Sagem AXIUM HDL27 User Manual

1. Important safety information

1.1. Safety

Respect all maintenance advice, safety precautions and instructions recommended in this user booklet for your

safety and to prolong the working life of the equipment.

• Definitions

CAUTION

The exclamation mark within a triangle is intended to tell the user about important operating and ser-

vicing instructions.

WARNING

The lightning flash with an arrowhead within a triangle is intended to tell the user that parts inside

the product are an electric shock hazard.

• Safety regulations

This LCD TV is a class 1 appliance; it MUST be connected to an electrical wall socket equipped

with an earth.

This LCD TV is designed to function:

– with a 220-240 V, 50 Hz, AC (alternating current) network,

– at an ambient temperature between +5°C and +35°C,

– in areas with humidity less than 85%.

This LCD TV uses high voltages. Never attempt to access the interior of the device.

Only suitably qualified persons are authorised to do this.

Do not open or dismantle this product, as this will expose you to risk of electrocution.

Damage:

Never use your TV if it is damaged in any way. If you break the LCD glass, avoid any contact with

bare hands. Always place your TV on a flat level surface avoiding anywhere that may be subject to

vibrations.

Weather:

It is advisable to unplug the power supply, and the aerial antenna during an thunder storm.

Moisture:

Do not allow your TV to be exposed to rain, moisture and dust. If any liquid is spilt into your TV it

can cause serious damage. If you spill any liquid into your TV switch it off at the mains immediate-

ly. Contact your store.

Interference:

Do not place your TV on or near appliances, which may cause electromagnetic interference. If you

do, it may adversely affect the working of the unit, and cause a distorted picture or sound.

Temperature:

Avoid extremes of temperature, either hot or cold, place your TV well away from heat sources such

as radiators or gas/electric fire.

Ventilation:

The TV must be well ventilated. Do not cover your TV or position in a small confined space. It is

recommended that you leave a 10cm gap all around your TV.

Covers:

Do not remove any fixed covers as this may expose dangerous voltage.

Standby:

Do not leave your TV in standby for long periods of time e.g. while on holiday.

TABLE OF CONTENTS

1. Important safety information 2

1.1. Safety 2

1.2. Maintenance 3

2. Overview of the LCD TV 4

2.1. Unpacking 4

2.2. Inserting the remote control batteries 4

2.3. Connecting power 5

3. First installation 5

3.1. Product functions 5

4. Remote control 7

5. Getting started 8

5.1 Basic connections 8

5.1.1. RF IN port 9

5.1.2. COMPONENT port 9

5.1.3. SCART ports 9

5.1.4. AV4S input 10

5.1.5. AV4 input 10

5.1.6. MULTIMEDIA port 10

5.1.7. HEADPHONE port 10

5.1.8. Hi-Fi OUTPUT port 11

6. Inserting memory flash cards 11

7. Using the OSD menus 12

7.1. Changing picture settings 12

7.2. Changing PC settings 13

7.2.1 PC mode 13

7.3. Changing audio settings 14

7.3.1. Advanced settings 14

7.4. Changing system settings 15

7.4.1. Protection 15

7.5. Channel search 16

7.5.1. Auto search 16

7.5.2. Manual search 16

7.5.3. Program edit 17

7.5.4. Sort 17

7.6. Source edit 18

7.6.1. Scart sources auto 18

7.6.2. Naming 18

7.6.3. Source enable/disable 19

7.6.4. Video noise reduction 19

7.6.5. PIP/PAP 19

8. Diagnosing trouble shooting 20

9. Technical characteristics 21

ENGLISH

Anglais LU 27 A5.qxd 15/12/2004 10:08 Page 1

2. Overview of the LCD TV

Congratulations on purchasing the SAGEM AXIUM

HD-L27 LCD colour television. This product has been desi-

gned to provide you with a rich audio and video experience, along with ease of use and convenient connection.

This television enables you to watch aerial or cable free to view television channels, connect a VCR, digital Set

Top Box, and a decoder or DVD player to watch your favourite movies, or connect a computer to use the display

as a monitor.You can also use the television set like a graphics memory card and display your digital photographs.

The TV is equipped with convenient control buttons located on the side panel and a handy remote control to let

you adjust the TV settings and customize the TV preferences through an easy-to-use menu displayed on the

screen.

2.1. Unpacking

When you unpack this LCD TV, make sure the box contains the following items:

If any of these items appears to be missing or damaged, please contact your vendor or authorized service per-

sonnel for assistance.

2.2. Inserting the remote control batteries

Insert the two AAA batteries provided into the remote control as described below:

– Do not mix old and new batteries or batteries of different types together.

– Do not short-circuit, disassemble, heat or fire batteries.

– Remove the batteries to avoid damage from possible battery leakage if you anticipate that the remote

control will not be used for an extended period of time.

– Please handle the remote control with care. Avoid dropping it, getting it wet, or placing it in direct sun

light, near a heater or in an area of high humidity.

Batteries:

Please use only suitable batteries that complies with the manufacturer's specifications (see § 9.

"technical specifications"). When defective or completely used, pay particular attention to

environmental matters and throw them in places provided for this effect in accordance to the current

regulations.

Batteries are easily swallowed by young children. Do not allow young children to play with remote

control unit.

Screen Burn:

ATTENTION! Please note that some programs are broadcast with a logo that will appear in the cor-

ner of your TV screen. Some of these logos can be very bright and may cause damage by perma-

nently making the logo on the screen. To prevent this, avoid leaving channels displaying a logo for

prolonged periods of time, particularly when the TV is not being watched.

Only use suitable batteries that comply with the maker's specifications (see § 2.2).

– the batteries supplied are not rechargeable;

– pay particular attention to environmental matters;

– take the defective or used batteries to the places provided for this effect in accordance with

current regulations; never throw them in the dustbin.

1.2. Maintenance

• Before doing anything, disconnect the mains lead from the wall socket.

• Clean the cabinet using a soft, slightly damp cloth and a non-abrasive and non- wax detergent.

• Never use Benzene, alcohol or petroleum-based cleaning products as these could damage the finish.

• Clean the screen carefully using a soft, damp cloth lightly impregnated with a soap solution.

The display of your LCD TV is a very performing but delicate part. Touching it can harm the

internal electronic components and damage pixels. In order to keep initial performance of

your Sagem LCD TV as long as possible, avoid touching the screen.

SAGEM AXIUM

HD-L27 LCD Colour Television

Remote control

Batteries AAA (*2)

User manual

Power cord

RF cable

Pull the latch on the battery

compartment, cover the rear

of the remote control and

remove the cover.

Replace the cover and make

sure that snaps are securely

back into place.

Insert the two supplied batte-

ries. Check the + and - ends

of the batteries before inser-

ting them in the compartment.

Anglais LU 27 A5.qxd 15/12/2004 10:08 Page 3

Rear View

2.3. Connecting power

– Connect the supplied power cord to the AC IN connector on the rear of your TV.

– Connect the other end of the power cord to an earth power outlet.

3. First installation

3.1. Product functions

The following section describes the various functions of the LCD TV. Please take a few moments to get used to

the product and its control panel before using it.

Front View

ENGLISH

Parts Function

1 Speakers Produces stereo and Virtual Dolby Surround sound.

2 Turns power on or off.

3 Pr-/Pr+ Increases or decreases program numbers.

4 Increases or decreases the volume.

5 MENU Turns the On-screen Display (OSD) menu on or off.

6 Press each time you want to switch between TV and Source inputs.

7 CF card slot Insert a CF card in this slot.

8 SD/MMC,MS slot Insert an SD/MMC or MS card in this slot.

9 SM card slot Insert an SM card in this slot.

Connectors Function

1 ANT Connect your Roof antenna or coaxial cord from local TV service provider.

2 AV4/S, R/L Connect the S-Video and (R/L) audio.

3 AV4/CVBS, R/L Connect the video composite and audio (R/L) (Same as AV4S)

4 Component, R/L Connect the audio and component video output (progressive or interlaced)

connectors of your A/V device, including High Definition devices such as dedica-

ted set top boxes.

5 PC/DVI, R/L Connect the audio outputs and VGA or DVI output of your PC or HDTV decoder.

6 HEADPHONE Connect your external headphones.

7 Hi-Fi OUTPUT Connect an external amplifier with extra speakers.

8 SCART1, SCART2,

SCART3

Connect the SCART output of your A/V device.

Option Function

LANGUAGE Select your language.

COUNTRY Select your country.

AUTO SEARCH

Launch Auto search by pressing .

Anglais LU 27 A5.qxd 15/12/2004 10:08 Page 5

1 1

SD/MMCSMMS

Pr-

Pr+

B/G

: SELECT : ADJUST

PR: 1

: EXIT OSD

FREQUENCY: 45.00MHz

FIRST INSTALLATION

LANGUAGE

COUNTRY

AUTO SEARCH

ENGLISH

Pb/Cb

Pr/Cr

RL R

PC/DVI

AUDIO

HEADPHONE

OUTPUT

HI-FI

CAR

321

ANT

AV4/ S

AV4/CVBS

CAR

5. Getting started

Please refer to the following sections for detailed instructions about connecting the audio/video (AV) device of your

choice to your LCD TV and view your favorite programs or movies. These sections describe the procedure

required to set up your TV for easy and convenient viewing.

5.1 Basic connections

The SAGEM AXIUM

HD-L27 LCD Television provides multiple input and output ports to enable you to connect

different types of A/V devices such as an antenna or cable TV line, a VCR /DVD player, cable or satellite Set Top

Boxes (HDTV compliant), or even a PC (HDTV compliant).

You can also use the LCD TV as a flash memory card reader and view your digital photographs directly on the TV

without requiring a PC connection.

The back panel of the LCD TV provides input and output connectors to make these connections possible. The

following sections discuss the various ports and the type of A/V devices that can be connected to your TV.

Notes:

– Refer to these notes before connecting any audio/video equipment to this TV.

– Refer to the manuals of your stereo amplifier, or other equipment as necessary.

– Disconnect all equipment from the power outlets. Connect the equipment to the power outlets only after you have

completed connecting everything. Never make or change connections with equipment connected to a power outlet.

– Connect a DVD player directly to the TV. For example, do not connect a DVD player to a VCR, and then connect the

VCR to your TV. This type of connection could distort both the picture and the sound. Your VCR might also have a

copy protection system, which could result in a distorted DVD image.

– Set the stereo system to the correct source if your LCD TV is also connected to a stereo system.

– You only need one audio connection and one video connection between your TV and other audio/video equipment

(e.g. DVD player, VCR, Camcorder). This means that you may not use all the connectors on the TV for a basic

installation.

– If you plan to watch TV with VCR off, connect a coaxial cable to the VCR's TUNER IN connector and to the ANT con-

nector on your LCD TV. This allows you to watch channels on the TV normally when the VCR is off.

– The existing connection possibilities determine the picture quality (decreasingly from top level to lowest quality:

Progressive Scan Component Video, Interlaced Component Video, RGB Scart, S-Video and Composite Video). The

selection of your video support should be carefully examined according to the expected quality.

4. Remote control

Key Function

1 POWER Turns power on or commands stand-by mode

2 COMPONENT source select Select interlaced or progressive component source

3 PC / DVI (HDTV)source select Select VGA or DVI source

Program

Program + / - select

5 VOL + - Volume + / -

JUMP TO PREVIOUS PRO-

GRAM

Switches to the previously viewed program

7 TXT HOT KEYS Select group of pages in teletext mode

8 TXT INDEX Teletext Index

9 TXT REVEAL Teletext Reveal - Display hidden data

10 TXT ZOOM HOLD Teletext Zoom and Hold

11 EXIT Menu Exit from the menu

12 ARROW KEYS

Press the up, down, left,

Right arrow keys to scroll,

Through the OSD menu options.

13 MENU Displays the OSD menu

14 TIMER Off Timer

15 3D AUDIO SELECT Selects Virtual Dolby Surrond (360° sound mode)

SOUND Select Mono / Stereo

PIP/PAP POSITION

PIP/PAP SWAP

PIP/PAP SUB SOURCE

PIP / PAP select

PIP picture position

Swap Main and sub source in PIP / PAP

PIP / PAP sub source select

Active PIP / PAP display

CARD READER SELECT Card Reader - Select the CARD READER function

from video or graphic source.

CARD READER PREVIEW /

FULL

Card Reader - Active the Photo preview / Photo full

screen display.

CARD READER ROTATE Card reader - Rotate photo

CARD READER AUTOPLAY Active automatic Photo card reader viewing

19 VIDEO MODE Select video mode settings

20 AUDIO Smart Volume Select AI Audio Smart Volume

21 DISPLAY INFORMATION Display information

DAY / NIGHT DISPLAY MODE Select back light Bright/Day/Night mode for the

display.

23 TXT PAGE Teletext page down and up

24 TELETEXT select TELETEXT ON / OFF.

25 1XX CHANNELS SELECT -/-- Channel numbers higher or equal to 100

26 NUMBER KEYS 1 to 9 and 0 number keys

27 SCART source select Select Scart1 to Scart3 sources

28 VIDEO TV/AV/S Source select Select TV, AV4 and AV4S source

29 Format Screen format select

30 MUTE Loudspeaker mute

– If sunlight shines directly on the remote sensor, the operation of the remote control may become unstable,

and the effective range will be shorter.

– Do not hit or violently shake the remote control.

– Never expose the remote control to high temperature or humidity.

– If the remote control is not used for an extended period of time, remove the batteries to prevent damage

or injury from possible battery leakage.

Anglais LU 27 A5.qxd 15/12/2004 10:08 Page 7

232422

161514

11109

765

321

Pr/Cr

RL R

PC/DVI

AUDIO

HEADPHONE

OUTPUT

HI-FI

CAR

Pb/Cb

CAR

ANT

AV4/S

AV4/CVBS

CAR

+ 8 hidden pages
