Samsung CLX-419xN User Guide

CLX-419x series CLX-626x series C145x series C186x series

User’s Guide

BASIC

This guide provides information concerning installation, basic operation and troubleshooting on Windows.

ADVANCED

This guide provides information about installation, advanced configuration, operation and troubleshooting on various OS environments.

Some features may not be available depending on models or countries.

Basic faxing 78

1. Introduction

Key benefits 5

Features by model 7

Useful to know 15

About this user’s guide 16

Safety information 17

Machine overview 22

Control panel overview 26

Turning on the machine 31

Installing the driver locally 32

Reinstalling the driver 34

2. Menu Overview and Basic Setup

Using USB memory device 82

3. Maintenance

Ordering supplies and accessories 89

Available consumables 90

Available accessories 92

Available maintenance parts 93

Storing the toner cartridge 94

Redistributing toner 96

Replacing the toner cartridge 98

Replacing the waste toner container 101

Installing accessories 103

Monitoring the supplies life 107

Menu overview 36

Machine’s basic settings 47

Media and tray 49

Basic printing 65

Basic copying 72

Basic scanning 77

Setting the toner low alert 108

Cleaning the machine 109

Tips for moving & storing your machine 115

4. Troubleshooting

Tips for avoiding paper jams 117

Clearing original document jams 118

Clearing paper jams 123

Understanding the status LED 135

Understanding display messages 137

5. Appendix

Specifications 144

Regulatory information 157

1. Introduction

This chapter provides information you need to know before using the machine.

•Key benefits 5

• Features by model 7

• Useful to know 15

• About this user’s guide 16

• Safety information 17

• Machine overview 22

• Control panel overview 26

• Turning on the machine 31

• Installing the driver locally 32

• Reinstalling the driver 34

Key benefits

Environmentally friendly

• To save toner and paper, this machine supports Eco feature (see "Eco printing" on page 69).

• To save paper, you can print multiple pages on one single sheet of paper (see "Using advanced print features" on page 298).

• To save paper, you can print on both sides of the paper (double-sided printing) (see "Using advanced print features" on page 298).

• To save electricity, this machine automatically conserves electricity by substantially reducing power consumption when not in use.

• We recommend using recycled paper for saving energy.

Fast high resolution printing

• You can print in a full range of colors using cyan, magenta, yellow, and black.

• You can print with a resolution of up to 9,600 x 600 dpi effective output (600 x 600 x 4 bit).

• Fast, on-demand printing.

- C145x series ▪ For single-side printing, up to 14 ppm (A4) or up to 15 ppm (Letter).

- CLX-419x series /C186x series ▪ For single-side printing, up to 18 ppm (A4) or up to 19 ppm (Letter).

- CLX-626x series

▪ For single-side printing, up to 24 ppm (A4) or up to 25 ppm (Letter). ▪ For duplex printing, up to 12 ppm (A4) or up to 12 ppm (Letter).

Convenience

• Simply touch your mobile device on the NFC tag on your printer and get the print job done (see "Using the NFC feature" on page 238).

• You can print on the go from your smartphone or computer using Google Cloud Print™ enabled apps (see "Google Cloud Print™" on page 247).

• Easy Capture Manager allows you to easily edit and print whatever you captured using the Print Screen key on the keyboard (see "Easy Capture

Manager" on page 336).

• Samsung Easy Printer Manager and Printing Status is a program that monitors and informs you of the machine’s status and allows you to customize the machine’s settings (see "Using Samsung Printer Status" on

page 348 or "Using Samsung Easy Printer Manager" on page 345).

Key benefits

• Samsung Easy Document Creator is an application to help users scan, compile, and save documents in multiple formats, including .epub format. These documents can be shared via social networking sites or fax (see "Using Samsung Easy Document Creator" on page 344).

• AnyWeb Print helps you screen-capture, preview, scrap, and print the screen of Windows Internet Explorer more easily than when you use the ordinary program (see "Samsung AnyWeb Print" on page 338).

• Smart Update allows you to check for the latest software and install the latest version during the printer driver installation process. This is available only for Windows.

• If you have Internet access, you can get help, support application, machine drivers, manuals, and order information from the Samsung website, www.samsung.com > find your product > Support or Downloads.

Wide range of functionality and application support

• Supports various paper sizes (see "Print media specifications" on page 147).

• Print watermark: You can customize your documents with words, such as “Confidential” (see "Using advanced print features" on page 298).

• You can print in various operating systems (see "System requirements" on page 153).

• Your machine is equipped with a USB interface and/or a network interface.

Supports various wireless network setting method

• Using the WPS (Wi-Fi Protected Setup™) button

- You can easily connect to a wireless network using the WPS button on the machine and the access point (a wireless router).

• Using the USB cable or a network cable

- You can connect and set various wireless network settings using a USB cable or a network cable.

• Using the Wi-Fi Direct

- You can conveniently print from your mobile device using the Wi-Fi or Wi-Fi Direct feature.

See "Introducing wireless set up methods" on page 196.

Features by model

Some features and optional goods may not be available depending on model or country.

Operating System

(●: Included, Blank: Not available)

Operating System

CLX-419xN

CLX-419xFN

C145xN

CLX-419xFW

C145xFW C186xFW

CLX-626xND

CLX-626xFD CLX-626xFR

CLX-626xFW

Windows ● ● ● ●

Mac ● ● ● ●

Linux ● ● ● ●

Unix ● ● ● ●

Features by model

Software

You can install the printer driver and software when you insert the software CD into your CD-ROM drive.

For windows, select the printer driver and software in the Select Software to Install window.

Software

CLX-419xN

CLX-419xFN

C145xN

CLX-419xFW

C145xFW C186xFW

CLX-626xND

CLX-626xFD CLX-626xFR

CLX-626xFW

SPL printer driver ● ● ● ●

PCL printer driver ● ● ● ●

PS printer driver ● ●

(C145xFW/ C186xFW

)

● ●

XPS printer driver

● ● ● ●

Direct Printing Utility

● ● ● ●

Samsung Easy Printer Manager

Scan to PC settings ● ● ● ●

Fax to PC settings ●

(CLX-419xFN only)

● ●

(CLX-626xFD/CLX-

626xFR only)

●

Device Settings ● ● ● ●

Samsung Printer Status ● ● ● ●

Samsung AnyWeb Print

● ● ● ●

Features by model

(●: Included, Blank: Not available)

Samsung Easy Document Creator ● ● ● ●

Easy Capture Manager ● ● ● ●

Samsung Easy Color Manager

● ● ● ●

SyncThru™ Web Service ● ● ● ●

SyncThru Admin Web Service ● ● ● ●

Easy Eco Driver ● ● ● ●

Fax Samsung Network PC Fax ●

(CLX-419xFN only)

● ●

(CLX-626xFD/CLX-

626xFR only)

●

Scan Twain scan driver ● ● ● ●

WIA scan driver ● ● ● ●

a. Download the software from the Samsung website and install it: (http://www.samsung.com > find your product > Support or Downloads). Before installing, check whether your

computer’s OS support the software.

Software

CLX-419xN

CLX-419xFN

C145xN

CLX-419xFW

C145xFW C186xFW

CLX-626xND

CLX-626xFD CLX-626xFR

CLX-626xFW

Features by model

Variety feature

Features

CLX-419xN

CLX-419xFN

C145xN

CLX-419xFW

C145xFW C186xFW

CLX-626xND

CLX-626xFD CLX-626xFR

CLX-626xFW

Hi-Speed USB 2.0 ● ● ● ●

Network Interface Ethernet 10/100/ 1000 Base TX wired LAN

● ● ● ●

Network Interface 802.11b/g/n

wireless LAN

● ●

NFC (Near Field Communication) ●

(C145xFW/C186xFW

only)

Google Cloud Print™ ● ● ● ●

AirPrint ● ●

Eco printing ● ● ● ●

Duplex (2-sided) printing ● ●

Duplex (2-sided) printing (manual)

● ●

USB memory interface ● ● ● ●

Memory module ○ ○ ○ ○

Optional tray (Tray2) ○ ○

Mass Storage Device

●

Features by model

Document Feeder

Duplex Automatic Document Feeder (DADF)

●

(CLX-626xFR only)

●

Automatic Document Feeder (ADF)

● ● ●

(CLX-626xND/ CLX-626xFD only)

Handset

Features

CLX-419xN

CLX-419xFN

C145xN

CLX-419xFW

C145xFW C186xFW

CLX-626xND

CLX-626xFD CLX-626xFR

CLX-626xFW

Features by model

Fax Multi-send ●

(CLX-419xFN only)

● ●

(CLX-626xFD/CLX-626xFR only)

●

Delay send ●

(CLX-419xFN only)

● ●

(CLX-626xFD/CLX-626xFR only)

●

Priority send

Duplex send ●

(CLX-626xFR only)

●

Secure receive ●

(CLX-419xFN only)

● ●

(CLX-626xFD/CLX-626xFR only)

●

Duplex print ●

(CLX-626xFR only)

●

Send/ Receive forward fax

●

(CLX-419xFN only)

● ●

(CLX-626xFD/CLX-626xFR only)

●

Send/ Receive forward email

●

(CLX-626xFD/CLX-626xFR only)

●

Send/ Receive forward server

●

(CLX-626xFD/CLX-626xFR only)

●

Features

CLX-419xN

CLX-419xFN

C145xN

CLX-419xFW

C145xFW C186xFW

CLX-626xND

CLX-626xFD CLX-626xFR

CLX-626xFW

Features by model

Scan Scanning to email ● ● ● ●

Scanning to SMB server ● ●

Scanning to FTP server ● ●

Duplex scan ●

(CLX-626xFR only)

●

Scan to PC ● ● ● ●

Features

CLX-419xN

CLX-419xFN

C145xN

CLX-419xFW

C145xFW C186xFW

CLX-626xND

CLX-626xFD CLX-626xFR

CLX-626xFW

Features by model

(●: Included, ○: Optional, Blank: Not available)

Copy ID card copying ● ● ● ●

Reduced or enlarged copying

● ● ● ●

Collation ● ● ● ●

Poster

Clone

Auto Fit ● ● ● ●

Book ● ● ● ●

2-up/4-up ● ● ● ●

Adjust background ● ● ● ●

Margin shift

Edge erase ● ●

Gray enhance

Duplex copy ● ●

a. Depending on your country, wireless LAN card may not be available. For some countries, only 802.11 b/g can be applied. Contact your local Samsung dealer or the retailer where you

bought your machine. b. Available for Windows OS only. c. Only tray1 is supported. d. The machine is equipped with 4GB of SD (secure digital) card.

Features

CLX-419xN

CLX-419xFN

C145xN

CLX-419xFW

C145xFW C186xFW

CLX-626xND

CLX-626xFD CLX-626xFR

CLX-626xFW

Useful to know

The machine does not print.

• Open the print queue list and remove the document from the list (see "Canceling a print job" on page 66).

• Remove the driver and install it again (see "Installing the driver locally" on page 32).

• Select your machine as your default machine in your Windows (see "Setting your machine as a default machine" on page 297).

Where can I purchase accessories or supplies?

• Inquire at a Samsung distributor or your retailer.

• Visit www.samsung.com/supplies. Select your country/region to view product service information.

The status LED flashes or remains constantly on.

A paper jam has occurred.

• Open and close the door (see "Front view" on page 23).

• Check the instructions on removing jammed paper in this manual and troubleshoot accordingly (see "Clearing paper jams" on page 123).

Printouts are blurry.

• The toner level might be low or uneven. Shake the toner cartridge (see "Redistributing toner" on page 96).

• Try a different print resolution setting (see "Opening printing preferences" on page 67).

• Replace the toner cartridge (see "Replacing the toner cartridge" on page 98).

Where can I download the machine’s driver?

• Turn the product off and on again.

• Check the meanings of LED indications in this manual and troubleshoot accordingly (see "Understanding the status LED" on page 135).

• You can get help, support application, machine drivers, manuals, and order information from the Samsung website, www.samsung.com > find your product > Support or Downloads.

About this user’s guide

This user's guide provides information for your basic understanding of the machine as well as detailed steps to explain machine usage.

• Do not discard this manual, and keep it for future reference.

• Read the safety information before using the machine.

• If you have a problem using the machine, refer to the troubleshooting chapter.

• Terms used in this user’s guide are explained in the glossary chapter.

• All illustrations in this user’s guide may differ from your machine depending on its options or model you purchased.

• The screenshots in this user’s guide may differ from your machine depending on the machine’s firmware/driver version.

• The procedures in this user’s guide are mainly based on Windows 7.

General icons

Icon Text Description

Gives users information to protect the machine from

Caution

Warning Used to alert users to the possibility of personal injury.

Note

possible mechanical damage or malfunction.

Provides additional information or detailed specification of the machine function and feature.

Conventions

Some terms in this guide are used interchangeably, as below:

• Document is synonymous with original.

• Paper is synonymous with media, or print media.

• Machine refers to printer or MFP.

1. Introduction

Safety information

These warnings and precautions are included to prevent injury to you and others, and to prevent any potential damage to your machine. Be sure to read and understand all of these instructions before using the machine. After reading this section, keep it in a safe place for future reference.

Important safety symbols

Explanation of all icons and signs used in this chapter

Warning

Caution

Hazards or unsafe practices that may result in severe personal injury or death.

Hazards or unsafe practices that may result in minor personal injury or property damage.

Operating environment

Warning

Do not use if the power cord is damaged or if the electrical outlet is not grounded.

This could result in electric shock or fire.

Do not place anything on top of the machine (water, small metal or heavy objects, candles, lit cigarettes, etc.).

This could result in electric shock or fire.

• If the machine gets overheated, it releases smoke, makes strange noises, or generates an odd odor, immediately turn off the power switch and unplug the machine.

Do not attempt.

• The user should be able to access the power outlet in case of emergencies that might require the user to pull the plug out.

This could result in electric shock or fire.

Do not bend, or place heavy objects on the power cord.

Stepping on or allowing the power cord to be crushed by a heavy object could result in electric shock or fire.

Do not remove the plug by pulling on the cord; do not handle the plug with wet hands.

This could result in electric shock or fire.

1. Introduction

Safety information

Caution

During an electrical storm or for a period of non-operation, remove the power plug from the electrical outlet.

This could result in electric shock or fire.

Be careful, the paper output area is hot.

Burns could occur.

If the machine has been dropped, or if the cabinet appears damaged, unplug the machine from all interface connections and request assistance from qualified service personnel.

Otherwise, this could result in electric shock or fire.

If the machine does not operate properly after these instructions have been followed, unplug the machine from all interface connections and request assistance from qualified service personnel.

Otherwise, this could result in electric shock or fire.

Operating method

Caution

Do not forcefully pull the paper out during printing.

It can cause damage to the machine.

Be careful not to put your hand between the machine and paper tray.

You may get injured.

Be careful when replacing paper or removing jammed paper.

New paper has sharp edges and can cause painful cuts.

When printing large quantities, the bottom part of the paper output area may get hot. Do not allow children to touch.

If the plug does not easily enter the electrical outlet, do not attempt to force it in.

Call an electrician to change the electrical outlet, or this could result in electric shock.

Do not allow pets to chew on the AC power, telephone or PC interface cords.

This could result in electric shock or fire and/or injury to your pet.

Burns can occur.

When removing jammed paper, do not use tweezers or sharp metal objects.

It can damage the machine.

Do not allow too many papers to stack up in the paper output tray.

It can damage the machine.

1. Introduction

Safety information

Do not block or push objects into the ventilation opening.

This could result in elevated component temperatures which can cause damage or fire.

Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.

This machine's power reception device is the power cord.

To switch off the power supply, remove the power cord from the electrical outlet.

Installation / Moving

Warning

Do not place the machine in an area with dust, humidity, or water leaks.

This could result in electric shock or fire.

Caution

Before moving the machine, turn the power off and disconnect all cords. The information below are only suggestions based on the units weight.

If you have a medical condition that prevents you from lifting, do not lift the machine. Ask for help, and always use the appropriate amount of people to lift the device safely.

Then lift the machine:

• If the machine weighs under 20 kg (44.09 lbs), lift with 1 person.

• If the machine weighs 20 kg (44.09 lbs) - 40kg (88.18 lbs), lift with 2 people.

• If the machine weighs more than 40 kg (88.18 lbs), lift with 4 or more people.

The machine could fall, causing injury or machine damage.

Choose a flat surface with enough space for ventilation to place the machine. Also consider the space required to open the cover and trays.

The place should be well-ventilated and be far from direct light, heat, and humidity.

Place the machine in the environment where it meets the operating temperature and humidity specification. Otherwise, quality problems can occur and cause damage to the machine (see "General specifications" on page 144).

When using the machine for a long period of time or printing a large number of pages in a non-ventilated space, it could pollute the air and be harmful to your health. Place the machine in a wellventilated space or open a window to circulate the air periodically.

1. Introduction

Safety information

Do not place the machine on an unstable surface.

The machine could fall, causing injury or machine damage.

Use only No.26 AWG

or larger, telephone line cord, if necessary.

Maintenance / Checking

Otherwise, it can cause damage to the machine.

Make sure you plug the power cord into a grounded electrical outlet.

Otherwise, this could result in electric shock or fire.

Use the power cord supplied with your machine for safe operation. If you are using a cord which is longer than 2 meters (6 feet) with a 110V machine, then the gauge should be 16 AWG or larger.

Otherwise, it can cause damage to the machine, and could result in electric shock or fire.

Do not put a cover over the machine or place it in an airtight location, such as a closet.

If the machine is not well-ventilated, this could result in fire.

Do not overload wall outlets and extension cords.

This can diminish performance, and could result in electric shock or fire.

The machine should be connected to

the power level which is specified on the label.

If you are unsure and want to check the power level you are using, contact the electrical utility company.

Caution

Unplug this product from the wall outlet before cleaning the inside of the machine. Do not clean the machine with benzene, paint thinner or alcohol; do not spray water directly into the machine.

This could result in electric shock or fire.

When you are working inside the machine replacing supplies or cleaning the inside, do not operate the machine.

You could get injured.

Keep cleaning supplies away from children.

Children could get hurt.

Do not disassemble, repair or rebuild the machine by yourself.

It can damage the machine. Call a certified technician when the machine needs repairing.

To clean and operate the machine, strictly follow the user's guide provided with the machine.

Otherwise, you could damage the machine.

a. AWG: American Wire Gauge

1. Introduction

Safety information

Supply usage

Caution

Keep the power cable and the contact surface of the plug clean from dust or water.

Otherwise, this could result in electric shock or fire.

• Do not remove any covers or guards that are fastened with screws.

• Fuser units should only be repaired by a certified service technician. Repair by non-certified technicians could result in fire or electric shock.

• The machine should only be repaired by a Samsung service technician.

When storing supplies such as toner cartridges, keep them away from children.

Toner dust can be dangerous if inhaled or ingested.

Using recycled supplies, such as toner, can cause damage to the machine.

In case of damage due to the use of recycled supplies, a service fee will be charged.

For supplies that contain toner dust (toner cartridge, waste toner bottle, imaging unit, etc.) follow the instructions below.

• When disposing of the supplies, follow the instructions for disposal. Refer to the reseller for disposal instructions.

• Do not wash the supplies.

• For a waste toner bottle, do not reuse it after emptying the bottle.

If you do not follow the instructions above, it may cause machine malfunction and environmental pollution. The warranty does not cover damages caused by a user’s carelessness.

Do not disassemble the toner cartridge.

Toner dust can be dangerous if inhaled or ingested.

Do not burn any of the supplies such as toner cartridge or fuser unit.

This could cause an explosion or uncontrollable fire.

When toner gets on your clothing, do not use hot water to wash it.

Hot water sets toner into fabric. Use cold water.

When changing the toner cartridge or removing jammed paper, be careful not to let toner dust touch your body or clothes.

Toner dust can be dangerous if inhaled or ingested.

1. Introduction

Machine overview

Components

Machine Power cord Quick installation guide

Software CD

a. The software CD contains the print drivers, user’s guide, and software applications. b. Miscellaneous accessories included with your machine may vary by country of purchase and specific model.

Misc. accessories

1. Introduction

Machine overview

Front view

• This illustration may differ from your machine depending on your model. There are various types of machine.

• Some features and optional goods may not be available depending on model or country (see "Features by model" on page 7).

CLX-419x series/ C145x series/C186x series/CLX-626xND/CLX-626xFD

1 Automatic Document Feeder

(ADF) cover

2 Automatic Document

Feeder(ADF) width guide

3 Automatic Document

Feeder(ADF) input tray

4 Automatic Document

Feeder(ADF) output tray

5 Control panel 16 Manual feeder

Control board cover

Front cover

8 Tray 1 19 Toner cartridge

9 USB memory port 20 Toner cartridge handle

10 Output tray 21 Intermediate Transfer Belt (ITB)

Front cover handle

Scanner lid

Scanner glass

15 Paper width guides on a manual

feeder

17 Paper width guides on a multi-

purpose tray

Multi-purpose support tray

NFC tag Communication)

(Near Field

Document feeder output support

a. CLX-626xND/ CLX-626xFD only. b. C145xFW/C186xFW only.

1. Introduction

Machine overview

CLX-626xFR/CLX-626xFW

4 Duplex Automatic Document

Feeder (DADF) output tray

5 Control panel 17 Scanner glass

Control board cover

7 Front cover 19 Multi-purpose support tray

8 Tray 1 20 Toner cartridge

Optional tray

10 Push-release of Multi-purpose

tray

11 Multi-purpose tray 23 Duplex jam cover

12 USB memory port

a. This is an optional feature. CLX-626x series only.

Scanner lid

18 Paper width guides on a multi-

purpose tray

21 Toner cartridge handle

Intermediate Transfer Belt (ITB)

1 Duplex Automatic Document

Feeder (DADF) cover

2 Duplex Automatic Document

Feeder (DADF) width guide

3 Duplex Automatic Document

Feeder (DADF) input tray

Output tray

Document feeder output support

Front cover handle

1. Introduction

Machine overview

8 9

Rear view

• This illustration may differ from your machine depending on your model. There are various types of machine.

• Some features and optional goods may not be available depending on model or country (see "Features by model" on page 7).

CLX-419x series/C145x series/C186x series CLX-626x series

1 Waster toner container 4 Power receptacle 7 Network port

Rear cover

Rear cover handle

a. CLX-419xFN/CLX-419xFW/C145xFW/C186xFW/CLX-626xFD/CLX-626xFR/CLX-626xFW only.

Power-switch

USB port

Telephone line socket (LINE)

Extension telephone socket (EXT.)

1. Introduction

Control panel overview

5 6

8 9 10 11

15 14

• This control panel may differ from your machine depending on its model. There are various types of control panels.

• Some features and optional goods may not be available depending on model or country (see "Features by model" on page 7).

• Some buttons may not work depending on the mode (copy, fax, or scan).

Type A(CLX-419xN/ C145xN/ CLX-419xFN/ CLX-626xND/CLX-626xFD/ CLX-626xFR)

1 Darkness Adjusts the brightness level to make a copy for easier reading, when the original contains faint markings and dark images.

Allows you to copy both sides of an ID card like a driver’s license on a single side of paper (see "ID card copying" on page 75).

Sends scanned data.

1. Introduction

ID Copy

Scan to

Control panel overview

3 Display screen Shows the current status and prompts during an operation.

6 Arrows Scroll through the options available in the selected menu, and increase or decrease values.

7 OK Confirms the selection on the screen.

8 Numeric keypad Dials a number or enters alphanumeric characters (see "Keypad letters and numbers" on page 290).

9 Address Book Allows you to store frequently used fax numbers or search for stored fax numbers (see "Storing email address" on page 288 or "Setting

Copy

Fax

Redial/Pause

Stop/Clear

Power/Wake Up

Switches to Copy mode.

Switches to Fax mode.

up the fax address book" on page 291).

Redials the recently sent fax number or received caller ID in ready mode, or inserts a pause(-) into a fax number in edit mode (see "Redialing the fax number" on page 322).

Stops current operation.

Turns the power on or off, or wakes up the machine from the power save mode. If you need to turn the machine off, press this button for more than three seconds.

Start

On Hook Dial

Color

Black

Begins a printing job in color mode.

Begins a printing job in black and white mode.

When you press this button, you can hear a dial tone. Then enter a fax number. It is similar to making a call using speaker phone (see "Receiving manually in Tel mode" on page 328).

1. Introduction

Control panel overview

Back

19 Status LED Indicates the status of your machine (see "Understanding the status LED" on page 135).

21 Direct USB Allows you to directly print files stored on a USB memory device when it is inserted into the USB port on the front of your machine.

a. CLX-419xFN/ CLX-626xFD/ CLX-626xFR only. b. CLX-419xN/ C145xN/ CLX-626xND only.

Scan

Toner colors

Eco

Sends you back to the upper menu level.

Enters Menu mode and scrolls through the available menus (see "Menu overview" on page 36).

Switches to Scan mode.

Show the status of each toner cartridge. If the toner cartridge is low or needs to be replaced, the Status LED turns red and the display shows the message. However, the arrow mark shows which color toner is of concern or may be installed with a new cartridge (see "Toner-related messages" on page 138).

Turn into eco mode to reduce toner consumption and paper usage when pc-printing and copying only (see "Eco printing" on page

69).

1. Introduction

Control panel overview

Type B(CLX-419xFW/C145xFW/C186xFW/CLX-626xFW)

1 Display screen Shows the current status and displays prompts during an operation.

2 Numeric keypad Dials a number or enters alphanumeric characters (see "Keypad letters and numbers" on page 290).

3 Clear Deletes characters in the edit area.

Stop

Power/Wake Up

Stops an operations at any time.

Turns the power on or off, or wakes up the machine from the power save mode. If you need to turn the machine off, press this button for more than three seconds.

1. Introduction

Control panel overview

Start

On Hook Dial

8 Help Gives detailed information about this machine’s menus or status.

9 Reset Resets the current machine’s setup.

10 Wireless LED Shows the current status of the wireless network connection (see "Understanding the status LED" on page 135).

11 Status LED Indicates the status of your machine (see "Understanding the status LED" on page 135).

Starts a job in black or color mode.

When you press this button, you can hear a dial tone. Then enter a fax number. It is similar to making a call using speaker phone (see "Receiving manually in Tel mode" on page 328).

1. Introduction

+ 396 hidden pages
