SAMSUNG SGH-E600 Service Manual Exploded View & Part List
3. SGH-E600/E608 Exploded View and its Part list
1. Cellular phone Exploded View
13
12
14
1
2
3
15
16
17
18
19
23
24
25
22
9
20
21
10
11
4
5
6
7
8
27
26
3-1
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
2. Cellular phone Parts list
SGH-E600/E608 Exploded view and its Part list
Location
NO.
1 MEC CAMERA RING ASS'Y GH75-03822A
2 PMO DUAL WINDOW GH72-10580A GH72-10580B
3 MEC F/UPPER GH75-03801A
4 LCD GH07-00471A
5 MICRO SPEAKER 3001-001481
6 MOTOR GH31-00075A
7 MEC F/LOWER GH75-03817A
8 MEC MAIN WINDOW GH75-03820A
9 UNIT CAMERA GH59-01175A
10 SCREW 6001-001479
11 LABEL SCREW HOLE COVER GH68-02948A
12 MEC FRONT COVER GH75-03800A
13 MEC CAMERA KEY ASS'Y GH75-03825A
Description
SEC CODE
(SGH-E600)
SEC CODE
(SGH-E608)
Remark
14 MEC VOL KEY ASS'Y GH75-03824A
15 MEC KEYPAD ASS'Y GH75-03821A GH75-03821B
16 MAIN PBA GH92-01608A GH92-01714A
17 UNIT METAL DOME GH59-01145A
18 UNIT VOL KEY GH59-01147A
19 ANTENNA GH42-00365A
20 MICROPHONE ASS'Y GH30-00075A
21 IF COVER GH72-10589A
22 EAR JACK COVER GH72-10587A
23 MEC REAR COVER GH75-03823A GH75-04277A
24 R/F COVER GH72-11998A
25 SCREW 6001-001478
26 REAR SCREW CAP GH72-11991A
27 BATTERY
GH43-01138A GH43-01238A 700MAH
GH43-01139A GH43-01239A 900MAH
3-2
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
