Rival CZF630 User Manual

Cool Zone/Cool Touch Deep Fryer

CZF630

Owner’s Guide

READ AND SAVE THESE INSTRUCTIONS

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed, including the following:

1. Read all instructions before using.

2. Do not touch hot surfaces. Use handles or knobs.

3. To protect against risk of fire, electric shock, and personal injury do not immerse Control Panel assembly, Power Strip, cord or plugs in water or other liquids.

4. Close supervision is necessary when Deep Fryer is used by or near children. Children should not use this appliance.

5. Unplug from outlet when not in use, before putting on or taking off parts and before cleaning. Allow to cool completely putting on or taking off parts, and before cleaning appliance.

6. Do not operate any appliance with a damaged cord or plug, or after the appliance malfunctions or has been dropped or damaged in any manner. Contact Customer Service (see warranty) for examination, repair, or electrical or mechanical adjustment.

7. The use of accessory attachments not recommended by Rival®may cause injury.

8. Do not use outdoors.

9. Do not let cord hang over edge of table or countertop, or touch hot surfaces including the stove.

10. Do not place on or near a hot gas or electric burner, or in a heated oven.

11. Extreme caution must be used when moving fryer containing hot oil. Always use oven mitts or hot pads.

12. Always attach plug to appliance first, then plug AC cord into the wall outlet. To disconnect, turn control to OFF, then remove AC cord from wall outlet.

13. Do not use appliance for other than intended use.

-2-

SAVE THESE INSTRUCTIONS

This appliance is for HOUSEHOLD USE ONLY. This Deep Fryer is equipped with an exclusive SureRELEASE™ Power Cord System, which includes a detachable magnetic cord designed to separate from the unit when certain amounts of force are applied (See details on pg.6 for instructions on proper usage of the SureRELEASE™ magnetic cord.).

A short power supply cord is provided to reduce the risk resulting from becoming entangled in or tripping over a longer cord. WARNING: Do not use an extension cord.

No user-serviceable parts inside. Do not attempt to service this product.

POLARIZED PLUG

This appliance has a polarized plug, (one blade is wider than

the other). As a safety feature to reduce the risk of electrical

shock, this plug is intended to fit in a polarized outlet only one way. If the plug does not fit fully in the outlet,

reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to defeat this safety feature or modify the plug in any way. If the plug fits loosely into the AC outlet or if the AC outlet feels warm do not use that outlet.

-3-

KNOW YOUR DEEP FRYER

1 0

1 5

3 0

5 F

L i

e l

e a

e ad

Pow

Filter Cover

Charcoal Odor Filter

White Grease Filter

Folding Handle

Control Panel

Oil Reservoir

Frying Basket

Housing

Lid

View Window

Power Strip

SureRELEASETMPower Cord

-4-

PREPARING YOUR DEEP FRYER FOR USE

Prior to first use, remove all packaging materials from the exterior and interior of the fryer. Make sure the fryer is unplugged. Wash the Frying Basket and removable Oil Reservoir in hot soapy water. Gently wipe the Cool Zone Heating Element with a damp cloth. Dry all parts thoroughly. See CARE AND CLEANING section.

CAUTION: Do not immerse cord, plug, Power Strip or Control Panel assembly in water.

TIPS FOR DEEP FRYING

• Fill the unit with oil between the maximum and minimum capacity lines only.

• Do not over fill the basket. To achieve quality results deep frying food needs to be surrounded by oil. Too much food causes the oil temperature to drop, resulting in “soggy” food. Food should be submerged completely in the oil.

• Be sure that all ice crystals are removed from the food and food is completely dry. Excessive water and ice can cause the oil to splatter and/or overflow.

• Coated foods (bread crumbs, batters, etc.) are best for deep frying. The coating acts as a protective layer keeping food moist on the inside and crisp on the outside.

• For best results, defrost frozen foods for 20 minutes prior to frying.

• Fry foods at the correct temperature for best results. This will prevent burning and give you even colored, crispy food.

• Prepackaged frozen, cooked chicken, may cook faster than uncooked food.

• For even cooking, shake basket half way through cooking cycle.

-5-
