Samsung LA32D403 User Manual

LCD TV

E-MANUAL

User Manual

imagine the possibilities

Thank you for purchasing this Samsung product.
To receive more complete service, please register
your product at

www.samsung.com/register

Model _____________ Serial No. _____________

For more information on how to use e-Manual (P.10)

Figures and illustrations in this User Manual are provided for reference only and may differ from actual product appearance.
Product design and specifications may be changed without notice.

Still image warning

Avoid displaying still images (like jpeg picture files) or still image element (like TV programme logo, panorama or 4:3 image
format, stock or news bar at screen bottom etc.) on the screen. Constant displaying of still picture can cause ghosting of LCD
screen, which will affect image quality. To reduce risk of this effect, please follow below recommendations:

• Avoid displaying the same TV channel for long periods.

• Always try do display any image on full screen, use TV set picture format menu for best possible match.

• Reduce brightness and contrast values to minimum required to achieve desired picture quality, exceeded values may speed

up the burnout process.

• Frequently use all TV features designed to reduce image retention and screen burnout, refer to proper user manual section
for details.

Securing the Installation Space

Keep the required distances between the product and other objects (e.g. walls) to ensure proper ventilation.
Failing to do so may result in fire or a problem with the product due to an increase in the internal temperature of the product.

When using a stand or wall-mount, use parts provided by Samsung Electronics only.

✎

• If you use parts provided by another manufacturer, it may result in a problem with the product or an injury due to the

product falling.

The appearance may differ depending on the product.

✎

Be careful when you contact the TV because some parts can be somewhat hot.

✎

Installation with a stand. Installation with a wall-mount.

10 cm

10 cm

10 cm10 cm

10 cm

10 cm

10 cm

English - 2

Accessories

✎

Please make sure the following items are included with your T V. If any items are missing, contact your dealer.

✎

The items’ colours and shapes may vary depending on the models.

y Remote Control & Batteries (AAA x 2)
y Owner’s Instructions
y Warranty Card / Safety Guide (Not available in some locations)

y Cleaning Cloth
y Power Cord

Viewing the Control Panel

✎

The product colour and shape may vary depending on the model.

Control Panel

Speakers

Remote control sensor Aim the remote control towards this spot on the TV.

Power Indicator Blinks and turns off when the power is on and lights up in standby mode.

SOURCE

MENU Displays an on-screen menu, the OSD (on screen display) of your TV’s features.

y

z

P

E

(Power)

Toggles between all the available input sources. In the on-screen menu, use this
button as you would use the ENTERE button on the remote control.

Adjusts the volume. In the OSD, use the
and ► buttons on the remote control.

Changes the channels. In the OSD, use the
▼ and ▲ buttons on the remote control.

Turns the TV on or off.

y

z

buttons as you would use the ◄

buttons as you would use the

Standby mode

Do not leave your TV in standby mode for long periods of time (when you are away on a holiday, for example). A small amount
of electric power is still consumed even when the power button is turned off. It is best to unplug the power cord.

English - 3

Viewing the Remote Control

Turns the TV on and off.

Press to directly access to channels.

Alternately select Teletext ON, Double,

Mix or OFF.

Adjusts the volume.

Displays the main on-screen menu.

Displays the My Downloads, Watch TV

and Source.

Quickly select frequently used functions.

Selects the on-screen menu items and
changes the values seen on the menu.

Returns to the previous menu.

Use these buttons in a specific feature.

For details, refer to the e-Manual.

CONTENT

A B C D

P.SIZE

E-MANUAL

AD/SUBT.

Displays and selects the available video
sources.

Returns to the previous channel.

Cuts off the sound temporarily.

Changes channels.

Displays channel lists on the screen.

Displays the EPG (Electronic Programme
Guide).

Displays information on the TV screen.

Exits the menu.

E-MANUAL: Displays the e-Manual

guide.

P.SIZE: Selects the picture size.
AD/SUBT.: Audio Description selection.

(Not available in some
locations) / Displays digital
subtitles.

Installing batteries (Battery size: AAA)

English - 4

Connecting to an Antenna

When the TV is initially powered on, basic settings proceed automatically.

✎

Preset: Connecting the mains and antenna.

✎

The position of power input port may differ depending on the model.

TV Rear Panel

or

VHF/UHF AntennaCable

Plug & Play (Initial Setup)

When the TV is initially powered on, a sequence of on-screen prompts will assist in configuring basic settings. Press the

POWERP button. Plug & Play is available only when the Source is set to TV.

✎

To return to the previous step, press the Red button.

Selecting a language

1

Selecting Store Demo or
Home Use

Selecting a country

2

Selecting an area

Setting the Clock Mode Set the Clock Mode automatically or manually.

3

Selecting a channel Select the desired broadcasting signal.

4

Enjoy your TV.

5

Press the ▲ or ▼ button, then press the ENTERE button.
Select the desired OSD (On Screen Display) language.

(Not available in some locations)

Press the ◄ or ► button, then press the ENTERE button.
Select the Home Use mode. Store Demo mode is for retail environments.
To return the unit’s settings from Store Demo to Home Use (standard):

Press the volume button on the TV. When the OSD volume is displayed,
press and hold MENU for 5 sec.

Store Demo is only for shop display. If you select it, several functions are not
able to use. Please select Home Use when you watch at home.

Press the ▲ or ▼ button, then press the ENTERE button.
Select the appropriate country. (Not available in some locations)

Press the ▲ or ▼ button, then press the ENTERE button.
Select the appropriate area. (Not available in some locations)

✎

If you select the Auto, select the time zone which you live. (Australia only)

Press the ◄ or ► button, then press the ENTERE button.
For more information, refer to Channel → Auto Tuning.

Press the ENTERE button at any time to interrupt the memorisation process.

Press the ENTERE button.

POWER

P

If You Want to Reset This Feature...

Select System - Plug & Play (Initial Setup). Enter your 4 digit PIN number. The default PIN number is “0-0-0-0”. If you want to
change the PIN number, use the Change PIN function.

You should do Plug & Play (MENU → System) again at home although you did in shop.

✎

If you forget the PIN code, press the remote control buttons in the following sequence in Standby mode, which resets
the PIN to “0-0-0-0” : MUTE → 8 → 2 → 4 → POWER (on)

English - 5

Connecting to an AV devices

¦ Available devices: DVD, Blu-ray player, HD cable box, HD STB (Set-Top-Box) satellite

receiver, VCR, Digital Audio System, Amplifier, DVD Home Theatre, PC

* The image may differ depending on the model.

HDMI connection

TV Rear

HDMI OUT

Using an HDMI or HDMI/DVI cable (up to 1080p)

✎

HDMI IN(DVI)

If an HDMI to DVI cable is connected to the HDMI IN(DVI) port, the audio does not work.

x

The picture may not display normally (if at all) or the audio may not work if an external device that uses an older

x

version of HDMI mode is connected to the TV. If such a problem occurs, ask the manufacturer of the external
device about the HDMI version and, if out of date, request an upgrade.

Be sure to purchase a certified HDMI cable. Otherwise, the picture may not display or a connection error may

x

occur.

A basic high-speed HDMI cable or one with ethernet is recommended. This product does not support the

x

ethernet function via HDMI.

* The image may differ depending on the model.

Component connection

G

TV Rear

G

B

R

R

W

B

R

W

R

COMPONENT OUT

PR PB Y

AUDIO OUT

R-AUDIO-L

Using a Component (up to 1080p) Video (480i only)

✎

When connecting to AV IN the colour of the AV IN [ Y/VIDEO] jack (Green) does not match the colour of the video
cable (Yellow).

✎

To obtain the best picture quality, the Component connection is recommended over the A/V connection.

English - 6

¦ Using an HDMI cable or HDMI to DVI Cable

✎

Connecting through the HDMI cable may not be supported depending on the PC.

✎

An HDMI cable supports digital video and audio signals, and does not require an audio cable.

* The image may differ depending on the model.

PC connection

TV Rear

Display Modes (HDMI/DVI Input)

LA32D403:Optimal resolution is 1360 x 768 @ 60Hz.

Mode Resolution

IBM

MAC

VESA DMT

640 x 350 31.469 70.086 25.175 + / -

720 x 400 31.469 70.087 28.322 - / +

640 x 480 35.000 66.667 30.240 - / -

832 x 624 49.726 74.551 57.284 - / -

640 x 480

800 x 600

1024 x 768

1360 x 768 47.712 60.015 85.500 + / +

Horizontal Frequency

(KHz)

31.469 59.940 25.175 - / -

37.861 72.809 31.500 - / -

37.500 75.000 31.500 - / -

37.879 60.317 40.000 + / +

48.077 72.188 50.000 + / +

46.875 75.000 49.500 + / +

48.363 60.004 65.000 - / -

56.476 70.069 75.000 - / -

60.023 75.029 78.750 + / +

Vertical Frequency (Hz)

HDMI OUT

DVI OUT

Pixel Clock Frequency

(MHz)

Sync Polarity (H / V)

English - 7

LA40D503: Optimal resolution is 1920 X 1080 @ 60 Hz.

Mode Resolution

IBM

MAC

VESA DMT

VESA DMT / DTV

CEA

640 x 350 31.469 70.086 25.175 +/-

720 x 400 31.469 70.087 28.322 -/+

640 x 480 35.000 66.667 30.240 -/-

832 x 624 49.726 74.551 57.284 -/-

1152 x 870 68.681 75.062 100.000 -/-

640 x 480 31.469 59.940 25.175 -/-

640 x 480 37.861 72.809 31.500 -/-

640 x 480 37.500 75.000 31.500 -/-

800 x 600 37.879 60.317 40.000 +/+

800 x 600 48.077 72.188 50.000 +/+

800 x 600 46.875 75.000 49.500 +/+

1024 x 768 48.363 60.004 65.000 -/-

1024 x 768 56.476 70.069 75.000 -/-

1024 x 768 60.023 75.029 78.750 +/+

1152 x 864 67.500 75.000 108.000 +/+

1280 x 1024 63.981 60.020 108.000 +/+

1280 x 1024 79.976 75.025 135.000 +/+

1280 x 800 49.702 59.810 83.500 -/+

1280 x 800 62.795 74.934 106.500 -/+

1280 x 960 60.000 60.000 108.000 +/+

1360 x 768 47.712 60.015 85.500 +/+

1440 x 900 55.935 59.887 106.500 -/+

1440 x 900 70.635 74.984 136.750 -/+

1680 x 1050 65.290 59.954 146.250 -/+

1920 x 1080p 67.500 60.000 148.500 +/+

Horizontal Frequency

(KHz)

Vertical Frequency (Hz) Pixel Clock Frequency (MHz) Sync Polarity (H / V)

✎✎

NOTE

For HDMI/DVI cable connection, you must use the HDMI IN(DVI) jack.

x

If an HDMI to DVI cable is connected to the HDMI IN (DVI) port, the audio does not work.

x

The interlace mode is not supported.

x

The set might operate abnormally if a non-standard video format is selected.

x

PC(D-Sub) input is not supported.

x

SERVICE

Connector for service only.

English - 8

Changing the Input Source

¦ Source List

Use to select TV or other external input sources such as DVD / Blu-ray players / cable box / STB satellite
receiver connected to the TV.

■ TV / HDMI/DVI / AV / Component / USB

✎

In the Source List, connected inputs will be highlighted.

✎

PC(D-Sub) input is not supported. If you want to connect PC to the TV, use HDMI/DVI input.

✎

If you want to see connected devices only, move to Connected using ◄ or ► button.

¦ Edit Name

How to use Edit Name

In the Source, press the TOOLS button, and then you can set an external input sources name you want.

■ VCR / DVD / Cable STB / Satellite STB / PVR STB / AV Receiver / Game / Camcorder / PC / DVI PC / DVI Devices /
TV / IPTV / Blu-ray / HD DVD / DMA: Name the device connected to the input jacks to make your input source selection
easier.

✎

When connecting a PC to the HDMI IN(DVI) port with HDMI cable, you should set the TV to PC mode under
Edit Name.

✎

When connecting a PC to the HDMI IN(DVI) port with HDMI to DVI cable, you should set the TV to DVI PC mode
under Edit Name.

✎

When connecting an AV devices to the HDMI IN(DVI) port with HDMI to DVI cable, you should set the TV to

DVI Devices mode under Edit Name.

Information

You can see detailed information about the selected external device.

English - 9

How to use the e-Manual

E-MANUAL

Screen Display

1

You can find instructions about your TV’s features in the e-Manual in your TV. To
use, press the E-MANUAL button on your remote. Move the cursor using the up/
down/right/left buttons to highlight a category, then a topic, and then press the

ENTERE button. The e-Manual displays the page you want to see.

You can also access it through the menu:

MENUm → Support → e-Manual → ENTER

O

✎

To return to the e-Manual main menu, press the E-MANUAL button on the remote.

✎

You cannot use Try Now directly if the T V is set to an external input source.

1 Currently displayed video, TV programme, etc.
2 The category list. Press ◄ or ► button to select

category you want.

3 Displays the sub-menu list. Use the arrow buttons on

your remote to move the cursor. Press ENTERE
button to select the sub-menu you want.

4 } Blue (Index): Displays the index screen.
5 E Enter: Selects a category or sub-menu.
6 e Exit: Exit the e-Manual.

Basic Features

Changing the Preset Picture Mode

Adjusting Picture Settings

Changing the Picture Options

Changing the Preset Sound Mode

Adjusting Sound Settings

}

Index E Enter e Exit

2

3

4 5 6

E

How to toggle between an e-Manual topic and the corresponding OSD menu(s).

Basic Features > Changing the Preset Picture Mode (1/1)

a Try Now

E-MANUAL

a

Try Now b Home { Zoom } Index L Page e Exit

✎

This function is not enabled in some menus.

Method 1 Method 2

1. If you want to use the menu that corresponds to an
e-Manual topic, press the red button to select Try Now.

2. To return to the e-Manual screen, press the E-MANUAL

button.

1. Press the ENTERE button when a topic is displayed.
“Are you sure?” appears. Select Yes, and then press the

ENTERE button. The OSD window appears.

2. To return to the e-Manual screen, press the E-MANUAL

button.


Picture Mode : Standard ►

Backlight : 7

Contrast : 95

Brightness : 45

Sharpness : 50

Colour : 50

Tint (G/R) : G50/R50

Screen Adjustment

English - 10

Viewing the Contents

Basic Features > Changing the Preset Picture Mode (1/1)

a

Try Now b Home { Zoom } Index L Page e Exit

2 3 4 5

Using the Zoom mode

U

Move

R

Return

1 Contents Area: Contains the topic contents, if you

selected a sub-menu. To move previous or next
page, press the ◄ / ► button.

2 Try Now: Displays the OSD menu that corresponds

1

to the topic. To return to the e-Manual screen, press
the E-MANUAL button.

3 Home: Moves to the e-Manual home screen.
4 Zoom: Magnifies a screen. You can scroll through the

magnified screen by using ▲ / ▼ buttons.

5 L (Page): Moves to previous or next page.

Select the Zoom, and then press ENTERE to magnify
the screen. You can scroll through the magnified screen
by using the ▲ or ▼ buttons.

✎

To return to the screen to normal size, press the

RETURN button.

How to search for a topic on the index page

✎

This function may not supported depending on the language.

1. If you want to search a keyword, press the blue button to select Index.

2. Press the ◄ or ► button to select a character order you want.

3. Press the ▲ or ▼ button to select a keyword you want to see, and then press the ENTERE button.

4. You can view the corresponding e-Manual instruction screen.

✎

To close the Index screen, press the RETURN button.

English - 11

Installing the Wall Mount

The wall mount kit (sold separately) allows you to mount the TV on the wall.
For detailed information on installing the wall mount, see the instructions provided with the wall mount. Contact a technician for

assistance when installing the wall mount bracket.
Samsung Electronics is not responsible for any damage to the product or injury to yourself or others if you elect to install the

TV on your own.

Wall Mount Kit Specifications (VESA)

✎

Wall mount kit is not supplied but sold separately.

Install your wall mount on a solid wall perpendicular to the floor. When attaching to other building materials, please contact
your nearest dealer. If installed on a ceiling or slanted wall, it may fall and result in severe personal injury.

✎

NOTE

Standard dimensions for wall mount kits are shown in the table below.

x

When purchasing our wall mount kit, a detailed installation manual and all parts necessary for assembly are provided.

x

Do not use screws that do not comply with the VESA standard screw specifications.

x

Do not use screws longer than the standard dimension, as they may cause damage to the inside of the TV set.

x

For wall mounts that do not comply with the VESA standard screw specifications, the length of the screws may differ

x

depending on their specifications.

Do not fasten the screws too strongly, this may damage the product or cause the product to fall, leading to personal

x

injury. Samsung is not liable for these kinds of accidents.

Samsung is not liable for product damage or personal injury when a non-VESA or non-specified wall mount is used or

x

the consumer fails to follow the product installation instructions.

Do not exceed 15 degrees tilt when mounting this TV.

x

Product

Family

inches VESA Spec. (A * B) Standard Screw Quantity

19~22 75 X 75

26 200 X 100

M4

LCD-TV

32~40 200 X 200 M6

46 400 X 400 M8

Do not install your Wall Mount Kit while your TV is turned on. It may result in personal injury due to electric
shock.

4

English - 12

Troubleshooting

If the TV seems to have a problem, first try this list of possible problems and solutions. If none of these
troubleshooting tips apply, visit “www.samsung.com”, then click on Support, or call Samsung customer service
centre on list of last page.

Issues Solutions and Explanations

The TV won’t turn on. • Make sure the AC power cord is securely plugged in to the wall outlet and the TV.

There is no picture/video. • Check cable connections (remove and reconnect all cables connected to the TV and

The remote control does not work. • Replace the remote control batteries with the poles (+/–) in the right direction.

The cable/set top box remote control
doesn’t turn the TV on or off, or
adjust the volume.

✎

You can keep your TV as optimum condition to upgrade the latest firmware on web site (samsung.com -> Support ->
Downloads) by USB.

✎

This TFT LCD panel uses a panel consisting of sub pixels which require sophisticated technology to produce. However,
there may be a few bright or dark pixels on the screen. These pixels will have no impact on the performance of the

product.

• Make sure the wall outlet is working.

• Try pressing the POWER button on the TV to make sure the problem is not the remote. If

the TV turns on, refer to “Remote control does not work” below.

external devices).

• Set your external device’s (Cable/Set top Box, DVD, Blu-ray etc) video outputs to match
the connections to the TV input. For example, if an external device’s output is HDMI, it
should be connected to an HDMI input on the TV.

• Make sure your connected devices are powered on.

• Be sure to select the TV’s correct source by pressing the SOURCE button on the remote

control.

• Reboot the connected device by reconnecting the device’s power cable.

• Clean the sensor’s transmission window on the remote.

• Try pointing the remote directly at the TV from 5~6 feet away.

• Programme the Cable/Set top box remote control to operate the TV. Refer to the Cable/

Set user manual for the SAMSUNG TV code.

Licence

List of Features

Excellent Digital Interface & Networking: With a built-in HD digital tuner, nonsubscription HD broadcasts can be viewed without
a cable box / STB (Set-Top-Box) satellite receiver.

English - 13

Securing the TV to the Wall

Caution: Pulling, pushing, or climbing onto the TV may cause the TV to fall. In particular, ensure that your
children do not hang over or destabilize the TV; doing so may cause the TV to tip over, resulting in serious
injuries or death. Follow all safety precautions provided on the included Safety Flyer. For added stability, install
the anti-fall device for safety purposes, as follows.

To avoid the TV from falling

1. Put the screws into the clamps and firmly fasten them onto the

wall. Confirm that the screws have been firmly installed onto the
wall.

✎

You may need additional material such as an anchor
depending on the type of wall.

✎

Since the necessary clamps, screws, and string are not
supplied, please purchase these additionally.

2. Remove the screws from the centre back of the TV, put the

screws into the clamps, and then fasten the screws onto the TV
again.

✎

Screws may not be supplied with the product. In this
case, please purchase the screws of the following
specifications.

✎

Screw Specifications

For a 32 ~ 40 Inch LCD TV: M6

x

For a 46 inch LCD TV: M8

x

3. Connect the clamps fixed onto the TV and the clamps fixed onto the wall with a strong string and then tie the string tightly.

✎

NOTE

Install the TV near to the wall so that it does not fall backwards.

x

It is safe to connect the string so that the clamps fixed on the wall are equal to or lower than the clamps fixed on

x

the TV.

Untie the string before moving the TV.

x

4. Verify all connections are properly secured. Periodically check connections for any sign of fatigue for failure. If you have any

doubt about the security of your connections, contact a professional installer.

Wall

Storage and Maintenance

✎

If you remove the attached sticker on the TV screen, clean the residues and then watch TV.

Do not spray water or a cleaning agent directly onto the
product. Any liquid that goes into the product may cause a
failure, fire, or electric shock.

Clean the product with a soft cloth dapped in a small amount
of water.

English - 14

Specifications

Environmental Considerations
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity

Model Name LA32D403

Display Resolution 1360 x 768

Screen Size 32 inches
Sound

(Output) 10 W X 2
Dimensions (WxDxH)

Body
With stand

Weight
Without Stand
With Stand

Model Name LA40D503
Display Resolution 1920 x 1080
Screen Size 40 inches
Sound

(Output) 10 W X 2
Dimensions (WxDxH)

Body
With stand

Weight
Without Stand
With Stand

10°C to 40°C (50°F to 104°F)

10% to 80%, non-condensing

-20°C to 45°C (-4°F to 113°F)
5% to 95%, non-condensing

784.4 X 98.1 X 502.9

784.4 X 182.4 X 545.3

7.7 kg

8.7 kg

970.0 X 98.1 X 586.6

970.0 X 206.9 X 629.1

11.6 kg

13.3 kg

✎

Design and specifications are subject to change without prior notice.

✎

For information about power supply, and more about power consumption, refer to the label attached to the product.

English - 15

Contact SAMSUNG WORLDWIDE

If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre.

Country Customer Care Centre Web Site

AUSTRALIA 1300 362 603 www.samsung.com

NEW ZEALAND 0800 SAMSUNG (0800 726 786) www.samsung.com

CHINA 400-810-5858 www.samsung.com

HONG KONG (852) 3698-4698 www.samsung.com/hk

INDIA

INDONESIA

3030 8282
1800 3000 8282

0800-112-8888
021-5699-7777

www.samsung.com

www.samsung.com

JAPAN 0120-327-527 www.samsung.com

MALAYSIA 1800-88-9999 www.samsung.com

1-800-10-SAMSUNG(726-7864)

PHILIPPINES

1-800-3-SAMSUNG(726-7864)
1-800-8-SAMSUNG(726-7864)

www.samsung.com

02-5805777

SINGAPORE 1800-SAMSUNG(726-7864) www.samsung.com

THAILAND

1800-29-3232
02-689-3232

www.samsung.com

TAIWAN 0800-329-999 www.samsung.com

VIETNAM 1 800 588 889 www.samsung.com

© 2011 Samsung Electronics Co., Ltd. All rights reserved.

BN68-03718A-00
