7. Exploded Views and Parts List
7-1 Exploded Views
MM01
MM129
MM57
MD11
MD05
MD04
MD02
MM123
MM17
MM17
MM67
MM55
MM59
MM07
MM55
MM05
MM26
MM06
MM03
MC09
MD03
MC03
MC05
MD10
MC12
MC04
MD07
MD06
MC08
MM18
MM19
MD01
MC01
MM20
MM16
MM88
MM22
MM28
MM27
MB01
MM14
MM13
MM64
MM29
MB05
MB03
MM17
MM10
MM08
MM09
MB02
MM50
MB04
MM30
MM32
MM31
7-2 Main Parts List
No. Code No. Description Specification Q’ty Remark
MB01 DE96-00115C ASSY BODY LATCH CE2611N,NC2000(BUTTON) 1
MB02 3405-000175 SWITCH-MICRO 250V,15A,200gf,SPST-NO 1
MB03 3405-000178 SWITCH-MICRO 250V,15A,200gf,SPST-NO 2 PRI,SEC
MB04 DE66-00088A LEVER-SWITCH NC2000(0.6/0.8/1.2),PP,-,-, 1
MB05 DE72-00138A BODY-LATCH NC2000(0.6/0.8/1.2),PP,-,-,-, 1
MM01 DE70-00184P PANEL-OUTER MW850WA,C/STEEL,T0.5,-,-,-,P 1 WHITE
MM01 DE70-00184H PANEL-OUTER NC-2000,SECC,T0.5,-,-,-,SILVER,0.6~0.8 1 SILVER
MM03 DE39-00334A WIRE HARNESS-A G2712N,230V50HZ,EUROPE QU 1
MM05 DE96-00008D ASSY NOISE FILTER SN-3WEB(12),250V12A,EU 1
MM06 DE96-00031A ASSY-MOTOR FAN SMF-3RDEA,230V50HZ,2400RP 1
MM07 DE39-20058L ASSY POWER CORD CE2713/XEF,1.5SQ,230V50H 1
MM08 OM75S(31)ESS ASSY-MAGNETRON OM75S(31)ESS 1
MM09 DE71-60457B COVER-AIR 3RD-0.7(BTM),PP,-,-,-,-,-,- 1
MM10 4713-001046 LAMP-INCANDESCENT 240V,104mA,25W,ORG,-,- 1 CV/AIR
MM123 DE47-70030D HEATER-CERAMIC 115V,490W,26OHM,6,-,-,-,- 2
MM129 DE39-30097B LEAD WIRE-G L100,MBQ45,GRILL,-,-,-,- 1
MM13 DE66-90113A LEVER-DOOR PP(TB53-GH41),T2.5,-,-,12g,NT 1
MM14 DE26-00079A TRANS-H.V SHV-EURO1,230V,50HZ,2130V/3.6V 1
MM16 DE71-00151A COVER-MGT MW850WA,PP,T2,W54,L129,-,GE-WH 1
MM17 DE47-00002B THERMOSTAT PW2N,-,-,100,110,-,-,-,187H,3 1 CAVITY
MM17 DE47-20009A THERMOSTAT PW2N-520PB,160/60,250V/7.5A,H 1 MGT
MM17 DE47-20032A THERMOSTAT PW-2N,85/75,-,-,-,-,-,- 1 GRILL
MM18 DE74-20102B TRAY-COOKING GLASS,T5.0,M745,-,- 1
MM19 DE97-00193B ASSY-GUIDE ROLLER NC2000 0.6,T2*P1198(14 1
MM20 DE67-00140A COUPLER NC2000(0.6~0.8),PPS(ESS840),-,3G 1
MM22 DE31-10154A MOTOR-SYNCHRONOUS M2HJ49ZR02,ST-16,50/60 1
MM26 DE71-00148A COVER-BLOWER MW850WA,PP,T1.5,-,-,-,NTR,N 1
MM27 DE61-40066A FOOT -,PP,-,BLK,-,-,- 2
MM28 DE80-00023A BASE-PLATE MW850WA,SGCC1,T0.6,-,-,NC2000 1
MM29 2501-001011 C-OIL 910nF,2100V,BK,54x35x75mm,20mm 1
MM30 DE61-00139A BRACKET-HVC NC2000,SECC,T0.8,-,-,-,0.6/0 1
MM31 DE59-00002A DIODE-H.V ESJC13-12B,12KV,-,-,-,MWO ALL, 1
MM32 DE91-70061J ASSY-H.V.FUSE THV060T-0650-H,5KV0.65A,WL 1
MM55 3601-001019 FUSE-CARTRIDGE 250V,12A,SLOW-BLOW,CERAMI 1
MM55 3601-001126 FUSE-CARTRIDGE 250V,1.6A,FAST-ACTING,CER 1
MM57 DE61-00265A BRACKET-HEATER N7Q88,ALSTAR,T0.5,W49.5,L 2
MM59 DE71-60298A COVER-BACK -,SECC,T0.6,W273,L633,-,M6Q45 1
MM64 DE74-70071D RACK-WIRE MSWR10,PI3,0.7/NC2000,D230,H85 1
MM67 DE61-00263A BRACKET-UPPER N7Q88,SECC,T0.5,-,-,-,QUAR 1
MM88 DE73-90027B FERRITE RU65(RU15*28.6*6.5),-,M2L(FE2O3+ 1
7-3 Control & Door Parts List
No. Code No. Description Specification Q’ty Remark
MC01 - ASSY CONTROL-BOX - 1 S.N.A
MC03 DE64-00462E CONTROL-PANEL M1618R/BWT,XET,ABS,-,P/WHT,-,-, 1 WHITE
MC03 DE64-00462G CONTROL-PANEL G2712NR-S/BWT,ABS,SILVER,SER,S4(CHINA) 1 SILVER
MC04 DE61-70076A SPRING-BUTTON -,HSWR,PI0.6,PI0.6,-,-,-,- 1
MC05 DE66-20275A BUTTON-PUSH 3RD-W S1 MW5592W,-,-,-,-,9g 1 WHITE
MC05 DE66-20275F BUTTON-PUSH MW5592S/XAX 1 SILVER
MC08 DE45-00003A TIMER TMFK60M1A1,-,-,-,-,-,-,310 GRILL 1
MC09 DE64-00349A KNOB N8C77,ABS,-,-,-,-,PURE-WHT,-,- 2 WHITE
MC09 DE64-00349B KNOB M1712NR-S/BWT,ABS,SILVER,-,SER,N8A77 2 SILVER
MC12 3501-000309 RELAY-POWER 240V,3750VA,15A,-,6mS,20mS 1
MC13 DE94-00611D ASSY CONTROL-PANEL 230V50HZ,G2712N/XEG/X 1
MD01 - ASSY DOOR - 1 S.N.A
MD02 DE64-00091T DOOR-A M1618R/BWT,XET,ABS,-,P/WHT,-,-, 1 WHITE
MD02 DE64-00091X DOOR-A M1712NR-S/BWT,ABS,SILVER,SER,S4(CHINA) 1 SILVER
MD03 DE67-20186A SCREEN-DOOR 3RD-0.7CU.FT,SAN,T2.2,W354,L 1
MD04 DE92-50133C ASSY DOOR-E MW4593G,-,BLK,3RD-0.7 1
MD05 DE01-00112A FILM-DOOR -,PET,-,L268,T0.15,W150,NTR,- 1
MD06 DE64-40008B DOOR-C -,PP,CE745G,-,-,-,BLK,- 1
MD07 DE61-00198A SPRING-KEY M1877,HSWR,D6,-,-,23 1/4,23 1 1
MD10 DE64-40006F DOOR-KEY POM(F20-02),-,-,12G,BLK,MW7897G 1
MD11 DE94-00124B ASSY DOOR-SUB MW4593G,BLK,3RD-0.7,-,-,-, 1
S.N.A : SERVICE NOT AVAILABLE
7-4 Standard Parts List
Code No. Description Specification Q’ty Remark
DE60-10012A SCREW-TAP TITE -,SWR10,M4,L10,TH,+,-,3,ZPC2,- 1 N/P EARTH
DE60-10012A SCREW-TAP TITE -,SWR10,M4,L10,TH,+,-,3,ZPC2,- 1 P/C EARTH
DE60-10012A SCREW-TAP TITE -,SWR10,M4,L10,TH,+,-,3,ZPC2,- 1 PCB EARTH
DE60-10012A SCREW-TAP TITE -,SWR10,M4,L10,TH,+,-,3,ZPC2,- 1 TCO-S/W
DE60-10063A SCREW-TAP TH -,-,FEFN,-,TH,M4,-,L12,-,- 1 O/PANEL
DE60-10080B SCREW-WASHER -,2S,SWRCH18A,ZP2,PH,PI5,-,L10,-,- 4 HVT
DE60-10080B SCREW-WASHER -,2S,SWRCH18A,ZP2,PH,PI5,-,L10,-,- 4 MGT
DE60-10082H SCREW-A -,-,-,-,2S-4X12,TOOTHED,-,- ,-,- 1 AIR/COVER
DE60-10082H SCREW-A -,-,-,-,2S-4X12,TOOTHED,-,- ,-,- 2 B/LATCH
DE60-10082H SCREW-A -,-,-,-,2S-4X12,TOOTHED,-,- ,-,- 3 B/PLATE
DE60-10082H SCREW-A -,-,-,-,2S-4X12,TOOTHED,-,- ,-,- 1 C/BLOWER
DE60-10082H SCREW-A -,-,-,-,2S-4X12,TOOTHED,-,- ,-,- 1 C/BOX
DE60-10082H SCREW-A -,-,-,-,2S-4X12,TOOTHED,-,- ,-,- 4 O/PANEL
DE60-10098A SCREW-ASSY TAP TITE -,GLD,SWRCH18A,ZPC2,PH,TC,-,M4X8,WT,- 1 D/MOTOR
DE60-30016A NUT-FLANGE M4,MSWR10,-,-,-,-,-,-,- 2 F-MOTOR
DE60-10069A SCREW-TAP TH -,-,FRFZY,-,TH,M4,-,L10,-,- 1 RELAY
DE60-10069A SCREW-TAP TH -,-,FRFZY,-,TH,M4,-,L10,-,- 4 TIMER
DE60-10012A SCREW-TAP TITE -,SWR10,M4,L10,TH,+,-,3,ZPC2,- 1 B/COVER
DE60-10098A SCREW-ASSY TAP TITE -,GLD,SWRCH18A,ZPC2,PH,TC,-,M4X8,WT,- 1 HVD
