Samsung SMG800R4 Users Manual

DRAFT FOR INTERNAL USE ONLY

4G LTE SMARTPHONE

This document is watermarked because certain important information in the document has not yet been verified. This document has been sent to you as a draft and for informational purposes only. The document should only be used for internal purposes and may not be distributed outside of the company. Distributing the document outside of the company could result in legal exposure to the company if the preliminary, unverified information in the draft turns out to be inaccurate.

User Manual

Please read this manual before operating your device,

and keep it for future reference.

DRAFT FOR INTERNAL USE ONLY

Legal Notices

Warning: This product contains chemicals known to the State of California to cause cancer and reproductive toxicity.

Intellectual Property

All Intellectual Property, as deﬁned below, owned by or which is otherwise the property of Samsung or its respective suppliers relating to the SAMSUNG Phone, including but not limited to, accessories, parts, or software relating there to (the “Phone System”), is proprietary to Samsung and protected under federal laws, state laws, and international treaty provisions. Intellectual Property includes, but is not limited to, inventions (patentable or unpatentable), patents, trade secrets, copyrights, software, computer programs, and related documentation and other works of authorship. You may not infringe or otherwise violate the rights secured by the Intellectual Property. Moreover, you agree that you will not (and will not attempt to) modify, prepare derivative works of, reverse engineer, decompile, disassemble, or otherwise attempt to create source code from the software. No title to or ownership in the Intellectual Property is transferred to you. All applicable rights of the Intellectual Property shall remain with SAMSUNG and its suppliers.

Open Source Software

Disclaimer of Warranties; Exclusion of Liability

EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY CONTAINED ON THE WARRANTY PAGE ENCLOSED WITH THE PRODUCT, THE PURCHASER TAKES THE PRODUCT “AS IS”, AND SAMSUNG MAKES NO EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT, INCLUDING BUT NOT LIMITED TO THE MERCHANTABILITY OF THE PRODUCT OR ITS FITNESS FOR ANY PARTICULAR PURPOSE OR USE; THE DESIGN, CONDITION OR QUALITY OF THE PRODUCT; THE PERFORMANCE OF THE PRODUCT; THE WORKMANSHIP OF THE PRODUCT OR THE COMPONENTS CONTAINED THEREIN; OR COMPLIANCE OF THE PRODUCT WITH THE REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION OR CONTRACT PERTAINING THERETO. NOTHING CONTAINED IN THE INSTRUCTION MANUAL SHALL BE CONSTRUED TO CREATE AN EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT. IN ADDITION, SAMSUNG SHALL NOT BE LIABLE FOR ANY DAMAGES OF ANY KIND RESULTING FROM THE PURCHASE OR USE OF THE PRODUCT OR ARISING FROM THE BREACH OF THE EXPRESS WARRANTY, INCLUDING INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, OR LOSS OF ANTICIPATED PROFITS OR BENEFITS.

Some software components of this product incorporate source code covered under GNU General Public License (GPL), GNU Lesser General Public License (LGPL), OpenSSL License, BSD License and other open source licenses. To obtain the source code covered under the open source licenses, please visit:

http://opensource.samsung.com.

Modiﬁcation of Software

SAMSUNG IS NOT LIABLE FOR PERFORMANCE ISSUES OR INCOMPATIBILITIES CAUSED BY YOUR EDITING OF REGISTRY SETTINGS, OR YOUR MODIFICATION OF OPERATING SYSTEM SOFTWARE.

USING CUSTOM OPERATING SYSTEM SOFTWARE MAY CAUSE YOUR DEVICE AND APPLICATIONS TO WORK IMPROPERLY. YOUR CARRIER MAY NOT PERMIT USERS TO DOWNLOAD CERTAIN SOFTWARE, SUCH AS CUSTOM OS.

Legal Notices USC- G800R4_UM_Eng_TN_NH1_080614_R2

DRAFT FOR INTERNAL USE ONLY

SAFE™ (Samsung Approved For Enterprise)

SAFE™: “SAFE™” (Samsung for Enterprise) is a mark for a Samsung device which has been tested against Samsung’s own internal criteria for interoperability with certain third party securityrelated solutions for MDM and VPN. The testing includes ﬁeld testing with local network connection and menu tree testing which tests functionality of the solutions in conjunction with the Samsung device. During the testing, the device is tested with the security solutions to see if the solutions work with the device as described by the third party security solution providers. The testing, for example, includes ﬁeld testing with local network connection and menu tree testing which tests functionality of the solutions in conjunction with the Samsung device. For more information about Samsung’s SAFE™ program, please refer to www.samsung.com/us/safe.

the software provider, solution provider or user. For complete statement of limited warranty, please refer to www.samsung.com/us/safe, available on the web and where Samsung smartphones and mobile devices are sold. [051214]

Samsung Telecommunications America (STA), LLC

Headquarters:

1301 E. Lookout Drive

Richardson, TX 75082

Phone:

1-800-SAMSUNG (726-7864)

Disclaimer of Warranties: EXCEPT AS OTHERWISE PROVIDED IN THEIR STANDARD END USER LICENSE AND WARRANTY, TO THE FULL EXTENT PERMITTED BY LAW SAMSUNG ELECTRONICS CO., LTD., SAMSUNG TELECOMMUNICATIONS AMERICA, LLC, AND THEIR AFFILIATES (COLLECTIVELY REFERRED TO HEREIN AS THE “SAMSUNG ENTITIES”) EXPRESSLY DISCLAIM ANY AND ALL WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, INTEROPERABILITY OR NONINFRINGEMENT, WITH RESPECT TO INFORMATION TECHNOLOGY SECURITY PROTECTION, SAFE™ DEVICES AND APPLICATIONS TESTED WITH SAFE™ DEVICES. IN NO EVENT SHALL THE SAMSUNG ENTITIES BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, PUNITIVE, OR CONSEQUENTIAL DAMAGES OF ANY KIND WHATSOEVER WITH RESPECT TO INFORMATION TECHNOLOGY SECURITY PROTECTION, SAFE™ DEVICES OR APPLICATIONS TESTED WITH SAFE™ DEVICES. In addition, information technology security protection will be aﬀected by features or functionality associated with, among other things the e-mail platform, master data management, and virtual private network solutions selected by the software provider, solution provider or user. Choice of an e-mail, master data management, and virtual private network solution is at the sole discretion of the software provider, solution provider or user and any associated eﬀect on information technology security protection is solely the responsibility of

1-888-987-HELP (4357)

Internet Address:

www.samsung.com

Do you have questions about your Samsung Mobile Phone?

For 24 hour information and assistance, we oﬀer a new FAQ/ARS System (Automated Response System) at: www.samsung.com/us/support

The actual available capacity of the internal memory is less than the speciﬁed capacity because the operating system and default applications occupy part of the memory. The available capacity may change when you upgrade the device.

Nuance®, VSuite™, T9® Text Input, and the Nuance logo are trademarks or registered trademarks of Nuance Communications, Inc., or its aﬃliates in the United States and/or other countries.

ACCESS® and NetFront™ are trademarks or registered trademarks of ACCESS Co., Ltd. in Japan and other countries.

Legal Notices

DRAFT FOR INTERNAL USE ONLY

The Bluetooth® word mark, ﬁgure mark (stylized “B Design”) , and combination mark (Bluetooth word mark and “B Design”) are registered trademarks and are wholly owned by the Bluetooth SIG.

Online Legal Information

The online version of the Health/Safety and Warranty guide for your device can be found at:

microSD™ and the microSD logo are Trademarks of the SD Card Association.

Openwave® is a registered Trademark of Openwave, Inc.

Google, the Google logo, Android, the Android logo, Google Play, Gmail, Google Mail, Google Maps, Google Music, Google Hangouts, Picasa, Play Newsstand, YouTube and other marks are trademarks of Google Inc.

Wi-Fi is a registered trademark of the Wireless Fidelity Alliance, Inc.

English: www.samsung.com/us/Legal/Phone_

HSGuide

Spanish: www.samsung.com/us/Legal/Phone_

HSGuide_SP

The online version of the End User Licensing Agreement for your device can be found:

Online at: www.samsung.com/us/Legal/EULA

iii

Legal Notices

DRAFT FOR INTERNAL USE ONLY

Table of Contents

Getting Started ............................................................. 1

Front View ........................................................................... 2

Back View ........................................................................... 3

Prepare Your Device .................................................... 4

Set Up Your Device ...................................................... 7

Set Up Accounts on Your Device ........................ 8

Know Your Device ..................................................... 9

Home Screen..................................................................10

Status Bar .........................................................................13

Notiﬁcation Panel .........................................................14

Entering Text ...................................................................15

Calling ..................................................................................16

Calling .................................................................................17

Applications ...................................................................20

Apps Screen ...................................................................21

Google Applications ..................................................23

Other Applications ......................................................25

Camera and Video ......................................................27

Contacts .............................................................................29

Calculator ..........................................................................33

Calendar ............................................................................34

Clock ....................................................................................35

Email ....................................................................................36

Gallery ................................................................................. 37

Internet ................................................................................39

Messaging ........................................................................40

Music Player ....................................................................42

MyFiles ..............................................................................43

S Health .............................................................................45

S Voice ...............................................................................46

Video Player ....................................................................47

WatchON ...........................................................................48

Settings ..............................................................................49

How to Use Settings ..................................................50

Wi-Fi and Wi-Fi Direct ................................................51

Bluetooth ...........................................................................53

Tethering and Wi-Fi Hotspot ..................................55

Airplane Mode ...............................................................57

Data Usage ......................................................................58

Location Services ........................................................59

Mobile Networks ...........................................................60

Default Messaging App ...........................................61

Virtual Private Networks (VPN) ...........................62

Sharing Files with NFC .............................................63

Nearby Devices .............................................................64

Printing ................................................................................65

Screen Mirroring ........................................................... 66

Sound ..................................................................................67

Display ................................................................................70

Wallpaper ..........................................................................73

Lock Screen ....................................................................74

Notiﬁcation Panel .........................................................75

Toolbox ...............................................................................76

Easy Mode .......................................................................77

Accessibility .....................................................................78

Blocking Mode ..............................................................80

Private Mode ...................................................................81

Fingerprint Scanner ....................................................82

Motions and Gestures...............................................83

Air View ..............................................................................84

Accounts ............................................................................85

Cloud ...................................................................................86

Backup and Reset.......................................................87

TOC

DRAFT FOR INTERNAL USE ONLY

Language and Input Settings ...............................88

Date and Time ...............................................................91

Safety Assistance ........................................................92

Battery ................................................................................. 93

Power Saving ..................................................................94

Storage ...............................................................................95

Security...............................................................................97

Help ......................................................................................99

About Your Device ................................................... 100

Application Manager ............................................... 101

Default Applications ................................................ 103

TOC

DRAFT FOR INTERNAL USE ONLY

Getting Started

Learn about your mobile device hardware and how to get started for the ﬁrst time.

DRAFT FOR INTERNAL USE ONLY

Front View

3.5mm Headset Jack

Status Light

Volume

Earpiece

Proximity and Gesture Sensors

Front Camera

Power/Lock

Recent Apps

3.5 mm Headset Jack: Connect an optional

•

headset (not included).

Back: Tap to return to the previous screen, or to

•

close a dialog box, menu, or keyboard.

Earpiece: Allows you to hear the caller.

•

Front Camera: Take pictures and videos of

•

yourself.

Home: Tap to return to the home screen. Activate

•

the Fingerprint security feature to use as a ﬁngerprint reader.

Home

Back

Power/Lock: Press and hold to turn the device

•

on or oﬀ, or press to lock or wake up the screen. Press and hold to turn the device oﬀ or restart it, or for easy access to Airplane or Emergency Mode, and to Mute, Vibrate, and Sound modes.

Proximity and Gesture Sensors: Detects the

•

presence of objects near the device.

Recent Apps: Tap to display recent apps, or touch

•

and hold for home screen options.

Status Light: Displays red when charging or the

•

battery is low, blue when a notiﬁcation has arrived or you are voice recording, and green when fully charged.

Volume: Press to adjust the volume of your

•

device’s sounds.

Front ViewGetting Started

DRAFT FOR INTERNAL USE ONLY

Back View

Microphone

Infrared Transmitter

Camera

Flash

Speaker

USB Charger/Accessory Port

Camera: Take pictures and record videos.

•

Flash: Illuminate subjects in low-light

•

environments when taking a photo or recording video.

Heart Rate Sensor: When using the S Health

•

app, this sensor measures your heart rate via your ﬁngertip.

Infrared Transmitter: Controls external devices

•

using infrared transmissions.

Heart Rate Sensor

Temperature and Humidity Sensor

Microphone

Speaker: Plays ringtones, music, and other

•

sounds.

Temperature and Humidity sensor: Monitors

•

both temperature and humidity conditions. This is used to calculate calories burned within S Health.

USB Charger/Accessory Port: Connect the

•

Charger/USB cable (included), and other optional accessories (not included) .

Microphone: Records audio and detects voice

•

commands.

Back ViewGetting Started

DRAFT FOR INTERNAL USE ONLY

Prepare Your Device

Prior to use, it is necessary to install the SIM card, optional memory card (not included), and the battery.

Remove the Back Cover

Install the SIM Card

When you subscribe to a cellular network, you are provided with a plug-in SIM card. During activation, your SIM card will be loaded with your subscription details, such as your PIN, available optional services, and many others features.

Warning: The plug-in SIM card information and its contacts can be easily damaged by scratching or bending, so be careful when handling, inserting, or removing the card. Keep all SIM cards out of reach of small children.

1. Remove the back cover using the slot on the top of your phone.

2. Lift the cover up and to the right of the phone.

Warning: Do not bend or twist the back cover excessively. Doing so may damage the cover.

► Carefully slide the SIM card into the SIM card

socket (as shown) until the card locks into place.

Make sure that the card’s gold contacts face into the phone and that the angled corner of the card is positioned as shown.

Caution If the card is not inserted correctly, the phone will not detect the SIM card. Re-orient the card back into the slot if the SIM is not detected.

Install a Optional Memory Card

You can use an optional microSD or microSDHC memory card (not included) to expand available memory space.

For more information on installing a memory card, see Install a Memory Card.

Prepare Your DeviceGetting Started

DRAFT FOR INTERNAL USE ONLY

Install the Battery

Charge the Battery

Your device is powered by a rechargeable, standard Li-Ion battery. A Wall/USB Charger (Charging Head and USB cable) is included with the device, for charging the battery.

The battery comes partially charged. You must fully charge the battery before using your device for the ﬁrst time. A fully discharged battery requires up to 4 hours of charge time. After the ﬁrst charge, you can use the device while charging.

1. Insert the battery into the opening on the back of the phone, making sure the connectors align.

2. Gently press down to secure the battery.

Replace the Back Cover

1. Place the battery cover onto the back of the phone and press down.

2. Press along the edge of the back cover until you have a secure seal.

Warning: Use only Samsung-approved charging devices and batteries. Samsung accessories are designed to maximize battery life. Using other accessories may invalidate your warranty and may cause damage.

Your device comes with a charger (charging head and USB cable) to charge your device from any 110/220 VAC outlet.

1. Insert the USB cable into the port.

2. Connect the USB cable to the charging head, then plug the charging head into a standard ACpower outlet.

3. When charging is complete, unplug the charging head from the power outlet and remove the USB cable from the device.

Caution Failure to unplug the wall charger before you remove the battery, can cause damage to the device.

Prepare Your DeviceGetting Started

DRAFT FOR INTERNAL USE ONLY

When to Charge the Battery

When the battery is weak and only a few minutes of talk time remain, the battery icon ( ) blinks and the device sounds a warning tone at regular intervals.

In this condition, your device conserves its remaining battery power, not by turning oﬀ the back light, but by entering the dimming mode.

When the battery level becomes too low, the device automatically turns oﬀ.

► For a quick check of your battery level, see the

battery charge indicator located in the upperright corner of your device’s display. Solid color (

) indicates a full charge.

You can also choose to display a percentage value. Having a percentage value onscreen can provide a better idea of the remaining charge on the battery. For more information, see Battery.

Prepare Your DeviceGetting Started

DRAFT FOR INTERNAL USE ONLY

Set Up Your Device

Turn Your Device On and Oﬀ

Turning the Device On

► Press and hold the Power/Lock until the device

vibrates and starts up.

Turning the Device Oﬀ

1. Press and hold the Power/Lock until the device vibrates and the Device Options menu displays.

2. At the prompt, tap Power oﬀ.

Setup Wizard

The ﬁrst time you turn your device on, Setup Wizard will guide you through the basics of setting up your device.

Follow the prompts to choose a default language, set up accounts, choose location services, and learn more about your device.

Secure Your Device

Use your device’s screen lock features to secure your device. To set a personal screen lock, use the Screen lock option.

Lock the Device

By default, the device locks automatically when the screen times out.

► Press the Power/Lock key.

Unlock the Device

Unlock the device using one of the default unlock screens, or use Screen lock options for increased security.

► Press the Power/Lock key, then touch and drag

your ﬁnger across the screen.

Set Up Your DeviceGetting Started

DRAFT FOR INTERNAL USE ONLY

Set Up Accounts on Your Device

Google Account

Your new device uses your Google account to fully utilize its Android features, including Gmail, Google Hangouts, and the Google Play Store. When you turn on your device for the ﬁrst time, set up a connection with your existing Google account, or create a new Google account.

To create a Google account, or set up your Google account on your device, use Accounts settings. Formore information, see Accounts.

► From Home, tap

Accounts > Add account > Google.

Apps > Settings >

Samsung Account

Create a Samsung account, for access to Samsung content and apps on your device.

To create a Samsung account or set up your Samsung account on your device, use Accounts settings. Formore information, see Accounts.

► From a Home screen, tap

> Accounts > Add account > Samsung account.

Apps > Settings

Set Up Accounts on Your DeviceGetting Started

DRAFT FOR INTERNAL USE ONLY

Know Your Device

Learn some of the key features of your mobile device, including the screens and icons that appear during use, as well as how to navigate the device and use the keyboard.

Warning: Please note that a touch screen responds best to a light touch from the pad of your ﬁnger or a non-metallic stylus. Using excessive force or a metallic object when pressing on the touch screen may damage the tempered glass surface and void the warranty.

DRAFT FOR INTERNAL USE ONLY

Home Screen

Widget

Notiﬁcations Icons

Status Icons

Status Bar

Home Screen Indicator

App Shortcuts: Shortcuts to your favorite

•

applications on the Home screen.

Apps Screen: Allows quick access to all of the

•

Applications available.

Home Screen Indicator: Indicates which Home

•

screen is presently displayed.

Status Bar: Displays device status icons (right)

•

and notiﬁcation icons (left).

App

Shortcuts

•

Apps Screen

Notiﬁcations Icons: Displays new messages and emails, notiﬁcations, available software updates, and so on.

Status Icons: Indicates information about the device, such as the network signal strength, battery level, the time, and so on.

Widgets: Self-contained onscreen applications (not shortcuts) . These can be placed onto any of the Home screens.

Home ScreenKnow Your Device

DRAFT FOR INTERNAL USE ONLY

The Home screen is the starting

App Shortcuts

point for using your device.

Customize your home screen by adding application shortcuts, widgets, folders, andusing wallpapers.

Manage Home Screens

Your device comes with multiple home screens by default, and you can additional screen. You can also rearrange the home screens in a diﬀerent order.

1. From a Home screen, pinch the screen.

– or –

Touch and hold an empty space on the screen.

2. Use these options to manage screens:

Add a screen: Scroll to the end of the

•

screens, and then tap Add.

Remove a screen: Touch and hold on a

•

screen, and then drag it to the

Remove.

You can use app shortcuts to launch an app from any home screen.

Add a Shortcut to a Home Screen

1. From a Home screen, tap Apps.

2. Touch and hold an app shortcut, and then drag it to a Home screen and release it.

Remove a Shortcut

1. Touch and hold a shortcut to releaseit.

2. Drag the icon to the Remove icon and then release it.

Note: Removing a shortcut does not delete the app, it just removes the shortcut from the home screen.

Widgets

Widgets are self-contained apps that display on a home screen. Unlike a shortcut, a widget operates right on the home screen. There are all kinds of widgets, including links to a speciﬁc contact, Internet bookmarks, Gmail and email accounts, and many others.

Set a screen as the main home screen:

•

Tap Main Home Screen at the top of a screen. This screen display when you press the Home Key.

Change the order of screens: Touch and hold

•

on a screen, and then drag to a new position.

Add a Widget to the Home Screen

1. Touch and hold an empty space on the screen, and then tap Widgets.

2. Touch and hold a widget, and then drag it to a home screen and release.

Remove a Widget

1. From a Home screen, touch and hold a widget to releaseit.

2. Drag the widget to the Remove icon and releaseit.

Note: Removing a widget does not delete the widget, it just removes the widget from the home screen.

Home ScreenKnow Your Device

DRAFT FOR INTERNAL USE ONLY

Folders

Change the Wallpaper

Place folders on the Home screen to organize items.

Adding Folders

1. From a Home screen, touch and hold on an app shortcut.

2. Drag the shortcut onto release.

Enter a folder name.

•

Tap Add to place additional apps in the

•

folder.

Tap Done on the keyboard.

•

A folder will be created with the shortcut(s) inside.

Create folder and

Using Folders

Tap the folder to open it and access the shortcuts

•

inside.

Change the look of the home and lock screens with wallpaper. You can display a favorite picture, or choose from preloaded wallpapers.

1. From a Home screen, pinch the screen.

– or –

Touch and hold an empty space on the screen.

2. Tap Wallpapers, and then choose Home screen, Lock screen, or Home and lock screens.

3. Tap a wallpaper to see a sample, and then tap Set wallpaper.

To add shortcuts to the folder, touch and hold

•

the shortcut, and then drag it onto the folder and release.

To delete a folder, touch and hold the folder until

•

it detaches, and then drag it to Remove and release.

Tap Menu to change the folder’s color scheme.

•

Home ScreenKnow Your Device

DRAFT FOR INTERNAL USE ONLY

Status Bar

The Status Bar at the top of the home screen provides device information (such as network status, battery charge, and time) on the right side and notiﬁcation alerts on the left.

Status Icons

Battery is fully charged.

Battery is low.

Battery is charging.

Wi-Fi is active.

Signal strength.

Notication Icons

App updates are available from the Google Play Store.

App updates are complete.

Keyboard is in use.

Location service (GPS) is active.

New email has arrived

New Gmail has arrived.

Download of a ﬁle or app is in progress.

Upload or sending of a ﬁle is in progress.

Connected to a computer using a USBcable.

No wireless network is available.

The device is connected to a 3G wireless network.

The device is connected to a 4G LTE wireless network.

Vibrate mode is enabled.

Mute mode is enabled.

NFC (Near-Field Communication) is enabled.

Missed call.

Call in progress.

Call is on hold.

Call is using speakerphone.

New voicemail message has been received.

New text or multimedia message has arrived.

No SIM card is installed, or the installed SIM card is not working.

Status BarKnow Your Device

DRAFT FOR INTERNAL USE ONLY

Notiﬁcation Panel

Quick settings

Adjust screen

brightness

Tap notiﬁcation

to launch app or

view detail

Settings

View additional Quick settings

Clear all notiﬁcations

Notiﬁcation icons display on the Status Bar displaying calendar events, device status, and more. For details about these notiﬁcations, open the Notiﬁcation Panel.

View the Notiﬁcation Panel

1. Swipe down on the Status Bar to display the Notiﬁcation Panel.

2. Scroll down the list to see notiﬁcation details.

Tap an item to open it.

•

To clear a single notiﬁcation, drag the

•

notiﬁcation left or right. Tap clear all notiﬁcations.

Clear all to

Quick Settings

In addition to notiﬁcations, the Notiﬁcation Panel also provides quick access to device functions such as Wi-Fi, allowing you to quickly turn them on or oﬀ.

► To view additional Quick settings, tap

Viewall.

Notiﬁcation Panel Settings

To customize the Notiﬁcation Panel, see

Notiﬁcation Panel.

3. To close the Notiﬁcation Panel, swipe upward from the bottom of the screen or tap

Back.

Notiﬁcation PanelKnow Your Device

DRAFT FOR INTERNAL USE ONLY

Entering Text

Using the SamsungKeyboard

Type your text input using a QWERTY keyboard.

Special Keys

Tap once to use Google Voice Typing.

Tap an hold to access keyboard settings and advanced keyboard features.

Using Google Voice Typing

Instead of typing, speak your text input.

1. On the Samsung Keyboard, tap Google Voice Type.

2. Speak your text.

Conﬁgure Google Voice Typing

Customize Google Voice Typing. For more information, see Google Voice Typing Settings.

Access the clipboard.

Access keyboard settings.

Tap to switch to numbers and symbols.

Tap to switch to letters.

Conﬁgure the Samsung Keyboard

Customize the Samsung Keyboard. For more information , see Samsung Keyboard Settings.

Entering TextKnow Your Device

DRAFT FOR INTERNAL USE ONLY

Calling

Make telephone calls using a variety of calling features and services.

DRAFT FOR INTERNAL USE ONLY

Calling

Learn how to make or answer a call. Explore features and functionality associated with making or answering a call.

Make a Call

1. From a Home screen, tap Phone.

2. Enter a number and tap

Quickly Dial a Number from YourContactList

1. From a Home screen, tap Apps > Contacts.

2. While viewing your contact list, swipe your ﬁnger

across a contact to the right call the contact.

Dial a Recent Number

All incoming, outgoing and missed calls are recorded in the Call log. If the number or caller is listed in your contacts list, the associated name is also displayed.

1. From a Home screen, tap

2. Tap the Logs tab. A list of recent calls is

displayed.

Dial.

Phone.

Answer a Call

When a call is received the phone rings and displays the caller’s phone number, or name if stored in the contacts list.

1. At the incoming call screen:

Touch and drag Answer in any direction to

answer the call.

Touch and drag Reject in any direction to

reject the call and send it to your voicemail.

2. Tap

Multitasking While on a Call

If you exit the call screen and return to a Home screen, your active call is indicated by an icon on the Status bar.

This lets you continue with your current call and do something else, such as access the contacts list, view a recent email, locate a picture, and so on.

► Tap the reactivate button to return to the

callscreen.

– or –

To end a call from any application, swipe the Status bar downward to reveal the Notiﬁcations panel, and then tap End call.

Endcall.

3. Tap a contact, and then tap

Call.

End a Call

► When you are ready to end your call, tap End.

CallingCalling

DRAFT FOR INTERNAL USE ONLY

Options During a Call

Your phone provides a number of functions that you can use during a call.

Adjusting the Call Volume

► Press the Volume Key to increase or decrease

the volume.

– or –

Quickly add more volume to the incoming audio by tapping

Listen with the Speaker or BluetoothHeadset

Listen to the call using the speaker or through a Bluetoothheadset (not included).

► Press Speaker to hear the caller using the

speaker.

– or –

Menu > Extra volume.

Call Waiting

If your service plan supports this feature, you can answer an incoming call while you have a call in progress. You are notiﬁed of an incoming call by a call waiting tone.

To answer a new call while you have a call in progress:

1. Slide new call. Tap an option:

2. Tap the previous On hold number entry and select Swap to switch between the two calls. This places the new caller on hold and activates the previous call.

Answer in any direction to answer the

Putting [Caller] on hold to place the previous caller on hold while you answer the new incoming call.

Ending call with [Caller] to end the previous call and answer the new call.

Press Bluetooth to use a Bluetooth headset (notincluded).

Personalize the Call Sound Setting

Adjust the sound by using an audio equalizer.

► From the currently active call, tap

Personalize call sound.

Menu >

Place a New Call While in a Call

If your service plan supports this feature, you can make another call while a call is in progress.

1. From the active call, tap Add call to dial the second call. The ﬁrst call is displayed as a thumbnail.

2. Dial the new number and tap

Tap Swap to switch between the two calls.

Tap Merge to hear both callers at once

(multiconferencing).

Dial.

Call Log

The numbers of the calls you have dialed, received, or missed are stored in the Call log.

1. From a Home screen, tap

2. Tap the Logs tab. A list of recent calls is displayed. If the caller is in your contacts list, their name is displayed.

Save a Recent Call to Your Contacts List

1. From a Home screen, tap Phone > Logs tab.

2. Tap the call you want to save add to your contacts list.

3. Tap Create contact.

– or –

If you want to replace the number for an existing contact, tap Update existing.

Phone.

CallingCalling

DRAFT FOR INTERNAL USE ONLY

Delete a Call from the Call Log

1. From a Home screen, tap Phone > Logs tab.

2. Touch and hold the call you want to delete from the Call log.

3. Tap Delete.

Make an Emergency Call

The Emergency calling mode makes redialing an emergency number a 1-tap process.

This mode can drain your battery power more rapidly than normal calling mode.

Add a Call to the Reject List

By adding a caller to your Reject list, future calls from this number will be sent directly to your voicemail.

1. From a Home screen, tap

2. Touch and hold the caller you want to add to the Reject list.

3. Tap

Menu > Add to reject list.

Phone > Logs.

Make a Call Using Speed Dial

You can assign a shortcut number to a contact for speed dialing their default number.

► To make a call using Speed Dial, tap

> Keypad and enter the speed dial number, hold down on the last digit.

Create a Speed Dial

Phone

Make an Emergency Call without a SIMCard

Without a SIM card, you can only make an emergency call with the phone; normal cell phone service is not available.

1. From the Lock screen, tap Emergency call.

2. Enter 911 and tap

3. Complete your call. During this type of call, you will have access to the Speaker mode, Keypad, and End Call features.

4. Tap

Endcall.

Dial.

Make an Emergency Call with a SIM Card

1. From a Home screen, tap Phone.

2. Enter the emergency number (example: 911), then tap

Dial.

1. From a Home screen, tap Apps > Contacts.

2. Tap

Menu > Speed dial. The Speed dial screen displays showing the numbers 1 through 100 (Number 1 is reserved for voicemail) .

Tap an unused number to assign it to a

contact’s default phone number.

To remove a speed dial number assignment,

tap Remove.

Call Settings

To access the Call settings menu:

► From a Home screen, tap

Settings > Call.

– or –

From a Home screen, tap Call.

Phone > Menu >

Apps > Settings >

CallingCalling

DRAFT FOR INTERNAL USE ONLY

Applications

The Apps screen displays all applications installed on your device, both preloaded apps and apps you download and install yourself.

Learn how to change the way apps appear, organize apps into folders, and uninstall or disable apps.

DRAFT FOR INTERNAL USE ONLY

Apps Screen

The Apps screen contains preloaded apps, plus apps you’ve downloaded. You can uninstall or disable apps, or hide them from view.

Shortcuts to app can be placed on any of the Home screens. For more information, see App Shortcuts.

Accessing Applications

1. From a Home screen, tap Apps.

2. Tap an application’s icon to launch it.

3. To return to the main Home screen, press the Home key.

Download and Install NewApps

Find new apps to download and install on your device:

Uninstall or Disable Apps

You can uninstall apps you download and install. Preloaded apps cannot be uninstalled, but they can be disabled.

1. From a Home screen, tap

2. Tap

3. Tap

Menu > Uninstall/disable apps. Apps that can be uninstalled or disabled have a Delete symbol appear on their icon.

Delete, and then follow the prompts to

uninstall or disable the app.

Apps.

Organize Your Apps

The Apps icons can be organized in folders and listed alphabetical or in your own custom order.

Change the Order Apps Are Listed

1. From a Home screen, tap Apps.

2. Tap

3. Tap an option:

Menu > View type.

Google Play Store: Download new apps from

•

the Google Play Store. Visit play.google.com/

store/apps to learn more.

Samsung Apps: Download apps speciﬁcally

•

designed for your Samsung device. Visit apps.

samsung.com to learn more.

Customizable grid: The default view, which

•

allows you to touch and hold on apps to move them from screen to screen.

Alphabetical grid: Icons are arranged in a

•

grid, in A-Z order.

Apps ScreenApplications

DRAFT FOR INTERNAL USE ONLY

Use Folders to Organize Apps

1. From a Home screen, tap Apps.

2. Tap

3. Enter a folder name.

4. Tap

Menu > Create folder.

, select apps to include in the folder, and

then tap Done.

Touch the folder to view its apps. Touch an

•

app to launch it.

Touch to select a background color for the

•

folder.

Apps Screen Options

1. From a Home screen, tap Apps.

2. Tap

Menu for these options:

Edit: Touch and hold an app icon then drag

•

it to the Create folder icon to create a new folder. Drag it to the Create page icon to create a new apps screen and place the icon on it. Drag it to App info to view information about this app. Or drag it to Disable or Delete to remove the app

Create folder: Create a new folder to hold the

•

app icon.

Hide Apps from View

You can hide (rather than uninstall or disable) any apps you do not wish to see on the App screen.

1. From a Home screen, tap

2. Tap

3. Tap apps to hide, and then tap Done.

Menu > Hide apps.

Apps.

Hide Apps from View

You can hide (rather than uninstall or disable) any apps you do not wish to see on the App screen.

1. From a Home screen, tap

2. Tap

3. Tap apps to hide, and then tap Done.

Menu > Hide apps.

Apps.

Show Hidden Apps

You can show (unhide) apps you have hidden and put them back on the App screen.

View type: Conﬁgure the apps screen.

•

Uninstall/disable apps: Remove an app that

•

you downloaded to your device. Preloaded apps cannot be uninstalled, but they can be disabled. Touch disable the selected app.

Hide apps: Hide apps from the Apps screen.

•

Show disabled apps: Display disabled apps.

•

Show hidden apps: Display hidden apps.

•

GALAXY Essentials: View and download

•

Samsung apps that are optimized for use with GALAXY devices.

Help: View information about your device.

•

Delete to remove or

1. From a Home screen, tap

2. Tap

3. Tap apps to unhide, and then tap Done.

Menu > Hidden apps.

Apps.

Apps ScreenApplications

DRAFT FOR INTERNAL USE ONLY

Google Applications

Chrome

Use Chrome to browse the Internet and bring your open tabs, bookmarks and address bar data from your computer to your tablet.

Visit google.com/chrome/browser to learn more.

Drive

Open, view, rename, and share your Google Docs and ﬁles.

Visit drive.google.com to learn more.

Gmail

Send and receive email with Gmail, Google’s web-based email.

Visit gmail.com to learn more.

Google

Search not only the Internet, but also applications and their contents on the device as well.

Google Settings

Quickly and easily change Google app settings to suit your preferences.

Note: You must be signed in to the application in which you want to conﬁgure. For example, sign in to Google+ in order to conﬁgure Google+ settings.

Google+

Stay connected and share life as it happens with Google+. Chat with friends and family, post photos, or see what others are sharing while you’re on the go.

Visit google.com/mobile/+ to learn more.

Hangouts

Hangouts is an online place to meet friends and family, share photos, and host video calls. Conversation logs are automatically saved to a Chats area in your Gmail account.

Visit google.com/hangouts to learn more.

Google Now

Google Now recognizes repeated actions performed on the device to automatically send user-speciﬁc information “cards.”

Visit google.com/landing/now to learn more.

► Press and hold Home.

When Google Now is enabled, you can also access it by touching

Maps

Use Google Maps to ﬁnd your current location, get directions, and other location-based information.

Visit google.com/maps to learn more.

You must enable location services to use Maps. For more information, see Location

Services.

Google ApplicationsApplications

DRAFT FOR INTERNAL USE ONLY

Photos

Play Newsstand

This application automatically backs up your photos and videos to a secure Google cloud location.

Play Books

With Google Play Books, you can ﬁnd millions of free e-books and hundreds of thousands more to buy in the eBookstore.

Visit play.google.com/store/books to learn more.

Play Games

Discover hundreds of games for download and purchase through the Google Play Store.

Visit play.google.com/store to learn more.

Play Movies & TV

Watch movies and TV shows purchased from Google Play. You can stream them instantly, or download them for viewing when you’re not connected to the Internet. You can also view videos saved on your device.

Subscribe to your favorite magazines so you can have them available to read on your device at your leisure.

Visit play.google.com/store/newsstand to learn more.

PlayStore

Find new apps, movies and TV shows, music, books, magazines, and games in Google Play Store.

Visit play.google.com/store to learn more.

Voice Search

Use voice commands to search the web with Google.

YouTube

View and upload YouTube videos, right from your device.

Visit youtube.com to learn more.

Visit play.google.com/about/movies to learn more.

Play Music

With Google Play Music, you can play music you’ve downloaded, and music you copied from your computer.

Visit play.google.com/about/music to learn more.

Google ApplicationsApplications

DRAFT FOR INTERNAL USE ONLY

Other Applications

Amazon

Shop at Amazon.com from your device.

Visit Amazon.com to learn more.

City ID

City ID is an enhanced Caller ID feature that automatically displays the city and state of incoming calls. City ID provides over 20,000 cities in North America, giving you an important tool to help identify unknown callers and more eﬀectively manage your communications.

Dropbox

View, edit, add, and delete ﬁles at any time in Dropbox from your computers, phones, or tablets. Files are automatically synchronized online, no matter what device is used to access or edit them.

KIDOZ

Provides fun and educational games, apps, videos, and sites for kids in one safe place.

Mobile Data Security

Keep your data safe and secure if your device is lost or stolen.

Visit uscellular.com/protector-series/

mobile-data-security to learn more.

Mobile TV

Mobile TV is a subscription service that lets you watch your favorite TV shows using your handset.

Visit uscellular.com/video/mobileTV to learn more.

Visit www.dropbox.com to learn more.

Flipboard

Use this application to access your personalized magazines.

Visit ﬂipboard.com to learn more.

Gameloft

Preview and download great mobile games for your device.

Visit gameloft.com to learn more.

Slacker

Enjoy free Internet radio with your mobile device.

Visit slacker.com to learn more.

Smart Remote

Discover and control your TV’s programming right from your device. You can control your entertainment system with gestures from your device. Peel Smart Remote also suggests TV shows for you based on what you watch and like.

Visit peel.com to learn more.

Other ApplicationsApplications

DRAFT FOR INTERNAL USE ONLY

Tone Room Deluxe

Your Navigator Deluxe

Access the latest and hottest content from your favorite artists for ringtones and ring back tones.

Visit toneroomdeluxe.uscellular.com to learn more.

Enjoy all the features of an advanced car navigation system. Obtain turnby-turn driving directions (including voice guided turn-by-turn directions) with GPS accuracy. Search for any destination (including gas stations, ATMs, restaurants, and more). View detailed maps of any location

Visit uscellular.com/apps/your-navigator-

deluxe to learn more.

Other ApplicationsApplications

DRAFT FOR INTERNAL USE ONLY

Camera and Video

Current ﬂashmode

Camera settings

Current shooting mode

Change shooting mode

View pictures and

videosintheGallery

Switch between the front and back cameras

Record video

Anti-shake active

Take a picture

Taking Pictures

Take pictures with your device’s front or back camera, or combine shots with Dual mode.

1. From a Home screen, tap

2. Using the display screen as a viewﬁnder, compose your shot by aiming the camera at the subject. While composing your picture, use the onscreen options, or these gestures:

3. Press the Volume key up or down to zoom in or out, or tap the screen with two ﬁngers and pinch or spread them on the screen to zoom.

4. Tap the screen to focus on the area you touched.

5. Tap

to take the picture.

Apps > Camera.

Shooting Mode

Several photo eﬀects are available. Some modes are not available when taking self-portraits.

► Tap MODE, and then scroll up or down the

screen at the right side of the screen.

Auto: Allow the camera to evaluate the

surroundings and determine the ideal mode for the photo.

Beauty face: Take a photo with lightened

faces for gentler images.

Shot & more: Take a quick burst of photos

and apply eﬀects to them.

Panorama: Take a photo composed of many

photos strung together.

Camera and VideoApplications

DRAFT FOR INTERNAL USE ONLY

HDR (Rich tone): Take photos without losing

details in bright and dark areas.

Dual camera: Take pictures and record videos

using the front and rear cameras at the same time. A variety of picture-in-picture styles are available.

Manage modes: Select which shooting modes

to display when you tap MODE.

Download: Download additional shooting

modes from the Samsung Apps store.

Camera Settings

► Tap to conﬁgure settings for Camera. Not all of

the following options are available in both still camera and video camera modes. The available options vary depending on the mode used.

Picture size: Select a resolution. Use higher

resolution for higher quality. Higher resolution photos take up more memory.

Video size: Select a resolution. Use higher

resolution for higher quality. Higher resolution videos take up more memory.

Recording mode: Select Normal, Limit for

email, or Fast motion mode.

Video stabilization: Activate anti-shake. Anti-

shake helps to keep the focus steady when the camera is moving.

Eﬀects: Add special graphical eﬀects.

Flash: Activate or deactivate the ﬂash.

Timer: Take time-delayed pictures or videos.

View mode: View pictures and videos in

standard ratio or full-screen.

Location tag: Attach a GPS location tag to the

photo.

Save as ﬂipped: Save the self-portrait or self-

recording as a reversed (or ‘mirrored’) image.

Storage location: Select the memory location

for storage.

Burst shot: Take a series of photos of moving

subjects.

Picture stabilization: Activate anti-shake. Anti-

shake helps to keep the focus steady when the camera is moving.

Face detection: Detect faces in pictures for

tagging with the person’s name.

ISO: Select an ISO value. This controls

camera light sensitivity. It is measured in ﬁlm-camera equivalents. Low values are for stationary or brightly-lit objects. Higher values are for fast-moving or poorly-lit objects.

Metering modes: Select a metering

method. This determines how light values are calculated. Center-weighted measures background light in the center of the scene. Spot measures the light value at a speciﬁc location. Matrix averages the entire scene.

Tap to take pics: Tap the image on the

preview screen to take photos.

Save as: Save the picture in HDR (rich tone)

only.

Review pics/videos: Set to show photos or

videos after taking them.

Remote viewﬁnder: Take pictures using the

viewﬁnder of a connected device. Wi-Fi Direct is required.

White balance: Select an appropriate white

balance, so images have a true-to-life color range. The settings are designed for speciﬁc lighting situations. These settings are similar to the heat range for white-balance exposure in professional cameras.

Exposure value: Change the exposure value.

This determines how much light the camera’s sensor receives. For low light situations, use a higher exposure.

Grid lines: Display viewﬁnder grid lines to help

composition when selecting subjects.

Volume key: Use the Volume key as the

camera key, the record key, or as a zoom key.

Voice control: Set the camera to take photos

with voice commands.

Help: View help on using the camera.

Reset settings: Reset the camera settings.

Camera and VideoApplications

DRAFT FOR INTERNAL USE ONLY

Contacts

Store and manage your contacts with the Contacts app, which can be synchronized with a variety of your existing personal accounts, including Google, Email, Facebook, and your Samsung account.

For more information on connecting with and managing your accounts through your device, see

Accounts.

Contacts

Access your list of contacts by using the Contacts app, which is a shortcut to the Contacts tab. To

access your Contacts list:

► From a Home screen, tap

Contacts.

Apps >

Adding a Contact

Use the following procedure to add a new contact.

1. From a Home screen, tap Contacts.

2. Tap

information.

Add, and then tap contact ﬁelds to enter

Choose a storage account for the contact. You

can choose Device to store the contact on the device, or choose an account.

Tap Photo to assign a picture to the new

contact.

Enter a name, phone number, email address,

and assign the contact to a group. Tap Addanother ﬁeld to add additional contact information.

Tap Add to enter additional entries.

Tap Delete to remove an entry.

Tap Expand for additional ﬁelds.

Apps >

Finding a Contact

You can search for a contact, or scroll the list to ﬁnd one by name.

1. From a Home screen, tap Contacts.

2. Tap the Search ﬁeld, and then enter characters

to ﬁnd contacts that match.

– or –

Tap a letter on the side of the list to jump directly to that letter in the alphabetical list. You can also press and slide across the alphabetical list to select a letter with better precision.

Apps >

Tap to choose a label for the ﬁeld.

3. Tap Save.

Edit a Contact

When editing a contact, you can tap a ﬁeld and change or delete the information, or you can add additional ﬁelds to the contact’s list of information.

1. From a Home screen, tap Contacts.

2. Tap the contact to display it, and then tap Edit.

3. Tap any of the ﬁelds to add, change, or delete

information.

4. Tap Save.

Apps >

ContactsApplications

DRAFT FOR INTERNAL USE ONLY

Share a Name Card

Unlink Contacts

When you share a name card, the contact’s information is sent as a vCard ﬁle (.vcf). You can share a vCard via Bluetooth or Wi-Fi Direct, attach it to a message, or save it to a storage location.

1. From a Home screen, tap Contacts.

2. Tap a contact to display it, and then tap

Moreoptions > Share name card via.

3. Choose a sharing method and follow the

prompts.

Apps >

Save a Business Card as a Contact

1. From a Home screen, tap Apps > Contacts.

2. Tap

3. When the camera opens, center the business

4. Your device analyzes the picture of the business

Moreoptions > Business cards > Add.

card in the guidelines on the screen. If the Camera can recognize the business card, it will take the picture automatically, or you can take the picture manually.

card to create a new contact. You can also add more information to the contact.

1. From a Home screen, tap Apps > Contacts.

2. Tap the contact to display it, and then tap

Link.

3. Tap

from the main contact.

Remove beside contacts to unlink them

Delete Contacts

You can delete a single contact, or choose multiple contacts to delete.

1. From a Home screen, tap Contacts.

2. Touch and hold on a contact to select it. You

can also tap other contacts, or choose Select all to select all contacts.

3. Tap

Delete, and then tap OK to conﬁrm.

Apps >

Favorites

When you mark contacts as favorites, they are easily accessible from other apps. Favorites display together on the Favorites tab in Contacts.

5. Tap Save. The business card is displayed as the picture for the contact.

Note: You can view all your business cards by tapping

Moreoptions > Businesscards.

Link Contacts

When you have contacts from various sources (Gmail, Facebook, etc.) , you may have multiple similar entries for a single contact. Contacts lets you link multiple entries into a single contact.

1. From a Home screen, tap

Contacts.

2. Tap the contact to display it, and then tap

Link.

3. Tap Link another contact, and then select contact(s) to link to the original contact.

4. Tap Done to save the linked contact.

Apps >

Mark Contacts as Favorites

1. From a Home screen, tap Apps > Contacts.

2. Tap a contact to display it, and then tap

Favorite (turns bright ).

Remove Contacts from Favorites

1. From a Home screen, tap Apps > Contacts.

2. Tap the Favorites tab, and then touch and

hold on a contact to select it. You can also tap other contacts, or choose Select all to select all contacts.

3. Tap

Delete.

ContactsApplications

DRAFT FOR INTERNAL USE ONLY

Create a Shortcut to a Favorite

Rename a Group

You can create a shortcut to a favorite on the home screen, to access their information directly from the home screen.

1. From a Home screen, tap Contacts.

2. Tap the Favorites tab, and then touch and hold

on a contact to select it.

3. Tap

Moreoptions > Add shortcut to home screen. The new shortcut displays in an empty area of the home screen.

Apps >

Groups

You can use groups to organize your contacts. Your device comes with preloaded groups, and you can create your own. You might create a group for your family, for coworkers, or a team. Groups make it easy to ﬁnd contacts, and you can send messages to the members of a group.

1. From a Home screen, tap Apps > Contacts.

2. Tap the Groups tab, and then tap a group.

3. Tap

4. Tap Save.

Moreoptions > Edit group and enter a

new name.

Add Contacts to a Group

1. From a Home screen, tap Apps > Contacts.

2. Tap the Groups tab, and then tap a group.

3. Tap

want to add.

4. Tap Done.

Add, and then tap the contact(s) you

Send an Email to a Group

You can send an email to members of a group.

Create a Group

1. From a Home screen, tap Apps > Contacts.

2. Tap the Groups tab, and then tap

3. Tap ﬁelds to enter information about the group:

Tap Create group in All Accounts in to

choose where to save the group. You can save it to a speciﬁc account, to the device memory, or to all accounts.

Tap Group name to enter a name for the new

group.

4. Tap Add member and select contact(s) to add to

the new group, and then tap Done.

5. Tap Save.

Add.

1. From a Home screen, tap Contacts.

2. Tap the Groups tab, and then tap a group.

3. Tap

4. Tap contacts to select them, or tap Select all,

5. Choose an account and follow the prompts.

Moreoptions > Send email.

and then tap Done. (You will only see group members that have email addresses in their contact records.)

Apps >

Delete a Group

Preset groups, such as Family, cannot be deleted.

1. From a Home screen, tap Contacts.

2. Tap the Groups tab.

3. Tap

4. Select groups to delete and tap Done.

Moreoptions > Delete groups.

Apps >

ContactsApplications

DRAFT FOR INTERNAL USE ONLY

Contact Settings

These settings allow you to modify settings associated with using the Contacts app.

1. From a Home screen, tap Contacts.

2. Tap

3. Tap an option and follow the onscreen

Moreoptions > Settings.

instructions.

Apps >

ContactsApplications

DRAFT FOR INTERNAL USE ONLY

Calculator

The Calculator provides basic and advanced arithmetic functions.

Basic Operation

1. From a Home screen, tap Apps > Calculator.

2. Enter the ﬁrst number using the numeric keys.

3. Tap the appropriate arithmetic function key.

4. Enter the next number.

5. To view the result, tap the = (Equals) key.

Additional Functions

To clear the results:

► Tap

To clear the calculator history:

► Tap

To copy all or part of the calculation to the clipboard:

► Touch and hold an entry in the displayﬁeld.

Clear.

Menu > Clearhistory.

Scientiﬁc Calculator

Turn the device landscape to use advanced arithmetic functions, such as sin, cos, and tan.

CalculatorApplications

DRAFT FOR INTERNAL USE ONLY

Calendar

Manage your events and tasks.

Create an Event or Task

1. From a Home screen, tap Apps >

Calendar.

2. Tap

methods:

3. Enter details for the event or task, and then

tapDone.

Add and use one of the following

Event: Enter an event with an optional repeat

setting.

Task: Enter a task with an optional priority

setting.

Delete an Event or Tasks

1. From a Home screen, tap Apps >

Calendar.

2. Tap to view an event or task. Tap > Delete.

– or –

To delete multiple events or tasks, tap

Moreoptions > Delete, select events or

tasks,and then tap Delete.

Moreoptions

Sharing Events

1. From a Home screen, tap Apps >

Calendar.

2. Tap to view an event or task. Tap > Share via, select a sharing method, and follow the prompts.

Moreoptions

Calendar Settings

These settings allow you to modify settings associated with using the Calendar.

1. From a Home screen, tap

Calendar.

Apps >

2. Tap

3. Tap an option and follow the prompts.

More options > Settings.

CalendarApplications

DRAFT FOR INTERNAL USE ONLY

Clock

The Clock app oﬀers features for keeping track of time and setting

Alarm tone: If you have chosen an alarm type

that includes sound, choose a sound to play for the alarm.

alarms.

1. From a Home screen, tap Apps > Clock.

2. Tap a tab to use a feature:

Alarm: This feature allows you to set an alarm

to ring at a speciﬁc time.

World clock: allows you to view the time of

day or night in other parts of the world. World Clock displays time in hundreds of diﬀerent cities, within all 24 time zones around the world.

Stopwatch: You can use this option to

measure intervals of time.

Timer: You can use this option to set a

countdown timer. Use a timer to count down to an event based on a preset time length (hours, minutes, and seconds).

Volume: If you have chosen an alarm type

that includes sound, drag the slider to set the volume of the alarm.

Smart alarm: When on, the alarm will start

playing a tone at a low volume at an interval before the alarm time, and slowly increase in volume. Choose a time interval and a tone to use with smart alarm. Available when you have chosen an alarm type that includes sound.

Name: Enter a name for the alarm.

3. Tap Save.

Delete an Alarm

1. From a Home screen, tap Apps > Clock.

2. Touch and hold an alarm, and then tap

Delete.

Create an Alarm

Create an alarm event. You can set one-time or recurring alarms, and choose options for how to be notiﬁed.

1. From a Home screen, tap

2. Tap

Moreoptions > Create alarm to

conﬁgure:

Time: Choose a time for the alarm.

Days: Choose the days to use this alarm.

Repeat weekly: When enabled, the alarm

repeats every week.

Alarm type: Choose whether the alarm will

use sound, vibration, or vibration and sound to alert you.

Apps > Clock.

ClockApplications

DRAFT FOR INTERNAL USE ONLY

Email

Use the Email app to view and manage all your email accounts in one application.

To access Email:

► From a Home screen, tap

Apps > Email.

Conﬁguring Email Accounts

You can conﬁgure Email for most accounts in just a few steps.

1. From a Home screen, tap

2. Follow the onscreen instructions to set up your email account.

– or –

For additional accounts, tap Settings > Add account.

Apps > Email.

More options >

Managing Your Email Accounts

You can view email you receive for all accounts on the Combined view screen or you can view email accounts individually.

1. From a Home screen, tap

2. Tap the screen to select:

Combined view: View all email in a combined

inbox.

<Account Name>: View email for only this

account.

drop-down menu at the top left of the

Apps > Email.

Refreshing Your Email Account

Refresh your account to update your email accounts.

1. From a Home screen, tap

Apps > Email.

The device communicates with the appropriate server to set up your account and synchronize your email. When complete, your email appears in the Inbox for the account.

Note: To conﬁgure email account settings at any time, tap

More options > Settings. Tap the account to

display Account settings.

2. In the Application Bar, tap

Refresh.

Deleting Email Accounts

To delete an Email account:

1. From a Home screen, tap

2. Tap

3. Tap the account you want to delete, and then tap

More options > Settings.

Delete account.

Apps > Email.

EmailApplications

DRAFT FOR INTERNAL USE ONLY

Gallery

View, edit, and manage pictures and videos.

View Images and Videos

Launching Gallery displays available folders. When another application, such as Email, saves an image, a Download folder is automatically created to contain the image. Likewise, capturing a screenshot automatically creates a Screenshots folder.

1. From a Home screen, tap

2. Tap choose the way items display.

3. Tap

newalbum.

4. Tap a folder to open it.

•

Menu, and then tap Time or Album to

Menu > Albums, and then tap

Moreoptions > Create album to create a

Tap an image or video to view it in fullscreen. Scroll left or right to view the next or previous image or video.

Apps > Gallery.

Trimming Segments of a Video

1. Select a video, and then tap Trim .

2. Using the sliders at the bottom of the screen to trim the video. Move the start bracket to the desired starting point, move the end bracket to the desired ending point, and then tap Done to save the video.

Editing Images

► While viewing an image, tap Moreoptions:

Edit: Use basic tools to edit your photo.

More info: View image details.

Copy to clipboard: Place a copy on the

clipboard.

Studio: Edit your photo with advanced tools.

Rotate left: Rotate the photo counter-

clockwise.

Rotate right: Rotate the photo clockwise.

Zoom In and Out

Use one of the following methods to zoom in or out on an image:

Double-tap anywhere on the screen to zoom in or

•

zoom out.

Spread two ﬁngers apart on any place to zoom in.

•

Pinch the screen to zoom out.

Playing Videos

► From a Home screen, tap Apps > Gallery.

Tap a folder to open it.

Tap a video to view it.

Crop: Resize the frame to crop the image.

Rename: Rename the ﬁle.

Slideshow: Start a slideshow with the images

and videos in the current folder.

Set as: Set the image as wallpaper or as a

contact’s photo.

Print: Print the image via a USB or Wi-Fi

connection. Some printers may not be compatible with the device.

Settings: Change the Gallery settings.

GalleryApplications

DRAFT FOR INTERNAL USE ONLY

Deleting Images

1. From a Home screen, tap Apps > Gallery.

2. Tap a folder to open it.

3. In a folder, tap images, and then tap Done.

– or –

When viewing an single image, tap

More Options > Delete, select

Delete.

Sharing Images

Use one of the following methods:

1. From a Home screen, tap

2. Tap a folder to open it.

3. In a folder, tap images, and then tap others or share them via social network services.

– or –

When viewing an image full screen, tap to send it to others or share it via social network services.

Moreoptions > Select, select

Apps > Gallery.

Share to send them to

Gallery Settings

These settings allow you to modify settings associated with using your Gallery.

1. From a Home screen, tap

2. Tap

3. Tap an option and follow the onscreen

4. Tap

More options > Settings.

instructions.

More options > Add account to add a

Samsung, Google, or Facebook account.

Apps > Gallery.

GalleryApplications

DRAFT FOR INTERNAL USE ONLY

Internet

Access the Internet with a fully featured web browser.

Access the Internet

► From a Home screen, tap Apps > Internet.

Command Keys

Tap Back or Back key to return to the

•

previous page.

Tap Forward to go forward to a recent page.

•

Tap Home to display your Internet Home

•

screen.

Tap Refresh to reload the current page.

•

Bookmarks

To bookmark the current web page, tap

•

Bookmark > Add.

To open a bookmarked web page, tap

•

Bookmark and tap an entry.

History

► Tap Bookmark > History tab to view a list of

recently visited web pages.

Saved Pages

To save a web page, tap More options >

•

Savepage.

Tap Bookmark > Saved tab to view a list of

•

saved web pages

Viewing Web Site

► To view a web site, tap the address ﬁeld, enter

the web address, and then tap Go.

To share, save, or print the current web page,

tap

More options.

Tap the screen twice to zoom in or out. Or

pinch the screen to zoom out and stretch the screen to zoom in.

Browser Tabs

Use tabs to view multiple web pages at the same time.

► To open a new tab, tap

Newtab.

Tap a diﬀerent tab to view it.

To close a tab, tap Close.

More options >

Sharing Pages

► To share a web page address with others, tap

More options > Share via and follow the

prompts.

Incognito Tabs

Pages viewed with incognito tabs do not appear within your browser history or search history, and leave no traces (such as cookies) on your device.

Note: Any downloaded ﬁles will remain on your device after you close the incognito tab.

Incognito tabs display

► To open a new incognito tab, tap

> Newincognito tab.

Incognito on their tab.

Moreoptions

InternetApplications

DRAFT FOR INTERNAL USE ONLY

Messaging

Learn how to send and receive diﬀerent messages using the default Messaging app on your phone.

Types of Messages

Your default Messaging app provides the following message types:

Text Messages (SMS)

•

Multimedia Messages (MMS)

•

The Short Message Service (SMS) lets you send and receive text messages to and from other mobile phones or email addresses. To use this feature, you may need to subscribe to your service provider’s message service.

The Multimedia Messaging Service (MMS) lets you send and receive multimedia messages (such as picture, video, and audio messages) to and from other mobile phones or email addresses. To use this feature, you may need to subscribe to your service provider’s multimedia message service.

Messaging icons are displayed at the top of the screen and indicate when messages are received and their type.

Creating and Sending Messages

This section describes how to create a send a message using the Messaging app.

1. From a Home screen, tap Compose.

2. Tap the Enter recipient ﬁeld to manually enter

a recipient or tap recipient from your Contacts. You can also select the recipient based on Groups, Favorites, or Logs.

3. If adding a recipient from your Contacts, tap the

contact to place a check mark then tap Done. The contact will be placed in the recipient ﬁeld.

4. Enter additional recipients by separating each

entry with a semicolon (;) and then using the previous procedure. More recipients can be added at any time before the message is sent.

Note: For the Group option, if the number of recipients is less than 10, all members in the group will be added. You will need to delete any unnecessary members in the list by selecting the trash can icon and deleting unwanted entries.

5. Tap the Enter message ﬁeld and use the

onscreen keypad to enter a message. For more information, please see Entering Text.

6. Tap

emoticon from an onscreen list and then add it into your message (at the cursor location) if desired.

Add emoticons to choose an available

Add Recipient to select a

Messaging >

7. Review your message and tap

Note: If you exit a message before you send it, the message is automatically saved as a draft.

Send.

MessagingApplications

DRAFT FOR INTERNAL USE ONLY

Viewing New Messages

Messaging Settings

When you receive a new message, a new message icon appears on the Status Bar.

To view the message:

1. Open the Notiﬁcation Panel and select the message. For more information, please see

Notiﬁcation Panel.

– or –

From a Home screen, tap then tap the new message to view it.

2. To play a multimedia message (audio or video), tap

3. To scroll through the list of messages, tap the screen and scroll up or down the page.

Play.

Messaging, and

Deleting Messages

To delete messages, follow these steps:

1. From a Home screen, tap

Messaging.

Conﬁgure the settings for text messages, multimedia messages, voicemail, and push messages.

► From a Home screen, tap

Messaging > More options > Settings.

Apps >

Emergency Alerts

This device is designed to receive wireless emergency alerts from the Commercial Mobile Alerting System (CMAS) which may also be known as the Personal Localized Alerting Network (PLAN) . For more information, please contact your wireless provider.

Emergency Alerts allows customers to receive geographically-targeted messages. Alert messages are provided by the US Department of Homeland Security and will alert customers of imminent threats to their safety within their area. There is no charge for receiving an Emergency Alert message.

There are three types of Emergency Alerts:

2. Tap

3. Tap each message you want to delete or tap

4. Tap Done.

5. At the Delete conversations prompt, tap OK to

More options > Delete.

Select all.

delete or Cancel to cancel.

Message Search

1. You can search through your messages by using the Message Search feature.

2. From a Home screen, tap

3. Tap

4. Enter a word or phrase to search for, and then tap

Search.

Search on the keyboard.

Messaging.

Alerts issued by the President

•

Alerts involving imminent threats to safety of life

•

(Extreme and Severe)

AMBER Alerts (missing child alert)

•

Users may choose not to receive Imminent Threats (Extreme and Severe) and AMBER Alerts. Alerts issued by the President cannot be disabled.

To disable Imminent Threats and AMBER Alerts, follow the instructions below:

1. From a Home screen, tap

2. Tap

3. Tap Emergency alerts.

4. All alerts are enabled by default (check mark

More options > Settings >

Emergencyalerts.

showing). Tap on an alert option to disable it.

Messaging.

MessagingApplications

DRAFT FOR INTERNAL USE ONLY

Music Player

Sound (opens Volume)

Stream the song to

another device

Mark as favorite

Playback position

Shuﬄe songs

Elapsed playing time

View playlist

Volume

Adjust the sound quality with SoundAlive

Repeat mode for the song orplaylist

Length of song

Add to playlist

Rewind song or go toprevious song

Listen to your favorite songs with the Music player. Navigate through your music library, play songs, and create customized playlists.

Pause/Play

Listen to Music

1. From a Home screen, tap Apps > Music.

2. Tap a library category at the top of the screen to

3. Scroll through the list of songs and tap an entry

Scan forward or gotonext song

view your music ﬁles.

to begin playback.

Music PlayerApplications

DRAFT FOR INTERNAL USE ONLY

MyFiles

Access ﬁles stored on your device, including images, videos, songs, and sound clips.

View Files

Files stored in the device are organized into the following groups:

Quick Search: Files are grouped into the

•

following categories:

Recent ﬁles: View recently saved ﬁles.

Images: View image ﬁles.

Videos: View video ﬁles.

Audio: View audio ﬁles.

Documents: View document ﬁles.

Downloaded apps: View downloaded

apps.

Download History: View all apps and ﬁles that

•

have been downloaded to the device.

Shortcuts: Contains shortcuts to ﬁles or folders

•

that you have added. This option only appears if you have added shortcuts to the MyFiles main screen.

Local Storage: View folders and ﬁles in their

•

storage locations.

Device storage: View folders and ﬁles

located on the device.

To view ﬁles in My Files:

1. From Home, tap

2. Tap a category to view the relevant ﬁles or folders.

3. Tap a ﬁle or folder to open it.

Apps > MyFiles.

My Files Options

On the main screen of My Files, the following options are available:

► Tap

information for your device and memory card (ifinstalled) .

► Tap

Search, and then enter search criteria.

Storage usage to view memory

Menu for these options:

Select: Select shortcuts. This option only

appears if you have added shortcuts to the MyFiles mains screen.

Delete: Select and delete ﬁles or folders.

This option only appears if you have added shortcuts to the MyFiles main screen.

Add shortcut: Add a shortcut on the My Files

main screen to any folder.

Add FTP server: Add an FTP server shortcut

on the My Files main screen.

Scan for nearby devices: Search for devices

that have media sharing activated.

Settings: Change the settings for viewing ﬁles.

SD card: View folders and ﬁles located on

the memory card (if installed).

Cloud Storage: Contains shortcuts to FTP

•

servers or other cloud storage locations that you have added. This option only appears if you have added shortcuts to the MyFiles main screen.

MyFilesApplications

DRAFT FOR INTERNAL USE ONLY

Category Options

Options for Selected Files and Folders

After tapping on a category, the following options are available:

► Tap

My Files app.

► Tap

Home to return to the main screen of the

Search, and then enter search criteria.

Menu to ﬁnd the following options:

Select: Select ﬁles or folders.

Delete: Select and delete ﬁles or folders.

Create folder: Add a folder to the current list.

This option only appears in Local Storage categories.

View as: Change the appearance of the ﬁles

or folders.

Sort by: Change the sort order of the ﬁles.

Add shortcut: Add a shortcut to the current

location on either a Home screen or the MyFiles main screen. This option only appears in Local Storage categories.

► Tap Menu > Select, select a ﬁle or folder, and

then use one of these functions:

Share via: Send ﬁles to others or share

them.

Delete: Delete ﬁles or folders.

► Tap

Menu for additional options:

Move: Move ﬁles or folders to another folder.

Copy: Copy ﬁles or folders to another folder

Rename: Rename a ﬁle or folder. This option

only appears when just one ﬁle or folder is selected.

Zip: Create a zip folder containing the selected

ﬁles. This option only appears in Local Storage categories. A selected zip folder has the additional options of Extract and Extract

to current folder.

Details: View details of the selected ﬁle(s) or

folder(s).

Settings: Change the settings for viewing ﬁles.

MyFilesApplications

DRAFT FOR INTERNAL USE ONLY

S Health

Use SHealth to plan, track, and manage your health goals and activities, including exercise, sleep, and meals.

1. From a Home screen, tap Apps > SHealth.

2. Read and accept the terms and conditions.

3. Set up your health proﬁle and goals.

S HealthApplications

DRAFT FOR INTERNAL USE ONLY

S Voice

Speak commands to perform operations on your device, and to speak criteria for searches and other operations.

Use SVoice to ﬁnd everything from directions to trivia answers to the current weather forecast.

1. From a Home screen, tap Apps > SVoice.

2. Speak a command.

3. Tap the microphone icon if the device does not hear you, or to give it another command.

Tip: Tap a tutorial.

Menu for example commands and to view

S VoiceApplications

DRAFT FOR INTERNAL USE ONLY

Video Player

Change player

Video ﬁle name

Playback position

Change screen ratio

More options

Volume

Pop up play

Rewind video or go toprevious video Scan forward or gotonext video

Pause/Play

Play and manage videos stored on your device.

To access video:

1. From a Home screen, tap

2. Scroll through the videos stored on your device. After a few seconds, each video thumbnail begins playing a preview of the clip.

3. Tap a video to view it.

Apps > Video.

Use Pop-Up Play

Multi task with Pop-Up Play — transform your video player into a pop-up window. The video will continue to play, and the pop-up window can be resized or moved anywhere on the screen.

1. From a Home screen, tap

2. Tap a video to view it.

3. Tap window.

•

to continue playing the video in a ﬂoating

Drag the window to any location on the screen.

Use two ﬁngers to pinch or spread to resize the ﬂoating window.

Apps > Video.

Video PlayerApplications

DRAFT FOR INTERNAL USE ONLY

WatchON

WatchON turns your tablet into a remote control. Not only can you control your TV, set-top box, DVR and other devices from your tablet, but it will recommend great shows and movies based on your preferences and past viewing behavior.

You can search, discover, explore, and access what’s on live TV, and on-demand movies and TV shows across multiple video-on-demand providers.

Note: Before initiating use, verify you have an active Internet connection available (either mobile network or Wi-Fi connection).

Conﬁgure Your Device as a Remote

1. From the WatchON tool bar, tap Remote Control.

2. Tap Setup at the prompt.

3. Follow the instructions to ﬁnd your TV or other devices and conﬁgure your phone to control their operation.

Set Up WatchON

1. From a Home screen, tap Apps > WatchON.

2. Tap Set up WatchON.

3. Follow the prompts to conﬁgure WatchON

options, such as ZIP code, TV service provider, channel list setup, and so on.

Note: Tap WatchON.

More > Help to learn more about

WatchONApplications

DRAFT FOR INTERNAL USE ONLY

Settings

Conﬁgure your device’s connections and settings, add accounts, and customize the home screen, apps, and

Some options use an ON/OFF button to turn

•

the option on ( ) or oﬀ ( ).

For some options, you must tap a ﬁeld,

•

such as Email address, to display and set options.

features.

Some options are enabled or disabled by

•

tapping a check box. When enabled, a check mark displays. Tap the check mark to remove it and disable the option.

DRAFT FOR INTERNAL USE ONLY

How to Use Settings

Accessing Settings

► From a Home screen, tap Apps >

Settings.

– or –

From a Home screen, drag down from the Status bar to display the Notiﬁcation panel, and then tap

Settings.

Search for Settings

If you are not sure exactly where to ﬁnd a certain setting, you can use the Setting search feature.

1. From a Home screen, tap Settings.

2. Tap

Search.

Enter a word or words in the Search box. As

you type, settings that match will appear on the screen.

Tap an entry to go to that setting.

Apps >

Changing the Quick Settings

You can change the Quick settings list to include your most frequently used settings.

1. From a Home screen, tap Settings.

2. Tap

3. Tap Done to save your new Quick settings menu.

Menu > Edit quick settings.

Select additional settings to appear in your

Quicksettings menu. Settings that are already in the Quick settings menu are checked.

Uncheck a highlighted item to remove it.

Apps >

Change How Settings Are Listed

Settings can be listed in grid view (default), a list view, or a tab view.

1. From a Home screen, tap Settings.

2. Tap

Menu > View by.

Apps >

Customize the Quick Settings Menu

Quick settings are the settings that you are most likely to frequently use. When you ﬁrst access the Settings menu, the Quick settings are set to a default list of settings.

3. Select a new view.

How to Use SettingsSetting s

DRAFT FOR INTERNAL USE ONLY

Wi-Fi and Wi-Fi Direct

Wi-Fi is a term used for certain types of Wireless Local Area Networks (WLAN). Wi-Fi communication requires access to a Wireless Access Point (WAP) .

Wi-Fi Direct creates a direct connection between two or more devices using Wi-Fi.

Turn Wi-Fi On or Oﬀ

Turning Wi-Fi on makes your device able to discover and connect to compatible in-range WAPs.

1. From a Home screen, tap Settings.

2. Tap Wi-Fi, and then tap ON/OFF to turn Wi-Fi on

or oﬀ.

Apps >

Scan and Connect to a Wi-Fi Network

1. From a Home screen, tap Apps > Settings.

4. Tap the network you want to connect to.

When you select an open network, you are

automatically connected to the network. Otherwise, enter a password to connect.

To manually scan for networks, tap Menu >

Scan.

Manually Connect to a Wi-FiNetwork

1. From a Home screen, tap Apps > Settings.

2. Tap Wi-Fi, and then tap ON/OFF to turn Wi-Fi on.

3. Tap Add Wi-Fi network.

4. Enter information about the Wi-Fi network:

Tap Network SSID to enter the name of the

Wi-Fi network.

Tap the Security ﬁeld and select a security

option and enter your password.

Tap Show advanced options, if you need to

add advanced options such as Proxy settings, IPsettings, or Key management.

5. Tap Connect to store the new information and

connect to your target WAP.

2. Tap Wi-Fi, and then tap ON/OFF to turn Wi-Fi on.

3. When Wi-Fi is ﬁrst turned on, your device will automatically scan for available networks and display them.

Wi-Fi and Wi-Fi DirectSettings

DRAFT FOR INTERNAL USE ONLY

Wi-Fi Status Indicators

These Status bar icons show your current Wi-Fi connection status:

Displays when Wi-Fi is connected, active,

and communicating with a Wireless Access Point (WAP).

An Wi-Fi access point is available, but you

are not connected to it. It may also display if there is a communication issue with the target Wireless Access Point (WAP).

Wi-Fi Settings

The Wi-Fi settings menu allows you to set up many of your device’s advanced Wi-Fi services.

1. From a Home screen, tap

Settings.

2. Tap Wi-Fi, and then tap ON/OFF to turn Wi-Fi on.

Apps >

IP address: View your device’s IP address (not

conﬁgurable).

WPS push button: Set up a connection to a

WPS (Wi-Fi Protected Setup) router or other equipment.

WPS PIN entry: View the PIN used by your

device to set up a PIN-secured connection to a Wi-Fi router or other equipment (not conﬁgurable).

Help: Learn about setting up and using Wi-Fi

networks, and other settings.

Wi-Fi Direct

Wi-Fi Direct allows direct device-to-device connections via Wi-Fi, without having to connect to a Wi-Fi network.

1. From a Home screen, tap Settings.

Apps >

3. Tap

Menu for options:

Advanced:

Network notiﬁcation: Receive a notiﬁcation

when new Wireless Access Points (WAPs) are available.

Passpoint: Connect to passpoint-enabled Wi-

Fi Access Points automatically.

Sort by: Sort Wi-Fi networks by Alphabet or

Signal strength.

Keep Wi-Fi on during sleep: Specify when to

disconnect from Wi-Fi.

Always allow scanning: Allow Google location

service and other apps to scan for networks, even when Wi-Fi is turned oﬀ.

Install certiﬁcates: Install authentication

certiﬁcates.

MAC address: View your device’s MAC

address, which is required when connecting to some secured networks (not conﬁgurable).

2. Tap Wi-Fi, and then tap ON/OFF to turn Wi-Fi on.

Wi-Fi must be on to conﬁgure settings.

3. Tap

4. After scanning for devices, select a device,

Menu > Wi-Fi Direct. Your device automatically scans for nearby Wi-Fi Direct devices, or you can tap Scan to start scanning.

and then follow the prompts to complete the connection.

Tap Menu > Multi connect to scan for

devices that support multi connect. Select the devices and follow the prompts to establish the connections.

To rename your device (as seen by other

devices), tap Menu > Rename device.

Wi-Fi Direct Status Indicator

Displays when connected to another device

using Wi-Fi Direct.

Wi-Fi and Wi-Fi DirectSettings

DRAFT FOR INTERNAL USE ONLY

Bluetooth

Bluetooth is a short-range communications technology that allows you to connect wirelessly to a number of Bluetooth devices, such as headsets and hands-free car Bluetooth systems, and Bluetooth-enabled computers, printers, and wireless devices.

Note: The Bluetooth communication range is approximately 30 feet.

Turn Bluetooth On and Oﬀ

1. From a Home screen, tap Apps > Settings.

2. Tap Bluetooth, and then tap ON/OFF to turn

Bluetooth on or oﬀ.

Making Your Device Visible to Other BluetoothDevices

When you make your device visible, other Bluetooth can ﬁnd it in a scan and initiate pairing. You can choose the length of time your device remains visible.

1. From a Home screen, tap Settings.

2. Tap Bluetooth, and then tap ON/OFF to turn

Bluetooth on.

3. Tap Bluetooth >

4. Select a time period for your device to remain

visible after you turn on visibility.

Menu > Visibility timeout.

Apps >

Scan for Bluetooth Devices

When you want to pair with another Bluetooth device, you can scan for nearby devices that are visible.

1. From a Home screen, tap Settings.

Apps >

Change Your Device’s Name

Change the name others will use when pairing with your device via Bluetooth.

1. From a Home screen, tap Settings.

2. Tap Bluetooth >

3. Tap Device name and edit your device name.

Menu > Rename device.

Apps >

2. Tap Bluetooth, and then tap ON/OFF to turn on Bluetooth.

3. When Bluetooth is ﬁrst turned on, it scans for nearby Bluetooth devices and displays them.

To manually perform a new scan, tap Scan.

BluetoothSettings

DRAFT FOR INTERNAL USE ONLY

Pair Bluetooth Devices

The Bluetooth pairing process allows you to establish trusted connections between your device and another Bluetooth device.

Delete a Paired Device (Unpairing)

When you unpair from a Bluetooth device, the two devices will no longer recognize each other. To connect again, you’d need to pair the devices.

Pairing between two Bluetooth devices is a onetime process. Once a pairing is created, the devices will continue to recognize their partnership and exchange information without having to re-enter a passcode again.

1. From a Home screen, tap Settings.

2. Tap Bluetooth, and then tap ON/OFF to turn on

Bluetooth.

3. Make sure that the target device is discoverable,

so that your device can ﬁnd it. Refer to the instructions that came with the device to ﬁnd out how to set it to discoverable mode.

4. Tap Scan. Your device will start to scan for

Bluetooth devices within range.

5. When you see the name of the target device

displayed in the Bluetooth devices section, tap the name. Your phone then automatically tries to pair with the target device. If automatic pairing fails, enter the passcode supplied with the target device.

Note: Due to diﬀerent speciﬁcations and features of other Bluetooth-compatible devices, display and operations may be diﬀerent, and functions such as transfer or exchange may not be possible with all Bluetooth compatible devices.

Apps >

1. Verify your Bluetooth is active.

2. From the Bluetooth settings page, tap to the previously paired device, and then tap Unpair to delete the paired device.

Review Files Received via Bluetooth

When you receive ﬁles from another device via Bluetooth, you can access them from Bluetooth settings.

1. From a Home screen, tap

Settings.

2. Tap Bluetooth >

Menu > Received ﬁles.

Apps >

Bluetooth Status Indicators

This Status bar icon show your current Bluetooth connection status:

Bluetooth is active.

Disconnect a Paired Device

Disconnecting a paired device breaks the connection between the device and your device, but retains the knowledge of the pairing. At a later point when you wish to reconnect the device, there is no need to setup the connection information again.

1. From a Home screen, tap Settings.

2. Tap Bluetooth, and then tap ON/OFF to turn on

Bluetooth.

3. Tap the previously paired device.

4. Tap OK to conﬁrm disconnection.

Apps >

BluetoothSettings

DRAFT FOR INTERNAL USE ONLY

Tethering and Wi-Fi Hotspot

Share your device’s Internet connection with a computer that connects to your device using a USB cable or via Bluetooth.

Use Portable Wi-Fi hotspot to share your device’s Internet connection with other devices using your device as a Portable Wi-Fi hotspot.

Connect Your Device to a Computer Using Tethering

1. From a Home screen, tap Apps > Settings

> Tethering and Wi-Fi hotspot.

2. Choose a tethering method:

Use Your Device as a PortableWi-Fi Hotspot

Note: You must have a tethering plan on your service account in order to use the Portable Wi-Fi hotspot.

Warning! Portable Wi-Fi hotspot consumes battery power and uses data service.

Turn Portable Wi-Fi Hotspot Onor Oﬀ

Activate your device’s Portable Wi-Fi hotspot application to allow other devices to use your device’s Internet connection.

1. From a Home screen, tap > Tethering and Wi-Fi hotspot.

2. Touch ON/OFF to turn Portable Wi-Fi hotspot on or oﬀ.

Warning! By default, your device’s Portable Wi-Fi hotspot has no security applied, and any device can connect. For more information, see

Conﬁgure Portable Wi-Fi Hotspot Settings.

Apps > Settings

USB tethering: Connect the computer to the

device using the USB cable, and then touch

USB tethering to turn tethering on.

Bluetooth tethering: Pair your device with the

computer using Bluetooth. Touch Bluetooth tethering to turn tethering on. For more information, see Bluetooth.

Connect a Device to YourMobileHotspot

Use the other device’s Wi-Fi control to connect to your device’s Portable Wi-Fi hotspot.

1. From a Home screen, tap > Tethering and Wi-Fi hotspot.

2. Touch ON/OFF to turn on Portable Wi-Fi hotspot.

3. Activate Wi-Fi on the target device.

4. Scan for Wi-Fi hotspots, and select the target device from the list.

5. On the target device, enter your device’s Portable Wi-Fi hotspot password. By default, the password is your device’s phone number.

Apps > Settings

Tethering and Wi-Fi HotspotSettings

DRAFT FOR INTERNAL USE ONLY

Allowed Device List

Conﬁgure Portable Wi-Fi Hotspot

Control whether devices connect to your Portable Wi-Fi hotspot with the Allowed device list. After you add devices to the list, they can scan for your device and connect using your device’s Portable Wi-Fi hotspot name and password.

Note: Using your device as a Portable Wi-Fi hotspot consumes battery power and uses data service. While Portable Wi-Fi hotspot is active, your device’s applications will use the Portable Wi-Fi hotspot data service. Roaming while using your device as a Portable Wi-Fi hotspot will incur extra datacharges.

1. From a Home screen, tap > Tethering and Wi-Fi hotspot.

2. Touch ON/OFF to turn on Portable Wi-Fi hotspot.

3. Tap Allowed devices, and then tap to enter the other device’s Device name and MACaddress.

4. Tap OK to add the device.

Apps > Settings

Add

Change the Portable HotSpot

Settings

Manage your Portable Wi-Fi hotspot security and connecting settings.

1. From a Home screen, tap > Tethering and Wi-Fi hotspot.

2. Tap

Menu for options:

Network SSID: View and change the name of

your Portable Wi-Fi hotspot.

Hide my device: Make your Portable Wi-Fi

hotspot invisible to other Wi-Fi devices during a scan. Other devices can still connect to your Portable Wi-Fi hotspot, but will have to set up the connection manually with your Network SSID and Password.

Security: Choose the security level for your

Portable Wi-Fi hotspot.

Password: If you choose a security level that

uses a password, enter the password. By default, the password is your device’s phone number.

Apps > Settings

Password

1. From a Home screen, tap Apps > Settings > Tethering and Wi-Fi hotspot.

2. Touch ON/OFF to turn on Portable Wi-Fi hotspot.

3. Tap the Security ﬁeld and select WPA2 PSK and enter a new password.

Turn Oﬀ Portable Wi-Fi Hotspot Automatically

Set your device to automatically turn oﬀ Portable Wi-Fi hotspot if there are no connected device.

1. From a Home screen, tap > Tethering and Wi-Fi hotspot.

2. Touch ON/OFF to turn on Portable Wi-Fi hotspot.

3. Tap

Menu and select an amount of time.

Apps > Settings

Show password: Display your password

instead of masking it.

Show advanced options: Access advanced

options, including Broadcast channel, and to specify the channel your device uses for Portable Wi-Fi hotspot.

Tethering and Wi-Fi HotspotSettings

DRAFT FOR INTERNAL USE ONLY

Airplane Mode

Airplane mode disconnects your device from all networks and turns oﬀ connectivity features, such as phone calls, Wi-Fi, and Bluetooth.

While in airplane mode, you can use other features, such as playing music, watching videos, and other online applications.

1. From a Home screen, tap Apps > Settings.

2. Tap Airplane mode, and then tap ON/OFF to

enable or disable the option.

Note: You can also control Airplane mode from the Device options menu. Press and hold the Power/Lock key, and then tap Airplane mode.

Airplane ModeSettings

DRAFT FOR INTERNAL USE ONLY

Data Usage

Monitor your mobile data usage.

Note: Your service provider may account for data usage diﬀerently.

1. From a Home screen, tap > Datausage for options:

Mobile data: Enable mobile data. You can also

control Mobile Data at the Notiﬁcation panel.

Set mobile data usage: Disable your mobile

data connection when the speciﬁed limit is reached. Drag the red limit line to set the data usage limit.

Data usage cycle: Tap the menu, and then

choose a time period for data usage. Data usage for the period displays on the graph, along with usage by application below.

Apps > Settings

2. Tap

Menu for options:

Data roaming: Enable data roaming on your

device.

Restrict background data: Restrict some

apps and services from working unless you are connected to a Wi-Fi network.

Auto sync data: Set your accounts to

automatically sync.

Show Wi-Fi usage: Display a Wi-Fi tab that

shows Wi-Fi usage.

Mobile hotspots: Select Wi-Fi networks that

are mobile hotspots. You can restrict apps from using these networks, and you can conﬁgure apps to warn you before using these networks for large downloads.

Data UsageSettings

DRAFT FOR INTERNAL USE ONLY

Location Services

Some apps, such as Google maps, may require one or more location services be turned on for full functionality.

Locating Method

1. From a Home screen, tap Apps > Settings > Location.

2. Tap ON/OFF to turn on Location services.

3. Tap Mode to select how your location is determined:

High accuracy: Use GPS, Wi-Fi, and mobile

networks.

Power saving: Use Wi-Fi and mobile networks

(no GPS) .

Location Reporting

Google uses Location Reporting to store and use your device’s most recent location data. Google apps, such as Google Maps, can use this data to improve your search results based on places that you have visited.

1. From a Home screen, tap > Location.

2. Tap ON/OFF to turn on Location services.

3. Tap Google Location Reporting for options:

Location Reporting: Allow Google apps to

use your device’s most recent location data.

Location History: Allow Google to store a

history of your location data. Tap DELETE LOCATION HISTORY to permanently delete your location history.

Apps > Settings

GPS only: Use GPS only.

Recent Location Requests

Apps that have requested your location are listed under Recent location requests.

1. From a Home screen, tap > Location.

2. Tap ON/OFF to turn on Location services.

3. Tap an entry to view the app’s settings.

Apps > Settings

My Places

You can save your favorite locations for use with services that require location information. This information can improve your search results and other location-related activities.

1. From a Home screen, tap > Location.

2. Tap ON/OFF to turn on Location services.

3. Tap My places.

4. Tap a category (Home, Oﬃce, or Car) to add a location:

Tap Add to add additional categories.

Tap Menu > Delete to delete a custom

category.

Home, Oﬃce, and Car cannot be deleted.

Apps > Settings

Location ServicesSettings

DRAFT FOR INTERNAL USE ONLY

Mobile Networks

Control your device’s access to networks and mobile data service.

1. From a Home screen, tap Apps > Settings.

2. Tap More networks > Mobile networks for

options:

Mobile data: Allow your device to connect to a

mobile data network.

Data Roaming Access: All your device to

connect to data services while roaming. Signiﬁcantly higher charges may result.

Network mode: Choose a preferred network

mode.

System select: Choose a CDMA roaming

mode.

Mobile NetworksSettings

DRAFT FOR INTERNAL USE ONLY

Default Messaging App

If you have multiple messaging apps installed, you can select which app should be your default messaging app.

1. From a Home screen, tap Apps > Settings.

2. Tap More settings > Default Messaging App to

select a default.

Default Messaging AppSettings

DRAFT FOR INTERNAL USE ONLY

Virtual Private Networks (VPN)

Set up and manage your VirtualPrivate Networks (VPNs).

Note: You must set a screen lock PIN or password before setting up a VPN. For more information, see

Lock Screen.

Adding a VPN

1. From a Home screen, tap Apps > Settings

> Moresettings > VPN.

2. Tap Basic VPN or Advanced IPSec and follow

the prompts to set up yourVPN.

Connect to a VPN

1. From a Home screen, tap Apps > Settings > VPN.

2. Tap the VPN, enter your log in information, and tap Connect.

Edit or Delete a VPN

1. From a Home screen, tap Apps > Settings > VPN.

2. Touch and hold the VPN that you want to edit or delete.

Virtual Private Networks (VPN)Settings

DRAFT FOR INTERNAL USE ONLY

Sharing Files with NFC

NFC (Near Field Communication) allows data exchange when you touch your device with another compatible device. This is used for applications such as Android Beam and S Beam.

To activate NFC:

1. From a Home screen, tap > NFC.

2. Tap ON/OFF to turn NFC on.

Apps > Settings

Android Beam

When Android Beam is activated, you can beam app content to another NFC-capable device by holding the devices close together. You can beam browser pages, YouTube videos, contacts, and more.

1. From a Home screen, tap > NFC.

2. Tap ON/OFF to turn NFC on.

3. Tap ON/OFF to turn Android Beam on.

4. Touch the back of your device with another NFCcapable device and the content is transferred.

Apps > Settings

S Beam

When S Beam is activated, you can beam ﬁles to another NFC-capable device by holding the devices close together.

You can beam images and videos from your Gallery, music ﬁles from your Music app, and more.

1. From a Home screen, tap > NFC.

2. Tap ON/OFF to turn NFC on.

3. Tap ON/OFF to turn S Beam on.

4. Touch the back of your device with another NFC-capable device and the content is transferred.

Apps > Settings

Tap and Pay

Tap and pay allows you to select the default payment application you want to use for making onphone purchases.

1. From a Home screen, tap > NFC.

2. Tap ON/OFF to turn NFC on.

3. Tap Tap and pay.

4. Select the app that you want as your default.

Apps > Settings

Sharing Files with NFCSettings

DRAFT FOR INTERNAL USE ONLY

Nearby Devices

Share your media ﬁles with nearby devices via Wi-Fi, Wi-Fi Direct, or Mobile Hotspot.

Warning! If ﬁle sharing is enabled, other devices can access your data. Use this option with care.

1. From a Home screen, tap > Nearby devices.

2. Tap ON/OFF to enable Nearby devices.

3. Set the following options:

Content to share: Select the content to share.

Choices are: Videos, Photos, and Music.

Allowed devices: Indicate the devices

accessible to your device.

Denied devices: Indicate devices not allowed

access to your device.

Download to: Allow downloading of data to

your device or optional memory card (not included).

Receive ﬁles from other phones: Warn if a

device attempts to upload data to your device.

Apps > Settings

Nearby DevicesSettings

DRAFT FOR INTERNAL USE ONLY

Printing

Print images and documents to Samsung printers and other compatible printers (notincluded).

1. From a Home screen, tap Apps > Settings > Printing.

2. Tap a print service and follow the prompts.

Note: Tap print service drivers.

Download plug-in to install additional

PrintingSettings

DRAFT FOR INTERNAL USE ONLY

Screen Mirroring

Share Your Device’s Screen with Another Device.

1. From a Home screen, tap Apps> Settings > ScreenMirroring.

2. Tap ON/OFF to enable Screen Mirroring. Available devices are listed.

Tap Scan to ﬁnd more devices.

3. Tap a device and follow the prompts to connect.

Screen MirroringSettings

DRAFT FOR INTERNAL USE ONLY

Sound

Conﬁgure the sounds and vibrations used to indicate notiﬁcations, screen touches, and other activities.

Change the Sound Mode

You can switch between sound modes, while preserving the individual sound settings you’ve made.

Tip: Sound modes are also available from the Device options menu. Press and hold the Power/Lock key, and then choose Mute, Vibrate, or Sound from the Device options.

1. From a Home screen, tap

Settings.

2. Tap Sound > Sound mode, and then choose a mode:

Sound: Your device uses the sounds,

vibrations, and volume levels you’ve chosen in Sound settings for notiﬁcations and alerts.

Apps >

Adjust the Volume

Set the system volume level, and set default volume for call ringtones, notiﬁcations, and other media.

Tip: You can also set System volume from the home screen by pressing the Volume key.

1. From a Home screen, tap Settings.

2. Tap Sound > Volume, and then drag the sliders

to set the default volume for:

Ringtone

Music, video, games, and other media

Notiﬁcations

System

Apps >

Select a Default Ringtone

Choose from preset ringtones or add your own.

1. From a Home screen, tap Settings.

Apps >

Vibrate: Your device vibrates for notiﬁcations

and alerts. This uses the Vibration intensity you choose in Sound settings.

Mute: Your device plays no sounds or

vibrations. On-screen reminders will still occur.

2. Tap Sound > Ringtones.

3. Tap a ringtone hear a preview, and then tap OK

to set it as your default ringtone.

– or –

Tap Add to use a use an audio ﬁle as a ringtone.

SoundSettings

DRAFT FOR INTERNAL USE ONLY

Select a Default Vibration Pattern

Play Tones When Touching or

Choose from preset vibration patterns or create your own pattern.

1. From a Home screen, tap Settings.

2. Tap Sound > Ringtones.

3. Tap a pattern to preview it, and then tap OK to

set it as your default vibration pattern.

– or –

Tap Create and follow the prompts instructions to create a new vibration pattern.

Apps >

Change the Notiﬁcation Sound

Choose a sound for notiﬁcations, such as for new messages and event reminders.

1. From a Home screen, tap Settings.

2. Tap Sound > Notiﬁcations.

3. Tap a sound to preview it, and then tap OK to set

it as your default notiﬁcation sound.

Apps >

Tapping theScreen

Play tones when you touch or tap the screen to make selections.

1. From a Home screen, tap Settings.

2. Tap Sound > Touch sounds to turn the

feature on.

Apps >

Set the Screen Lock Sound

Play a sound when you unlock the screen.

1. From a Home screen, tap Settings.

2. Tap Sound > Screen lock sound to turn the

feature on.

Apps >

Select an Emergency Tone

Set an alert tone or vibration when receiving an emergency message.

1. From a Home screen, tap Settings.

Apps >

Vibrate When Ringing

Your device can vibrate in addition to ringing when you receive a call.

1. From a Home screen, tap Settings.

2. Tap Sound > Vibrate when ringing to turn the

feature on.

Apps >

Play Tones When Entering a Phone Number

Play tone when the dialing keypad is tapped.

1. From a Home screen, tap Settings.

2. Tap Sound > Dialing keypad tone to turn the

feature on.

Apps >

2. Tap Sound > Emergency tone and select Oﬀ, Alert, or Vibrate.

Use Haptic Feedback

Set the device to vibrate when you tap the Menu and Recent apps keys, and for certain screen interactions.

1. From a Home screen, tap

Settings.

2. Tap Sound > Haptic feedback to turn the feature on.

Apps >

SoundSettings

DRAFT FOR INTERNAL USE ONLY

Play a Sound When Using the

Music Eﬀects

Samsung Keyboard

Play a sound when typing on the SamsungKeyboard.

1. From a Home screen, tap Settings.

2. Tap Sound > Sound when tapped to turn the

feature on.

Apps >

Set Notiﬁcation Sounds for Samsung Applications

Choose notiﬁcation alerts for new messages, email, and calendar events..

1. From a Home screen, tap Settings.

2. Tap Sounds for options:

Messaging: Customize messaging

notiﬁcations and alerts.

Apps >

Select a default music eﬀects control panel to use when playing music on your device.

1. From a Home screen, tap Settings.

2. Tap Sounds > Music eﬀects and select a music

eﬀects control panel.

Apps >

Email: Conﬁgure your email account

notiﬁcations.

Calendar: Conﬁgure your event notiﬁcations.

SoundSettings

DRAFT FOR INTERNAL USE ONLY

Display

Adjust the Screen Brightness

Adjust the screen brightness to suit your surroundings or personal preference. You may also want to adjust screen brightness to conserve battery power.

1. From a Home screen, tap Settings.

2. Tap Display > Brightness for options:

Tap Automatic brightness to allow the device

to adjust brightness automatically.

To set a custom brightness level, clear the

Automatic brightness check mark and then tap and drag the Brightness level.

Note: You can also control Brightness from the Notiﬁcation panel. Drag down the Status bar at the top of the screen to ﬁnd the Brightness options.

Apps >

Automatically Rotate the Screen

Use the front camera to rotate the screen based on the orientation of your face.

1. From a Home screen, tap Settings.

2. Tap Display > Screen rotation

3. Ta p ON/OFF, and then tap Smart rotation to

turn the feature on.

Apps >

Smart Stay

Using the front camera to detect your face, the screen will not time out as long as you are facing the screen.

1. From a Home screen, tap Settings.

2. Tap Display > Smart stay to turn the feature on.

Apps >

Change the Font Style and Size

You can set the font style and size for all text that displays on the screen.

1. From a Home screen, tap Settings.

2. Tap Display > Font to choose a Font style and

Font size.

Tap Download to ﬁnd new fonts from the

Google Play Store.

Apps >

Set the Screen Timeout Delay

Choose how long the display screen remains lit after you tap the screen or press any key.

1. From a Home screen, tap Settings.

2. Tap Display > Screen timeout, and then choose

a time period.

Apps >

DisplaySettings

DRAFT FOR INTERNAL USE ONLY

Select a Screen Mode

Auto Adjust the Screen Tone

Choose a screen mode to match your type of viewing. You can choose to have the device automatically adapt the display depending on the type of image being displayed, and other criteria such as battery level.

1. From a Home screen, tap Settings.

2. Tap Display > Screen mode, and then choose a

screen mode.

To have your device automatically optimize

the display to match the type of image being displayed and other criteria, such as battery level, tap Adaptive display.

– or –

Choose a specify type of screen mode based on what your are viewing.

Apps >

Auto Adjust the Screen Tone

Your device will analyze the images displayed on the screen and automatically adjusts the brightness to conserve battery power.

1. From a Home screen, tap Settings.

2. Tap Display > Auto adjust screen tone to turn

the feature on.

Apps >

Daydream (Screen Saver)

The Daydream setting controls what the screen displays when the device is docked (dock not included), or while charging. You can choose to display colors, or display photos stored on your device.

1. From a Home screen, tap Settings.

2. Tap Display > Daydream. Tap ON/OFF to turn

Daydream on. Conﬁgure options:

Apps >

Adjust the screen brightness to suit your surroundings, or to your personal preference. You may also want to adjust screen brightness to conserve battery power.

1. From a Home screen, tap Settings.

2. Tap Display > Brightness for options:

Tap Automatic brightness to allow the device

to adjust brightness automatically.

To set a custom brightness level, clear the

Automatic brightness check mark and then tap and drag the Brightness level.

Note: You can also control Brightness from the Notiﬁcation panel. Drag down the Status bar at the top of the screen to ﬁnd the Brightness options.

Apps >

Colors: Tap the selector to display a changing

screen of colors.

Desk home screen: Select items to display

while the device is docked.

Flipboard: Display pictures from Flipboard.

Tap

Google Photos: Display pictures from your

Google Photos account. Tap Settings for options.

Photo frame: Display pictures in a photo

frame. Tap

Photo table: Display pictures in a photo table.

Tap Settings for options.

3. Tap Preview to see a demonstration of Daydream.

Settings for options.

DisplaySettings

DRAFT FOR INTERNAL USE ONLY

Conﬁgure the LED Indicator

Increase the Touch Sensitivity of

Select which functions (such as charging or low battery) the LED indicator on the front of the device will display.

1. From a Home screen, tap Settings.

2. Tap Display > LED indicator for options.

Apps >

Set the Touch Key Light Duration

Set the length of time the Recent apps key and

Back key remain lit after you touch them.

1. From a Home screen, tap Settings.

2. Tap Display > Touch key light duration to

choose a timeout period.

Apps >

the Screen

Increase the sensitivity of the touch screen to improve results when wearing gloves.

1. From a Home screen, tap Settings.

2. Tap Display > Increase tap sensitivity to turn

the feature on.

Apps >

DisplaySettings

DRAFT FOR INTERNAL USE ONLY

Wallpaper

Change the look of the home and lock screens with wallpaper.

You can display a favorite picture, or choose from preloaded wallpapers.

1. From a Home screen, pinch the screen.

– or –

Touch and hold an empty space on the screen.

2. Tap Wallpapers, and then choose Home screen, Lock screen, or Home and lock screens.

3. Tap a wallpaper to see a sample, and then tap Set wallpaper.

Tap More images to select an image from the

Gallery, Google Photos, or other location (if available).

Tap Bubbles or Phase beam for animated

wallpaper. (Animated wallpaper consumes additional battery power).

Tap Travel wallpaper to see recommended

travel destinations (Lock screen only).

WallpaperSettings

DRAFT FOR INTERNAL USE ONLY

Lock Screen

Choose a method for unlocking your screen. Diﬀerent Screen Locks have diﬀerent levels of security and options.

Set a Screen Lock

1. From a Home screen, tap Apps >

Settings.

2. Tap Lock Screen

3. Tap Screen lock to select a screen lock and level of security:

Swipe: Swipe the screen to unlock it. This

option provides no security.

Pattern: A screen unlock pattern is a tap

gesture you create and use to unlock your device. This option provides medium security.

Screen Lock Options

Swipe Only

Unlock eﬀect: Set the visual eﬀect used when

unlocking the screen.

Pattern Only

Pattern type: Select a pattern type.

Make pattern visible: Display the pattern as

your draw it.

All Screen Locks

Dual clock: Display a dual clock on your

Lock screen when roaming.

Clock size: Select the size of the clock that

will appear on your Lock screen.

Show date: Display the date on the

Lockscreen.

Camera shortcut: Display a camera shortcut

on your Lock screen.

PIN: Select a PIN to use for unlocking the

screen. This option provides medium to high security.

Password: Create a password for unlocking

the screen. This option provides high security.

Fingerprint: Use ﬁngerprint recognition

to unlock the screen. This option provides medium to high security.

None: Never use a Lock screen.

Owner Information: Show owner information

on the Lock screen.

Additional information: Display Weather

information or the step count when Pedometer in SHealth is turned on.

Help text: Show help information on unlocking

the screen on the Lock screen.

Lock ScreenSettings

DRAFT FOR INTERNAL USE ONLY

Notiﬁcation Panel

Customize which Quicksetting buttons appear on the Notiﬁcation Panel.

You can also customize which apps appear on the Recommended applications menu on the Notiﬁcation pane when you perform certain actions, such as plugging in earphones.

1. From a Home screen, tap Apps >

Settings>Notiﬁcation panel.

– or –

From the Notiﬁcation panel, tap

Edit.

View all >

Recommended Applications

When you perform certain actions, such as plugging in earphones, the Notiﬁcation panel can display shortcut to your favorite related apps, such as Music Player or Google Play Music.

1. From a Home screen, tap Settings>Notiﬁcation panel.

2. Tap Recommended applications.

3. Tap ON/OFF to turn the feature on.

To customize which shortcuts appear on the

Recommended apps menu, tap

Apps >

Edit.

2. Tap Notiﬁcation panel for options:

Tap Brightness adjustment to be able

to adjust the screen brightness from the Notiﬁcation Panel.

Tap Recommended applications to show

selected apps on the Notiﬁcation Panel after certain actions, such as connecting earphones. Tap ON/OFF to turn the feature on.

To customize which quick setting buttons

appear at the top of the Notiﬁcation Panel, tap and drag buttons to reorder them. Tap Reset to use the default layout.

Notiﬁcation PanelSettings

DRAFT FOR INTERNAL USE ONLY

Toolbox

The Toolbox is a ﬂoating shortcut menu that displays on every screen, giving you quick access to your favorite apps.

1. From the Home screen, tap Apps > Settings > Devicetab.

2. Tap Toolbox. Tap

3. Tap

Toolbox.

to choose up to ﬁve apps to display in

to enable.

ToolboxSettings

DRAFT FOR INTERNAL USE ONLY

Easy Mode

View your Home screen using the default layout or provide an easier user experience for the ﬁrst-time smartphone users using Easy mode.

1. From the Home screen, tap Apps > Settings > Devicetab.

2. Tap Easy mode.

Tap the Easy mode radio button to activate it.

Tap any application to uncheck if you want the

standard display for that application.

Easy ModeSettings

DRAFT FOR INTERNAL USE ONLY

Accessibility

Accessibility services are special features to make using the device easier for those with

Negative colors: Reverse the display

of onscreen colors from White text on a Black background to Black text on a White background.

certain physical disabilities.

Note: You can download additional accessibility applications from the Google Play Store.

1. From a Home screen, tap Settings.

2. Tap Accessibility for options:

Vision

TalkBack: Speak feedback aloud to help blind

and low-vision users.

TalkBack can collect all of the text you

enter, except passwords, including personal data and credit card numbers. It may also log your user interface interactions with the device.

Dark screen: Keep the screen turned oﬀ at all

times for privacy.

Rapid key input: Release your ﬁnger to enter

selection instead of double tapping.

Speak passwords: Read the characters aloud

as you enter your passwords.

Font size: Set the font size.

Apps >

Color adjustment: Adjust the color of the

screen if you are color blind or have diﬃculty reading the display because of the screen color. Tap Color adjustment for options.

Accessibility shortcut: Quickly enable

accessibility features in two quick steps. Tap to turn the feature on.

Text-to-speech options: Set your preferred

TTS engine and options. For more information, see Text-To-Speech Options.

Hearing

Flash notiﬁcation: Set your camera light to

blink whenever you receive a notiﬁcation.

Turn oﬀ all sounds: Turn oﬀ all sounds

including receiver voice.

Samsung subtitles (CC): Use Samsung

subtitles with multimedia ﬁles when available Tap Samsung subtitles (CC) for options.

Google subtitles (CC): Use Google subtitles

with multimedia ﬁles when available. Tap Google subtitles (CC) for options.

Sound balance: Use the slider to set the Left

and Right balance when using a stereo device.

Magniﬁcation gestures: Use exaggerated

gestures such as triple-tapping, double pinching, and dragging two ﬁngers across the screen.

Notiﬁcation reminder: Play a beep when a

notiﬁcation for a call, message, and so on, has been missed.

Mono audio: Switch audio from stereo to

mono for use with one earphone.

AccessibilitySettings

DRAFT FOR INTERNAL USE ONLY

Dexterity and Interaction

Assistant menu: Improve the device

accessibility for users with reduced dexterity.

Press and hold delay: Select a time interval

for this tap gesture.

Interaction control: Enable motions and

screen timeout. You can also block areas of the screen from tap interaction.

More Settings

Direct Access: Open your accessibility

settings by pressing the Home Key three times in quick succession.

Single tap mode: Tap to stop/snooze alarms

and calendar events.

Manage accessibility: Export your

accessibility settings and share them with another device.

Services

Additional accessibility apps may be downloaded from the Google Play Store. Certain accessibility services you install may be conﬁgured here.

AccessibilitySettings

DRAFT FOR INTERNAL USE ONLY

Blocking Mode

Turn oﬀ notiﬁcations for selectedfeatures.

1. From a Home screen, tap Apps > Settings.

2. Tap Blocking mode. Tap ON/OFF to turn the

feature on.

3. Conﬁgure options:

Tap Turn oﬀ notiﬁcations to block all

notiﬁcations.

Tap Turn oﬀ alarm to block all alarms.

The Set time option allows you to set Blocking

mode for a speciﬁc time range or always.

Tap the Always ﬁeld to disable it and

conﬁgure the From and To time ﬁelds.

Note: When Blocking Mode is enabled, the Status Bar.

displays in

Blocking ModeSettings

DRAFT FOR INTERNAL USE ONLY

Private Mode

Hide personal content from being accessed by anyone else using your device.

Private mode is only available for certain applications.

Note: A secure screen lock (Pattern, PIN, Fingerprint, or Password) is required to use Private Mode.

Set Up Private Mode

1. From a Home screen, tap Apps > Settings.

2. Tap Private mode.

3. Follow the prompts to learn about and set up

Private mode.

Private ModeSettings

DRAFT FOR INTERNAL USE ONLY

Fingerprint Scanner

Use ﬁngerprint recognition as an alternative to entering passwords in certain apps.

You can also use your ﬁngerprint to verify your identity when logging in to your Samsung account.

You can register up to 3 ﬁngerprints. A password will also set up as an alternative to your ﬁngerprint.

1. From a Home screen, tap Settings.

2. Tap Fingerprint > Fingerprint manager.

To add a ﬁngerprint, tap and follow the

instructions to register a ﬁngerprint and password.

Apps >

Change Your Alternative Password

1. From a Home screen, tap Apps > Settings.

2. Tap Fingerprint > Change alternative

password.

3. Enter your ﬁngerprint or password.

Additional Settings

1. From a Home screen, tap Apps > Settings.

2. Tap Fingerprint for options.

Screen lock: Change your Screen lock

and access Screen lock settings. For more information, see Lock Screen.

Verify Samsung account: Verify your identity

using your ﬁngerprint when logging in to your Samsung account.

To rename a ﬁngerprint, touch and hold the

ﬁngerprint, and then touch .

To delete a ﬁngerprint, touch and hold the

ﬁngerprint, and then touch

Fingerprint ScannerSettings

DRAFT FOR INTERNAL USE ONLY

Motions and Gestures

Control certain device actions by touching the screen with the palm of your hand.

1. From a Home screen, tap Apps > Settings.

2. Tap Motions and gestures.

3. Tap ON/OFF to enable each of the following:

Direct call: Call the contact whose call log,

message, or contact details are currently on the screen by bringing the device close to yourear.

Smart alert: Set the device to vibrate when

you pick it up to notify you about missed calls and messages.

Mute/pause: Mute or pause sounds and video

by covering the screen or turning over the device.

Palm swipe to capture: Capture an image of

the screen when you sweep your hand left or right across the screen.

Motions and GesturesSettings

DRAFT FOR INTERNAL USE ONLY

Air View

Preview information, extend text, or enlarge pictures by hovering your ﬁnger over the screen.

1. From a Home screen, tap Apps > Settings.

2. Tap Air view.

3. Tap ON/OFF to turn the feature on.

Air ViewSettings

DRAFT FOR INTERNAL USE ONLY

Accounts

Set up and manage accounts, including your Google Account, Samsung account, email, and social networking accounts.

Depending on the account, you can choose to synchronize your calendar, contacts, and other types of content.

Add an Account

1. From a Home screen, tap Apps > Settings.

ap Accounts > Add account.

3. Tap one of the account types.

4. Follow the prompts to enter your credentials and

set up the account.

Account Settings

Each account has its own set of settings. In addition, you can conﬁgure common settings for all accounts of the same type.

Note: Account settings and available features vary between account types and service providers. Contact your service provider for more information on your account’s settings.

1. From a Home screen, tap Apps > Settings.

ap Accounts > (

Tap an account to conﬁgure that account’s

settings.

Tap Settings or other available options to

conﬁgure common settings for all accounts of this type.

account type) .

Delete an Account

1. From a Home screen, tap Apps > Settings.

Synchronize Accounts

1. From a Home screen, tap Apps > Settings.

2. Tap Accounts > (account type).

3. Tap an account to view the sync settings for that

account.

Check individual data items to sync.

Tap Sync to synchronize the account.

ap Accounts > (

3. Tap the account, and then tap Menu > Removeaccount.

account type) .

AccountsSettings

DRAFT FOR INTERNAL USE ONLY

Cloud

Back up your personal data using your Samsung Account or Dropbox.

Using Your Samsung Account

1. From a Home screen, tap Apps > Settings.

2. Tap Cloud.

3. Tap your Samsung account to manage your sync

settings and backup options.

If you have not signed in to your Samsung

•

Account, tap Add Samsung account.

Tap Storage usage to show the storage used

•

and remaining storage available.

Tap Sync settings to select which data to

•

sync.

Using Your Dropbox Account

For more information about Dropbox, visitdropbox.com.

1. From a Home screen, tap Settings.

2. Tap Cloud.

3. Tap your Dropbox account to manage your sync

settings and backup options.

If you have not signed in to your Dropbox

•

account, tap Link Dropbox account.

Follow the prompts to set up and use Dropbox.

•

Apps >

Tap Backup to manage your back up and

•

restore options.

Tap Restore to retrieve data from your

•

Samsung account.

CloudSettings

DRAFT FOR INTERNAL USE ONLY

Backup and Reset

Back up your data to Google servers. You can also reset your device to its factory defaults.

Backup and Restore

Enable backup of your information to Google servers.

1. From a Home screen, tap Settings.

2. Tap Backup and reset for options:

Back up my data: Enable back up of

application data, Wi-Fi passwords, and other settings to Google servers.

Backup account: Select a Google account to

be used as your backup account.

Apps >

Factory Data Reset

Return your device to its factory defaults.

Warning! This action permanently erases ALL data from the device, including Google or other account settings, system and application data and settings, downloaded applications, as well as your music, photos, videos, and other ﬁles.

1. From a Home screen, tap Settings.

2. Tap Backup and reset > Factory data reset.

3. Tap Reset device and follow the prompts to

perform the reset.

Apps >

Automatic restore: Enable automatic

restoration of settings from Google servers. When enabled, backed-up settings are restored when you reinstall an application.

Backup and ResetSettings

DRAFT FOR INTERNAL USE ONLY

Language and Input Settings

Conﬁgure your device’s language and input settings.

Set Your Default Language

1. From a Home screen, tap Apps > Settings.

2. Tap Language and input > Language.

3. Select a language from the list.

Select Your Default Keyboard orInput Method

1. From a Home screen, tap Apps > Settings.

2. Tap Language and input > Default.

3. Select a keyboard.

Note: Additional keyboards can be downloaded from the Google Play Store.

3. Tap options:

Settings next to Samsung keyboard for

Select input languages: Choose which

languages are available on the keyboard. To switch between languages, slide the space bar sideways.

Predictive text: Allow Predictive text to

suggest words matching your text entries, and, optionally, complete common words automatically. Predictive text can learn your personal writing style from your Contacts, Messages, Gmail, and social networking sites — improving its accuracy of predicting your text entries.

Additional keyboard settings provide

assistance with capitalization, punctuation, and much more.

Swype Keyboard Settings

Conﬁgure options for using the Swype keyboard.

1. From a Home screen, tap

Settings.

Apps >

Samsung Keyboard Settings

Conﬁgure options for using the Samsung keyboard.

1. From a Home screen, tap Settings.

2. Tap Language and input.

Apps >

2. Tap Language and input.

3. Tap

Settings next to Swype for options:

Settings: Conﬁgure basic options.

Themes: Change the keyboard layout.

My Words: Manage your personal dictionary,

new word updates, as well as how Swype can learn from your writing style in various apps.

Languages: Set the current language.

Additional languages can be downloaded.

Gestures: Learn about using Swype gestures.

Help: View information on using Swype.

Language and Input SettingsSettings

DRAFT FOR INTERNAL USE ONLY

Google Voice Typing Settings

Text-To-Speech Options

Speak rather than type your text entries using Google Voice Typing.

1. From a Home screen, tap Settings.

2. Tap Language and input.

3. Tap

options:

Settings next to Google voice typing for

Choose input languages: Select languages

for Google voice typing.

Block oﬀensive words: Hide words many

people ﬁnd oﬀensive are in results of Google voice searches. Oﬀensive words are replaced in results with a placeholder (####).

Oﬄine speech recognition: Download and

install speech recognition engines, allowing you to use voice input while not connected to the network.

Apps >

Conﬁgure your Text-To-Speech (TTS) options. TTS is used for various accessibility features, such as TalkBack. For more information, see Accessibility.

1. From a Home screen, tap Settings.

2. Tap Language and input > Text-to-speech for

options:

Choose either the Samsung or Goggle text-to-

speech engine. Tap Settings next to each TTS engine for options.

Speech rate: Set the speed at which the text

is spoken.

Listen to an example: Play a sample of

speech synthesis (available if voice data is installed).

Default language status: Display the default

language in use.

Apps >

Voice Search

Use Google voice recognition to perform Google searches using spoken commands.

To perform a voice search, tap search bar or widget. Or say “Ok Google” to launch a Google search (if the hotword detection option is enabled).

1. From a Home screen, tap Settings.

2. Tap Language and input > Voice search for

options.

Tap “Ok Google” hotword detection to

launch a Google search whenever you say “OkGoogle.”

Additional options include selecting a default

language, blocking oﬀensive words, and more.

in the Google

Apps >

Read New Notiﬁcations Aloud

Set the device to read new notiﬁcations aloud for incoming calls, messages, and emails, as well as caller or sender information.

1. From a Home screen, tap Settings.

2. Tap Language and input > Read notiﬁcations

aloud.

3. Touch ON/OFF to enable each option.

Apps >

Language and Input SettingsSettings

DRAFT FOR INTERNAL USE ONLY

Mouse/Trackpad Settings

Conﬁgure settings for using an optional mouse or trackpad (not included) .

1. From a Home screen, tap Settings.

2. Tap Language and input for options:

Mouseover: Show more information when you

move the pointer over items on the screen.

Preview and icons labels: Show previews,

progress information, speed dial information and icon labels.

List scrolling: Scroll down or up lists by

holding the mouse pointer over the edge of the screen.

Pointer speed: Set the speed of the pointer.

Apps >

Language and Input SettingsSettings

DRAFT FOR INTERNAL USE ONLY

Date and Time

By default, your device receives date and time information from the wireless network.

When you are outside network coverage, you may want to set date and time information manually using the date and time settings.

1. From a Home screen, tap Apps > Settings.

2. Tap Date and time.

3. Set the date, time, time zone, time format, and

date format.

Date and TimeSettings

DRAFT FOR INTERNAL USE ONLY

Safety Assistance

Receive real-time information about emergencies and severe weather conditions.

You can also enable Emergency mode (a power-conserving mode which restricts certain apps and functions while allowing access to Messages, Contacts, and emergency calls).

Emergency Mode

Use Emergency mode to conserve batter power during emergencies. Power-hungry apps and functions are disable, but you are still able to sendmessages, use Contacts, and make emergencycalls.

1. From a Home screen, tap Settings>SafetyAssistance.

2. Tap Emergency mode.

Apps >

Send Help Messages

Send a quick alert to your primary contacts when you are in an emergency situation.

To enable this feature:

1. From a Home screen, tap Settings>SafetyAssistance.

2. Tap Send help messages.

3. Tap OFF/ON to turn the feature on.

Tap Send pictures to send photos taken with

the front and back cameras to your emergency contacts.

Tap Send sound recording to send a short

audio message to your emergency contacts.

To send a help messages:

► Press the Power/Lock key quickly three times.

Apps >

Manage Primary Contacts

Select contacts or create new ones to be your emergency contacts. These contacts automatically receive your help message.

3. Tap ON/OFF to turn the feature on.

Geo News

Receive information about weather, environmental situations, and geological information for your location during emergencies.

1. From a Home screen, tap Settings>SafetyAssistance.

2. Tap Geo News.

3. Tap ON/OFF to turn the feature on.

Tap Geo News notiﬁcation pop-ups to

receive pop-up alerts.

Apps >

1. From a Home screen, tap Settings>SafetyAssistance.

2. Tap Manage primary contacts.

Tap Create primary contacts:

Tap Create new contacts to enter a name and

phone number for a new emergency contact.

Tap Select from contacts to designate a

contact to be an emergency contact.

Apps >

Safety AssistanceSettings

DRAFT FOR INTERNAL USE ONLY

Battery

View how battery power is used for device activities.

1. From a Home screen, tap Apps > Settings.

2. Tap Battery for options:

Show battery percentage: Display the battery

charge percentage next to the battery icon on the Status bar.

Battery Chart: The battery level displays as

a percentage. The amount of time the battery has been used also displays.

Apps and OS Usage: Battery usage displays

in percentages per application.

Tap Screen, Android System, Android OS,

or an app to view they are aﬀecting battery use.

Tap Refresh to update the listing.

Tap Show battery percentage to display the

device battery status next to the battery icon.

Note: Other applications may be running that aﬀect battery use.

BatterySettings

DRAFT FOR INTERNAL USE ONLY

Power Saving

Conserve battery power by automatically adjusting the screen brightness, limiting the performance of the CPU, and other power reduction activities.

Ultra power saving mode saves even more battery power by using a gray scale theme on the Home screen and limiting the number of usable apps.

1. From a Home screen, tap Apps > Settings.

2. Tap Power saving for options:

Power saving mode: Tap ON/OFF to turn the

feature on. Tap Power saving mode to select options.

Ultra power saving mode: Tap ON/OFF to

turn the feature on. Tap Ultra power saving

mode for options.

Tip: Tap Learn about power saving to display more

information about conserving power.

Power SavingSettings

Samsung SMG800R4 Users Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Getting Started

Front View

Back View

Prepare Your Device

Set Up Your Device

Set Up Accounts on Your Device

Know Your Device

Home Screen

Status Bar

Entering Text

Calling

Calling

Applications

Apps Screen

Google Applications

Other Applications

Camera and Video

Contacts

Calculator

Calendar

Clock

Email

Gallery

Internet

Messaging

Music Player

S Health

S Voice

Video Player

WatchON

Settings

How to Use Settings

Wi-Fi and Wi-Fi Direct

Bluetooth

Tethering and Wi-Fi Hotspot

Airplane Mode

Data Usage

Location Services

Mobile Networks

Default Messaging App

Virtual Private Networks (VPN)

Sharing Files with NFC

Nearby Devices

Printing

Screen Mirroring

Sound

Display

Wallpaper

Lock Screen

Toolbox

Easy Mode

Accessibility

Blocking Mode

Private Mode

Fingerprint Scanner

Motions and Gestures

Air View

Accounts

Cloud

Backup and Reset

Language and Input Settings

Date and Time

Safety Assistance

Battery

Power Saving
