Samsung D528, SGH-D528 User Manual

Page 1

Depending on the software installed or your service provider or country, some of the descriptions in this guide may not match your phone exactly.

* Depending on your country, your phone and accessories may appear

different from the illustrations in this guide.

World Wide Web http://www.samsungmobile.com

Printed in Korea

Code No.:GH68-09480A

English. 09/2006. Rev. 1.1

Page 2

SGH-D528 User’s Guide

Page 3

Important

safety

precautions

Failure to comply with the following precautions may be dangerous or illegal.

Drive safely at all times

Do not use a hand-held phone while driving. Park the vehicle first.

Switch off the phone when refuelling

Do not use the phone at a refuelling point (service station) or near fuels or chemicals.

Switch off in an aircraft

Wireless phones can cause interference. Using them in an aircraft is both illegal and dangerous.

Switch off the phone near all medical equipment

Hospitals or health care facilities may be using equipment that could be sensitive to external radio frequency energy. Follow any regulations or rules in force.

Interference

All wireless phones may be subject to interference, which could affect their performance.

Page 4

Be aware of special regulations

Meet any special regulations in force in any area and always switch off your phone whenever it is forbidden to use it, or when it may cause interference or danger.

Water resistance

Your phone is not water-resistant. Keep it dry.

Sensible use

Use only in the normal position (held to the ear). Avoid unnecessary contact with the antenna when the phone is switched on.

Emergency calls

Key in the emergency number for your present location, then press .

Keep your phone away from small children

Keep the phone and all its parts, including accessories, out of the reach of small children.

Accessories and batteries

Use only Samsung-approved accessories and batteries. Use of any unauthorised accessories could damage your phone and may be dangerous.

• The phone could explode if the battery is replaced with an incorrect type.

• Dispose of used batteries according to the manufacturer’s instructions.

Use of authorised software

Use only Samsung-authorised software. The use of any unauthorised software could damage your phone.

Qualified service

Only qualified service personnel may repair your phone.

For more detailed safety information, see "Health and safety information" on page 92.

Important safety precautions

Page 5

About this Guide

This User’s Guide provides you with condensed information about how to use your phone. To quickly learn the basics for your phone, please refer to “Get started” and “Step outside the phone.”

In this guide, the following instruction icons appear:

Indicates that you need to pay careful attention to the subsequent information regarding safety or phone features.



[ ]

< >

Indicates that you can get more information on the referenced page.

Indicates that you need to press the Navigation

→

keys to scroll to the specified option and then select it.

Indicates a key on the phone. For example,

[]

Indicates a soft key, whose function is displayed on the phone screen. For example, <

• Camera and camcorder

Use the camera module on your phone to take a photo or record a video.

Special

features of your phone

• Image editor

Crop, resize, rotate, and decorate your photos.

•MP3 player

Play MP3 music files using your phone as a MP3 player.

•

File viewer

Open documents in various formats on the phone without corruption.

Page 6

•Bluetooth

Transfer media files and personal data and connect to other devices using free, wireless Bluetooth technology. You can also use a Bluetooth stereo headset to let you enjoy music with high quality stereo sound.

• Get personal with photo caller ID

See who’s calling you when their very own photo displays.

•Name card

Create name cards with your number and profile. Whenever introducing yourself to others, use this convenient electronic name card.

•

Multimedia Message Service (MMS)

Send and receive MMS messages with a combination of text, images, video, and audio.

•

E-mail

Send and receive e-mails with images, video, and audio attachments.

•Web browser

Access the wireless web to get up to-the-minute information and a wide variety of media content.

•Java

Enjoy Java™-based embedded games and download new games.

•Calendar

Keep track of your daily, weekly, and monthly schedule.

• Voice recorder

Record memos or sounds.

Special features of your phone

Page 7

Contents

Unpack 6

Make sure you have each item

Your phone 6

Buttons, features, and locations

Get started 7

First steps to operating your phone

Install and charge the phone ..................................... 7

Power on or off........................................................ 8

Keys and display ..................................................... 9

Access menu functions ............................................ 11

Customise your phone............................................. 12

Make/Answer calls .................................................. 14

Step outside the phone 14

Begin with your camera, the MP3 player, the web, and other special features

Use the camera ...................................................... 14

Play music ............................................................. 15

Browse the web...................................................... 16

Use Phonebook ...................................................... 17

Send messages ...................................................... 18

View messages....................................................... 19

Use Bluetooth ........................................................ 20

Enter text 22

Pinyin, PTI, Stroke, Quick English, English, Number, and Symbol modes

Call functions 28

Advanced calling features

Menu functions 32

All menu options listed

Solve problems 90

Help and personal needs

Health and safety information 92

Page 8

Overview of menu functions

To access Menu mode, press <

1 Call log

1 Recent contacts 2 Missed calls 3 Dialled calls 4 Received calls 5 Delete all 6 Call time 7 Call costs

2 Phonebook

1 Contact list 2 Create contact 3 Group 4 Speed dial 5 My namecard 6 Own number 7 Management 8 Service number



     



      



p. 32

p. 32 p. 33 p. 33 p. 33 p. 33 p. 33 p. 34

p. 34

p. 34 p. 35 p. 35 p. 36 p. 37 p. 37 p. 37 p. 38

3 Applications

1 MP3 player 2 Voice recorder 3 Image editor 4 Java world 5 World time 6 Alarm 7 Calculator 8 Converter 9 Timer 10 Stopwatch 11 Key management 12 SIM AT

4 Browser

1 Home 2 SFC home 3 Enter URL 4 Bookmarks 5 Saved pages 6 History 7 Clear cache 8 Browser settings

> in Idle mode.



p. 38



p. 38



p. 41



p. 42



p. 44



p. 44



p. 45



p. 45



p. 46



p. 46



p. 47



p. 47



p. 47



p. 47



p. 48



p. 49



p. 50



p. 50



p. 51



p. 51



p. 51



p. 51

5 Messages

1 Create message 2 My messages 3 Templates 4 Delete all 5 Settings 6 Memory status

6 File manager

1 Images 2 Videos 3 Music 4 Sounds 5 Other files 6 Memory status

7 Calendar



p. 51



p. 51



p. 54



p. 58



p. 59



p. 59



p. 64



p. 64



p. 65



p. 66



p. 67



p. 67



p. 68



p. 69



p. 69

8 Camera

9 Settings

1 Time and date 2 Phone settings 3 Display settings 4 Sound settings 5 Light settings 6 Network services 7 Bluetooth 8 Security 9 Connect settings 10 Reset settings

* Shows only if supported by your

SIM card.



p. 73



p. 78



p. 78



p. 78



p. 79



p. 80



p. 82



p. 82



p. 85



p. 87



p. 88



p. 90

Page 9

Unpack

Make sure you have each item

Your phon e

Buttons, features, and locations

Phone

Battery

Travel Adapter

User’s Guide

You can obtain various accessories from your local Samsung dealer.

• The items supplied with your phone and accessories available at your Samsung dealer may vary, depending on your country or service provider.

• Use the purchased accessories with only Samsung-authorised devices. The use of these accessories with other devices could cause problems and any repair costs would not be covered by the warranty.

Earpiece

Web access/

Confirm key

Volume ke ys

Left soft key

Dial key

Headset jack

Alphanumeric

keys

Special

function keys

Display

Navigation keys (Up/Down/Left/ Right)

Right soft key

Power on/off/ Menu exit key

Microphone

Delete key

Flash

Camera lens

Camera key

Page 10

Get started

First steps to operating your phone

SIM card information

When you subscribe to a cellular network, you receive a plug-in SIM (Subscriber Identity Module) card loaded with your subscription details, such as your PIN, and available optional services.

Install and charge the phone

Remove the battery cover.

Insert the SIM card.

Install the battery. Replace the battery

cover.

Plug the travel adapter into the phone.

If the phone is already on, first turn it off by pressing and holding [].

Make sure that the goldcoloured contacts on the card face down into the phone.

Plug the adapter into a standard AC wall outlet.

Page 11

Get started

When the phone is completely charged (the battery icon becomes still), unplug the adapter from the power outlet.

Remove the adapter from the phone.

Power on or off

Switch on

Do not turn on the phone when mobile phone use is prohibited.

1. Open the phone.

2. Press and hold [ ] to turn on

3. If necessary, enter the PIN and

the phone.

press <OK>.

Low battery indicator

When the battery is low:

• a warning tone sounds,

• the low battery message displays, and

• the empty battery icon blinks.

If the battery level becomes too low, the phone automatically turns off. Recharge your battery.

Switch off

Keypad lock

When you close the phone, the keypad lock feature locks the exposed keys so that nothing will happen if the keys are accidentally pressed.

To unlock the keypad, press < <OK>.

1. Open the phone.

2. Press and hold [ ].

Unlock

> and press

Page 12

Keys and display

Keys

Perform the function indicated on the bottom line of the display.

In Idle mode, access your favourite menus



directly. In Menu mode, scroll through menu options.

In Idle mode, launch the web browser. In Menu mode, select the highlighted menu

option or confirm input.

Make or answer a call. In Idle mode, retrieve the recent numbers

dialled, missed, or received.

Delete characters from the display or an item in an application.

End a call. Press and hold to switch the phone on or off. In Menu mode, cancel input and return the

phone to Idle mode.

p. 79

Enter numbers, letters, and some special characters.

In Idle mode, press and hold your voicemail server. Press and hold [ enter an international call prefix.

Enter special characters. In Idle mode, press and hold [ ] to activate

or deactivate Quiet mode. Press and hold [ ] to enter a pause between numbers.

Adjust the phone volume. In Idle mode, with the phone open, adjust

the keypad tone volume. With the phone closed, press and hold to turn on the display.

In Idle mode, press and hold to turn on the camera.

In Camera mode, take a photo or record a video.

[1]

to access

] to

Get started

Page 13

Get started

Display

Layout

Icons

Menu Contacts

Icons

display various icons.

Text and graphics

display messages, instructions, and information you enter.

Soft key function indicators

show the current functions assigned to the soft keys.

Received signal strength Call in progress Out of your service area; you

cannot make or receive calls GPRS network Connecting to GPRS network Roaming network New message New e-mail

New voicemail Call diverting feature active Home Zone, if registered for the

appropriate service



p. 82

Office Zone, if registered for the appropriate service

Connected to Bluetooth hands-free car kit or headset

Bluetooth active



p. 85 Synchronised with PC MP3 playback in progress MP3 playback paused Alarm set Call ringer set to vibrate



p. 45



p. 80 Quiet mode (Vibration) Quiet mode (Mute) Mute mode, during a call Battery power level

* Depending on your country or service provider, the icons

shown on the display may vary.

Page 14

Access menu functions

Use the soft keys

The roles of the soft keys vary depending on the function you are using. The bottom line of the display indicates their current role.

Select Bac

Press the left soft key to select the highlighted option.

Press the right soft key to return to the previous menu level.

Select an option

1. Press the appropriate soft key.

2. Press the Navigation keys to move to the next or previous option.

3. Press <

Select

>, <OK>, or [ ] to confirm the function displayed or option highlighted.

4. To exit, choose either of the following methods:

•Press <

Back

> to move up

one level.

• Press [ ] to return to Idle

mode.

Get started

Use shortcuts

Press the number key corresponding to the option you want. For the index numbers 10, 11 and 12, press [0], [ ], and [ ], respectively.

Page 15

Get started

Customise your phone

Display language

Call ringer melody

1. In Idle mode, press < and select

settings → Language

2. Select a language.

1. In Idle mode, press < and select

settings → Incoming call → Ringtone

2. Select a ringtone category.

3. Select a ringtone.

4. Press <

Settings → Phone

Settings → Sound

Save

Idle mode

wallpaper

Menu mode skin colour

You can set wallpaper for the idle screen on the display.

1. In Idle mode, press < and select

settings → Wallpaper → Main display

2. Select an image category.

3. Select an image.

4. Press <

You can change the colour for the display components, such as title bars and highlight bars.

1. In Idle mode, press < and select

settings → Skin

2. Select a colour pattern.

Settings → Display

Save

Settings → Display

Page 16

Menu shortcuts

Quiet mode

You can set the Navigation keys to function as shortcuts to access your favourite menus.

1. In Idle mode, press < and select

settings → Shortcut

2. Select a key.

3. Select a menu to be assigned to the key.

You can switch the phone to Quiet mode to avoid disturbing other people.

Press and hold [ ] in Idle mode.

Settings → Phone

Phone lock

You can protect the phone against unauthorised use with a phone password. The phone will require the password on power-up.

1. In Idle mode, press < and select

Security → Change password

2. Enter the default password,

00000000

3. Enter a new 4- to 8-digit password and press <OK>.

4. Enter the new password again and press <OK>.

5. Select

6. Select

7. Enter the password and press <OK>.

Settings →

, and press <OK>.

Phone lock

Enable

Get started

Page 17

Make/Answer calls

Make a call

Answer a call

Adjust the volume during a call

1. In Idle mode, enter an area code and phone number.

2. Press [ ].

3. To end the call, press [ ].

1. When the phone is ringing, press [ ].

2. To end the call, press [ ].

Press [ / ].

Step outside the phone

Begin with your camera, the MP3 player, the web, and other special features

Use the camera

Take a photo

1. Open the phone.

2. In Idle mode, press and hold [] to turn on the camera.

3. Aim the lens at the subject and make any desired adjustments.

4. Press [ ] or [] to take a photo. The photo is saved automatically.

Pres

s <

Preview

another photo.

> to

take

View a photo

1. In Idle mode, press < and select

Images → My photos

2. Select the photo you want.

File manager →

Page 18

Record a video

Play a video

1. In Idle mode, press and hold [] to turn on the camera.

2. Press [1] to switch to Record mode.

3. Press [ ] or [] to start recording.

4. Press [ ], < > or [] to stop recording. The video is saved automatically.

5. Press <

2. Select the video you want.

Preview

another video.

In Idle mode, press < and select

Videos → My video clips

> to record

File manager →

Play music

Copy music files to the phone

Create a play list

Use these methods:

• Download from the wireless webp. 47

• Download from a computer using the optional Samsung PC StudioSamsung PC Studio User’s Guide

• Receive via Bluetoothp. 87

1. In Idle mode, press < and select

MP3 player

2. Press <

Add music → Add all files

Applications →

Options

> and select

Add

Step outside the phone

Page 19

Step outside the phone

Create a play list

(continued)

Play music files

3. For

Add files

select the files you want and press <

4. Press < MP3 player screen.

1. From the MP3 player screen, press [ ].

2. During playback, use the following keys:

• : pauses or resumes

playback.

• Left: moves back to the

previous file.

• Right: skips to the next file.

• Up: opens the play list.

• / : adjusts the volume.

• Down: stops playback.

, press [ ] to

Select

Back

> to return to the

Browse the web

Using a built-in web browser, you can easily access the wireless web to get a variety of up-to-date services and information and to download web content.

Launch the web browser

Navigate the web

In Idle mode, press [ ] and select

Home

• To scroll through browser items, press [Up] or [Down].

• To select an item, press [ ].

• To return to the previous page, press <

Back

• To move to the next page, press <

Options

Forward

• To access options, press <

Options

> and select Go →

Page 20

Use Phonebook

Add an entry

To the phone’s memory:

1. In Idle mode, enter a phone

2. Select

3. Specify contact information:

4. Press <

To t h e S I M c a rd :

1. In Idle mode, enter a phone

2. Select

3. Enter a name.

4. Press <

number and press <

Save contact → Phone

→

a number type.

First name, Last name, Mobile, Home, Office, Fax, Other, Email, Caller ID, Ringtone, Group, and Memo.

Save

number and press <

Save contact → SIM

Save

Options

> to save the entry.

Options

> to save the entry.

Find an entry

Create and send a name card

1. In Idle mode, press <

Contacts

2. Enter the first few letters of the name you want.

3. Select an entry.

4. Scroll to a number and press [] edit contact information.

1. In Idle mode, press < and select

namecard

2. Specify your contact information.

3. Press < name card.

4. To send the name card, press <

Options

via → a sending method.

to dial, or press [ ] to

Phonebook →

Save

> to save the

> and select

Send

Step outside the phone

Page 21

Step outside the phone

Send messages

Send a text message (SMS)

Send a multimedia message (MMS)

1. In Idle mode, press < and select

message →

2. Enter the message text.

3. Press <

Save and send

4. Enter destination numbers.

5. Press [ ] to send the message.

1. In Idle mode, press < and select

message → message

2. Select

3. Enter the message subject and press [ ].

Messages → Create

Text message

Options

Messages → Create

Multimedia

Subject

> and select or

Send only

4. Select

5. For

6. Select

7. Enter the message text and

8. Press <

9. Enter destination numbers or

10. Press [ ] to send the

Image and video

Sound

Image and video

Add image

add an image or video clip. For

and add a sound clip.

press [ ].

Send

addresses.

message.

Sound

Message

Options

, select

Add video

Add sound

> and select

and

Page 22

Send an e-mail

1. In Idle mode, press < and select

message →

2. Select

3. Enter the e-mail subject and press [ ].

4. Select

5. Enter the e-mail text and press [].

6. Select

7. Add image, video, sound, music files, or document files.

8. Press <

Send

9. Enter e-mail addresses.

10. Press [ ] to send the e-mail.

Messages → Create

Subject

Message

File attached

Options

Menu>

> and select

View messages

View a text message

View a multimedia message

When a notification appears:

1. Press <

2. Select the message from the

From the Inbox:

1. In Idle mode, press <

2. Select an SMS message ( ).

When a notification appears:

1. Press <

2. Press <

3. Select the message from the

View

Inbox.

and select

messages → Inbox

Retrieve

Inbox.

Messages → My

View

Options

> and select

Step outside the phone

Page 23

Step outside the phone

View a multimedia message

(continued)

View an e-mail

From the Inbox:

1. In Idle mode, press < and select

messages → Inbox

2. Select an MMS message ( ).

1. In Idle mode, press < and select

messages →

2. Select an account.

3. Press < e-mails or headers.

4. Select an e-mail or a header.

5. If you selected a header, press <

Options

Retrieve

the e-mail.

Messages → My

Yes

> to download new

> and select

to view the body of

Email inbox

Use Bluetooth

Your phone is equipped with Bluetooth technology, enabling you to connect the phone wirelessly to other Bluetooth devices and exchange data with them, talk hands-free, or control the phone remotely.

Turn on Bluetooth

Search for and pair with a Bluetooth device

In Idle mode, press < select

Settings → Bluetooth →

Activation → On

1. In Idle mode, press < and select

Bluetooth → My devices → Search for new devices

2. Select a device.

3. Enter a Bluetooth PIN or the other device’s Bluetooth PIN, if it has one, and press <OK>.

When the owner of the other device enters the same code, pairing is complete.

Settings →

> and

Page 24

Send data

1. Access an application,

Phonebook, File manager Calendar

2. Scroll to an item.

3. Press <

Send via →

4. Select a device.

5. If necessary, enter the Bluetooth PIN and press <OK>.

Options

Bluetooth

> and select

, or

Step outside the phone

Receive data

To receive data via Bluetooth, your phone’s Bluetooth feature must be active.

If necessary, press < confirm that you are willing to receive.

Yes

> to

Page 25

Enter text

Pinyin, PTI, Stroke, Quick English, English, Number, and Symbol modes

You can enter text for some features, such as Messages, Phonebook, or Calendar, by using Pinyin, PTI, and Stroke modes for Chinese, and Quick English and English modes for English. You can also enter Korean, numbers and symbols.

Changing the text input mode

• Press the right soft key and select the text input mode you want.

Pinyin ( ) PTI ( )

Chinese S Stroke ( ) Chinese T Stroke ( )

Number ( ) Symbol (No indicator)

Korean ( ) Quick English ( )

English ( )

• Press and hold [ ] to quickly switch to Symbol mode.

Using Chinese Pinyin mode

Pinyin is a system to enter Chinese words by spelling them phonetically (how they sound) using the Latin alphabet. With the Pinyin input method, you can enter Chinese characters by keying in the Pinyin string using the phone’s keypad.

Entering characters in Pinyin mode

1. Press the keys corresponding to the phonetic spelling, referring to the letters printed on the keys.

Example

ni.

2. Press [Left] or [Right] to select alternative pinyins for the keys you have pressed.

3. If you cannot find the character you want from the display, press [Up] or [Down] to scroll through the word choices.

4. Press [1] to activate the character selection field. A number, from 1 to 5, is added to each character.

: To enter , press [6] and [4] to enter

Page 26

5. Press the number key corresponding to the character you want.

Rapid character entry

To enter the word zhong guo ( ), enter the first character using the following keystrokes; [9], [4], [6], [6], [1], and [1]. You do not have to complete the Pinyin spelling to include guo ( ). The character displays automatically.

Tips for using Pinyin mode

• Press [ ] to insert a space.

• Press and hold [ ] to start a new line.

• Press [Left] or [Right] to move the cursor.

•Press [C] to clear letters one by one. Press and hold [C] to clear the entire display.

Using Phrasal Text Input mode

Phrasal Text Input (PTI) is an advanced Pinyin mode which predicts not only words, but phrases for your key presses. Using PTI mode, you can also add new words or phrases to the PTI dictionary.

Entering characters in PTI mode

Entering characters in PTI mode is basically the same as in Pinyin mode except that you can enter phrases. Refer to “Using Chinese Pinyin mode.”

Adding words or phrases to the PTI dictionary

Once you have assigned words or phrases to the PTI dictionary, the words or phrases will be the first choices for the corresponding key presses.

1. Press <

2. Enter the word or the phrase you want.

3. Press <OK> to add the word or the phrase to the

Options

add the word or the phrase you want to the PTI dictionary.

PTI dictionary, and it is inserted into your text automatically.

> and select

Add new phrases

Using Chinese Stroke mode

This mode allows you to enter individual Chinese strokes, in written order, from top to bottom, and from left to right.

Enter text

Page 27

The Chinese strokes are classified into five basic categories; heng, shu, pie, dian, and zhe. The basic strokes are printed on keys [1] to [5] on the keypad.

Refer to the following table:

Category Key Strokes represented in each category

Entering strokes and characters in Stroke mode

1. Press the keys that correspond to a character’s component strokes. Press keys in the order that you would write the strokes, using one press per stroke.

Example

: To enter , press [5] to enter and

[3] to enter .

If you are uncertain of the stroke order, press [6] in place of each questionable stroke. Continue entering strokes until the character displays or until you finish the character.

2. Press [Up] or [Down] to scroll through the choices.

3. To select a character and add it to your message, press the corresponding key, [7] to [ ].

Rapid character entry

Try entering the characters zhong guo () using the following keystrokes: [2], [0], and [7]. Even though zhong guo ( ) is a twelve stroke character, your phone allows you to enter the complete pair in only three key presses.

Tips for Stroke mode

• Press

• Press and hold

[

]

to insert a space.

[

]

to start a new line.

• Press [Left] or [Right] to move the cursor.

• Press [C] to clear letters one by one. Press and hold [C] to clear the entire display.

Page 28

Using Quick English mode

This mode allows you to enter English by using T9 technology. T9 is a predictive text input mode that allows you to key in any character using single keystrokes.

Entering a word in Quick English mode

1. Press [2] to [9] to start entering a word. Press each key once for each letter.

Example

enter Hello. T9 predicts the word that you are typing, and it

may change with each key that you press.

2. Enter the whole word before editing or deleting the characters.

3. When the word displays correctly, go to step 4. Otherwise, press [0] to display alternative word choices for the keys that you have pressed.

Example

4. Press word.

: Press [4], [3], [5], [5], and [6] to

: Of and Me use [6] and [3].

[

]

to insert a space and enter the next

Tips for using Quick English mode

• Press [1] to enter periods or apostrophes automatically.

• Press

• Press and hold

• Press the Navigation keys to move the cursor.

• Press [C] to delete characters one by one. Press

[

]

to change case.

[

]

to start a new line.

and hold [C] to clear the entire display.

Adding a new word to the T9 dictionary

1. Enter the word that you want to add.

2. Press [0] to display alternative words for your keys presses. When there are no more alternative words,

Add

appears on the bottom line.

3. Press <

4. Enter the word you want using English mode and

Add

press <OK>.

Enter text

Page 29

Enter text

Using English mode

Press the appropriate key until the character you want appears on the display.

Key

. , - ? ! @ : ( ) / # _ ~ 1

A B C 2 a b c 2

D E F 3 d e f 3

G H I 4 g h i 4

J K L 5 j k l 5

M N O 6 m n o 6

P Q R S 7 p q r s 7

T U V 8 t u v 8

W X Y Z 9 w x y z 9

space

Tips for using English mode

• To enter the same letter twice or to enter a different letter on the same key, wait for the cursor to move to the right automatically or press [Right]. Then, enter the next letter.

Characters in order displayed

Upper case Lower case

+ = < > £ $ % & ¥ ¤ 0

• Press

• Press and hold

[

]

to insert a space.

[

]

to start a new line.

• Press the Navigation keys to move the cursor.

• Press [C] to delete characters one by one. Press and hold [C] to clear the display.

Using Korean mode

You can enter Korean words by pressing the associated keys repeatedly as you would in English mode.

Entering Korean consonants

When typing Korean consonants, you should press the corresponding keys according to the character selection field on the display until the character you want appears.

Example

Press the 4 key once for .

Press the 4 key twice for .

Page 30

The double consonants ( , , , , ) don’t display in the character selection field. You can enter them in the following way:

Press the 4 key three times for .

Press the 6 key three times for .

Press the 7 key three times for“ .

Press the 8 key three times for .

Press the 9 key three times for .

Entering Korean vowels

Korean vowels are entered by using , , or . is dependent and should be added to or to complete a letter.

Example

Press the 0, 2 and 1 key for .

Press the 0, 1, 2, 2, and 1 key for .

Press the 0, 3 and 2 key for .

Press the 0, 3, 2, and 2 key for .

Press the 0, 3, 2, 2, 1, and 1 key for .

Entering a Korean word

You can enter a Korean word using the combination of consonants and vowels.

Example

Press the 7, 1, 2, and 5 keys for .

Press the 4, 1, 2, and 7 keys for .

Press the 8, 3, and 7 keys for .

Press the 5 and 1 keys for .

Press the 6, 1, and 2 keys for .

: Entering

Other Korean mode operations

• Press

• Press and hold

• Press the Navigation keys to move the cursor.

• Press [C] to delete characters one by one. Press

[

]

to insert a space between characters.

[

]

to start a new line.

and hold [C] to clear the display.

Using Number mode

Number mode enables you to enter numbers.

Press the keys corresponding to the digits you want.

Page 31

Using Symbol mode

Symbol mode enables you to insert symbols.

To Press

display more symbols [Up] or [Down].

select a symbol the corresponding

number key.

clear the entered symbols [C].

insert the symbols <OK>.

Call functions

Advanced calling features

Making a call

1. In Idle mode, enter the area code and phone number.

2. Press [ ].

• Press [C] to clear the last digit or press and hold

] to clear the whole display.

[

• Press and hold [ ] to enter a pause between numbers.

Making an international call

1. In Idle mode, press and hold [0]. The + character appears.

2. Enter the country code, area code, and phone number, then press [ ].

Redialling recent numbers

1. In Idle mode, press [ ] to display the list of recent numbers.

2. Scroll to the number you want and press [ ].

Page 32

Making a call from Phonebook

Once you have stored a number in Phonebook, you can dial the number by selecting it from Phonebook.



p. 34

You can also use the speed dial feature to assign your most frequently called numbers to specific number keys.p. 36

You can quickly dial a number from the SIM card using its location number assigned when stored.

1. In Idle mode, enter a location number and press [].

2. Press [Left] or [Right] to scroll through other numbers.

3. Press <

Dial

> or [ ] to dial the number you want.

Ending a call

Close the phone or press [ ].

Answering a call

When you receive an incoming call, the phone rings and displays the incoming call image.

Press <

> or [ ] to answer the call.

Tips for answering a call

• When

• Press <

• Press and hold [ / ] to reject a call or mute the

Anykey answer

any key, except for <

Reject

ringer, depending on the setting.p. 79

Reject

> or [ ] to reject a call.

is active, you can press

> and [ ].p. 79

Volume key

Viewing missed calls

If you have missed calls, the screen displays how many calls you have missed.

1. Press <

2. If necessary, scroll through the missed calls.

3. Press [ ] to dial the number you want.

View

Call functions

Page 33

Call functions

Using the headset

Use the headset to make or answer calls without holding the phone.

Connect the headset to the jack on the left side of the phone. The button on the headset works as follows:

To Press

redial the last call and hold the button twice.

answer a call the button.

end a call the button.

Options during a call

You can access a number of functions during a call.

Adjusting the volume during a call

Use [ / ] to adjust the earpiece volume during a call.

Press [ ] to increase the volume level and [ ] to decrease the volume level.

Placing a call on hold/Retrieving

Press <

Hold

> or <

or retrieve the call.

Retrieve

> to place a call on hold

Making a second call

You can make another call if your network supports this function.

1. Press <

2. Make the second call in the normal way.

3. Press <

4. Press <

5. To end the current call, press [ ].

Hold

> to put the call on hold.

Swap

> to switch between the calls.

Options

the call on hold.

> and select

End held call

to end

Answering a second call

You can answer an incoming call while already on the phone, if your network supports this function and you have activated the call waiting feature.p. 83

1. Press [ ] to answer the call. The first call is automatically put on hold.

2. Press <

Swap

> to switch between the calls.

Page 34

3. Press <

Options

> and select

End held call

to end

the call on hold.

4. To end the current call, press [ ].

Using the speakerphone feature

Use the speakerphone feature to talk and listen with the phone a short distance away.

Press [ ] and then <

Yes

> to activate the Speakerphone feature. Press the key again to switch back to the earpiece.

Using In-call options

Press <

Options

during a call:

•

Speaker on/Normal

feature or switch back to Normal mode.

•

Switch to headset/Switch to phone

call to a Bluetooth headset or hands-free car kit or back to the phone. To use this feature, you first need to connect your headset to the phone.



p. 85

•

> to access the following options

: turn on the Speakerphone

: switch the

: access the phone's menu functions.

•

Voice on/Voice off

: switch off the phone's microphone so that the other person on the phone cannot hear you, or switch it back on.

•

Mute keys/Send keys

: switch the key tones on

or off.

To communicate with answering machines or computerised telephone systems, must be selected.

•

Send DTMF

: send the DTMF (Dual tone multi-

Send keys

frequency) tones as a group. The DTMF tones are the tones used in phones for tone dialling, sounding when you press the number keys. This option is helpful for entering a password or an account number when you call an automated system, like a banking service.

•

Phonebook

•

End held call

: access the contact list.

: disconnect the call currently on

hold.

•

Transfer

: transfer the currently active call to a caller on hold. The two callers can talk to each other, but you are disconnected from the call.

Page 35

Menu functions

•

Join

: set up a multi-party call by adding a caller on hold to a currently active call. You can include up to 5 people on a multi-party call.

•

Select one

participants. You can then use the following options:

Private

multi-party call participant. The other participants can converse with each other. After the private conversation, select participants to the multi-party call.

Remove

participant.

: select one of multi-party call

: have a private conversation with one

Join

to return both all private

: disconnect one multi-party call

Menu functions

All menu options listed

Call log

Use this menu to view the calls you have dialled, received, or missed, and the length of calls. You can also check the cost of your calls, if your SIM card supports this function.

To access this menu, press < select

Recent contacts

This menu displays the most recent calls dialled, received, or missed.

Accessing a call record

1. Press [Left] or [Right] to move to another call

2. Press [Up] or [Down] to scroll through the call list.

3. Press [ ] to view the details of a call, or [ ] to

(Menu 1)

Call log

type.

dial a number.

(Menu 1.1)

> in Idle mode and

Page 36

Using call record options

While viewing call details, press < the following options:

•

Call

: edit the number and dial it.

•

Add to Phonebook

Phonebook.

•

Send

: send an SMS or MMS message to the

selected number.

•

Delete

: delete the selected call record or all

records.

Missed calls

This menu displays the most recent calls you did not answer.

Dialled calls

This menu displays the most recent calls you have dialled.

(Menu 1.3)

Received calls

This menu displays the most recent calls you have received.

: save the number to

(Menu 1.2)

(Menu 1.4)

Options

> to access

Delete all

Use this menu to delete all of the records in each call type.

1. Press [ ] to select the call types to be cleared.

2. Press <

3. Press <

Call time

This menu displays the time log for calls made and received. The actual time invoiced by your service provider will vary.

•

Last call time

•

Total dialled calls

the calls you have dialled.

•

Total received calls

the calls you have received.

• To reset the call tiomer, press < to enter the phone password.

(Menu 1.5)

Delete Yes

(Menu 1.6)

The password is preset to change this password.

> to confirm the deletion.

: check the length of your last call.

: check the total length of all



Reset

00000000

p. 88

>. You need

. You can

Menu functions

Call log

(Menu 1)

Page 37

Menu functions

Call costs

This network feature displays the cost of calls. This menu is available only if supported by your SIM card. Note that this is not intended to be used for billing purposes.

•

Last call cost

•

Total cost

If the total cost exceeds the maximum cost set in

Set max. cost

you can make another call.

•

Max. cost Set max. cost

•

Reset counters

•

Set max. cost

for your calls.

•

Price/Unit

when the cost of your calls is calculated.

(Menu 1.7)

: check the maximum cost limit set in

: check the cost of your last call.

: check the total cost of all of your calls.

, you must reset the counter before

: reset the cost counters.

: set the maximum cost authorised

: set the price per unit that is applied

Phonebook

You can store phone numbers on your SIM card and in your phone’s memory. The SIM card and phone’s memory are physically separate, but they are used as a single entity called Phonebook.

To access this menu, press < select

Phonebook

Contact list

Use this menu to search for numbers in Phonebook.

(Menu 2)

(Menu 2.1)

> in Idle mode and

Finding an entry

1. Enter the first few letters of the name that you want to find.

2. Select the name from the list.

3. Scroll to a number and press [ ] to dial or press [ ] to edit contact information.

Using Phonebook options

While viewing contact details, press < access the following options:

•

Edit

: edit contact information.

Options

> to

Page 38

•

Send message

: send an SMS or MMS message to the selected number, or an e-mail to the selected address.

•

Copy to

: copy the contact to the phone’s memory

or to the SIM card.

•

Send via

: send the contact via SMS, MMS, e-mail,

or Bluetooth.

•

Delete

: delete the selected contact.

Create contact

(Menu 2.2)

Use this menu to add a new contact to Phonebook.

Storing a number in the phone’s memory

1. Select

Phone

2. Change the settings or enter information about the contact.

•

First name/Last name

•

Mobile/Home/Office/Fax/Other

: assign a name.

: add a

number in any type.

•

: assign an e-mail address.

•

Caller ID

: assign an image to alert you to a

call from the person.

•

Ringtone

: assign a ringtone to alert you to a

call from the person.

•

Group

: assign the contact to a caller group.

•

Memo

: add a memo about the person.

3. Press <

Save

> to save the contact.

Storing a number on the SIM card

1. Select

SIM

2. Enter information about the contact.

•

Name

: assign a name.

•

Phone number

•

Location

To assign a caller ID image, ringtone, or group, the contact must be saved to the phone’s memory.

3. Press <

Group

Save

(Menu 2.3)

: add a number.

: assign a location number.

> to save the contact.

Use this menu to organise your contacts in caller groups.

Menu functions

Phonebook

(Menu 2)

Page 39

Menu functions

Creating a new caller group

1. Press <

2. Enter a name for the group.

3. Select the caller ID line and set an image.

4. Select the ringtone line and set a melody.

5. Press <

Adding members to a caller group

1. Select a group.

2. Press <

3. Press [ ] to select the contacts to be added.

4. Press <

Managing caller groups

While viewing the group list, press < access the following options:

•

Options

Save

Add

Options

View

: display the members of the selected group.

Create group Edit

: change the group properties.

Send message

message to the group members you want.

> and select

> to save the group.

> and choose

: add a new group.

: send an SMS, MMS, or e-mail

Create group

Select

Options

> to

•

Delete

: delete the selected group or all groups. Group members, however, will not be deleted from Phonebook.

Speed dial

Use this menu to assign a speed dial number (2 to 9) for 8 of your most frequently called numbers.

(Menu 2.4)

Assigning speed dial numbers

1. Select a key location from 2 to 9. Key 1 is reserved for your voicemail server.

2. Select a contact from the contact list.

3. Select a number, if the contact has more than one number.

Managing speed dial entries

From the Speed dial screen, press < access the following options:

•

Add

: assign a number to an unassigned key.

•

View

: check the name and number assigned to a

key.

•

Change

: assign a different number to a key.

•

Remove

: clear the speed dial setting for a key.

Options

> to

Page 40

Dialling speed dial entries

In Idle mode, press and hold the appropriate key.

My namecard

Use this menu to create a name card and send it to other people.

(Menu 2.5)

Saving your name card

The procedure for creating your name card is the same as the one for saving a phone number in the phone’s memory.p. 35

Using name card options

After saving your name card, press < access the following options:

•

Edit

: edit the name card.

•

Send via

e-mail, or Bluetooth.

•

Exchange namecard

another person via Bluetooth.

•

Delete

: send the name card via SMS, MMS,

: exchange name cards with

: delete the name card.

Options

> to

Own number

Use this menu to check your phone numbers, or to assign a name to each of the numbers. Changes made here do not affect the actual subscriber numbers on your SIM card.

Management

Use this menu to manage Phonebook entries.

•

Save new contact to

location for saving contacts. If you select

ask

, the phone will ask you to select a memory

location each time you save a number.

•

Copy all to

SIM card to the phone’s memory, or vice versa.

•

Delete all

phone’s memory, your SIM card, or both.

•

Memory status

you have stored in the phone’s memory and on the SIM card.

(Menu 2.6)

(Menu 2.7)

: copy all of the contacts stored on the

: delete all of the contacts from your

: select a default memory

Always

: check the number of contacts

Menu functions

Phonebook

(Menu 2)

Page 41

Menu functions

Service number

Use this menu to view the list of Service Dialling Numbers (SDN) assigned by your service provider, including emergency numbers and numbers for directory enquiries. This menu is available if your SIM card supports SDN.

1. Scroll to the number you want.

2. Press <

Dial

Applications

Use this menu to play Java games, play music files, or edit photos. You can also use convenient features, such as a voice recorder, alarm clock, calculator, converter, and stopwatch.

To access this menu, press < select

Applications

(Menu 2.8)

> or [ ].

(Menu 3)

> in Idle mode and

MP3 player

Use this menu to enjoy music. First, you need to save music files into your phone’s memory. You can play MP3, AAC, and M4A files from the phone’s memory.

To enjoy high quality music, you can use an optional Bluetooth stereo headset.

Normal headsets and Blooth mono headsets are not compatible with the MP3 player.

(Menu 3.1)

Downloading or receiving music files

Use these methods to save music files to your phone’s memory:

• Download from the wireless webp. 47

• Download from a computer using the optional Samsung PC StudioSamsung PC Studio User’s Guide

• Receive via an active Bluetooth connectionp. 87

The downloaded or received files are stored in the

Music

folder.p. 67

Page 42

Creating a play list

1. From the MP3 player screen, press < and select

2. Select either of the following options:

•

3. If you select and press <

4. Press <

Add music

Add all

: add all of the files in the phone’s

memory to the play list.

Add files

: add specific files to the play list.

Add files

Select

Back

> to return to the MP3 player screen.

, select the files you want

Options

Playing music files

1. From the MP3 player screen, press < and select

2. Select Select

Bluetooth headset and then search for and connect to the headset.

During playback, use the following keys:

Key Function

Play via Phone Bluetooth stereo headset

Pauses or resumes playback.

to use the phone speaker.

Options

to use a

Key Function

Left Moves back to the previous file. Right Skips to the next file. Up Opens the play list. Down Stops playback.

/ Adjusts the volume level.

2 3

5 6

Turns 3D sound on or off. Changes the playback animation. Changes the repeat mode. Changes the equaliser mode. Changes the skin type. Turns Shuffle mode on or off.

Using MP3 player options

From the MP3 player screen, press < access the following options:

•Play via Bluetooth stereo headset

•

Play/Pause

: select a sound output mode,

: begin or pause playback.

Options

> to

Phone

Menu functions

Applications

(Menu 3)

Page 43

Menu functions

•

Transfer to phone

the phone speaker.

•

Open playlist

album or album list. On the album list, you can set up multiple albums.

•

Go to music

•

Send via

Bluetooth.

•

Set as

ringtone for a Phonebook entry.

•

Activate key

the selected DRM file expires.

•

Remove from playlist

from the play list.

•

Settings

music files.

Repeat mode Shuffle

random order.

MP3 overrides other sounds

to continue playback even if you exit it.

: send the current file via e-mail or

: set the file as your ringtone or as a

: change the default settings for playing

: set the MP3 player to play tracks in

: switch the sound output to

: access the play list of the current

: access the

: get a license key when the key for

: select a repeat mode.

Music

folder.

: remove the selected file

: set the MP3 player

Equaliser 3D sound Visualisation

and select the length of time the backlight remains on while playing MP3 files.

Skin Volume

•

Details

•

Key management

have acquired.

: select an equaliser setting.

: turn 3D sound on or off.

: change the playback animation

: select a skin type.

: select a volume level.

: access the file properties.

: manage the license keys you

Accessing the play list

From the MP3 player screen, press [Up].

Press <

Options

•

Play via Bluetooth stereo headset

currently selected file.

•

Add music

•

Go to album list

•

Move to

•

Copy to

> to access the following options:

: select a sound output mode,

and then play the

: add files to the play list.

: access the album list.

: move the selected file to another album.

: copy the selected file to another album.

Phone

Page 44

•

Move track in playlist

the position you want within the play list.

•

Activate key

for the selected DRM file expires.

•

Remove

the play list.

•

Details

•

Key management

have acquired.

: get a new license key when the key

: remove the selected file or all files from

: access the file properties.

Voice recorder

Use this menu to record voice memos. A voice memo can be up to one hour long.

: move the selected file to

: manage the license keys you

(Menu 3.2)

Recording a voice memo

1. Press [ ] to start recording.

2. Speak into the microphone. Press [ ] to pause or resume recording.

3. Press <

4. Press [ ] to review the voice memo, or [Up] to

Stop

voice memo is saved automatically.

record a new memo.

> or [Down] to end recording. The

Playing a voice memo

1. From the Voice recorder screen, press < and select

2. Select a voice memo.

During playback, use the following keys:

Key Function

Left Moves backward in a memo.

Right Moves forward in a memo.

/ Adjusts the volume.

Down Stops playback.

Go to My voice clips

Pauses or resumes playback.

Options

Changing the recording mode

You can change the recording mode of the voice recorder. The maximum recording time is determined by this setting. Before recording a memo, press <

Options

•

> and select

Limit for multimedia message

memo for adding to an MMS message.

Settings → a recording mode:

: record a voice

Menu functions

Applications

(Menu 3)

Page 45

Menu functions

•

Limit for email

to an e-mail.

•

Maximum 1 hour

one hour.

Image editor

Use this menu to edit your photos using various editing tools.

Applying an effect

1. Press <

2. Select a photo or take a new photo.

3. Press <

4. Press <

5. Press <

6. Enter a new file name, press <

Options

Take photo

Options

option.

Done Options

select OK.

Transforming

1. Select a photo or take a new photo.

: record a voice memo for adding

: record a voice memo of up to

(Menu 3.3)

> and select

New image → Open

Effects →

Save as

Options

an effect

> and

2. Press <

3. Press <

4. Press <

5. Enter a new file name, press <

Options

option:

•

Resize

: change the photo size.

•

Rotate

: rotate the photo 90 degrees clockwise

or counterclockwise.

•

Flip

: flip the photo.

Done

Options

select OK.

> and select

Transform →

Save as

Options

Cropping

1. Select a photo or take a new photo.

2. Press <

3. Move the cropping frame to the area of the image

4. Press <

5. Press <

6. Enter a new file name, press <

Options

you want. Press <

Options

frame size.

Options Options

select OK.

> and select

> and select > and select

Crop

Resize

Done Save as

Options

> and

to change the

> and

Page 46

Adding visual features

You can decorate photos by adding a frame, an image, or a note.

1. Select a photo or take a new photo.

2. Press <

Options

> and select

Insert →

a feature

type.

3. Select an item or enter text to be inserted.

4. Adjust the position of the inserted item and press <

Done

5. Press <

6. Enter a new file name, press <

Options

> and select

Save as

Options

> and

select OK.

Merging a stamp effect

This editing tool allows you to make an outline stamp of a photo and then merge it with another photo. You can use this tool to create your own photo postcard by taking a photo of a handwritten message and merging it with a photo.

1. Select a photo or take a new photo.

2. Press <

Options

> and select

Merge stamp

. The background photo appears in the image box next to .

3. Press <

Options

> and select

Add image

4. Add a photo by selecting or taking a photo. The added photo appears in the image box next to

. This will be the stamp.

5. Press <

Options

> and select

Merge

. The stamp photo is added to the background photo as an outline.

6. Press <

Options

> to access the following stamp

edit options:

•

Resize

: change the stamp size.

•

Move

: change the position of the stamp.

•

Rotate

: rotate the stamp.

•

Stamp colour

•

Shadow on

7. When you have finished, press < select

Done

8. Press <

Options

9. Enter a new file name, press <

: change the stamp colour.

: apply a shadow to the stamp.

Options

> and select

Save as

Options

> and

select OK.

Menu functions

Applications

(Menu 3)

Page 47

Menu functions

Java world

Use this menu to access the embedded Java games and downloaded Java applications.

Accessing an embedded game

1. Select

2. Press [ ].

Using Java application options

From the application list, press < the following options:

•

Start

•

Move to

•

Delete

applications, except for the embedded games.

•

Lock/Unlock

from being deleted, or unlock the application.

•

Details

•

Permissions

charging you additional costs, such as network access and SMS.

(Menu 3.4)

My games →

: launch the selected application.

: move the application to another folder.

: delete the selected application or all

: access the application properties.

a game.

Options

: lock the application to protect it

: set permission settings for services

> to access

•

Upgrade

version.

•

Send information via text message

URL containing the application via SMS.

•

Memory status

applications.

•

Settings

applications requiring network access. You can also create or edit a profile.p. 88

World time

Use this menu to set your local time zone and find out what time it is in another part of the world.

: upgrade the application to the latest

: send the

: access memory information for

: select a connection profile to be used for

(Menu 3.5)

Viewing world time

1. From the world map, press [Left] or [Right] to scroll to the city you want. As the time line moves, the time and date of the given zone display.

2. Press [ ] to save the city as your local time zone.

Page 48

Applying daylight savings time

1. From the world map, press <

Apply daylight saving time

2. Press [ ] to select the time zones you want.

3. Press <

Alarm

Use this menu to set alarms. The alert type for a normal alarm corresponds to the call alert type settings. A wake-up alarm is not affected by your sound settings.

Save

(Menu 3.6)

Options

> and select

Setting an alarm

1. Select the type of alarm.

2. Set each alarm option:

•

Alarm

: activate the alarm.

•

Alarm time

ring.

•

AM/PM

•

Repeat

•

Alarm tone

3. Press <

Save

: enter the time for the alarm to

: set AM or PM in 12-hour format.

: select a repeat option.

: select an alarm tone.

Stopping an alarm

• For a non-wake-up alarm, press any key.

• For a wake-up alarm, press < Press any key, except <

cause it to sound again after 5 minutes. You can do this a maximum of 5 times.

Confirm

> or [ ].

> and [ ], to

Setting the alarm to sound even if the phone is off

From the Alarm screen, select

If the phone is off when it is time for the alarm to sound, the phone switches on and sounds the alarm.

Auto power → On

Deactivating an alarm

1. Select the alarm you want to deactivate.

2. Select

3. Press <

Calculator

Use this menu to perform basic arithmetic functions, such as addition, subtraction, multiplication, and division.

Off

on the Alarm line.

Save

(Menu 3.7)

Menu functions

Applications

(Menu 3)

Page 49

Menu functions

1. Enter the first number.

•Press <

•

2. Press one of the Navigation keys to access the math function you want.

3. Enter the second number.

4. Press [ ] to view the result.

5. If necessary, repeat from step 2 to continue the calculation.

Converter

Use this menu for common conversions, such as currency and temperature.

1. Select a converter.

2. Press [Left] or [Right] to select the original unit and press [Down].

3. Enter the value to be converted and press [Down].

• Press [ ] to insert a decimal point.

• Press [ ] to change the temperature to above

.()

bracket. Press

zero (+) or below zero (-).

> to insert a decimal point or

[] or []

(Menu 3.8)

to move the cursor.

4. Press [Left] or [Right] to select the unit to which you want to convert.

The equivalent value for the amount you entered displays.

For the currency converter, you can view and set currency rates by pressing <

Timer

(Menu 3.9)

Use this menu to set a period of time for the phone to count down. The phone will sound an alarm when the specified period of time has expired.

View rate

Starting the timer

1. Press <

2. Enter the length of time you want to count down

3. Press [ ] to start counting down.

Set

and press <OK>.

Stopping the timer

• Press any key when the timer rings.

• Press [ ] on the Timer screen to stop the timer before it rings.

Page 50

Stopwatch

Use this menu to measure elapsed time. The maximum time is 10 hours.

1. Press [ ] to start the stopwatch.

2. Press [ ] to check an interval. You can repeat this step for a total of 4 intervals.

Key management

Use this menu to manage the license keys you have acquired to activate media contents locked by DRM systems.

Press <

•

View

•

Delete

•

Go to My messages

containing the media content.

•

Go to My items

folder.

•

Details

(Menu 3.10)

(Menu 3.11)

Options

> to access the following options:

: open the corresponding media content.

: delete the selected licence key.

: access the message

: access the corresponding file

: access the properties of the licence key.

SIM AT

This menu is available if you use a SIM AT card that supports SIM Application Toolkit menus and provides additional services, such as news, weather, sports, entertainment, and location services. Available services may vary, depending on your service provider’s plans. For details, see your SIM card instructions or contact your service provider.

Browser

The Wireless Application Protocol (WAP) browser on your phone allows you to access the wireless web. From the wireless web, you can access up-to-date information and a wide variety of media content, such as games, wallpapers, ringtones, and music files.

To access this menu, press < select

(Menu 3.12)

(Menu 4)

Browser

> in Idle mode and

Menu functions

Browser

(Menu 4)

Page 51

Menu functions

Home

(Menu 4.1)

Use this menu to connect your phone to the network and load the homepage of the wireless web service provider. You can also press [ ] in Idle mode and select

Home

Navigating the web browser

To Press

scroll through browser items

select a browser item [ ], or <

return to the previous page

move to the next page <

[Up] or [Down].

and select

Back

and select Go →

Options

→ Forward

Options

Go to

>, or <

Options

> and select Go

Back

Using page options

From any web page, press < following options:

•

Go to

: access the linked web page.

•

Go to homepage

•

Enter URL

•Go: move backward or forward through pages in history.

•

Reload

information.

•

Bookmarks

the bookmark list.

•

Send URL

SMS or e-mail.

•

To Desktop view/To SmartFit view

display mode of the browser.

•

Save

•

Page details

•

Browser options

the browser.

: enter a URL address manually.

: reload the current page with updated

: bookmark the current page or access

: send the URL of the current page via

: save the selected image or page.

: access the page properties.

Options

: return to the homepage.

: change the various settings for

> to access the

: change the

Page 52

Cache

: change the cache mode or clear the cache. A cache is a temporary memory that stores recently accessed web pages.

: change the cookie acceptance mode or delete cookies. Cookies are pieces of personal information sent to a web server while navigating the web.

Preferences

: change the browser display and

sound settings.

Certificates About browser

: access certificate information.

: access version and copyright

information about the browser.

Exiting the browser

Press [ ] to end the network connection and exit the browser.

SFC home

(Menu 4.2)

Use this menu to access Samsung Fun Club, the preset website providing Samsung mobile phone users with attractive download services of updated ringtones and wallpapers.

You can download:

• colour images.

• polyphonic melodies.

• information and electronic catalogues for Samsung Electronics products.

SFC home

(Menu 4.2.1)

Selecting this menu loads the Samsung Fun Club homepage. You can also press [ ] in Idle mode and select

SFC home

When you access Samsung Fun Club for the first time, please launch the web browser first, then access Samsung Fun Club. This service requires WAP subscription and may be unavailable depending on your local system and services.

Menu functions

Browser

(Menu 4)

Page 53

Menu functions

Service area

Each time you move to China or HongKong, you need to change this setting to use the SFC service, according to the area where you are.

Enter URL

Use this menu to manually enter a URL address and access the associated web page.

You can add the entered URL to the Bookmark list by selecting

Bookmarks

Use this menu to save URL addresses in order to quickly access web pages.

Adding a bookmark

1. Press < saved, press <

bookmark

2. Enter a title for the bookmark and press [Down].

3. Enter a URL address and press <

(Menu 4.2.2)

(Menu 4.3)

Add bookmark

(Menu 4.4)

Add

>. If a bookmark has already been

Options

> and select

Save

Add

Accessing a bookmarked page

Selecting a bookmark item launches the web browser and accesses the associated web page.

Using bookmark options

After saving an item, press < following options:

•

Go to

: access the bookmarked web page.

•

Go to homepage

•

Enter URL

•

Edit bookmark

the bookmark.

•

Add bookmark

•

Send URL

via SMS or e-mail.

•

Delete

bookmarks.

•

Add new phrases

PTI dictionary.

•

Cancel

: enter a URL address manually.

: edit the URL address and title of

: add a new bookmark.

: send the URL address of the bookmark

: delete the selected bookmark or all

: exit the current screen.

Options

: access the homepage.

: add words or phrases to the

> to access the

Page 54

Saved pages

You can access the list of pages you have saved while online.

If you select a link on the page, the phone switches to online to access the linked page.

History

You can access the list of pages you have accessed recently.

Select a URL from the list to access the corresponding web page.

Clear cache

Use this menu to clear information stored in the cache.

Browser settings

Use this menu to select a connection profile to be used for accessing the wireless web. edit a profile.p. 88

(Menu 4.5)

(Menu 4.6)

(Menu 4.7)

(Menu 4.8)

You can also create or

Messages

Use the messages, multimedia messages, and e-mails. You can also use push message and cell broadcast message features.

To access this menu, press < select

Create message

Use this menu to create and send messages.

Text message

Short Message Service (SMS) allows you to send or receive text messages that may include simple pictures, animated images, and melodies.

1. Enter your message.

2. Press < for creating a message:

(Menu 5)

Messages

The maximum number of characters allowed in a message varies by service provider. If your message exceeds the maximum number of characters, the phone will split the message.

menu to send and receive text

(Menu 5.1.1)

Options

(Menu 5.1)

> to access the following options

> in Idle mode and

Menu functions

Messages

(Menu 5)

Page 55

Menu functions

•

Insert

: add a template, Phonebook entry, or

bookmark to text.

•

Add image/Add animation/Add melody

attach a simple image, animated image, or melody.

•

Attach

: attach a Phonebook entry as a name card or calendar data as a data format attachment.

•

Save in

: save the message in another

message box.

•

Add new phrases

phrase to the PTI dictionary.

•

Cancel

: return to the previous level.

3. When you have finished, press < select

Save and send

4. Enter a destination number. To send the message to more than one recipient,

fill in additional destination fields.

5. Press [ ] to send the message.

: add the entered word or

Options

Send only

Multimedia message

Multimedia Message Service (MMS) delivers messages containing a combination of text, image, video, and

(Menu 5.1.2)

audio, from phone to phone or from phone to e-mail.

1. Select the

Subject

line.

2. Enter the message subject and press [ ].

3. Select the

Image and video

Sound

line and

add an image, a video, or a sound file.

• The maximum size allowed for a message can differ, depending on your service provider.

• Depending on the file type or DRM (Digital Rights Management) system, some files may

> and

not be able to be forwarded.

4. Select the

Message

line.

5. Enter the message text.

6. Press <

Options

Insert

: add a template, Phonebook entry, or

> to access the following options:

bookmark.

Save in

: save the message in another folder.

Add new phrases

: add a new word to the PTI

dictionary.

Page 56

7. Enter the message text press [ ].

8. Press <

Options

•

Edit

: edit the subject or text of your message.

•

Preview

> to access the following options:

: view the message as it will be shown

on the recipient’s phone.

•

Change image/Change video/Change sound

•

: replace an added item.

Send

: send the message.

Save in

: save the message in another box.

Add page

: add pages. Move to each page by

pressing [Left] or [Right].

•

Delete page

•

Edit page

: delete an added page.

: change the duration of page display or move the page forward among the other pages.

•

Attach

: attach a Phonebook entry as a name card or calendar data as a data format attachment, or a document file stored in the

Other files

•

Remove subject/Remove message

folder.

Remove media/Remove sound/Remove

remove an added item.

9. When you have finished, press < select

Send

10. Enter a phone number or e-mail address. To send the message to more than one recipient,

Options

> and

Menu functions

fill in additional destination fields.

11. Press [ ] to send the message.

(Menu 5.1.3)

You can create and send e-mails that include text, audio, and images. To use this feature, you need to

Messages

subscribe to an e-mail service and set up your e-mail account and profile.p. 62

1. Select the

Subject

line.

(Menu 5)

2. Enter the subject of your e-mail and press [ ].

3. Select the

Message

line.

4. Enter the e-mail text.

5. Press <

Options

Insert

: add a template, Phonebook entry, or

> to access the following options:

bookmark.

Save to

: save the message in another folder.

Add new phrases

: add a new word to the PTI

dictionary.

Page 57

Menu functions

6. When you have finished, press [ ].

7. Select the following options to add files:

•

8. Press <

•

File attached

Add image/Add video/Add sound/Add music

: add media files stored in the phone’s

memory.

Depending on the file type or DRM (Digital Rights Management) system, some files may not be able to be forwarded.

Add other files

the

Other files

Attach

: attach name cards or calendar data as

data format attachments.

Options

Edit

: edit the subject or text.

Remove subject/Remove message

the subject or text.

Remove attachment

attachment.

Remove all attachments

attachments..

> to access the following options:

line and select one of the

: add document files stored in

folder.

: delete the selected

: delete all

: clear

9. When you have finished, press < select

Send

10. Enter an e-mail address. To send the e-mail to more than one recipient, fill

in additional destination fields.

11. Press [ ] to send the e-mail.

My messages

Use this menu to access messages you have received, sent, or which have failed in sending.

Inbox

(Menu 5.2.1)

This folder stores all of the messages you have received, except for e-mails.

(Menu 5.2)

Options

> and

Viewing a message

The following icons may appear on the message list to show the message type:

• SMS

• MMS

• MMS notification ( : Being retrieved,

: Failed to retrieve)

Page 58

• Voicemail

• Push message from web servers.

• Configuration message, containing network parameters from your service provider.

• CB (Cell broadcast) message from your service provider

• Delivery report for your sent messages

• Depending on the DRM (Digital Rights Management) system, messages having web content may not be able to be forwarded.

icon next to a message means that the

• A message is of high priority. A grey-coloured message icon indicates low priority.

Using message options

While viewing a message, press <

Options

> to access

the following options:

SMS messages

•

Reply via

•

Forward

•

Delete

: reply to the sender via SMS or MMS.

: forward the message to other people.

: delete the message.

•

Move to phone/Move to SIM

: move the message between the SIM card and the phone’s memory.

•

Cut address

: extract URLs, e-mail addresses, or

phone numbers from the message.

•

Attached items

: save media content from the

message to your phone’s memory.

•

Protection

: protect the message from being deleted. You can protect only those messages stored in the phone’s memory.

•

Add to block list

: add the sender’s number to the

Block list to reject the messages from the sender.

MMS messages/MMS notifications

•

Retrieve

: retrieve the MMS message from the

MMS server.

•

Reply via text message

: reply to the sender via

SMS.

•

Reply via multimedia message to

: reply to the

sender via MMS.

•

Forward

•

Delete

: forward the message to other people.

: delete the message.

Menu functions

Messages

(Menu 5)

Page 59

Menu functions

•

Cut address

phone numbers from the message.

•

Attached items

message to your phone’s memory.

•

Protection

deleted.

•

Details

Configuration messages

•

Install

message to your phone.

•

Cut address

phone numbers from the message.

•

Delete

Push messages

•

Go to URL

message.

•

Cut address

phone numbers from the message.

•

Delete

•

Protection

deleted.

: extract URLs, e-mail addresses, or

: save media content from the

: protect the message from being

: access the message properties.

: apply the configuration specified in the

: extract URLs, e-mail addresses, or

: delete the message.

: connect to the URL specified in the

: extract URLs, e-mail addresses, or

: delete the message.

: protect the message from being

CB messages

•

Save

: save the message to the phone’s memory.

•

Cut address

phone numbers from the message.

•

Delete

Delivery reports

•

Cut address

phone numbers from the report.

•

Delete

•

Protection

Drafts

(Menu 5.2.2)

This folder stores messages you have saved to send at a later time.

When you select a message, it opens in Edit mode so that you can edit and send the message.

Outbox

This folder stores messages that the phone is attempting to send or has failed to send.

The following icons are available to show the message status:

: extract URLs, e-mail addresses, or

: delete the message.

: extract URLs, e-mail addresses, or

: delete the report.

: protect the report from being deleted.

(Menu 5.2.3)

Page 60

• Being sent

• Failed to send

While viewing a message, press <

Options

> to access

the following options:

•

Send again

•

Forward

•

Cut address

: retry sending the message.

: forward the message to other people.

: extract URLs, e-mail addresses, or

phone numbers from the message.

•

Delete

: delete the message.

•

Protection

: protect the message from being

deleted.

•

Details

: access the message properties.

Sent box

(Menu 5.2.4)

This folder stores messages that you have sent.

While viewing a message, press <

Options

> to access

the following options:

•

Send

: send the MMS message.

•

Forward

•

Cut address

: forward the message to other people.

: extract URLs, e-mail addresses, or

phone numbers from the message.

•

Delete

: delete the message.

•

Protection

: protect the message from being deleted.

•

Details

: access the message properties.

Email inbox

(Menu 5.2.5)

This folder stores e-mails that you have received.

Viewing an e-mail

1. Select an e-mail account.

2. Press < press <

Yes

> when

Options

Check new mail

> and select

displays, or

Check new mail

The phone checks the e-mail server and downloads new e-mails.

The following icons may appear on the list to show the e-mail status:

• Retrieved from the server

• Being retrieved

• Failed to retrieve

A ! icon next to a message means that the message is of high priority. A grey-coloured message icon indicates low priority.

Menu functions

Messages

(Menu 5)

Page 61

Menu functions

3. Select an e-mail or a header.

4. Press [Left] or [Right] to view the previous or next e-mail.

5. Press [ ] or [ ] to view other pages in the e-mail.

Using e-mail options

While viewing the e-mail or header, press < to access the following options:

•

Retrieve

e-mail server.

•

Reply to

sender and all of the other recipients.

•

Forward

•

Delete

•

Add to block list

address or subject to the Block list to reject e-mails from that address or containing that subject.

•

Cut address

phone numbers from the e-mail.

•

Attached items

e-mail to your phone’s memory.

: retrieve the body of the e-mail from the

: send a reply to the sender or to the

: forward the e-mail to other people.

: delete the e-mail.

: add the sender’s e-mail

: extract URLs, e-mail addresses, or

: save the attached files from the

Options

•

Protection

•

Details

My folders

Use this menu to create new folders and organise your messages.

Creating a new folder

1. Press <

2. Enter a folder name, press <

Using folder options

On the folder list, press < following options:

•

Open

•

Create folder

•

Rename folder

•

Delete

Templates

Use this menu to make and use templates of frequently used messages.

: protect the e-mail from being deleted.

: access the e-mail properties.

(Menu 5.2.6)

Yes

Options

: open the selected folder.

: add a new folder.

: change the folder name.

: delete the selected folder.

(Menu 5.3)

> to access the

> and select

Page 62

Text message templates

You can create SMS templates with the sentences you use frequently so that you can retrieve and insert them when composing an SMS message.

Creating a template

1. Select an empty location.

2. Enter a message, press <

Using template options

From the template list, press < the following options:

•

Edit

: edit the selected template.

•

Send message

•

Delete

•

Add new

: delete the selected template.

: create and send a new message.

: add a new template.

Multimedia message templates

You can access embedded MMS templates or ones you have saved so that you can use them in composing an MMS message.

From the template list, press < the following options:

(Menu 5.3.1)

Options

> and select OK.

Options

(Menu 5.3.2)

Options

> to access

•

View

: open the selected template.

•

Edit

: edit the template.

•

Send message

•

Delete

: delete the selected template or all

templates, except for the embedded ones.

Delete all

Use this menu to delete messages in each message folder all at once.

1. Press [ ] to select the message folders to be cleared.

Pressing the key twice displays the message types so that you can specify the ones to be cleared.

2. Press <

3. Press [ ] to select the check box to delete protected messages, and then press <

4. Press <

Settings

Use this menu to set up various options for using the messaging service.

: create and send a new message.

(Menu 5.4)

Delete

Yes

> to confirm the deletion.

(Menu 5.5)

Yes

Menu functions

Messages

(Menu 5)

Page 63

Menu functions

Text message

You can configure SMS settings.

•

Sending options

SMS messages:

Send read receipt

along with your message.

Send delivery receipt

you when your messages have been delivered.

Bearer selection prefer

•

Block list

you want to reject messages.

•

Current profile

•

Profile settings

profile.

Service centre

your SMS server.

Default destination

destination. It will be displayed on the first field on the Recipients field.

(Menu 5.5.1)

: set up the options for sending

: send a read-reply request

: set the network to inform

, depending on your network.

: select either

: store the phone numbers from which

: select an SMS setting profile.

: set the properties of each

: store or change the number of

: enter the default

GSM

GPRS

Default type

network can convert the messages into the selected format.

Validity period

messages are stored in the SMS server.

Setting name

Multimedia messages

You can configure MMS settings.

•

Sending options

MMS messages:

Send delivery receipt

you when your messages have been delivered.

Hide address

the recipient’s phone.

Send read receipt

along with your messages.

Priority Expiry date

stored in the MMS server.

Delivery time

are sent.

: set the default message type. The

: set the length of time your

: enter a profile name.

(Menu 5.5.2)

: set up the options for sending

: set the network to inform

: set your address to be hidden from

: send a read-reply request

: set the priority level of messages.

: set the length of time messages are

: set a time delay before messages

Page 64

Outgoing message size

: select a maximum size

of attached items allowed for messages.

•

Receiving options

: set up the options for

receiving MMS messages:

Reject unknown sender

: reject messages from

unknown senders.

Advert allowed Information allowed

: accept advertisements.

: accept information

messages.

Report allowed

: set the network to inform the

sender when a message has been delivered to you.

Home reception

: determine if your phone retrieves new messages automatically when you are in your home service area.

Roaming reception

: determine if your phone retrieves new messages automatically when you are roaming on another network.

Reception within home network or abroad has the following options:

Automatic

: the phone automatically retrieves

messages from the server.

Reject

: the phone rejects all messages.

Manual

: the phone displays notifications. Use

the

Retrieve

option to manually download new

messages.

•

Multimedia message profiles

: select a connection profile to be used for MMS. You can also create or edit a profile.p. 88

Emails

(Menu 5.5.3)

You can configure default e-mail settings.

You cannot change e-mail profile and account settings while an e-mail is being sent or retrieved.

•

Sending options

: set up the options for sending

e-mails:

Keep a copy

: send a copy of your e-mails to your

e-mail account.

Send delivery receipt

: set the network to inform

you when your e-mails have been delivered.

Send read receipt

: send a read-reply request

along with e-mails.

Reply-To address

: set an e-mail address to

receive read-reply messages from recipients.

Priority

: select the priority level of e-mails.

Menu functions

Messages

(Menu 5)

Page 65

Menu functions

Add signature

a simple memo, or a tag line to your e-mails.

Edit name Edit telephone number

in your signature.

Edit note

•

Receiving options

receiving e-mails:

Check interval

checks the server for incoming e-mails. If you select

Do not notify

option to receive new e-mails manually.

Send read receipt

phone sends a read-reply for incoming e-mails. If you select a read-reply.

Download limit

incoming e-mails. Your phone will reject e-mails that exceed the specified size.

Download method

downloads e-mail headers only or e-mail headers

and bodies both.

: attach your name, phone number,

: edit the name in your signature.

: edit the phone number

: edit the tag line in your signature.

: set up the options for

: determine how often the phone

, use the

: determine whether or not the

Announce

, the phone asks you to send

: determine the maximum size for

: set whether the phone

Check new email

Keep in server

mail server after retrieving.

•

Block list

you want to reject.

•

Email accounts

select an account to be used.

Current account Account settings

using different e-mail servers. Set the options for each account:

Account name

selected account.

User name

Email address

SMTP server

of the outgoing e-mail server.

SMTP port

Connect to POP3 server first

POP3 server before connecting to the SMTP server to send e-mails.

: leave copies of e-mails on the e-

: specify e-mail addresses or subjects

: set up an e-mail account and

: select an account.

: configure e-mail accounts

: enter a name for the currently

: enter a user name.

: enter your e-mail address.

: enter the IP address or host name

: enter the SMTP port number.

: connect to the

Page 66

Protocol type

: select the protocol for the incoming e-mail server. The remaining options depend on the protocol type setting.

When the protocol type is

POP3 server:

enter the IP address or host name

POP3

of the server that receives your e-mail.

POP3 port

User ID

Password

User SMTP authentication

: enter the POP3 port number.

: enter the POP3 user name.

: enter the POP3 password.

: enable SMTP authentication, which requires the user to login before sending e-mails.

Same as POP3

: select if you want the SMTP server to have the same parameters as the POP3 server.

SMTP user ID

SMTP password

APOP login

: enter the SMTP user name.

: enter the SMTP password.

: connect to the server by using the

APOP login scheme.

Secure connection

: use a secure connection for

the e-mail service.

When the protocol type is

IMAP4 server

: enter the IP address or host

IMAP4

name of the server that receives your e-mail.

IMAP4 port

User ID

Password

User SMTP authentication

: enter the IMAP4 port number.

: enter the IMAP4 user name.

: enter the IMAP4 password.

: enable SMTP authentication, which requires the user to login before sending e-mails.

Same as IMAP4

: select if you want the SMTP server to have the same parameters as the IMAP4 server.

SMTP user ID

SMTP password

Include attachments

: enter the SMTP user name.

: enter the SMTP password.

: select this option to

receive attachments with e-mails.

Email retrieval limit

: set the number of

headers you will retrieve from the server.

Secure connection

: use a secured connection

for e-mail service.

Menu functions

Messages

(Menu 5)

Page 67

Menu functions

•

Email profile

used for e-mail services. You can also create or edit a profile.p. 88

Push messages

You can change the settings for receiving push messages from the wireless web server.

•

Receive

messages. If you select not accept messages from the specified addresses on the Black list.

•

Block list

Broadcast messages

You can change the settings for receiving CB messages.

•

Receive

•

Channel list

you wish to receive CB messages. Please contact your service provider for further details.

•

Language

which CB messages display.

: select a connection profile to be

(Menu 5.5.4)

: set how your phone receives push

: manage blocked server addresses.

: select to receive CB messages, or not.

: indicate the channels from which

: select the preferred languages in

Block list

(Menu 5.5.5)

, the phone will

Memory status

Use this menu to view the amount of memory currently in use in each folder.

File manager

The

File manager

videos, music files, and sound files stored in the phone’s memory.

To access this menu, press < select

File manager

Tips for Digital Rights Management

As a result of the Digital Rights Management (DRM) system, some of the media items you download from the Internet or receive by MMS may require a license key to access them.

You can acquire the key from the website which owns the rights to the content; use the option.

Note the following icons on the list:

• : Forwardable item with a valid key.

(Menu 5.6)

(Menu 6)

menu allows you to access images,

> in Idle mode and

Activate key

Page 68

• : Forwardable item without a valid key.

• : Unforwardable item with a valid key.

• : Unforwardable item without a valid key.

Images

This menu displays photos you have taken and images you have downloaded, received in messages, or imported from your computer.

(Menu 6.1)

Viewing an image

1. Select an image folder.

2. Select an image.

Viewing a slide show

You can view your photos as a slide show, a sequential presentation of each photo in the current folder.

1. Select

2. Press <

3. Select an interval option. The slide show begins.

4. Press <

My photos

Options

Stop

> and select

> to stop the slide show.

Slide show

Using image options

While viewing an image, press < the following options:

•

List

: return to the image list.

•

Send via

Bluetooth.

•

Set as

or as a caller ID image for a Phonebook entry.

•

Edit

a photo taken by the camera on the phone.



•

Activate key

the selected DRM file expires.

•

Delete

•

Rename

•

Move to Favourite images/Move to My photos/Move to Downloaded images

the file to another folder.

•

Bluetooth visibility

other Bluetooth devices.

•

Protection

: send the file via MMS, e-mail, or

: set the image as wallpaper for the display

: edit the image using the Image editor if it is

p. 42

: get a license key when the key for

: delete the file.

: change the file name.

: protect the file from being deleted.

Options

: share the file or all files with

> to access

Menu functions

File manager

(Menu 6)

: move

Page 69

Menu functions

•

Details

: access the file properties.

•

Key management

have acquired.

Videos

This menu displays video clips you have recorded, downloaded, received in messages, or imported from your computer.

(Menu 6.2)

Video clips recorded on other devices, such as camcorders, may not play correctly.

Playing a video clip

1. Select a video folder.

2. Select a video clip.

During playback, use the following keys:

Key Function

Pauses or resumes playback.

Left Moves backward in a file when held

Right Skips forward in a file when held down.

down. Moves back to the previous file.

Skips to the next file.

: manage the license keys you

Key Function

/ Adjusts the volume.

Down Stops playback.

Using video options

After playback, press < following options:

•

List

: return to the video list.

•

Send via

Bluetooth.

•

Set as main display

as a 3GP file, as wallpaper for the display.

•

Activate key

the selected DRM file expires.

•

Delete

•

Rename

•

Move to Favourite videos/Move to My video clips/Move to Downloaded videos

file to another folder.

•

Bluetooth visibility

other Bluetooth devices.

: send the file via MMS, e-mail, or

: delete the file.

: change the file name.

Options

: get a license key when the key for

> to access the

: set the video clip, if saved

: move the

: share the file or all files with

Page 70

•

Protection

•

Details

•

Key management

: protect the file from being deleted.

: access the file properties.

: manage the license keys you

have acquired.

Music

(Menu 6.3)

This menu displays MP3 files you have downloaded or imported from your computer.

Select a file. The MP3 player opens.p. 39

When you play a file from this menu, without first adding it to the play list in the MP3 player, background play is not supported.

Sounds

(Menu 6.4)

This menu displays voice memos you have recorded, and sound files you have downloaded, received in messages, or imported from your computer.

Playing a sound clip

1. Select a sound folder.

2. Select a sound clip. For a voice memo, see

recorder

. p. 41

Voice

Using sound options

While playing a sound file, press <

Options

> to access

the following options:

•

List

: return to the sound list.

•

Send via

: send the file via MMS, e-mail, or

Bluetooth.

•

Set as

: set the sound as your call ringtone or a

ringtone for a Phonebook entry.

•

Activate key

: get a license key when the key for

the selected DRM file expires.

•

Delete

: delete the file.

•

Rename

•

Move to Favourite sounds/Move to My voice clips/Move to Downloaded sounds

: change the file name.

: move the

file to another folder.

•

Bluetooth visibility

: share the file or all files with

other Bluetooth devices.

•

Protection

•

Details

•

Key management

: protect the file from being deleted.

: access the file properties.

: manage the license keys you

have acquired.

Menu functions

File manager

(Menu 6)

Page 71

Menu functions

Other files

Use this menu to view various document files and files stored in the phone’s memory without corruption. Available file formats are DOC, XLS, PPT, PDF, and TXT.

Viewing a file

Select a file. Picsel File Viewer runs to open the document.

• Depending on the file size or memory capacity of Picsel File Viewer, a file may not open properly.

• If a document file contains languages unsupported by Picsel File Viewer, the content of the document will not display correctly.

Use the following keys to view the document:

Key Function

Up/Down/ Left/Right

/1 Zooms in.

/3 Zooms in out.

(Menu 6.5)

Pans around the page.

Fits the document to the page size.

Key Function

Returns to the first page.

Returns to the previous page.

Rotates the document.

Moves to the next page.

Moves to the last page.

Changes the display to Full screen view or Normal screen view.

Using document options

While viewing a document, press <

Options

access the following options:

•

Full screen view/Normal view

: change the

display to Full screen view or Normal view.

•

Zoom

: zoom in or out.

•

Fit to

: fit the document to the page size, screen

width, or screen height.

•

Go to

: move to another page of the document.

•

Rotate

: rotate the document.

> to

Page 72

•

Screen panning/Normal panning

panning mode to by screen or by preset pixel.

•

Hide controller/Show controller

the shortcut tool bar in Full screen view.

•

Send via

Bluetooth.

•

Delete

•

Rename

•

Bluetooth visibility

other Bluetooth devices.

•

Protection

•

Details

•

Shortcuts

use in Picsel File Viewer.

Memory status

Use this menu to view memory information for media items in the phone’s memory. For the phone’s memory, press [Left] or [Right] to view the memory status by size or number of items.

: send the file via MMS, e-mail, or

: delete the selected file.

: change the file name.

: share the file or all files with

: protect the file from being deleted.

: access the file properties.

: view the functions of the keys you can

(Menu 6.6)

: change the

: hide or display

Calendar

The

Calendar

schedule.

To access this menu, press < select

(Menu 7)

menu enables you to keep track of your

Calendar

> in Idle mode and

Consulting the calendar

When you enter the Month view appears with today’s date indicated by a blue box.

Calendar

menu, the calendar in

Selecting a day

• Press [Left] or [Right] to move by day.

• Press [Up] or [Down] to move by week.

• Press [ / ] to move by month.

Using calendar options

Press <

•

Options

View by



p. 72

Create Go to

> to access the following options:

: change the view mode of the calendar.

: add a new item.next section

: select today’s date or enter a specific date.

Menu functions

Calendar

(Menu 7)

Page 73

Menu functions

•

Event list

•

Delete

using various deleting options.

•

Missed alarm events

you have missed.

•

Memory status

the items stored on the calendar.

: sort items by type of item.

: delete the items stored on the calendar by

You can delete recurring events in Day view only.

: view items whose alarms

: access memory information for

Creating an item

You can store appointments, anniversaries, memos, and tasks on the calendar. More than one item per day can be stored.

Entering a new appointment

1. Select a date on the calendar.

2. Press <

3. Enter information or change the settings:

Options

Appointment

•

Subject Details

: enter a title for the appointment.

: enter appointment details.

> and select

Create →

•

Start date

date and time for the appointment.

•

AM/PM

format.

•

End date

and time for the appointment.

•

AM/PM

format.

•

Location

of the appointment.

•

Alarm

•

Before

the alarm is to alert you.

•

Alarm tone

•

Repeat

select a repeat unit.

•

Until

will recur.

4. Press <

and

Start time

: select AM or PM in 12-hour time

and

End time

: select AM or PM in 12-hour time

: enter information about the location

: set an alarm for the appointment.

: set how long before the appointment

: select an alarm tone.

: set the appointment to recur and

: set the ending date, if the appointment

Save

> to save the appointment.

: enter the starting

: enter the ending date

Page 74

Entering a new anniversary

1. Select a date on the calendar.

2. Press <

3. Enter information or change the settings:

4. Press <

Options

Anniversary

•

Occasion

anniversary.

•

Date

•

Alarm

anniversary.

•

Before

the alarm is to alert you.

•

Alarm time

ring.

•

AM/PM

format.

•

Alarm tone

•

Repeat every year

you of the anniversary every year.

Save

> and select

: enter information about the

: enter the date.

: select to set an alarm for the

: set how long before the anniversary

: enter the time for the alarm to

: select AM or PM in 12-hour time

: select an alarm tone.

: set the phone to remind

> to save the anniversary.

Create →

Entering a memo

1. Select a date on the calendar.

2. Press <

3. Enter a memo, press <

Options

> and select

Options

Create → Memo

> and select

Save

Entering a task

1. Select a date on the calendar.

2. Press <

3. Enter information or change the settings:

4. Press <

Options

•

Task

: enter information about the task.

•

Start date

•

Due date

•

Select priority

Save

> and select

: enter the starting date.

: enter the ending date.

: select a priority level.

> to save the task.

Create → Task

Viewing an item

Once you have scheduled things, the item icons and the number of items for a specific day appears at the bottom of the calendar.

• Appointment • Anniversary

• Task • Memo

• Festival

Menu functions

Calendar

(Menu 7)

Page 75

Menu functions

Accessing an item

1. Select a date on the calendar to display the items for the day.

2. Select an time to view its details.

3. Press [Left] or [Right] to access the other items scheduled for the selected day.

Using options

While viewing an time, press < the following options:

•

Edit

: edit the item.

•

Create

: add a new item.

•

Send via

Bluetooth.

•

View by

•

Delete

•

Memory status

the items stored on the calendar.

: send the item via SMS, MMS, e-mail, or

: change the view mode of the calendar.

: delete the item.

: access memory information for

Options

> to access

Viewing an item in a different mode

You can change the calendar display to Day view or Week view. Press < view mode.

Options

> and select

View by →

Day view

You can view items for the selected date. Select an item to view its details.

The following icons may display to indicate the item status:

• Alarm set

• Recurring time

• Task priority (Red: high, Blue: normal, Grey: low)

• Completed task

Week view

You can view items for the selected week. A cell on the timetable indicates the presence of a schedule item. Select a cell in the day you want.

Page 76

Camera

(Menu 8)

You can use the camera module embedded in your phone to take photos and record videos.

To access this menu, press < select

Camera

, or press and hold [].

• Do not take photos of people without their permission.

• Do not take photos in a place where cameras are not allowed.

• Do not take photos in a place where you may interfere with another person’s privacy.

> in Idle mode and

Taking a photo

You can take photos in various modes. The camera produces JPEG photos.

When you take a photo in direct sunlight or in bright conditions, shadows may appear on the photo.

1. Access the turn on the camera.

2. Make any desired adjustments.

• Press < > to access camera options.



next section

Camera

menu or press and hold [] to

• Use the keypad to change the camera settings or switch to other modes.p. 74

3. Press [ ] or [] to take a photo. The photo is saved in the

To Press

access photo options <

delete the photo [C] and then <

return to Capture mode <

My photos

folder.

Options>.

Preview

p. 75

Yes

Using camera options in Capture mode

In Capture mode, press < > to access the following options:

•

Record video

•

Shooting mode

: switch to Record mode.

: take a photo in the following

modes:

Single shot

: take a photo in Normal mode. You can select whether or not the camera automatically saves a photo.

Multi shot

: take a series of action stills. You can select the number of photos the camera will take and the shooting speed.

Menu functions

Camera

(Menu 8)

Page 77

Menu functions

Mosaic shot

one frame. You can select the layout.

•

Effects

effect.

•

Frames

•

Flash

•

Timer

photo.

•

Go to My photos

•

Settings

photo.

Size

: select an image size.

Quality Viewfinder Shutter sound

when you press the shutter release, [].

Zoom sound

on or off.

Brightness sound

brightness adjustment on or off.

: take several stills and save them in

: change the colour tone or apply a special

: apply a decorative frame.

: determine the use of the flash.

: set a time delay before the camera takes a

: access the

: change the default settings for taking a

: select an image quality setting.

: select a preview screen.

: select the sound that you hear

: turn the sound effect for zooming

: turn the sound effect for

My photos

folder.

White balance

image. You can make your photo appear warmer or cooler.

ISO

: change the ISO setting, which controls the sensitivity of your camera. For low light situations, select a higher ISO number. The higher the ISO number, the faster the camera shutter functions and the more sensitive the camera is to light. Higher ISO settings may bring some distortion to an image.

•

Camera shortcuts

you can use in Capture mode.

: adjust the colour balance of the

: view the functions of the keys

Using the keypad in Capture mode

You can use the keypad to customise your camera settings in Capture mode.

Key Function

Left/Right Adjusts the brightness.

Up/Down Zooms in or out.

Flips the image vertically.

Shows the mirror image.

Page 78

Key Function

Switches to Record mode.p. 75

Changes the image size.

Changes the image quality.

Changes the shooting mode.

Changes the colour tone or applies a special effect.

Changes the ISO setting.

Selects a decorative frame.

Sets the timer.

Goes to the

Changes the preview screen.

Determines the use of the flash.

Changes the white balance.

My photos

folder.

Using photo options

After saving a photo, press < following options:

•

View

: access one of the multi-shot photos.

•

Viewfinder

•

Send via

Bluetooth.

•

Set as

or as a caller ID image for a Phonebook entry.

•

Edit



p. 42

•

Delete

•

Rename

•

Go to My photos



p. 65

•

Protection

•

Details

: return to Capture mode.

: send the file via MMS, e-mail, or

: set the photo as wallpaper for the display

: edit the photo using the Image editor.

: delete the file.

: change the file name.

: protect the file from being deleted.

: access the file properties.

Options

: access the

> to access the

My photos

folder.

Recording a video

You can record a video of what is displayed on the camera screen and save it.

1. In Capture mode, press [1].

Menu functions

Camera

(Menu 8)

Page 79

Menu functions

2. Make any desired adjustments.

• Press < > to access camera options.



next section

• Use the keypad to change the camera settings or switch to other modes.p. 77

3. Press [ ] or [] to start recording.

4. Press [] or < > to stop recording. The video is automatically saved in the

To Press

play back the video clip [ ].

access video options <

delete the video clip [C] and then <

return to Record mode <

Using camera options in Record mode

In Record mode, press < > to access the following options:

•

Take photo Effects

effect.

: switch to Capture mode.

: change the colour tone or apply a special

My video clips

Options

>.p. 77

Preview

folder.

Yes

•

Flash

•

: determine the use of the flash.

Timer

: set a time delay before the camera starts

recording.

Go to My video clips

folder.

Settings

recording a video:

Recording mode

Select

Wallpaper

messaging or for setting as wallpaper. The video clip is saved in 3GP format.

Select the currently available memory. The video clip is saved in MP4 format.

Size Quality Viewfinder Record audio Zoom sound

on or off.

: change the following settings for

Limit for multimedia messages/

to record a video suitable for

Normal

: select a frame size.

: select an image quality.

: select a preview screen.

: turn the sound effect for zooming

: access the

: select a video recording mode.

to record a video within the limit of

: record audio with a video clip.

My video clips

Page 80

Brightness sound

: turn the sound effect for

brightness adjustment on or off.

White balance

: adjust the colour balance of the image. You can make your video appear warmer or cooler.

•

Camcorder shortcuts

: view the functions of the

keys you can use in Record mode.

Using the keypad in Record mode

You can use the keypad to customise your camera settings in Record mode:

Key Function

Left/Right Adjusts the brightness.

Up/Down Zooms in or out.

Flips the image vertically.

Shows the mirror image.

Switches to Capture mode.p. 73

Changes the frame size.

Changes the image quality.

Key Function

Changes the video recording mode.

Changes the colour tone or applies a special effect.

Mutes or unmutes audio.

Sets the timer.

Goes to the

My video clips

Changes the preview screen.

Determines the use of the flash.

Changes the white balance.

Using video options

After saving a video clip, press <

Options

the following options:

•

Viewfinder

•

Send via

: return to Record mode.

: send the file via MMS, e-mail, or

Bluetooth.

•

Set as main display

: set the video clip, if saved

as a 3GP file, as wallpaper for the display.

folder.

> to access

Menu functions

Camera

(Menu 8)

Page 81

Menu functions

•

Delete

•

Settings

The options to customise the phone to your preferences and needs. You can also reset the settings to their default status.

To access this menu, press < select

Time and date

Use this menu to change the time and date displayed on your phone. Before setting the time and date, specify your time zone in the



: delete the file.

Rename Go to My video clips

folder.



Protection Details

p. 44

: change the file name.

p. 66

: protect the file from being deleted.

: access the file properties.

(Menu 9)

Settings

menu provides you with various setting

Settings

(Menu 9.1)

: access the

> in Idle mode and

World time

My video clips

menu.

•

Set time

•

AM/PM

•

Time format

•

Set date

•

Date format

•

Calendar starting day

week the calendar starts with.

Phone settings

Many different features of your phone’s system can be customised to suit your preferences.

Language

Use this menu to select one of several languages for the display text.

Greeting message

Use this menu to enter the greeting that is displayed briefly when the phone is switched on.

: enter the current time.

: select AM or PM in 12-hour time format.

: select a time format.

: enter the current date.

: select the date format.

: set which day of the

(Menu 9.2)

(Menu 9.2.1)

(Menu 9.2.2)

Page 82

Slide settings

(Menu 9.2.3)

Use this menu to set how the phone reacts when you open it for an incoming call, and when you close it while using a function.

•Up: set whether or not to answer a call by opening the phone.

•

Down

: set whether or not the phone maintains

the menu you are using when you close the phone.

When you set keypad lock works only in Idle mode.

Shortcut

Down

(Menu 9.2.4)

Continue operation

, the

You can use the Navigation keys as shortcuts to access specific menus directly from Idle mode. Use this menu to assign a shortcut to a key.

Assigning a shortcut menu

1. Select a key to be used as a shortcut key.

2. Select the menu to be assigned to the key.

Using shortcut options

Press <

•

Options

Change

> to access the following options:

: assign or change a shortcut menu.

•

Remove

: deactivate the shortcut assignment to

the selected key.

•

Remove all

Volume key

: deactivate all shortcut assignments.

(Menu 9.2.5)

Use this menu to set whether the phone mutes the call ringer or rejects a call if you press and hold [ / ] when a call comes in.

Extra settings

(Menu 9.2.6)

You can turn the automatic redialling or answering feature on or off.

•

Auto redial

: set the phone to make up to ten attempts to redial a phone number after an unsuccessful call.

•

Anykey answer

pressing any key, except [ ] and <

Display settings

: answer an incoming call by

Reject

(Menu 9.3)

Use this menu to change settings for the display.

Wallpaper

(Menu 9.3.1)

You can set up the idle screen on the display.

Menu functions

Settings

(Menu 9)

Page 83

Menu functions

•

Main display

displayed on the display.

•

Text position

want to display text in Idle mode, select

•

Text mode

•

Text colour

•

Graphic logo

icon instead of the service provider’s logo on the idle screen. This is only available if a graphic icon has been received in a message.

Main menu style

You can select a display style for the main menu screen.

Skin

(Menu 9.3.3)

You can select a skin colour pattern for Menu mode.

Brightness

You can adjust the brightness of the display for varying lighting conditions.

: select an image or video clip to be

: select a text position. If you don’t

: select a font style.

: select a font colour.

: set the phone to display a graphic

(Menu 9.3.2)

(Menu 9.3.4)

Off

Dialling display

Use this menu to select a font colour for the numbers

entered while dialling.

Show caller information

Use this menu to set the phone to display missed call notifications with the most recently missed caller’s information.

Sound settings

Use this menu to customise various sound settings.

Incoming call

Use this menu to change the sound settings for incoming calls.

•

Ringtone

ringer.

•

Volume

•

Alert type

incoming calls.

(Menu 9.3.5)

(Menu 9.4)

(Menu 9.4.1)

: select a ringtone to be used for the call

: select a ringtone volume.

: specify how you are to be informed of

(Menu 9.3.6)

Page 84

Keypad tone

(Menu 9.4.2)

Use this menu to select the tone that the phone sounds when you press a key.

• Sound effects by your Flash Dial Font setting will override this key tone setting.

• You can adjust the keypad tone volume using [ / ] in Idle mode.

Message tone

(Menu 9.4.3)

Use this menu to change the sound settings for incoming SMS messages, MMS messages, e-mails, and CB messages individually.

•

Tone

: select one of several message tones.

•

Alert type

: specify how you are to be informed

when a message comes in.

•

Repetition

: specify how often the phone informs

you of a new message.

Power on/off

(Menu 9.4.4)

Use this menu to select the melody that the phone sounds when it is switched on or off.

Slide tone

(Menu 9.4.5)

Use this menu to select the tone that the phone sounds when you open or close the phone.

Ontime alarm

(Menu 9.4.6)

Use this menu to set the phone to sound an alert every hour on the hour.

Quiet mode

(Menu 9.4.7)

Use this menu to set how the phone acts to alert you to a specific event while in Quiet mode.

Extra tones

(Menu 9.4.8)

Use this menu to customise additional tones for the phone.

•

Minute minder

: set the phone to beep every minute during an outgoing call to keep you informed of the length of your call.

•

Connection tone

: set the phone to beep when an

outgoing call connects to the system.

•

Alerts on call

: set the phone to beep when you receive a new message or when the time for an alarm comes during a call.

Menu functions

Settings

(Menu 9)

Page 85

Menu functions

•

Indicative tone

pop-up window displays.

Light settings

Use this menu to change settings for the backlight.

Backlight time

You can select the length of time the backlight or display stays on.

•

Main display normal

the backlight stays on.

•

Main display dim

display stays on in Dim mode after the backlight turns off. After a specified time, the display turns off.

Keypad light

You can set how the phone controls the use of the keypad light.

•

Any time

•

Night time

5:00 PM and 9:00 AM.

: set the phone to beep when a

(Menu 9.5)

(Menu 9.5.1)

: select the length of time

: select the length of time the

(Menu 9.5.2)

: the keypad light is always used.

: the keypad light is used only between

•

Custom time

keypad light is used.

External light

Use this menu to activate or deactivate the use of the service light on the front of the phone. The service light blinks at regular intervals when your network is available.

Network services

Use this menu to access network services. Please contact your service provider to check their availability and subscribe to them, if you wish.

Call diverting

This network service reroutes incoming calls to a phone number that you specify.

1. Select a call diverting option:

•

Divert always

•

Busy

call.

•No

the phone.

: specify the time period that the

(Menu 9.5.3)

(Menu 9.6)

(Menu 9.6.1)

: divert calls when you are on another

: divert all calls.

: divert calls when you do not answer

Page 86

•

Unreachable

: divert calls when you are not in an area covered by your service provider or when your phone is switched off.

•

Cancel all

: cancel all call diverting options.

2. Select the type of calls to be diverted.

3. Select

4. Move to the

Activate

Deactivate

. To deactivate call diverting, select

Divert to

line.

5. Enter the number to which calls are to be diverted.

6. If you selected

No reply

, move to the

Seconds

line and select the length of time the network delays before diverting a call.

7. Press <

Call barring

Select

(Menu 9.6.2)

This network service allows you to restrict your calls.

1. Select a call barring option:

•

All outgoing calls

•

International

•

International except home

: prohibit all outgoing calls.

: prohibit international calls.

: only allow calls to numbers within the current country when you are abroad, and to your home country.

•

All incoming calls

•

Incoming while abroad

: prohibit incoming calls.

: prohibit incoming calls when you use your phone outside of your home country.

•

Cancel all

: cancel all call barring settings,

allowing calls to be sent and received normally.

•

Change barring password

: change the call barring password obtained from your service provider.

2. Select the type of calls to be barred.

3. Select

Activate

Deactivate

. To deactivate call barring, select

4. Enter the call barring password supplied by your service provider and press <

Call waiting

(Menu 9.6.3)

Select

This network service informs you when someone is trying to reach you while you are on another call.

1. Select the type of calls to which call waiting option will apply.

2. Select

Activate

Deactivate

. To deactivate call waiting, select

Menu functions

Settings

(Menu 9)

Page 87

Menu functions

Network selection

This network service allows you to either automatically or manually select the network to be used while roaming outside of your home area. You can select a network other than your home network only if there is a valid roaming agreement between the two.

Caller ID

(Menu 9.6.5)

This network service allows you to prevent your phone number from being displayed on the phone of the person being called. If you select will use the default setting provided by the network.

Some networks may not allow you to change this setting.

Voice mail server

Use this menu to store the number of the voicemail server and access your voicemails.

You must store the voicemail server number before accessing the server. Your service provider can give you the number.

•

Connect to voice server

voicemail server to listen to your messages.

(Menu 9.6.4)

(Menu 9.6.6)

: connect to the

Default

, the phone

•

Voice server number

: enter the voicemail server

number.

Closed user group

(Menu 9.6.7)

Use this menu to set incoming and outgoing calls to be restricted to a selected user group. For details about how to create a closed user group (CUG), contact your service provider.

•

Index list

: add, delete, or activate CUG index

numbers.

•

Outside access

: enable calls to numbers other than those in the closed user group. This feature depends on the nature of your CUG subscription.

•

Default group

: enable the default CUG, if you have set one with your service provider. When making a call, you are given the option of using your default CUG, instead of selecting one from the list.

Band selection

(Menu 9.6.8)

For the phone to make and receive phone calls, it must register with an available network. Your phone can handle any of the following types of networks: GSM 1900 and Combined GSM 900/1800.

Page 88

The country where you purchased your phone determines the default band that it uses. When you travel abroad, you may need to change to an appropriate band.

Bluetooth

(Menu 9.7)

Using the Bluetooth feature, you can connect the phone wirelessly to other Bluetooth devices and exchange data with them, talk hands-free, or control the phone remotely.

Bluetooth technology allows free wireless connections between all Bluetooth-compliant devices within a range of 10 meters. Since the devices communicate using radio waves, they do not need to be in line of sight to each other.

• If there are obstacles between the devices, the operating distance may be reduced.

• It is recommended that you don’t use the

Bluetooth feature while using multimedia features, such as voice recorder, camera, and MP3 player, or vice versa, for better performance.

• Some devices may not be compatible with your

phone.

Setting up the Bluetooth feature

The

Bluetooth

•

Activation

menu provides the following options:

: activate or deactivate the Bluetooth

feature.

•

My devices

: search for connectable Bluetooth

devices.

•

My phone’s visibility

: allow other Bluetooth

devices to search for your phone.

•

My phone’s name

: assign a Bluetooth device name to your phone, which is then displayed on other devices.

•

Secure mode

: determine if the phone asks for your confirmation when other devices access your data.

•

Bluetooth services

: display available Bluetooth

services.

Searching for and pairing with a Bluetooth device

1. From the Bluetooth setting options, select

devices

2. Select

Search for new devices

Menu functions

Settings

(Menu 9)

Page 89

Menu functions

After searching, a list of devices to which you can connect displays. The following icons indicate the type of device:

• Stereo headset • Printer

• Computer • PDA

• Mobile phone • Unknown device

• Mono headset/ Hands-free car kit

The colour of the icon indicates the status of the the device:

• Grey for unpaired devices

• Blue for paired devices

• Red for devices that are currently connected to your phone

3. Select a device.

4. Enter a Bluetooth PIN and press <OK>. This code is used just once and you don’t need to memorise it.

When the owner of the other device enters the same code, pairing is complete.

Some devices, especially headsets or hands-free car kits, may have a fixed Bluetooth PIN, such as If the other device has a code, you must enter it.

Using device options

From the device list, press <

Options

> to access the

following options:

•

Connect

: connect to a headset or hands-free car

kit.

•

Disconnect

: end the connection with the

connected device.

•

Browse files

: search for data from the device and

import data directly to your phone.

•

Service list

: access the Bluetooth service list of

the device.

•

Rename

•

Authorise device/Unauthorised device

: rename the paired device.

determine whether or not the phone asks you to permit connection when other devices try to connect to your phone.

0000

Page 90

•

Delete

: remove the selected device or all devices

from the list.

Sending data via Bluetooth

1. Activate the Bluetooth feature.

2. Select the application in which the item you want to send is stored.

3. Scroll to the item you want and press <

4. Select

5. Select a device.

6. If necessary, enter the Bluetooth PIN needed for

Send via → Bluetooth

The phone searches for devices within range and displays a list of available devices.

pairing and press <OK>.

Options

Receiving data via Bluetooth

To receive data via Bluetooth, your phone’s Bluetooth feature must be active.

1. If an unauthorised Bluetooth device sends data to your phone, press < access your phone.

2. Press <

Yes

> to receive data.

Yes

> to allow the device to

Security

Use this menu to protect the phone against unauthorised use by managing the several access codes of your phone and SIM card.

PIN check

The 4- to 8-digit PIN (Personal Identification Number) protects your SIM card against unauthorised use. When this feature is enabled, the phone requires your PIN each time it is switched on.

Change PIN code

Use this menu to change your PIN. The PIN check feature must be enabled to change the PIN.

(Menu 9.8)

If you enter an incorrect PIN/PIN2 three times in succession, the SIM card is blocked. To unblock it, you need to enter your PUK/PUK2 (Personal Unblocking Key). The codes are supplied by your service provider.

(Menu 9.8.1)

(Menu 9.8.2)

Page 91

Phone lock

(Menu 9.8.3)

Use this menu to lock the phone from unauthorised use. When this feature is enabled, you must enter a 4to 8-digit phone password each time the phone is switched on.

The password is preset to password, use the

Change password

00000000

Change password

(Menu 9.8.4)

. To change the

menu.

Use this menu to change your phone password.

Privacy

(Menu 9.8.5)

Use this menu to lock access to messages, files, or all menu functions on the phone, except for call functions. When a privacy option is enabled, you must enter the phone password to access the locked items or functions.

SIM lock

(Menu 9.8.6)

This menu allows your phone to work only with the current SIM card by assigning a SIM lock code. You must enter the SIM lock code to use a different SIM card.

Fixed dialling mode

(Menu 9.8.7)

If supported by your SIM card, Fixed Dialling Number (FDN) mode restricts your outgoing calls to a limited set of phone numbers. When this feature is enabled, you can make calls only to phone numbers stored on the SIM card.

Change PIN2 code

(Menu 9.8.8)

If supported by your SIM card, use this menu to change your current PIN2.

Connect settings

(Menu 9.9)

Use this menu to create and customise the profiles containing the settings for connecting your phone to the network. You need these settings to use the web browser or send MMS messages or e-mails.

Your phone is set up by default for connecting to the network. If you change the settings without first checking with your service provider, the web browser, MMS, and e-mail features may not work properly.

Page 92

Creating a profile

1. Press <

2. Set profile parameters:

New

press <

connection

•

Profile name

•

Homepage URL

page to be used as your homepage.

•

Proxy

•

IP address

server.

•

Port

server.

•

Linger time

network is disconnected if there has been no new data traffic in that time.

•

DNS

Name Server) addresses.

•

DNS 1

secondary DNS addresses.

•

Bearer

>. If a profile has already been saved,

Options

> and select

: enter a profile name.

: enter the URL address of the

: activate or deactivate the proxy server.

: enter the IP address of the proxy

: enter the port number of the proxy

: set a time period after which the

: activate or deactivate the DNS (Domain

and

DNS 2

: select the network bearer type.

Add new

: enter the primary and

•

Advanced settings

options. Depending on the bearer setting, available options vary.

When the bearer is set to

APN

: enter the access point name.

When the bearer is set to

Dial number Login ID Password Data call type

transmission.

3. Press <

: enter the login ID.

: enter the login password.

: enter the login ID.

: enter the login password.

Save

> to save the profile.

: change the advanced

: enter the PPP phone number.

: select a call type for data

Using profile options

Press <

Options

•

Edit

•

Delete

•

Add new connection

> to access the following options:

: edit the selected profile.

: delete the profile.

: add a new profile.

GPRS

GSM

Page 93

Reset settings

Use this menu to reset the phone’s settings you have changed.

1. Press [ ] to select the setting categories to be reset.

2. Press <

3. Press <

4. Enter the phone password and press <OK>.

The password is preset to change this password.

(Menu 9.10)

Reset

Yes

> to confirm the reset.

00000000



p. 88

. You can

Solve problems

Help and personal needs

To save the time and expense of an unnecessary service call, perform the simple checks in this section before contacting a service professional.

When you switch on your phone, the following messages may appear:

“Insert SIM”

• Be sure that the SIM card is correctly installed.

“Enter password”

• The automatic locking function has been enabled. You must enter the phone’s password before you can use the phone.

“Enter PIN”

• You are using your phone for the first time. You must enter the PIN supplied with the SIM card.

• The PIN check feature is enabled. Every time the phone is switched on, the PIN has to be entered. To disable this feature, use the

PIN check

menu.

Page 94

“Enter PUK”

• The PIN has been entered incorrectly three times in succession, and the SIM card is now blocked. Enter the PUK supplied by your service provider.

“No service,” “Network failure,” or “Not done” displays

• The network connection has been lost. You may be in a weak signal area. Move and try again.

• You are trying to access an option for which you have no subscription with your service provider. Contact the service provider for further details.

You have entered a number but it was not dialled

• Be sure that you have pressed [ ].

• Be sure you have accessed the right cellular network.

• Be sure that you have not set an outgoing call barring option.

Your correspondent cannot reach you

• Be sure that your phone is switched on. ([ ] pressed for more than one second.)

• Be sure that you are accessing the correct cellular network.

• Be sure that you have not set an incoming call barring option.

Your correspondent cannot hear you speaking

• Be sure that you have switched on the microphone.

• Be sure that you are holding the phone close enough to your mouth. The microphone is located at the bottom of the phone.

The phone starts beeping and “Warning. Low battery” flashes on the display

• Your battery is insufficiently charged. Recharge the battery.

The audio quality of the call is poor

• Check the signal strength indicator on the display ( ). The number of bars indicates the signal strength from strong ( ) to weak ( ).

• Try moving the phone slightly or moving closer to a window if you are in a building.

Page 95

Health and safety information

No number is dialled when you re-call a Phonebook entry

•Use the

• Re-store the number, if necessary.

The battery doesn’t charge properly or the phone sometimes turns itself off

• Wipe the charging contacts both on the phone and

If the above guidelines do not help you to solve the problem, take note of:

• The model and serial numbers of your phone

•Your warranty details

• A clear description of the problem

Then contact your local dealer or Samsung after-sales service.

Contact list

menu to ensure the number

has been stored correctly.

on the battery with a clean soft cloth.

Health and safety information

SAR certification information

This phone meets European Union (EU) requirements concerning exposure to radio waves.

Your mobile phone is a radio transmitter and receiver. It is designed and manufactured to not exceed the limits for exposure to radio-frequency (RF) energy, as recommended by the EU Council. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines were developed by independent scientific organisations through the periodic and thorough evaluation of scientific studies. The limits include a substantial safety margin designed to ensure the safety of all persons, regardless of age and health.

The exposure standard for mobile phones employs a unit of measurement known as Specific Ab so rpt io n Rate (S AR ). The SAR limit recommended by the EU Council is 2.0

W/kg.

The highest SAR value for this model phone was 0.679 W/kg

Page 96

SAR tests are conducted using standard operating positions with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a base station, the lower the power output of the phone.

* The SAR limit for mobile phones used by the public is 2.0 watts/

kilogram (W/kg) averaged over ten grams of body tissue. The limit incorporates a substantial margin of safety to give additional protection for the public and to account for any variations in measurements. The SAR values may vary, depending on national reporting requirements and the network band.

Precautions when using batteries

• Never use a charger or battery that is damaged in any way.

• Use the battery only for its intended purpose.

• If you use the phone near the network’s base station, it uses less power. Talk and standby time are greatly affected by the signal strength on the cellular network and the parameters set by the network operator.

• Battery charging time depends on the remaining battery charge, the type of battery, and the charger used. The battery can be charged and discharged hundreds of times, but it will gradually wear out. When the operation time is noticeably shorter than normal, it is time to buy a new battery.

• If left unused, a fully charged battery will discharge itself over time.

• Use only Samsung-approved batteries, and recharge your battery only with Samsung-approved chargers. Disconnect the charger from the power source when it is not in use. Do not leave the battery connected to a charger for more than a week, since overcharging may shorten its life.

• Extreme temperatures will affect the charging capacity of your battery: it may require cooling or warming first.

Page 97

Health and safety information

• Do not leave the battery in hot or cold places because the capacity and lifetime of the battery will be reduced. Try to keep the battery at room temperature. A phone with a hot or cold battery may not work temporarily, even when the battery is fully charged. Li-ion batteries are particularly affected by temperatures below 0°C (32°F).

• Do not short-circuit the battery. Accidental shortcircuiting can occur when a metallic object like a coin, clip or pen causes a direct connection between the + and – terminals of the battery (metal strips on the battery). For example, do not carry a spare battery in a pocket or bag where the battery may contact metal objects. Short-circuiting the terminals may damage the battery or the object causing the short-circuiting.

• Dispose of used batteries in accordance with local regulations. Always recycle. Do not dispose of batteries in a fire.

Road safety

Your wireless phone gives you the powerful ability to communicate by voice, almost anywhere, anytime. But an important responsibility accompanies the benefits of wireless phones, one that every user must uphold.

When you are driving a car, driving is your first responsibility. When using your wireless phone while driving, follow local regulations in the country or region you are in.

Operating environment

Remember to follow any special regulations in force in the area you are in, and always switch off your phone whenever it is forbidden to use it, or when it may cause interference or danger.

When connecting the phone or any accessory to another device, read its user’s guide for detailed safety instructions. Do not connect incompatible products.

As with other mobile radio transmitting equipment, users are advised that for the satisfactory operation of the equipment and for the safety of personnel, it is recommended that the equipment should only be used in the normal operating position (held to your ear with the antenna pointing over your shoulder).

Page 98

Electronic devices

Most modern electronic equipment is shielded from radio frequency (RF) signals. However, certain electronic equipment may not be shielded against the RF signals from your wireless phone. Consult the manufacturer to discuss alternatives.

Pacemakers

Pacemaker manufacturers recommend that a minimum distance of 15 cm (6 inches) be maintained between a wireless phone and a pacemaker to avoid potential interference with the pacemaker. These recommendations are consistent with the independent research and recommendations of Wireless Technology Research. If you have any reason to suspect that interference is taking place, switch off your phone immediately.

Hearing aids

Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may wish to consult your hearing aid manufacturer to discuss alternatives.

Other medical devices

If you use any other personal medical devices, consult the manufacturer of your device to determine if it is adequately shielded from external RF energy.

Your physician may be able to assist you in obtaining this information.

Switch off your phone in health care facilities when regulations posted in these areas instruct you to do so.

Vehicles

RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles. Check with the manufacturer or its representative regarding your vehicle.

You should also consult the manufacturer of any equipment that has been added to your vehicle.

Posted facilities

Switch off your phone in any facility where posted notices require you to do so.

Health and safety information

Page 99

Health and safety information

Potentially explosive environments

Switch off your phone when in any area with a potentially explosive atmosphere, and obey all signs and instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.

Users are advised to switch off the phone while at a refuelling point (service station). Users are reminded of the need to observe restrictions on the use of radio equipment in fuel depots (fuel storage and distribution areas), chemical plants, or where blasting operations are in progress.

Areas with a potentially explosive atmosphere are often but not always clearly marked. They include the areas below decks on boats, chemical transfer or storage facilities, vehicles using liquefied petroleum gas, such as propane or butane, areas where the air contains chemicals or particles, such as grain, dust or metal powders, and any other area where you would normally be advised to turn off your vehicle engine.

Emergency calls

This phone, like any wireless phone, operates using radio signals, wireless, and landline networks as well as userprogrammed functions, which cannot guarantee connection in all conditions. Therefore, you should never rely solely on any wireless phone for essential communications like medical emergencies.

To make or receive calls, the phone must be switched on and in a service area with adequate signal strength. Emergency calls may not be possible on all wireless phone networks or when certain network services and/or phone features are in use. Check with local service providers.

To make an emergency call:

1. Switch on the phone.

2. Key in the emergency number for your present location. Emergency numbers vary by location.

3. Press

Certain features like Call Barring may need to be deactivated before you can make an emergency call. Consult this document and your local cellular service provider.

[]

Page 100

Other important safety information

• Only qualified personnel should service the phone or install the phone in a vehicle. Faulty installation or service may be dangerous and may invalidate any warranty applicable to the device.

• Check regularly that all wireless phone equipment in your vehicle is mounted and operating properly.

• Do not store or carry flammable liquids, gases, or explosive materials in the same compartment as the phone, its parts, or accessories.

• For vehicles equipped with an air bag, remember that an air bag inflates with great force. Do not place objects, including installed or portable wireless equipment, in the area over the air bag or in the air bag deployment area. Improperly installed wireless equipment could result in serious injury if the air bag inflates.

• Switch off your phone before boarding an aircraft. It is dangerous and illegal to use wireless phones in an aircraft because they can interfere with the operation of the aircraft.

• Failure to observe these instructions may lead to the suspension or denial of telephone services to the offender, or legal action, or both.

Care and maintenance

Your phone is a product of superior design and craftsmanship and should be treated with care. The suggestions below will help you fulfill any warranty obligations and allow you to enjoy this product for many years.

• Keep your phone and all its parts and accessories out of the reach of small children and pets. They may accidentally damage these things or choke on small parts.

• Keep the phone dry. Precipitation, humidity, and liquids contain minerals that corrode electronic circuits.

• Do not use the phone with a wet hand. Doing so may cause an electric shock to you or damage to the phone.

• Do not use or store the phone in dusty, dirty areas, as its moving parts may be damaged.

• Do not store the phone in hot areas. High temperatures can shorten the life of electronic devices, damage batteries, and warp or melt certain plastics.

• Do not store the phone in cold areas. When the phone warms up to its normal operating temperature, moisture can form inside the phone, which may damage the phone’s electronic circuit boards.

Health and safety information
