Samson SWC88XBGT Datasheet

Concert 88x UHF Wireless System

WIRELESS

POSITIONING

Samson Concert 88x wireless systems combine professional-grade
audio with extreme ease-of-use. One-touch scan analyzes and
selects the clearest of 100 available channels. True-Diversity design,
auto-mute, and tone-key circuitry provide 300' of reliable wireless
performance, free from noise and interference. Each transmitter
provides up to 8 hours of operation from two AA batteries. Available

in handheld, presentation (lavalier), headworn, and guitar solutions.

FEATURES

Easy to Use

Simplicity and performance are at the core of Concert 88x wireless systems. The
system’s rack mountable CR88x receiver provides 100 wireless channels across a
broad 25 MHz bandwith and uses one-touch scanning to automatically select the
clearest channel available in your performance space. The receiver’s True Diversity
design minimizes dropouts while Tone-key and auto-mute technology prevents
undesired noise and interference when the transmitter is out of range. The True­Diversity dual-antenna design provides flawless wireless reception within a 300'
range.

At Home Anywhere

The CR88x receiver is designed to easily integrate into nearly any amplifier, sound
system or recording device, providing both balanced XLR and unbalanced 1/4”
audio connections. The half-rack housing and included rackmount kit allow a
single CR88x receiver – or multiple units – to be installed in a portable rack or at a
permanent venue.

Stay in Control

Available in handheld or beltpack transmitter configurations, Concert 88x provides
crystal clear audio and cable free performance. Concert 88x transmitters offer up
to eight hours of continuous operation using two AA batteries. Each transmitter
includes a convenient Mute switch, while advanced circuitry prevents annoying
pops when the system is muted. Concert 88x Handheld system includes the
Samson Q6 dynamic microphone tailored for vocal performance. The Concert 88x

APPLICATIONS

• Club-date musicians

• Wedding DJs and performers

• House of worship

• Education / Corporate AV

SPECIFICATIONS

System

Working Range 300' (100m) line of sight
Audio Frequency Response 50 Hz – 15 kHz
T.H.D. (Overall) <1% (@AF 1 kHz, RF 46 dBu)
Dynamic Range >10 0 dB A-weighted
Signal to Noise >90 dB
Tone Key Frequency 35 kHz
Transmitter RF Power 10 mW EIRP
Transmitter Power Requirements 2 x AA (LR6) alkaline batteries
Transmitter Battery Life Up to 8 hours

CB88 Beltpack Transmit ter

Input Connector Mini-XLR (P3)
Input Impedance 1M Ω
Input Gain Range 38 dB
Dimensions (HxLxD) 3.75" x 2.44" x 0.75"

96mm x 62mm x 18.5mm

Weight 0.2 lb / 93 g

CH88 Handheld Transmitt er

Input Gain Range 28 dB
Dimensions (HxØ) 10.23" x 2.1" / 260mm x 54mm
Weight 0.48 lb / 218 g

CR88x Receiver

Audio Output Level +14 dBu Unbalanced

+9 dBu Balanced
Sensitivity -100 dBm / 30 dB sinad
Image Rejection >50 dB
Operating Voltage 15 VDC 200mA
Dimensions (LxWxH) 8.25" x 4.9" x 1.75"

210mm x 125mm x 44mm
Weight 0.88 lb / 400 g

Beltpack is available in Presentation (LM5), Headset (HS5), Earset (SE10) and
Guitar systems.

©2019 Samson. All product descriptions and specs subject to change . samsontech.com
