Ryobi RJS750-G User Manual
RJS750
ORIGINAL INSTRUCTIONS
Jigsaw
Important!
It is essential that you read the instructions in this manual before operating
this machine.
Subject to technical modifications.
Safety
GENERAL POWER TOOL SAFETY WARNINGS
WARNING
Read all safety warnings and all instructions. Failure
to follow the warnings and instructions may result in
electric shock, fi re and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool’’ in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
1) WORK AREA SAFETY
a) Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
b) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords
increase the risk of electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
3) PERSONAL SAFETY
a) Stay alert, watch what you are doing and
use common sense when operating a power
tool. Do not use a power tool while you are
tired or under the influence of drugs, alcohol
or medication. A moment of inattention while
operating power tools may result in serious
personal injury.
b) Use personal protective equipment. Always
wear eye protection. Protective equipment such
as dust mask, non-skid safety shoes, hard hat or
hearing protection used for appropriate conditions
will reduce personal injuries.
c) Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking
up or carrying the tool. Carrying power tools with
your finger on the switch or energising power tools
that have the switch on invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may
result in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewellery
or long hair can be caught in moving parts.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at the
rate for which it was designed.
b) Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must
be repaired.
c) Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions
to operate the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment
or binding of moving parts, breakage of parts
and any other condition that may affect the
power tool’s operation. If damaged, have the
1
Safety
power tool repaired before use. Many accidents
are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits
etc, in accordance with these instructions,
taking into account the working conditions and
the work to be performed. Use of the power tool
for operations different from those intended could
result in a hazardous situation.
5) SERVICE
Have your power tool serviced by a qualified repair
person using only identical replacement parts.
This will ensure that the safety of the power tool is
maintained.
JIGSAW SAFETY WARNINGS
a) Hold power tool by insulated gripping surfaces,
when performing an operation where the cutting
accessory may contact hidden wiring or its own
cord. Cutting accessory contacting a “live” wire may
make exposed metal parts of the power tool “live” and
could give the operator an electric shock.
b) Keep mains lead clear from working range of the
machine. Always lead the cable away behind you.
c) Wear a dust mask.
Additional safety instructions
WARNING
The product is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the product by a
person responsible for their safety.
Children should be supervised to ensure that they
do not play with the product.
a) Avoid running your saw at low speeds for extended
periods of time. Running at low speeds under constant
usage may cause your saw to become overheated. If
this occurs, cool your saw by running it without a load
at full speed.
b) Use the correct dust collection system as per the
instructions in this manual.
c) We recommend the use of a residual current device
with a residual current rating of 30 mA or less.
INTENDED USE
a) Cutting all types of wood
b) Cutting plastic
c) Cutting drywall
d) Cutting metals
Do not use this product in any way other than those stated
for intended use.
RESIDUAL RISKS
The product has been designed with safety features and in
accordance with regulations but there are still risks which
cannot be completely avoided and the operator should be
aware of these:
– Contact with the cutting blade; gloves should be
worn.
– Damage to hearing; protection should be worn.
– Inhalation of dust and fibres; a face mask should
be worn.
– Damage to sight; eye protection should be worn.
RISK REDUCTION
It has been reported that vibrations from hand-held tools
may contribute to a condition called Raynaud’s Syndrome
in certain individuals. Symptoms may include tingling,
numbness and blanching of the fi ngers, usually apparent
upon exposure to cold environments.
Hereditary factors, exposure to cold and dampness, diet,
smoking and work practices are all thought to contribute to
the development of the these symptoms.
There are measures that can be taken by the operator to
possibly reduce the effects of vibration:
Keep your body warm in cold weather. When operating the
unit wear gloves to keep the hands and wrists warm. It is
reported that cold weather is a major factor contributing to
Raynaud’s Syndrome.
– After each period of operation, exercise to increase
blood circulation.
– Take frequent work breaks.
– Limit the amount of exposure per day.
If you experience any of the symptoms of this condition,
immediately discontinue use and see your doctor.
Injuries may be caused, or aggravated, by prolonged use of
a tool. When using any tool for prolonged periods, ensure
you take regular breaks.
MAINTENANCE
WARNING
The product should never be connected to a power supply
when you are assembling parts, making adjustments,
cleaning, performing maintenance, or when the product
is not in use. Disconnecting the product will prevent
accidental starting that could cause serious injury.
2
a) When servicing, use only original manufacturer’s
replacement parts, accessories and attachments.
Use of any other parts may create a hazard or cause
product damage.
b) Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to various types of commercial
solvents and may be damaged by their use. Use clean
cloths to remove dirt, carbon dust, etc.
c) Do not at any time let brake fluids, gasoline, petroleum-
based products, penetrating oils, etc., come in contact
with plastic parts. They contain chemicals that can
damage, weaken or destroy plastic.
d) Always wear safety goggles or safety glasses with
side shields when operating or cleaning the product. If
operation is dusty, also wear a dust mask.
e) Clean the product using a brush or a dust collection
system.
f) If the supply cord of this power tool is damaged, it must
be replaced by a specially prepared cord available
through the service organization.
g) For greater safety and reliability, all repairs should be
performed by an authorised service centre.
h) All of the bearings in the product are lubricated with
a sufficient amount of high grade lubricant for the life
span of the product under normal operating conditions.
Therefore, no further lubrication is required.
ENVIRONMENTAL PROTECTION
Recycle raw materials instead of disposing
of as waste. The machine, accessories and
packaging should be sorted for environmentalfriendly recycling.
Safety
SYMBOLS
Safety alert
Please read the instructions carefully
before starting the machine.
No-load speed.
Class II tool, double insulation
Regulatory Compliance Mark (RCM).
Product meets applicable regulatory
requirements.
Waste electrical products should not be
disposed of with household waste. Please
recycle where facilities exist. Check with
your local authority or retailer for recycling
advice.
3
2
1
1
2
1
3
Getting started
4
3
