Samsung C480 User Guide

Samsung Multifunction Xpress

C48x series C48xW series

C48xFN series

C48xFW series

User’s Guide

BASIC

This guide provides information concerning the installation, basic operation and troubleshooting on windows.

ADVANCED

This guide provides information about the installation, advanced configuration, operation and troubleshooting on various OS environments.

Some features may not be available depending on models or countries.

1. Introduction

3. Maintenance

Key benefits 5

Features by model 7

Useful to know 12

About this user’s guide 13

Safety information 14

Machine overview 20

Control panel overview 24

Turning on the machine 29

Installing the driver locally 30

Reinstalling the driver 32

2. Menu Overview and Basic Setup

Menu overview 34 Machine’s basic settings 42

Ordering supplies and accessories 81

Available supplies 82

Available maintenance parts 84

Storing the toner cartridge 85

Redistributing toner 87

Replacing the toner cartridge 90

Replacing the imaging unit 92

Replacing the waste toner container 95

Monitoring the supplies life 98

Setting the toner low alert 99

Cleaning the machine 100

Tips for moving & storing your machine 105

4. Troubleshooting

Media and tray 44 Basic printing 59 Basic copying 65 Basic scanning 69 Basic faxing 71 Using USB memory device 75

Tips for avoiding paper jams 107

Clearing paper jams 108

Understanding the status LED 115

Understanding display messages 117

5. Appendix

Specifications 125

Regulatory information 133

1. Introduction

This chapter provides information you need to know before using the machine.

•Key benefits 5

• Features by model 7

• Useful to know 12

• About this user’s guide 13

• Safety information 14

• Machine overview 20

• Control panel overview 24

• Turning on the machine 28

• Installing the driver locally 29

• Reinstalling the driver 31

Key benefits

Environmentally friendly

• To save toner and paper, this machine supports Eco feature (see "Eco printing" on page 58).

• To save paper, you can print multiple pages on one single sheet of paper (see "Using advanced print features" on page 231).

• To save paper, you can print on both sides of the paper (double-sided printing) (Manual) (see "Using advanced print features" on page 231).

• To save electricity, this machine automatically conserves electricity by substantially reducing power consumption when not in use.

• We recommend using recycled paper for saving energy.

Fast high resolution printing

• You can print in a full range of colors using cyan, magenta, yellow, and black.

• You can print with a resolution of up to 2,400 x 600 dpi effective output (600 x 600 x 2 bit).

• Fast, on-demand printing.

Convenience

• Simply touch your cell phone on the NFC tag on your printer and get the print job done (see "Using the NFC feature" on page 187).

• You can print on the go from your smartphone or computer using Samsung Cloud Print apps (see "Samsung Cloud Print" on page 198).

• You can print on the go from your smartphone or computer using Google Cloud Print enabled apps (see "Google Cloud Print™" on page 201).

• Easy Capture Manager allows you to easily edit and print whatever you captured using the Print Screen key on the keyboard (see "Easy Capture Manager" on page 259).

• Samsung Easy Printer Manager and Printing Status is a program that monitors and informs you of the machine’s status and allows you to customize the machine’s settings (see "Using Samsung Easy Printer Manager" on page 268 or "Using Samsung Printer Status" on page 271).

• Samsung Easy Document Creator is an application to help users compile and share large documents or other scanned or faxed information digitally. (see "Using Samsung Easy Document Creator" on page 270).

• Smart Update allows you to check for the latest software and install the latest version during the printer driver installation process. This is available only for Windows.

• If you have Internet access, you can get help, support application, machine drivers, manuals, and order information from the Samsung website, www.samsung.com > find your product > Support or Downloads.

Key benefits

Wide range of functionality and application support

• Supports various paper sizes (see "Print media specifications" on page 127).

• Print watermark: You can customize your documents with words, such as “CONFIDENTIAL” (see "Using advanced print features" on page 231).

• Print posters: The text and pictures of each page of your document are magnified and printed across the multiple sheets of paper and can then be taped together to form a poster (see "Using advanced print features" on page 231).

• You can print in various operating systems (see "System requirements" on page 130).

• Your machine is equipped with a USB interface and/or a network interface.

Supports various wireless network setting method

• Using the WPS (Wi-Fi Protected Setup™) button

- You can easily connect to a wireless network using the WPS button on

the machine and the access point (a wireless router).

• Using the USB cable or a network cable

- You can connect and set various wireless network settings using a USB cable or a network cable.

• Using the Wi-Fi Direct

- You can conveniently print from your mobile device using the Wi-Fi or Wi-Fi Direct feature.

See "Introducing wireless set up methods" on page 168.

Features by model

Some features and optional goods may not be available depending on model or country.

Operating System

(●: Supported, Blank: Not supported)

Operating System C48x series C48xW series C48xFN series C48xFW series

Windows ● ● ● ●

Mac ● ● ● ●

Linux ● ● ● ●

Features by model

Software

You can install the printer driver and software when you insert the software CD into your CD-ROM drive.

For Windows, select the printer driver and software in the Select Software to Install window.

Software C48x series C48xW series C48xFN series C48xFW series

SPL printer driver ● ● ● ●

PCL printer driver ● ● ● ●

PS printer driver

● ● ● ●

XPS printer driver

● ● ● ●

Samsung Easy Printer Manager

Scan to PC settings

●

● ● ●

Fax to PC settings ● ●

Advanced Setting ● ● ● ●

Samsung Easy Document Creator

● ● ● ●

Samsung Easy Color Manager ● ● ● ●

Samsung Printer Status ● ● ● ●

Samsung Printer Center ● ● ● ●

SyncThru™ Web Service ● ● ●

Samsung Eco Driver Pack

● ● ● ●

Features by model

(●: Supported, Blank: Not supported)

Samsung Stylish Driver Pack

● ● ● ●

SyncThru™ Web Service ● ● ● ●

Fax Samsung Network PC

Fax

● ●

Scan Twain scan driver ● ● ● ●

WIA scan driver ● ● ● ●

a. Download the software from the Samsung website and install it: (http://www.samsung.com > find your product > Support or Downloads). Before installing, check whether your

computer’s OS support the software. b. Some models do not support this feature. If this feature doesn't appear in the menu of Samsung Easy Printer Manager, then this feature is not available on your model. c. To use the Easy Eco Driver features, the Eco Driver Pack must be installed. d. The printer driver includes a user interface that is optimized for touchscreens. To use this UI, click Samsung Printer Center > Device Options and then select Stylish User Interface

(see "Using Samsung Printer Center" on page 262).

Software C48x series C48xW series C48xFN series C48xFW series

Features by model

Variety feature

(●: Supported, Blank: Not supported)

Features C48x series C48xW series C48xFN series C48xFW series

Hi-Speed USB 2.0 ● ● ● ●

Network Interface Ethernet 10/100 Base TX wired LAN

● ● ●

Network Interface 802.11b/g/n wireless LAN

a. Depending on your country, wireless LAN card may not be available. For some countries, only 802.11 b/g can be applied. Contact your local Samsung dealer or the retailer where you

bought your machine.

● ●

NFC (Near Field Communication) ● ●

Mopria™ ● ● ●

Samsung Cloud Print ● ● ●

Google Cloud Print™ ● ● ●

AirPrint ● ● ●

Eco printing (Control panel) ● ● ●

Duplex (2-sided) printing (Manual)

b. Windows only.

● ● ● ●

USB memory interface ● ● ●

Automatic Document Feeder (ADF) ● ●

Features by model

(●: Supported, Blank: Not supported)

Features C48x series C48xW series C48xFN series C48xFW series

Fax Multi-send ● ●

Delay send ● ●

Secure receive ● ●

Send/ Receive forward - fax/ Email

● ●

Scan Scan to PC ● ● ●

Copy ID card copying ● ● ● ●

Reduced or enlarged copying ● ● ● ●

Collation ● ● ● ●

2-up/4-up ● ● ● ●

Adjust background ● ● ● ●

Useful to know

The machine does not print.

• Open the print queue list and remove the document from the list (see "Canceling a print job" on page 55).

• Remove the driver and install it again (see "Installing the driver locally" on page 29).

• Select your machine as your default machine in your Windows (see "Setting your machine as a default machine" on page

230).

Where can I purchase accessories or supplies?

• Inquire at a Samsung distributor or your retailer.

• Visit www.samsung.com/supplies. Select your country/region to view product service information.

A paper jam has occurred.

• Open and close the cover (see "Front view" on page 21).

• Check the instructions on removing jammed paper in this manual and troubleshoot accordingly (see "Clearing paper jams" on page 108).

Printouts are blurry.

• The toner level might be low or uneven. Shake the toner cartridge (see "Redistributing toner" on page 85).

• Try a different print resolution setting (see "Opening printing preferences" on page 56).

• Replace the toner cartridge (see "Replacing the toner cartridge" on page 87).

The status LED flashes or remains constantly on.

• Turn the product off and on again.

• Check the meanings of LED indications in this manual and troubleshoot accordingly (see "Understanding the status LED" on page 115).

Where can I download the machine’s driver?

• You can get help, support application, machine drivers, manuals, and order information from the Samsung website, www.samsung.com > find your product > Support or Downloads.

About this user’s guide

This user's guide provides information for your basic understanding of the machine as well as detailed steps to explain machine usage.

• Do not discard this manual, and keep it for future reference.

• Read the safety information before using the machine.

• If you have a problem using the machine, refer to the troubleshooting chapter.

• Terms used in this user’s guide are explained in the glossary chapter.

• All illustrations in this user’s guide may differ from your machine depending on its options or model you purchased.

• The screenshots in this administrator’s guide may differ from your machine depending on the machine’s firmware/driver version.

• The procedures in this user’s guide are mainly based on Windows 7.

General icons

Icon Text Description

Used to alert users to the possibility of personal injury.

Warning

Gives users information to protect the machine from

Caution

Note

possible mechanical damage or malfunction.

Provides additional information or detailed specification of the machine function and feature.

Conventions

Some terms in this guide are used interchangeably, as below:

• Document is synonymous with original.

• Paper is synonymous with media, or print media.

• Machine refers to printer or MFP.

1. Introduction

Safety information

These warnings and precautions are included to prevent injury to you and others, and to prevent any potential damage to your machine. Be sure to read and understand all of these instructions before using the machine. After reading this section, keep it in a safe place for future reference.

Important safety symbols

Explanation of all icons and signs used in this chapter

Warning

Caution

Hazards or unsafe practices that may result in severe personal injury or death.

Hazards or unsafe practices that may result in minor personal injury or property damage.

Operating environment

Warning

Do not use if the power cord is damaged or if the electrical outlet is not grounded.

This could result in electric shock or fire.

Do not place anything on top of the machine (water, small metal or heavy objects, candles, lit cigarettes, etc.).

This could result in electric shock or fire.

• If the machine gets overheated, it releases smoke, makes strange noises, or generates an odd odor, immediately turn off the power switch and unplug the machine.

Do not attempt.

• The user should be able to access the power outlet in case of emergencies that might require the user to pull the plug out.

This could result in electric shock or fire.

Do not bend, or place heavy objects on the power cord.

Stepping on or allowing the power cord to be crushed by a heavy object could result in electric shock or fire.

Do not remove the plug by pulling on the cord; do not handle the plug with wet hands.

This could result in electric shock or fire.

1. Introduction

Safety information

Caution

During an electrical storm or for a period of non-operation, remove the power plug from the electrical outlet.

This could result in electric shock or fire.

Be careful, the paper output area is hot.

Burns could occur.

If the machine has been dropped, or if the cabinet appears damaged, unplug the machine from all interface connections and request assistance from qualified service personnel.

Otherwise, this could result in electric shock or fire.

If the machine does not operate properly after these instructions have been followed, unplug the machine from all interface connections and request assistance from qualified service personnel.

Otherwise, this could result in electric shock or fire.

Operating method

Caution

Do not forcefully pull the paper out during printing.

It can cause damage to the machine.

Be careful not to put your hand between the machine and paper tray.

You may get injured.

Be care when replacing paper or removing jammed paper.

New paper has sharp edges and can cause painful cuts.

When printing large quantities, the bottom part of the paper output area may get hot. Do not allow children to touch.

If the plug does not easily enter the electrical outlet, do not attempt to force it in.

Call an electrician to change the electrical outlet, or this could result in electric shock.

Do not allow pets to chew on the AC power, telephone or PC interface cords.

This could result in electric shock or fire and/or injury to your pet.

Burns can occur.

When r emov ing j amme d pap er, d o not use t weez ers o r sha rp m etal objects.

It can damage the machine.

Do not allow too many papers to stack up in the paper output tray.

It can damage the machine.

1. Introduction

Safety information

Do not block or push objects into the ventilation opening.

This could result in elevated component temperatures which can cause damage or fire.

Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.

This machine's power reception device is the power cord.

To switch off the power supply, remove the power cord from the electrical outlet.

Installation / Moving

Warning

Do not place the machine in an area with dust, humidity, or water leaks.

This could result in electric shock or fire.

Place the machine in the environment where it meets the operating temperature and humidity specification.

Do not use the machine when it is below freezing temperature or has recently been moved from a location below freezing temperature. Doing so may damage the machine. Only operate the machine when the internal temperature of the machine is within the operating temperature and humidity specifications.

Otherwise, quality problems can occur and cause damage to the machine.

See "General specifications" on page 125.

Caution

Before moving the machine, turn the power off and disconnect all cords. The information below are only suggestions based on the units weight.If you have a medical condition that prevents you from lifting, do not lift the machine. Ask for help, and always use the appropriate amount of people to lift the device safely.

Then lift the machine:

• If the machine weighs under 20 kg (44.09 lbs), lift with 1 person.

• If the machine weighs 20 kg (44.09 lbs) - 40kg (88.18 lbs), lift with 2 people.

• If the machine weighs more than 40 kg (88.18 lbs), lift with 4 or more people.

The machine could fall, causing injury or machine damage.

1. Introduction

Safety information

Choose a flat surface with enough space for ventilation to place the machine. Also consider the space required to open the cover and trays.

The place should be well-ventilated and be far from direct light, heat, and humidity.

When using the machine for a long period of time or printing a large number of pages in a non-ventilated space, it could pollute the air and be harmful to your health. Place the machine in a wellventilated space or open a window to circulate the air periodically.

Do not place the machine on an unstable surface.

The machine could fall, causing injury or machine damage.

Use only No.26 AWG

Otherwise, it can cause damage to the machine.

Make sure you plug the power cord into a grounded electrical outlet.

or larger, telephone line cord, if necessary.

Do not put a cover over the machine or place it in an airtight location, such as a closet.

If the machine is not well-ventilated, this could result in fire.

Do not overload wall outlets and extension cords.

This can diminish performance, and could result in electric shock or fire.

The machine should be connected tothe power level which is specified on the label.

If you are unsure and want to check the power level you are using, contact the electrical utility company.

a. AWG: American Wire Gauge

Maintenance / Checking

Otherwise, this could result in electric shock or fire.

Use the power cord supplied with your machine for safe operation. If you are using a cord which is longer than 2 meters (6 feet) with a 110V machine, then the gauge should be 16 AWG or larger.

Otherwise, it can cause damage to the machine, and could result in electric shock or fire.

Caution

Unplug this product from the wall outlet before cleaning the inside of the machine. Do not clean the machine with benzene, paint thinner or alcohol; do not spray water directly into the machine.

This could result in electric shock or fire.

1. Introduction

Safety information

When you are working inside the machine replacing supplies or cleaning the inside, do not operate the machine.

You could get injured.

Supply usage

Keep cleaning supplies away from children.

Children could get hurt.

Do not disassemble, repair or rebuild the machine by yourself.

It can damage the machine. Call a certified technician when the machine needs repairing.

To clean and operate the machine, strictly follow the user's guide provided with the machine.

Otherwise, you could damage the machine.

Keep the power cable and the contact surface of the plug clean from dust or water.

Otherwise, this could result in electric shock or fire.

• Do not remove any covers or guards that are fastened with screws.

• Fuser units should only be repaired by a certified service technician. Repair by non-certified technicians could result in fire or electric shock.

• The machine should only be repaired by a Samsung service technician.

Caution

Do not disassemble the toner cartridge.

Toner dust can be dangerous if inhaled or ingested.

Do not burn any of the supplies such as toner cartridge or fuser unit.

This could cause an explosion or uncontrollable fire.

When storing supplies such as toner cartridges, keep them away from children.

Toner dust can be dangerous if inhaled or ingested.

For supplies that contain toner dust (toner cartridge, waste toner bottle, imaging unit, etc.) follow the instructions below.

• When disposing of the supplies, follow the instructions for disposal. Refer to the reseller for disposal instructions.

• Do not wash the supplies.

• For a waste toner bottle, do not reuse it after emptying the bottle.

If you do not follow the instructions above, it may cause machine malfunction and environmental pollution. The warranty does not cover damages caused by a user's carelessness.

1. Introduction

Safety information

Using recycled supplies, such as toner, can cause damage to the machine.

In case of damage due to the use of recycled supplies, a service fee will be charged.

When toner gets on your clothing, do not use hot water to wash it.

Hot water sets toner into fabric. Use cold water.

When changing the toner cartridge or removing jammed paper, be careful not to let toner dust touch your body or clothes.

Toner dust can be dangerous if inhaled or ingested.

1. Introduction

Machine overview

Components

The actual component may differ from the illustration below. Some components may change depending on the configuration.

Power cord Quick installation guide

Software CD

a. The software CD contains the print drivers, user’s guide, and software applications. b. Miscellaneous accessories included with your machine may vary by country of purchase and specific model.

Misc. accessories

1. Introduction

Machine overview

Front view

• This illustration may differ from your machine depending on your model. There are various types of machine.

• Some features and optional goods may not be available depending on model or country (see "Features by model" on page 7).

C48x/C48xW series

Front door

Output support

Scan unit

USB memory port

6 Control panel 13 Scanner glass

NFC tag

a. Close the scanner lid before opening the scan unit. b. Be careful not to pinch your fingers. c. C48xW series only.

a b

8 7

1 Scanner lid 8 Toner cartridges

2 Front handle 9 Waste toner container

3Tray 10Imaging unit

1. Introduction

Machine overview

C48xFN/C48xFW series

1 3

Document feeder cover

2 Document feeder width

guide

2 4

NFC tag

Toner cartridges

a. C48xFW series only. b. Close the scanner lid before opening the scan unit. c. Be careful not to pinch your fingers.

3 Document feeder input tray 12 Waste toner container

4 Document feeder output

support

Front handle

6 Tray 15 USB memory port

7 Front cover 16 Scanner lid

8 Output support 17 Scanner glass

9 Control panel

Imaging unit

Scan unit

b c

1. Introduction

Machine overview

Rear view

C48xFN/C48xFW series

• This illustration may differ from your machine depending on your model. There are various types of machine.

• Some features and optional goods may not be available depending on model or country (see "Features by model" on page 7).

C48x/C48xW series

1 Rear cover 4 Network port

2 Power receptacle 5 Telephone line socket (LINE)

3 USB port 6 Extension telephone socket (EXT.)

1 Rear cover 3 USB port

Power receptacle

a. C48xW series only.

Network port

1. Introduction

Control panel overview

3 5

9 10

• This control panel may differ from your machine depending on its model. There are various types of control panels.

• Some features and optional goods may not be available depending on model or country (see "Features by model" on page 7).

C48x/C48xW series

WPS

Scan to

Configures the wireless network connection easily without a computer (see "Using the WPS Settings menu" on page 169).

Switches between scan and copy mode. The Scan to LED turns on scan mode and turns off on copy mode.

3 Display screen Shows the current status and displays prompts during an operation.

4 Arrows Scrolls through the options available in the selected menu and increases or decreases values.

1. Introduction

Control panel overview

6 OK Confirms the selection on the screen.

Stop/Clear

Power/Wake Up

Start

Back

Status/Wireless LED

Status LED

Eco

Opens Menu mode and scrolls through the available menus (see "Menu overview" on page 34).

Stops an operations at any time.

Turns the power on or off, or wakes up the machine from the power save mode. If you need to turn the machine off, press this button for more than three seconds when the machine is in ready mode.

Starts a job.

Sends you back to the upper menu level.

Indicates the status of your machine (see "Understanding the status LED" on page 115).

Turn into eco mode to reduce toner consumption and paper usage when pc-printing and copying only (see "Eco printing" on page

58).

Direct USB

a. C48xW series only. b. C48x series only.

Allows you to directly print files stored on a USB memory device when it is inserted into the USB port on the front of your machine.

1. Introduction

Control panel overview

C48xFN/C48xFW series

WPS

Configures the wireless network connection easily without a computer (see "Using the WPS Settings menu" on page 169).

8 9 10 11

15 14

2 ID Copy Allows you to copy both sides of an ID card like a driver’s license on a single side of paper (see "ID card copying" on page 62).

3 Display screen Shows the current status and displays prompts during an operation.

Copy

Switches to Copy mode.

Fax

Switches to Fax mode.

6 Arrows Scrolls through the options available in the selected menu and increases or decreases values.

Opens Menu mode and scrolls through the available menus (see "Menu overview" on page 34).

8 OK Confirms the selection on the screen.

1. Introduction

Control panel overview

9 Numeric keypad Dials a number or enters alphanumeric characters (see "Keypad letters and numbers" on page 226).

10 Address Book Allows you to store frequently used fax numbers or search for stored fax numbers (see "Setting up the fax address book" on page 227).

Redial/Pause

Stop/Clear

Power/Wake Up

Start

On Hook Dial

Back

Scan

Status/Wireless LED

Status LED

Redials the recently sent fax number or received caller ID in ready mode, or inserts a pause(-) into a fax number in edit mode (see "Redialing the fax number" on page 249).

Stops an operations at any time.

Turns the power on or off, or wakes up the machine from the power save mode. If you need to turn the machine off, press this button for more than three seconds when the machine is in ready mode.

Starts a job.

When you press this button, you can hear a dial tone. Then enter a fax number. It is similar to making a call using speaker phone (see "Receiving manually in Tel mode" on page 254).

Sends you back to the upper menu level.

Switches to Scan mode.

Indicates the status of your machine (see "Understanding the status LED" on page 115).

19 Eco Turn into eco mode to reduce toner consumption and paper usage when pc-printing and copying only (see "Eco printing" on page 58).

20 Direct USB Allows you to directly print files stored on a USB memory device when it is inserted into the USB port on the front of your machine.

a. C48xFW series only. b. C48xFN series only.

1. Introduction

Turning on the machine

Power is turned on automatically.

Keep in mind that you should use the power cord supplied with the machine. Otherwise, it can cause damage or fire to the machine.

Connect the machine to the electricity supply first.

For C48x/C48xW series, press (Power/Wake Up) button on the

control panel.

If you want to turn the power off, press and hold (Power/Wake Up)

Turn the switch on if the machine has a power switch.

button for about 3 seconds.

Illustrations on this user’s guide may differ from your machine depending on its options or models. Check your machine type (see "Front view" on page 21).

1. Introduction

Installing the driver locally

A locally connected machine is a machine directly attached to your computer using a USB cable. If your machine is attached to a network, skip the following steps below and go on to installing a network connected machine’s driver (see "Installing driver over the network" on page 160).

• If you are a Mac or Linux operating systems user, refer to the "Installation for Mac" on page 151 or "Installation for Linux" on page 153.

• The installation window in this User’s Guide may differ depending on the machine and interface in use.

• Only use a USB cable no longer than 3 meters (118 inches).

Windows

Make sure that the machine is connected to your computer and

powered on.

Insert the supplied software CD into your CD-ROM drive.

If the installation window does not appear, click Start > All programs > Accessories > Run.

X:\Setup.exe replacing “X” with the letter, which represents your CDROM drive and click OK.

• For Windows 8,

If the installation window does not appear, from Charms, select Search > Apps and search for Run. Type in X:\Setup.exe, replacing “X” with the letter that represents your CD-ROM drive and click OK.

If “Tap to choose what happens with this disc.” pop-up window appears, click the window and select Run Setup.exe.

Review and accept the installation agreements in the installation

window. Then, click Next.

Select USB on the Printer Connection Type screen. Then, click Next.

Follow the instructions in the installation window.

1. Introduction

Installing the driver locally

You can select the software applications in the Select Software to Install window.

From the Windows 8 Start Screen

• The V4 driver is automatically downloaded from the Windows Update if your computer is connected to the Internet. If not, you can manually download the V4 driver from Samsung website, www.samsung.com > find your product > Support or downloads.

• You can download Samsung Printer Experience app from the Windows

Store. You need have a Microsoft account to use the Windows Store.

1 From Charms, select Search. 2 Click Store. 3 Search and click Samsung Printer Experience. 4 Click Install.

Make sure that your computer is connected to the Internet and powered

on.

Make sure that the machine is powered on.

Connect the computer and the machine with a USB cable.

The driver is automatically installed from the Windows Update.

• If you install the driver using the supplied software CD, V4 driver is not installed. If you want to use the V4 driver in the Desktop screen, you can download from the Samsung website, www.samsung.com >find your product > Support or downloads.

• If you want to install Samsung’s printer management tools, you need to install them using the supplied software CD.

1. Introduction

+ 283 hidden pages
