QNO-6082R
2 MP Network IR Bullet Camera
Key Features
2 Megapixel (1920 x 1080) resolution
•
• 0.095Lux (Color), 0Lux (B/W, IR LED on)
• 3.2 ~ 10mm (3.1x) motorized varifocal lens
30fps@2 MP (H.265/H.264)
•
• H.265, H.264, MJPEG codec supported, Multiple streaming
Defocus detection, Directional/Virtual Line detection, Motion detection, Enter/Exit, Tampering
•
Hallway view (90˚/270˚), LDC support , WiseStream II support
•
•
Micro SD/SDHC/SDXC memory slot (Maximum 128GB)
• IR viewable length 30m
• IP66, IK10, PoE/12VDC
Dimensions Accessories (Optional)
Unit : mm (inch)
Ø78 (3.07")
Ø78.0 (3.07")
Ø83.2 (3.28")
Ø83.2 (3.28")
160.5 (6.32")
160.5 (6.32")
87.0 (3.43")
87.0 (3.43")
144.0 (5.67")
144 (5.67")
259.8 (10.23")
259.8 (10.23")
FIRST EDITION 072019 © 2019 Hanwha Techwin Co., Ltd. All rights reserved.
SBP-302PMSBO-100B1
QNO-6082R
VIDEO
Imaging Device
Eective Pixels 1920(H) x 1080(V)
Minimum Illumination
Video Out
LENS
Focal Length (Zoom Ratio) 3.2~10mm(3.1x) motorized varifocal
Maximum Aperture Ratio
Angular Field of View
Focus Control Simple focus
OPERATIONAL
IR Viewable Length 30m (98.42ft)
Camera Title
Day & Night Auto (ICR)
Backlight Compensation BLC, WDR, SSDR
Wide Dynamic Range 120dB
Digital Noise Reduction SSNR
Motion Detection 4ea, polygonal zones
Privacy Masking 6ea, rectangular zones
Gain Control Low / Middle / High
White Balance ATW / AWC / Manual / Indoor / Outdoor
LDC Support
Electronic Shutter Speed Minimum / Maximum / Anti icker (1/5~1/12,000sec)
Video Rotation Flip, Mirror, Hallway view (90˚/270˚)
Analytics
Alarm I/O Input 1ea / Output 1ea
Alarm Triggers Analytics, Network disconnect, Alarm input
Alarm events
Audio In
NETWORK
Ethernet RJ-45 (10/100BASE-T)
Video Compression H.265/H.264: Main/High, MJPEG
Resolution
Maximum Framerate
Smart Codec
Video Quality Adjustment
Bitrate Control
Streaming
Audio Compression
1/2.8" 2 MP CMOS
Color : 0.095Lux (F1.6, 1/30sec)
BW : 0Lux (IR LED on)
CVBS : 1.0 Vp-p / 75 composite, 720 x 480 for installation
F1.6(Wide)~F2.9(Tele)
H : 109.0°(Wide)~33.2°(Tele)
V : 57.4°(Wide)~18.7°(Tele)
D : 132.0°(Wide)~38.0°(Tele)
Displayed up to 85 characters, 5 lines, English / Numeric / Special & International characters, 6 colors, Transparency, Auto scale by resolution
Defocus detection, Directional/Virtual Line detection, Motion detection, Enter/Exit, Tampering
File upload via FTP and e-mail,
Notification via e-mail,
SD/SDHC/SDXC or NAS recording at event triggers,
Alarm output, Handover
Selectable (mic in/line in)
Supply voltage : 2.5VDC(4mA), Input impedance : 2K Ohm
1920 x 1080, 1280 x 960, 1280 x 720, 800 x 600, 800 x 448, 720 x 576, 720 x 480, 640 x 480,
640 x 360
H.265/H.264 : Maximum 30fps
MJPEG : Maximum 15fps
Manual (5ea area), WiseStream II
H.264/H.265 : Target bitrate level control
MJPEG : Quality Level control
H.264/H.265 : CBR or VBR
MJPEG : VBR
Unicast (6 users) / Multicast
Multiple streaming (Up to 3 proles)
G.711 u-law / G.726 Selectable
G.726(ADPCM) 8KHz, G.711 8KHz
G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps
FIRST EDITION 072019 © 2019 Hanwha Techwin Co., Ltd. All rights reserved.
QNO-6082R
Protocol
Security
Edge Storage
Application Programming Interface
Webpage Language
Web Viewer
Memory 512MB RAM, 256MB Flash
ENVIRONMENTAL
Operating Temperature / Humidity
Storage Temperature / Humidity -30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH
Certication IP66, IK10
ELECTRICAL
Input Voltage PoE(IEEE802.3af, Class3), 12VDC
Power Consumption
MECHANICAL
Color / Material Dark grey / Aluminum
Product Dimensions / Weight
Gangbox Compatibility
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP,
SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP
HTTPS (SSL) login authentication, Digest login authentication,
IP address ltering, User access log,
802.1X authentication (EAP-TLS, EAP-LEAP)
Micro SD/SDHC/SDXC 1 slot maximum 128GB
ONVIF Prole S/G/T
SUNAPI (HTTP API)
Wisenet open platform
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish,
Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek
Supported OS : Windows 7, 8.1, 10, Mac OS X 10.12, 10.13, 10.14
Recommended Browser : Google Chrome
Supported Browser : MS Explorer 11, MS Edge, Mozilla Firefox (Window 64-bit only),
Apple Safari (Mac OS X only)
-30°C ~ +55°C (-22°F ~ +131°F) / Less than 90% RH
* Start up should be done at above -20°C
PoE : Maximum 7.4W, typical 5.4W
12VDC : Maximum 6.5W, typical 4.8W
Ø78.0 x 259.8mm (Ø3.07 x 10.23"), 900g (1.984 lb)
Single, double, 4" octagon gangbox with optional SBO-100B1
*
The lastest product information / specification can be found at hanwhasecurity.com
* Design and specications are subject to change without notice.
* Wisenet is the proprietary brand of Hanwha Techwin.
