Roberts Radio R9969 User Manual

R9969

PLL Synthesised World Radio

ROBERTS

Sound for Generations

Please read this manual before use

Contents

Contents ............................................................................2

Controls ..........................................................................3-6

Installing the batteries ...................................................... 7

Switching on and setting the clock .................................. 8

Setting local time 1 ........................................................... 8

Setting local time 2 ........................................................... 9

Setting and storing radio stations .................................. 10

Tuning radio stations directly ..........................................10

Tuning radio stations manually (1) .................................10

Tuning radio stations manually (2) .................................11

Saving radio stations at preset positions .......................11

Storing shortwave (SW) stations .................................... 12

Automatic station search................................................12

Deleting preset stations ..................................................13

Calling up stored radio stations ...................................... 14

Checking stored radio stations ......................................14

Changing preset positions ..............................................15

Adjusting the volume .......................................................15

Adjusting the tone ...........................................................15

Listening with headphones .............................................. 16

Switch between stereo and mono reception ..................16

Setting the reception sensitivity ..................................... 16

Special features of SW reception .................................. 17

Connecting the external SW antenna ............................ 17

SSB reception ................................................................. 18

Alarm mode - displaying the alarm time ........................ 19

Alarm with signal tone ..................................................... 19

Alarm with radio station ..................................................20

Cancelling the alarm for the day..................................... 21

Cancelling alarm stand-by ..............................................21

Sleep timer mode ............................................................ 21

Setting the sleep timer ...................................................21

Deactivating the sleep timer ........................................... 22

Additional functions - displaying local time 1 or 2......... 22

Setting various function modes ...................................... 23

Switching on the back lighting for the display ............... 24

Disabling and enabling the buttons ...............................24

Disabling and enabling the fine tuning dial....................24

Deleting all settings ........................................................ 25

Specifications..................................................................26

Guarantee........................................................................27

CONTROLS Controls - Front

3 42 5 6 7

10 11

12 13

1. Light

2. Tune/SSB LED

3. 1 to 9Numerical buttons

4. Display

If you need any further advice, please call our Technical Helpline on :020 8758 0338 (Mon-Fri)

5. Band selection

6. Memo AM/PM

7. Mode

8. On/Off Sleep

9. Display button

10. SW Page Clock 1/2 button

11. Signal Alarm button

12. Radio Alarm button

171819

13. SW Select button

14. Lock switch

15. Fine tuning dial

16. Tuning lock switch

17. Freq./Clock button

18. Memo Scan button

19. Memo Del button

Controls Right side

Left side

20. SSB Fine Tuning

21. SSB On/Off

22. Tone (low/high)

23. Volume

24. SW External Antenna

25. FM/SW DX./Local

26. FM St./FM

27. Headphone socket

28. DC 6 V socket for mains adapter (not supplied)

Controls Top

Bottom

29. Antenna

30. Reset button

If you need any further advice, please call our Technical Helpline on :020 8758 0338 (Mon-Fri)

Controls Back

31. Map of world time zones

32. Frequency scale

33. Battery compartment

Installing the batteries

4 x 1.5V, LR6 (AA size) type batteries are required.

1. Open the battery compartment on the back of your receiver by pressing the marking and opening the lid.

2. Insert the batteries into the compartment. Make sure the (+) and (-) ends of the batteries are positioned as shown on the rear of the receiver.

3. Close the battery compartment cover.

Note: When the batteries are low, the battery level icon flashes in the display. Each time the radio is switched off the battery charge indicator appears for seven seconds. If the charge level falls below 2 the batteries must be changed. If the batteries are not replaced within 3 minutes all stored settings will be lost.

Remove the batteries if the reciever is not going to be used for an extended period of time. The manufacturer accepts no liability for damage resulting from used batteries.

Environmental note: Batteries, including those which contain no heavy metal, may not be disposed of with household waste. Please dispose of used batteries in an environmentally sound manner.

If you need any further advice, please call our Technical Helpline on :020 8758 0338 (Mon-Fri)

Switching on and setting the clock

Before setting the clock make sure that the local time zone is known. There are 24 time zones based on a standard time zone called the UTC (Universal Time Co-ordinated), previously known as GMT (Greenwich Mean Time), as shown in the diagram on the back of the receiver.

Two different local times can be set, local time '1' and local time '2'.

Setting local time 1

When the receiver is first switched on the display indicates that the clock has to be set. The digital display will show '0:00' and the local time '1' symbol will be shown.

Note: If you are operating the receiver in the 12-hour format, AM and PM can be set by pressing the Memo AM/PM button.

1. Place the receiver on a flat surface. Make sure that the batteries have been inserted correctly, or if using mains power, plug the mains lead into a wall socket and switch on at the wall socket.

2. Press down and hold the Freq./Clock button until the display indicates the time can be set. The digital display will show '-:--' and the local time '1' symbol will flash.

Note: If the radio is switched on, press the Display button to switch the display to the clock.

3. Enter the time using the numerical buttons '1 ..... 0' in the correct

sequence.

Note: If the digits are entered incorrectly, a signal sounds and 'Err' flashes briefly in the display. The time will have to be entered again.

4. Press the Freq./Clock button to confirm the entry.

Setting local time 2

1. Press the SW Page Clock 1/2 button. The display flashes for local time '2'.

2. To set the display to local time '2' press the Freq./Clock button.

3. Press down and hold the Freq./Clock button until the display indicates the time can be set. The digital display will show '-:--' and the local time '2' symbol will flash.

4. Enter the time using the numerical buttons '1 ..... 0' in the correct

sequence.
