Samsung N900W8 User Manual
User Manual
N900W8
www.samsung.com
About this manual
This device provides high quality mobile communication and entertainment using Samsung’s
high standards and technological expertise. This user manual is specially designed to detail
the device’s functions and features.
•
Please read this manual before using the device to ensure safe and proper use.
•
Descriptions are based on the device’s default settings.
•
Images and screenshots may differ in appearance from the actual product.
•
Content may differ from the final product, or from software provided by service providers
or carriers, and is subject to change without prior notice. For the latest version of the
manual, refer to the Samsung website,
•
Content (high quality content) that requires high CPU and RAM usage will affect the
overall performance of the device. Applications related to the content may not work
properly depending on the device’s specifications and the environment that it is used in.
•
Available features and additional services may vary by device, software, or service
provider.
•
Applications and their functions may vary by country, region, or hardware specifications.
Samsung is not liable for performance issues caused by applications from any provider
other than Samsung.
•
Samsung is not liable for performance issues or incompatibilities caused by edited
registry settings or modified operating system software. Attempting to customize the
operating system may cause the device or applications to work improperly.
•
Software, sound sources, wallpapers, images, and other media provided with this device
are licensed for limited use. Extracting and using these materials for commercial or other
purposes is an infringement of copyright laws. Users are entirely responsible for illegal
www.samsung.com
.
use of media.
•
You may incur additional charges for data services, such as messaging, uploading and
downloading, auto-syncing, or using location services. To avoid additional charges, select
an appropriate data tariff plan. For details, contact your service provider.
2
About this manual
•
Default applications that come with the device are subject to updates and may no longer
be supported without prior notice. If you have questions about an application provided
with the device, contact a Samsung Service Centre. For user-installed applications,
contact service providers.
•
Modifying the device’s operating system or installing software from unofficial sources
may result in device malfunctions and data corruption or loss. These actions are violations
of your Samsung licence agreement and will void your warranty.
Instructional icons
Warning: situations that could cause injury to yourself or others
Caution: situations that could cause damage to your device or other equipment
Note: notes, usage tips, or additional information
Copyright
Copyright © 2013 Samsung Electronics
This guide is protected under international copyright laws.
No part of this guide may be reproduced, distributed, translated, or transmitted in any form or
by any means, electronic or mechanical, including photocopying, recording, or storing in any
information storage and retrieval system, without the prior written permission of Samsung
Electronics.
3
About this manual
Trademarks
•
SAMSUNG and the SAMSUNG logo are registered trademarks of Samsung Electronics.
•
The Android logo, Google™, Google Maps™, Gmail™, YouTube™, and Google Play™
Store are trademarks of Google, Inc.
•
Bluetooth® is a registered trademark of Bluetooth SIG, Inc. worldwide.
•
Wi-Fi®, Wi-Fi Protected Setup™, Wi-Fi Direct™, Wi-Fi CERTIFIED™, and the Wi-Fi logo are
registered trademarks of the Wi-Fi Alliance.
•
All other trademarks and copyrights are the property of their respective owners.
IC Notice
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is
subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired
operation of the device.
4
Table of Contents
Getting started
8 Device layout
9 Buttons
10 S Pen
10 Package contents
11 Installing the SIM card and battery
14 Charging the battery
17 Inserting a memory card
19 Replacing the S Pen nib
20 Turning the device on and off
20 Holding the device
20 Adjusting the volume
21 Switching to silent mode
38 Samsung Smart Scroll
39 Adjusting touch screen sensitivity
39 Activating Multi Window
41 Notifications
42 Home screen
44 Locked screen
46 Using applications
46 Applications screen
47 Help
47 One-handed operation
48 Entering text
50 Connecting to a Wi-Fi network
51 Setting up accounts
52 Transferring files
53 Securing the device
Basics
22 Indicator icons
23 Using the touch screen
27 Control motions
30 Palm motions
31 Air Gesture
33 Using the S Pen
34 Air command
36 S Pen Keeper
37 Air view
38 Samsung Smart Pause
55 Upgrading the device
Communication
56 Phone
60 Contacts
64 Messages
66 Email
68 Gmail
70 Hangouts
70 ChatON
5
Table of Contents
Web & network
71 Internet
72 Chrome
73 Bluetooth
74 Screen Mirroring
75 Samsung Link
76 Group Play
78 NFC
79 S Beam
80 WatchON
Media
81 Music
83 Camera
90 Gallery
94 Story Album
97 Video
99 YouTube
100 My magazine
101 Flipboard
102 SketchBook for Galaxy
103 Bloomberg+
106 Play Magazines
106 Play Movies
107 Play Music
Utilities
108 S Note
115 S Planner
117 Dropbox
118 Cloud
119 Clock
121 Calculator
121 S Health
129 S Translator
130 Voice Recorder
132 S Voice
133 S Finder
134 Google
134 Voice Search
135 Scrapbook
136 My Files
137 Downloads
137 TripAdvisor
137 Evernote
Application & media stores
104 Play Store
105 Samsung Hub
105 Samsung Apps
106 Play Books
106 Play Games
138 KNOX
Travel & local
139 Maps
6
Table of Contents
Settings
140 About Settings
140 Connections
144 Device
151 Controls
157 General
Troubleshooting
Health and Safety
7
Getting started
Proximity/Light/
Microphone for
Device layout
Notification light
Earpiece
Home button
Menu button
Microphone
Gesture sensor
Front camera
Power button
Touch screen
Back button
Speaker
Multipurpose jack
IrLED
GPS antenna
Rear camera
Flash
S Pen
speakerphone
Headset jack
Volume button
Back cover
Main antenna
8
Getting started
The microphone at the top of the device is active only when you use the speakerphone or
take videos.
•
Do not cover the antenna area with your hands or other objects. This may cause
connectivity problems or drain the battery.
•
Do not use a screen protector. This causes sensor malfunctions.
•
Do not allow water to contact the touch screen. The touch screen may malfunction
in humid conditions or when exposed to water.
Buttons
Button Function
Power
Menu
Home
Back
Volume
•
Press and hold to turn the device on or off.
•
Press and hold for more than 7 seconds to reset the device if
it has fatal errors or hang-ups, or freezes.
•
Press to lock or unlock the device. The device goes into lock
mode when the touch screen turns off.
•
Tap to open a list of options available for the current screen.
•
Tap and hold on the Home screen to launch S Finder.
•
Press to return to the Home screen.
•
From the Home screen, press to open My Magazine.
•
Press and hold to open the list of recent applications.
•
Tap to return to the previous screen.
•
Press to adjust the device volume.
9
Getting started
S Pen
S Pen button
S Pen tip
Name Function
S Pen tip
S Pen button
•
Perform basic S Pen actions. (p. 33)
•
Perform advanced S Pen actions. (p. 34)
Package contents
Check the product box for the following items:
•
Device
•
Battery
•
Quick start guide
•
The items supplied with the device and any available accessories may vary
depending on the region or service provider.
•
The supplied items are designed only for this device and may not be compatible
with other devices.
•
Appearances and specifications are subject to change without prior notice.
•
You can purchase additional accessories from your local Samsung retailer. Make
sure they are compatible with the device before purchase.
•
Other accessories may not be compatible with your device.
•
Use only Samsung-approved accessories. Malfunctions caused by using
unapproved accessories are not covered by the warranty service.
•
Availability of all accessories is subject to change depending entirely on
manufacturing companies. For more information about available accessories, refer
to the Samsung website.
10
Getting started
Installing the SIM card and battery
Insert the SIM card provided by the mobile telephone service provider, and the included
battery.
•
Only microSIM cards work with the device.
•
Some LTE services may not be available depending on the service provider. For
details about service availability, contact your service provider.
Remove the back cover.
1
Be careful not to damage your fingernails when you remove the back cover.
Do not bend or twist the back cover excessively. Doing so may damage the cover.
Insert the SIM card with the gold-coloured contacts facing downwards.
2
11
Getting started
Push the SIM card into the slot until it locks in place.
3
•
Do not insert a memory card into the SIM card slot. If a memory card happens to
be lodged in the SIM card slot, take the device to a Samsung Service Centre to
remove the memory card.
•
Use caution not to lose or let others use the SIM card. Samsung is not responsible
for any damages or inconveniences caused by lost or stolen cards.
Insert the battery.
4
Replace the back cover.
5
12
Getting started
Removing the SIM card and battery
Remove the back cover.
1
Pull out the battery.
2
Press the SIM card gently with your finger, and then pull it out.
3
13
Getting started
Charging the battery
Use the charger to charge the battery before using it for the first time. A computer can be also
used to charge the device by connecting them via the USB cable.
Use only Samsung-approved chargers, batteries, and cables. Unapproved chargers or
cables can cause the battery to explode or damage the device.
•
When the battery power is low, the device emits a warning tone and displays a low
battery power message.
•
If the battery is completely discharged, the device cannot be turned on
immediately when the charger is connected. Allow a depleted battery to charge for
a few minutes before turning on the device.
•
If you use multiple applications at once, network applications, or applications
that need a connection to another device, the battery will drain quickly. To avoid
disconnecting from the network or losing power during a data transfer, always use
these applications after fully charging the battery.
•
This device is compatible with USB 3.0 and under devices. When using a USB 3.0
device, make sure to use a USB 3.0 cable.
Charging with the charger
Connect the USB cable to the USB power adapter and then plug the end of the USB cable into
the multipurpose jack.
14
Getting started
When using a USB 2.0 cable, plug the USB cable into the right side of the multipurpose jack as
shown in the image below.
Connecting the charger improperly may cause serious damage to the device. Any
damage caused by misuse is not covered by the warranty.
•
The device can be used while it is charging, but it may take longer to fully charge
the battery.
•
If the device receives an unstable power supply while charging, the touch screen
may not function. If this happens, unplug the charger from the device.
•
While charging, the device may heat up. This is normal and should not affect the
device’s lifespan or performance. If the battery gets hotter than usual, the charger
may stop charging.
•
If the device is not charging properly, take the device and the charger to a
Samsung Service Centre.
After fully charging, disconnect the device from the charger. First unplug the charger from the
device, and then unplug it from the electric socket.
Do not remove the battery before removing the charger. This may damage the
device.
To save energy, unplug the charger when not in use. The charger does not have a
power switch, so you must unplug the charger from the electric socket when not in
use to avoid wasting power. The device should remain close to the electric socket
while charging.
15
Getting started
Checking the battery charge status
When you charge the battery while the device is off, the following icons will show the current
battery charge status:
Charging Fully charged
Reducing the battery consumption
Your device provides options that help you save battery power. By customizing these options
and deactivating features in the background, you can use the device longer between charges:
•
When you are not using the device, switch to sleep mode by pressing the Power button.
•
Close unnecessary applications with the task manager.
•
Deactivate the Bluetooth feature.
•
Deactivate the Wi-Fi feature.
•
Deactivate auto-syncing of applications.
•
Decrease the backlight time.
•
Decrease the brightness of the display.
16
Getting started
Inserting a memory card
Your device accepts memory cards with maximum capacity of 64 GB. Depending on the
memory card manufacturer and type, some memory cards may not be compatible with your
device.
•
Some memory cards may not be fully compatible with the device. Using an
incompatible card may damage the device or the memory card, or corrupt the data
stored in it.
•
Use caution to insert the memory card right-side up.
•
The device supports the FAT and the exFAT file systems for memory cards. When
inserting a card formatted in a different file system, the device asks to reformat the
memory card.
•
Frequent writing and erasing of data shortens the lifespan of memory cards.
•
When inserting a memory card into the device, the memory card’s file directory
appears in the
Remove the back cover.
1
Insert a memory card with the gold-coloured contacts facing downwards.
2
Push the memory card into the slot until it locks in place.
3
Samsung
→
My Files
→
All
→
SD memory card
folder.
Replace the back cover.
4
17
Getting started
Removing the memory card
Before removing the memory card, first unmount it for safe removal. On the Home screen, tap
Apps
→
Settings
Remove the back cover.
1
Push the memory card until it disengages from the device, and then pull it out.
2
Replace the back cover.
3
Do not remove the memory card while the device is transferring or accessing
information. Doing so can cause data to be lost or corrupted or damage to the
memory card or device. Samsung is not responsible for losses that result from the
misuse of damaged memory cards, including the loss of data.
→
General
→
Storage
→
Unmount SD card
.
Formatting the memory card
A memory card formatted on a computer may not be compatible with the device. Format the
memory card on the device.
On the Home screen, tap
Format SD card
Before formatting the memory card, remember to make backup copies of all
important data stored on the device. The manufacturer’s warranty does not cover loss
of data resulting from user actions.
→
Erase everything
Apps
→
Settings
→
General
.
→
Storage
→
Format SD card
→
18
Getting started
Replacing the S Pen nib
While using the S Pen, the S Pen nib may get dull. If the nib is dull, replace it with a new one.
Hold the nib with the tweezer firmly, and then pull it out.
1
Insert a new nib into the S Pen until you hear a click.
2
Do not let your finger get caught between the tweezer and the nib.
•
Do not reuse old nibs. Doing so may cause the S Pen to malfunction.
•
Do not press the nib excessively when inserting the nib into the S Pen.
•
Do not insert the round end of the nib into the S Pen. This may cause damage to
the S Pen or your device.
The black-coloured nib has a white rubber cap on the tip. If the rubber cap is worn
down, replace the nib with a new one.
19
Getting started
Turning the device on and off
When turning on the device for the first time, follow the on-screen instructions to set up your
device.
Press and hold the Power button for a few seconds to turn on the device on and off.
•
Follow all posted warnings and directions from authorized personnel in areas
where the use of wireless devices is restricted, such as aeroplanes and hospitals.
•
Press and hold the Power button and tap
features.
To turn off the device, press and hold the Power button, and then tap
Flight mode
to disable the wireless
Power off
.
Holding the device
Do not cover the antenna area with your hands or other objects. This may cause connectivity
problems or drain the battery.
Adjusting the volume
Press the Volume button up or down to adjust the ringtone volume, or to adjust the sound
volume when playing music or video.
20
Getting started
Switching to silent mode
Use one of the following methods:
•
Press and hold the Volume button down until it switches to silent mode.
•
Press and hold the Power button, and then tap
•
Open the notifications panel at the top of the screen, and then tap
Mute
or
Vibrate
.
Sound
or
Vibrate
.
21
Basics
Indicator icons
The icons displayed at the top of the screen provide information about the status of the
device. The icons listed in the table below are most common.
Icon Meaning
No signal
Signal strength
Roaming (outside of normal service area)
GPRS network connected
EDGE network connected
UMTS network connected
HSDPA network connected
HSPA+ network connected
LTE network connected
Wi-Fi connected
Bluetooth feature activated
GPS activated
Call in progress
Missed call
Air gesture feature activated
Smart screen feature activated
Synced with the web
Connected to computer
No SIM card
New text or multimedia message
Alarm activated
S Pen removed
22
Basics
Icon Meaning
Silent mode activated
Vibration mode activated
Flight mode activated
Error occurred or caution required
Battery power level
Using the touch screen
Use only fingers or the S Pen to use the touch screen.
•
Do not allow the touch screen to come into contact with other electrical devices.
Electrostatic discharges can cause the touch screen to malfunction.
•
To avoid damaging the touch screen, do not tap it with anything sharp or apply
excessive pressure to it with your fingertips.
•
The device may not recognize touch inputs close to the edges of the screen, which
are outside of the touch input area.
•
Leaving the touch screen idle for extended periods may result in afterimages
(screen burn-in) or ghosting. Turn off the touch screen when you do not use the
device.
23
Basics
Finger gestures
Tapping
To open an application, to select a menu item, to press an on-screen button, or to enter a
character using the on-screen keyboard, tap it with a finger.
Tapping and holding
Tap and hold an item for more than 2 seconds to access available options.
24
Basics
Dragging
To move an icon, thumbnail, or preview to a new location, tap and hold it and drag it to the
target position.
Double-tapping
Double-tap on a webpage, map, or image to zoom in a part. Double-tap again to return.
25
Basics
Flicking
Flick left or right on the Home screen or the Applications screen to see another panel. Flick up
or down to scroll through a webpage or a list, such as contacts.
Pinching
Spread two fingers apart on a webpage, map, or image to zoom in a part. Pinch to zoom out.
26
Basics
Control motions
Simple motions allow easy control of the device.
Before using motions, make sure the motion feature is activated. On the Home screen, tap
Apps
→
Settings
Excessive shaking or impact to the device may result in unintended inputs. Control
motions properly.
Rotating the screen
Many applications allow display in either portrait or landscape orientation. Rotating the
device causes the display to automatically adjust to fit the new screen orientation.
→
Controls
→
Motions
, and then drag the
Motions
switch to the right.
To prevent the display from rotating automatically, open the notifications panel and deselect
Screen rotation
•
Some applications do not allow screen rotation.
•
Some applications display a different screen depending on the orientation. The
calculator turns into a scientific calculator when rotated to landscape.
.
27
Basics
Picking up
When you pick up the device after it has been idle for some time or when the screen has
turned off, it vibrates if you have missed calls or new messages.
Holding to ear
While viewing call, message, or contact details, pick up and hold the device to your ear to
make a call.
28
Basics
Panning to browse
Turning over
Turn over the device to mute ringtone or pause media playback.
29
Basics
Tilting
Tap and hold two points on the screen, and then tilt the device back and forth to zoom in or
out.
Palm motions
Use palm motions to control the device by touching the screen.
Before using motions, make sure the palm motion feature is activated. On the Home screen,
tap
Apps
→
Settings
to the right.
Sweeping
Sweep your hand across the screen to capture a screenshot. The image is saved in
Screenshots
. It is not possible to capture a screenshot while using some applications.
→
Controls
→
Palm motion
, and then drag the
Palm motion
Gallery
switch
→
30
Loading...
