Samsung HT-TZ525, HT-TZ522, HT-Z520 User Manual

Digital Home

Theater System

user manual

imagine the possibilities

Thank you for purchasing this Samsung product.

To receive more complete service, please register your product at

www.samsung.com/global/register

HT-Z520 HT-TZ522 HT-TZ525

features

Playback of many disc types

This Home Theater System allows you to play back various discs, including DVD-VIDEO, CD, MP3-CD, WMA-CD, DivX, CD-R/RW, and DVD±R/RW.

USB Host support

You can enjoy media ﬁles such as pictures, movies and music saved on an MP3 player, digital camera or USB memory stick by connecting the storage device to the USB port of the Home Theater.

Dolby Pro Logic II

Dolby Pro Logic II is a form of multi-channel audio signal decoding technology that improves upon existing Dolby Pro Logic.

DTS (Digital Theater Systems)

DTS is an audio compression format developed by Digital Theater Systems Inc. It delivers full-frequency 5.1 channel sound.

TV Screen Saver Function

If the main unit remains in Stop mode for 5 minutes, the Samsung logo appears on the TV screen.

The HT-Z520/HT-TZ522/HT-TZ525 will automatically switch to the Power Saving mode after 20 minutes in the Screen Saver mode.

Power Saving Function

The

HT-Z520/HT-TZ522/HT-TZ525

Customized TV Screen Display

The HT-Z520/HT-TZ522/HT-TZ525 allows you to select your favorite image during JPEG or DVD playback and set it as your background wallpaper.

will automatically shut off after 20 minutes in Stop mode.

Anynet+ (HDMI-CEC) Function

Anynet+ is a function that can be used to operate the main unit using a Samsung TV remote control, by connecting the Home Theater to a SAMSUNG TV using an HDMI Cable. (This is only available with SAMSUNG TV's that support Anynet+.)

iPod & iPhone support

You can enjoy music ﬁles by connecting your iPod to the home theater with the supplied iPod dock.

Wireless receiver amplifier

Samsung ’s rear- channel wireless module does away with cables running between your DVD receiver and rear- channel speakers. Instead, the rear speakers connect to a compact wireless module that communicates with your DVD receiver.

AV SYNC Function

Video may lag behind the audio if the unit is connected to a digital TV. To compensate for this, you can adjust the audio delay time to sync up with the video.

ENG

WHAT’S INCLUDED

Check for the supplied accessories below.

Video Cable

(AH39-40001V)

FM Antenna

( AH42-00017A )

iPod Dock Package

( AH97-02650C )

User's Manual

( A H 6 8 - 0 2 1 6 7 B )

Remote Control

( AH59-02131J )

/ Batteries (AAA size)

( 4301-000116 )

ASC microphone

( AH30-00099A )

SWA-4100

Wireless Receiver Module

(AH97-03207A)

TX Card

(AH40-00149A)

Speaker Cable (2EA)

(AH81-02137A)

safety information

SAFETY WARNINGS

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER(OR BACK). NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

The lighting ﬂash and Arrowhead within Triangle Is a warning sign alerting you of

dangerous voltage inside the product

CAUTION: TO REDUCE THE RISK OF

ELECTRIC SHOCK, DO NOT REMOVE

COVER (OR BACK) NO USER SERVICEABLE

PARTS INSIDE. REFER SERVICING TO

QULAIFIED SERVICE PERSONNEL.

The explanation point within the triangle is a

warning sign alerting you of important

instructions accompanying the product.

WARNING

To reduce the risk of ﬁre or electric shock, do not expose this appliance to rain or moisture.• To prevent injury, this apparatus must be securely attached to the ﬂoor/wall in accordance with the installation instructions. • If this power supply is used at 240V ac, a suitable plug adapter should be used.•

CAUTION

Apparatus shall not be exposed to dripping or splashing and no objects ﬁlled with liquids, such as vases, shall be placed on the apparatus. • The Mains plug is used as a disconnect device and shall stay readily operable at any time.•

This product satisﬁes FCC regulations when shielded cables and connectors are used to connect the unit to other equipment. To prevent electromagnetic interference with electric appliances, such as radios and televisions, use shielded cables and connectors for connections.

FCC NOTE (for U.S.A):

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.• Increase the separation between the equipment and receiver.• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.•

Consult the dealer or an experienced radio/TV technician for help.•

Caution : FCC regulations state that any unauthorized changes or modiﬁcations to this equipment may void the user's authority to operate it.

Important Safety Instructions

Read these operating instructions carefully before using the unit. Follow all the safety instructions listed below. Keep these operating instructions handy for future reference.

CLASS 1 LASER PRODUCT

This Compact Disc player is classified as a CLASS 1 LASER product. Use of controls, adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.

CAUTION :

INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCKS DEFEATED, AVOID EXPOSURE TO BEAM.

CLASS 1 LASER PRODUCT KLASSE 1 LASER PRODUKT LUOKAN 1 LASER LAITE KLASS 1 LASER APPARAT PRODUCTO LASER CLASE 1

1) Read these instructions.

2) Keep these Instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliﬁers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not ﬁt into your outlet, consult an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11) Only use attachment/accessories speciﬁed by the manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table speciﬁed by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualiﬁed service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

ENG

PRECAUTIONS

Ensure that the AC power supply in your house complies with the identification sticker located on the back of your player. Install your player horizontally, on a suitable base (furniture), with enough space around it for ventilation (3~4 inches). Make sure the ventilation slots are not covered. Do not stack anything on top of the player. Do not place the player on amplifiers or other equipment which may become hot. Before moving the player, ensure the disc tray is empty. This player is designed for continuous use. Switching off the DVD player to the stand-by mode does not disconnect the electrical supply. In order to disconnect the player completely from the power supply, remove the main plug from the wall outlet, especially when left unused for a long period of time.

During thunderstorms, disconnect the AC main plug from the wall outlet. Voltage peaks due to lightning could damage the unit.

Protect the player from moisture (i.e. vases) , and excess heat

(e.g.fireplace) or equipment creating strong magnetic or electric fields (i.e.speakers...). Disconnect the power cable from the AC supply if the player malfunctions. Your player is not intended for industrial use. Use of this product is for personal use only.

Condensation may occur if your player or disc has been stored in cold temperatures. If transporting the player during the winter, wait approximately 2 hours until the unit has reached room temperature before using.

Do not expose the unit to direct sunlight or other heat sources. This could lead to overheating and malfunction of the unit.

The batteries used with this product contain chemicals that are harmful to the environment. Do not dispose of batteries in the general household trash.

This product is covered by one or more of the following U.S. patents:

5,060,220 5,457,669 5,561,649 5,705,762 6,043,912 6,438,099 6,467,061 6,556,521 6,578,163 6,697,307 6,728,474 6,771,891 6,894,963 6,895,593 6,937,815 6,996,327 7,009,926 7,085,221 7,088,649 7,092,327 7,099,566 7,123,564 7,142,493 7,142,495 7,145,861 7,146,624 7,151,729 7,161,879 7,164,647 7,167,437 7,173,891 7,177,250 7,194,187 7,203,891 7,209,423 7,210,067 7,228,062 7,245,566 7,245,567 7,257,065 7,263,045 7,269,110 7,272,086 7,272,106 7,280,460 7,283,729 7,286,454 7,304,938

This device is protected by U.S. Patent Nos.

6,836,549; 6,381,747; 7,050,698; 6,516,132; and 5,583,936.

This product is covered by the following U.S. patents:

US4,930,158 US4,930,160

Phones

FEATURES

3 What’s included

SAFETY INFORMATION

4 Safety Warnings 4 Important Safety Instructions 5 Precautions

GETTING STARTED

8 Before Reading the User’s Manual 9 Playable Discs 9 Do not use the following types of disc! 9 Copy Protection 10 Disc Type and Characteristics

DESCRIPTION

11 Front Panel 12 Display 13 Rear Panel

REMOTE CONTROL

14 Tour of the Remote Control 16 Setting the Remote Control

CONNECTIONS

18 Connecting the Speakers 24 Connecting the Rear Speakers to the

Wireless Receiving Ampliﬁer 26 Connecting the Video Out to your TV 27 Connecting the HDMI In/Out 28 HDMI Auto Detection Function 29 BD Wise 30 HDMI Function 31 Connecting an iPod 33 Connecting Audio from External

Components 35 Connecting the FM Antenna

PLAYBACK

37 Disc Playback 38 MP3/WMA-CD playback 39 JPEG File Playback 40 DivX Playback 42 Using the Playback Function 50 Using an iPod 52 Playing Media Files Using The USB Host

Feature

BEFORE USING YOUR HOME

THEATER

36 Before using your home theater

ENG

SYSTEM SETUP

54 Setting the Language 55 Setting the TV Screen Type 56 Setting Parental Controls (Rating Level) 56 Setting the Password 57 Setting The Wallpaper 57 To Select one of the 3 Wallpaper Settings

you've made 58 Setting the Speaker Mode 59 Setting the Delay Time 60 Setting the Test Tone 60 Setting the Audio 61 Setting the DRC (Dynamic Range

Compression) 62 Setting the AV SYNC 62 Setting the HDMI Audio 63 Sound ﬁeld (DSP)/EQ Function 63 Dolby Pro Logic II Mode 64 Dolby Pro Logic II Effect 64 ASC (Auto Sound Calibration) Setup

RADIO

66 Listening To Radio 66 Presetting Stations

CONVENIENT FUNCTION

67 Sleep Timer Function 67 Adjusting Display Brightness 67 Mute Function 68 S.VOL 68 P.BASS/Audio Upscaling 69 CD Ripping

TROUBLESHOOTING

70 Troubleshooting

APPENDIX

73 Cautions on Handling and Storing Discs 74 Speciﬁcations 76 Warranty

LANGUAGE CODE LIST

72 Language Code list

getting started

BEFORE READING THE USER’S MANUAL

Make sure to check the following terms before reading the user manual.

Icons that will be used in manual

Icon Term Deﬁnition

DVD

This involves a function available with DVD or DVD-R/DVD-RW discs that have been recorded and ﬁnalized in Video Mode.

CD This involves a function available with a data CD (CD-R or CD-RW).

MP3 This involves a function available with CD-R/-RW discs.

JPEG This involves a function available with CD-R/-RW discs.

DivX

This involves a function available with MPEG4 discs. (DVD±R/RW, CD-R or CD-RW)

Caution

This involves a case where a function does not operate or settings may be cancelled.

Note

This involves tips or instructions on the page that help each function operate.

In this manual, the instructions marked with "DVD ( `

DVD

)" are applicable to DVDVIDEO, DVD-AUDIO and DVD-R/-RW discs that have been recorded in Video Mode and then ﬁnalized. Where a particular DVD type is mentioned, it is indicated separately.

If a DVD-R/-RW disc has not been recorded properly in DVD Video format, it will not be

playable.

About the use of this user’s manual

Be sure to be familiar with Safety Information before using this product. (See pages 4~5)1)

If a problem occurs, check the Troubleshooting. (See pages 70~71)2)

ENG

● GETTING STARTED

PLAYABLE DISCS

Disc Type Mark (Logo) Recorded Signals Disc Size Max. Playing Time

DVD-VIDEO VIDEO

5 inches

Approx. 240 min. (single-sided)

Approx. 480 min. (double-sided)

3 1/2 inches

Approx. 80 min. (single-sided)

Approx. 160 min. (double-sided)

AUDIO-CD

COMPACT

DIGITAL AUDIO

AUDIO

5 inches 74 min.

3 1/2 inches 20 min.

DivX

AUDIO + VIDEO

5 inches

—

3 1/2 inches

—

DO NOT USE THE FOLLOWING TYPES OF DISC!

LD, CD-G, CD-I, CD-ROM, DVD-ROM and DVD-RAM discs cannot be played on this player. • If such discs are played, a <WRONG DISC FORMAT> message appears on the TV screen.

DVD discs purchased abroad may not play on this player. • If such discs are played, a <CAN'T PLAY THIS DISC PLEASE, CHECK REGION CODE> message appears on the TV screen.

COPY PROTECTION

Many DVD discs are encoded with copy protection. Because of this, you should only connect your DVD player • directly to your TV, not to a VCR. Connecting to a VCR results in a distorted picture from copy-protected DVD discs.

This product incorporates copyright protection technology that is protected by methods claims of certain U.S. • patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

DVD (Digital Versatile Disc) offers fantastic audio and video, thanks to Dolby Digital surround sound and MPEG-2 video compression technology. Now you can enjoy these realistic effects in the home, as if you were in a movie theater or concert hall.

DVD players and the discs are coded by region. These regional codes must match in order for the disc to play. If the codes do not match, the disc will not play. The Region Number for this player is given on the rear panel of the player. (Your DVD player will only play DVDs that are labeled with identical region codes.)

1 6

getting started

DISC TYPE AND CHARACTERISTICS

This product does not support Secure (DRM) Media ﬁles.

CD-R Discs ❖

Some CD-R discs may not be playable depending on the disc recording device (CD-Recorder or PC) and the •

condition of the disc.

Use a 650MB/74 minute CD-R disc. •

Do not use CD-R discs over 700MB/80 minutes as they may not be played back.

Some CD-RW (Rewritable) media, may not be playable. • Only CD-Rs that are properly "closed" can be fully played. If the session is closed but the disc is left open, you •

may not be able to fully play the disc.

CD-R MP3 Discs ❖

Only CD-R discs with MP3 ﬁles in ISO 9660 or Joliet format can be played.• MP3 ﬁle names should be 8 characters or less in length and contain no blank spaces or special characters •

(. / = +).

Use discs recorded with a compression/decompression data rate greater than 128Kbps.• Only ﬁles with the ".mp3" and ".MP3" extensions can be played.• Only a consecutively written multisession disc can be played. If there is a blank segment in the Multisession •

disc, the disc can be played only up to the blank segment.

If the disc is not closed, it will take longer to begin playback and not all of the recorded ﬁles may be played.• For ﬁles encoded in Variable Bit Rate (VBR) format, i.e. ﬁles encoded in both low bit rate and high bit rate •

(e.g., 32Kbps ~ 320Kbps), the sound may skip during playback.

A maximum of 500 tracks can be played per CD. • A maximum of 300 folders can be played per CD.•

CD-R JPEG Discs ❖

Only ﬁles with the "jpg" extensions can be played.• If the disc is not closed, it will take longer to start playing and not all of the recorded ﬁles may be played.• Only CD-R discs with JPEG ﬁles in ISO 9660 or Joliet format can be played.• JPEG ﬁle names should be 8 characters or less in length and contain no blank spaces or special characters •

(. / = +).

Only a consecutively written multisession disc can be played. If there is a blank segment in the multisession •

disc, the disc can be played only up to the blank segment.

A maximum of 9,999 images can be stored on a single CD.• When playing a Kodak/Fuji Picture CD, only the JPEG ﬁles in the picture folder can be played.• Picture discs other than Kodak/Fuji Picture CDs may take longer to start playing or may not play at all.•

DVD±R/RW, CD-R/RW DivX Discs ❖

Software updates for incompatible formats are not supported. •

(Example : QPEL, GMC, resolution higher than 800 x 600 pixels, etc.)

Sections with a high frame rate might not be played while playing a DivX ﬁle.• DivX® is a digital video format created by DivX, Inc. This is an ofﬁcial DivX Certiﬁed or DivX Ultra Certiﬁed device •

that plays DivX video.

ENG

● DESCRIPTION

FRONT PANEL

POWER( ) BUTTON PHONES JACK

TUNING DOWN & SKIP (

) BUTTON

DISC TRAY AUX IN 1/ASC IN

STOP ( ) BUTTON

OPEN/CLOSE BUTTON

USB PORT

PLAY/PAUSE (

) BUTTON

VOLUME CONTROL

DISPLAY

TUNING UP & SKIP (

) BUTTON

DISC CHANGE BUTTON

FUNCTION BUTTON

VOLUME

DISC CHANGE

AUX IN 1/ ASC IN

PHONES

FUNC.

description

DISPLAY

DISC INDICATOR

TUNER PRESETTING INDICATOR

SYSTEM STATUS DISPLAY

RADIO FREQUENCY INDICATOR

ENG

● DESCRIPTION

REAR PANEL

iPod JACK

Connect the iPod dock connector here.

TX CARD CONNECTION (WIRELESS)

The TX card enables communication between the main unit and the wireless receiver ampliﬁer.

AUX IN 2 JACKS

Connect to the 2CH analog output of an external device (such as a VCR).

VIDEO OUTPUT JACK

Connect your TV's Video Input jack (VIDEO IN) to the VIDEO OUT jack.

COMPONENT VIDEO OUTPUT JACKS

Connect a TV with Component video inputs to these jacks.

External Digital Optical Input Jack

Use this to connect external equipment capable of digital output.

HDMI OUT JACK

Use the HDMI cable, connect this HDMI output terminal to the HDMI input terminal on your TV for the best quality picture.

HDMI IN JACK

Connect the HDMI IN jack of this unit and the HDMI OUT jack of a Set-Top/Cable Box.

FM 75Ω COAXIAL JACK

Connect the FM antenna.

COOLING FAN

The fan always revolves when the power is on. Ensure a minimum of 4 inches of clear space on all sides of the fan when installing the product.

SPEAKER OUTPUT CONNECTORS

Connect the front, center speakers and subwoofer. The rear speakers must be connected to the Wireless Receiver.

CLAMP-WIRE

Fasten the speaker wires.

HDMI IN

92 5 843 6 7

remote control

TOUR OF THE REMOTE CONTROL

38 39

ENG

● REMOTE CONTROL

OPEN/CLOSE button

DVD

DVD button

TUNER button

DVD

AUX button

PORT button

SUBTITLE

PAUSE button

PLAY button STOP button

SEARCH buttons

MUTE button

TUNING/CH button

REMAIN button

RETURN button

EXIT

button

CANCEL button

SOUND EDIT button

S.VOL button

SLEEP button

DSP/EQ button

AUDIO UPSCALE/P.BASS button

DIMMER button

ASC button

POWER button

DVD RECEIVER button

TV button

Number (0~9) buttons

AUDIO

STEP button

Tuning Preset/CD Skip buttons

VOLUME button

MENU button

Cursor/ENTER button

INFO

button

PL II MODE button

TUNER MEMORY, SD(Standard Definition)/HD(High Definition) button

ZOOM button

REPEAT button

LOGO button

CD RIPPING button

SLOW, MO/ST button

PL II EFFECT button

DISC SKIP, SOURCE button

Insert Remote Batteries

1. Remove the battery cover in the direction of the arrow.

2. Insert two 1.5V AAA batteries, paying attention to the correct polarities (+ and –).

3. Replace the battery cover.

Follow these precautions to avoid leaking or cracking cells:

Place batteries in the remote control so they match the polarity : (+) to (+) and (–) to (–).

Use the correct type of batteries. Batteries that look similar may differ in voltage. ` Always replace both batteries at the same time. ` Do not expose the batteries to heat or a ﬂame. `

Operation Range of the Remote Control

The remote control can be used up to approximately 23 feet (7 meters) in a straight line. It can also be operated at a horizontal angle of up to 30° from the remote control sensor.

When operating a TV with the remote control

1. Press the TV button to set the remote to TV mode.

2. Press the POWER button to turn on the TV.

3. While holding down the POWER button, enter the code

corresponding to your brand of TV.

If there is more than one code listed for your TV in the • table, enter one at a time to determine which code works.

Example : For a Samsung TV

While holding down the POWER button, use the number buttons to enter 00, 15, 16, 17 or 40.

4. If the TV turns off, the setting is complete.

You can use the TV POWER, VOLUME, CHANNEL, and Numeric buttons (0~9).•

The remote control may not work on some brands of TV's. Also, some operations may not ` be possible depending on your brand of TV.

If you do not set the remote control with the code for your brand of TV, the remote control

will work on a Samsung TV by default.

SETTING THE REMOTE CONTROL

You can control certain functions of your TV with this remote control.

remote control

ENG

● REMOTE CONTROL

TV Brand Code List

Admiral (M.Wards)

A Mark

Anam

AOC

Bell & Howell (M.Wards)

Brocsonic

Candle

Cetronic

Citizen

Cinema

Classic

Concerto

Contec

Coronado

Craig

Croslex

Crown

Curtis Mates

CXC

Daewoo

Daytron

Dynasty

Emerson

Fisher

Funai

Futuretech

General Electric (GE)

Hall Mark

Hitachi

Inkel

JC Penny

JVC

KTV

KEC

KMC

LG (Goldstar)

Luxman

LXI (Sears)

Magnavox

Marantz

Matsui

MGA

Mitsubishi/MGA

37 38

56, 57, 58

01, 15

01, 02, 03, 04, 05, 06, 07, 08, 09, 10, 11,

12, 13, 14

01, 18, 40, 48

57, 58, 81

59, 60

03, 18, 25

03, 05, 61, 82, 83, 84

59, 61, 63

02, 03, 04, 15, 16, 17, 18, 19, 20, 21, 22, 23, 24,

25, 26, 27, 28, 29, 30, 32, 34, 35, 36, 48, 59, 90

03, 15, 40, 46, 59, 61, 64, 82, 83, 84, 85

19, 65

06, 40, 56, 59, 66, 67, 68

15, 18, 50, 59, 69

56, 59, 67, 86

59, 61, 87, 88

03, 15, 40

01, 15, 16, 17, 37, 38, 39, 40, 41, 42, 43, 44

19, 54, 56, 59, 60, 62, 63, 65, 71

15, 17, 18, 48, 54, 59, 60, 62, 72, 89

40, 54

18, 40

18, 40, 59, 60, 75

MTC

NEC

Nikei

Onking

Onwa

Panasonic

Penney

Philco

Philips

Pioneer

Portland

Proton

Quasar

Radio Shack

RCA/Proscan

Realistic

Sampo

Samsung

Sanyo

Scott

Sears

Sharp

Signature 2000 (M.Wards)

Sony

Soundesign

Spectricon

SSS

Sylvania

Symphonic

Tatung

Techwood

Teknika

TMK

Toshiba

Vidtech

Videch

Wards

Yamaha

York

Yupiteru

Zenith

Zonda

Dongyang

18, 19, 20, 40, 59, 60

06, 07, 08, 09, 54, 66, 67, 73, 74

03, 15, 17, 18, 48, 54, 59, 62, 69, 90

15, 17, 18, 40, 48, 54, 62, 72

63, 66, 80, 91

15, 18, 59

06, 66, 67

17, 48, 56, 60, 61, 75

18, 59, 67, 76, 77, 78, 92, 93, 94

03, 19

00, 15, 16, 17, 40, 43, 46, 47, 48, 49,

59, 60, 98

19, 61, 65

03, 40, 60, 61

15, 18, 19

15, 57, 64

57, 58

50, 51, 52, 53, 55

03, 40

18, 40, 48, 54, 59, 60, 62

61, 95, 96

03, 15, 18, 25

18, 40

19, 57, 63, 71

59, 60, 69

15, 17, 18, 40, 48, 54, 60, 64

58, 79

03, 54

No.

Brand

Code

Brand

Code

CONNECTING THE SPEAKERS

Position of the DVD Player

Place it on a stand or cabinet shelf.

Selecting the Listening Position

The listening position should be located about 2.5 to 3 times the distance of the TV's screen size away from the TV. Example : For 32" TV's 2~2.4m (6~8feet)

For 55" TV's 3.5~4m (11~13feet)

Front Speakers

Place these speakers in front of your listening position, facing inwards (about 45°) toward you. Place the speakers so that their tweeters will be at the same height as your ear. Align the front face of the front speakers with the front face of the center speaker or place them slightly in front

of the center speakers.

Center Speaker

It is best to install it at the same height as the front speakers. You can also install it directly over or under the TV.

Rear Speakers

Place these speakers behind your listening position. If there isn't enough room, place these speakers so they face each other. Place them about 60 to 90cm (2 to 3feet) above your ear, facing slightly downward.

Unlike the front and center speakers, the rear speakers are used to handle mainly sound effects and sound will not

come from them all the time.

Sound will be heard from the rear speakers in DVD 5.1-CH or Dolby Pro Logic II mode only.

Subwoofer

The position of the subwoofer is not so critical. Place it anywhere you like.

This section involves various methods of connecting the Digital Home Theater to other external components.

Before moving or installing the product, be sure to turn off the power and disconnect the power cord.

connections

ENG

● CONNECTIONS

Speaker Components

HT-Z520

SUBWOOFER

(AH81-04975A)

CENTER

(AH81-04973A)

SPEAKER CABLE

(AH81-04976A)

SPEAKER CABLE

(AH81-04976A)

SPEAKER CABLE

(AH81-04976A)

CENTER

(AH81-04979A)

CENTER

(AH81-04973A)

FRONT

(AH81-04670A)

CRADLE STAND/

WALL MOUNT

FRONT

(AH81-04972A)

(AH81-04676A)

(L) (R)

REAR

(AH81-04974A)

(AH81-04677A)

(L) (R)

SUBWOOFER (AH81-04975A)

STAND BASE (AH81-04982A)

STAND

(AH81-04981A)

FRONT

(AH81-04980B)

(AH81-04681B)

SCREW (Large): 2EA

(AH81-04983B)

SCREW (Small): 10EA

(AH81-04984B)

HT-TZ522

(L)

(R)

SUBWOOFER (AH81-04975A)

STAND BASE (AH81-04982A)

FRONT L (AH81-04980A) R (AH81-04681A)

SCREW (Large): 4EA

(AH81-04983A)

SCREW (Small): 20EA

(AH81-04984A)

(L) (R)

STAND

(AH81-04981A)

REAR L (AH81-04980C) R (AH81-04681C)

HT-TZ525

REAR

(AH81-04974B)

(AH81-04677B)

(L) (R)

connections

Installing the Cradle Stand

1. Insert the stand so that it ﬁts into the hole

as described in the ﬁgure.

2. Turn the stand clockwise to lock it.

(Turning it counter-clockwise will loosen it.)

3. This is the completion of the stand

installation.

<Front>

(HT-Z520 - Front Speakers)

ENG

● CONNECTIONS

Front Speakers Wall Mount Installation

3. Use the wall mount hole (bracket) to install

the speaker on the wall.

Installing the Wall Mount

<Front>

1. Insert the wall mount so that it ﬁ ts into the

rear hole of the speaker as in the ﬁgure.

2. Turn the wall mount counter clockwise to

ﬁx it. (This is in the reverse direction of the cradle stand installation.)

Make sure the speaker is hung properly to avoid accidents or injury. `

HT-Z520 - Front Speakers

connections

Front/Rear Tallboy Stand

Turn the 1. STAND upside-down and connect it to the STAND BASE.

Insert ﬁve small 2. SCREWS into the ﬁve holes marked with arrows using a screwdriver as shown in the illustration.

Connect upper SPEAKER to the assembled 3. STAND.

Insert another large 4. SCREW into the hole on the rear of the speaker marked with arrow using a

screwdriver.

STAND BASE

STAND

1 2

3 4

How to Install the Speaker on the Stand

HT-TZ522 - Front Speakers

HT-TZ525 - Front/Rear Speakers

ENG

● CONNECTIONS

Connecting the Front, Center and Subwoofer Speakers

Press down the terminal tab on the back of the speaker. 1.

Insert the black wire into the black terminal (–) and the color wire into 2. the red terminal(+), and then release the tab.

Insert the other end of the black wire into the black terminal (-) and the 3. color wire(Purple,White,Red. Green) into the respective (+) color terminal on the back of the Home Theater, and then release the tab. Connect the connecting plugs for the rear speakers to the back of the Wireless Receiving module.

• Make sure the colors of the speaker terminals match the speaker

wire.

If you place a speaker near your TV set, screen color may be distorted because of the ` magnetic ﬁeld generated by the speaker. If this occurs, place the speaker away from your TV set.

Do not let children play with or near the speakers. They could get hurt if the speaker falls.

When connecting the speaker wires to the speakers, make sure that the polarity (+/ –) is correct. ` Keep the subwoofer speaker out of reach of children so as to prevent them from inserting `

their hands or alien substances into the duct (hole) of the subwoofer speaker.

Do not hang the subwoofer on

` a wall through the duct (hole).

* To connect the rear speakers, refer to page 24.

HDMI IN

Subwoofer

Center Speaker

Front Speaker (R)

Front Speaker (L)

Speaker

Stand

Subwoofer

Center Speaker

Front Speaker (L)

Front Speaker (R)

HT-Z520

HDMI IN

HT-TZ522/TZ525

Black

Red

connections

CONNECTING THE REAR SPEAKERS TO THE WIRELESS RECEIVING AMPLIFIER

Wireless Receiving Module (SWA-4100)

HDMI IN

AUDIO

Rear Speaker (L)

Rear Speaker (R)

WIRELESS RECEIVER MODULE

HT-Z520/TZ522

Rear Speaker (L)

Rear Speaker (R)

WIRELESS RECEIVER MODULE

The HT-Z520/TZ522/TZ525 only can connect with wireless receiving module ` (SWA-4100).

HT-TZ525

+ 54 hidden pages

Samsung HT-TZ525, HT-TZ522, HT-Z520 User Manual

features

safety information

PRECAUTIONS

contents

getting started

FRONT PANEL

description

DISPLAY

REAR PANEL

remote control

connections

Connecting the Front, Center and Subwoofer Speakers
