Sagem MY 304X, MY 302X User Manual

ENGLISH
MY 302X MY 304X
251108518.qxd 19/12/01 9:36 Page 1
Switch on
Press .
1
Lock and unlock the keyboard from the standby screen
Press * then OK.
Redial last number
Call
Dial the number then press .
Answer
Press .
Hang up
Press .
Switch off
Press (long press).
Hands-free
To communicate, press .
MY_304X_EN-00.p65 28/12/01, 11:161
Press twice.
Make a call from a number stored in the directory
By name: enter the first letter of the name,
press
correspondent, then press to call.
By location in the directory: enter the location number then press
, scroll down the list to find your
to call.
*
Briefly, the functions
MENUS
Enter using
or
Navigate using and
Games
2
Validate using OK Quit or return to the previous
menu using C
Services
Directory
Accessories
Security
Briefly, the menus
MY_304X_EN-00.p65 28/12/01, 11:162
Controls
Text messages
Call services
Ringing and beeps
You have just bought a mobile phone and we congratulate you on your choice.
Your phone will allow you to use different international networks depending on the roaming agreements between the operators.
We would like to remind you that this phone is approved to European standards.
To get the most out of using your phone, we recommend that you read this manual carefully and keep it handy for future reference if needed.
WARNING
According to the configuration of the networks and associated subscriptions, certain functions may not be available (indicated by *).
If an incompatible SIM card is inserted, a message will be displayed when switching on your phone. For further information, contact your Operator.
The SAGEM logo and trademark are the property of SAGEM SA. AT is a registered trademark of Hayes Microcomputer products Inc. Hayes is a registered trademark of Hayes Microcomputer Products Inc. T9 Text Input is a registered trademark of ©Tegic Communications Inc. T9 is licensed under one or more of the following U.S. Patents: 5,818,437, 5,953,541, 5,187,480, 5,945,928, 6,011,554 and additional patents are pending worldwide.
Compatibility of your SIM card
Your phone is compatible with SIM 3V cards only.
3
GLOSSARY
Outgoing call A call made from your phone.
Incoming call A call received by your phone.
SIM card The card containing your subscription
and access rights to services. The detachable part is the micro-SIM.
PIN The personal code linked to your SIM
card.
PIN2 The second personal code linked to
your SIM card to access certain functions (*).
Phone code The phone code is a secret code
intended to protect the phone in case of theft.
IMEI The identification number of your
phone.
SMS Short Message Service: sending and
receipt of text messages, icons, animated screen savers and melodies.
Service Company which manages the network provider or subscription. Operator
MY_304X_EN-00.p65 28/12/01, 11:163
1. Presentation of the phone ..................................... 6
1.1 Exchanging the coloured front panel ................... 9
2. Getting started ..................................................... 10
2.1 Information on the SIM card .............................. 10
2.2 Installing the SIM card and the battery .............. 11
2.3 Charging the battery ......................................... 12
2.4 Switching on/switching off, starting up .............. 13
2.5 Menu access .................................................... 14
2.6 Deleting characters ........................................... 14
3. Initial communication - Hands-free mode ............ 15
3.1 Making a call ..................................................... 15
3.2 Receiving a call ................................................ 16
3.3 Volume control .................................................. 16
3.4 Hands-free mode .............................................. 16
3.5 Ending a call ..................................................... 16
4. Menu list .............................................................. 17
How to use the directory ...................................... 20
5.
5.1 Directory display ............................................... 20
5.2 Storing a number .............................................. 20
5.3 Deleting a number ............................................ 21
5.4 Call groups ....................................................... 21
5.5 Sorting .............................................................. 23
5.6 Sending a short message to a stored number .. 23
5.7 Directory space memory ................................... 23
5.8 Displaying personal numbers ........................... 23
5.9 Making a call with a stored number ................... 23
Contents
4
6. SMS ..................................................................... 25
6.1 Receiving an SMS message ............................. 25
6.2 Editing a message using Easy Message T9 .. 28
6.3 Edited messages .............................................. 30
7. How to use the call related features .................... 31
7.1 Forwarding calls ............................................... 31
7.2 Viewing the list of the last numbers used .......... 32
7.3 Monitoring the duration and cost of calls ........... 32
7.4 Displaying the numbers .................................... 33
7.5 Authorising double call ...................................... 34
7.6 Configuring automatic redial ............................. 34
7.7 Voice mail number ............................................ 34
7.8 Local information distribution ............................ 34
7.9 Replacing the international prefix ...................... 34
7.10 Placing calls on hold ........................................ 34
7.11 Multi-conferencing (*) ...................................... 35
8. How to adjust the ringing tones
and the vibrator ................................................... 36
8.1 Selecting the volume and the type
of ringing tone ................................................... 36
8.2 Call groups ....................................................... 37
8.3 Personalising the ringing tone ........................... 37
8.4 Setting the vibrator ............................................ 37
8.5 Selecting silent mode ........................................ 38
8.6 Setting the beeps .............................................. 38
8.7 Deleting DTMF tones ........................................ 38
MY_304X_EN-00.p65 28/12/01, 11:164
9. How to adjust and customize your phone............ 39
9.1 Customizing your phone ................................... 39
9.2 Selecting the display language ......................... 41
9.3 Select the type of response .............................. 41
9.4 Selecting the network ....................................... 42
9.5 Setting the time and date .................................. 43
9.6 Controlling screen contrast ............................... 43
9.7 Converting currencies....................................... 43
10.How to use the security features
of your phone ....................................................... 44
10.1 Locking the keyboard ...................................... 44
10.2 Changing the PIN number ............................... 44
10.3 Changing the PIN2 number (*) ........................ 45
10.4 Changing the phone code ............................... 45
10.5 Changing the operator password (*) ................ 46
10.6 Limiting incoming calls (*) ................................ 46
10.7 Limiting outgoing calls (*) ................................ 46
10.8 Setting up the pre-set directory (*) ................... 47
10.9 Charge checking (*) ........................................ 47
11. Other functions .................................................... 48
11.1 Calculator ........................................................ 48
11.2 Setting the alarm ............................................. 49
11.3 Setting the timer .............................................. 49
11.4 Configure your phone with a car kit ................. 49
11.5 Data parameters ............................................. 49
12. WAP Function ..................................................... 50
13.
Games ................................................................. 53
Available accessories .......................................... 54
14.
5
15.
Upkeep ................................................................ 55
Recommendations .............................................. 56
16.
Answers to your questions ........................................ 59
Contents
MY_304X_EN-00.p65 28/12/01, 11:175
Antenna
6
Ear phone/speaker
High definition graphics screen
Programmable key 1
Correction
Stop/End call
Scrolling arrow
Microphone
WARNING!
During a call, mind you do not obstruct the microphone with your hand.
1. Presentation of the phone
MY_304X_EN-01.p65 28/12/01, 11:196
Indicator light
Programmable key 2
@
(depending on model)
Mobile Internet access key
Operate/Call
Activation of hands-free
Validate
Scrolling arrow
Battery charging and accessories socket
Function keys
Stop  Reject a call  Hang up
Go  Call a number  Receive a call  Hands-free mode
C Short press: Return to the previous
menu  Delete a character Long press: Exit menu mode  Complete deletion of the entry
OK Validate
- Programmable keys for direct access to the functions that you have selected (depending on model)
- Volume control during conversation
key: lower, key: louder)
(
- Contextual action
@ Mobile Internet access key
and Entry and scrolling through the
menus.
7
Alphanumeric keyboard
Made up of 12 keys: 0 to 9, * and #. To obtain a number or letter, hold down the
relevant key until the desired number or letter appears.
Letters with accents are obtained by a long press on accent.
Punctuation marks and special symbols are obtained by a long press on the # key.
after entering the letter with no
*
Key 1
A long press on key 1 allows you to access the voicemail service (depending on model).
1. Presentation of the phone
MY_304X_EN-01.p65 28/12/01, 11:207
Display
The high definition graphics screen enables you to read messages easily. Various icons inform you about the status of functions.
Battery charge indicator (black if charged, clear if discharged)
Received signal strength indicator (maximum strength: 5 bars) ; the R letter indicates if the network found does not correspond to the subscription
flashes, the phone is
If searching for a network
Hands-free loudspeaker
Call in progress
Permanent call forwarding
Silent mode
1. Presentation of the phone
8
The three keys located under the screen are allocated to actions described at the bottom of the screen just above the key, each time it is necessary.
For example:
Validate Pressing
Receipt of SMS and presence of SMS not read; Flashing: SMS memory full.
Voice messages present.
validates the current
function.
MY_304X_EN-01.p65 28/12/01, 11:208
1.1 Exchanging the coloured front
1
2
panel
Switch off the phone. Remove the rear cover and the battery
(see on page 11). Hold the phone with the front panel facing
downward, and with the antenna pressed against you.
Free the front panel by moving the
retention lugs ().
11
22
9
Release the front panel by moving the retention lugs
() if necessary and pushing them with a pen for
example.
11
Install the keyboard in the new front panel. Position the phone and the new front panel as
shown.
Replace the battery and the cover.
1. Presentation of the phone
MY_304X_EN-01.p65 28/12/01, 11:209
10
2.1 Information on the SIM card
2. Getting started
2. Getting started
MY_304X_EN-02.p65 28/12/01, 11:2110
To use your phone, you have a small card called a SIM card. In addition to all of the information necessary for the network, this card contains other information that you can modify:
 secret codes (PIN and PIN2 -
Personal Identification Number)  directory  mini-messages  functioning of specific services.
SIM card
This card must be handled and stored with care in order to avoid excessive stresses or scratches that would damage it. If your SIM card is lost, contact your Operator or Service Provider immediately. Note: Do not leave you SIM card within the reach of small children.
PIN code
This is the personal code for your SIM card. You may be asked to enter this code when the instruction: Pin number ? appears after you switch on your phone.
Enter the code of between 4 and 8 digits given to you by your operator. These digits will not be displayed on the screen for security reasons.
Press # or OK or to validate.
PIN2 code (*)
If one was given to you by your Operator, a second PIN code provides secure access to certain functions.
Warni ng
If the wrong PIN code is entered three times in a row, the card will be locked. To unlock your card:
- enter **05*
- enter the PUK code (Personal Unlocking Key) provided by your Network Operator and validate,
- enter your PIN code and validate,
- enter your PIN code again and validate.
After 5 or 10 times (depending on SIM card type), the SIM card will be permanently locked. Contact your Operator or your Service Provider to obtain a new card. The same procedure (entering 052) applies when the PIN-2 code is blocked (PUK 2 code).
11
2.2 Installing the SIM card and the battery
Switch off your phone and disconnect the charger.
The SIM card is inserted beneath the phones battery.
Turn your phone over and remove the rear cover. Press on top and make it slide.
Slide the card along the base beneath the retaining plate, with the gold coloured sections facing towards the phone and the cut­off corner lined up to match the drawing on the phone.
Place the battery by first inserting the upper section into the opening.
Replace the cover sliding it until it locks.
2. Getting started
S
1
2
MY_304X_EN-02.p65 28/12/01, 11:2211
2.3 Charging the battery
Your phone is powered by a rechargeable battery. A new battery must be charged for at least 4 hours before it is used for the first time. It will reach its nominal capacity after several usage cycles.
When your battery has run down, the phone displays it and cuts out.
To recharge your battery:
Connect the charger to a wall outlet. Connect the end of the charging cable to
the bottom of your phone.
The phone will start charging. The battery charging indicator indicates the charge. Charging stops by itself.
Unplug the cable.
It is possible that during charging, the battery may heat up slightly; this is normal.
2. Getting started
12
WARNING
There is a risk of explosion if the battery is incorrectly replaced or disposed of in fire.
Do not short-circuit. The battery does not contain any
components that can be changed by you. Do not attempt to open the battery case. Only use the correct chargers and
batteries as shown in the manufacturers catalogue.
Spent batteries must be collected at the appropriate sites.
You are advised to remove the battery if you intend to leave your telephone unused for a long period.
MY_304X_EN-02.p65 28/12/01, 11:2212
2.4 Switching on/switching off, starting up
To switch on your phone:
Press to switch on your phone. If access to the SIM card is
protected by a secret code, the phone will ask you to enter your PIN code.
Enter the code of between 4 and 8 digits given to you when you were given your SIM card. These digits will not be displayed on the screen for security reasons.
Press # or OK or to validate.
Control of the PIN code
If your phone displays SIM absent,
press (long
press) to switch off your phone and check that your SIM card is correctly positioned.
13
Searching for a network
The phone then searches for a network on which it can communicate:
If it finds one, the name of the network appears on the screen, and the indicator light flashes green.
You are ready to make or receive a call.
If the R letter and a network name are displayed, calls can be made and the indicator light flashes green.
If the R letter is displayed without any network name, only emergency services will be accessible (police, ambulance, fire brigade).
If the flashes, the phone will keep searching. No network is available.
2. Getting started
Network indicator
The indicator of the level of network signal received enables you to visualise the quality of reception. If it shows less than three bars, look for better reception to make your call in good conditions.
MY_304X_EN-02.p65 28/12/01, 11:2213
Switching off
14
2.6 Deleting characters
Hold down the key until the end message is displayed. Release the key. The phone
switches off.
2.5 Menu access
The menu functions permit you to verify or modify the various functions of your phone to adapt it to your needs.
Press the scrolling arrows or
to access the menus.
Scroll through the menus using the scrolling arrows then press OK to access the selected menu.
Each time you want to validate an action, press OK.
To abandon an action, press C. To exit the menu mode, press
and hold C.
2. Getting started
MY_304X_EN-02.p65 28/12/01, 11:2214
Direct access to menus
To directly access a menu, press then enter the number of the selected menu.
You can cancel an entry error:
Press quickly on C to delete the last character.
If you press this key longer, you will delete the previous word.
3. Initial communication
Hands-free mode
15
3.1 Making a call
The network is displayed.
Dial the number, including the area code if necessary, by pressing keys on the alphanumeric keypad.
Press .
During the call, flashes on the screen, and tones may signal the establishment of a connection.
When the person you have called answers, speak.
Emergency services
Depending on the operator, you can contact the emergency services with or without a SIM card or when the keyboard is locked. It is sufficient to be in a zone served by a network. To call the international emergency service, dial 11 2 then press .
Other emergency service numbers may exist, depending on the country.
3. Initial communication
International call
Press 0 (long press) to display + then dial the country code without waiting for a tone, then the number you require.
MY_304X_EN-03.p65 28/12/01, 11:2315
3.2 Receiving a call
When you receive a call:
Press then speak.
The callers number is displayed when it is presented to the network.
All incoming and outgoing call numbers are registered in the list of the last calls.
3.3 Volume control
Increase or decrease the volume during a conversation by pressing the
or
keys.
3. Initial communication
16
3.4 Hands-free mode
During a call, you can transfer from handset mode to hands-free mode simply by pressing one key and the reverse.
Press .
The screen displays
for
The Hands-free mode enables you to follow a conversation with several people and be free to move, for example, to take notes during your conversation.
handset mode and for «hands-free» mode.
Before putting the phone to your ear, check the volume control settings as well as the selected listening method, especially if using integrated hands free mode, which could cause ear damage if used incorrectly.
3.5 Ending a call
Press .
The end of call message appears on the screen.
MY_304X_EN-03.p65 28/12/01, 11:2316
4. Menu list
According to the model of your phone, to the configuration of the networks and associated subscriptions, certain functions may not be available (indicated by *).
17
You have the option of personalising the presentation of the menus, and so of limiting access to certain functions (See chapter How to adjust and customize your phone).
The following list presents the expert level (limiting itself to the 3rd sub-menu).
Services
Access to specific services offered by the operator
Directory
Directory menu 20
Sort by location Create record Call groups Available memory Personal numbers Quit
Scroll through the names entered 23
See record Modify Delete Call Send message Quit
4. Menus
MY_304X_EN-04.p65 04/01/02, 08:3717
Text messages
Access to the SMS 25
Call services
Call forwarding 31
All voice calls All conditional fwd Cancel voice forwards Forward if busy Forward if no answer Forward if unavailable Data forwarding Faxes forwarding
View last numbers 32
Options Call
Duration and cost of calls (*) 32
Counters Delete durations Costs (*) Delete costs (*) Display of duration
Display numbers 33
Anonymous mode Your number Callers number
4. Menus
18
Double call 34
Activation De-activation Status
Automatic redial 34 Voice mail number 34 Local information (*) 34 Replace + prefix (*) 34
Ringing and beeps
Volume and choice of music 36 Call groups 37 Personalised ringing tone 37
Create a tune
Vibrate 37
Vibrate and ring Vibrate then ring Inactive vibrate Only vibrate
Silent mode 38 Beeps 38
Keypad beeps Network beep Low battery beep
Tones 38
MY_304X_EN-04.p65 04/01/02, 08:3718
Loading...
+ 44 hidden pages
