*Some of the contents of this manual may differ from your phone, depending on the software installed or your service provider.

World Wide Web

http://www.samsungmobile.com

Draft

SCH-U710

User’s Guide

Intellectual Property

All Intellectual Property, as defined below, owned by or which is otherwise the property of Samsung or its respective suppliers relating to the SAMSUNG Phone, including but not limited to, accessories, parts, or software relating there to (the “Phone System”), is proprietary to Samsung and protected under federal laws, state laws, and international treaty provisions. Intellectual Property includes, but is not limited to, inventions (patentable or unpatentable), patents, trade secrets, copyrights, software, computer programs, and related documentation and other works of authorship. You may not infringe or otherwise violate the rights secured by the Intellectual Property. Moreover, you agree that you will not (and will not attempt to) modify, prepare derivative works of, reverse engineer, decompile, disassemble, or otherwise attempt to create source code from the software. No title to or ownership in the Intellectual Property is transferred to you. All applicable rights of the Intellectual Property shall remain with SAMSUNG and its suppliers.

Samsung Telecommunications

America (STA), Inc.

Headquarters:

1301 East Lookout Drive Suite 150 Richardson,

TX 75082

Tel: 972.761.7000

Customer Care Center:

1601 E. Plano Parkway, Suite 150 Plano, TX 75074 Toll Free Tel: 1.888.987.HELP (4357)

Fax: 972.801.6065

Internet Address: http://www.samsungusa.com

©2004 Samsung Telecommunications America, Inc. is a registered trademark of Samsung Electronics America, Inc. and its related entities.

Licensed by Qualcomm Incorporated under one or more of the following patents: U.S. Patent No. 4, 901, 307; 5, 056, 109; 5, 099, 204; 5,101, 501; 5, 103, 459; 5, 107, 225; 5, 109, 390.

Openwave® is a registered Trademark of Openwave, Inc. RSA® is a registered TrademarSk RSA Security, Inc.

Disclaimer of Warranties; Exclusion of Liability

EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY CONTAINED ON THE WARRANTY PAGE ENCLOSED

WITH THE PRODUCT, THE PURCHASER TAKES THE PRODUCT "AS IS", AND SAMSUNG MAKES NO EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT, INCLUDING BUT

NOT LIMITED TO THE MERCHANTABILITY OF THE PRODUCT OR ITS FITNESS FOR ANY PARTICULAR

PURPOSE OR USE; THE DESIGN, CONDITION OR QUALITY OF THE PRODUCT; THE PERFORMANCE OF THE PRODUCT; THE WORKMANSHIP OF THE PRODUCT OR THE COMPONENTS CONTAINED THEREIN; OR COMPLIANCE OF THE PRODUCT WITH THE

REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION OR CONTRACT PERTAINING THERETO. NOTHING

CONTAINED IN THE INSTRUCTION MANUAL SHALL BE CONSTRUED TO CREATE AN EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT. IN ADDITION, SAMSUNG

SHALL NOT BE LIABLE FOR ANY DAMAGES OF ANY KIND RESULTING FROM THE PURCHASE OR USE OF

THE PRODUCT OR ARISING FROM THE BREACH OF THE EXPRESS WARRANTY, INCLUDING INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, OR LOSS OF ANTICIPATED PROFITS OR BENEFITS.

Important safety

precautions

Failure to comply with the following precautions may be dangerous or illegal.

Use road safety at all times

Do not use a hand-held phone while driving. Park the vehicle first.

Switch off the phone when refuelling

Do not use the phone at a refuelling point (service station) or near fuels or chemicals.

Switch off in an aircraft

Wireless phones can cause interference. Using them in an aircraft is both illegal and dangerous.

Switch off the phone near all medical equipment

Hospitals or health care facilities may be using equipment that could be sensitive to external radio frequency energy. Follow any regulations or rules in force.

Interference

All wireless phones may be subject to interference, which could affect their performance.

Be aware of special regulations

Meet any special regulations in force in any area and always switch off your phone whenever it is forbidden to use it, or when it may cause interference or danger.

Water resistance

Your phone is not water-resistant. Keep it dry.

Sensible use

Use only in the normal position (held to the ear). Avoid unnecessary contact with the antenna when the phone is switched on.

Emergency call

Key in the emergency number for your present location, then press [].

Keep your phone away from small children

Keep the phone and all its parts, including accessories, out of the reach of small children.

Accessories and batteries

Use only Samsung-approved accessories and batteries. Use of any unauthorized accessories could damage your phone and may be dangerous.

The phone could explode if the battery is replaced with an incorrect type.

Dispose used batteries according to the manufacturer’s instructions.

Qualified service

Only qualified service personnel may repair your phone.

For more detailed safety information, see "Health and safety information" on page 17.

precautions safety Important

1

Contents

Unpack

3





Make sure you have each item



Get started

4





First steps to operate your phone



Menu functions

8





All menu options listed



Solve problems

17





Help and personal needs



Health and safety information

19





2

Unpack

Make sure you have each item

Phone

Travel adapter

Battery

User’s manual

You can obtain the following accessories for your phone from your local Samsung dealer.

• Headset

• Battery charger

Portable hands-free • Data link cable

Standard/Extended • Travel charger/ battery adapter

• Car charger/adapter • Bluetooth full hands-free kit

• Bluetooth headset kit

3

Samsung SCHU710 Users Manual

Get started

First steps to operate your phone

Install and charge the phone

1

Install the battery:

2

Plug the adapter into



To remove the battery,



the phone.



slide the battery catch







toward the top of the







phone and hold it.





3 Plug the adapter into a standard AC wall outlet.

4 When the phone is completely charged (the battery icon stops blinking), unplug the adapter from the power outlet.

5 Remove the adapter from the phone.

Low battery indicator

When the battery is low:

a warning tone sounds,

the battery low message displays, and

the empty battery icon blinks.

If the battery level becomes too low, the phone automatically turns off. Recharge your battery.

Power on or off

Power on

Do not turn on the phone when mobile phone use is prohibited.

Power off

1.Open the phone.

2.Press and hold [] to turn on the phone.

3.If necessary, enter the PIN and press <OK>

1.Open the phone.

2.Press and hold [].

4

Keys and display

Key(s) Description

Softkeys Perform the function indicated on the bottom line of the display.

Navigation In Standby mode, access menu options keys directly.

In Menu mode, scroll through the menu options.

OK key In Idle mode, enters Menu mode.

In Menu mode, selects the highlighted menu option.

SEND key Sends or answers a call.

In Standby mode, retrieves the last number dialed, missed, or received.

CLR key Deletes characters from the display.

In Menu mode, returns to the previous menu level.

Key(s) Description

Speaker Turns on the external speaker during a call. phone key

END key Ends a call. Hold down to switch the phone on and off.

In Menu mode, cancels input and returns the phone to Idle mode.

Numeric Enter numbers, letters, and some special keys characters.

In Standby mode, hold [1] down to access your voicemail.

*/# keys Enter special characters.

Use for some special functions.

started Get

5

Get started

Volume

Adjusts the phone volume.

keys

In Standby mode, with the phone open,

(on the left)



adjusts the master volume. With the phone



closed, hold down to turn on the display.



In Menu mode, scrolls through the menu



options.





Camera key In Standby mode, with the phone open, turns on the camera. With the phone closed, hold down to turn on the camera.

In Capture mode, takes a photo.

6

Overview of menu functions

To access Menu mode, press [OK] in Standby mode.







3 Contacts

1 Get it now







1

New Contact

1

Music & Tones

2

Contact List

2

Picture & Video

3

Groups

3

Games

4

Speed Dials

4

News & info

5

My Name Card

5

Tools on the Go







6

Extras



4

Recent calls

2 Messaging



1

Missed





2

Received

1

New Message

3

Dialed

2

Inbox

4

All

3

Sent

5

View Timers

4

Drafts







5

Voicemail



5

Settings & tools

6

E-Mail



1

My Account

7

Mobile IM

2

Tools

8

Chat

3

Bluetooth Menu









4

Sounds Settings





5

Display Settings





6

Phone Settings





7

Call Settings





8

Memoty





9

Phone Info

7

Menu functions

All menu options listed

Get it now

With Get it now, you can download full featured applications over the air including games, personalized ring tones, pictures, videos. You can also browse the web to catch up on all the latest news and information.

To access this menu, press [OK] in Standby mode and select Get it now.

Music & Tones

Use this menu to download your favorite ring tones and set them as your ring tone. You can record voice memos in this menu as well.

Picture & Video

Use this menu to take photos or record videos and manage photo and video albums separately. You can

furthermore upload your pictures or videos through the wireless web, and get Pix/Flix services provided by your service provider.

Games

Use this menu to download a broad category of games that you can play on your phone.

News & Info

Use this menu to view the latest news and a variety of updated information by your service provider.

Tools on the go

Use this menu to download applications that keep you in touch with the world, keep you organized, and help you find the coolest spots.

Extras

8

Messaging

Use the Messaging menu to send and receive short text messages to and from other mobile phones. In addition, your phone supports the Enhanced Messaging Service (EMS), which enables you to include simple pictures, melodies, and animated images in your messages. You can also use the voice mail feature.

To access this menu, press [OK] in Standby mode and select Messaging.

New Message

In this menu, you can create and send new text messages and multimedia messages using various images and sounds (pix message) and video clips (flix message).

Inbox

You can view the messages you have received in this message box. When you access this menu, a list of messages displays.

Sent

You can view the messages you have sent in this message box. When you access this menu, a list of messages displays.

Drafts

You can view the messages you have saved in this message box while creating a message.

Voicemail

Use this menu to store the number of the voice mail server and access your voice mails.

You must enter the voice server number before you can access your voice mails. Your service provider can give the voice server number.

functions Menu

9

Menu functions

E-Mail

You can view the received e-mails that include text, audio, and images in this menu.

Mobile IM

With Mobile IM, you can send short, simple messages that are delivered immediately to users online at that moment.

Before using this feature, you need to subscribe to a messenger service. For further details, contact your service provider.

Chat

Use this menu to have a conversation with your friends, family, or co-workers by sending and receiving instant messages.

Contacts

You can store phone numbers in your phone.

To access this menu, press [OK] in Standby mode and select Contacts.

New Contact

This menu allows you to add a new entry to your Contacts. A name can contain up to 7 numbers in different categories; Mobile 1/2, Home, Work, Email 1/2, and Fax.

Contact List

This menu allows you to find an entry by scrolling through the Contact list or by entering the entry name you want.

10

Groups

Use this menu to add new groups or manage the existing groups in your Contacts. You can also send text or multimedia messages to the selected group.

Speed Dials

Once you have stored phone numbers in Contacts, you can set up to 500 speed-dial entries and then dial them easily whenever you want, simply by pressing and holding the associated number key(s) in Standby mode.

My Name Card

Use this menu to create a name card and send it to other people.

Recent calls

Use this menu to view the calls you have dialed, received, or missed, and the length of your calls.

To access this menu, press [OK] in Standby mode and select Recent calls.

Missed

The phone stores the most recent numbers you have failed to answer. When you access this menu, a list of the missed calls displays.

Received

This menu lets you view the most recent calls you have received if you are a subscribe to the Caller Line Identification service. Contact your service provider for further details about this service. When you access this menu, a list of the incoming calls displays.

functions Menu

11
