Samsung BD-D5500-ZA, BD-D5500 User Manual

Download

BD-D5500

Blu-ray

user manual

imagine the possibilities

Thank you for purchasing this Samsung product. To receive more complete service, please register your product at

www.samsung.com/register

™

Disc Player

2 English

Key features

Blu-ray Disc Features

Blu-ray Discs support the highest quality HD video available in the industry - Large capacity means no compromise on video quality.

The following Blu-ray Disc features are disc dependant and will vary. Appearance and navigation of features will also vary from disc to disc. Not all discs will have the features described below.

Video highlights

The BD-ROM format supports three highly advanced video codecs, including AVC, VC-1 and MPEG-2.

HD video resolutions are also supported:

1920 x 1080 High Definition

• 1280 x 720 High Definition

•

For High-Definition Playback

To view high-definition contents on a Blu-ray Disc, you need an HDTV (High Definition Television). Some Blu-ray Discs may require you to use the player’s HDMI OUT to view high-definition content. The ability to view high-definition content on Blu-ray Discs may be limited depending on the resolution of your TV.

BD-LIVE

You can use a Blu-ray Disc that supports BDLIVE to download content provided by the disc manufacturer through a network connection.

Blu-ray Disc Player Features

This player can play 3D contents through an HDMI cable.

To implement the 3D effect, connect a 3D device (3D-compliant AV receiver, 3D-compliant TV) to the player using an HDMI cable, and play the 3D content while wearing 3D vision glasses.

Smart Hub

You can download various for pay or freeof-charge applications through a network connection. These applications provide a range of Internet services and content including news, weather forecasts, stock market quotes, games, movies, and music.

AllShare

You can play videos, music, and photos saved on your devices (such as your PC, mobile phones, or NAS) through a network connection.

Playing multimedia files

You can use the USB connection to play various kinds of multimedia files (MP3, JPEG, DivX, etc.) located from a USB storage device.

English 3

Safety Information

Warning

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK). NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

The lighting flash and Arrowhead within the triangle is a warning sign alerting you of dangerous voltage inside the product.

WARNING

To reduce the risk of fire or electric shock, do

• not expose this appliance to rain or moisture.

FCC NOTE (for U.S.A)

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on.

The user is encouraged to try to correct the interference by one or more of the following measures.

Reorient or relocate the receiving antenna.

• Increase the separation between the equipment

• and receiver.

Connect this equipment into an outlet on a

• circuit different from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV

• technician for help.

This class B digital product meets all

• requirements of the Canadian Interference Causing Equipment Regulations.

Note to CATV system installer

This reminder is provided to call CATV system installer’s attention to Article 820-40 of the National Electrical Code (Section 54 of Canadian Electrical Code, Part I) that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as practical.

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The explanation point within the triangle is a warning sign alerting you of important instructions accompanying the product.

CLASS 1 LASER PRODUCT

This Compact Disc player is classified as a CLASS 1 LASER product. Use of controls, adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.

Complies with 21CFR 1040.10 except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007.

DANGER :

VISIBLE AND INVISIBLE LASER RADIATION

• WHEN OPEN. AVOID DIRECT EXPOSURE TO BEAM. (FDA 21 CFR)

CAUTION :

CLASS 3B VISIBLE AND INVISIBLE LASER

• RADIATION WHEN OPEN. AVOID EXPOSURE TO THE BEAM (IEC 60825-1)

THIS PRODUCT UTILIZES A LASER. USE

• OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. DO NOT OPEN COVER AND DO NOT REPAIR YOURSELF. REFER SERVICING TO QUALIFIED PERSONNEL.

CLASS 1 LASER PRODUCT KLASSE 1 LASER PRODUKT LUOKAN 1 LASER LAITE KLASS 1 LASER APPARAT PRODUCTO LÁSER CLASE 1

NOTE

✎

If the Region number of a Blu-ray Disc/DVDs does

▪

not correspond to the Region number of this player, the player cannot play the disc.

02 Safety Information

4 English

Safety Information

Precautions

Important Safety Instructions

Read these operating instructions carefully before using the unit. Follow all the safety instructions listed below. Keep these operating instructions handy for future reference.

Read these instructions.

Keep these instructions.

Heed all warnings.

Follow all instructions.

Do not use this apparatus near water.

Clean only with a dry cloth.

Do not block any ventilation openings. Install

in accordance with the manufacturer’s instructions.

Do not install near any heat sources such

as radiators, heat registers, stoves, or other apparatus (including AV receivers) that produce heat.

Do not defeat the safety purpose of the

polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

Protect the power cord from being walked on

10.

or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

Only use attachments/accessories specified

11.

by the manufacturer.

Use only with the cart,

12.

stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

Unplug this apparatus during lightning storms

13.

or when unused for long periods of time.

Refer all servicing to qualified service

14.

personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

Viewing using 3D function

IMPORTANT HEALTH AND SAFETY INFORMATION FOR 3D PICTURES. Read and understand the following safety information before using the 3D function.

Some viewers may experience discomfort while

• viewing 3D TV such as dizziness, nausea, and headaches. If you experience any such symptom, stop viewing 3D TV, remove the 3D Active Glasses, and rest.

Watching 3D images for an extended period of

• time may cause eye strain. If you feel eye strain, stop viewing 3D TV, remove your 3D Active Glasses, and rest.

A responsible adult should frequently check on

• children who are using the 3D function. If there are any reports of tired eyes, headaches, dizziness, or nausea, have the child stop viewing 3D TV and rest.

Do not use the 3D Active Glasses for other

• purposes (such as general eyeglasses, sunglasses, protective goggles, etc.)

Do not use the 3D function or 3D Active Glasses

• while walking or moving around. Using the 3D function or 3D Active Glasses while moving around may cause you to bump into objects, trip, and/or fall, and cause serious injury.

English 5

02 Safety Information

Disc Storage & Management

Disc Handling

Disc Shape

Use discs with regular

• shapes. If you use an irregular disc (a disc with a special shape), you can damage the player.

Holding discs

Avoid touching the surface of

• a disc where data has been recorded.

Blu-ray Discs

Do not leave a Blu-ray Disc in the player for long

• periods of time. Remove the Blu-ray Disc from the player and store it in its case.

Be careful not to scratch or leave fingerprints on

• the surface of the Blu-ray Disc.

DVD-VIDEO, Audio CD (CD-DA)

Wipe off dirt or contamination on the disc with a

• soft cloth.

Disc Storage

Be careful not to damage the disc because the data on these discs is highly vulnerable to the environment.

Do not keep under direct sunlight.

• Keep in a cool ventilated area.

• Store vertically.

• Keep in a clean protection jacket.

• If you move your player suddenly from a cold

• place to a warm place, condensation may occur on the operating parts and lens and cause abnormal disc playback. If this occurs, unplug the player, wait for two hours, and then connect the plug to the power outlet. Then, insert the disc, and try to play back again.

Handling Cautions

Do not write on the printed side with a ball-point

• pen or pencil.

Do not use record cleaning sprays or antistatic

• sprays to clean discs. Also, do not use volatile chemicals, such as benzene or thinner.

Do not apply labels or stickers to discs. (Do not

• use discs fixed with exposed tape adhesive or leftover peeled-off stickers.)

Do not use scratch-proof protectors or covers.

• Do not use discs printed with label printers

• available on the market.

Do not load warped or cracked discs.

• Before connecting other components to this

• player, be sure to turn them off.

Do not move the player while it is playing a disc.

• The disc can be scratched or damaged and the player’s internal parts can be damaged.

Do not put a flower vase filled with water or any

• small metal objects on the player.

Be careful not to put your hand into the disc

• tray.

Do not place anything other than the disc in the

• disc tray.

Interference from exterior sources such as

• lightening and static electricity can affect the normal operation of this player. If this occurs, turn the player off and on again with the POWER button, or disconnect and then reconnect the AC power cord to the AC power outlet. The player will operate normally.

Be sure to remove the disc and turn off the

• player after use.

Disconnect the AC power cord from the AC

• outlet when you don’t intend to use the player for long periods of time.

To clean a disc, wipe it in a straight

• line from the inside to the outside of the disc.

Do not expose the player to any

• liquid.

When the AC plug is connected to a wall outlet,

• the player will still draw power (standby mode) when it is turned off.

6 English

Safety Information

Apparatus shall not be exposed to dripping or

• splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus.

The main plug is used as a disconnect device

• and shall stay readily operable at any time.

Maintenance of Cabinet

Before you clean the Blu-ray Disc’s cabinet, be sure to disconnect the AC power cord from the AC outlet.

Do not use benzene, thinner, or other solvents

• for cleaning.

Wipe the cabinet with a soft cloth.

•

Restrictions on Playback

This player may not respond to all operating

• commands because some Blu-ray Disc, DVD, and CD discs allow specific or limited operation and provide only certain features during playback. Please note that this is not a defect in the player.

Samsung cannot guarantee that this player

• will play every disc bearing the Blu-ray Disc, DVD or CD logo because disc formats evolve, and problems and errors may occur during the creation of Blu-ray Disc, DVD, and CD software and/or the manufacture of discs. Please contact the SAMSUNG customer care center if you have questions or encounter difficulty in playing Blu-ray Disc, DVD, or CD discs in this player. Also, refer to rest of this user manual for additional information on playback restrictions.

English 7

Contents

KEY FEATURES

SAFETY INFORMATION

GETTING STARTED

2 Blu-ray Disc Features 2

Blu-ray Disc Player Features

3 Warning 4

Precautions

4 Important Safety Instructions 4 Viewing using 3D function 5

Disc Storage & Management

5 Disc Handling

11 Before using the User Manual 11 Disc Types and Contents your player can play 11 12 12 13 13 14 15 15 Accessories 16 17 18 18 Tour of the Remote Control 19

Disc types your player cannot play Blu-ray Disc Compatibility Disc Types Region Code Copyright Supported File Formats Logos of Discs the player can play

Front Panel Rear Panel Remote Control

Setting the Remote Control to Operate Your TV

ENGLISH

CONNECTIONS

20 Connecting to a TV 20 Case 1 : Connecting to a TV with an HDMI Cable

- Best Quality (Recommended) Case 2 : Connecting to a TV with a Component

Cable - Better Quality Case 3 : Connecting to a TV with an Audio/Video

cable - Good Quality

8 English

Contents

CONNECTIONS

SETUP

23 Connecting to an Audio System 23 Case 1 : Connecting to an Audio System

25 Connecting to the Network 25 Cable Network 26

27 Initial Settings 28 29 29 3D Settings 30 30 30 30 32 32 33 33 33 33 Audio 33 Digital Output 35 35 35 36 Network 36 Network Settings 39 40

(HDMI supported AV receiver) (Recommended)

Case 2 : Connecting to an Audio System (AV receiver with Dolby Digital or DTS decoder)

- Better Quality Case 3 : Connecting to an Audio System

(Stereo Amplifier) - Good Quality

Wireless Network

Accessing the Settings Menu Display

TV Aspect Smart Hub Screen Size BD Wise (Samsung Players only) Resolution HDMI Color Format Movie Frame (24Fs) HDMI Deep Color Still Mode Progressive Mode

PCM Downsampling Dynamic Range Control Downmixing Mode

Network Status BD-LIVE Internet Connection

- Best Quality

English 9

ENGLISH

SETUP

40 System 40 Initial Settings 40 40 41 41 41 41 Language 41 41 BD Parental Rating 41 41 42 General 42 Front Display 42 42 Support 42 Software Upgrade 44

Anynet+(HDMI-CEC) BD Data Management Time Zone DivX® Video On Demand Reset

Security

DVD Parental Rating Change Password

Network Remote Control

Contact Samsung

BASIC FUNCTIONS

45 Playing a Video 45 Playback 45 45 Using the Disc Menu/Title Menu/Popup Menu 45 Using the Disc Menu 46 46 46 46 Using the Search and Skip Functions 46 Searching for a Desired Scene 46 47 Slow Motion Play/Step Motion Play 47 Slow Motion Play 47

Disc Structure

Using the Title Menu Playing the Title List Using the Popup Menu

Skipping Chapters

Step Motion Play

10 English

Contents

BASIC FUNCTIONS

NETWORK SERVICES

47 Using the TOOLS button 47 Moving to a Desired Scene Directly 47 48 48 48 48 49 49 49 50 Listening to Music 50 Buttons on the Remote Control used for Music

50 51 51 52 Playing back Pictures 52 Playing a JPEG files 52 53 Playing back a USB Storage Device

54 Using Smart Hub 54 Starting Smart Hub for the First Time 57 59 61 61 Samsung Apps 61 For Pay Apps 63 BD-LIVE™ 63

Repeating the Title or Chapter Repeating a Section Changing to Full Screen Selecting the Picture Settings Selecting the Audio Language Selecting the Subtitle Language Changing the Camera Angle Setting BONUSVIEW

Playback Playing an Audio CD (CD-DA)/MP3 Repeat an Audio CD (CD-DA)/MP3 Playlist

Using the TOOLS button

The Settings Menu - BLUE (D) The Edit Mode Menu - YELLOW (C) The Sort Menu - GREEN (B)

Using the AllShare Function

APPENDIX

64 Troubleshooting 66 Repairs 67 Index 68

Specifications

English 11

Getting Started

Before using the User Manual

Disc Types and Contents your player can play

Term Logo Icon Definition

Indicates a function available on a BD-ROM or BD-RE/-R disc recorded in the BD-RE format.

VIDEO

Indicates a function available on a DVD-VIDEO or recorded DVD+RW/ DVD-RW(V)/DVD-R/+R discs that have been recorded and finalized.

Indicates a function available in a CD-RW/-R, DVD-RW/-R, BD-RE/-R disc or a USB storage media containing DivX, MKV, MP4 contents.

Indicates a function available on an audio CD-RW/-R (CD-DA format).

Indicates a function available in a CD-RW/-R, DVD-RW/-R, BD-RE/-R disc or a USB storage media containing MP3 or WMA contents.

Indicates a function available in a CD-RW/-R, DVD-RW/-R, BD-RE/-R disc or a USB storage media containing JPEG contents.

MUSIC


x o

03 Getting Started

NOTE

✎

The player may not play certain CD-RW/-R and DVD-R because of the disc type or recording conditions.

▪

If a DVD-RW/-R disc has not been recorded properly in DVD video format, it will not be playable.

▪

Your player will not play content that has been recorded on a DVD-R at a bit-rate that exceeds 10 Mbps.

▪

Your player will not play content that has been recorded on a BD-R or USB device at a bit rate that exceeds 30 Mbps.

▪

Disc types your player cannot play

HD DVD

• DVD-ROM/PD/MV-

• Disc, etc

DVD-RAM

• Super Audio CD

• (except CD layer)

DVD-RW(VR mode)

• CVD/CD-ROM/CDV/

• CD-G/CD-I/LD (CD-Gs play audio only, not graphics.)

3.9 GB DVD-R Disc for

• Authoring.

12 English

Getting Started

NOTE

✎

Some commercial discs and DVDs purchased

▪

outside your region may not play on this player.

Playback may not work for some types of discs, or

▪

when you use specific operations, such as angle change and aspect ratio adjustment. Information about the discs is written in detail on the disc box. Please refer to this if necessary.

Do not allow the disc to become dirty or scratched.

▪

Fingerprints, dirt, dust, scratches or deposits of cigarette smoke on the recording surface may make it impossible to use the disc for playback.

Discs with PAL programs recorded on them cannot

▪

be played using this player.

This player is compatible with the NTSC color system

▪

only.

When you play a BD-J title, loading may take longer

▪

than a normal title or some functions may perform slowly.

This player may not respond to all operating

▪

commands because some Blu-ray Disc, DVD, and CD discs allow specific or limited operation and provide only certain features during playback. Please note that this is not a defect in the player.

Samsung cannot guarantee that this player will play

▪

every disc bearing the Blu-ray Disc, DVD or CD logo because disc formats evolve, and problems and errors may occur during the creation of Blu-ray Disc, DVD, and CD software and/or the manufacture of discs. Please contact the SAMSUNG customer care center if you have questions or encounter difficulty when playing Blu-ray Disc, DVD, or CD discs in this player. Also, refer to rest of this user manual for additional information on playback restrictions.

Blu-ray Disc Compatibility

Blu-ray Disc is a new and evolving format. Accordingly, disc compatibility issues are possible. Not all discs are compatible and not every disc will play back. For additional information, refer to the Compliance and Compatibility Notice section of this user manual.

Disc Types

BD-ROM

Blu-ray ROM discs can only be played back. This player can play back pre-recorded commercial BD-ROM discs.

BD-RE/-R

Blu-ray RE/-R discs can be recorded on and played back. This player can play back a BD-RE/-R disc recorded by other compatible Blu-ray Disc recorders.

DVD-VIDEO

This player can play back pre-recorded

• commercial DVDs (DVD-VIDEO discs) with movies.

When switching from the first layer to the

• second layer of a dual-layered DVD-VIDEO disc, there may be momentary distortion in the image and sound. This is not a malfunction of the player.

DVD-RW/-R/+R

This player can play back a DVD-RW/-R/+R disc recorded and finalized with a DVD video recorder. The ability to play back may depend on recording conditions.

DVD+RW

This player can play back a DVD+RW disc

• recorded with a DVD Video recorder. The ability to play back may depend on recording conditions.

Audio CD (CD-DA)

This player can play back CD-DA format audio

• CD-RW/-R discs.

The player may not be able to play some

• CD-RW/-R discs due to the condition of the recording.

English 13

03 Getting Started

CD-RW/-R

Use a 700MB (80 minute) CD-RW/-R disc.

• If possible, do not use an 800MB (90 minute) or larger disc, as the disc may not play back.

If the CD-RW/-R disc was not recorded as a

• closed session, you may experience delays when playing back the beginning of the disc or all recorded files may not play.

Some CD-RW/-R discs may not play on this

• player, depending on the device which was used to burn them. For contents recorded on CD-RW/-R media from CDs for your personal use, playability may vary depending on the contents and discs.

Region Code

Both players and discs are coded by region. These regional codes must match for a disc to play. If the codes do not match, the disc will not play. The Region Number for this player is displayed on the rear panel of the player.

Disc Type

Region

Code

North America, Central America, South America, Korea, Japan,

Taiwan, Hong Kong and South East Asia.

Area

AVCHD (Advanced Video Codec High Definition)

This player can play back AVCHD format discs.

• These discs are normally recorded and used in camcorders.

The AVCHD format is a high definition digital

• video camera format.

The MPEG-4 AVC/H.264 format compresses

• images with greater efficiency than the conventional image compressing format.

Some AVCHD discs use the “x.v.Color” format.

• This player can play back AVCHD discs that use “x.v.Color” format.

“x.v.Color” is a trademark of Sony Corporation.

• “AVCHD” and the AVCHD logo are trademarks

• of Matsushita Electronic Industrial Co., Ltd. and Sony Corporation.

NOTE

✎

Some AVCHD format discs may not play, depending

▪

on the recording condition. AVCHD format discs need to be finalized.

“x.v.Color” offers a wider color range than normal

▪

DVD camcorder discs.

Some DivX, MKV and MP4 format discs may not

▪

play, depending on the video resolution and frame rate condition.

Blu-ray Disc

DVD-VIDEO

Europe, Greenland, French territories, Middle East, Africa,

Australia and New Zealand.

India, China, Russia, Central

and South Asia.

The U.S., U.S. territories and

Canada

Europe, Japan, the Middle East,

Egypt, South Africa, Greenland

Taiwan, Korea, the Philippines,

Indonesia, Hong Kong

Mexico, South America, Central America, Australia,

New Zealand, Pacific Islands, Caribbean

Russia, Eastern Europe, India, most of Africa, North Korea,

Mongolia

China

Copyright

manual may be reproduced or copied without the prior written permission of Samsung Electronics Co.,Ltd.

14 English

Getting Started

Supported File Formats

Notes on the USB connection

Your player supports USB storage media, MP3 players, digital cameras, and USB card readers.

• The player does not support folder or file names longer than 128 characters.

• Some USB/digital camera devices may not be compatible with the player.

• Your player supports the FAT16, FAT32, and NTFS files systems.

• Connect USB devices directly to the player’s USB port. Connecting through a USB cable may cause

• compatibility problems.

Inserting more than one memory device into a multi-card reader may cause the reader to operate

• improperly.

The player does not support the PTP protocol.

• Do not disconnect a USB device during a “loading” process.

• The bigger the image resolution, the longer the image takes to display.

• This player cannot play MP3 files with DRM (Digital Rights Management) downloaded from commercial

• sites.

External HDD device is not supported.

• Your player only supports the video that is under 30fps (frame rate).

•

Video File Support

File Extension Container Video Codec Audio Codec Resolution

*.avi

*.mkv

*.wmv

*.mp4

*.mpg

*.mpeg

AVI

MKV

WMV (wmv9)

MP4

DivX 3.11/4.x/5.1/6.0

XviD

MP4v3

H.264 BP/MP/HP

VC-1 AP

DivX 5.1/6.0

XviD

H.264 BP/MP/HP

VC-1 AP

VC-1 SM

MP4 (mp4v)

H.264 BP/MP/HP

MPEG1 MPEG2

H.264 BP/MP/HP

MP3 AC3

DTS

WMA

PCM

MP3 AC3

DTS

WMA

AAC

MP1, 2

AC3

DTS

1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080 1920x1080

Music File Support

File Extension Container Audio Codec Support Range

*.mp3

*.wma

MP3

WMA

MP3 -

Compliant with WMA version 10

WMA

* Sampling rates (in kHz) - 8, 11, 16, 22, 32, 44.1, 48 * Bit rates - All bit-rates in the range 5kbps to 384kbps

English 15

03 Getting Started

Logos of Discs the player can play

ALL

2D�3D

INTERNET@

MUTE

VOL CH

POWER

SOURCE

DISC MENU TITLE MENUMENU

SEARCHSMART

SUBTITLE

AUDIO

INFO

POPUP

TOOLS

EXITRETURN

HUB

1 2 3

4 5 6

7 8 9

BONUSVIEW

Blu-ray Disc 3D Blu-ray Disc DTS-HD Master Audio DivX

BD-LIVE Dolby TrueHD

Check for the supplied accessories below.

Audio/Video cable

Batteries for Remote Control

(AC39-00073A)

User Manual

(AK68-01995A)

NTSC broadcast system in

U.S.A, Canada, Korea, Japan

Accessories

(AAA Size)

(AC43-12002H)

Quick Guide

(AK68-01996A)

Java

Remote Control (AK59-00123A)

16 English

Getting Started

DISC TRAY Opens to accept a disc.

POWER BUTTON Turns the player on and off.

DISPLAY Displays the playing status, time, etc.

Front Panel

gfedcb ha

STOP BUTTON Stops disc playback.

PLAY/PAUSE BUTTON Plays a disc or pauses playback. (It may not play a Blu-ray Disc.)

ENTER BUTTON Selects menu items or starts a disc.

OPEN/CLOSE BUTTON Opens and closes the disc tray.

REMOTE CONTROL SENSOR Detects signals from the remote control.

USB HOST

NOTE

✎

You can perform software upgrades using the USB Host jack with a USB memory flash stick only.

▪

When the player displays the Blu-ray disc menu, you cannot start the movie by pressing the Play button on the player

▪

or the remote. To play the movie, you must select Play Movie or Start in the disc menu, and then press the ENTER button.

You can connect a USB memory flash stick here and use it as storage when the player is connected to BD-LIVE. You can also use the USB Host for software upgrades and MP3/JPEG/DivX/MKV/MP4 playback.

English 17

03 Getting Started

Rear Panel

b ca d

g ef

WIRELESS LAN ADAPTER

LAN

HDMI OUT

COMPONENT OUT Connects to external devices that have Component video input.

VIDEO OUT Connects to the video input of external devices using a video cable.

AUDIO OUT Connects to the audio input of external devices using audio cables.

DIGITAL AUDIO OUT Connects to an AV receiver.

Connect the optional Wireless LAN Adapter (WIS09ABGN) here to use a Wireless network.

Use for network based services (See pages 54~63), BD-LIVE, and software upgrades using a network connection.

Using an HDMI cable, connect this HDMI output terminal to the HDMI input terminal on your TV for the best quality picture or to your AV receiver for the best quality sound.

18 English

Getting Started

ALL

INTERNET@

MUTE

VOL CH

POWER

SOURCE

DISC MENU TITLE MENUMENU

SEARCHSMART

SUBTITLE

AUDIO

INFO

POPUP

TOOLS

EXITRETURN

HUB

1 2

4 5 6

7 8 9

BONUSVIEW

Tour of the Remote Control

Remote Control

Turn the player on and off.

To open and close the disc tray.

Press to use the bonusview function.

Press numeric buttons to operate options.

Press to switch the Blu-ray Disc/DVD’s

Press to skip backwards or forwards.

Press to move to the home menu.

Return to the previous menu.

subtitle language.

Press to stop a disc.

Use to enter the disc menu.

Press to use Tools menu.

Mutes the speakers of your TV.

Press to use Netflix.

Press to use Smart Hub.

TV volume adjustment.

Turn the TV on and off. (To operate your TV, please refer to page

19)

After setup, allows you to set the input source on your TV.

Use to access various audio functions on a disc (Blu-ray Disc/DVD).

Press to search a disc backwards or forwards.

Press to pause a disc.

Press to play a disc.

Use to enter the popup menu/title menu.

Use to display the playback information during playing a Blu-ray Disc/DVDs.

Use to select menu items and change menu value.

Press to exit the menu.

These buttons are used both for menus on the player and also several Blu-ray Disc functions.

Press to search contents.

Use to select a TV channel.

Installing batteries

NOTE

✎

If the remote does not operate properly:

▪

Check the polarity +/– of the batteries.

•

Check if the batteries are drained.

•

Check if the remote sensor is blocked by

•

obstacles. Check if there is any fluorescent lighting nearby.

•

CAUTION

Dispose of batteries according to local environmental

▪

regulations. Do not put them in the household trash.

English 19

03 Getting Started

Setting the Remote Control to Operate Your TV

You can control certain functions of your TV with this remote control.

Button Function

TV POWER Used to switch the television on and off.

TV SOURCE

TV VOL (+/–) Used to adjust the volume of the television.

TV CH (,/.) Used to select the desired channel.

TV MUTE Used to toggle the sound on and off.

NOTE

✎

▪

To determine whether your television is compatible, follow the instructions below.

Switch your television on.

Point the remote control towards the

television.

Press and hold the TV POWER button, and

then enter the two-figure code in the table to the right that corresponds to the brand of your television by pressing the appropriate number buttons. If your television is compatible with the remote control, it will switch off. The remote is now programmed to operate the TV.

NOTE

✎

▪

Used to select an external source connected to the TV.

The functions listed above will not necessarily work on all televisions. If you encounter problems, use the TV remote control.

If several codes are listed for your television brand, try each one in turn until you find one that works.

If you replace the remote control’s batteries, you must set the brand code again.

TV Control Codes

Brand Code

SAMSUNG

BANG & OLUFSEN

BLAUPUNKT TV POWER+71

BRIONVEGA TV POWER+57

CONTINENTAL

EMERSON TV POWER+64

FERGUSON TV POWER+73

FORMENTI TV POWER+57

GRADIENTE TV POWER+70

IMPERIAL TV POWER+52

LOEWE OPTA TV POWER+06, +57

MAGNAVOX TV POWER+40

MITSUBISHI

TV POWER+01, +02, +03, +04, +05, +06, +07, +08, +09

AIWA TV POWER+82

TV POWER+10, +11,

ANAM

+12, +13, +14, +15, +16, +17, +18

TV POWER+57

BRANDT TV POWER+73

CGE TV POWER+52

TV POWER+75

EDISON

TV POWER+19, +20, +23, +24, +25,

DAEWOO

+26, +27, +28, +29, +30, +31, +32, +33, +34

TV POWER+06, +49,

FINLUX

+57

FUJITSU TV POWER+84

TV POWER+49, +52,

GRUNDIG

+71

TV POWER+60, +72,

HITACHI

+73, +75

JVC TV POWER+61, +79

TV POWER+06, +19,

+20, +21, +22, +78

LOEWE TV POWER+06, +69

METZ TV POWER+57

TV POWER+06, +48, +62, +65

MIVAR TV POWER+52, +77

NEC TV POWER+83

NEWSAN TV POWER+68

Brand Code

NOBLEX TV POWER+66

NOKIA TV POWER+74

NORDMENDE

PANASONIC

PHONOLA

RADIOMARELLI TV POWER+57

SCHNEIDER TV POWER+06

SINUDYNE TV POWER+57

TELEFUNKEN

THOMSON

THOMSON ASIA TV POWER+80, +81

TV POWER+72, +73, +75

TV POWER+53, +54, +74, +75

TV POWER+06, +55,

PHILIPS

+56, +57

TV POWER+06, +56, +57

TV POWER+58, +59,

PIONEER

+73, +74

RADIOLA TV POWER+06, +56

RCA TV POWER+45, +46

REX TV POWER+74

TV POWER+57, +72,

SABA

+73, +74, +75

SALORA TV POWER+74

TV POWER+41, +42,

SANYO

+43, +44, +48

SELECO TV POWER+74

TV POWER+36, +37,

SHARP

+38, +39, +48

SIEMENS TV POWER+71

SINGER TV POWER+57

SONY TV POWER+35, +48

TELEAVA TV POWER+73

TV POWER+67, +73, +75, +76

TV POWER+72, +73, +75

TV POWER+47, +48,

TOSHIBA

+49, +50, +51, +52

WEGA TV POWER+57

YOKO TV POWER+06

ZENITH TV POWER+63

20 English

Connections

Connecting to a TV

Case 1 : Connecting to a TV with an HDMI Cable - Best Quality (Recommended)

Using an HDMI cable, connect the HDMI OUT terminal on the rear of the player to the HDMI IN

terminal of your TV.

Turn on the player and TV.

Press the input selector on your TV remote control until the HDMI signal from the player appears on

your TV screen.

If you have set the remote control to operate your TV (See page 19), press the TV SOURCE

• button on the remote control and select HDMI as the external source of the TV.

HDMI cable

(not included)

NOTE

✎

An HDMI cable outputs digital video/audio, so you don’t need to connect an audio cable.

▪

If the player is connected to your TV in the HDMI 720p, 1080i, or 1080p output mode, you must use a High speed

▪

(category 2) HDMI cable.

HDMI outputs only a pure digital signal to the TV.

▪

If your TV does not support HDCP (High-bandwidth Digital Content Protection), random noise appears on the screen.

Depending on your TV, certain HDMI output resolutions may not work. Please refer to the user manual of your TV.

▪

When you connect the player to the TV using the HDMI cable for the first time or to a new TV, the HDMI output

▪

resolution will be automatically set to the highest supported by the TV.

You must have an HDMI connection to enjoy videos with 3D technology.

▪

A long HDMI cable may cause a screen noise. If this occurs, set Deep Color to Off in the menu.

▪

If you use HDMI-to-DVI cable to connect to your display device, you must also connect the AV Out or Digital Audio Out to

▪

your display device or an audio sytem to hear audio.

English 21

04 Connections

Case 2 : Connecting to a TV with a Component Cable - Better Quality

You can connect the player to your TV using Component video cables.

You will enjoy high quality images with accurate color reproduction. Component video separates

the picture element into black and white (Y), blue (PB) and red (PR) signals to present clear and clean images. (Audio signals are delivered through the audio output.)

Using a Component video cable, connect the COMPONENT OUT terminals on the rear of the player

to the COMPONENT IN terminals of your TV.

Using audio cables, connect the AUDIO OUT (red and white) terminals on the rear of the player to

the AUDIO IN (red and white) terminals of your TV.

Turn on the player and TV.

Press the input selector on your TV remote control until the “COMPONENT” signal from the player

appears on the TV screen.

If you have set the remote control to operate your TV (See page 19), press the TV SOURCE

• button on the remote control and select COMPONENT as the external source of the TV.

Component cable

Audio cable

(not included)

Red

White Red Blue Green

NOTE

✎

Depending on the manufacturer, the component terminals on your TV may be marked “R-Y, B-Y, Y ” or “Cr, Cb, Y”

▪

instead of “PB, PR, Y”. The number and position of terminals may vary depending on the TV set. Please refer to the user manual of your TV.

You can select from a variety of resolution settings as 1080i, 720p, 480p, or 480i, depending on the contents type.

▪

(See pages 30~33)

The actual resolution may differ from the setting in the setup menu if you have connected both Component and HDMI

▪

cables. The resolution may also be different depending on the contents type. (See pages 30~33)

22 English

Connections

Case 3 : Connecting to a TV with an Audio/Video cable - Good Quality

Using an Audio/Video cable, connect the VIDEO OUT (yellow) / AUDIO OUT (red and white)

terminals on the rear of the player to the VIDEO IN (yellow) / AUDIO IN (red and white) terminals of your TV.

Turn on the player and TV.

Press the input selector on your TV remote control until the “VIDEO” signal from the player appears

on the TV screen.

If you have set the remote control to operate your TV (See page 19), press the TV SOURCE

• button on the remote control and select VIDEO as the external source of the TV.

Audio/Video cable

WhiteRed Yellow

NOTE

✎

Noise may be generated if the audio cable is placed too close to the power cable.

▪

If you want to connect to an AV receiver, please refer to the AV receiver connection pages. (See pages 23~24)

▪

The number and position of input terminals may vary depending on your TV set. Please refer to the user manual of your

▪

TV.

CAUTION

Do not connect the player to your TV through a VCR. Video signals fed through VCRs may be affected by copyright

▪

protection systems and the picture will be distorted on the television.

English 23

04 Connections

Connecting to an Audio System

Please turn the volume down when you turn on the AV receiver. A sudden loud sound may cause

• damage to the speakers and your ears.

Set the audio output format according to the capabilities of your AV receiver. (See pages 33~35)

• The position of HDMI input terminals may vary depending on your AV receiver. Please refer to the

• user manual of your AV receiver.

Case 1 : Connecting to an Audio System (HDMI supported AV receiver)

- Best Quality (Recommended)

Using an HDMI cable, connect the HDMI OUT terminal on the rear of the player to the HDMI IN

terminal of your AV receiver.

Using an HDMI cable, connect the HDMI OUT terminal of the AV receiver to the HDMI IN terminal of

your TV.

Turn on the player, TV, and AV receiver.

Press the input select button of the AV receiver and TV to select the external input to hear sound

from the player. Refer to your AV receiver’s user manual to set the AV receiver’s audio input.

HDMI cable

(not included)

HDMI cable

(not included)

24 English

Connections

Case 2 : Connecting to an Audio System (AV receiver with Dolby Digital or DTS decoder) - Better Quality

Using an optical cable, connect the DIGITAL

1. AUDIO OUT (OPTICAL) terminal on the rear of the player to the DIGITAL AUDIO IN (OPTICAL) terminal of your AV receiver.

Using the video signal cable(s), connect

the HDMI, COMPONENT, or VIDEO OUT terminals on the rear of the player to the HDMI, COMPONENT, or VIDEO IN terminal of your TV. (See pages 20~22)

Turn on the player, TV, and AV receiver.

Press the input select button of the

to select the external input and hear sound from the player. Refer to your manual to set the

Press the input selector on your TV remote

control to select the video source (HDMI, Component, or Video.)

AV receiver’s

receiver

user

audio input.

Case 3 : Connecting to an Audio System (Stereo Amplifier)

- Good Quality

Using the audio cables, connect the AUDIO

1. OUT (red and white) terminals on the rear of

the player to the AUDIO IN (red and white) terminals of your Stereo Amplifier.

Using the video signal cable(s), connect

the HDMI, COMPONENT, or VIDEO OUT terminals on the rear of the player to the HDMI, COMPONENT, or VIDEO IN terminal of your TV. (See pages 20~22)

Turn on the player, TV and Stereo Amplifier.

Press the input select button of the

Amplifier

to select the external input in order to hear sound from the player. Refer to your Stereo Amplifier’s Amplifier’s

Press the input selector on your TV remote control to select the video source (HDMI, Component, or Video.)

user manual to set the

audio input.

Stereo

Case 2 : Optical cable

(not included)

WhiteRed

NOTE

✎

If you use the Digital Audio connection described in Case 2, you will hear only front two speakers with Digital Output

▪

setting as PCM.

Case 3 : Audio cable

English 25

04 Connections

Connecting to the Network

This player lets you use network based services (See pages 54~63) such as Smart Hub and BD-LIVE, and software upgrades when it is connected to a network. We recommend using an AP (Access Point) or IP router for the connection. For more information on router connections, refer to the user manual of the router or contact the router manufacturer for technical assistance.

Cable Network

Using the Direct LAN Cable (UTP cable), connect the LAN terminal of the player to the LAN terminal

of your modem or router.

To set the network options, see pages 36~40.

Router

Broadband modem

(with integrated router)

Broadband

service

NOTE

✎

Internet access to Samsung’s software update server may not be allowed, depending on the router you use or your ISP’s

▪

policy. For more information, contact your ISP (Internet Service Provider).

For DSL users, please use a router to make a network connection.

▪

To use the AllShare function, you must connect your PC to your network as shown in the figure.

▪

The connection can be wired or wireless.

Networking with PC for AllShare function

Broadband modem

Broadband service

26 English

Connections

Wireless Network

You can connect to network with a Wireless IP sharer (a router or a modem).

A wireless AP/IP router and the Samsung Wireless LAN Adapter is required to make a wireless

network connection. Connect the Wireless LAN adapter (not included) to the Wireless LAN Adapter jack on the rear panel of the player. See the diagram below.

To set the network options, see pages 36~40.

Broadband

service

Wireless LAN Adapter

Networking with PC for AllShare function

Wireless IP sharer

(not included)

NOTE

✎

Use only the Samsung wireless LAN adapter with this player. (Model name : WIS09ABGN).

▪

Do not use this wireless adapter with any third-party players. To purchase the Samsung wireless LAN adapter, visit your Samsung retailer.

You must use a wireless IP sharer that supports IEEE 802.11 a/b/g/n. (n is recommended for stable operation of the

▪

wireless network.)

Wireless LAN, by its nature, may cause interference, depending on the operating conditions (AP performance, distance,

▪

obstacles, interference by other radio devices, etc).

Set the wireless IP sharer to Infrastructure mode. Ad-hoc mode is not supported.

▪

The player supports only the following wireless security key protocols :

▪

WEP (OPEN/SHARED), WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES)

Due to changes in WiFi policy, this player cannot support the TKIP encryption method in the 802.11n mode.

▪

To use the AllShare function, you must connect your PC to your network as shown in the figure.

▪

The connection can be wired or wireless.

English 27

Setup

Initial Settings

Turn on your TV after connecting the player.

When you connect the player to a TV for the first time, player turns on automatically and the Initial Settings screen appears.

Initial Settings | On-Screen Language

Select a language for the on-screen displays.

Български Hrvatski Čeština Dansk Nederlands Eesti keel Suomi Français Deutsch Ελληνικά Magyar Indonesia Italiano

Press the ▲▼◄► buttons to select the

desired language, and then press the ENTER button.

Press the ENTER button to select Start.

Press the ▲▼ buttons to select the desired

TV Aspect Ratio, and then press the ENTER button. (See page 30)

Press the ▲▼ buttons to select the desired

5. Network Settings : Wired, Wireless (General), WPS(PBC) or One Foot Connection, and then press the ENTER

button. If you do not know the details of your Network Settings, press the BLUE (D) button on your remote instead to skip Network Settings here, finish the Initial Settings, and go to the Home menu. If you selected a Network Setting, go to pages 36~40 for more information about the Network settings. When done, go to Step 6.

The Home menu appears. (For more

information about the Home menu, please see page 28.)

English

한국어

m Move " Enter

Home Menu

•

My Contents

Videos

Photos Music

My Devices Internet Settings

NOTE

✎

When the player is connected to the TV for the first

▪

time, the player turns on automatically. This is not a malfunction.

The Home menu will not appear if you do not

▪

configure the initial settings except as noted below. If you press the BLUE (D) button during the network

▪

setup, you can access the Home menu even if the network setup is not completed yet.

If you want to display the Initial Setting screen again

▪

to make changes, select the Reset option. (See page

41)

If you use an HDMI cable to connect the player to an

▪

Anynet+(HDMI-CEC)-compliant Samsung TV and

1.) You have set the Anynet+(HDMI-CEC) feature to On in both the TV and the player and 2.) You have set the TV to a language supported by the player, the player will select that language as the preferred language automatically.

If you leave the player in the stop mode for more

▪

than 5 minutes without using it, a screen saver will appear on your TV. If the player is left in the screen saver mode for more than 20 minutes, the power will automatically turn off.

05 Setup

d PBC(WPS)

28 English

Setup

2D�3D

POWER

SOURCE

DISC MENU TITLE MENUMENU

SUBTITLE

AUDIO

INFO

POPUP

TOOLS

EXITRETURN

1 2 3

4 5 6

7 8 9

BONUSVIEW

Accessing the Settings Menu

2 4

MENU Button : Press to move to the Home menu.

RETURN Button : Return to the previous menu.

ENTER / DIRECTION Button : Move the cursor or select an item.

Activate the currently selected item. Confirm a setting.

EXIT Button : Press to exit the current menu.

Press the ◄► buttons to select Settings,

and then press the ENTER button.

Press the ▲▼ buttons to select the desired

submenu, and then press the ENTER button.

Press the ▲▼ buttons to select the desired

item, and then press the ENTER button.

Press the EXIT button to exit the menu.

NOTE

✎

When the player is connected to a network, select

▪

Smart Hub from the Home menu. Download the desired content from Samsung Apps. (See pages 61~63)

The access steps may differ depending on the menu

▪

you selected.

The OSD (On Screen Display) may change in this

▪

player after you upgrade the software version.

Settings menu

•

To access the Settings menu and sub-menus, follow these steps:

Press the POWER button.

The Home Menu appears.

Home Menu

•

My Contents

Videos

Photos

Music

My Devices Internet Settings

Selects My Devices.

Selects My Contents.

Selects Internet.

Selects Settings.

Displays the buttons available.

d PBC(WPS)

Settings

Display

Audio Network System Language Security General Support

Above : The Settings menu showing the 3D

Settings sub-menu.

3D Settings

3D Blu-ray Playback Mode : Auto Screen Size :

Move " Enter ' Return

HDMI Deep Color : Auto

inch

The following menu items are on the Settings Menu :

Display

•

Audio

• Network

• System

• Language

• Security

• General

• Support

•

The menu items are addressed in the order listed above on the following pages, starting with Display.

English 29

05 Setup

Display

You can configure various display options such as the TV Aspect Ratio, Resolution, etc.

3D Settings

Select whether to play a Blu-ray Disc with 3D contents in 3D Mode.

Settings

Display

Audio Network System Language Security General Support

3D Blu-ray Playback Mode

You can choose whether to watch a 3D Blu-ray Disc in 3D or 2D mode before playing the 3D disc. It is automatically played in 2D mode if your TV cannot support 3D contents.

Auto : Automatically detect the 3D capability of

• the connected TV and play a 3D Blu-ray Disc in 3D or 2D accordingly.

3D  3D : 3D Blu-ray Discs are played in 3D

• mode at all times. If a TV cannot support 3D Blu-ray Discs, the playing screen can be blank.

3D  2D : 3D Blu-ray Discs are played in 2D

• mode at all times. Choose this to view a picture without the 3D effect or when a TV cannot support 3D Blu-ray Discs.

NOTE

✎

For some 3D discs, to stop a movie during 3D

▪

playback, press the STOP ( ) button once. The movie stops and the 3D mode option is de-activated. To change a 3D option selection when you are playing a 3D movie, press the STOP ( ) button once. The Blu-ray menu appears. Press the STOP ( ) button again, then select 3D Settings in the Blu-ray menu.

Depending on the content and the position of the

▪

picture on your TV screen, you may see vertical black bars on the left side, right side, or both sides.

3D Settings

3D Blu-ray Playback Mode : Auto Screen Size :

Move " Enter ' Return

HDMI Deep Color : Auto

inch

Screen Size

Lets you enter the actual screen size of your TV so that the player can adjust the image according to the screen size and display an optimal 3D image. (For 3D displays bigger than 116 inches, simply setting it as 116 is also a safe choice.)

CAUTION

If you want to enjoy 3D content, connect a 3D device

▪

(3D compliant AV receiver or TV) to the player’s HDMI OUT port using a high-speed HDMI cable. Put on 3D glasses before playing the 3D content.

The player outputs 3D signals only through HDMI

▪

cable connected to the HDMI OUT port.

As the video resolution in 3D play mode is fixed

▪

according to the resolution of the original 3D video, you can not change the resolution to your preference.

Some functions such as BD Wise, screen size

▪

adjustment, and resolution adjustment may not operate properly in 3D play mode.

You must use a high-speed HDMI cable for proper

▪

output of the 3D signal.

Stay at least three times the width of the screen from

▪

the TV when watching 3D images. For example, if you have a 46 inch screen, stay 138 inches (11.5 feet) from the screen.

Place the 3D video screen at eye level for the

best 3D picture.

When the player is connected to some 3D devices,

▪

the 3D effect may not function properly.

This player does not convert 2D content into 3D.

▪

“Blu-ray 3D” and “Blu-ray 3D” logo are trademarks

▪

of the Blu-ray Disc Association.

30 English

Setup

TV Aspect

Depending on the type of television you have, you may want to adjust the screen size setting.

16:9 Original : Select when you connect the

• player to a 16:9 TV screen. The player will display all content in its original aspect ratio. Content formatted in 4:3 will be displayed with black bars on the left and right.

16:9 Full : Select when you connect the player

• to a 16:9 TV screen. All content will fill the full screen. Content formatted in 4:3 will be stretched.

4:3 Letter Box : Select when you connect the

• player to a 4:3 TV screen. The player will display all content in its original aspect ratio. Content formatted in 16:9 will be displayed with black bars on the top and bottom.

4:3 Pan-Scan : Select when you connect the

• player to a 4:3 TV screen. 16:9 content will have the extreme left and right portions cut off.

NOTE

✎

Depending on the disc type, some aspect ratios may

▪

not be available.

If you select an aspect ratio and option which is

▪

different than the aspect ratio of your TV screen, then the picture might appear to be distorted.

If you select the 16:9 Original, your TV may display

▪

4:3 Pillarbox (black bars on sides of picture).

Smart Hub Screen Size

Set the Smart Hub Screen to the optimal size.

Size 1 : Smart Hub screen size will be smaller

• than default. You may see some black on sides of screen.

Size 2 : This is the default setting for Smart

• Hub. The player displays the normal Smart Hub screen size.

Size 3 : This will display a larger Smart Hub

• screen size. The image may be too large for your TV screen.

BD Wise (Samsung Players only)

BD Wise is Samsung’s latest inter-connectivity feature.

When you connect a Samsung player and a Samsung TV with BD Wise to each other via HDMI, and BD Wise is on in both the player and TV, the player outputs video at the video resolution and frame rate of the Blu-ray Disc/DVDs.

Off : The output resolution stays fixed at the

• resolution you set previously in the Resolution menu, regardless of the resolution of the disc. See Resolution below.

On :

The player outputs video at the original

• resolution and frame rate of the Blu-ray Disc/DVDs.

NOTE

✎

When BD Wise is on, the Resolution setting

▪

automatically defaults to BD Wise and BD Wise appears in the Resolution menu.

If the player is connected to a device that does not

▪

support BD Wise, you can not use the BD Wise function.

For proper operation of BD Wise, set the BD Wise

▪

menu of both the player and the TV to On.

Resolution

Lets you set the output resolution of the Component and HDMI video signal to Auto, 1080p, 1080i, 720p, 480p, or 480i. The number indicates the number of lines of video per frame. The i and p indicate interlaced and progressive scan, respectively. The more lines, the higher the quality.

Auto : Automatically sets the output resolution

• to the connected TV’s maximum resolution.

BD Wise : Automatically sets the resolution to

• the resolution of the Blu-ray Disc/DVDs if you have connected the player via HDMI to a TV with the BD Wise feature. (The BD Wise menu item appears only if BD Wise is set to On. See BD Wise above.)

1080p : Outputs 1080 lines of progressive

• video.

1080i : Outputs 1080 lines of interlaced video.

• 720p : Outputs 720 lines of progressive video.

• 480p : Outputs 480 lines of progressive video.

• 480i : Outputs 480 lines of interlaced video.

•

English 31

05 Setup

Resolution according to the output mode

Blu-ray Disc/E-contents/Digital Contents playback

•

HDMI / connected HDMI / not connected

Setup

BD Wise

1080p@60F 1080p@60F 1080p@60F 480i - - -

Movie Frame : Auto (24Fs) 1080p@24F 1080p@24F 480i - - -

1080i 1080i 1080i 480i 480i 1080i 480i

720p 720p 720p 480i 480i 720p 480i

480p 480p 480p 480i 480i 480p 480i

DVD playback

•

Setup

BD Wise 480i 480i - -

1080p@60F 1080p@60F 480i - -

1080i 1080i 480i 480p 480i

720p 720p 480i 480p 480i

480p 480p 480i 480p 480i

Output

Auto

480i - - - 480i 480i 480i

Output

Auto

480i - - 480i 480i

HDMI Mode

Blu-ray Disc

Resolution of

Blu-ray Disc

Max.

Resolution of

TV input

Max. Resolution of TV

E-contents/

Digital

contents

1080p@60F 480i - - -

Max.

Resolution of

TV input

HDMI / connected HDMI / not connected

HDMI Mode

input

Component/ VIDEO Mode

480i - - -

Component/VIDEO Mode

480i - -

Component Mode

Blu-ray Disc

Component Mode VIDEO Mode

E-contents/

Digital

contents

VIDEO Mode

32 English

Setup

NOTE

✎

If the TV you connected to the player does not

▪

support Movie Frame or the resolution you selected, the message “If no pictures are shown after selecting ‘Yes’, please wait for 15 seconds to return to the previous resolution. Do you want to change the resolution?” appears. If you select Yes, the TV’s screen will go blank for 15 seconds, and then the resolution will revert to the previous resolution automatically.

If the screen stays blank after you have changed the

▪

resolution, remove all discs, and then press and hold the STOP ( ) button on the front of the player for more than 5 seconds. All settings are restored to the factory default. Follow the steps on the previous page to access each mode and select the Display Setup that your TV will support.

When the factory default settings are restored, all

▪

stored user BD data is deleted.

The Blu-ray Disc must have the 24 frame feature for

▪

the player to use the Movie Frame (24Fs) mode.

If both HDMI and Component jacks are connected

▪

and you are currently viewing Component output, the resolution is fixed to 480i.

HDMI Color Format

Lets you set the color space format for HDMI output to match the capabilities of the connected device (TV, monitor, etc).

Auto : Automatically sets the player to the

• optimum format supported by your device.

YCbCr (4:4:4) : If your TV supports the YCbCr

• color space via HDMI, select this to output the normal YCbCr color gamut.

RGB (Standard) : Select this to output the

• normal RGB color gamut.

RGB (Enhanced) : If you have connected the

• player to a DVI display device such as a monitor, select this to output the enhanced RGB color gamut.

Movie Frame (24Fs)

Setting the Movie Frame (24Fs) feature to Auto allows you to adjust the player’s HDMI output to 24 frames per second for improved picture quality. You can enjoy the Movie Frame (24Fs) feature only on a TV supporting this frame rate. You can select Movie Frame only when the player is in the HDMI 1080i or 1080p output resolution modes.

Auto : Movie Frame (24Fs) functions work.

• Off : Movie Frame (24Fs) functions are off.

•

English 33

05 Setup

HDMI Deep Color

Lets you output video from the HDMI OUT jack with Deep Color. Deep Color provides more accurate color reproduction with greater color depth.

Auto : The player outputs video with Deep Color

• to a connected TV which supports HDMI Deep Color.

Off : The picture is output without Deep Color.

•

Still Mode

Lets you set the type of picture the player displays when you pause DVD playback.

Auto : Automatically shows the best still picture

• depending on the content.

Frame : Select when pausing a scene with a

• little action.

Field : Select when pausing a scene with a lot

• of action.

Progressive Mode

Lets you improve picture quality when viewing DVDs.

Auto :

•

Select to have the player automatically select the best picture quality for the DVD you’re watching.

Video : Select for the best picture quality from concert or TV show DVDs.

Audio

Digital Output

You set the Digital Output to match the capabilities of the AV receiver you’ve connected to the player :

PCM : Choose if you have connected an HDMI

• supported AV receiver.

Bitstream (Unprocessed) : Select if you have

• connected an HDMI supported AV receiver with Dolby TrueHD and DTS-HD Master Audio decoding capabilities.

Bitstream (Re-encoded DTS) : Choose if you

• have connected an AV receiver using a Digital Optical input that can decode DTS.

Bitstream (Re-encoded Dolby D) : Select if

• you don’t have an HDMI supported AV receiver, but have an AV receiver with Dolby Digital decoding capabilities.

For more details, please refer to the digital output selection table. (See page 34)

34 English

Setup

Digital Output Selection

Setup PCM

Connection

PCM Up to 7.1ch PCM 2ch PCM PCM 2ch DTS re-encoded

Dolby Digital Up to 7.1ch PCM 2ch Dolby Digital Dolby Digital DTS re-encoded

Dolby Digital

Audio Stream

on Blu-ray

Disc

Audio Stream

on DVD

Definition for

Blu-ray Disc

* If the Source Stream is 2ch, “Re-encoded Dolby D” Setting are not applied. Output will be LPCM 2ch.

Plus

Dolby TrueHD Up to 7.1ch PCM 2ch Dolby TrueHD Dolby Digital DTS re-encoded

DTS Up to 5.1ch PCM 2ch DTS DTS DTS re-encoded

DTS-HD HRA Up to 5.1ch PCM 2ch DTS-HD HRA DTS DTS re-encoded

DTS-HD MA Up to 5.1ch PCM 2ch DTS-HD MA DTS DTS re-encoded

PCM PCM 2ch PCM 2ch PCM 2ch PCM 2ch PCM 2ch PCM 2ch

Dolby Digital Up to 5.1ch PCM 2ch Dolby Digital Dolby Digital Dolby Digital Dolby Digital

DTS Up to 5.1ch PCM 2ch DTS DTS DTS DTS

Any

HDMI

supported

AV receiver

Up to 7.1ch PCM 2ch

Decodes the main feature

audio and BONUSVIEW

audio stream together

into PCM audio and adds

Navigation Sound Effects.

Optical

Bitstream

(Unprocessed)

HDMI

supported

AV receiver

Dolby Digital

Plus

Outputs only the main feature audio stream so that your AV receiver can decode

the audio bitstream.

You will not hear

BONUSVIEW audio or

Navigation Sound Effects.

Optical

Dolby Digital DTS re-encoded

Bitstream

(Re-encoded

DTS)

HDMI supported

AV receiver or

Optical

Decodes the main feature audio and BONUSVIEW audio

stream together

into PCM audio and

adds Navigation

Sound Effects, then

re-encodes the

PCM audio into DTS

bitstream.

Bitstream

(Re-encoded

Dolby D)

HDMI supported

AV receiver or

Optical

Re-encoded

Dolby Digital *

Re-encoded

Dolby Digital *

Re-encoded

Dolby Digital *

Re-encoded

Dolby Digital *

Re-encoded

Dolby Digital *

Re-encoded

Dolby Digital *

Re-encoded

Dolby Digital *

Decodes the main

feature audio and

BONUSVIEW audio

stream together

into PCM audio and

adds Navigation

Sound Effects, then

re-encodes the PCM

audio into Dolby

digital bitstream or

PCM.

Blu-ray Discs may include three audio streams :

Main Feature Audio : The audio soundtrack of the main feature.

BONUSVIEW audio : An additional soundtrack such as the director or actor’s commentary.

Navigation Sound Effects : When you choose some menu navigation, Navigation Sound Effects may

sound. Navigation Sound Effects are different on each Blu-ray Disc.

English 35

05 Setup

NOTE

✎

Be sure to select the correct Digital Output or you

▪

will hear no sound or just loud noise.

If the HDMI device (AV receiver, TV) is not compatible

▪

with compressed formats (Dolby digital, DTS), the audio signal outputs as PCM.

Regular DVDs do not have BONUSVIEW audio and

▪

Navigation Sound Effects.

Some Blu-ray Discs do not have BONUSVIEW audio

▪

and Navigation Sound Effects.

This Digital Output setup does not effect the analog

▪

(L/R) audio or HDMI audio output to your TV. It effects the optical and HDMI audio output when your player is connected to an AV receiver.

If you play MPEG audio soundtracks, the audio signal

▪

outputs as PCM regardless of your Digital Output selections (PCM or Bitstream).

PCM Downsampling

Lets you set 48kHz and 96kHz PCM downsampling on or off.

Off : Select when the AV receiver connected to

• the player is 96kHz compatible.

On : Select when the AV receiver connected

• to the player is not 96kHz compatible. 96kHz signals will be down converted to 48kHz.

NOTE

✎

Even when PCM Downsampling is set to Off, some

▪

discs will only output downsampled audio through the optical digital outputs.

Dynamic Range Control

You can listen at low volumes, but still hear dialog clearly. This is only active if your player detects a Dolby Digital signal.

Auto : The Dynamic Range Control will be set

• automatically based on the information provided by the Dolby TrueHD Soundtrack.

Off : You can enjoy the movie with the standard

• Dynamic Range.

On : When Movie soundtracks are played at low

• volume or through smaller speakers, the system can apply appropriate compression to make low-level content more intelligible and prevent dramatic passages from getting too loud.

Downmixing Mode

Lets you select how the player will downmix multichannel audio into fewer channels.

Normal Stereo : Downmixes the multi-channel

• audio into two channel stereo. Choose when connected to equipment that does not support virtual surround functions such as Dolby Pro Logic.

Surround Compatible : Downmixes multi-

• channel audio into surround compatible stereo. Choose when connected to equipment that supports virtual surround functions such as Dolby Pro Logic.

HDMI

If your TV is not compatible with compressed

• multi-channel formats (Dolby Digital, DTS), the player may output PCM 2ch downmixed audio even though you selected Bitstream (either Reencoded or Unprocessed) in the setup menu.

If your TV is not compatible with PCM sampling

• rates over 48kHz, the player may output 48kHz downsampled PCM audio even though you set PCM Downsampling to Off.

36 English

Setup

Network

Before you begin, contact your ISP to find out if your IP address is static or dynamic. If it is dynamic, and you are using a wired or wireless connection, we recommend using the Auto procedures. If you are using a wireless connection and your router has the capability, you can use WPS(PBC) or One Foot Connection.

If your IP address is static, you must use the manual set up procedure for both wired and wireless connections.

Network Settings

To begin setting up the network connection for your player, follow these steps:

In the Home menu, press the ◄► buttons to

select Settings, and then press the ENTER button.

Press the ▲▼ buttons to select Network, and

then press the ENTER button.

Press the ▲▼ buttons to select Network

3. Settings, and then press the ENTER button.

Press the ▲▼ buttons to select Wired,

4. Wireless (General), WPS(PBC) or One Foot Connection, and then press the ENTER

button.

If you have a wired network, go to Wired

Network below. If you have a wireless network, go to Wireless Network on pages 37~39.

Wired Network

Setting Up a Wired Connection - Auto

Press the ▲▼ buttons to select Wired.

Settings

Display Audio

Network

System Language Security General Support

Press the ENTER button.

The Network Status screen appears. The player connects to the network after the network connection is verified.

Setting Up a Wired Connection - Manual

If you have a static IP address or the Auto Setting does not work, you’ll need to set the Network Settings values manually.

To view your Network Settings values on most Windows computers, follow these steps:

Windows XP



Right click the Network icon on the bottom

right of the Windows desktop.

In the pop-up menu, click Status.

On the dialog that appears, click the Support

tab.

On the Support tab, click the Details button.

The Network settings are displayed.

Windows 7



Click the Network icon on the bottom right of

the Windows desktop.

In the pop-up menu, click Network and

Sharing Center.

Network Settings

Select a network connection type.

Wired

Wireless

(General)

Connect to the network using LAN cable. Please make

WPS(PBC)

sure that the LAN cable is connected.

One Foot

Connection

Move " Enter ' Return

English 37

05 Setup

On the dialog that appears, click the Local Area Connection or Wireless Network Connection depending on your network connection.

On the Support tab, click the Details button. The Network settings are displayed.

NOTE

✎

Depending on your Windows version, the information

▪

may differ.

To enter the Network settings into your player, follow these steps:

Press the ▲▼ buttons to select Wired, and then press the ENTER button.

Press the ◄► buttons to select IP Settings, and then press the ENTER button.

On the Network Status screen, select Cancel, and then press Enter.

Settings

Display Audio

IP Mode Manual

Network

System Language

DNS Mode Manual

Security General Support

Press the ENTER button to select IP Mode.

Press the ▲▼ buttons to select Manual, and

IP Address Subnet Mask Gateway

DNS Server

IP Settings

0.0.0.0

Move " Enter ' Return

then press the ENTER button.

Press the ▼ button to go to the first entry field (IP Address).

Use the number buttons on your remote to enter numbers.

When done with each field, press the ► button to move successively to the next field. You can also use the other arrow buttons to move up, down, and back.

Enter the IP Address, Subnet Mask, and Gateway values.

Press the ▼ button to go to DNS Mode.

10.

Press the ▼ button to go to the first DNS

11.

entry field. Enter the numbers as above.

Press the ENTER button to select OK.

12.

The Network Status screen appears. The player connects to the network after the network connection is verified.

Wireless Network

You can setup a wireless network three ways:

Wireless (General)

• Using WPS(PBC)

• One Foot Connection

•

Wireless (General) includes both Automatic and Manual setup procedures.

Setting Up the Wireless Network Connection

- Auto

Most wireless networks have an optional security system that requires devices that access the network to transmit an encrypted security code called an Access or Security Key. The Security Key is based on a Pass Phrase, typically a word or a series of letters and numbers of a specified length you were asked to enter when you set up security for your wireless network. If you use this method of setting up the network connection, and have a Security Key for your wireless network, you will have to enter the Pass Phrase during the Auto setup process.

Press the ▲▼ buttons to select Wireless

(General).

Settings

Display

Select a network connection type.

Audio

Network

Wired

System

Wireless

Language

(General)

Security

WPS(PBC)

General

One Foot

Connection

Support

Press the ENTER button.

When done, it displays a list of the available networks.

Network Settings

Set up wireless network by selecting your Wireless Router. You may need to enter security key depending on the setting of the Wireless Router.

Move " Enter ' Return

38 English

Setup

Press the ▲▼ buttons to select the desired

network, and then press the ENTER button. The Security screen appears.

On the Security screen, enter your network’s

Pass Phrase. Enter numbers directly using your remote control. To select a letter, press the ▲▼◄► buttons to move the cursor, then press the ENTER button.

Settings

Display Audio

Network

System Language Security General Support

NOTE

✎

You should be able to find the Pass Phrase on one of

▪

the set up screens you used to set up your router or modem.

When done, press the GREEN (B) button on

your remote, or press the ▲▼◄► buttons to move the cursor to Done, and then press the ENTER button. The Network Status screen appears. The player connects to the network after the network connection is verified.

Setting Up the Wireless Network Connection

- Manual

If the Auto Setting does not work, you need to enter the Network setting values manually.

To view the Network Settings values on most Windows computers, follow these steps:

Windows XP



Right click the Network icon on the bottom

right of the Windows desktop.

In the pop-up menu, click Status.

On the dialog that appears, click the Support

tab.

On the Support tab, click the Details button.

The Network settings are displayed.

Network Settings

Enter security key. 0 entered

a b c d e f 1 2 3

g h i j k l 4 5 6 m n o p q r 7 8 9 s t u v w x y z 0

a/A * Delete Space Done

Previous m Move " Enter ' Return

Windows 7



Click the Network icon on the bottom right of

the Windows desktop.

In the pop-up menu, click Network and

Sharing Center.

On the dialog that appears, click the Local

Area Connection or Wireless Network Connection depending on your network connection.

On the Support tab, click the Details button.

The Network settings are displayed.

NOTE

✎

Depending on your Windows version, the information

▪

may differ.

To enter the Network settings into your player, follow these steps:

Follow Steps 1 through 4 in the ‘Setting Up

the Wireless Network Connection - Auto’ procedure.

When done, press the GREEN (B) button on

your remote, or press the ▲▼◄► buttons to move the cursor to Done, and then press the ENTER button. The Network Status screen appears.

Settings

Display Audio

IP Mode Manual

Network

System Language

DNS Mode Manual

Security General Support

On the Network Status screen, select Cancel,

IP Address Subnet Mask Gateway

DNS Server

IP Settings

0.0.0.0

Move " Enter ' Return

and then press Enter.

Press the ◄► buttons to select IP Settings,

and then press the ENTER button.

Press the ENTER button to select IP Mode.

Press the ▲▼ buttons to select Manual, and

then press the ENTER button.

Press the ▼ button to go to the first entry field

(IP Address).

English 39

05 Setup

Use the number buttons to enter numbers.

When done with each field, press the ►

button to move successively to the next field. You can also use the other arrow buttons to move up, down, and back.

Enter the IP Address, Subnet Mask, and

10. Gateway values.

Press the ▼ to go to DNS Mode.

11.

Press the ▼ button to go to the first DNS

12.

entry field. Enter the numbers as above.

Press the OK button.

13.

The Network Status screen appears. The

14.

player connects to the network after the network connection is verified.

WPS(PBC)

The easiest way to set up the wireless network connection is using the WPS(PBC) function or the One Foot Connection function.

If your wireless router has a WPS(PBC) button, follow these steps:

Press the ▲▼ buttons to select WPS(PBC).

Settings

Display

Select a network connection type.

Audio

Network

Wired

System

Wireless

Language

(General)

Security

WPS(PBC)

General

One Foot

Connection

Support

Press the ENTER button.

Press the WPS(PBC) button on your router

within two minutes. Your player automatically acquires all the network settings values it needs and connects to your network.

The Network Status screen appears. The

player connects to the network after the network connection is verified.

Network Settings

Connect to the Wireless Router easily by pressing the WPS(PBC) button. Choose this if your Wireless Router supports Push Button Conﬁguration(PBC).

Move " Enter ' Return

One Foot Connection

You can set up the wireless connection automatically if you have a Samsung Wireless Router which supports One Foot Connection. To connect using the One Foot Connection function, follow these steps:

Press the ▲▼ buttons to select One Foot

1. Connection.

Settings

Display

Select a network connection type.

Audio

Network

Wired

System

Wireless

Language

(General)

Security

WPS(PBC)

General

One Foot

Connection

Support

Press the ENTER button.

Place the Samsung Wireless Router within 25

Network Settings

Connect to wireless network automatically if your Wireless Router supports One Foot Connection. Select this connection type after placing the Wireless Router within 10 inches(25cm) of Samsung Wireless LAN Adapter.

Move " Enter ' Return

cm (10 inches) of your player to connect.

Wait until the connection is automatically

established.

Network Status

Check whether a connection to the network and the Internet have been established.

Settings

Display Audio

Network

System

Internet is connected successfully.

Language

If you have a problem using any Internet services, contact your Internet service

Security

provider.

General Support

KT_WLAN

Network Status

MAC Address XX:XX:XX:XX:XX:XX IP Address 0.0.0.0 Subnet Mask 0.0.0.0 Gateway 0.0.0.0 DNS Server 0.0.0.0

IP Settings Retry OKNetwork Settings

< Move " Enter ' Return

40 English

Setup

BD-LIVE Internet Connection

Set to allow or prohibit an Internet connection when you use the BD-LIVE service.

Allow (All) : The Internet connection is allowed

• for all BD-LIVE contents.

Allow (Valid Only) : The Internet connection is

• allowed only for BD-LIVE contents containing a valid certificate.

Prohibit : No Internet connection is allowed for

• any BD-LIVE content.

NOTE

✎

What is a valid certificate?

▪

When the player uses BD-LIVE to send the disc data and a request to the server to certify the disc, the server uses the transmitted data to check if the disc is valid and sends the certificate back to the player.

The Internet connection may be restricted while you

▪

are using BD-LIVE contents.

System

Initial Settings

By using the Initial Settings function, you can set the language, Network Settings, etc. For more information about the Initial Settings function, refer to the Initial Settings section of this user manual. (See pages 27~44)

Anynet+(HDMI-CEC)

Anynet+ is a convenient function that offers linked operations with other Samsung players that have the Anynet+ feature. To operate this function, connect this player to a Samsung TV with an HDMI cable. With Anynet+ on, you can operate this player using a Samsung TV remote control and start disc playback simply by pressing the PLAY ( ) button on the TV’s remote control. For more information, please see the TV user manual.

Off : Anynet+ functions will not work.

• On : Anynet+ functions will work.

•

NOTE

✎

This function is not available if the HDMI cable does

▪

not support CEC.

If your Samsung TV has an Anynet+ logo, then it

▪

supports the Anynet+ function.

Depending on your TV, certain HDMI output

▪

resolutions may not work. Please refer to the user manual of your TV.

BD Data Management

Lets you manage the downloaded contents you accessed through a Blu-ray Disc that supports the BD-LIVE service and stored on an attached Flash memory device.

You can check the device’s information including the storage size, delete the BD data, or change the Flash memory device.

BD Data Management Screen Information :

Total Size : Total memory size of the device.

•

Available Size : Available memory in the device.

•

NOTE

✎

In the external memory mode, disc playback may

▪

be stopped if you disconnect the USB device in the middle of playback.

Only those USB devices formatted in FAT file

▪

system (DOS 8.3 volume label) are supported. We recommend you use USB devices that support USB

2.0 protocol with 4 MB/sec or faster read/write speed.

The Resume Play function may not work after you

▪

format the storage device.

The total memory available to BD Data Management

▪

may differ, depending on the conditions.

English 41

05 Setup

Time Zone

You can specify the time zone that is applicable to your area.

Settings

Display Audio Network

System

Language Security General Support

Time Zone

GMT + 00:00

London, Lisbon, Casablanca

Change " Save ' Return

Security

This function works in conjunction with Blu-ray Disc/DVDs that have been assigned an age rating or numeric rating that indicates the maturity level of the content. These numbers help you control the types of Blu-ray Disc/DVDs that your family can watch.

Select an age rating you want to set for the BD Parental Rating and a rating level you want to set for the DVD Parental Rating. The player will only play Blu-ray Discs rated at or below the age rating and DVDs rated below the numeric rating unless the password is entered.

Larger numbers indicate more mature content.

DivX® Video On Demand

View DivX® VOD Registration Codes to purchase and play DivX® VOD contents.

Reset

All settings will revert to the default except for the network and Smart Hub settings.

Language

You can select the language you prefer for the Home menu, disc menu, etc.

On-Screen Menu : Select the language for the

• on-screen displays.

Disc Menu : Select the language for the disc

• menu displays.

Audio : Select the language for disc audio.

• Subtitle : Select the language for disc subtitles.

•

NOTE

✎

The selected language will only appear if it is

▪

supported on the disc.

BD Parental Rating

Prevent playback of Blu-ray Discs with specific age ratings unless a password is entered.

DVD Parental Rating

Prevent playback of DVDs with specific numerical ratings unless a password is entered.

Change Password

Change the 4-digit password used to access security functions.

If you forgot your password

Remove the disc.

Press and hold the STOP ( ) button on the

front panel for 5 seconds or more. All settings will revert to the factory settings.

NOTE

✎

When the factory default settings are restored, all

▪

the user stored BD data will be deleted.

42 English

Setup

General

Front Display

Change the brightness of the front panel.

Auto : Dim during playback.

•

Dim : Dim the display window.

•

Bright : Brighten the display window.

•

Network Remote Control

The Network Remote Control function lets you control your Blu-ray Disc player from a remote device such as a smart phone through a wireless connection to your local area network.

To use the Network Remote Control function, follow these steps:

Select On in the Network Remote Control

menu.

Install the Samsung network remote control

application to control your player on your compatible portable device.

Make sure your portable device and your

player are connected to the same wireless router.

Start the application on your portable device.

The application should find your player and display it on a list.

Select the player.

If this is the first time you are using the

function, it will ask you to allow or deny remote control of the player. Select Allow.

Follow the instructions that came with the

application to control the player.

Support

Software Upgrade

The Software Upgrade menu allows you to upgrade the player’s software for performance improvements or additional services. You can upgrade in four ways:

By Internet

• By USB

• By Disc

• By Downloaded (File)

•

The four methods are explained below.

By Internet

To upgrade by Internet, follow these steps:

Select By Internet, and then press the

ENTER button. The Connecting to Server

message appears.

If there is a download available, the Download

pop-up appears with a progress bar and the download starts.

When the download is complete, the Upgrade

Query window appears with three choices: Upgrade Now, Upgrade Later, or Don’t Upgrade.

If you select Upgrade Now, the player

upgrades the software, turns off, and then turns on automatically.

If you do not make a selection in one minute

or select Upgrade Later, the player stores the new upgrade software. You can upgrade the software later using the By Downloaded function.

If you select Don’t Upgrade, the player

cancels the upgrade.

NOTE

✎

Your player must be connected to the Internet to use

▪

the By Internet function.

The upgrade is complete when the player turns off,

▪

and then turns on again by itself.

Never turn the player off or back on manually during

▪

the update process.

English 43

05 Setup

Samsung Electronics shall take no legal responsibility

▪

for player malfunction caused by an unstable Internet connection or consumer negligence during a software upgrade.

If you want to cancel the upgrade while the upgrade

▪

software is downloading, press the ENTER button.

By USB

To upgrade by USB, follow these steps:

Visit www.samsung.com/bluraysupport

Download the latest USB software upgrade

zip archive to your computer.

Unzip the zip archive to your computer. You

should have a single folder with the same name as the zip file.

Copy the folder to a USB flash drive.

Make sure the disc tray is empty, and then

insert the USB flash drive into the USB port of the player.

In the player’s menu, go to Settings > Support

> Software Upgrade.

Select By USB.

NOTE

✎

The disc tray must be empty when you upgrade the

▪

software using the USB Host jack.

When the software upgrade is done, check the

▪

software details in the software Upgrade menu.

Do not turn off the player during the software

▪

upgrade. It may cause the player to malfunction.

Software upgrades using the USB Host jack must be

▪

performed with a USB memory flash stick only.

By Disc

To upgrade by Disc, follow these steps:

Visit www.samsung.com/bluraysupport.

Download the latest disc software upgrade

zip archive to your computer.

Unzip the zip archive to your computer. You

should have a single folder with the same name as the zip file.

Write the folder onto a disc. We recommend

a CD-R or DVD-R.

Finalize the disc before you remove it from

your computer.

Insert the disc into player.

In the player’s menu, go to Settings > Support

> Software upgrade.

Select By Disc.

NOTE

✎

When the system upgrade is done, check the

▪

software details in the software Upgrade menu.

Do not turn off the player during the Software

▪

Upgrade. It may cause the player malfunction.

By Downloaded

The By Downloaded option lets you upgrade using a file the player downloaded earlier but you decided not to install immediately or a file downloaded by the player in Standby Mode (See Download in Standby Mode below).

To upgrade By Downloaded, follow these steps:

If upgrade software has been downloaded,

you will see the software version number to the right of By Downloaded.

Select By Downloaded, and then press the

2. ENTER button.

The player displays a message asking if you

want to upgrade. Select Yes. The player begins the upgrade.

When the update is complete, the player turns

off automatically, and then turns on.

NOTE

✎

When the system upgrade is done, check the

▪

software details in the software Upgrade menu.

Do not turn off the player during the software

▪

Upgrade. It may cause the player to malfunction.

Download in Standby Mode

You can set the Download in Standby Mode function so that the player downloads new upgrade software when it is in Standby mode. In Standby mode, the player is off, but its Internet connection is active. This allows the player to download upgrade software automatically, when you are not using it.

44 English

Setup

To set Download in Standby Mode, follow these steps:

Press the ▲▼ buttons to select Download in

1. Standby Mode, and then press the ENTER

button.

Select On or Off.

Off : If you select Off, the player will notify

•

you with a pop up message when new upgrade software is available.

On : If you select On, the player will

•

automatically download new upgrade software when it is in Standby mode with the power off. If it downloads new upgrade software, the player will ask you if you want to install it when you turn the player on.

NOTE

✎

To use the Download in Standby Mode function, your

▪

player must be connected to the Internet.

Contact Samsung

Provides contact information for assistance with your player.

English 45

Basic Functions

Playing a Video

Playback

Press the OPEN/CLOSE ( ) button to

open the disc tray.

Place a disc gently into the tray with the disc’s

label facing up.

Press the OPEN/CLOSE ( ) button to

close the disc tray.

Press the PLAY ( ) button.

Playback related buttons

PLAY ( ) Starts playback.

Stops playback.

If you press the button once : The

STOP ( )

PAUSE ( ) Pauses playback.

•

stop position is memorized. If you press the button twice : The

•

stop position is not memorized.

Disc Structure

The content of discs are usually divided as shown below.

Blu-ray Disc, DVD-VIDEO

•

title 1 title 2

chapter 1 chapter 2 chapter 1 chapter 2 chapter 3

Audio CD (CD-DA)

•

track 1 track 2 track 3 track 4 track 5

MP3, WMA, DivX, MKV and MP4

•

folder (group) 1 folder (group) 2

file 1 file 2 file 1 file 2 file 3

Using the Disc Menu/Title Menu/

Popup Menu

Using the Disc Menu

06 Basic Functions

NOTE

✎

For some discs, pressing the STOP ( ) button

▪

once may not memorize the stop position.

Video files with high bit rates of 20Mbps or more

▪

strain the player’s capabilities and may stop playing during playback.

During playback, press the DISC

1. MENU button on the remote control.

Press the ▲▼◄► buttons to make a

selection, and then press the ENTER button.

NOTE

✎

Depending on the disc, the menu items may differ

▪

and this menu may not be available.

46 English

Basic Functions

Using the Title Menu

During playback, press the TITLE

1. MENU button on the remote control.

Press the ▲▼◄► buttons to make

the desired selection, then press the

ENTER button.

NOTE

✎

Depending on the disc, the menu items may differ

▪

and this menu may not be available.

Playing the Title List

During playback, press the DISC

1. MENU or TITLE MENU button.

Press the ▲▼ buttons to select an

entry you want to play from the Title List, and then press the ENTER button.

NOTE

✎

If your disc has a playlist, press the GREEN (B)

▪

button to go to the playlist.

Using the Search and Skip Functions

During play, you can search quickly through a chapter or track, and use the skip function to jump to the next selection.

Searching for a Desired Scene

hzZyx

During playback, press the SEARCH ( )

• button.

Each time you press the SEARCH ( button, the playback speed will change as follows

BD-ROM,

BD-RE/-R,

DVD-RW/-R,

DVD+RW/+R,

DVD-VIDEO

DivX, MKV, MP4

To return to normal speed playback, press the

•

PLAY ( ) button.

NOTE

✎

The player does not play sound in search mode.

▪

) )

( (

)

(



)

2  ) 3 

)

5  ) 6  ) 7

(

2  ( 3 

(

5  ( 6  ( 7

)

2  ) 3

(

2  ( 3

)

Using the Popup Menu

During playback, press the POPUP

1. MENU button on the remote control.

Press the ▲▼◄► buttons or ENTER

button to select the desired menu.

NOTE

✎

Depending on the disc, the menu items may differ

▪

and this menu may not be available.

Skipping Chapters

hzZyx

During playback, press the SKIP ( )

• button.

If you press the SKIP ( ) button, the disc moves to the next chapter.

If you press the SKIP ( ) button, the disc moves to the beginning of the chapter. One more press makes the disc move to the beginning of the previous chapter.

English 47

06 Basic Functions

Slow Motion Play/Step Motion Play

Slow Motion Play

hzZyx

In pause mode, press the SEARCH ( )

• button.

Each time you press the SEARCH ( ) button, the playback speed will change as follows:

1/8 * 1/4 * 1/2

To return to normal speed playback, press the

•

PLAY ( ) button.

NOTE

✎

The player does not play sound in Slow mode.

▪

NOTE

✎

Depending on the disc, the Tools menu may differ.

▪

Moving to a Desired Scene Directly

hzZy

During playback, press the TOOLS button.

Press the ▲▼ buttons to select Title Search,

2. Chapter Search, or Time Search.

Press the ◄► or number button to select

desired Title, Chapter or Time, then press the

ENTER button.

Repeating the Title or Chapter

Step Motion Play

hzZyx

In pause mode, press the PAUSE ( ) button.

•

Each time you press the PAUSE ( ) button, a new frame appears.

To return to normal speed playback, press the

•

PLAY ( ) button.

NOTE

✎

The player does not play sound in Step mode.

▪

Using the TOOLS button

During playback, you can operate the disc menu by pressing the TOOLS button.

Tools Menu Screen

•

Tools

Title Search 1/2 Chapter Search : 1/20 Time Search : 00:00:13/01:34:37 Repeat Mode : 0ff Full Screen : Original Picture Settings : Normal Audio : 1/1 JPN 2CH Subtitle : 0/2 Off Angle : 1/1 BONUSVIEW Video : Off BONUSVIEW Audio : 0/1 Off

Change

Enter ' Return

hzZy

To repeat the disc title or chapter. Depending on the disc, the Repeat function may

not be available.

During playback, press the TOOLS

button.

Press the ▲▼ buttons to select Repeat Mode.

Press the ◄► buttons to select Chapter or

3. Title, then press the ENTER button.

To return to normal play, press the TOOLS

button again.

Press the ▲▼ buttons to select Repeat Mode.

Press the ◄► buttons to select Off, then

6. press the ENTER button.

48 English

Basic Functions

Repeating a Section

hzZy

During playback, press the TOOLS

button.

Press the ▲▼ buttons to select Repeat Mode.

Press the ◄► buttons to select Repeat A-B,

then press the ENTER button.

Press the ENTER button at the point where

you want repeat play to start (A).

Press the ENTER button at the point where

you want repeat play to stop (B).

To return to normal play, press the TOOLS

button again.

Press the ▲▼ buttons to select Repeat Mode.

Press the ◄► buttons to select Off, and then

8. press the ENTER button.

NOTE

✎

If you set point (B) before 5 seconds has lapsed, a

▪

prohibition message appears.

Depending on the disc, the menu items may differ

▪

and this menu may not be available.

Changing to Full Screen

During playback, press the TOOLS button.

Press the ▲▼ buttons to select Full Screen.

Press the ◄► buttons to select the desired

mode.

NOTE

✎

This function is available when the TV aspect ratio is

▪

16:9 full. (See page 30)

Selecting the Picture Settings

hzZy

This function enables you to adjust video quality when the player is connected to a TV.

During playback, press the TOOLS button.

Press the ▲▼ buttons to select Picture

2. Settings, and then press the ENTER button.

Press the ◄► buttons to select the desired

3. Picture Settings, and then press the ENTER

button.

Dynamic : Choose this setting to increase

•

Sharpness.

Normal : Choose this setting for most

•

viewing applications.

Movie : This is the best setting for watching

•

movies.

User : Lets you adjust the sharpness and

•

noise reduction function respectively.

NOTE

✎

When you use BD wise function, this menu will not

▪

appear.

Selecting the Audio Language

hzZx

You can also operate this function by pressing the AUDIO button on the remote control.

During playback, press the TOOLS button.

Press the ▲▼ buttons to select Audio.

Press the ◄► buttons to select the desired

audio language.

NOTE

✎

The ◄► indicator will not appear on the screen

▪

if the BONUSVIEW section does not contain any BONUSVIEW audio settings.

Information about the main feature/BONUSVIEW

▪

mode will also appear if the Blu-ray Disc has a BONUSVIEW section. Press the ◄► button to switch between main feature and BONUSVIEW audio modes.

English 49

06 Basic Functions

The languages available through the Audio Language

▪

function depend on the languages that are encoded on the disc. This function or certain languages may not be available.

A Blu-ray Disc can contain up to 32 audio languages

▪

and a DVD up to 8.

Some Blu-ray Discs may allow you to select either

▪

the multi-channel LPCM or Dolby digital audio soundtrack in English.

If you press the AUDIO button on the remote control,

▪

Audio bar appears. Press the RETURN button to remove the Audio bar.

Selecting the Subtitle Language

hZx

You can also operate this function by pressing the SUBTITLE button on the remote control.

Changing the Camera Angle

When a Blu-ray Disc/DVD contains multiple angles of a particular scene, you can use the ANGLE function.

During playback, press the TOOLS button.

Press the ▲▼ buttons to select Angle.

Press the ◄► buttons to select the desired

Angle.

Setting BONUSVIEW

The BONUSVIEW feature allows you to view additional content (such as commentaries) in a small screen window while the movie is playing. This function is only available if the disc has the Bonusview feature.

During playback, press the TOOLS button.

Press the ▲▼ buttons to select Subtitle.

Press the ◄► buttons to select the desired

subtitle language.

NOTE

✎

Depending on the Blu-ray Disc / DVD, you may be

▪

able to change the desired subtitle in the Disc Menu. Press the DISC MENU button.

This function depends on the selection of subtitles

▪

that are encoded on the disc and may not be available on all Blu-ray Discs/DVDs.

A Blu-ray Disc can contain up to 255 subtitle

▪

languages and a DVD up to 32.

Information about the main feature/BONUSVIEW

▪

mode will also appear if the Blu-ray Disc has a BONUSVIEW section.

This function changes both the primary and

▪

secondary subtitles at the same time.

The total numbers of primary and secondary

▪

subtitles are displayed respectively. If you press the SUBTITLE button on the remote

▪

control, the subtitle bar appears. Press the RETURN button to remove the subtitle bar.

You can also operate this function by pressing the BONUSVIEW button on the remote control.

During playback, press the TOOLS button.

Press the ▲▼ buttons to select BONUSVIEW

2. Video or BONUSVIEW Audio.

Press the ◄► buttons to select the desired

Bonusview.

NOTE

✎

If you switch from BONUSVIEW Video, BONUSVIEW

▪

Audio will change automatically in accordance with BONUSVIEW Video.

50 English

Basic Functions

2D�3D

POWER

SOURCE

SUBTITLE

AUDIO

1 2 3

4 5 6

7 8 9

BONUSVIEW

ALL

2D�3D

INTERNET@

POWER

SOURCE

DISC MENU TITLE MENUMENU

SEARCHSMART

SUBTITLE

AUDIO

INFO

POPUP

TOOLS

EXITRETURN

HUB

1 2 3

4 5 6

7 8 9

BONUSVIEW

Listening to Music

Buttons on the Remote Control used for Music Playback

SEARCH buttons : Fast Play.

(Audio CD (CD-DA) only)

PAUSE button : Pauses playback.

PLAY button : Plays the currently selected track.

▲▼ buttons : Select a track in the Music List or

Playlist. YELLOW (C) button : Displays check box in the

music list.

ENTER button : Plays the selected track.

◄► buttons : Jump Play.

(except for Audio CD (CD-DA))

STOP button : Stops a track.

2 3

SKIP button : During playback, moves to the next page in the Music List or moves to the next track in

the Playlist. SKIP button : During playback, moves to the

previous page in the Music List or moves to the previous track in the Playlist. If you press this button after three seconds of

playback in the Playlist, the current track is replayed from the beginning. But, if you press this button less than three seconds after playback starts in the Playlist, the previous track is played.

NUMBER buttons : During the Playlist playback, press the desired track number. The selected track

is played.

Playing an Audio CD (CD-DA)/MP3

Insert an Audio CD (CD-DA) or an MP3 Disc

into the disc tray.

For an Audio CD (CD-DA), the first track

• plays automatically.

For an MP3 disc, press the ▲▼ buttons

• to select Music, then press the ENTER button.

Audio CD (CD-DA)/MP3 Screen Elements

1/13

Music

00:13 / 00:43

Audio CD

Displays the music information.

Displays the playlist.

TRACK 001

Enter < Pages / Tools ' Return

TRACK 001

00:43

TRACK 002

03:56

TRACK 003

04:41

TRACK 004

04:02

English 51

06 Basic Functions

Display the current track/total tracks.

Displays buttons available.

Shows the current play time/total play time.

Displays the current playback status.

Displays the repeated playback status.

Press the ▲▼ buttons to select the track

you want to play, and then press the ENTER button.

Repeat an Audio CD (CD-DA)/MP3

During the Playlist playback, press the

1. TOOLS button.

Press the ▲▼ buttons to select

2. Repeat Mode, and then press the ◄►

buttons to select the desired repeat mode.

Press the ▲▼ buttons to select Shuffle

3. Mode, and then press the ◄► buttons to

select On or Off.

Press the ENTER button.

Off

(

) One Song The current song is repeated.

(

) All All songs are repeated.

Songs are played in the order in which they were recorded.

The random option plays songs in

( )

Shuffle Mode

random order. To operate this function, please set the shuffle mode to On.

Playlist

Insert an Audio CD (CD-DA) or an MP3 Disc

into the disc tray.

For an Audio CD (CD-DA), the first track

•

plays automatically.

For an MP3 disc, press the ▲▼ buttons

•

to select Music, then press the ENTER button.

To move to the Music List, press the STOP

( ) or RETURN button. The Music List screen appears.

Press the YELLOW (C) button.

Press the ▲▼◄► buttons to move to a

desired track, and then press the ENTER button. A check appears on the track. Repeat this procedure to select additional tracks.

Audio CD | Music

TRACK 001

00:43

TRACK 003

04:41

TRACK 005

03:43

TRACK 007

04:06



Close Edit Mode

To remove a track from the list, move to the

Selected Items : 3

TRACK 002

03:56

TRACK 004

04:02

TRACK 006

03:40

TRACK 008

03:52

( )

Page / Tools " Select ' Return

track, and then press the ENTER button again. The check on the track is cancelled.

When done, press the TOOLS button.

Press the ▲▼ buttons to select Play

7. Selected, and then press the ENTER button.

The tracks you selected play automatically.

Music

TRACK 001

00:13 / 00:43

Audio CD

To go to the Music List, press the RETURN

TRACK 001

00:43

TRACK 002

03:56

TRACK 003

04:41

Enter / Tools ' Return

button.

NOTE

✎

You can create a playlist with up to 99 tracks on

▪

Audio CDs (CD-DA).

1/2 Page

1/3

52 English

Basic Functions

Playing back Pictures

Playing a JPEG files

Insert a JPEG disc into the disc tray.

Press the ▲▼ buttons to select Photos, and

then press the ENTER button.

Press the ▲▼◄► buttons to select the folder

you want to play, and then press the ENTER button.

Press the ▲▼◄► buttons to select the photo

you want to play, and then press the ENTER button.

NOTE

✎

You can’t enlarge the subtitle and PG graphic in the

▪

full screen mode.

Using the TOOLS button

You can use various function by pressing the TOOLS button.

Tools

Start Slide Show Background Music : Off Background Music Setting Zoom Rotate Information

Enter ' Return

Zoom : Select to enlarge the current picture.

• (Enlarged up to 4 times)

Rotate : Select to rotate the picture. (This will

• rotate the picture either clockwise or counter clockwise.)

Information : Shows the picture information

• including the name and size, etc.

NOTE

✎

To enable the background music function, the photo

▪

file must be in the same storage media as the music file. However, the sound quality can be affected by the bit rate of the MP3 file, the size of the photo, and the encoding method.

Using the Slide Show function

Press the TOOLS button.

Press the ▲▼ buttons to select Start Slide

Show, and then press the ENTER button.

The Slide Show starts.

To pause the slide show, press the TOOLS

button again.

Tools

Pause Slide Show Slide Show Speed : Normal Slide Show Effect : Blind Background Music : Off Background Music Setting Zoom Rotate Information

Enter ' Return

Start Slide Show : Select to start the slide

• show.

Background Music : Select to listen to music

• while viewing a picture.

Background Music Setting : Select to set the

• background music setting.

Press the ▲▼ buttons to select Pause Slide

4. Show, and then press the ENTER button.

You can also set the slide show speed and

effect using the same method.

English 53

06 Basic Functions

Playing back a USB Storage Device

You can use the USB connection to play multimedia files (MP3, JPEG, DivX, etc) located from a USB storage device.

Move to the Home menu.

My Contents

Videos

Photos Music

My Devices Internet Settings

d PBC(WPS)

In Stop mode, connect the USB storage

device to the USB port on the front panel of the player.

My Contents

Videos

Connected Device

Photos Music

123

NOTE

✎

You must remove the USB storage device safely

▪

(by performing the “Safely Remove USB” function) in order to prevent a possible damage to the USB memory. Press the MENU button to move to the Home menu, select the YELLOW (C) button, and then press the ENTER button.

If you insert a disc when playing a USB storage

▪

device, the device mode changes to “DVD or CD” automatically.

My Devices Internet Settings

Press the ENTER button.

Press the ▲▼◄► buttons to select the

Enter ' Return



Safely Remove USB d PBC(WPS)

desired Videos, Music, or Photos, and then press the ENTER button.

For playing back Video, Music or Photo files,

see pages 45~52.

54 English

Network Services

You can enjoy various network services such as Smart Hub or BD-LIVE by connecting the player to your network.

Read the following instructions before using any network service.

Connect the player to the network.

(See pages 25~26)

Configure the network settings.

(See pages 36~40)

Using Smart Hub

Using Smart Hub, you can stream movies, videos, and music from the Internet, access various for pay or free-of-charge applications and view them on your TV. Application content includes news, sports, weather forecasts, stock market quotes, maps, photos, and games.

You can also start this function by pressing the SMART HUB button on the remote control.

Starting Smart Hub for the First Time

To start Smart Hub for the first time, follow these steps :

Go to the Home menu.

The Smart Hub screen appears.

In a few cases, the Country screen appears immediately after.

If the Country screen has appeared, press

the ▲▼ buttons to select your country, then press the ENTER button.

NOTE

✎

Certain applications are available only in certain

▪

countries.

The Terms of Service Agreement screen

appears. If you want to agree, press the ◄► buttons to select Agree, then press the ENTER button.

NOTE

✎

Screens can take a few seconds to appear.

▪

The Service Update screen appears and

installs a number of services and applications. When done, it closes. The applications and services downloaded are displayed on the Smart Hub screen. This may take some time.

NOTE

✎

Smart Hub may close momentarily during the

▪

installation process.

A number of screens may appear after installation.

▪

You can press the ENTER button to close them or let them close on their own.

To start an application, press the ▲▼◄►

buttons to highlight a widget, then press the ENTER button.

My Contents

Videos

Photos

Music

My Devices Internet Settings

d PBC(WPS)

Press the ◄► buttons to select Internet, and

2. then press the ENTER button.

English 55

07 Network Services

Smart Hub at a Glance

xxxxxxxx

Contents 1

xxxxxxxx

Contents 6

xxxxxxxx

Contents 5

xxxxxxxx

Contents 4

xxxxxxxx

Contents 3

xxxxxxxx

Contents 2

xxxxxxxx

Contents 7

xxxxxxxx

Contents 8

xxxxxxxx

Contents 9

xxxxxxxx

Contents 10

xxxxxxxx

Contents 11

xxxxxxxx

Contents 12

xxxxxxxx

Contents 1

xxxxxxxx

Contents 2

xxxxxxxx

Contents 3

xxxxxxxx

Contents 4

xxxxxxxx

Contents 5

Contents 1 Contents 2 Contents 3 Contents 4

1 2 3 5

Your Video

Recommended

Samsung Apps

7 6

Commercial : Displays the Smart Hub Guide, an introduction to the player, and new application

introductions.

Your Video : Provides recommendations for videos based on your tastes.

Lets you see movie recommendations based on

•

your previous preferences. Lets you select a movie, displays a list of VOD

•

(Video on Demand) providers that have the movie, and then lets you choose a provider for streaming. (Streaming is unavailable in some areas.)

For instructions to use Your Video, please visit

•

www.samsung.com.

Search : Provides an integrated search of your video providers and connected AllShare devices.

Usable while using Smart Hub (except when you

•

are watching a Blu-ray Disc).

For easy access, use the SEARCH button on the

•

remote control. For instructions to use search function, please

•

visit www.samsung.com.

Samsung Apps : You can download various for pay

or free-of-charge application services.

Recommended : Displays recommended contents

managed by Samsung.

Navigation Help : Displays the remote control buttons you can use to navigate in Smart Hub.

RED (A) : To log in to Smart Hub.

•

GREEN (B) : To sort the applications.

•

YELLOW (C) : To edit the applications.

•

BLUE (D) : To change the settings of Smart Hub.

•

My Applications : Displays your personal gallery of applications which you can add to, modify, and

delete.

NOTE

✎

Samsung Electronics takes no legal responsibility for

▪

any interruption of the Smart Hub service caused by the service provider for any reason.

The Smart Hub service downloads and processes

▪

data via the Internet so that you can enjoy the Internet contents on your TV screen. If the Internet connection is unstable, the service may be delayed or interrupted. Furthermore, the player may turn off automatically in response to conditions on the Internet. If this occurs, check the Internet connection and try again.

Application services may be provided in English only

▪

and the contents available may vary, depending on your area.

For more information about a Smart Hub service,

▪

visit the web site of the applicable service provider.

The services provided are subject to change by the

▪

Smart Hub service provider without notice.

The Smart Hub service contents may differ

▪

depending on the player’s firmware version.

56 English

Network Services

xxxxxxxx

Contents 1

xxxxxxxx

Contents 6

xxxxxxxx

Contents 5

xxxxxxxx

Contents 4

xxxxxxxx

Contents 3

xxxxxxxx

Contents 2

xxxxxxxx

Contents 7

xxxxxxxx

Contents 8

xxxxxxxx

Contents 9

xxxxxxxx

Contents 10

xxxxxxxx

Contents 11

xxxxxxxx

Contents 12

xxxxxxxx

Contents 1

xxxxxxxx

Contents 2

xxxxxxxx

Contents 3

xxxxxxxx

Contents 4

xxxxxxxx

Contents 5

Contents 1 Contents 2 Contents 3 Contents 4

Using the Keypad

Through your remote, you can use the On-Screen Keypad to enter letters, numbers, and symbols.

1 2 3

. , –

abc def

4 5 6

ghi jkl mno

7 8 9

pqrs tuv wxyz

2 6

Shift Delete

ab Ab AB 1 

Input Method / Language: English

4 5

The current keypad.

Use to enter letters, numbers, and symbols.

Press the SUBTITLE button on the remote control to shift the input mode.

: ab, Ab, AB, numbers or icons.

Displays the current input mode.

Press the GREEN (B) button on the remote control

to change the input method. (T9 or ABC)

Press the TOOLS button on the remote control to

change the language.

Press the AUDIO button on the remote control to

delete a character.

Entering Text, Numbers and Symbols

To enter text, press the number button on the remote that corresponds to the letter you want to enter. Press the button rapidly to enter a letter that is not the first letter listed on the On-Screen keypad button. For example, if you want to enter the letter b, press the 2 button on your remote rapidly twice. To enter the first letter listed on a button, press, release, and then wait.

To move within the text, use the Arrow buttons. To delete text, move the cursor to the right of the character you want to delete, and then press the AUDIO button. To change case or enter numbers or punctuation, press the SUBTITLE button.

Creating an Account

To establish your own, exclusive, configuration of Smart Hub, create your own Smart TV Account.

To create an account, follow these steps:

Press the RED (A) button on your remote

control. The Create Account screen appears.

Your Video

Recommended

Smart TV ID

Password

Press the ▲▼◄► buttons to select Create

Press [Enter]

Remember my Smart TV ID and password



Create Account Forgot Password

Account, and then press the ENTER button.

On the next screen, select Smart TV ID, and

then press the ENTER button. An entry screen and keypad appear.

Use the keypad to enter your e-mail address.

This will serve as your ID.

NOTE

✎

The keypad works like the keypad on a cell phone.

▪

When done, press the ENTER button to

select OK, and then press the ENTER button again. The Create Account screen reappears.

Select Password, and then press the ENTER

button. An entry screen and a keypad appear.

Use the keypad to enter a password.

The password can be any combination of letters, numbers, and symbols.

NOTE

✎

Press the RED (A) button on your remote to show or

▪

hide the password as you enter it.

Samsung Apps



English 57

07 Network Services

When done, press the ENTER button to select OK, and then press the ENTER button again. The Create Account screen reappears.

Select Confirm password, and then press the ENTER button.

10.

Repeat Steps 7 and 8.

11.

When the Create Account screen re-appears, select Create Account, and then press the ENTER button. The Confirmation window appears.

12.

Select OK, and then press the ENTER button. The Continue to Register Service window appears.

13.

Select Go Register, and then press the ENTER button.

14.

The Register Service Account Window appears.

•

If you have existing accounts with any of the listed providers, you can associate the provider account and the provider account password with your Smart TV Account. Registration makes it easier to access the providers web site. For registration instructions, go to Step 2 in Account Management under the Settings Menu.

•

If you don’t have existing provider accounts or do not want to register existing accounts at this time, select OK, and then press the ENTER button. You can also let the window close on its own in about a minute.

NOTE

✎

You must use an e-mail address as an ID.

▪

You can register up to 10 User Accounts.

▪

You do not need an account to use Smart Hub.

▪

Account Log In

To log in to your Smart TV Account, follow these steps:

With the Smart Hub main screen displayed on your TV, press the RED (A) button on your remote. The Create Account screen appears.

Select the Down Arrow next to the Smart TV ID field, and then press the ENTER button.

Select your ID from the list that appears, and

then press the ENTER button. The Create Account screen re-appears.

Select Password, and then press the ENTER

button. An entry screen and a keypad appears.

Using the keypad and your remote, enter your

password. When done, press the ENTER button, select OK, and then press the ENTER button again.

NOTE

✎

If you want Smart Hub to enter your password

▪

automatically, select Remember my Smart TV ID and password after you have entered your password, and then press the ENTER button. A check appears. Smart Hub will now enter your password automatically when you select or enter your ID.

The Settings Menu - BLUE (D)

The Settings Menu Screen gives you access to account management, reset, and properties functions.

To access the Settings Menu, and then select a menu item, follow these steps:

Press the BLUE (D) button on your remote.

Press the ▲▼ to select a menu item, and

then press the ENTER button.

The functions on the Settings Menu screen are described below.

NOTE

✎

The Service Manager item listed in the Settings

▪

Menu is not available for Blu-ray Disc players.

Account Management

The Account Management Menu contains functions that let you register your service provider accounts, change your Smart Hub password, and delete or deactivate your Smart TV Account.

58 English

Network Services

If you have existing accounts with any of the providers listed by the Register Service Account function, you can associate the provider account and the provider account password with your Smart TV Account. If you associate the account, you will be able to log onto the account through Smart Hub easily, without entering your account name or password.

To use the Register Service Account function, follow these steps:

In the Account Management menu, select

Press the ▲▼ buttons to select a Service

Provider you want to associate with your Smart TV Account, and then press the

ENTER button.

NOTE

✎

If you have a Samsung apps account and you want

▪

to use the Samsung Apps function in Smart Hub, you must register your Samsung Apps account here. See pages 61~63 for more information.

Press the ▲▼ buttons to select Register, and

then using your remote and the on-screen Keypad, enter your site ID and password. When done, press the ENTER button.

NOTE

✎

This is the ID and password you normally use to

▪

access your account on this site.

If you have entered the ID and password

correctly, the Registered Successfully message appears.

If you pressed OK, repeat Steps 2 through 4

to associate another Service Provider.

When you are done, press the RETURN

button.

Change Password

The Change Password function lets you change your Smart Hub password. To change the password, follow these steps:

Select Change Password, and then press

the ENTER button.

Enter your current password. The next screen

appears.

On the next screen, enter a new password on

the first line. Enter it again on the second line to confirm.

The Changing Password Complete message

screen appears. Press the ENTER button or wait for the screen to close - about 5 seconds.

Remove Service Accounts

The Remove Service Accounts function cancels all your current registered Service Accounts that you registered on the Register Service Account screen.

Deactivate Account

The Deactivate Account function deactivates your Smart TV Account and deletes it and all your account settings entirely from Smart Hub.

Reset

The Reset function initializes all downloaded widgets, erases all user accounts and settings from the player, and resets all Smart Hub settings to the factory default settings. It then restarts Smart Hub as if it were starting for the first time. Your account, however, remains on the Smart Hub server. To log into your account, enter your ID and password on the Create Account screen.

To use the Reset function, follow these steps:

In the Settings menu, select Reset, and then

press the ENTER button. The Reset screen appears.

Enter the your Security password. This is the

password you entered if you set up a BD or DVD Parental rating (See page 41). If you did not, enter 0000.

English 59

07 Network Services

After a few moments, Smart Hub automatically

resets. The screen may go black, then Smart Hub re-appears. In a few moments, it starts the re-initialization procedure.

To complete the re-initialization, go to Step 4

in Starting Smart Hub for the First Time. (See page 54)

NOTE

✎

If you forgot your password, press the STOP ( )

▪

button on the front panel of the player for more than 5 seconds with no disc inserted.

Properties

The Properties menu item lists three functions that display information about Smart Hub :

Detail

Lists information about Smart Hub including version number, the number of services installed, memory usage, and the unique product ID.

Check the speed of your internet connection

Runs a test which shows how fast your connection to the Samsung's server is in Mbps (Megabits per second). Speeds lower than 1.5 Mbps can limit your enjoyment of Smart Hub.

Displays the Terms of Service Agreement.

The Edit Mode Menu - YELLOW (C)

The functions in the Edit Mode menu let you manipulate the widgets in the My Applications section of the Smart Hub screen. Using these functions, you can lock and unlock access to some widgets, New Folder and move widgets to them, rename folders, delete widgets, and change the position of widgets on the screen.

To access the Edit Mode Menu, and then select a menu item, follow these steps:

Press the YELLOW (C) button on your

remote. The Edit Mode menu bar appears on the bottom of the screen.

Press the ▲▼◄► to select a menu item, and

then press the ENTER button.

The functions in the Edit Mode Menu bar are described below.

NOTE

✎

Some menu items may not appear on the screen.

▪

To see these items, press the ◄► to move to the screen edge, and then press one more time to reveal the items.

You can close the bar by highlighting the X on the

▪

bottom right side, and then pressing the ENTER button.

Move

The Move function lets you change the screen position of a widget. To use the Move function, follow these steps:

Press the YELLOW (C) button on your

remote.

Select a widget, and then press the ENTER

button. A check appears above the widget.

Press the ▲▼◄► to select Move, and then

press the ENTER button. A position change icon appears above the widget.

Press the ▲▼◄► to move the icon. Press

the ENTER button when the icon is in the position of your choice. The widget moves to its new location.

Move to Folder

The Move to Folder function lets you move a widget to a folder. To use the Move to Folder function, follow these steps:

Press the YELLOW (C) button on your

remote.

Select a widget, and then press the ENTER

button. If you already create a folder, the widget can be moved.

Press the ▲▼◄► to select Move to Folder,

and then press the ENTER button. The Move to Folder window opens.

Press the ▲▼◄► to select a folder, and

then press the ENTER button. The Moved to Folder message appears, and then closes. The widget has been moved to the folder.

60 English

Network Services

To Access Widgets in a Folder

Close the Edit Mode menu.

In My Applications, press the ▲▼◄► to

select a folder, and then press the ENTER button. The folder opens.

Select a widget, and then press the ENTER

button. The widget’s application or service starts.

To Edit Items in a Folder

Select a folder, and then press the ENTER button. The folder opens.

Press the YELLOW (C) button on your remote. The Edit buttons appear at the bottom of the screen.

These buttons work the same as the Edit Mode menu buttons on the main screen. For example, to move a widget back to the My Applications main screen:

Select the widget.

Select Move to Folder, and then press the

2. ENTER button. The Move to Folder window

appears.

Select My Applications, and then press the

3. ENTER button. The Move to Folder window

closes and the widget returns to the main My Applications screen.

New Folder

The New Folder function lets you create and name new folders. Once you have created a folder, you can move widgets into it. To use the New Folder function, follow these steps:

Press the YELLOW (C) button on your

remote.

Press the ▲▼◄► to move the cursor to New

Folder, and then press the ENTER button. The New Folder window and a keypad appear.

Use the keypad to enter the name of the

folder, and then press the ENTER button. The New Folder screen closes and the New Folder appears on the Smart Hub screen.

Rename Folder

The Rename Folder function lets you rename folders. To use the Rename Folder function, follow these steps:

Press the YELLOW (C) button on your

remote.

Press the ▲▼◄► to select a folder, and then

press the ENTER button.

Press the ▲▼◄► to select Rename a Folder,

and then press the ENTER button. The Folder Rename window and a keypad appears.

Use the keypad to enter a new name, and

then press the ENTER button. The Rename window closes and the new name appears below the folder.

Lock

The Lock function lets you lock some widgets in My Applications so they can not be opened without entering the Parental Security Code.

To use the Lock function, follow these steps:

Press the YELLOW (C) button on your

remote.

Press the ▲▼◄► to select a widget, and

then press the ENTER button. If the widget can be locked, the Lock menu item is enabled.

Press the ▲▼◄► to select Lock, and then

press the ENTER button. The Lock Service window appears.

Enter your Parental Security Code (See

page 41). If you have not created a Parental Security Code, enter 0000.

Press the ENTER button. The Lock Service

window appears confirming the lock, and then closes. A lock symbol appears next to the widget.

English 61

07 Network Services

Unlock

Press the YELLOW (C) button on your

remote.

Press the ▲▼◄► to select a locked widget,

and then press the ENTER button.

Press the ▲▼◄► to select Unlock, and then

press the ENTER button. The Lock Service window appears.

Enter the Parental Security Code (See page

41). If you have not created a Parental Security Code, enter 0000.

Press the ENTER button. The Lock Service

Released window appears confirming the lock has been release, and then closes.

Delete

The Delete function lets you delete widgets from My Applications. To use the Delete function, follow these steps:

Press the YELLOW (C) button on your

remote.

Press the ▲▼◄► to select a widget, and

then press the ENTER button.

Press the ▲▼◄► to select Delete, and then

press the ENTER button. The message, “Do you want to delete selected item(s)?” appears.

Select Yes, and then press the ENTER

4. button. The widget is deleted.

The Sort Menu - GREEN (B)

The functions in the Sort Menu let you sort the widgets in My Applications by Name, Date, Frequency (of use), and Category. If you manually change the position of a widget, the Sort Menu automatically highlights User Defined when you start it.

To sort the widgets in My Applications, follow these steps:

Press the GREEN (B) button on your remote.

Press the ◄► to select a sorting method,

and then press the ENTER button. Smart Hub sorts the widgets by the method you have chosen.

Samsung Apps

Samsung Apps lets you download for pay or freeof-charge applications and services to your Bluray Disc player and view or use them on your TV.

These applications and services include videos, music, photos, games, news, sports, etc. Widgets for the new apps appear in My Applications.

Additional applications and services are added regularly.

For Pay Apps

To download for pay apps, you need to create a Samsung Apps account and add a credit card to the account.

To create a Samsung Apps account, please visit www.samsung.com

NOTE

✎

This service may not provided in some countries.

▪

Accessing the Samsung Apps Screen

To access Samsung Apps, press the ▲▼◄► buttons to navigate to the Samsung Apps area on the Smart Hub main screen, and then press the ENTER button. The Samsung Apps screen appears.

NOTE

✎

If this is the first time you are accessing this screen,

▪

the terms of service window appears. If you want to agree, select Agree, and then press the ENTER button.

62 English

Network Services

Using the Samsung Apps Screen

To use the Samsung Apps screen, follow these steps:

Press the ◄► buttons to move to the

category list on the left.

Press the ▲▼ to highlight a category. In a few

seconds, the Samsung Apps screen displays the applications in that category. The Sort tabs appear across the top.

Press the ► button to move to the displayed

applications or services.

Press the ▲▼◄► buttons to select an

application or service, and then press the ENTER button. The Application Details screen appears describing the service or application.

Select Download Now, and then press the

5. ENTER button. If the application or service is

free, it downloads and runs. If not, and there is a fee, follow the directions on the screen to complete the download.

NOTE

✎

Some apps are free to download, but require

▪

registration with the provider or a paid account with the provider to use.

Widgets for applications and services you have

▪

downloaded from Samsung Apps appear in My Applications.

Sort By Tabs

You can access the Sort By tabs on the top of the screen using the ▲▼◄► buttons. Each tab displays the services or applications in the category you chose, sorted by the criteria on the tab (Recommended, Most Downloaded, Most Recent, Name).

You can also use the BLUE (D) button on your remote to access the Sort By tabs. Each time you press the BLUE (D) button, you change the display from one sort tab to the next.

Samsung Apps by category

The following categories are available:

What’s New? : Displays newly registered

• applications.

Video : Displays various video media such as

• movies, TV shows, and short length videos.

Game : Displays various games such as sudoku

• and chess.

Sports : Displays various sports media services

• such as match information, images, and short length videos.

Lifestyle : Includes various lifestyle media

• services such as music, personal photo management tools, and social networking such as Facebook and Twitter.

Information : Includes various information

• services such as news, stocks, and weather.

Other : Includes other miscellaneous services.

•

My Account

My Account gives you access to your Samsung Apps order and download history, and to the My Apps Cash screen. You must have a Samsung Apps account to access this information.

Help

If you have questions about Samsung Apps, check Help first. If none of the tips apply, please visit www.samsung.com.

To use the Help function, follow these steps:

Press the ▲▼◄► buttons to select Help,

and then press the ENTER button.

Press the ▲▼ to scroll the Help text.

Press the ◄ to exit Help.

English 63

07 Network Services

Using the colored buttons on your remote with Samsung Apps

RED (A) (Login) : To log into your Smart TV

• Account.

GREEN (B) (Thumbnail View/List View) : To

• toggle applications between Thumbnail and List view.

BLUE (D) (Sort By) : To sort the applications

• in a category by Recommended, Most Downloaded, Most Recent, or Name.

Return : To return to the previous menu.

•

NOTE

✎

The Internet contents services may be added or

▪

deleted by providers without notice.

For instructions to use Your Video or Search Function, please visit www.samsung.com

BD-LIVE™

Once the player is connected to the network, you can enjoy various movie-related service contents using a BD-LIVE compliant disc.

Attach a USB memory stick to the USB jack

on the side of the player, and then check its remaining memory. The memory device must have at least 1GB of free space to accommodate the BD-LIVE services.

Insert a Blu-ray Disc that supports BD-LIVE.

Select an item from various BD-LIVE service

contents provided by the disc manufacturer.

NOTE

✎

The way you use BD-LIVE and the provided contents

▪

may differ, depending on the disc manufacturer.

Using the AllShare Function

AllShare lets you play music, video, and photo files located in your PC or your DLNA compatible mobile phone or NAS on the player.

To use AllShare with your player, you must connect the player to your network (See pages 25~26). To use AllShare with your PC, you must install AllShare software on your PC.

If you have a DLNA compatible mobile phone or NAS, you can use AllShare without any additional software.

You can download the PC software and get detailed instructions for using AllShare from the Samsung.com web site.

64 English

Appendix

Troubleshooting

Before requesting service, please check the following.

PROBLEM SOLUTION

No operation can be performed with the remote control.

Check the batteries in the remote control. They may need replacing.

•

Operate the remote control at a distance of no more than 20 feet.

•

Remove batteries and hold down one or more buttons for several minutes

•

to drain the microprocessor inside the remote control to reset it. Reinstall batteries and try to operate the remote control again.

Disc does not play. Ensure that the disc is installed with the label side facing up.

Disc Menu does not appear. Ensure that the disc has disc menus.

The prohibition message appears on the screen.

Play mode differs from the Setup Menu selection.

The screen ratio cannot be changed. The Screen Ratio is ﬁxed on your Blu-ray Disc/DVD.

No audio. Make sure you have selected the correct Digital Output in the Audio Options

The screen is blocked If the HDMI output is set to a resolution your TV cannot support (for

•

Check the region number of the Blu-ray Disc/DVD.

•

This message appears when an invalid button is pressed.

•

The Blu-ray Disc/DVD’s software doesn’t support the feature (e.g., angles).

•

You’ve requested a title or chapter number or search time that is out of

•

range.

Some of the functions selected in the Setup Menu may not work properly if

•

the disc is not encoded with the corresponding function.

•

This is not a problem with the player.

•

Menu.

•

example, 1080p), you may not see a picture on your TV. Press the STOP ( ) button (on front panel) for more than 5 seconds with

•

no disc inside. All settings will revert to the factory settings. When the factory default settings are restored, all stored user BD data is

•

deleted.

English 65

08 Appendix

PROBLEM SOLUTION

Forgot password Press the STOP ( ) button (on front panel) for more than 5 seconds with

•

no disc inside. All settings including the password will revert to the factory settings. Don’t use this unless absolutely necessary.

When the factory default settings are restored, all stored user BD data is

•

deleted.

If you experience other problems. Go to the contents and ﬁnd the section of the user manual that contains the

•

explanations regarding the current problem, and follow the procedure once again.

If the problem still cannot be solved, please contact your nearest Samsung

•

authorized service center.

The picture is noisy or distorted Make sure that the disc is not dirty or scratched.

No HDMI output. Check the connection between the TV and the HDMI jack of the player.

•

Clean the disc.

•

Check if your TV supports 480p, 720p, 1080i, 1080p HDMI input

•

resolution.

Abnormal HDMI output screen. If random noise appears on the screen, it means that TV does not support

•

HDCP (High-bandwidth Digital Content Protection).

AllShare function

I can see folders shared through AllShare, but I cannot see the files.

AllShare shows only ﬁles corresponding to the Image, Music, and Movie

•

categories. Files that do not correspond to these categories may not be displayed.

Video is played intermittently. Check if the network is stable.

•

Check if the network cable is properly connected and if the network is not

•

overloaded. The wireless connection between the DLNA compatible device and the

•

player is unstable. Check the connection.

AllShare connection between TV and PC is unstable.

The IP address under the same subnetwork should be unique. If they are

•

not, IP interference can cause this phenomenon. Check if you have a ﬁrewall enabled.

•

If so, disable the ﬁrewall function.

66 English

Appendix

PROBLEM SOLUTION

BD-LIVE

I cannot connect to the BD-LIVE server. Check whether the network connection is successful or not by using the

•

Network Status menu. (See page 39) Check whether the USB memory device is connected to the player.

•

The memory device must have at least 1GB of free space to accommodate

•

the BD-LIVE service. You can check the available size in BD Data Management. (See page 40)

Check whether the BD-LIVE Internet Connection menu is set to Allow(All).

•

If all above fails, contact the contents provider or update the player to the

•

latest ﬁrmware.

When using the BD-LIVE service, an error occurs.

NOTE

✎

When the factory default settings are restored, all stored user BD data is deleted.

▪

The memory device must have at least 1GB of free space to accommodate

•

the BD-LIVE service. You can check the available size in BD Data Management. (See page 40)

Repairs

If you contact us to repair your player, an administration fee may be charged if either:

An engineer is called out to your home at your request and there is no defect in the product.

You bring the unit to a repair center and there is no defect in the product.

We will provide you with the amount of the administration fee before we make a home visit or begin any work on your player. We recommend you read this manually thoroughly, search for a solution on line at www.samsung.com, or contact Samsung Customer Care at 1-800-SAMSUNG (726-7864) before seeking to repair your player.

English 67

08 Appendix

Index

Accessories 15 AllShare 63 Anynet+ (HDMI-CEC) 40 Audio Language 48~49

Background Music 52 BD Data Management 40 BD-LIVE 40, 63 BD Wise 30 BONUSVIEW 49

Camera Angle 49 Contact Samsung 44

Digital Output 33~35 Disc Menu 45 Disc Structure 45 Disc Types 11~13 Downmixing Mode 35 Dynamic Range Control 35

HDMI Deep Color 33

Keypad 56

Movie Frame (24Fs) 32 MP3 50~51

Network Settings 36~40

PCM Downsampling 35 Popup Menu 46 Progressive Mode 33

Region Code 13 Remote Control 18 Remote Control Sensor 16 Resolution 30~32

Samsung Apps 61~63 Slide Show 52 Smart Hub 54~61 Software Upgrade 42~44 Subtitle Language 49

USB Storage Device 53

Wired Network 36~37 Wireless Network 37~39

Zoom 52

Initial Settings 40

JPEG 52

3D Settings 29 Title Menu 46 TV Aspect 30

68 English

Appendix

Specifications

Power Requirements AC 120V, 60Hz Power Consumption 19W

General

Disc

Video Output

Video/Audio HDMI

Audio Output

Network

Design and specifications are subject to change without prior notice.

Weight and dimensions are approximate.

Weight 3.8 Ibs Dimensions 17.0 (W) X 8.3 (D) X 1.6 (H) inches Operating Temperature Range +41°F to +95°F Operating Humidity Range 10 % to 75 % BD (Blu-ray Disc) Reading Speed : 9.834 m/sec

DVD (Digital Versatile Disc)

CD : 5 inches (COMPACT DISC)

CD : 3 1/2 inches (COMPACT DISC)

Composite Video

Component Video

2 Channel L(1/L), R(2/R) Digital Audio Output Optical

*Frequency Response

*S/N Ratio 110 dB *Dynamic Range 100 dB *Total Harmonic Distortion 0.003% Ethernet 10/100BASE-TX Terminal

Wireless LAN

Security

WPS(PBC) Supported

Reading Speed : 6.98 ~ 7.68 m/sec Approx. Play Time (Single Sided, Single Layer Disc) : 135 min. Reading Speed : 4.8 ~ 5.6 m/sec. Maximum Play Time : 74 min. Reading Speed : 4.8 ~ 5.6 m/sec. Maximum Play Time : 20 min. 1 Channel : 1.0 Vp-p (75Ω load) Blu-ray/DVDs : 480i Y : 1.0 Vp-p (75Ω load) PR : 0.70 Vp-p (75Ω load) PB : 0.70 Vp-p (75Ω load) Blu-ray Disc : 480i DVD : 480p, 480i 2D : 1080p, 1080i, 720p, 480p

3D : 1080p, 720p PCM multichannel audio, Bitstream audio

48 kHz Sampling : 4 Hz to 22 kHz 96 kHz Sampling : 4 Hz to 44 kHz

Supports when the player is connected with the Samsung Wireless LAN Adapter. (Model Name : WIS09ABGN)

WEP (OPEN/SHARED) WPA-PSK (TKIP/AES) WPA2-PSK (TKIP/AES)

*: Nominal specification

English 69

08 Appendix

Compliance and Compatibility Notice

NOT ALL discs are compatible

Subject to the restrictions described below and those noted throughout this Manual, including the Disc

• Type and Characteristics section of this user manual, disc types that can be played are: pre-recorded commercial BD-ROM, DVD-VIDEO, and Audio CD (CD-DA) discs; BD-RE/-R, DVD-RW/-R discs; and CD-RW/-R discs.

Discs other than the above cannot and/or is not intended to be played by this player. And some of the

• above discs may not play due to one or more reasons provided below.

Samsung cannot assure that this player will play every disc bearing the BD-ROM, BD-RE/-R,

• DVD-VIDEO, DVD-RW/-R, DVD+RW/+R and CD-RW/-R logos, and this player may not respond to all operating commands or operate all features of every disc. These and other disc compatibility and player operation issues with new and existing format discs are possible because:

Blu-ray is a new and evolving format and this player may not operate all features of Blu-ray Discs

because some features may be optional, additional features may have been added to the Blu-ray Disc format after the production of this player, and certain available features may be subject to delayed availability;

not all new and existing disc format versions are supported by this player;

new and existing disc formats may be revised, changed, updated, improved and/or supplemented;

some discs are produced in a manner that allows specific or limited operation and feature during

playback; some features may be optional, additional features may have been added after the production of this

player or certain available features may be subject to delayed availability; some discs bearing the BD-ROM, BD-RE/-R, DVD-VIDEO, DVD-RW/-R, DVD+RW/+R and

CD-RW/-R logos may still be non-standardized discs; some discs may not be played depending on their physical state or recording conditions;

problems and errors can occur during the creation of Blu-ray Disc, DVD software and/or the

manufacture of discs; this player operates differently than a standard DVD player or other AV equipment; and/or

for reasons noted throughout this user manual and for other reason(s) discovered and posted by

SAMSUNG customer care center.

If you encounter disc compatibility or player operation problems, please contact SAMSUNG customer

• care center. You may also contact SAMSUNG customer care center for possible updates on this player.

For additional information on playback restrictions and disc compatibility, refer to the Precautions,

• Before Reading the user manual, Disc Types and Characteristics, and Before Playing sections of this user manual.

Copy Protection

Because AACS (Advanced Access Content System) is approved as content protection system for

• Blu-ray Disc format, similar to use of CSS (Content Scramble System) for DVD format, certain restrictions are imposed on playback, analog signal output, etc., of AACS protected contents. The operation of this product and restrictions on this product may vary depending on your time of purchase as those restrictions may be adopted and/or changed by AACS after the production of this product. Furthermore, BD-ROM Mark and BD+ are additionally used as content protection system for Blu-ray Disc format, which imposes certain restrictions including playback restrictions for BD-ROM Mark and/or BD+ protected contents. To obtain additional information on AACS, BD-ROM Mark, BD+, or this product, please contact SAMSUNG customer care center.

70 English

Appendix

Many Blu-ray Disc/DVDs are encoded with copy protection. Because of this, you should only connect

• your Player directly to your TV, not to a VCR. Connecting to a VCR results in a distorted picture from copy-protected Blu-ray Disc/DVDs.

This item incorporates copy protection technology that is protected by U.S. patents and other

• intellectual property rights of Rovi Corporation. Reverse engineering and disassembly are prohibited.

Under the U.S. Copyright laws and Copyright laws of other countries, unauthorized recording, use,

• display, distribution, or revision of television programs, videotapes, Blu-ray Discs, DVDs, and other materials may subject you to civil and/or criminal liability.

For Blu-ray Disc Player progressive scan output : CONSUMERS SHOULD NOTE THAT NOT

• ALL HIGH DEFINITION TELEVISION SETS ARE FULLY COMPATIBLE WITH THIS product AND MAY CAUSE ARTIFACTS TO BE DISPLAYED IN THE PICTURE. IN CASE OF PROGRESSIVE SCAN PICTURE PROBLEMS, IT IS RECOMMENDED THAT THE USER SWITCH THE CONNECTION TO THE ‘STANDARD DEFINITION’ OUTPUT. IF THERE ARE QUESTIONS REGARDING OUR TV SET COMPATIBILITY WITH THIS product, PLEASE CONTACT OUR CUSTOMER SERVICE CENTER.

Network Service Disclaimer

All content and services accessible through this device belong to third parties and are protected by copyright, patent, trademark and/or other intellectual property laws. Such content and services are provided solely for your personal noncommercial use. You may not use any content or services in a manner that has not been authorized by the content owner or service provider. Without limiting the foregoing, unless expressly authorized by the applicable content owner or service provider, you may not modify, copy, republish, upload, post, transmit, translate, sell, create derivative works, exploit, or distribute in any manner or medium any content or services displayed through this device.

THIRD PARTY CONTENT AND SERVICES ARE PROVIDED “AS IS.” SAMSUNG DOES NOT WARRANT CONTENT OR SERVICES SO PROVIDED, EITHER EXPRESSLY OR IMPLIEDLY, FOR ANY PURPOSE. SAMSUNG EXPRESSLY DISCLAIMS ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO, WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. SAMSUNG DOES NOT GUARANTEE THE ACCURACY, VALIDITY, TIMELINESS, LEGALITY, OR COMPLETENESS OF ANY CONTENT OR SERVICE MADE AVAILABLE THROUGH THIS DEVICE AND UNDER NO CIRCUMSTANCES, INCLUDING NEGLIGENCE, SHALL SAMSUNG BE LIABLE, WHETHER IN CONTRACT OR TORT, FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, ATTORNEY FEES, EXPENSES, OR ANY OTHER DAMAGES ARISING OUT OF, OR IN CONNECTION WITH, ANY INFORMATION CONTAINED IN, OR AS A RESULT OF THE USE OF ANY CONTENT OR SERVICE BY YOU OR ANY THIRD PARTY, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

Third party services may be terminated or interrupted at any time, and Samsung makes no representation or warranty that any content or service will remain available for any period of time. Content and services are transmitted by third parties by means of networks and transmission facilities over which Samsung has no control. Without limiting the generality of this disclaimer, Samsung expressly disclaims any responsibility or liability for any interruption or suspension of any content or service made available through this device.

Samsung is neither responsible nor liable for customer service related to the content and services. Any question or request for service relating to the content or services should be made directly to the respective content and service providers.

English 71

08 Appendix

License

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol

• are trademarks of Dolby Laboratories.

Manufactured under license under U.S. Patent #’s : 5,451,942; 5,956,674; 5,974,380;

• 5,978,762; 6,487,535 & other U.S. and worldwide patents issued & pending. DTS and the Symbol are registered trademarks & DTS Digital Surround and the DTS logos are trademarks of DTS, Inc. Product includes software. © DTS, Inc. All Rights Reserved.

DivX

•

ABOUT DIVX VIDEO : DivX® is a digital video format created by DivX, Inc.

This is an official DivX Certified® device that plays DivX video. Visit www.divx.com for more information and software tools to convert your files into DivX video.

ABOUT DIVX VIDEO-ON-DEMAND : This DivX Certified® device must be registered in order to

play purchased DivX Video-on-Demand (VOD) movies. To obtain your registration code, locate the DivX VOD section in your device setup menu. Go to vod.divx.com for more information on how to complete your registration.

DivX Certified® to play DivX® video up to HD 1080p, including premium content.

DivX®, DivX Certified® and associated logos are trademarks of DivX, Inc. and are used under license.

Covered by one or more of the following U.S. patents : 7,295,673; 7,460,668; 7,515,710; 7,519,274.

HDMI, the HDMI Logo, and High-Definition Multimedia Interface are trademarks

• or registered trademarks of HDMI Licensing LLC in the United States and other countries.

Oracle and Java are registered trademarks of Oracle and/or its affiliates. Other names

• may be trademarks of their respective owners

This license is limited to private non-commercial use by end-user consumers for licensed contents.

• No rights are granted for commercial use. The license does not cover any product unit other than this product unit and the license does not extend to any unlicensed product unit or process conforming to ISO/IEC 11172-3 or ISO/IEC 13818-3 used or sold in combination with this product unit. The license only covers the use of this product unit to encode and/or decode audio files conforming to the ISO/IEC 11172-3 or ISO/IEC 13818-3. No rights are granted under this license for product features or functions that do not conform to the ISO/IEC 11172-3 or ISO/IEC 13818-3.

Open Source License Notice

•

In the case of using open source software, Open Source Licenses are available on the product

menu.

Blu-ray Disc™, Blu-ray™ and the logos are trademarks of the Blu-ray Disc Association.

•

This item incorporates copy protection technology that is protected by U.S. patents and other

• intellectual property rights of Rovi Corporation. Reverse engineering and disassembly are prohibited.

LIMITED WARRANTY TO ORIGINAL PURCHASER

This SAMSUNG brand product, as supplied and distributed by SAMSUNG and delivered new, in the original carton to the original consumer purchaser, is warranted by SAMSUNG against manufacturing defects in materials and workmanship for a limited warranty period of:

One (1) Year Parts and Labor*

(*90 Days Parts and Labor for Commercial Use)

This limited warranty begins on the original date of purchase, and is valid only on products purchased and used in the United States. To receive warranty service, the purchaser must contact SAMSUNG for problem determination and service procedures. Warranty service can only be performed by a SAMSUNG authorized service center. The original dated bill of sale must be presented upon request as proof of purchase to SAMSUNG or SAMSUNG's authorized service center. Transportation of the product to and from the service center is the responsibility of the purchaser.

SAMSUNG will repair or replace this product, at our option and at no charge as stipulated herein, with new or reconditioned parts or products if found to be defective during the limited warranty period specified above. All replaced parts and products become the property of SAMSUNG and must be returned to SAMSUNG. Replacement parts and products assume the remaining original warranty, or ninety (90) days, whichever is longer.

SAMSUNG’s obligations with respect to software products distributed by SAMSUNG under the SAMSUNG brand name are set forth in the applicable end user license agreement. Non-SAMSUNG hardware and software products, if provided, are on an “AS IS” basis. Non-SAMSUNG manufacturers, suppliers, publishers, and service providers may provide their own warranties.

This limited warranty covers manufacturing defects in materials and workmanship encountered in normal, and except to the extent otherwise expressly provided for in this statement, noncommercial use of this product, and shall not apply to the following, including, but not limited to: damage which occurs in shipment; delivery and installation; applications and uses for which this product was not intended; altered product or serial numbers; cosmetic damage or exterior finish; accidents, abuse, neglect, fire, water, lightning or other acts of nature; use of products, equipment, systems, utilities, services, parts, supplies, accessories, applications, installations, repairs, external wiring or connectors not supplied and authorized by SAMSUNG, or which damage this product or result in service problems; incorrect electrical line voltage, fluctuations and surges; customer adjustments and failure to follow operating instructions, cleaning, maintenance and environmental instructions that are covered and prescribed in the instruction book; product removal or reinstallation; reception problems and distortion related to noise, echo, interference or other signal transmission and delivery problems. SAMSUNG does not warrant uninterrupted or error-free operation of the product.

THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE LISTED AND DESCRIBED ABOVE, AND NO WARRANTIES WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, SHALL APPLY AFTER THE EXPRESS WARRANTY PERIODS STATED ABOVE, AND NO OTHER EXPRESS WARRANTY OR GUARANTY GIVEN BY ANY PERSON, FIRM OR CORPORATION WITH RESPECT TO THIS PRODUCT SHALL BE BINDING ON SAMSUNG. SAMSUNG SHALL NOT BE LIABLE FOR LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, OR ANY OTHER SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT, REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. NOR SHALL RECOVERY OF ANY KIND AGAINST SAMSUNG BE GREATER IN AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT SOLD BY SAMSUNG AND CAUSING THE ALLEGED DAMAGE. WITHOUT LIMITING THE FOREGOING, PURCHASER ASSUMES ALL RISK AND LIABILITY FOR LOSS, DAMAGE OR INJURY TO PURCHASER AND PURCHASER’S PROPERTY AND TO OTHERS AND THEIR PROPERTY ARISING OUT OF THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT SOLD BY SAMSUNG NOT CAUSED DIRECTLY BY THE NEGLIGENCE OF SAMSUNG. THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL PURCHASER OF THIS PRODUCT, IS NONTRANSFERABLE AND STATES YOUR EXCLUSIVE REMEDY.

Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

To obtain warranty service, please contact SAMSUNG customer care center.

Contact SAMSUNG WORLD WIDE

If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center.

Area Contact Center

North America

Canada 1-800-SAMSUNG (726-7864) www.samsung.com Mexico 01-800-SAMSUNG (726-7864) www.samsung.com U.S.A 1-800-SAMSUNG (726-7864) www.samsung.com

Latin America

Argentine 0800-333-3733 www.samsung.com Brazil 0800-124-421 / 4004-0000 www.samsung.com Chile 800-SAMSUNG (726-7864) www.samsung.com Colombia 01-8000112112 www.samsung.com Costa Rica 0-800-507-7267 www.samsung.com Dominica 1-800-751-2676 www.samsung.com Ecuador 1-800-10-7267 www.samsung.com El Salvador 800-6225 www.samsung.com Guatemala 1-800-299-0013 www.samsung.com Honduras 800-7919267 www.samsung.com Jamaica 1-800-234-7267 www.samsung.com Nicaragua 00-1800-5077267 www.samsung.com Panama 800-7267 www.samsung.com Peru 0-800-777-08 www.samsung.com Puerto Rico 1-800-682-3180 www.samsung.com Trinidad &

Tobago Venezuela 0-800-100-5303 www.samsung.com

Europe

Albania 42 27 5755 -

Austria

Belgium 02-201-24-18

Bosnia 05 133 1999 Bulgaria 07001 33 11 www.samsung.com Croatia 062 SAMSUNG (062 726 7864) www.samsung.com

Czech

Denmark 70 70 19 70 www.samsung.com Finland 030 - 6227 515 www.samsung.com France 01 48 63 00 00 www.samsung.com

Germany

Hungary 06-80-SAMSUNG (726-7864) www.samsung.com Italia 800-SAMSUNG (726-7864) www.samsung.com Kosovo +381 0113216899 Luxemburg 261 03 710 www.samsung.com Macedonia 023 207 777 Montenegro 020 405 888 -

Netherlands

Norway 815-56 480 www.samsung.com

Poland

Portugal 80820-SAMSUNG (726-7864) www.samsung.com

Rumania

1-800-SAMSUNG (726-7864) www.samsung.com

0810 - SAMSUNG (7267864, € 0.07/min)

800-SAMSUNG (800-726786) Samsung Zrt., česká organizační

složka, Oasis Florenc, Sokolovská394/17, 180 00, Praha 8

01805 - SAMSUNG (726-7864 € 0,14/Min)

0900-SAMSUNG (0900-7267864) (€ 0,10/Min)

0 801 1SAMSUNG (172678) / 022-607-93-33

1. 08010 SAMSUNG (72678) doar din reţeaua Romtelecom, tarif local

2. 021.206.01.10 - din orice reţea, tarif normal



Web Site

www.samsung.com

www.samsung.com/ be (Dutch) www.samsung.com/ be_fr (French)

www.samsung.com

Area Contact Center

Serbia

Slovakia 0800-SAMSUNG (726-7864) www.samsung.com Spain 902-1-SAMSUNG (902 172 678) www.samsung.com Sweden 0771 726 7864 (SAMSUNG) www.samsung.com

Switzerland

U.K Eire 0818 717100 www.samsung.com Lithuania 8-800-77777 www.samsung.com Latvia 8000-7267 www.samsung.com Estonia 800-7267 www.samsung.com

CIS

Russia 8-800-555-55-55 www.samsung.com Georgia 8-800-555-555 Armenia 0-800-05-555 Azerbaijan 088-55-55-555 -

Kazakhstan

Uzbekistan 8-10-800-500-55-500 www.samsung.com Kyrgyzstan 00-800-500-55-500 www.samsung.com Tadjikistan 8-10-800-500-55-500 www.samsung.com

Ukraine 0-800-502-000

Belarus 810-800-500-55-500 Moldova 00-800-500-55-500 -

Asia Pacific

Australia 1300 362 603 www.samsung.com New Zealand China

Hong Kong (852) 3698 4698

India

Indonesia

Japan 0120-327-527 www.samsung.com Malaysia 1800-88-9999 www.samsung.com

Philippines

Singapore 1800-SAMSUNG (726-7864) www.samsung.com Thailand 1800-29-3232 / 02-689-3232 www.samsung.com Taiwan 0800-329-999 www.samsung.com Vietnam 1 800 588 889 www.samsung.com

Middle East

Bahrain 8000-4726 www.samsung.com Egypt 08000-726786 www.samsung.com Jordan 800-22273 www.samsung.com Morocco 080 100 2255 www.samsung.com Oman 800-SAMSUNG (726-7864) www.samsung.com Saudi Arabia 9200-21230 www.samsung.com Turkey 444 77 11 www.samsung.com U.A.E 800-SAMSUNG (726-7864) www.samsung.com

Africa

Nigeria 0800-SAMSUNG (726-7864) www.samsung.com South Africa 0860-SAMSUNG (726-7864 ) www.samsung.com

0700 Samsung (0700 726

7864)

0848-SAMSUNG (7267864, CHF 0.08/min)

0330 SAMSUNG (7267864) www.samsung.com

8-10-800-500-55-500 (GSM: 7799)

0800 SAMSUNG (0800 726 786) 400-810-5858 / 010-6475 1880

3030 8282 / 1800 110011 / 1800 3000 8282 / 1800 266 8282

0800-112-8888 / 021-5699-7777

1-800-10-SAMSUNG(726-7864) / 1-800-3-SAMSUNG(726-7864) / 1-800-8-SAMSUNG(726-7864) / 02-5805777



Web Site

www.samsung.com
