Page 1
RYOBI
VARIABLE SPEED
RECIPROCATING SAW
MODEL NO. RJ161V
REPAIR SHEET
Page 2
41
RYOBI RECIPROCATING SAW – MODEL NUMBER RJ161V
5
4
3
2
1
20
21
27
26
25
40
6
7
4
8
9
10
11
12
13
14
15
16
17A
17B
18
19
28
22
23
24
39
29
38
37
21
30
36
34
32
33
19
31
7
4
35
42
43
44
45
46
47
48
54
52
53
51
50
49
2
2
Page 3
RYOBI RECIPROCATING SAW – MODEL NUMBER RJ161V
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your Reciprocating Saw or when ordering repair parts.
PARTS LIST
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 6934201 COVER PLATE (1) ..................1
2 9066701 GEAR CASE SEAL ..................1
3 5909501 GEAR CASE COVER .............. 1
4 6703001 SPRING WASHER ................. 12
5 6616503 * SCREW (M4 X 18 mm) ............6
6 5682601 SEAL ........................................1
7 6621202 * SCREW (M4 X 10 mm) ............6
8 6934901 COVER PLATE (2) ..................1
9 6935601 GUIDE BLOCK ......................... 2
10 3000330 SAW BAR ASSEMBLY............1
11 6934501 YOKE PLATE ........................... 1
12 6770401 RETAINING RING ....................1
13 6829601 ROLLER BEARING ................. 1
14 3036203 GEAR ASSEMBLY .................. 1
15 6621301 * SCREW (M4 X 16 mm) ............3
16 6839502 SHAFT MOUNTING PLATE ....1
17A 6368803 WASHER..................................1
17B 6368804 WASHER..................................1
18 6842301 SLEEVE ...................................1
19 6939501 BALL BEARING (6001ZZ)....... 2
20 6940401 GEAR SHAFT .......................... 1
21 6814104 BALL BEARING (608ZZ) ......... 2
22 4009401 BLADE RELEASE LEVER ...... 1
23 6950201 SPRING....................................1
24 6951801 PIN ...........................................1
25 6453501 GEAR CASE ............................ 1
26 6886301 LOCK WASHER (M5) ..............4
27 6625902 SCREW (SELF TAPPING) ......4
28 6617001 * SCREW (M10 X 10 mm) ..........1
29 5909101 RUBBER BOOT ....................... 1
KEY PART
NO. NUMBER DESCRIPTION QTY.
30 6942301 GUARD PLATE ........................ 1
31 3021607 SHOE ASSEMBLY .................. 1
32 6934701 SAW BLADE (6 in.) ..................1
6934801 SAW BLADE (4 in.) ..................1
33 6950301 BEARING RETAINER .............. 1
34 6622801 * FLAT HEAD SCREW
(M3 X 8 mm).............................4
35 6939601 RETAINING RING ....................1
36 7436901 ARMATURE ............................. 1
37 5909001 BAFFLE....................................1
38 6615601 SCREW (SELF TAPPING) ......2
39 7437001 FIELD .......................................1
40 5908901 SUPPORT HOUSING .............. 1
41 9429807 LOGO PLATE .......................... 1
42 5629001 BEND RELIEF .......................... 1
43 7320112 POWER CORD ........................ 1
44 5909301 CORD CLAMP .........................1
45 6620805 * SCREW (M4 X 16 mm) ............2
46 2800855 SPEED CONTROL BOARD ....1
47 7615501 SWITCH (DEFOND).................1
7628601 SWITCH (BAICHENG) .............1
48 2913301 LEAD ASSEMBLY ................... 1
49 6620802 SCREW (SELF TAPPING) ......6
50 9429808 DATA PLATE ...........................1
51 5908801 COVER HOUSING ................... 1
52 5909201 TRIGGER .................................1
53 5678601 RUBBER PLUG .......................2
54 2906912 BRUSH TUBE ASSEMBLY ..... 2
55 300636030 CARRYING CASE
(NOT SHOWN).........................1
983000-131R OPERATOR’S MANUAL .......... 1
7-03
WARNING: Improper repair of a double insulated tool can result in damage to the double insulation
system possibly causing electrical shock or electrocution. Any repairs requiring disassembly of your
tool requires safety testing and should only be performed by a Ryobi Authorized Service Center. For the
service center nearest you call 1-800-525-2579.
* Standard Hardware Item – May Be Purchased Locally
3
