RUNCAM
Micro Sparrow 2
USER MANUAL
3.5-5.5v in
GND
RunCam TX200
Connection
5-36v in
GND
Video out
VBAT+
To VBAT+
Model: Micro Sparrow 2
1x OSD Key-press Board
RIGHT
LEFT
UP
ENTER
DOWN
RunCam
Dimensions & Installation
17mm
19mm
12mm
12mm
19mm
M2 Screws10mm
OSD Menu
16.8V RUNCAM
01:08
·
·
QUICK SETTINGS
Quick settings:
·
·
Long press UP button for three seconds to access
to the OSD setting‘s screen
·
·
Long press LEFT button for three seconds to
calibrate the voltage. When the voltage text
flashes, press UP/DOWN button to adjust it
·
·
Long press DOWN button for ten seconds to reset
OSD settings to default
·
·
Long press RIGHT button for three seconds to
switch between the camera presets
· · CLR: clear the ID character;
·
·
ALARM: low voltage warning value, smartly judge
the warning value of the battery when it's low; if set
it manually, then it saves the manual preset value;
·
·
Press the middle button to switch ON / OFF, then
move to POS to enter the position adjustment..
RUNCAM_ _ _CLR
OSD Menu
1234567890ABCDEFGHIJ
KLMNOPQRSTUVWXYZ&:=./
ALARM
PILOT
TIMER
VOLTAGE
HORIZON
EXIT
: 11.1V
: ON
: ON
: ON
: OFF
POS
POS
POS
POS
SETUP MENU
ENGLISH
YES
· · SETUP MENU
·
·
LANGUAGE ( ENGLISH / DEUTSCH / FRANCAIS /
PYCCKNN / PORTUGUES / ESPANOL / 中文 )
·
·
WHITE BAL (ATW / PUSH / USER1 / USER2
/ MANUAL / PUSH LOCK )
· · FLIP ( OFF / H-FLIP / V-FLIP / HV-FLIP )
·
·
BRIGHTNESS ( 120 / 0-255 )
Camera Menu
PICT ADJUST
·
·
CONTRAST ( 138 / 0-255 )
·
·
SHARPNESS ( 148 / 0-255 )
·
·
HUE ( 90 / 0-180 )
·
·
COLOR GAIN ( 168 / 0-255 )
FLIP
BRIGHTNESS
CONTRAST
SHARPNESS
HUE
COLOR GAIN
RETURN
OFF
120
138
148
090
168
PICT ADJUST
WHITE BAL
LANGUAGE
CAMERA RESET
EXIT
AT W
Parameters
Model
Image Sensor
Horizontal Resolution
Lens
Screen Format
Signal System
Mirror/Flip
Integrated OSD
One Touch Scene Setting
S/N Ratio
Electronic Shutter Speed
Min. Illumination
WDR
Day/Night
Power
Current
Housing Material
Net Weight
Dimensions
RunCam Micro Sparrow 2
Super WDR CMOS Sensor
700TVL
2.1mm (M8) FOV150° 2.3mm(M8) FOV 140°
4:3
NTSC / PAL
Available
Yes
Personal / Lightrax / Outdoor / Indoor / Cloudy / Twilight
>50dB
Auto
0.01Lux@1.2F
Super WDR
Auto
DC 5-36V
120mA@5V / 50mA@12V
ABS
4.5g
L19mm*W19mm*H17mm
