SAMSUNG CL21M2MQ2X-XAX Part List

Electrical Part List

5. Electrical Part List

5-1 CL21M2MQ2X/XAX

You can search for the updated part code through ITSELF web site.
URL:http://itself.sec.samsung.co.kr

Loc. No. Code No. Description Specification Q'ty SA/SNA Remark

ASSY CHASSIS

M0017 AA91-09606L ASSY CHASSIS CL21M2MQ2X/XAX,K16A,RHUMBA 1 S.N.A

T0091 AA94-14616A ASSY PCB MISC-A/V SIDE CT21T20MQUX,KS7A 1 S.A

T0245 0202-001366 SOLDER-WIRE FLUX -,RS60S,D1.2,63Sn/37Pb, 2.5 S.N.A
JE01 3722-000143 JACK-PHONE 1P(VER),3.4PI,AG,BLK,NO 1 S.A
0 AA41-01070A PCB-AV SIDE CT-25K10G,FR-1,1,A,1.6,KS7A, 1 S.N.A
CA01 2401-003102 C-AL 100uF,20%,10V,GP,TP,5x11,5 1 S.A
CA02 2401-003102 C-AL 100uF,20%,10V,GP,TP,5x11,5 1 S.A
JA01 3722-001031 JACK-PIN 3P,3.6mm,#18,AU 1 S.A
RA01 2001-000028 R-CARBON(S) 100OHM,5%,1/2W,AA,TP,2.4X6.4 1 S.A
RA02 2001-000028 R-CARBON(S) 100OHM,5%,1/2W,AA,TP,2.4X6.4 1 S.A
T0238 AA97-15391A ASSY AUTO CT21T20MQUXXTC,KS7A 1 S.N.A
T0245 AA39-20009D LEAD CONNECTOR-ASSY ,1P,500,YFH800-01,16 1 S.A
T0245 AA39-20068E LEAD CONNECTOR-ASSY ,8P,500,YBNH025-08,6 1 S.A
T0245 AA39-20069D LEAD CONNECTOR-ASSY ,5P,300,YBNH025-05,6 1 S.A
T0603 AA63-10002A BAND-TIE NYLON66 V2,L100,NTR 1 S.N.A

T0098 AA94-14788E ASSY PCB MISC-TACT S/W,CONTROL CL21M21EQ 1 S.N.A

0 AA41-01085A PCB-TACT SWITCH M21,FR-1,1,A,245*245*1.6 1 S.N.A
CY01 2401-002291 C-AL 47uF,20%,16V,GP,TP,6.3x5,5 1 S.A
D0254 AA32-00012A MODULE REMOCON ORC-50HF2,38KHZ,940NM,MES 1 S.A
DY01 0401-000005 DIODE-SWITCHING 1N4148,75V,150mA,DO-35,T 1 S.A
DY02 0401-000005 DIODE-SWITCHING 1N4148,75V,150mA,DO-35,T 1 S.A
DZP01 0403-000508 DIODE-ZENER MTZJ5.6B,5.45-5.73V,500MW,DO 1 S.A
DZY01 0403-000508 DIODE-ZENER MTZJ5.6B,5.45-5.73V,500MW,DO 1 S.A
LDY02 0601-000465 LED ROUND,GRN,5mm,565 1 S.A
RY01 2001-000020 R-CARBON(S) 22OHM,5%,1/2W,AA,TP,2.4X6.4M 1 S.A
RY02 2001-000449 R-CARBON 2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
RY03 2001-000613 R-CARBON 3.9KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
RY04 2001-000878 R-CARBON 6.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
RY05 2001-000347 R-CARBON 13KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
RY07 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
SW07 3404-000243 SWITCH-TACT 15V,20mA,160gf+-50gf,6x3.4mm 1 S.A
SWY02 3404-000243 SWITCH-TACT 15V,20mA,160gf+-50gf,6x3.4mm 1 S.A
SWY03 3404-000243 SWITCH-TACT 15V,20mA,160gf+-50gf,6x3.4mm 1 S.A
SWY04 3404-000243 SWITCH-TACT 15V,20mA,160gf+-50gf,6x3.4mm 1 S.A
SWY05 3404-000243 SWITCH-TACT 15V,20mA,160gf+-50gf,6x3.4mm 1 S.A
SWY06 3404-000243 SWITCH-TACT 15V,20mA,160gf+-50gf,6x3.4mm 1 S.A
T0245 0202-001366 SOLDER-WIRE FLUX -,RS60S,D1.2,63Sn/37Pb, 0.09 S.N.A
T0245 AA39-00385A LEAD CONNECTOR-ASSY GOLR RUSH,UL1007#26, 1 S.A
T0245 AA39-20050A LEAD CONNECTOR-ASSY ,3P,200,YBNH250-03,Y 1 S.A

M0014 AA94-15674B ASSY PCB MAIN CL21M2MQ2X/XAX,K16A,RHUMBA 1 S.A

C101 2202-002037 C-CERAMIC,MLC-AXIAL 100nF,80-20%,50V,Y5V 1 S.A
C102 2401-003578 C-AL 1000uF,20%,10V,GP,TP,8x20mm,5 1 S.A
C103 2202-002037 C-CERAMIC,MLC-AXIAL 100nF,80-20%,50V,Y5V 1 S.A
C104 2401-000302 C-AL 100uF,20%,25V,GP,TP,6.3x11,5 1 S.A
C105 2401-000480 C-AL 10uF,20%,50V,GP,TP,5x11,5 1 S.A
C106 2202-002037 C-CERAMIC,MLC-AXIAL 100nF,80-20%,50V,Y5V 1 S.A
C109 2401-003036 C-AL 100uF,20%,16V,GP,TP,5X11mm,5mm 1 S.A
C110 2202-002037 C-CERAMIC,MLC-AXIAL 100nF,80-20%,50V,Y5V 1 S.A
C115 2202-002037 C-CERAMIC,MLC-AXIAL 100nF,80-20%,50V,Y5V 1 S.A
C125 2202-002037 C-CERAMIC,MLC-AXIAL 100nF,80-20%,50V,Y5V 1 S.A
C130 2305-000412 C-FILM,LEAD-PEF 470nF,5%,63V,TP,-,5mm 1 S.A
C131 2305-000412 C-FILM,LEAD-PEF 470nF,5%,63V,TP,-,5mm 1 S.A
C132 2305-000412 C-FILM,LEAD-PEF 470nF,5%,63V,TP,-,5mm 1 S.A
C133 2305-000665 C-FILM,LEAD-PEF 100nF,5%,63V,TP,7.5x4.0x 1 S.A
C137 2401-000660 C-AL 2.2uF,20%,50V,GP,TP,5x11,5 1 S.A
C139 2401-000660 C-AL 2.2uF,20%,50V,GP,TP,5x11,5 1 S.A
C140 2305-000665 C-FILM,LEAD-PEF 100nF,5%,63V,TP,7.5x4.0x 1 S.A
C143 2202-000222 C-CERAMIC,MLC-AXIAL 3.3nF,20%,16V,Y5P,TP 1 S.A
C144 2202-000127 C-CERAMIC,MLC-AXIAL 10nF,+80-20%,25V,Y5V 1 S.A

AA97-15540B ASSY AUTO-TACT S/W,CONTROL CL21M21EQ2XXA 1 S.N.A

5-1Samsung Electronics

Electrical Part List

Loc. No. Code No. Description Specification Q'ty SA/SNA Remark

C145 2306-000134 C-FILM,LEAD-PPF 150nF,5%,400V,TP,19x17x1 1 S.A
C146 2401-000480 C-AL 10uF,20%,50V,GP,TP,5x11,5 1 S.A
C147 2202-000807 C-CERAMIC,MLC-AXIAL 22nF,+80-20%,25V,Y5V 1 S.A
C148 2305-000289 C-FILM,LEAD-PEF 220nF,5%,63V,TP,-,5mm 1 S.A
C202 2401-003517 C-AL 22uF,20%,50V,LZ,TP,5x11mm,5 1 S.A
C204 2202-002037 C-CERAMIC,MLC-AXIAL 100nF,80-20%,50V,Y5V 1 S.A
C205 2202-002037 C-CERAMIC,MLC-AXIAL 100nF,80-20%,50V,Y5V 1 S.A
C206 2401-000050 C-AL 10uF,20%,16V,GP,TP,5x11,2.5 1 S.A
C218 2401-000050 C-AL 10uF,20%,16V,GP,TP,5x11,2.5 1 S.A
C219 2202-002037 C-CERAMIC,MLC-AXIAL 100nF,80-20%,50V,Y5V 1 S.A
C301 2305-000285 C-FILM,LEAD-PEF 220NF,5%,100V,TP,10.5X5. 1 S.A
C302 2201-000259 C-CERAMIC,DISC 0.18NF,10%,500V,Y5P,TP,5. 1 S.A
C303 2201-000556 C-CERAMIC,DISC 0.47NF,10%,500V,Y5P,TP,5. 1 S.A
C304 2401-001397 C-AL 470uF,20%,25V,GP,TP,10x16,5 1 S.A
C305 2201-000556 C-CERAMIC,DISC 0.47NF,10%,500V,Y5P,TP,5. 1 S.A
C306 2401-001397 C-AL 470uF,20%,25V,GP,TP,10x16,5 1 S.A
C307 2401-000360 C-AL 100uF,20%,50V,GP,TP,8x11.5,5 1 S.A
C308 2401-000360 C-AL 100uF,20%,50V,GP,TP,8x11.5,5 1 S.A
C309 2301-000253 C-FILM,LEAD-PEF 39NF,5%,100V,TP,7.5X4.5X 1 S.A
C312 2202-000796 C-CERAMIC,MLC-AXIAL 1NF,10%,50V,Y5P,TP,3 1 S.A
C313 2202-000796 C-CERAMIC,MLC-AXIAL 1NF,10%,50V,Y5P,TP,3 1 S.A
C403 2401-002268 C-AL 2.2uF,20%,250V,LZ,TP,8X11,5 1 S.A
C406 2401-002619 C-AL 47uF,20%,25V,GP,TP,5x11,5 1 S.A
C407 2305-000178 C-FILM,LEAD-PEF 10nF,5%,100V,TP,-,5mm 1 S.A
C408 2201-000599 C-CERAMIC,DISC 0.56NF,10%,500V,Y5P,TP,5. 1 S.A
C413 2201-000556 C-CERAMIC,DISC 0.47NF,10%,500V,Y5P,TP,5. 1 S.A
C417 2202-000796 C-CERAMIC,MLC-AXIAL 1NF,10%,50V,Y5P,TP,3 1 S.A
C420 2301-001065 C-FILM,LEAD-PPF 47nF,5%,630V,TP,19x15.5x 1 S.A
C501 2001-000429 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
C502 2001-000429 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
C503 2001-000429 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
C504 2301-001259 C-FILM,LEAD-PPF 100nF,5%,400V,TP,19x8x16 1 S.A
C505 2202-000825 C-CERAMIC,MLC-AXIAL 680pF,10%,50V,Y5P,TP 1 S.A
C506 2401-000430 C-AL 10uF,20%,250V,GP,TP,10x16mm,5m 1 S.A
C507 2401-000430 C-AL 10uF,20%,250V,GP,TP,10x16mm,5m 1 S.A
C508 2201-000723 C-CERAMIC,DISC 4.7NF,20%,3KV,Y5U,TP,16X5 1 S.A
C509 2201-002147 C-CERAMIC,DISC 2.7NF,10%,500V,Y5P,TP,10X 1 S.A
C510 2201-002147 C-CERAMIC,DISC 2.7NF,10%,500V,Y5P,TP,10X 1 S.A
C511 2401-000553 C-AL 1uF,10%,50V,GP,TP,5x11,5 1 S.A
C601 2401-001914 C-AL 1uF,20%,50V,BP,TP,5x11,5 1 S.A
C602 2401-001914 C-AL 1uF,20%,50V,BP,TP,5x11,5 1 S.A
C607 2202-000231 C-CERAMIC,MLC-AXIAL 0.33NF,10%,50V,Y5P,T 1 S.A
C608 2202-000231 C-CERAMIC,MLC-AXIAL 0.33NF,10%,50V,Y5P,T 1 S.A
C610 2301-000289 C-FILM,LEAD-PEF 5.6nF,5%,50V,TP,7x6x3mm, 1 S.A
C611 2301-000289 C-FILM,LEAD-PEF 5.6nF,5%,50V,TP,7x6x3mm, 1 S.A
C612 2401-001914 C-AL 1uF,20%,50V,BP,TP,5x11,5 1 S.A
C613 2401-001914 C-AL 1uF,20%,50V,BP,TP,5x11,5 1 S.A
C617 2401-000480 C-AL 10uF,20%,50V,GP,TP,5x11,5 1 S.A
C618 2001-000786 R-CARBON 47KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
C620 2305-000665 C-FILM,LEAD-PEF 100nF,5%,63V,TP,7.5x4.0x 1 S.A
C621 2401-001998 C-AL 1000uF,20%,25V,GP,TP,10x20,5mm 1 S.A
C627 2202-000231 C-CERAMIC,MLC-AXIAL 0.33NF,10%,50V,Y5P,T 1 S.A
C629 2202-000231 C-CERAMIC,MLC-AXIAL 0.33NF,10%,50V,Y5P,T 1 S.A
C638 2202-000231 C-CERAMIC,MLC-AXIAL 0.33NF,10%,50V,Y5P,T 1 S.A
C642 2202-000231 C-CERAMIC,MLC-AXIAL 0.33NF,10%,50V,Y5P,T 1 S.A
C643 2202-000231 C-CERAMIC,MLC-AXIAL 0.33NF,10%,50V,Y5P,T 1 S.A
C644 2202-000231 C-CERAMIC,MLC-AXIAL 0.33NF,10%,50V,Y5P,T 1 S.A
C701 2202-000243 C-CERAMIC,MLC-AXIAL 33pF,5%,50V,SL,TP,3. 1 S.A
C702 2202-000243 C-CERAMIC,MLC-AXIAL 33pF,5%,50V,SL,TP,3. 1 S.A
C703 2202-000243 C-CERAMIC,MLC-AXIAL 33pF,5%,50V,SL,TP,3. 1 S.A
C704 2202-000243 C-CERAMIC,MLC-AXIAL 33pF,5%,50V,SL,TP,3. 1 S.A
C705 2202-000243 C-CERAMIC,MLC-AXIAL 33pF,5%,50V,SL,TP,3. 1 S.A
C713 2305-000289 C-FILM,LEAD-PEF 220nF,5%,63V,TP,-,5mm 1 S.A
C715 2305-000289 C-FILM,LEAD-PEF 220nF,5%,63V,TP,-,5mm 1 S.A
C717 2305-000289 C-FILM,LEAD-PEF 220nF,5%,63V,TP,-,5mm 1 S.A
C719 2305-000289 C-FILM,LEAD-PEF 220nF,5%,63V,TP,-,5mm 1 S.A
C721 2401-000660 C-AL 2.2uF,20%,50V,GP,TP,5x11,5 1 S.A
C722 2401-000660 C-AL 2.2uF,20%,50V,GP,TP,5x11,5 1 S.A
C723 2202-002037 C-CERAMIC,MLC-AXIAL 100nF,80-20%,50V,Y5V 1 S.A
C724 2202-002037 C-CERAMIC,MLC-AXIAL 100nF,80-20%,50V,Y5V 1 S.A
C725 2202-002037 C-CERAMIC,MLC-AXIAL 100nF,80-20%,50V,Y5V 1 S.A
C801 2401-002251 C-AL 470uF,20%,200V,GP,BK,25x40mm,1 1 S.A
C802 2301-000383 C-FILM,LEAD-PEF 10nF,5%,50V,TP,6x7x3.2mm 1 S.A
C803 2305-000665 C-FILM,LEAD-PEF 100nF,5%,63V,TP,7.5x4.0x 1 S.A
C805 2201-000556 C-CERAMIC,DISC 0.47NF,10%,500V,Y5P,TP,5. 1 S.A
C806 2301-001158 C-FILM,LEAD-PPF 1nF,5%,800V,TP,15x12x5.5 1 S.A
C807 2201-000291 C-CERAMIC,DISC 1NF,10%,500V,Y5P,TP,7.5X3 1 S.A

Samsung Electronics5-2

Electrical Part List

Loc. No. Code No. Description Specification Q'ty SA/SNA Remark

C808 2401-002300 C-AL 47uF,20%,50V,GP,TP,6.3x11,5 1 S.A
C809 2201-000558 C-CERAMIC,DISC 0.47NF,10%,50V,Y5P,TP,5X3 1 S.A
C810 2305-000665 C-FILM,LEAD-PEF 100nF,5%,63V,TP,7.5x4.0x 1 S.A
C811 2401-000698 C-AL 2200uF,20%,16V,WT,TP,12.5x25,5 1 S.A
C812 2401-002075 C-AL 4.7uF,20%,50V,GP,TP,5x11,5 1 S.A
C813 2401-001486 C-AL 47uF,20%,160V,HR,TP,13x20mm,5m 1 S.A
C814 2201-000599 C-CERAMIC,DISC 0.56NF,10%,500V,Y5P,TP,5. 1 S.A
C815 2401-000689 C-AL 2200uF,20%,16V,GP,TP,13x25,5 1 S.A
C816 2201-000406 C-CERAMIC,DISC 0.27NF,10%,2KV,Y5P,TP,6.3 1 S.A
C818 2401-000703 C-AL 2200uF,20%,25V,GP,-,12.5x25mm, 1 S.A
C819 2401-000262 C-AL 100uF,20%,160V,HR,TP,16x25,7.5 1 S.A
C820 2401-002463 C-AL 470uF,20%,16V,GP,TP,8x11.5,5 1 S.A
C822 2401-002144 C-AL 47uF,20%,16V,GP,TP,5x11,5 1 S.A
C823 2401-002463 C-AL 470uF,20%,16V,GP,TP,8x11.5,5 1 S.A
C824 2305-000289 C-FILM,LEAD-PEF 220nF,5%,63V,TP,-,5mm 1 S.A
C825 2401-002463 C-AL 470uF,20%,16V,GP,TP,8x11.5,5 1 S.A
C827 2401-000927 C-AL 22uF,20%,250V,GP,TP,13x20,5 1 S.A
C828 2201-000374 C-CERAMIC,DISC 0.22NF,5%,50V,C0G,TP,10.5 1 S.A
C843 2301-000192 C-FILM,LEAD-PEF 1nF,5%,50V,TP,5.3x10mm,5 1 S.A
C844 2301-000356 C-FILM,LEAD-PEF 47nF,5%,50V,TP,7.5x4.0x6 1 S.A
C888 2201-000556 C-CERAMIC,DISC 0.47NF,10%,500V,Y5P,TP,5. 1 S.A
C901 2401-002144 C-AL 47uF,20%,16V,GP,TP,5x11,5 1 S.A
C902 2202-000796 C-CERAMIC,MLC-AXIAL 1NF,10%,50V,Y5P,TP,3 1 S.A
C903 2401-003036 C-AL 100uF,20%,16V,GP,TP,5X11mm,5mm 1 S.A
C904 2202-002037 C-CERAMIC,MLC-AXIAL 100nF,80-20%,50V,Y5V 1 S.A
C905 2401-003036 C-AL 100uF,20%,16V,GP,TP,5X11mm,5mm 1 S.A
C906 2401-000050 C-AL 10uF,20%,16V,GP,TP,5x11,2.5 1 S.A
C907 2202-002037 C-CERAMIC,MLC-AXIAL 100nF,80-20%,50V,Y5V 1 S.A
C908 2401-003036 C-AL 100uF,20%,16V,GP,TP,5X11mm,5mm 1 S.A
C909 2202-002037 C-CERAMIC,MLC-AXIAL 100nF,80-20%,50V,Y5V 1 S.A
C911 2202-002037 C-CERAMIC,MLC-AXIAL 100nF,80-20%,50V,Y5V 1 S.A
C912 2401-003036 C-AL 100uF,20%,16V,GP,TP,5X11mm,5mm 1 S.A
C913 2202-002037 C-CERAMIC,MLC-AXIAL 100nF,80-20%,50V,Y5V 1 S.A
C914 2202-002037 C-CERAMIC,MLC-AXIAL 100nF,80-20%,50V,Y5V 1 S.A
C915 2401-003036 C-AL 100uF,20%,16V,GP,TP,5X11mm,5mm 1 S.A
C916 2202-002037 C-CERAMIC,MLC-AXIAL 100nF,80-20%,50V,Y5V 1 S.A
C917 2202-002037 C-CERAMIC,MLC-AXIAL 100nF,80-20%,50V,Y5V 1 S.A
C918 2401-003036 C-AL 100uF,20%,16V,GP,TP,5X11mm,5mm 1 S.A
C919 2401-003036 C-AL 100uF,20%,16V,GP,TP,5X11mm,5mm 1 S.A
C920 2202-002037 C-CERAMIC,MLC-AXIAL 100nF,80-20%,50V,Y5V 1 S.A
C921 2401-003578 C-AL 1000uF,20%,10V,GP,TP,8x20mm,5 1 S.A
C922 2401-003036 C-AL 100uF,20%,16V,GP,TP,5X11mm,5mm 1 S.A
C924 2202-002037 C-CERAMIC,MLC-AXIAL 100nF,80-20%,50V,Y5V 1 S.A
C925 2401-000050 C-AL 10uF,20%,16V,GP,TP,5x11,2.5 1 S.A
C926 2202-002037 C-CERAMIC,MLC-AXIAL 100nF,80-20%,50V,Y5V 1 S.A
C927 2401-003036 C-AL 100uF,20%,16V,GP,TP,5X11mm,5mm 1 S.A
C928 2301-000383 C-FILM,LEAD-PEF 10nF,5%,50V,TP,6x7x3.2mm 1 S.A
C929 2301-000301 C-FILM,LEAD-PEF 6.8nF,5%,50V,TP,6.5X5.5X 1 S.A
C930 2401-000553 C-AL 1uF,10%,50V,GP,TP,5x11,5 1 S.A
C931 2202-002037 C-CERAMIC,MLC-AXIAL 100nF,80-20%,50V,Y5V 1 S.A
CIS1 0205-001154 OIL-SILICON G746,-,- 0.1 S.N.A
CIS1 0205-001154 OIL-SILICON G746,-,- 0.1 S.N.A
CIS1 0205-001154 OIL-SILICON G746,-,- 0.1 S.N.A
CIS1 0205-001154 OIL-SILICON G746,-,- 0.1 S.N.A
CIS1 0205-001154 OIL-SILICON G746,-,- 0.1 S.N.A
CIS1 0205-001154 OIL-SILICON G746,-,- 0.2 S.N.A
CIS1 0205-001154 OIL-SILICON G746,-,- 0.2 S.N.A
CIS3 AA40-00016A TUNER-F/S TDQ-6F/13F2S,NTSC,181CH,45.75M 1 S.A
CN601 3711-003043 HEADER-BOARD TO CABLE BOX,4P,1R,2.5MM,ST 1 S.A
CN602 3711-002644 HEADER-BOARD TO CABLE BOX,5P,1R,2.5mm,ST 1 S.A
CN701 3711-002647 HEADER-BOARD TO CABLE BOX,8P,1R,2.5mm,ST 1 S.A
CN901 3711-000999 HEADER-BOARD TO CABLE BOX,5P,1R,2.5mm,ST 1 S.A
CN902 3711-003043 HEADER-BOARD TO CABLE BOX,4P,1R,2.5MM,ST 1 S.A
CN909 AA37-00001A CONNECTOR-FBT FIX PIN JM-3500,CPTTV,0.36 1 S.A
CN909 AA37-00001A CONNECTOR-FBT FIX PIN JM-3500,CPTTV,0.36 1 S.A
CR402S 2306-000350 C-FILM,LEAD-PPF 270NF,5%,400V,BK,26X18.5 1 S.A
CR404S 2201-000639 C-CERAMIC,DISC 0.68NF,10%,2KV,Y5P,TP,9X5 1 S.A
CR405S 2305-000382 C-FILM,LEAD-PEF 4.7nF,5%,400V,TP,-,5mm 1 S.A
CR409S 2201-000229 C-CERAMIC,DISC 0.15NF,10%,2KV,Y5P,TP,6.3 1 S.A
CR410A 2301-001268 C-FILM,LEAD-PPF 33nF,5%,630V,TP,20x11x17 1 S.A
CR411S 2303-001015 C-FILM,LEAD-PPF 5.5NF,5%,1.6KV,BK,29X9.5 1 S.A
CV113 2202-000127 C-CERAMIC,MLC-AXIAL 10nF,+80-20%,25V,Y5V 1 S.A
CV114 2202-000127 C-CERAMIC,MLC-AXIAL 10nF,+80-20%,25V,Y5V 1 S.A
CX801S 2306-000318 C-FILM,LEAD-PPF 220nF,20%,275V,BK,26x7x1 1 S.A
CY802S 2201-000446 C-CERAMIC,DISC 3.3NF,20%,400V,Y5U,BK,15X 1 S.A
D101 0401-000005 DIODE-SWITCHING 1N4148,75V,150mA,DO-35,T 1 S.A
D201 0401-000005 DIODE-SWITCHING 1N4148,75V,150mA,DO-35,T 1 S.A

5-3Samsung Electronics

Electrical Part List

Loc. No. Code No. Description Specification Q'ty SA/SNA Remark

D301 0402-000546 DIODE-RECTIFIER TVR10G,400V,1.0A,DO-41,T 1 S.A
D302 0402-001352 DIODE-RECTIFIER GUF15G-20A,400V,1.5A,MEL 1 S.A
D303 0402-000132 DIODE-RECTIFIER 1N4004,400V,1A,DO-41,TP 1 S.A
D304 0402-000546 DIODE-RECTIFIER TVR10G,400V,1.0A,DO-41,T 1 S.A
D305 0401-000005 DIODE-SWITCHING 1N4148,75V,150mA,DO-35,T 1 S.A
D306 0401-000005 DIODE-SWITCHING 1N4148,75V,150mA,DO-35,T 1 S.A
D401 0402-000537 DIODE-RECTIFIER RH1A,600V,0.6A,DO-204AC 1 S.A
D402 0402-001599 DIODE-RECTIFIER DGP30L,1500,3A,DO-201AD( 1 S.A
D403 0402-000540 DIODE-RECTIFIER RU20A,600V,1.5A,-,TP 1 S.A
D409 0401-000005 DIODE-SWITCHING 1N4148,75V,150mA,DO-35,T 1 S.A
D501 0401-000006 DIODE-SWITCHING BAV21,250V,200MA,DO-35,T 1 S.A
D502 0401-000006 DIODE-SWITCHING BAV21,250V,200MA,DO-35,T 1 S.A
D503 0401-000006 DIODE-SWITCHING BAV21,250V,200MA,DO-35,T 1 S.A
D504 0402-000546 DIODE-RECTIFIER TVR10G,400V,1.0A,DO-41,T 1 S.A
D510 0401-000005 DIODE-SWITCHING 1N4148,75V,150mA,DO-35,T 1 S.A
D511 0401-000005 DIODE-SWITCHING 1N4148,75V,150mA,DO-35,T 1 S.A
D512 0401-000005 DIODE-SWITCHING 1N4148,75V,150mA,DO-35,T 1 S.A
D513 0401-000005 DIODE-SWITCHING 1N4148,75V,150mA,DO-35,T 1 S.A
D606 0401-000005 DIODE-SWITCHING 1N4148,75V,150mA,DO-35,T 1 S.A
D630 0401-000005 DIODE-SWITCHING 1N4148,75V,150mA,DO-35,T 1 S.A
D631 0401-000005 DIODE-SWITCHING 1N4148,75V,150mA,DO-35,T 1 S.A
D801 0401-000006 DIODE-SWITCHING BAV21,250V,200MA,DO-35,T 1 S.A
D801S 0402-001477 DIODE-BRIDGE GSIB460,600V,4A,SIP-4,ST 1 S.A
D803 0402-000546 DIODE-RECTIFIER TVR10G,400V,1.0A,DO-41,T 1 S.A
D804 0401-000006 DIODE-SWITCHING BAV21,250V,200MA,DO-35,T 1 S.A
D805A 0402-001603 DIODE-RECTIFIER MUR480E,800V,4A,DO-201AD 1 S.A
D806 0402-000493 DIODE-RECTIFIER 1R5GU41,400V,1.5A,DO-15L 1 S.A
D807 AA96-00243D ASSY HEAT SINK P D06U20S,AA62-00045B,BRI 1 S.N.A
D809 0402-000132 DIODE-RECTIFIER 1N4004,400V,1A,DO-41,TP 1 S.A
D811 0402-000132 DIODE-RECTIFIER 1N4004,400V,1A,DO-41,TP 1 S.A
D812 0402-000493 DIODE-RECTIFIER 1R5GU41,400V,1.5A,DO-15L 1 S.A
D816 0402-000493 DIODE-RECTIFIER 1R5GU41,400V,1.5A,DO-15L 1 S.A
DZ242 0403-001318 DIODE-ZENER MTZJ4.3B,4.17-4.43V,500MW,DO 1 S.A
DZ301 0403-001328 DIODE-ZENER MTZJ22A,20.15-21.2V,500MW,DO 1 S.A
DZ302 0403-001221 DIODE-ZENER UZ39BSB,35.36-37.19V,500MW,D 1 S.A
DZ303 0403-000700 DIODE-ZENER TZP33A,5%,1000MW,DO-41,TP 1 S.A
DZ304 0403-000753 DIODE-ZENER MTZJ27D,26.2-27.6V,500MW,DO- 1 S.A
DZ305 0403-001328 DIODE-ZENER MTZJ22A,20.15-21.2V,500MW,DO 1 S.A
DZ402 0403-000508 DIODE-ZENER MTZJ5.6B,5.45-5.73V,500MW,DO 1 S.A
DZ501 0403-000720 DIODE-ZENER MTZJ9.1B,8.57-9.01V,500MW,DO 1 S.A
DZ502 0403-000720 DIODE-ZENER MTZJ9.1B,8.57-9.01V,500MW,DO 1 S.A
DZ503 0403-000720 DIODE-ZENER MTZJ9.1B,8.57-9.01V,500MW,DO 1 S.A
DZ510 0403-000717 DIODE-ZENER MTZJ5.1B,4.94-5.2V,500mW,DO- 1 S.A
DZ605 0403-000714 DIODE-ZENER MTZJ3.3B,3.32-3.53V,500MW,DO 1 S.A
DZ701 0403-000720 DIODE-ZENER MTZJ9.1B,8.57-9.01V,500MW,DO 1 S.A
DZ702 0403-000720 DIODE-ZENER MTZJ9.1B,8.57-9.01V,500MW,DO 1 S.A
DZ703 0403-000720 DIODE-ZENER MTZJ9.1B,8.57-9.01V,500MW,DO 1 S.A
DZ704 0403-000720 DIODE-ZENER MTZJ9.1B,8.57-9.01V,500MW,DO 1 S.A
DZ705 0403-000720 DIODE-ZENER MTZJ9.1B,8.57-9.01V,500MW,DO 1 S.A
DZ707 0403-000720 DIODE-ZENER MTZJ9.1B,8.57-9.01V,500MW,DO 1 S.A
DZ708 0403-000720 DIODE-ZENER MTZJ9.1B,8.57-9.01V,500MW,DO 1 S.A
DZ712 0403-000720 DIODE-ZENER MTZJ9.1B,8.57-9.01V,500MW,DO 1 S.A
DZ713 0403-000720 DIODE-ZENER MTZJ9.1B,8.57-9.01V,500MW,DO 1 S.A
DZ714 0403-000720 DIODE-ZENER MTZJ9.1B,8.57-9.01V,500MW,DO 1 S.A
DZ801 0403-000508 DIODE-ZENER MTZJ5.6B,5.45-5.73V,500MW,DO 1 S.A
DZ802 0403-000717 DIODE-ZENER MTZJ5.1B,4.94-5.2V,500mW,DO- 1 S.A
DZ804 0403-000508 DIODE-ZENER MTZJ5.6B,5.45-5.73V,500MW,DO 1 S.A
DZ806 0403-000714 DIODE-ZENER MTZJ3.3B,3.32-3.53V,500MW,DO 1 S.A
DZ807 0403-000718 DIODE-ZENER MTZJ6.8B,6.52-6.79V,500mW,DO 1 S.A
DZ808 0403-000508 DIODE-ZENER MTZJ5.6B,5.45-5.73V,500MW,DO 1 S.A
DZ811 0403-000700 DIODE-ZENER TZP33A,5%,1000MW,DO-41,TP 1 S.A
DZ812 0403-000700 DIODE-ZENER TZP33A,5%,1000MW,DO-41,TP 1 S.A
DZ813 0403-000720 DIODE-ZENER MTZJ9.1B,8.57-9.01V,500MW,DO 1 S.A
DZ814 0403-001320 DIODE-ZENER MTZJ6.2C,6.16-6.4V,500MW,DO- 1 S.A
DZ815 0403-001321 DIODE-ZENER MTZJ6.8C,6.7-6.97V,500MW,DO- 1 S.A
DZ816 0401-000005 DIODE-SWITCHING 1N4148,75V,150mA,DO-35,T 1 S.A
DZ818 0403-000720 DIODE-ZENER MTZJ9.1B,8.57-9.01V,500MW,DO 1 S.A
DZ901 0403-000719 DIODE-ZENER MTZJ7.5B,7.11-7.44V,500MW,DO 1 S.A
DZ902 0403-000719 DIODE-ZENER MTZJ7.5B,7.11-7.44V,500MW,DO 1 S.A
DZ903 0403-000508 DIODE-ZENER MTZJ5.6B,5.45-5.73V,500MW,DO 1 S.A
DZ904 0403-000508 DIODE-ZENER MTZJ5.6B,5.45-5.73V,500MW,DO 1 S.A
DZ905 0403-001317 DIODE-ZENER MTZJ3.0B,3.01-3.22V,500MW,DO 1 S.A
EL403 6042-000001 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 1 S.N.A
EL501 6042-000001 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 1 S.N.A
EL502 6042-000001 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 1 S.N.A
EL802 6042-000001 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 1 S.N.A
EL803 6042-000001 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 1 S.N.A

Samsung Electronics5-4

Electrical Part List

Loc. No. Code No. Description Specification Q'ty SA/SNA Remark

EL804 6042-000001 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 1 S.N.A
EL808 6042-000001 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 1 S.N.A
EL809 6042-000001 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 1 S.N.A
EY401 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY403 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY404 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY405 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY406 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY407 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY408 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY409 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY410 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY411 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY412 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY414 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY415 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY416 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY417 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY419 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY420 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY421 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY422 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY423 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY428 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY429 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY430 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY600 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY601 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY602 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY603 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY800 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY801 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY820 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY821 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY823 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY825 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY826 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY827 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY828 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY829 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY831 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY832 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY833 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY834 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY835 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY836 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY837 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY854 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY855 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY856 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY857 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY858 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY859 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY860 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY861 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY862 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY863 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY872 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY873 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY874 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY875 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY876 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY878 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY880 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY881 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY887 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY890 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY896 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY898 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY899 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY901 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY902 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY903 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
EY904 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 1 S.N.A
F101 2901-000297 FILTER-EMI ON BOARD -,3A,-,-,3.5x5,TP,- 1 S.A
F101 2901-000297 FILTER-EMI ON BOARD -,3A,-,-,3.5x5,TP,- 1 S.A
F801A 3602-000114 FUSE-HOLDER -,-,30mohm 1 S.A

5-5Samsung Electronics

Electrical Part List

Loc. No. Code No. Description Specification Q'ty SA/SNA Remark

F801B 3602-000114 FUSE-HOLDER -,-,30mohm 1 S.A
FD801S 3601-001086 FUSE-AXIAL LEAD 125V,5A,FAST-ACTING,GLAS 1 S.A
FD802 3601-000281 FUSE-CARTRIDGE 250V,4A,TIME-LAG,GLASS,5. 1 S.A
FD803S 3601-001163 FUSE-AXIAL LEAD 125V,7A,-,EPOXY,2.4X7.1M 1 S.A
GT101 BH71-40300A PIN-HINGE BRASS,D2.36!,HEAT/SINK,SN 1 S.N.A
GT102 BH71-40300A PIN-HINGE BRASS,D2.36!,HEAT/SINK,SN 1 S.N.A
GT104 BH71-40300A PIN-HINGE BRASS,D2.36!,HEAT/SINK,SN 1 S.N.A
GT301 AA60-40012F PIN-GT 4P,2.36PI,6/12/14mm,NYLON66,LOCKI 1 S.N.A
GT401 BH71-40300A PIN-HINGE BRASS,D2.36!,HEAT/SINK,SN 1 S.N.A
GT402 BH71-40300A PIN-HINGE BRASS,D2.36!,HEAT/SINK,SN 1 S.N.A
GT501 BH71-40300A PIN-HINGE BRASS,D2.36!,HEAT/SINK,SN 1 S.N.A
GT502 BH71-40300A PIN-HINGE BRASS,D2.36!,HEAT/SINK,SN 1 S.N.A
GT503 BH71-40300A PIN-HINGE BRASS,D2.36!,HEAT/SINK,SN 1 S.N.A
GT504 BH71-40300A PIN-HINGE BRASS,D2.36!,HEAT/SINK,SN 1 S.N.A
GT801 AA60-40012G PIN-GT 3P,2.36PI,10/5mm,NYLON66,LOCKING 1 S.N.A
GT804 BH71-40300A PIN-HINGE BRASS,D2.36!,HEAT/SINK,SN 1 S.N.A
GT805 BH71-40300A PIN-HINGE BRASS,D2.36!,HEAT/SINK,SN 1 S.N.A
GT806 BH71-40300A PIN-HINGE BRASS,D2.36!,HEAT/SINK,SN 1 S.N.A
IC012 1203-001217 IC-POSI.ADJUST REG. 431,TO-92,3P,4.58MIL 1 S.A
IC063 AA13-00116A IC HYBRID STR-W6750F,6,-20 to +115,TO-3P 1 S.A
IC112 1103-001211 IC-EEPROM 24C16,2Kx8Bit,DIP,8P,10.16x7.1 1 S.A
IC301 AA96-00244M ASSY HEAT SINK P LA78040N,S,AA64-00046 1 S.N.A
IC501 AA96-50311P ASSY HEAT SINK P AA62-30175D,TDA6108AJF, 1 S.N.A
IC601 AA96-02124B ASSY HEAT SINK P AA62-30182G,SCREW,TDA72 1 S.N.A
IC801S AA96-50373P ASSY HEAT SINK P AA62-30181K,STR-W6750F, 1 S.N.A
IC802 AA96-00243Q ASSY H/S SCREW,AA62-00045A,1203-001944,O 1 S.N.A
IC803 AA96-00243R ASSY HEAT SINK P AA62-00045A,KA78R08,TVD 1 S.N.A
IC804 AA96-00243K ASSY HEAT SINK P -,REGULATOR,AA62-000450 1 S.N.A
J293 2001-001078 R-CARBON(S) 15KOHM,5%,1/2W,AA,TP,2.4X6.4 1 S.A
J304 2001-000734 R-CARBON 4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
J812 2004-001390 R-METAL(S) 1Kohm,2%,1/2W,AA,TP,2.4x6.4mm 1 S.A
JA701A 3722-001333 JACK-PIN 9P,3.2mm,NI,BLK,- 1 S.A
JA702 3722-001423 JACK-PIN 3P+S1P,3.4mm,NI,BLK,- 1 S.A
JP104 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
JP105 2001-000005 R-CARBON 390ohm,5%,1/8W,AA,TP,1.8x3.2mm 1 S.A
L101 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
L102 2701-000114 INDUCTOR-AXIAL 10UH,10%,2534 1 S.A
L103 2701-000114 INDUCTOR-AXIAL 10UH,10%,2534 1 S.A
L106 2701-000114 INDUCTOR-AXIAL 10UH,10%,2534 1 S.A
L107 2701-000159 INDUCTOR-AXIAL 22UH,10%,4298 1 S.A
L108 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
L201 2701-000114 INDUCTOR-AXIAL 10UH,10%,2534 1 S.A
L202 2001-000793 R-CARBON 47OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
L204 2701-000114 INDUCTOR-AXIAL 10UH,10%,2534 1 S.A
L2514 3301-000287 BEAD-AXIAL ,3.5x1.0x6.0mm,3000mA,TP,,,50 1 S.N.A
L2514 3301-000287 BEAD-AXIAL ,3.5x1.0x6.0mm,3000mA,TP,,,50 1 S.N.A
L2514 3301-000287 BEAD-AXIAL ,3.5x1.0x6.0mm,3000mA,TP,,,50 1 S.N.A
L2514 3301-000287 BEAD-AXIAL ,3.5x1.0x6.0mm,3000mA,TP,,,50 1 S.N.A
L2514 3301-000287 BEAD-AXIAL ,3.5x1.0x6.0mm,3000mA,TP,,,50 1 S.N.A
L2514 3301-000287 BEAD-AXIAL ,3.5x1.0x6.0mm,3000mA,TP,,,50 1 S.N.A
L2514 3301-000287 BEAD-AXIAL ,3.5x1.0x6.0mm,3000mA,TP,,,50 1 S.N.A
L404 2701-000142 INDUCTOR-AXIAL 1UH,10%,2534 1 S.A
L405 2701-000116 INDUCTOR-AXIAL 10UH,10%,4298 1 S.A
L503A 2702-001092 INDUCTOR-RADIAL 2.2uH,10%,4x6mm 1 S.A
L605 2701-000177 INDUCTOR-AXIAL 33UH,10%,2534 1 S.A
L606 2701-000177 INDUCTOR-AXIAL 33UH,10%,2534 1 S.A
L607 2701-000177 INDUCTOR-AXIAL 33UH,10%,2534 1 S.A
L608 2701-000177 INDUCTOR-AXIAL 33UH,10%,2534 1 S.A
L702 2701-000142 INDUCTOR-AXIAL 1UH,10%,2534 1 S.A
L704 2701-000142 INDUCTOR-AXIAL 1UH,10%,2534 1 S.A
L705 2701-000177 INDUCTOR-AXIAL 33UH,10%,2534 1 S.A
L706 2701-000177 INDUCTOR-AXIAL 33UH,10%,2534 1 S.A
L707 2701-000142 INDUCTOR-AXIAL 1UH,10%,2534 1 S.A
L708 2701-000142 INDUCTOR-AXIAL 1UH,10%,2534 1 S.A
L709 2701-000142 INDUCTOR-AXIAL 1UH,10%,2534 1 S.A
L710 2701-000142 INDUCTOR-AXIAL 1UH,10%,2534 1 S.A
L804 2701-001032 INDUCTOR-AXIAL 100UH,10%,4514 1 S.A
L902 2701-000114 INDUCTOR-AXIAL 10UH,10%,2534 1 S.A
L903 2701-000114 INDUCTOR-AXIAL 10UH,10%,2534 1 S.A
L906 2701-000114 INDUCTOR-AXIAL 10UH,10%,2534 1 S.A
L907 2701-000114 INDUCTOR-AXIAL 10UH,10%,2534 1 S.A
L908 2701-000114 INDUCTOR-AXIAL 10UH,10%,2534 1 S.A
L909 2701-000114 INDUCTOR-AXIAL 10UH,10%,2534 1 S.A
L910 2701-000114 INDUCTOR-AXIAL 10UH,10%,2534 1 S.A
L911 2701-000114 INDUCTOR-AXIAL 10UH,10%,2534 1 S.A
LX801S AA29-30002N FILTER LINE NOISE -,16MH,1.5A,AC100~260V 1 S.A
M0014 AA97-16239A ASSY AUTO-MAIN CL21M2MQ2X/XAX,K16A,RHUMB 1 S.N.A

Samsung Electronics5-6

Electrical Part List

Loc. No. Code No. Description Specification Q'ty SA/SNA Remark

M0018 AA97-16124A ASSY MICOM ,K16A,RHUMBA,TDA12005PQ,T-RHM 1 S.A
M0081 6003-000335 SCREW-TAPTITE RH,+,2S,M3,L8,ZPC(YEL),SWR 1 S.N.A
M0081 6003-000335 SCREW-TAPTITE RH,+,2S,M3,L8,ZPC(YEL),SWR 1 S.N.A
M0081 6003-000335 SCREW-TAPTITE RH,+,2S,M3,L8,ZPC(YEL),SWR 1 S.N.A
M0081 6003-000333 SCREW-TAPTITE RH,+,2S,M3,L10,ZPC(YEL),SW 1 S.N.A
M0081 6003-000335 SCREW-TAPTITE RH,+,2S,M3,L8,ZPC(YEL),SWR 1 S.N.A
M0081 6003-000333 SCREW-TAPTITE RH,+,2S,M3,L10,ZPC(YEL),SW 1 S.N.A
M0081 6003-000334 SCREW-TAPTITE RH,+,2S,M3,L6,ZPC(YEL),SWR 1 S.N.A
M0081 6003-000333 SCREW-TAPTITE RH,+,2S,M3,L10,ZPC(YEL),SW 1 S.N.A
P803T 1404-001265 THERMISTOR-PTC 4.5OHM/100OHM,+30/-20%,22 1 S.A
PC801S 0604-001032 PHOTO-COUPLER TR,170-260%,300mW,DIP-4,ST 1 S.A
Q207 0501-000283 TR-SMALL SIGNAL KSA539,PNP,400mW,TO-92,T 1 S.A
Q261 0501-000283 TR-SMALL SIGNAL KSA539,PNP,400mW,TO-92,T 1 S.A
Q262 0501-000389 TR-SMALL SIGNAL KSC815,NPN,400mW,TO-92,T 1 S.A
Q401 0502-001255 TR-POWER ST2001HI(028Y),NPN,55000mW,-,ST 1 S.A
Q402 0501-000369 TR-SMALL SIGNAL KSC2331-Y,NPN,1000mW,TO- 1 S.A
Q501 0501-000389 TR-SMALL SIGNAL KSC815,NPN,400mW,TO-92,T 1 S.A
Q502 0501-000389 TR-SMALL SIGNAL KSC815,NPN,400mW,TO-92,T 1 S.A
Q805 0501-000389 TR-SMALL SIGNAL KSC815,NPN,400mW,TO-92,T 1 S.A
Q806 0501-000389 TR-SMALL SIGNAL KSC815,NPN,400mW,TO-92,T 1 S.A
Q902 0501-000389 TR-SMALL SIGNAL KSC815,NPN,400mW,TO-92,T 1 S.A
Q903 0501-000283 TR-SMALL SIGNAL KSA539,PNP,400mW,TO-92,T 1 S.A
Q904 0501-000283 TR-SMALL SIGNAL KSA539,PNP,400mW,TO-92,T 1 S.A
Q905 0501-000389 TR-SMALL SIGNAL KSC815,NPN,400mW,TO-92,T 1 S.A
R105 2001-000331 R-CARBON 12KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R106 2001-000947 R-CARBON 7.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R109 2001-000786 R-CARBON 47KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R113 2001-000645 R-CARBON 330KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R114 2001-000319 R-CARBON 120KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R123 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R124 2001-000515 R-CARBON 220OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R163 2001-000577 R-CARBON 2KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R167 2001-000924 R-CARBON 680OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R169 2004-001914 R-METAL 39Kohm,2%,1/8W,AA,TP,1.8x3.5mm 1 S.A
R208 2001-000302 R-CARBON 10OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R210 2001-000563 R-CARBON 27KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R211 2001-000857 R-CARBON 560OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R213 2001-000908 R-CARBON 62KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R215 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R216 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R217 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R218 2001-000290 R-CARBON 10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R262 2001-000429 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R263 2001-000429 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R301 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R302 2004-001970 R-METAL(S) 1.8Kohm,1%,1/2W,AA,TP,6.5x2.5 1 S.A
R303 2003-002279 R-METAL OXIDE(S) 1.2OHM,5%,2W,AG,TP,5.6X 1 S.A
R304 2008-000264 R-FUSIBLE(S) 1ohm,5%,1W,AF,TP,3.9x10mm 1 S.A
R305 2008-001159 R-FUSIBLE(S) 1.5OHM,5%,1W,AF,TP,3.9X10MM 1 S.A
R306 2004-004097 R-METAL 1.6Kohm,2%,1/2W,AA,TP,2.4X6.4mm 1 S.A
R307 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R310 2001-000016 R-CARBON(S) 1OHM,5%,1/2W,AA,TP,2.4X6.4MM 1 S.A
R312 2001-000290 R-CARBON 10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R315 2003-001032 R-METAL OXIDE(S) 220ohm,5%,1W,AF,TP,2.5x 1 S.A
R316 2003-001032 R-METAL OXIDE(S) 220ohm,5%,1W,AF,TP,2.5x 1 S.A
R317 2001-000290 R-CARBON 10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R318 2001-000734 R-CARBON 4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R401 2003-002288 R-METAL OXIDE(S) 2.2KOHM,5%,2W,AF,TP,3.9 1 S.A
R403 2003-002151 R-METAL OXIDE 18KOHM,5%,2W,AG,TP,6X16MM 1 S.A
R405 2001-001116 R-CARBON(S) 27OHM,5%,1/2W,AA,TP,2.4X6.4M 1 S.A
R406 2008-000264 R-FUSIBLE(S) 1ohm,5%,1W,AF,TP,3.9x10mm 1 S.A
R407 2001-001078 R-CARBON(S) 15KOHM,5%,1/2W,AA,TP,2.4X6.4 1 S.A
R409 2001-000022 R-CARBON(S) 33OHM,5%,1/2W,AA,TP,2.4X6.4M 1 S.A
R411 2001-001114 R-CARBON(S) 270OHM,5%,1/2W,AA,TP,2.4X6.4 1 S.A
R414 2001-001078 R-CARBON(S) 15KOHM,5%,1/2W,AA,TP,2.4X6.4 1 S.A
R421 2008-001137 R-FUSIBLE(S) 3.3ohm,5%,1W,AF,TP,3.9x10mm 1 S.A
R422 2001-000331 R-CARBON 12KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R423 2004-001408 R-METAL(S) 91Kohm,1%,1/2W,AA,TP,2.4x6.4m 1 S.A
R424 2001-000548 R-CARBON 270KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R425 2004-000433 R-METAL 1Kohm,1%,1/8W,AA,TP,1.8x3.2mm 1 S.A
R427 2001-000786 R-CARBON 47KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R428 2001-000258 R-CARBON 1.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R429 2001-000563 R-CARBON 27KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R430 2004-001402 R-METAL(S) 6.8Kohm,1%,1/2W,AA,TP,2.4x6.4 1 S.A
R501 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R501H 2002-001017 R-COMPOSITION 1Kohm,10%,1/2W,AA,TP,3.7x9 1 S.A
R502H 2002-001017 R-COMPOSITION 1Kohm,10%,1/2W,AA,TP,3.7x9 1 S.A

5-7Samsung Electronics

Electrical Part List

Loc. No. Code No. Description Specification Q'ty SA/SNA Remark

R504 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R505 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R511 2002-001017 R-COMPOSITION 1Kohm,10%,1/2W,AA,TP,3.7x9 1 S.A
R514 2001-001062 R-CARBON(S) 10MOHM,5%,1/2W,AA,TP,2.4X6.4 1 S.A
R516 2008-000204 R-FUSIBLE(S) 0.22ohm,10%,1/2W,AF,TP,2.5x 1 S.A
R520 2001-000734 R-CARBON 4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R521 2001-000679 R-CARBON 36KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R522 2001-000734 R-CARBON 4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R523 2001-000734 R-CARBON 4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R551 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R603 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R606 2001-000837 R-CARBON 51KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R607 2001-000241 R-CARBON 1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R608 2001-000241 R-CARBON 1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R609 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R610 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R620 2001-000290 R-CARBON 10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R621 2001-000241 R-CARBON 1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R622 2001-000241 R-CARBON 1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R623 2001-000290 R-CARBON 10KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R701 2001-000969 R-CARBON 75OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R702 2001-000969 R-CARBON 75OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R703 2001-000969 R-CARBON 75OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R704 2001-000969 R-CARBON 75OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R705 2001-000969 R-CARBON 75OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R706 2001-000812 R-CARBON 5.6KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R707 2001-000812 R-CARBON 5.6KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R708 2001-000812 R-CARBON 5.6KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R709 2001-000812 R-CARBON 5.6KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R710 2001-000969 R-CARBON 75OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R711 2001-000969 R-CARBON 75OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R712 2001-000969 R-CARBON 75OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R719 2001-000812 R-CARBON 5.6KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R720 2001-000812 R-CARBON 5.6KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R721 2001-000812 R-CARBON 5.6KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R722 2001-000812 R-CARBON 5.6KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R726 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R727 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R728 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R729 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R730 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R802 2003-000586 R-METAL OXIDE(S) 22Kohm,5%,2W,AF,TP,4x12 1 S.A
R803 2003-000586 R-METAL OXIDE(S) 22Kohm,5%,2W,AF,TP,4x12 1 S.A
R804 2003-000586 R-METAL OXIDE(S) 22Kohm,5%,2W,AF,TP,4x12 1 S.A
R805 2001-001088 R-CARBON(S) 1KOHM,5%,1/2W,AA,TP,2.4X6.4M 1 S.A
R806 2001-000037 R-CARBON(S) 330OHM,5%,1/2W,AA,TP,2.4X6.4 1 S.A
R808 2001-001150 R-CARBON(S) 470KOHM,5%,1/2W,AA,TP,2.4X6. 1 S.A
R809 2001-001150 R-CARBON(S) 470KOHM,5%,1/2W,AA,TP,2.4X6. 1 S.A
R810 2001-001097 R-CARBON(S) 2.4KOHM,5%,1/2W,AA,TP,2.4X6. 1 S.A
R811 2003-000713 R-METAL OXIDE(S) 47ohm,5%,2W,AF,TP,4x12m 1 S.A
R812 2003-000713 R-METAL OXIDE(S) 47ohm,5%,2W,AF,TP,4x12m 1 S.A
R814 2005-001171 R-WIRE WOUND 0.22ohm,5%,1W,AA,TP,3.3x9mm 1 S.A
R815 2008-000266 R-FUSIBLE(S) 1ohm,5%,2W,AF,TP,3.9x10mm 1 S.A
R816 2004-001891 R-METAL(S) 133Kohm,1%,1/2W,AA,TP,2.5x6.5 1 S.A
R817 2001-001088 R-CARBON(S) 1KOHM,5%,1/2W,AA,TP,2.4X6.4M 1 S.A
R818 2001-001131 R-CARBON(S) 33KOHM,5%,1/2W,AA,TP,2.4X6.4 1 S.A
R819 2004-001983 R-METAL(S) 2.49Kohm,1%,1/2W,AA,TP,2.4x6. 1 S.A
R820 2001-001088 R-CARBON(S) 1KOHM,5%,1/2W,AA,TP,2.4X6.4M 1 S.A
R821 2003-002020 R-METAL OXIDE(S) 56Kohm,5%,2W,AF,TP,3.9x 1 S.A
R822 2001-000003 R-CARBON 330ohm,5%,1/8W,AA,TP,1.8x3.2mm 1 S.A
R823 2001-001070 R-CARBON(S) 120OHM,5%,1/2W,AA,TP,2.4X6.4 1 S.A
R824 2003-002064 R-METAL OXIDE(S) 7.5OHM,5%,2W,AF,TP,3.9X 1 S.A
R825 2003-002064 R-METAL OXIDE(S) 7.5OHM,5%,2W,AF,TP,3.9X 1 S.A
R826 2001-001077 R-CARBON(S) 150OHM,5%,1/2W,AA,TP,2.4X6.4 1 S.A
R827 2001-001077 R-CARBON(S) 150OHM,5%,1/2W,AA,TP,2.4X6.4 1 S.A
R829 2001-001078 R-CARBON(S) 15KOHM,5%,1/2W,AA,TP,2.4X6.4 1 S.A
R830 2003-002020 R-METAL OXIDE(S) 56Kohm,5%,2W,AF,TP,3.9x 1 S.A
R831 2004-004089 R-METAL(S) 123Kohm,1%,1/2W,AA,TP,2.5x6.5 1 S.A
R833 2001-000734 R-CARBON 4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R836 2008-001011 R-FUSIBLE(S) 0.18ohm,10%,2W,AF,TP,3.9x10 1 S.A
R839 2003-002148 R-METAL OXIDE 3.9OHM,2%,2W,AF,TP,3.9X10M 1 S.A
R840 2003-002148 R-METAL OXIDE 3.9OHM,2%,2W,AF,TP,3.9X10M 1 S.A
R842 2001-000734 R-CARBON 4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R844 2003-002148 R-METAL OXIDE 3.9OHM,2%,2W,AF,TP,3.9X10M 1 S.A
R895 2001-001152 R-CARBON(S) 47KOHM,5%,1/2W,AA,TP,2.4X6.4 1 S.A
R901 2001-000440 R-CARBON 1OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R902 2001-000429 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A

Samsung Electronics5-8

Electrical Part List

Loc. No. Code No. Description Specification Q'ty SA/SNA Remark

R903 2001-000734 R-CARBON 4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R905 2001-000008 R-CARBON 15KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R906 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R908 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R910 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R911 2001-000347 R-CARBON 13KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R912 2001-000347 R-CARBON 13KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R913 2001-000005 R-CARBON 390ohm,5%,1/8W,AA,TP,1.8x3.2mm 1 S.A
R918 2001-000429 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R919 2001-000008 R-CARBON 15KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R920 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R921 2001-000734 R-CARBON 4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R923 2001-000786 R-CARBON 47KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R924 2001-000591 R-CARBON 3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R925 2001-000440 R-CARBON 1OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R926 2001-000591 R-CARBON 3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R927 2001-000302 R-CARBON 10OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R928 2001-000302 R-CARBON 10OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R929 2001-000331 R-CARBON 12KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R930 2001-000007 R-CARBON 3KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R932 2001-000786 R-CARBON 47KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R933 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R934 2001-000924 R-CARBON 680OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R935 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R936 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R939 2001-000522 R-CARBON 22KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
R941 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
RP100 2001-000924 R-CARBON 680OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
RP101 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
RP102 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
RP701 2001-000429 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
RP702 2001-000221 R-CARBON 1.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM 1 S.A
RX801S 2002-000133 R-COMPOSITION 3.3Mohm,5%,1/2W,AA,TP,3.5x 1 S.A
RY801S 2002-001012 R-COMPOSITION 8.2Mohm,5%,1/2W,AA,TP,3.7x 1 S.A
SF101 2904-001107 FILTER-SAW AV 45.75MHz,SIP5K,TP,12.6dB,N 1 S.A
SF102 2904-001418 FILTER-SAW AV 45.75MHZ,-,ST,-,-,- 1 S.A
T0010 AA27-00296A COIL CHOKE 220UH,CPTTV,220UH,10%,3A,DR14 1 S.A
T0066 AA62-30182G HEAT SINK-ES CT-29A20HR,A6063S,T2.0,26.2 1 S.N.A
T0066 AA62-30181V HEAT SINK-ES CT-29M16V,AL6063,T2.0,64,40 1 S.N.A
T0074 1201-002244 IC-VIDEO AMP TDA6108AJF,DBS9MPF,9P,21.8x 1 S.A
T0077 AA41-01155A PCB MAIN CL21M21,FR-1,1,00,T1.6,245X330, 1 S.N.A
T0085 1201-002121 IC-AUDIO AMP TDA7266SA,CLIPWATT,15P,19.8 1 S.A
T0087 1203-001006 IC-POSI.FIXED REG. 78R05,TO-220F,4P,-,PL 1 S.A
T0087 1203-001944 IC-POSI.FIXED REG. 78RM33,TO-220,3P,-,PL 1 S.A
T0087 1203-001697 IC-POSI.FIXED REG. 78R08,TO-220,4P,-,PLA 1 S.A
T0088 1204-002121 IC-VERTICAL DEF. LA78040N,TO220,7P,-,PLA 1 S.A
T0119 AA09-00508A IC MICOM TDA12005PQ/N1FCO-MTP,CL21M21EQ2 1 S.A
T0175 AA62-00045A HEAT SINK-PS -,-,T1.0,-,-,DREAM,-,-,-,-, 1 S.N.A
T0175 AA62-00045A HEAT SINK-PS -,-,T1.0,-,-,DREAM,-,-,-,-, 1 S.N.A
T0175 AA62-00045A HEAT SINK-PS -,-,T1.0,-,-,DREAM,-,-,-,-, 1 S.N.A
T0175 AA62-00045A HEAT SINK-PS -,-,T1.0,-,-,DREAM,-,-,-,-, 1 S.N.A
T0175 AA62-00046A HEAT SINK-PS -,-,T1.0,-,D1(DREAM) 60X25X 1 S.N.A
T0175 AA62-30175D HEAT SINK-PS -,SECC,T1.0,-,33X15X30 FT-2 1 S.N.A
T0245 0202-001366 SOLDER-WIRE FLUX -,RS60S,D1.2,63Sn/37Pb, 0.25 S.N.A
T0245 AA39-20604A LEAD CONNECTOR-ASSY ,UL1007#26,UL/CSA,9/ 1 S.A
T0296 AA27-30003L COIL LINEARITY -,73uH,DR12x15,0.55mm,-,B 1 S.A
T0310 4715-000001 SURGE ABSORBER 1KV,+50-10%,-,-, 1 S.N.A
T0310 4715-000001 SURGE ABSORBER 1KV,+50-10%,-,-, 1 S.N.A
T0310 4715-000001 SURGE ABSORBER 1KV,+50-10%,-,-, 1 S.N.A
T0310 4715-000001 SURGE ABSORBER 1KV,+50-10%,-,-, 1 S.N.A
T0607 AA61-01390A BRACKET-IC CT-29A20HR,SECC,T1.0 1 S.N.A
T0900 1404-001045 THERMISTOR-NTC 4.7ohm,15%,2900K,35.0mW,T 1 S.A
T401 AA26-50001B TRANS-HORIZ.DRIVE -,-,-,7.1mH,-,-,102uH, 1 S.A
T444S AA26-00201A TRANS FBT FCA173B,KS1A-1,3.8mH,FERRITE,1 1 S.A
T801S AA26-00228B TRANS SWITCHING EER4245,CT-29K10G,PL5,PM 1 S.A
V999S 3704-001197 SOCKET-CRT 8P+SEN,29PI,22.5PI,NI+SN,- 1 S.A
VP801 1405-000152 VARISTOR 560V,2500A,14x8.5mm,TP 1 S.A
VX801S 1405-000187 VARISTOR 750V,1250A,12.5x7mm,TP 1 S.A
X201 2801-003316 CRYSTAL-UNIT 24.576MHz,30ppm,28-AAM,20pF 1 S.A

0402-001374 DIODE-RECTIFIER FFPF06U20S,200V,6A,TO-22 1 S.A

ASSY COVER FRONT

M0001 AA90-05387X ASSY COVER FRONT CL21M2MQ2X/XAX 1 S.N.A

M0081 6003-001026 SCREW-TAPTITE RH,+,B,M4,L15,ZPC(BLK),SWR 2 S.N.A

5-9Samsung Electronics

Electrical Part List

Loc. No. Code No. Description Specification Q'ty SA/SNA Remark

M0081 6003-001026 SCREW-TAPTITE RH,+,B,M4,L15,ZPC(BLK),SWR 5 S.N.A
M0081 6003-001268 SCREW-TAPTITE TH,+,B,M4,L12,ZPC(YEL),SWR 1 S.N.A
CCM1 AA60-10050R SCREW-MACHINE -,SWRCH18A,M5,L31.5,HH,+,W 4 S.A
T0081 AA60-10050T SCREW-TAPPING -,SWRCH18A,M4,L20,RH,+,2S, 4 S.N.A
T0003 AA96-02475Y ASSY COVER P-FRONT 21M21,SAMEX,HIPS,HB,G 1 S.A
M0081 6003-001019 SCREW-TAPTITE RH,+,B,M4,L12,ZPC(BLK),SWR 1 S.N.A
M0081 6003-001019 SCREW-TAPTITE RH,+,B,M4,L12,ZPC(BLK),SWR 8 S.N.A
M0081 6003-001019 SCREW-TAPTITE RH,+,B,M4,L12,ZPC(BLK),SWR 1 S.N.A
T0069 AA60-00091G SPACER-FELT -,FELT,200X10,-,-,BLK,T0.5,- 2 S.N.A
T0069 AA60-00091R SPACER-FELT ,FELT,250X10,,,BLK,T0.5,, 1 S.N.A
T0245 AA61-00711D HOLDER-PCB 29U1,U2,HIPS VO,BK502(HB-PROP 2 S.A
CIS7 AA61-60003J SPRING ETC-CS -,SUS304,-,-,OD6,N7,OD6,-, 1 S.N.A
T0578 AA64-03660V INLAY AV RHUMBA,K16A,PS,T0.3,BLK,SHEET,N 1 S.N.A
CIS3 AA64-04048A DECORATION-POWER 29M21,ABS,HB,G3676,AL 1 S.N.A
T0023 AA64-04049A KNOB POWER 29M21,ABS,HB,G3676,SVM3012 1 S.N.A
T0022 AA64-04050E KNOB CONTROL 29M21,ABS,HB,G3676,SVM3012 1 S.N.A
T0592 AA64-04051A WINDOW-CONTROL 29M21,PC,CLEAR 1 S.N.A
T0003 AA64-04079G CABINET FRONT 21M21,SAMEX,HIPS,HB,GR503, 1 S.N.A
T0057 AA64-70123A BADGE-BRAND NEW,AL,L50,FLAT,SILVER,SAMSU 1 S.A
CIS1 AA65-00011C CLAMPER CORE-WIRE ALL MODEL,NYLON 66,V2, 1 S.N.A
CIS1 AA65-30105A CLAMPER CORE-WIRE ALL MODEL,NYLON 66,V2, 2 S.N.A
T0175 AA96-03137A ASSY SPEAKER P 8ohm,6*13cm,15W,900/600mm 1 S.A
T0382 BP61-00509C HOLDER-CARE PJT,ACRYL-FOAM,T0.25,W20.0mm 0.28 S.N.A
T0382 BP61-00495C HOLDER-CARE PJT,ACRYL-FOAM,T0.25,W30.0mm 0.2 S.N.A

ASSY COVER REAR

M0002 AA90-05388C ASSY COVER REAR 21M21,SAMEX,HIPS,HB,GR50 1 S.N.A

T0069 AA60-00091J SPACER-FELT -,FELT,330X10,-,-,BLK,T0.5,- 3 S.N.A
T0066 AA64-03974H INLAY-BACK K16A,PS,SHEET,T0.3,BLK,RCA9P+ 1 S.N.A
T0015 AA64-04086A CABINET BACK 21M21,(SAMEX),HIPS,HB,G4309 1 S.A
T0522 AA65-30008A CLAMPER CORE-CORD -,PE,HB,-,BLK,- 1 S.N.A

ASSY FIXING

T0892 AA91-08458G ASSY FIXING EP2(H/C300MM),KS7A,GOLDRUSH 1 S.N.A

T0245 AA39-20010B LEAD CONNECTOR-ASSY ,1P,500,YFH800-01,S, 1 S.A
T0245 AA39-20010D LEAD CONNECTOR-ASSY ,1P,400,YFH800-01,S, 1 S.A
T0016 AA65-30009A CLAMPER CORE-FBT -,ABS,V0,-,BLK,- 1 S.N.A
CIS1 AA65-30018A CLAMPER CORE-WIRE DONG-A,NYLON-66,-,-,-, 1 S.N.A
CIS1 AA65-30104C CLAMPER CORE-WIRE ALL MODEL,NYLON 66,V2, 1 S.N.A
T0066 AA96-20112A ASSY POWER CORD -,EP2/NO,H/C300,KJ10,THA 1 S.A

T0268 AA39-10006K CBF-POWER CORD -,KJ-10,SPT-2 2/18AWG,240 1 S.A
T0010 AA61-20284A HOLDER P-CORD,PP,-,-,-,BLK,VO,KE-002 1 S.N.A

3811-001609 WIRE-PVC CU BCWA,300V,ROLL,-,#22,BLK 0.15 S.N.A

ASSY CPT

T0521 AA91-09169H ASSY CPT 21 INCH,A51QDX993X(A),,+380MG 1 S.N.A

T0063 AA03-10001B CRT COLOR A51QDX993X(A),380MG,1.75MH,18. 1 S.A
T0079 AA27-00002A MAGNET CONVERGENCE JH291-11D,29.1MM 1 S.A
T0089 AA27-00256A COIL DEGAUSSING ,21IHCH,10%,35TS,4.5OHM, 1 S.A
T0078 AA27-00324A DEFLECTION YOKE ,DIF-2192AA(A),S/T,A51QD 1 S.A
T0299 AA63-60028A SPACER-DY -,NEOPRENE,-,-,-,BLK,-,-,V0 W1 4 S.N.A
T0527 AA65-00009B CLAMPER CORE-D,COIL 21A8,NYLON 66,V0,-,- 4 S.A
T0603 AA98-00125A ASSY TBC WIRE P ,21,NTSC,2P,UL1015#22 1 S.A

ASSY P/MATERIAL

M0113 AA92-10287A ASSY P/MATERIAL 21M21 1 S.N.A

T0376 6902-000001 BAG AIR LDPE,T0.2,L1800,W1000,TRP,,,LDPE 0.007 S.N.A
T0524 6902-000005 BAG PE HDPE/NITRON/HDPE,T0.015/T0.5/T0.0 1 S.N.A
T0376 6902-000061 BAG AIR LDPE,T0.2,L1000,W500,TRP,,, 0.033 S.N.A
T0214 AA60-40006A PIN-STAPLE AUTO,33X17.8X2.4,H18,33X17.8X 6 S.N.A

Samsung Electronics5-10

Electrical Part List

Loc. No. Code No. Description Specification Q'ty SA/SNA Remark

ASSY ACCESSORY

M0045 AA92-11354S ASSY ACCESSORY CL21M2MQ2X/XAX,K16A 1 S.N.A

T0524 6902-000009 BAG PE HDPE,T0.03,L400,W240,TRP,8,2,PE M 1 S.N.A
T0903 AA26-90001F TRANS MATCHING -,300ohm/75ohm,NTSC,40-89 1 S.A
T0116 AA39-40001B CABLE RCA ,3P,1500MM,RED/WHT/YEL,RCA,RCA 1 S.A
T0075 AA42-00003A ANT ROD -,3S,720mm,ABS,UL/CSA,- 1 S.A
T0074 AA59-00316D REMOCON TM75,ET,30,G6148A,NT,EX 1 S.A
T0610 AA68-03242F MANUAL-SAFETY GUIDE All Model,SEC,Eng/Fr 1 S.N.A
T0156 BN68-00797A MANUAL-01,WARRANT CARD SAMEX BASIC ALL,M 1 S.N.A

M0596 AA68-03671D MANUAL USERS-00 COMM,SAMSUNG,ENGLISH,S.A 1 S.N.A
M0596 AA68-03671E MANUAL USERS-00 COMM,SAMSUNG,SPANISH,S.A 1 S.N.A

BP68-00515A MANUAL-REGISTRATION CARD PRC CARD,SAMSUN 1 S.N.A

5-11Samsung Electronics

MEMO

Samsung Electronics5-12
