Samsung SL35 User Manual

Instructions

Getting to Know your camera

Use this camera in the following order.

Setting up the application
software

Take a picture

Insert the USB cable

Check the camera's power

Check [Removable Disk]

To use this camera with a PC,
install the application software
fi rst. After this has been done, the
stored images in the camera can be
moved to the PC and can be edited
by an image editing program. (p.88)

Take a picture. (p.18)

Insert the supplied USB cable
into the PC’s USB port and the
camera’s USB connection
terminal. (p.90)

Check the camera’s power. If the
power is turned off, preset the
camera button to turn it on.

Open Windows’s EXPLORER
and search for [Removable Disk].
(p.91)

Thank you for buying a Samsung Digital Camera.



Prior to using this camera, please read the user manual
thoroughly.



If you require After Sales service, please bring the camera and
the cause of the camera malfunction (such as battery, Memory
card etc.) to the A/S centre.



Please check that the camera is operating properly prior to when
you intend to use it (e.g. for a trip or an important event) to avoid
disappointment. Samsung takes no responsibility for any loss or
damage that may result from camera malfunction.



Keep this manual in a safe place.



If you use a card reader to copy the images on the memory card to
your PC, the images could be damaged. When transferring the
images taken with the camera to your PC, be sure to use the
supplied USB cable to connect the camera to your PC. Please note
that the manufacturer holds no responsibility for loss or damage of
images on the memory card due to the use of a card reader.



The contents and illustrations of this manual are subject to
change without prior notice for upgrading the camera functions.

Ä

Microsoft, Windows and Windows logo are registered trademarks
of Microsoft Corporation incorporated in the United States and/or
other countries.

Ä

Adobe and Reader are either trademarks or registered
trademarks in the United States and/or other countries.

Ä

All brand and product names appearing in this manual are
registered trademarks of their respective companies.

1

Danger

Warning

DANGER indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.



Do not attempt to modify this camera in any way. To do so may

result in fi re, injury, electric shock or severe damage to you or
your camera. internal inspection, maintenance and repairs should
only be carried out by your dealer or Samsung Camera Service
centre.



Please do not use this product in close proximity to fl ammable or

explosive gases, as this could increase the risk of explosion.



Should any form of liquid or a foreign object enter the camera,

do not use it. Switch off the camera, and then disconnect the
power source. You must contact your dealer or Samsung Camera
Service centre. Do not continue to use the camera as this may
cause a fi re or electric shock.



Do not insert or drop metallic or infl ammable foreign objects into

the camera through access points e.g. the memory card slot and
battery chamber. This may cause a fi re or electric shock.



Do not operate this camera with wet hands. This could pose a

risk of electric shock.

2

WARNING indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.



Do not use the fl ash in close proximity to people or animals.

Positioning the fl ash too close to your subject’s eyes may cause
eyesight damage.



For safety reasons keep this product and accessories out of

reach of children or animals to prevent accidents e.g.:

- Swallowing battery or small camera accessories. If an accident
should occur, please consult a doctor immediately.

- There is the possibility of injury from the camera’s moving parts.



Battery and camera may become hot during prolonged use and it

may result in camera malfunction. Should this be the case, allow
the camera to sit idle for a few minutes to allow it time to cool.



Do not leave this camera in places subject to extremely high

temperatures, such as a sealed vehicle, direct sunlight or other
places of extremes in temperature. Exposure to extreme
temperatures may adversely affect the camera’s internal
components and could cause a fi re.



When in use, do not cover the camera or Charger. This may cause
heat to build up and distort the camera body or cause a fi re. Always
use the camera and its accessories in a well-ventilated area.

Caution

Contents

CAUTION indicates a potentially hazardous situation which, if not
avoided, may result in a minor or moderate injury.



Leaking, overheating, or damaged battery could result in fi re or injury.

- Use battery with the correct specifi cation for the camera.

- Do not short circuit, heat or dispose of battery in fi re.

- Do not insert the battery with the polarities reversed.



Remove the battery when not planning to use the camera for a

long period of time. Otherwise the battery may leak corrosive
electrolyte and permanently damage the camera’s components.



Do not fi re the fl ash while it is in contact with hands or objects. Do

not touch the fl ash after using it continuously. It may cause burns.



Do not move the camera while it is switched on, if you are using

the AC adapter. After use, always switch off the camera before
unplugging the cable from the wall socket. Then make sure that
any connector cords or cables to other devices are disconnected
before moving the camera. Failure to do so may damage the
cords or cables and cause a fi re or electric shock.



Take care not to touch the lens or lens cover to avoid taking an

unclear image and possibly causing camera malfunction.



Avoid obstructing the lens or the fl ash when you capture an image.



When using this camera in low temperatures, you may experience

the following. These are not camera malfunctions and usually
recover at normal temperature.

- It takes longer to turn on the LCD monitor and the colour may
differ from the subject.

- When changing the composition, there may be an after image on
the LCD monitor.



Credit cards may be demagnetized if left near case. Avoid leaving

magnetic strip cards near the case.



After turning on the camera, Check whether the battery type and
the camera setting set on the [Settings] > [Battery Type] menu
(p. 54) are same.

READY

RECORDING

007 System chart

007 Package Contents

007 Sold Separately

008 Identifi cation of features

008 Front & Top

009 Back

010 Bottom

010 5 Function button

011 Self-timer lamp

011 Camera Status Lamp

011 Mode icon

012 Connecting to a Power Source

013 Inserting the memory card

Instructions on how to use the memory card

014

016 LCD monitor indicator

017 How to use the menu

018 Starting the recording mode

018 Selecting modes

018 How to use the Smart Auto mode

019 How to use the Auto mode

020 How to use the Program mode

020 How to use the DIS mode

021 Using the Photo Help Guide mode

022 How to use the Scene modes

3

Contents

024 How to use the Movie clip mode

Recording the movie clip without sound

024

024 Pausing while recording a movie clip

(Successive Recording)

025 Things to Watch Out for When Taking

Pictures

Using the camera buttons to set the camera

026

026 POWER button

026 SHUTTER button

026 ZOOM button

028 Info (DISP) / Up button

028 Macro / Down button

030 Focus lock

030 Flash / Left button

032 Self-timer / Right button

034 MENU button

034 OK button

034 Functions

035 How to Enable Functions Using the

MENU Button

035 Exposure compensation

036 White balance

037 ISO

037 Face Detection

039 Face Tone

4

SETUP

039 Face Retouch

040 Image Size

040 Quality / Frame rate

041 ACB

041 Metering

042 Drive mode

042 Auto Focus type

043 Photo Style Selector

044 Image Adjust

045 Voice Memo

045 Voice Recording

Recording the movie clip without voice

046

047 Sound menu

047 Sound

047 Volume

047 Start up sound

047 Shutter sound

047 Beep Sound

048 AF sound

048 Setup menu

048 Display

048 Language

048 Function Description

049 Start up image

Contents

049 Display Bright

049 Quick view

049 Display SAVE

050 Settings

050 Formatting a memory

050 Initialisation

051 Setting up the Date / Time / Date type

051 Time Zone

051 File name

052 Imprinting the recording date

052 Auto power off

053 Selecting Video out type

054 Auto Focus lamp

054 Setting the USB

054 Selecting a battery type

055 Starting play mode

PLAY

055 Playing back a still image

055 Playing back a movie clip

056 Movie clip capture function

056 Playing back a recorded voice

057 Playing back a voice memo

057 LCD monitor Indicator

Using the camera buttons to set the camera

058

058 Play mode button

058 Thumbnail / Enlargement button

058 Smart Album

061 Info (DISP) / Up button

061 Play & Pause / OK button

062 Left / Right / Down / MENU button

062 Delete button

063 Setting up the play back function using

the LCD monitor

065 Edit

065 Resize

066 Rotating an image

066 Photo Style Selector

067 Image Adjust

069 View

069 Starting the Multi Slide Show

069 Start the Multi Slide Show

070 Selecting Images
070 Confi gure Multi Slide Show effects

071 Setting play interval

071 Setting Background Music

071 File Options

071 Deleting images

072 Protecting images

072 Voice memo

073 DPOF

5

Contents

075 Copy To Card

076 PictBridge

077 PictBridge : Picture Selection

077 PictBridge : Print Setting

078 PictBridge : Reset

078 Important notes

080 Warning indicator

081 Before contacting a service centre

083 Specifi cations

SOFTWARE

6

086 Software Notes

086 System Requirements

087 About the software

088 Setting up the application software

090 Starting PC mode

093 Removing the removable disk

094 Samsung Master

097 Setting up the USB Driver for MAC

097 Using the USB Driver for MAC

098 FAQ

System chart

Please check that you have the correct contents before using this product. The contents can vary depending on the sales region. To buy the
optional equipment, contact your nearest Samsung dealer or Samsung service centre. Parts and accessories illustrated below may differ
from exact appearance.

Package Contents

Camera

Sold Separately

SD/SDHC memory

card / MMC

(see p.15)

AA Alkaline Batteries

AD81-00867A

Rechargeable battery

AD81-00879A

USB cable

AD81-09092A

Charger

AD81-00898A

Camera strap

AD63-02596A
AD63-02604A

AV cable

AD81-00735A

Software CD

(see p.87)

AD46-00284A

AC cord

AD81-00696A

User manual,

Product warranty

AD68-04185A

Camera case

7

Identifi cation of features

Front & Top

Shutter button

Flash

Microphone

8

Power button

Speaker

Self-timer lamp /
AF sensor

Lens/ Lens cover

USB / AV terminal

Identifi cation of features

Back

LCD monitor

Camera status lamp

Zoom Wide(W) button (Thumbnail)

Zoom Tele(T) button (Digital zoom)

Strap eyelet

MENU button

Play mode button

Fn / Delete button

5 function button

9

Identifi cation of features

Bottom

Memory card slot

Battery chamber cover

Tripod socket

Ä

To open the battery chamber cover, slide it in the direction shown
above.

10

Battery chamber

5 Function button

Flash /

Left button

Information / Up button

OK / Play & Pause
button

Self-timer /
Right button

Macro / Down button

Identifi cation of features

Self-timer lamp

Icon Status Description

- For the fi rst 8 seconds, the lamp blinks at 1 second

Blinking

Blinking

Blinking

Blinking

intervals.

- For the fi nal 2 seconds, the lamp blinks quickly at

0.25-second intervals.

For the 2 seconds, the lamp blinks quickly at

0.25-second intervals.

A picture will be taken after about 10 seconds and 2
seconds later a second picture will be taken.

After pressing the Shutter button, the image is taken
in accordance with the subject’s movement.

Camera Status Lamp

Status Description

Power on

After taking a picture

When fl ash battery is charging

When the USB cable is
inserted to a PC

Transmitting Data with a PC

When the USB cable is
inserted into a printer

When the printer is printing

When the AF activates

The lamp turns on and off when the camera
is ready to take a picture
The lamp blinks while saving the image data and
turns off when the camera is ready to take a picture

The lamp blinks

The lamp lights up
(LCD monitor turns off after initializing the device)

The lamp blinks (LCD monitor turns off)

The lamp blinks

The lamp blinks

The lamp turns on
(The camera focus on the subject)

The lamp blinks
(The camera doesn’t focus on the subject)

Mode icon

Refer to page 18 for more information about the camera mode setting.

MODE Smart Auto Auto Program DIS

ICON

MODE

ICON

MODE

ICON

MODE Children Landscape Close up Text

ICON

MODE Sunset Dawn Backlight Firework

ICON

MODE

ICON

Photo Help

Guide

Beauty Shot

Beach&Snow

Scene Movie

SCENE

Frame Guide

-

-

Night Portrait

-

-

11

Connecting to a Power Source

We recommend batteries for a digital camera (Within a year from
the date of manufacture). The batteries are listed below.

Non rechargeable batteries : 2 X AA Alkaline (High Capacity)

-

- Rechargeable batteries (Optional) : SNB-2512 (Ni-MH)



SNB-2512 rechargeable battery Specifi cation

Model SNB-2512

Type Ni-MH

25

Capacity

Voltage 1.2V x 2

C

harging time

Ä

Included battery may vary depending on sales region.

12

00mAh

Approximately 300 Minutes (Use for SBC-N2)

Important information about battery usage.



When camera is not in use, turn off the power.



Please remove the battery if the camera will not be used for
long periods. Batteries can lose power over time and are
prone to leaking if kept inside the camera.



Low temperatures (below 0°C) can affect the performance
of the battery and you may experience reduced battery life.



Batteries will usually recover at normal temperatures.



During extended use of the camera, the camera body may
become warm. This is perfectly normal.



It is easy to buy alkaline batteries. However, the duration
for using batteries varies in accordance with the battery
manufacturer or the photographic conditions



Do not use manganese batteries as manganese batteries
cannot deliver suffi cient power.

For this camera, it recommended that a high-capacity battery



(alkaline, nickel-hydride) is used. If another battery is used,
the camera’s usage time may be lowered.

Connecting to a Power Source



Insert the battery as shown

- If the camera does not turn on
after you have inserted battery,
please check whether the
battery (+ / -).

- When the battery chamber
cover is opened, do not force
the battery chamber cover,
this may damage it.



There are 4 indicators for battery condition that are displayed on
the LCD monitor.

Battery

indicator

The battery is

Battery

Ä

fully charged

status

When using the camera and the battery in a place that is excessively cold or hot,
the battery status on the LCD may be different from the actual battery status.

Low battery

capacity

(Prepare to

recharge or use

spare battery)

Low battery

capacity

(Prepare to

recharge or use

spare battery)

Battery empty.

(Recharge

or use spare

battery)

Inserting the memory card



Insert the memory card as shown.

- Turn off the camera’s power be­fore inserting the memory card.

- Have the front of the memory
card facing toward the front of
the camera (lens) and the card
pins toward the back of the
camera (LCD monitor).

- Do not insert the memory card
the wrong way round.
Doing so may damage the
memory card slot.

13

Instructions on how to use the memory card





Be sure to format the memory card (see p.50) if you are using
a newly purchased memory card for the fi rst time, if it contains
data that the camera cannot recognise, or if it contains images
captured with a different camera.



Turn off the camera power whenever the memory card is being
inserted or removed.



Repeated use of the memory card will eventually reduce the
memory card’s performance. Should this be the case, you will
need to purchase a new memory card. Wear and tear on the
memory card is not covered by the Samsung warranty.



The memory card is an electronic precision device.
Do not bend, drop or subject the memory card to any heavy
impact.



Do not store the memory card in an environment with strong
electronic or magnetic fi elds, e.g. near loud speakers or TV
receivers.



Please do not use or store in an environment where there are
extremes in temperature.



Do not allow the memory card to become dirty or to come into
contact with any liquid. Should this happen, clean the memory
card with a soft cloth.



Please keep the memory card in its case when not in use.



During and after periods of extended use, you may notice that the
memory card is warm. This is perfectly normal.



Do not use a memory card that is used in another digital camera.
To use the memory card in this camera, format the memory card
using this camera.



Do not use a memory card formatted by another digital camera or
memory card reader.

If the memory card is subjected to any of the following, the
recorded data may become corrupted :

- When the memory card is used incorrectly.

- If the power is switched off or the memory card is removed
while recording, deleting (formatting) or reading.



Samsung cannot be held responsible for lost data.



It is advisable to copy important data onto other media as back-up
e.g. fl oppy disks, hard disks, CD etc.



If there is insuffi cient memory available :
A [Memory Full] message will appear and the camera will not
operate. To optimise the amount of memory in the camera,
replace the memory card or delete unnecessary images stored
on the memory card.



Don't remove the memory card when the camera status lamp is
blinking as this may cause damage to data in the memory card.

14

Instructions on how to use the memory card

The camera can use SD/SDHC Memory Cards and MMC (Multi
Media Cards).

Card pins

Write protect switch

Label

[SD (Secure Digital) memory card]



The SD/SDHC memory card has a write protect switch that
prevents image fi les from being deleted or formatted. By sliding
the switch to the bottom of the SD/SDHC memory card, the data
will be protected. By sliding the switch to the top of the SD/SDHC
memory card, the data protection will be cancelled.



Slide the switch to the top of the SD/SDHC memory card before
taking a picture.

When using a 1GB SD memory, the specifi ed shooting capacity will be
as follows. These fi gures are approximate as image capacities can be
affected by variables such as subject matter and memory card type.

Recorded

image size

Still


*Movie

clip





Super Fine Fine

About

218

About

240

About

281

About

290

About

365

About

850

About

1892

---

---

The zoom button doesn’t function during the movie recording.
The recording times can be changed by the zoom operation.
You can record videos of up to 4GB or 2hours each.

Normal

About

303

About

340

About

394

About

411

About

506

About

112 0

About

2185

About

506

About

548

About

616

About

657

About

822

About

1263

About

2397

30 FPS 15 FPS

--

--

--

--

--

--

--

About
13'42"

About
34'17"

About
27'04"

About
59'24"

15

LCD monitor indicator



The LCD monitor displays information about the shooting
functions and selections.

[Image & Full Status]

No. Description Icons Page

1 Recording mode

Optical / Digital Zoom bar /

2

Digital Zoom rate

3

4

16

Voice Memo

Number of available shots

remaining

Remaining time 00:00:00

00001

p.18

p.26

p.45

p.15

No. Description Icons Page

Memory card icon /

5

Internal memory icon

6 Battery

7Flash

8 Self-timer

9 Macro

10 Photo Style Selector

11 Face Detection

12 Face Tone

Image Adjust / Without Sound /

13

14 Date / Time 2009/08/01 01:00 PM p.51

15 Camera shake Warning

16

17 Drive mode

18 Metering

19

20 Image Size

21 ISO

22

23

Face Retouch

Auto Focus Frame

Image Quality / Frame Rate

White Balance

Exposure compensation

-

p.13

p.30

p.32

p.28

p.43

p.37

p.39

p.44/

46/39

p.25

p.42

p.42

p.41

p.40

p.40

p.37

p.36

p.35

How to use the menu

1.

Turn on the camera and press the MENU button. A menu for each camera mode appears.

Mode

Functions

Sound

Display

Settings

Exit Change

Smart Auto

Auto

Program

DIS

Photo Help Guide

Scene

Movie

2. Use the up or down buttons to navigate through the menus.

Mode

Functions

Sound

Display

Settings

Exit Change

Smart Auto

Auto

Program

DIS

Photo Help Guide

Scene

Movie

Press the

UP or DOWN

button.

Mode

Functions

Sound

Display

Settings

Exit Change Exit Change

Face Detection

Photo Size

Quality

Focus Area

Photo Style Selector

Voice

Press the

UP or DOWN

button.

3. Use the left or right buttons to select a sub menu.

Volume

Mode

Start Sound

Functions

Shutter Sound

Beep Sound

Sound

AF Sound

Display

Settings

Exit Change

Press the

LEFT or

RIGHT button.

Volume :Medium

Start Sound :Off

Shutter Sound :1

Beep Sound :1

AF Sound :On

Exit Back

Press the

LEFT or

RIGHT button.

4. Select a submenu and click the OK button to save settings and return to the previous window.

Volume

Mode

Start Sound

Functions

Shutter Sound

Beep Sound

Sound

AF Sound

Display

Settings

Volume :Medium

Start Sound :Off

Shutter Sound :1

Beep Sound :1

AF Sound :On

Back Set

Off

Low

Medium

High

17

Starting the recording mode

Selecting modes

You can select the desired working mode
using the MENU button located on the back
of the camera.



How to use the MENU button

1. Press the MENU button and a menu
will be displayed.

2.

Press the Up / Down button to select
the [Mode] menu and press the Right

button.

3. Select a desired mode by pressing
the Up / Down button and then press
the OK button.

18

Mode

Functions

Sound

Display

Settings

Exit Change

Smart Auto

Auto

Program

DIS

Photo Help Guide

Scene

Movie

Smart Auto

Auto

Program

DIS

Photo Help Guide

Scene

Movie

Exit Back

Smart Auto

Auto

Program

DIS

Photo Help Guide

Scene

Movie

Exit Back

Smart Auto

Auto

Program

DIS

Photo Help Guide

Scene

Movie

Exit Back

Mode

Functions

Sound

Display

Settings

Exit Change

Smart Auto

Auto

Program

DIS

Photo Help Guide

Scene

Movie

How to use the Smart Auto mode ( )

The camera automatically chooses the appropriate camera settings
based on a detected type of scene. It will be helpful if you are not
familiar with the camera settings for various scenes.

1. Select the Smart Auto mode by
pressing the MENU button.

2. The camera selects a scene
automatically. An appropriate mode
icon will appear at the top left of the
screen.

3. Press the shutter button to capture
an image.

If the camera does not recognize a proper scene mode, the



default settings will be used.
Even if there is a face detected, the camera may not select a



portrait mode depending on the subject’s position or lighting.
The camera may not select the correct scene depending on



shooting environments, such as camera shake, lighting, and
distance to the subject.
The [Night] mode recognizes scenes only when the fl ash is set



to off. The camera operates the [Tripod] mode after checking the
shooting condition on the tripod for a certain time.
Despite using a tripod, the camera may not select a tripod mode



depending on the subject’s movement.

Starting the recording mode

Each scene is recognized in the following conditions;

[Landscape] (

[White] (

[Nights] ( ) : When shooting the nighttime scenes

[Night Portrait] (

[Backlight] (

[Backlight Portrait]

[Portrait] (

[Macro] (

[Macro Text] (

[Tripod] (

[Action] (

) : When shooting outdoor scenes

) :

When shooting in a very bright environment

) : When shooting people in a dark out-

door place

) : When shooting a backlit scenery

without a portrait

( ) : When shooting a backlit portrait

) : When shooting a portrait

) : When shooting close-ups

) : When shooting texts in a close focus

) : When shooting a subject without any

movement on the tripod

) : When shooting a subject making

frequent movements

How to use the Auto mode ( )

Select this mode for quick and easy picture taking with minimal
user interaction.

1.

Insert the batteries (p.13). Insert the

batteries taking note of the polarity (+ / -).

2. Insert the memory card (p.13).
As this camera has a 7MB internal
memory, you do not need to insert
the memory card. If the memory
card is not inserted, an image will be
stored in the internal memory. If the memory card is inserted,
an image will be stored on the memory card.

3. Close the battery chamber cover.

4. Press the power button to turn on the camera.

5. Select the Auto mode by pressing the MENU button.

6. Point the camera towards the subject and compose the image
by using the LCD monitor.

7. Press the shutter button to capture an image.

If the auto focus frame turns to red when you press the shutter



button down half way, it means that the camera cannot focus
on the subject. Should this be the case, the camera is unable
to capture an image clearly.

Avoid obstructing the lens or the fl ash when you capture an



image.

19

Starting the recording mode

How to use the Program mode ( )

Selecting the automatic mode will confi gure the camera with
optimal settings. You can still manually confi gure all functions
except the aperture value and shutter speed.

1. Select the Program mode by pressing
the MENU button. (p.18)

2. Press the Menu button to confi gure
advanced functions.

See p.34 for further details.

20

How to use the DIS mode ( )

Digital Image Stabilisation (DIS) mode.
This mode will reduce the effect of camera shake and help you get
a well-exposed image in dim conditions.

1. Select the DIS mode by pressing the
MENU button. (p.18)

2. Point the camera towards the subject
and compose the image by using the
LCD monitor.

3. Press the Shutter button to capture an
image.



Things to watch out for using the DIS mode

1. The digital zoom will not operate in the DIS mode.

2. If the lighting conditions are brighter than fl uorescent lighting

conditions, the DIS will not activate.

3. If the lighting condition is darker than in fl uorescent lighting

conditions, camera shake warning indicator ( Ã ) will display.
For best results only take pictures in situations where the
camera shake warning indicator ( Ã ) is not displayed.

4. If the subject is moving, the captured image may be blurred.

5.

As the DIS uses the camera’s digital signal processor, it may take

a little longer for the camera to process and save the images.

Starting the recording mode

Using the Photo Help guide mode ( )

Helps the user learn the correct picture taking method and includes
solutions for potential problems that may occur. This also enables
the user to practice the best way to take the pictures.

Photo Help Guide

Photo Help Guide

Features to use when the image is out of focus

Features to reduce camera shake
Features to use in low light conditions
Features to use when adjusting brightness
Features to use when adjusting colours

Guide list

Pressing the

Left/Right button

Pressing the OK button

[Function that can be used when focusing is diffi cult]

Photo Help Guide

Features to use when the image is out of focus

Half-press the shutter button to focus

To focus on a subject 80 cm away or more
To focus on a subject less than 80 cm away
To focus on people’s faces

Back ChangeChange

Pressing the
Up button

Press the shutter button
to practice using this
feature.

Guide list

Available functions of the photo help guide

Function that can be used when focusing is diffi cult



Functions that can be used when the image is blurred



Function that can be used when fi lming in the dark



Function that can be used when adjusting the picture brightness



Function that can be used when adjusting the picture colour



Pressing the

Left/Right button

Photo Help Guide

To focus on your subject, half­press the shutter button:

- Green frame: subject is in focus

- Red frame: subject is out of focus

1/2

Pressing the OK button

Back Practice

Pressing the

Up/Down button

Photo Help Guide

When the subject is in focus,
press the shutter button
completely to capture the image

Pressing the OK buttonPressing the shutter button

or video. If the subject is out of
focus, try half-pressing the shutter
button again.

Back Practice

2/2

21

Starting the recording mode

How to use the Scene modes ( )

Use the menu to easily confi gure optimal settings for a variety of
shooting situations.

1. Select the Scene mode by pressing
the MENU button. (p.18)

2. Point the camera towards the subject
and compose the image by using the
LCD monitor.

3. Press the shutter button to capture an
image.

22

The scene modes are listed below.

[Beauty Shot] (

[Frame Guide] (

[Night] ( ) : Use this for shooting still images at night

[Portrait] (

[Children] (

[Landscape] (

[Close Up] (

[Text] (

[Sunset] (

[Dawn] (

[Backlight] (

[Firework] (

[Beach&Snow] (

) : Take a photo of a person with options to

hide facial imperfections.

) : Use this mode when you want someone

else to take a picture for you from the

angle you choose.

or in other dark conditions.

) : To take a picture of a person.

) : To take a picture of fast moving

objects, for example, children.

) : To take pictures of distant scenery.

) : Close-up shooting for small objects such

as plants and insects.

) : Use this mode to shoot a document.

) : For taking pictures of sunsets.

) : Daybreak scenes.

) : Portrait without shadows caused by

backlight.

) : Firework scenes.

) : For ocean, lake, beach and snowscape

scenes.

Starting the recording mode

Ŷ How to use the [Frame Guide] mode

Set [Frame Guide] mode when you want someone else to take a
picture for you from the angle you choose.

1. Take a picture from the angle
you choose.

- A guide appears round the

sides of the picture.

Guide

Cancel Frame: OK

2. Then another person can take
the picture by aligning the edge
of the picture to be taken with
the guide framing the sides of
the window.

Cancel Frame: OK

Cancel Frame: OK

Ŷ How to use the [Long Time Shutter] mode

This camera automatically adjusts the shutter speed and aperture
values to the shooting environment. However, in Night scene
mode, you can set the shutter speed and aperture values to your
preference.

Changing the Shutter speed and Aperture value

1. Select the [Night] mode. (p.22)

2. Press the Fn button and Long Time
shutter menu will be displayed.

Long Time Shutter

3.5

1S

3. Configure the Long Time shutter
value with the 5 function button.

4. Press the Fn button again. The value

Exit Move

you set will be saved and the mode
will switch to Night scene mode.

23

Starting the recording mode

How to use the Movie clip mode ( )

A movie clip can be recorded for as long as the available recording
time of the memory capacity allows.

1. Select the Movie clip mode by pressing
the MENU button. (The Movie clip
mode icon and available recording time
will display on the LCD monitor.)

2. Point the camera towards the subject
and compose the image by using the
LCD monitor.

3. Press the shutter button once and movie clips are recorded for
as long as the available recording time allows. Movie clips will
still be recorded if the shutter button is released. If you wish to
stop recording, press the shutter button again.

Ä

Image size and type are listed below.

- Image size : 640x480, 320x240 (Selectable)

- Movie clip fi le type : AVI (MJPEG)

- Frame Rate : 30 FPS, 15 FPS (Selectable)

Recording the movie clip without sound

You can record the movie clip without sound.

Steps from 1 -3 are the same as those for
MOVIE mode.

4. Press the Menu button.

5. Press the Up / Down button to select the

[Functions] menu and press the Right
button.

24

6. Select the [Voice] menu by pressing the Up / Down button and
press the OK button.

7. Select the [Off] menu by pressing the Left / Right button.

8. Press the OK button. You can record a movie without sound.

Ä

See p.46 for further details.

Pausing while recording a movie clip (Successive Recording)

This camera allows you to temporarily stop during unwanted
scenes, while recording a movie clip. Using this function, you can
record your favourite scenes into a movie clip without having to
create multiple movie clips.



Using Successive Recording

Steps from 1-2 are the same as those for

MOVIE CLIP mode.

3. Press the shutter button and movie
clips are recorded for as long as the
available recording time. Movie clips
will still be recorded if the shutter
button is released.

4. Press the OK button to pause recording.

5. Press the OK button again to resume the recording.

6. If you wish to stop recording, press the shutter button again.

Stop Record

Things to Watch Out for When Taking Pictures



Pressing the shutter button down half way.

Lightly press the shutter button to confi rm focus and fl ash battery
charge. Press the shutter button all way down to take the picture.

[Lightly press the shutter button]



The available memory capacity may vary depending on shooting
conditions and camera settings.



When the Flash Off, Slow synchro mode or DIS mode is selected
in a low lighting condition, the camera shake warning indicator
(Ã ) may appear on the LCD monitor. In this case, use a tripod,
support the camera on a solid surface or change to fl ash shot
mode.



Shooting against the light : Please do not take pictures against



Avoid obstructing the lens or the fl ash when you capture an image.



Compose the image by using the LCD monitor.

[Press the shutter button]

the sun. Doing so may make the
picture dark. To take a picture against
the light, please use the [Backlight]
in scene shooting mode (see page

22), fi ll-in fl ash (see page 31), spot
metering (see page 41), exposure
compensation (see page 35) or ACB
(see page 41) function.



Under certain conditions the auto focus system may not perform
as expected.

- When photographing a subject that has little contrast.

- If the subject is highly refl ective or shiny.

- If the subject is moving at high speed.

- When there is strong refl ected light, or when the background is

very bright.

- When the subject matter has only horizontal lines or the subject

is very narrow (such as a stick or fl agpole).

- When the surroundings are dark.

25

Using the camera buttons to set the camera

ZOOM button

The recording mode function can be set up by using the camera buttons.

POWER button

Used for turning the camera’s power on / off.
If there is no operation during the specifi ed
time, the camera's power will be turned off
automatically to save battery life.
Refer to page 52 for more information
about the auto power off function.

If the menu is not displayed, this button
works as the OPTICAL ZOOM or
DIGITAL ZOOM button.
This camera has a 4X optical zoom and
a 5X digital zoom function. Using both
will offer a total zoom ratio of 20X.



TELE Zoom

Optical zoom TELE : Pressing the ZOOM T button. This will

Digital zoom TELE : When the maximum (4X) optical zoom

SHUTTER button

Used for taking an image or recording voice in the RECORDING
mode.



In MOVIE CLIP mode
Pressing the shutter button down fully
starts the process for recording a movie
clip. Press the shutter button once and
the movie clip is recorded for as long
as the available recording time in the
memory allows. If you wish to stop recording, press the shutter
button again.



In STILL IMAGE mode

Pressing the shutter button down halfway activates the autofocus
and checks the condition of the fl ash. Pressing the shutter button
down fully takes and stores the image. If you select voice memo
recording, the recording will start after the camera has fi nished
storing the image data.

26

[WIDE zoom]

zoom into the subject i.e. the subject will
appear nearer.

is selected, pressing the ZOOM T button
activates the digital zoom software.
Releasing ZOOM T button stops the digital
zooming at the required setting. Once the
maximum digital zoom (5X) is achieved,
pressing the ZOOM T button will have no
effect.

Pressing

the ZOOM

T button

[TELE zoom] [Digital zoom 5.0X]

Pressing

the ZOOM

T button

ZOOM button



WIDE Zoom

Optical zoom WIDE : Pressing the ZOOM W button. This will

zoom out from the subject i.e. the subject
will appear further away. Pressing the
ZOOM W button continuously will set the
camera to its minimum zoom setting i.e.
the subject appears at its furthest from the
camera.

Pressing

the ZOOM

W button

[TELE zoom] [Optical zoom 2X] [WIDE zoom]

Pressing

the ZOOM

W button

Digital zoom WIDE : When the digital zoom is in operation,

Optical zoom

pressing the ZOOM W button will reduce
the digital zooming in steps. Releasing
ZOOM W button stops digital zooming.

Digital zoom

Pressing the ZOOM W button will reduce
the digital zoom and then it will continue to
reduce the optical zoom until the minimum
setting is reached.

Pressing

the ZOOM

W button

[Digital zoom 5.0X] [TELE zoom] [WIDE zoom]

Pressing

the ZOOM

W button

Images taken using the digital zoom may take a little longer for



the camera to process. Allow time for this to take place.
If the Zoom buttons are being pressed during the Movie shots,



the voice will not be recorded.
You may notice a decrease in image quality when using the



digital zoom.
To view a clearer digital zoom image, press the shutter button



halfway at the maximum optical zoom position and press the
zoom T button again.
The digital zoom can’t be activated in some Scene modes



(Night, Children, Text, Close up, Firework), DIS modes, movie
mode and Face Detection.
Take care not to touch the lens to avoid taking an unclear image



and possibly causing camera malfunction. If the image is dim, turn
the camera power off and on again to modify the lens position.
Take care not to press the lens as this may cause a camera



malfunction.
When the camera is turned on, take care not to touch the camera’s



moving lens parts as this may cause the resulting image to be dim
and unclear.
Take care not to touch the lens when operating the zoom button.



27

Info (DISP) / Up button

While the menu is showing, the Up button operates as a direction button.
In the recording modes or playback mode, pressing this button will
display the image information.

[Information screen][Filming screen]

Macro

While the menu is showing, the Down button operates as a direction button.
When the menu is not showing, you can use the MACRO ( ) /
DOWN button to take macro pictures.
The distance ranges are shown below. Press the Macro button until
the desired macro mode indicator appears on the LCD monitor.

( )

/ Down button

[Auto Focus]

[Auto Macro ( )]

[Macro ( )]

28

Macro



Focus range

Focus range

Focus range

( )

/ Down button

Types of focus mode and focus range (W : Wide, T : Tele)

Mode Auto ( )

Focus Type Auto macro (

W : 10 ~ Infi nity

T : 50 ~ Infi nity

Mode Program ( )

Focus Type macro (

W : 10 ~ 80
T : 50 ~ 80

Mode DIS Mode ( )

Focus Type Auto macro (

W : 10 ~ Infi nity

T : 50 ~ Infi nity

When the macro mode is selected, be particularly careful to avoid



camera shake.
When you take a picture within 40cm (Wide zoom) or 50cm



(Tele zoom) in the Macro mode, select the FLASH OFF mode.

) Normal

W : 80 ~ Infi nity
T : 80 ~ Infi nity

) Normal

W : 80 ~ Infi nity
T : 80 ~ Infi nity

) Normal

W : 80 ~ Infi nity
T : 80 ~ Infi nity

(Unit: cm)



Available focusing method, by recording mode

( o : Selectable, : Infi nity focus range)

Mode Auto macro Macro Normal

oo

oo

oo

oo

oo

Mode

Auto macro Macro Normal

o

o

o

SCENE

o

o

o

o

o

o

o

o



o

29

Focus lock

To focus on a subject not positioned in the centre of the picture, use
the focus lock function.



Using the Focus Lock

1. Ensure the subject is in the centre of the autofocus frame.

2. Press the SHUTTER button halfway. When the green auto focus
frame lights up, it means the camera is focused on the subject.
Be careful not to press the SHUTTER button all the way down to
avoid taking an unwanted picture.

3. With the SHUTTER button still pressed down only halfway, move
the camera to recompose your picture as desired, and then
press the SHUTTER button completely to take the picture. If you
release your fi nger from the SHUTTER button, the focus lock
function will be cancelled.

( )

Flash

When the menu is displayed on the LCD
monitor, pressing the LEFT button makes
the cursor shift to the left tab.
When the menu is not displayed on the
LCD monitor, the LEFT button operates as
the FLASH ( ) button.



Selecting the fl ash mode

1. Press the MENU button to select a RECORDING mode with the
exception of the Movie clip mode or the DIS mode. (p.18)

2. Press the Flash button until the desired fl ash mode indicator is
displayed on the LCD monitor.

3. A fl ash mode indicator will be displayed on the LCD monitor.
Use the correct fl ash to suit the environment.

/ Left button

[Selecting the Auto fl ash]

1. The image to be
captured.

30

2.

Press the SHUTTER
button halfway and
focus on the subject.

3. Recompose the picture
and fully depress the
SHUTTER button.



Flash range

ISO

AUTO 0.8~3.5 0.8~2.0 0.4~0.8 0.5~0.8 0.4~3.5 0.5~2.0

Normal Macro Auto macro

WIDE TELE WIDE TELE WIDE TELE

(Unit: m)

Flash

( )

/ Left button

If you press the shutter button after selecting the fl ash, the fi rst



fl ash fi res to check the shooting condition (Flash range and
Power ratio of fl ash). Do not move the camera until the second
fl ash fi res.
Using the fl ash frequently will reduce the life of the battery.



Under normal operating conditions the re-charging time for



the fl ash is usually within 5 seconds. If the battery is weak, the
charging time will be longer.
In the DIS mode, [Landscape], [Close up], [Text], [Sunset],



[Dawn], [Firework] scene modes and the Movie clip mode, the
fl ash function will not operate.
Take photographs within the fl ash range.



The image quality is not guaranteed if the subject is too close



or highly refl ective.
When taking an image in poorly lit conditions with the fl ash,



there may be a white speck in the captured image. The speck
is caused by the fl ash light refl ecting off atmospheric dust.



Flash mode indicator

Icon Flash mode Description

Auto fl ash

Auto & Red eye

reduction

Fill in fl ash

Slow synchro

Red-eye reduction

Flash off

If the subject or background is dark, the
camera fl ash will operate automatically.

If a subject or background is dark, the
camera fl ash will work automatically and
will reduce the red-eye effect by using the
red-eye reduction function.

The fl ash fi res regardless of the avail-
able light. The intensity of the fl ash will be
automatically controlled to suit the prevailing
conditions.

The fl ash operates with a slow shutter speed
to obtain a balanced correct exposure. In
poor lighting conditions the camera shake
warning indicator (
LCD monitor.

When a shot with "red eye" is detected,
this mode will reduce the red-eye effect
automatically.

The fl ash does not fi re.
Select this mode when capturing images in
a place or situation where fl ash photography
is prohibited. When you capture an image
in poorly lit conditions, the camera shake
warning indicator (
LCD monitor.

) will display on the

Ã

) will appear on the

Ã

31

( )

Flash



Available fl ash mode, by recording mode ( o : Selectable)

Mode

Mode

32

/ Left button

oo oo

oooooo

oooooo

SCENE

ooo

ooo

ooo

ooo

oo

o

o



Smart Auto fl ash ( ) icon will appear in [Smart Auto]
mode.

Self-timer

When the menu is displayed on the LCD monitor, pressing the Right
button makes the cursor shift to the right tab.
When the menu is not displayed on the LCD monitor, the RIGHT
button operates as the Self-timer ( ) button. This function is used
when the photographer would also like to be in the image.

o

o

o

o

o

o

o

o






( )

/ Right button

If you operate the Self-timer button during the self-timer
operation, the self-timer function is cancelled.
Use a tripod to prevent the camera from shaking.
In Movie Clip mode, only the 10SEC self-timer will work.

Self-timer



Selecting the self-timer

1.

Select a Recording mode with the

( )

/ Right button

exception of Voice recording mode. (p.18)

2.

Press the SELF-TIMER / RIGHT ( )

button until the desired mode indicator
displays on the LCD monitor. A 10 second,
2 second, Double self-timer or Motion timer
icon appears on the LCD monitor.

3. When you press the SHUTTER button,
the picture will be taken after the
specifi ed time has elapsed.



Self-timer mode indicator

Icon Mode Description

10SEC

self-timer

self-timer

Double

self-timer

Motion

Pressing the shutter button will allow an interval
of 10 seconds before the image is taken.

2SEC

Pressing the shutter button will allow an interval
of 2 seconds before the image is taken.

A picture will be taken after about 10 seconds
and 2 seconds later a second picture will be
taken. When using the fl ash, the 2-second
self-timer may be delayed for longer than 2
seconds depending on the fl ash charging time.

The camera detects the subject's movement 6
seconds after pressing the Shutter button, and the

Timer

picture is taken when the movement is stopped.

[Selecting the 10 SEC

self-timer]



Motion Timer

Pressing the Shuter button after
setting the Motion Timer

Detecting the subject's movement Blink (0.25 second interval)

No movement is detected



The Motion Timer fl ows are as followings. (Movie Clip mode excluded)

Selecting the Motion Timer  Pressing the Shutter button
Confi rming the composition (Within 6 sec.)
detection (Swing your hands fully)

Motion Icon & Self-timer lamp

Blink (1 second interval)

Turn on and the image is taken
after 2 seconds

*1



*2



Starting the

Stopping the detection



(Do not move)  Taking an image (after 2 sec.)

*1: The camera detects the subject's movement 6 seconds after pressing the

Shtter button, so confi rm the composition within 6 seconds.

*2: Move your body or hands fully.

In the following cases, the Motion Timer may not operate.

The focus distance is over 3m.



The exposure is too bright or dark



In backlight conditions.



The movement is insignifi cant



The movement is detected beyond



the center part (50%) of the sensor
where the movement is recognized.
If the camera doesn`t sense any



movement for 30 seconds, or the
camera doesn’t sense stillness
after sensing movement

The detection range of

Motion Timer

33

MENU button

- When you press the MENU button, a menu related to each
camera mode will be displayed on the LCD monitor. Pressing it
again will return the LCD to the initial display.

- A menu option can be displayed when the following are selected :
MOVIE CLIP and STILL IMAGE mode. There is no menu
available when the voice recording function is selected.

[Menu off]

[Pressing the MENU button]

Mode

Functions

Sound

Display

Settings

Exit Change

[Menu on]

Smart Auto

Auto

Program

DIS

Photo Help Guide

Scene

Movie

Functions ( )

Use the menu that enables the functions, or the Fn button, to bring up the
menus below:

Mode Menu

EV p.35

White Balance p.36

ISO

Face Detection

Face Tone

Face Retouch p.39

Photo Size /

Movie Size

Available mode Page

p.37

p.37

p.39

p.40

OK button

- When the menu is displayed on the LCD monitor, this button is

used for shifting the cursor to the sub menu or for confi rming data.

34

Mode

Functions

Sound

Display

Settings

Exit Change

Smart Auto

Auto

Program

DIS

Photo Help Guide

Scene

Movie

[Pressing the

OK button]

Smart Auto

Auto

Program

DIS

Photo Help Guide

Scene

Movie

Exit Back

Quality / Frame Rate

(

Functions

)

ACB p.41

Metering

Drive

Focus Area

Photo Style Selector p.43

Image Adjust

Voice

p.40

p.41

p.42

p.42

p.44

p.45

Functions ( )

How to Enable Functions Using the MENU Button

1. Press the MENU button in an available mode.

2. Press the Up / Down button to select the [Functions] menu and
press the Right/OK button.

Mode

Functions

Sound

Display

Settings

Exit Change

EV

White Balance

ISO

Face Detection

Photo Size

Quality

ACB

Right/OK

button

3. Select a desired menu by pressing the Up / Down button and
then press the OK button.

EV

White Balance

ISO

Face Detection

Photo Size

Quality

ACB

Exit Back

Up / Down

button

4. Select a desired menu by pressing the Left / Right button and
then press the OK button.

White Balance

Left / Right

Back Move

button

EV

White Balance

ISO

Face Detection

Photo Size

Quality

ACB

Exit Back

EV

White Balance

ISO

Face Detection

Photo Size

Quality

ACB

Exit Back

Daylight

Back Move

Use the Fn button on the rear of the camera to bring up the menus
that enable frequently used functions faster.

Exposure compensation

This camera automatically adjusts the exposure according to the
ambient lighting conditions.
You can also select the exposure value by using the [EV] menu.



Compensating Exposure

1. Click the Up/Down button from the
Functions menu to select [EV] (

2. Use the LEFT and RIGHT buttons to
set the desired exposure compensation
factor.

3. Press the OK button. The value you
set will be saved and the Exposure Compensation setup mode
will be closed. If you change the exposure value, the exposure
indicator ( ) will be displayed on the Left of the LCD monitor.

Ä

A negative exposure compensation value reduces the exposure.

Note that a positive exposure compensation value increases the
exposure and the LCD monitor will appear white or you may not
get good pictures.

).

EV

Back Move

35

Functions ( )

White balance

The white balance control allows you to
adjust the colours to appear more natural.

White Balance



Using the Custom White Balance

White balance settings may vary slightly depending on the
shooting environment. You can select the most appropriate
white balance setting for a given shooting environment by setting
up the custom white balance.

Back Move

Mode Icon Description

The camera automatically selects the ap-

Auto WB

Daylight

Cloudy

Fluorescent_H

Fluorescent_L

Tungsten

Custom Set

Ä

Different lighting conditions may cause a colour cast on your images.

propriate white balance settings, depending
on the prevailing lighting conditions.

For taking images outside.

For taking images under a cloudy and over­cast sky.

For shooting under daylight fl uorescent types
of three-way fl uorescent lighting.

Shooting under white fl uorescent lighting.

For shooting under tungsten (standard light
bulb) lighting.

Allows the user to set the white balance ac­cording to the shooting condition.

36

1. Select the CUSTOM ( ) menu
of the White Balance and place a
sheet of white paper in front of the
camera so that the LCD monitor
shows only white.

2. OK button : selects previous

White paper

custom white balance.

Shutter button : saves new custom white balance.

- The custom white balance value will be applied, starting with
the next picture you take.

- The user confi gured white balance will be remain effective
until it is overwritten.

Functions ( )

ISO

You can select the ISO sensitivity when taking pictures.The speed or
specifi c light-sensitivity of a camera is rated by ISO numbers.

[Auto] : The camera's sensitivity is

automatically changed by
variables such as lighting value
or subject brightness.

ISO

Face Detection

If you use face detection options, your
camera can detect a human face. When
focusing on a human face, the brightness
of the face is also adjusted. You can also
capture natural facial expressions by using
self portrait, smile shot or blink detection.

[ISO 80, 100, 200, 400, 800, 1600] :

You can increase the shutter speed while
the same amount of light is present, by in­creasing the ISO sensitivity. However, the image may be saturated
in high luminance.
The higher the ISO value, the higher the camera’s sensitivity to
light and therefore the greater its capacity to take pictures in dark
conditions. However, the noise level in the image will increase as

Back Move



This mode detects the face position of the subject automatically
and then sets the focus and exposure. Select this mode for quick
and easy face picture.

Ä

the ISO value increases, making the image appear coarse.

Ä

When [Motion Capture] is set, ISO speed will be set to Auto.

Ä

[ISO] is enabled only in [Program] or [Photo Help Guide] mode.

1. The size and position of the auto

Face Detection

Back Move

Normal

Selectable modes: Auto, Program, DIS, Photo Help Guide, Beauty

Shot, Portrait, Children, Beach & Snow

focus frame is set at the face of the
subject automatically.

2. Press the shutter button halfway.
The focus frame turns to green
when the focus is activated.

3. Press the shutter button fully to take
a picture.

37

Functions ( )



This function can detect up to 10 persons.



When the camera recognises many people at the same
time, it will focus on the nearest person.



The Digital zoom is not activated in this mode.



When the camera detects a target face, the white colour
focus frame will be displayed over the target face and the
grey colour focus frame appears over the remaining faces.
Press the shutter button halfway down to focus on the face
and the white focus frame turns green.



Return to previous AF mode if face detection was failure.



In some conditions this function cannot work properly.

- When a person wears dark glasses or some part of the
face is hidden.

- When the person being taken does not look at the camera.

- Camera doesn't detect a face as the brightness is too dark
or too bright.

- The distance between the camera and object are far.



The maximum available Face Detection range is 2.5m (Wide).



The nearer the subject, the faster the camera can recognize
the subject.



In [Beauty Shot], [Portrait], and [Children] mode, the
[Face Detection] function setting is set to its default value.

38



Self Portrait

When taking pictures of yourself, the area of your face is automatically
detected so that you can take self pictures more easily and quickly.

Ä

Selectable modes: Auto, Program, DIS, Photo Help Guide,

1. For self-fi lming, set the camera lens

towards the face of the object. It
automatically detects the face of the
object, and emits a guiding sound.

2. Start fi lming by pressing the shutter

button.



When locating the face in the center of the screen, it repeatedly
emits a faster sound unlike the sounds that are emitted when
the face is not in the center.



Smile Shot

Ä

Selectable modes: Auto, Program, DIS, Photo Help Guide,

The camera automatically takes a picture
by detecting the face of the subject
although you don’t press the shutter
button. If you press the Shutter button, the
picture is taken in the normal way. When
taking a picture of smile shot, showing
teethes or keeping the smiley face of your subject helps detecting
the smile face of the subject.

Beauty Shot, Portrait, Children,

Beauty Shot, Portrait, Children,

Beach & Snow

Beach & Snow

Functions ( )



Blink Detection

Ä

Selectable modes: Auto, Program, DIS, Photo Help Guide,

If the eyes of the subject are closed
when the shutter button is pressed, the
camera takes 2 continuous shots and
then the images are saved. The camera
takes only one picture if the eyes of the
subject are open when the Shutter button
is pressed.



Detecting the smiling face or the blinking eyes may not be
available if any of the following situations occurs:

- If the subject is wearing sunglasses.

- When the subject is not facing directly to the camera.

- If the environmental light is too bright or too dark to detect

the face of the subject.

- When the camera is far from the subject. (Orange colored

focusing mark)

- If there is refl ection of the light or the back light that are

too bright.

Beauty Shot, Portrait, Children, Beach & Snow

Face Tone

This menu allows you to control the skin tone in images in beauty
shot mode. The higher the level you select, the brighter the skin tone.

1. Select [Face Tone] by pressing the
Up/Down button.

Face Tone

2. Select a desired face tone by pressing
the Left / Right button and then press
the OK button.

3. Press the Shutter button to take an
image.

Back Move

Face Retouch

This menu allows you to make skin appear clear and beautiful before
recording in beauty shot mode. The higher the level selected, the
more effective the control.

1. Select [Face Retouch] by pressing the
Up/Down button.

2. Select a desired face retouch by
pressing the Left / Right button and
then press the OK button.

3. Press the Shutter button to take an
image.

Face Retouch

Back Move

39

Functions ( )

Image Size

You can select the image size appropriate for your application.

(Unit: pixel)

Icon

Still


mode

Movie

clip

mode

40

3648X

3648X

3648X

3072X

2592X

Size

2736

2432

2052

2304

1944

2048X

1536

Icon

X

480 320X240

Size

Photo Size

Back Move

[ STILL IMAGE mode ]

The higher the resolution, the lower the number of shots



640

Movie Size

Back Move

[ MOVIE CLIP mode ]

available because high resolution images require more memory.

1024X

768

Quality / Frame rate

You can select the compression ratio appropriate for your application
of the captured images. The higher the compression ratio, the lower
the picture quality.

Mode STILL IMAGE mode MOVIE CLIP mode

Icon

Sub menu Super Fine Fine Normal 30 FPS 15 FPS

File

Format

jpeg jpeg jpeg avi avi

Quality

Back Move

[ STILL IMAGE mode ]

This fi le format complies with the DCF (Design rule for Camera



Frame Rate

Back Move

[ MOVIE CLIP mode ]

File system).
JPEG (Joint Photographic Experts Group) :



JPEG is the image compression standard developed by the
Joint Photographic Experts Group. This type of compression
is most commonly used for compressing photos and graphics
because it can compress the fi les effi ciently.

Functions ( )

ACB

This function is to adjust the contrast automatically when taking
photos in an environment with big exposure difference i.e. backlight or
contrast. This function adjusts the brightness automatically and allows
the subject to be photographed clearly.

- [ACB] Sub menus: [Off], [On]

ACB

Back Move

Ä

When using the [Program] mode, the ACB function will operate.

Metering

If you cannot obtain suitable exposure conditions, you can change
the metering method to take brighter pictures.

[Multi] ( ) : Exposure will be calculated

[Spot] ( ) : Only the rectangular area in the centre of the LCD

[Center We ighted] ( )

Ä

If the subject is not the centre of the focus area, do not use the

spot metering as this may result in an exposure error. In this
circumstance, it is better to use exposure compensation.

based on an average of

Metering

the available light in the
image area. However, the
calculation will be biased
towards the centre of the
image area. This is suitable

Back Move

for general use.

monitor will be metered for light. This is suitable
when the subject in the centre is exposed correctly,
regardless of the back lighting.

: Exposure will be calculated based on an average of

the available light in the image area. However, the
calculation will be biased towards the centre of the
image area. This is suitable for taking a picture of
small object like a fl ower or insects.

41

Functions ( )

Drive mode

You can select single, continuous, motion capture, and AEB (Auto
Exposure Bracketing).

[Single] ( ) :
[Continuous] ( ) : Images will be taken

[Motion Capture] ( )

[AEB] ( ) :



High resolution and picture quality increases fi le saving time,
which increases stand-by time.



If the [Continuous], [Motion Capture], [AEB] sub menu is se­lected, the fl ash will be off automatically.



If less than 3 pictures are available in the memory, the AEB
shooting is not available.



It is best to use a tripod for the AEB shooting as the time to save
each image fi le is longer and blurring caused by camera shake
may occur.

42

Take one picture only.

continuously until the

Drive

shutter button is
released.

: This takes 5 shots

Back Move

per second, when the shutter is pressed and
held down. After completing the continuous
shooting, images are saved and the images
play back on the Rear LCD. The maximum
number of shots is 30 and the image size is
fi xed as VGA.
Take three pictures in a series in different
exposures: standard exposure (0.0EV), short
exposure (-1/2EV) and over exposure (+1/2EV).

Auto Focus type

You can select your preferred Focus Area
according to the shooting conditions.

Focus Area

Back Move

[Center AF] (

[Multi AF] ( ) : This camera selects all of available AF point

Ä

When the camera focuses on the subject, the auto focus frame
turns to green. When the camera doesn't focus on the subject,
the auto focus frame turns to red.

) : The rectangular area in the center of the LCD

monitor will be focused

from the 9 AF points.

[Center AF] [Multi AF]

Functions ( )

Photo Style Selector

You can add various effects to the image
without using image editing software.

Photo Style Selector

Back Move

1. Select the desired Photo style selector by pressing the Left/Right
button and press the OK button.

2. Press the Shutter button to take an image.

Style mode Icon Description

Normal

Soft

Vivid

Forest

Retro

Cool

Calm

Classic

Negative

Custom RGB

No style effect is applied.

Soft style is applied.

Vivid style is applied.

Forest style is applied.

Sepia style is applied.

Cool style is applied.

Calm style is applied.

Black & white effect is applied.

Negative effect is applied.

Defi ne an RGB tone to create your own photo style.



Custom colour : You can change the

R (Red), G (Green)
and B (Blue) values
of the image.

Back Move

- Up/Down button : Selects R, G, B

- Left/Right button : Changes the values

Back Move

When picture style is set, face detection is not available.



When Soft or Vivid in photo style is set, saturation is not available.



When Negative in photo style is set, contrast is not available.



43

Functions ( )

Image Adjust



Contrast
You can change the contrast of the image.

1. Select [Contrast] by pressing the
Up/Down button.

2. Change the contrast by pressing the
Left/Right button.

3. Press the Shutter button to take an
image.

When Negative in photo style is set, contrast is not available.





Sharpness
You can adjust the sharpness of the
picture you are about to take.
You cannot check the sharpness effect
on the LCD monitor before you take a
picture, because this function is applied
only when the captured image is stored
on the memory.

1. Select [Sharpness] by pressing the Up/Down button.

2. Change the Sharpness by pressing the Left/Right button.

3. Press the Shutter button to take an image.

Image Adjust

Contrast

Sharpness

Saturation

Back Move

Image Adjust

Contrast

Sharpness

Saturation

Back Move



Saturation
You can change the saturation of the image.

1. Select [Saturation] by pressing the
Up/Down button.

2. Change the saturation by pressing
the Left/Right button.

Press the Shutter button to take an

3.
image.

When Soft or Vivid in photo style is set, saturation is not avail-



Image Adjust

Contrast

Sharpness

Saturation

Back Move

able.

44

Functions ( )

Voice Memo

You can add your voice-over to a stored
still image. (Max. 10 sec.)

If the voice memo indicator is displayed

­on the LCD monitor, the setting is
completed.

- Press the shutter button and take a
picture. The picture is stored on the
memory card.

- Voice memo will be recorded for ten
seconds from the moment the picture
is stored. In the middle of the sound
recording, pressing the shutter button
will stop the voice memo.

Memo

Back Move

Stop

Voice Recording

A voice can be recorded for as long as the
available recording time (Max. 10 hour)
allows.

Press the shutter button to record a voice.

- Press the shutter button once and voice
is recorded for as long as the available
recording time (max:10 hour) allows. The
recording time will be displayed on the
LCD monitor. Voice will still be recorded
if the shutter button is released.

- If you wish to stop recording, press the
shutter button again.

- File type : *.wav

Record

Back Move

Record Exit

[Voice recording mode]

45

Functions ( )



Pausing while recording a voice

Using this function, you can record your
favourite voice clips into a voice recording
fi le without having to create multiple voice
recording fi les.

1.

Press the OK button to pause recording.

2. Press the OK button again to resume the recording.

3. If you wish to stop recording, press the shutter button again.

A distance of 25cm between you and the camera (microphone)



is the best distance to record sound.
If the camera power is turned off while the voice recording is



paused, the voice recording is cancelled.

Stop Record

[Voice recording mode]

Recording the movie clip without voice

You can record the movie without voice.

Select [Off] of [Voice] menu in the Movie
clip mode. ( ) icon will appear on the
LCD monitor. Press the Shutter button
and a movie will record for as long as the
memory capacity allows without voice.

Off

Back Move

46

Sound menu

In this mode, you can set up sound settings. You can use the setup
menu in all camera modes, except Voice Recording mode.



The items indicated by * are default settings.

Ä

Menus are subject to change without prior notice.

)

(

Sound



Volume

You can select a volume of start up
sound, shutter sound, beep sound and AF
sound.

- [Volume] sub menu : [Off], [Low],
[Medium]*, [High]

Volume :Medium

Start Sound :Off

Shutter Sound :1

Beep Sound :1

AF Sound :On

Back Set

Off

Low

Medium

High

Start up sound

You can select the sound that is activated
whenever the camera is turned on.

- Start up sound : [Off]*, [1], [2], [3]

Volume :Medium

Start Sound :Off

Shutter Sound :1

Beep Sound :1

AF Sound :On

Back Set

Off

1

2

3

Shutter sound

You can select the shutter sound.

- Shutter sound : [Off], [1]*, [2], [3]

Volume :Medium

Start Sound :Off

Shutter Sound :1

Beep Sound :1

AF Sound :On

Back Set

Off

1

2

3

Beep Sound

If you set sound to ON, a beep will sound when buttons are
pressed, letting you know the camera operation status.

- [Beep Sound] sub menu : [Off], [1]*, [2], [3]

Volume :Medium

Start Sound :Off

Shutter Sound :1

Beep Sound :1

AF Sound :On

Back Set

Off

1

2

3

47

(

)

Sound



AF sound

If you set AF sound to on, AF sound will be activated when the
Shutter button is pressed down half way so that you can be aware
of the camera operation status.

- [AF sound] sub menu : [Off], [On]*

Volume :Medium

Start Sound :Off

Shutter Sound :1

Beep Sound :1

AF Sound :On

Back Set

Off

On

Setup menu

In this mode, you can set up basic settings. You can use the setup
menu in all camera modes, except Voice Recording mode.



The items indicated by * are default settings.

Ä

Menus are subject to change without prior notice.

Display ( )

Language

There is a choice of language that can be
displayed on the LCD monitor. Even if the
battery is removed and inserted again, the
language setting will be preserved.

Function Description

You can select whether the function description can be displayed
on the window in recording mode.

- Function Description sub menu
[Off] : The function description

function can’t be activated.

[On]* : The name and description of the

option is displayed.

Language :English

Function Description :On

Start Image :Off

Display Brightness :Auto

Quick View :0.5sec

Power Save :Off

Back Set

Language :English

Function Description :On

Start Image :Off

Display Brightness :Auto

Quick View :0.5sec

Power Save :Off

Back Set

English

䚐ạ㛨

Français

Deutsch

Español

Italiano

Off

On

48

Display ( )

Start up image

You can select the image that is fi rst displayed on the LCD monitor
whenever the camera is turned on.

- Sub menus : [Off]*, [Logo], [User Image]

- Use a saved image for the start-up
image with the [Start Image] in the
[Resize] menu in the play mode.

- The start-up image will not be deleted by
[Delete] or [Format] menu.

- The User images will be deleted by

Language :English

Function Description :On

Start Image :Off

Display Brightness :Auto

Quick View :0.5sec

Power Save :Off

Exit Back



Off



[Reset] menu.

Display Bright

You can adjust the LCD brightness.

- Sub menus : [Auto]*, [Dark],

[Normal], [Bright]

Language :English

Function Description :On

Start Image :Off

Display Brightness :Auto

Quick View :0.5sec

Power Save :Off

Back Set

Auto

Dark

Normal

Bright

Quick view

If you enable Quick View before capturing an image, you can view
the image you just captured on the LCD monitor for the duration
set in the [Quick View] setup. Quick view is possible only with still
images.

- Sub menus
[Off] : The quick view function can’t

be activated.

[0.5 sec]*, [1 sec], [3 sec]

: The captured image is briefl y

displayed during the selected
time.

Language :English

Function Description :On

Start Image :Off

Display Brightness :Auto

Quick View :0.5sec

Power Save :Off

Back Set

Off

0.5 sec

1 sec

3 sec

Display SAVE

If you set the [Power Save] to On and the camera isn't operated
during the specifi ed time, the LCD monitor will be turned off
automatically.

- Sub menus
[Off]* :

The LCD monitor will not be turned off.

[On] :

If the camera isn't operated
during the specifi ed time (about
30 SEC.), the camera power will
be idle (Camera status lamp:
Blinking) automatically.

Ä

You can’t set the [Power Save] menu of Playback Mode.

Language :English

Function Description :On

Start Image :Off

Display Brightness :Auto

Quick View :0.5sec

Power Save :Off

Back Set

Off

On

49

Settings

(” )

Formatting a memory

This is used for formatting the memory. If you run [Format] on the
memory, all images, including the protected images, will be deleted.
Be sure to download important images to your PC before formatting
the memory.

- Sub menus
[Yes] :

A window for confi rming the
selection displays. Select the [Yes]
menu. A [Formatting] message
appears and the memory will be
formatted. If you run FORMAT in
Play mode, a [Format is completed]
message will appear.

[No]* : The memory will not be formatted.



Be sure to run [Format] on the following types of memory card.

- A new memory card, or an unformatted memory card

- A memory card that has a fi le this camera can't recognise or one

that has been taken from another camera.

- Always format the memory card using this camera. If you insert a
memory card that has been formatted using other cameras,
memory card readers, or PCs, you will get a [Card Error]
message.

50

Format

Reset

Date & Time :

Time Zone :London

File No. :Series

Imprint :Off

Auto Power Off :3 min

Back Set

Yes

No

Off

Initialisation

All camera menu and function settings will be restored to their
default values. However, values for DATE / TIME, LANGUAGE,
and VIDEO OUT will not be changed.

- Sub menus

[Yes] : A window to confi rm the

selection will be displayed.
Select the [Yes] menu and
all settings will be restored
to their defaults.

[No]* : Settings will not be restored to

their defaults.

Format

Reset

Date & Time :Off

Time Zone :London

File No. :Series

Imprint :Off

Auto Power Off :3 min

Back Set

Yes

No

Settings

(” )

Setting up the Date / Time / Date type

You can change the date and time that will be displayed on the
captured images and set up the date type. Setting [Time Zone]
enables you to display the local date and time on the LCD monitor
when travelling overseas.

-

Date type : [yyyy/mm/dd], [mm/dd/yyyy],

[dd/mm/yyyy], [Off]*

Format

Reset

Date & Time :

yyyy mm dd

Time Zone :London

2009 / 08 / 01 13:00 Off

File No. :Series

Imprint :Off

Auto Power Off :3 min

Back Set

Off

Time Zone



Available cities:
London, Cape Verde, Mid-Atlantic,
Buenos Aires, Newfoundland, Caracas,
La Paz, NewYork, Miami, Chicago,
Dallas, Denver, Phoenix, LA, San Fran­cisco, Alaska, Honolulu, Hawaii, Samoa,
Midway, Wellington, Auckland, Okhotsk,
Guam, Sydney, Darwin Adelaide, Seoul,
Tokyo, Beijing, Hong Kong, Bankok, Jakarta, Yangon, Almaty,
Kathmandu, Mumbai, New Delhi, Tashkent, Kabul, Abu Dhabi,
Teheran, Moscow, Athens, Helsinki, Rome, Paris, Berlin

Ä

DST : Daylight Saving Time

Time Zone

London
[GMT +00:00] 2009/08/01 01:00 PM

Back DST

File name

This function allows the user to select the fi le naming format.

[Reset] : After using the reset function,

the next fi le name will be set
from 0001 even after formatting,
deleting all or inserting a new
memory card.

[Series]*

: New fi les are named using

numbers that follow the previous sequence, even when
a new memory card is used, or after formatting, or after
deleting all pictures.

- The fi rst stored folder name is 100PHOTO, and the fi rst fi le

name is SAM_0001.

- File names are assigned sequentially from SAM_0001
SAM_0002 ~  SAM_9999.

- The folder number is assigned sequentially from 100 to 999 as
follows: 100PHOTO  101PHOTO  ~  999PHOTO.

- Maximum numbers of fi les in a folder are 9999.

- The fi les used with the memory card conform to the DCF (Design
rule for Camera File systems) format. If you change the image
fi le name, the image may not play back.

Format

Reset

Date & Time :

Time Zone :London

File No. :Series

Imprint :Off

Auto Power Off :3 min

Back Set

Reset

Series

Off



51

Settings

(” )

Imprinting the recording date

There is an option to include DATE / TIME on still images.

- Sub menus
[Off]* : The DATE & TIME will not be

imprinted on the image fi le.

[Date] : Only the DATE will be

imprinted on the image fi le.

[Date & Time] : The DATE & TIME will be

imprinted on the image fi le.

Ä

The Date & Time are imprinted at the bottom right side of the still
image.

Ä

The imprint function is applied only to still images.

Ä

Depending on the manufacturer and print mode, the date printed
on an image may not be printed correctly.

Format

Reset

Date & Time :

Time Zone :London

File No. :Series

Imprint :Off

Auto Power Off :3 min

Back Set

Off

Date

Date & Time

Off

Auto power off

This function switches the camera off after a set amount of time in
order to prevent unnecessary battery drainage.

- Sub menus
[Off] : The power off function will not

operate.

[1 min], [3 min]*, [5 min], [10 min]

: The power will turn off

automatically if not used for the
period of time specifi ed.

-

After replacing the battery, the power off setting will be preserved.

- Note that the automatic power off function will not operate if the

camera is in the PC / Printer mode, slide show, playing back a
voice recording and playing back a movie clip.

Format

Reset

Date & Time :Off

Time Zone :London

File No. :Series

Imprint :Off

Auto Power Off :3 min

Back Set

Off

1 min

3 min

5 min

10 min

52

Settings

(” )

Selecting Video out type

The Movie output signal from the camera can be NTSC or PAL.
Your choice of output will be governed by the type of device
(monitor or TV, etc.) to which the camera is connected. PAL
mode can support only BDGHI.



Connecting to an external monitor

When the camera is connected to an

external monitor, the image and menus
on the LCD monitor will be visible on the
external monitor and the LCD monitor of
the camera.

Yellow - Video
White - Sound

Video Out :NTSC

AF Lamp :On

USB :Auto

Battery Type :Alkaline

Back Set

NTSC

PAL

- NTSC : U.S.A, Canada, Japan, South Korea, Taiwan, Mexico.

- PAL : Australia, Austria, Belgium, China, Denmark, Finland,

Germany, U.K., Holland, Italy, Kuwait, Malaysia, New
Zealand, Singapore, Spain, Sweden, Switzerland,
Thailand, Norway.

- When using a TV as an external monitor, you will need to select
the external or AV channel of the TV.

- There will be a digital noise on the external monitor, but it is not a

malfunction.

- If the image is not in the centre of the screen, use the TV controls
to centre it.

- When the camera is connected to an external monitor, some parts
of the image may not be displayed.

- When the camera is connected to an external monitor, the menu
will be visible on the external monitor and the menu functions are
the same as those indicated on the LCD monitor.

53

Settings

(” )

Auto Focus lamp

You can turn on and off the Auto Focus lamp.

- Sub menus
[Off] : The AF lamp will not light up in

low light conditions.

[On]*

: The AF lamp will light up in low

light conditions.

Video Out :NTSC

AF Lamp :On

USB :Auto

Battery Type :Alkaline

Back Set

Off

On

Setting the USB

If the camera is set to connect automatically to a PC or a printer
using a USB cable, you can manually set [Computer] or [Printer].

-[USB] sub menus:
[Auto]* : Automatically enables an

external device connected
with a USB cable.

[Computer] :

Sets computer connection
mode if the connected external
device cannot be recognized
automatically.

[Printer] :

Sets printer connection mode if the connected external

Video Out :NTSC

AF Lamp :On

USB :Auto

Battery Type :Alkaline

Back Set

Auto

Computer

Printer

device cannot be recognized automatically.

Selecting a battery type

If a battery type is selected, the camera will be optimized according
to the selected battery type.

[Battery Type] sub Menu : [Alkaline]* / [Ni-MH]

Video Out :NTSC

AF Lamp :On

USB :Auto

Battery Type :Alkaline

Back Set

Alkaline

Ni-MH

54

Starting play mode

Turn the camera on and select Play mode by pressing the play
mode button ( Î ). The camera can now play back the images
stored in the memory.
If the memory card is inserted in the camera, all the camera
functions apply only to the memory card.
If the memory card is not inserted in the camera, all the camera
functions apply only to the internal memory.

Playing back a still image

1. Select the PLAY mode by pressing
the play mode button ( Î ).

2. The last image stored on the

memory is displayed on the
LCD monitor.

3. Select an image that you want to

view by pressing the Left/ Right
button.

Ä

Press and hold the Left or Right
button to play back the images
quickly.

Playing back a movie clip

1. Select the recorded movie clip that
you want to play back by using the
Left/Right button.

2. Press the OK button to play back a
movie clip file.

- To pause a movie clip file while playing
it back, press the OK button again.

- Pressing the OK button again will
cause the movie clip file to restart.

To rewind the movie clip while it is

­playing, press the Left button. To
fast forward the movie clip, press
the Right button.

- To stop playback of the movie clip,
press the OK button, and then press the Left or Right button.

Play Capture

55

Starting play mode

Movie clip capture function

You can capture still images from the movie clip.



How to capture the movie clip

1. Press the OK button while playing the
movie clip. Then press the Down button.

2. The paused movie clip is saved in a

new file name.

Ä

The captured movie clip file is the

same size as the original movie clip
(640x480, 320x240).

Ä

When you press the down button at
the beginning of the movie clip, the
first frame of the movie clip will be
saved as a still image.

Play Capture

[Press the down button]

[Paused]

Playing back a recorded voice

1.

Select the recorded voice that you want to
play back by using the Left/Right button.

2. Press the OK button to play back a
recorded voice file.

- To pause a recorded voice file, while
playing it back, press the OK button
again.

- To resume playback of the voice file, press the OK button.

- To rewind the voice file while it is playing, press the Left button.
To fast forward the voice file, press the Right button.

- To stop playback of the voice memo, press the Down button.

Play

56

Starting play mode

Playing back a voice memo

1. Select a still image that has the voice
memo.

2. Press the OK button to play back the
voice memo.

- To pause the voice memo, while
playing it back, press the OK button
again.

- To resume playback of the voice memo,

press the OK button.

LCD monitor Indicator

The LCD monitor displays shooting information about the displayed image.

Play

Pause

No. Description Icon Page

1 Playback mode

2 Voice Memo

3 DPOF

4 Protect p.72
5 Folder name & File name 100-0010 p.51

6 Memory card indicator

7 Battery

8 ISO 80~1600 p.37
9 Aperture value F2.8 ~ F6.1 -

10 Shutter speed 8 ~ 1/2,000 -

11 Flash On/Off p.30
12 Image size 3648X2736 ~ 1024X768 p.40
13 Recording date 2009/08/01 p.51

Î

p.55

p.72

p.73

-

p.13

57

Using the camera buttons to set the camera

In Play mode, you can use the buttons on the camera to conveniently
set up the Play mode functions.

Thumbnail ( º ) / Enlargement ( í ) button

Smart Album

You can view multiple pictures, enlarge a selected picture, and crop
and save a selected area of an image.

Play mode button



If you have turned on the camera by
pressing the POWER button, you can
press the Play mode button once to
switch to Play mode and press it again
to switch to Recording mode.



You can turn the power on with the Play

1. Once a picture has been played back,

2. Press the Left/Right button to move to

3. Press the Digital Zoom button to return

mode button. The camera is turned on in
play mode. Press the Play mode button
again to turn off the camera.



Manner mode: To select the Manner mode, press the Play mode

button for more than 3 seconds. In the Manner
mode, Operating sound, Effect sound, Start-up
sound and Shutter sound will not be generated. To
cancel the Manner mode, turn on the camera by
pressing the POWER button.

press the Thumbnail button to run
Smart Album mode.

a desired image.

to the normal display mode.

Pressing the thumbnail

button ( º )

Pressing the enlargement

button ( í )

[Highlighted image]

1 31 31211 5

Filter 2009/08/01

[Smart Album

3-Thumbnail Window]

58

Thumbnail ( º ) / Enlargement ( í ) button



Searching or Deleting Files

1. Press the Thumbnail button in Smart
Album.

2. Each time you press the Thumbnail but­ton, the fi les in a category are displayed
in Smart Album screen.

3. Select the fi le by pressing the Up/Down/ Left/Right buttons.

4. Press the Delete ( Õ ) button to delete the selected fi le.

1 31 31211 5

Filter 2009/08/01

[3-Thumbnail Window]

Ɣ When Smart Album feature runs or a category is selected, it

may take few seconds depends on recorded data volume.
However, it is not a malfunction please wait until Smart Album
screen appears.

1 31 31211 5

Filter 2009/08/01

[9-Thumbnail Window]

1 31 31211 5

Filter 2009/08/01

[20-Thumbnail Window]

Ŷ Smart Album Filter

1. Press the MENU button in Smart
Album mode.

2.

Selecting the desired category enables
to categorize and search the fi les by
using the Up/Down button.

Type

Date

Colour

Week

1 31 31211 5

Back Set

ŶDetails of Each Category

Category Description File Format

Type

Date

Colour Categorized depending on the main color.

Week

Categorized depending on the fi le type
(e.g., picture, video, or voice)

Categorized depending on the sequence
of recorded dates.

Videos, Voice

Categorized depending on the sequence
of recorded weeks.

Pictures,

59

Thumbnail ( º ) / Enlargement ( í ) button



Image enlargement

1. Select an image that you want to
enlarge and press the enlargement
button.

2. Different parts of the image can be
viewed by pressing the 5 function
button.

3. Pressing the thumbnail button will
zoom back to the original full sized
image.

- You can tell whether the image
displayed is an enlarged view by
checking the image enlargement
indicator shown at the top left of
the LCD monitor. (If the image is not an enlarged view,
the indicator will not be displayed.) You can also check the
area of enlargement.

- Movie clips and WAV files can’t be enlarged.

- If an image is enlarged, a loss of quality may occur.

Trim



The maximum enlargement rate in proportion to the image size

Image size

Maximum

enlargement

rate



Trimming : You can extract part of the image that you want and

X10.2 X10.1 X8.1 X9.6 X8.1 X6.4 X3.2

save it separately.

1.

Select an image that you want to

enlarge and press the enlargement
button. Press the OK button and a
message will be displayed.

2. Select a desired sub menu by
pressing the Up / Down button
and press the OK button.

Trimming?

Confirm

Yes
No

- [Yes] : The trimmed image will be saved as a new file name,
and appear on the LCD monitor.

- [No] : The trimming menu will disappear.

Ä

If there is not enough memory space to save the trimmed

image, the image can’t be trimmed.

60

Info (DISP) / Up button

Play & Pause / OK button

When the menu is displayed on the LCD monitor, the UP button
operates as a direction button.
When the menu is not displayed on the LCD monitor, pressing the
Info button will display image information on the LCD monitor.

Info (DISP) button

Info (DISP) buttonInfo (DISP) button

In Play mode, the play & pause/ OK button works as follows:

When the menu is displayed on the LCD monitor, the OK button

-
is used for confirming data that is changed by using the 5 function
button.

- If a still image with a voice memo, a voice file, or a movie clip is
playing

·In Stop mode : Plays a still image with a voice memo, a

·During playback : Temporarily stops playback.

·In Pause mode : Resumes playback

[ Voice recording is stopped ]

voice file, or a movie clip.

Play StopPause StopPlay

[ Voice recording is playing ] [ Voice recording is paused ]

61

Left / Right / Down / MENU button

Delete

(Õ )

button

LEFT / RIGHT / DOWN / MENU buttons activate the following.

- LEFT button : While the menu is showing, the LEFT button
operates as a direction button. While the menu is
not showing, press the LEFT button to select the
previous image.

- RIGHT button : While the menu is showing, the RIGHT button
operates as a direction button. While the menu
is not showing, press the RIGHT button to select
the next image.

- DOWN button :

While the menu is showing, the DOWN button
operates as a direction button.

- MENU button :

When you press the MENU button, the play mode
menu will be displayed on the LCD monitor. Pressing
it again will return the LCD to the initial display.

62

This deletes images stored on the memory card.

1. Select an image that you want to delete by pressing the
Left / Right button and press the DELETE ( Õ ) button.

Delete File?

Yes
No

Multiple Delete

Set

[Single Image] [Thumbnail Image]

Delete File?

Set

Yes
No

Multiple Delete

1 31 31211 5

2. To add images to delete, select the [Multiple Delete] menu.

- Left/Right button : Selects images

- OK button :

checks for deletion

- Fn button : deletes the
selected images.

Prev Next

Select Delete

3. Select the submenu values by pressing the Up / Down button
and then press the OK button.

- If [Yes] is selected : deletes the selected images.

- If [No] is selected : cancels "Delete Image".

Setting up the play back function using the LCD monitor

PLAY mode functions can be changed by using the LCD monitor.
In the PLAY mode, pressing the MENU button displays the menu
on the LCD monitor. The menus you can set up in Play mode are
as follows. To capture an image after setting up the play menu,
press the PLAY mode button or shutter button.

Menu Tab Main Menu Sub Menu Page

2592X1944 2048X1536

1024X768 2592X1728

1800X1200 2592X1458

1920X1080 Start Image

Right 90˚ Left 90˚

Vertical -

Normal Soft

Vivid Forest

Retro Cool

Calm Classic

Negative Custom

ACB Red-eye Fix

Face Retouch Brightness

Contrast Saturation

Add Noise -

Single, 3, 9, 20 p.69

All Date

Select -

p.65

p.66180˚ Horizontal

p.66

p.67

p.70

Edit

( )

View

()

Multi Slide

Show

)

(



Resize

Rotate

Photo Style

Selector

Image Adjust

Start Play / Repeat - p.69

Images

Menu Tab Main Menu Sub Menu

Off Calm -

Sweet Rural -

Vivid Lively -

Shine Relax -

Off Mist -

Muse Fall -

Dawn Party -

Drops Trip -

Select -

All Yes / No

Select -

All Unlock / Lock

Off -

On -

Standard

Index Yes / No

Size

Yes

No

Multi Slide

Show

)

(



File

Options

( )

Effect

Interval 1, 3, 5, 10 sec - p.71

Music

Delete

Protect

Voice memo

DPOF

Copy To Card

Secondary Menu

Select / All / Reset

Select / All / Reset

-

-

Page

p.70

p.71

p.71

p.72

p.72

p.73

~

p.74

p.75

63

Setting up the play back function using the LCD monitor

This menu is available while the camera is connected to a PictBridge
supporting printer (direct connection to the camera, sold separately)
with a USB cable.

Menu Tab Main Menu Sub Menu Secondary Menu Page

Images

Size

❹

Layout

One Photo -

All Photos -

Auto -

PostCard -

Card -

4X6 -

L-

2L -

Letter -

A4 -

A3 -

Auto -

Full -

1-

2-

4-

8-

9-

16 -

Index -

p.77

p.77

Menu Tab Main Menu Sub Menu Secondary Menu Page

Type

Quality

❹

Date

File Name

Reset

Menus are subject to change without prior notice.

Ä

Auto -

Plain -

Photo -

FastPhoto -

Auto -

Draft -

Normal -

Fine -

Auto -

Off -

On -

Auto -

Off -

On -

Yes -

No -

p.77

p.78

64

Edit ( )

Resize

Change the resolution (size) of pictures taken. Select [Start image]
to save an image to be the start-up image.

1. Press the play mode button and
press the MENU button.

2. Click the Up/Down button from the
Edit menu to select [Resize] ( )
menu tab and press the OK button.

3. Select a desired sub menu by
pressing the Left / Right button and
press the OK button.



Image Resize Types ( o : Selectable)

oooo

oooo

ooo

ooo

ooo

Resize

Back Move

oo

o

- A large sized image can be resized to a smaller sized image,
but not vice versa.

- Only JPEG images can be resized. Movie clip (AVI), Voice

recording (WAV) files can’t be resized.

- You can change the resolution of only those files compressed in

the JPEG 4:2:2 format.

- The resized image will have a new file name. The [Start

Image] image is stored not on the memory card but on the
internal memory.

- If a new user image is saved, one of the two user images will be

deleted in order.

- If the memory capacity is insufficient to store the resized image,

a [Memory Full] message will appear on the LCD monitor and
the resized image can't be stored.

65

Edit ( )

Rotating an image Photo Style Selector

You can rotate the stored images by various degrees.

1. Press the play mode button and press
the MENU button.

2.

Click the Up/Down button from the Edit

Rotate

menu to select [Rotate] ( ò ) menu tab
and press the OK button.

3. Select a desired sub menu by pressing
the Left / Right button and press the

Back Move

OK button.

180˚Left 90˚Right 90˚

Back MoveBack MoveBack Move

: Right 90˚]

[

ô

: Rotate picture in a

clock-wise direction

[ : Horizontal]
: Rotate picture horizontally

[ó : Left 90˚]
: Rotate picture in a

counter-clock-wise direction

VerticalHorizontal

Back MoveBack Move

[® : Vertical]
: Rotate picture vertically

[õ : 180˚]
: Rotate picture 180 degrees

If you display the rotated image on the LCD monitor, empty

spaces may appear to the left and right of the image.

66

It is possible to add various effects to your images by using this function.

1. Press the play mode button and
press the MENU button.

2.

Click the Up/Down button from the

Edit menu to select [Photo Style
Selector ] ( ) menu tab and press

the OK button.

3.

Select a desired sub menu by pressing

the Left / Right button and press the
OK button.

Style mode Icon Description

Normal

Soft

Vivid

Forest

Retro

Cool

Calm

Classic

Negative

Custom RGB

4. The changed image is saved as a new file name.

Photo Style Selector

Back Move

No style effect is applied.

Soft style is applied.

Vivid style is applied.

Forest style is applied.

Sepia style is applied.

Cool style is applied.

Calm style is applied.

Black & white effect is applied.

Negative effect is applied.

Defi ne an RGB tone to create your own photo style.

Edit ( )



Custom colour

You can change the R (Red), G (Green)
and B (Blue) values of the image.

- OK button : Select / setup the Custom
Colour

- Up / Down button : Selects R, G, B

- Left / Right button : Change the values

Image Adjust

1. Press the play back button and press the MENU button.

2.

Click the Up/Down button from the Edit menu to select
[Image Adjust] ( ) menu tab and press the OK button.



ACB

You can automatically adjust the brightness of the dark area,
caused by under exposure to the light source.

1. Select ( ) by pressing the Left/Right

button and press the OK button.

2. The [Making New Image] message is

displayed and the image is saved as a
new file name.

Back Move

Back Move

ACB

Back Move



Red eye Removal

Red eye effect can be removed from the captured image.

1. Select (  ) by pressing the Left/Right
button and press the OK button.

2. The [Making New Image] message is
displayed and the image is saved as a

Red-eye Fix

new file name.

Back Move



Face Retouch

You can make the skin in an image appear clear and beautiful.

1. Select ( ) by pressing the
Left/Right button and press the OK
button. Then a bar for selecting the
face retouch will be displayed.

Face Retouch

2. Change the face retouch by pressing the
Left/Right button.

3. Press the OK button and the image will

Back Move

be saved as a new file name.

67

Edit ( )



Brightness control

You can change the brightness of the image.

1. Select ( ) by pressing the
Left/Right button and press the OK
button. Then a bar for selecting the
brightness will be displayed.

2. Change the brightness by pressing the

Left/Right button.

3. Press the OK button and the image will

be saved as a new file name.



Contrast control

You can change the contrast of the image.

1. Select (  ) by pressing the Left/Right

button and press the OK button. Then
a bar for selecting the contrast will be
displayed.

2. Change the contrast by pressing the

Left/Right button.

3. Press the OK button and the image will be

saved as a new file name.

Brightness

Back Move

Contrast

Back Move



Saturation control

You can change the saturation of the image.

1. Select ( ) by pressing the Left/Right
button and press the OK button. Then
a bar for selecting the saturation will be
displayed.

Saturation

2. Change the saturation by pressing the
Left/Right button.

3. Press the OK button and the image will be

Back Move

saved as a new file name.



Noise effect

You can add noise to an image to add a more classic feel to
your photo.

1. Select ( )

by pressing the Left/Right

button and press the OK button.

2. The [Making New Image] message is
displayed and the image is saved as a

Add Noise

new file name.

Back Move

68

View ( )

You can view the thumbnails and easily categorize or search a large
amount of content such as pictures and videos.

1. Press the MENU button in playback
mode.

2. Press the Up/Down button to select
the desired menu.

3. Press the OK button and selected
thumbnail screen will appear.

Single

3

9

20

Exit Back

Starting the Multi Slide Show

( )

Images can be displayed continuously at pre-set intervals.
You can view the Multi Slide Show by connecting the camera to an
external monitor.

1. Press the play mode button and press the menu button.

2. Press the Up / Down button and select the [Multi Slide Show]
menu tab and press the OK button.

Start the Multi Slide Show

The Multi Slide Show can start only in the [Start] menu.

1. Use the Up / Down buttons to select the [Start] menu and press
the Right button.

2. Select a desired sub menu by pressing
the Up / Down button.

[Play] : The Multi Slide Show is

closed after one cycle.

[Repeat] : The Slide show is repeated

until cancelled.

3. Press the OK button and the slideshow will be started.

- To pause the slide shown while playing it back, press the OK
button again.

- Pressing the OK button again will cause the Multi Slide Show
restart.

- To stop playback of the Multi Slide Show, press the OK button,
and then press the Left or Right button.

Start

Images :All

Effect :Off

Interval :1 sec

Music :Off

Back Set

Play

Repeat

69

Starting the Multi Slide Show

( )

Selecting Images

You can select image to view

1. Use the Up / Down buttons to select the
[Images] menu and press the Right button.

2. Select a desired sub menu by pressing
the Up / Down button.

[All] : All images saved in the

Memory are played back.
Press the OK button to save the configuration.

[Date] : Images taken in a specified date are played back.

Press the OK button to save the configuration.

[Select] :

Play only the selected images. The selected image
can be saved as [Select1], [Select2] and [Select3].
If you save the selected image with the [New Select]
command, it will be saved as [Select1]. But when a
new image is saved again using [New Select], the
former image which had been saved as [Select1] will
be saved as [Select2] automatically.You can change
and cancel the images which were saved as [Select1],
[Select2] and [Select3].
Press the Fn button to save the configuration.

3. Select [Play] or [Repeat] in the [Start] menu to start the multi
slide show.

Start

Images :All

Effect :Off

Interval :1 sec

Music :Off

Back Set

All

Date

Select

Configure Multi Slide show effects

Unique screen effects can be used for the Multi Slide Show.

1.

Select the [Effect] sub menu by press-

ing the UP / DOWN button and press
the RIGHT button.

2. Use the Up / Down button to select
the type of effect.

3. Press the OK button to confirm the
setting.

Start

Images :All

Effect :Off

Interval :1 sec

Music :Off

Back Set

Off

Calm

Sweet

Rural

Vivid

Lively

70

Starting the Multi Slide Show

( )

Setting play interval

Set the Multi Slide Show play interval.

1. Select the [Interval] sub menu by
pressing the UP / DOWN button and
press the RIGHT button.

2. Use the Up / Down buttons to select
the desired interval.

3. Press the OK button to save the
configuration.

The loading time depends on the image size and quality.



While the Multi Slide Show is playing, only the first frame



Start

Images :All

Effect :Off

Interval :1 sec

Music :Off

Back Set

of a MOVIE file is displayed.
While the Multi Slide Show is playing, the voice recording file



will not display.
The interval menu functions in the [Off] menu only.



Setting Background Music

Set the Multi Slide Show music.

1. Select the [Music] sub menu by pressing
the UP / DOWN button and press the
RIGHT button.

2. Use the Up / Down buttons to select the
desired Music.

3. Press the OK button to save the

configuration.

Start

Images :All

Effect :Off

Interval :1 sec

Music :Off

Back Set

1 sec

3 sec

5

10 sec

Off

Mist

Muse

Fall

Dawn

Party

File Options

( )

1. Press the play mode button and press the menu button.

2. Press the Up / Down button and select the [File Options] menu
tab and press the OK button.

Deleting images

sec

This deletes images stored on the memory.

1. Press the Up / Down button and select
the [Delete] menu tab. And then press
the Right button.

2. Select a desired sub menu by pressing the

UP / DOWN button and press the OK button.

[Select] : Selection window for an image

to delete is displayed.

Delete

Protect

Voice memo :Off

DPOF

Copy To Card

Back Set

Select

All

- Up/ Down/ Left/ Right : Select an image

- OK button : Select the image for
deletion. ( Ë mark)

- Fn Button : Press the Fn button to display

the confirmation message.
Select the [Yes] menu and

1 31 31211 5

Select Delete

press the OK button to delete
marked images.

[All] :

Displays confirmation window.

Select the [Yes] menu and press the
OK button to delete all unprotected
images. If there aren’t protected
images, all the images are deleted

Delete All File(s)?

Set

Yes
No

and a [No Image File] message will appear.

3. After deletion, the screen will be changed to the play mode screen.

71

File Options



Of all the files stored in the memory card, the unprotected files

( )

in the DCIM subfolder will be deleted. Remember that this
will permanently delete unprotected images. Important shots
should be stored on a computer before deletion takes place.
The startup image is stored in the camera's internal memory
(i.e., not on the memory card) and it will not be deleted even if
you delete all files on the memory card.

Protecting images

This is used to protect specific shots from being accidentally erased (Lock).
It also unprotects images that have been previously protected (Unlock).

1. Press the Up / Down button and select
the [Protect] menu tab. And then press
the Right button.

2. Select a desired sub menu by pressing the
UP / DOWN button and press the OK button.

[Select ] : Selection window for an

image to be protected /
released is displayed.

- Up / Down / Left / Right : Select an image

- OK button : Protect / release the

- Fn button : Your changes will be

saved and the menu will
disappear.

Delete

Protect

Voice memo :Off

DPOF

Copy To Card

Back Set

Select Set

Select

All

1 31 31211 5

Voice memo

You can add your voice to a stored still image.

- Press the shutter button to record up to 10 seconds of voice into

- To stop the recording, press the shutter button.

[All] : Protect / release all saved images

- If you protect an image, the protect
icon will be displayed on the LCD
monitor. (An unprotected image has
no indicator)

- An image in LOCK mode will be
protected from the delete function
or [Delete] functions, but will NOT be
protected from the [Format] function.

Delete

Protect

Voice memo :Off

DPOF

Copy To Card

Back Set

Off

On

Start Stop

[Ready for recording] [Voice is recording][Voice memo menu]

a stored still image.

Set

Protect All?

Lock

Unlock

72

File Options

( )

DPOF



DPOF(Digital Print Order Format) allows you to embed printing
information on your memory card’s MISC folder. Select the
pictures to be printed and how many prints to make.



The DPOF indicator will display on the LCD monitor when an image
that has DPOF information plays back. Images can then be printed
on DPOF printers, or at an increasing number of photo labs.



This function is not available for Movie clips and Voice recording files.



When the wide angle image is printed as a wide angle print, 8%
of the left and right side of the image may not be printed. Check
that your printer can support the wide angle image when you print
the image. When you print the image at a photo lab, request that
the image is printed as a wide angle image. (Some photo labs
may not support the wide angle size print.)



Standard

This function allows you to embed printing quantity information on
a stored image.

1. Press the Up / Down button and select
the [DPOF] menu tab. And then press
the Right button.

2. Press the Right button again and
[Standard] sub menu will display.

3. Select a desired sub menu by pressing

Delete

Protect

Select Image

Voice memo :Off

Select

DPOF

Copy To Card

Back Set

Reset

Standard

All

Index

Size

the Up / Down button and press the OK
button.

[Select] : Selection window for an

image to print is displayed.

- Up / Down / Left / Right : Select an
image to print.

- Zoom button : Select the number of

1 31 31211 5

Quantity Set

prints.

[All] : Configure number of prints for all

pictures except movie and voice

01

files.

- Up / Down button : Select a number of

prints

Quantity Set

[Reset] : Cancel the print setup.

4. Press the OK button to confirm the setting. If an image carries
DPOF instructions, the DPOF indicator ( ) will show.

73

File Options



Index

( )

Images (except for movie clips and voice file) are printed as index

type.

1. Press the Up / Down button and select
the [DPOF] menu tab. And then press
the Right button.

2. Select the [Index] menu and press
the Right button again. Sub menu will
display.

Delete

Protect

Voice memo :Off

Setting Index?

DPOF

Yes

Standard

No

Copy To Card

Back Set

Index

Size

3. Select a desired sub menu by pressing the UP / DOWN button.

If [Yes] is selected : The image will be printed in index format.
If [No] is selected : Cancel the index print setting.

4. Press the OK button to confirm the setting.

74



Print size
You can specify the print size when printing images stored on the
memory card. The [Size] menu is available only for DPOF 1.1
compatible printers.

1. Press the Up / Down button and select
the [DPOF] menu tab. And then press
the Right button.

2. Select the [Size] menu and press the
Right button again. Sub menu will
display.

Delete

Protect

Select Image

Voice memo :Off

Select

DPOF

Copy To Card

Back Set

Reset

Standard

All

Index

Size

3. Select a desired sub menu by pressing
the UP / DOWN button and press the
OK button.

[Select] : Selection window to change

the printed size of the image
is displayed.

- Up / Down / Left / Right : Select an image.

1 31 31211 5

Size Set

- Zoom W/T Button : Change the print size.

- Fn button : Your changes will be
saved and the menu will

3X5

disappear.

[All] : Change print size of all saved

images.

Size Set

- Up / Down button : Select a print size

- OK button : Confirm the changed setting.

[Reset] : Cancel all of the print size settings.

Ä

DPOF [Size] secondary menu : Cancel, 3X5, 4X6, 5X7, 8X10

Depending on the manufacturer and print model, cancelling the



printing may take a little longer for the printer to process.

File Options

( )

Copy To Card

This enables you to copy image files, movie clips and voice recording
files to the memory card.

1. Select the [Copy To Card] menu tab by
pressing the Up / Down button. And then
press the Right button.

2. Select a desired sub menu by pressing
the UP/ DOWN button and press the OK
button.

- [Yes] :

All images, movie clips and voice
recording files saved in the internal memory are copied
to the memory card after the [Copying] message is
displayed. After copying has been completed, the screen
will return to play mode.

- [No] : Cancels "Copy to Card".

Delete

Protect

Voice memo :Off

DPOF

Copy To Card

Back Set

Yes

No

If there is not enough space available in the memory card to



copy saved images in the internal memory (About 7MB), the
[Copy To Card] command will copy only some of the images
and display [Memory Full] message. Then the system will
return to the playback mode. Please be sure to delete any
unnecessary files to free up space before inserting the memory
card into the camera.
When you move the images that are stored in the internal



memory by doing [Copy To Card] to the card, the next number
of file names will be created in the card to avoid duplication of
the file name.

- When the [Reset] of the [File No.] setup menu is set : The
copied file names start from after the last stored file name.

- When the [Series] of the [File No.] setup menu is set : The

copied file names start from after the last captured file name.
After completing [Copy To Card], the last stored image of the
last copied folder is displayed on the LCD monitor.

75

PictBridge

You can use the USB cable to connect this camera to a printer that
supports PictBridge (sold separately) and print the stored images
directly. Movie clips and voice files cannot be printed.



Setting up the camera for connection to the printer

1. Connect the camera and printer with USB cable.

2. Once the camera is turned on, the camera automatically
recognizes the printer and is connected to it.

Ä

If automatic connection fails, set the [USB] menu to [Printer].
(p.54)

Ä

For a printer that can enable removable disks, set the [USB]
menu to [Printer].



Connecting the Camera to a Printer



Easy printing

When you connect the camera to printer

in the Play back mode, you can print a
picture easily.

- Pressing the Left / Right button :
Selects a previous / next image.

- Pressing the OK button :
Currently displayed image will be

printed with the printer’s default setting.

Print Menu

76

PictBridge : Picture Selection

PictBridge : Print Setting

You can select images you want to print.



Setting the Number of Copies to Print

1. Press the Menu button and the
PictBridge menu will display.

2. Use the Up / Down buttons to
select the [Images] menu and
press the Right button.

Images :One Photo

Size :Auto

Layout :Auto

Type :Auto

Quality :Auto

Back Set

One Photo

All Photos

3. Use the Up / Down buttons to select a desired sub menu and
press the OK button.

- Select [One Photo] or [All Photos]. A screen where you can
set the number of copies to print will appear as shown below.

0

Quantity Set

[When [One Photo] is selected]

[When [All Photos] is selected]

1

Quantity Set

- Press the Up / Down button to select the number of prints.

- When [One Photo] is selected : Use the Left / Right button to
select another picture. After
selecting another picture, select
the number of prints for another
picture.

- After setting the number of prints, press the OK button to save.

- Press the Shutter button to return to the menu without setting

the number of prints.

4. Press the play mode button ( Î ) and images will be printed.

You can select the Paper Size, Print Format, Paper Type, Print
Quality, Date Print, and File Name Print menus for printed pictures.

1. Press the Menu button and the
PictBridge menu will display.

2. Use the Up / Down buttons to select
the desired menu, and then press the
Right button.

3. Use the Up / Down buttons to select
the desired sub menu value, and then

Images :One Photo

Size :Auto

Layout :Auto

Type :Auto

Quality :Auto

Back Set

Auto

Postcard

Card

4x6

L

2L

press the OK button.

Menu Function Sub menu

Size

Layout

Type

Quality

Set the size of the printing
paper

Set the number of pictures to
be printed on a sheet of paper

Set the quality of the printing
paper

Set the quality of the picture
to be printed

Auto, PostCard, Card,
4X6, L, 2L, Letter, A4, A3

Auto, Full, 1, 2, 4, 8, 9,
16, Index

Auto, Plain, Photo,
FastPhoto

Auto, Draft, Normal, Fine

Date Set whether to print the date Auto, Off, On

File Name

Ä

Set whether to print the file name

Some menu options are not supported on all printers.

Auto, Off, On

If not supported, the menus are still displayed in the LCD, but are not
selectable.

77

PictBridge : Reset

Initialises user-changed configurations.

1. Use the Up / Down buttons to select
the [Reset] menu tab. And then press
the Right button.

2. Use the Up / Down buttons to select
the desired sub menu value, and then
press the OK button.

If [Yes] is selected : All print and image settings will be reset.
If [No] is selected : Settings will not be reset.

Ä

Default print setting varies depending on the printer manufacturer.

For your printer’s default setting, refer to the user’s guide that
came with your printer.

78

Date :Auto

File Name :Auto

Reset No

Back Set

Important notes

Be sure to observe the following precautions!



This unit contains precision electronic components. Do not use or
store this unit in the following locations.

Yes

No

- Areas exposed to severe changes in temperature and humidity.

- Areas exposed to dust and dirt.

- Areas exposed to direct sunlight or the inside of a vehicle in hot
weather.

- Environments where there is high magnetism or excessive vibration.

- Areas with high explosives or highly flammable materials.



Do not leave this camera in places subject to dust, chemicals (like
naphthalene and mothballs), high temperature and high humidity.

Keep this camera with silica gel in a hermetically sealed box when
not planning to use the camera for a long period of time



Sand can be particularly troublesome to cameras.

- Do not let sand get inside the camera when using it on beaches,

coastal dunes, or other areas where there is lots of sand.

- Doing so may result in failure or may permanently render the

camera unusable.



Handling the camera

- Never drop the camera or subject it to severe shocks or vibrations.

- Protect the large size LCD monitor from an impact. When this

camera is not used, keep it in the camera case.

- Avoid obstructing the lens or the flash when you capture an image.

- This camera is not waterproof.

To avoid dangerous electrical shocks, never hold or operate the
camera with wet hands.

- If you use this camera in wet places, such as beach or pool,

do not let water or sand get inside the camera. Doing so may
result in failure or may permanently damage the unit.

Important notes



Extremes in temperature may cause problems.

- If the camera is transferred from a cold to a warm and humid
environment, condensation can form on the delicate electronic
circuitry. If this occurs, turn the camera off and wait for at least
1 hour until all moisture is dispersed. Moisture built up can also
occur on the memory card. If this happens, turn off the
camera and remove the memory card. Wait until the moisture
has dispersed.



Caution on Using the Lens

- If the lens is subjected to direct sunlight, it could result in the
discoloration and deterioration of the image sensor.

- Take care not to get fingerprints or foreign substances on the
surface of the lens.



If the digital camera is not used for a long period, an electric
discharge can occur. It is a good idea to remove the battery and

the memory card if you do not intend using the camera for an
extended period of time.



If the camera is exposed to an electronic interference, it will turn
itself off to protect the memory card.



Camera Maintenance

- Use a soft brush (available from photo stores) to gently clean the
lens and LCD assemblies. If this does not work, lens-cleaning
paper with lens cleaning fluid can be used.
Clean the camera body with a soft cloth. Do not allow this
camera to come into contact with solvent materials such as
benzol, insecticide, thinners etc. This may damage the body
shell of the camera and also affect its performance. Rough
handling can damage the LCD monitor. Take care to avoid
damage and keep the camera in its protective carry case at all
times when not in use.



Do not attempt to disassemble or modify the camera.



Under certain conditions, static electricity can cause the flash unit
to fire. This is not harmful to the camera and is not a malfunction.



When images are uploaded or downloaded, the data transfer may
be affected by static electricity. In this case, disconnect and re-

connect the USB cable before trying the transfer again.



Before an important event or going on a trip, you should check
the camera condition.

- Take a picture for testing the camera condition and prepare extra battery.

- Samsung cannot be held responsible for camera malfunctions.



If the digital camera is not used for a long period, the date and time
may adopt the default settings by automatical battery discharged. In

this case, reset the date and time correctly before the recording.

79

Warning indicator

There are several warnings that may appear on the LCD display.

[Card Error]



Memory card error



Turn off the camera power and turn it on again



Insert the memory card again



Insert and format the memory card (p.50)

[Card Locked]



The memory card is locked



SD/SDHC memory card : Slide the write protect switch to the

[Memory Full]



The memory card or internal memory is full.



Insert new memory card.



Delete the unnecessary image files

[No Image File]



There are no images stored on the memory



Take images



Insert a memory card that is holding some images

80

top of the memory card

[File Error]



File error



Delete the file.



Memory card error



Contact a camera service centre.

[Low Battery]



There is low battery capacity



Insert fresh batteries.

Before contacting a service centre

Please check the following Camera does not take images when pressing the Shutter button

The camera doesn’t switch on



There is low battery capacity



Insert fresh batteries. (p.13)



Battery is inserted incorrectly with the polarities reversed.



Insert the battery according to the polarity marks (+, -).

The camera power ceases while in use



The battery is exhausted



Insert fresh batteries.



The Camera is turned off automatically



Turn on the camera power again.



Operation has ceased in a low temperature outside of the camera
usage temperature range.



Make the camera and battery warm by placing them in your
pocket, etc. and then immediately before shooting, place the
battery in the camera and then shoot.



There is insufficient memory capacity



Delete unnecessary image files



The memory card has not been formatted



Format the memory card (p.50)



The memory card is exhausted



Insert a new memory card



The memory card is locked



Refer to [Card Locked] error message



The camera's power is off



Turn the camera power on



The battery is exhausted



Insert fresh batteries (p.13)



Battery is inserted incorrectly with the polarities reversed.



Insert the battery according to the polarity marks (+, -)

The camera suddenly stops working while in use



The camera stopped due to a malfunction



Remove /re-insert battery and switch the camera on

The images are unclear



A picture was taken of the subject without setting an appropriate
macro mode



Select an appropriate macro mode to take a clear image.



Taking a picture beyond the flash range



Take a picture within the flash range



The lens is smudged or dirty



Clean the lens

81

Before contacting a service centre

The flash does not fire



Flash off mode has been selected



Dis-engage flash off mode



The camera mode can't use the flash



Refer to the FLASH instruction (p.30)

Incorrect date and time is displayed



The date and time have been set incorrectly or the camera has
adopted the default settings



Reset the date and time correctly

The camera buttons do not operate



Camera malfunction



Remove/re-insert battery and switch the camera on

A card error has occurred while the memory card is in the camera.



Incorrect memory card format



Re-format the memory card

The images don't play back



Incorrect file name (Violation of DCF format)



Do not change the image file name

Colour of image is different to the original scene



White balance or effect setting is incorrect



Select appropriate White balance and effect

Images are too bright



Exposure is excessive



Reset exposure compensation

82

No image on external monitor



The external monitor has not been connected properly with
the camera



Check the connection cables



There are incorrect files in the memory card



Insert a memory card that has correct files

When using the PC’s explorer, the [Removable Disk] file does not show



Cable connection is incorrect



Check the connection



The camera is off



Turn the camera on



The operating system is not Windows 2000, XP, Vista / Mac OS

10.3. Alternatively the PC does not support USB



Install Windows 2000, XP, Vista / Mac OS 10.3 to PC that
supports USB

A part of the LCD screen does not occasionally turn on or a spot appears.



Although the LCD screen is manufactured with high precision
technology, the precision pixels are not occasionally lighted or the
red, white and blue spots appear.

ĺ

This phenomenon does not affect the quality of the recorded
image and it is not a malfunction.

A vertical line appears on the LCD screen when taking a picture of a
bright object.



If a subject is exposing bright lights, a gray, black, red or purple
vertical line may appear.

ĺ

This is a phenomenon called smear and it does not affect the
quality of the recorded image. This is not a malfunction.

Specifications

Image Sensor - Type : 1/2.33" CCD

- Effective Pixel : Approx. 10.2 Mega-pixel

- Total Pixel : Approx. 10.3 Mega-pixel

Lens -

- F No. : F2.8(W) ~ F6.1(T)

- Digital Zoom : ·Still Image mode :1.0X ~ 5.0X

·Play mode : 1.0X ~ 10.2X
(depends on image size)

LCD Monitor - 2.5" color TFT LCD (230,000 dots)

Focusing - Type : TTL auto focus (Multi AF, Center AF,

- Range

Wide

Tele 50cm ~ 80cm 50cm ~ Infinity

Shutter - Auto : 1 ~ 1/2,000 sec., Program : 1 ~ 1/2,000 sec.,

Exposure - Control : Program AE

- Metering : Multi, Spot, Center-Weighted,

- Compensation : ±2EV (1/3EV steps)

- ISO : Auto, 80, 100, 200, 400, 800, 1600

Focal Length : SAMSUNG Lens f = 6.0 ~ 24.0mm

(35mm film equivalent : 34mm ~ 136mm)

Face Detection AF)

Normal Macro Auto Macro

80cm ~ Infinity

10cm ~ 80cm 10cm ~ Infinity

Night : 8 ~ 1/2,000 sec., Firework : 2 sec.

Face Detection AE

Flash - Modes : Auto, Auto & Red-eye reduction, Fill-in

flash, Slow sync, Flash off, Red Eye Fix

- Range : Wide : 0.4m ~ 3.5m,
Tele : 0.5m ~ 2.0m

- Recharging Time : Approx. 5 sec.

Sharpness - Soft+, Soft, Normal, Vivid, Vivid+

White Balance - Auto, Daylight, Cloudy, Fluorescent_H,

Fluorescent_L, Tungsten, Custom

Voice Recording - Voice Recording (max. 10 hours)

- Voice Memo in Still Image (max. 10 sec.)

Date Imprinting - Date, Date & Time, Off (user selectable)

Shooting - Still Image

·Mode : Smart Auto, Auto, Program, DIS,
Photo Help Guide, Scene

·Scene : Beauty Shot, Frame Guide,

Night,
Portrait, Children, Landscape, Close-up,
Text, Sunset, Dawn, Backlight, Firework,
Beach & Snow

·Shooting : Single, Continuous, Motion Capture, AEB

·Self-timer : 10 sec., 2 sec., Double,
Motion Timer

Ä Smart Auto : Macro, Macro Text, White,

Landscape, Action, Tripod,
Night, Night Portrait, Backlight,
Backlight Portrait, Portrait

83

Specifications

- Movie Clip

·Size : 640x480, 320x240

· Frame rate : 30 fps, 15 fps

·4X Optical Zoom and Mute in Zooming

Storage - Media

·Internal memory : About 7MB flash memory

· External Memory (Optional) :

- File Format

·Still Image : JPEG (DCF), EXIF 2.21, DPOF 1.1,

·Movie Clip : AVI (MJPEG)

·Audio : WAV

- Image Size

3648X

2736

·

With Audio or without Audio
(user selectable, recording time : max 2 hours)

·Movie Editing (Embedded):
Still Image Capture, Time Trimming

MMC card (Up to 2GB guaranteed)
SD card (Up to 4GB guaranteed)
SDHC card (Up to 8GB guaranteed)

PictBridge 1.0

3648X

3648X

3072X

2592X

2432

2052

2304

2048X

1944

1536

1024X

768

- Capacity (1GB Size)

Super

About

About

About

About

About

About

Fine

218

240

281

290

365

About

About

About

About

Fine

303

340

394

About

About

Normal

506

Ä

These figures are measured under Samsung standard conditions and

548

About

616

411

About

657

About

506

About

822

850

About

1120

About

1263

About

1892

About

2185

About

2397

may vary depending on shooting conditions and camera settings.

Effect

- Effect : Photo Style Selector, Image Adjust
(Sharpness, Contrast, Saturation)

-

Editing :

Resize, Rotate, Photo Style Selector,
Image Adjust (ACB, Red-eye Fix, Face
Retouch, Brightness, Contrast, Saturation,
Add Noise)

Image Play - Type : Single image, Thumbnails,

Multi slide show, Movie Clip, Smart Album

Interface - Digital output connector : USB 2.0

- Audio : Mono

- Video output : NTSC, PAL (user selectable)

84

Specifications

Power Source

- Rechargeable battery

Dimensions (WxHxD) - 96.4 x 62.3 x 27.2mm

Weight - Approx. 125g (without batteries and card)

Operating Temperature - 0 ~ 40°C

Operating Humidity - 5 ~ 85%

Software - Samsung Master, Adobe Reader

Specifications are subject to change without prior notice.

All trademarks are the property of their respective owners.

- Primary Battery : 2x AA Alkaline

: SNB-2512B KIT (Optional)

(2xAA Ni-MH Battery & Charger)

Ä

Included battery may vary depending on
sales region.

(excluding protrusions)

85

Software Notes

System Requirements

Please ensure that you read the instruction manual carefully before use.

- Under no circumstances should all or part of either the software
or the user manual be reproduced.

- Copyrights for software are licensed only for use with a camera.

- In the unlikely event of a manufacturing fault, we will repair or
exchange your camera.
We cannot, however, be held responsible in any way for damage

Connection

Specifi cations

caused by inappropriate use.

- Using a Hand-made PC or a PC and OS that has not been
guaranteed by the manufacturer is not covered by the Samsung
warranty.

- Before reading this manual, you should have a basic knowledge
of computers and O/S (Operating Systems).

Specifi cations

Ä
Ä

86

For Windows For Macintosh

PC with processor better
than Pentium III 500MHz

USB

(Pentium III 800MHz recommended)
Windows 2000 / XP / Vista
Minimum 256MB RAM
(Over 512MB recommended)
250MB of available hard disk
space (Over 1GB recommend)

Software

1024x768 pixels, 16bit color

Support

display compatible monitor
(24bit color display recommended)
Microsoft DirectX 9.0c or later

Power Mac G3 or later
Mac OS 10.3 or later

Minimum 256MB RAM
(Over 512MB recommended)
110MB of available hard disk
space

-

It is not compatible with Windows XP and Vista 64-bit Edition.
Samsung is not responsible for any defects or damages caused
by the use of unauthorized computer including an assembled PC.

About the software

After inserting the CD-ROM provided with this camera into the
CD-ROM drive, the following window should automatically run.



Samsung Master : This is the all-in-one multi media software

You can download, view, edit and save your digital images and
movie clips with this software. This software is only compatible
with Windows.

solution.



You should allow 5 ~ 10 seconds for running the automatic
setup program according to the capability of your computer.
If the frame does not appear, run the [Windows Explorer] and
select [Installer.exe] in the CD-ROM Drive root directory.

87

Setting up the application software

To use this camera with a PC, install the application software first.
After this has been done, the stored images in the camera can be
moved to the PC and can be edited by an image editing program.



You can visit the Samsung web-site through the internet.

http://www.samsung.com

1. The auto run frame will display.

Click the [Samsung Digital
Camera Installer] menu in the
Auto run frame.

88

2. Install DirectX, Samsung Master by selecting a button shown on
the monitor. If a recent version of DirectX has been installed on
your computer, DirectX may not be installed.

Setting up the application software

3. After restarting the computer, connect the PC to the camera with
the USB cable.

4. Turn the camera power on.
The [Found New Hardware Wizard]
will open and the computer will
recognise the camera.

Ä

If your OS is Windows XP/ Vista, an image viewer program will
open.

89

Setting up the application software

PDF documents of user manual are included in the Software



CD-ROM supplied with this camera. Search the PDF files with
Windows explorer. Before opening the PDF files, you must
install the Adobe Reader included in the Software CD-ROM.
Install Adobe Reader from the CD provided. If the Internet is
not enabled, install Adobe Reader by using the executable file
located in the CD.
To install the Adobe Reader 6.0.1 correctly, Internet Explorer



5.01 or later has to be installed. Visit "www.microsoft.com" and
upgrade the Internet Explorer.

Starting PC mode

If you connect the USB cable to a USB port on your PC and then
turn on the power, the camera will automatically switch to "computer
connection mode". In this mode, you can download stored images
to your PC through the USB cable.



Camera settings for connection

1. Turn on the camera.

2. Connect the camera and computer with the supplied USB
cable.

3. Once the camera is turned on, the camera automatically
recognizes the computer and is connected to it.

Ä

If automatic connection fails, set the [USB] menu to [Computer].
(p.54)

90

Starting PC mode



Connecting the camera to a PC



Disconnecting the camera and PC

Refer to page 93 (Removing the removable disk).



Downloading stored images

You can download the still images stored on the camera to your PC's

hard disk and print them or use a photo editing software to edit them.

1. Connect the camera to your PC with the USB cable.

2. On your computer's desktop display,
select [My computer] and double
click [Removable Disk  DCIM
100PHOTO].The image files will
then be displayed.

3. Select an image and press the right
mouse button.



91

Starting PC mode

4. A pop-up menu will open.
Click the [Cut] or [Copy] menu.

- [Cut] : cuts a selected file.

- [Copy] : copies files.

5. Click a folder where you want to paste the file.

6. Press the right mouse button and a
pop-up menu will open.
Click [Paste].

7. An image file is transferred from the
camera to your PC.

92

- By using [Samsung Master], you can see the stored images in the
memory directly on the PC monitor and you can copy or move the
image files.

We recommend that you should copy the images to the PC to



view them. Opening images directly from the removable disk
may be subject to unexpected disconnection.
When you upload a file that is not taken by this camera to the



Removable Disk, the [File Error] message will be displayed on
the LCD monitor in the PLAY mode, and nothing is displayed in
THUMBNAIL mode.

Removing the removable disk



Windows 2000/XP/Vista
(The illustrations may differ from those shown depending on the
Windows O/S.)

1. Check whether the camera and PC are transferring a file.
If the camera status lamp blinks, please wait until the lamp has
finished blinking and is constantly on.

2. Double-click the [Unplug or Eject
Hardware] icon on the task bar.

[Double-click!]

3. The [Unplug or Eject Hardware]
window will open. Select the [USB
Mass Storage Device] and click the
[Stop] button.

4. The [Stop a Hardware device]
window will open. Select the [USB
Mass Storage Device] and click the
[OK] button.

5. A [Safe to Remove Hardware] window
will open. Click the [OK] button.

6. A [Unplug or Eject Hardware] window
will open. Click the [Close] button and
the removable disk will be removed
safely.

7. Unplug the USB cable.

93

Samsung Master

You can download, view, edit and save your images and movies
with this software. This software is only compatible with Windows.
To start the program, click [Start  Programs Samsung
Samsung Master].



Downloading images

1. Connect the camera to your PC.

2. A window for downloading images
will be displayed after connecting
the camera to your PC.

- To download the captured images,
select the [Select All] button.

- Select desired folder in the
window and click the [Select All]
button. You can save captured
images and selected folder.

- If you click the [Cancel] button, downloading will be cancelled.

3. Click [Next >] button.

94



4. Select a destination and make
a folder to save downloaded
images and folders.

- Folder names can be made in
order of date and images will be
downloaded.

- Folder name will be made as
you want and images will be
downloaded.

- After selecting a folder that was
made before, images will be
downloaded.

5. Click [Next >] button.

6. A window will open as shown
alongside.
The destination of the selected
folder will be displayed on the
upper side of the window.
Click the [Start] button to
download the images.

7. Downloaded images will be
displayed.

Samsung Master



Image viewer : You can view the stored images.

- Image viewer functions are listed below.

Ì

Menu bar : You can select menus. File, Edit, View, Tools,

Í

Image selection window : You can select the desired images



Media type selection menu : You can select image viewer, image edit



Preview window : You can preview an image or a movie clip and



Zoom bar : You can change preview size.



Folder display window : You can see the folder location of the



Image display window : Images of the selected folder are displayed.

Ä

Refer to the [Help] menu in Samsung Master for further information.

Change functions, Auto download, help, etc.

in this window.

and movie edit functions in this menu.

check the multi media information.

selected image.



Image edit : You can edit the still image.

- Image edit functions are listed below.

Ì

Edit menu : You can select the following menus.

[Tools] : You can resize or crop the selected image. See the

[Adjust] : You can modify image quality. See the [Help] menu.
[Retouch] : You can change image or insert effects on the image.

Í

Drawing tools : Tools for editing an image.



Image display window : A selected image displays in this window.



Preview window : You can preview the changed image.

Ä

A still image edited with Samsung Master can’t be played back on
the camera.

Ä

Refer to the [Help] menu in Samsung Master for further information.

[Help] menu.

See the [Help] menu.

95

Samsung Master



Movie edit : You can get the still image, movie clip, narration,

- Movie clip edit functions are listed below.

Ì

Edit menu : You can select the following menus.
[Add Media] : You can add other media elements to a movie.
[Edit Clip] : You can change the brightness, contrast, colour

[Effects] : You can insert an effect.
[Set Text] : You can insert texts.
[Narrate] : You can insert a narration.
[Produce] : You can save the edited multi media as a new file

Í

Frame display window : You can insert multi media in this window.

96

music files together in a movie clip.

and saturation.

name. You can select AVI, Windows media (wmv)
and Windows media (asf) file types.

Ä

Some movie clips that were compressed with a codec that is
not compatible with the Samsung Master can’t play back in the
Samsung Master.

Ä

Refer to the [Help] menu in Samsung Master for further information.

Setting up the USB Driver for MAC

1. A USB Driver for MAC is not included with the software CD as
MAC OS supports the camera driver.

2. Check the MAC OS version during start-up. This camera is com­patible with MAC OS 10.3.

3. Connect the camera to the Macintosh and turn the camera power
on.

4. A new icon will be displayed on the desktop after connecting the
camera to the MAC.

1. Double click a new icon on the desktop and the folder in the

2. Select an image file and copy or move it to MAC.

Using the USB Driver for MAC

memory will be displayed.

First complete uploading from computer to camera and then



remove the removable disk with the Extract command.

97

FAQ

Please check the following if the USB connection malfunctions.

Case 1 USB cable is not connected or it is not the supplied

Case 2 The camera is not recognised by your PC.

Case 3 There is an unexpected error during file transfer.

Case 4 When using the USB hub.

Case 5 Are other USB cables connected to the PC?

USB cable.



Connect the supplied USB cable.

Sometimes, the camera may appear under [Unknown
Devices] in Device Manager.



Turn off the camera, remove the USB cable, plug in the
USB cable again, and then turn on the camera.



Turn the camera power off and on again. Transfer the
file again.



There may be a problem in connecting the camera to
the PC through the USB hub if the PC and the hub are
not compatible. Wherever possible, connect the camera
to the PC directly.



The camera may malfunction when it is connected to
the PC at the same time as another USB cable. In this
case, disconnect the other USB cable, and connect
only one USB cable to the camera.

Case 6 When I open the Device Manager (by clicking Start

Case 7 In some security programs (Norton Anti Virus, V3,

Case 8 The camera is connected to the USB port located on

(Settings) Control Panel (Performance and Main­tenance) System (Hardware) Device Manager),
there are Unknown Devices or Other Devices entries
with a yellow question mark(?) beside them or devices
with an exclamation mark(!) beside them.



Right-click on the entry with the question (?) or exclamation
(!) mark and select "Remove". Restart the PC and connect
the camera again.

etc.), the computer may not recognise the camera as a
removable disk.



Stop the security programs and connect the camera to
the computer. Refer to the security program instructions
about how to temporarily disable the program.

the front of the computer.



When the camera is connected to the USB port located
on the front of the computer, the computer may not
recognise the camera. Connect the camera to the USB
port located on the back of the computer.

98

FAQ



When the DirectX 9.0c or later is not installed



Install the DirectX 9.0c or later

1) Insert the CD provided with the camera

2) Run the windows explorer and select the [CD-ROM drive:\
DirectX] folder and click the DXSETUP.exe file.
The DirectX will be installed. Visit the following site for
downloading the DirectX.http://www.microsoft.com/directx



If a PC connected with the camera stops responding while
Windows is starting.



In this case, disconnect the PC and the camera and Windows
will start. If the problem happens continuously, set the Legacy
USB Support to disable and re-start the PC. The Legacy USB
Support is in the BIOS setup menu. (The BIOS setup menu
differs from the PC manufacturers and some BIOS menus don’
t have Legacy USB Support) If you can’t change the menu by
yourself, contact to the PC manufacturer or BIOS manufacturer.



If the movie clip can’t be deleted, or the removable disk can’t be
extracted or an error message displays during the file transfer.



If you install only the Samsung Master, the problems mentioned
above occasionally happen.

- Close the Samsung Master program by clicking the Samsung
Master icon on the Taskbar.

- Install all the application programs included in the software CD.

Samsung Eco-mark

It is Samsung’s own symbol mark is used to effectively
communicate Samsung’s environmental friendly product
activities to the consumers. The mark represents
Samsung’s continuous effort on development of
environmental conscious products.

99
