Rollei Car DVR 300 User Guide
CarDVR-300
www.rollei.com
User Guide
in English
CarDVR-300
Contents (GPS)
About this Guide ...........................................4
WEEE Notice .............................................. 4
Battery Warning............................................ 4
Notes on Installation........................................ 5
Caution .............................................. 6
1 Introduction ............................................. 7
1.1 Features.............................................. 7
1.2 Package Contents ...................................... 7
1.3 Product Overview ...................................... 8
2 Getting Started .......................................... 9
2.1 Inserting the Memory Card ............................... 9
2.2 Installing in Vehicles ................................... 10
2.2.1 Mount to Windshield .............................. 10
2.2.2 Adjust the Device Position .......................... 11
2.3 Connecting to Power ................................... 12
2.4 Powering the Device On / Off............................. 14
2.4.1 Auto Power On/Off ................................ 14
2.4.2 Manual Power On/Off.............................. 14
2.5 Initial Settings ........................................ 15
2.5.1 Set the Date and Time.............................. 15
3 Using the Car Recorder .................................. 16
3.1 Recording Videos...................................... 16
3.1.1 Record Videos while Driving ......................... 16
3.1.2 Parking Mode .................................... 17
3.1.3 Emergency Recording ..............................18
3.1.4 The Recording Screen .............................. 19
3.2 Playback Videos and Photos ............................. 20
3.2.1 The Playback Screen ............................... 20
3.2.2 Deleting Files .................................... 21
4 Adjusting the Settings ................................... 22
4.1 Using the Menu ....................................... 22
4.2 Menu Tree ........................................... 23
5 Installing the Software .................................. 26
6 SuperCar ............................................. 27
7 Specifications .......................................... 28
8 CE Conformity .......................................... 29
4
About this Guide
The content in this document is for information purpose and is subject to
change without prior notice. We made every effort to ensure that this User
Guide is accurate and complete. However, no liability is assumed for any errors
and omissions that may have occurred. The manufacturer reserves the right to
change the technical specifications without prior notice.
WEEE Notice
Disposal of Waste Electrical and Electronic Equipment and/or
Battery by users in private households in the European Union.
This symbol on the product or on the packaging indicates that this
cannot be disposed of as a household waste. You must dispose of
your waste equipment and/or battery by handling it over to the applicable take-back scheme for the recycling of electrical and electronic
equipment and/or battery. For more information about recycling of
this equipment and/or battery, please contact your city office, the shop where
you purchased the equipment or your household waste disposal service. The
recycling of materials will help to conserve natural resources and ensure that it
is recycled in a manner that protects human health and environment.
Battery Warning
• Never dismantle, crush, or pierce the battery, or allow the battery to
short-circuit. Do not expose battery being placed in high temperature
environment, if battery leaks or bulges, stop continue to use.
• Always charge using the system. Risk of explosion if battery is replaced by
an incorrect type.
• Keep the battery out of reach of children.
• Batteries may explode if exposed to naked fire. Never dispose of batteries in
a fire.
• Never replace the battery on your own; have the dealer do it for you.
• Disposed of used batteries observing local regulations.
• Before disposing the device, please remove the battery.
To remove the battery open the screws on the housing of the device.
5
Notes on Installation
1. This product shall be installed near the rear view-mirror, at the center of
windshield, if possible, for optimal viewing.
2. Make sure that the lens is within the wiping range of the windscreen wiper
to ensure a clear view even when it rains.
3. Do not touch the lens with your fingers. Finger grease may be left on the
lens and will result in unclear videos or snapshots. Clean the lens on a
regular basis.
4. Do not install the device on a tinted window. Doing so may damage the tint
film.
5. Make sure that the installation position is not hindered by the tinted
window.
6. To use the products of the attached power charger only, please do not use
other brand power charger, in order to avoid equipment burn or cause the
battery explosion.
6
Caution
• Due to local laws and vehicles safety considerations, do not operate the
device while driving.
• Set up time and date accurately before you use this device.
• Please use SuperCar software in condition that Google Map is function
normally.
• The firmware function in the device is for reference only, please follow the
actual road condition.
• The results of GPS positioning are only for reference, and should not affect
the actual driving situation. The system also cannot ensure the positioning
accuracy.
• GPS positioning accuracy may differ depending on weather and location
such as high buildings, tunnels, undergrounds, or forests.
GPS satellite signals cannot pass through solid materials (except glass). Tin-
ted window will also affect the performance of the GPS satellite reception.
• GPS reception performance on each device may differ. The system cannot
determine the accuracy of the positioning results from different devices.
• The values displayed in this system, such as speed, position, and the distan-
ce warning to the speed camera set points, may be inaccurate due to the
influence of surrounding environment. They are for your reference only.
• The system is used only for non-commercial use, within the maximum limits
permitted by applicable law. Our company does not accept any responsibility
for any data loss during the operation.
• It is normal that this product gets warm when in use.
• Improper use or operation of the product may result in damage of the
product or its accessories and void the warranty.
7
1 Introduction
Thank you for purchasing this advanced Car Recorder. This device is specifi-
cally designed for real time video and audio recording when driving.
1.1 Features
• WFHD camera (2560x1080 @ 30fps)
• 2.4” LCD color screen
• Wide angle lens
• Motion detection
• Automatic Emergency recording for collision detection
• Supports SDHC up to 32GB
• Supports WDR / GPS/ Parking Mode
1.2 Package Contents
The package contains the following items. In case there is any missing or
damaged item, contact your dealer immediately.
1 Car Recorder
2 Quick start guide
3 CD-ROM
4 Bracket
5 Car adapter
1
3
4
2
5
8
1.3 Product Overview
No Item
1 Bracket Socket
2 Microphone
3 Power Button
4 Memory Card Slot
5 USB Connector
6 HD(Mini HDMI) Connector
7 Back Button (
)
8 LED Indicator
9 LCD Panel
10 Up Button (
)
11 Down Button (
)
12
Enter Button (OK)
13 Wide Angle Lens
14 Speaker
Note:
To operate the camcorder, press
the corresponding buttons
(7,10,11,12) according to guide
icons shown the screen.
1
3
2
5
6
8
11
12
9
13
10
7
14
9
2 Getting Started
2.1 Inserting the Memory Card
Insert memory card with the gold section facing upward and the screen of
the device facing upward too, as illustrated.
Push the memory card in until a click sound is heard, indicating the card is
in position.
To remove the memory card
Push to eject the memory card out of the slot.
Note:
1. Do not remove or insert the memory card when the device is turned on.
This may damage the memory card.
2. Please use a 32GB, Class 6 or above Micro SD card.
3. Please format the micro SD cards before the initial use.
