

•

To view the open source licence for the Gear VR, refer to

opensource.samsung.com

www.samsung.com

to see a

Read me first

Instructional icons

Warning: situations that could cause injury to yourself or

others

Caution: situations that could cause damage to your device or other equipment

Notice: notes, usage tips, or additional information

Getting started

Package contents

Check the product box for the following items:

•

Gear VR, top strap, main strap, Micro USB connector, and user manual

•

The items supplied with the device and any available accessories may vary depending on the region or service provider.

•

The supplied items are designed only for this device and may not be compatible with other devices.

•

Appearances and specifications are subject to change without prior notice.

•

Use only Samsung-approved accessories. Using unapproved accessories may cause performance problems and malfunctions that are not covered by the warranty.

•

Availability of all accessories is subject to change depending entirely on manufacturing companies. For more information about available accessories, refer to the Samsung website.

Getting started

Focus

Device layout

Back key

Home key

Touchpad

Volume key

Touchpad and keys Function

•

Tap to select an item. You can move to the next or previous

Touchpad

item by swiping forwards or backwards. For more information, refer to Using the touchpad. (p. 30)

adjustment wheel

Front cover

Getting started

Touchpad and keys Function

•

Home

Press to return to the Oculus Home screen.

•

Press to return to the previous screen.

•

Back

Press and hold to open the Universal menu. You can view the status of the Gear VR and configure settings.

•

Volume

Press to adjust the Gear VR volume.

Focus adjustment wheel

•

Rotate to focus by adjusting the distance between the mobile device and the Gear VR's lenses.

Getting started

Main strap loop

Top strap loop

Device holder

Multipurpose

cushioning

(left)

jack (USB

Type-C)

Foam

Main strap loop

Device holder (right)

Proximity sensor

Lenses

Getting started

•

The Gear VR does not require charging as it is powered using the mobile device’s battery.

•

You can charge your mobile device by connecting a charger to the Gear VR's multipurpose jack. Use only Samsung-approved chargers. Unapproved chargers can cause the mobile device's battery to explode or damage your devices.

–

If you use a Micro USB charger, connect a Micro USB connector before plugging the charger into the Gear VR. The Micro USB connector is only for battery charging.

Getting started

–

If you use the Gear VR while the charger is connected to the Gear VR's multipurpose jack, it is powered by the charger and does not use the mobile device's battery. When you use content that has high power demand (more than 1 A) while the charger is connected, the Gear VR uses two power sources. In high power demand situations, the Gear VR is powered by the charger and the mobile device's battery at the same time.

–

If the Gear VR is not used while the charger is connected, the mobile device's battery will be charged.

–

If the Gear VR is disconnected from the charger while the Gear VR is being used, the image on the screen may be briefly inactive. During this period, the screen recalibrates and the Gear VR may not recognise your head movements.

•

To save energy, unplug the charger when not in use. The charger does not have a power switch, so you must unplug the charger from the electric socket when not in use to avoid wasting power. The charger should remain close to the electric socket and easily accessible while charging.

Getting started

Connecting the mobile device and wearing the Gear VR

•

Do not put on the Gear VR when you are wearing glasses. Doing so may cause facial injuries. If you need corrective lenses, it is recommended that you wear contact lenses when using the Gear VR.

•

If you are farsighted or there is a big difference between your left and right eyes' vision, wear corrective lenses before using the Gear VR.

•

Factory lens protectors are pre-installed on the Gear VR. Remove the lens protectors before you use the Gear VR so you can see clearly.

•

Keep the lenses clean and protect them from getting scratched. If the lenses get dirty or steam up, clean them with the lens cleaning cloth.

Getting started

•

The foam cushioning may get dirty if your face is sweating while you are wearing the Gear VR.

•

The touchpad works only while you are wearing the Gear VR.

•

When you are not wearing the Gear VR, do not place objects near the proximity sensor inside the Gear VR. Doing so may cause the mobile device's screen to remain on and drain its battery.

Getting started

Connecting straps

Insert the ends of the straps through the strap loops on the

Gear VR and use the velcro to fasten each end.

Getting started

Pull the device holder (right) to the right (

front cover (

) then remove the

Getting started

Removing straps

Remove the top strap by pulling its loop towards the foam cushioning. Then, remove the main strap from the Gear VR.

Getting started

Connecting the mobile device

Pull the device holder (right) to the right thoroughly (

push the device holder (left) gently (

A or B ( you want to use.

Indicates the current mobile device size

) depending on the size of the mobile device's screen

Position B Position A

) and slide it to position

Device holder (left)

). Then,

• Position A: For larger devices.

• Position B: For smaller devices.

Getting started

While the mobile device is on, connect it to the connector on

the device holder (

Insert the mobile device into the centre of the Gear VR and gently push the mobile device until it locks into place ( device holder (right) will return to the previous position and

hold the mobile device (

The mobile device will emit a sound when it is connected to the Gear VR properly.

). The

Getting started

•

Do not forcefully insert the connector into the mobile device. Doing so may damage the connector.

•

Do not twist or bend the Gear VR’s connector when you connect or disconnect the mobile device. Doing so may damage the connector.

•

Push the mobile device into the Gear VR firmly until it locks in place. If it is not securely locked, the mobile device may accidentally separate from the Gear VR and be damaged.

•

If you insert the mobile device tilted to one side, it may cause discomfort.

Getting started

If the sound is not emitted when you insert the connector into the mobile device, the Gear VR may not have recognised it. Reconnect the devices until you hear the sound.
