Samsung SCP-3430H User Manual

Smart Dome Camera

User Manual

SCP-3430H

2_ overview

overview

CAUTION

RISK OF ELECTRIC SHOCK.

DO NOT OPEN

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER
(OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.

This symbol indicates that dangerous voltage consisting a risk of
electric shock is present within this unit.

This symbol indicates that there are important operating and
maintenance instructions in the literature accompanying this unit.

WARNING

To reduce the risk of fire or electric shock, do not expose this appliance to rain or
moisture.

To prevent injury, this apparatus must be securely attached to the floor/wall in
accordance with the installation instructions.

Use only the 24V, 60Hz AC adaptor for power supply.

WARNING

Be sure to use only the standard adapter that is specified in the specification sheet.
Using any other adapter could cause fire, electrical shock, or damage to the
product.

Incorrectly connecting the power supply or replacing battery may cause explosion,
fire, electric shock, or damage to the product.

Do not connect multiple cameras to a single adapter. Exceeding the capacity may
cause abnormal heat generation or fire.

Securely plug the power cord into the power receptacle. Insecure connection may
cause fire.







1.

2.

3.

4.

English _3

● 

When installing the camera, fasten it securely and firmly. The fall of camera may
cause personal injury.

Do not place conductive objects (e.g. screwdrivers, coins, metal parts, etc.) or
containers filled with water on top of the camera. Doing so may cause personal
injury due to fire, electric shock, or falling objects.

Do not install the unit in humid, dusty, or sooty locations. Doing so may cause fire
or electric shock.

If any unusual smells or smoke come from the unit, stop using the product. In such
case, immediately disconnect the power source and contact the service center.
Continued use in such a condition may cause fire or electric shock.

If this product fails to operate normally, contact the nearest service center. Never
disassemble or modify this product in any way. (SAMSUNG is not liable for
problems caused by unauthorized modifications or attempted repair.)

When cleaning, do not spray water directly onto parts of the product. Doing so may
cause fire or electric shock

Do not expose the product to the direct airflow from an air conditioner.
Otherwise, it may cause moisture condensation inside the Clear Dome due to
temperature difference between internal and external of the dome camera.

If you install this product in a low-temp area such as inside a cold store, you must
seal up the wiring pipe with silicon, so that the external air can not flow inside the
housing.
Otherwise, external high, humid air may flow inside the housing, pooling moisture
or vapor inside the product due to a difference between internal and external
temperature.

5.

6.

7.

8.

9.

10.

11.

12.

overview

4_ overview

CAUTION

Do not drop obje.cts on the product or apply strong blows to it. Keep away from a
location subject to excessive vibration or magnetic interference.

Do not install in a location subject to high temperature (over 50°C), low temperature
(below -10°C), or high humidity. Doing so may cause fire or electric shock.

If you want to relocate the already installed product, be sure to turn off the power
and then move or reinstall it.

Remove the power plug from the outlet when there is a lighting storm. Neglecting
to do so may cause fire or damage to the product.

Keep out of direct sunlight and heat radiation sources. It may cause fire.

Install it in a place with good ventilation.

Avoid aiming the camera directly towards extremely bright objects such as sun, as
this may damage the CCD image sensor.

Apparatus shall not be exposed to dripping or splashing and no objects filled with
liquids, such as vases, shall be placed on the apparatus.

The Mains plug is used as a disconnect device and shall stay readily operable at
any time.

When using the camera outdoors, moisture may occur inside the camera due
to temperature difference between indoors and outdoors. For this reason, it is
recommended to install the camera indoors. For outdoor use, use the camera with
built-in fan and heater.

1.

2.

3.

4.

5.

6.

7.

8.

9.

10.

English _5

● 

FCC STATEMENT

This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions :

1) This device may not cause harmful interference, and

2) This device must accept any interference received including interference that may
cause undesired operation.

CAUTION

This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated
in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to
correct the interference at his own expense.

IC Compliance Notice

This Class A digital apparatus meets all requirements of the Canadian
Interference.-Causing Equipment Regulations of ICES-003.

overview

6_ overview

IMPORTANT SAFETY INSTRUCTIONS

Read these instructions.

Keep these instructions.

Heed all warnings.

Follow all instructions.

Do not use this apparatus near water.

Clean only with dry cloth.

Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.

Do not install near any heat sources such as radiators, heat registers, or other
apparatus (including amplifiers) that produce heat.

Do not defeat the safety purpose of the polarized or grounding-type plug.
A polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade or the third prong
is provided for your safety. If the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.

Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.

Only use attachments/accessories specified by the manufacturer.

Use only with the cart, stand, tripod, bracket, or table specified
by the manufacturer, or sold with the apparatus. When a
cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.

Unplug this apparatus during lightning storms or when unused
for long periods of time.

Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as powersupply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.

Apparatus shall not be exposed to dripping or splashing and no objects
filled with liquids, such as vases, shall be placed on the apparatus

1.

2.

3.

4.

5.

6.

7.

8.

9.

10.

11.

12.

13.

14.

English _7

● 

CONTENTS

OVERVIEW

2

6 important safety instructions
7 contents
8 Features
8 What’s Included
9 At a Glance

INSTALLATION &

CONNECTION

10

10 Optional Accessories for

Installation

12 precautions
12 Preparation
13 Installation
16 Initial Setup
19 Connecting With Other Device

SETUP

22

22 How to use the keyboard

controller

23 Main Menu
24 Profile
26 Camera Set
35 Intelligent Video
37 Privacy Zone
38 Preset
40 Auto Set
44 Zone Set
45 Alarm Set
47 Clock Set
47 Other Set
49 Communication
50 System Info

APPENDIX

49

49 Shortcut Keys
50 Specifications
52 Product Appearance

overview

8_ overview

FEATURES

With the state-of-the-art digital signal processing technology, full digital image
processing and special algorithm of 600-line high resolution implemented

High performance surveillance camera, equipped with x43 zoom lens and digital
zoom IC, enabling monitoring up to 688 times

WDR to cover the full screen irregardless of its brightness
DAY/NIGHT to improve the sensitivity by automatic conversion into the black and

white mode at night or in the environment with low illumination
White Balance to control the brightness to the illumination
Backlight Compensation under spotlight or utmost bright illumination
Auto Focus to automatically adjust the focus to the subject movement
Privacy zone to hide a specific area for personal privacy
PAN/TILT for precise control at high speed

WHAT’S INCLUDED

Please check if your camera and accessories are all included in the product package.

Camera Housing Connectors

User Manual

User Manual Grease Pin & Bush














English _9

● 

AT A GLANCE

CAMERA

FRAME SET

Wipe out a dirty surface of the lens softly with a lens tissue or cloth to which you
have applied ethanol.

M



LENS

HOOK

HOOK

ALARM IN

ALARM OUT

RS-485

POWER
INPUT

10_ installation & connection

installation & connection

OPTIONAL ACCESSORIES FOR INSTALLATION

For your easier installation, you can purchase appropriate optional accessories available.

WALL MOUNT ADAPTOR (SCX-300WM)
This is a wall mount adaptor, used for wall­mounted installation of SMART DOME
CAMEA units.

CEILING MOUNT ADAPTOR (SCX-300CM)
This is a ceiling mount adaptor, used for
installation of SMART DOME CAMEA units on
a concrete ceiling.

POLE MOUNT ADAPTOR (SCX-300PM)
This is an adaptor for WALL MOUNT
ADAPTOR (SCX-300WM) installation on a
pole whose diameter is bigger than 80mm.

1.

2.

3.

English _11

● 

CORNER MOUNT ADAPTOR (SCX-300KM)
This is an adaptor for WALL MOUNT
ADAPTOR (SCX-300WM) installation on the
corner of wall joint.

PARAPET (LONG) MOUNT (SCX-300LM)
This is a mounting kit used for installation of
SMART DOME CAMEA units on a parapet.

4.

5.

installation & connection

12_ installation & connection

PRECAUTIONS

Select an installation spot which can endure more than 4 times of the product
weight.

When installing, prevent peoples approaching to avoid personal injury.
Move valuables to a safer place before installing.

PREPARATION

Run all the external cables through the bracket adaptor’s PIPE or MOUNT hole.
Wrap around the HOUSING’s screw hole with the Teflon Tape.

1.

2.

PIPE OR

MOUNT

1.5" PT

EXTERNAL

CABLE

1.5" PT

TEFLON TAPE

HOUSING

English _13

● 

INSTALLATION

Press the SNAP FIT of the ADAPTOR in the HOUSING to open the ADAPTOR
part, and then insert all external cables into the HOUSING. Secure the HOUSING
on the PIPE or MOUNT by turning it clockwise.
(Secure two components tightly, to avoid loosened HOUSING.)

Connect external cables to the CONNECTORS(ALARM IN, POWER, RS-485,
ALARM OUT) and connect the CONNECTOR to the ADAPTOR.
Insert the cable into the FRAME SET, and close the ADAPTOR.

Then, wrap the BNC JACK with the INSULATION TUBE, and use an insulation tape
to seal up the end of the INSULATION TUBE so that the BNC JACK does not
protrude outside of the INSULATION TUBE coating.
For more information about cable connection, refer to Connecting the adaptor
cable. (page 19)

1.

2.

M



PIPE OR

MOUNT

HOUSING

EXTERNAL

CABLE

ADAPTOR

SNAP-FIT

PIPE OR

MOUNT

HOUSING

HOUSING

EXTERNAL

CABLE

ADAPTOR

BNC JACK

INSULATION
TUBE

ALARM OUT

ALARM IN

RS-485

POWER INPUT

installation & connection

14_ installation & connection

Note that BUSHINGs are provided for outdoor installations where exposed to a
moisture condition through the PIPE or MOUNT, install the HOUSING using the
BUSHING to prevent moisture entering.

- Apply grease of proper dose on the BUSHING before assembling, and run
cables through each hole of the bushings. Use PINS to stop up empty holes
having no cable running.

- Assemble the

BUSHING to the top side of HOUSING’s inside as shown in the
diagram below. At the moment, apply pressure evenly on the BUSHING to
secure it tightly to the HOUSING as shown in the diagram.

BUSH

BUSH

ETC CABLE

POWER
(24V) CABLE

BNC CABLE

BUSH

BUSH

PIN



BUSH

HOUSING

PIPE OR
MOUNT

BUSH

HOUSING

English _15

● 

Tie up the SAFETY WIRE of the CAMERA on the BRACKET WIRE of the FRAME
SET.

Arrange the 22P CONNECTOR of the CAMERA in line with that of the ADAPTOR,
push the HOOKs on either end of the CAMERA in the RACK direction of the
FRAME SET to secure the two.
Then, ensure that all of the two HOOKs clicks to fix to the RACK properly.

When the installation is completed, remove the PROTECTIVE COVER and
PRETOECTIVE TAPE from the lens.

Align each of the 3 SCREWS of COVER DOME and 3 SCREW HOLEs of the
HOUSING respectively, and assemble the COVER DOME and HOUSING. During

the assembling, note on the followings.

Insert and arrange SAFETY WIRE into the HOUSING while not disturbing the
camera operation.

Ensure that the GASKET DOME component does not separate from the

COVER DOME

. (If the GASKET DOME is not properly assembled, it damages

the waterproofness.)

3.

M



4.





22P CONNECTOR

HOUSING

RACK

RACK

BRACKET WIRE

FRAME SET

SAFETY WIRE

HOOK

HOOK

CAMERA

PROTECTIVE

COVER

PROTECTIVE

TAPE

SCREWS

HOUSING

COVER DOME

COVER DOME

GASKET DOME

CAMERA

HOUSING

SAFETY WIRE

installation & connection

16_ installation & connection

INITIAL SETUP

Camera Address Setup

Use SW606, SW605, and SW604 to specify the camera address.
You can specify between 0 and 255 for the address, where the hundreds digit is
with SW606, the tens digit with SW605, and the ones digit with SW604.
ex) Camera address: If the address is 1, follow the steps in the figure below.

Communication Protocol Setup

Use pins #1~#4 of SW603 to specify the communication protocol.





    

A OFF OFF OFF OFF OFF

B ON OFF OFF OFF OFF
C OFF ON OFF OFF OFF
D ON ON OFF OFF OFF
E OFF OFF ON OFF OFF

--- ON OFF ON OFF OFF

--- OFF ON ON OFF OFF
H ON ON ON OFF OFF

I OFF OFF OFF ON OFF

J ON OFF OFF ON OFF

--- OFF ON OFF ON OFF

--- ON ON OFF ON OFF

--- OFF OFF ON ON OFF
N ON OFF ON ON OFF
O OFF ON ON ON OFF
P ON ON ON ON OFF
Q OFF OFF OFF OFF ON
R ON OFF OFF OFF ON

A : SAMSUNG HALF
B : SAMSUNG FULL

<Bottom of the camera holder>

SW606

(x100)

SW605

(x10)

SW604

(x1)

English _17

● 

Baud Rate Setup

Use pins #5, #6 of SW603 to set the baud rate.

BAUD RATE PIN 5 PIN 6

4800 BPS ON ON

9600 BPS OFF ON

19200 BPS ON OFF

38400 BPS OFF OFF

The factory default is 9600 BPS.

Setting RS-422A/RS-485 Termination

As it is shown in the structure map, when Controller and RS-422A/RS-485 is
connected, it should be terminated according to the Cable feature of impedance
on the each end of the transmitting line to transfer the signals in long distance by
controlling the reflection of the signals to the lowest.

Termination : Using numbers 1 and 2 PIN, turn to <ON> and it will be terminated.

Controller

Termination

n < 32

Termination
SW1-ON

CAM n

CAM n-1

CAM 2

CAM 1

TX+(DATA+)
TX-(DATA-)

RX-

RX+

RX+ RX- RX+ RX- RX+ RX-

<RS-485 Half Duplex Organization>

installation & connection

18_ installation & connection

A communication error may occur if you connect multiple cameras that are assigned
the same address in the network.

M



Controller

Termination

n < 32

Termination
SW1-ON
SW2-ON

CAM n

CAM n-1

CAM 2CAM 1

<RS-422A/RS-485 Full Duplex Organization>

English _19

● 

CONNECTING WITH OTHER DEVICE

Connecting to a monitor

Connect one end of the BNC
video cable connector to the
Video Output Terminal (VIDEO
OUT).

Connect the other end of the
connector to the Video Input
Terminal of the monitor.

1.

2.

Video terminal on the
rear of monitor

BNC Cable

MONITOR

ALARM IN

POWER SOURCE

ALARM OUT

CONTROLLER/DVR

installation & connection

20_ installation & connection

To connect ALARM IN

Connect one end of the external device's signal line to a corresponding ALARM
IN port of the monitor.

Connect the other end of the signal line to the earth-grounding [GND] port.

To connect ALARM OUT

Connect one end of the external device's signal line to a corresponding ALARM
OUT port of the monitor.

Connect the other end of the signal line to the common [COM] port.

To connect the controller

Connect an external controller or DVR to the camera, with which you can adjust the
camera.

Connect the Rx+ pin of the
camera to the Tx+ pin of the
controller.

Connect the Rx- pin of the
camera to the Tx- pin of the
controller.

Connect the Tx+ pin of the
camera to the Rx+ pin of the
controller.

Connect the Tx- pin of the
camera to the Rx- pin of the
controller.

1.

2.

1.

2.

1.

2.

3.

4.

TxRx

English _21

● 

Connecting the adaptor cable

Power Supply

Connect the cables as necessary, and turn on the camera to check if it works
properly.

Connect the adaptor to the power terminal of the camera.
Plug the power cord of the adaptor into the wall outlet.

1.

2.

Adaptor Board

22_ setup

Connect the camera to the keyboard controller or DVR, with which you
can manipulate and change the settings of the camera.

HOW TO USE THE KEYBOARD CONTROLLER

Follow the steps below to set the camera menu using the controller.

Open the Camera Setup screen.
Use the joystick to navigate through the menus.
Press [ENTER] to select a menu item.
Use the joystick to change the value of the selected item.
Press [ENTER] to apply your changes.

Using OSD icons

_+

:

If these icons appear in the left and right corner of a menu item, you can use
the joystick to move to the previous or next menu.

(EXIT): Exits the menu setup screen.

Before exiting the setup screen, select <SAVE> to save your settings
to the whole menus, or <QUIT> to cancel them.

(RET): Saves your settings and returns to the previous screen.
(HOME): Returns to the main menu.
(SAVE): Use this icon if you want to save your settings after you specified the

mask area and privacy area, etc.
Once you saved your settings, the changes remain intact even if you
select <QUIT> on exit.

(DEL): Use this icon if you want to delete a mask, or privacy area, etc.

Once you deleted your settings, the deletions remain valid even if you
select <QUIT> on exit.

: This icon appears in the right of a menu containing sub menu items.

While any operation of PRESET, AUTO PAN, SCAN, and PATTERN is running, and if
the camera is turned off and back on without any particular manipulation, the
camera will resume the last run operation.

You can set the menu item only if the tilt angle is within 90°.
If you enter the menu setup screen with the camera positioned out of a tilt of 90°,
the camera will rotate by 180° to fall into the opposite position within a tilt of 90°.

1.

2.

3.

4.

5.















M





setup

English _23

● 

MAIN MENU

This is the first screen you ever see when you turn on the camera where you can set the
camera environment to your needs.

For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 22)

PROFILE

Select a mode appropriate to the camera
installation environment.

CAMERA SET

You can configure the camera settings.

INTELLIGENCE

Offers motion detection and tracking
functions.

PRIVACY ZONE

You can configure the privacy settings.

PRESET

You can set the PRESET POSITION and
DURATION.

AUTO SET

Contains sub menu items of AUTO PAN,
PATTERN, SCAN and AUTO PLAY.

ZONE SET

You can set the standard azimuth and
zone area for the camera.

ALARM SET

You can set the alarm priority and I/O sequence.

CLOCK SET

You can set the display time and format.

OTHER SET

You can set preferred language, reset the system, and select an OSD color to
your preference.

COMMUNICATION

Configures the settings pertaining to RS-485 communication.

SYSTEM INFO

Shows the system information such as the camera version or communication
settings.



























MAIN M ENU



PROFILE

CAMERA SE T
INTELLI GENCE
PRIVACY ZONE

PRESET
AUTO SET
ZONE SE T

ALARM S ET
CLOCK S ET
OTHER S ET

COMMUNI CATION

SYSTEM INFO

24_ setup

setup

PROFILE

You can select one from the pre-determined configurations as appropriate to your
specific camera installation environment.
Your selection on each item in PROFILE will affect all other settings of the camera.

STANDARD

Automatically optimizes the camera settings
to the normal environment.

ITS

This setting enables you to analyze the traffic
situation and take the traffic information at a
glance.

BACKLIGHT

This setting enables you to view a sharp
background and object even in a severe
backlight scene.

DAY/NIGHT

Automatically optimizes the camera settings to the day and night scene.

GAMING

This automatically configures the settings so that you can work in a stable illumina­tion condition as indoors.

CUSTOM

Your change to any of the PROFILE settings will switch the display to CUSTOM.













CAMERA SETUP MENU

STANDARD ITS BACKLIGHT DAY/NIGHT GAMING

Parent Menu

Sub-menus

VPS

OFF ON OFF OFF OFF

IRIS

ALC ALC ALC ALC ALC

ALC - - - - -

LEVEL

0 0 0 0 0

BACKLIGHT OFF OFF WDR OFF OFF

WDR - - - - -

WEIGHT Custom Setting Custom Setting MEDIUM Custom Setting Custom Setting

WDR LEVEL

Custom Setting Custom Setting 0 Custom Setting Custom Setting

WHITE BAL Custom Setting Custom Setting Custom Setting Custom Setting Custom Setting



PROFI LE





STANDARD

ITS

BACKLIG HT

DAY/NIGHT

GAMING
CUSTOM

English _25

● 

CAMERA SETUP MENU

STANDARD ITS BACKLIGHT DAY/NIGHT GAMING

Parent Menu

Sub-menus

MOTION

(F.FAST)

---

(F.FAST)

---

NORM

(F.FAST)

---

SLOW

DNR MEDIUM MEDIUM MEDIUM MEDIUM MEDIUM

SHUTTER (OFF)--- (OFF)--- (OFF)--- (OFF)--- (OFF)---

SENSE UP AUTO X4 AUTO X2 AUTO X4 AUTO X4 AUTO X4

XDR

MEDIUM MEDIUM MEDIUM MEDIUM MEDIUM

DAY/NIGHT

AUTO AUTO DAY AUTO DAY

NIGHT - - - - -

BURST OFF ON OFF OFF OFF

EXT

- - - - -

BURST OFF ON OFF OFF OFF

WHITE BAL

DAY DAY/NIGHT DAY DAY/NIGHT DAY

DAY

- - - - -

MODE

ATW2 ATW1 ATW1 ATW1 ATW1

RED 0 0 0 0 0

BLUE 0 0 0 0 0

NIGHT - - - - -

BRIGHTNESS

Custom Setting MEDIUM Custom Setting MEDIUM Custom Setting

MODE

OFF ATW2 OFF ATW2 OFF

RED Custom Setting 0 Custom Setting 0 Custom Setting

BLUE Custom Setting 0 Custom Setting 0 Custom Setting

DETAIL 2 2 2 2 2

26_ setup

setup

CAMERA SET

You can configure the general settings of the camera module.

For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 22)

Select <MAIN MENU> - <CAMERA SET>.
The Camera Setup menu appears.

Change the settings as necessary, or select
an item to check.

CAMERA ID

Provide the ID and location for a camera that displays on the screen.

For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 22)

Select <CAMERA SET> - <CAMERA ID>.
Use the joystick to select a desired character,

then press [ENTER].
In the lower input box of the screen, the
selected character will be entered.

You can enter up to 54 characters including
alphabets, numbers and special characters.

LOCATION : Specify the display position
of the camera ID.

When done, press [ENTER].
The camera ID will be displayed in the specified position.

VPS

If you set it to <ON>, the camera images will be displayed in progressive mode.

1.

2.

1.

2.





3.



CAMER A SET



CAMERA ID OFF
VPS OFF
IRIS ALC
MOTION (F.FAST)

--­DNR MID
SHUTTER (OFF)

--­SENS-UP AUTO X4
FLICKER LESS OFF
XDR MID

CAMER A ID

ABC DEFGHI JKLMN OPQ RSTUVW XYZO

12 34 56 78 9

: ?

_

+



()/

SP SP LOCATION

-

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

English _27

● 

IRIS

The IRIS menu is useful if you set to adjust the
intensity of radiation incoming to the camera.

ALC : Adjust the open and close of the iris.

- LEVEL : Select an overall brightness level.

- BLC : With <

BACKLIGHT> set to
<BLC>, you can specify the BLC area.
With AREA set to <USER>, you can
specify the position and size.

- WDR : If you set <BACKLIGHT> to
<WDR>, you will see a menu where you
can set the WDR options.
Specify the shutter speed in WDR LEVEL,
and, the composition level in <WEIGHT>.
Select OUTDOOR, or INDOOR in
<WHITE BAL>.
<ANTI ROLLING> enables you to reduce
the color rolling on the screen.
The WDR feature provides an extension of
the gain range, which is useful, especially if
you work on pictures both indoors and outdoors from inside of a building.
Namely, it improves the sharpness of the picture in outdoor scenery as well as
indoor.

As long as you use the VPS function, the WDR will not be available as the CCD read
method differs accordingly. If you set VPS to ON, WDR will be set to <OFF>
accordingly.

MANUAL : Adjust the iris level manually.

The overall brightness target of a camera
will be set to ALC level 0, while the iris
can be adjusted manually.



M





M



ALC

LEVEL

[

00]

----I----

BACKLIG HT BLC
AREA USER
<SIZE>
<LOCATION>

MANUA L

LEVEL

[ 00]

----I----

ALC

LEVEL

[ 00]

----I----

BACKLIG HT WDR

WEIGHT MID
WDR LEVEL

[ 0]

----I---­ WHITE BAL IND OOR
ANTI RO LLING OFF

28_ setup

setup

AGC

With this, you can adjust the AGC level of a
camera.
With AGC active, if the signal strength falls
below the standard level, AGC will amplify the
video signal to automatically improve the
sensitivity.
If <SENS-UP> is set to <OFF>, or <FIX>
mode, the <MOTION> menu will switch to
<AGC>.
With the USER

( )

submenu selected, press
[ENTER] to display the corresponding screen.
In this mode, you can select from VERY LOW
to VERY HIGH in 16 levels, enabling deeper, wider choices to your convenience.
With the FIX

( )

submenu selected, press [ENTER] to display the corresponding
screen. In this mode, you can select an individualized mode in 16 levels, regardless of
the brightness.

As long as the DAY/NIGHT menu is set to AUTO in Camera Setup, the AGC menu is
not available.

As long as FLICKERLESS is set to ON, the FIX mode is not available.

If you set BACKLIGHT to WDR, the AGC fix mode is not available.

MOTION

You can specify a level of AGC for controlling the camera motion.
This is available only of the SENSE UP menu is set to AUTO.
Select F.FAST if you want to monitor a very fast moving object in a low contrast
scene, and S.SLOW if monitoring a very slow moving, inanimate object in the same
condition.

As long as DAY/NIGHT is set to <AUTO>, the <MOTION> menu is not available.

DNR

Reduces the noise on the camera image.
The higher the level is, the greater the effect is.
Set it to <USER> to specify the level.

M











CAMERA SE T



CAMERA ID OFF
VPS OFF
IRIS ALC

AGC (VERY H IGH)

---

DNR MID
SHUTTER OFF
SENS-UP OFF
FLICKER LESS OFF
XDR MID

English _29

● 

SHUTTER

You can select a fixed fast electronic shutter
speed in 7 options ranging from 1/100 to 1/10k,
which is mostly used to take a picture of a fast
moving object.

As long as SENSE UP is set to AUTO, FIXED /
FLICKERLESS to ON / BACKLIGHT to WDR, the
SHUTTER menu is not available.

SENS-UP

Automatically senses the darkness level at night or in a low contrast scene, and
extends the accumulation time accordingly; you can select <AUTO> or <FIX> for a
bright and sharp image.

If the SHUTTER menu is set to fixed electronic shutter mode, the SENSE UP menu
will not be available.

If FLICKERLESS is set to ON, or BACKLIGHT to WDR, the FIX mode of the SENSE UP
menu is not available.

FLICKERLESS

This will prevent possible screen distortion due to a mismatch between the vertical
sync frequency and the blinking frequency of the lighting; if set to <ON>, the shutter
speed will be fixed to 1/100 second.

If SHUTTER is set to FIX, SENSE UP to FIX, and AGC to FIX, the <FLICKERLESS> menu is
not available.

XDR

This will correct a brightness difference between different scenes for the optimal
visibility by calculating the ambient luminance contrast in a certain unit of pixels.
The higher the value is, the higher the correction level is.



M









CAMERA SE T



CAMERA ID OFF
VPS OFF
IRIS ALC
AGC (VERY H IGH)

--­DNR MID

SHUTTER 1/100

SENS-UP (OFF)

--­FLICKER LESS (OFF)

--­XDR MID

30_ setup

setup

DAY/NIGHT

You can specify a recording mode according to the scene.

For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 22)

Select <CAMERA SET> - <DAY/NIGHT>.
Select a screen transition mode according

to the illumination, and set options as
appropriate.

DAY : Fixed to DAY mode, regardless of
the scene.

NIGHT : Fixed to NIGHT mode,
regardless of the scene.
If BURST is set to <ON>, the burst
signal will be output along with the
black-and-white composite video signal.

AUTO : According to the luminance, this
will switch DAY to NIGHT mode, or vice
versa.

BURST : If set to <OFF>, the burst
signal will not be output in NIGHT mode.

DAYNIGHT BRIGHTNESS : Specify
the brightness level switching from
COLOR to BW filter.
Adjusting from HIGH to LOW will cause
to switch the filter in a darker screen.

DAYNIGHT DWELL TIME : Time
required to determine the filter switch.

NIGHTDAY BRIGHTNESS : Specify the brightness level switching from
BW to COLOR filter. Adjusting from HIGH to LOW will cause to switch the
filter in a darker screen.

NIGHTDAY DWELL TIME : Time required to determine the filter switch.
MASK AREA : If there exists a bright

spot light source in a night scene, you
can specify the size and position as
needed.
This will prevent an error in switching
filter, or failure to determine the filter
switch in a night scene where a bright
spot light source exists.
Any excessively bright area in a night
scene will be MASKed.

1.

2.







-

-

-

-

-

-

AUTO

BURST OFF

DAYNIGHT
BRIGHTNESS MID
DWELL TIME 2SEC
NIGHTDAY
BRIGHTNESS MID
DWELL TIME 5SEC
MASK AREA

1 2

MASK AR EA

<SIZE>

<LOCATION>

DAY/NIGHT AUTO

WHITE B AL
FOCUS M ODE ONEAF
ZOOM SP EED [2]
DISPLAY ZOOM OFF
DISPLAY P/T OFF
DIGITAL ZOOM OFF
DETAIL [2]
V-SYNC INT

English _31

● 

You can specify MASK 1 and 2 simultaneously.

If <BACKLIGHT> is set to <BLC>, the MASK AREA function is not available.

EXT : The interface to an external alarm enables an automatic switch between
DAY and NIGHT mode.
If you set <DAY/NIGHT> to EXT, and alarm #1 to NO/NC in ALARM SET-
ALARM IN SET, the alarm can be used for an input signal in EXT mode of
<DAY/NIGHT>.
If an alarm signal occurs, the mode will switch to NIGHT.

If <DAY/NIGHT> is set to EXT, ALARM1 in ALARM OUT SET, and ALARM1 in ALARM
SET-AUTO SET are not available.

If you use an infrared light source while in AUTO mode, this may cause a failure in
AUTO SWITCH or AUTO FOCUS.

WHITE BAL

If you need to adjust the color according to the ambient illumination, you can use
the <WHITE BAL> function.

For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 22)

Illumination is generally referred to as color temperature, which is represented in a
measurement of kelvin (K). Color temperatures for ordinary lighting are as follows:

In the <WHITE BAL> menu, you
can set a mode for correcting the
<WHITE BAL>.

- ATW1,2 : If you set the <

WHITE

BAL> menu to <ATW1> or

<ATW2> mode, this will monitor
the change of the color temperature
to correct the <WHITE BAL> as
needed.
The following color temperature
ranges are assured in individual
modes:
ATW1 : 2500K ~ 9300K (1)
ATW2 : 2000K ~ 10000K
(suitable to sodium light source) (2)



1 :

With <ATW1> mode active in a color temperature environment ranging
beyond between 2500K and 9300K, a proper white balance value may not be
produced; if this is the case, you are recommended to use <ATW2> mode.



2 : With <

ATW2> mode active in a mostly single color environment, the display
color and the actual one may differ; so select a mode as appropriate to your
color temperature environment.







M





Blue sky

Rainy

Cloudy

Sunny

Partly Cloudy

Fluorescent lamp

Halogen lamp

Tungsten lamp

Candlelight

10000K

9000K

8000K

7000K

6000K

5000K

4000K

3000K

2000K

1000K

32_ setup

setup

Select <CAMERA SET> - <WHITE BAL>.
Select a mode where you set the <WHITE BAL>.

DAY : You can set the RED, and BLUE
value in DAY mode.
The screen will be displayed in colors
according to your settings.

You can set the R-GAIN, and B-GAIN value
only in <AWC> mode.

If AGC is set to <OFF> or <FIX>, the NIGHT
menu can not be accessed.

NIGHT : You can set the <WHITE BAL>
according to the ambient illumination.
If NIGHT mode is set to <OFF>, the
<WHITE BAL> will operate in a mode
specified in DAY mode at all times;
otherwise, the screen will switch to a
mode specified in <DAY/NIGHT>.
You can set the RED, BLUE and
BRIGHTNESS value in DAY mode.
The screen will be displayed in colors
according to your settings.

According to the specified recording mode, select a <WHITE BAL> mode with
necessary options.

ATW1,2 : The camera can automatically adjust the color temperature in real
time, according to the ambient conditions.
(Color temperature range 1: 2500K ~ 9300K, 2 : 2000K ~ 10000K)

AWC : Pressing [ENTER] on a desired item will perform ATW once.

You can set the R-GAIN/B-GAIN value.

3200K : Set the color temperature to 3200K.
5600K : Set the color temperature to 5600K.

BRIGHTNESS : Specify a brightness level switching from DAY mode to
NIGHT mode setting.

RED : Adjust the strength of the red color.
BLUE : Adjust the strength of the blue color.
R-GAIN/B-GAIN : Specify the current color temperature manually.

1.

2.









3.










-

-

-

-

WHITE BAL

DAY/NIGHT NIGHT
BRIGHTN ESS MID

MODE AWC

RED

[ 00]

----

I

----

BLUE

[ 00]

----

I

----

R-GAIN

[

0128

]

B-GAIN

[

0128

]

WHITE BAL

DAY/NIGHT DAY

MODE AWC

RED

[ 00]

----

I

----

BLUE

[ 00]

----

I

----

R-GAIN

[

0128

]

B-GAIN

[

0128

]

English _33

● 

FOCUS MODE

You can select a focus mode according to the
angle that you adjusted for camera recording.

- AF : This will monitor the screen continuously
to focus automatically. If you adjust the focus
manually, that will operate the same as in
<MF>. This will also restore focus after the
operation of pan/tile/zoom.

- SENSITIVITY : Indicates the sensitivity of auto
focus, which you can adjust between level 1
and level 7.
The closer your setting is to 7, the more
sensitively the auto focus function performs.
The Night setting is used when a strong light
reflects in a low contrast scene.
You can set it to OFF, LOW, MEDIUM, or
HIGH; set it to <HIGH> when there exist a
strong light such as street light.

- ONEAF : Restores focus after the operation
of pan/tile/zoom, and operates the same as
in <MF> unless the operation of pan/tile/
zoom is executed.

- MF : You can adjust the focus manually.

While you are working on the following objects, <AF> may not work properly.
If this is the case, use <MF> instead.

- Very bright object, or dominant object in a dark scene

- Object against the rear side of a moist or dirty glass

- A scene where nearby and distant objects co-exist

- White wall or single-colored object

- Venetian blinds and other horizontally striped objects

ZOOM SPEED

You can adjust the zoom operation speed.

DISPLAY ZOOM

You can set to display the zoom status on the screen.

It will disappear in about 3 seconds if the zoom factor has no further change.

M





AF

SENSITI VITY [5]

NIGHT MID

DAY/NIGHT AU TO
WHITE B AL

FOCUS M ODE A F

ZOOM SP EED [2]
DISPLAY ZOOM OFF
DISPLAY P/T OFF
DIGITAL ZOOM X 16
DETAIL [2]
V-SYNC INT

34_ setup

setup

DISPLAY P/T

You can set to display the operation status of pan/tilt when it is active.

It will disappear in about 3 seconds if the pan/tilt position has no further change.
However, the allowable error is ±2°.

DIGITAL ZOOM

You can set the maximum allowable digital zoom ratio.
Digital Zoom will start operation after it is zoomed in to the maximum optical ratio of
x43. If you set DIGITAL ZOOM to x16, you can take a shot at up to x688 (43x16).

DETAIL

Used to adjust the vertical and horizontal distinction, respectively.

V-SYNC

You can set the V-SYNC mode.

- If you select <INT>, the camera will use the internal synchronization.

- If selecting <LINE>, the camera will use an external power frequency for
synchronization. The LL-PHASE can be adjusted as appropriate.

AGC COLOR SUP

You can adjust the color reproduction range
according to AGC.

REVERSE

You can reverse the video signal from left
to right, upside down, or vice versa to your
convenience.

POSI/NEGA

You can set the video brightness signal to
normal or reverse.

PIP

You can view a main image with a sub image on the same screen.



AGC COL OR SUP MID

REVERSE OFF
POSI/NE GA +
PIP OFF
DIS OFF

English _35

● 

If more than one PRIVACY ZONE is specified, and PRIVACY SET to <ON>, the PIP
function is not available.

As long as SENSE UP is set to FIXED, PIP menu is not available.

According to the luminance, PIP will disappear if the SENSE UP menu is set to AUTO.

DIS (Digital Image Stabilization)

If you set it to <ON> for a camera that is trembled or vibrated from an ambient
change, this will automatically compensate for the flicker on the screen.

If you set <DIS> to <ON>, the image will be enlarged with digital zoom as much
area as compensated. (Approximately 1.2 times of the optical zoom factor)
If you set the digital zoom to a larger ratio than the actual enlargement for
compensation, the <DIS> function will be disabled.

<DIS> may not work properly in the following images:
Single-colored flat image / Low contrast scene / High frequency image taken under
a fluorescent lamp / Regular-patterned image

INTELLIGENT VIDEO

You can enable the motion detection and tracking functions.

For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 22)

Select <MAIN MENU>-<INTELLIGENCE>.
Select each item and set appropriately.

MOTION

You can enable the motion detection and
tracking functions.

If you set it to <DETECTION>, the
<FIXED/MOVED> option of ADVANCED
menu will not be available.

In following situations, motion detection and tracking function may not work
properly.

- When there is sudden changes of brightness

- When the device moves

- When a certain object’s movement fills most of the framing area

- When there is difficulties in distinguishing the moving object and background

M







M





1.

2.

M







INTEL LIGENCE



MOTION OFF
ADVANCED OFF
MASK AREA

1 2 3 4
DISPLAY ON
SENSITI VITY

[4]

RESOLUT ION

[3]

ALARM O UT

36_ setup

setup

ADVANCED

You can detect motions and mark the video that contains such motion, and enables
tracking of the movement. (The auto PTZ function is not supported for tracking an object.)
Selecting the <FIXED/MOVED> option will mark a region if an existing object
disappears, or a new object appears and fixed for a certain period of time.

In following situations, FIXED/MOVED detection may not work properly.

- When multiple motions continue arbitrarily.

- When the object that is fixed continues to move in the same position.

- When a newly appearing object conceals another object that is moving.

MASK AREA

Select the number of the area to be
masked that will be excluded from motion
detection.

Select the mask number and set the mask
size and its coverage.

DISPLAY

When selected <ON>, it displays the motion
detected and detection of configured
advanced function.

SENSITIVITY

Sets the sensitivity of motion sensor.

RESOLUTION

The bigger the resolution setting, the smaller the object that can be detected.

ALARM OUT

When selected <ON>, it outputs alarm
signal when the motion is detected and on a
detection of configured advanced function.

M



1.

2.

MASK AR EA

<SIZE>

<LOCATION>

ALARM O UT

MOTION ON

FIXED/M OVED ON

English _37

● 

PRIVACY ZONE

You can set up to 12 privacy zones that will be hided for privacy of the subject when
recording.

Zone Setup

For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 22)

Select <MAIN MENU>-<PRIVACY ZONE>.
Select the number of the zone and press

[ENTER].
The Zone setup screen appears.

Select the <SET P/T/Z> and press
[ENTER].
Using the joystick, adjust the camera’s
pan, tilt and zoom.

Select the <PIXEL LEVEL>.
Select the pixel level for the SIZE and
LOCATION settings.

Select <POINT> and press [ENTER]. The
Privacy zone would be marked each time
you press [ENTER].

Use the joystick to set the position of each
point (top left, top right, bottom right,
bottom left), and press [ENTER]. Position
setting is completed.

Save the changes and move to the previous screen and select the <STYLE>.
Select the <COLOR> and pick a desired color.

Setting one or more privacy zone and enabling privacy function will disable the PIP
function.

For better privacy protection, make your privacy zone bigger than the required,
bigger by about 30%.

Video portion of mosaic pattern or colored by the privacy zone setup is not
recoverable.

1.

2.

3.

4.

5.

6.

7.

M









PRIVACY ZO NE



1 2 3 4 5 6
7 8 9 10 11 12

PRIVACY SET

ON

STYLE

MOSAIC1

PRIVACY ZO NE SET 1

<SET P/ T/Z>

PIXEL LE VEL [4]
<POINT>

38_ setup

setup

PRESET

This function provides preset camera settings such as pan, tilt, zoom and focus so to
enable quicker and easier accessing and monitoring, which supports up to 512 presets.

For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 22)

Select <MAIN MENU>-<PRESET>.

Select the preset number.

Select <POSITION> and adjust <PAN/

TILT/ZOOM

> to the desired setup using

the joystick.
Set <PRESET ID> to <ON> and enter the

name.

For entering the name, refer to “CAMERA ID”.
(page 26)

1.

2.

3.

4.





MAIN M ENU



PROFILE

CAMERA SE T
INTELLI GENCE
PRIVACY ZONE

PRESET

AUTO SET

ZONE SE T

ALARM S ET

CLOCK S ET
OTHER S ET



PRESE T



0* 1 2 3 4
5 6 7 8 9
10 11 1 2 13 14
15 16 1 7 18 19
20 21 2 2 23 24
25 26 2 7 28 29
30 31



1/16



PRESE T NO. 1

POSITIO N

PRESET ID ON
PRESET SPEED [5]
DWELL TI ME 3SEC
IMAGE H OLD O FF
CAMERA SE T ON

English _39

● 

Select <PRESET SPEED> and adjust the pan/tilt speed of the preset.
Set the <DWELL TIME> that defines the camera's hold duration and <IMAGE

HOLD> of the preset.

If you set the <IMAGE HOLD> to <ON>, the video image will be held still until the
camera reaches the preset position.

Set <CAMERA SET> to <ON>.
You can adjust camera setups for each
preset.

For details on setting <IRIS>, <WHITE BAL>
and <FOCUS MODE>, refer to “CAMERA
SET”. (pages 26 ~ 35)

If VPS is set to ON in Camera Setup from
the main menu, the camera will operate in
VPS even if it's set to WDR in PRESET.

If you use WDR in PRESET, the camera will operate in WDR and release any previous
settings even if AGC has been set to FIX, SHUTTER to ON, SENSE UP to FIX in the
main menu.

The preset position can be specified for a tilt range of between -6° and 90°.
Those presets that are out of a tilt of 90° can not be specified.

If you try to specify a preset position for a range exceeding a tilt of 90° using a
controller (SSC-1000, 2000 or 5000), you will see a message of <SET AGAIN> on
the screen. If this is the case, try again for a range below a tilt of 90°.

If you upload/download the menu setting using SSC-1000, 2000 or 5000, the
preset may differ from the menu setting so define the preset again after the
operation.

5.

6.



7.



M











CAMER A SET

IRIS ALC

WHITE B AL
FOCUS M ODE MF

40_ setup

setup

AUTO SET

You can set the AUTO PAN, PATTERN, and AUTO PLAY.

If you upload/download the menu setting using SSC-1000, 2000 or 5000, the
settings for AUTO PAN, PATTERN, SCAN, and PRESET may differ from the menu
settings so define them again after the operation.

Auto Pan Setup

Set the starting and ending positions to patrol between points at specified speed.

For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 22)

Select <MAIN MENU>-<AUTO SET>.

Select the number of <AUTO PAN>.
AUTO PAN setup screen appears.

M



1.

2.



AUTO SET



AUTO PAN

1 2 3 4

PATTERN

1* 2* 3*

SCAN

1 2 3 4

AUTO PLAY OFF



MAIN M ENU



PROFILE

CAMERA SE T
INTELLI GENCE
PRIVACY ZONE

PRESET

AUTO SET

ZONE SE T

ALARM S ET

CLOCK S ET
OTHER S ET

English _41

● 

Select each item and set appropriately.

POSITION : Set the starting and ending
positions for the <AUTO PAN>.
Move to the setting screen and adjust
pan/tilt to the desired starting position,
and then press [ENTER].
Again, adjust pan/tilt to the desired
ending position and press [ENTER] to
finish <AUTO PAN> setup.

DIRECTION : Sets the direction of the camera’s movement from the starting to
the end position. (Based on panning)

ENDLESS : Instead of shuttling between start and end positions, the camera
turns 360° endlessly while stops for the <DWELL TIME> at both positions.

SPEED : Sets the moving speed of the camera, from 1 to 64.
DWELL TIME : Sets the dwell time at the starting and ending positions, from

1 to 60 seconds.

Pattern Setup

You can manually record your pan/tilt/zoom movements to a monitoring pattern for
up to 2 minutes.

For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 22)

Select <MAIN MENU>-<AUTO SET>.
Select the pattern number.

PATTERN setup screen appears.
Select the <POSITION> and set the

pattern's starting position and press
[ENTER].

3.










1.

2.

3.

<RIGHT> <LEFT>

START START

END

END

AUTO PAN 1

POSITIO N

DIRECTI ON LEFT
ENDLESS OFF
SPEED

[10]

DWELL TI ME 3SEC

PATTERN SET 1

<POSITI ON>

START

42_ setup

setup

Select the <START> and move the
camera using pan/tilt/zoom.

Your manual camera actions will be
recorded for up to 2 minutes, and returns
to the previous menu automatically.

To stop manual recording and return to the
previous menu before 2 minutes, press
[ENTER].

Scan Setup

You can set the SCAN operation to include a defined preset position.

For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 22)

Select <MAIN MENU>-<AUTO SET>.
Select the scan number.

SCAN setup screen appears.
Move the cursor to a number with the []

mark which contains a defined preset.
Press [ENTER].

[S] mark appears beside the [] and the
corresponding preset is included in the
scan.

SCAN numbers configured for a certain page can be saved only in the corresponding
page. Make sure to save it before moving to the next page.

4.

5.



1.

2.

3.

4.

M



PATTERN SET 1

<POSITI ON>

START

SCAN 1

0S 1 2 3 4
5 6 7 8 9
10 11 1 2 13 14
15 16 1 7 18 19
20 21 2 2 23 24
25 26 2 7 28 29
30 31



1/16



English _43

● 

Auto Play Setup

AUTO PLAY runs configured AUTO PAN, PATTERN, and SCAN functions
automatically.

For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 22)

Select <MAIN MENU>-<AUTO SET>.
Select the <AUTO PLAY> and select a

number.
AUTO PLAY setup screen appears.

AUTO PLAY1 : Sets overall function
properties of the AUTO PLAY.

AUTO RETURN : Sets the interval
between auto plays.

AUTO PLAY : Sets the auto play action
at every auto play interval.
You can set between 1 ~ 4 for SCAN
or AUTO PAN, 1 ~ 3 for PATTERN, and
0 ~ 511 for PRESET.

PLAY NUMBER : Sets the number of
the defined auto play operation.

AUTO PLAY2 : Select the auto play
action and set its starting / ending time.
When the time hits the defined starting
time, configured auto play will begin.
You can set between 1 ~ 4 for SCAN or
AUTO PAN, 1 ~ 3 for PATTERN, and
0 ~ 511 for PRESET.

1.

2.



-

-

-



AUTO PLAY 1

AUTO RET URN 1MIN

AUTO PLAY PRESE T
PLAY NUMBER 0



AUTO SET



AUTO PAN

1 2 3 4

PATTERN

1 2 3



SCAN

1 2 3 4

AUTO PLAY 1

AUTO PLAY 2
ID: START END PLAY NO .
1 00:00 03:00 OF F 0
2 03:00 06:00 OF F 0
3 06:00 09:00 OF F 0
4 09:00 12:00 OF F 0
5 12:00 15:00 OF F 0
6 15:00 18:00 OF F 0
7 18:00 21:00 OF F 0
8 21:00 00:00 OF F 0

44_ setup

setup

ZONE SET

You can set the north direction and the zone coverage.

For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 22)

Select <MAIN MENU>-<ZONE SET>.

Set <AZIMUTH> to <ON>.
Set the north direction using the joystick

and press [ENTER].

SET NORTH : In SET NORTH, press
[ENTER] to set the north direction
which will be the reference for all other
directions.

Set <ZONE AREA SET> to <ON>.

When the <ZONE AREA MAP> screen
appears, select a number.

When the <ZONE AREA SET> screen
appears, set the <POSITION> and
<ZONE ID SET>.

For entering the name, refer to “CAMERA ID”.
(page 26)

POSITION : Sets the left/right boundaries
of the zone.

1.

2.

3.



4.

5.

6.







ZONE SET



AZIMUTH OFF
ZONE AREA S ET OFF



MAIN M ENU



PROFILE

CAMERA SE T
INTELLI GENCE
PRIVACY ZONE

PRESET

AUTO SET

ZONE SE T

ALARM S ET

CLOCK S ET
OTHER S ET

ZONE AR EA MAP

1 2 3 4

5 6 7 8

English _45

● 

ALARM SET

It provides 8 alarm inputs and 3 alarm outputs. Detects alarm inputs from the external
sensors cooperating with configured presets, patterns, and scan functions, and
produces alarm outputs. Alarm’s dwell time is defined by the corresponding preset’s
<DWELL TIME> and its alarm action.

For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 22)

Select <MAIN MENU>-<ALARM SET>.

Select each item and set appropriately.

ALARM PRIORITY : Sets the priorities of
alarms. Setting the priorities of 8 alarms
defines the alarm notification priorities
of them in the highest orders.
By default, the priorities are set as

Alarm 1  Alarm 2  .....  Alarm 8.

When multiple alarms are generated
at the same time, alarm notifies in the
order of the default priority setting.
While an alarm is generating, no motion
is detected.

1.

2.





ALARM S ET



ALARM P RIORITY SET
ALARM I N SET
ALARM O UT SET
AUTO SET
AUX OUT CONTRO L



MAIN M ENU



PROFILE

CAMERA SE T
INTELLI GENCE
PRIVACY ZONE

PRESET
AUTO SET
ZONE SE T

ALARM S ET

CLOCK S ET
OTHER S ET

ALARM P RIORITY SET

ALARM1 1

ALARM2 2
ALARM3 3
ALARM4 4
ALARM5 5
ALARM6 6
ALARM7 7
ALARM8 8

46_ setup

setup

ALARM IN SET : Select the alarm sensor
operation between <NO>, <NC> and
<OFF>.

ALARM OUT SET : Set the alarm out
port matched to the alarm input port.

AUTO SET : Sets the pattern and scan
action for the corresponding alarm
input. When the alarm is generated, the
camera moves to the preset position
coupled to the corresponding alarm.
Presets 1 ~ 8 are coupled with alarms
1 ~ 8 inputs respectively, and the preset 9 is coupled to the motion
detection.
The camera stops and remains in the corresponding preset position for the
defined <DWELL TIME>, and performs pattern or scan action defined by
the <AUTO SET>. Setting to <OFF> will discard with the pattern or scan
action after moving to the preset position.

- PATTERN 1 ~ 3 : Defined pattern action

- HALF1 : Patterns 1 and 2 in serial action

- HALF2 : Patterns 2 and 3 in serial action

- WHOLE : Patterns 1, 2 and 3 in serial action

- SCAN 1 ~ 4 : Predefined SCAN action

The <ALARM1> is used as external switching signal if the <DAY/NIGHT> is set to
<EXT>.

AUX OUT CONTROL : Sets whether to
sustain the alarm output despite of the
alarm generation or to output alarm out
signal while the coupled alarm is alive.
When selected <OFF>, outputs alarm
only if the alarm is generated. When
selected <ON>, it always outputs
alarm out signal despite of the alarm
generation.







M





AUX OUT CONTRO L

OUT1 OFF

OUT2 OFF
OUT3 OFF

AUTO SET

ALARM1 OFF

ALARM2 OFF
ALARM3 OFF
ALARM4 OFF
ALARM5 OFF
ALARM6 OFF
ALARM7 OFF
ALARM8 OFF
MOTION OFF

English _47

● 

CLOCK SET

Sets whether to display the clock on the screen and its time format.

For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 22)

Select <MAIN MENU>-<CLOCK SET>.
Select <DISPLAY> and set whether to

display the time on the screen.
Select the time format and set the clock.
Select the date format and set the date.

OTHER SET

You can reset the system by running FACTORY DEFAULTS, or set the font color, zoom,
turbo pan/tilt, etc.

For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 22)

Select <MAIN MENU>-<OTHER SET>.
Select each item and set appropriately.

1.

2.

3.

4.

1.

2.



CLOCK SET



DISPLAY OF F
TIME FO RMAT 12HOUR
SET TIM E AM 07:34: 48
DATE FORMAT MM/DD/Y YYY
SET DATE 0 1/01/2009



OTHER SET



LANGUAG E ENGL ISH
FACTORY DEFAULTS
OSD COL OR BW
PROPORT IONAL P/ T ON
P/T SPE ED

[2]

AUTO CAL . OFF
D-FLIP OFF
PASSWORD OFF

48_ setup

setup

Language

Select <LANGUAGE> and use the left/right
button to select a preferred display language.

FACTORY DEFAULTS

When selected, the <FACTORY DEFAULTS>
screen appears and you can reset all settings
to the factory default settings by selecting
the <OK>. However, the protocol, baud rate,
address and the language settings will not be
reset.

Note that the resetting the system to the
factory default will erase all settings data.

OSD COLOR

Selects the color of the on-screen display font.

PROPORTIONAL P/T

When selected <ON>, manual pan / tilt movement speed will vary proportionally to
the zoom ratio.

P/T SPEED

When selected <ON>, manual pan / tilt movement speed will be doubled.

M



FACTORY DEFAULTS

OK

CANCEL



OTHER SET



LANGUAG E ENGL ISH

FACTORY DEFAULTS
OSD COL OR BW
PROPORT IONAL P/ T ON
P/T SPE ED [2]
AUTO CAL . OFF
D-FLIP OFF
PASSWORD OFF

English _49

● 

AUTO CAL. (AUTO CALIBRATION)

To enhance the lens and pan/tilt motor’s accuracy, the automatic compensation
function is provided. It automatically resets the lens and pan/tilt when there is no
user operation for a specified time period.

D-FLIP (DIGITAL FLIP)

When selected <ON>, the displayed screen will be flipped vertically and horizontally
if the subject turns over 90°.

PASSWORD

When selected <ON>, it is asked to enter the
password for accessing the menu.
Select the numbers using direction keys and
press [ENTER].

The default password is “4321”.

COMMUNICATION

You can set the RS-485 communications setting in regard of the camera.

For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 22)

Select <MAIN MENU>-<COMMUNICATION>.
Select each item and set appropriately.

PRIORITY : Set the priority by selecting
<HW> or <SW>.
When selected <HW>, the protocol,
baud rate and address settings will
follow those settings of the adaptor
switch.

PROTOCOL, BAUD RATE, ADDRESS :
When selected <SW>, you can manually
set the protocol, baud rate and address.



1.

2.





PASSWORD

0 1 2 3 4
5 6 7 8 9

[



]

[



]



COMMU NICATION



RS485
PRIORIT Y HW
PROTOCOL SA MSUNG-E
HALF
BAUD RATE 9600
ADDRESS 0

50_ setup

setup

SYSTEM INFO

You can check the system information.

For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 22)

Select <MAIN MENU>-<SYSTEM INFO>.
The current system information is displayed.

1.

2.



SYSTE M INFO



TYPE 4_43PTZ_WDR_N
PROTOCOL SAMS UNG-E
ADDRESS 0
COMM. T YPE HW, RS485, HAL F
BAUD RATE 9600
SERIAL N O. 0000000 0000000 0
CAMERA VE R. v2.00_100501
ALARM V ER. v2.0 0_100501

English _51

● appendix

appendix

SHORTCUT KEYS

Function Key

CAMERA SET

DAY/NIGHT - DAY [PRESET] + [5] + [1] + [2] + [ENTER]

DAY/NIGHT - NIGHT [PRESET] + [5] + [1] + [3] + [ENTER]

DAY/NIGHT - AUTO [PRESET] + [5] + [1] + [4] + [ENTER]

DAY/NIGHT - EXT [PRESET] + [5] + [1] + [5] + [ENTER]

IRIS – ALC – BACKLIGHT – WDR [PRESET] + [5] + [1] + [6] + [ENTER]

IRIS – ALC – BACKLIGHT – OFF [PRESET] + [5] + [1] + [7] + [ENTER]

IRIS - ALC [PRESET] + [5] + [1] + [8] + [ENTER]

IRIS - MANU [PRESET] + [5] + [1] + [9] + [ENTER]

FOCUS MODE – AF [PRESET] + [5] + [2] + [0] + [ENTER]

FOCUS MODE – MF [PRESET] + [5] + [2] + [1] + [ENTER]

FOCUS MODE – ONEAF [PRESET] + [5] + [2] + [2] + [ENTER]

ALARM SET

AUX OUT CONTROL – OUT1 – ON [PRESET] + [5] + [2] + [3] + [ENTER]

AUX OUT CONTROL – OUT1 – OFF [PRESET] + [5] + [2] + [4] + [ENTER]

AUX OUT CONTROL – OUT2 – ON [PRESET] + [5] + [2] + [5] + [ENTER]

AUX OUT CONTROL – OUT2 – OFF [PRESET] + [5] + [2] + [6] + [ENTER]

AUX OUT CONTROL – OUT3 – ON [PRESET] + [5] + [2] + [7] + [ENTER]

AUX OUT CONTROL – OUT3 – OFF [PRESET] + [5] + [2] + [8] + [ENTER]

OTHER SET

PROPORTIONAL P/T – ON [PRESET] + [5] + [2] + [9] + [ENTER]

PROPORTIONAL P/T – OFF [PRESET] + [5] + [3] + [0] + [ENTER]

P/T SPEED – 9 [PRESET] + [5] + [3] + [1] + [ENTER]

P/T SPEED – 5 [PRESET] + [5] + [3] + [2] + [ENTER]

D-FLIP – ON [PRESET] + [5] + [3] + [3] + [ENTER]

D-FLIP – OFF [PRESET] + [5] + [3] + [4] + [ENTER]

AUTO SET

AUTO PLAY – 1 [PRESET] + [5] + [3] + [5] + [ENTER]

AUTO PLAY – 2 [PRESET] + [5] + [3] + [6] + [ENTER]

AUTO PLAY – OFF [PRESET] + [5] + [3] + [7] + [ENTER]

Function

Running A.C (Auto Calibration) [PRESET] + [5] + [3] + [8] + [ENTER]

appendix

52_ appendix

SPECIFICATIONS

Item Description

Product Type

SMART DOME CAMERA

Power Source

AC 24 V (50 Hz)

Use an adaptor over 3A when the heater works.

Power Consumption

16.3W(Camera, Fan) / 47W(Heater ON)

TV Standard

NTSC / PAL STANDARD COLOR SYSTEM

Image Sensor

ExView-HAD PS CCD

Effective Pixels

PAL-752(H) × 582(V)
NTSC-768(H) × 494(V)

TV line frequency

PAL- Horizontal : 15, 625 Hz (INT) / 15, 625 Hz (L/L)

Vertical : 50 Hz (INT) / 50 Hz (L/L)

NTSC- Horizontal : 15, 734 Hz (INT) / 15, 750 Hz (L/L)

Vertical : 59.94 Hz (INT) / 60 Hz (L/L)

Synchronization

INT/LINE LOCK

Resolution

Horizontal : 600 TV LINES
Vertical : 350 TV LINES

S/N Ratio

Approximately 52 dB

Minimum subject
illumination

SENS-UP Illumination Color B/W

Off 50IRE 0.7 Lux 0.07 Lux

Off 30IRE 0.42 Lux 0.042 Lux

Off 15IRE 0.21 Lux 0.021 Lux

x512 50IRE 0.00137 Lux 0.00014 Lux

x512 30IRE 0.00082 Lux 0.00008 Lux

x512 15IRE 0.00041 Lux 0.00004 Lux

WDR

x128

Signal Output

COMPOSITE VIDEO OUT : 1.0 Vp-p 75 ohms/BNC

Lens

x43 Zoom Lens Integrated
Focal length : 3.2 ~ 138.5mm
Aperture : F1.65(Wide) F3.7(Tele)

- MOD(Minimum Object Distance) : 1000mm

English _53

● appendix

Item Description

PAN

PAN range : 360˚Endless
Preset Pan Speed : 600˚/sec, maximum
Manual Pan Speed : 0.01˚~ 180˚/sec

TILT

Tilt range : -6˚~186˚
Preset Tilt Speed : 600˚/sec, maximum
Manual Tilt Speed : 0.01˚~ 180˚/sec

Remote Control

RS485(Half&Full Duplex)/RS422,
Data on Coaxial Cable

Alarm

Alarm Inputs : 8 IN
Alarm Outputs : 3 OUT (2 Open collector 1 relay)

Operation Temperature

-50°C(absolute minimum) ~ +50°C

Operation Humidity

~90%

Dimensions (Ø x H)

228(Ø) x 256(H)mm

Weight

5.6 Kg

Product Color

Light Gray

appendix

54_ appendix

PRODUCT APPEARANCE

256mm

240mm

Ø216mm (Housing Body)

Ø228mm (Shield Sun)

Correct Disposal of This Product

(Waste Electrical & Electronic Equipment)

(Applicable in the European Union and other European countries with separate collection systems)

This marking on the product, accessories or literature indicates that the product and its electronic accessories
(e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their
working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal,
please separate these items from other types of waste and recycle them responsibly to promote the sustainable
reuse of material resources.

Household users should contact either the retailer where they purchased this product, or their local government
office, for details of where and how they can take these items for environmentally safe recycling.

Business us ers should conta ct their supplier and check the terms and conditions of the purcha se contract.
This product and its electronic accessories should not be mixed with other commercial wastes for disposal.

SALES NETWORK

SAMSUNG TECHWIN CO., LTD.

Samsungtechwin R&D Center, 701, Sampyeong-dong, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea, 463-400
TEL : [phone]~60 FAX : [phone]

SAMSUNG TECHWIN AMERICA Inc.

1480 Charles Willard St, Carson, CA 90746, UNITED STATES
Tol Free : [phone] FAX : [phone]
www.samsungcctvusa.com

SAMSUNG TECHWIN EUROPE LTD.

Samsung House, 1000 Hillswood Drive, Hillswood Business Park
Chertsey, Surrey, UNITED KINGDOM KT16 OPS
TEL : [phone] FAX : [phone]

www.samsungtechwin.com
www.samsungsecurity.com
