OPERATOR’S MANUAL
18V CORDLESS DRY HAND VAC
P711
BATTERIES AND CHARGERS
SOLD SEPARATELY
This hand vac is intended for household
use only.
Your hand vac has been engineered and manufactured to our high standard for dependability, ease of operation, and
operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual before using
this product.
Thank you for your purchase.
SAVE THIS MANUAL FOR FUTURE REFERENCE
TABLE OF CONTENTS
Introduction ..................................................................................................................................................................... 2
� Warranty .......................................................................................................................................................................... 2
� Important Safety Instructions ....................................................................................................................................... 3-5
� Symbols ........................................................................................................................................................................6-7
�� Features ........................................................................................................................................................................... 8
�� Assembly ......................................................................................................................................................................... 9
� Operation .................................................................................................................................................................. 10-12
� Maintenance .............................................................................................................................................................12-13
Parts Ordering / Service ................................................................................................................................... Back Page
INTRODUCTION
This product has many features for making its use more pleasant and enjoyable. Safety, performance, and dependability
have been given top priority in the design of this product making it easy to maintain and operate.
WARRANTY
RYOBI® POWER TOOL - LIMITED TWO YEAR WARRANTY AND 30 DAY EXCHANGE POLICY
One World Technologies, Inc., warrants its RYOBI®
30-DAY EXCHANGE POLICY: During the first 30 days after date of purchase, you may either request service under this
warranty or you may exchange any RYOBI
materials by returning the power tool to the dealer from which it was purchased. To receive a replacement power tool
or requested warranty service, you must present proof of purchase and return all original equipment packaged with the
original product. The replacement power tool will be covered by the limited warranty for the balance of the two year period
from the date of the original purchase.
WHAT THIS WARRANTY COVERS: This warranty covers all defects in workmanship or materials in your RYOBI® power
tool for a period of two years from the date of purchase. With the exception of batteries, power tool accessories are
warranted for ninety (90) days. Batteries are warranted for two years.
HOW TO GET SERVICE: Just return the power tool, properly packaged and postage prepaid, to an Authorized Service
Center. You can obtain the location of the Service Center nearest you by contacting a service representative at One
World Technologies, Inc., P.O. Box 1207, Anderson, SC 29622-1207, by calling 1-800-525-2579 or by logging on to
www.ryobitools.com. When you request warranty service, you must also present proof of purchase documentation, which
includes the date of purchase (for example, a bill of sale). We will repair any faulty workmanship, and either repair or replace
any defective part, at our option. We will do so without any charge to you. We will complete the work in a reasonable time,
but, in any case, within ninety (90) days or less.
WHAT’S NOT COVERED: This warranty applies only to the original purchaser at retail and may not be transferred. This
warranty only covers defects arising under normal usage and does not cover any malfunction, failure or defects resulting
from misuse, abuse, neglect, alteration, modification or repairs by other than Authorized Service Centers. One World
Technologies, Inc. makes no warranties, representations or promises as to the quality or performance of its power tools
other than those specifically stated in this warranty.
ADDITIONAL LIMITATIONS: Any implied warranties granted under state law, including warranties of merchantability or
fitness for a particular purpose, are limited to two years from the date of purchase. One World Technologies, Inc. is not
responsible for direct, indirect, or incidental damages, so the above limitations and exclusions may not apply to you. This
warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
® power tool which does not work properly due to defective workmanship or
power tools with the following conditions:
2
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
When using an electrical appliance, basic precautions should always be followed, including the following:
Do not use without dust bowl or filter in place.
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS.
Failure to follow all instructions listed below, may result
in electric shock, fire and/or serious personal injury.
READ ALL INSTRUCTIONS BEFORE USING
THIS APPLIANCE
WARNING:
To reduce the risk of electric shock DO NOT expose to
rain. Store indoors.
Dress properly. Do not wear loose clothing or jewelry.
Contain long hair. Keep your hair and clothing, away
from moving parts. Loose clothes, jewelry, or long hair
can be caught in internal moving parts.
Do not overreach. Keep proper footing and balance
at all times. Proper footing and balance enables better
control of the hand vac in unexpected situations. Do not
use on a ladder or unstable support.
Use safety equipment. Dust mask must be used for
appropriate conditions.
Do not allow children to operate hand vac or play with
hand vac as a toy. Close attention is necessary when
used by or near children.
Use this hand vac ONLY for its intended use as described
in this manual. Use only the attachments recommended
in this manual.
If hand vac is not working properly, has been dropped,
damaged, left outdoors, or dropped into water, return to
your nearest service center.
Do not handle charger plug or hand vac with wet
hands.
Do not put any objects in ventilation openings. Do not
use with any opening blocked. Keep openings free of
dust, lint, hair, and anything that may reduce air flow.
NEVER vacuum materials such as hot coals, cigarette
butts, matches, burning or smoking ashes, etc.
DO NOT use to pick up flammable or combustible liquids,
such as gasoline, or use in areas where they may be
present.
Turn off all controls before unplugging from or plugging
into an electrical outlet for charging.
Use extra care when using on stairs.
Do not use to pick up hard objects such as nails, screws,
coins, etc. Damage or injury could result.
Do not incinerate this appliance even if it is severely
damaged. The batteries can explode in a fire.
Hand vac does not have to be plugged into an electrical
outlet, therefore it is always in operating condition. Be
aware of possible hazards when using the hand vac or
when changing accessories.
Remove battery when the vacuum is not in use and
before servicing.
Use only the charger recommended for your hand
vac. Do not substitute any other charger. Use of another
charger could cause batteries to explode causing possible
serious injury.
Use battery only with charger listed.
MODEL BATTERY PACK (P100) CHARGER (P110)
P711 130255004 1423701, 140237021
130224028 or 140237023
Do not place hand vac or batteries near fire or heat.
They may explode.
The hand vac should be charged in a location where the
temperature is more than 50°F but less than 100°F.
Under extreme usage or temperature conditions, battery
leakage may occur. If liquid comes in contact with skin,
wash at least 10 minutes then seek immediate medical
attention.
Batteries vent hydrogen gas and can explode in the
presence of a source of ignition, such as a pilot light.
To reduce the risk of serious personal injury, never use
any cordless product in the presence of an open flame.
An exploded battery can propel debris and chemicals. If
exposed, flush with water immediately.
Protect your lungs. Wear a face or dust mask if the
operation is dusty. Following this rule will reduce the
risk of serious personal injury.
Save these instructions. Refer to them frequently and
use them to instruct others who may use this hand
vac. If you loan someone this hand vac, loan them
these instructions also.
3
IMPORTANT SAFETY INSTRUCTIONS (CONT.)
BATTERY PACK REMOVAL AND
PREPARATION FOR RECYCLING
To preserve natural resources, please
rec y c l e or disp o s e o f batte r i es
properly.
This product contains nickel-cadmium
batteries. Local, state or federal laws
may prohibit disposal of nickel-cadmium
batteries in ordinary trash.
Consult your local waste authority for information regarding
available recycling and/or disposal options.
WARNING:
Upon removal, cover the battery pack’s terminals with
heavy-duty adhesive tape. Do not attempt to destroy
or disassemble battery pack or remove any of its
components. Nickel-cadmium batteries must be recycled
or disposed of properly. Also, never touch both terminals
with metal objects and/or body parts as short circuit may
result. Keep away from children. Failure to comply with
these warnings could result in fire and/or serious injury.
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS.
Failure to follow all instructions listed below, may result
in electric shock, fire and/or serious personal injury.
Before using battery charger, read all instructions and
cautionary markings in this manual, on battery charger,
battery, and product using battery to prevent misuse of
the products and possible injury or damage.
CAUTION:
To reduce the risk of electric shock or damage to the
charger and battery, charge only nickel-cadmium
rechargeable batteries as specifically designated on
your charger. Other types of batteries may burst, causing
personal injury or damage.
Do not use charger outdoors or expose to wet or damp
conditions. Water entering charger will increase the risk
of electric shock.
Use of an attachment not recommended or sold by the
battery charger manufacturer may result in a risk of
fire, electric shock, or injury to persons. Following this
rule will reduce the risk of electric shock, fire, or serious
personal injury.
Do not abuse cord or charger. Never use the cord to
carry the charger. Do not pull the charger cord rather than
the plug when disconnecting from receptacle. Damage
to the cord or charger could occur and create an electric
shock hazard. Replace damaged cords immediately.
Make sure cord is located so that it will not be stepped
on, tripped over, come in contact with sharp edges
or moving parts or otherwise subjected to damage or
stress. This will reduce the risk of accidental falls, which
could cause injury, and damage to the cord, which could
result in electric shock.
Ke ep cord and char ger fr om heat to prev ent
damage to housing or internal parts.
Do not let gasoline, oils, petroleum-based products,
etc. come in contact with plastic parts. They contain
chemicals that can damage, weaken, or destroy plastic.
An extension cord should not be used unless
absolutely necessary. Use of improper extension
cord could result in a risk of fire and electric shock. If
extension cord must be used, make sure:
a. T hat pins on plug of extensi on cord are th e
s a m e n u m b e r , s i z e a n d s h a p e a s t h o s e o f
plug on charger.
b. Th at extension cord is properly wire d and in
good electrical condition; and
c. That wire size is large enough for AC ampere
rating of charger as specified below:
Cord Length (Feet) 25' 50' 100'
Cord Size (AWG) 16 16 16
NOTE: AWG = American Wire Gauge
Do not operate charger with a damaged cord or
plug, which could cause shorting and electric shock. If
damaged, have the charger replaced by an authorized
serviceman.
Do not operate charger if it has received a sharp blow,
been dropped, or otherwise damaged in any way.
Take it to an authorized serviceman for electrical check
to determine if the charger is in good working order.
Do not disassemble charger. Take it to an authorized
serviceman when service or repair is required. Incorrect
reassembly may result in a risk of electric shock or fire.
Unplug charger from outlet bef ore attem pting
any maintenance or cleaning to reduce the risk of
electric shock.
Disconnect charger from the power supply when
not in use. This will reduce the risk of electric shock or
damage to the charger if metal items should fall into the
opening. It also will help prevent damage to the charger
during a power surge.
Risk of electric shock. Do not touch uninsulated
portion of output connector or uninsulated battery
terminal.
Save these instructions. Refer to them frequently and
use them to instruct others who may use this hand vac.
If you loan someone this hand vac, loan them these
instructions also to prevent misuse of the product and
possible injury.
4
IMPORTANT SAFETY INSTRUCTIONS (CONT.)
Check for misalignment or binding of moving parts,
breakage of parts, and any other condition that may
affect the hand vac’s operation. If damaged, have the
hand vac serviced before using. Many accidents are
caused by poorly maintained hand vacs.
Use only accessories that are recommended by the
manufacturer for your model. Accessories that may be
suitable for one hand vac may create a risk of injury when
used on another hand vac.
Hand vac service must be performed only by qualified
repair personnel. Service or maintenance performed by
unqualified personnel could result in a risk of injury.
When servicing a ha nd vac, use only identical
re placement parts. Follow instructi ons in th e
Maintenance section of this manual. Use of unauthorized
parts or failure to follow Maintenance Instructions may
create a risk of electric shock or injury.
If the power supply cord is damaged, it must be replaced
only by the manufacturer or by an authorized service
center to avoid risk.
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
1. SAVE THESE INSTRUCTIONS
This manual contains important safety and operating instructions for battery charger 1423701, 140237021, or
140237023.
2. Before using battery charger, read all instructions and cautionary markings on battery charger, battery, and product
using battery.
3. CAUTION: To reduce the risk of injury, charge only nickel-cadmium rechargeable batteries. Other types of batteries
may burst, causing personal injury or damage.
5
Loading...
