Samsung MAX-N50, MAX-N52, MAX-N53, MAX-N54, MAX-N55 Service manual

...

3 CD CHANGER MINI MINI COMPONENT

MAX-N50/52/53/54/55/57

SERVICE

Manual

MIMI MIMI COMPONENT SYSTEM CONTENTS

On/Standby

Demo

AI Off /Sleep

TUNER C D TAPE AUX

–

Volume

Disc Change

Disc 3Disc 2Disc 1

Disc Selection / Direct Play

Band

Mono/ST Memory Repeat Program Deck 1/2 REV mode

Normal

TAPE TAPE REC

HI-SpeedCD SYNC.REC/Pause

Phones

REC Lock

Shuffle

Tuning ModeDown Up

Timer On/Off

Timer /Clock

S .

1. Alignment and Adjustments

2. Exploded Views and Parts List

3. Electrical Parts List

4. Block Diagrams

5. PCB Diagrams

6. Wiring Diagram

7. Schematic Diagrams

On/Standby

Demo

AI Off /Sleep

TUNER C D TAPE AUX

–

Volume

Disc Change

Disc 3Disc 2Disc 1

Disc Selection / Direct Play

Band

Mono/ST Memory Repeat Program Deck 1/2 REV mode

Normal

TAPE TAPE REC

HI-SpeedCD SYNC.REC/Pause

Phones

REC Lock

Shuffle

Tuning ModeDown Up

Timer On/Off

Timer /Clock

S .

ELECTRONICS

Printed in Korea Code no. AH68-00073Q

1-1Samsung Electronics

1. Alignment and Adjustments

1-1 Tuner

FM THD Adjustment

Output

23 dB

60 dB

Minumum Distortion (0.3% below) (Figure 1-1)

SSG FREQ.

Adjustment point (TL3)

98 MHz

FM DETECTOR COIL

FM Search Level Adjustment

Adjust TSR1 so that “TUNED” of FLT is lighted (Figure 1-2)

Figure1-2 FM Auto Search Level Adjustment

*Adjust FM S.S.G level to 23dB

Figure1-1 IF CENTER and THD Adjustment

SSG FREQ.

Adjustment point

(TSR1)

98 MHz

BEACON SENSITIVITY SEMI-VR(5KΩ)

FM S.S.G

GND

23 dB

FM S.S.G

Output GND

Speaker Terminal

FM Antenna Terminal

Distortion Meter

Input

SET

Input

output

Oscilloscope

FM IN

FM Antenna

SET

5 kΩ

OUTPUT

AM SSG 450KHZ

INPUT

AM ANT IN

Speaker Terminal

60cm

TL2

VTVM Oscilloscope

AM(MW) I.F Adjustment

Maximum output (Figure 1-3)

SSG FREQ.

Frequency

Adjustment point (TL2)

450 kHz

522 kHz

AM I.F COIL

Figure1-3 AM I.F Adjustment

OUTPUT

* Adjustment Location of SW Band

* Adjustment Location of LW Band

Alignment and Adjustments

1-2 Samsung Electronics

1-1-2 AM(MW),LW,SW1,SW2 Adjustment

Circuit Measuring Instrument & Step S.S.G Radio dial Adjusting Adjust for to be Arrangement Frequency Setting Point Adjusted

1 522KHz 522KHz MW OSC Aduust for 1.0V±0.1V at the low.

OSC Connect AM signal (IR117)

generator to loop antenna,VTVM AND oscilloscope 2 1611KHz 1611KHz MW OSC

Check for 7.0V±1.0V at the high.

(Fig 1-3) (IR117)

(MW)

RF “ 1 594KHz 594KHz MW ANT Maximum out

INTER FREQ “ 1 455KHz 522KHz TL2 Maximum out

OSC Fig 1-3 1 146KHz LW OSC Aduust for 2.0V±0.1V at the low.

LW 2 290KHz LW OSC Check for 7.0V±1.0V at the high.

RF 1 150KHz 150KHz LW ANT Maximum out

OSC Fig 1-3 1 2.3MHz SW1 OSC Aduust for

1.0V±0.1V at the low.

SW1 2 7.3MHz -

Check for 8.5V±1.0V at the high.

RF 1 3.5MHz 3.5MHz SW1 ANT Maximum out

OSC Fig 1-3 1 9.5MHz SW2 OSC Aduust for 1.5V±0.1V at the low.

SW2 2 26.1MHz - Check for 8.0V±1.0V at the high.

RF 1 10MHz 10MHz SW2 ANT Maximum out

Alignment and Adjustments

1-3Samsung Electronics

(GND)

VTVM

1-2-1 To Adjust Tape Speed

1) Measuring tape: i) MTT-111 (or equivalent) (Tapes recorded with 3kHz)

ii) MTT-5512 (or equivalent)

2) Connect the cassette deck to the frequency counter

as in figure 1-4.

1) Before the actual adjustment, clean the play/recording

head.

2) Measuring tape :

i) MTT-114(or equivalent 10kHz AZIMUTH control)

ii) MTT-112(or equivalent) :

3) The cassette deck is connections as shown in figure 1-6.

Notes

NOR SPEED Control

OUT

(connected

to the frequency

counter)

Turn CSR1 to left and right

3KHz

5200~6600Hz :Check

FIXED

Remark

Standard

To Adjust

Pre-Setup

Item

Step

Pre-Setup Condition

Same as above

1) Deck 1:MTT-111

2) Press PLAY

SW button

3) Deck 2:MTT-5512

1) Deck 1:MTT-111

2) Deck 2:MTT-5512

3) Press Hi-SPEED

button.

HI SPEED

Control

AZIMUTH

SPK OUT

(VTVM is

connected to

the scope)

1) Turn the control screw to as shown in Figure 1-5.

Max output and same phase (both channels)

After adjustment secure it with REGION LOCK.

Adjust to level and same as R-CH.

L-CH:Turn JSR2L

to the right and left

R-CH : fixed.

See the diagram for adjustment locations.

Remark

Standard

To Adjust

Pre-Setup

Item

Step

Pre-Setup Condition

Same as above

After putting MTT-

114 into Deck 1

1)Press PLAY button.

PLAY MTT-112

on Deck 1.

PlayBack out Level

AZIMUTH

SPK OUT

(VTVM is

connected to

the scope)

1) Turn the control screw to as shown in Figure 1-5.

Max output and same phase (both channels)

After adjustment secure it with REGION LOCK.

Check level and same as Deck1 level

No Adjustment

See the diagram for adjustment locations.

Remark

Standard

To Adjust

Pre-Setup

Item

Step

Pre-Setup Condition

Same as above

After putting MTT-

114 into Deck 2

1)Press PLAY button.

PLAY MTT-150

on Deck 2.

PlayBack out Level

1-2-2 To Adjust PlayBack Level

@ Adjust Deck 2 Play Level

! Adjust Deck 1 Play Level

Cassette Deck

output

SPK OUT

Frequency Counter

Figure 1-4

Figure 1-5

SPK OUT

Recording /Play head

AZIMUTH control screw

Figure 1-6

In Out

SET

Oscilloscope

1-2 Cassette Deck

REC Bias Voltage

Connect to

JCW3 as in

Fig.1-7 and read

the VTVM.

L-CH;JSR2L and R-CH;JSR2R to the right and left.

8mV

Remark

Standard

To Adjust

Pre-Setup

Item

Step

Pre-Setup Condition

Input MTT-5512

into Deck2,then

press REC button.

See diagram for adjustment location

Adjust REC Bias Voltage

Figure 1-7

SET

Oscilloscope

VTVM

JCW3

Samsung Electronics 2-1

2.Exploded Views and Parts List

2-1 Cassette Deck :ADR241AMW1(OPTION)

No. Code No. Description Specification Remarks

AH59-20006T DECK-CASSETTE ADR241AMW1 1 AH81-00140A ASS.Y RP HEAD ADR2400-RP(SANKYO) MT91-11011P 2 AH81-00141A HEAD PB TC881CB MT59-00044A 3 AH81-00142A ASS,Y MOTOR ADR2400-SHU2L MT91-11013D 4 AH81-00143A BELT MAIN1 ADR2400-MAIN 76.2 6602-001038 5 AH81-00144A BELT MAIN2 ADR2400-MAIN 64.6 6602-001050 6 AH81-00101A BELT SUB ADR2400-FR 6602-001055 7 AH81-00102A SOLENOID ADR2400-1 MT75-00049A

Samsung Electronics

2-2

2-1-1 Cassette Deck :ADR241DSW1(OPTION)

No. Code No. Description Specification Remarks

AH59-20006U DECK-CASSETTE ADR241DSW1 1 AH81-00141A HEAD TC881CB MT59-00044A 2 AH81-00142A ASS,Y MOTOR ADR2400-SHU2L MT91-11013D 3 AH81-00143A BELT MAIN1 ADR2400-MAIN 76.2 6602-001038 4 AH81-00144A BELT MAIN2 ADR2400-MAIN 64.6 6602-001050 5 AH81-00101A BELT SUB ADR2400-FR 34.7 6602-001055 6 AH81-00102A SOLENOID ADR2400-1 MT75-00049A 7 AH81-00284A E-HEAD TC2131F MT59-00046A

Samsung Electronics 2-3

2-2 Total Exploded View and Parts List

2-2-1 Total Exploded

Samsung Electronics

2-4

2-2-2 Parts List of Total Exploded view(MAX-N50/52/53/54/55/57)

No. Code No. Description ; Specification Q’ty Use Model

1 AH64-00577B WINDOW-CD:PMMA,VIOLET, 1 COMMON 2 AH64-70003H BADGE-BRAND 1 COMMON 3 AH64-00573B DOOR—CD;ABS L/GRAY, 1 COMMON 4 AH64-00578B WINDOW-CD DOOR;PMMA,VIOLET 1 MAX-N55

AH64-00578D WINDOW-CD DOOR;PMMA,VIOLET 1 MAX-N54 AH64-00578E WINDOW-CD DOOR;PMMA,VIOLET 1 MAX-N53 AH64-00578F WINDOW-CD DOOR;PMMA,VIOLET 1 MAX-N52 AH64-00578G WINDOW-CD DOOR;PMMA,VIOLET 1 MAX-N50

AH64-00578H WINDOW-CD DOOR;PMMA,VIOLET 1 MAX-N57 5 AH63-00149A FILTER-VFD 1 COMMON 6 AH64-00579B WINDOW-VFD;PMMA,VIOLET 1 COMMON 7 AH64-00569B KNOB-VOLUME;ABS L/GRAY 1 COMMON 8 AH64-00580B WINDOW-CASS A;,PMMA, 1 COMMON 9 AH64-00566B WINDOW-CASS B;PMMA 1 COMMON 10 AH64-00571B DOOR-CASS,A;ABS L/GRAY 1 COMMON 11 AH64-00572B DOOR-CASS,B;ABS L/GRAY 1 COMMON 12 AH61-00353A HOLDER-CASS A;ABS 94HB 1 COMMON 13 AH61-00354A HOLDER-CASS B;ABS 94HB 1 COMMON 14 AH61-62004A SPRING-EJECT,A;STS 1 COMMON 15 AH61-62005A SPRING-EJECT,B;,STS,PI1.0 1 COMMON 16 AH64-00585A KNOB-MIC;ABS, 1 COMMON(OPTION) 17 AH64-00575B DECORATION-TUNING A;ABS 94HB 1 MAX-N54/55/57(1-MIC)

AH64-00575D DECORATION-TUNING A;ABS 94HB 1 MAX-N50/52/53(1-MIC)

AH64-00575C DECORATION-TUNING A;ABS 94HB 1 MAX-N54/55/57(2-MIC)

AH64-00575E DECORA TION-TUNING A;ABS 94HB 1 MAX-N50/52/53(2-MIC)

AH64-00576B DECORATION-TUNING B;ABS 94HB 1 MAX-N54/55/57(NO-MIC)

AH64-00576C DECORATION-TUNING B;ABS 94HB 1 MAX-N50/52/53(NO-MIC) 18 AH64-00574B DECORATION-FRONTA;ABS 94HB 1 MAX-N54/55/57 18_1 AH64-00589B DECORATION-FRONT B;ABS 94HB 1 MAX-N50/52/53 19 AH64-00586B KNOB-JOG;ABS 1 MAX-N54/55/57 20 AH67-00051A LENS-JOG;PMMA SMOLE 1 MAX-N54/55/57 21 AH61-00356A HOLDER-JOG;ABS 94HB 1 MAX-N54/55/57 22 AH64-00584B KNOB-EQ;ABS 1 MAX-N54/55/57 23 AH67-00052A LENS-TPOWER;PMMA SMOKE 1 MAX-N54/55/57 24 AH64-00570B CABINET FRONT;MIPS GRAY 1 COMMON 25 AH61-80030A DAMPER-ASSY;POM 2 COMMON 26 AH95-50001A ASSY-LATCH; 2 COMMON 27 AH64-00568B KNOB-POWER;ABS 1 COMMON 28 AH67-00049A LENS-POWER;PMMA SMOKE 1 COMMON 29 AH64-00567B KNOB-CD;ABS 1 COMMON 30 AH67-00048A LENS-CD;PMMA SMOKE 1 COMMON 31 AH61-00359A BRACKET-MIC;SPTE T1.0 1 COMMON 32 AH64-00581B KNOB-FUNCTION;ABS 1 COMMON 33 AH67-00050A LENS-FUNCTION;PMMA SMOKE 1 COMMON 34 AH61-00355A HOLDER-FUNCTION:ABS 94HB 1 COMMON 35 AH61-00357A HOLDER-VFD;ABS 94HB 1 COMMON 36 AH64-00587B KNOB-ECHO;ABS 1 COMMON(OPTION) 37 AH64-00583B KNOB-TUNING:ABS MAX-N55 1 COMMON 38 AH64-00582B KNOB-RECORD:ABS MAX-N55 1 COMMON 39 AH67-00053A LENS-REC;PMMA SMOKE 1 COMMON

40 AH64-00431A CABINET-SIDE-L;MIPS 1 MAX-N50/52/53/54/55 41 AH64-00432A CABINET-SIDE-R;MIPS 1 MAX-N50/52/53/54/55 42 AH64-00443A CABINET-TOP:MIPS 1 MAX-N50/52/53/54/55 43 AH61-00021A SUPPORT-PCB;ABS 1 COMMON 44 AH61-20540A HOLDER-TUNER;ABS,94HB 1 COMMON 45 AH62-00027A HEAT SINK-MAIN;AL EXTR 1 MAX-N50/52/53/54/55 45_1 AH62-00028A HEAT SINK-MAIN;AL EXTR,MAX-N75 1 MAX-N57 46 AH61-00250A BRACKET-HEAT SINK;SECC 0.8T 1 MAX-N50/52/53/54/55 46_1 AH61-00377A BRACKET-HEAT SINK;SECC 1.0T 1 MAX-N57 47 AH64-30416C CABINET-BOTTOM;SECC,T1.0 1 COMMON 48 AH64-00591B CABINET-REAR;MIPS GRAY 1 MAX-N50/52/53/54/55

AH64-00591C CABINET-REAR;MIPS GRAY 1 MAX-N50/52/53/54/55,DIGITAL OUT(OPTION)

48_1 AH64-00366G CABINET-REAR;SECC T0.8 1 MAX-N57

AH64-00366H CABINET-BOTTOM;SECC T1.0 1 MAX-N57,DIGITAL OUT(OPTION) AH64-00366J CABINET-BOTTOM;SECC T1.0 1 MAX-N57,VOLTAGE(OPTION)

AH64-00366M CABINET-BOTTOM;SECC T1.0 1 MAX-N57,SURROUND SPK.(OPTION) 49 AH67-00054B LENS-TURBO:PMMA SMOKE 1 MAX-N50/52/53 50 AH64-00588B KNOB-TURBO:ABS 1 MAX-N50/52/53 51 AH64-00593A CABINET-TOP:PCM T0.625 1 MAX-N57

No. Code No. Description ; Specification Q’ty Remarks

Samsung Electronics 2-5

2-3 CD Deck Exploded View and Parts list

CD SUB PCB

TRAY STOPPER

BASE MAIN

No. Code No. Description Specification Remarks

AJ59-20150T ASS’Y-DECK CMS-300 1 AH66-80022A SLIDER-CAM ABS HF-380 NTR 2 AH66-60034A BELT-LOAD CR 3 AH66-20186A GEAR-PULLEY POM (M90-44) WHT 4 AH66-20187A GEAR-LOAD POM (M90-44) BLK 5 AH66-20188A GEAR-CAM POM (M90-44) WHT 6 AH66-20189A GEAR-TRAY POM (M90-44) BLK 7 AH66-20190A GEAR-CONVERT POM (M90-44) WHT 8 AH66-20191A GEAR-SYNCRO ABS HF-380 NTR 9 AH66-20192A GEAR-WORM POM(M90-44),M0.5,PCD4.5 10 AH31-12001A MOTOR-LOADING FF-030PN-09120 11 AH66-20193A GEAR-ROULLETE POM(M90-44) BLK 12 AH66-90056A TRAY-ROULLETE ABS XR-401 BLK 13 AH66-90055A TRAY-DISC ABS BLK 14 AH59-10099A ASSY-PCB SENSOR CMS-300,ASSY SENSOR 15 AH61-00225A BRKT-CHUCK SECC T0.8,CMS-300 16 3302-000159 MAGNET-CHUCK AC,3500-3800G,2.6-3.2MGOe,30 17 AH66-90057A TABLE-CHUCK ,ABS,BLK,CMS-300 18 AH69-20342B SHEET-CHUCK SHEET,HYMERON,BLK,0.4T 19 AH59-10102A ASSY-PCB SW CMS-300,ASSY SW 20 AH31-10021A MOTOR-DC RF-500TB,9VDC/130MA 21 AH66-10008A PULLEY-MOTOR POM,BLK,CMS-CR3 22 AH73-10031A RUBBER-CD(R) SI,CMS-300,40,RED 23 AH91-60150A CDP DECK ASSY CMS-D50SG6,CMS-300D 24 AH66-30098A LEVER-LIFTER ABS BLK CMS-300 25 AH30-00003A PICK-UP SOH-AA,D51SG6(W/D/CO) 26 AH73-10034A RUBBER-CD(G) SI,CMS-300,40,GREEN 27 AH61-20428A BASE-MAIN ABS,BLK,CMS-300

Samsung Electronics

2-6

2-4 SPEAKER Exploded View and Parts list

4 3

* PS-N50 : ASS’Y SPK(AH81-00258A)

Description

2-4-1 MAX-N50

2-4-2 MAX-N52

Description

* PS-N52 : ASS’Y SPK(AH81-00257A)

* CAUSION : It is used the bonding, connet NET FRAME(or FRONT PANEL ASS’Y) to CABINETASS’Y.

So when the disassembly, take extreme care not to demage the SPEAKER.

Samsung Electronics 2-7

2-4-3 MAX-N53

2-4-4 MAX-N54

* PS-N53 : ASS’Y SPK(AH81-00254B)

Description

AH81-00254E

F/R

* PS-N54 : ASS’Y SPK(AH81-00255A)

Description

Samsung Electronics

2-8

2-4-5 MAX-N55

2-4-6 MAX-N57

* PS-N55 : ASS’Y SPK(AH81-00254A)

Description

* PS-N57 : ASS'Y SPK(AH81-00252B)

Description

AH81-00277R

W/F

AH81-00277J

6 1/2

Samsung Electronics 3-1

***** MAXN50 Parts List *****

AH26-00084A TRANS-POWER;EI66*45,-,-,115/230V,50/60HZ,-,MAX-N50 AH38-10001A WIRE-LEAD;1007#22,1500MM AH39-10002L POWER CORD;CP2,KLCE-2F,2.15M,5239,VDE AH42-20001Q ANT-LOOP;-,KS980214-01,18.5uH,CONNECTOR AH59-00004P REMOCON—ASSY;-,-,-,22KEY,MAX-N55,SAMSUNG AH68-00088C LABEL-IMPEDANCE;MAXN50RH/ELS AH68-00305G LABLE-POP,A;FASCAL400R,MAX-N50,-,-,-,-,-,-,-,-,-,-,-

AH90-10752Y ASSY-PCB-TUNER;MAX900,CE+RDS BAND S.N.A.

TJW100 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012 TJW22 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012 TJW41 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012 TJW42 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012 TR6 2007-000030 R-CHIP;560OHM,5%,1/10W,DA,TP,2012 TR101 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216 TR102 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216 TR103 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216 TR104 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216 TR19 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012 TR45 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012 TR47 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012 TR49 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012 RR2 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012 TR24 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012 TR43 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012 TR2 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012 TR21 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012 TR22 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012 TR46 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012 TR48 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012 TR50 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012 TR53 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012 TR54 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012 TR56 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012 TR10 2007-000308 R-CHIP;10OHM,5%,1/10W,DA,TP,2012 TR20 2007-000409 R-CHIP;15KOHM,5%,1/10W,DA,TP,2012 TR28 2007-000457 R-CHIP;18KOHM,5%,1/10W,DA,TP,2012 TR52 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012 TR9 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012 TR35 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012 TR36 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012 TR40 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012 TR7 2007-000518 R-CHIP;2.7KOHM,5%,1/10W,DA,TP,2012 TR11 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012 TR105 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012 TR15 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012 TR37 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012 TR12 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012 TR29 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012 TR23 2007-000710 R-CHIP;3.9KOHM,5%,1/10W,DA,TP,2012 TR8 2007-000822 R-CHIP;390OHM,5%,1/10W,DA,TP,2012 TR4 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012 TR51 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012 TR17 2007-000981 R-CHIP;5.6KOHM,5%,1/10W,DA,TP,2012 TR25 2007-001043 R-CHIP;56OHM,5%,1/10W,DA,TP,2012 TR27 2007-001071 R-CHIP;6.8KOHM,5%,1/10W,DA,TP,2012 TR38 2007-001177 R-CHIP;8.2KOHM,5%,1/10W,DA,TP,2012 TR44 2007-001177 R-CHIP;8.2KOHM,5%,1/10W,DA,TP,2012 TC41 2203-000239 C-CERAMIC,CHIP;0.1nF,5%,50V,NP0,TP,2012 RC2 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012 TC20 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012 TC28 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012 TC29 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012 TC3 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012 TC44 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012 TC7 2203-000429 C-CERAMIC,CHIP;0.018nF,5%,50V,NP0,TP,2012 TC1 2203-000609 C-CERAMIC,CHIP;22nF,10%,50V,X7R,TP,2012 TC5 2203-000609 C-CERAMIC,CHIP;22nF,10%,50V,X7R,TP,2012 TC99 2203-000609 C-CERAMIC,CHIP;22nF,10%,50V,X7R,TP,2012 TC33 2203-000844 C-CERAMIC,CHIP;39nF,10%,50V,X7R,TP,2012,RC7 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012 TC10 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012 TC13 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012 TC15 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012 TC35 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012 TC45 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012 TC6 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012 RC8 2203-001058 C-CERAMIC,CHIP;0.56nF,5%,50V,NP0,TP,2012 TC61 2203-001105 C-CERAMIC,CHIP;6.8nF,10%,50V,X7R,TP,2012 TC62 2203-001105 C-CERAMIC,CHIP;6.8nF,10%,50V,X7R,TP,2012 TC32 2203-001132 C-CERAMIC,CHIP;0.68nF,5%,50V,NP0,TP,2012 TC2 2203-001517 C-CERAMIC,CHIP;0.015nF,5%,50V,NP0,TP,2012 RC4 2203-001524 C-CERAMIC,CHIP;0.047nF,5%,50V,NP0,TP,2012 RC5 2203-001524 C-CERAMIC,CHIP;0.047nF,5%,50V,NP0,TP,2012 TC63 2203-001551 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,2012 TC64 2203-001551 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,2012

TC50 2203-001611 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,2012 TC51 2203-001611 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,2012 TD3 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP TD4 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP TD5 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP TD6 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP TZD1 0403-000367 DIODE-ZENER;UZ7.5BSC,7.5V,7.33-7.64V,500mW RZD1 0403-000393 DIODE-ZENER;UZP5.1B,5.1V,4.8-5.4V,1W,DO-41 TZD2 0403-000393 DIODE-ZENER;UZP5.1B,5.1V,4.8-5.4V,1W,DO-41 TQ4 0501-000294 TR-SMALL SIGNAL;KSA708-Y,PNP,800mW,TO-92,TP,12 TQ2 0501-000392 TR-SMALL SIGNAL;KSC838-O,NPN,250mW,TO-92,-,70TQ3 0501-000392 TR-SMALL SIGNAL;KSC838-O,NPN,250mW,TO-92,-,70TQ1 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120TQ5 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120TQ6 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120TQ7 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120TR30 2001-000117 R-CARBON(S);68OHM,5%,1/2W,AA,TP,2.4X6.4MM RR1A 2001-000118 R-CARBON(S);180ohm,5%,1/2W,AA,TP,2.4x6.4mm TR44 2001-000118 R-CARBON(S);180ohm,5%,1/2W,AA,TP,2.4x6.4mm TR58 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2MM TR5 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM

- 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM TR39 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM TR1 2001-000331 R-CARBON;12KOHM,5%,1/8W,AA,TP,1.8X3.2MM RR3 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM RR4 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM RR5 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM TR32 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM TR34 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM TR55 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM TR18 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM TR3 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM TR13 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM TR40 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM TR61 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM TR62 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM TR42 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM TR16 2001-000745 R-CARBON;4.7OHM,5%,1/8W,AA,TP,1.8X3.2MM TR41 2001-000802 R-CARBON;5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m TR57 2001-000802 R-CARBON;5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m TSR1 2103-000290 VR-SEMI;20Kohm,30%,1/10W,TOP TC14 2201-000565 C-CERAMIC,DISC;47nF,20%,50V,Y5V,12.5x4.0mm,5mm,TP TC39 2201-000565 C-CERAMIC,DISC;47nF,20%,50V,Y5V,12.5x4.0mm,5mm,TP RC9 2202-000796 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,3.5x19,TC40 2202-000796 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,3.5x19,TC42 2202-000796 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,3.5x19,TC48 2202-000807 C-CERAMIC,MLC-AXIAL;22NF,+80-20%,25V,Y5V,TP,3.5X19 TC21 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5 TC46 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5 TC12 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5 TC26 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5 TC27 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5 TC30 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5 RC1 2401-000907 C-AL;22UF,20%,16V,GP,-,5X11,2MM TC34 2401-000907 C-AL;22UF,20%,16V,GP,-,5X11,2MM TC37 2401-001022 C-AL;3.3UF,20%,50V,GP,-,5X11,2MM TC38 2401-001164 C-AL;33UF,20%,16V,GP,-,5X11,2MM TC47 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m TC11 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK TC17 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK TC19 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK TC16 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5 TC23 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5 TC25 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5 TC18 2401-001968 C-AL;470NF,20%,50V,GP,TP,5X11MM,5 TC43 2401-001968 C-AL;470NF,20%,50V,GP,TP,5X11MM,5 TC4 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5 TC9 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5 RC6 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM RIC1 AH14-10008E IC;BU1923F,SOP,+5V

AH94-10015R ASSY-PCB,CD,MANU;CMS55HK/E, S.N.A.

VVC1 0405-000137 DIODE-VARACTOR;KV-1260,20V,100NA,T0-92S TFL4 14529-304-610 FILTER CERAMIC;AHCM2-450BL JA 2202-000263 C-CERAMIC,MLC-AXIAL;470pF,10%,50V,Y5P,TP,3.5x19,PACK 2202-000263 C-CERAMIC,MLC-AXIAL;470pF,10%,50V,Y5P,TP,3.5x19,TO 2202-000263 C-CERAMIC,MLC-AXIAL;470pF,10%,50V,Y5P,TP,3.5x19,TX1 2801-000734 CRYSTAL-UNIT;7.2MHZ,50PPM,28-AAM,12PF,30OHM RX1 2801-003601 CRYSTAL-UNIT;4.332MHz,30ppm,28-AAM,30pF, TFL2 2903-000105 FILTER-CERAMIC;BP,10.7MHZ+-25KHZ,180KHZ+-50KH TFL1 2903-000119 FILTER-CERAMIC;SFE10.7MJA-10-A TWA1 3710-001421 CONNECTOR-SOCKET;14P,1R,2mm,ANGLE,SN TJ2 3711-000814 CONNECTOR-HEADER;BOX,2P,1R,2.5mm,ANGLE,SN TJ1 3716-000210 TERMINAL-BLOCK;-,-,-,60V,7A HIC1 AH14-10007G IC;LC72131,DIP,STICK PLL TIC1 AH14-10008B IC;LA1837,DIP,RF+MPX TLPF1 AH26-00005A TRANS-IF;-,LKS75M00-X000264-0,LOW PASS FILTER,-,7 TLPF2 AH26-00005A TRANS-IF;-,LKS75M00-X000264-0,LOW PASS FILTER,-,7

Location no. Code no. Description & Specifiation Remarks

3. Electrical Parts List

*S.N.A. : Service Not Available

Location no. Code no. Description & Specifiation Remarks Location no. Code no. Description & Specifiation Remarks

3-2 Samsung Electronics

TL2 AH26-10001E TRANS-IF;KS940228-09,-,-,7.6X12.0,-,450KHZ,BULK, TL3 AH26-10020A TRANS-DET;-,7KLL,DET,-,7.8MM,91PF,11.32M LW AH27-00007A COIL-OSC;LKS7FB00-0060BLO-0,-,LW OSC OSC AH27-00007A COIL-OSC;LKS7FB00-0060BLO-0,-,LW OSC MW AH27-00008A COIL-OSC;LKS75M00-0060LMO-0,-,MW OSC OSC AH27-00008A COIL-OSC;LKS75M00-0060LMO-0,-,MW OSC ANT AH27-00011A COIL-OSC;LKS75M00-X000262-0,-,LW ANT LW AH27-00011A COIL-OSC;LKS75M00-X000262-0,-,LW ANT ANT AH27-00012A COIL-OSC;LKS75M00-X000263-0,365UH,MW ANT MW AH27-00012A COIL-OSC;LKS75M00-X000263-0,365UH,MW ANT

AH39-00134A LEAD-PASTEN;-,-,-,-,-,-,-,DP,RING,-,1P,50MM,1007#24 FM AH40-10025S TUNER-FM;KST-F404VA-1,4G,75ohm PACK AH40-10025S TUNER-FM;KST-F404VA-1,4G,75ohm PCB AH41-10599A PCB-LW PCB;MAX980LW,1L,FR-1,247*163*1.6T* FREE AH61-20540A HOLDER-TUNER;-,ABS,94HB,BLK,-,MAX940

AH92-00512E ASSY MAIN PCB;MAXN50RH,OPTICAL S.N.A.

FD1 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP FD2 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP JD1 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP JD2 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP JD3 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP RD7 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP RD8 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP RD14 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP RD3 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP RD4 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP RD5 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP RD6 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP RD9 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP RD10 0402-000151 DIODE-RECTIFIER;1N5392,100V,1.5A,DO-15,TP RD11 0402-000151 DIODE-RECTIFIER;1N5392,100V,1.5A,DO-15,TP RD12 0402-000151 DIODE-RECTIFIER;1N5392,100V,1.5A,DO-15,TP RD13 0402-000151 DIODE-RECTIFIER;1N5392,100V,1.5A,DO-15,TP FZD1 0403-000377 DIODE-ZENER;UZP10B,10V,9.4-10.6V,1W,DO-41, RZD4 0403-000393 DIODE-ZENER;UZP5.1B,5.1V,4.8-5.4V,1W,DO-41 RZD5 0403-000396 DIODE-ZENER;UZP6.8B,6.8V,6.4-7.2V,1W,DO-41 RZD6 0403-000399 DIODE-ZENER;UZP9.1B,8.5-9.6V,1W,DO-41,TP RZD2 0403-000564 DIODE-ZENER;TZP16A,16V,15.3-17.1V,1W,DO-41 RZD3 0403-000564 DIODE-ZENER;TZP16A,16V,15.3-17.1V,1W,DO-41 JQ2L 0501-000010 TR-SMALL SIGNAL;KSC1008,NPN,800mW,TO-92,TP,120 JQ2R 0501-000010 TR-SMALL SIGNAL;KSC1008,NPN,800mW,TO-92,TP,120 JQ3L 0501-000010 TR-SMALL SIGNAL;KSC1008,NPN,800mW,TO-92,TP,120 JQ3R 0501-000010 TR-SMALL SIGNAL;KSC1008,NPN,800mW,TO-92,TP,120 RQ10 0501-000010 TR-SMALL SIGNAL;KSC1008,NPN,800mW,TO-92,TP,120 RQ7 0501-000010 TR-SMALL SIGNAL;KSC1008,NPN,800mW,TO-92,TP,120 AQ4 0501-000294 TR-SMALL SIGNAL;KSA708-Y,PNP,800mW,TO-92,TP,12 RQ4 0501-000294 TR-SMALL SIGNAL;KSA708-Y,PNP,800mW,TO-92,TP,12 RQ8 0501-000294 TR-SMALL SIGNAL;KSA708-Y,PNP,800mW,TO-92,TP,12 JQ15 0501-000369 TR-SMALL SIGNAL;KSC2331-Y,NPN,1W,TO-92L,-,120FQ3L 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120FQ3R 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120FQ4 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120JQ12L 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120JQ12R 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120JQ16 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120JQ4L 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120JQ4R 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120RQ3 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120RQ5 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120AQ1L 0501-000407 TR-SMALL SIGNAL;KSD471A-Y,NPN,800mW,TO-92,-,12 AQ1R 0501-000407 TR-SMALL SIGNAL;KSD471A-Y,NPN,800mW,TO-92,-,12 JQ11L 0501-000407 TR-SMALL SIGNAL;KSD471A-Y,NPN,800mW,TO-92,-,12 JQ11R 0501-000407 TR-SMALL SIGNAL;KSD471A-Y,NPN,800mW,TO-92,-,12 JQ5L 0501-000407 TR-SMALL SIGNAL;KSD471A-Y,NPN,800mW,TO-92,-,12 JQ5R 0501-000407 TR-SMALL SIGNAL;KSD471A-Y,NPN,800mW,TO-92,-,12 JQ14 0501-000610 TR-SMALL SIGNAL;KSA928A-Y,PNP,1W,TO-92L,TP,160 RQ2 0501-000610 TR-SMALL SIGNAL;KSA928A-Y,PNP,1W,TO-92L,TP,160 JQ10 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP JQ1L 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP JQ1R 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP JQ9L 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP JQ9R 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP FQ1L 0504-000122 TR-DIGITAL;KSR1009Y,NPN,300mW,4.7K,TO-92, FQ1R 0504-000122 TR-DIGITAL;KSR1009Y,NPN,300mW,4.7K,TO-92, AQ2 0504-001003 TR-DIGITAL;KSR2003,PNP,300MW,22K/22K,TO-92,TP FQ2 0504-001003 TR-DIGITAL;KSR2003,PNP,300MW,22K/22K,TO-92,TP FQ5 0504-001003 TR-DIGITAL;KSR2003,PNP,300MW,22K/22K,TO-92,TP JQ6 0504-001003 TR-DIGITAL;KSR2003,PNP,300MW,22K/22K,TO-92,TP JQ8 0504-001003 TR-DIGITAL;KSR2003,PNP,300MW,22K/22K,TO-92,TP JR17L 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm JR17R 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm FR1L 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3.2MM FR1R 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR41L 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR41R 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3.2MM RR23 2001-000019 R-CARBON(S);10OHM,5%,1/2W,AA,TP,2.4X6.4MM JR27 2001-000023 R-CARBON;47OHM,5%,1/4W,AA,TP,2.4X6.4MM RR11 2001-000027 R-CARBON;100OHM,5%,1/4W,AA,TP,2.4X6.4MM RR14 2001-000027 R-CARBON;100OHM,5%,1/4W,AA,TP,2.4X6.4MM ER150 2001-000034 R-CARBON;220OHM,5%,1/4W,AA,TP,2.4X6.4MM FR4L 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM FR4R 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM FR30L 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM

FR30R 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR20L 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR20R 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR32L 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR32R 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM AR20 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2MM FR21 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2MM FR22 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2MM FR9 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM JR21 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM JR9L 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM JR9R 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM AR22L 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM AR22R 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM AR7 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM FR28 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR11L 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR11R 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR22 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR25 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR33 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR36L 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR36R 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR39 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR40 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM MR18 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM RR13 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM RR20 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM RR8 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR40L 2001-000302 R-CARBON;10OHM,5%,1/8W,AA,TP,1.8X3.2MM JR40R 2001-000302 R-CARBON;10OHM,5%,1/8W,AA,TP,1.8X3.2MM FR12L 2001-000411 R-CARBON;18KOHM,5%,1/8W,AA,TP,1.8X3.2MM FR12R 2001-000411 R-CARBON;18KOHM,5%,1/8W,AA,TP,1.8X3.2MM FR2L 2001-000411 R-CARBON;18KOHM,5%,1/8W,AA,TP,1.8X3.2MM FR2R 2001-000411 R-CARBON;18KOHM,5%,1/8W,AA,TP,1.8X3.2MM AR1L 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM AR1R 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM AR3L 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM AR3R 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM ER15 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM FR25 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM FR31 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR34L 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR34R 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR42L 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR42R 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM RR22 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM AR23L 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM AR23R 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM FR10L 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM FR10R 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR10L 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR10R 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR1L 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR1R 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR2L 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR2R 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR5L 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR5R 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR6L 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR6R 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM RR18 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR32 2001-000456 R-CARBON;2.2OHM,5%,1/4W,AA,TP,2.4X6.4MM FR13L 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM FR13R 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM FR18 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM AR11 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM ER2 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM FR19 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM FR26 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR19L 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR19R 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR4 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM RR12 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM RR17 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM RR9 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR16L 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR16R 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR23 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR30 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR3L 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR3R 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM JSR1R 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM RR7 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM AR17 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR24L 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR24R 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP,1.8X3.2MM RR1 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP,1.8X3.2MM RR2 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR15 2001-000708 R-CARBON;39OHM,5%,1/8W,AA,TP,1.8X3.2MM

- 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM FR20L 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM FR20R 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM FR24 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM

JR12L 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR12R 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR18L 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR18R 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR26 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR28L 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR28R 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM RR10 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM RR15 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM RR16*2 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM FR23 2001-000773 R-CARBON;470KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR13 2001-000773 R-CARBON;470KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR35L 2001-000773 R-CARBON;470KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR35R 2001-000773 R-CARBON;470KOHM,5%,1/8W,AA,TP,1.8X3.2MM FR27L 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM FR27R 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM FR5L 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM FR5R 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR29 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR37L 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR37R 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM FR8L 2001-000802 R-CARBON;5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m FR8R 2001-000802 R-CARBON;5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m JR14 2001-000802 R-CARBON;5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m AR2L 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM AR2R 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM AR4L 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM AR4R 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM AR6L 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM AR6R 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM FR6L 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM FR6R 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR38 2001-000890 R-CARBON;6.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR7L 2001-000890 R-CARBON;6.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM JR7R 2001-000890 R-CARBON;6.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM AR5L 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM AR5R 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM FR28L 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM FR28R 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM FR14 2001-000995 R-CARBON;820OHM,5%,1/8W,AA,TP,1.8X3.2MM FR50 2001-000995 R-CARBON;820OHM,5%,1/8W,AA,TP,1.8X3.2MM AR16 2001-001088 R-CARBON(S);1KOHM,5%,1/2W,AA,TP,2.4X6.4MM RR19 2001-001096 R-CARBON(S);2.2OHM,5%,1/2W,AA,TP,2.4X6.4MM RR3 2001-001146 R-CARBON(S);4.7OHM,5%,1/2W,AA,TP,2.4X6.4MM RR5 2001-001153 R-CARBON(S);47ohm,5%,1/2W,AA,TP,2.4x6.4mm RR6 2001-001153 R-CARBON(S);47ohm,5%,1/2W,AA,TP,2.4x6.4mm AR10L 2003-000689 R-METAL OXIDE(S);4.7ohm,5%,1W,AA,TP,3.3x9mm AR10R 2003-000689 R-METAL OXIDE(S);4.7ohm,5%,1W,AA,TP,3.3x9mm RR21 2003-000689 R-METAL OXIDE(S);4.7ohm,5%,1W,AA,TP,3.3x9mm AR9 2008-000153 R-FUSIBLE;33ohm,5%,1/2W,AA,TP,3.5x9.4mm JSR2L 2103-000248 VR-SEMI;200KOHM,30%,1/10W,TOP JSR2R 2103-000248 VR-SEMI;200KOHM,30%,1/10W,TOP JSR1L 2103-000492 VR-SEMI;5KOHM,30%,1/10W,TOP RC16 2201-000163 C-CERAMIC,DISC;10nF,+80-20%,50V,Y5V,TP,7x3,2.5 RC17 2201-000163 C-CERAMIC,DISC;10nF,+80-20%,50V,Y5V,TP,7x3,2.5 RC20 2201-000163 C-CERAMIC,DISC;10nF,+80-20%,50V,Y5V,TP,7x3,2.5 RC21 2201-000163 C-CERAMIC,DISC;10nF,+80-20%,50V,Y5V,TP,7x3,2.5 AC10L 2201-000198 C-CERAMIC,DISC;10pF,0.5pF,50V,SL,TP,5x3.5,5 AC10R 2201-000198 C-CERAMIC,DISC;10pF,0.5pF,50V,SL,TP,5x3.5,5 AC2L 2201-000368 C-CERAMIC,DISC;220PF,10%,50V,SL,TP,6.5X3.0,5 AC2R 2201-000368 C-CERAMIC,DISC;220PF,10%,50V,SL,TP,6.5X3.0,5 FC13L 2201-000368 C-CERAMIC,DISC;220PF,10%,50V,SL,TP,6.5X3.0,5 FC13R 2201-000368 C-CERAMIC,DISC;220PF,10%,50V,SL,TP,6.5X3.0,5 FC1L 2201-000368 C-CERAMIC,DISC;220PF,10%,50V,SL,TP,6.5X3.0,5 FC1R 2201-000368 C-CERAMIC,DISC;220PF,10%,50V,SL,TP,6.5X3.0,5 JC10L 2201-000368 C-CERAMIC,DISC;220PF,10%,50V,SL,TP,6.5X3.0,5 JC10R 2201-000368 C-CERAMIC,DISC;220PF,10%,50V,SL,TP,6.5X3.0,5 JC16L 2201-000368 C-CERAMIC,DISC;220PF,10%,50V,SL,TP,6.5X3.0,5 JC16R 2201-000368 C-CERAMIC,DISC;220PF,10%,50V,SL,TP,6.5X3.0,5 JC1L 2201-000368 C-CERAMIC,DISC;220PF,10%,50V,SL,TP,6.5X3.0,5 JC1R 2201-000368 C-CERAMIC,DISC;220PF,10%,50V,SL,TP,6.5X3.0,5 JC30L 2201-000368 C-CERAMIC,DISC;220PF,10%,50V,SL,TP,6.5X3.0,5 JC30R 2201-000368 C-CERAMIC,DISC;220PF,10%,50V,SL,TP,6.5X3.0,5 JC23L 2201-000470 C-CERAMIC,DISC;330pF,10%,50V,SL,TP,6.5x3,5 JC23R 2201-000470 C-CERAMIC,DISC;330pF,10%,50V,SL,TP,6.5x3,5 AC20 2201-000547 C-CERAMIC,DISC;4.7nF,20%,500V,Y5T,TP,14x3,5 AC1L 2201-000557 C-CERAMIC,DISC;0.47nF,10%,50V,SL,TP,8x3.5,5 AC1R 2201-000557 C-CERAMIC,DISC;0.47nF,10%,50V,SL,TP,8x3.5,5 JC24L 2201-000674 C-CERAMIC,DISC;0.82nF,10%,50V,Y5P,BK,5x3,2.5 JC24R 2201-000674 C-CERAMIC,DISC;0.82nF,10%,50V,Y5P,BK,5x3,2.5 JC88 2201-000674 C-CERAMIC,DISC;0.82nF,10%,50V,Y5P,BK,5x3,2.5 JC999 2201-000674 C-CERAMIC,DISC;0.82nF,10%,50V,Y5P,BK,5x3,2.5 JC50 2201-000783 C-CERAMIC,DISC;100nF,+80-20%,50V,Y5V,TP,8x3,5 JC51 2202-000780 C-CERAMIC,MLC-AXIAL;100NF,+80-20%,50V,Y5V,3.5X19,FC12L 2202-000806 C-CERAMIC,MLC-AXIAL;220pF,10%,50V,Y5P,TP,3.5x19,FC12R 2202-000806 C-CERAMIC,MLC-AXIAL;220pF,10%,50V,Y5P,TP,3.5x19,AC13L 2202-000817 C-CERAMIC,MLC-AXIAL;4.7NF,20%,16V,Y5R,TP,3.5X19,AC13R 2202-000817 C-CERAMIC,MLC-AXIAL;4.7NF,20%,16V,Y5R,TP,3.5X19,JC2L 2202-000829 C-CERAMIC,MLC-AXIAL;.82NF,10%,50V,Y5P,TP,3.5X1.9MM,JC2R 2202-000829 C-CERAMIC,MLC-AXIAL;.82NF,10%,50V,Y5P,TP,3.5X1.9MM,AC9L 2301-000375 C-FILM,PEF;100nF,5%,50V,TP,11x12.5x6.5,7m AC9R 2301-000375 C-FILM,PEF;100nF,5%,50V,TP,11x12.5x6.5,7m FC10L 2301-000375 C-FILM,PEF;100nF,5%,50V,TP,11x12.5x6.5,7m

FC10R 2301-000375 C-FILM,PEF;100nF,5%,50V,TP,11x12.5x6.5,7m FC9L 2301-000375 C-FILM,PEF;100nF,5%,50V,TP,11x12.5x6.5,7m FC9R 2301-000375 C-FILM,PEF;100nF,5%,50V,TP,11x12.5x6.5,7m JC26 2301-000404 C-FILM,PEF;2.2NF,10%,50V,TP,5.5X7X3.2MM,5 JC27 2301-000404 C-FILM,PEF;2.2NF,10%,50V,TP,5.5X7X3.2MM,5 JC22L 2301-000407 C-FILM,PEF;2.7NF,10%,50V,TP,5.5X7X3MM,5MM JC22R 2301-000407 C-FILM,PEF;2.7NF,10%,50V,TP,5.5X7X3MM,5MM JC29 2301-000407 C-FILM,PEF;2.7NF,10%,50V,TP,5.5X7X3MM,5MM JC17L 2301-000412 C-FILM,PEF;22NF,10%,50V,TP,6.5X10.5X4MM,5 JC17R 2301-000412 C-FILM,PEF;22NF,10%,50V,TP,6.5X10.5X4MM,5 JC4L 2301-000412 C-FILM,PEF;22NF,10%,50V,TP,6.5X10.5X4MM,5 JC4R 2301-000412 C-FILM,PEF;22NF,10%,50V,TP,6.5X10.5X4MM,5 JC8L 2301-000412 C-FILM,PEF;22NF,10%,50V,TP,6.5X10.5X4MM,5 JC8R 2301-000412 C-FILM,PEF;22NF,10%,50V,TP,6.5X10.5X4MM,5 JC18L 2301-000422 C-FILM,PEF;3.3NF,10%,50V,TP,5.5X7X3MM,5MM JC18R 2301-000422 C-FILM,PEF;3.3NF,10%,50V,TP,5.5X7X3MM,5MM FC8L 2301-000454 C-FILM,PEF;5.6NF,10%,50V,TP,6X12X3,3.5MM FC8R 2301-000454 C-FILM,PEF;5.6NF,10%,50V,TP,6X12X3,3.5MM JC19L 2301-000462 C-FILM,PEF;6.8NF,10%,50V,TP,6X12X3,3.5MM JC19R 2301-000462 C-FILM,PEF;6.8NF,10%,50V,TP,6X12X3,3.5MM JC9 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5 AC6 2401-000357 C-AL;100UF,20%,50V,GP,-,8X11.5,3.5M AC8 2401-000357 C-AL;100UF,20%,50V,GP,-,8X11.5,3.5M AC4L 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5 AC4R 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5 AC897 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5 FC19 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5 FC50 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5 FC9 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5 JC12L 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5 JC12R 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5 JC20L 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5 JC20R 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5 JC21L 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5 JC21R 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5 JC7 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5 RC7 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5 RC8 2401-000438 C-AL;10uF,20%,25V,GP,-,5x11,2mm JC11 2401-000795 C-AL;220UF,20%,16V,GP,-,8X11.5,3.5M AC3L 2401-001164 C-AL;33UF,20%,16V,GP,-,5X11,2MM AC3R 2401-001164 C-AL;33UF,20%,16V,GP,-,5X11,2MM JC14L 2401-001465 C-AL;47UF,20%,10V,GP,-,5X11,2MM JC14R 2401-001465 C-AL;47UF,20%,10V,GP,-,5X11,2MM JC31 2401-001465 C-AL;47UF,20%,10V,GP,-,5X11,2MM JC3L 2401-001465 C-AL;47UF,20%,10V,GP,-,5X11,2MM JC3R 2401-001465 C-AL;47UF,20%,10V,GP,-,5X11,2MM

- 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m RC12 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m RC19 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m FC2L 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK FC2R 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK FC3L 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK FC3R 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK FC4L 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK FC4R 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK FC5L 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK FC5R 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK RC8 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK FC14L 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5 FC14R 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5 FC15 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5 FC18 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5 JC10 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5 JC5L 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5 JC5R 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5 RC10 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5 FC11 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5 JC25 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5 JC28 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5 FC16 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM FC6L 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM FC6R 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM FC7L 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM FC7R 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM JC13L 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM JC13R 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM JC15L 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM JC15R 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM RC11 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM RC5 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM RC6 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM RL2 2701-000178 INDUCTOR-AXIAL;33uH,10%,3x7mm JL1 2701-000298 INDUCTOR-AXIAL;470uH,10%,4.2x9.8mm RL1 2701-000298 INDUCTOR-AXIAL;470uH,10%,4.2x9.8mm

- 3602-000147 FUSE-CLIP;250V,7.5A,30MOHM RF2*2 3602-000147 FUSE-CLIP;250V,7.5A,30MOHM AL2L 3811-000389 WIRE-NO SHEATH CU;SPCW,300V,52.4MM,1/0.5MM,-,AL2R 3811-000389 WIRE-NO SHEATH CU;SPCW,300V,52.4MM,1/0.5MM,-,RBD1 0402-001258 DIODE-BRIDGE;GBU606,600V,6A,SIP-4,BK RQ1 0502-000424 TR-POWER;2SB1566-F,PNP,2W,TO-220FN,BK,1

0502-000425 TR-POWER;2SD2395-F,NPN,2W,TO-220FN,BK,1 RQ6 0502-000425 TR-POWER;2SD2395-F,NPN,2W,TO-220FN,BK,1 RQ9 0502-000425 TR-POWER;2SD2395-F,NPN,2W,TO-220FN,BK,1

Location no. Code no. Description & Specifiation Remarks Location no. Code no. Description & Specifiation Remarks

Samsung Electronics 3-3

FIC2 1201-000163 IC-OP AMP;4560,SOP,8P,173MIL,DUAL,100V/mV,PLASTIC, FIC3 1201-000163 IC-OP AMP;4560,SOP,8P,173MIL,DUAL,100V/mV,PLASTIC, JIC1 1201-000358 IC-PREAMP;22291,DIP,24P,-,DUAL,-,PLASTIC AIC1 1201-001575 IC-POWER AMP;402,SIP,14P,46MIL,SINGLE,40,PALSTIC,56V, RIC3 1203-000110 IC-NEGA.FIXED REG.;7912,TO-220,3P,-,PLASTIC,-11.5 RIC1 1203-000242 IC-POSI.FIXED REG.;7812,TO-220,3P,-,PLASTIC,11.5/ RIC2 1203-000276 IC-POSI.FIXED REG.;7805,TO-220,3P,-,PLASTIC,4.8/5 FIC1 1204-001465 IC-VOLUME/TONE CONT.;TDA7440D,SOP,28,18.1,PLASTIC,1 AR14L 2003-000390 R-METAL OXIDE(S);0.27OHM,5%,2W,AA,TP,4X12MM AR14R 2003-000390 R-METAL OXIDE(S);0.27OHM,5%,2W,AA,TP,4X12MM AR15L 2003-000390 R-METAL OXIDE(S);0.27OHM,5%,2W,AA,TP,4X12MM AR15R 2003-000390 R-METAL OXIDE(S);0.27OHM,5%,2W,AA,TP,4X12MM RFR7 2003-000689 R-METAL OXIDE(S);4.7ohm,5%,1W,AA,TP,3.3x9mm RR4 2003-000701 R-METAL OXIDE(S);470ohm,5%,2W,AA,TP,4x12mm AR8 2008-000122 R-FUSIBLE;100OHM,5%,1W,AA,TP,4.3X13MM RC13 2201-000546 C-CERAMIC,DISC;4.7NF,20%,400V,Y5U,BK,16X7,10 RC14 2201-000546 C-CERAMIC,DISC;4.7NF,20%,400V,Y5U,BK,16X7,10 RC9 2401-000230 C-AL;100uF,20%,100V,GP,TP,12.5x20,5 AC13 2401-000871 C-AL;220uF,20%,50V,GP,-,10x16mm,5mm RC4 2401-001886 C-AL;1000UF,20%,35V,GP,BK,16X25MM,5 RC1 2401-001942 C-AL;3300uF,20%,35V,GP,BK,18x35.5mm RC2 2401-001942 C-AL;3300uF,20%,35V,GP,BK,18x35.5mm RC3 2401-003116 C-AL;4700uF,20%,35V,-,BK,18X35.5,7. RF2 3601-000304 FUSE-CARTRIDGE;250V,630mA,TIME-LAG,GLASS,5x20mm FCW1 3710-001567 CONNECTOR-SOCKET;10P,1R,1.25mm,ANGLE,SN FCW2 3710-001568 CONNECTOR-SOCKET;22P,1R,1.25mm,ANGLE,SN RCW2 3711-000190 CONNECTOR-HEADER;1WALL,2P,1R,7.92MM,STRAIGHT,SN JCW3 3711-000907 CONNECTOR-HEADER;BOX,3P,1R,2mm,STRAIGHT,SN CCW1 3711-002809 CONNECTOR-HEADER;BOX,8P,1R,2mm,STRAIGHT,SN JCW1 3711-003107 CONNECTOR-HEADER;BOX,3P,1R,2.5mm,STRAIGHT,SN RCW4 3711-003107 CONNECTOR-HEADER;BOX,3P,1R,2.5mm,STRAIGHT,SN JCW2 3711-003111 CONNECTOR-HEADER;BOX,6P,1R,2.5mm,-,BRAS RCW1 3711-003113 CONNECTOR-HEADER;BOX,9P,1R,2.5MM,STRAIGHT,SN TCW1 3711-004109 CONNECTOR-HEADER;3WALL,14P,1R,2mm,STRAIGHT,SN SPK 3716-000209 TERMINAL-BLOCK;,-,-,60V,7A AUX 3722-000377 JACK-RCA;4P/2C,3.5MM,SN,BLK,#16~22 JLPF1L AH26-10002W COIL-TRAP;BIAS-TRAP105K,BIAS-TRAP,32DB,9.0,100PF,1 JLPF1R AH26-10002W COIL-TRAP;BIAS-TRAP105K,BIAS-TRAP,32DB,9.0,100PF,1 JL2 AH26-10003C COIL-TRAP;PCHNS-5371EQJ,BIAS-TRAP,-,-,850PF,105KHZ JL1L AH27-10001D COIL-CHOKE;5.6MH,K,Q80,-,-,-,-,-, JL1R AH27-10001D COIL-CHOKE;5.6MH,K,Q80,-,-,-,-,-, RL3 AH27-10001F COIL-CHOKE;27UH,K,Q30,-,-,DR(6.5*7.5),-,-, RL4 AH27-10001F COIL-CHOKE;27UH,K,Q30,-,-,DR(6.5*7.5),-,-, AL3L AH27-90001A COIL-SPRING;,2.2UH,-,-,SPRING AL3R AH27-90001A COIL-SPRING;,2.2UH,-,-,SPRING AL4L AH27-90001A COIL-SPRING;,2.2UH,-,-,SPRING AL4R AH27-90001A COIL-SPRING;,2.2UH,-,-,SPRING RCW1 AH39-00144A LEAD-CONNECTOR,ASS’Y;-,-,-,-,1007#22,-,-,-,5264,51088,-,-,HCW1 AH39-00157D CONNECT WIRE;-,-,-,H/P LINE(MAIN),1007#22/24,-,BLK,WH OJACK 0603-001051 OPTIC TRANSMITTER;5V,6Mb/s,5m,-15dBm,660nm,20mA OC1 2201-000381 C-CERAMIC,DISC;22NF,20%,50V,Y5V,8.0x4.0mm,5mm,TP OC2 2201-000487 C-CERAMIC,DISC;33pF,5%,50V,SL,TP,5x3,5m OC3 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m OLPF 2901-001139 FILTER-EMI ON BOARD;50V,.5A,-,390PF,7X2.5X5MM,TP,RADIAL JW118 3301-000297 CORE-FERRITE BEAD;AA,3.6x1.2x5.7mm,1400,2900G JW145 3301-000297 CORE-FERRITE BEAD;AA,3.6x1.2x5.7mm,1400,2900G OCW 3711-000907 CONNECTOR-HEADER;BOX,3P,1R,2mm,STRAIGHT,SN OIC1 AH14-10004R IC;M74HCU04,SOP,TAPE 14P OCW AH39-00023A LEAD CONNECTOR-ASSY;-,51004-03,51004-03,03P,300MM,2547#28 WIRE AH39-00023A LEAD CONNECTOR-ASSY;-,51004-03,51004-03,03P,300MM,2547#28

AH92-00513C ASSY FRONT PCB;MAXN52,FRONT S.N.A.

AH39-00134A LEAD-PASTEN;-,-,-,-,-,-,-,DP,RING,-,1P,50MM,1007#24 ULD16 0601-001432 LED;ROUND,BLUE,3mm,455nm ULD19 0601-001432 LED;ROUND,BLUE,3mm,455nm UX2 2801-001394 CRYSTAL-UNIT;32.768KHz,20ppm,28-AAY,12.5pF, UX1 2802-000181 RESONATOR-CERAMIC;6MHZ,0.3%,BK,9.0X4.0X7.5MM E1 3406-001047 SWITCH-ROTARY;5V DC,0.5mA,-,12mm CDW1 3708-000178 CONNECTOR-FPC/FC/PIC;16P,1.25mm,ANGLE,SN

- 3708-000449 CONNECTOR-FPC/FC/PIC;7P,1.25MM,STRAIGHT, FCW3 3708-000449 CONNECTOR-FPC/FC/PIC;7P,1.25MM,STRAIGHT, CDW2 3708-000454 CONNECTOR-FPC/FC/PIC;22P,1.25MM,STRAIGHT, FCW4 3711-000907 CONNECTOR-HEADER;BOX,3P,1R,2mm,STRAIGHT,SN HCW1 3711-001011 CONNECTOR-HEADER;BOX,5P,1R,2.5mm,STRAIGHT,SN FCW1 3711-004420 CONNECTOR-HEADER;2WALL,10P,1R,1.25mm,ANGLE,SN FCW2 3711-004422 CONNECTOR-HEADER;2WALL,22P,1R,1.25mm,ANGLE,SN H/PHONE 3722-000363 JACK-PHONE;9P,6.4MM,AU,BLK,-

3809-001185 CABLE-FLAT;30V,80C,120mm,16P,1.25mm,UL2896

- 3809-001186 CABLE-FLAT;30V,80C,150mm,7P,1.25mm,UL2896 R1 AC59-60060A MODULE-REMOCON;GP1U281R,SHARP,38KHZ,-,-,-,VFD AH07-00022A VF DISPLAY;HNA-13MM15,17SEG,125*29,MAX-N55 UIC1 AH11-00022A MASK ROM;LC86P6548-XXXX,100P,QFP,N55,-,8BIT UIC2 AH14-10004L IC;NJU3718,SOP,BULK FCW4 AH39-00201A LEAD CONNECTOR-ASSY;-,1007#28,-,03P,250mm,-,-,35023-03,51004 GND AH39-50001L LEAD-FASTEN;RING,1007#24,200MM,BLK MJACK1 AH39-50001L LEAD-FASTEN;RING,1007#24,200MM,BLK

AH61-00357A HOLDER-VFD;-,ABS 94HB,-,BLK,-,MAX-N55

AH63-00149A FILTER-VFD;-,PC,0.3T,-,-,-,-,-,MAX-N55 CD1 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP CD2 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP CD3 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP UD1 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP UD11 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP

UD12 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP UD13 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP UD14 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP UD15 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP UD16 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP UD17 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP UD7 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP UQ10 0501-000294 TR-SMALL SIGNAL;KSA708-Y,PNP,800mW,TO-92,TP,12 CQ4 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120UQ1 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120CQ2 0501-000610 TR-SMALL SIGNAL;KSA928A-Y,PNP,1W,TO-92L,TP,160 CQ7 0501-000610 TR-SMALL SIGNAL;KSA928A-Y,PNP,1W,TO-92L,TP,160 CQ8 0501-000610 TR-SMALL SIGNAL;KSA928A-Y,PNP,1W,TO-92L,TP,160 CQ1 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP CQ3 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP CQ5 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP CQ6 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP UQ11 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP UQ2 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP UQ3 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP UQ4 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP UQ5 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP UQ6 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP UQ7 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP UQ8 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP ULD1 0601-001232 LED;TR,LED,1PCS,130-260% ULD10 0601-001232 LED;TR,LED,1PCS,130-260% ULD11 0601-001232 LED;TR,LED,1PCS,130-260% ULD2 0601-001232 LED;TR,LED,1PCS,130-260% ULD20 0601-001232 LED;TR,LED,1PCS,130-260% ULD21 0601-001232 LED;TR,LED,1PCS,130-260% ULD22 0601-001232 LED;TR,LED,1PCS,130-260% ULD23 0601-001232 LED;TR,LED,1PCS,130-260% ULD24 0601-001232 LED;TR,LED,1PCS,130-260% ULD30 0601-001232 LED;TR,LED,1PCS,130-260% ULD31 0601-001232 LED;TR,LED,1PCS,130-260% ULD4 0601-001232 LED;TR,LED,1PCS,130-260% ULD5 0601-001232 LED;TR,LED,1PCS,130-260% ULD7 0601-001232 LED;TR,LED,1PCS,130-260% ULD8 0601-001232 LED;TR,LED,1PCS,130-260% ULD12 0601-001236 LED;ROUND,AMB,3.1mm,610nm ULD3 0601-001236 LED;ROUND,AMB,3.1mm,610nm ULD6 0601-001236 LED;ROUND,AMB,3.1mm,610nm ULD9 0601-001236 LED;ROUND,AMB,3.1mm,610nm ULD14 0601-001238 LED;ROUND,RED,3.1mm,697nm ULD15 0601-001238 LED;ROUND,RED,3.1mm,697nm UR90 2001-000034 R-CARBON;220OHM,5%,1/4W,AA,TP,2.4X6.4MM AR24L 2001-000037 R-CARBON(S);330ohm,5%,1/2W,AA,TP,2.4x6.4mm AR24R 2001-000037 R-CARBON(S);330ohm,5%,1/2W,AA,TP,2.4x6.4mm UR67 2001-000037 R-CARBON(S);330ohm,5%,1/2W,AA,TP,2.4x6.4mm UR69 2001-000037 R-CARBON(S);330ohm,5%,1/2W,AA,TP,2.4x6.4mm UR71 2001-000037 R-CARBON(S);330ohm,5%,1/2W,AA,TP,2.4x6.4mm UR73 2001-000037 R-CARBON(S);330ohm,5%,1/2W,AA,TP,2.4x6.4mm UR13 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR24 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR34 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR14 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR25 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR35 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR15 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR26 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR36 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM CR1 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM CR13 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM CR14 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM CR15 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM CR2 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM CR3 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM CR4 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM CR5 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM CR6 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR42 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR43 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR44 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR45 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR46 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR47 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR48 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR49 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR50 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR51 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR52 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR53 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR55 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR56 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR57 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR58 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR7 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR8 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR9 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR96 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR6 2001-000295 R-CARBON;10MOHM,5%,1/8W,AA,TP,1.8X3.2MM UR66 2001-000325 R-CARBON;120OHM,5%,1/8W,AA,TP,1.8X3.2MM

Location no. Code no. Description & Specifiation Remarks Location no. Code no. Description & Specifiation Remarks

3-4 Samsung Electronics

UR68 2001-000325 R-CARBON;120OHM,5%,1/8W,AA,TP,1.8X3.2MM UR70 2001-000325 R-CARBON;120OHM,5%,1/8W,AA,TP,1.8X3.2MM UR72 2001-000325 R-CARBON;120OHM,5%,1/8W,AA,TP,1.8X3.2MM UR20 2001-000411 R-CARBON;18KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR31 2001-000411 R-CARBON;18KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR40 2001-000411 R-CARBON;18KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR12 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR23 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR33 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR74 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR75 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR76 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR77 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR78 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR79 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR80 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR81 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR82 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR83 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR84 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR87 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR88 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR93 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR94 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR95 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR5 2001-000435 R-CARBON;1MOHM,5%,1/8W,AA,TP,1.8X3.2MM UR2 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR3 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR92 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR16 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR27 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR91 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR4 2001-000508 R-CARBON;220KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR1 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM UR63 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM UR97 2001-000552 R-CARBON;270OHM,5%,1/4W,AA,TP,2.4X6.4MM CR11 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR17 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR28 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR37 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP,1.8X3.2MM CR10 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM CR12 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR10 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR21 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR41 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR54 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR18 2001-000802 R-CARBON;5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m UR29 2001-000802 R-CARBON;5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m UR38 2001-000802 R-CARBON;5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m UR22 2001-000850 R-CARBON;560KOHM,5%,1/8W,AA,TP,1.8X3.2MM

- 2001-000855 R-CARBON;560OHM,5%,1/4W,AA,TP,2.4X6.4MM UR64 2001-000855 R-CARBON;560OHM,5%,1/4W,AA,TP,2.4X6.4MM UR19 2001-000977 R-CARBON;8.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR30 2001-000977 R-CARBON;8.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR39 2001-000977 R-CARBON;8.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM UR11 2001-000995 R-CARBON;820OHM,5%,1/8W,AA,TP,1.8X3.2MM UR22 2001-000995 R-CARBON;820OHM,5%,1/8W,AA,TP,1.8X3.2MM UR32 2001-000995 R-CARBON;820OHM,5%,1/8W,AA,TP,1.8X3.2MM CR7 2001-001178 R-CARBON(S);680OHM,5%,1/2W,AA,TP,2.4X6.4MM CR8 2001-001178 R-CARBON(S);680OHM,5%,1/2W,AA,TP,2.4X6.4MM CR9 2001-001178 R-CARBON(S);680OHM,5%,1/2W,AA,TP,2.4X6.4MM CSR1 2103-000341 VR-SEMI;2Kohm,30%,1/10W,TOP UC8 2201-000389 C-CERAMIC,DISC;0.022nF,5%,50V,NP0,TP,5x3,5 UC9 2201-000389 C-CERAMIC,DISC;0.022nF,5%,50V,NP0,TP,5x3,5 UC4 2201-000825 C-CERAMIC,DISC;0.027nF,5%,50V,NP0,TP,5x3,5 UC5 2201-000825 C-CERAMIC,DISC;0.027nF,5%,50V,NP0,TP,5x3,5 AC17L 2202-000854 C-CERAMIC,MLC-AXIAL;47NF,30%,50V,Y5R,TP,3.5X1.9,AC17R 2202-000854 C-CERAMIC,MLC-AXIAL;47NF,30%,50V,Y5R,TP,3.5X1.9,UC13 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5 UC7 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5 UC6 2401-000244 C-AL;100uF,20%,10V,GP,TP,6.3x7,5 UC10 2401-000475 C-AL;10UF,20%,50V,GP,-,5X11,2MM UC11 2401-000475 C-AL;10UF,20%,50V,GP,-,5X11,2MM UC14 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK UC15 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK UC16 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK UC2 2401-001919 C-AL;2.2uF,20%,50V,-,TP,4x7mm,5 UC3 2401-001931 C-AL;220nF,20%,50V,-,TP,4x7mm,5 UC1 2409-000123 C-EDL;47000UF,4UA,5.5V,-,BK,-,5MM USW1 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST USW10 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST USW11 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST USW12 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST USW13 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST USW14 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST USW15 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST USW17 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST USW18 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST USW19 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST USW2 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST USW20 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST USW21 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST USW22 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST

USW23 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST USW24 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST USW25 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST USW26 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST USW27 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST USW29 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST USW3 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST USW30 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST USW31 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST USW32 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST USW33 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST USW34 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST USW35 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST USW4 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST USW5 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST USW6 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST USW7 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST USW8 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST USW9 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST UIC3 AC14-12001G IC;KA78L05,T,-

AH92-00577A ASSY PCB;MAX-N52,TAPE,DECK AH59-20006T DECK;ADR241AMW1,-,DC12V,-,-,MAXN55,-

G3V1-F ASSY DECK CDP;MAXN25/22 S.N.A.

2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM AH39-50001X LEAD-FASTEN;RING,1007#24,200MM,BLK

AH92-00005A ASSY-PCB-CD MAIN;G3VI,CD PACK S.N.A.

NQ1502 0501-000314 TR-SMALL SIGNAL;KSA812,PNP,150mW,SOT-23,TP,90NIC928 0904-001442 IC-DSP;9286,8Bit,QFP,80P,-,16.9344MHz,TR,CMOS,P NIC925 1003-000179 IC-MOTOR DRIVER;KA9258D,SOP,28P,-,SINGLE,-,ST, NIC922 1204-001286 IC-ASP;KB9223,QFP,80P,-,PLASTIC,6V,20 JW1 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012 JW10 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012 JW11 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012 JW12 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012 JW14 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012 JW2 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012 JW24 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012 JW25 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012 JW3 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012 JW30 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012 JW32 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012 JW34 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012 JW35 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012 JW5 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012 JW6 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012 JW9 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012 JW13 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216 JW15 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216 JW16 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216 JW17 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216 JW18 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216 JW19 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216 JW20 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216 JW21 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216 JW22 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216 JW23 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216 JW26 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216 JW27 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216 JW28 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216 JW29 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216 JW30 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216 JW31 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216 JW33 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216 JW4 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216 JW7 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216 JW8 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216 NR109 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012 NR203 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012 NR300 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012 NR57L 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012 NR57R 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012 NR606 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012 NR602 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012 NR603 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012 NR104 2007-000338 R-CHIP;120KOHM,5%,1/10W,DA,TP,2012 NR107 2007-000338 R-CHIP;120KOHM,5%,1/10W,DA,TP,2012 NR100 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012 NR120 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012 NR121 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012 NR204 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012 NR103 2007-000395 R-CHIP;150KOHM,5%,1/10W,DA,TP,2012 NR119 2007-000395 R-CHIP;150KOHM,5%,1/10W,DA,TP,2012 NR13 2007-000395 R-CHIP;150KOHM,5%,1/10W,DA,TP,2012 NR400 2007-000409 R-CHIP;15KOHM,5%,1/10W,DA,TP,2012 NR115 2007-000444 R-CHIP;180KOHM,5%,1/10W,DA,TP,2012 NR10 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012 NR11 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012 NR12 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012 NR4 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012 NR5 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012 NR54L 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012

Location no. Code no. Description & Specifiation Remarks Location no. Code no. Description & Specifiation Remarks

Samsung Electronics 3-5
