MIDI Implementation
Model: HandSonic HPD-20
Date: AUG. 01, 2013
Version: 1.00
1. Receive Data
Channel Voice Messages
* Following Channel Voice Messages can be received in MIDI Channel (MENU --> SYS
--> MIDI --> MIDI).
* Not received when MIDI Channel is set to “OFF.”
Note O
Status 2nd byte 3rd byte
8nH kkH vvH
9nH kkH 00H
n = MIDI channel number: 0H–FH (ch.1–ch.16)
kk = note number: 00H–7FH (0–127)
vv = note o velocity: 00H–7FH (0–127)
* When the pad or D-BEAM TriggerMode (MENU --> INST --> SETUP) is set to “GATE,”
only the note number set for the pad or D-BEAM is received, using GATE to function
in the same manner as releasing the pad or taking your hand away from D-BEAM.
Note On
Status 2nd byte 3rd byte
9nH kkH vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
kk = note number: 00H–7FH (0–127)
vv = note on velocity: 01H–7FH (1–127)
* Received only the note numbers which are specied by the kit.
Polyphonic Key Pressure
Status 2nd byte 3rd byte
AnH kkH vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
kk = note number: 00H–7FH (0–127)
vv = key pressure: 00H–7FH (0–127)
* Received only the note numbers which are specied by the kit.
* Not received when Pressure Rx (MENU --> SYS --> MIDI --> MIDI) is set to “OFF.”
* When a note number for an external pad is received, if the external pad
TriggerMode (MENU --> INST --> SETUP) is set to “SHOT” and value of the received
key pressure is 40H (64) or higher, the decay of the sound produced by the external
pad is shortened.
Foot Controller (Controller Number 4)
Status 2nd byte 3rd byte
BnH 04H vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127: Open–Close)
* This adjusts the hi-hat control pedal position.
Eect Controller 1 (Controller Number 12)
Status 2nd byte 3rd byte
BnH 0CH vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127)
* When D-BEAM CC# (MENU --> SYS --> MIDI --> MIDI) setting is “EFFECT1 (12) ,” this
message is used as D-BEAM position information.
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting
is “EFFECT1 (12) ,” this message is used as Realtime Modify (PITCH) control
information.
* When Realtime Modify Eect CC# (MENU --> SYS --> MIDI --> MIDI) setting
is “EFFECT1 (12) ,” this message is used as Realtime Modify (EFFECT) control
information.
Eect Controller 2 (Controller Number 13)
Status 2nd byte 3rd byte
BnH 0DH vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127)
* When D-BEAM CC# (MENU --> SYS --> MIDI --> MIDI) setting is “EFFECT2 (13) ,” this
message is used as D-BEAM position information.
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting
is “EFFECT2 (13) ,” this message is used as Realtime Modify (PITCH) control
information.
* When Realtime Modify Eect CC# (MENU --> SYS --> MIDI --> MIDI) setting
is “EFFECT2 (13) ,” this message is used as Realtime Modify (EFFECT) control
information.
General Purpose Controller 1 (Controller Number 16)
Status 2nd byte 3rd byte
BnH 10H vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127: Center–Edge)
* This message is used as Pad M1 position information.
General Purpose Controller 2 (Controller Number 17)
Status 2nd byte 3rd byte
BnH 11H vvH
Control Change
* Not received when Control Change Rx (MENU --> SYS --> MIDI --> MIDI) is set to
“OFF.”
Bank Select (Controller Number 0, 32)
Status 2nd byte 3rd byte
BnH 00H mmH
BnH 20H llH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
mm = bank number MSB: 00H–01H
ll = bank number LSB: processed as 00H
* Bank Select processing will be suspended until a Program Change message is
received.
2
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127: Center–Edge)
* This message is used as Pad M2 position information.
General Purpose Controller 3 (Controller Number 18,
50)
Status 2nd byte 3rd byte
BnH 12H mmH
BnH 32H llH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
mm = control value MSB 0H–CH (0–12: Pad M1–S8)
ll = control value LSB 00H–7FH (0–127: Open–Close)
* This message is used as hi-hat open–close information.
MIDI Implementation
General Purpose Controller 4 (Controller Number 19)
Status 2nd byte 3rd byte
BnH 13H vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–63: OFF, 64–127: ON)
* This message is used as Realtime Modify (PITCH) on/o information.
Hold 1 (Controller Number 64)
Status 2nd byte 3rd byte
BnH 40H vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–63: OFF, 64–127: ON)
* This message is used as Roll on/o information.
Sound Controller 1 (Controller Number 70)
Status 2nd byte 3rd byte
BnH 46H vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127)
* When D-BEAM CC# (MENU --> SYS --> MIDI --> MIDI) setting is “SOUND1 (70) ,” this
message is used as D-BEAM position information.
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting
is “SOUND1 (70) ,” this message is used as Realtime Modify (PITCH) control
information.
* When Realtime Modify Eect CC# (MENU --> SYS --> MIDI --> MIDI) setting
is “SOUND1 (70) ,” this message is used as Realtime Modify (EFFECT) control
information.
Sound Controller 2 (Controller Number 71)
Status 2nd byte 3rd byte
BnH 47H vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127)
* When D-BEAM CC# (MENU --> SYS --> MIDI --> MIDI) setting is “SOUND2 (71) ,” this
message is used as D-BEAM position information.
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting
is “SOUND2 (71) ,” this message is used as Realtime Modify (PITCH) control
information.
* When Realtime Modify Eect CC# (MENU --> SYS --> MIDI --> MIDI) setting
is “SOUND2 (71) ,” this message is used as Realtime Modify (EFFECT) control
information.
Sound Controller 3 (Controller Number 72)
Status 2nd byte 3rd byte
BnH 48H vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127)
* When D-BEAM CC# (MENU --> SYS --> MIDI --> MIDI) setting is “SOUND3 (72) ,” this
message is used as D-BEAM position information.
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting
is “SOUND3 (72) ,” this message is used as Realtime Modify (PITCH) control
information.
* When Realtime Modify Eect CC# (MENU --> SYS --> MIDI --> MIDI) setting
is “SOUND3 (72) ,” this message is used as Realtime Modify (EFFECT) control
information.
Sound Controller 4 (Controller Number 73)
Status 2nd byte 3rd byte
BnH 49H vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127)
* When D-BEAM CC# (MENU --> SYS --> MIDI --> MIDI) setting is “SOUND4 (73) ,” this
message is used as D-BEAM position information.
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting
is “SOUND4 (73) ,” this message is used as Realtime Modify (PITCH) control
information.
* When Realtime Modify Eect CC# (MENU --> SYS --> MIDI --> MIDI) setting
is “SOUND4 (73) ,” this message is used as Realtime Modify (EFFECT) control
information.
Sound Controller 5 (Controller Number 74)
Status 2nd byte 3rd byte
BnH 4AH vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127)
* When D-BEAM CC# (MENU --> SYS --> MIDI --> MIDI) setting is “SOUND5 (74),” this
message is used as D-BEAM position information.
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting
is “SOUND5 (74) ,” this message is used as Realtime Modify (PITCH) control
information.
* When Realtime Modify Eect CC# (MENU --> SYS --> MIDI --> MIDI) setting
is “SOUND5 (74) ,” this message is used as Realtime Modify (EFFECT) control
information.
Sound Controller 6 (Controller Number 75)
Status 2nd byte 3rd byte
BnH 4BH vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127)
* When D-BEAM CC# (MENU --> SYS --> MIDI --> MIDI) setting is “SOUND6 (75) ,” this
message is used as D-BEAM position information.
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting
is “SOUND6 (75) ,” this message is used as Realtime Modify (PITCH) control
information.
* When Realtime Modify Eect CC# (MENU --> SYS --> MIDI --> MIDI) setting
is “SOUND6 (75) ,” this message is used as Realtime Modify (EFFECT) control
information.
Sound Controller 7 (Controller Number 76)
Status 2nd byte 3rd byte
BnH 4CH vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127)
* When D-BEAM CC# (MENU --> SYS --> MIDI --> MIDI) setting is “SOUND7 (76) ,” this
message is used as D-BEAM position information.
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting
is “SOUND7 (76) ,” this message is used as Realtime Modify (PITCH) control
information.
* When Realtime Modify Eect CC# (MENU --> SYS --> MIDI --> MIDI) setting
is “SOUND7 (76) ,” this message is used as Realtime Modify (EFFECT) control
information.
3
MIDI Implementation
Sound Controller 8 (Controller Number 77)
Status 2nd byte 3rd byte
BnH 4DH vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127)
* When D-BEAM CC# (MENU --> SYS --> MIDI --> MIDI) setting is “SOUND8 (77) ,” this
message is used as D-BEAM position information.
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting
is “SOUND8 (77) ,” this message is used as Realtime Modify (PITCH) control
information.
* When Realtime Modify Eect CC# (MENU --> SYS --> MIDI --> MIDI) setting
is “SOUND8 (77) ,” this message is used as Realtime Modify (EFFECT) control
information.
Sound Controller 9 (Controller Number 78)
Status 2nd byte 3rd byte
BnH 4EH vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127)
* When D-BEAM CC# (MENU --> SYS --> MIDI --> MIDI) setting is “SOUND9 (78) ,” this
message is used as D-BEAM position information.
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting
is “SOUND9 (78) ,” this message is used as Realtime Modify (PITCH) control
information.
* When Realtime Modify Eect CC# (MENU --> SYS --> MIDI --> MIDI) setting
is “SOUND9 (78) ,” this message is used as Realtime Modify (EFFECT) control
information.
General Purpose Controller 7 (Controller Number 82)
Status 2nd byte 3rd byte
BnH 52H vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127)
* When D-BEAM CC# (MENU --> SYS --> MIDI --> MIDI) setting is “GENERAL7 (82) ,” this
message is used as D-BEAM position information.
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“GENERAL7 (82) ,” this message is used as Realtime Modify (PITCH) control
information.
* When Realtime Modify Eect CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“GENERAL7 (82) ,” this message is used as Realtime Modify (EFFECT) control
information.
General Purpose Controller 8 (Controller Number 83)
Status 2nd byte 3rd byte
BnH 53H vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127)
* When D-BEAM CC# (MENU --> SYS --> MIDI --> MIDI) setting is “GENERAL8 (83) ,” this
message is used as D-BEAM position information.
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“GENERAL8 (83) ,” this message is used as Realtime Modify (PITCH) control
information.
* When Realtime Modify Eect CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“GENERAL8 (83) ,” this message is used as Realtime Modify (EFFECT) control
information.
Sound Controller 10 (Controller Number 79)
Status 2nd byte 3rd byte
BnH 4FH vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127)
* When D-BEAM CC# (MENU --> SYS --> MIDI --> MIDI) setting is “SOUND10 (79) ,” this
message is used as D-BEAM position information.
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“SOUND10 (79) ,” this message is used as Realtime Modify (PITCH) control
information.
* When Realtime Modify Eect CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“SOUND10 (79) ,” this message is used as Realtime Modify (EFFECT) control
information.
General Purpose Controller 5 (Controller Number 80)
Status 2nd byte 3rd byte
BnH 50H vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–63: OFF, 64–127: ON)
* This message is used as Realtime Modify (EFFECT) on/o information.
General Purpose Controller 6 (Controller Number 81)
Status 2nd byte 3rd byte
BnH 51H vvH
Program Change
Status 2nd byte
CnH ppH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
pp = program number: 00H–7FH (prog.1–prog.128)
* The sound will change beginning with the next note on after the Program Change
is received.
* Not received when Program Change Rx (MENU --> SYS --> MIDI --> MIDI) is set to
“OFF.”
Bank Select MSB / LSB Program Number Kit Number
000 / 000 001–128 001–128
001 / 000 001–072 129–200
Pitch Bend Change
Status 2nd byte 3rd byte
EnH llH mmH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
mm, ll = pitch bend value: 00 00H–40 00H–7F 7FH
(-8192–0–+8191)
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting is “PITCH
BEND,” this message is used as Realtime Modify (PITCH) control information.
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127)
* When D-BEAM CC# (MENU --> SYS --> MIDI --> MIDI) setting is “GENERAL6 (81) ,” this
message is used as D-BEAM position information.
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“GENERAL6 (81) ,” this message is used as Realtime Modify (PITCH) control
information.
* When Realtime Modify Eect CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“GENERAL6 (81) ,” this message is used as Realtime Modify (EFFECT) control
information.
4
MIDI Implementation
Channel Mode Messages
* Following Channel Voice Messages can be received in MIDI Channel (MENU --> SYS
--> MIDI --> MIDI).
All Sound O (Controller Number 120)
Status 2nd byte 3rd byte
BnH 78H 00H
n = MIDI channel number: 0H–FH (ch.1–ch.16)
* When this message is received, all currently-sounding notes on the corresponding
channel will be turned o immediately.
Reset All Controller (Controller Number 121)
Status 2nd byte 3rd byte
BnH 79H 00H
n = MIDI channel number: 0H–FH (ch.1–ch.16)
* When this message is received, the following controllers will be set to their reset
values.
Controller Reset value
Polyphonic key pressure 0
Foot Controller 0 (Open)
Hold 1 0 (O)
General Purpose Controller 4, 5 0 (O)
General Purpose Controller 6–8 Depends on Realtime Modify settings
Eect Controller 1, 2 Depends on Realtime Modify settings
Sound Controller 1–10 Depends on Realtime Modify settings
Pitch Bend Depends on Realtime Modify settings
MONO (Controller Number 126)
Status 2nd byte 3rd byte
BnH 7EH 00H
n = MIDI channel number: 0H–FH (ch.1–ch.16)
* The same processing will be carried out as when All Sound O is received.
POLY (Controller Number 127)
Status 2nd byte 3rd byte
BnH 7FH 00H
n = MIDI channel number: 0H–FH (ch.1–ch.16)
* The same processing will be carried out as when All Sound O is received.
All Note O (Controller Number 123)
Status 2nd byte 3rd byte
BnH 7BH 00H
n = MIDI channel number: 0H–FH (ch.1–ch.16)
* The same processing will be carried out as when All Sound O is received.
OMNI OFF (Controller Number 124)
Status 2nd byte 3rd byte
BnH 7CH 00H
n = MIDI channel number: 0H–FH (ch.1–ch.16)
* The same processing will be carried out as when All Sound O is received.
OMNI ON (Controller Number 125)
Status 2nd byte 3rd byte
BnH 7DH 00H
n = MIDI channel number: 0H–FH (ch.1–ch.16)
* The same processing will be carried out as when All Sound O is received.
5
MIDI Implementation
System Realtime Messages
Active Sensing
Status
FEH
* When Active Sensing is received, the unit will begin monitoring the intervals of all
further messages. While monitoring, if the interval between messages exceeds
420 ms, the same processing will be carried out as when All Sounds O is received,
and message interval monitoring will be halted.
System Exclusive Messages
Status Data byte Status
F0H iiH, ddH, ......, eeH F7H
F0H: System Exclusive Messages Status
ii = ID number: ID number (manufacturer ID) to indicate the
manufacturer whose Exclusive message this is.
Roland’s manufacturer ID is 41H.
ID numbers 7EH and 7FH are extensions of the
MIDI standard; Universal Non-realtime Messages
(7EH) and Universal Realtime Messages (7FH).
dd,...,ee = Data: 00H–7FH (0–127)
F7H: EOX (End Of Exclusive)
The System Exclusive Messages received by this instrument are Universal Nonrealtime System Exclusive messages.
Universal Non-Realtime System Exclusive Messages
Identity Request Message
Status Data byte Status
F0H 7EH, dev, 06H, 01H F7H
Byte Explanation
F0H Exclusive Status
7EH ID number (Universal Non-realtime messages)
dev Device ID (10H or 7FH)
06H Sub ID#1 (General Information)
01H Sub ID#2 (Identity Request)
F7H EOX (End Of Exclusive)
* When Identity Request is received, Identity Reply message will be transmitted
2. Data Transmission
Channel Voice Messages
* The following channel voice messages are transmitted on the channel specied as
the MIDI Channel (MENU --> SYS --> MIDI --> MIDI).
* Not transmitted when MIDI Channel is set to “OFF.”
* Channel Voice messages linked to the D-BEAM are not transmitted when the
[D-BEAM] button is OFF.
Note O
Status 2nd byte 3rd byte
8nH kkH vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
kk = note number: 00H–7FH (0–127)
vv = note o velocity: 00H–7FH (0–127)
* Transmitted the note numbers which are specied by the kit.
* When the pad or D-BEAM TriggerMode (MENU --> INST --> SETUP) is set to “GATE,”
note o is transmitted after the interval specied in GateTime (MENU --> KIT -->
MIDI --> GATE).
* When the pad or D-BEAM TriggerMode is set to “GATE,” note o is transmitted when
the pad is released or the user’s hand is removed from the D-BEAM.
* When the D-BEAM TriggerMode is set to “GATE,” note o is transmitted before note
on when the pad is tapped while being pressed down.
Note On
Status 2nd byte 3rd byte
9nH kkH vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
kk = note number: 00H–7FH (0–127)
vv = note on velocity: 01H–7FH (1–127)
* Transmitted the note numbers which are specied by the kit.
* This is transmitted when the pad/external pad is tapped or the D-BEAM/hi-hat
control pedal is used.
Polyphonic key pressure
Status 2nd byte 3rd byte
AnH kkH vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
kk = note number: 00H–7FH (0–127)
vv = key pressure: 00H–7FH (0–127)
* Transmitted using the note number set for the pad when the pad is pressed.
* When the rim of a pad connected to TRIG IN is pressed, 7FH is transmitted using
the note number set for the pad; 00H is transmitted when the rim is released (when
using a pad compatible with choking).
* Not transmitted when Pressure Tx (MENU --> SYS --> MIDI --> MIDI) is set to “OFF.”
6
MIDI Implementation
Control Change
* Not transmitted when Control Change Tx (MENU --> SYS --> MIDI --> MIDI) is set to
“OFF.”
Bank Select (Controller Number 0, 32)
Status 2nd byte 3rd byte
BnH 00H mmH
BnH 20H llH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
mm = bank number MSB: 00H–01H
ll = bank number LSB: Fixed as 00H
* When a kit is selected, the corresponding bank select is transmitted.
Foot Controller (Controller Number 4)
Status 2nd byte 3rd byte
BnH 04H vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127: Open–Close)
* When the hi-hat control pedal is adjusted, this message is transmitted.
Eect Controller 1 (Controller Number 12)
Status 2nd byte 3rd byte
BnH 0CH vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127)
General Purpose Controller 2 (Controller Number 17)
Status 2nd byte 3rd byte
BnH 11H vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127: Center–Edge)
* This is the strike position data for Pad M2. It is transmitted before its note on
message.
* 00H is transmitted when Position Area (MENU --> SYS --> PAD SETTINGS --> POSI)
is set to “OFF.”
General Purpose Controller 3 (Controller Number 18,
50)
Status 2nd byte 3rd byte
BnH 12H mmH
BnH 32H llH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
mm = control value MSB 0H–CH (0–12: Pad M1–S8)
ll = control value LSB 00H–7FH (0–127: Open–Close)
* This is transmitted as hi-hat open–close information when the pad is tapped.
General Purpose Controller 4 (Controller Number 19)
Status 2nd byte 3rd byte
BnH 13H vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–63: OFF, 64–127: ON)
* When D-BEAM CC# (MENU --> SYS --> MIDI --> MIDI) setting is “EFFECT1 (12) ,” this is
transmitted when D-BEAM is used.
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“EFFECT1 (12) ,” this is transmitted when Realtime Modify (PITCH) is adjusted.
* When Realtime Modify Eect CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“EFFECT1 (12) ,” this is transmitted when Realtime Modify (EFFECT) is adjusted.
Eect Controller 2 (Controller Number 13)
Status 2nd byte 3rd byte
BnH 0DH vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127)
* When D-BEAM CC# (MENU --> SYS --> MIDI --> MIDI) setting is “EFFECT2 (13) ,” this is
transmitted when D-BEAM is used.
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“EFFECT2 (13) ,” this is transmitted when Realtime Modify (PITCH) is adjusted.
* When Realtime Modify Eect CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“EFFECT2 (13) ,” this is transmitted when Realtime Modify (EFFECT) is adjusted.
General Purpose Controller 1 (Controller Number 16)
Status 2nd byte 3rd byte
BnH 10H vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127: Center–Edge)
* This is the strike position data for Pad M1. It is transmitted before its note on
message.
* 00H is transmitted when Position Area (MENU --> SYS --> PAD SETTINGS --> POSI)
is set to “OFF.”
* This is transmitted when the [PITCH] button is pressed.
Hold 1 (Controller Number 64)
Status 2nd byte 3rd byte
BnH 40H vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–63: OFF, 64–127: ON)
* This is transmitted when the [ROLL] button is pressed.
Sound Controller 1 (Controller Number 70)
Status 2nd byte 3rd byte
BnH 46H vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127)
* When D-BEAM CC# (MENU --> SYS --> MIDI --> MIDI) setting is “SOUND1 (70) ,” this
is transmitted when D-BEAM is used.
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“SOUND1 (70) ,” this is transmitted when Realtime Modify (PITCH) is adjusted.
* When Realtime Modify Eect CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“SOUND1 (70) ,” this is transmitted when Realtime Modify (EFFECT) is adjusted.
7
MIDI Implementation
Sound Controller 2 (Controller Number 71)
Status 2nd byte 3rd byte
BnH 47H vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127)
* When D-BEAM CC# (MENU --> SYS --> MIDI --> MIDI) setting is “SOUND2 (71) ,” this
is transmitted when D-BEAM is used.
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“SOUND2 (71) ,” this is transmitted when Realtime Modify (PITCH) is adjusted.
* When Realtime Modify Eect CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“SOUND2 (71) ,” this is transmitted when Realtime Modify (EFFECT) is adjusted.
Sound Controller 3 (Controller Number 72)
Status 2nd byte 3rd byte
BnH 48H vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127)
* When D-BEAM CC# (MENU --> SYS --> MIDI --> MIDI) setting is “SOUND3 (72) ,” this
is transmitted when D-BEAM is used.
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“SOUND3 (72) ,” this is transmitted when Realtime Modify (PITCH) is adjusted.
* When Realtime Modify Eect CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“SOUND3 (72) ,” this is transmitted when Realtime Modify (EFFECT) is adjusted.
Sound Controller 4 (Controller Number 73)
Status 2nd byte 3rd byte
BnH 49H vvH
Sound Controller 6 (Controller Number 75)
Status 2nd byte 3rd byte
BnH 4BH vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127)
* When D-BEAM CC# (MENU --> SYS --> MIDI --> MIDI) setting is “SOUND6 (75) ,” this
is transmitted when D-BEAM is used.
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“SOUND6 (75) ,” this is transmitted when Realtime Modify (PITCH) is adjusted.
* When Realtime Modify Eect CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“SOUND6 (75) ,” this is transmitted when Realtime Modify (EFFECT) is adjusted.
Sound Controller 7 (Controller Number 76)
Status 2nd byte 3rd byte
BnH 4CH vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127)
* When D-BEAM CC# (MENU --> SYS --> MIDI --> MIDI) setting is “SOUND7 (76) ,” this
is transmitted when D-BEAM is used.
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“SOUND7 (76) ,” this is transmitted when Realtime Modify (PITCH) is adjusted.
* When Realtime Modify Eect CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“SOUND7 (76) ,” this is transmitted when Realtime Modify (EFFECT) is adjusted.
Sound Controller 8 (Controller Number 77)
Status 2nd byte 3rd byte
BnH 4DH vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127)
* When D-BEAM CC# (MENU --> SYS --> MIDI --> MIDI) setting is “SOUND4 (73) ,” this
is transmitted when D-BEAM is used.
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“SOUND4 (73) ,” this is transmitted when Realtime Modify (PITCH) is adjusted.
* When Realtime Modify Eect CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“SOUND4 (73) ,” this is transmitted when Realtime Modify (EFFECT) is adjusted.
Sound Controller 5 (Controller Number 74)
Status 2nd byte 3rd byte
BnH 4AH vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127)
* When D-BEAM CC# (MENU --> SYS --> MIDI --> MIDI) setting is “SOUND5 (74) ,” this
is transmitted when D-BEAM is used.
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“SOUND5 (74) ,” this is transmitted when Realtime Modify (PITCH) is adjusted.
* When Realtime Modify Eect CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“SOUND5 (74) ,” this is transmitted when Realtime Modify (EFFECT) is adjusted.
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127)
* When D-BEAM CC# (MENU --> SYS --> MIDI --> MIDI) setting is “SOUND8 (77) ,” this
is transmitted when D-BEAM is used.
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“SOUND8 (77) ,” this is transmitted when Realtime Modify (PITCH) is adjusted.
* When Realtime Modify Eect CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“SOUND8 (77) ,” this is transmitted when Realtime Modify (EFFECT) is adjusted.
Sound Controller 9 (Controller Number 78)
Status 2nd byte 3rd byte
BnH 4EH vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127)
* When D-BEAM CC# (MENU --> SYS --> MIDI --> MIDI) setting is “SOUND9 (78) ,” this
is transmitted when D-BEAM is used.
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“SOUND9 (78) ,” this is transmitted when Realtime Modify (PITCH) is adjusted.
* When Realtime Modify Eect CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“SOUND9 (78) ,” this is transmitted when Realtime Modify (EFFECT) is adjusted.
8
MIDI Implementation
Sound Controller 10 (Controller Number 79)
Status 2nd byte 3rd byte
BnH 4FH vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127)
* When D-BEAM CC# (MENU --> SYS --> MIDI --> MIDI) setting is “SOUND10 (79) ,” this
is transmitted when D-BEAM is used.
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“SOUND10 (79) ,” this is transmitted when Realtime Modify (PITCH) is adjusted.
* When Realtime Modify Eect CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“SOUND10 (79) ,” this is transmitted when Realtime Modify (EFFECT) is adjusted.
General Purpose Controller 5 (Controller Number 80)
Status 2nd byte 3rd byte
BnH 50H vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–63: OFF, 64–127: ON)
* This is transmitted when the [EFFECT] button is pressed.
General Purpose Controller 6 (Controller Number 81)
Status 2nd byte 3rd byte
BnH 51H vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127)
Program Change
Status 2nd byte
CnH ppH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
pp = program number: 00H–7FH (prog.1–prog.128)
* When a kit is selected, the corresponding program number is transmitted.
* Not transmitted when Program Change Tx (MENU --> SYS --> MIDI --> MIDI) is set
to “OFF.”
Pitch Bend Change
Status 2nd byte 3rd byte
EnH llH mmH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
mm, ll = pitch bend value: 00 00H–40 00H–7F 7FH
(-8192–0–+8191)
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting is “PITCH
BEND,” this is transmitted when Realtime Modify (PITCH) is adjusted.
* When D-BEAM CC# (MENU --> SYS --> MIDI --> MIDI) setting is “GENERAL6 (81) ,” this
is transmitted when D-BEAM is used.
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“GENERAL6 (81) ,” this is transmitted when Realtime Modify (PITCH) is adjusted.
* When Realtime Modify Eect CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“GENERAL6 (81) ,” this is transmitted when Realtime Modify (EFFECT) is adjusted.
General Purpose Controller 7 (Controller Number 82)
Status 2nd byte 3rd byte
BnH 52H vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127)
* When D-BEAM CC# (MENU --> SYS --> MIDI --> MIDI) setting is “GENERAL7 (82) ,” this
is transmitted when D-BEAM is used.
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“GENERAL7 (82) ,” this is transmitted when Realtime Modify (PITCH) is adjusted.
* When Realtime Modify Eect CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“GENERAL7 (82) ,” this is transmitted when Realtime Modify (EFFECT) is adjusted.
General Purpose Controller 8 (Controller Number 83)
Status 2nd byte 3rd byte
BnH 53H vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = control value 00H–7FH (0–127)
* When D-BEAM CC# (MENU --> SYS --> MIDI --> MIDI) setting is “GENERAL8 (83) ,” this
is transmitted when D-BEAM is used.
* When Realtime Modify Pitch CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“GENERAL8 (83) ,” this is transmitted when Realtime Modify (PITCH) is adjusted.
* When Realtime Modify Eect CC# (MENU --> SYS --> MIDI --> MIDI) setting is
“GENERAL8 (83) ,” this is transmitted when Realtime Modify (EFFECT) is adjusted.
9
MIDI Implementation
Channel Mode Messages
* The following channel mode messages are transmitted on the channel specied as
the MIDI Channel (MENU --> SYS --> MIDI --> MIDI).
All Sound O (Controller Number 120)
Status 2nd byte 3rd byte
BnH 78H 00H
n = MIDI channel number: 0H–FH (ch.1–ch.16)
* This is transmitted when the ALL SOUND OFF ( [SHIFT] + [EXIT] ) is used.
Reset All Controller (Controller Number 121)
Status 2nd byte 3rd byte
BnH 79H 00H
n = MIDI channel number: 0H–FH (ch.1–ch.16)
* This is transmitted when the Factory Reset (MENU --> SYS --> Factory Reset) is
executed.
System Realtime Messages
Active Sensing
Status
FEH
* This message is transmitted at intervals of approximately 250 msec.
System Exclusive Messages
Identity Reply, V-LINK message, and MIDI Visual Control message are the only System
Exclusive messages transmitted by this device.
V-LINK Messages
V-LINK ON
Transmitted when entering V-LINK mode.
Status Data byte Status
F0H 41H, 10H, 00H, 51H, 12H, F7H
10H, 00H, 00H, 01H, nnH,
10H, 02H, sum
Byte Explanation
F0H Exclusive Status
41H ID Number (Roland)
10H Device ID (10H xed)
00H Model ID#1 (V-LINK)
51H Model ID#2 (V-LINK)
12H Command ID (DT1)
10H 00H 00H Address
01H Data (V-LINK ON)
nnH Data (Clip Control Rx MIDI Ch.
(00H-0FH (ch.1-ch.16) ) Initial Value = 0FH (ch.16) )
10H Data (Color Control Rx MIDI Ch. (OFF) )
02H Data (Note Message Enabled (Assignable) )
sum Check Sum
F7H EOX (End Of Exclusive)
* The unit will enter V-LINK mode if Control Mode (MENU --> SYS --> MIDI --> VISUAL)
is set to “V-LINK” and MIDI Visual Control (MENU --> SYS --> MIDI --> VISUAL) is
turned “ON.”
* MIDI Channel (MENU --> SYS --> MIDI --> VISUAL) setting is used as the Clip Control
Rx MIDI Ch.
* Only the Clip Control Rx MIDI Ch address (10H 00H 01H) and data are transmitted
when the MIDI Channel setting is made in V-LINK mode.
V-LINK OFF
Transmitted when exiting V-LINK mode.
Universal Non-Realtime System Exclusive Messages
Identity Reply Message
Status Data byte Status
F0H 7EH, dev, 06H, 02H, 41H, F7H
78H, 02H, 00H, 00H, 00H,
01H, 00H, 00H
Byte Explanation
F0H Exclusive Status
7EH ID number (Universal Non-Realtime Message)
dev Device ID (10H xed)
06H Sub ID#1 (General Information)
02H Sub ID#2 (Identity Request)
41H ID Number (Roland)
78H 02H Device Family Cord
00H 00H Device Family Number Code
00H 01H 00H 00H Software Revision Level
F7H EOX (End Of Exclusive)
* When Identity Request is received, Identity Reply message will be transmitted.
Status Data byte Status
F0H 41H, 10H, 00H, 51H, 12H, F7H
10H, 00H, 00H, 00H, 70H,
Byte Explanation
F0H Exclusive Status
41H ID Number (Roland)
10H Device ID (10H xed)
00H Model ID#1 (V-LINK)
51H Model ID#2 (V-LINK)
12H Command ID (DT1)
10H 00H 00H Address
00H Data (V-LINK OFF)
70H Check Sum
F7H EOX (End Of Exclusive)
* The unit will exit V-LINK mode if the MIDI Visual Control (MENU --> SYS --> MIDI -->
VISUAL) is turned “OFF” or if the Control Mode (MENU --> SYS --> MIDI --> VISUAL)
is set to “MVC.”
10
MIDI Visual Control Messages
MIDI Visual Control ON
Transmitted when entering MIDI Visual Control mode.
Status Data byte Status
F0H 7EH, 00H, 0CH, 01H, F7H
10H, 00H, 00H, 01H, nnH,
10H, 01H, sum
Byte Explanation
F0H Exclusive Status
7EH ID Number (Roland)
00H Device ID (00H xed)
0CH Model ID#1
01H Model ID#2
10H 00H 00H Address
01H Data (MIDI Visual Control ON)
nnH Data (Clip Control Rx MIDI Ch.
(00H-0FH (ch.1-ch.16) ) Initial Value = 0FH (ch.16) )
10H Data (Eect Control Rx MIDI Ch. (OFF) )
01H Data (Note Message Enabled (ON) )
sum Check Sum
F7H EOX (End Of Exclusive)
* The unit will enter MIDI Visual Control mode if Control Mode (MENU --> SYS -->
MIDI --> VISUAL) is set to “MVC” and MIDI Visual Control (MENU --> SYS --> MIDI -->
VISUAL) is turned “ON.”
* MIDI Channel (MENU --> SYS --> MIDI --> VISUAL) setting is used as the Clip Control
Rx MIDI Ch.
* Only the Clip Control Rx MIDI Ch address (10H 00H 01H) and data are transmitted
when the MIDI Channel setting is made in MIDI Visual Control mode.
MIDI Implementation
MIDI Visual Control OFF
Transmitted when exiting MIDI Visual Control mode.
Status Data byte Status
F0H 7EH, 00H, 0CH, 01H, F7H
10H, 00H, 00H, 00H, 70H,
Byte Explanation
F0H Exclusive Status
7EH ID Number (Roland)
00H Device ID (00H xed)
00H Model ID#1
0CH Model ID#2
01H Command ID (DT1)
10H 00H 00H Address
00H Data (MIDI Visual Control OFF)
70H Check Sum
F7H EOX (End Of Exclusive)
* The unit will exit MIDI Visual Control mode if the MIDI Visual Control (MENU --> SYS
--> MIDI --> VISUAL) is turned “OFF” or if Control Mode (MENU --> SYS --> MIDI -->
VISUAL) is set to “V-LINK.”
11
MIDI Implementation
3. Supplementary Material
Decimal and Hexadecimal Table
In MIDI documentation, data values and addresses/sizes of exclusive messages etc.
are expressed as hexadecimal values for each 7 bits.
The following table shows how these correspond to decimal numbers.
+------+------++------+------++------+------++------+------+
| D | H || D | H || D | H || D | H |
+------+------++------+------++------+------++------+------+
| 0 | 00H || 32 | 20H || 64 | 40H || 96 | 60H |
| 1 | 01H || 33 | 21H || 65 | 41H || 97 | 61H |
| 2 | 02H || 34 | 22H || 66 | 42H || 98 | 62H |
| 3 | 03H || 35 | 23H || 67 | 43H || 99 | 63H |
| 4 | 04H || 36 | 24H || 68 | 44H || 100 | 64H |
| 5 | 05H || 37 | 25H || 69 | 45H || 101 | 65H |
| 6 | 06H || 38 | 26H || 70 | 46H || 102 | 66H |
| 7 | 07H || 39 | 27H || 71 | 47H || 103 | 67H |
| 8 | 08H || 40 | 28H || 72 | 48H || 104 | 68H |
| 9 | 09H || 41 | 29H || 73 | 49H || 105 | 69H |
| 10 | 0AH || 42 | 2AH || 74 | 4AH || 106 | 6AH |
| 11 | 0BH || 43 | 2BH || 75 | 4BH || 107 | 6BH |
| 12 | 0CH || 44 | 2CH || 76 | 4CH || 108 | 6CH |
| 13 | 0DH || 45 | 2DH || 77 | 4DH || 109 | 6DH |
| 14 | 0EH || 46 | 2EH || 78 | 4EH || 110 | 6EH |
| 15 | 0FH || 47 | 2FH || 79 | 4FH || 111 | 6FH |
| 16 | 10H || 48 | 30H || 80 | 50H || 112 | 70H |
| 17 | 11H || 49 | 31H || 81 | 51H || 113 | 71H |
| 18 | 12H || 50 | 32H || 82 | 52H || 114 | 72H |
| 19 | 13H || 51 | 33H || 83 | 53H || 115 | 73H |
| 20 | 14H || 52 | 34H || 84 | 54H || 116 | 74H |
| 21 | 15H || 53 | 35H || 85 | 55H || 117 | 75H |
| 22 | 16H || 54 | 36H || 86 | 56H || 118 | 76H |
| 23 | 17H || 55 | 37H || 87 | 57H || 119 | 77H |
| 24 | 18H || 56 | 38H || 88 | 58H || 120 | 78H |
| 25 | 19H || 57 | 39H || 89 | 59H || 121 | 79H |
| 26 | 1AH || 58 | 3AH || 90 | 5AH || 122 | 7AH |
| 27 | 1BH || 59 | 3BH || 91 | 5BH || 123 | 7BH |
| 28 | 1CH || 60 | 3CH || 92 | 5CH || 124 | 7CH |
| 29 | 1DH || 61 | 3DH || 93 | 5DH || 125 | 7DH |
| 30 | 1EH || 62 | 3EH || 94 | 5EH || 126 | 7EH |
| 31 | 1FH || 63 | 3FH || 95 | 5FH || 127 | 7FH |
+------+------++------+------++------+------++------+------+
D: decimal
H: hexadecimal
* Decimal values such as MIDI channel, bank select, and program change are listed as
one (1) greater than the values given in the above table.
* A 7-bit byte can express data in the range of 128 steps. For data where greater
precision is required, we must use two or more bytes.
For example, two hexadecimal numbers aa bbH expressing two 7-bit bytes would
indicate a value of aa x 128 + bb.
* In the case of values which have a ± sign, 00H = -64, 40H = ±0, and 7FH = +63, so
that the decimal expression would be 64 less than the value given in the above
chart. In the case of two types, 00 00H = -8192, 40 00H = ±0, and 7F 7FH = +8191.
For example if aa bbH were expressed as decimal, this would be
aa bbH - 40 00H = aa x 128 + bb - 64 x 128.
* Data marked “nibbled” is expressed in hexadecimal in 4-bit units. A value expressed
as a 2-byte nibble 0a 0bH has the value of a x 16 + b.
Examples of Actual MIDI Messages
<Example1> 92 3E 5F
9n is the note on status, and n is the MIDI channel number. Since 2H = 2, 3EH = 62,
and 5FH = 95, this is a note on message with MIDI CH = 3, note number 62 (note
name is D4), and velocity 95.
<Example2> CE 49
CnH is the Program Change status, and n is the MIDI channel number. Since EH = 14
and 49H = 73, this is a Program Change message with MIDI CH = 15, program number
74 (Flute in GS).
<Example3> EA 00 28
EnH is the Pitch Bend Change status, and n is the MIDI channel number. The 2nd byte
(00H = 0) is the LSB and the 3rd byte (28H = 40) is the MSB, but Pitch Bend Value is a
signed number in which 40 00H (= 64 x 128 + 0 = 8192) is 0, so this Pitch Bend Value
is 28 00H - 40 00H = 40 x 128 + 0 - (64 x 128 + 0) = 5120 - 8192 = -3072
Example of an Exclusive Message and Calculating a
Checksum
Roland Exclusive messages are transmitted with a checksum at the end (before F7)
to make sure that the message was correctly received. The value of the checksum is
determined by the address and data (or size) of the transmitted exclusive message.
How to Calculate the Checksum (Hexadecimal Num-
bers are Indicated by ‘H’)
The checksum is a value derived by adding the address, size and checksum itself and
inverting the lower 7 bits.
Here’s an example of how the checksum is calculated. We will assume that in the
exclusive message we are transmitting, the address is aa bb ccH and the data or size
is dd ee H.
aa + bb + cc + dd + ee + = sum
sum / 128 = quotient ... remainder
128 - remainder = checksum
(However, the checksum will be 0 if the remainder is 0.)
<Example1>
What is the decimal expression of 5AH?
From the preceding table, 5AH = 90
<Example2>
What is the decimal expression of the value 12 34H given as hexadecimal for each 7
bits?
From the preceding table, since 12H = 18 and 34H = 52
18 x 128 + 52 = 2356
<Example3>
What is the decimal expression of the nibbled value 0A 03 09 0D?
From the preceding table, since 0AH = 10, 03H = 3, 09H = 9, 0DH = 13
((10 x 16 + 3) x 16 + 9) x 16 + 13 = 41885
<Example4>
What is the nibbled expression of the decimal value 1258?
16) 1258
16) 78... 10
16) 4... 14
0... 4
Since from the preceding table, 0 = 00H, 4 = 04H, 14 = 0EH, 10 = 0AH, the answer is
00 04 0E 0AH.
12
Digital Hand Percussion
Model: HandSonic HPD-20
Function Transmitted Recognized Remarks
Basic
Channel
Mode
Note
Number
Velocity
After
Touch
Pitch Bend O O
Control
Change
Default
Changed
Default
Messages
Altered
: True Voice
Note On
Note O
Key’s
Channel’s
100, 101 X X RPN LSB, MSB
1–16, OFF
1–16, OFF
Mode 3
X
**************
0–127
**************
O 9nH v = 1–127
O 8nH v = 0–127
O *1
X
0, 32 O O Bank Select
1 X X Modulation
2 X X Breath Controller
4 O *2 O *2 Foot Controller
6, 38 X X Data Entry
7 X X Volume
10 X X Pan
11 X X Expression
12, 13 O *3 O *3 Eect Controller 1, 2
16, 17 O *4 O *4 General Purpose Controller 1, 2
18, 50 O *5 O *5 General Purpose Controller 3
19, 80 O *6 O *6 General Purpose Controller 4, 5
64 O *7 O *7 Hold 1
70–79 O *3 O *3 Sound Controller 1–10
81–83 O *3 O *3 General Purpose Controller 6–8
91 X X General Purpose Eect 1
93 X X General Purpose Eect 3
MIDI Implementation Chart
1–16, OFF
1–16, OFF
Mode 3
X
**************
0–127
0–127
O
O
O *1
X
Memorized
Date: AUG. 01, 2013
Version: 1.00
Program
Change
System Exclusive O O
System
Common
System
Real Time
Aux
Messages
Notes
: True Number
: Song Position
: Song Select
: Tune Request
: Clock
: Commands
: All Sound O
Reset All Controllers
:
: Local ON/OFF
: All Note O
: Active Sensing
: System Reset
O *1
**************
X
X
X
X
X
O
O
X
X
O
X
*1: OX is selectable.
*2: Position data for hi-hat control pedal
*3: Position data for D-BEAM or control information for Realtime Modify knob
*4: Strike position data for pads
*5: Open-close data for pads
*6: On/o information for Realtime Modify buttons
*7: On/o information for [Roll] button
O *1
0–127 Program Number: 1–128
X
X
X
X
X
O
O
X
O (123–127)
O
X
Mode 1 : OMNI ON, POLY Mode 2 : OMNI ON, MONO
Mode 3 : OMNI OFF, POLY Mode 4 : OMNI OFF, MONO
O : Yes
X : NO
13
Loading...
