Rudd RGFG-06EMCK User Manual

MINIMUM 95% A.F.U.E.
90 PLUS COMMUNICATING
MODULATING UPFLOW GAS
FURNACES EQUIPPED WITH
THE COMFORT CONTROL

2

SYSTEM AND

CONTOUR

COMFORT CONTROL

®

The Rheem

Prestige Series

™ 90 Plus High Efficiency line of upflow gas fur-

naces are designed for utility rooms, closets, or alcoves. Because of the low-

profile 34 inch height, the RGFG- model can be used vertically to satisfy
most applications that traditionally call for a horizontal furnace.

The design is certified by CSA.

Features

■ The

Comfort Control2System

™ provides 28 on-board diagnostic codes
and fault history codes by detecting system and electrical problems. “Call
for Service” alert notification is sent to the thermostat to alert the home­owner of required service.

■

Serial Communication Enhanced – When installed with a Serial Com muni ­cat ing Condensing Unit and user interface control (RHC-TST550CMMS)
500 Series thermostat this unit offers 4 or 2 wire installation, auto-configura­tion, and diagnostic messaging with full communicating capability.

■ Heat exchanger is constructed of all stainless steel for maximum corro­sion resistance and thermal fatigue reliability.

■ Modulating Function: when used with a modulating or communicating
thermostat, modulation rate between 40% and 100% of total capacity.

■ Two-stage Function: when used with a two-stage thermostat, furnace
operates at 40% on first stage, and stages up to 65%, then 100% for sec­ond stage.

■ Multistage Function: when used with a single-stage thermostat, furnace
functions as a three stage furnace operating at 40%, 65% and 100% of
total capacity.

■ Reduced firing rates, electrically efficient ECM 3.0 motor, and solid doors
provide the ultimate in quiet operation.

■ Low speed constant fan.

■ Constant temperature rise for superior comfort.

■ Seven segment LED for system diagnostics.

■ Diagnostic history for troubleshooting.

■ Two-speed induced draft motor.

■ Hot surface ignition with remote sense.

■ Optional indoor or outdoor combustion air.

A variety of cooling coils and plenums designed to use with the

Prestige

Series

™ 90 Plus gas furnaces are available as optional accessories.

✝A.F.U.E. (Annual Fuel Utilization Efficiency) calculated in accordance with Department of Energy test

procedures.

FORM NO. G11-510 REV. 1

Supersedes Form No. G11-510

GAS FURNACES

RGFG- SERIES

Models with Input Rates
from 60,000 to 120,000 BTU/HR
[17.58 to 35.16 kW]

(All Models 95% A.F.U.E.† or Above)

Equipped with

Comfort Control2System

™

• Serial communication enabled

• Increased system reliability and efficiency

• 28 on-board diagnostic and operating codes

•

Active Protection

™

with homeowner

“Call for Service” alert

• Dual 7-segment LED display

RHC-TST550CMMS

Modulating Furnace Thermostat

■

The Rheem Dual 7-Segment LED Display easily shows sys­tem operating status codes and diagnostic codes.

■

The Status Indication
System Diagnostics feature
thermostat communication
capability and built-in diag­nostics. The thermostat com-

munication capability and
alerts the homeowner to any
necessary service require­ments. Faster, more accurate
service is provided by the built­in diagnostics, by providing the HVAC professional with depend­able information.

■

The fault recall feature will allow for the last six fault-codes
to be displayed, and will retain these codes even if power
failure occurs.

■

In order to save time and money, replacement automotive
style fuses can be utilized instead of replacing the entire
control board.

FEATURES & BENEFITS OF THE

COMFORT CONTROL2SYSTEM

™

2 Rheem Heating, Cooling and Water Heating

Rheem Heating, Cooling and Water Heating 3

WARNING

THIS FURNACE IS NOT APPROVED

OR RECOMMENDED

FOR USE IN MOBILE HOMES

PRIMARY
AND SECONDARY
HEAT EXCHANGER

IN-SHOT BURNERS

PRESSURE
SWITCHES

BLOWER ASSEMBLY WITH
ECM MOTOR

DRAFT INDUCER

INTEGRATED
FURNACE CONTROL

GAS VALVE

PRESTIGE SERIES

™

90 PLUS HIGH EFFICIENCY

MODULATING UPFLOW GAS FURNACE

REMOTE SENSOR

OPTIONAL EQUIPMENT

Side and bottom filter racks; return air cabinet for all sizes.
NOTE: Furnace is not listed for use with fuels other than natural or L.P.

(propane) gas.

All models can be converted by a qualified distributor or local service dealer to
use L.P. (propane) gas without changing burners. Factory approved kits must
be used to convert from natural to L.P. (propane) gas and may be ordered as
optional accessories from a parts distributor.

For L.P. (propane) operation, refer to Conversion Kit Index Form.
Fossil Fuel Kits for use with Heat Pumps.
Communicating Thermostat System

STANDARD EQUIPMENT

Completely assembled and wired; heat exchanger; primary: 409 and aluminized
409 stainless steel, secondary: 29-4C stainless steel; induced draft; pressure
switches; redundant modulating main gas control; blower compartment door
safety switch; solid state time on/off blower control; limit controls; manual shut­off valve; 100% safety lock out; cool fan off delay; one hour automatic retry;
power and self-test diagnostics; flame sense current diagnostics; electronic air
cleaner connections; humidifier connections; humidifier on/off delay;
dehumidifier connection; low speed continuous fan option; transformer; direct
drive, ECM variable speed blower motor. (Please note: a thermostat is not
included as standard equipment. See “Accessories”)

INDUCER CONTROL MODULE

HOT SURFACE IGNITOR

MODEL NUMBERS RGFG-06EMCK RGFG-09EZCM RGFG-10EZCM RGFG-12ERCM

INPUT–MAXIMUM (BTU/HR) [kW] 60,000 [17.58] 90,000 [26.38] 105,000 [30.77] 120,000 [35.17]
HEATING CAPACITY–MAXIMUM [kW] 55,800 [16.35] 86,000 [25.20] 100,000 [29.31] 115,000 [33.70]
INPUT–MINIMUM (BTU/HR) [kW] 24,000 [7.03] 36,000 [10.55] 42,000 [12.31] 48,000 [14.07]
HEATING CAPACITY–MINIMUM [kW] 22,560 [6.61] 33,840 [9.92] 39,000 [11.57] 45,120 [13.22]
HEATING EXT. STATIC PRESSURE [kPa] 0.12 [.029] 0.15 [.037] 0.20 [.049] 0.20 [.049]
BLOWER (D X W IN.) [mm] 11 x 7 [279 x 178] 12 x 11 [305 x 279] 12 x 11 [305 x 279] 11 x 10 [279 x 254]
ECM MOTOR HP [W] 1/2 [373] 1 [746] 1 [746] 1 [746]
UNIT AMPS 8.7 12.0 12.0 12.0

HEATING CFM–MAXIMUM [L/s] 795 [375] 1195 [564] 1395 [658] 1595 [753]
HEATING CFM–MINIMUM [L/s] 320 [151] 515 [243] 600 [283] 685 [323]
COOLING CFM–RANGE [L/s] 600-1200 [283-566] 1200-2000 [566-944] 1200-2000 [566-944] 1200-2000 [566-944]
MAXIMUM EXT. STATIC PRESSURE [kPa] 0.80 [0.20] 0.80 [0.20] 0.80 [0.20] 0.80 [0.20]
TEMPERATURE RISE RANGE °F [°C] 40-70 [22.2-38.9] 40-70 [22.2-38.9] 40-70 [22.2-38.9] 40-70 [22.2-38.9]

RETURN AIR CABINETS–RXGR- C17B C21B C21B C24B
FILTER SIZE (IN.) [mm] BOTTOM 153/4x 25 [400 x 635] 191/4x 25 [489 x 635] 191/4x 25 [489 x 635] 223/4x 25 [578 x 635]

MAX OUTLET AIR TEMPERATURE °F [°C]

170 [76.7] 180 [82.2] 180 [82.2] 180 [82.2]

APPROX. SHIPPING WEIGHT (LBS.) [kg] 127 [57.6] 158 [71.7] 162 [73.5] 170 [77.1]
AFUE 96.0% 95.1% 95.3% 95.6%

RGFG-07EMCK

95.3%

75,000 [21.98]
72,000 [21.10]
30,000 [8.79]
28,200 [8.26]

0.12 [.029]

11 x 7 [279 x 178]

1/2 [373]

8.7

995 [470]
430 [203]

600-1200 [283-566]

0.80 [0.20]

40-70 [22.2-38.9]

C17B

153/4x 25 [400 x 635]

180 [82.2]

133 [60.3]

15MAXIMUM OVERCURRENT PROTECTION 15 15 15 15

153/4x 25 [400 x 635]FILTER SIZE (IN.) [mm] SIDE 153/4x 25 [400 x 635] 153/4x 25 [400 x 635] 153/4x 25 [400 x 635] 153/4x 25 [400 x 635]

4 Rheem Heating, Cooling and Water Heating

R

G F G

07E

M C K S

Rheem Gas

Furnace

Modulating

Prestige
Series

™

90 Plus

Gas Furnace

Design

Series

Communicating

Heating Input

Designation

Blower Size

M = 11 x 7

[279 x 178 mm]

R = 11 x 10

[279 x 254 mm]

Z = 12 x 11

[305 x 279 mm]

Variations

C = Single/

Multi Zone

Heat/Cool

Designation

K = 600-1200 CFM

[283-566 L/s]

M = 1200-2000 CFM

[566-944 L/s]

Fuel Code

S = U.S. and

Canadian
Natural Gas

Electric

Ignition

06E
07E
09E
10E
12E

Electric

Ignition–

NOx Models

06N
07N
09N
10N

—

Input

BTU/HR

60,000 [17.6 kW]
75,000 [22.0 kW]

90,000 [26.4 kW]
105,000 [30.7 kW]
120,000 [35.2 kW]

—

BEFORE PURCHASING THIS APPLIANCE, READ IMPORTANT ENERGY COST AND EFFICIENCY INFORMATION AVAILABLE
FROM YOUR RETAILER.

PHYSICAL DATA AND SPECIFICATIONS—UPFLOW MODELS

U.S. and Canadian Models

MODEL IDENTIFICATION

[ ] Designates Metric Conversions

Rheem Heating, Cooling and Water Heating 5

UPFLOW MODELS

[ ] Designates Metric Conversions

MODEL

RGFG-

06 171/2 [445] 163/8 [416] 155/8 [397] 2 [51] 15 [422] 1313/16 [351] 0 0 0 1 [25] 2 [51] 0
07
09 21 [533] 197/8 [505] 191/8 [487] 2 [51] 181/2 [511] 175/16 [440] 0 0 0 1 [25] 2 [51] 0
10 21 [533] 197/8 [505] 191/8 [487] 2 [51] 181/2 [511] 175/16 [440] 0 0 0 1 [25] 2 [51] 0
12 241/2 [622] 233/8 [594] 225/8 [575] 2 [51] 22 [600] 2013/16 [529] 0 0 0 1 [25] 2 [51] 0

A B C D E F

171/2 [445] 163/8 [416] 155/8 [397]

2 [51]

15 [422] 1313/16 [351]

LEFT
SIDE

0 0 0 1 [25] 2 [51] 0

MINIMUM CLEARANCE (IN.) [mm]

RIGHT

SIDE

BACK TOP FRONT VENT

6 Rheem Heating, Cooling and Water Heating

BLOWER PERFORMANCE DATA—RGFG MODELS

[ ] Designates Metric Conversions

MODEL

RGFG-

06

07

09

10

12

BLOWER SIZE

IN. [mm]

[279 x 178]

[279 x 178]

[305 x 279]

[305 x 279]

[279 x 254]

(D x W)

11 x 7

11 x 7

12 x 11

12 x 11

11 x 10

ECM

MOTOR H.P.

[W]

1/2

[373]

1/2

[373]

1

[746]

1

[746]

1

[746]

BLOWER

SPEED

(SELECTED W/DIP

SWITCHES)

HIGH

MED-HI

MED
LOW

HIGH

MED-HI

MED
LOW

HIGH

MED-HI

MED
LOW

HIGH

MED-HI

MED
LOW

HIGH

MED-HI

MED
LOW

CFM [L/s] AIR DELIVERY

EXTERNAL STATIC PRESSURE

INCHES WATER COLUMN [kPa]

0.1 [.02]-0.8 [.20]

1200 [566]
1000 [472]

800 [378]
600 [283]

1200 [566]
1000 [472]

800 [378]
600 [283]

2000 [944]
1600 [755]
1400 [661]
1200 [566]

2000 [944]
1600 [755]
1400 [661]
1200 [566]

2000 [944]
1600 [755]
1400 [661]
1200 [566]

Rheem Heating, Cooling and Water Heating 7

CONTRACTOR BENEFITS:

• Multi-Purpose Thermostat-Setup, Control & Diagnostics

• Auto-Configuration – No Manual Settings Required in the Field

• System History – More Accurate Diagnostics

• Easy Installation – Requires only 4 wires

• Diagnostic Messages (Service Access to Fault Codes)

• Blower Adjustment in Heat and Cool

• Programmable Fan

• USB Interface for contractor contact information and thermostat
programming

HOMEOWNER BENEFITS:

• Scrolling System Status

• De-Humidification Control

• Humidification Control

• Heat/Cool/Auto Change-over

• Outdoor Temperature Display

• Backlight On/Off

• Intelligent Scheduling Ramp-Up/Program Anticipation

• Audio Notifications On/Off

• Air Filter, UV Lights & Humidifier Maintenance Reminder

• Temperature Offset

• Continuous Fan (Hi, Med, Lo)

FOSSIL FUEL KIT

RXPF-F02

*PROGRAMMABLE THERMOSTAT ACCESSORIES:

Adapter Plate = F61-2600
Remote F1451328 and F1451378 Sensor

*Available through PROSTOCK

®

.

[ ] Designates Metric Conversions

ACCESSORIES—UPFLOW

VENT TERMINATION KITS CONCENTRIC: HORIZONTAL/

VERTICAL =

RXGY-E03A (US & Canadian Installations)

HORIZONTAL TWO PIPE: RXGY-D02, RXGY-D03, RXGY-D04

(US Installations)

RXGY-D02A, RXGY-D03A, RXGY-D04A (Canadian Installations)

RXGY-G02 (US Only)
CONDENSATE PUMP KIT: RXGY-B01
NEUTRALIZER KIT: RXGY-A01
RETURN AIR PLENUM: RXGR-C17B

RXGR-C21B
RXGR-B24B

EXTERNAL BOTTOM FILTER RACK: RXGF-CB

EXTERNAL SIDE FILTER RACK: RXGF-CA

*Filter racks are shipped without filters.

Filters shipped with furnace may be used or a suitable 1" [25.4 mm] filter.

PLENUM DATA FOR “A” COILS

Plenum adapters are required in some instances for use on upflow
applications when plenum and furnace size do not match.

Note: See Form Number C11-206 for MultiFlex®coil data.

LP KIT: (Available through PROSTOCK®)

U.S./Canadian = RXGJ-FP27 (HU Fuel codes).

RHC-TST550CMMS

THERMOSTATS

RECOMMENDED MODULATING FURNACE THERMOSTAT

MODEL

RGFG-

FILTER RACK FILTER SIZES* INCHES [mm]

RXGF-CB

(BOTTOM)

06

07

09

10

12

153/4 x 25

[400 x 635]

153/4 x 25

[400 x 635]

191/4 x 25

[489 x 635]

191/4 x 25

[489 x 635]

223/4 x 25

[578 x 635]

RXGF-CA

(SIDE)

153/4 x 25

[400 x 635]

153/4 x 25

[400 x 635]

153/4 x 25

[400 x 635]

153/4 x 25

[400 x 635]

153/4 x 25

[400 x 635]

FURNACE

WIDTH

IN. [mm]

171/2 [445] 161/4 [413] RXAA-C185 RXAL-B16BU
171/2 [445] 201/4 [514] RXAA-C173 RXAL-B20BU
171/2 [445] 215/8 [549] RXAA-C187 RXAL-B21BU
171/2 [445] 251/4 [641]
21 [533] 251/4 [641]
21 [533] 221/4 [565] RXAA-C176 RXAL-B22BU
21 [533] 215/8 [549]
241/2 [622] 251/4 [641] RXAA-C177 RXAL-B25BU
241/2 [622] 215/8 [549] RXAA-C187 RXAL-B21BU

PLENUM

WIDTH

IN. [mm]

PLENUM ADAPTER

UPFLOW

RXAA-C174 RXAL-B25BU
RXAA-C175 RXAL-B25BU

RXAA-C188 RXAL-B21BU

PLENUM

COIL

ACCESSORIES—UPFLOW (con’t.)

FOR HIGH ALTITUDES:

Installations up to 5,000 ft. do not require a special kit or option.
However, an orifice change may be required based on heating value
and elevation. See Installation Instructions for more information.

Installations above 5,000 ft. are not permitted.
CAUTION: Always follow National Fuel Gas Code (NFGC) guidelines

when converting furnaces for high altitudes.
For all installations above 2000 ft. the burner orifice size needs to be

recalculated and verified at elevations above 2000 ft. A burner
orifice change may still be required. See Installation Instructions
for more information.

Manifold gas pressure reduction methods to adjust for altitude may
NOT be used on these models. The only method permitted on
modulating furnace models is to recalculate the burner orifice size.
See Installation Instructions for more information.

[ ] Designates Metric Conversions

Before proceeding with installation, refer
to installation instructions packaged
with each model, as well as complying
with all Federal, State, Provincial, and
Local codes, regulations, and practices.

Rheem Heating,
Cooling and
Water Heating

P.O. Box 17010, Fort Smith, AR 72917

“In keeping with its policy of continuous progress and product improvement, Rheem reserves the right to make changes without notice.”

PRINTED IN U.S.A. 1-11 DC FORM NO. G11-510 REV. 1

Supersedes Form No. G11-510

GENERAL TERMS OF LIMITED WARRANTY*

Rheem will furnish a replacement for any part of this product
which fails in normal use and service within the applicable
period stated, in accordance with the terms of the limited
warranty.

Primary and Secondary Heat Exchanger ......Limited Lifetime

Conditional Unit Replacement Warranty*

(Registration Required) ..............................Limited Lifetime

Parts ..........................................................Ten (10) Years

*For Complete Details of the Limited Warranty, Including Applicable Terms

and Conditions, See Your Local Installer or Contact the Manufacturer for
a Copy.
