Samson GT-P6800 User Manual
Some contents in this manual may differ from your device
depending on the software of the device or your service
provider.
www.samsung.com English (SEA). 05/2013. Rev. 1.0
To install Samsung Kies (PC Sync)
Download the latest version of Samsung Kies from 1.
the Samsung website (www.samsung.com/kies)
and install it on your computer.
Connect your device to a computer with a USB 2.
cable.
Refer to the Samsung Kies help for more
information.
GT-P6800
user manual
Using this manual
2
Using this manual
Thank you for choosing this Samsung mobile device.
This device will provide you with high-quality mobile
communication and entertainment based on Samsung’s
exceptional technology and high standards.
This manual has been specially designed to guide you
through the functions and features of your device.
Read me first
Before using your device, read the entire manual and all
●
safety instructions to ensure safe and proper use.
The descriptions in this manual are based on the default
●
settings of your device.
The images and screenshots used in this manual may differ
●
from the actual product.
The contents of this manual may differ from the product,
●
or from software provided by service providers or carriers,
and are subject to change without prior notice. Access
the Samsung website (
www.samsung.com
) for the latest
version of the manual.
Content (high quality content) that requires high CPU
●
and RAM usage will affect the overall performance of the
device. Applications related to the content may not work
properly depending on the device’s specifications and the
environment that it is used in.
Available features and additional services may vary by
●
device, software, or service provider.
Formatting and delivery of this manual is based on Android
●
operating systems and may vary depending on the user’s
operating system.
Applications on this device may perform differently from
●
comparable computer applications and may not include all
functions available in the computer version.
Using this manual
3
Applications and their functions may vary by region
●
or hardware specifications. Samsung is not liable for
performance issues caused by third-party applications.
Samsung is not liable for performance issues or
●
incompatibilities caused by edited registry settings or
modified operating system software. Attempting to
customise the operating system may cause your device or
applications to work improperly.
You can upgrade your device’s software by accessing the
●
Samsung website (
www.samsung.com
).
Software, audio, wallpapers, and images provided in this
●
device are licensed for limited use between Samsung
and their respective owners. Extracting and using
these materials for commercial or other purposes is an
infringement of copyright laws. Samsung is not liable for
such copyright infringement by users.
You may incur additional charges for data services, such as
●
messaging, uploading and downloading, auto-syncing, or
using location services. To avoid additional charges, select
an appropriate data tariff plan. For details, contact your
service provider.
Please keep this manual for future reference.
●
Instructional icons
Before you start, familiarise yourself with the icons used in this
manual:
Warning—situations that could cause injury to
yourself or others
Caution—situations that could cause damage to
your device or other equipment
Note—notes, usage tips, or additional information
Using this manual
4
►
Refer to—pages with related information; for
example:
► p. 12 (represents “refer to page 12”)
→
Followed by—the order of options or menus you
must select to perform a step; for example: In the
application list, select Settings
→
About device
(represents Settings, followed by About device)
Copyright
Copyright © 2013 Samsung Electronics
This manual is protected under international copyright laws.
No part of this manual may be reproduced, distributed,
translated, or transmitted in any form or by any means,
electronic or mechanical, including photocopying, recording,
or storing in any information storage and retrieval system,
without the prior written permission of Samsung Electronics.
Trademarks
SAMSUNG and the SAMSUNG logo are registered
●
trademarks of Samsung Electronics.
The Android logo, Google
●
™
, Google Maps™, Google
Mail
™
, YouTube™, Google Play™ Store, Google Latitude™,
and Google Talk
™
are trademarks of Google, Inc.
Bluetooth
●
®
is a registered trademark of the Bluetooth SIG,
Inc. worldwide.
Windows Media Player
●
®
is a registered trademark of the
Microsoft Corporation.
Using this manual
5
Wi-Fi
●
®
, Wi-Fi Protected Setup™, Wi-Fi Direct™, Wi-Fi
CERTIFIED
™
, and the Wi-Fi logo are registered trademarks
of the Wi-Fi Alliance.
Your device uses a non-harmonised frequency and is
intended for use in all European countries. The WLAN can
be operated in the EU without restriction indoors, but
cannot be operated outdoors.
DivX
●
®
, DivX Certified®
and associated logos
are trademarks of Rovi
Corporation or its subsidiaries
and are used under licence.
All other trademarks and copyrights are the property of
●
their respective owners.
Using this manual
6
ABOUT DIVX VIDEO
DivX® is a digital video format created by DivX, LLC, a
subsidiary of Rovi Corporation. This is an official DivX
Certified
®
device that has passed rigorous testing to verify
that it plays DivX video. Visit
www.divx.com
for more
information and software tools to convert your files into DivX
videos.
ABOUT DIVX VIDEO-ON-DEMAND
This DivX Certified® device must be registered in order to play
purchased DivX Video-on-Demand (VOD) movies. To obtain
your registration code, locate the DivX VOD section in your
device setup menu. Go to
vod.divx.com
for more information
on how to complete your registration.
DivX Certified
®
to play DivX® video up to HD 720p, including
premium content.
Contents
7
Assembling ........................................................ 11
Unpack ................................................................................................. 11
Device layout ..................................................................................... 12
Keys ........................................................................................................ 14
Insert the SIM or USIM card ......................................................... 15
Charge the battery .......................................................................... 16
Insert a memory card (optional) ................................................ 18
Getting started .................................................. 21
Turn on or off your device ............................................................ 21
Use the touch screen ...................................................................... 21
Lock or unlock the touch screen and the keys .................... 24
Get to know the Home screen ................................................... 25
Access applications ......................................................................... 29
Launch multiple applications ..................................................... 31
Customise your device .................................................................. 32
Enter text ............................................................................................. 38
Web and GPS-based services ............................ 40
Internet ................................................................................................. 40
Game Hub ........................................................................................... 44
Maps ...................................................................................................... 44
Music Hub ........................................................................................... 46
Navigation ........................................................................................... 46
Local ....................................................................................................... 47
Play Store ............................................................................................. 48
Play Music ............................................................................................ 49
Contents
Contents
8
Pulse ...................................................................................................... 49
Readers Hub ....................................................................................... 50
Samsung Apps .................................................................................. 50
YouTube ............................................................................................... 51
Voice Search ....................................................................................... 52
Communication ................................................. 53
Calling ................................................................................................... 53
Messages ............................................................................................. 64
Google Mail ........................................................................................ 66
Email ...................................................................................................... 67
Talk ......................................................................................................... 71
Messenger ........................................................................................... 72
Google+ ............................................................................................... 72
Entertainment .................................................... 73
Camera ................................................................................................. 73
Video Player ........................................................................................ 82
Gallery ................................................................................................... 85
Photo Editor ....................................................................................... 88
Video Editor ........................................................................................ 89
Music Player ........................................................................................ 91
Personal information ........................................ 95
Contacts ............................................................................................... 95
S Planner .............................................................................................. 98
Memo .................................................................................................. 100
Pen memo ......................................................................................... 101
Contents
9
Connectivity ..................................................... 102
USB connections ............................................................................ 102
Wi-Fi ..................................................................................................... 104
Wi-Fi Direct ........................................................................................ 107
Mobile network sharing .............................................................. 108
Bluetooth ........................................................................................... 110
GPS ....................................................................................................... 112
VPN connections ............................................................................ 113
Tools .................................................................. 116
Alarm ................................................................................................... 116
Calculator .......................................................................................... 116
Downloads ........................................................................................ 117
Dropbox ............................................................................................. 118
My Files ............................................................................................... 119
Polaris Office .................................................................................... 121
Google ................................................................................................ 122
SIM Toolkit ......................................................................................... 123
World Clock ...................................................................................... 123
Settings ............................................................ 124
Access the setting options ......................................................... 124
Wi-Fi ..................................................................................................... 124
Bluetooth ........................................................................................... 124
Data usage ........................................................................................ 124
More settings ................................................................................... 125
Blocking mode ................................................................................ 127
Sound .................................................................................................. 127
Contents
10
Display ................................................................................................ 128
Storage ............................................................................................... 129
Power saving mode ...................................................................... 129
Battery ................................................................................................ 129
Application manager ................................................................... 130
Location services ............................................................................ 130
Lock screen ....................................................................................... 130
Security ............................................................................................... 131
Language and keyboard ............................................................. 133
Cloud ................................................................................................... 135
Backup and reset ............................................................................ 135
Add account ..................................................................................... 135
Motion ................................................................................................ 136
Accessory ........................................................................................... 136
Date and time .................................................................................. 137
Accessibility ...................................................................................... 137
Developer options ......................................................................... 138
About device .................................................................................... 140
Troubleshooting .............................................. 141
Assembling
11
Assembling
Unpack
Check your product box for the following items:
Mobile device
●
Quick start guide
●
Use only Samsung-approved software. Pirated or illegal
software may cause damage or malfunctions that are
not covered by your manufacturer's warranty.
The items supplied with your device and available
●
accessories may vary depending on your region or
service provider.
You can buy additional accessories from your local
●
Samsung retailer.
The supplied items are designed only for your device
●
and may not be compatible with other devices.
Other accessories may not be compatible with your
●
device.
Assembling
12
Device layout
Front view
›
Number Function
1
Earpiece
2
Proximity sensor
3
Light sensor
4
Speaker
5
Microphone
6
Front camera lens
7
Power/Reset/Lock key
8
Volume key
9
Multifunction jack
Assembling
13
Rear view
›
Number Function
10
Microphone
1
1 1
Rear camera lens
12
Flash
13
Main antenna
14
Headset jack
2
15
GPS antenna
3
16
SIM card slot
17
Memory card slot
1. Active only when you use the speakerphone feature or record
videos.
2. Connecting a headset to your device improperly can damage
the headset jack or the headset.
3. Do not touch or cover the area around the antenna with your
hands or other objects while using the GPS functions.
Assembling
14
Keys
Key Function
Power/
Reset
1
/
Lock
Turn on the device (press and hold);
Access the device options (press
and hold); Reset the device (press
and hold for 10-15 seconds); Turn
off and lock the touch screen or turn
it on.
Volume Adjust the device’s volume.
1. If your device experiences fatal errors, hanging, or freezing, you
may need to reset the device to regain functionality.
Assembling
15
Insert the SIM or USIM card
When you subscribe to a cellular service, you will receive
a Subscriber Identity Module (SIM) card, with subscription
details, such as your personal identification number (PIN) and
optional services. To use UMTS or HSDPA services, you can
purchase a Universal Subscriber Identity Module (USIM) card.
Open the cover of the SIM card slot.
1
Insert the SIM or USIM card with the gold-coloured
2
contacts facing downwards.
Do not insert a memory card into the SIM card slot.
●
If the memory card becomes lodged in the SIM card
slot, you must take your device to a Samsung Service
Centre to have the memory card removed.
The SIM card slot of your device is only suited for
●
standard SIM cards. Inserting a microSIM card or a
microSIM card with an unauthorised holder may
cause damage to the SIM card slot of your device.
Close the cover of the SIM card slot.
3
Assembling
16
Charge the battery
Before using the device for the first time or when the battery
has been unused for an extended period, you must charge
the battery. Charge the battery only with a charger. You
cannot charge the battery with a USB cable.
You cannot replace the battery in the device. If you have
problems with the battery or need it replaced, take the device
to a Samsung Service Centre.
Use only Samsung-approved chargers and cables.
●
Unapproved chargers or cables may cause batteries
to explode or damage your device.
The back cover of your device is made of metal. Use
●
only the ETA-P12X/ETA-P11JBE series charger with
your device to prevent electric shock.
When your battery is low, the device will emit a
●
warning tone and show a low battery message.
Recharge your battery to continue using your device.
If the battery is completely discharged, you cannot
●
turn on the device, even while it is charging. Allow a
depleted battery to charge for a few minutes before
you try to turn on the device.
The shape of the USB power adapter may differ
●
depending on your region.
Assembling
17
Connect the USB cable to the USB power adapter and
1
then plug the end of the USB cable into the multifunction
jack.
Connecting the USB cable improperly may cause
serious damage to the device or USB power adapter.
Any damage caused by misuse is not covered by the
warranty.
Plug the USB power adapter into an electrical socket.
2
If the device receives an unstable power supply while
●
charging, the touch screen may not function. If this
happens, unplug the USB cable from the device.
The device may heat up while charging. This is
●
normal and should not affect your device’s lifespan or
performance.
If your device is not charging properly, take your
●
device and the charger to a Samsung Service Centre.
When the battery is fully charged, first unplug the USB
3
cable from the device, and then unplug the USB power
adapter from the electrical socket.
Assembling
18
To save energy, unplug the USB power adapter when
not in use. The USB power adapter does not have a
power switch, so you must unplug the USB power
adapter from the electrical socket when not in use to
avoid wasting power. The device should remain close to
the electrical socket while charging.
Reduce the battery consumption
›
Your device provides options that help you save battery
power. By customising these options and deactivating
features in the background, you can use the device longer
between charges:
When you are not using your device, switch to Sleep mode
●
by pressing the Power key.
Close unnecessary applications with the task manager.
●
Deactivate the Bluetooth feature.
●
Deactivate the Wi-Fi feature.
●
Deactivate auto-syncing of applications.
●
Decrease the backlight time.
●
Decrease the brightness of the display.
●
Insert a memory card (optional)
Your device accepts memory cards with maximum capacities
of 32 GB. Depending on the memory card manufacturer and
type, some memory cards may not be compatible with your
device.
Samsung uses approved industry standards for memory
cards, but some brands may not be fully compatible
with your device. Using an incompatible memory card
may damage your device or the memory card. It may
also corrupt data saved on the memory card.
Assembling
19
Your device supports only the FAT file structure for
●
memory cards. If you insert a memory card formatted
with a different file structure, your device will ask you
to reformat the memory card.
Frequent writing and erasing of data will shorten the
●
lifespan of your memory cards.
When you insert a memory card into your device,
●
the memory card’s file directory will appear in the
extSdCard folder.
Open the cover of the memory card slot.
1
Insert a memory card with the gold-coloured contacts
2
facing downwards.
Push the memory card in the memory card slot until it
3
locks in place.
Close the cover of the memory card slot.
4
Assembling
20
Remove a memory card
›
Ensure that the device is not currently accessing the memory
card.
In the application list, select
1
Settings → Storage →
Unmount SD card
→
OK.
Open the cover of the memory card slot.
2
Push the memory card gently until it disengages from the
3
device.
Remove the memory card.
4
Close the cover of the memory card slot.
5
Do not remove a memory card while the device is
transferring or accessing information, as this could
result in loss of data or damage to the memory card or
device.
Format a memory card
›
Formatting your memory card on a computer may cause
incompatibilities with your device. Format the memory card
only on the device.
In the application list, select Settings
→
Storage → Format
SD card
→
Format SD card → Delete all.
Before formatting the memory card, remember to make
backup copies of all important data. The manufacturer’s
warranty does not cover loss of data resulting from user
actions.
21
Getting started
Getting started
Turn on or off your device
To turn on your device, press and hold the Power key.
If you are turning on your device for the first time, follow
the on-screen instructions to set up your device. You
must sign in to Google or create a Google account to
use applications that interact with the Google server.
To turn off your device, press and hold the Power key, and
then select Power off
→
OK.
Follow all posted warnings and directions from
●
approved personnel in areas where the use of wireless
devices is restricted, such as aeroplanes and hospitals.
To use only your device’s non-network features,
●
switch to Flight mode. ► p. 125
Use the touch screen
Your device’s touch screen lets you easily select items or
perform functions. Learn basic actions for using the touch
screen.
22
Getting started
Do not press the touch screen with your fingertips,
●
or use sharp tools on the touch screen. Doing so may
damage the touch screen or cause it to malfunction.
Do not allow the touch screen to come into contact
●
with other electrical devices. Electrostatic discharges
can cause the touch screen to malfunction.
Do not allow the touch screen to come into contact
●
with liquids. The touch screen may malfunction in
humid conditions or when exposed to liquids.
Leaving the touch screen idle for extended periods
●
may result in afterimages (screen burn-in) or ghosting.
Turn off the touch screen when you do not use the
device.
For optimal use of the touch screen, remove the
●
screen protection film before using your device.
Your touch screen has a layer that detects small
●
electrical charges emitted by the human body. For
best performance, tap the touch screen with your
fingertip. The touch screen will not react to touches
from sharp objects, such as a stylus or pen.
Control your touch screen with the following actions:
Tap
Touch once to select or launch a
menu, option, or application.
23
Getting started
Tap and hold
Tap an item and hold it for more than
2 seconds.
Drag
Tap an item and move it to a new
location.
Double-tap
Tap an item twice quickly.
Flick
Briskly scroll up, down, left, or right to
move through lists or screens.
24
Getting started
Pinch
Place two of your fingers far apart,
and then pinch them together.
Your device turns off the touch screen when you do
●
not use it for a specified period. To turn on the screen,
press the Power key.
You can set the length of time that the device waits
●
before turning off the screen. In the application list,
select Settings
→
Display → Screen time-out.
Lock or unlock the touch screen and the
keys
When you do not use the device for a specified period, your
device turns off the touch screen and locks the touch screen
and the keys automatically to prevent unintended operations.
To lock the touch screen and the keys manually, press the
Power key.
To unlock them, turn on the screen by pressing the Power
key, tap anywhere on the screen, and then drag your finger
outside of the large circle.
You can activate the screen lock feature to prevent
others from using or accessing your personal data and
information saved in your device.
► p. 35
25
Getting started
Get to know the Home screen
From the Home screen, you can view your device’s status and
access applications.
The Home screen has multiple panels. Scroll left or right to
view the panels on the Home screen. You can also select one
of the dots at the bottom of the screen to move directly to the
corresponding panel.
System bar
›
From the system bar at the bottom of the screen, you can
quickly navigate screen and more.
6
Number Function
1
Return to the previous screen.
2
Return to the Home screen; Launch the Google
search application (tap and hold).
3
Open the list of recent applications; Access the
application list (tap and hold).
4
Launch the application that you specified as
the quick launch shortcut. You can change this
quick launch shortcut by selecting Settings
→
Display
→
Quick launch
.
5
Open the mini apps panel.
6
View the current time and your device’s status;
Open the notifications panel.
26
Getting started
Indicator icons
›
Icons shown on the display may vary depending on
your region or service provider.
Icon Definition
No signal
Signal strength
Connected to GPRS network
Connected to EDGE network
Connected to HSDPA network
Wi-Fi AP connected
Bluetooth feature activated
GPS-based services in use
Call in progress
Missed call
Connected to computer
No SIM or USIM card
New message
Alarm activated
Roaming (outside of service area)
Flight mode activated
27
Getting started
Icon Definition
Error occurred or caution required
Battery power level
Use the notifications panel
›
To open the notifications panel, tap the right bottom of the
screen. To hide the panel, select
.
From the notifications panel, you can view your device’s
current status and use the following options:
Wi-Fi
●
: Activate or deactivate the Wi-Fi feature. ► p. 104
GPS
●
: Activate or deactivate the GPS feature. ► p. 112
Sound
●
: Activate or deactivate Silent mode. You can mute
your device or set it to vibrate in Silent mode.
Screen rotation
●
: Allow or prevent the interface from
rotating when you rotate the device.
Bluetooth
●
: Activate or deactivate the Bluetooth feature.
► p. 110
Mobile data
●
: Activate or deactivate the data connection.
Blocking mode
●
: Activate or deactivate Blocking mode. In
Blocking mode, the device will block notifications. To select
which notifications will be blocked, select Settings
→
Blocking mode.
Power saving
●
: Activate or deactivate Power saving mode.
Sync
●
: Activate or deactivate auto-syncing of applications.
The options available may vary depending on your
region or service provider.
28
Getting started
Move an item on the Home screen
›
Tap and hold an item, and then
drag it to a new location.
You can add an item to a new
folder or move it to a new panel.
Tap and hold the item, and
then drag it to Create folder or
Create page.
Remove an item from the Home screen
›
Tap and hold an item, and then drag it to the rubbish bin.
›
Add or remove a panel from the Home screen
You can add or remove Home screen panels to organise
widgets.
On the Home screen, place two fingers on the screen and
1
pinch them together to switch to Edit mode.
29
Getting started
Add, remove, or reorganise panels:
2
To remove a panel, tap and hold the panel’s thumbnail
●
image, and then drag it to the rubbish bin.
To add a new panel, select
●
.
To set the first panel of the Home screen, select
●
.
To change the order of panels, tap and hold the panel’s
●
thumbnail image, and then drag it to a new location.
Select
3
to return to the previous screen.
Use widgets
›
Widgets are small applications that provide convenient
functions and information on your Home screen.
The widgets available may vary depending on your
region or service provider.
In the application list, select
1
Widgets to open the widget
panel.
Scroll left or right on the widget panel to find a widget.
2
Tap and hold a widget to add it to the Home screen.
3
Access applications
Launch applications and take full advantage of features on
your device. You can reorganise the application list to match
your preferences, or download applications from the Internet
to enhance your device’s functionality.
On the Home screen, select
1
to access the application
list.
Scroll left or right to another screen.
2
You can also select one of the dots at the bottom of the
screen to move directly to the corresponding screen.
Loading...
