Roland CUBE 60D Service Manual

Owner’s Manual

Thank you, and congratulations on your choice of the Roland CUBE-60 Guitar Amplifier.

These sections provide important information concerning the proper operation of the unit.
Additionally, in order to feel assured that you have gained a good grasp of every feature
provided by your new unit, Owner’s manual should be read in its entirety. The manual
should be saved and kept on hand as a convenient reference.

Before using this unit, carefully read the sections entitled

• IMPORTANT SAFETY INSTRUCTIONS (p. 2)

• USING THE UNIT SAFELY (p. 3–p. 4)

• IMPORTANT NOTES (p. 5).

This unit is equipped with a protection circuit.
The protection circuit helps ensure safety by operating when excessive input continues for
a long time while the device is at a location with a high ambient temperature. Sound drop­out may occur when the protection circuit is actuated during use.
Please read through the documentation carefully to ensure correct use.

Main Features

• 60-watt output, high-performance, DSP guitar amp with built-in 30 cm (12-inch) speaker.

• Offers nine types of COSM amps, including realistic modeling of seven of the most
popular guitar amps and two original amp types, “ACOUSTIC” and “DYNA AMP.”
The newly developed “DYNA AMP” lets you achieve previously unexperienced levels
of tonal variation based on your picking dynamics, for whole new levels of expression.

Composite Object Sound Modeling (
sound modeling technology. COSM analyzes the many factors that make up the
original sound, such as the electrical and physical characteristics of the original, and
then produces a digital model that can reproduce the same sound.

• Channel can be switched between “JC CLEAN” and “LEAD.” Channel switching can
be done via foot switch (optional).

• In addition to an easy-to-use, 3-band equalizer, the CUBE-60 also features a PRESENCE
knob, which you can use to create a wide variety of precisely defined sounds.

• Comes equipped with four effects types, chorus, flanger, phaser, and tremolo, along
with an independent system with the basic delay and reverb effects. You can also use
foot switches (optional) to switch these effects on and off.

• Equipped with a convenient “RECORDING OUT jack” handy for use in recording.
This output also functions as a headphone jack.
Also features LINE OUT, TUNER OUT, and EXT SPEAKER outs. These outputs can be
used for all kinds of performances, from recording to live gigs.

Copyright © 2004 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form
without the written permission of ROLAND CORPORATION.

COSM

) is Roland’s innovative and powerful

30

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

ATTENTION: RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the product.

INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS.

IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS

WARNING - When using electric products, basic precautions should always be followed, including the following:

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any of the ventilation openings. Install in
accordance with the manufacturers instructions.

8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. When the provided
plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.

WARNING:
IMPORTANT:

As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying

the terminals in your plug, proceed as follows:

The wire which is coloured GREEN-AND-YELLOW must be connected to the terminal in the plug which is marked by the

letter E or by the safety earth symbol or coloured GREEN or GREEN-AND-YELLOW.

The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or coloured BLACK.
The wire which is coloured BROWN must be connected to the terminal which is marked with the letter L or coloured RED.

THIS APPARATUS MUST BE EARTHED
THE WIRES IN THIS MAINS LEAD ARE COLOURED IN ACCORDANCE WITH THE FOLLOWING CODE.
GREEN-AND-YELLOW: EARTH, BLUE: NEUTRAL, BROWN: LIVE

For the U.K.

10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.

11. Only use attachments/accessories specified by the
manufacturer.

12. Never use with a cart, stand, tripod, bracket,
or table except as specified by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or when
unused for long periods of time.

14. Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.

2

USING THE UNIT SAFELY

Used for instructions intended to alert
the user to the risk of death or severe
injury should the unit be used
improperly.

Used for instructions intended to alert
the user to the risk of injury or material
damage should the unit be used
improperly.

* Material damage refers to damage or

other adverse effects caused with
respect to the home and all its
furnishings, as well to domestic
animals or pets.

001

• Before using this unit, make sure to read the
instructions below, and the Owner’s Manual.

..........................................................................................................

002a

• Do not open or perform any internal modifica­tions on the unit.

..........................................................................................................

003

• Do not attempt to repair the unit, or replace parts
within it (except when this manual provides
specific instructions directing you to do so). Refer
all servicing to your retailer, the nearest Roland
Service Center, or an authorized Roland
distributor, as listed on the “Information” page.

..........................................................................................................

004

• Never use or store the unit in places that are:

• Subject to temperature extremes (e.g., direct

sunlight in an enclosed vehicle, near a heating
duct, on top of heat-generating equipment); or are

• Damp (e.g., baths, washrooms, on wet floors); or are

• Humid; or are

• Exposed to rain; or are

• Dusty; or are

• Subject to high levels of vibration.

..........................................................................................................

007

• Make sure you always have the unit placed so it is
level and sure to remain stable. Never place it on
stands that could wobble, or on inclined surfaces.

..........................................................................................................

008a

• The unit should be connected to a power supply
only of the type described in the operating instruc­tions, or as marked on the rear side of unit.

..........................................................................................................

009

• Do not excessively twist or bend the power cord,
nor place heavy objects on it. Doing so can
damage the cord, producing severed elements and
short circuits. Damaged cords are fire and shock
hazards!

..........................................................................................................

The symbol alerts the user to important instructions
or warnings.The specific meaning of the symbol is
determined by the design contained within the
triangle. In the case of the symbol at left, it is used for
general cautions, warnings, or alerts to danger.

The symbol alerts the user to items that must never
be carried out (are forbidden). The specific thing that
must not be done is indicated by the design contained
within the circle. In the case of the symbol at left, it
means that the unit must never be disassembled.

The ● symbol alerts the user to things that must be
carried out. The specific thing that must be done is
indicated by the design contained within the circle. In
the case of the symbol at left, it means that the power­cord plug must be unplugged from the outlet.

010

• This unit, either alone or in combination with an
amplifier and headphones or speakers, may be
capable of producing sound levels that could
cause permanent hearing loss. Do not operate for
a long period of time at a high volume level, or at
a level that is uncomfortable. If you experience
any hearing loss or ringing in the ears, you should
immediately stop using the unit, and consult an
audiologist.

..........................................................................................................

011

• Do not allow any objects (e.g., flammable material,
coins, pins); or liquids of any kind (water, soft
drinks, etc.) to penetrate the unit.

..........................................................................................................

012a:

• Immediately turn the power off, remove the
power cord from the outlet, and request servicing
by your retailer, the nearest Roland Service
Center, or an authorized Roland distributor, as
listed on the “Information” page when:

• The power-supply cord, or the plug has been

damaged; or

• If smoke or unusual odor occurs

• Objects have fallen into, or liquid has been

spilled onto the unit; or

• The unit has been exposed to rain (or otherwise

has become wet); or

• The unit does not appear to operate normally or

exhibits a marked change in performance.

..........................................................................................................

013

• In households with small children, an adult
should provide supervision until the child is
capable of following all the rules essential for the
safe operation of the unit.

..........................................................................................................

014

• Protect the unit from strong impact.

(Do not drop it!)

..........................................................................................................

3

015

• Do not force the unit’s power-supply cord to share
an outlet with an unreasonable number of other
devices. Be especially careful when using
extension cords—the total power used by all
devices you have connected to the extension
cord’s outlet must never exceed the power rating
(watts/amperes) for the extension cord. Excessive
loads can cause the insulation on the cord to heat
up and eventually melt through.

..........................................................................................................

016

• Before using the unit in a foreign country, consult
with your retailer, the nearest Roland Service
Center, or an authorized Roland distributor, as
listed on the “Information” page.

..........................................................................................................

026

• Do not put anything that contains water (e.g.,
flower vases) on this unit. Also, avoid the use of
insecticides, perfumes, alcohol, nail polish, spray
cans, etc., near the unit. Swiftly wipe away any
liquid that spills on the unit using a dry, soft cloth.

..........................................................................................................

101a

• The unit should be located so that its location or
position does not interfere with its proper venti­lation.

..........................................................................................................

102a

• Always grasp only the plug on the power-supply
cord when plugging into, or unplugging from an
outlet.

..........................................................................................................

103a:

• At regular intervals, you should unplug the power
plug and clean it by using a dry cloth to wipe all
dust and other accumulations away from its prongs.
Also, disconnect the power plug from the power
outlet whenever the unit is to remain unused for an
extended period of time. Any accumulation of dust
between the power plug and the power outlet can
result in poor insulation and lead to fire.

..........................................................................................................

104

• Try to prevent cords and cables from becoming
entangled. Also, all cords and cables should be
placed so they are out of the reach of children.

..........................................................................................................

106

• Never climb on top of, nor place heavy objects on
the unit.

..........................................................................................................

107a

• Never handle the power cord or its plug with wet
hands when plugging into, or unplugging from,
an outlet.

..........................................................................................................

108a

• Before moving the unit, disconnect the power
plug from the outlet, and pull out all cords from
external devices.

..........................................................................................................

109a

• Before cleaning the unit, turn off the power and
unplug the power cord from the outlet (P. 5).

..........................................................................................................

110a

• Whenever you suspect the possibility of lightning
in your area, pull the plug on the power cord out
of the outlet.

..........................................................................................................

For EU Countries

This product complies with the requirements of European Directives EMC 89/336/EEC and LVD 73/23/EEC.

For the USA

FEDERAL COMMUNICATIONS COMMISSION

RADIO FREQUENCY INTERFERENCE STATEMENT

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:

– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.

Unauthorized changes or modification to this system can void the users authority to operate this equipment.
This equipment requires shielded interface cables in order to meet FCC class B Limit.

For Canada

NOTICE

This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.

AVIS

Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.

4

IMPORTANT NOTES

291b

In addition to the items listed under “IMPORTANT SAFETY INSTRUCTIONS” and “USING THE UNIT SAFELY” on pages 2,
3 and 4, please read and observe the following:

Power Supply

301

• Do not connect this unit to same electrical outlet that is being
used by an electrical appliance that is controlled by an
inverter (such as a refrigerator, washing machine,
microwave oven, or air conditioner), or that contains a
motor. Depending on the way in which the electrical
appliance is used, power supply noise may cause this unit to
malfunction or may produce audible noise. If it is not
practical to use a separate electrical outlet, connect a power
supply noise filter between this unit and the electrical outlet.

307

• Before connecting this unit to other devices, turn off the
power to all units. This will help prevent malfunctions
and/or damage to speakers or other devices.

308

• Although the LEDs are switched off when the POWER
switch is switched off, this does not mean that the unit has
been completely disconnected from the source of power. If
you need to turn off the power completely, first turn off
the POWER switch, then unplug the power cord from the
power outlet. For this reason, the outlet into which you
choose to connect the power cord’s plug should be one
that is within easy reach.

Placement

351

• Using the unit near power amplifiers (or other equipment
containing large power transformers) may induce hum. To
alleviate the problem, change the orientation of this unit; or
move it farther away from the source of interference.

352a

• This device may interfere with radio and television reception.
Do not use this device in the vicinity of such receivers.

352b

• Noise may be produced if wireless communications devices,
such as cell phones, are operated in the vicinity of this unit.
Such noise could occur when receiving or initiating a call, or
while conversing. Should you experience such problems,
you should relocate such wireless devices so they are at a
greater distance from this unit, or switch them off.

354b

• Do not expose the unit to direct sunlight, place it near
devices that radiate heat, leave it inside an enclosed
vehicle, or otherwise subject it to temperature extremes.
Also, do not allow lighting devices that normally are used
while their light source is very close to the unit (such as a
piano light), or powerful spotlights to shine upon the
same area of the unit for extended periods of time.
Excessive heat can deform or discolor the unit.

355b

• When moved from one location to another where the
temperature and/or humidity is very different, water
droplets (condensation) may form inside the unit. Damage
or malfunction may result if you attempt to use the unit in
this condition. Therefore, before using the unit, you must
allow it to stand for several hours, until the condensation
has completely evaporated.

356

• Do not allow rubber, vinyl, or similar materials to remain
on the unit for long periods of time. Such objects can
discolor or otherwise harmfully affect the finish.

359

• Do not paste stickers, decals, or the like to this instrument.
Peeling such matter off the instrument may damage the
exterior finish.

Maintenance

401a

• For everyday cleaning wipe the unit with a soft, dry cloth
or one that has been slightly dampened with water. To
remove stubborn dirt, use a cloth impregnated with a
mild, non-abrasive detergent. Afterwards, be sure to wipe
the unit thoroughly with a soft, dry cloth.

402

• Never use benzine, thinners, alcohol or solvents of any kind,
to avoid the possibility of discoloration and/or deformation.

Additional Precautions

553

• Use a reasonable amount of care when using the unit’s
buttons, sliders, or other controls; and when using its jacks
and connectors. Rough handling can lead to malfunctions.

556

• When connecting / disconnecting all cables, grasp the
connector itself—never pull on the cable. This way you
will avoid causing shorts, or damage to the cable’s
internal elements.

557

•A small amount of heat will radiate from the unit during
normal operation.

558a

• To avoid disturbing your neighbors, try to keep the unit’s
volume at reasonable levels. You may prefer to use
headphones, so you do not need to be concerned about
those around you (especially when it is late at night).

559a

• When you need to transport the unit, package it in the box
(including padding) that it came in, if possible. Otherwise,
you will need to use equivalent packaging materials.

921

• To prevent malfunction and/or damage to speakers or
other devices, always turn down the volume, and turn off
the power on all devices before making any connections.

941

• Once the connections have been completed, turn on power
to your various devices in the order specified. By turning
on devices in the wrong order, you risk causing
malfunction and/or damage to speakers and other devices.

1. Turn on the device connected to the CUBE-60’s input
jack.

2. Turn on the CUBE-60.

3. Switch on any equipment connected to the CUBE-60’s
LINE OUT and RECORDING OUT/PHONES jacks.

Turn off the devices in the reverse order to which they
were switched on.

• Wrap the power cord around the cord hook when trans­porting or storing the unit.

• Do not insert hands, fingers, etc, into the openings in the
unit's rear panel. In particular, if the unit is to used in
households with small children, always provide adult
supervision to ensure that children keep their hands and
feet out of these openings.

5

Panel Descriptions

Control Panel

fig.01

98

16

12

14131110

31 4 5 6

2

1. INPUT Jack

Connect your guitar here.

2. SELECT Switch

Switches you between the JC CLEAN and LEAD channels.
You can confirm which channel is selected by checking the

indicator’s color (JC CLEAN: green; LEAD: red).
The channel can be switched using the optional BOSS FS-5U
foot switch.

JC CLEAN Channel

This is a model of Roland’s famous JC-120 Jazz Chorus guitar
amplifier.
The ultra-clean, ultra-flat sound offers a smooth. This becomes
more effective when used in combination with a multi effector.

3. BRIGHT Switch

Creates a sparkling midrange and high end for a crisp and
distinct sound.

This is perfect for chord strumming with humbucking pickups.

4. VOLUME Knob

Adjusts the JC CLEAN channel volume. On the CUBE-60,
distortion is gradually added as you turn this knob to the
right, producing a crunch sound as the knob is turned up
near maximum.

LEAD Channel

5. Type Switch

You can select from the following eight amp types:

ACOUSTIC

This is an original amp type included with the acoustic
simulator. Turns the sounds from your electric guitar into a
clear, refined acoustic guitar sound.

Using this type together with a single coil pickup in the
front position provides optimum sound quality. If using
a humbucking pickup, slightly turn down the
equalizer’s BASS and MIDDLE settings.

7

BLACK PANEL

This is modeled on the classic Fender Twin Reverb amplifier,
used in a wide variety of musical styles, from country to blues,
jazz and rock. Exhibiting rich lows and a bright high end.

BRIT COMBO

This is modeled on the Vox AC-30TB, the rock amplifier that
created the Liverpool sound of the ’60s. It can produce a
broad range of sounds, from clean to overdrive.

TWEED

This is modeled on the vintage Tweed Fender Bassman 4x10
Combo. The amplifier’s four 10-inch speakers produce a
clear upper-midrange with a fat low end, and its unique
crunch tones make it a favorite of blues-rock guitarists.

CLASSIC STACK

This is modeled on the sound and response of a Marshall
JMP1987. Used extensively in hard rock during the 1970s,
this is truly the perfect amp for the “top rock” guitar sound.

METAL STACK

This is modeled on the Peavey EVH-5150. This is the high
gain amp, so even at low volumes, you can still get heavy
distortion and sustain.

R-FIER STACK

This is modeled on the MESA/Boogie Rectifier. This super
high gain amp is capable of producing slash metal, grunge,
and a wide range of other lead sounds.

DYNA AMP

This is an original amp sound that lets the player create
previously unobtainable tonal changes according to the
picking strength. Soft picking produces a transparent clean
amp sound, while hard picking results in a deeply distorted
high-gain amp sound. Once the sound is distorted, the tone
then changes according to the force used in picking, greatly
expanding your range of expression.

Setting the GAIN knob to the optimal position provides
the greatest effect.
Start by setting the GAIN knob to the center position,
then adjust the knob so that a clean tone is obtained
with soft picking and deep distortion is obtained with
hard picking.

“Sample Settings” (p. 10; Dynamic Style)

15

6

Panel Descriptions

* All product names mentioned in this document are trademarks or

registered trademarks of their respective owners, and are not
related to Roland Corporation.
In this manual, these names are used as appropriate ways to
indicate sounds that are simulated using COSM technology.

6. GAIN Knob

Adjusts the LEAD channel’s distortion level.

7. VOLUME Knob

Adjusts the LEAD channel volume.

EQUALIZER

8. BASS Knob

Adjusts the tone of the lower range.

9. MIDDLE Knob

Adjusts the tone of the midrange.

10.TREBLE Knob

Adjusts the tone of the upper range.

* No sound will be produced when BASS, MIDDLE, and TREBLE

knobs are all set to 0 while the Type switch is set to BLACK
PANEL or TWEED.

PRESENCE

fig.04

PHASER

This effect adds a variable phase­shifted signal to the direct sound,
giving the sound a swirling character.

fig.05

TREMOLO

Tremolo is an effect that creates a
cyclic change in volume.

DELAY/REVERB

13

. DELAY/REVERB Knob

Turn this knob to DELAY or REVERB to switch to that effect.

Turn the knob to adjust the amount of effect applied.
The ON indicator lights up when
turned on, and goes out when
off. You can also turn
an optional foot switch (the BOSS FS-5U).

* Graduations for DELAY, REVERB on a panel are for reference.

Be sure to check the sound as you adjust the effects.

fig.05a

DELAY

Turn the knob to change the time and
amount of delay effects.

DELAY or REVERB

DELAY or REVERB

DELAY or REVERB

on and off using

is turned

is

. PRESENCE Knob

11

Gives the midrange and high end a more lustrous contour.
Very effective when you want to give the sound a good
feeling of airiness.

EFX (Effects)

. EFX (Effects) Knob

12

Turn this knob to chorus, flanger, phaser, or tremolo to
select the corresponding effect. Turn the knob to adjust the
amount of effect applied.
The ON indicator lights up when EFX is turned on, and
goes out when EFX is turned off. You can also turn EFX on
and off using an optional foot switch (the BOSS FS-5U).

* Graduations for CHORUS, FLANGER, PHASER, TREMOLO

on a panel are for reference. Be sure to check the sound as you
adjust the effects.

fig.02

CHORUS

In this effect, a slightly detuned sound
is added to the original sound, giving
the sound greater breadth and
fullness.

fig.03

FLANGER

This creates a flanging effect that
creates a sort of spinning sensation
with the sound.

fig.05b

REVERB

Turn the knob to adjust the reverb level.

. RECORDING OUT/PHONES Jack

14

When Using RECORDING OUT

Connect to a recorder or other recording device.
Features COSM speaker modeling, allowing you to use the
CUBE-60 as a high-performance amp simulator.

When Using Headphones

Connect headphones to this jack.
The COSM speaker modeling allows the guitar amp to
produce sounds with real punch.

* No sound is output from the CUBE-60’s speaker or any external

speaker when the RECORDING OUT/PHONES jack is in use.

15

. POWER Switch

Turn the power on and off.

* This unit is equipped with a protection circuit. A brief interval (a few

seconds) after power up is required before the unit will operate normally.

* Always make sure to have the volume level turned down before

switching on power. Even with the volume all the way down, you
may still hear some sound when the power is switched on, but this
is normal, and does not indicate a malfunction.

16

. Power Indicator

This indicator lights when the unit is turned on.

7

Panel Descriptions

INPUT

Mixer

Speaker

cable

Tuner

External Speaker

INPUT

INPUT

INPUT

FS-5U FS-5U FS-5U

31 42

Rear Panel

1. FOOT SW (Foot Switch) Jack

Foot switches (the optional BOSS FS-5U) are connected here.

* Set the polarity switch as shown below.

fig.06

Polarity switch

(CH SELECT)

Switches JC CLEAN/LEAD channels.

(EFX)

Switches on and off of EFX.

(DELAY/REVERB)

Switches on and off of DELAY/REVERB.

2. EXT SPEAKER (External Speaker) Jack

You can connect external speaker here.

When connected, sounds are played from both the CUBE-60
and the external speakers.

* When connecting to an external speaker, make sure the speaker

conforms to the following specifications.
Impedance: 8
Allowable power input: 60 watts minimum

Ω

maximum

* Only use speaker cable to connect the speaker. Do not use any

shielded cable designed for use with guitars.

* No sound is output from the CUBE-60’s speaker or any external

speaker when the RECORDING OUT/PHONES jack is in use.

3. LINE OUT Jack

Connects to a PA system, recorder, or other external system.

The COSM speaker modeling allows the guitar amp to
produce sounds with real punch.

Use this when using the unit with an external PA system or
when line-recording performances while listening to the
sound from the CUBE-60’s speaker.

Adjust the output level with the JC CLEAN channel or
LEAD channel VOLUME knob.

4. TUNER OUT Jack

Connect tuner to this jack.

* The output from here is unaffected by the CUBE-60’s knob and

switch settings.

................................................................................................................

Q:

The volume level of the instrument connected to the CUBE­60 is too low.

A:

Could you be using a connection cable that contains a resistor?
Use a connection cable that does not contain a resistor.

................................................................................................................

8

Sample Settings

Alternative Metal

SELECT : LEAD

Space Clean

SELECT : JC CLEANBRIGHT : ON or OFF

The perfect sound for heavy, sharp riffs.

Select the high-gain R-FIER amp, then use the equalizer to
boost the low end even more.

You can add even more to the distortion’s edge by raising
the presence.

Used with a humbucking pickup in the rear position, it
results in an extreme distortion effect.

Plus, you can add a long delay to use this as a lead sound
with great sustain.

This is a transparent sound using spacial effects.

Select the JC CLEAN amp, modeled on the Roland JC-120,
then add chorus and long delay.

Using this setting with a guitar equipped with single coil
pickups makes beautiful sounding arpeggios and chord
strumming.

If using a humbucking pickup, turn the BRIGHT switch to
ON to achieve a bright, sparkling sound.

Depending on the phrase being played, it can be effective
to set the delay sound’s delay time slightly slower than the
phrase’s tempo.

Swamp Crunch

Classic Rock

SELECT : LEAD

SELECT : LEAD

This is a blues sound found in vintage amps.

The boosted midrange is a particular characteristic of the
TWEED amp.

By adjusting the TREBLE knob, you can emphasize the
picking’s attack sound.

To create a fat, sweet sound, reduce the presence a little.

To produce a transparent and sharp crunch sound, lower
the midrange and boost the presence slightly.

You can also control the tube amp’s characteristic sustain
by adjusting the GAIN knob.

This is a 70s-style rock sound.

Turning up the gain produces a powerful rock sound in all
riffs and solos.

A powerful low end is a characteristic of the sound emitted
by the surfaces of the cabinet, so you can turn up the
equalizer knobs, especially the BASS knob, and increase
the presence to produce a sound with great punch.

Turning the GAIN knob and equalizer all the way up
produces an even more powerful, driving sound.

Turning down the GAIN knob is also a perfect way to get a
sharp crunch sound.

9

Sample Settings

Dynamic Style

Country Twang

SELECT : LEAD

SELECT : LEAD

DYNA AMP is an original amp that uses relative picking
strength to create changes in distortion depth.

First, adjust the GAIN knob so that a clean tone is obtained
with soft picking and deep distortion is obtained when you
pick hard.

Now, mixing arpeggios played with a gentle touch along
with firmly picked chords and solos results in a guitar
sound with huge dynamics.

Now, to create a broader, more open sound, cut the
midrange and raise the low end and presence.

Using this in combination with the EFX and delay and
reverb creates a sound with an even greater feeling of scale.

A dry, distinctive country sound.
The BLACK PANEL amp has a powerful midrange

supported by a thick, solid low end, providing a clean
sound that is punchy and sweet.

By adjusting the sound while maintaining the balance
between the low and high ends, and in some cases cutting
back on the midrange, you bring out the guitar's bright
resonance even more.

Adding deep tremolo and reverb creates a good effect on
guitars equipped with single-coil pickups.

On guitars equipped with humbucking pickups, turning
down the highs creates a sweet sound that is perfectly
matched for jazz and similar genres.

Mersey Beat

Setting Name:

BRIGHT switch

ON

OFF

SELECT : LEAD

SELECT switch

JC CLEAN

LEAD

This is the famous Liverpool sound from the past.

This sound features a mild distortion that still lets all the
notes in a chord come through clearly and distinctly.

Raise the midrange and presence on the BRIT COMBO
amp to create a lively, energetic sound.

Adjust the GAIN knob so that sound does not distort too
much when you play chords.

Use of a rear pickup provides a powerful sound with no
muddiness, producing a beautiful resonance when mixing
open strings with chords.

The sound may distort excessively when a guitar equipped
with humbucking pickups or other high-output guitar is
used. If this occurs, you can reduce the gain in order to get
a good balance between the guitar sound and the
distortion sound, or alternatively, you can adjust the sound
by cutting back the low end.

Use this for keeping notes regarding your settings.

.....................................................................................................

.....................................................................................................

.....................................................................................................

.....................................................................................................

.....................................................................................................

.....................................................................................................

.....................................................................................................

.....................................................................................................

10

Main Specifications

Rated Power Output

60 W

Nominal Input Level (1 kHz)

INPUT: -10 dBu/1 M

Ω

Speaker

30 cm (12 inches)

Controls

POWER Switch, SELECT Switch

<JC CLEAN Channel>

BRIGHT Switch, VOLUME Knob

<LEAD Channel>

TYPE Switch (ACOUSTIC, BLACK PANEL, BRIT COMBO,
TWEED, CLASSIC STACK, METAL STACK, R-FIER STACK,
DYNA AMP), GAIN Knob, VOLUME Knob

<EQUALIZER>

BASS Knob, MIDDLE Knob, TREBLE Knob

<PRESENCE>

PRESENCE Knob

<EFX>

EFX Knob (CHORUS, FLANGER, PHASER, TREMOLO)

<DELAY/REVERB>

DELAY/REVERB Knob

Indicators

JC CLEAN Channel, LEAD Channel, EFX, DELAY/REVERB,
POWER

Connectors

INPUT Jack (1/4” phone type)
RECORDING OUT/PHONES Jack (Stereo 1/4” phone type)
FOOT SW Jack (CH SELECT, EFX, DELAY/REVERB) (1/4”
phone type)
EXT SPEAKER Jack (1/4” phone type)
LINE OUT Jack (1/4” phone type)
TUNER OUT Jack (1/4” phone type)

Power Supply

AC 117 V, AC 230 V, AC 240 V (50/60 Hz)
AC 220 V (60 Hz)

Power Consumption

60 W

Dimensions

410 (W) x 275 (D) x 440 (H) mm
16-3/16 (W) x 10-7/8 (D) x 17-3/8 (H) inches

Weight

14.5 kg / 32 lbs

Accessory

Owner’s Manual

Option

Foot Switch FS-5U (BOSS)

*0 dBu = 0.775 Vrms

* In the interest of product improvement, the specifications and/or

appearance of this unit are subject to change without prior notice.

Block Diagram

INPUT

SELECT

JC CLEAN

LEAD

ACOUSTIC

BLACK PANEL

BRIT COMBO

TWEED

CLASSIC STACK

METAL STACK

R-FIER STACK

DYNA AMP

EFX

DELAY/

REVERB

POWER AMP

CABINET &
SPEAKER
SIMULATOR

* No sound is played through the unit’s speaker and

external speaker while the PHONES jack is in use.

SPEAKER

EXT SPEAKER

LINE OUT

RECORDING OUT/
PHONES

TUNER OUT

11

Information

When you need repair service, call your nearest Roland Service Center or authorized Roland distributor in your country as
shown below.

AFRICA

AFRICA

EGYPT

Al Fanny Trading Office

9, EBN Hagar A1 Askalany Street,
ARD E1 Golf, Heliopolis,
Cairo 11341, EGYPT
TEL: [phone]

REUNION

Maison FO - YAM Marcel

25 Rue Jules Hermann,
Chaudron - BP79 97 491
Ste Clotilde Cedex,
REUNION ISLAND
TEL: [phone]

SOUTH AFRICA

That Other Music Shop
(PTY) Ltd.

11 Melle St., Braamfontein,
Johannesbourg, SOUTH AFRICA

P.O.Box 32918, Braamfontein 2017
Johannesbourg, SOUTH AFRICA
TEL: [phone]

Paul Bothner (PTY) Ltd.

17 Werdmuller Centre,
Main Road, Claremont 7708
SOUTH AFRICA

P.O.BOX 23032, Claremont 7735,
SOUTH AFRICA
TEL: [phone]

ASIA

CHINA

Roland Shanghai Electronics
Co.,Ltd.

5F. No.1500 Pingliang Road
Shanghai 200090, CHINA
TEL: [phone]

Roland Shanghai Electronics
Co.,Ltd.

(BEIJING OFFICE)

10F. No.18 Anhuaxili
Chaoyang District, Beijing 100011
CHINA
TEL: [phone]

Roland Shanghai Electronics
Co.,Ltd.

(GUANGZHOU OFFICE)

2/F., No.30 Si You Nan Er Jie Yi
Xiang, Wu Yang Xin Cheng,
Guangzhou 510600, CHINA
Tel: [phone]

HONG KONG

Tom Lee Music Co., Ltd.
Service Division

22-32 Pun Shan Street, Tsuen
Wan, New Territories,
HONG KONG
TEL: [phone]

Parsons Music Ltd.

8th Floor, Railway Plaza, 39
Chatham Road South, T.S.T,
Kowloon, HONG KONG
TEL: [phone]

INDIA

Rivera Digitec (India) Pvt. Ltd.

409, Nirman Kendra Mahalaxmi
Flats Compound Off. Dr. Edwin
Moses Road, Mumbai-400011,
INDIA
TEL: [phone]

INDONESIA

PT Citra IntiRama

J1. Cideng Timur No. 15J-150
Jakarta Pusat
INDONESIA
TEL: [phone]

KOREA

Cosmos Corporation

1461-9, Seocho-Dong,
Seocho Ku, Seoul, KOREA
TEL: [phone]

MALAYSIA

BENTLEY MUSIC SDN BHD

140 & 142, Jalan Bukit Bintang
55100 Kuala Lumpur,MALAYSIA
TEL: [phone]

PHILIPPINES

G.A. Yupangco & Co. Inc.

339 Gil J. Puyat Avenue
Makati, Metro Manila 1200,
PHILIPPINES
TEL: [phone]

SINGAPORE

Swee Lee Company

150 Sims Drive,
SINGAPORE 387381
TEL: [phone]

CRISTOFORI MUSIC PTE
LTD

Blk 3014, Bedok Industrial Park E,
#02-2148, SINGAPORE 489980
TEL: [phone]

TAIWAN

ROLAND TAIWAN
ENTERPRISE CO., LTD.

Room 5, 9fl. No. 112 Chung Shan
N.Road Sec.2, Taipei, TAIWAN,
R.O.C.
TEL: [phone]

THAILAND

Theera Music Co. , Ltd.

330 Verng NakornKasem, Soi 2,
Bangkok 10100, THAILAND
TEL: [phone]

VIETNAM

Saigon Music

Suite DP-8
40 Ba Huyen Thanh Quan Street
Hochiminh City, VIETNAM
Tel: [phone]

AUSTRALIA/
NEW ZEALAND

AUSTRALIA

Roland Corporation
Australia Pty., Ltd.

38 Campbell Avenue
Dee Why West. NSW 2099
AUSTRALIA
TEL: [phone]

NEW ZEALAND

Roland Corporation Ltd.

32 Shaddock Street, Mount Eden,
Auckland, NEW ZEALAND
TEL: [phone]

CENTRAL/LATIN
AMERICA

ARGENTINA

Instrumentos Musicales S.A.

Av.Santa Fe 2055
(1123) Buenos Aires
ARGENTINA
TEL: [phone]

BRAZIL

Roland Brasil Ltda

Rua San Jose, 780 Sala B
Parque Industrial San Jose
Cotia - Sao Paulo - SP, BRAZIL
TEL: [phone]

COSTA RICA

JUAN Bansbach
Instrumentos Musicales

Ave.1. Calle 11, Apartado 10237,
San Jose, COSTA RICA
TEL: [phone]

CHILE

Comercial Fancy S.A.

Rut.: 96.919.420-1
Nataniel Cox #739, 4th Floor
Santiago - Centro, CHILE
TEL: [phone]

EL SALVADOR

OMNI MUSIC

75 Avenida Norte y Final
Alameda Juan Pablo ,
Edificio No.4010 San Salvador,
EL SALVADOR
TEL: [phone]

MEXICO

Casa Veerkamp, s.a. de c.v.

Av. Toluca No. 323, Col. Olivar
de los Padres 01780 Mexico D.F.
MEXICO
TEL: [phone]

PANAMA

SUPRO MUNDIAL, S.A.

Boulevard Andrews, Albrook,
Panama City, REP. DE PANAMA
TEL: [phone]

PARAGUAY

Distribuidora De
Instrumentos Musicales

J.E. Olear y ESQ. Manduvira
Asuncion PARAGUAY
TEL: [phone]

URUGUAY

Todo Musica S.A.

Francisco Acuna de Figueroa 1771
C.P.: 11.800
Montevideo, URUGUAY
TEL: [phone]

VENEZUELA

Musicland Digital C.A.

Av. Francisco de Miranda,
Centro Parque de Cristal, Nivel
C2 Local 20 Caracas
VENEZUELA
TEL: [phone]

EUROPE

AUSTRIA

Roland Austria GES.M.B.H.

Siemensstrasse 4, P.O. Box 74,
A-6063 RUM, AUSTRIA
TEL: [phone]

BELGIUM/HOLLAND/
LUXEMBOURG

Roland Benelux N. V.

Houtstraat 3, B-2260, Oevel
(Westerlo) BELGIUM
TEL: [phone]

CZECH REP.

K-AUDIO

Kardasovska 626.
CZ-198 00 Praha 9,
CZECH REP.
TEL: [phone]

DENMARK

Roland Scandinavia A/S

Nordhavnsvej 7, Postbox 880,
DK-2100 Copenhagen
DENMARK
TEL: [phone]

FRANCE

Roland France SA

4, Rue Paul Henri SPAAK,
Parc de l'Esplanade, F 77 462 St.
Thibault, Lagny Cedex FRANCE
TEL: [phone]

FINLAND

Roland Scandinavia As,
Filial Finland

Elannontie 5
FIN-01510 Vantaa, FINLAND
TEL: [phone]

GERMANY

Roland Elektronische
Musikinstrumente HmbH.

Oststrasse 96, 22844 Norderstedt,
GERMANY
TEL: [phone]

GREECE

STOLLAS S.A.
Music Sound Light

155, New National Road
Patras 26442, GREECE
TEL: [phone]

HUNGARY

Roland East Europe Ltd.

Warehouse Area ‘DEPO’ Pf.83
H-2046 Torokbalint, HUNGARY
TEL: [phone]

IRELAND

Roland Ireland

G2 Calmount Park, Calmount
Avenue, Dublin 12
Republic of IRELAND
TEL: [phone]

ITALY

Roland Italy S. p. A.

Viale delle Industrie 8,
20020 Arese, Milano, ITALY
TEL: [phone]

NORWAY

Roland Scandinavia Avd.
Kontor Norge

Lilleakerveien 2 Postboks 95
Lilleaker N-0216 Oslo
NORWAY
TEL: [phone]

POLAND

MX MUSIC SP.Z.O.O.

UL. Gibraltarska 4.
PL-03664 Warszawa POLAND
TEL: [phone]

PORTUGAL

Tecnologias Musica e Audio,
Roland Portugal, S.A.

Cais Das Pedras, 8/9-1 Dto
4050-465 PORTO
PORTUGAL
TEL: [phone]

ROMANIA

FBS LINES

Piata Libertatii 1,
535500 Gheorgheni, ROMANIA
TEL: [phone]

RUSSIA

MuTek

3-Bogatyrskaya Str. 1.k.l
107 564 Moscow, RUSSIA
TEL: [phone]

SPAIN

Roland Electronics
de España, S. A.

Calle Bolivia 239, 08020
Barcelona, SPAIN
TEL: [phone]

SWEDEN

Roland Scandinavia A/S
SWEDISH SALES OFFICE

Danvik Center 28, 2 tr.
S-131 30 Nacka SWEDEN
TEL: [phone]

SWITZERLAND

Roland (Switzerland) AG

Landstrasse 5, Postfach,
CH-4452 Itingen,
SWITZERLAND
TEL: [phone]

UKRAINE

TIC-TAC

Mira Str. 19/108
P.O. Box 180
295400 Munkachevo, UKRAINE
TEL: [phone]

UNITED KINGDOM

Roland (U.K.) Ltd.

Atlantic Close, Swansea
Enterprise Park, SWANSEA
SA7 9FJ,
UNITED KINGDOM
TEL: [phone]

MIDDLE EAST

BAHRAIN

Moon Stores

No.16, Bab Al Bahrain Avenue,
P.O.Box 247, Manama 304,
State of BAHRAIN
TEL: 211 005

CYPRUS

Radex Sound Equipment Ltd.

17, Diagorou Street, Nicosia,
CYPRUS
TEL: [phone]

IRAN

MOCO, INC.

No.41 Nike St., Dr.Shariyati Ave.,
Roberoye Cerahe Mirdamad
Tehran, IRAN
TEL: [phone]

ISRAEL

Halilit P. Greenspoon &
Sons Ltd.

8 Retzif Ha'aliya Hashnya St.
Tel-Aviv-Yafo ISRAEL
TEL: [phone]

JORDAN

AMMAN Trading Agency

245 Prince Mohammad St.,
Amman 1118, JORDAN
TEL: [phone]

KUWAIT

Easa Husain Al Yousifi Est.

Abdullah Salem Street,
Safat, KUWAIT
TEL: [phone]

LEBANON

Chahine S.A.L.

Gerge Zeidan St., Chahine Bldg.,
Achrafieh, P.O.Box: 16-5857
Beirut, LEBANON
TEL: [phone]

QATAR

Al Emadi Co. (Badie Studio
& Stores)

P.O. Box 62, Doha, QATAR
TEL: [phone]

SAUDI ARABIA

aDawliah Universal
Electronics APL

Corniche Road, Aldossary Bldg.,
1st Floor, Alkhobar,
SAUDI ARABIA

P.O.Box 2154, Alkhobar 31952
SAUDI ARABIA
TEL: [phone]

SYRIA

Technical Light & Sound
Center

Khaled Ebn Al Walid St.
Bldg. No. 47, P.O.BOX 13520,
Damascus, SYRIA
TEL: [phone]

TURKEY

Ant Muzik Aletleri Ithalat
Ve Ihracat Ltd Sti

Siraselviler Caddesi Siraselviler
Pasaji No:74/20
Taksim - Istanbul, TURKEY
TEL: [phone]

U.A.E.

Zak Electronics & Musical
Instruments Co. L.L.C.

Zabeel Road, Al Sherooq Bldg.,
No. 14, Grand Floor, Dubai, U.A.E.
TEL: [phone]

NORTH AMERICA

CANADA

Roland Canada Music Ltd.
(Head Office)

5480 Parkwood Way Richmond
B. C., V6V 2M4 CANADA
TEL: [phone]

Roland Canada Music Ltd.
(Toronto Office)

170 Admiral Boulevard
Mississauga On L5T 2N6
CANADA
TEL: [phone]

U. S. A.

Roland Corporation U.S.

5100 S. Eastern Avenue
Los Angeles, CA 90040-2938,
U. S. A.
TEL: [phone]

As of November 1, 2003 (Roland)

SD000453 1GT
