LASER PRINTER

ML- 7000 Series

User ’s Guide

ELECTRONICS

Printed in Korea

P/N: JC68-61021A Rev. 3.00

CCooppyyrriigghhtt

The software described in this document is supplied under a license agreement. The software may be used or copied only in accordance with the terms of this agreement. It is against the law to copy the software on any medium except as specifically allowed in the license agreement. The purchaser may make only one copy of the software for backup purposes.

No part of this manual may be photocopied or transmitted in any from or by any means, electronic or mechanical including photocopying, recording or information storage and retrieval systems, for any purpose other than the purchaserÕs personal use, without the expressly written consent of Samsung Electronics Co., Ltd.

Information in this document is subject to change without notice and does not represent a commitment on the part of Samsung Electronics Co., Ltd. Samsung Electronics Co., Ltd. or its distributors can in no circumstances be held responsible for any prejudice, whether direct or indirect, resulting from the use of the software or the documentation.

July 1998

TTrraaddeemmaarrkk NNoottiicceess

◆ All other brand or product names are trademarks or registered trademarks of their

respective companies or organizations.

◆ ML-7000 series and Samsung logo are trademarks of Samsung Electronics Co., Ltd.

◆ Centronics is a registered trademark of Centronics Data Computer Corporation.

◆ HP, PCL5e, PCLXL are registered trademarks of Hewlett-Packard Company.

◆ IBM, IBM PC, XT, AT, PS/2 are registered trademarks of International Business

Machines Corporation.

◆ Apple, AppleTalk, LocalTalk, LaserWriter, TrueType, Macintosh are registered trademarks

of Apple Computer Inc.

◆ Microsoft, MS-windows, MS-DOS are registered trademarks of Microsoft Corporation.

◆ CompuServe is a registered trademark of CompuServe inc.

◆ TrueDoc

◆ Font Navigator

◆ PostScript is a registered trademark of Adobe Systems Inc.

◆ PowerPage

is a registered trademark of Bitstream Inc.

is a registered trademark of Electronics for Imaging, Inc.

CCoonntteennttss

Safety Precautions Features and Model Descriptions

Getting Started

Setting up Your Printer

Unpacking Your Printer

Items Supplied Front View Rear View

Preparation Installing Toner Cartridge Connecting the Parallel Cable

Cable Specifications

Connecting the Parallel Cable Connecting the AC Power Cord Loading Paper into the Cassette Loading Paper into the MP Tray Testing the Printer

6 7

9 10 10

11 12 14 14 14 16 17 20 22

Contents

Setting up the Printer Driver

Overview Installing the Driver

Hardware Requirements Software Requirements Install Procedure

- With Windows 95/98/NT 4.0

- In case of Plug & Play

- With Windows 3.1

Uninstalling the Printer Driver

Selecting the Printer

Default Printer

Selection Loading the Smart Monitor Font Navigator Directory (FontNav)

23 24 24 24 24 25 27 28 28 29 29 29 29 30

Operation

Using Your Printer

Overview Using Features in the Printer Driver

With Windows 95/98/NT 4.0 With Windows 3.1

Using the Samsung 7000 Series Printer Driver

Paper Tab Graphics Tab Finishing Tab Printer Tab Overlays Tab Watermarks Tab

Using the Operator Panel

Operator Panel Buttons

Operator Panel Menus Changing Printer Settings Overview of Printer Menu PRINTING MENU CONFIG MENU

JOB MENU TEST MENU I/O MENU PCL MENU Printing Both Sides of Paper

Procedure Menu Setting Procedure

Paper Orientation for Printing both sides of Paper Manually Feeding Paper from MP Tray Printing Special Paper

Letterhead/Prepunched Paper

Envelopes

Label

Transparencies

32 33 33 34 35 35 36 37 38 39 40 41 42 42 43 44 45 49 52 55 55 56 58 58 59 60 61 62 62 63 65 66

Contents

Troubleshooting

Caring for Your Printer

Problem Solving

Overview Maintaining the Toner Cartridge

Toner Cartridge Storage Toner Cartridge Life Distributing the Toner

Cleaning the Printer

Procedure Cleaning LSU

Problem Solving

Overview Clearing Paper Jams Error Messages General Printing Problems Poor Print Quality PS Problems

68 69 69 69 69 72 72 74

75 76 80 83 84 85

Contents

Options

Memory and Option Cards

Overview Preparations

- Understanding the Printer Control Board

- Closing the Printer Cover Printer Memory

- Installing Procedure

- Removing the Printer Memory Option Network Option Card(PortThru)

- Installing Procedure

87 88 89 90 92 92 95 96 96

Options

Memory and Option Cards

Printing a document Using PS option in PC

- Adding more Memory

- Installing PS SIMM

- Installing PS Driver

- Selecting the Default Printer Printing a document using PS option in Macintosh

- Adding more Memory

- Installing PS SIMM

- Installing Serial/LocalTalk Option Card

- Connecting the LocalTalk Cable

- Installing the PS Driver

Infrared Adapter

Overview Installing procedure Printing Procedure

Optional Cassette

Overview Installing Procedure Loading the Plain Paper into the Option Cassette Paper Source Selection

99 99

99 100 105 107 107 107 108

110 110

112 113 114

115 116 117

121

Technical Specifications

Appendix

Technical Specifications

Paper Specifications

Supported Types of Paper Guidelines for Using Paper

Printer Specifications

Notices

124 125 125

126

129 134

Contents

SSaaffeettyy PPrreeccaauuttiioonnss

Before using the printer, please read the instructions in this guide carefully and put the guide in a safe place close to the printer, so that it is available when you need it later. Please take the following precautions when using and maintaining your printer.

●

Unplug the printer before cleaning it. Do Not use any liquid or aerosol cleaners.

Simply use a damp cloth. Refer to the page of this guide for further details.

●

Do Not place the printer on an unstable surface or close to a radiator or source

of heat.

●

Take care not to block or cover the ventilation holes on the side of the printer.

Do Not insert any object in these holes.

●

Check that the electrical power source to which you wish to connect the

complies with the electrical specifications of this printer : (230V)

●

Connect all your computer equipment, including the printer to a power point with

earthing device. Avoid plugging your printer into the same power point as equipment likely to cause voltage variations, such as a photocopying machine or an air conditioner.

●

Check regularly that the power cable is in good condition and is not damaged

in any way.

printer

●

Safety Precautions

If you use an extension cord, check that total intensity of all equipment connected

to it does not exceed the maximum intensity allowed for the extention cord. Check that the total intensity of the equipment connected to the same power point does not exceed 15 amps.

Unless otherwise indicated in this guide, do not attempt to repair the printer yourself.

Should you detect a fault, return your printer to an authorized service center or your dealer.

Systematically return your printer to an authorised service center or your local dealer

if one of the following situations occurs :

- The power cord or plug is damaged

- A liquid has been spilled on and/or in the printer.

- T

he printer has fallen or been dropped or the bodywork is damaged in any way.

- The printer is not operating correctly or you have noticed a significant drop in the quality of the printing.

FFeeaattuurreess aanndd MMooddeell DDeessccrriippttiioonnss

Your New Printer

Your new Laser Printer is designed for use in an office environment, providing such advantages as :

●

Printing both sides of paper

●

High-quality, high-speed text and graphics printing

●

Vast choice of paper types and sizes

●

Full operating status and error messages on operator panel display

●

On-screen feedback of the printing status

●

Various printer menus

Printer Information

ML-7000

●

The ML-7000 comes standard with 4MB RAM and

one 500-sheet cassette.

ML-7000P

●

The ML-7000P comes standard with 12MB RAM, PS SIMM

for printing by PS driver and one 500-sheet cassette.

ML-7000N

●

The ML-7000N comes standard with network card(PortThru).

Install the network printer driver(SyncThru) for network printing.

Main Features

This Laser Printer provides the following main features.

●

Built in Duplex function which printing both sides of paper

●

Printing speeds of 16PPM(Pages Per Minutes) for A4-size paper

●

High-quality printing at a maximum resolution of 600 DPI

●

Automatic paper feed with a capacity of up to 500 sheets

●

Wide range of paper sizes and weights

●

Expandable design

- 500-sheet universal paper cassette

- Memory(up to 68 MB)

- Connectors for optional RS-232C/LocalTalk Card and Network Interface Card

- Connector for optional Infrared Adapter

Features and Model Descriptions

Getting Started

SSeettttiinngg UUpp yyoouurr PPrriinntteerr

Unpacking Your Printer

Items Supplied

When you start unpacking the box of your printer, you will find the following items in addition to your printer

Toner cartridge

Power cord

●

If you find that any of the above items are missing or damaged, contact

your local dealer.

●

A printer cable is not included in the package items.

●

Cable specifications

- The parallel cable should be compatible with the centronics parallel interface and IEEE standard 1284.

CD-ROM Disk

This manual

Setting Up your Printer

Front View

The following illustration shows the front view of your printer and indicates the various main elements.

Print prevention sensor

Top output bin

MP tray

(100-sheet,

with extension)

(It prevents the printer

from printing when 250 sheets of paper are piled up on the top output bin.)

Operator panel

Power switch

Cassette

(500-sheet, closed)

Paper level indicator

Top cover

LSU cleaner

(When the top

cover is opened)

Rear View

The following illustration shows the rear view of your printer and indicates the various main elements.

Rear cover Parallel interface

connector

Setting Up your Printer

Power connector

Preparation

During the storage and transport of your printer, adhesive tape is used to block some of the elements that may move or open unexpectedly and consequently be damaged.

1. Before connecting up your printer and starting to use it, you must

1. therefore remove all the adhesive tapes, as illustrated in the figure

1. below.

2. Slide cassette out of the printer.

1. Remove the packaging material from the cassette.

Setting Up your Printer

Installing Toner Cartridge

To install a toner cartridge in your printer proceed as follows.

1. Remove the toner cartridge from its packaging.

●

Do not remove the cartridge from its packaging until you are

ready to use it.

●

Do not expose the cartridge to light, it could damage the cartridge

permanently.

2. Open the top cover of the printer by pressing the button on right side of the printer.

Setting Up your Printer

3. Rotate the cartridge and gently shake it from side to side to distribute the toner evenly inside the cartridge.

4. Position the cartridge as shown with the arrow pointing into the printer. Slide the cartridge into the printer as far as it will go.

5. Close the top cover.

●

If toner gets on your clothing, wipe it off with a dry cloth and

wash clothing in cold water.

●

When printing text at 5% coverage, a toner cartridge lasts an average of 8000pages in simplex mode.

Setting Up your Printer

Connecting the Parallel Cable

To print from computer software, you need to connect your printer to your computer with a parallel interface cable.

Cable Specifications (Not provided)

The parallel cable should be compatible with the CentronicsRparallel interface and IEEE standard 1284. If you purchase parallel cable, ensure that it :

●

Is compatible with Centronics interface.

●

Supports bi-directional communications(IEEE standard 1284)

●

Is shielded

●

Has the appropriate connector :

- 25 pin D-Sub connector on the computer side

- Amphenol 36 connector on the printer side

Connecting the Parallel Cable

To connect the printer to your computer use a parallel cable and proceed as follows.

1. Check that both the printer and the computer to which it is to be connected are powered off and disconnected from the power point.

2. Plug the appropriate end of the parallel cable into the connector on the rear of the printer.

Setting Up your Printer

3. Push the clip at each end of the connector down into the notches on

MIDI/GAME PHONE LINE

LINE OUT

LINE IN

the plug as shown.

4. Plug the other end of the cable into the appropriate parallel connector on your computer and tighten the screw.

Setting Up your Printer

Connecting the AC Power Cord

To connect the printer to a power point, proceed as follows.

1. Plug the appropriate end of the power cable supplied to the connector on the rear of the printer.

2. Plug the other end into a suitable power point 230V(220~240).

3. Power the printer on by pressing the power on/off button.

RReessuulltt

You will hear some movement inside the printer. The printer enters the Ready state.

Setting Up your Printer

Loading Paper into the Cassette

Your printer has a standard Cassette that can hold up to 500 sheets of paper and a MP(Multi-Purpose) tray that can hold up to 100 sheets of paper, 10 envelopes or 10 index cards.

Cassette

To load paper in the cassette, proceed as follows.

1. Pull the cassette completely out of the printer.

2. Squeeze the back of the rear paper guide and slide it to the desired paper size until it clicks into place. The paper sizes are indicated on the bottom of the cassette.

Rear paper guide

Setting Up your Printer

3. Lift the rear right guide and slide it to match the width of the paper. The paper sizes are indicated on the bottom of the cassette.

4. Squeeze the width guide, rear right guide and slide it to the far right side of the cassette.

Width guide

Rear right guide

If the cassette is not properly adjusted, the printer might display an error message or paper might jam.

5. Place the paper against the left of the rear paper guide.

Paper Limit Line

Printing side(down)

●

Do not fold or crease the paper.

●

Place the paper with the recommended print side face down.

●

DonÕt exceed the paper limit line indicated on the cassette when

the paper is held up.

Setting Up your Printer

6. Squeeze the width guide and slide it to the left until it lightly rests against the edge of the paper.

7. Make sure the paper is set below the tab on the cassette.

8. Gently slide the cassette back into the printer. The printer automatically senses the size of paper

loaded if the cassette is adjusted correctly.

To load the paper of the Legal or Folio(24Ib,

90g/m lever on the left side of the cassette to lock it.

) size into the cassette, push down the

Setting Up your Printer

Loading Paper into the MP(Multi-Purpose) Tray

MP tray provides a convenient way to print envelopes, transparencies, or other type of media without having to unload the other tray.

To load paper in the MP tray, proceed as follows.

1. Pull the MP tray towards you.

2. Slide the length guide out toward you.

Setting Up your Printer

3. Flex the sheets back and forth to loosen them, then fan them.

Printing side(up)

●

Do not fold or crease the paper.

●

Place the paper with the recommended print side face up.

4. Place the paper against the side of the MP tray with the recommended print side face up and the top edge going in first toward the printer as shown.

5. Adjust the paper guide to the size of the paper inserted by pushing the guide.

Setting Up your Printer

Testing the Printer

0FFLNE

TEST

SELFTEST

Print a configuration page to make sure the printer is operating correctly.

1. Make sure the printer is plugged in and the READY status message appears on the display.

2. Press On Line.

RReessuulltt

3. Press Menu > or < Menu to enter the menus.

4. Press Menu > or < Menu one or more times until the TEST MENU message is displayed.

The OFFLINE message appears on the display and the printer is off-line.

5. Press Item> or <Item one or more times until the SELFTEST message is displayed.

6. Press Enter to print.

RReessuulltt

●

The message ÔPRINTING PCL6Õ appears and remains on

l the display until the page prints.

●

The printer returns to the Ready state after printing.

Setting Up your Printer

SSeettttiinngg UUpp tthhee PPrriinntteerr DDrriivveerr

Overview

The printer drivers provided on the CD must be installed to take full advantage of the printerÕs features. Printer drivers access the printer features and allow the computer to communicate with the printer.

Printer driver

If you install the printer driver using the CD, PCLXL and PCL5e are installed. The CD includes the printer drivers as follows.

●

PCL5e ●PCLXL

- You can use PCL5e driver in Windows 3.x/95/98 and Windows NT4.0.

In case of PCLXL, you can use only Windows 3.x/95/98 but it supports Watermark, Overlay, N-up printing and so forth.

●

PS(ML-7000P or if the PS option is installed)

●

Font Navigator

●

SyncThru(ML-7000N or if the network card is installed)

●

You cannot use PCLXL driver in Windows NT 4.0

●

You cannot use PS in Windows 3.1

●

PCL6 is the combination of PCL5e and the

new PCLXL printer language.

Setting Up your Printer

Installing the Driver

Hardware Requirements

To install and run the PCL printer driver, you must have the following minimum hardware configuration.

●

PC-compatible 486 microcomputer or better

●

8MB of RAM for Windows 3.1 and 3.11 (16MB recommended for some

applications) or 16MB for Windows 95/98, Windows NT 4.0

●

10MB available hard-disk space.

●

CD-ROM Drive

Software Requirements

To install and run the printer driver, you must have one of the following minimum software configuration :

●

Windows 3.1 or Windows for Workgroups (Windows 3.11)

●

Windows 95, Windows 98, Windows NT 4.0

●

Novell NetWare Version 3.x or 4.x (If the Network card is installed)

●

Above the Macintosh System 7.x (To print the document from

Macintosh)

Setting Up your Printer

Install Procedure

To install the printer driver on your hard disk, make backup copies of the print driver CD. Keep the original CD in a safe place and use the copies.

If you do not have access to a CD-ROM drive, contact your local dealer and request the printer driver diskettes.

Then, proceed as follows.

With Windows 95/98/NT 4.0 :

1. Insert the CD into the CD-ROM drive.

2. Type the user name and company. Click on the NEXT button.

3. Select the printer model which is connected to your computer(ML-7000 Series or QwikLaser 7000 Series). Click on the NEXT button.

4. Select the printer driver to install. Click on the NEXT button.

●

The installation of the printer driver is started.

Setting Up your Printer

5. Select the desired language, and then click on the NEXT button in the Font Navigator dialogue box.

If the printer driver is installed together with SyncThru, the SyncThru installation dialogue box is displayed.

6. Follow the instructions on the screen.

7. Select the directory to install Font Navigator. Click on the Finish button.

Setting Up your Printer

8. Click on the Yes button, when asked to restart windows.

RReessuulltt

Windows is restarted. The installation of the printer driver and Font Navigator is completed.

If windows does not run the CD-ROM

1. Insert the compact disk into the CD-ROM drive.

2. Select Start-Run from the windows task bar.

3. Type d:(or e:)\ Setup.exe on the command line, then click on the OK button.

4. Follow the instructions on the screen.

In case of Plug & Play

In case of Win 95

1. Make sure the printer is plugged and connected to your computer.

2. Turn on the printer and start Windows on your PC.

3. Windows recognizes the printer, and ÔNew Hardware FoundÕ dialogue box is displayed.

4. Click on the OK button.

5. Insert CD into the CD-ROM drive, and click on the Browse button.

6. Select the CD-ROM drive, then click on the OK button.

7. Follow step2 through 8 on page 25 to complete the installation.

In case of Win 98

1. Make sure the printer is plugged and connected to your computer.

2. Turn on the printer and start Windows on your PC.

3. Windows recognizes the printer, and ÔAdd New Hardware WizardÕ dialogue box is displayed.

4. Select search for the best driver for your device(Recommended), then click on the NEXT button.

5. Insert CD into the CD-ROM drive, then click on the Browse button.

6. Select the CD-ROM drive, then click on the OK button.

7. Follow step2 through 8 on page 25 to complete the installation.

To Install Shared Win 95/98 Printer Driver from NT Server to Client PC

1. Select Sharing in Properties of the printer driver.

2. Select Windows 95 in Alternate Drivers.

3. Type D:(or E:)\ PCLDRV\PCLXL\ENGLISH\WIN95_98\ML-7000

4. Install the network printer in the client PC.

Setting Up your Printer

With Windows 3.1 :

1. Make sure the printer is plugged and connected to your computer.

2. Turn on the computer.

3. Insert the compact disk into the CD-ROM drive.

4. From program manager window, select Run from the file menu.

RReessuulltt

The Run dialogue box appears.

5. Type d:(or e:)\ Setup.exe on the command line, then click on

the OK button.

6. From now on, follow the instructions on page 25 to complete

the installation.

Uninstalling the Printer Driver

An uninstall utility is supplied with the printer driver to enable you to remove the driver and all associated files from your hard disk, if so required.

Setting Up the Printer Driver

To uninstall the driver, proceed as follows.

Select Start-Programs-Samsung ML&QwikLaser 7000-Samsung 7000 Series uninstaller from the windows task bar.

●

PCLXL and PCL5e drivers are removed from your hard disk.

Selecting the Printer

Default Printer

After installing the printer driver Samsung 7000 Series PCLXL is selected automatically as the default printer.

If you did not select this Laser printer as the default printer when you installed it, you must select it before attempting to print a document on it.

Selection

To select the printer, proceed as follows.

1. Select Start-Settings-Printers from the Windows task bar.

2. Double click the desired printer drivers(PCL5e, PCLXL) icon.

3. Select File-Default Printer.

The printer driver PCLXL cannot use in Windows NT 4.0.

Loading the Smart Monitor

The Smart Monitor is a program which shows the current printer status.

To run the Smart monitor, select Smart Monitor from Samsung ML&QwikLaser 7000 folder. You cannot monitor the status of the printer which is connected by network.

Setting Up the Printer Driver

Font Navigator Directory(FontNav)

Font Navigator is a font manager for Windows 95/98, Windows NT(4.0), and Windows 3.1. It gives a quick and easy way to find fonts, install those fonts, and view and print font samples.

Font Navigator is installed automatically when the printer driver is installed. If the printer driver is installed together with SyncThru, Font Navigator is not installed. In that case, install it.

To access the Font Navigator, select Start ➔ Programs ➔ Font Navigator.

Setting Up the Printer Driver

Operation

UUssiinngg YYoouurr PPrriinntteerr

Overview

This chapter contains information about using features in the printer driver, using the printer operator panel, understanding operator panel menus, and using your printer.

●

Using Features in the Printer Driver

●

Using the Operator Panel

●

Printer Menu

●

Printing Tasks

Using Your Printer

Using Features in the Printer Driver

When you print from software application, many of the printerÕs features are available from the printer driver.

To change the settings from a software application, do the following way.

With Windows 95/98/NT 4.0

1. Select Start-Settings-Printers from the windows task bar.

2. Double-Click on the desired printer driver icon.

3. Select Printer-Properties.

4. Click on the appropriate tab.

5. Select the required options.

Using Your Printer

With Windows 3.1

1. From Program Manager windows, double-click on the Control Panel icon within the Main Program group.

2. Double click on the printers icon within the Control Panel Windows.

RReessuulltt

3. In the Installed Printers list, click on Samsung 7000 Series (PCLXL or PCL 5e) if it is not already highlighted.

4. Click on the Setup button.

5. Select the required options.

The OFFLINE message appears on the display and the printer is off-line.

See page 37

General

You can print a test page and view the driver information.

See page 38

See page 40

See page 36

See page 35

See page 39

Sharing

You can share the printer.

Details

You can select the printer port and spool setting.

Changes made from a software application override the user default setting made from the printer operator panel.

Using Your Printer

Using the Samsung 7000 Series Printer Driver

The features of the printer driver are arranged on nine tabs : To access one of the tab dialog boxes, click the tab at the top of the properties windows.

Each tab of Samsung 7000 Series PCLXL is described as an example in this section.

Paper Tab

Orientation

Choose Portrait or Landscape to select the default orientation of the printed page.

Paper sizes

Use this setting to select the paper size.

You can see version and copyright information about this printer driver by clicking About.

Source

The source setting identifies the default paper tray.

Copies

Use the Copies box to set the number of copies you want to print.

Duplex

Use the Duplex box to select the both side printing.

You can restore all settings of PCLXL printer driver by clicking Restore Defaults.

If you want to know more about each menu, click on the Help button.

The help screen gives detailed information about each menu.

Using Your Printer

Graphics Mode

This setting can image the page in several different ways.

Halftoning

This setting lets you fine-tune the way colors in graphics images are covered to gray dot patterns.

Graphics Tab

The settings on the Graphics tab allow you to fine tune your image quality and to balance print quality and print speed.

SRT Mode

You can set the resolution

for the graphics images.

Using Your Printer

Paper type

The Paper type setting lets you specify the type of print material installed in each tray.

If you want to know more about each menu, click on the Help button. The help screen gives detailed information about each menu.

Finish Mode

This setting allows you to print multiple pages on one sheet of paper.

Finishing Tab

You can restore all settings of PCLXL printer driver by clicking Restore Defaults.

Multiple Images

Use the Multiple Images setting to print multiple page images on a single page.

●

The pages per sheet itemÕs values are 1, 2, 4, 6, 9 and 16. For example, 2 means two page images are printed on one page.

●

The print page borders setting determines whether a border is printed around each page image.

If you want to know more about each menu, click on the Help button. The help screen gives detailed information about each menu.

Using Your Printer

Printer Tab

Resolution

Select from the available setting to set the maximum resolution for your print jobs.

Printer Memory

Select the value of the printer memory installed in the printer.

After adding more memory, set the value of the printer memory.

Using Your Printer

If you want to know more about each menu, click on the Help button. The help screen gives detailed information about each menu.

Overlays

To select a bitmap to be used as a graphic, enter the path to locate the bitmap file.

Overlays Tab

The Overlay is a graphic that is superimposed on your final output, usually in a lighter gray. You can also create an overlay with your graphic.

Load Overlay

You can use an externally source file as an overlay.

Selected Overlay Status

The preview area shows any selected bitmap.

Create Overlay

You can create a page overlay.

If you want to know more about each menu, click on the Help button. The help screen gives detailed information about each menu.

Using Your Printer

Watermark

You can select a watermark from list.

Watermarks Tab

A Watermark is text that is superimposed on your final output. Usually in a lighter gray you can create a watermark with your own text.

Edit

Use this dialog box to enter the text and layout of your watermark. You can set the watermarkÕs font, size and darkness, as well as the angle and position on the page.

The preview area shows the effect of your settings.

If you want to know more about each menu, click on the Help button. The help screen gives detailed information about each menu.

Using Your Printer

Using the Operator panel

The operator panel, on the front right side of your printer, has a 2-line LCD(Liquid Crystal Display) and five buttons.

Operator Panel Display

Light Color Light State The Printer is...

Green

Orange

Off

Blinking

Online

Offline

Processing information

In Non-recoverable error state

●

Solve the problems for the error

message, by going through check lists and tests.

In recoverable error state

Using Your Printer

Operator Panel Buttons

Use the five operator panel buttons to open a menu, scroll through a list of values, change printer settings, and respond to printer messages. The following table describes the functions of each button.

Button

On Line/Continue

Enter/Cancel

Item

Value

●

Operator Panel Menus

Function

Places the printer either online or offline.

Allows the printer, to continue printing

when the printer is in recoverable error state.

Cancels the print job that the printer is

processing when the printer is online.

Saves the selected value for that item when

the printer is offline.

Cycles through the operator panel menus.

Cycles through the selected menuÕs items.

Cycles through the selected menu itemÕs

values.

Using Your Printer

A number of menus are available to make it easy for you to change printer settings. Some menus are displayed only if a specific option is installed in the printer.

When you select a new setting from the operator panel, the asterisk(❊)

moves next to the selected setting to identify it as the current user default setting.

Changes mode from a software application override the user default settings made from the printer operator panel.

Changing Printer Settings

To change an operator panel setting, proceed as follows.

1. Make sure the ÔREADYÕ message appears on the display.

2. Press On Line

RReessuulltt

The ÔOFF LINEÕ message appears on the display and the printer is off-line

3. Press Menu until the menu you need appears on the display.

4. Press Item until the menu item you need appears on the display.

5. Press Value until the setting you need appears on the display.

6. Press Enter to save the selection.

RReessuulltt

An asterisk(❊) appears beside the current user default

setting for that menu item.

A value can be :

●

A phrase or word that describes a setting

●

A numerical value that you can increase or decrease

●

An On or Off setting.

Using Your Printer

Overview of Printer Menu

PRINTING

PAPER

MP SIZE

COPIES

ORIENT

TRAY

T-MARGIN

L-MARGIN

DUPLEX

AUTO CR

QUALITY

CONFIG

EMUL

SWITCH

LOCKTRAY

PWR SAVE

AUTOCONT

ECONO

JAM RECV

TONERLOW

JOB

SRT MODE TIMEOUT DENSITY PAP.TYPE MENU CLR SMET DUP.TOP DUP.LEFT S-BIND L-BIND FUSER CLEAN

TEST

SELFTEST

DEMOPAGE

FONTLIST

TYPEFACE

SYMBOL

LINES

PITCH

PT.SIZE

COURIER

Some menus are displayed only if a required option is installed. They are as follows.

I/O MENU

If the serial/LocalTalk option3 card is installed in your printer

BAUDRATE

ROBU.XON

NETWORK MENU

If the Network card(PortThru)

is installed in your printer

IP ADDR SET ?

IP ADDRESS

SUBNET MASK

GATEWAY

UPGRADE FLASH

FACTORY DEFAULT

TEST PRINT

PS II MENU

If the PS option is

installed in your printer

FONT LISTRESET NETCARD

PCL

Using Your Printer

See Network printer Card UserÕs Guide for more information.

PRINTING MENU

Use the PRINTING MENU to define all settings relating to printer input and output, as well as the specific print materials you are using with your printer.

PRINTING MENU Items

Item Values and Functions

PAPER

MP SIZE

Cassette Size

A4(country specific) ; Factory Default

LEGAL, A4, EXE, JIS B5, ISO B5, FOLIO

Mp Tray Size

LETTER(country specific), A4, EXE, JIS B5, ISO B5, COM-10, MONARCH, DL, C5,

POST A6, C6, FOLIO, A5, STS, A6

Option Tray Size

Letter(country specific), A4 (country specific), Legal, Executive, ISO B5, JIS B5, Envelope (Com - 10, Monarch, DL, C5)

Duplex Size

Letter (country specific), A4 (country specific), Legal, ISO B5, JIS B5, FOLIO

The PAPER SIZE setting identifies the default formatting size for each tray. It is important to select the correct paper size from the menu when using trays.

Using Your Printer

Item Values and Functions

COPIES

ORIENT

1 to 999(1 ; Factory Default)

The COPIES setting determines the number of copies printed for each page. The printer does not automatically collate the copies. For example, if you send three pages to print and set Copies to 2, the printer prints page1, page 1, page 2, page 2, page 3, page 3.

P : Portrait (Factory Default)

L : Landscape

The ORIENT setting determines how the printing is oriented on the page.

P(Portrait) means the printing is parallel to the short edge of the paper.

L(Landscape) means the printing is parallel to the long edge of the paper.

Using Your Printer

LandscapePortrait

Item Values and Functions

TRAY

AUTO(Factory Default)

1ST

OPT(If the optional cassette is installed)

MANUAL

The TRAY setting identifies the default paper tray.

1ST means that the printer feeds print material from Cassette unless it is empty or closed.

MP means that the printer feeds print material from MP tray unless it is empty or closed

Use the MANUAL selection when manually feeding envelopes or other print material through the MP tray.

OPT is available only if the optional tray is installed. See ÔOptional CassetteÕ on page 115.

T-MARGIN

Auto means that the printer feeds print material from the other tray when one tray is empty. If you are using the same size and type of print material in all the trays, the trays are automatically linked.

0.0Ó ~ 9.9Ó

The T-MARGIN menu item lets you select the top margin of the print materials

Using Your Printer

Item Values and Functions

L-MARGIN

DUPLEX

0.0Ó ~ 9.9Ó

The L-MARGIN menu item lets you select the left margin of the print materials

OFF (Factory Default)

LONG

SHORT

The printer can automatically print on both sides of paper

Use the OFF selection when printing of one side of a sheet of paper. For more information, see page 58.

Long Short

Using Your Printer

AUTO CR

QUALITY

LF(Factory Default)

LF + CR

The AUTO CR setting determines if the printer automatically performs carriage return after a line feed control command.

300

600(Factory Default)

QUALITY setting determines the print resolution while printing the page.

CONFIG MENU

Use the CONFIG MENU to configure a variety of printer features.

CONFIG MENU Items

Item Values and Functions

EMUL

PWR SAVE

AUTOCONT

AUTO (Factory Default)

PCL

PS II(If the PS option is installed)

HEXDUMP

You can select the emulation for printing a document.

OFF

30(Factory Default)

The PWR SAVE menu item lets you reduce power usage when the printer is idle. The PWR SAVE setting determines the length of time (in minutes) the printer waits after a job is printed before it goes to a reduced power state.

ON (Factory Default)

OFF

The AUTOCONT setting determines whether the printer continues printing after it detects paper mismatch.

If an error occurs and AUTOCONT is set to OFF, the printer stops and waits for operator intervention. If the Continue button on the operator panel is pressed, the printer continues printing regardless of paper mismatch. When AUTOCONT is set to ON, the printer automatically resumes processing.

Using Your Printer

Item Values and Functions

ECONO

JAM RECV

OFF (Factory Default)

The ECONO setting helps conserve the toner cartridge by controlling how much toner the printer uses for print job.

Select OFF if toner conservation is not a concern.

But this setting may affect the print quality of your job.

OFF (Factory Default)

When JAM RECV is set to OFF, the printer does not reprint a page that has been jammed after all the image has been drawn on the page.

When JAM RECV is set to ON, the printer keeps printed page until the printer signals that the page has successfully exited the printer. The printer reprints the jammed page .

Using Your Printer

TONERLOW

CONTINU (Factory Default)

STOP

This setting determines whether the printer continue printing after the printer detects that the toner is low.

If the toner is low and TONERLOW is set to ÔStopÕ, press the Continue button to print. In that case, replace the toner cartridge or set the TONERLOW menu item to CONTINU.

Item Values and Functions

SWITCH

(If the optional

cassette is installed)

LOCKTRAY

(If the optional cassette

is installed and the SWITCH set to on)

menu item is

ON (Factory Default)

OFF

The ON setting makes the printer supply the paper from another cassette when a cassette is empty.

In case of the OFF setting, an error message is displayed.

NONE (Factory Default)

1ST

OPT

The cassette set to LOCKTRAY doesnÕt occurres cassette change.

For example, If LOCKTRAY is set to MP, the cassette is not switched to MP tray.

Using Your Printer

JOB MENU

Use the JOB MENU to define all settings relating to print quality, as well as Menu clear.

JOB MENU Items

Item Values and Functions

SRT MODE

(Samsung Resolution

Enhancement

Technology)

TIMEOUT

ENHANCE (Factory Default)

NORMAL

GRAY

Use the printerÕs SRT(Samsung Resolution enhancement Technology) setting to produce print with smooth angles, curves, and edges.

ENHANCE : Better Text Image GRAY : Better Photo Image

0~300

15 (Factory Default)

The TIMEOUT Setting determines the amount of time(in seconds) the printer waits before printing the last page of a print job that does not end with a command to print the page. When a print timeout occurs, the printer prints the data in the print buffer. 0 : No timeout.

Using Your Printer

DENSITY

LIGHT

MEDIUM (Factory Default)

DARK

Lighten or darken the print on the page by changing the DENSITY setting.

The MEDIUM setting usually produces the best results.

Item Values and Functions

PAP.TYPE

MENU CLR

NORMAL (Factory Default)

THICK

WET

TRANSP.

The PAP.TYPE setting lets you specify the type of print material installed in each tray

Select NORMAL if the printer material is plain paper.

Select THICK if the printer material is thick paper, high cotton paper or envelopes.

Select WET if printer material is thin paper(60g) and the air is humid.

Select TRANSP. if printer material is transparencies.

When you select MENU CLR, the printer resets to the factory default setting for each menu item.

SMET

(Samsung Memory

Enhancement Technology)

ON (Factory Default)

OFF

This setting makes the printer process more data by optimizing the memory. If the value is set to ON, the complex data can be processed.

Using Your Printer

Item Values and Functions

DUP.TOP

DUP.LEFT

S-BIND

L-BIND

5.0 (Factory Default)

0~9.9mm (In increments of 0.1)

This item lets you select the top margin of the print materials when the Duplex menu item is set to Long.

5.0 (Factory Default)

0~9.9mm (In increments of 0.1)

This item lets you select the left margin of the print materials when the Duplex menu item is set to Long.

0 (Factory Default)

0~99mm (In increments of 1)

This item lets you select the left margin for the binding when short edge duplexing.

0 (Factory Default)

0~99mm (In increments of 1)

This item lets you select the left margin for the binding when long edge duplexing.

Using Your Printer

FUSER CLEAN

If there happens random dirty spots on the back side of paper, Select FUSER CLEAN. It cleans fuser contamination.

TEST MENU

Use the TEST MENU to print a variety of listings relating to available printer resources, printer settings and print jobs.

TEST MENU Items

Item Values and Functions

SELFTEST

DEMOPAGE

Select SELFTEST to print a configuration page. This menu item lets you make sure the printer is operating correctly. For more information, See page 22.

Select DEMOPAGE to print the standard demonstration page.

I/O MENU

This menu is only available if the Serial/LocalTalk option card is installed in your printer.

I/O MENU Items

Item Values and Functions

BAUDRATE

This setting lets you select the rate at which data is being sent to or from your computer.

ROBU.XON

300~115200

9600(Factory Default)

ON(Factory Default)

OFF

Using Your Printer

PCL MENU

Use the PCL MENU to change printer settings that only affect jobs printed using the PCL emulation printer language.

PCL MENU Items

Item Values and Functions

FONTLIST

TYPEFACE

SYMBOL

LINES

You can print a font sample list showing all the fonts available for PCL emulation.

PCL 1 ~ PCL 54

PCL 1 (Factory Default)

ROMAN 8

DESKTOP

PC8 (Factory Default)

List of symbol set name

A SYMBOL set is a set of alphabetic and numeric characters, punctuation, and specific symbols used when printing with a selected font.

In PCL emulation, a symbol set also defines which character will be print for each key on the keyboard (or more specifically, for each code point)

5 ~ 128

64 (Factory Default)

Using Your Printer

Use the LINES menu item to change the number of lines that print on each page. The setting can range from 5 to 128 lines per page.

The printer sets the amount of space between each line based on the Lines, Paper size, and Orientation settings.

Item Values and Functions

PITCH

PT.SIZE

COURIER

0.44 ~ 99.99

10(Factory Default)

If you chose a scalable monospaced font, you can select the font pitch. PITCH refers to the number of fixed - space characters in a horizontal inch of type.

You can select from 0.44 to 99.99 characters per inch in increments of 0.01 cpi.

You can select the character size for the font. PITCH or PT.SIZE appears according to the value of TYPEFACE.

REGULAR (Factory Default)

DARK

Using Your Printer

Printing Both Sides of Paper

The printer can automatically print on both sides of paper by setting the Printing Menu or Paper tab of Samsung 7000 Series PCLXL Driver.

Do not print on both sides of labels, transparencies, envelopes, or paper heavier than 24lb. Damage to printer and paper jamming might result.

Procedure

To print both sides of paper, proceed as follows :

Place the paper against the left side of the cassette(See page 60)

1. Open the document to be printed in appropriate application.

2. Click on the Print button.

3. Click on Properties.

RReessuulltt

The PCL printer driver is displayed with the General tab selected.

4. Click on the Paper tab.

RReessuulltt

The paper tab is displayed.

5. Set the Duplex item to Short Edge or Long Edge, and select the source item.

Long

Short

Using Your Printer

Menu Setting Procedure

If you use the driver which has not the properties, you can select ÔDUPLEXÕ by setting the control panel menu.

1. Make sure the READY message appears on the display.

2. Press On Line.

RReessuulltt

3. Press Menu until you see PRINTING MENU.

4. Press Item until you see DUPLEX.

5. Press Value until the setting you need appears on the display. (For more information, see page 48.)

6. Press Enter to save the selection.

RReessuulltt

The ÔOFFLINEÕ message appears on the display and the printer is off-line.

An asterisk(❊) appears beside the current user

default setting for that menu item.

Settings in the printer driver and software application override operator panel setting.

Using Your Printer

Paper Orientation for Printing both sides of Paper

The printer prints the second sides of paper first, so paper such as letterhead and preprinted paper needs to be oriented as illustrated in the figure below.

For MP tray,

●

Set the source item in the properties dialogue box to Manual or MP.

- To print continuously from MP tray, set the source item to MP. To print a sheet of paper from MP tray, set the source item to Manual.

For all other cassettes,

load the first side facing down and the top toward you.

MP Tray

load the first side facing up and the top toward

the printer.

Using Your Printer

Cassette

Sam sung

Manually Feeding Paper from MP Tray

The Manual Feed feature allows you to print on special paper from MP tray such as envelopes or letterhead. If the Tray menu item is set to Manual, the printer will print only from MP tray. Manual Feed is selected through the software or print driver too.

To print from the MP Tray, proceed as follows.

1. Select Manual as the paper source.

●

Set the source item in the properties dialogue box to Manual

●

You can select Manual as the paper source by setting the Tray item

of the operator panel menu.

2. Print your document.

3. Place a sheet of paper in the MP tray.

4. Press continue key when you are prompted.

Using Your Printer

Printing Special Paper

Special paper includes letterhead, prepunched, envelopes, labels, and transparencies.

Letterhead / Prepunched Paper

When printing letterhead, prepunched paper, it is important to load the trays with the correct orientation.

Paper orientation

For MP tray, load the paper with the side-to-be-printed facing up, and the top, short edge toward the printer.

●

Set the source item in the properties dialogue box to Manual or MP.

- To print continuously from MP tray, set the source item to MP. To print a sheet of paper from MP tray, set the source item to Manual.

Using Your Printer

Printing Side(up)

For All other trays, load paper with the side-to-be-printed facing down, and the top, short edge toward you.

Printing Side(down)

Envelopes

Many types of envelopes can be printed from MP tray. The types of envelopes are COM-10, MONARCH, DL, C5 and C6(60~90g/m The printer will automatically feed up to 10 envelopes. Printing performance depends on the construction of the envelope.

Printing information

●

Set margins at least 0.6inch(15mm) from the edge of the envelope.

●

Always test a few sample envelopes before purchasing large quantities.

●

Select THICK paper for better quality.

Envelopes guidelines

For best performance, use envelopes made from 75g/m2(20lb bond) paper.

Do not use envelopes that :

●

Are damaged in any way.

●

Use metal claps, string ties, metal folding bars.

●

Contain windows, holes, cutouts or embossing.

●

Have exposed flap adhesive when the flap is in the sealed or closed

position. For envelope specifications, see page 124.

)

Loading envelopes

1. Open the MP tray. Pull out the extension.

Using Your Printer

2. Load up to 10 envelopes in the left side of MP tray with the side-to-be

Samsung

printed facing up, and the postage-end toward the printer.

3. Adjust the guide to touch the envelope stack without bending the envelopes.

Using Your Printer

4. Set the source item in the properties dialogue box to Manual or MP.

Do not use an envelope curled down side, refer to the figure.

(Side View)

Label

Labels automatically feed from the MP tray or the other trays.

Label guidelines

Make sure that labels meet the specifications for the tray you use.

●

Use full label sheet. Partial sheets may cause labels to peel off during printing, resulting in a paper jam.

●

The adhesive material should be stable at 400OF(205OC), the printers maximum temperature.

●

Do not use labels that have the backing sheet exposed.

Do not print on both sides of labels.

Label Orientation

●

For MP tray, load the labels with the side-to-be-printed facing up, and

the short edge toward the printer. Print a stack of 25 labels from MP tray.

Using Your Printer

Transparencies

Transparencies automatically feed from the MP tray or the other trays. Some brand of transparencies may require manual feeding. The MP tray is a tray that holds the paper of A4 or Letter, including up to 30 sheets.

Transparencies guidelines

●

Use only transparencies recommended for use in laser printers.

●

Place transparencies on a flat surface to cool after removing them from printer

Transparencies orientation

●

For MP tray, load the transparencies with side-to-be-printed facing up, and the top toward the printer. Print a stack of 30 transparencies from MP tray.

Using Your Printer

●

Because transparencies are heavier than paper, do not load the trays to capacity.

●

Remove each transparency from the output bin before printing another.

Troubleshooting

CCaarriinngg ffoorr YYoouurr PPrriinntteerr

Overview

This chapter provides information about maintaining your printer.

●

Maintaining the Toner Cartridge.

●

Cleaning the Printer.

●

Cleaning the LSU

Caring for Your Printer

Maintaining the Toner Cartridge

Toner Cartridge Storage

Do not remove the toner cartridge from its package until you are ready to use it.

To prevent damage to toner cartridge, do not expose it to light.

Toner Cartridge Life

The life of the toner cartridge depends on the amount of toner that print jobs require. When printing text at 5% coverage, a Samsung toner cartridge lasts an average of 8000 pages in simplex mode, depending on which toner cartridge is installed. This assumes that print DENSITY and ECONO menu items are set to default.

Distributing the Toner

When toner is low, faded or light area might appear on a printed page. You might be able to temporarily improve print quality by distributing the toner.

Caring for Your Printer

Procedure

To distribute the toner, proceed as follows.

1. Open the top cover by pushing the button on the side of the printer.

2. Remove the toner cartridge from the printer.

Caring for Your Printer

3. Rotate the toner cartridge and gently shake it from side to side to distribute the toner.

4. Reinsert the toner cartridge into the printer and close the top cover.

If the print remains light, install a new toner cartridge.

Caring for Your Printer

Cleaning the Printer

To maintain print quality, you should clean the printer.

●

Never use alcohol or solvent based cleaning agents to clean the printer as they may damage the printer casing and components.

●

Never use a hard-bristled brush or abrasive pad.

Procedure

To clean your printer, proceed as follows.

1. Check that the printer is powered off and disconnected from power point.

2. Remove the paper from MP tray.

Caring for Your Printer

3. Open the top cover and remove the toner cartridge.

4. Use a soft cloth to remove any dust.

5. If the outer casing or the paper feed guides are dirty, clean them with

3. a soft, clean cloth, slightly dampened with a gentle detergent.

6. Clean the inside of the printer with a damp cloth

7. Replace the toner cartridge, close the top cover, plug in the power cord, and turn the printer on.

While cleaning the printer, be careful not to touch the transfer roller(the black, rubber roller, located under neath the toner cartridge). Skin oils on the roller can cause print quality problems.

Caring for Your Printer

Cleaning LSU(Laser Scanning Unit)

To obtain high quality from your printer, clean the LSU when characters have lines running through them.

1. Open the top cover and remove the toner cartridge.

2. Pull up on the LSU cleaner and put it on the LSU.

3. Slide the LSU cleaner horizontally across a track on the top of the LSU.

Caring for Your Printer

For more information on using method, see attached label on the inside of the top cover.

PPrroobblleemm SSoollvviinngg

Overview

Introduction

Most printer problems can be easily solved, by going through simple check lists and test. To help you locate the check list applicable to the type of problem that you are encountering. The most frequent problems have been divided into several categories, as listed below.

Problem Categories

The problems that you may encounter when using your printer have been divided into the following categories.

●

Paper jams

●

Error messages

●

General printing problems

●

Poor print quality

●

PS problems

Problem Solving

Clearing Paper Jams

If the printerÕs operator panel displays a paper jam message, look for paper in the locations indicated in the figure below, then perform the procedure for clearing the paper jam.

Be very careful not to tear the paper, when clearing paper jams. If a small piece of paper is left in the printer, it could cause additional jams.

Paper Jam Locations

Problem Solving

Problem Solution

‘PAPER JAM 0’

message appears on the LCD

1. Slide the cassette out of the printer, and remove any damaged paper from the tray.

If the edge of paper is visible in the feed area, slowly pull the paper down and out of the printer.

2. Make sure the paper is below the tab on the guide.

3. Replace the cassette.

4. Open and close the top cover to clear the paper jam message.

Problem Solving

Problem Solution

‘PAPER JAM 1’ or ‘PAPER JAM 2’

messages appear on the LCD

Check 1

●

Open and close the top cover

The paper comes out of the printer.

Check 2 (JAM 1)

●

Open the top cover and remove

the toner cartridge.

●

Slowly pull the paper out of the

printer. Do not tear the paper.

●

Replace the toner cartridge,

and close the top cover.

Check 3 (JAM 2)

●

Open the rear cover

●

Grasp both sides of the paper, and

slowly pull the paper out of the printer.

Check 4

Problem Solving

●

Open and close the top cover to clear the

paper jam message.

The paper jam locations for both sides printing are different from those of normal printing. Refer to page 76.

Problem Solution

‘DUPLEX JAM 1’ or ‘DUPLEX JAM 2’

messages appear on the LCD

Check 1 (DUPLEX JAM 1)

●

Open the rear cover

●

Grasp both sides of the paper, and

slowly pull the paper out of the printer.

Check 2 (DUPLEX JAM 2)

●

Pull the cassette completely out of

the printer.

●

Pull down the metal plate inside

of the printer.

●

Slowly pull the paper out of the

printer.

Problem Solving

Error Messages

COVER OPEN

Toner

READY

Toner STOP

PAPERJA

,0, 1 2

DUPLEX

1JAM , 2

E A

PTY 1S

MPaper

Size

OP T

The following table explains messages that might display on the printer operator panel.

Message

Meaning and Required Action

A cover is open.

●

Close the cover.

The printer is running out of toner. Purchase a new cartridge and replace the toner cartridge.

The toner is low. The TonerLow menu item is set to STOP.

●

Purchase a new cartridge and replace the toner

cartridge.

●

Set the TonerLow menu item to CONTINU.

●

Press the Continue button.

The printer detects a paper jam. Open the cover and remove the jammed paper, Refer to page 77 for more information.

Problem Solving

The printer detects a paper jam while printing both sides of paper.

●

Open the cover and remove the jammed paper.

Load the paper to clear the message.

MANUAL

PTY

INTERNAL

ROR

OVERRUN

Message


L A

AD 1S

MPaper

Size

OP T

Meaning and Required Action

The requested paper size does not correspond with the loaded paper size in the displayed cassette.

Press Continue key.

Load the paper into the MP tray.

An internal error has occurred.

●

Turn the printer off, and then turn the printer on.

●

Contact your local dealer or after-sales service.

Data which was too complex was sent to the printer.

●

If this message persists, expand the memory.

The program in the memory has been damaged in someway.

●

Contact your local dealer.

Problem Solving

SERIA

ERROR

MEMOR

OVERFLO

Message

Meaning and Required Action

The printer detects a serial interface error.

●

Set the same Baudrate.

There is not enough memory in the printer.

●

You might want to add more memory to

the printer.

●

Check that the SMET menu item is set to ON.

Problem Solving

General Printing Problems

Problem

The power does not turn on.

The printer does not operate by pressing the button on the operator panel.

It cannot print from software application.

The printed data is not sent to the printer.

Solution

●

Check the power cord connections

●

Check that the power supplied to the printer is

steady and meets printer specifications.

●

Turn the printer off, and then turn the printer

on.

1. Select START-Settings-Printers from Window 95 task bar.(See page 33)

2. Click on the PCLXL, PCL5e or PS printer icon.

3. Select File-Default Printer.

●

Check the printer cable connections.(See page 14)

●

Check the printer port on your computer.

The test page is not printed.

●

Check that all trays are properly loaded,

adjusted, and installed in the printer.

●

Check that all covers are correctly closed.

Problem Solving

Poor Print Quality

Problem

The vertical lines are printed on the page. Print is too light.

There are toner speckles.

The printer drops letters

The printer drops letters in case of printing from Dos mode in Windows 95

Solution

●

Distribute the toner in toner cartridge.(See page 69)

●

Adjust the ÔDensityÕ

●

Clean the inside of the printer.(See page 72.)

●

Print a few more pages to see if the problem

will correct itself.

●

Clean the inside of the printer.(See page 72.)

●

Check the paper type and quality.

●

Check the paper type and quality.

●

Check the printers environment.

●

Install a new toner cartridge.

●

Check the printer cable connections.

●

Close the SM(Smart Monitor) program.

menu item setting.(See page 52)

Problem Solving

“Check parallel Cable/Smart Monitor can not monitor network printing” appears in Smart Monitor program.

Dirty spots on the back side of paper of fuser assy contamination.

●

Check the printer cable connections.

●

You cannot monitor the status of the printer which

is connected by network. Close the SM(Smart Monitor) program.

●

Much printing may accumulate toners on the pressure roller of fuser assy. The accumulated toner may be melted and transferred on the back side of paper.

●

Select ÔFUSER CLEANÕ in the JOB MENU.

●

ÔFUSER CLEANÕ selection rotate the motor about 10

seconds and print one page duplex printing of specified pattern for fuser clean and stop.

PS(PostScript) Problems

Problem

The PS file is not printed.

The Error messages (This job contains binary data...) are printed.

For Macintosh User Your printer name

does not the chooser box.

appear on

dialogue

Solution

●

Check that the PS is available for printing, and the total memory is installed more than or equal to 12MB by printing selftest page.

- If PS is not available for printing, install the

PS SIMM. (For information about procedure of the PS SIMM, see page 99)

- If the total memory is lower than 12MB, Install

the 8MB SIMM provided with the PS option. (For more information about installing procedure

of the printer memory, see page 92)

1. Open the Properties of PS driver.

2. Click on PostScript.

3. Click on the Advanced button.

4. The pure binary data is not supported. Choose the others.

●

Make sure that the printer is powered on.

●

Check that the LocalTalk cable is completely plugged

into the printer and your Macintosh.

installing

The Optional cassette is not selected in PS driver.

1. Open the PS driver Properties.

2. Set Ôoption cassetteÕ item of Device Option to installed.

Problem Solving

Options

MMeemmoorryy aanndd OOppttiioonn CCaarrddss

Overview

You can customize your printer memory and connectivity. This chapter provides instructions for installing.

Turn to the appropriate section for instructions on installing the option.

Option Go to page...

●

Printer Memory

●

Network Option Card(installed in ML-7000N already)

●

PS SIMM

●

Serial/LocalTalk

(installed in ML-7000P already)

You need a small screwdriver to do the installation of some options

108

Memory and Option Cards

Preparations

Complete the following steps before you install the printer options

1. Unplug the printer power cord.

2. Disconnect all cables from the back of the printer.

3. Remove the printer cover. a. Open the rear cover.

b. Remove the two screws from the back of the printer.

Save the screws.

Memory and Option Cards

c. Grasp the cover(as illustrated) and pull it firmly toward the rear of

the printer until it stops.

d. Remove the cover from the printer.

e. Remove the five screws from the metal plate covering the

control board.

f. Remove the plate.

Understanding the Printer Control Board

If the printer cover is opened, you can see the printer control board as below.

Printer Memory Connector

ROM SIMM Connector

Serial/LocalTalk Connector

Memory and Option Cards

Network Card Connector

Closing the Printer Cover

When you have finished installing an Option, follow these steps.

1. Close the metal plate and tighten all the screws.

2. Set the bottom of the cover onto the printer Make sure the bottom tabs on the cover fit into the corresponding slots in the printer. Rotate the cover up towards the printer. Slide the cover toward the front of the printer until it clicks into place.

Memory and Option Cards

3. Gently tighten all the screws.

4. Reconnect any interface cables and the power cord.

Memory and Option Cards

Printer Memory

The printer memory option increases the printer dynamic random access memory(DRAM).

Your printer was shipped with 4MB of standard printer Memory. You can install two printer memory options in your printer. Printer memory upgrade options available are 4, 8, 16 or 32MB.

DRAM SIMM Features for Upgrade

- Speed(Access Time): 60nS

- Refresh Time: 1K(1024 cycles/16 ms) / 2K(2048 cycles/32 ms)

- The Method of refresh is CAS-befor-RAS refresh

- Mode: EDO Mode / Fast Page Mode

- Single +5V +/-10% power supply

- The SDRAM does not support.

Installing Procedure

Before you install the printer memory option, follow steps under ÔpreparationsÕ on page 88.

Memory Connector

Memory and Option Cards

The printer memory option is easily damaged by static electricity. Touch something metal before you touch the memory option.

1. Locate the memory connector on the printer control board.

2. Unpack the memory option.

Notch

Connection points

Avoid touching the connection points along the edge. Save the packaging.

3. Hold the memory option with the connection points pointing toward the connector and position the notch as shown. Insert the memory option all the way into the connector at a 30

angle, and rotate it left until it snaps into place.

Memory and Option Cards

4. Make sure both metal clips on the connector are fastened, and the two pins on each of the connector are pushed through the holes on the memory option.

5. Continue with Ôclosing the printer coverÕ on page 90.

6. Set the printer memory item on the printer tab of the properties dialogue box to the value of the added printer memory.

Memory and Option Cards

Removing the Printer Memory Option

Complete the following steps if you need to remove a printer memory option before you install a new one.

1. Push the metal clips at each end of the connector away from memory option.

2. Rotate the memory option right to a 30Oangle and gently pull it out of the connector as shown.

3. Place the printer memory option in its original packaging.

If you did not save the packaging, wrap the memory option in paper and store it in a box.

Memory and Option Cards

Network Option Card(PortThru)

The network option card lets you connect the printer to a local area network(LAN).

You can install one network option card in your printer.

RJ-45 Port(Ethernet 10 Base T network)

Card Connector Points

BNC Port(Ethernet 10 Base 2 network)

Memory and Option Cards

Installing Procedure

Before you install the network option card, follow steps under ÔpreparationsÕ on page 88.

1. Locate the card connector on the printer control board.

Network card connector

2. Remove the two screws from the metal plate covering the opening for cable connector. Remove the plate.

4. Unpack the option card.

5. Align the connector on the card with the connector on the printer control board. Push the card firmly into the connector until it is completely in place.

RReessuulltt

The two connectors should fit snugly together.

7. Gently tighten the screws to secure the card to the system board.

8. Continue with Ôclosing the printer coverÕ on page 90.

Memory and Option Cards

9. Install the network printer driver(called SyncThru) provided on the CD-ROM. See Network Printer Card UserÕs Guide for installation instructions and network menu displayed on the operator panel display.

Connecting to Ethernet 10 Base 2 Network

Attach your ThinLAN cable to the BNC ÔTÕ connector.

Memory and Option Cards

Connecting to Ethernet 10 Base-T Network

Connect a twisted-pair network cable to the RJ-45 port.

Samsung ML-7000 User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual
