COLOR TELEVISION RECEIVER

Chassis : KS2A(REV.1) Model : CT15K8W6X/XAP

CL25K4W7X/XAX CL29C1W7FX/XAP MR29410X/TCE

COLOR TELEVISION RECEIVER CONTENTS

Precautions

Reference Information

Specifications

Alignment and Adjustments

Troubleshooting

Exploded Views and Parts List

Electrical Parts List

Block Diagrams

Wiring Diagram

Schematic Diagrams

10.

ELECTRONICS

Printed in Korea

3KS2A-SMX-2952

1. Precautions

1-1 Safety Precautions

1. Be sure that all of the built-in protective devices are replaced. Restore any missing protective shields.

2. When reinstalling the chassis and its assemblies, be sure to restore all protective devices, including: nonmetallic control knobs and compartment covers.

3. Make sure that there are no cabinet openings through which people—particularly children—might insert fingers and contact dangerous voltages. Such openings include the spacing between the picture tube and the cabinet mask, excessively wide cabinet ventilation slots, and improperly fitted back covers.

If the measured resistance is less than 1.0 megohm or greater than 5.2 megohms, an abnormality exists that must be corrected before the unit is returned to the customer.

4. Leakage Current Hot Check (Figure 1-1): Warning: Do not use an isolation transformer during this test. Use a leakagecurrent tester or a metering system that complies with American National Standards Institute (ANIS C101.1, Leakage Current for Appliances), and Underwriters Laboratories (UL Publication UL1410, 59.7).

5. With the unit completely reassembled, plug the AC line cord directly into the power outlet. With the unit’s AC switch first in the ON position and then OFF, measure the current between a known earth ground (metal water pipe, conduit, etc.) and all exposed metal parts, including: antennas, handle brackets, metal cabinets, screwheads and control shafts. The current measured should not exceed 0.5 milliamp. Reverse the powerplug prongs in the AC outlet and repeat the test.

Fig. 1-1 AC Leakage Test

6. Antenna Cold Check: With the unit’s AC plug disconnected from the AC source, connect an electrical jumper across the two AC prongs. Connect one lead of the ohmmeter to an AC prong. Connect the other lead to the coaxial connector.

7. X-ray Limits: The picture tube is especially designed to prohibit X-ray emissions. To ensure continued X-ray protection, replace the picture tube only with one that is the same type as the original. Carefully reinstall the picture tube shields and mounting hardware; these also provide X-ray protection.

8. High Voltage Limits: High voltage must be measured each time servicing is done on the B+, horizontal deflection or high voltage circuits. Correct operation of the X-ray protection circuits must be reconfirmed whenever they are serviced.

(X-ray protection circuits also may be called

“horizontal disable” or “hold-down”.)

Heed the high voltage limits. These include the X–ray Protection Specifications Label, and the Product Safety and X-ray Warning Note on the service data schematic.

Precautions

Samsung Electronics 1-1

LEAKAGE CURRENT

TESTER

DEVICE UNDER

TEST

TEST ALL

EXPOSED METAL

SURFACES

2-WIRE CORD

ALSO TEST WITH

PLUG REVERSED (USING AC ADAPTER PLUG AS REQUIRED)

EARTH

GROUND

(READING SHOULD

NOT BE ABOVE

0.5mA)

Follow these safety, servicing and ESD precautions to prevent damage and protect against potential hazards such as electrical shock and X-rays.

1-1 Safety Precautions (Continued)

9. High voltage is maintained within specified

limits by close-tolerance, safety-related components and adjustments. If the high voltage exceeds the specified limits, check each of the special components.

10. Design Alteration Warning:

Never alter or add to the mechanical or electrical design of this unit. Example: Do not add auxiliary audio or video connectors. Such alterations might create a safety hazard. Also, any design changes or additions will void the manufacturer’s warranty.

11. Hot Chassis Warning:

Some TV receiver chassis are electrically connected directly to one conductor of the AC power cord. If an isolation transformer is not used, these units may be safely serviced only if the AC power plug is inserted so that the chassis is connected to the ground side of the AC source.

To confirm that the AC power plug is inserted correctly, do the following: Using an AC voltmeter, measure the voltage between the chassis and a known earth ground. If the reading is greater than 1.0V, remove the AC power plug, reverse its polarity and reinsert. Re-measure the voltage between the chassis and ground.

12. Some TV chassis are designed to operate with

85 volts AC between chassis and ground, regardless of the AC plug polarity. These units can be safely serviced only if an isolation transformer inserted between the receiver and the power source.

13. Some TV chassis have a secondary ground

system in addition to the main chassis ground. This secondary ground system is not isolated from the AC power line. The two ground systems are electrically separated by insulating material that must not be defeated or altered.

14. Components, parts and wiring that appear to

have overheated or that are otherwise damaged should be replaced with parts that meet the original specifications. Always determine the cause of damage or overheating, and correct any potential hazards.

15. Observe the original lead dress, especially near the following areas: Antenna wiring, sharp edges, and especially the AC and high voltage power supplies. Always inspect for pinched, out-of-place, or frayed wiring. Do not change the spacing between components and the printed circuit board. Check the AC power cord for damage. Make sure that leads and components do not touch thermally hot parts.

16. Picture Tube Implosion Warning: The picture tube in this receiver employs “integral implosion” protection. To ensure continued implosion protection, make sure that the replacement picture tube is the same as the original.

17. Do not remove, install or handle the picture tube without first putting on shatterproof goggles equipped with side shields. Never handle the picture tube by its neck. Some “in-line” picture tubes are equipped with a permanently attached deflection yoke; do not try to remove such “permanently attached” yokes from the picture tube.

18. Product Safety Notice: Some electrical and mechanical parts have special safety-related characteristics which might not be obvious from visual inspection. These safety features and the protection they give might be lost if the replacement component differs from the original—even if the replacement is rated for higher voltage, wattage, etc.

Components that are critical for safety are indicated in the circuit diagram by shading, ( ) or ( ). Use replacement components that have the same ratings, especially for flame resistance and dielectric strength specifications. A replacement part that does not have the same safety characteristics as the original might create shock, fire or other hazards.

Precautions

1-2 Samsung Electronics

1-2 Servicing Precautions

1. Servicing precautions are printed on the cabinet. Follow them.

2. Always unplug the unit’s AC power cord from the AC power source before attempting to: (a) Remove or reinstall any component or assembly, (b) Disconnect an electrical plug or connector, (c) Connect a test component in parallel with an electrolytic capacitor.

3. Some components are raised above the printed circuit board for safety. An insulation tube or tape is sometimes used. The internal wiring is sometimes clamped to prevent contact with thermally hot components. Reinstall all such elements to their original position.

4. After servicing, always check that the screws, components and wiring have been correctly reinstalled. Make sure that the portion around the serviced part has not been damaged.

5. Check the insulation between the blades of the AC plug and accessible conductive parts (examples: metal panels, input terminals and earphone jacks).

6. Insulation Checking Procedure: Disconnect the power cord from the AC source and turn the power switch ON. Connect an insulation resistance meter (500V) to the blades of the AC plug.

The insulation resistance between each blade of the AC plug and accessible conductive parts (see above) should be greater than 1 megohm.

7. Never defeat any of the B+ voltage interlocks. Do not apply AC power to the unit (or any of its assemblies) unless all solid-state heat sinks are correctly installed.

8. Always connect a test instrument’s ground lead to the instrument chassis ground before connecting the positive lead; always remove the instrument’s ground lead last.

Precautions

Samsung Electronics 1-3

Warning1: First read the “Safety Precautions” section of this manual. If some unforeseen circumstance creates a conflict between

the servicing and safety precautions, always follow the safety precautions.

Warning2: An electrolytic capacitor installed with the wrong polarity might explode.

1. Some semiconductor (“solid state”) devices are easily damaged by static electricity. Such components are called Electrostatically Sensitive Devices (ESDs); examples include integrated circuits and some field-effect transistors. The following techniques will reduce the occurrence of component damage caused by static electricity.

2. Immediately before handling any semicon ductor components or assemblies, drain the electrostatic charge from your body by touching a known earth ground. Alternatively, wear a discharging wrist-strap device. (Be sure to remove it prior to applying power— this is an electric shock precaution.)

3. After removing an ESD-equipped assembly, place it on a conductive surface such as aluminum foil to prevent accumulation of electrostatic charge.

4. Do not use freon-propelled chemicals. These can generate electrical charges that damage ESDs.

5. Use only a grounded-tip soldering iron when soldering or unsoldering ESDs.

6. Use only an anti-static solder removal device. Many solder removal devices are not rated as “anti-static”; these can accumulate sufficient electrical charge to damage ESDs.

7. Do not remove a replacement ESD from its protective package until you are ready to install it. Most replacement ESDs are packaged with leads that are electrically shorted together by conductive foam, aluminum foil or other conductive materials.

8. Immediately before removing the protective material from the leads of a replacement ESD, touch the protective material to the chassis or circuit assembly into which the device will be installed.

9. Minimize body motions when handling unpackaged replacement ESDs. Motions such as brushing clothes together, or lifting a foot from a carpeted floor can generate enough static electricity to damage an ESD.

Precautions

1-4 Samsung Electronics

1-3 Precautions for Electrostatically Sensitive Devices (ESDs)

CAUTION

These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so.

Reference Information

Samsung Electronics 2-1

2. Reference Information

2-1 Tables of Abbreviations and Acronyms

A Ah Å dB dBm

°C °F °K F G GHz g H Hz h ips kWh kg kHz kΩ km km/h kV kVA kW I MHz

Ampere Ampere-hour Angstrom Decibel Decibel Referenced to One Milliwatt Degree Celsius Degree Fahrenheit degree Kelvin Farad Gauss Gigahertz Gram Henry Hertz Hour Inches Per Second Kilowatt-hour Kilogram Kilohertz Kilohm Kilometer Kilometer Per Hour Kilovolt Kilovolt-ampere Kilowatt Liter Megahertz

MV MW MΩ m µA µF µH µm µs µW mA mg mH mI mm ms mV nF

Ω

pF Ib rpm rps s V VA W Wh

Megavolt Megawatt Megohm Meter Microampere Microfarad Microhenry Micrometer Microsecond Microwatt Milliampere Milligram Millihenry Milliliter Millimeter Millisecond Millivolt Nanofarad Ohm Picofarad Pound Revolutions Per Minute Revolutions Per Second Second (Time) Volt Volt-ampere Watt Watt-hour

Table 2-1 Abbreviations

Reference Information

2-2 Samsung Electronics

Table 2-2 Table of Acronyms

ABL AC ACC AF AFC AFT AGC AM ANSI APC APC A/V AVC BAL BPF B-Y CATV CB CCD CCTV Ch CRT CW DC DVM EIA ESD ESD FBP FBT FF FM FS GND G-Y H HF HI-FI IC IC IF

Automatic Brightness Limiter Alternating Current Automatic Chroma Control Audio Frequency Automatic Frequency Control Automatic Fine Tuning Automatic Gain Control Amplitude Modulation American National Standards Institute Automatic Phase Control Automatic Picture Control Audio-Video Automatic Volume Control Balance Bandpass Filter Blue-Y Community Antenna Television (Cable TV) Citizens Band Charge Coupled Device Closed Circuit Television Channel Cathode Ray Tube Continuous Wave Direct Current Digital Volt Meter Electronics Industries Association Electrostatic Discharge Electrostatically Sensitive Device Feedback Pulse Flyback Transformer Flip-Flop Frequency Modulation Fail Safe Ground Green-Y High High-Frequency High Fidelity Inductance-Capacitance Integrated Circuit Intermediate Frequency

I/O L L LED LF MOSFET MTS NAB NEC NTSC OSD PCB PLL PWM QIF R RC RF R-Y SAP SAW SIF SMPS S/N SW TP TTL TV UHF UL UV VCD VCO VCXO VHF VIF VR VTR VTVM TR

Input/output Left Low Light Emitting Diode Low Frequency Metal-Oxide-Semiconductor-Field-Effect-Tr Multi-channel Television Sound National Association of Broadcasters National Electric Code National Television Systems Committee On Screen Display Printed Circuit Board Phase-Locked Loop Pulse Width Modulation Quadrature Intermediate Frequency Right Resistor & Capacitor Radio Frequency Red-Y Second Audio Program Surface Acoustic Wave(Filter) Sound Intermediate Frequency Switching Mode Power Supply Signal/Noise Switch Test Point Transistor Transistor Logic Television Ultra High Frequency Underwriters Laboratories Ultraviolet Variable-Capacitance Diode Voltage Controlled Oscillator Voltage Controlled Crystal Oscillator Very High Frequency Video Intermediate Frequency Variable Resistor Video Tape Recorder Vacuum Tube Voltmeter Transistor

REMARK

Refer to Table 2-3-1

Refer to Table 2-3-2

VM Option

DH01

Option

DDR01

LOC. NO

IC201S

IC601 IC901 IC902

IC602

HIC201

IC301 DH01

DAMPER-D

IC801S

D801S

PC801S

DDR01

IC804 IC803

IC903 IC904

Q909 Q910

TU01 D813

IC501

Table 2 - 3 IC Line - Up

Reference Information

Samsung Electronics 2-3

2-2 IC Line Up

BOARD

MAIN

CRT

SPEC

VDP3130Y-B1

MSP3440G-B6

SIM408A

24WC16

TDA7297 DRGB001

LA7845 KSD5703 FMP-3FU

KA3A1265RD

D5SB60 PC123Y

KA78R05

KA7806

KA78R08

KA78RM33 KIA7025AP

2N7000

TAFC-H0051

FML-G12S

STV5109

DESCRIPTION

Video Processor NTSC Sound Processor MICOM, Caption (MTP)

EEPROM Audio AMP

RGB Drive AMP Hybrid IC Vertical IC

Horizontal Drive IC

SPS Controllor Bridge Diode

Photo Coupler Regulator

6V Regulator 8V Controlled Regulator

3.3V Regulator MICOM Reset IC

IIC Level Shifter

Main Tuner with IF Block Rectifier Diode

Video Output AMP R.G.B Drive

2-4 Samsung Electronics

Reference Information

SPEC

VDP3108B VDP3130Y

FUNCTION

Basic 1H Comb Filter 2H Comb Filter, DVD Input

REMARK

Table 2-3-1 VIDEO IC

SPEC

TDA7297

FUNCTION

7W x 2CH, 10W x 2CH

REMARK

Table 2-3-2 SOUND AMP

Specifications

Samsung Electronics 3-1

3. Specifications

Specifications are subject to change.

Television

System

Antena Input

Multi

Power

Consumption

Requirements

Frequency

Sound

Output

Effect

Jacks

Front

(AV2)

Back

NTSC-M, PAL N.M

120W (Applied When 29” Flat) Free Volts(100V-240Volts) Free Voltage 50/60Hz 15W x 2CH 10W x 2CH

5W x 2CH Vitual Dolby Turbo Sound Pseudo Stereo RCA Input

S-VHS Head-Phone

2 AV Input

DVD Input(YPbPr) AV2 Monitor Audio Output

S-VHS

75ohms, Coaxial Cable

Not Present R815

Option

Option Option

Option

Option Option

3-2 Samsung Electronics

MEMO

Alignment and Adjustments

Samsung Electronics 4-1

4. Alignment and Adjustments

4-1 General Alignment Instructions

1. Usually, a color TV-VCR needs only slight touch-up adjustment upon installation. Check the basic characteristics such as height, horizontal and vertical sync and focus.

2. Observe the picture for good black and white details. There should be objectionable color shading; if color shading is present, demagnetize, perform purity and convergence adjustments described below.

3. Use the specified test equipment or its equivalent.

4. Correct impedance matching is essential.

5. Avoid overload. Excessive signal from a sweep generator might overload the front-end of the TV. When inserting signal markers, do not allow the marker generator to distort test results.

6. Connect the TV only to an AC power source with voltage and frequency as specified on the backcover nameplate.

7. Do not attempt to connect or disconnect any wires while the TV is turned on. Make sure that the power cord is disconnected before replacing any parts.

8. To protect against shock hazard, use an isolation transformer.

4-2 Automatic Degaussing

A degaussing coil is mounted around the picture tube, so that external degaussing after moving the TV should be unnecessary. But the receiver must be properly degaussed upon installation.

The degaussing coil operates for about 1 second after the power is switched ON. If the set is moved or turned in a different direction, the power should be OFF for at least 10 minutes.

If the chassis or parts of the cabinet become magnetized, poor color purity will result. If this happens, use an external degaussing coil. Slowly move the degaussing coil around the faceplate of the picture tube and the sides and front of the receiver. Slowly withdraw the coil to a distance of about 6 feet before turning power OFF.

If color shading persists, perform the following Color purity and Convergence adjustments.

4-3 High Voltage Check

CAUTION : There is no high voltage adjustment on this chassis. The B+ power supply should be +135 volts (with full color- bar input and normal picture level).

1. Connect a digital voltmeter to the second anode of the picture tube.

2. Turn on the TV. Set the Brightness and Contrast controls to minimum (zero beam current).

3. Adjust the Brightness and contrast controls to both extremes. Ensure that the high voltage does not exceed 30 KV under any conditions.

Alignment and Adjustments

4-2 Samsung Electronics

4-5 SCREEN Adjustment

1. Input Toshiba Pattern

2. Enter “Service Mode”.(Refer to “4-8-1 Service Mode”)

3. Select “G2-Adjust”.

4. Set the values as below.

4-4 FOCUS Adjustment

1. Input a black and white signal.

2. Adjust the tuning control for the clearest picture.

3. Adjust the FOCUS control for well defined scanning lines in the center area of the screen.

5. Turn the SCREEN VR until “MRCR G B” and “MRWDG” are green and those value are about 100. (The incorrect SCREEN Voltage may result that “MRCR G B” and “MRWDG” should be red)

INCH / CRT

14” / SDI

15PF / SDI

21” 1.7R / SDI

20V 10.0R/SDI

21PF / TSB

21PF / LG

21PF / SDI

25PF / SDI

27V 1.3R / SDI

27V 1.0R/SDI

25V 1.0R/SDI

23V 1.3R/SDI

IBRM

205

220

205

220

230

225

210

205

WDRV

CDL

100

180

115

180

230

220

160

170

150

120

COLR G B

(Smallest Value)

100

120

150

180

140

Table 1. Screen Adjustment Table

REGION

Normal

Alignment and Adjustments

Samsung Electronics 4-3

4-6 E2PROM (IC902) Replacement

1. When IC902 is replaced, all adjustment data revert to the initial values. So, all adjustment values when servicing should be readjusted.

2. After IC902 is replaced, connect the AC power supply cord.

3. Turn the power switch ON.

4. In stand-by, warm up the TV for at least 10 seconds.

5. Power on the TV.

4-7 White Balance Adjustment

Equipment : Color-Analyzer (CA-100)

Input Signal : Pattern signal (Toshiba pattern)

1. Select STANDARD from the menu.

2. Input an 100% White pattern.

3. Enter the “Service Mode”. (Refer to “4-8 Service Mode”)

4. Warm up the TV set at least for 30 minutes.

5. Input a Toshiba pattern signal.

6. Enter the “Video Adjust1”.

- Adjust “Sub Contrast” so that Y (luminance) becomes 65 ft ± 3.

- Use “Red Drive” and “ Blue Drive” to adjust High-Light (x : 275, y : 265)

- Adjust “Sub Bright” so that Y (luminance) becomes 1.2ft ± 0.3.

- Use “Red Cutoff” and “Blue Cutoff” to adjust Low-Light (x : 275, y : 265).

7. Adjust CA-100 so that the final adjustment value can be fixed.

8. Use the Channel Up/Down ( / ) buttons to move the cursor on the adjustment modes.

9. Use the Volume +/- buttons to change the adjustment value.

Alignment and Adjustments

4-4 Samsung Electronics

4-8 Factory Adjustment

1. To enter the “Service Mode”, Press the remote-control keys in this sequence :

- If you do not have Factory remote-control

- If you have Factory remote-control

2. After the Service Mode is entered, the initial screen is as shown in the figure below.

3. Use the Channel Up/Down buttons to move the cursor in the adjustment parameters.

Note :

- When CRT, CRT PCB, FBT, E

PROM (sometimes MICOM) is replaced, the adjustment values

should be controlled.

- After the Service adjustment is completed, Do not select “Reset” in the service mode menu.

(After above procedure is done, power is on initially and the “Plug and Play” will be operated.)

4-8-1 Service Mode

These hexa digits are check sum value which depends on the MICOM version. If check sum value is changed, the value of

PROM Data newly initialed.

PICTURE OFF PICTURE ON

PICTURE ON

MUTE 1,8,2

DISPLAY

()

FACTORY

xx xx xx

Alignment and Adjustments

Samsung Electronics 4-5

4-8-2 Deflection (Memory Data)

- SIM408A USA, LATIN FACTORY (VDP IC VDP3108B)

25V 1R

27V 1R

20V 1R

INIT

H Angle

V AMP V SLOPE

H EW

H SYMMETRY H CORNER

PIP CONTRAST PIP TINT

PIP NTSC V.POS

CL25M6P

CL25M6W

4-8-2(A) GEOMETRIC ADJUSTMENT VALUE

DEFLECTION INIT H Bow 0 FIX 0 0 0 0 0 0 H Angle H Dscc 0 FIX 3 3 3 3 3 3 V SHIFT -40 Control -27 -24 -18 -18 -40 -35 V AMP V SLOPE V SC -7 FIX 0 -13 -13 -13 -13 -13 H EW H TRAPEZIUM -20 Control -82 -48 -20(FIX) -20(FIX) -20(FIX) -20(FIX) H PARABOLA -13 Control -89 -44 -13(FIX) -13(FIX) -13(FIX) -13(FIX) H SYMMETRY H CORNER H SHIFT 4 Control 0 8 13 13 4 13 PIP CONTRAST PIP TINT PIP PAL V.POS FIX 12 12 12 12 12 12 PIP NTSC V.POS PIP H.POS FIX 12 12 12 12 12 12

INCH

Model

0 FIX 0 0 0 0 0 0

5 Control -50 -41 18 18 5 20

-2 Control -7 -4 -4 -4 -2 -4

64 Control 10 -37 64(FIX) 64(FIX) 64(FIX) 64(FIX)

13 FIX 13 13 13 13 13 13 15 Control 0 69 69(FIX) 69(FIX) 69(FIX) 69(FIX)

FIX 0 0 0 0 0 0 FIX 0 0 0 0 0 0

FIX 12 12 12 12 12 12

27V 1.3R 23V 1.3R 25V 1R

TXK2550

TXK2767 CL25D4W

TXK2554 TXK2566 TXK2567

CL663BW

27V 1R

TXK2750 TXK2754

20V 1R

TXK2060 TXK2066 TXK2067

15" FLAT

CT-15A8

21" STEREO

CL21A8W7X

0 0 3

-40

-20

-6

-5

-20 20 13

-24

25" STEREO

CL25M6P

CL25M6W

0 0 3

-50

-15

-2

-6

-20

-60 13 40

-27 7

0 10 10

Alignment and Adjustments

4-6 Samsung Electronics

4-8-2(B) SCREEN CHANGE (I2C BUS GEOMETRIC ADJUSTMENT)

1 V Shift

V Slope

3 H EW

6 V Amp

V SC

H Trapizium

4 H Parabola

5 H Corner

H Symmetry

H Shift

Alignment and Adjustments

Samsung Electronics 4-7

4-8-2(C) VIDEO ADJUST 1

27V 1.3R 23V 1.3R 25V 1R 27V 1R 20V 1R 15" FLAT

TXK2767 CL25D4W

TXK2550 TXK2554 TXK2566 TXK2567

CL663BW

TXK2750 TXK2754

TXK2060 TXK2066 TXK2067

CT-15A8

DEFLECTION INIT H Bow

0 FIX 0 0 0 0 0 0

H Angle 0 FIX 0 0 0 0 0 0 H Dscc 0 FIX 3 3 3 3 3 3 V SHIFT -40 Control -27 -24 -18 -18 -40 -35 V AMP 5 Control -50 -41 18 18 5 20 V SLOPE -2 Control -7 -4 -4 -4 -2 -4 V SC -7 FIX 0 -13 -13 -13 -13 -13 H EW 64 Control 10 -37 64(FIX) 64(FIX) 64(FIX) 64(FIX) H TRAPEZIUM -20 Control -82 -48 -20(FIX) -20(FIX) -20(FIX) -20(FIX) H PARABOLA -13 Control -89 -44 -13(FIX) -13(FIX) -13(FIX) -13(FIX) H SYMMETRY 13 FIX 13 13 13 13 13 13 H CORNER 15 Control 0 69 69(FIX) 69(FIX) 69(FIX) 69(FIX) H SHIFT 4 Control 0 8 13 13 4 13 PIP CONTRAST FIX 0 0 0 0 0 0 PIP TINT FIX 0 0 0 0 0 0 PIP PAL V.POS FIX 12 12 12 12 12 12 PIP NTSC V.POS FIX 12 12 12 12 12 12 PIP H.POS FIX 12 12 12 12 12 12

25" STEREO

0 0 3

-50

-15

-2

-6

-20

-60 13 40

-27 7

0 10 10

21" STEREO

CL21A8W7X

0 0 3

-40

-20

-6

-5

-20 20 13

-24

25V 1R

27V 1R

20V 1R

GREEN CUT OFF

GREEN DRIVE BLUE DRIVE

SUB CONTRAST

SUB TINT

BCL TIME DVD SUB TINT N. YC DELAY

INCH

Model

CL21S8W7X

CL25M6P

CL25M6W

CL25M6P

CL25M6W

Note 1. Beam Control Limit Characteristic

INCH

Model

VIDEO ADJUST1 RED CUT OFF 127 Control 127 127 127 127 127 127 GREEN CUT OFF BLUE CUT OFF 127 Control 127 127 127 127 127 127 RED DRIVE 127 Control 150 127 127 127 127 127 GREEN DRIVE BLUE DRIVE SUB BRIGHT 110 Control 100 110 100 100 114 110 SUB CONTRAST SUB COLOR 27 FIX 50 50 50 50 50 67 SUB TINT BCL THRESHOLD 62 FIX 60 54 58 58 70 40 BCLGAIN 8 FIX 8 8 8 8 8 8 BCL TIME DVD SUB TINT N. YC DELAY

INIT

127 FIX 127 127 127 127 127 127

127 FIX 127 127 127 127 127 127 127 Control 170 127 127 127 127 127

52 Control 52 52 52 52 52 52

30 FIX 70 70 70 70 30 15

13 FIX 10 10 10 10 10 13 90 FIX 100 100 100 100 100 120

0 FIX 3 3 3 3 3 4

27V 1.3R 23V 1.3R 25V 1R

TXK2550

TXK2767 CL25D4W

TXK2554 TXK2566 TXK2567

CL663BW

27V 1R

TXK2750 TXK2754

TXK2060 TXK2066 TXK2067

20V 1R

15" FLAT

CT-15A8

21" STEREO

CL21S8W7X

127 127 127 127 127 127 100

52 60 30 62

25" STEREO

CL25M6P

CL25M6W

127 127 127 127 127 127 110

52 60 30 67

Alignment and Adjustments

4-8 Samsung Electronics

4-8-2(E) VIDEO 3 ADJUST

4-8-2(D) VIDEO 2 ADJUST

TXK2767 CL25D4W

TXK2550 TXK2554 TXK2566 TXK2567

CL663BW

TXK2750 TXK2754

TXK2060 TXK2066 TXK2067

CT-15A8

DEFLECTION INIT H Bow

0 FIX 0 0 0 0 0 0

0 0 3

-50

-15

-2

-6

-20

-60 13

-27 7 0

10 10 15

CL21A8W7X

0 0 3

-40

-20

-6

-5

-20 20

13 40

-24

27V 1.3R 23V 1.3R 25V 1R 27V 1R 20V 1R 15" FLAT

TXK2767 CL25D4W

TXK2550 TXK2554 TXK2566 TXK2567

CL663BW

TXK2750 TXK2754

TXK2060 TXK2066 TXK2067

CT-15A8

VIDEO ADJUST1

INIT

RED CUT OFF 127 Control 127 127 127 127 127 127 GREEN CUT OFF 127 FIX 127 127 127 127 127 127 BLUE CUT OFF 127 Control 127 127 127 127 127 127 RED DRIVE 127 Control 150 127 127 127 127 127 GREEN DRIVE 127 FIX 127 127 127 127 127 127 BLUE DRIVE 127 Control 170 127 127 127 127 127 SUB BRIGHT 110 Control 100 110 100 100 114 110 SUB CONTRAST 52 Control 52 52 52 52 52 52 SUB COLOR 27 FIX 50 50 50 50 50 67 SUB TINT 30 FIX 70 70 70 70 30 15 BCL THRESHOLD 62 FIX 60 54 58 58 70 40 BCLGAIN 8 FIX 8 8 8 8 8 8 BCL TIME 13 FIX 10 10 10 10 10 13 DVD SUB TINT 90 FIX 100 100 100 100 100 120 N. YC DELAY 0 FIX 3 3 3 3 3 4

INIT

B STRETCH-BTHR

CORING NTSC COMB FILTER

RG B CONTRAST EHT TIME

DTI CORING

DTI BAND

EHT HORIZONTAL

INCH

Model

21" STEREO

CL21S8W7X

127 127 127 127 127 127 100

52 60 30 62

25" STEREO

CL25M6P

CL25M6W

CL25M6P

CL25M6W

CL25M6P

CL25M6W

127 127 127 127 127 127 110

52 60 30 67

15" FLAT

PEAK WHITE LIMLT SOFT LIMIT SLOPE B HARD LIMIT MODULATION ON/OFF A TILT POINT B TILT POINT GAIN 1 (VIDEO)

LIMIT VALUE VELOCITY DELAY VELOCITY CORING

CL21S8W7X

CL25M6W

CL25M6P

VIDEO ADJUST2 INIT B STRETCH-BTHR B DTRETCH-BTLT 8 FIX 8 8 8 8 8 8 B STERTCH-BAM 4 FIX 4 4 4 4 4 4 CORING NTSC COMB FILTER RGB BRIGHT 0 FIX 0 0 0 0 0 0 RG B CONTRAST EHT TIME EHT VERTICAL FIX 60 60 60 60 60 60 DTI CORING DTI GAIN FIX 1 1 1 1 1 1 DTI BAND EHT OFFSET FIX 0 0 0 0 0 0 EHT HORIZONTAL

VIDEO ADJUST3 INIT PEAK WHITE LIMLT SOFT LIMIT SLOPE B HARD LIMIT MODULATION ON/OFF A TILT POINT B TILT POINT GAIN 1 (VIDEO) DELAY 1 (VIDEO) FIX PEAK VIDEO REF FIX PEAK VIDEO GAIN FIX LIMIT VALUE VELOCITY DELAY VELOCITY CORING ACC-REF 20 FIX ACCR 21 FIX

INCH

Model

50 FIX 50 50 50 50 50 50

31 FIX 31 31 31 31 31 31

1 FIX 1 1 1 1 1 1

0 FIX 0 0 0 0 0 0 0 FIX 0 0 0 0 0 0

INCH

Model

FIX 0 0 0 0 0 0

FIX 1 1 1 1 1 1

FIX 0 0 0 0 0 0

255 FIX

4 FIX

255 FIX

0 FIX 0 FIX 0 FIX

FIX

FIX FIX FIX

27V 1.3R 23V 1.3R 25V 1R 27V 1R 20V 1R 15" FLAT

TXK2767

27V 1.3R 23V 1.3R 25V 1R 27V 1R 20V 1R 15" FLAT

TXK2767 CL25D4W

255 255 255 255 255 255

4 4 4 4 4 4

255 255 255 255 255 255

0 0 0 0 0 0 0 0 0 0 0 0

114 114 114 114 114 114

11 11 11 11 11 11

3 3 3 3 3 3 0 0 0 0 0 0 0 0 0 0 0 0

74 74 74 74 74 74

7 7 7 7 7 7 10 10 10 10 10 10 20 20 20 20 20 20 21 21 21 21 21 21

CL25D4W

TXK2550 TXK2554 TXK2566 TXK2567

CL663BW

TXK2550 TXK2554 TXK2566 TXK2567

CL663BW

TXK2750 TXK2754

TXK2060 TXK2066 TXK2067

CT-15A8

21" STEREO

CL21S8W7X

8 4

3 0 0 8

0 1 1 0 0

21" STEREO

CL21S8W7X

255

0 0

114

3 0 0

7 10 20 21

25" STEREO

CL25M6P

CL25M6W

8 4

3 0 0 8

0 1 1 0 0

25" STEREO

CL25M6W

CL25M6P

255

180

0 0

114

3 0 0

7 10 20 21

Alignment and Adjustments

Samsung Electronics 4-9

“Soft Limit” is that Limitting

the peak white without feed-back, but “Peak Limit” is that with feed-back for white peak level

Note 2. Soft Limit & Hard Limit Characteristics

4-8-2(F) OTHERS

27V 1.3R 23V 1.3R 25V 1R 27V 1R 20V 1R 15" FLAT

TXK2767 CL25D4W

TXK2550 TXK2554 TXK2566 TXK2567

CL663BW

TXK2750 TXK2754

TXK2060 TXK2066 TXK2067

CT-15A8

VIDEO ADJUST3 INIT PEAK WHITE LIMLT 255 FIX

255 255 255 255 255 255

SOFT LIMIT SLOPE B 4 FIX

44 444 4

HARD LIMIT 255 FIX

255 255 255 255 255 255

MODULATION ON/OFF 0 FIX

00 000 0

A TILT POINT 0 FIX

00 000 0

B TILT POINT 0 FIX

114 114 114 114 114 114

GAIN 1 (VIDEO) FIX

11 11 11 11 11 11

DELAY 1 (VIDEO) FIX

33 333 3

PEAK VIDEO REF FIX

00 000 0

PEAK VIDEO GAIN FIX

00 000 0

LIMIT VALUE FIX

74 74 74 74 74 74

VELOCITY DELAY FIX

77 777 7

VELOCITY CORING FIX

10 10 10 10 10 10

ACC-REF 2 0 FIX

20 20 20 20 20 20

ACCR 21 FIX

21 21 21 21 21 21

255

0 0

114

3 0 0

7 10 20 21

27V 1.3R

23V 1.3R

25V 1R

27V 1R

20V 1R

15" FLAT

TXK2767

CL25D4W

TXK2550 TXK2554 TXK2566 TXK2567

CL663BW

TXK2750 TXK2754

TXK2060 TXK2066 TXK2067

CT-15A8

OTHERS VSU VSU2 H QEW H ZOOM Parabola H 16:9 Parabola

-18 TTX H Shift PAL V SHIFT

OFFSET

PAL H SHIFT

OFFSET

Melidy Volume

Control

275/295 35FL

275/295 95FL

Control

275/295 1.2FL

275/295 2.0FL

INCH

Model

INCH

Model

WHITE BALANCE

INIT

21" STEREO

CL21S8W7X

255

180

0 0

114

3 0 0

7 10 20 21

25" STEREO

CL25M6W

CL25M6P

275/265 65FL

275/265 1.2FL

CL21S8W7X

-61

-22

PIP BRIGHT PIP COLOR PIP VSPD

275/265 45FL

275/265 1.4FL

CL25M6W

CL25M6P

4-8-2(G) G2 ADJUST

27V 1.3R 23V 1.3R 25V 1R 27V 1R 20V 1R 15" FLAT

TXK2767 CL25D4W

TXK2550 TXK2554 TXK2566 TXK2567

CL663BW

TXK2750 TXK2754

TXK2060 TXK2066 TXK2067

CT-15A8

255 255 255 255 255 255

44 4 44 4

255 255 255 255 255 255

00 0 00 0 00 0 00 0

114 114 114 114 114 114

11 11 11 11 11 11

33 3 33 3 00 0 00 0 00 0 00 0

74 74 74 74 74 74

77 7 77 7 10 10 10 10 10 10 20 20 20 20 20 20 21 21 21 21 21 21

255

0 0

114

3 0 0

7 10 20 21

27V 1.3R

23V 1.3R

25V 1R 27V 1R 20V 1R 15" FLAT

TXK2767

CL25D4W

TXK2550 TXK2554 TXK2566 TXK2567

CL663BW

TXK2750 TXK2754

TXK2060 TXK2066 TXK2067

CT-15A8

H Control 275/295 35FL 275/295 35FL 275/295 35FL 275/295 35FL 275/295 35FL 275/295 95FL

L Control 275/295 1.2FL 275/295 1.2FL 275/295 1.2FL 275/295 1.2FL 275/295 1.2FL 275/295 2.0FL

15" FLAT

MRC R G B

INCH

Model

INCH

Model

INIT

21" STEREO

CL21S8W7X

255

180

0 0

114

3 0 0

7 10 20 21

25" STEREO

CL25M6W

CL25M6P

100

0 0

-30 1

-51

-19 7

275/265 65FL

275/265 1.2FL

21" STEREO

CL21S8W7X

108

0 0

-12 0

-61

-22

7 3 9

275/265 45FL

275/265 1.4FL

25" STEREO

CL25M6W

CL25M6P

21" STEREO

25" STEREO

WHITE BALANCE

OTHERS VSU VSU2 H QEW H ZOOM Parabola H 16:9 Parabola TTX H Shift PAL V SHIFT PAL H SHIFT Melidy Volume PIP BRIGHT PIP COLOR PIP VSPD

G2 Adjust MRC R G B MRWDG 110 IBRM FIX 210 WDRV FIX 35 CDL FIX 170 COL MIN 150

INCH

Model

INIT

108 FIX 108 104 100 100 104 110

0 FIX 0 0 0 0 0 0 8 FIX -22 -35 8 8 8 8

-10 FIX 8 13 -18 0 FIX 0 0 0 0 0 0

5 FIX 7 7 7 7 7 7

H Control L Control

INCH

Model

Max 110

27V 1.3R

TXK2767

FIX 0 0 0 0 0 0

23V 1.3R

CL25D4W

25V 1R

TXK2550 TXK2554 TXK2566 TXK2567

CL663BW

27V 1R

TXK2750 TXK2754

-18 -18 -10

FIX OFFSET FIX OFFSET

FIX FIX FIX

275/295 35FL 275/295 35FL 275/295 35FL

275/295 1.2FL 275/295 1.2FL 275/295 1.2FL 275/295 1.2FL

27V 1.3R

TXK2767

OFFSET OFFSET

23V 1.3R

CL25D4W

110 110 205

35 120 140

OFFSET OFFSET

275/295 35FL

275/295 35FL 275/295 95FL

275/295 1.2FL

25V 1R 27V 1R 20V 1R 15" FLAT

TXK2550 TXK2554 TXK2566 TXK2567

CL663BW

TXK2750 TXK2754

110 110 110 110

TXK2060 TXK2066 TXK2067

110 110 110 110 210 210 205 220

35 35 35 35 150 150 115 180 150 150 120 100

20V 1R

TXK2060 TXK2066 TXK2067

OFFSET OFFSET

15" FLAT

CT-15A8

OFFSET OFFSET

275/295 2.0FL

CT-15A8

21" STEREO

CL21S8W7X

100

0 0

-30 1

-51

-19 7

275/265 65FL

275/265 1.2FL

21" STEREO

CL21S8W7X

110 110 225

220

25" STEREO

CL25M6W

CL25M6P

108

0 0

-12 0 1

-61

-22 7 3 9 0

275/265 45FL

275/265 1.4FL

25" STEREO

CL25M6W

CL25M6P

110 110 205

45 150 140

Alignment and Adjustments

4-10 Samsung Electronics

4-8-3 Deflection (Memory Data)

- SIM408A USA, LATIN FACTORY (VDP IC VDP3130Y)

25V 1R

27V 1R

20V 1R

INIT

H Angle

V AMP V SLOPE

H EW

H SYMMETRY H CORNER

PIP CONTRAST PIP TINT

PIP NTSC V.POS

4-8-3(A) GEOMETRIC ADJUSTMENT VALUE

INCH

Model

0 FIX 0 0 0 0 0 0

5 Control -50 -41 18 18 5 20

-2 Control -7 -4 -4 -4 -2 -4

64 Control 10 -37 64(FIX) 64(FIX) 64(FIX) 64(FIX)

13 FIX 13 13 13 13 13 13 15 Control 0 69 69(FIX) 69(FIX) 69(FIX) 69(FIX)

FIX 0 0 0 0 0 0 FIX 0 0 0 0 0 0

FIX 12 12 12 12 12 10

27V 1.3R 23V 1.3R 25V 1R

TXK2550

TXK2767 CL25D4W

TXK2554 TXK2566 TXK2567

CL663BW

27V 1R

TXK2750 TXK2754

20V 1R

TXK2060 TXK2066 TXK2067

15" FLAT

CT-15A8

21" STEREO

CL21A8W7X

-40

-20

-24

-5

20 13

25" STEREO

CL25M6W

CL25M6P

0 0 3

-6

-5

0 0 3

-50

-15

-2

-6

-20

-60 13 40

-27

0 10 10 15

4-9-1 Pin Layout

Alignment and Adjustments

Samsung Electronics 4-11

4-9 MICOM

Write Protect

EEPROM SDA

EEPROM SCL

Bus-Stop

Main SDA

Main SCL

Sound Reset

Video Reset

VDD 2.5V

GND

VDD 3.3V

CVBS Input

VDD 2.5V

GND

AFT

Scart1 Ident

I/O

ADC

4 0 8

PWM

I/O

Tilt

N.C.

Power Sound Mute N.C.

N.C.

PX. Y PX. Y

VDD 3.3V GND

VDD 2.5V CORE

OSD-B

OSD-G

OSD-R VDD 2.5V

Scart2 Ident

Key 1 H-Sync V-Sync

Key 3

Key 2

X-Ray Protect

IR Input

Stand-By LED

Time LED

ADC

I/O

GND

X-TAL Out X-TAL In MICOM Reset

N.C.

N.C. VDD 3.3V GND

N.C.

Relay

Alignment and Adjustments

4-12 Samsung Electronics

4-9-2 Pin Assignment Specification

DESCRIPTION

EEPROM Write Protection

EEPROM Serial Data Line

EEPROM Serial Clock Line

Disable Micom IIC

Peripheral IC Serial Data Line

Peripheral IC Serial Clock Line

MSP IC Initial Control

VDP IC Initial Control

TTX CVBS Input

Analog B+

Analog Ground

Auto Fine Tuning Control

Scart1 Ident

Scart2 Ident

Key1 Input

Horizontal Sync Input

Vertical Sync Input

Key3 Input

Key2 Input

X-Ray Protection

Remocon Signal Input

LED Drive Output(Red)

LED Drive Output(Green)

PIN NO

FUNCTION

I/O

Vdd

GND

Vdd

CVBS

Vdd

GND

ADC

I/O

ASSIGN

Write Protect

ROM SDA

ROM SCL

Bus Stop

Main SDA

Main SCL

Sound Reset

Video Reset

VDD 2.5V

VDD 3.3V

CVBS Input

VDD 2.5V

AFT

SC1-ID

SC2-ID

Key1

H-Sync

V-Sync

Key3

Key2

X-Ray

IR-In

STD-LED

TIM-LED

IN/OUT

Out

I/O

Out

ACTIVE H/L

Low

Alignment and Adjustments

Samsung Electronics 4-13

4-9-2 Pin Assignment Specification (Continued)

PIN NO

FUNCTION

I/O

N.C.

GND

Vdd

N.C.

Reset

X-In

X-Out

GND

Vdd

COR

Vdd

GND

Vdd

I/O

N.C.

I/O

N.C.

I/O

ASSIGN

Relay

VDD 3.3V

Reset

X-TAL In

X-TAL Out

VDD 2.5V

OSD-R

OSD-G

OSD-B

CORE

VDD 2.5V

VDD 3.3V

PX.Y

S-Mute

Power

IN/OUT

Out

ACTIVE H/L

Low

6MHz

High

Low

DESCRIPTION

Activate Degausssing Coil

Not Used (Programmed Gound Level)

Analog Ground

Not Used (Programmed Gound Level)

Micom Hardware Reset

Crystal Oscillation Input

Crystal Oscillation Output

Analog Ground

Analog B+

OSD/TTX Output (Red)

OSD/TTX Output (Green)

OSD/TTX Output (Blue)

Fast Blank/Half Contrast Output

When The Caption Function Adopted, Used.

Not Used (Programmed Gound Level)

Sound Amp Mute

Picture On/Off Control

Not Used (Programmed Gound Level)

4-14 Samsung Electronics

MEMO

Troubleshooting

Samsung Electronics 5-1

5. Troubleshooting

5-1 No Power

Disconnect the Power Cord

Check Power LED

LED OFF

Check

IC901 B+

Abnormal

Check

the voltage of

IC804

Abnormal

Check

the resistance of

FD803

LED ON

Normal

Check

IC803

Normal

Check

IC803

Abnormal

Check IC901 Pin

Abnormal

Check Q909, Q910

Abnormal

Replace

Q909,Q910

Abnormal

Replace

IC902

Normal Normal

Normal

Check IC902

Check

SCL, SDA Line

Normal

Check IC901 Pin

Abnormal

Replace IC901

Abnormal

Replace

Abnormal

Check Q401 and

Horizontal Circuit

IC201

Check/Replace

IC803, DDR01

Abnormal

Check

the voltage of

IC803, 805

Normal

Check

H-OUT of IC201

Normal

Check the

voltage of

IC803, 805

Normal

Check FBT and

B+(130V)

Normal

Check

IC801, D801 FUSE

Replace FD803

5-2 No Raster (Sound OK)

Troubleshooting

5-2 Samsung Electronics

Check

Fusible Resistance

Abnormal

Check

voltage of

heater

Normal

Check

CRT and FBT

Check / Replace

IC201

Normal

No Raster

(Sound OK)

Check

RK,GK,BK Signal

output from

CRT PCB

Abnormal

Check

the signal output

from IC201 Pin

Abnormal

Check tuner B+ and Main CVBS

Abnormal

Check

R.G.B Signal

input to CRT PCB

Abnormal

Check

R.G.B Signal

Output from

IC201

Normal

Check Q202, Q203, Q204, Q207, Q209, Q213,

Q206, Q208, Q210

Normal

Check

the fusible resistance

of abnormal volatge line

Abnormal

Check

B+

(200V, 16V)

Normal

Re-adjust

Screen Voltage

Troubleshooting

Samsung Electronics 5-3

5-3 No Sound

No Sound

Normal

Check/Replace

IC601

Normal Abnormal

Check

Speaker and Wire

Normal

Check

IC601 B+

Abnormal

Check

B+ Line (8V)

Check

the signal output

from 602 Pins

Check the signal input to IC601 Pin

Check

tuner B+ and SIF

Abnormal

Check

the signal input

to IC602 pins

Abnormal

Check/Replace

the resistance

of FD802

Normal

Check

IC602 B+

Normal

Replace

IC602

Troubleshooting

5-4 Samsung Electronics

5-4 Horizontal Lines Appear on screen

Horizontal Lines Apper on screen

Normal

Check/Replace

IC301

Normal

Check

the VDP Signal

output from IC201

31Pin

Abnormal

Check

IC201

Check

IC301 B+

(16V, -16V)

Abnormal

Check B+ Line and the fusible resistance of R425, 424

6. Exploded View & Parts List

6-1 CT15K8W6X/XAP

Exploded View & Parts List

Samsung Electronics 6-1

No Code No Description;Specification Q’ty Remark

1 AA92-00771A ASSY-CABINET,FRONT;15K8,SV907P+DB004P,HB 1 A/FRNT

AA64-01730D CABINET FRONT;15K8,S907P+D004P NT TURBO, 1 F/C

1-1 INLAY-COVER 1

1-2 AA64-01371B KNOB POWER;15K8,ABS,G3676,SV907P+W971,HB 1 KP

1-3 AA61-60003J SPRING-CS;-,-,SUS304,0.5,OD6,H 1 SPRING

1-4 AA61-40113A STOPPER-PCB;-,ABS,HB,NTR. 1 STOPPE

1-5 3001-001020 SPEAKER;3W,8ohm,90dB,140Hz 2 SPK

1-6 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR 8 SPK+CF

1-7 AA64-01370B KNOB CONTROL;15K8,ABS,G3676,SV907P+W971, 1 KC

1-8 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR 1 KC+CF

1-9 AA64-00816B WINDOW REMOCON;-,21A8,-,PC,V0,VIOLET,- 1 WR

1-10 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR 1 WR+CF

1-11 AA65-30105A CLAMP-WIRE;NYLON 66N,VO,NTR,15MM 1 CWFC

1-12 AA64-00818B INDICATOR LED;-,21A8,-,ACRYL,-,CLR,- 1 IL

2 AA03-00146A CRT COLOR;A36QDT351X,-,15inch,-,-,-,FLAT 1 CRT

2-1 AA60-10050R SCREW-ASSY;WC,HH,+M5,L31.5,SWR 4 CRT+CF

2-2 3704-001105 SOCKET-CRT;11P,20PI,26.5PI,NI,- 1 V999S

3 AA64-01731B CABINET BACK;15K8,HIPS,HB,BLK 1 B/C

3-1 6002-000514 SCREW-TAPPING;RH,+,2,M4,L15,ZP 4 CB+CF

3-2 AA96-00570A ASSY POWER CORD;-,CP2/NO,H/C200,KKP419C, 1 PWR/AC

Exploded View & Parts List

6-2 Samsung Electronics

6-2 CL25K4W7X/XAX

No Code No Description;Specification Q’ty Remark

1 AA92-00543A ASSY-CABINET,FRONT;KS2A,25,FLAT,CL25A6 1 A/FRNT

AA64-01440A CABINET FRONT;TOOL.S25A6,MOLD,-,-,- 1 F/C

1-1 AA64-00240B DOOR-AV;-,25A6,BK702P,ABS,HB,BLK,-,- 1 DOOR

1-2 AA64-01713B INLAY-AV;PS,SHEET,T0.3,BLK,25A6 1 IN/AV

1-3 AA64-70117B BADGE-BRAND;AL,SS,R2000,25,SILVER CT-633 1 BADGE

1-4 AA61-00343A SPRING-CS;-,SUS304,-,-,-,-,0.4,0D6,H12,N 1 SPRING

1-5 AA64-00243D KNOB-POWER;-,25A6,NO-SILK W971,ABS,HB,G3 1 KP

1-6 AA64-00241C WINDOW-REMOCON;-,25A6,W971,PC,VO,VIOLET, 1 WR

1-7 AA98-00081A ASSY-PCB,A/V;FRONT,KS2A 1 A/A-V

1-8 6002-000522 SCREW-TAPPING;TH,+,2,M4,L15,ZP 2 PC+CF

1-9 AA64-00242B INDICATOR-LED;-,25A6,-,ACRYL,-,CLEAR,- 1 IL

1-10 6002-000514 SCREW-TAPPING;RH,+,2,M4,L15,ZP 1 IL+CF

1-11 AA64-00245B KNOB-CONTROL;-,25A6,BK702P+W971,ABS,HB,B 1 KC

1-12 6002-000514 SCREW-TAPPING;RH,+,2,M4,L15,ZP 2 KC+CF

2 AA03-00322A CRT COLOR;A59QDF891X999,+380MG,1.05MH,1. 1 CRT

2-1 AA65-30017A CLAMP-D,COIL;-,NYLON-66,V0,NTR,DADH300,2 4 CDCOIL

2-2 AA60-10050V SCREW-ASSY;WC,HH,+,M6,L30,SWRCH18A,ZPC(S 4 CRT+CF

2-3 3704-001105 SOCKET-CRT;11P,20PI,26.5PI,NI,- 1 V999S

3 AA91-00427B ASSY HOLDER SPK;DP,PP,8ohm/10W,BLK,SEMI- 1 A/HSPK

3-1 6006-001095 SCREW-ASS’Y TAPT;WP,BH,+,M4,L12,ZPC(YEL) 8 SPK+CF

4 AA64-01441A CABINET BACK;TOOL.S25A6,MOLD,-,-,- 1 B/C

4-1 6002-000514 SCREW-TAPPING;RH,+,2,M4,L15,ZP 4 CB+CF

4-2 AA96-20112A ASSY-POWER,CORD;EP2/NP,H/C300 1 PWR/AC

Exploded View & Parts List

Samsung Electronics 6-3

6-3 CL29C1W7FX/XAP

No Code No Description;Specification Q’ty Remark

1 AA92-00750A ASSY-CABINET,FRONT;29C1,SV907P,HIPS,HB 1 A/FRNT

AA64-01625A CABINET FRONT;29C1,SV907P,HIPS,HB,G4309 1 F/C

1-1 AA64-70117B BADGE-BRAND;AL,SS,R2000,25,SILVER CT-633 1 BADGE

1-2 AA64-01627A KNOB POWER;29C1,ABS HB G3676,SV907P+W971 1 KP

1-3 AA61-60003J SPRING-CS;-,-,SUS304,0.5,OD6,H 1 SPRING

1-4 AA65-30018A CLAMP-WIRE;-,NYLON6.6,-,-,DATL 2 DRESPK

1-5 AA61-40113A STOPPER-PCB;-,ABS,HB,NTR. 1 STOPPE

1-6 3001-001005 SPEAKER,10W,8ohm,90db,150Hz 2 SPK

1-7 6002-000514 SCREW-TAPPING;RH,+,2,M4,L15,ZP 12 SPK+CF

1-8 AA64-01629A INDICATOR LED;29C1,ACRYL HB CLR 1 IL

1-9 AA64-01628A WINDOW REMOCON;29C1,PC V0 VIOLET 1 WR

1-10 6002-000514 SCREW-TAPPING;RH,+,2,M4,L15,ZP 1 WIN+CF

1-11 AA64-01630A KNOB CONTROL;29C1,ABS HB G3676,SV907P+W9 1 KC

1-12 6002-000514 SCREW-TAPPING;RH,+,2,M4,L15,ZP 1 KC+CF

2 AA03-00289A CRT COLOR;A68AJB82X03,0MG,1.31MH,18.0MH, 1 CRT

2-1 AA65-30113A CLAMP-D,COIL;NYLON66,V2,BLK,TVI25~29,- 4 CDCOIL

2-2 AA60-10050V SCREW-ASSY;WC,HH,+,M6,L30,SWRCH18A,ZPC(S 4 CRT+CF

2-3 3704-001105 SOCKET-CRT;11P,20PI,26.5PI,NI,- 1 V999S

3 AA64-01626A CABINET BACK;29C1,HIPS HB,BLK 1 B/C

3-1 6002-000514 SCREW-TAPPING;RH,+,2,M4,L15,ZP 7 CB+CF

3-2 AA64-00892G INLAY BACK;D2,D3,RCA9P+S-VHS+DVD,PS SHEE 1 INLAYB

3-3 AA96-20109A ASSY-POWER,CORD;-,CP2/NO(4.0),H/C400,KKP 1 PWR/AC

Exploded View & Parts List

6-4 Samsung Electronics

6-4 MR29410X/TCE

No Code No Description;Specification Q’ty Remark

1 AA92-01062A ASSY-CABINET,FRONT;KS2A,SV809P,RCA,29D6 1 A/FRNT

AA91-00609B ASSY CABINET FRONT;DP,29D6 KS2A,S809P RC 1 F/C

1-1 AA64-00179A BADGE-BRAND;AL FORGING,R800 RCA,SILVER,3 1 BADGE

1-2 AA64-00386E KNOB POWER;29D6,ABS,-,-,-,HB,G3676,-,NO- 1 KP

1-3 AA61-60003T SPRING-CS;-,-,SUS304,0.5,OD7,H 1 SPRING

1-4 PANEL CONTROL 1

1-5 INLAY COVER 1

1-6 AA64-60448W INLAY AV;S51A,3P EPG,PS SHEET,T0.3,BLK, 1 IN/AV

1-7 AA98-00084A ASSY-PCB,A/V;SIDE,CL29D4,KS2A, 1 A/A-V

1-8 6002-000522 SCREW-TAPPING;TH,+,2,M4,L15,ZP 1 AV+CF

1-9 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR 3 PC+CF

1-10 AA61-40113A STOPPER-PCB;-,ABS,HB,NTR. 1 STOPPE

1-11 BOSS-CABINET 1

1-12 3001-001072 SPEAKER;5W,16ohm,90dB,180Hz 4 SPK

1-13 6002-000430 SCREW-TAPPING;RH,+,2,M4,L10,ZP 8 SPK+CF

1-14 AA64-01208B KNOB CONTROL;DP,29D6,-,-,-,-,-,-,-,AA64- 1 KC

1-15 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR 1 KC+CF

1-16 AA65-30105A CLAMP-WIRE;NYLON 66N,VO,NTR,15MM 2 CWFC

1-17 AA64-00387B INDICATOR-LED;29D6,ACRYL,-,CLEAR,-,-,- 1 IL

1-18 AA64-00383B WINDOW-REMOCON;-,29D6,-,PC,V0,VIOLET,- 1 WR

1-19 6002-000522 SCREW-TAPPING;TH,+,2,M4,L15,ZP 1 WIN+CF

2 AA03-00071A CRT-COLOR;-,A68AEG25X02,+380MG,-,110,37. 1 CRT

2-1 AA65-30113A CLAMP-D,COIL;NYLON66,V2,BLK,TVI25~29,- 4 CDCOIL

2-2 AA60-10050R SCREW-ASSY;WC,HH,+M5,L31.5,SWR 4 CRT+CF

2-3 3704-001105 SOCKET-CRT;11P,20PI,26.5PI,NI,- 1 V999S

3 AA64-31266E CABINET-BACK;-,29D4,-,HIPS,HB,BLK,-,- 1 B/C

3-1 6002-000514 SCREW-TAPPING;RH,+,2,M4,L15,ZP 8 CB+CF

4 AA96-20112D ASSY-POWER,CORD;-,EP2/NO,N(H/C500MM),KJ1 1 PWR/AC

ASSY-PCB,MAIN(COM)

1 A/MAIN AA94-03510A ASSY-PCB,MAIN(COM);K15A(H),15FLAT,LATIN

2 Q401 0502-001115 TR-POWER;KSC5386,NPN,50W,TO-3PF,ST,8 2 PC801S 0604-001038 PHOTOCOUPLER;TR,130-260%,200MW 2 IC902 1103-001107 IC-EEPROM;24C020,256X8BIT,DIP,8P,300MIL 2 IC802 1203-000576 IC-S/WREGU;TDA8139SIP7POUT-9.5 2 IC201S 1204-001259 IC-VIDEOSYSTEM;TA1282N,DIP,56P 2 CY801S 2201-000446 C-CERAMIC,AC;CK45PE400V332-M(T 2 X901 2801-003224 CRYSTAL-UNIT;32.768KHZ,20PPM,2 2 X202 2802-000172 RESONATOR-CERAMIC;503.5KHZ,0.5 2 SF101S 2904-000287 FILTER-SAWAV;M3951M45.75MHz,SIP5P,12.5dB 2 SW906 3404-000295 SW-TACT,V;KPT1122R1KEYSTT=0.3M 2 FP801S 3601-001012 FUSE-FERRULE;250V,4A,SLOW-BLOW 2 V999S 3704-001105 SOCKET-CRT;11P,20PI,26.5PI,NI,2 CN604 3711-002643 POST-HEADER;YW025-04(AUTO) 2 JA701 3722-001453 JACK-RCA;3P,3.4mm,NI,BLK,2 IC901 AA09-00074A IC-MCU;Z9036512PSC-R50C7,CT-5066,42P, 2 T801S AA26-00043A TRANS SWITCHING;-,-,-,AC90~260V,125/12.5 2 T444S AA26-30001Y TRANS-FRYBACK;-,FSV-20A001,20,125V 2 T401 AA26-50001B HORIZ.DRIVE;-,7.1MH,102UH,10-2 2 LR401S AA27-00122A COIL LINEARITY;90UH,90UH,L81 DR10x10,7.5 2 LX801S AA29-30001D FILTER-LINE;-,6.0MH,2A,-,SQ191 2 GT101A AA39-20010D LEAD-CONNECTOR,ASSY;-,YFH800-01,S,1P,400 2 CN501 AA39-20109A LEAD-CONNECTOR,ASSY;-,YBNH0252 TU01S AA40-00045A TUNER-F/S;TECC1070PG32A(S),NTSC,TR,181CH 2 RM901 AA32-00008A MODULE REMOCON;SRV-19M,38KHZ,800,MESH,V, 2 A/AUTO AA94-05002A ASSY-PCB,MAIN(AUTO);K15A(H),15,FLAT,LAT 3 D806 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D901 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D903 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D904 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D907 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D601 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D202 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D203 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D204 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D206 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D207 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D402 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41 3 D401 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41 3 D208 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41 3 D103 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41 3 D805 0402-001111 DIODE-RECTIFIER;1N5397GP,600V,1.5A,DO-20 3 D804S 0402-001111 DIODE-RECTIFIER;1N5397GP,600V,1.5A,DO-20 3 D803S 0402-001111 DIODE-RECTIFIER;1N5397GP,600V,1.5A,DO-20 3 D802S 0402-001111 DIODE-RECTIFIER;1N5397GP,600V,1.5A,DO-20 3 D801S 0402-001111 DIODE-RECTIFIER;1N5397GP,600V,1.5A,DO-20 3 D802 0402-000540 DIODE-RECTIFIER;RU20A,600V,1.5 3 D803 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,40 3 D407 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,40 3 D405 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,40 3 D301 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,40 3 D403 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,40 3 D404 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,40 3 DZ806 0403-001318 DIODE-ZENER;MTZJ4.3B,4.17-4.43V,500mW,DO 3 DZ903 0403-001319 DIODE-ZENER;MTZJ4.7C,4.68-4.93V,500mW,DO 3 D205 0403-001319 DIODE-ZENER;MTZJ4.7C,4.68-4.93V,500mW,DO 3 D906 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ901 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ902 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ904 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 D905 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 D102 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 D855 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 D856 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 D902 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ601 0403-000719 DIODE-ZENER;MTZJ7.5B,7.5V,7.07-7.45V,500

3 D210 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 3 DZ204 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D 3 DZ205 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D 3 DZ206 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D 3 DZ207 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D 3 DZ208 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D 3 DZ209 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D 3 DZ203 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D 3 D299 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D 3 D302 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D 3 D701 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D 3 DZ202 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D 3 DZ201 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D 3 D804 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D 3 DZ603 0403-001325 DIODE-ZENER;MTZJ15C,14.35-15.09V,500mW,D 3 DZ602 0403-001325 DIODE-ZENER;MTZJ15C,14.35-15.09V,500mW,D 3 DS603 0403-001325 DIODE-ZENER;MTZJ15C,14.35-15.09V,500mW,D 3 DS602 0403-001325 DIODE-ZENER;MTZJ15C,14.35-15.09V,500mW,D 3 DZ802 0403-001327 DIODE-ZENER;MTZJ18A,16.22-17.06V,500mW,D 3 D201 0403-001316 DIODE-ZENER;MTZJ3.0A,2.85-3.07V,500mW,DO 3 DZ808 0403-000699 DIODE-ZENER;TZP27B,27V,27-30.8 3 D101 0403-000700 DIODE-ZENER;TZP33A,33V,31-35V, 3 Q402 0501-000369 TRANSISTOR;KSC2331-Y(TAPG) 3 Q151 0501-000436 TR-SMALLSIGNAL;KTC3197,NPN,30V 3 Q503 0501-002014 TR-SMALLSIGNAL;KSC2330-RNPN 3 Q502 0501-002014 TR-SMALLSIGNAL;KSC2330-RNPN 3 Q501 0501-002014 TR-SMALLSIGNAL;KSC2330-RNPN 3 Q903 0501-002183 TR-SMALL SIG;KTC9014,NPN,625MW,TO-92,100 3 Q601 0501-002183 TR-SMALL SIG;KTC9014,NPN,625MW,TO-92,100 3 Q203 0501-002183 TR-SMALL SIG;KTC9014,NPN,625MW,TO-92,100 3 Q202 0501-002183 TR-SMALL SIG;KTC9014,NPN,625MW,TO-92,100 3 Q201 0501-002183 TR-SMALL SIG;KTC9014,NPN,625MW,TO-92,100 3 QU01 0504-000123 TR-DIGITAL;KSR1010,NPN,300MW,1 3 Q801 1203-001217 IC-POST,ADJUSTREG;431,T0-92,3P,4.58MIL,P 3 VX801S 1405-000152 VARISTOR;560V,2500A,14X8.5MM,T 3 R302 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP, 3 R208 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP, 3 R209 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP, 3 R210 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP, 3 R503 2001-000007 R-CARBON;3KOHM,5%,1/8W,AA,TP,1 3 R502 2001-000007 R-CARBON;3KOHM,5%,1/8W,AA,TP,1 3 R501 2001-000007 R-CARBON;3KOHM,5%,1/8W,AA,TP,1 3 R159 2001-000007 R-CARBON;3KOHM,5%,1/8W,AA,TP,1 3 R158 2001-000007 R-CARBON;3KOHM,5%,1/8W,AA,TP,1 3 R926 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3.2MM 3 R820 2001-000019 R-CARBON(S);10ohm,5%,1/2W,AA,TP,2.4x6.4m 3 R416 2001-000022 R-CARBON(S);33OHM,5%,1/2W,AA,T 3 R823 2001-000109 R-CARBON(S);470OHM,5%,1/2W,AA, 3 R242 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP 3 R152 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP 3 R204 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP 3 R205 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP 3 R206 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP 3 R229 2001-000258 R-CARBON;1.8Kohm,5%,1/8W,AA,TP,1.8x3.2m 3 R228 2001-000258 R-CARBON;1.8Kohm,5%,1/8W,AA,TP,1.8x3.2m 3 R606 2001-000258 R-CARBON;1.8Kohm,5%,1/8W,AA,TP,1.8x3.2m 3 RS604 2001-000258 R-CARBON;1.8Kohm,5%,1/8W,AA,TP,1.8x3.2m 3 R607 2001-000258 R-CARBON;1.8Kohm,5%,1/8W,AA,TP,1.8x3.2m 3 RS605 2001-000258 R-CARBON;1.8Kohm,5%,1/8W,AA,TP,1.8x3.2m 3 R903 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R904 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R922 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R923 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R155 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R211 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R212 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R509 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R508 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R507 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,

Samsung Electronics 7-1

Electrical Parts List

7. Electrical Parts List

7-1 CT15K8W6X/XAP

Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark

3 RS614 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R941 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R930 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R932 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R933 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R937 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R927 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R237 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R602 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R911 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R921 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R916 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R917 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R918 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R215 2001-000331 R-CARBON;12KOHM,5%,1/8W,AA,TP, 3 R214 2001-000331 R-CARBON;12KOHM,5%,1/8W,AA,TP, 3 RU06 2001-000397 R-CARBON;180KOHM,5%,1/8W,AA,TP 3 R234 2001-000405 R-CARBON;180OHM,5%,1/8W,AA,TP, 3 R902 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R905 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R931 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R938 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 RS606 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R201 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R241 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R301 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R601 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R611 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R230 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R925 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP 3 R924 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP 3 R939 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP 3 R952 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP 3 R906 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP 3 R227 2001-000508 R-CARBON;220KOHM,5%,1/8W,AA,TP 3 R226 2001-000508 R-CARBON;220KOHM,5%,1/8W,AA,TP 3 R988 2001-000508 R-CARBON;220KOHM,5%,1/8W,AA,TP 3 R402 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP, 3 R236 2001-000548 R-CARBON;270KOHM,5%,1/8W,AA,TP 3 R240 2001-000577 R-CARBON;2KOHM,5%,1/8W,AA,TP,1 3 R914 2001-000577 R-CARBON;2KOHM,5%,1/8W,AA,TP,1 3 R940 2001-000577 R-CARBON;2KOHM,5%,1/8W,AA,TP,1 3 R253 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP 3 R252 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP 3 R251 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP 3 R218 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP 3 R909 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP 3 R512 2001-000628 R-CARBON;300OHM,5%,1/8W,AA,TP, 3 R511 2001-000628 R-CARBON;300OHM,5%,1/8W,AA,TP, 3 R510 2001-000628 R-CARBON;300OHM,5%,1/8W,AA,TP, 3 R231 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP, 3 R517 2001-000666 R-CARBON;33OHM,5%,1/8W,AA,TP,1 3 R514 2001-000666 R-CARBON;33OHM,5%,1/8W,AA,TP,1 3 R513 2001-000666 R-CARBON;33OHM,5%,1/8W,AA,TP,1 3 R157 2001-000666 R-CARBON;33OHM,5%,1/8W,AA,TP,1 3 R219 2001-000674 R-CARBON;360OHM,5%,1/8W,AA,TP, 3 R951 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R915 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R203 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R202 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R153 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 RS601 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 RS602 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R222 2001-000773 R-CARBON;470KOHM,5%,1/8W,AA,TP 3 RU02 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R401 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R223 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R154 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R901 2001-000793 R-CARBON;47OHM,5%,1/8W,AA,TP,1 3 R610 2001-000793 R-CARBON;47OHM,5%,1/8W,AA,TP,1 3 R156 2001-000793 R-CARBON;47OHM,5%,1/8W,AA,TP,1 3 R213 2001-000837 R-CARBON;51KOHM,5%,1/8W,AA,TP, 3 R814 2001-000864 R-CARBON;56Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R913 2001-000924 R-CARBON;680ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 RU10 2001-000924 R-CARBON;680ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R239 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP 3 R604 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP

3 R305 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP 3 R919 2001-000977 R-CARBON;8.2Kohm,5%,1/8W,AA,TP,1.8x3.2m 3 R910 2001-000995 R-CARBON;820OHM,5%,1/8W,AA,TP, 3 R907 2001-000995 R-CARBON;820OHM,5%,1/8W,AA,TP, 3 R102 2001-001000 R-CARBON ;82Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 RU07 2001-001062 R-CARBON(S);10MOHM,5%,1/2W,AA, 3 R444 2001-001099 R-CARBON/METALFILM;RD1/2T2.7K3 R825 2001-001108 R-CARBON(S);22KOHM,5%,1/2W,AA, 3 R920 2001-001108 R-CARBON(S);22KOHM,5%,1/2W,AA, 3 R207 2001-001111 R-CARBON(S);240OHM,5%,1/2W,AA, 3 R403 2001-001114 R-CARBON(S);270OHM,5%,1/2W,AA, 3 R854 2001-001125 R-CARBON(S);300KOHM,5%,1/2W,AA 3 R801 2001-001150 R-CARBON(S);470KOHM,5%,1/2W,AA 3 R808 2001-001150 R-CARBON(S);470KOHM,5%,1/2W,AA 3 R101 2001-001155 R-CARBON(S);5.6Kohm,5%,1/2W,AA,TP,2.4x6. 3 R817 2001-001170 R-CARBON(S);6.8OHM,5%,1/2W,AB, 3 R811 2001-001170 R-CARBON(S);6.8OHM,5%,1/2W,AB, 3 R701 2001-001187 R-CARBON(S);75OHM,5%,1/2W,AA,T 3 R816 2001-001192 R-CARBON(S);820OHM,5%,1/2W,AB, 3 R417 2001-001410 R-CARBON;RD1/2T(S)430-J43R 3 R515 2002-001006 R-COMPOSITION;4.7KOhm,5%,1/2W,AA,TP,3.7X 3 RH01 2002-001006 R-COMPOSITION;4.7KOhm,5%,1/2W,AA,TP,3.7X 3 RH02 2002-001006 R-COMPOSITION;4.7KOhm,5%,1/2W,AA,TP,3.7X 3 RY801S 2002-001013 R-COMPOSITION;4.7MOhm,5%,1/2W,AA,TP,3.7X 3 R405 2003-000540 R-METALOXIDE(S);1KOHM,5%,2W,AD 3 R104 2003-000592 R-METALOXIDE(S);22OHM,5%,2W,AD 3 R105 2003-000592 R-METALOXIDE(S);22OHM,5%,2W,AD 3 R106 2003-000664 R-METAL OXIDE(S);330HM,5%,2W,AF,TP,4X12M 3 R107 2003-000664 R-METAL OXIDE(S);330HM,5%,2W,AF,TP,4X12M 3 R415 2003-000784 R-METAL OXIDE(S);7.5KOHM,5%,2W,AF,TP,3.7 3 R802 2003-000994 R-METALOXIDE(S);33KOHM,5%,2W,AF,TP,3.9X1 3 R803 2003-000994 R-METALOXIDE(S);33KOHM,5%,2W,AF,TP,3.9X1 3 R807 2003-000994 R-METALOXIDE(S);33KOHM,5%,2W,AF,TP,3.9X1 3 R407 2003-002102 R-METAL OXIDE;68Kohm,5%,2W,AF,TP,4x12mm 3 R504 2003-001025 R-METALOXIDE(S);15KOHM,5%,2W,A 3 R505 2003-001025 R-METALOXIDE(S);15KOHM,5%,2W,A 3 R506 2003-001025 R-METALOXIDE(S);15KOHM,5%,2W,A 3 R936 2004-000195 R-METAL;100Kohm,1%,1/8W,AA,TP,1.8x3.2m 3 R603 2004-000195 R-METAL;100Kohm,1%,1/8W,AA,TP,1.8x3.2m 3 R235 2004-000195 R-METAL;100Kohm,1%,1/8W,AA,TP,1.8x3.2m 3 RS613 2004-000195 R-METAL;100Kohm,1%,1/8W,AA,TP,1.8x3.2m 3 R233 2001-000011 R-CARBON;75Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R852 2004-001371 R-METAL(S);1.5KOHM,1%,1/2W,AA, 3 R702 2004-001373 R-METAL,FILM;RM1/2T100K-F 3 RS607 2004-001373 R-METAL,FILM;RM1/2T100K-F 3 R853 2004-001390 R-METAL(S);1KOHM,2%,1/2W,AA,TP 3 RR401S 2004-001390 R-METAL(S);1KOHM,2%,1/2W,AA,TP 3 R824 2004-001983 R-METAL;2.49KOHM,1%,1/2W,AA,TP,2.4X6.4 3 R821 2004-004089 R-METAL;123KOHM,1%,1/2W,AA,TP,2.5X6.5 3 R809 2008-000205 R-FUSIBLE(S);10OHM,5%,1/2W,AF, 3 R410 2008-000206 R-FUSIBLE(S);1OHM,5%,1/2W,AF,T 3 R812 2008-000252 R-FUSIBLE(S);0.47OHM,10%,1/2W, 3 R409 2008-000253 R-FUSIBLE(S);0.47OHM,5%,1W,AF, 3 R819 2008-001049 R-FUSIBLE(S);3.9OHM,5%,2W,AF,T 3 R819A 2008-001049 R-FUSIBLE(S);3.9OHM,5%,2W,AF,T 3 R599 2008-001053 R-FUSIBLE;22OHM,5%,1/2W,AF,TP, 3 R406 2008-001107 R-FUSIBLE(S);300ohm,5%,2W,AG,TP,3.9x12mm 3 C802 2201-000119 C-CERAMIC,DISC;100NF,+80-20%,50V,5MM,TAP 3 C907 2201-000119 C-CERAMIC,DISC;100NF,+80-20%,50V,5MM,TAP 3 C213 2201-000193 C-CERAMIC,DISC;10PF,0.25PF,50V 3 C908 2201-000193 C-CERAMIC,DISC;10PF,0.25PF,50V 3 C201 2201-000292 C-CERAMIC,DISC;1NF,10%,50V,Y5P 3 C602 2201-000292 C-CERAMIC,DISC;1NF,10%,50V,Y5P 3 CS602 2201-000292 C-CERAMIC,DISC;1NF,10%,50V,Y5P 3 C823 2201-000370 C-CERAMIC,DISC;220PF,10%,50V,Y5P,TP 3 C445 2201-000441 C-CERAMIC,DISC;3.3nF,10%,500V,Y5P,TP,10x 3 C444 2201-000441 C-CERAMIC,DISC;3.3nF,10%,500V,Y5P,TP,10x 3 C411 2201-000556 C-CERAMIC,DISC;470PF,10%,500V, 3 C408 2201-000556 C-CERAMIC,DISC;470PF,10%,500V, 3 C406 2201-000556 C-CERAMIC,DISC;470PF,10%,500V, 3 C302 2201-000556 C-CERAMIC,DISC;470PF,10%,500V, 3 C909 2201-000573 C-CERAMIC,DISC;47PF,5%,50V,NPO 3 C807 2201-000599 C-CERAMIC,DISC;560PF,10%,500V, 3 C212 2201-000982 C-CERAMIC,DISC;10NF,+80-20%,50 3 C805 2201-000991 C-CERAMIC,HIC;CK45(T)B2KV561-K 3 C505 2201-000723 C-CERAMIC,DISC;4.7nF,20%,3KV,Y5U,TP,16x5 3 C229 2202-000127 C-CERAMIC,MLC-AXIAL;10NF,+80-2

Electrical Parts List

7-2 Samsung Electronics

Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark

3 C236 2202-000127 C-CERAMIC,MLC-AXIAL;10NF,+80-2 3 C303 2202-000127 C-CERAMIC,MLC-AXIAL;10NF,+80-2 3 C915 2202-000127 C-CERAMIC,MLC-AXIAL;10NF,+80-2 3 C101 2202-000127 C-CERAMIC,MLC-AXIAL;10NF,+80-2 3 C104 2202-000127 C-CERAMIC,MLC-AXIAL;10NF,+80-2 3 C151 2202-000127 C-CERAMIC,MLC-AXIAL;10NF,+80-2 3 C153 2202-000127 C-CERAMIC,MLC-AXIAL;10NF,+80-2 3 C705 2202-000183 C-CERAMIC;CKOAX7R16VT222-MEP05 3 CS608 2202-000183 C-CERAMIC;CKOAX7R16VT222-MEP05 3 CS609 2202-000183 C-CERAMIC;CKOAX7R16VT222-MEP05 3 C612 2202-000279 C-CERAMIC,MLC-AXIAL;47PF,5%,50 3 C611 2202-000279 C-CERAMIC,MLC-AXIAL;47PF,5%,50 3 C235 2202-000279 C-CERAMIC,MLC-AXIAL;47PF,5%,50 3 C237 2202-000791 C-CERAMIC,MLC-AXIAL;150pF,10%,50V,Y5P,TP 3 CS603 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50 3 C904 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50 3 C902 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50 3 C503 2202-000825 C-CERAMIC,MLC-AXIAL;680PF,10%,50V,Y5P,TP 3 C502 2202-000862 C-CERAMIC;CCOASL50VT391-JUP050 3 C501 2202-000863 C-CERAMIC;CKOAX7R50VT561-KUP050561 3 C808 2301-000016 C-FILMPEF;22NF,5%,100V,TP,7.2X 3 C301 2301-000016 C-FILMPEF;22NF,5%,100V,TP,7.2X 3 C204 2301-000188 C-FILM,PEF;1NF,5%,100V,10.5X12 3 C822 2301-000192 C-FILM,PEF;1NF,5%,50V,5.3X10MM 3 C410 2301-000224 C-FILM,PEF;22NF,5%,50V,7.4X3.9 3 C401 2301-000224 C-FILM,PEF;22NF,5%,50V,7.4X3.9 3 C852 2301-000235 C-FILM,PEF;3.9NF,5%,50V,6.5X3.0X5.5MM,5M 3 C308 2301-000310 C-FILM,PEF;68NF,5%,50V,8.0X8.5 3 C218 2301-000395 C-FILM,PEF;18nF,5%,50V,TP,6.5x12.5x3.5mm 3 C910 2301-000445 C-FILM,PEF;4.7nF,5%,50V,TP,5.5x7x3mm,5mm 3 C803 2301-001435 C-FILM,PPF;1.5nF,5%,1.2kV,TP,15x8x12.5mm 3 C810 2305-000412 C-FILM,MPEF;470NF,5%,63V,-,5MM 3 C912 2305-000470 C-FILM,MPEF;68NF,5%,100V,-,5MM 3 C313 2305-000470 C-FILM,MPEF;68NF,5%,100V,-,5MM 3 CU02 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C701 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C227 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C222 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C815 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C405 2305-000704 C-M,POLYESTER;CFS922MTAPG250V1 3 C206 2305-001011 C-FILM,MPEF;22NF,5%,100V,3.5X12.5X7.5MM, 3 C806 2401-000262 C-AL;100UF,20%,160V,GP,16X25MM,5MM, 3 C309 2401-000365 C-AL;100uF,20%,50V,WT,TP,10x12.5mm, 3 C911 2401-000480 C-AL;10UF,20%,50V,GP,5X11MM,5M 3 C903 2401-000480 C-AL;10UF,20%,50V,GP,5X11MM,5M 3 C816 2401-000480 C-AL;10UF,20%,50V,GP,5X11MM,5M 3 C310 2401-000480 C-AL;10UF,20%,50V,GP,5X11MM,5M 3 C225 2401-000480 C-AL;10UF,20%,50V,GP,5X11MM,5M 3 C220 2401-000480 C-AL;10UF,20%,50V,GP,5X11MM,5M 3 C108 2401-000480 C-AL;10UF,20%,50V,GP,5X11MM,5M 3 CS601 2401-000603 C-AL;1UF,20%,50V,GP,5X11MM,5MM 3 C604 2401-000603 C-AL;1UF,20%,50V,GP,5X11MM,5MM 3 C603 2401-000603 C-AL;1UF,20%,50V,GP,5X11MM,5MM 3 C226 2401-000603 C-AL;1UF,20%,50V,GP,5X11MM,5MM 3 C219 2401-000603 C-AL;1UF,20%,50V,GP,5X11MM,5MM 3 C214 2401-000660 C-ELECTROLYTIC;CE04WTAPG50V2.2 3 C102 2401-000660 C-ELECTROLYTIC;CE04WTAPG50V2.2 3 C820 2401-000703 C-ELEC;CE04-40/8525VT222-MWSD 3 C412 2401-000927 C-AL;22UF,20%,250V,GP,13X20MM, 3 C851 2401-001192 C-AL;33UF,20%,50V,GP,6X11MM,5MM,TP 3 C905 2401-001333 C-ELECTROLYTIC;CE04WTAPG50V0.4 3 C311 2401-001333 C-ELECTROLYTIC;CE04WTAPG50V0.4 3 C207 2401-001333 C-ELECTROLYTIC;CE04WTAPG50V0.4 3 C205 2401-001333 C-ELECTROLYTIC;CE04WTAPG50V0.4 3 C202 2401-001333 C-ELECTROLYTIC;CE04WTAPG50V0.4 3 CK03 2401-001333 C-ELECTROLYTIC;CE04WTAPG50V0.4 3 CK04 2401-001333 C-ELECTROLYTIC;CE04WTAPG50V0.4 3 C407 2401-001429 C-ELECTROLYTIC;CE04WTAPG50V470 3 C821 2401-001486 C-AL;47UF,20%,160V,HR,13X20MM,5MM,T 3 C817 2401-001840 C-AL;100UF,20%,16V,GP,TP,6.3X1 3 C215 2401-001840 C-AL;100UF,20%,16V,GP,TP,6.3X1 3 CK05 2401-001840 C-AL;100UF,20%,16V,GP,TP,6.3X1 3 C601 2401-001998 C-AL;1000UF,20%,25V,GP,TP,10X20 3 C409 2401-001998 C-AL;1000UF,20%,25V,GP,TP,10X20 3 C901 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5 3 C232 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5 3 C231 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5

3 CU03 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5 3 C413 2401-002268 C-ELEC;CE04-40/105250VT2R2-MWR 3 C306 2401-002458 C-AL;1000UF,20%,35V,GP,16X25MM 3 C221 2401-002462 C-ELECTROLYTIC;CE04WTAPG16V33M 3 C110 2401-002594 C-AL;220uF,20%,16V,GP,TP,8x11.5,5 3 L206 2701-000111 INDUCTOR-AXIAL;100UH,10%,2.5X3 3 L202 2701-000111 INDUCTOR-AXIAL;100UH,10%,2.5X3 3 L902 2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3. 3 L208 2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3. 3 L901 2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3. 3 LK01 2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3. 3 L999 2701-000115 INDUCTOR-AXIAL;10UH,10%,2.8X7M 3 L301 2701-000116 INDUCTOR-AXIAL;10UH,10%,4.2X9. 3 L602 2701-000158 INDUCTOR-AXIAL;22UH,10%,2.5X3. 3 L203 2701-000158 INDUCTOR-AXIAL;22UH,10%,2.5X3. 3 L102 2701-000178 INDUCTOR-AXIAL;33UH,10%,2.8X7MM 3 L503 2701-000184 INDUCTOR-AXIAL;4.7UH,10%,2.5X3.4MM 3 L502 2701-000184 INDUCTOR-AXIAL;4.7UH,10%,2.5X3.4MM 3 L501 2701-000184 INDUCTOR-AXIAL;4.7UH,10%,2.5X3.4MM 3 L152 2701-000202 INDUCTOR-AXIAL;560NH,10%,2.5X3 3 L204 2701-000207 INDUCTOR-AXIAL;56UH,5%,2.5X3.4 3 L810 2701-001032 INDUCTOR-AXIAL;100UH,10%,5X14MM 3 L402 2701-001032 INDUCTOR-AXIAL;100UH,10%,5X14MM 3 X201 2801-003725 CRYSTAL-UNIT;3.579545MHz,20ppm,28-AAM,16 3 L803 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,3 L805 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,3 L811 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,3 Z601 2903-000135 FILTER-CERAMIC;BP,4.5MHZ 3 Z201 2903-001022 FILTER-CERAMIC;TR,4.5MHZ 3 L804 3301-001223 CORE-FERRITE BEAD;AB,-,3.5X5X0.8MM,-,TP, 3 L802 3301-001223 CORE-FERRITE BEAD;AB,-,3.5X5X0.8MM,-,TP, 3 SW901 3404-000244 SWITCH-TACT;15V,20MA,90-170GF, 3 SW902 3404-000244 SWITCH-TACT;15V,20MA,90-170GF, 3 SW903 3404-000244 SWITCH-TACT;15V,20MA,90-170GF, 3 SW904 3404-000244 SWITCH-TACT;15V,20MA,90-170GF, 3 SW905 3404-000244 SWITCH-TACT;15V,20MA,90-170GF, 3 FA801S 3601-001086 FUSE-AXIAL LEAD;125V,5A,FAST-ACTING,GLAS 3 F801B 3602-000114 FUSE-HOLDER;-,-,30MOHM 3 F801A 3602-000114 FUSE-HOLDER;-,-,30MOHM 3 J602 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J601 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J505 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J603 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J803 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J802 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J612 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J609 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J606 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J605 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J604 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J503 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J203 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J159 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J155 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J153 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J150 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J204 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J502 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J501 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J450 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J445 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J206 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 JU91 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 JU10 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 JU04 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 JU03 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 JWX01 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 JU94 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 JU96 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 JUS96 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 JWK04 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J902 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J901 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J807 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J806 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J805 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 JF01 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A

Electrical Parts List

Samsung Electronics 7-3

Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark

3 JS05 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 JS04 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 JS03 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 JS02 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 JS01 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J145 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J081 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J080 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J079 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J078 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J077 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J076 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J082 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J095 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J094 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J093 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J092 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J091 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J089 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J075 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J022 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J017 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J016 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J015 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J011 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J010 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J024 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J074 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J073 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J071 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J069 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J067 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J025 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J120 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J119 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J118 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J117 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J115 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J114 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J123 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J142 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J140 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J137 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J134 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J130 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J124 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J113 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J104 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J103 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J102 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J098 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J097 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J096 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J105 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J112 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J109 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J108 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J107 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J106 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J026 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J029 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J027 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J033 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J030 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J034 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J041 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J043 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J036 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J045 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J047 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J049 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J050 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J054 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J053 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J052 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J051 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J058 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A

3 J064 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J152 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 JS07 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 JS06 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 JK01 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J059 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 JAW05 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 JK02 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 JS08 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 JWU02 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 EY818 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY811 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY819 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY831 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY832 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY835 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY836 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY837 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY821 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY824 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY825 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY827 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY828 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY408 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY409 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY410 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY411 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY412 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY413 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY101 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY401 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY402 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY403 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY405 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY406 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY414 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY604 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY701 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY702 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY415 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY418 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY419 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY603 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY602 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY601 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY803 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY809 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EL802 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 EL801 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 EL301 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 EL302 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 EL404 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 EL826 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 GT801 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT802 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT803 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT804 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT805 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT806 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT101 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT301 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT302 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT401 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT402 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT501 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 C216 2201-000354 C-CERAMIC,DISC;20PF,5%,50V,NPO 3 R413 2001-001037 R-CARBON(S);0.39OHM,5%,1/2W,AA 3 06VER AA41-11037H PCB-MAIN;K15A,1L,CEM-1,245x245x1.6T,1A, 3 L/LINE AA68-01544A LABEL;LINE,ALL MDL COMMON 3 C811 2401-000302 C-AL;100UF,20%,25V,GP,6X11MM,5 3 C812 2401-002463 C-ELECTROLYTIC;CE04WTAPG16V470M-M(SG)-VE 3 RU03 2001-000832 R-CARBON;510OHM,5%,1/8W,AA,TP, 3 C305 2305-000149 C-FILM;CF922N100VT104-J-40/105 3 C304 2401-003594 C-AL;0.68uF,10%,50V,GP,TP,5x11mm,5 3 R303 2001-000908 R-CARBON ;62Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R308 2001-000908 R-CARBON ;62Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R304 2003-000436 R-METALOXIDE(S);1.5OHM,5%,1W,A

Electrical Parts List

7-4 Samsung Electronics

Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark

3 R306 2001-000766 R-CARBON;43KOHM,5%,1/8W,AA,TP, 3 R307 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP, 3 R310 2001-001117 R-CARBON(S);2KOHM,5%,1/2W,AA,T 3 R309 2003-001043 R-METALOXIDE(S);510OHM,5%,1W,A 3 R404 2001-001136 R-CARBON(S);36OHM,5%,1/2W,AA,T 3 R411 2004-001889 R-METAL(S);127KOHM,1%,1/2W,AA,TP,2.5X6.5 3 R412 2004-001889 R-METAL(S);127KOHM,1%,1/2W,AA,TP,2.5X6.5 3 R810A 2008-000299 R-FUSIBLE;RF2RT470-J 3 C209 2202-002037 C-CERAMIC,MLC-AXIAL;100NF,+80-20 3 C210 2202-002037 C-CERAMIC,MLC-AXIAL;100NF,+80-20 3 C211 2202-002037 C-CERAMIC,MLC-AXIAL;100NF,+80-20 3 C230 2202-002037 C-CERAMIC,MLC-AXIAL;100NF,+80-20 3 C312 2401-000553 C-AL;1UF,10%,50V,GP,5X11MM,5MM 3 C906 2201-000863 C-CERAMIC,DISC;680PF,10%,50V,Y 3 CK01 2202-000127 C-CERAMIC,MLC-AXIAL;10NF,+80-2 3 CK06 2202-000286 C-CERAMIC,MLC-AXIAL;56PF,5%,50 3 CR403S 2306-000171 C-FILM,MPPF;270NF,5%,250V,21.5X12.5MM,7. 3 R257 2008-000266 R-FUSIBLE(S);1OHM,5%,2W,AF,TP, 3 R518 2008-000266 R-FUSIBLE(S);1OHM,5%,2W,AF,TP, 3 R815 2004-001408 R-METAL(S);91KOHM,1%,1/2W,AA,T 3 R928 2001-000679 R-CARBON;36KOHM,5%,1/8W,AA,TP, 3 DZ610 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 3 CR402S 2201-000467 C-CERAMIC,DISC;330PF,10%,2KV,Y 3 R518A 2008-001015 R-FUSIBLE;1.50HM,5%2WAF,TP39X10 3 R929 2001-000232 R-CARBON;1.3KOHM,5%,1/8W,AA,TP 2 LD901 AA96-00555A ASSY LED GUIDE;-,-,UEX-LD-030,GREEN 2 L205 AA26-10004C TRANS-IF;-,7MG,VIF,0.37UH,7MM, 2 L201 AA26-10004K TRANS-IF;-,7MG,SIF,-,7MM,100PF 2 A/SUBM AA97-01633A ASSY-SUB MATERIAL;SOLVENTES Y SOLDADURAS 3 0204-000442 SOLVENT;CH3-CH5H-CH396%IM-1000 3 0202-000008 SOLDER-WIRE;S63S-D3.0,S63A,D3,63/37 3 0204-001024 FLUX;DF-96TVS,-,20%,3 0202-000187 SOLDER-WIREFLUX;-,RS60S,D1.2,6 2 D814A AA96-00243D ASSY H/S;-,BRIDGE,AA62-00045A,D06U20S,D 3 0205-000129 GREASE-SILICON;SC102,JAPAN 3 6003-000335 SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR 3 AA62-00045A HEAT SINK-PS;-,-,T1.0,-,-,DREAM,-,-,-,-, 3 0402-001374 DIODE-RECTIFIERSDS60U20S,200V,6A,TO-22 2 IC601 AA96-50397A ASSY-H/S;LA62-30180J,TDA7266S. 3 1201-001308 IC-POWERAMP;7266,ZIP,15P,-,DUAL,26dB,PL 3 0205-000129 GREASE-SILICON;SC102,JAPAN 3 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW 3 AA62-30180J HEATSINK-ES;-,A6063EXTR,-,WHT,-,-,-,40 2 PWR/AC AA96-00570A ASSY POWER CORD;-,CP2/NO,H/C200,KKP419C, 3 AA39-10006X POWER-CORD;-,KKP419C,KLCE-2F,2.286MT 3 AA61-20284A HOLDER P CORD;PP,VO,BLK,KE-002 2 L/PQS AA68-01018A LABEL-PQS,-,50mmX,13,-,WHITE,2 IC801S AA96-00242A ASSY H/S;-,-,AA62-30186B,KA5Q0765R,3 1203-001932 IC-PWM CONTROLLER;5Q0765,TO-220F,5P,185M 3 AA62-30186B HEAT SINK-ES;-,-,-,SILVER,171J + COVER-H 3 0205-000129 GREASE-SILICON;SC102,JAPAN 3 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW 2 IC301 AA96-50075A ASSY-H/S;-,VERT,AA62-30032A,KA2131 3 1204-000475 IC;KA2131 3 6003-000334 SCREW-TAPTITE;RH,+,2S,M3,L6,ZP 3 AA62-30032A HEAT SINK-PS/-,SPC-1,T1.0-,FT-2V2 NT801S 1404-001045 THERMISTOR NTC;4.7OHM,15%,2900K,35.0MW,T 2 ADH-SI 0201-001059 ADHESIVE-SILICON;B#9590,CARTRIGE 2 C203 2401-000133 C-AL;1000UF,20%,16V,GP,13X20MM 2 CN704 3711-003641 CONNECTOR-HEADER;BOX,12P,1R,2. 2 ICK01 1204-000506 IC-LINEAR;LA7510SIP9P 2 SFK01 2904-000289 FILTER-SAWAV;45.75MHZ,SIP5P,ST 2 C801 2401-002219 C-AL;220UF,20%,400V,-,25X40,10MM,ST 2 P801S 1404-001156 THERMISTOR-PTC;9OHM,+30%/-20%,220VRMS,27 2 CR401S 2306-000327 C-FILM;CF922P1.6KVT632-H-25/85

ASSY-PCB SOUND

1 A/SOUN AA95-00624A ASSY-PCB SOUND;CT2188BW6X/XAX,K15A,STR

2 CNA01 3711-002702 PIN-HEADER;YFAW-025-104(4PIN2.5MM)10.0X 2 CNA02 3711-002703 CONNECTOR-HEADER;NOWALL,5P,1R,2.5mm,ANGL 2 CNA03 AA61-10068A BRACKET-PCB;-,SPTE,-,T0.3,-,-, 2 ICA02 1204-001455 IC-VOLUME/TONECONT.;TDA7449,DIP,20P,300 2 ICA01 1209-001116 IC-ETC,LINEAR;CXA2104S,DIP,30P,-,PLASTI

2 QA01 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 2 RA07 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 2 RA08 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 2 RA13 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 2 RA14 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 2 RA19 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 2 RA22 2001-000007 R-CARBON;3KOHM,5%,1/8W,AA,TP,1 2 RA16 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP 2 RA15 2001-000435 R-CARBON;1MOHM,5%,1/8W,AA,TP,1 2 RA21 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP 2 RA23 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP 2 RA18 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm 2 RA01 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP, 2 RA11 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP 2 RA12 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP 2 RA20 2004-004970 R-METAL(S);62Kohm,1%,1/8W,AA,TP,1.8x3.2m 2 CA16 2301-000160 C-FILM,PEF;12NF,5%,50V,11.0X6. 2 CA25 2301-000204 C-FILM,PEF;2.7NF,5%,50V,7.4X3. 2 CA15 2301-000289 C-FILM,PEF;5.6NF,5%,50V,6.5X5. 2 CA10 2301-000289 C-FILM,PEF;5.6NF,5%,50V,6.5X5. 2 CA11 2301-000289 C-FILM,PEF;5.6NF,5%,50V,6.5X5. 2 CA26 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m 2 CA12 2401-000027 C-AL;4.7UF,20%,50V,GP,5*11MM,5MEA 2 CA13 2401-000027 C-AL;4.7UF,20%,50V,GP,5*11MM,5MEA 2 CA20 2401-000027 C-AL;4.7UF,20%,50V,GP,5*11MM,5MEA 2 CA23 2401-000027 C-AL;4.7UF,20%,50V,GP,5*11MM,5MEA 2 CA01 2401-000480 C-AL;10UF,20%,50V,GP,5X11MM,5M 2 CA19 2401-000480 C-AL;10UF,20%,50V,GP,5X11MM,5M 2 CA30 2401-000480 C-AL;10UF,20%,50V,GP,5X11MM,5M 2 CA02 2401-000603 C-AL;1UF,20%,50V,GP,5X11MM,5MM 2 CA03 2401-000603 C-AL;1UF,20%,50V,GP,5X11MM,5MM 2 CA04 2401-000603 C-AL;1UF,20%,50V,GP,5X11MM,5MM 2 CA05 2401-000603 C-AL;1UF,20%,50V,GP,5X11MM,5MM 2 CA17 2401-000603 C-AL;1UF,20%,50V,GP,5X11MM,5MM 2 CA28 2401-000603 C-AL;1UF,20%,50V,GP,5X11MM,5MM 2 CA27 2401-001026 C-AL;3.3UF,20%,50V,GP,5X11MM,5 2 CA21 2401-001840 C-AL;100UF,20%,16V,GP,TP,6.3X1 2 CA18 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5 2 CA22 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5 2 CA24 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5 2 CA14 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5 2 CA29 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5 2 CA31 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5 2 CA06 2305-000708 C-FILM;CF922N100VT154-J-40/105 2 CA09 2305-000708 C-FILM;CF922N100VT154-J-40/105 2 CA07 2305-000355 C-FILM,MPEF;330NF,5%,63V,-,5MM 2 CA08 2305-000355 C-FILM,MPEF;330NF,5%,63V,-,5MM 2 JA01 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 2 00VER AA41-00072A PCB-STEREO MODULE;K15A,1L,FR-1,245X245X1 2 RA09 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP 2 RA10 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP 2 RA05 2001-000577 R-CARBON;2KOHM,5%,1/8W,AA,TP,1 2 RA06 2001-000577 R-CARBON;2KOHM,5%,1/8W,AA,TP,1 2 DA01 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D 2 A/STD AA98-00131A ASSY PCB(P);SOUND,STD+TURBO,K15A,(H)

ASSY-PCB,A/V FRONT;

1 A/A-V AA95-00577A ASSY-PCB,A/V FRONT;CT2188BL6,K15A,STR

2 JE601 3722-000143 JACK-PHONE;1P,3.4MM,-,MBAG 2 JR01 3722-001031 JACK-RCA;3P,3.6MM,#18,AU 2 CN705A AA39-20071F LEAD CONNECTOR-ASSY;YBNH250-12,12P,200MM 2 A/MAIN AA95-01332A ASSY-PCB,A/V FRONT,(AUTO);K15A(H) 3 RE01 2001-001077 R-CARBON(S);150OHM,5%,1/2W,AA, 3 RE02 2001-001077 R-CARBON(S);150OHM,5%,1/2W,AA, 3 CE01 2401-000480 C-AL;10UF,20%,50V,GP,5X11MM,5M 3 CE02 2401-000480 C-AL;10UF,20%,50V,GP,5X11MM,5M 3 01VER AA41-00227B PCB-A/V;CT-20S4,FR-1,1L,B,1.6T,245X245

ASSY-CABINET,FRONT

1 A/FRNT AA92-00771A ASSY-CABINET,FRONT;15K8,SV907P+DB004P,HB

Electrical Parts List

Samsung Electronics 7-5

Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark

2 DCOIL AA27-00077A COIL DEGAUSSING;-,-,4.3mH,20%,70T,9OHM,2 SPK+CF 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR 2 CRT+CF AA60-10050R SCREW-ASSY;WC,HH,+M5,L31.5,SWR 2 CWFC AA65-00011B CLAMP-WIRE;ALL MODEL,NYLON 66,V2,NTR,15M 2 F/C AA64-01730D CABINET FRONT;15K8,S907P+D004P NT TURBO, 3 SPRING AA61-60003J SPRING-CS;-,-,SUS304,0.5,OD6,H 3 KC AA64-01370B KNOB CONTROL;15K8,ABS,G3676,SV907P+W971, 3 KP AA64-01371B KNOB POWER;15K8,ABS,G3676,SV907P+W971,HB 3 IL AA64-00818B INDICATOR LED;-,21A8,-,ACRYL,-,CLR,3 WR AA64-00816B WINDOW REMOCON;-,21A8,-,PC,V0,VIOLET,3 KC+CF 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR 3 WR+CF 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR 2 L/QMS AA68-01554A LABEL;QMS,UARCOWHITEPAPER#1343 2 AV+CF 6006-001095 SCREW-ASS’Y TAPT;WP,BH,+,M4,L12,ZPC(YEL) 2 DRESPK AA65-30018A CLAMP-WIRE;-,NYLON6.6,-,-,DATL 2 A/SPK AA96-10137A ASSY-SPEAKER;3W,8OHM X 2,SY4,R700/L350 3 SPK 3001-001020 SPEAKER;3W,8ohm,90dB,140Hz 3 L/SPK AA39-20505MLEAD-CONNECTOR;SY4XREC,R700/L350 2 CDCOIL AA61-00735A HOLDER;20POLYVINIL,DEGAUSSING,CHLORI 2 BADGE AA64-70127A BADGE-BRAND;AL,FLAT,SILVER,L=40,SAMSUNG, 2 CWFC AA65-30105A CLAMP-WIRE;NYLON 66N,VO,NTR,15MM 2 STOPPE AA61-40113A STOPPER-PCB;-,ABS,HB,NTR.

ASSY-CABINET,(COM)

1 A/BACK AA92-00798A ASSY-CABINET,(COM);K15A(H),15K8,BLK,GSU

2 CB+CF 6002-000514 SCREW-TAPPING;RH,+,2,M4,L15,ZP 2 STAPLE AA60-40006A PIN-STAPLE;-,-,-,H18,33X17.8X2 2 B/C AA64-01731B CABINET BACK;15K8,HIPS,HB,BLK 2 INLAB AA64-60385G INLAY BACK;3E,K15A-1 3PIN S/T,PS SHEET,T 2 C/SET AA69-00372B CUSHION SET;15A8,PS C=0.02,-,-,-,-,-,-,2 PE-BAG AA69-01207A BAG;SHEET,9-13,W35,L42,FOAM,OEM 2 PCK AA69-01212F PACKING CASE;15K8 NT-AMER,CB S-1,YEL,TAN 2 BXTAPE 0203-001295 TAPE-OPP MASKING;1242,T0.06,W100,L91.4M, 2 AC-TAP 0203-001279 TAPE-OPP MASKING;#232,T0.14,W15,L50000,Y 2 TAPE-D 0203-001279 TAPE-OPP MASKING;#232,T0.14,W15,L50000,Y 2 FBT AA65-30018A CLAMP-WIRE;-,NYLON6.6,-,-,DATL 2 AC+BC AA65-30008A CLAMP-CORD;-,PE,HB,BLK,-,2 L/BOX AA68-01542A LABEL;(UNIBOX),PAPER WHT ALLMD 2 L/RAT AA68-01547A LABEL RATING;TETRONEPAPER90(S)B,LATIN 2 CLW/HS AA65-30018A CLAMP-WIRE;-,NYLON6.6,-,-,DATL

ASSY-CRT

1 A/CRTP AA97-01104A ASSY-CRT;A36QDT351X,+380mG,15INCH,BEAR,C

2 TAPE 0203-000432 TAPE-ACETATE;ACETATET0.25W19WH 2 CRT AA03-00146A CRT COLOR;A36QDT351X,-,15inch,-,-,-,FLAT 2 C-Y AA27-00002A MAGNET-CONVERGENCE;JH291-SC-OB,29.1M 2 D-Y AA27-00069A DEFLECTION-YOKE;-,DIF-1592CA,15,ST,2.0mH 2 SPACER AA63-60028A SPACER-DY;-,NEOPRENE,-,BLK,V0W

ASSY TBC WIRE(P)

1 A/TBC AA98-70014G ASSY TBC WIRE(P);-,15inch,NTSC,1P,KS2A/C

ASSY-ACCESSORY

1 A/ACCE AA97-01184A ASSY-ACCESSORY;K15A(H),15FLAT,XAP/XBM

2 T/MATC AA26-90001F TRANS-MATCHING;-,300OHM/75OHM,NTSC,40-89 2 A/ROD AA42-00004A ANT ROD;VHF,4SDODIPOLE850MMBRN 2 BAG-PE AA69-01195A BAG PE;CL29A6W8X,HDPET0.012,93/4X151 2 I/B AA68-01496A MANUAL USERS;K15A,SPANISH,WP/100 2 C/WARR AA68-00987A CARD WARRANTY;-,-,W/P100,-,-,-,-,-,A4,1P 2 AC/TAP 0203-001279 TAPE-OPP MASKING;#232,T0.14,W15,L50000,Y 2 PLUG 3721-000136 PLUG-CONVERSION;15A300VPI4.0CP 2 I/B2 AA68-01497A MANUAL USERS;K15A,ENGLISH,WP/100

REMOCON

1 RMT AA59-00108C REMOCON;DP,TM59,AA59-00077C,21,STR

Electrical Parts List

7-6 Samsung Electronics

Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark

Electrical Parts List

Samsung Electronics 7-7

7-2 CL25K4W7X/XAX

Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark

ASSY-PCB,MAIN(COM)

1 A/MAIN AA94-05338A ASSY-PCB,MAIN(COM);KS2A 25,SEM,W/O SVHS

2 PC801S 0604-001032 PHOTO-COUPLER;TR,170-260%,300M 2 CR402S 2306-000329 C-FILM;CF922P1.6KVT702-H-25/+8 2 CX801S 2306-000318 C-FILM,MPPF;220NF,20%,250V,-,2 2 C806 2401-001426 C-AL;470UF,400V 2 RL801S 3501-001040 RELAYPOWER;12VDC,500MW,10A,1FO 2 FP801S 3601-001012 FUSE-FERRULE;250V,4A,SLOW-BLOW 2 V999S 3704-001105 SOCKET-CRT;11P,20PI,26.5PI,NI,2 JA701 3722-001333 JACK-RCA9P,3.2mm,NI,BLK 2 IC901 AA09-00165A IC MICOM;SIM408A1-A015,CT21A8,52P,-0.3 2 T801S AA26-00044C TRANS SWITCHING,CODE-NO,CT-21A8,AC90-260 2 T444S AA26-00057A TRANS-FBT;-,FUH-29A001B(S),25/29,130 2 T401 AA26-50001R TRANS HORIZ DRIVE;80MH,580UH,4UH,G11AEI1 2 TU01S AA40-00074A TUNER;TCPN3081PA09A(B),NTSC,181CH,45 2 IC501 AA96-00582A ASSY H/S;-,CRT,AA62-00096A,STV5109,KS1A 3 0205-000129 GREASE-SILICON;SC102,JAPAN 3 6003-000335 SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR 3 AA62-00096A HEAT SINK;KS2A,AL5052,T1.0,W36.0,H35.0,S 3 1201-001687 IC-VIDEO AMP;STV5109,ZIP,15P,-,SIGLE,50d 2 IC801S AA96-50373F ASSY H/S;-,PWM,AA62-30181K,KA3A1265RD 3 AA13-00101A IC HYBRID;KA3A1265RD,CN5039,5Pin,-50to12 3 0205-000129 GREASE-SILICON;SC102,JAPAN 3 AA62-30181K HEATSINK-ES;-,AL6063EXTR.,2,WHT,40MM,3 AA61-10386A BRACKET-IC;-,-,SECC100,T1.0,-,KA2S0680, 3 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW 3 AA02-00007A MICA;DPM-04,MICA,22x29x0.15mm 2 IC301 AA96-50406A ASSY-H/S;LA62-30180K,LA7845 3 1204-000517 IC-LINEAR;LA7845SIPVERTICALAMP 3 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW 3 AA62-30180K HEATSINK-ES;-,A6063EXTR,-,WHT,50/13,-, 2 A/MAIN AA94-05339A ASSY-PCB,MAIN(AUTO);KS2A,25,W/O SVHS 3 D406 0402-001321 DIODE-RECTIFIER;1A4G,400,1A,R-1,TP 3 D403 0402-001321 DIODE-RECTIFIER;1A4G,400,1A,R-1,TP 3 D808 0402-001321 DIODE-RECTIFIER;1A4G,400,1A,R-1,TP 3 D811 0402-001321 DIODE-RECTIFIER;1A4G,400,1A,R-1,TP 3 D907 0402-001321 DIODE-RECTIFIER;1A4G,400,1A,R-1,TP 3 D810 0402-001321 DIODE-RECTIFIER;1A4G,400,1A,R-1,TP 3 D504 0402-001321 DIODE-RECTIFIER;1A4G,400,1A,R-1,TP 3 D908 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D201 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D602 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D207 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D202 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D804 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 DZ402 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D501 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D502 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D503 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D508 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D604 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D407 0402-000493 DIODE-RECTIFIER;1R5GU41,400V,1 3 D410 0402-000493 DIODE-RECTIFIER;1R5GU41,400V,1 3 D402 0402-000540 DIODE-RECTIFIER;RU20A,600V,1.5 3 D401 0402-000540 DIODE-RECTIFIER;RU20A,600V,1.5 3 DZ201 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ203 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ204 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ602 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ903 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ904 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ907 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ906 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ905 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ902 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ601 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ802 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ806 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ908 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ305 0403-001221 DIODE-ZENER;UZ39BSB,35.36-37.19V,500MW,D 3 DZ302 0403-001329 DIODE-ZENER;MTZJ24B,22.61-23.77V,500mW,

3 DZ303 0403-001329 DIODE-ZENER;MTZJ24B,22.61-23.77V,500mW, 3 DZ304 0403-001329 DIODE-ZENER;MTZJ24B,22.61-23.77V,500mW, 3 DZ306 0403-000700 DIODE-ZENER;TZP33A,33V,31-35V, 3 DZ804 0403-000700 DIODE-ZENER;TZP33A,33V,31-35V, 3 Q206 0501-000283 TRANSISTOR;KSA539-Y(TAPG)/YTAM 3 Q208 0501-000283 TRANSISTOR;KSA539-Y(TAPG)/YTAM 3 Q210 0501-000283 TRANSISTOR;KSA539-Y(TAPG)/YTAM 3 Q405 0501-000283 TRANSISTOR;KSA539-Y(TAPG)/YTAM 3 Q802 0501-000369 TRANSISTOR;KSC2331-Y(TAPG) 3 Q201 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q202 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q203 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q204 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q207 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q209 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q213 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q222 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q901 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q902 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q903 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q904 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q905 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q906 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q907 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q908 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q911 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 DZ805 1203-001217 IC-POST,ADJUSTREG;431,T0-92,3P,4.58MIL,P 3 R245 2001-000005 R-CARBON;390OHM,5%,1/8W,AA,TP, 3 R250 2001-000005 R-CARBON;390OHM,5%,1/8W,AA,TP, 3 R255 2001-000005 R-CARBON;390OHM,5%,1/8W,AA,TP, 3 R214 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3.2MM 3 R303 2001-000016 R-CARBON(S);1OHM,5%,1/2W,AA,TP 3 R407 2001-000066 R-CARBON(S);10KOHM,5%,1/2W,AA, 3 R825 2001-000066 R-CARBON(S);10KOHM,5%,1/2W,AA, 3 R507 2001-000085 R-CARBON(S);100KOHM,5%,1/2W,AA 3 R510 2001-000085 R-CARBON(S);100KOHM,5%,1/2W,AA 3 R513 2001-000085 R-CARBON(S);100KOHM,5%,1/2W,AA 3 R209 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP 3 R914 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP 3 R440 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP 3 R103 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R201 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R203 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R204 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R246 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R251 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R256 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R609 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R610 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R611 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R612 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R613 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R619 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R706 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R707 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R708 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R723 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R730 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R731 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R902 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R907 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R909 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R940 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R941 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R942 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R945 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R411 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R944 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R202 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R205 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R206 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R211 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R309 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R310 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,

3 R601 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R602 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R606 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R715 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R716 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R935 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R620 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R268 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R627 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 J909 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R222 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R231 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R232 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R233 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R234 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R235 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R252 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R603 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R910 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R912 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R924 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R929 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R930 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R943 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R607 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R608 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 D505 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 D506 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 D507 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 C906 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R207 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP 3 R833 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP 3 R215 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP, 3 R824 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP, 3 R213 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R901 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R903 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R904 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R905 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R906 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R908 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R921 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R926 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R937 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R947 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R948 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R952 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R953 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R614 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R615 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R616 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R617 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R812 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R831 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R919 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R920 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R931 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R933 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R106 2001-000864 R-CARBON;56Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R709 2001-000938 R-CARBON ;68ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R524 2001-001062 R-CARBON(S);10MOHM,5%,1/2W,AA, 3 R816 2001-001088 R-CARBON(S);1KOHM,5%,1/2W,AA,TP,2.4X6.4 3 R817 2001-001088 R-CARBON(S);1KOHM,5%,1/2W,AA,TP,2.4X6.4 3 RR430S 2001-001088 R-CARBON(S);1KOHM,5%,1/2W,AA,TP,2.4X6.4 3 R418 2001-001088 R-CARBON(S);1KOHM,5%,1/2W,AA,TP,2.4X6.4 3 R239 2001-001114 R-CARBON(S);270OHM,5%,1/2W,AA, 3 R805 2001-001150 R-CARBON(S);470KOHM,5%,1/2W,AA 3 R806 2001-001150 R-CARBON(S);470KOHM,5%,1/2W,AA 3 R427 2001-001150 R-CARBON(S);470KOHM,5%,1/2W,AA 3 R437 2001-001150 R-CARBON(S);470KOHM,5%,1/2W,AA 3 R813 2001-001153 R-CARBON(S);47OHM,5%,1/2W,AA,T 3 R832 2001-001153 R-CARBON(S);47OHM,5%,1/2W,AA,T 3 R810 2001-001178 R-CARBON(S);680OHM,5%,1/2W,AA, 3 RY802S 2002-001013 R-COMPOSITION;4.7MOhm,5%,1/2W,AA,TP,3.7X 3 R521 2002-001009 R-COMPOSITION;2.7KOHM,10%,1/2W,AA,TP,3.7 3 R426 2003-000540 R-METALOXIDE(S);1KOHM,5%,2W,AD 3 R821 2004-001889 R-METAL(S);127KOHM,1%,1/2W,AA,TP,2.5X6.5

3 R819 2004-001983 R-METAL;2.49KOHM,1%,1/2W,AA,TP,2.4X6.4 3 R304 2008-000254 R-FUSIBLE(S);0.68OHM,5%,2W,AF, 3 R828 2008-000266 R-FUSIBLE(S);1OHM,5%,2W,AF,TP, 3 C910 2201-000980 C-CERAMIC,DISC;30PF,5%,50V,NPO,5.0X3.0,5 3 C911 2201-000980 C-CERAMIC,DISC;30PF,5%,50V,NPO,5.0X3.0,5 3 C305 2305-000149 C-FILM;CF922N100VT104-J-40/105 3 C304 2305-000149 C-FILM;CF922N100VT104-J-40/105 3 C804 2201-000332 C-CERAMIC,AC;CK45PTAPGE250V222 3 C805 2201-000332 C-CERAMIC,AC;CK45PTAPGE250V222 3 C401 2201-000556 C-CERAMIC,DISC;470PF,10%,500V, 3 C403 2201-000556 C-CERAMIC,DISC;470PF,10%,500V, 3 C421 2201-000556 C-CERAMIC,DISC;470PF,10%,500V, 3 C908 2202-000863 C-CERAMIC;CKOAX7R50VT561-KUP050561 3 C817 2201-000599 C-CERAMIC,DISC;560PF,10%,500V, 3 C819 2201-000599 C-CERAMIC,DISC;560PF,10%,500V, 3 C822 2201-000599 C-CERAMIC,DISC;560PF,10%,500V, 3 C115 2202-000121 C-CERAMIC,MLC-AXIAL;100PF,10%, 3 C116 2202-000121 C-CERAMIC,MLC-AXIAL;100PF,10%, 3 C243 2202-000121 C-CERAMIC,MLC-AXIAL;100PF,10%, 3 C244 2202-000121 C-CERAMIC,MLC-AXIAL;100PF,10%, 3 C245 2202-000121 C-CERAMIC,MLC-AXIAL;100PF,10%, 3 C647 2202-000286 C-CERAMIC,MLC-AXIAL;56PF,5%,50 3 C654 2202-000286 C-CERAMIC,MLC-AXIAL;56PF,5%,50 3 C211 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50 3 C607 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50 3 C608 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50 3 C905 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50 3 C419 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50 3 C504 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50 3 C505 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50 3 C506 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50 3 C821 2301-000192 C-FILM,PEF;1NF,5%,50V,5.3X10MM 3 C212 2301-000224 C-FILM,PEF;22NF,5%,50V,7.4X3.9 3 C242 2301-000310 C-FILM,PEF;68NF,5%,50V,8.0X8.5 3 C306 2301-000342 C-FILM,PEF;2.2nF,5%,50V,TP,7.4x3.9x13mm, 3 C228 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m 3 C803 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m 3 C809 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m 3 C214 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C216 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C308 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C620 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C635 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C646 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C823 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C829 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C831 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C837 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C839 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C907 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C914 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C916 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C919 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C417 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C205 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C513 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C508 2305-000704 C-M,POLYESTER;CFS922MTAPG250V1 3 C511 2305-000704 C-M,POLYESTER;CFS922MTAPG250V1 3 C816 2401-000262 C-AL;100UF,20%,160V,GP,16X25MM,5MM, 3 C307 2401-000360 C-AL;100UF,20%,50V,GP,8X11MM,5 3 C920 2401-000480 C-AL;10UF,20%,50V,GP,5X11MM,5M 3 C106 2401-000603 C-AL;1UF,20%,50V,GP,5X11MM,5MM 3 C301 2401-000603 C-AL;1UF,20%,50V,GP,5X11MM,5MM 3 C412 2301-000188 C-FILM,PEF;1NF,5%,100V,10.5X12 3 C217 2401-001026 C-AL;3.3UF,20%,50V,GP,5X11MM,5 3 C636 2401-001026 C-AL;3.3UF,20%,50V,GP,5X11MM,5 3 C510 2401-001232 C-AL;4.7UF,20%,250V,GP,10X12.5 3 C637 2401-000027 C-AL;4.7UF,20%,50V,GP,5*11MM,5MEA 3 C640 2401-000027 C-AL;4.7UF,20%,50V,GP,5*11MM,5MEA 3 C641 2401-000027 C-AL;4.7UF,20%,50V,GP,5*11MM,5MEA 3 C643 2401-000027 C-AL;4.7UF,20%,50V,GP,5*11MM,5MEA 3 C104 2401-002463 C-ELECTROLYTIC;CE04WTAPG16V470M-M(SG)-VE 3 C826 2401-002463 C-ELECTROLYTIC;CE04WTAPG16V470M-M(SG)-VE 3 C512 2401-002463 C-ELECTROLYTIC;CE04WTAPG16V470M-M(SG)-VE 3 C402 2401-001397 C-AL;470UF,20%,25V,GP,10X16MM, 3 C404 2401-001397 C-AL;470UF,20%,25V,GP,10X16MM, 3 C634 2401-001840 C-AL;100UF,20%,16V,GP,TP,6.3X1

Electrical Parts List

7-8 Samsung Electronics

Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark

3 C652 2401-001840 C-AL;100UF,20%,16V,GP,TP,6.3X1 3 C832 2401-001840 C-AL;100UF,20%,16V,GP,TP,6.3X1 3 C838 2401-001840 C-AL;100UF,20%,16V,GP,TP,6.3X1 3 C917 2401-001840 C-AL;100UF,20%,16V,GP,TP,6.3X1 3 C918 2401-001840 C-AL;100UF,20%,16V,GP,TP,6.3X1 3 C660 2401-001840 C-AL;100UF,20%,16V,GP,TP,6.3X1 3 C207 2401-001840 C-AL;100UF,20%,16V,GP,TP,6.3X1 3 C250 2401-001840 C-AL;100UF,20%,16V,GP,TP,6.3X1 3 C626 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5 3 C628 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5 3 C621 2401-001998 C-AL;1000UF,20%,25V,GP,TP,10X20 3 L202 2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3. 3 L301 2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3. 3 L602 2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3. 3 L603 2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3. 3 L906 2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3. 3 L406 2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3. 3 R604 2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3. 3 R605 2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3. 3 L907 2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3. 3 L804 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,3 L807 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,3 L407 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,3 L411 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,3 L501 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,3 L203 3301-000287 CORE-FERRITEBEAD;AA,3.5X1.0X6. 3 L610 3301-000287 CORE-FERRITEBEAD;AA,3.5X1.0X6. 3 L801 3301-000287 CORE-FERRITEBEAD;AA,3.5X1.0X6. 3 L802 3301-000287 CORE-FERRITEBEAD;AA,3.5X1.0X6. 3 L803 3301-000287 CORE-FERRITEBEAD;AA,3.5X1.0X6. 3 L806 3301-000287 CORE-FERRITEBEAD;AA,3.5X1.0X6. 3 L809 3301-000287 CORE-FERRITEBEAD;AA,3.5X1.0X6. 3 L302 3301-000287 CORE-FERRITEBEAD;AA,3.5X1.0X6. 3 L303 3301-000287 CORE-FERRITEBEAD;AA,3.5X1.0X6. 3 L401 3301-000287 CORE-FERRITEBEAD;AA,3.5X1.0X6. 3 J709 3301-000287 CORE-FERRITEBEAD;AA,3.5X1.0X6. 3 F801B 3602-000114 FUSE-HOLDER;-,-,30MOHM 3 F801A 3602-000114 FUSE-HOLDER;-,-,30MOHM 3 J102 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J103 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J104 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J106 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J107 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J109 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J110 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J112 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J115 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J116 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J127 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J118 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J119 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J120 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J122 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J126 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J202 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J204 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J205 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J206 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J209 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J210 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J211 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J212 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J213 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J215 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J216 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J217 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J219 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J221 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J222 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J223 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J224 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J225 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J226 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J227 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J228 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J229 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J231 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A

3 J232 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J233 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J234 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J237 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J238 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J239 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J240 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J243 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J246 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J247 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J248 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J249 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J250 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J252 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J254 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J257 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J258 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J259 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J261 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J290 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J291 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J292 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J311 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J401 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J402 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J404 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J405 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J406 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J407 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J408 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J409 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J410 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J411 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J412 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J413 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J415 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J416 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J418 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J420 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J421 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J422 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J424 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J429 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J444 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J445 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J502 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J504 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J505 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J601 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J602 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J603 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J605 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J606 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J608 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J609 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J610 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J611 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J613 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J615 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J616 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J617 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J619 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J623 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J626 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J627 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J629 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J632 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J635 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J703 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J704 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J708 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J712 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J715 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J801 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J802 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J803 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J804 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A

Electrical Parts List

Samsung Electronics 7-9

Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark

3 J805 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J807 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J810 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J811 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J816 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J817 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J818 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J819 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J820 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J821 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J822 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J823 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J824 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J826 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J831 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J832 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J835 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J902 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J904 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J906 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J907 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J911 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J912 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J913 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J914 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J915 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J916 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J917 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J918 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J920 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J924 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J925 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J926 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J927 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J928 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J929 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J930 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J931 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J933 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J934 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J935 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J941 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J942 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J995 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J996 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J997 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J998 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 L101 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 L410 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 R820 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 RY801S 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J621 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J825 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J312 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J900 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J923 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J628 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J630 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J245 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J994 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J313 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J814 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J815 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J833 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J834 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J901 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 R939 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J128 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J260 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J264 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J510 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J634 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J665 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J908 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J921 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 JJ01 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 L605 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A

3 L606 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 L607 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 L608 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 L701 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 L702 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 L705 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 L706 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J922 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J251 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J620 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J501 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 R623 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J201 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J214 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J244 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J713 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J705 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J446 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J235 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J117 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J419 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 07VER AA41-00132J PCB-MAIN;CS2139T,FR-1,1L,J,1.6T,330X245 3 EY301 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY302 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY303 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY304 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY403 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY405 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY406 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY409 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY410 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY411 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY412 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY413 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY414 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY415 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY416 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY417 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY418 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY419 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY420 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY421 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY422 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY423 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY424 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY425 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY426 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY427 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY428 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY429 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY430 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY431 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY432 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY433 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY434 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY435 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY436 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY437 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY439 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY440 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY441 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY442 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY443 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY445 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY602 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY604 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY605 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY606 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY701 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY702 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY801 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY802 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY803 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY804 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY809 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY810 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY811 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST

Electrical Parts List

7-10 Samsung Electronics

Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark

3 EY812 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY813 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY814 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY815 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY816 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY817 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY818 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY820 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY822 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY823 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY824 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY830 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY831 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY832 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY833 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY835 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY836 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY837 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY839 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY840 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY841 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY842 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY843 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY844 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY845 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY846 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY847 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY848 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY849 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY850 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY851 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY852 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY853 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY854 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY855 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY856 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY858 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY859 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY865 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY868 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY869 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY401 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY402 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY870 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY871 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY805 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY806 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EL401 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 EL402 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 EL403 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 EL404 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 EL802 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 EL803 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 EL806 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 EL807 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 EL808 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 EL501 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 EL502 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 EL805 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 EL801 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 EL405 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 GT102 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT301 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT302 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT401 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT402 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT501 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT502 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT801 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT802 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT803 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT804 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT805 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT806 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT503 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT407 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 L/LINE AA68-01544A LABEL;LINE,ALL MDL COMMON

3 C808 2401-002300 C-ELECTROLYTIC;CE04WTAPG50V47U 3 C913 2401-000287 C-AL;100UF,20%,16V,WT,6X11MM,5 3 C915 2401-000287 C-AL;100UF,20%,16V,WT,6X11MM,5 3 R412 2001-000020 R-CARBON(S);22OHM,5%,1/2W,AA,T 3 C632 2202-000231 C-CERAMIC,MLC-AXIAL;330PF,10%,50V,Y5P,3. 3 C233 2305-000412 C-FILM,MPEF;470NF,5%,63V,-,5MM 3 C234 2305-000412 C-FILM,MPEF;470NF,5%,63V,-,5MM 3 C235 2305-000412 C-FILM,MPEF;470NF,5%,63V,-,5MM 3 C236 2305-000412 C-FILM,MPEF;470NF,5%,63V,-,5MM 3 FD801S 3601-001163 FUSE-AXIAL LEAD;125V,7A,-,EPOXY,2.4X7.1M 3 FD803S 3601-001163 FUSE-AXIAL LEAD;125V,7A,-,EPOXY,2.4X7.1M 3 FD802S 3601-001163 FUSE-AXIAL LEAD;125V,7A,-,EPOXY,2.4X7.1M 3 D204 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100MA,DO-34,TP 3 D205 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100MA,DO-34,TP 3 D206 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100MA,DO-34,TP 3 D903 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100MA,DO-34,TP 3 D203 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100MA,DO-34,TP 3 D901 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100MA,DO-34,TP 3 D902 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100MA,DO-34,TP 3 D904 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100MA,DO-34,TP 3 D905 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100MA,DO-34,TP 3 D803 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1. 3 D301 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1. 3 D408 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1. 3 D411 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1. 3 VP801S 1405-000152 VARISTOR;560V,2500A,14X8.5MM,T 3 VX801S 1405-000152 VARISTOR;560V,2500A,14X8.5MM,T 3 C843 2201-000681 C-CERAMIC,DISC;82PF,5%,50V,SL,4X3.5MM,5M 3 D404 0402-000534 DIODE-RECTIFIER;RG10V,400V,1.5 3 DZ808 0403-000719 DIODE-ZENER;MTZJ7.5B,7.5V,7.07-7.45V,500 3 DZ803 0403-001167 DIODE-ZENER;MTZJ30D,30V,29.02-30.51V,500 3 D413 0402-000537 DIODE-RECTIFIER;RH1A,600V,0.6A, 3 DZ701 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 3 DZ702 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 3 R264 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP, 3 R265 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP, 3 R267 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP, 3 R934 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP, 3 R223 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP, 3 R224 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP, 3 R225 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP, 3 R226 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP, 3 DZ801 0403-001322 DIODE-ZENER;MTZJ8.2B,7.78-8.19V,500mW,DO 3 R927 2001-000837 R-CARBON;51KOHM,5%,1/8W,AA,TP, 3 R925 2001-001035 R-CARBON ;91ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R105 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP, 3 R302 2004-001984 R-METAL;26.7KOHM,1%,1/2W,AA,TP 3 R301 2004-001397 R-METAL(S);4.7KOHM,1%,1/2W,AA, 3 R429 2004-001397 R-METAL(S);4.7KOHM,1%,1/2W,AA, 3 R432 2004-001397 R-METAL(S);4.7KOHM,1%,1/2W,AA, 3 R236 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP, 3 R237 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP, 3 R238 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP, 3 R249 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP, 3 R254 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP, 3 R259 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP, 3 R932 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP, 3 R946 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP, 3 R807 2003-000746 R-METALOXIDE(S);56OHM,5%,2W,AD 3 R808 2003-000746 R-METALOXIDE(S);56OHM,5%,2W,AD 3 R408 2008-000284 R-FUSIBLE(S);0.1OHM,10%,2W,AF,TP,3.9X10M 3 R827 2008-000284 R-FUSIBLE(S);0.1OHM,10%,2W,AF,TP,3.9X10M 3 R403 2003-002037 R-METAL OXIDE(S);270OHM,5%,2W,AF,TP,3.9X 3 R826 2001-001072 R-CARBON(S);12ohm,5%,1/2W,AA,TP,2.4x6.4m 3 R802 2003-001025 R-METALOXIDE(S);15KOHM,5%,2W,A 3 R803 2003-001025 R-METALOXIDE(S);15KOHM,5%,2W,A 3 R804 2003-001025 R-METALOXIDE(S);15KOHM,5%,2W,A 3 R811 2001-001078 R-CARBON(S);15KOHM,5%,1/2W,AA, 3 R313 2004-001137 R-METAL;6.8KOHM,1%,1/8W,AA,TP,1.8*3.2M 3 R248 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1 3 R253 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1 3 R258 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1 3 R701 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1 3 R702 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1 3 R703 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1 3 R704 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1 3 R705 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1

Electrical Parts List

Samsung Electronics 7-11

Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark

3 R719 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1 3 C424 2201-000132 C-CERAMIC,DISC;100PF,10%,500V,Y5P,6X3MM, 3 R913 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP 3 R405 2008-001018 R-FUSIBLE(S);0.47OHM,10%,2W,AF 3 R424 2008-001018 R-FUSIBLE(S);0.47OHM,10%,2W,AF 3 R425 2008-001018 R-FUSIBLE(S);0.47OHM,10%,2W,AF 3 R413 2008-001018 R-FUSIBLE(S);0.47OHM,10%,2W,AF 3 R228 2001-001170 R-CARBON(S);6.8OHM,5%,1/2W,AB, 3 R434 2003-000664 R-METAL OXIDE(S);330HM,5%,2W,AF,TP,4X12M 3 R829 2003-001036 R-METALOXIDE(S);3.3OHM,5%,2W,A 3 R314 2004-001986 R-METAL;35.7KOHM,1%,1/2W,AA,TP 3 R409 2001-001165 R-CARBON(S);56OHM,5%,1/2W,AB,T 3 R818 2001-001113 R-CARBON(S);270KOHM,5%,1/2W,AA 3 C408 2305-000382 C-FILM,MPEF;4.7NF,5%,400V,TP,-,5MM. 3 C414 2401-002597 C-AL;220uF,20%,35V,GP,TP,10x12.5,5 3 C418 2401-002597 C-AL;220uF,20%,35V,GP,TP,10x12.5,5 3 C610 2301-000314 C-FILM,PEF;8.2NF,5%,50V,6.5X3. 3 C611 2301-000314 C-FILM,PEF;8.2NF,5%,50V,6.5X3. 3 C415 2301-000314 C-FILM,PEF;8.2NF,5%,50V,6.5X3. 3 C215 2401-002235 C-ELECTROLYTIC;CE04W(T)16V10M 3 C229 2401-002235 C-ELECTROLYTIC;CE04W(T)16V10M 3 C231 2401-002235 C-ELECTROLYTIC;CE04W(T)16V10M 3 C630 2401-002235 C-ELECTROLYTIC;CE04W(T)16V10M 3 C631 2401-002235 C-ELECTROLYTIC;CE04W(T)16V10M 3 C645 2401-002235 C-ELECTROLYTIC;CE04W(T)16V10M 3 C827 2401-002235 C-ELECTROLYTIC;CE04W(T)16V10M 3 C840 2401-002235 C-ELECTROLYTIC;CE04W(T)16V10M 3 C210 2401-002235 C-ELECTROLYTIC;CE04W(T)16V10M 3 C227 2401-002235 C-ELECTROLYTIC;CE04W(T)16V10M 3 C903 2401-002235 C-ELECTROLYTIC;CE04W(T)16V10M 3 C825 2306-000122 C-FILM,MPPF;100NF,5%,50V,7.3X4 3 C103 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm 3 C105 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm 3 C224 2201-002031 C-CERAMIC,DISC;5pF,0.25pF,50V,NPO,TP,5x3 3 C225 2201-002031 C-CERAMIC,DISC;5pF,0.25pF,50V,NPO,TP,5x3 3 C617 2401-000493 C-AL;10UF,20%,50V,WT,5X11MM,5M 3 C237 2401-000914 C-AL;22UF,20%,16V,GP,5X11,5,TP 3 C302 2401-000326 C-AL;100UF,20%,35V,GP,8X11MM,5 3 C102 2401-002463 C-ELECTROLYTIC;CE04WTAPG16V470M-M(SG)-VE 3 C820 2401-001054 C-AL;3300UF,20%,25V,GP,18X26MM,7.5M 3 C612 2401-001914 C-AL;1uF,20%,50V,BP,TP,5x11,5 3 C613 2401-001914 C-AL;1uF,20%,50V,BP,TP,5x11,5 3 C427 2401-002267 C-AL;2.2UF,20%,250V,GP,8X12MM, 3 C507 2401-002267 C-AL;2.2UF,20%,250V,GP,8X12MM, 3 L901 2901-000299 FILTER-EMIBEAD;BL02RN2-R65T2DB 3 L903 2901-000299 FILTER-EMIBEAD;BL02RN2-R65T2DB 3 L904 2901-000299 FILTER-EMIBEAD;BL02RN2-R65T2DB 3 L402 2901-000299 FILTER-EMIBEAD;BL02RN2-R65T2DB 3 R923 2001-000924 R-CARBON;680ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R922 2001-000924 R-CARBON;680ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R102 2001-000924 R-CARBON;680ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 L103 2701-000115 INDUCTOR-AXIAL;10UH,10%,2.8X7M 3 R208 2001-000405 R-CARBON;180OHM,5%,1/8W,AA,TP, 3 R243 2001-000405 R-CARBON;180OHM,5%,1/8W,AA,TP, 3 R509 2001-000405 R-CARBON;180OHM,5%,1/8W,AA,TP, 3 R511 2001-000405 R-CARBON;180OHM,5%,1/8W,AA,TP, 3 R517 2001-000405 R-CARBON;180OHM,5%,1/8W,AA,TP, 3 C420 2301-001065 C-FILM,MPPF;47NF,55,630V,TP,19 3 C650 2201-000558 C-CERAMIC,DISC;470PF,10%,50V,Y 3 C422 2401-001527 C-AL;47UF,20%,250V,HR,13X25MM, 3 C902 2401-000553 C-AL;1UF,10%,50V,GP,5X11MM,5MM 3 C201 2401-000553 C-AL;1UF,10%,50V,GP,5X11MM,5MM 3 C618 2401-000553 C-AL;1UF,10%,50V,GP,5X11MM,5MM 3 Q909 0505-000109 FET-SILICON;2N7000,N,60V,200mA,5ohm,400 3 Q910 0505-000109 FET-SILICON;2N7000,N,60V,200mA,5ohm,400 3 IC904 1203-001943 IC-VOL.DETECTOR;7025,T0-92,3P,PLASTIC 3 R436 2003-002151 R-METALOXIDE;18KOHM,5%,2W,AG,TP,6X16 3 R401 2003-002186 R-METALOXIDE(S);22Kohm,5%,2W,AG,TP,3x 3 R402 2003-002186 R-METALOXIDE(S);22Kohm,5%,2W,AG,TP,3x 3 R835 2003-002211 R-METALOXIDE(S)91Kohm,5%,2W,AG,TP,3x 3 R836 2003-002211 R-METALOXIDE(S)91Kohm,5%,2W,AG,TP,3x 3 R433 2008-001127 R-FUSIBLE(S);6.8Kohm,5%,1W,AF,TP,3.9x10m 3 C656 2201-000304 C-CERAMIC,DISC0.001nF,0.25pF,50V,NP0,TP 3 C657 2201-000304 C-CERAMIC,DISC0.001nF,0.25pF,50V,NP0,TP 3 CW901 2503-000156 C-NETWORK;100pFx4,20&,50V 3 L102 2701-000159 INDUCTORAXIAL;22uH,10%,4.2x9.8mm 3 L207 2701-000168 INDUCTORAXIAL;3.3uH,5%,2.5x3.4mm

3 L208 2701-000168 INDUCTORAXIAL;3.3uH,5%,2.5x3.4mm 3 L209 2701-000168 INDUCTORAXIAL;3.3uH,5%,2.5x3.4mm 3 J699 2701-000168 INDUCTORAXIAL;3.3uH,5%,2.5x3.4mm 3 J625 2701-000168 INDUCTORAXIAL;3.3uH,5%,2.5x3.4mm 3 L604 2701-000168 INDUCTORAXIAL;3.3uH,5%,2.5x3.4mm 3 L905 2001-000995 R-CARBON;820OHM,5%,1/8W,AA,TP, 3 X201 2801-003432 CRYSTAL-UNIT;20.25MHZ,30PPM,28-AAM,13P 3 X901 2801-003728 CRYSTAL-UNIT;6MHz,30ppm,28AAM,20pf,40oh 3 X601 2801-003903 CRYSTAL-UNIT18.432MHz,25ppm,28AAM,12 3 R809 2001-001410 R-CARBON;RD1/2T(S)430-J43R 3 C605 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C429 2301-000232 C-FILM,PEF;3.3NF,5%,50V,8.1X4. 3 DZ401 0403-001325 DIODE-ZENER;MTZJ15C,14.35-15.09V,500mW,D 3 DZ501 0403-001325 DIODE-ZENER;MTZJ15C,14.35-15.09V,500mW,D 3 R415 2001-001054 R-CARBON(S);1.6KOHM,5%,1/2W,AB,TP,2.4X6. 3 R420 2001-001168 R-CARBON(S);6.8KOHM,5%,1/2W,AB 3 R421 2001-001144 R-CARBON(S);4.7KOHM,5%,1/2W,AA,TP,2.4X6. 3 R441 2001-001144 R-CARBON(S);4.7KOHM,5%,1/2W,AA,TP,2.4X6. 3 R438 2001-001131 R-CARBON(S);33KOHM,5%,1/2W,AA, 3 R417 2004-001893 R-METAL(S);22KOHM,1%,1/2W,AA,T 3 R241 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP, 3 R315 2004-004970 R-METAL(S);62Kohm,1%,1/8W,AA,TP,1.8x3.2m 3 D801 0402-001111 DIODE-RECTIFIER;1N5397GP,600V,1.5A,DO-20 3 R414 2001-001165 R-CARBON(S);56OHM,5%,1/2W,AB,T 3 R522 2008-000206 R-FUSIBLE(S);1OHM,5%,1/2W,AF,T 3 R523 2008-000206 R-FUSIBLE(S);1OHM,5%,1/2W,AF,T 3 J113 2701-000142 INDUCTOR-AXIAL;1UH,10%,2.5X3.4 3 R410 2001-001192 R-CARBON(S);820OHM,5%,1/2W,AB, 3 C416 2301-000289 C-FILM,PEF;5.6NF,5%,50V,6.5X5. 3 C303 2201-002103 C-CERAMIC,DISC;0.015nF,5%,500V,NP0,TP,6. 3 R305 2003-002157 R-METAL OXIDE;220OHM,5%,2W,AG,TP,6X16MM 3 R306 2003-002157 R-METAL OXIDE;220OHM,5%,2W,AG,TP,6X16MM 3 C411 2301-000104 C-FILM,PEF;1.2NF,5%,50V,6.5X3.0X5.5MM,5M 3 R428 2001-001106 R-CARBON(S);220KOHM,5%,1/2W,AA 3 DZ202 0403-001321 DIODE-ZENER;MTZJ6.8C,6.66-7.01V,500mW,DO 3 C248 2401-002619 C-AL;47uF,20%,25V,GP,TP,5x11,5 3 DZ509 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D 3 R212 2004-000218 R-METAL;10KOHM,1%,1/8,1.8X3.2M 3 R501 2001-000904 R-CARBON;620OHM,5%,1/8W,AA,TP,1.8X3.2MM 3 R502 2001-000904 R-CARBON;620OHM,5%,1/8W,AA,TP,1.8X3.2MM 3 R503 2001-000904 R-CARBON;620OHM,5%,1/8W,AA,TP,1.8X3.2MM 3 R504 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP 3 R505 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP 3 R506 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP 3 R515 2002-001008 R-COMPOSITION;1.8KOHM,10%1/2W,AA,TP,3.7 3 R518 2002-001008 R-COMPOSITION;1.8KOHM,10%1/2W,AA,TP,3.7 3 R512 2002-001008 R-COMPOSITION;1.8KOHM,10%1/2W,AA,TP,3.7 3 R527 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AB, 3 L204 2702-001094 INDUCTOR-RADIAL;10uH,10%,6x4mm 3 L601 2702-001094 INDUCTOR-RADIAL;10uH,10%,6x4mm 3 L609 2702-001094 INDUCTOR-RADIAL;10uH,10%,6x4mm 3 C218 2202-002037 C-CERAMIC,MLC-AXIAL;100NF,+80-20 3 C219 2202-002037 C-CERAMIC,MLC-AXIAL;100NF,+80-20 3 C220 2202-002037 C-CERAMIC,MLC-AXIAL;100NF,+80-20 3 C221 2202-002037 C-CERAMIC,MLC-AXIAL;100NF,+80-20 3 C222 2202-002037 C-CERAMIC,MLC-AXIAL;100NF,+80-20 3 C223 2202-002037 C-CERAMIC,MLC-AXIAL;100NF,+80-20 3 C232 2202-002037 C-CERAMIC,MLC-AXIAL;100NF,+80-20 3 C901 2202-002037 C-CERAMIC,MLC-AXIAL;100NF,+80-20 3 C921 2202-002037 C-CERAMIC,MLC-AXIAL;100NF,+80-20 3 C960 2202-002037 C-CERAMIC,MLC-AXIAL;100NF,+80-20 3 C509 2201-000723 C-CERAMIC,DISC;4.7nF,20%,3KV,Y5U,TP,16x5 3 C807 2301-001435 C-FILM,PPF;1.5nF,5%,1.2kV,TP,15x8x12.5mm 3 C814 2201-000991 C-CERAMIC,HIC;CK45(T)B2KV561-K 3 C818 2401-000711 C-AL;2200uF,20%,25V,GP,TP,16x25,7.5 3 C202 2401-002594 C-AL;220uF,20%,16V,GP,TP,8x11.5,5 3 R210 2001-000812 R-CARBON;5.6Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 C213 2301-000247 C-FILM,PEF;33NF,5%,50V,8.1X4.5 3 C835 2401-003139 C-AL;1000UF,20%,25V,WT,TP,10*2 3 R519 2702-001096 INDUCTOR-RADIAL;33uH,10%,6x4mm 3 R621 2001-000890 R-CARBON;6.8KOHM,5%,1/8W,AA,TP 3 R622 2001-000890 R-CARBON;6.8KOHM,5%,1/8W,AA,TP 3 C811 2301-000254 C-FILM,PEF;39NF,5%,50V,7.5X3.5X6.5MM,5MM 3 L902 2701-000183 INDUCTOR-AXIAL;39uH,5%,2.4x3.4mm 3 C912 2202-000719 C-CERAMIC,MLC-AXIAL;6.8nF,20%,16V,Y5R,TP 2 PWR/AC AA96-20112A ASSY-POWER,CORD;EP2/NP,H/C300 3 AA39-10006K POWER-CORD;KJ-10W,AWG SPT-2

Electrical Parts List

7-12 Samsung Electronics

Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark

3 AA61-20284A HOLDER P CORD;PP,VO,BLK,KE-002 2 A/SUBM AA97-01633A ASSY-SUB MATERIAL;SOLVENTES Y SOLDADURAS 3 0204-000442 SOLVENT;CH3-CH5H-CH396%IM-1000 3 0202-000008 SOLDER-WIRE;S63S-D3.0,S63A,D3,63/37 3 0204-001024 FLUX;DF-96TVS,-,20%,3 0202-000187 SOLDER-WIREFLUX;-,RS60S,D1.2,6 2 CR401S 2303-001032 C-FILM,PPF;10nF,5%,1600V,TP,28.5x12x19.5 2 IC902 1103-001211 IC-EEPROM;24C16-PC27 C,2048x8Bit,DIP,8P, 2 NT802S 1404-001045 THERMISTOR NTC;4.7OHM,15%,2900K,35.0MW,T 2 C815 2401-000786 C-ELECTROLYTIC;CE04W160V220M-M(18X37) 2 IC804 AA96-00243C ASSY H/S;-,REGULATOR,AA62-00045A,KA7806 3 0205-000129 GREASE-SILICON;SC102,JAPAN 3 6003-000335 SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR 3 AA62-00045A HEAT SINK-PS;-,-,T1.0,-,-,DREAM,-,-,-,-, 3 1203-000284 IC-POSI.FIXEDREG.;7806,TO-220, 2 DH01 AA96-00275A ASSY H/S;-,COMPLEX,AA62-00051A,KSD5703, 3 0205-000129 GREASE-SILICON;SC102,JAPAN 3 6003-000335 SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR 3 AA60-30001A WASHER-PLATE;-,M3,ID3.5,15X8.5,T1.0,-,SB 3 AA62-00051A HEAT SINK-PS;-,-,-,SILVER,HOLE 31mm,ALL, 3 0402-001296 DIODE-RECTIFIER;FMP-3FU,1500V,5A,T0-3PF 3 0502-001136 TR-POWER;KSD5703,NPN,70W,TO-3PF,ST,82 D813 0402-000233 DIODE-RECTIFIER;FML-G12S,200V, 2 D801S 0402-001160 DIODE-BRIDGE;D5SB60,600V,2.8A,SIP-4,ST 2 LX801S AA29-30002F FILTER-LINENOISE;-,6MH,2.45A,2 IC602 AA96-50398B ASSY-H/S;-,-,AA62-30182E,TDA7266S,3 AA62-30182E HEAT-SINK,ES;-,A6063 EXTR,-,WHT,-,-,-,40 3 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW 3 0205-000129 GREASE-SILICON;SC102,JAPAN 3 1201-001308 IC-POWERAMP;7266,ZIP,15P,-,DUAL,26dB,PL 2 LR401S AA27-00100A COIL LINEARITY;45uH,45uH,DR14x15C:6.0,11 2 CN501B AA39-00172A LEAD-CONNECTOR,ASSY;DREAM,1007#26,UL/CSA 2 L808 AA27-00098A COIL CHOKE;-,-,24uH,10%,-,0.1,3.0A,DR10X 2 DDR01 AA96-00469F ASSY H/S;-,REGULATOR,AA62-00053B,D10U60 3 0205-000129 GREASE-SILICON;SC102,JAPAN 3 0402-001358 DIODE-RECTIFIER;SDS10U60S,600V,10A,TO-22 3 0402-001375 DIODE-RECTIFIER;FFPF10U20S,200V,10A,TO-2 3 6003-000334 SCREW-TAPTITE;RH,+,2S,M3,L6,ZP 3 1203-001006 IC-VOLTAGEREGULATOR78R05,TO-220F,4P 3 AA62-00053B HEAT SINK;DREAM (D2,D3),AL ,T1.0,147,50, 2 IC803 1203-002085 IC-VOLTAGEREGULATOR;78R08,TO-220,4P 2 IC903 1203-001944 IC-POSI.FIXEDREG.78RM33,TO-220,3P,PLAST 2 C407 2301-001338 C-FILM,MPE,PPF0.68nF,5%,1.6kV,TP,28x7x1 2 IC401 1202-000103 IC-VOLTAGECOMP.393,DIP,8P,300MIL,DUAL, 2 L405 AA27-00096A COIL HORIZ. WIDTH;-,10.0mH,DR15 X 27.5,U 2 L408 AA27-00097A COIL HORIZ. WIDTH;-,700uH,DR15 X 27.5,US 2 Q404 0505-000156 FET-SILICON;IRF620,N,200V,5A,0.8ohm,50W, 2 CR403S 2303-001001 C-FILM,PPF;22nF,5%,630V,TP,18x14.5x8.5mm 2 CR404S 2301-001257 C-FILM,MPPF;640nF,5%,400V,TP,26x14.5x24, 2 L/PQS AA68-01018A LABEL-PQS,-,50mmX,13,-,WHITE,2 IC601 1204-001594 IC-SOUND PROCESSOR;MSP3440G-B6,SDIP,52P, 2 P801S 1404-000002 THERMISTOR;NTC,90HM,20%,TR,AC290VRMS,120 2 Q402 0502-001007 TR-POWER;KSC2073-H2,NPN,150V,1 2 CN602 3711-002644 POST-HEADER;67094-005(AUTO) 2 CN701 3711-002647 POST-HEADER;67094-008(AUTO) 2 CY802S 2201-000446 C-CERAMIC,AC;CK45PE400V332-M(T 2 CN902 3711-003043 CONNECTOR-HEADER;BOX,4P,1R,2.5mm,STRAIGH 2 GT407 AA39-20010H LEAD-CONNECTOR,ASSY;,YFH800-01,S,1P,300, 2 IC201S 1204-001633 IC-VIDEO PROCESS;VDP3112B-C3,DIP,64P,709 2 INLA/P AA61-00686B HOLDER-COVER;ALL MODEL,NYLON-66,T1.0 2 GT101 AA39-20010B LEAD-CONNECTOR,ASSY;-,YFH800-01,500MM,1P 2 CN601 3711-003043 CONNECTOR-HEADER;BOX,4P,1R,2.5mm,STRAIGH 2 CN901 3711-002644 POST-HEADER;67094-005(AUTO) 2 CR405S 2301-001257 C-FILM,MPPF;640nF,5%,400V,TP,26x14.5x24, 2 CX802S 2306-000318 C-FILM,MPPF;220NF,20%,250V,-,2

ASSY PCB CONTROL

1 A/CTRL AA95-00940A ASSY PCB CONTROL;CL25A6W,KS2A,

2 DC01 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 2 LDC901 0601-000262 LED;ROUND,RED,5mm,700nm 2 LDC902 0601-000465 LED;ROUND,GRN,5mm,565 2 RC916 2001-000007 R-CARBON;3KOHM,5%,1/8W,AA,TP,1 2 RC918 2001-000009 R-CARBON;20KOHM,5%,1/8W,AA,TP,

2 RC915 2001-000577 R-CARBON;2KOHM,5%,1/8W,AA,TP,1 2 RC939 2001-000793 R-CARBON;47OHM,5%,1/8W,AA,TP,1 2 RC917 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP 2 CC904 2401-001496 C-AL;47UF,20%,16V,GP,5X7MM,5MM 2 SWC901 3404-000176 SWITCH-TACT;12V,50MA,90-150GF, 2 SWC902 3404-000176 SWITCH-TACT;12V,50MA,90-150GF, 2 SWC903 3404-000176 SWITCH-TACT;12V,50MA,90-150GF, 2 SWC904 3404-000176 SWITCH-TACT;12V,50MA,90-150GF, 2 SWC905 3404-000176 SWITCH-TACT;12V,50MA,90-150GF, 2 SWC906 3404-000176 SWITCH-TACT;12V,50MA,90-150GF, 2 SWC907 3404-000176 SWITCH-TACT;12V,50MA,90-150GF, 2 JC01 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 2 JC02 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 2 JC03 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 2 RC02 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 2 RC03 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 2 CNC902 AA39-00100A LEAD CONNECTOR-ASSY;4P,YBNH250-04,300mm 2 CNC901 AA39-20523A LEAD CONNECTOR-ASSY;-,YBNH025-05,67096-0 2 00VER AA41-00405A PCB-CONTROL;CL25F1D,FR-1,1L,A,1.6T,245x2 2 RMC901 AA59-60002B MODULE-REMOCON;-,ORC-50HF,38KH 2 A/AV AA95-00897A ASSY PCB CONTROL;-,KS2A,-,2 AVPCB AA63-10002A BAND-TIE;-,NYLON66V2,-,-,L100,NTR,-,-

ASSY-PCB,A/V

1 A/A-V AA98-00081A ASSY-PCB,A/V;FRONT,KS2A

2 JE01 3722-000143 JACK-PHONE;1P,3.4MM,-,MBAG 2 BAND/WAA63-10002A BAND-TIE;-,NYLON66V2,-,-,L100,NTR,-,2 BAND-W AA63-10002A BAND-TIE;-,NYLON66V2,-,-,L100,NTR,-,2 00VER AA41-00320A PCB-AV FRONT;CL568B,FR-1,1L,A,1.6T,245x2 2 A/V AA95-00759A ASSY-PCB,A/V FRONT, KS2A 2 CN05A AA39-20069D LEAD-CONNECTOR,ASSY;-,YBNH0252 JR01 3722-001031 JACK-RCA;3P,3.6MM,#18,AU 2 CA02 2202-000121 C-CERAMIC,MLC-AXIAL;100PF,10%, 2 CA03 2202-000121 C-CERAMIC,MLC-AXIAL;100PF,10%, 2 CA04 2202-000720 C-CERAMIC,MLC-AXIAL;8.2nF,20%,16V,Y5R,TP 2 CA05 2202-000720 C-CERAMIC,MLC-AXIAL;8.2nF,20%,16V,Y5R,TP 2 LA04 2701-000180 INDUCTOR-AXIAL;33UH,5%,2.5X3.4 2 LA05 2701-000180 INDUCTOR-AXIAL;33UH,5%,2.5X3.4 2 CA06 2401-003102 C-AL;100uF,20%,10V,GP,TP,5x11,5 2 CA07 2401-003102 C-AL;100uF,20%,10V,GP,TP,5x11,5 2 LA02 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 2 LA03 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 2 RA01 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AB, 2 RA02 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AB, 2 CN01A AA39-20068E LEAD CONNECTOR-ASSY;-,YBNH025-08,67096-0

ASSY-CABINET,FRONT

1 A/FRNT AA92-00543A ASSY-CABINET,FRONT;KS2A,25,FLAT,CL25A6

2 DCOIL AA27-20004U COIL-DEGAUSSING;-,26,14.0ohm,55T,L2830,E 2 SPK+CF 6006-001095 SCREW-ASS’Y TAPT;WP,BH,+,M4,L12,ZPC(YEL) 2 CRT+CF AA60-10050V SCREW-ASSY;WC,HH,+,M6,L30,SWRCH18A,ZPC(S 2 CDCOIL AA65-30113A CLAMP-D,COIL;NYLON66,V2,BLK,TVI25~29,2 CWFC AA65-00011B CLAMP-WIRE;ALL MODEL,NYLON 66,V2,NTR,15M 2 F/C AA64-01440A CABINET FRONT;TOOL.S25A6,MOLD,-,-,3 KC AA64-00245B KNOB-CONTROL;-,25A6,BK702P+W971,ABS,HB,B 3 KP AA64-00243D KNOB-POWER;-,25A6,NO-SILK W971,ABS,HB,G3 3 IL AA64-00242B INDICATOR-LED;-,25A6,-,ACRYL,-,CLEAR,3 WR AA64-00241C WINDOW-REMOCON;-,25A6,W971,PC,VO,VIOLET, 3 SPRING AA61-00343A SPRING-CS;-,SUS304,-,-,-,-,0.4,0D6,H12,N 3 KC+CF 6002-000514 SCREW-TAPPING;RH,+,2,M4,L15,ZP 3 IL+CF 6002-000514 SCREW-TAPPING;RH,+,2,M4,L15,ZP 3 DOOR AA64-00240B DOOR-AV;-,25A6,BK702P,ABS,HB,BLK,-,3 HOLDER AA61-00529A HOLDER-RAIL;TOOL,S25A6,-,-,-,-,MOLD 3 HR+CF 6002-000522 SCREW-TAPPING;TH,+,2,M4,L15,ZP 2 L/QMS AA68-01554A LABEL;QMS,UARCOWHITEPAPER#1343 2 AV+CF 6006-001095 SCREW-ASS’Y TAPT;WP,BH,+,M4,L12,ZPC(YEL) 2 DRESPK AA65-30018A CLAMP-WIRE;-,NYLON6.6,-,-,DATL 2 A/HSPK AA91-00427B ASSY HOLDER SPK;DP,PP,8ohm/10W,BLK,SEMI2 CDCOIL AA65-30017A CLAMP-D,COIL;-,NYLON-66,V0,NTR,DADH300,2

Electrical Parts List

Samsung Electronics 7-13

Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark

2 S/CRT AA60-00038A SPACER-CRT;PS,SHEET,T1.0,BLK,OD22,ID10. 2 CF+CRT AA61-10053A BRACKET-CRATER;-,7277,STS304,T0.5,-,-,2 BRAC+C 6002-000514 SCREW-TAPPING;RH,+,2,M4,L15,ZP 2 BADGE AA64-70117B BADGE-BRAND;AL,SS,R2000,25,SILVER CT-633 2 PC+CF 6002-000522 SCREW-TAPPING;TH,+,2,M4,L15,ZP 2 IN/AV AA64-01713B INLAY-AV;PS,SHEET,T0.3,BLK,25A6

ASSY-CABINET,(COM)

1 A/BACK AA92-01152A ASSY-CABINET,(COM);KS2A,25,FLAT,W/O SVH

2 CB+CF 6002-000514 SCREW-TAPPING;RH,+,2,M4,L15,ZP 2 TER+RK 6002-000514 SCREW-TAPPING;RH,+,2,M4,L15,ZP 2 STAPLE AA60-40006A PIN-STAPLE;-,-,-,H18,33X17.8X2 2 SPCBC AA63-60001X SPACER-FELT;FELT,T0.5,330X15MM 2 AC+BC AA65-30008A CLAMP-CORD;-,PE,HB,BLK,-,2 B/C AA64-01441A CABINET BACK;TOOL.S25A6,MOLD,-,-,2 L/RAT AA68-01546A LABEL RATING;TETRONEPAPER90(S)N,SEM 2 C/SET AA69-00471B CUSHION SET;25A6(NEW0,PS C=0.02,-,-,-,-, 2 PE-BAG AA69-01209A BAG;SHEET,25-27,W54,L60,FOAM,OEM. 2 FBT AA65-30018A CLAMP-WIRE;-,NYLON6.6,-,-,DATL 2 H/T AA61-00356B HOLDER-TUNER,F/JACK;-,501F,ABS,HB,BLK,2 BXTAPE 0203-001295 TAPE-OPP MASKING;1242,T0.06,W100,L91.4M, 2 AC-TAP 0203-001279 TAPE-OPP MASKING;#232,T0.14,W15,L50000,Y 2 INLAYB AA64-00892B INLAY BACK;D2,D3,RCA9P,PS SHEET,T0.3,BLK 2 DRESB AA65-30018A CLAMP-WIRE;-,NYLON6.6,-,-,DATL 2 H/S+CW AA65-30018A CLAMP-WIRE;-,NYLON6.6,-,-,DATL 2 C/HS AA65-30105B CLAMP-WIRE;NYLON 66,V2,NTR,25MM,ALL MODE 2 L/SPON AA68-01462A LABEL;SPONSOR,SEM,ART-PAPE 2 L/BN AA68-01793A LABEL;BOX & NOM,WTH,PAPER,MEX & TIJ 2 PCK AA69-01214E PACKING CASE;25A6 SAMEX,CB D-2,YEL,AMERI

ASSY CRT

1 A/CRTP AA94-05547A ASSY CRT;A59QDF891X999,+380MG,25,ITC

2 CRT AA03-00322A CRT COLOR;A59QDF891X999,+380MG,1.05MH,1.

ASSY-TBC,WIRE(P)

1 A/TBC AA98-70008B ASSY-TBC,WIRE(P);-,TVI 25’,NTSC,2P-WH,-

ASSY-ACCESSORY

1 A/ACCE AA97-01519A ASSY-ACCESSORY;KS2A,25,MEX & TIJ,CL25A6

2 W/CARD AA68-00559C CARD WARRANTY;-,-,W/P150(G),-,138X212,-, 2 BAG-PE AA69-01195A BAG PE;CL29A6W8X,HDPET0.012,93/4X151 2 L/CONS AA68-01574A LABEL;CONSIGN-REEXP,L,W;3,1/2; 1,15 2 T/REG AA68-01585A CARD;REGISTRATION,8.5X11,80GL,MEX 2 M/SERV AA68-00501A MANUAL-SERVICE;-,-,-,,WHT,ALL MEX&TIJ. 2 L/RMT AA68-00685A LABEL-REMOCON;PAPER90(G),SEM&TIJ,AA,BLK 2 BATT 4301-000120 BATTERY-MN;1.5V,-,AA 2 C/RCA AA39-40001B PATCH-CORD;3P-3P1500MMRED,WHT,YEL,500 2 I/B AA68-01871A MANUAL USERS;KS2A,SPANISH,B5,W/P100(G)

REMOCON

1 RMT AA59-10113H REMOCON;DP,TM59,-,-,-,-,-,AA59-10110H,

Electrical Parts List

7-14 Samsung Electronics

Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark

Electrical Parts List

Samsung Electronics 7-15

7-3 CL29C1W7FX/XAP

Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark

ASSY-PCB;MAIN(COM)

1 A/MAIN AA94-03654A ASSY-PCB;MAIN(COM);29 CRT PIN FREE

2 PC801S 0604-001032 PHOTO-COUPLER;TR,170-260%,300M 2 CR402S 2303-001015 C-FILM,PPFF;5.5NF,5%,1.6KV,TP, 2 CX801S 2306-000318 C-FILM,MPPF;220NF,20%,250V,-,2 2 C806 2401-001426 C-AL;470UF,400V 2 SW906 3404-001004 SWITCH TACT;12V,50MA,160GF8.4X22.7MM 2 RL801S 3501-001040 RELAYPOWER;12VDC,500MW,10A,1FO 2 FP801S 3601-001012 FUSE-FERRULE;250V,4A,SLOW-BLOW 2 V999S 3704-001105 SOCKET-CRT;11P,20PI,26.5PI,NI,2 JA701 3722-001333 JACK-RCA9P,3.2mm,NI,BLK 2 IC901 AA09-00243A IC MICOM;SIM-408A3,CL-21A8,52P,-0.3~+7, 2 T401 AA26-50001R TRANS HORIZ DRIVE;80MH,580UH,4UH,G11AEI1 2 CN501B AA39-00172A LEAD-CONNECTOR,ASSY;DREAM,1007#26,UL/CSA 2 TU01S AA40-00074A TUNER;TCPN3081PA09A(B),NTSC,181CH,45 2 RM901 AA59-60001U MODULE-REMOCON;-,ORC-50VF,38KH 2 LD901 AA96-00555A ASSY LED GUIDE;-,-,UEX-LD-030,GREEN 2 IC501 AA96-00582A ASSY H/S;-,CRT,AA62-00096A,STV5109,KS1A 3 0205-000129 GREASE-SILICON;SC102,JAPAN 3 6003-000335 SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR 3 AA62-00096A HEAT SINK;KS2A,AL5052,T1.0,W36.0,H35.0,S 3 1201-001687 IC-VIDEO AMP;STV5109,ZIP,15P,-,SIGLE,50d 2 IC801S AA96-50373F ASSY H/S;-,PWM,AA62-30181K,KA3A1265RD 3 AA13-00101A IC HYBRID;KA3A1265RD,CN5039,5Pin,-50to12 3 0205-000129 GREASE-SILICON;SC102,JAPAN 3 AA62-30181K HEATSINK-ES;-,AL6063EXTR.,2,WHT,40MM,3 AA61-10386A BRACKET-IC;-,-,SECC100,T1.0,-,KA2S0680, 3 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW 3 AA02-00007A MICA;DPM-04,MICA,22x29x0.15mm 2 IC301 AA96-50406A ASSY-H/S;LA62-30180K,LA7845 3 1204-000517 IC-LINEAR;LA7845SIPVERTICALAMP 3 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW 3 AA62-30180K HEATSINK-ES;-,A6063EXTR,-,WHT,50/13,-, 2 A/MAIN AA94-05022A ASSY-PCB,MAIN(AUTO);KS2A(G),P/FREE,FLAT, 3 D908 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D201 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D602 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D207 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D202 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D804 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 DZ402 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D501 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D502 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D503 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D508 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D604 0401-000005 DIODE;1N4148,100V,300mA,,1V,8nS,TAPING 3 D407 0402-000493 DIODE-RECTIFIER;1R5GU41,400V,1 3 D402 0402-000540 DIODE-RECTIFIER;RU20A,600V,1.5 3 D401 0402-000540 DIODE-RECTIFIER;RU20A,600V,1.5 3 DZ201 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ203 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ204 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ602 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ903 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ904 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ907 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ906 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ905 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ901 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ902 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ601 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ802 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ806 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ908 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 3 DZ305 0403-001221 DIODE-ZENER;UZ39BSB,35.36-37.19V,500MW,D 3 DZ302 0403-001329 DIODE-ZENER;MTZJ24B,22.61-23.77V,500mW, 3 DZ303 0403-001329 DIODE-ZENER;MTZJ24B,22.61-23.77V,500mW, 3 DZ304 0403-001329 DIODE-ZENER;MTZJ24B,22.61-23.77V,500mW, 3 DZ306 0403-000700 DIODE-ZENER;TZP33A,33V,31-35V, 3 DZ804 0403-000700 DIODE-ZENER;TZP33A,33V,31-35V, 3 Q206 0501-000283 TRANSISTOR;KSA539-Y(TAPG)/YTAM

3 Q208 0501-000283 TRANSISTOR;KSA539-Y(TAPG)/YTAM 3 Q210 0501-000283 TRANSISTOR;KSA539-Y(TAPG)/YTAM 3 Q802 0501-000369 TRANSISTOR;KSC2331-Y(TAPG) 3 Q201 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q202 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q203 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q204 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q207 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q209 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q213 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q222 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q901 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q902 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q903 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q904 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q905 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q906 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q907 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q908 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 Q911 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 3 DZ805 1203-001217 IC-POST,ADJUSTREG;431,T0-92,3P,4.58MIL,P 3 R245 2001-000005 R-CARBON;390OHM,5%,1/8W,AA,TP, 3 R250 2001-000005 R-CARBON;390OHM,5%,1/8W,AA,TP, 3 R255 2001-000005 R-CARBON;390OHM,5%,1/8W,AA,TP, 3 R916 2001-000007 R-CARBON;3KOHM,5%,1/8W,AA,TP,1 3 R214 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3.2MM 3 R303 2001-000016 R-CARBON(S);1OHM,5%,1/2W,AA,TP 3 R825 2001-000066 R-CARBON(S);10KOHM,5%,1/2W,AA, 3 R307 2001-000066 R-CARBON(S);10KOHM,5%,1/2W,AA, 3 R209 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP 3 R914 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP 3 R103 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R201 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R203 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R204 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R246 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R251 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R256 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R609 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R610 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R611 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R612 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R613 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R619 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R706 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R707 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R708 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R723 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R730 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R731 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R902 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R907 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R909 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R940 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R941 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R942 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R944A 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 3 R202 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R205 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R206 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R211 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R309 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R310 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R601 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R602 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R606 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R715 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R716 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R935 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R620 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R268 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 R627 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP, 3 J909 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R222 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm

3 R231 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R232 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R233 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R234 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R235 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R252 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R603 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R910 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R912 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R924 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R929 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R930 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R943 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R607 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R608 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 D505 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 D506 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 D507 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R216 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 C906 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R207 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP 3 R833 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP 3 R215 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP, 3 R824 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP, 3 R915 2001-000577 R-CARBON;2KOHM,5%,1/8W,AA,TP,1 3 R213 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R901 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R903 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R904 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R905 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R906 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R908 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R921 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R926 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R937 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R947 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R948 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R952 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R953 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 3 R614 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R615 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R616 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R617 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R812 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R831 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R919 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R920 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R931 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R933 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R106 2001-000864 R-CARBON;56Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R709 2001-000938 R-CARBON ;68ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R524 2001-001062 R-CARBON(S);10MOHM,5%,1/2W,AA, 3 R308 2001-001062 R-CARBON(S);10MOHM,5%,1/2W,AA, 3 R816 2001-001088 R-CARBON(S);1KOHM,5%,1/2W,AA,TP,2.4X6.4 3 R817 2001-001088 R-CARBON(S);1KOHM,5%,1/2W,AA,TP,2.4X6.4 3 RR430S 2001-001088 R-CARBON(S);1KOHM,5%,1/2W,AA,TP,2.4X6.4 3 R239 2001-001114 R-CARBON(S);270OHM,5%,1/2W,AA, 3 R410 2001-001114 R-CARBON(S);270OHM,5%,1/2W,AA, 3 R805 2001-001150 R-CARBON(S);470KOHM,5%,1/2W,AA 3 R806 2001-001150 R-CARBON(S);470KOHM,5%,1/2W,AA 3 R813 2001-001153 R-CARBON(S);47OHM,5%,1/2W,AA,T 3 R832 2001-001153 R-CARBON(S);47OHM,5%,1/2W,AA,T 3 R939 2001-001153 R-CARBON(S);47OHM,5%,1/2W,AA,T 3 R810 2001-001178 R-CARBON(S);680OHM,5%,1/2W,AA, 3 R521 2002-001009 R-COMPOSITION;2.7KOHM,10%,1/2W,AA,TP,3.7 3 R426 2003-000540 R-METALOXIDE(S);1KOHM,5%,2W,AD 3 R821 2004-002015 R-METAL,FILM;RM1/2T140K-F 3 R819 2004-001983 R-METAL;2.49KOHM,1%,1/2W,AA,TP,2.4X6.4 3 R304 2008-000254 R-FUSIBLE(S);0.68OHM,5%,2W,AF, 3 R828 2008-000266 R-FUSIBLE(S);1OHM,5%,2W,AF,TP, 3 R519 2702-001096 INDUCTOR-RADIAL;33uH,10%,6x4mm 3 C910 2201-000980 C-CERAMIC,DISC;30PF,5%,50V,NPO,5.0X3.0,5 3 C911 2201-000980 C-CERAMIC,DISC;30PF,5%,50V,NPO,5.0X3.0,5 3 C804 2201-000332 C-CERAMIC,AC;CK45PTAPGE250V222 3 C805 2201-000332 C-CERAMIC,AC;CK45PTAPGE250V222 3 C401 2201-000556 C-CERAMIC,DISC;470PF,10%,500V, 3 C403 2201-000556 C-CERAMIC,DISC;470PF,10%,500V,

3 C421 2201-000556 C-CERAMIC,DISC;470PF,10%,500V, 3 C908 2202-000863 C-CERAMIC;CKOAX7R50VT561-KUP050561 3 C817 2201-000599 C-CERAMIC,DISC;560PF,10%,500V, 3 C819 2201-000599 C-CERAMIC,DISC;560PF,10%,500V, 3 C822 2201-000599 C-CERAMIC,DISC;560PF,10%,500V, 3 C425 2201-000599 C-CERAMIC,DISC;560PF,10%,500V, 3 C814 2201-000406 C-CERAMIC,HIC;CK45(T)B2KV271-K 3 C509 2201-000723 C-CERAMIC,DISC;4.7nF,20%,3KV,Y5U,TP,16x5 3 C115 2202-000121 C-CERAMIC,MLC-AXIAL;100PF,10%, 3 C116 2202-000121 C-CERAMIC,MLC-AXIAL;100PF,10%, 3 C243 2202-000121 C-CERAMIC,MLC-AXIAL;100PF,10%, 3 C244 2202-000121 C-CERAMIC,MLC-AXIAL;100PF,10%, 3 C245 2202-000121 C-CERAMIC,MLC-AXIAL;100PF,10%, 3 C647 2202-000286 C-CERAMIC,MLC-AXIAL;56PF,5%,50 3 C654 2202-000286 C-CERAMIC,MLC-AXIAL;56PF,5%,50 3 C211 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50 3 C607 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50 3 C608 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50 3 C905 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50 3 C504 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50 3 C505 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50 3 C506 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50 3 C821 2301-000192 C-FILM,PEF;1NF,5%,50V,5.3X10MM 3 C242 2301-000310 C-FILM,PEF;68NF,5%,50V,8.0X8.5 3 C213 2301-000310 C-FILM,PEF;68NF,5%,50V,8.0X8.5 3 C306 2301-000342 C-FILM,PEF;2.2nF,5%,50V,TP,7.4x3.9x13mm, 3 C228 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m 3 C803 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m 3 C809 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m 3 C214 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C216 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C308 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C620 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C635 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C646 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C823 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C829 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C831 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C837 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C839 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C907 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C914 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C916 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C919 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C605 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C513 2305-000665 C-FILM;104J, 60V,5MM TAPING 3 C508 2305-000704 C-M,POLYESTER;CFS922MTAPG250V1 3 C511 2305-000704 C-M,POLYESTER;CFS922MTAPG250V1 3 C816 2401-000262 C-AL;100UF,20%,160V,GP,16X25MM,5MM, 3 C904 2401-000302 C-AL;100UF,20%,25V,GP,6X11MM,5 3 C307 2401-000360 C-AL;100UF,20%,50V,GP,8X11MM,5 3 C302 2401-000360 C-AL;100UF,20%,50V,GP,8X11MM,5 3 C920 2401-000480 C-AL;10UF,20%,50V,GP,5X11MM,5M 3 C106 2401-000603 C-AL;1UF,20%,50V,GP,5X11MM,5MM 3 C301 2401-000603 C-AL;1UF,20%,50V,GP,5X11MM,5MM 3 C412 2305-000178 C-FILM,MPEF;10NF,5%,100V,-,5MM 3 C217 2401-001026 C-AL;3.3UF,20%,50V,GP,5X11MM,5 3 C636 2401-001026 C-AL;3.3UF,20%,50V,GP,5X11MM,5 3 C510 2401-001232 C-AL;4.7UF,20%,250V,GP,10X12.5 3 C637 2401-000027 C-AL;4.7UF,20%,50V,GP,5*11MM,5MEA 3 C640 2401-000027 C-AL;4.7UF,20%,50V,GP,5*11MM,5MEA 3 C641 2401-000027 C-AL;4.7UF,20%,50V,GP,5*11MM,5MEA 3 C643 2401-000027 C-AL;4.7UF,20%,50V,GP,5*11MM,5MEA 3 C104 2401-002463 C-ELECTROLYTIC;CE04WTAPG16V470M-M(SG)-VE 3 C826 2401-002463 C-ELECTROLYTIC;CE04WTAPG16V470M-M(SG)-VE 3 C512 2401-002463 C-ELECTROLYTIC;CE04WTAPG16V470M-M(SG)-VE 3 C402 2401-001397 C-AL;470UF,20%,25V,GP,10X16MM, 3 C404 2401-001397 C-AL;470UF,20%,25V,GP,10X16MM, 3 C634 2401-001840 C-AL;100UF,20%,16V,GP,TP,6.3X1 3 C652 2401-001840 C-AL;100UF,20%,16V,GP,TP,6.3X1 3 C832 2401-001840 C-AL;100UF,20%,16V,GP,TP,6.3X1 3 C838 2401-001840 C-AL;100UF,20%,16V,GP,TP,6.3X1 3 C917 2401-001840 C-AL;100UF,20%,16V,GP,TP,6.3X1 3 C918 2401-001840 C-AL;100UF,20%,16V,GP,TP,6.3X1 3 C660 2401-001840 C-AL;100UF,20%,16V,GP,TP,6.3X1 3 C250 2401-001840 C-AL;100UF,20%,16V,GP,TP,6.3X1 3 C203 2401-001840 C-AL;100UF,20%,16V,GP,TP,6.3X1

Electrical Parts List

7-16 Samsung Electronics

Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark

3 C207 2401-001840 C-AL;100UF,20%,16V,GP,TP,6.3X1 3 C626 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5 3 C628 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5 3 C621 2401-001998 C-AL;1000UF,20%,25V,GP,TP,10X20 3 L202 2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3. 3 L301 2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3. 3 L602 2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3. 3 L603 2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3. 3 L906 2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3. 3 R604 2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3. 3 R605 2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3. 3 L907 2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3. 3 L804 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,3 L807 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,3 L407 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,3 L411 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,3 L501 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,3 L203 3301-000287 CORE-FERRITEBEAD;AA,3.5X1.0X6. 3 L610 3301-000287 CORE-FERRITEBEAD;AA,3.5X1.0X6. 3 L801 3301-000287 CORE-FERRITEBEAD;AA,3.5X1.0X6. 3 L802 3301-000287 CORE-FERRITEBEAD;AA,3.5X1.0X6. 3 L803 3301-000287 CORE-FERRITEBEAD;AA,3.5X1.0X6. 3 L806 3301-000287 CORE-FERRITEBEAD;AA,3.5X1.0X6. 3 L809 3301-000287 CORE-FERRITEBEAD;AA,3.5X1.0X6. 3 L302 3301-000287 CORE-FERRITEBEAD;AA,3.5X1.0X6. 3 L303 3301-000287 CORE-FERRITEBEAD;AA,3.5X1.0X6. 3 J709 3301-000287 CORE-FERRITEBEAD;AA,3.5X1.0X6. 3 SW901 3404-000244 SWITCH-TACT;15V,20MA,90-170GF, 3 SW902 3404-000244 SWITCH-TACT;15V,20MA,90-170GF, 3 SW903 3404-000244 SWITCH-TACT;15V,20MA,90-170GF, 3 SW904 3404-000244 SWITCH-TACT;15V,20MA,90-170GF, 3 SW905 3404-000244 SWITCH-TACT;15V,20MA,90-170GF, 3 F801B 3602-000114 FUSE-HOLDER;-,-,30MOHM 3 F801A 3602-000114 FUSE-HOLDER;-,-,30MOHM 3 J102 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J103 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J104 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J106 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J107 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J109 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J110 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J112 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J113 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J115 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J116 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J118 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J119 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J120 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J122 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J124 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J126 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J202 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J204 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J205 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J206 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J209 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J210 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J211 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J212 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J213 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J215 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J216 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J217 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J219 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J221 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J222 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J223 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J224 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J225 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J226 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J227 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J228 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J229 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J231 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J232 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J233 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J234 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A

3 J237 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J238 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J239 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J240 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J243 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J246 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J247 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J248 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J249 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J250 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J252 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J254 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J256 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J257 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J258 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J259 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J261 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J290 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J291 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J292 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J311 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J404 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J405 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J406 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J407 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J408 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J409 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J410 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J411 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J412 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J413 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J416 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J420 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J421 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J422 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J429 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J444 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J445 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J502 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J504 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J505 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J601 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J602 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J603 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J605 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J606 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J608 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J609 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J610 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J611 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J613 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J615 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J616 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J617 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J619 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J620 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J623 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J625 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J626 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J627 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J629 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J632 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J635 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J703 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J704 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J708 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J712 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J715 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J801 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J802 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J803 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J804 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J805 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J807 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J810 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J811 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J816 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A

Electrical Parts List

Samsung Electronics 7-17

Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark

3 J817 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J818 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J819 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J820 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J821 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J822 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J826 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J831 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J832 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J835 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J902 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J904 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J906 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J907 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J908 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J911 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J912 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J913 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J914 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J915 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J916 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J917 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J918 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J920 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J924 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J925 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J926 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J927 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J928 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J929 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J930 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J931 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J933 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J934 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J935 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J941 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J942 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J995 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J996 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J997 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J998 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 L101 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 L410 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 R820 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 RY801S 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J621 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J506 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J312 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J901 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J900 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J127 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J245 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J313 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J628 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J630 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J814 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J815 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J833 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J834 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J923 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J994 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J128 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J260 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J264 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J501 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J510 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J634 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J665 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J921 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J922 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 JJ01 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J251 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J253 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J255 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J262 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J263 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J701 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A

3 J905 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 L605 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 L606 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 L607 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 L608 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 L701 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 L702 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 L705 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 L706 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 L711 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 R623 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J117 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 J419 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 3 07VER AA41-00132J PCB-MAIN;CS2139T,FR-1,1L,J,1.6T,330X245 3 EY301 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY302 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY303 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY304 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY403 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY405 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY406 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY409 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY410 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY411 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY412 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY413 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY414 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY415 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY416 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY417 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY418 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY419 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY421 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY422 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY423 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY424 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY425 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY426 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY427 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY429 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY430 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY431 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY432 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY433 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY434 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY435 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY436 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY437 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY439 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY440 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY441 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY442 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY445 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY602 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY604 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY701 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY702 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY801 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY802 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY803 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY804 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY805 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY806 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY809 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY810 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY811 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY812 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY815 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY816 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY817 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY818 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY820 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY822 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY823 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY824 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY825 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY826 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST

Electrical Parts List

7-18 Samsung Electronics

Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark

3 EY830 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY831 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY832 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY833 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY835 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY836 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY837 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY839 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY840 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY841 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY842 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY843 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY844 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY845 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY846 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY847 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY848 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY849 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY850 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY851 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY853 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY854 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY855 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY856 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY858 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY859 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY861 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY863 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY865 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY870 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY871 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY401 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EY402 AA60-40011A EYELET;-,ID2.0,OD2.8,-,-,BST 3 EL401 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 EL402 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 EL404 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 EL802 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 EL803 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 EL805 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 EL806 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 EL807 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 EL808 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 EL405 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 EL501 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 EL502 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 EL801 AA60-40011B EYELET;-,ID2.2,OD3.2,-,-,BSP 3 GT301 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT302 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT401 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT402 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT407 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT501 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT502 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT801 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT802 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT803 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT804 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT805 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT806 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT503 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 GT102 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO 3 L/LINE AA68-01544A LABEL;LINE,ALL MDL COMMON 3 C808 2401-002300 C-ELECTROLYTIC;CE04WTAPG50V47U 3 C913 2401-000287 C-AL;100UF,20%,16V,WT,6X11MM,5 3 C915 2401-000287 C-AL;100UF,20%,16V,WT,6X11MM,5 3 C304 2305-000285 C-FILM,MPEF;220NF,5%,100V,-,5M 3 R412 2001-000020 R-CARBON(S);22OHM,5%,1/2W,AA,T 3 C632 2202-000231 C-CERAMIC,MLC-AXIAL;330PF,10%,50V,Y5P,3. 3 J218 2202-000231 C-CERAMIC,MLC-AXIAL;330PF,10%,50V,Y5P,3. 3 C702 2202-000231 C-CERAMIC,MLC-AXIAL;330PF,10%,50V,Y5P,3. 3 C233 2305-000412 C-FILM,MPEF;470NF,5%,63V,-,5MM 3 C234 2305-000412 C-FILM,MPEF;470NF,5%,63V,-,5MM 3 C235 2305-000412 C-FILM,MPEF;470NF,5%,63V,-,5MM 3 C236 2305-000412 C-FILM,MPEF;470NF,5%,63V,-,5MM 3 FD803S 3601-001163 FUSE-AXIAL LEAD;125V,7A,-,EPOXY,2.4X7.1M 3 FD801S 3601-001163 FUSE-AXIAL LEAD;125V,7A,-,EPOXY,2.4X7.1M 3 FD802S 3601-001163 FUSE-AXIAL LEAD;125V,7A,-,EPOXY,2.4X7.1M

3 D204 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100MA,DO-34,TP 3 D205 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100MA,DO-34,TP 3 D206 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100MA,DO-34,TP 3 D903 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100MA,DO-34,TP 3 D203 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100MA,DO-34,TP 3 D901 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100MA,DO-34,TP 3 D902 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100MA,DO-34,TP 3 D904 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100MA,DO-34,TP 3 D905 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100MA,DO-34,TP 3 D803 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1. 3 D301 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1. 3 D411 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1. 3 VP801S 1405-000152 VARISTOR;560V,2500A,14X8.5MM,T 3 VX801S 1405-000152 VARISTOR;560V,2500A,14X8.5MM,T 3 C843 2201-000681 C-CERAMIC,DISC;82PF,5%,50V,SL,4X3.5MM,5M 3 DZ803 0403-001167 DIODE-ZENER;MTZJ30D,30V,29.02-30.51V,500 3 D413 0402-000537 DIODE-RECTIFIER;RH1A,600V,0.6A, 3 DZ701 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 3 DZ702 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 3 R264 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP, 3 R265 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP, 3 R267 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP, 3 R934 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP, 3 R918 2001-000009 R-CARBON;20KOHM,5%,1/8W,AA,TP, 3 DZ801 0403-001322 DIODE-ZENER;MTZJ8.2B,7.78-8.19V,500mW,DO 3 DZ808 0403-001322 DIODE-ZENER;MTZJ8.2B,7.78-8.19V,500mW,DO 3 R927 2001-000837 R-CARBON;51KOHM,5%,1/8W,AA,TP, 3 R925 2001-001035 R-CARBON ;91ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R105 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP, 3 R302 2004-001984 R-METAL;26.7KOHM,1%,1/2W,AA,TP 3 R301 2004-001397 R-METAL(S);4.7KOHM,1%,1/2W,AA, 3 R429 2004-001397 R-METAL(S);4.7KOHM,1%,1/2W,AA, 3 R432 2004-001397 R-METAL(S);4.7KOHM,1%,1/2W,AA, 3 R236 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP, 3 R237 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP, 3 R238 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP, 3 R249 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP, 3 R254 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP, 3 R259 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP, 3 R932 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP, 3 R946 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP, 3 R807 2003-000746 R-METALOXIDE(S);56OHM,5%,2W,AD 3 R808 2003-000746 R-METALOXIDE(S);56OHM,5%,2W,AD 3 R827 2008-000284 R-FUSIBLE(S);0.1OHM,10%,2W,AF,TP,3.9X10M 3 R405 2008-000284 R-FUSIBLE(S);0.1OHM,10%,2W,AF,TP,3.9X10M 3 R403 2003-002037 R-METAL OXIDE(S);270OHM,5%,2W,AF,TP,3.9X 3 R826 2001-001072 R-CARBON(S);12ohm,5%,1/2W,AA,TP,2.4x6.4m 3 R802 2003-001025 R-METALOXIDE(S);15KOHM,5%,2W,A 3 R803 2003-001025 R-METALOXIDE(S);15KOHM,5%,2W,A 3 R804 2003-001025 R-METALOXIDE(S);15KOHM,5%,2W,A 3 R811 2001-001135 R-CARBON(S);36KOHM,5%,1/2W,AA, 3 R917 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP 3 R313 2004-001137 R-METAL;6.8KOHM,1%,1/8W,AA,TP,1.8*3.2M 3 R248 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1 3 R253 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1 3 R258 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1 3 R701 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1 3 R702 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1 3 R703 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1 3 R704 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1 3 R705 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1 3 R719 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1 3 R711 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1 3 R712 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1 3 R720 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1 3 R722 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1 3 R721 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1 3 C424 2201-000132 C-CERAMIC,DISC;100PF,10%,500V,Y5P,6X3MM, 3 R913 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP 3 RY802S 2002-001013 R-COMPOSITION;4.7MOhm,5%,1/2W,AA,TP,3.7X 3 R424 2008-001018 R-FUSIBLE(S);0.47OHM,10%,2W,AF 3 R425 2008-001018 R-FUSIBLE(S);0.47OHM,10%,2W,AF 3 R228 2001-001170 R-CARBON(S);6.8OHM,5%,1/2W,AB, 3 R434 2003-000664 R-METAL OXIDE(S);330HM,5%,2W,AF,TP,4X12M 3 R829 2003-001036 R-METALOXIDE(S);3.3OHM,5%,2W,A 3 R314 2004-001986 R-METAL;35.7KOHM,1%,1/2W,AA,TP 3 R409 2001-001410 R-CARBON;RD1/2T(S)430-J43R

Electrical Parts List

Samsung Electronics 7-19

Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark

3 R809 2001-001410 R-CARBON;RD1/2T(S)430-J43R 3 R818 2001-001113 R-CARBON(S);270KOHM,5%,1/2W,AA 3 R512 2002-001008 R-COMPOSITION;1.8KOHM,10%1/2W,AA,TP,3.7 3 R515 2002-001008 R-COMPOSITION;1.8KOHM,10%1/2W,AA,TP,3.7 3 R518 2002-001008 R-COMPOSITION;1.8KOHM,10%1/2W,AA,TP,3.7 3 C408 2305-000382 C-FILM,MPEF;4.7NF,5%,400V,TP,-,5MM. 3 C807 2301-001435 C-FILM,PPF;1.5nF,5%,1.2kV,TP,15x8x12.5mm 3 C414 2401-002597 C-AL;220uF,20%,35V,GP,TP,10x12.5,5 3 C610 2301-000314 C-FILM,PEF;8.2NF,5%,50V,6.5X3. 3 C611 2301-000314 C-FILM,PEF;8.2NF,5%,50V,6.5X3. 3 C215 2401-002235 C-ELECTROLYTIC;CE04W(T)16V10M 3 C229 2401-002235 C-ELECTROLYTIC;CE04W(T)16V10M 3 C231 2401-002235 C-ELECTROLYTIC;CE04W(T)16V10M 3 C630 2401-002235 C-ELECTROLYTIC;CE04W(T)16V10M 3 C631 2401-002235 C-ELECTROLYTIC;CE04W(T)16V10M 3 C645 2401-002235 C-ELECTROLYTIC;CE04W(T)16V10M 3 C827 2401-002235 C-ELECTROLYTIC;CE04W(T)16V10M 3 C840 2401-002235 C-ELECTROLYTIC;CE04W(T)16V10M 3 C210 2401-002235 C-ELECTROLYTIC;CE04W(T)16V10M 3 C227 2401-002235 C-ELECTROLYTIC;CE04W(T)16V10M 3 C202 2401-002235 C-ELECTROLYTIC;CE04W(T)16V10M 3 C903 2401-002235 C-ELECTROLYTIC;CE04W(T)16V10M 3 C825 2306-000122 C-FILM,MPPF;100NF,5%,50V,7.3X4 3 C103 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm 3 C105 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm 3 C224 2201-002031 C-CERAMIC,DISC;5pF,0.25pF,50V,NPO,TP,5x3 3 C225 2201-002031 C-CERAMIC,DISC;5pF,0.25pF,50V,NPO,TP,5x3 3 C303 2201-002031 C-CERAMIC,DISC;5pF,0.25pF,50V,NPO,TP,5x3 3 C617 2401-000493 C-AL;10UF,20%,50V,WT,5X11MM,5M 3 C230 2401-000493 C-AL;10UF,20%,50V,WT,5X11MM,5M 3 C237 2401-000914 C-AL;22UF,20%,16V,GP,5X11,5,TP 3 C102 2401-002463 C-ELECTROLYTIC;CE04WTAPG16V470M-M(SG)-VE 3 C820 2401-001054 C-AL;3300UF,20%,25V,GP,18X26MM,7.5M 3 C612 2401-001914 C-AL;1uF,20%,50V,BP,TP,5x11,5 3 C613 2401-001914 C-AL;1uF,20%,50V,BP,TP,5x11,5 3 C427 2401-002267 C-AL;2.2UF,20%,250V,GP,8X12MM, 3 C507 2401-002267 C-AL;2.2UF,20%,250V,GP,8X12MM, 3 C835 2401-003139 C-AL;1000UF,20%,25V,WT,TP,10*2 3 L901 2901-000299 FILTER-EMIBEAD;BL02RN2-R65T2DB 3 L903 2901-000299 FILTER-EMIBEAD;BL02RN2-R65T2DB 3 L904 2901-000299 FILTER-EMIBEAD;BL02RN2-R65T2DB 3 R923 2001-000924 R-CARBON;680ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 R102 2001-000924 R-CARBON;680ohm,5%,1/8W,AA,TP,1.8x3.2mm 3 L204 2702-001094 INDUCTOR-RADIAL;10uH,10%,6x4mm 3 L201 2702-001094 INDUCTOR-RADIAL;10uH,10%,6x4mm 3 L601 2702-001094 INDUCTOR-RADIAL;10uH,10%,6x4mm 3 L609 2702-001094 INDUCTOR-RADIAL;10uH,10%,6x4mm 3 L103 2701-000115 INDUCTOR-AXIAL;10UH,10%,2.8X7M 3 R208 2001-000405 R-CARBON;180OHM,5%,1/8W,AA,TP, 3 R243 2001-000405 R-CARBON;180OHM,5%,1/8W,AA,TP, 3 R509 2001-000405 R-CARBON;180OHM,5%,1/8W,AA,TP, 3 R511 2001-000405 R-CARBON;180OHM,5%,1/8W,AA,TP, 3 R517 2001-000405 R-CARBON;180OHM,5%,1/8W,AA,TP, 3 C420 2301-001065 C-FILM,MPPF;47NF,55,630V,TP,19 3 C818 2401-000711 C-AL;2200uF,20%,25V,GP,TP,16x25,7.5 3 C650 2201-000558 C-CERAMIC,DISC;470PF,10%,50V,Y 3 C422 2401-001527 C-AL;47UF,20%,250V,HR,13X25MM, 3 C902 2401-000553 C-AL;1UF,10%,50V,GP,5X11MM,5MM 3 C201 2401-000553 C-AL;1UF,10%,50V,GP,5X11MM,5MM 3 C618 2401-000553 C-AL;1UF,10%,50V,GP,5X11MM,5MM 3 R306 2008-001107 R-FUSIBLE(S);300ohm,5%,2W,AG,TP,3.9x12mm 3 R305 2008-001107 R-FUSIBLE(S);300ohm,5%,2W,AG,TP,3.9x12mm 3 Q909 0505-000109 FET-SILICON;2N7000,N,60V,200mA,5ohm,400 3 Q910 0505-000109 FET-SILICON;2N7000,N,60V,200mA,5ohm,400 3 IC904 1203-001943 IC-VOL.DETECTOR;7025,T0-92,3P,PLASTIC 3 R436 2003-002151 R-METALOXIDE;18KOHM,5%,2W,AG,TP,6X16 3 R401 2003-002186 R-METALOXIDE(S);22Kohm,5%,2W,AG,TP,3x 3 R402 2003-002186 R-METALOXIDE(S);22Kohm,5%,2W,AG,TP,3x 3 R835 2003-002211 R-METALOXIDE(S)91Kohm,5%,2W,AG,TP,3x 3 R836 2003-002211 R-METALOXIDE(S)91Kohm,5%,2W,AG,TP,3x 3 R433 2008-001127 R-FUSIBLE(S);6.8Kohm,5%,1W,AF,TP,3.9x10m 3 C656 2201-000304 C-CERAMIC,DISC0.001nF,0.25pF,50V,NP0,TP 3 C657 2201-000304 C-CERAMIC,DISC0.001nF,0.25pF,50V,NP0,TP 3 CW901 2503-000156 C-NETWORK;100pFx4,20&,50V 3 L102 2701-000159 INDUCTORAXIAL;22uH,10%,4.2x9.8mm 3 L207 2701-000168 INDUCTORAXIAL;3.3uH,5%,2.5x3.4mm 3 J699 2701-000168 INDUCTORAXIAL;3.3uH,5%,2.5x3.4mm

3 L208 2701-000168 INDUCTORAXIAL;3.3uH,5%,2.5x3.4mm 3 L209 2701-000168 INDUCTORAXIAL;3.3uH,5%,2.5x3.4mm 3 L604 2701-000168 INDUCTORAXIAL;3.3uH,5%,2.5x3.4mm 3 X201 2801-003432 CRYSTAL-UNIT;20.25MHZ,30PPM,28-AAM,13P 3 X901 2801-003728 CRYSTAL-UNIT;6MHz,30ppm,28AAM,20pf,40oh 3 X601 2801-003903 CRYSTAL-UNIT18.432MHz,25ppm,28AAM,12 3 DZ501 0403-001325 DIODE-ZENER;MTZJ15C,14.35-15.09V,500mW,D 3 R223 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP, 3 R224 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP, 3 R225 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP, 3 R226 2001-000003 R-CARBON;330OHM,5%,1/8W,AA,TP, 3 R241 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP, 3 R315 2004-004970 R-METAL(S);62Kohm,1%,1/8W,AA,TP,1.8x3.2m 3 R414 2001-001165 R-CARBON(S);56OHM,5%,1/2W,AB,T 3 D801 0402-001111 DIODE-RECTIFIER;1N5397GP,600V,1.5A,DO-20 3 L905 2001-000995 R-CARBON;820OHM,5%,1/8W,AA,TP, 3 C248 2401-002619 C-AL;47uF,20%,25V,GP,TP,5x11,5 3 C305 2305-000149 C-FILM;CF922N100VT104-J-40/105 3 R212 2004-000218 R-METAL;10KOHM,1%,1/8,1.8X3.2M 3 R501 2001-000904 R-CARBON;620OHM,5%,1/8W,AA,TP,1.8X3.2MM 3 R502 2001-000904 R-CARBON;620OHM,5%,1/8W,AA,TP,1.8X3.2MM 3 R503 2001-000904 R-CARBON;620OHM,5%,1/8W,AA,TP,1.8X3.2MM 3 R504 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP 3 R505 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP 3 R506 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP 3 D403 0402-001321 DIODE-RECTIFIER;1A4G,400,1A,R-1,TP 3 D406 0402-001321 DIODE-RECTIFIER;1A4G,400,1A,R-1,TP 3 D504 0402-001321 DIODE-RECTIFIER;1A4G,400,1A,R-1,TP 3 D808 0402-001321 DIODE-RECTIFIER;1A4G,400,1A,R-1,TP 3 D810 0402-001321 DIODE-RECTIFIER;1A4G,400,1A,R-1,TP 3 D811 0402-001321 DIODE-RECTIFIER;1A4G,400,1A,R-1,TP 3 D907 0402-001321 DIODE-RECTIFIER;1A4G,400,1A,R-1,TP 3 R210 2001-000812 R-CARBON;5.6Kohm,5%,1/8W,AA,TP,1.8x3.2mm 3 C205 2201-000504 C-CERAMIC,DISC;39PF,5%,50V,SL,-,5MM,TP 3 C912 2202-000719 C-CERAMIC,MLC-AXIAL;6.8nF,20%,16V,Y5R,TP 3 DZ202 0403-001321 DIODE-ZENER;MTZJ6.8C,6.66-7.01V,500mW,DO 3 DZ301 0403-001328 DIODE-ZENER;MTZJ22A,20.15-21.20V,500mW,D 3 J706 2701-000142 INDUCTOR-AXIAL;1UH,10%,2.5X3.4 3 J705 2701-000142 INDUCTOR-AXIAL;1UH,10%,2.5X3.4 3 J707 2701-000142 INDUCTOR-AXIAL;1UH,10%,2.5X3.4 3 J713 2701-000142 INDUCTOR-AXIAL;1UH,10%,2.5X3.4 3 R713 2701-000142 INDUCTOR-AXIAL;1UH,10%,2.5X3.4 3 R507 2001-001065 R-CARBON(S);110KOHM,5%,1/2W,AA 3 R510 2001-001065 R-CARBON(S);110KOHM,5%,1/2W,AA 3 R513 2001-001065 R-CARBON(S);110KOHM,5%,1/2W,AA 3 R527 2001-001077 R-CARBON(S);150OHM,5%,1/2W,AA, 3 R621 2001-000605 R-CARBON;3.6KOHM,5%,1/8W,AA,TP 3 R622 2001-000605 R-CARBON;3.6KOHM,5%,1/8W,AA,TP 3 DZ509 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D 3 C218 2202-002037 C-CERAMIC,MLC-AXIAL;100NF,+80-20 3 C219 2202-002037 C-CERAMIC,MLC-AXIAL;100NF,+80-20 3 C220 2202-002037 C-CERAMIC,MLC-AXIAL;100NF,+80-20 3 C221 2202-002037 C-CERAMIC,MLC-AXIAL;100NF,+80-20 3 C222 2202-002037 C-CERAMIC,MLC-AXIAL;100NF,+80-20 3 C223 2202-002037 C-CERAMIC,MLC-AXIAL;100NF,+80-20 3 C232 2202-002037 C-CERAMIC,MLC-AXIAL;100NF,+80-20 3 C901 2202-002037 C-CERAMIC,MLC-AXIAL;100NF,+80-20 3 C921 2202-002037 C-CERAMIC,MLC-AXIAL;100NF,+80-20 3 C960 2202-002037 C-CERAMIC,MLC-AXIAL;100NF,+80-20 3 C206 2202-002037 C-CERAMIC,MLC-AXIAL;100NF,+80-20 3 C226 2202-002037 C-CERAMIC,MLC-AXIAL;100NF,+80-20 3 L401 3301-001223 CORE-FERRITE BEAD;AB,-,3.5X5X0.8MM,-,TP, 3 R522 2008-001029 R-FUSIBLE(S);5.6OHM,5%,2W,AF,T 3 C811 2301-000254 C-FILM,PEF;39NF,5%,50V,7.5X3.5X6.5MM,5MM 3 L902 2701-000183 INDUCTOR-AXIAL;39uH,5%,2.4x3.4mm 2 PWR/AC AA96-20109A ASSY-POWER,CORD;-,CP2/NO(4.0),H/C400,KKP 2 A/SUBM AA97-01633A ASSY-SUB MATERIAL;SOLVENTES Y SOLDADURAS 3 0204-000442 SOLVENT;CH3-CH5H-CH396%IM-1000 3 0202-000008 SOLDER-WIRE;S63S-D3.0,S63A,D3,63/37 3 0204-001024 FLUX;DF-96TVS,-,20%,3 0202-000187 SOLDER-WIREFLUX;-,RS60S,D1.2,6 2 CR401S 2303-001015 C-FILM,PPFF;5.5NF,5%,1.6KV,TP, 2 IC902 1103-001211 IC-EEPROM;24C16-PC27 C,2048x8Bit,DIP,8P, 2 NT802S 1404-001045 THERMISTOR NTC;4.7OHM,15%,2900K,35.0MW,T 2 C815 2401-003602 C-AL;220uF,20%,160V,GP,BK,22x25mm,1 2 GT101 AA39-20010B LEAD-CONNECTOR,ASSY;-,YFH800-01,500MM,1P 2 IC804 AA96-00243C ASSY H/S;-,REGULATOR,AA62-00045A,KA7806

Electrical Parts List

7-20 Samsung Electronics

Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark

3 0205-000129 GREASE-SILICON;SC102,JAPAN 3 6003-000335 SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR 3 AA62-00045A HEAT SINK-PS;-,-,T1.0,-,-,DREAM,-,-,-,-, 3 1203-000284 IC-POSI.FIXEDREG.;7806,TO-220, 2 DH01 AA96-00275A ASSY H/S;-,COMPLEX,AA62-00051A,KSD5703, 3 0205-000129 GREASE-SILICON;SC102,JAPAN 3 6003-000335 SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR 3 AA60-30001A WASHER-PLATE;-,M3,ID3.5,15X8.5,T1.0,-,SB 3 AA62-00051A HEAT SINK-PS;-,-,-,SILVER,HOLE 31mm,ALL, 3 0402-001296 DIODE-RECTIFIER;FMP-3FU,1500V,5A,T0-3PF 3 0502-001136 TR-POWER;KSD5703,NPN,70W,TO-3PF,ST,82 D813 0402-000233 DIODE-RECTIFIER;FML-G12S,200V, 2 D801S 0402-001160 DIODE-BRIDGE;D5SB60,600V,2.8A,SIP-4,ST 2 LX801S AA29-30002F FILTER-LINENOISE;-,6MH,2.45A,2 IC602 AA96-50398A ASSY-H/S;-,-,AA62-30182E,TDA7297,3 0205-000129 GREASE-SILICON;SC102,JAPAN 3 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW 3 AA62-30182E HEAT-SINK,ES;-,A6063 EXTR,-,WHT,-,-,-,40 3 1201-001064 IC-POWERAMP;7297,ZIP,15P,-,DUA 2 CY802S 2201-000446 C-CERAMIC,AC;CK45PE400V332-M(T 2 L808 AA27-00098A COIL CHOKE;-,-,24uH,10%,-,0.1,3.0A,DR10X 2 DDR01 AA96-00469F ASSY H/S;-,REGULATOR,AA62-00053B,D10U60 3 0205-000129 GREASE-SILICON;SC102,JAPAN 3 0402-001358 DIODE-RECTIFIER;SDS10U60S,600V,10A,TO-22 3 0402-001375 DIODE-RECTIFIER;FFPF10U20S,200V,10A,TO-2 3 6003-000334 SCREW-TAPTITE;RH,+,2S,M3,L6,ZP 3 1203-001006 IC-VOLTAGEREGULATOR78R05,TO-220F,4P 3 AA62-00053B HEAT SINK;DREAM (D2,D3),AL ,T1.0,147,50, 2 IC803 1203-002085 IC-VOLTAGEREGULATOR;78R08,TO-220,4P 2 IC903 1203-001944 IC-POSI.FIXEDREG.78RM33,TO-220,3P,PLAST 2 IC202 1203-001944 IC-POSI.FIXEDREG.78RM33,TO-220,3P,PLAST 2 IC201S 1204-001812 IC-VIDEO PROCESS;VDP3130Y-B2,DIP,64P,760 2 C407 2301-001338 C-FILM,MPE,PPF0.68nF,5%,1.6kV,TP,28x7x1 2 CN602 3711-002644 POST-HEADER;67094-005(AUTO) 2 CN701 3711-002647 POST-HEADER;67094-008(AUTO) 2 CR403S 2301-001259 C-FILM,MPPF;100nF,5%,400V,TP,19x8x16,7.5 2 L/PQS AA68-01018A LABEL-PQS,-,50mmX,13,-,WHITE,2 IC601 1204-001594 IC-SOUND PROCESSOR;MSP3440G-B6,SDIP,52P, 2 P801S 1404-000002 THERMISTOR;NTC,90HM,20%,TR,AC290VRMS,120 2 HOL-PC AA61-00686B HOLDER-COVER;ALL MODEL,NYLON-66,T1.0 2 Q402 0502-001007 TR-POWER;KSC2073-H2,NPN,150V,1 2 GT407 AA39-20010D LEAD-CONNECTOR,ASSY;-,YFH800-01,S,1P,400 2 CN601 3711-003043 CONNECTOR-HEADER;BOX,4P,1R,2.5mm,STRAIGH 2 CR405S 2306-000195 C-FILM,MPPF;360NF,5%,400V,26.0 2 JA702 3722-001423 JACK-RCA;3P+S1P,3.4mm,NI,BLK,2 T801S AA26-00046C TRANS SWITCHING;,CS29A6HP,80-260V,PM5/PL 2 T444S AA26-00125A TRANS FBT;FUH29A002M(S),CT29D4,3.2MH,130 2 LR401S AA27-00170A COIL LINEARITY;43UH,43UH,L-81 OWA 12X15 2 CR404S AA27-00171A COIL HORIZ. WIDTH;18UH,18UH,YL-81 DR 14X

ASSY-VIDEO S/W

1 A/VS AA97-00726A ASSY-VIDEO S/W;-,CS7202GT7C/EGC,KS2A,-,-

2 ICS01 1001-001114 IC-VIDEO SWITCH;TEA6425,VIDEO SWITCH ,DI 2 CNS01 3711-002704 PINHEADER;YFAW-025-106(6PIN2.5MM)15.0X 2 CNS02 3711-002706 PIN-HEADER;YFAW025-108(8PIN2.5M/M)20.0 2 QS01 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 2 QS02 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 2 QS03 0501-000389 TRANSISTOR;KSC815-Y(TAPG)/YTAM 2 RS01 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP, 2 RS03 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 2 RS05 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 2 RS07 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 2 RS10 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 2 RS11 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm 2 RS02 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 2 RS04 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 2 RS06 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP 2 CS01 2305-000412 C-FILM,MPEF;470NF,5%,63V,-,5MM 2 CS02 2305-000412 C-FILM,MPEF;470NF,5%,63V,-,5MM 2 CS03 2305-000412 C-FILM,MPEF;470NF,5%,63V,-,5MM 2 CS04 2305-000412 C-FILM,MPEF;470NF,5%,63V,-,5MM 2 CS05 2305-000412 C-FILM,MPEF;470NF,5%,63V,-,5MM 2 CS06 2305-000412 C-FILM,MPEF;470NF,5%,63V,-,5MM

2 CS08 2305-000665 C-FILM;104J, 60V,5MM TAPING 2 CS07 2401-002009 C-AL;100UF,20%,16V,GP,TP,6.3X7 2 LS01 2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3. 2 JS01 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 2 JS02 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 2 JS03 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 2 JS04 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 2 RS08 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 2 RS09 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 2 04VER AA41-00153E PCB-VIDEO SWITCH;CS29A6,FR-1,1L,E,1.6T,2 2 DZS01 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 2 DZS02 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 2 H001 AA98-00126A ASSY PCB(P);VIDEO,S/W,KS2A/KS3A

ASSY-PCB,A/V

1 A/A-V AA98-00084A ASSY-PCB,A/V;SIDE,CL29D4,KS2A,

2 JA01 3722-001031 JACK-RCA;3P,3.6MM,#18,AU 2 JE01 3722-000143 JACK-PHONE;1P,3.4MM,-,MBAG 2 CN05A AA39-20069A LEAD-CONNECTOR,ASSY;-,YBNH0252 CA06 2401-001840 C-AL;100UF,20%,16V,GP,TP,6.3X1 2 CA07 2401-001840 C-AL;100UF,20%,16V,GP,TP,6.3X1 2 00VER AA41-00322A PCB-AV SIDE;CL29D4,FR-1,1L,A,1.6T,245x24 2 CRTPCB AA63-10002A BAND-TIE;-,NYLON66V2,-,-,L100,NTR,-,2 A/AV AA95-00762A ASSY-PCB,A/V;SIDE,KS2A,CL29D4 2 JA101 3812-000219 WIRE-SO,COPPER;TA0.6SN/52M/M(A 2 RA01 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AB, 2 RA02 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AB, 2 CN01A AA39-20068E LEAD CONNECTOR-ASSY;-,YBNH025-08,67096-0

ASSY-CABINET,FRONT

1 A/FRNT AA92-00750A ASSY-CABINET,FRONT;29C1,SV907P,HIPS,HB

2 D-COIL AA27-20003E DEGAUSSINGCOIL;29F/V,L3000,60 2 F/C AA64-01625A CABINET FRONT;29C1,SV907P,HIPS,HB,G4309 3 SPRING AA61-60003J SPRING-CS;-,-,SUS304,0.5,OD6,H 3 KC AA64-01630A KNOB CONTROL;29C1,ABS HB G3676,SV907P+W9 3 KP AA64-01627A KNOB POWER;29C1,ABS HB G3676,SV907P+W971 3 IL AA64-01629A INDICATOR LED;29C1,ACRYL HB CLR 3 WR AA64-01628A WINDOW REMOCON;29C1,PC V0 VIOLET 3 KC+CF 6002-000514 SCREW-TAPPING;RH,+,2,M4,L15,ZP 3 WIN+CF 6002-000514 SCREW-TAPPING;RH,+,2,M4,L15,ZP 2 SPK+CF 6002-000514 SCREW-TAPPING;RH,+,2,M4,L15,ZP 2 CRT+CF AA60-10050V SCREW-ASSY;WC,HH,+,M6,L30,SWRCH18A,ZPC(S 2 DRESPK AA65-30018A CLAMP-WIRE;-,NYLON6.6,-,-,DATL 2 A/SPK AA96-00615A ASSY SPEAKER;,10W,8OHM,3001-001005,30013 SPK 3001-001088 SPEAKER;5W,8ohm,90dB,250Hz+-50Hz 3 L/SPK AA39-00122A LEAD CONNECTOR-ASSY;,4P/4.7UF,35155-0400 3 SPK 3001-001005 SPEAKER,10W,8ohm,90db,150Hz 2 CDCOIL AA65-30113A CLAMP-D,COIL;NYLON66,V2,BLK,TVI25~29,2 AV+CF 6002-000522 SCREW-TAPPING;TH,+,2,M4,L15,ZP 2 IN/AV AA64-60448W INLAY AV;S51A,3P EPG,PS SHEET,T0.3,BLK, 2 BADGE AA64-70117B BADGE-BRAND;AL,SS,R2000,25,SILVER CT-633 2 L/QMS AA68-01554A LABEL;QMS,UARCOWHITEPAPER#1343 2 STOPPE AA61-40113A STOPPER-PCB;-,ABS,HB,NTR. 2 CWFC AA65-00011C CLAMP-WIRE;ALL MODEL,NYLON 66,V2,NTR,25M 2 CRT AA60-00038A SPACER-CRT;PS,SHEET,T1.0,BLK,OD22,ID10.

ASSY CABINET(COM)

1 A/BACK AA92-00800A ASSY CABINET(COM);KS2A,CL29C1W7X,LATIN

2 CB+RCA 6002-000514 SCREW-TAPPING;RH,+,2,M4,L15,ZP 2 CB+CF 6002-000514 SCREW-TAPPING;RH,+,2,M4,L15,ZP 2 SPCBC AA63-60001X SPACER-FELT;FELT,T0.5,330X15MM 2 INLAYB AA64-00892G INLAY BACK;D2,D3,RCA9P+S-VHS+DVD,PS SHEE 2 AC+BC AA65-30008A CLAMP-CORD;-,PE,HB,BLK,-,2 C/SET AA69-00872A CUSHION SET;TOOL,29C1,-,-,-,-,-,-,-,CAST 2 PE-BAG AA69-01209A BAG;SHEET,25-27,W54,L60,FOAM,OEM. 2 STAPLE AA60-40006A PIN-STAPLE;-,-,-,H18,33X17.8X2

Electrical Parts List

Samsung Electronics 7-21

Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark

2 AC-TAP 0203-001279 TAPE-OPP MASKING;#232,T0.14,W15,L50000,Y 2 TAPE-D 0203-001279 TAPE-OPP MASKING;#232,T0.14,W15,L50000,Y 2 L/BOX AA68-01542A LABEL;(UNIBOX),PAPER WHT ALLMD 2 BXTAPE 0203-001295 TAPE-OPP MASKING;1242,T0.06,W100,L91.4M, 2 FBT AA65-30018A CLAMP-WIRE;-,NYLON6.6,-,-,DATL 2 H/S+CW AA65-30018A CLAMP-WIRE;-,NYLON6.6,-,-,DATL 2 DRESB AA65-30018A CLAMP-WIRE;-,NYLON6.6,-,-,DATL 2 L/RAT AA68-01547A LABEL RATING;TETRONEPAPER90(S)B,LATIN 2 H/T AA61-00356B HOLDER-TUNER,F/JACK;-,501F,ABS,HB,BLK,2 B/C AA64-01626A CABINET BACK;29C1,HIPS HB,BLK 2 C/HS AA65-30105B CLAMP-WIRE;NYLON 66,V2,NTR,25MM,ALL MODE 2 PCK AA69-00915B PACKING CASE;29C1,CB D-2,A1,YEL,SMAEX

ASSY-CRT

1 A/CRTP AA97-01252A ASSY-CRT;A68AJB82X03,-0mg,1.3MH,PHILLIPS

2 CRT AA03-00289A CRT COLOR;A68AJB82X03,0MG,1.31MH,18.0MH, 2 DY AA27-00156A DEFLECTION-YOKE;AT6027,PHILLIPS,27V,29 2 TAPE 0203-000432 TAPE-ACETATE;ACETATET0.25W19WH 2 CY AA27-00002A MAGNET-CONVERGENCE;JH291-SC-OB,29.1M 2 SPACER AA63-60028A SPACER-DY;-,NEOPRENE,-,BLK,V0W

ASSY-TBC,WIRE(P)

1 A/TBC AA98-70008C ASSY-TBC,WIRE(P);-,TVI 29’,NTSC,2P-WH,-

ASSY ACCESSORY

1 A/ACCE AA97-01187A ASSY ACCESSORY;KS2A,CL29C1W7X,SELA

2 PLUG 3721-000136 PLUG-CONVERSION;15A300VPI4.0CP 2 W/BOOK AA68-00987A CARD WARRANTY;-,-,W/P100,-,-,-,-,-,A4,1P 2 BAG-PE AA69-01195A BAG PE;CL29A6W8X,HDPET0.012,93/4X151 2 I/B AA68-02140A MANUAL USERS;SPA,W/P100(G),B5,52P,KS2A 2 I/B2 AA68-02139A MANUAL USERS;ENG,W/P100(G),B5,52P,KS2A

REMOCON

1 RMT AA59-10113H REMOCON;DP,TM59,-,-,-,-,-,AA59-10110H,

Electrical Parts List

7-22 Samsung Electronics

Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark

8. Block Diagrams

Samsung Electronics

Schematic Diagrams

8-1

8-1 Power Diagram

8-2 Block Diagram

Schematic Diagrams

8-2 Samsung Electronics

9. Wiring Diagram

Wiring Diagram

Samsung Electronics 9-1

CN06A

CN05A

TO SPEAKER

VO G VI G LO RO LI RI

FRONT AV PCB

CN01A

GT804

CN501A

B Out

G Out

R Out

Sense

GND

Heater

CN602

GND

+16V

180V

CN501B

CN502B

CN701

CN502A

+16V

Heat NC

180 220V

GT102

9-2 Samsung Electronics

MEMO

TP09

TP07

TP08

TP01

TP02

TP05

TP03

TP06

TP04

10. Schematic Diagrams

Samsung Electronics

Schematic Diagrams

10-1

10-1 MAIN 1/4 (WITH EW)

TP07

TP08

TP09

TP01

TP02

TP03

TP04

TP05

TP06

: Power Line

: Signal Line

10-2 MAIN 2/4

Schematic Diagrams

10-2 Samsung Electronics

TP10

TP11

TP12

TP13

TP14

TP11

TP12

TP10

TP13

TP14

: Power Line

: Signal Line

10-3 MAIN 3/4

Samsung Electronics

Schematic Diagrams

10-3

TP21

TP22

TP23

TP15

TP16

TP17

TP18

TP19

TP20

TP24

TP16

TP15

TP17

TP22

TP21

TP20

TP18

TP19

TP23

TP24

: Power Line

: Signal Line

10-4 MAIN 4/4

Schematic Diagrams

10-4 Samsung Electronics

TP31

TP32

TP33

TP34

TP25

TP26

TP27

TP28

TP29

TP30

TP25

TP26

TP27

TP31

TP32

TP33

TP28

TP30

TP29

: Power Line

: Signal Line

SAMSUNG CT15K8W6X-XAP, CL25K4W7X-XAX, CL29C1W7FX-XAP, MR29410X-TCE Service Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
