Operation / Installation
Manual
To Suit Water Heater Models:
INFINITY 32 REU-VR3237WG
INFINITY 26 REU-VR2626WG
INFINITY 26 Plus REU-VRM2630WD
INFINITY 26i REU-VR2632FFUG
INFINITY 20 REU-VR2024WG
INFINITY 16 REU-VR1620WG
INFINITY ENVIRO 32 REU-KM3237WD
INFINITY ENVIRO 26 REU-KM2635WD
V1500 REU-VR2426WB
V1200 REU-VR1620WB
HD250e REU-VRM3237WC
HD200e REU-VRM2632WC
HD200i REU-VRM2632FFUC
How to use and install Rinnai continuous flow water heaters
This appliance shall be installed in accordance with:
• Manufacturer’s Installation Instructions
• Current AS/NZS 3000, AS/NZS 3500 & AS 5601
• Local Regulations and Municipal Building Codes
This appliance must be installed, serviced and removed by an Authorised Person.
Please see the inside front cover of this manual for additional
Rinnai continuous flow water heater models covered by this manual.
NOTE
IMPORTANT
IMPORTANT
Some additional Rinnai continuous flow water heater models not listed on the front
cover of this manual are also covered by this manual.
The following table lists these additional models and their equivalent.
When using this manual use the specifications of the equivalent model listed below.
Model not listed on the front cover Equivalent Model
REU-V3237WG REU-VR3237WG
REU-V2626WG REU-VR2626WG
REU-VM2630WD REU-VRM2630WD
REU-V2632FFUG REU-VR2632FFUG
REU-V2024WG REU-VR2024WG
REU-V1620WG REU-VR1620WG
REU-K2430WG REU-KR2430WG
REU-V2426WB REU-VR2426WB
REU-V1620WB REU-VR1620WB
REU-V2024WE REU-VR2024WG
REU-VM3237WC REU-VRM3237WC
REU-VM2630WC REU-VR2626WG
REU-VM2632FFUC REU-VRM2632FFUC
Other Rinnai continuous flow water heater models that are not listed above are
therefore not covered by this manual.
REU-V2632FFUG and REU-VM2632FFUC internal continuous flow water heaters use
an older (male) flue spigot design. Refer to the “Flue Installation Manual” issue 3 or
earlier for the flue installation details for these models.
OPERATION MANUAL
REGULATORY INFORMATION..................................................................................1
WARNING ABOUT HOT WATER...............................................................................1
FEATURES AND BENEFITS ......................................................................................2
IMPORTANT INFORMATION .....................................................................................3
OPERATION WITHOUT CONTROLLERS..................................................................5
GENERAL WATER CONTROL INFORMATION ........................................................6
UNIVERSAL WATER CONTROLLERS......................................................................7
ABOUT THE UNIVERSAL WATER CONTROLLER (MC-91Q)................................................................... 7
TURNING ON THE CONTROLLER.............................................................................................................7
ADJUSTING TEMPERATURE.....................................................................................................................7
HOW TO USE TWO OR MORE UNIVERSAL WATER CONTROLLERS ................................................... 8
TRANSFERRING PRIORITY....................................................................................................................... 8
ADJUSTING TEMPERATURE.....................................................................................................................8
DELUXE BATHROOM WATER CONTROLLERS......................................................9
ABOUT THE DELUXE BATHROOM WATER CONTROLLER (BC-100V)..................................................9
TURNING ON THE CONTROLLER.............................................................................................................9
SETTING THE SOUND OPTIONS ............................................................................................................ 10
SETTING THE CLOCK ..............................................................................................................................10
ADJUSTING TEMPERATURE...................................................................................................................10
OPERATING THE SHOWER SAVER / BATH FILL FUNCTION ............................................................... 11
USING MULTIPLE WATER CONTROLLERS ...........................................................................................12
COMBINING UNIVERSAL AND DELUXE WATER CONTROLLERS ....................................................... 12
DELUXE KITCHEN WATER CONTROLLERS.........................................................13
ABOUT THE DELUXE KITCHEN WATER CONTROLLER (MC-100V) .................................................... 13
TURNING ON THE CONTROLLER...........................................................................................................13
SETTING THE SOUND OPTIONS ............................................................................................................ 13
SETTING THE CLOCK ..............................................................................................................................14
ADJUSTING TEMPERATURE...................................................................................................................14
SMARTSTART® PRE-HEAT OPERATION..............................................................15
ABOUT THE SMARTSTART® PREHEAT SYSTEM................................................................................. 15
TROUBLESHOOTING...............................................................................................16
INSTALLATION MANUAL ........................................................................................19
ACCESSORIES ........................................................................................................35
PRODUCT RECORDS .............................................................................................35
CONTACT INFORMATION ......................................................................................36
Rinnai Australia i Operation Manual
Rinnai Australia ii Operation Manual
REGULATORY INFORMATION
Your Rinnai Continuous Flow water heater has been certified by the Australian Gas Association.
The A.G.A. Certification Number is shown on the data plate.
This Appliance must be installed correctly by an author ised person. The installation of gas, water, and
electricity must conform to local regulations.
The installation must also comply with the instructions supplied by Rinnai.
All dimensions referred to in these instructions are in millimetres, unless otherwise specified.
Please keep this instruction booklet in a safe place for future reference.
Notice to Victorian Consumers
This appliance must be installed by a person licensed with the Plumbing Industry Commission.
Only a licensed person will have insurance protecting their workmanship.
So make sure you use a licensed person to install this appliance and ask for your Compliance
Certificate. For Further information contact the Plumbing Industry Commission on 1800 015 129.
WARNING ABOUT HOT WATER
Heated water can be dangerous, especially for young
children and the infirm.
Water temperatures above 50°C can cause severe burns
instantly and may even result in death.
Those most at risk are children, disabled, elderly and the
infirm.
Hot water at 65°C (a very common hot water temperature in
Australia) can severely burn a child in less than half a second.
At 50°C it takes five minutes.
ALWAYS......
Test the temperature of the water with your elbow before plac ing your child in the bath, also
carefully feel water before bathing or showering yourself.
Supervise children whenever they are in the bathroom.
Make sure that the hot water tap is turned off tigh tl y.
CONSIDER.....
Installing child proof tap covers or child resistant taps (both approaches will prevent a small
hand being able to turn on the tap).
Setting your appliance at a maximum temperature of 50°C (Contact Rinnai Australia).
NEVER…..
Leave a toddler in the care of another child. They may not understand the need to have the
water temperature set at a safe level.
Rinnai Australia 1 Operation Manual
FEATURES AND BENEFITS
Congratulations on purchasing the latest technology temperature controlled Rinnai continuous flow
water heating system.
• The Rinnai Continuous Flow water heater products NEVER RUN OUT of hot water. Whilst
electricity , water and g as supplies are co nnected, hot water is availabl e whenever hot water tap s are
open.
• Built into the main micro-processor is the facility to LIMIT THE MAXIMUM TEMPERATURE of the
hot water supplied. The water temperature may be limited to various values. This is particularly
useful when the hot water unit is installed where young children or the infirm may be using the hot
water.
• The Rinnai Continuous Flow water heater products are power flued appliances. This makes them
COMPACT, saving both floor and wall space.
• The temperature of hot water is CONSTANTLY MONITORED by a BUILT-IN SENSOR. If the
temperature of the hot water rises to more than 3°C above the selected temperature the burner is
turned OFF and only turned ON again when the temperature falls below the selected temperature.
• The burner lights automatically when the hot water tap is opened, and goes out when the tap is
closed. IGNITION IS ELECTRONIC, so there is no pilot light. When the hot water tap is off, no gas is
used.
• The "Smartstart®" system when fitted can pre-heat the water in the pipework between the water
heater and the hot water outlets. This results in water savings and reduces waiting time for heated
water at the outlets.
• 'Deluxe' or 'Universal' Water Controllers are available as an optional extra. Depending on the
models chosen, these offer the following features:
• Bath fill function (Deluxe Bathroom Control Only).
• Voice Prompting (Deluxe Control Only).
• Clock (Deluxe Control Only).
• Up to four water controllers can be fitted. See page 6 for details.
• Water controller cables are connected easily by the end user using a convenient quick connect
system.
• Operating NOISE LEVEL IS VERY LOW.
• ERROR MESSAGES ARE DISPLAYED on the Water Controllers and Status Monitor*, assisting
with service. *Status Monitor available on INFINITY 26 Plus (REU-VRM2630WD), HD250e (REUVRM3237WC), HD200e (REU-VRM2632WC) and HD200i (REU-VRM2632FFUC) models only.
Rinnai Australia 2 Operation Manual
IMPORTANT INFORMATION
NOTE
OFF!
HOT!
Filter
Drain
Gas
Valve
GasColdHot
Turn Water Off
Turn Gas Off
Drain Water
43°C
5
5
°
C
The range of Rinnai continuous flow water heaters referred to in this manual are
incompatible with solar water heating systems. A dedicated range of solar
compatible continuous flow water heaters is available from Rinnai.
Always check water temperature carefully before
use. Refer to the WARNING ABOUT HOT WATER
on "page 1" of this manual for important safety
information.
Do Not touch the unit cover or the flue outlet.
Do Not insert objects into the flue outlet.
On colder days steam may discharged from the flue
outlet. This condition is normal for high efficiency
appliances and does not indicate a fault.
At low water flows, the hot water unit may extingu ish
without warning. Opening the tap further will restart
the appliance.
Keep flammable materials, spray cans, fuel
containers, pool chemicals, trees, shrubs, etc. well
clear of the flue outlet.
Do Not spray water directly into the flue terminal.
If freezing conditions are expected, turn off water and
gas and drain all water from the appl iance. If power
and the automatic frost protection are connected,
freezing will be prevented. (Anti-frost protection is
fitted as standard equipment on External units and is
available as an optional extra on Internal Units)
The delivered water temperature is controlled
automatically. The flow may vary depending on the
delivery temperature selected and the ambient water
temperature.
Rinnai Australia 3 Operation Manual
IMPORTANT INFORMATION
S
O
L
V
E
N
T
Max.
43°C
49°C
50°C
Kitchen
Kitchen
Bathroom
To clean your water controller(s) use a soft
damp cloth with a mild detergent.
Do Not use solvents!
Depending on the weather conditions and the
length of the pipe between the hot water unit
and the outlet in use, there may be a variation
between the temperatures displayed at the
water controller(s) and the temperature of the
water at the outlet.
Whilst hot water outlets are open the set
temperature may be lowered. However they
cannot then be raised above 43°C. In addition
transfer of 'priority' between controllers is not
possible. These are safety features.
There is no need to turn the water controller(s)
off after use. However, if you prefer to turn the
water controller(s) off, selected temp eratures
to a maximum of 50°C will be stored in the
system memory at all times whilst mains power
remains connected.
As a safety precaution, if a Kitchen Controller's
temperature is set above 50°C, transferring
and then returning 'priority' to the Kitchen
Controller will result in a default set
temperature of 50°C being selected. This is a
safety feature.
Rinnai Australia 4 Operation Manual
Do Not push the On/Off button on any
Controller when the ‘Red’ water heater ‘In Use’
indicator is illuminated as this will turn off the
water heater causing the water to go cold.
Someone maybe in the middle of having a
shower or filling a bath.
OPERATION WITHOUT CONTROLLERS
HOTHOT
COLDCOLD
ON!ON!
ON!ON!
HOTHOT
COLDCOLD
OFF!OFF!
OFF!OFF!
NOTE
CAUTION
Rinnai Continuous Flow water heater products do not use a pilot light.
When installed and operated without water controllers, the opening of any hot water tap will
automatically start the appliance.
Once water is flowing through the appliance the burner will be ignited by electronic ignition.
When the hot water tap is closed and water flowing through the appliance has stopped the burner
flame will extinguish.
The Rinnai Continuous Flow water heater range other than the Rinnai Heavy Duty
(HD) series are factory pre-set to a temperature limit of 50°C or 55°C. The HD series
are factory pre-set to a temperature limit of 65°C. Other limits, lower or higher, are
available on request for the entire Continuous Flow water heaters range.
Temperature controllers are available to allow precise digital temperature control.
Controllers can be fitted at any time after installation of the hot water unit.
Heated water can be dangerous, especially for young children and the infirm.
Water temperatures above 50°C can cause severe burns instantly and may even
result in death.
Those most at risk are children, disabled, elderly and the infirm.
Hot water at 65°C (a very common hot water temperature in Australia) can
severely burn a child in less than half a second. At 50°C it takes five minutes.
ALWAYS......
Test the temperature of the water with your elbow before placing your child in the
bath, also carefully feel water before bathing or showering yourself.
Supervise children whenever they are in the bathroom.
Make sure that the hot water tap is turned off tightly.
CONSIDER.....
Installing child proof tap covers or child resistant taps (both approaches will
prevent a small hand being able to turn on the tap).
Setting your appliance at a maximum temperature of 50°C (Contact Rinnai
Australia).
NEVER…..
Leave a toddler in the care of another child. They may not understand the need
to have the water temperature set at a safe level.
Rinnai Australia 5 Operation Manual
GENERAL WATER CONTROL INFORMATION
Remote water controllers allow precise temperature control by the user. When used correctly, the hot
water unit will deliver the selected temperature, even when the water flow is varied, or more than one
tap is in use. Each water controller can be individually programmed, however the water heater can
only deliver one set temperature at any time. The available temperatures (°C) are as follows:
Kitchen Controller:
37, 38, 39, 40, 41, 42, 43, 44, 45, 46, 48, 50, 55°C* ( 60, 65°C HD models only )
Bathroom Controller:
Hot Water Delivery: 37, 38, 39, 40, 41, 42, 43, 44, 45, 46, 48, 50°C
Bath fill Delivery: 37, 38, 39, 40, 41, 42, 43, 44, 45, 46, 47, 48°C
Whilst hot water outlets are open the set temperature may be lowered. However the set temperature
cannot then be raised above 43°C. In addition, transfer of 'priority' between water controllers is not
possible. These are safety features.
Suggested temperatures are:
Kitchen 50°C ~ 55°C* Shower 37°C ~ 43°C, Bath fill 39°C ~ 45°C
* Temperature may not be available on all installations. Rinnai water heaters can be programmed to deliver higher temperatures
via the kitchen water controller. Contact Rinnai for more details.
These temperatures are suggestions only. You may find higher or lower temperatures more
comfortable. Maintaining lower temperatures helps sa ve ener gy. To o btain wa ter tem peratures lo wer
than 37°C simply add cold water.
Water controllers are an optional extra. 'Universal' and 'Deluxe' water controllers can be fitted.
Universal water controllers allow temperature selection only. Deluxe water controllers allow
temperature selection, shower saver / bath fill and have a clock function.
Water controllers allow the water tem perature to be set from the various locations whe re they are
installed. The temperature selected will be available to all outlets.
Universal (MC-91Q) and Deluxe (MC/BC-100V) Water Controllers - available configurations:
A maximum of 4 water controllers ca n be fitted. An y combina tion of both deluxe and
universal controllers can be used with the following provisions:
All
Models
Only ONE
Up to TWO
The FOURTH
MC-100V water controller can be installed.
BC-100V water controllers can be installed.
water controllers in any installation MUST BE a MC-91Q.
Rinnai Australia 6 Operation Manual
UNIVERSAL WATER CONTROLLERS
Indicates that the Smartstart®
preheater (when fitted)is
activated.
Used to start and stop the
Smartstart® preheat unit (when
fitted),See Smartstart® Operation
on page 15.
Used to switch the water heater
on and off.
Used to transfer control priority
between the temperature
controllers. The controller with
priority has command of the hot
water delivery temperature.
Indicates that a water heater is in
operation and delivering hot
water.
Indicates the temperature
selected. Error message flash in
event of a fault.
Used to select water temperature.
Indicates if this temperature
controller is in control of water
delivery temperature.
WATER HEATER
'In Use' INDICATOR
DIGITAL MONITOR
TEMPERATURE
CONTROL BUTTONS
CONTROLLER
ON INDICATOR
TRANSFER BUTTON
PREHEAT BUTTON
PREHEAT INDICATOR
ON/OFF BUTTON
HOTHOT
COLDCOLD
ON!ON!
CAUTION
NOTE
ABOUT THE UNIVERSAL WATER CONTROLLER (MC-91Q)
TURNING ON THE CONTROLLER
If the water controller is switched off (N o digits displayed in the
digital monitor window) press the On/Off button once.
The ON indicator will illuminate, indicating that the hot water unit
will be ready to supply hot water once a hot water tap is opened.
ADJUSTING TEMPERATURE
Select the desired temperature using the 'Hot water temp' or
buttons until the required temperature is displayed on the
digital monitor.
To operate the hot water unit, open any hot water tap. This will
automatically light the burner providing hot water. The water
heater ‘In Use’ indicator will illuminate on the water controller.
Once the hot water is running, if the set temperature is either too
hot or cold press the 'Hot water temp' or buttons until the
desired temperature is reached.
Rinnai 7 Operation Manual
CHECK WATER TEMPERATURE BEFORE USE.
A parent or carer should always check the temperature before a child is placed
in contact with hot water, see page 5.
Whilst hot water outlets are open the set temperature may be lowered. However
they cannot then be raised above 43°C. In addition, transfer of 'priority ' between
controllers is not possible. These are safety features.
The 'beep' sound can be muted by pressing the 'Hot water temp' Up and
Down buttons simultaneously for more than 3 seconds.
UNIVERSAL WATER CONTROLLERS
HOTHOT
COLDCOLD
ON!ON!
CAUTION
NOTE
HOW TO USE TWO OR MORE UNIVERSAL WATER CONTROLLERS
TURNING ON THE CONTROLLERS
If the controllers are switched off (No digits displayed in the dig ital
monitor window) press the On/Off button once at any controller.
The ON indicator on the desired controller will illuminate,
indicating that the hot water unit will be ready to supply hot water
once a hot water tap is opened.
TRANSFERRING PRIORITY
An illuminated On/Off indicator confirms that the desired controller
is in control of the water delivery temperature, if the On/Off
indicator is not illuminated press the TRANSFER button once.
The On/Off indicator on the controller will now illuminate indicating
that hot water temperatur e control has now been transferred to
this controller and that the hot water unit will be ready to supply hot
water once a hot water tap is opened.
ADJUSTING TEMPERATURE
Select the desired temperature using the 'Hot water temp' or
buttons until the required temperature is displayed on the
digital monitor.
To operate the hot water unit, open any hot water tap. This will
automatically light the burner providing hot water. The water
heater ‘In Use’ indicator will illuminate on the water controller.
Once the hot water is running, if the set temperature is either too
hot or cold press the 'Hot water temp' or buttons until the
desired temperature is reached.
CHECK WATER TEMPERATURE BEFORE USE.
A parent or carer should always check the temperature before a child is placed
in contact with hot water, see page 5.
Whilst hot water outlets are open the set temperature may be lowered. However
they cannot then be raised above 43°C. In addition transfer of 'priority' between
controllers is not possible. These are safety features.
Temperatures higher than 50ºC should not be able to be selected on controllers
installed in bathrooms, ensuites or toilets. This is to help reduce the risk of burns
from hot water. If this is not the case, the controllers have been incorrectly
installed. CONTACT YOUR INSTALLER.
The temperature of outgoing hot water is constantly monitored by a built-in
sensor. If the temperature of the outgoing hot water rises to more than 3°C above
the selected temperature shown on the digital monitor or the pre-set limit when
water controllers are not fitted, the burner will automatically go out. The ‘in use’
indicator will also go out. The burner will ignite again once the outgoing hot
water temperature falls to that show n on the digita l monitor (or the pre-set limit
of the appliance).
Rinnai 8 Operation Manual
DELUXE BATHROOM WATER CONTROLLERS
Used to transfer control priority between
the Water Controllers . Thecontroller with
priority has command of the hot water
delivery temperature. This button is
illuminated when this con tr oller has
priority.
TRANSFER BUTTON
SPEAKER
Used to start and stop the Smartstart®
preheat unit (when fitted), See
Smartstart® Operation on page 15.
This button is illuminat ed when the
Smartstart® preheater (when fitted) is
activated.
PREHEAT BUTTON
Indicates the selected hot water
temperature.
WATER TEMPER ATURE
INDICATOR
Indicates that the Shower Saver / Bath
Fill function has been selected and that
a shower is running or the bath is filling.
SHOWER SAVER /
BATH FILL INDICATOR
12 Hour AM / PM clock display.
Indicates how much water remains to
flow for the selected Shower Saver /
Bath Fill volume, decreasin g whi le
shower runs or bath fills.
In the event of a fault, error message
codes will flash here.
CLOCK & REMAINING WATER
VOLUME INDICATOR
In Normal and Shower Saver / Bath Fill
modes these buttons are used to select
the water temperature.
In 'Clock' mode these button are used to
set the clock.
TEMPERATURE BUTTONS
Indicates Shower Saver /Bath Fill volume
selected.
WATER LEVEL INDICATOR
Used to select Shower Saver / Bath Fill
volumes.
WATER VOLUME BUTTONS
Used to select the voice and audible tone
options.
SOUND VOLUME BUTTON
Used to select Shower Saver / Bath Fill
function. This button is illuminated when
the Shower Saver / Bath Fill function is
selected.
Used select clock setting mode.
CLOCK SETTING BUTTON
SHOWER SAVER /
BATH FILL BUTTON
Used to switch the water heater on and
off. This button is illuminated when the
hot water heating system is on.
ON/OFF BUTTON
Indicates that the water heater is in
operation and delivering hot water.
WATER HEATER
'In Use' INDICATOR
DIGITAL
MONITOR
NOTE
ABOUT THE DELUXE BATHROOM WATER CONTROLLER (BC-100V)
TURNING ON THE CONTROLLER
If the controller is switched off (No d igits other tha n the
clock digits displayed in the digital monitor) press the
On/Off button once.
The On/Off and Transfer buttons illuminate to indicate
that the hot water unit will be ready to supply hot water
once a hot water tap is opened.
Refer to page 6 to confirm the maximum number and combination of controllers
that can be fitted to your Water Heater model.
Avoid getting water directly in the speaker as this may cause damage.
If more than one controller is fitted press the ‘Transfer’
button to transfer priority to the desired controller.
Rinnai Australia 9 Operation Manual
DELUXE BATHROOM WATER CONTROLLERS
NOTE
HOTHOT
COLDCOLD
ON!ON!
NOTE
CAUTION
SETTING THE SOUND OPTIONS
To set the sound options press the 'Sound Volume' button an d sele ct the de sir ed au dible setting
as follows:
Voice High, Med, Low or Off, sets the voice prompt volume but does not affect the audible tones.
Sound OFF, mutes all voice prompts and audible tones.
Press any of the or buttons to return to normal mode, if no buttons are pressed for a period
of approximately 10 seconds the controller will return to normal mode
SETTING THE CLOCK
The clock is a 12 hour AM/PM style display.
To set the time press the 'Clock' button once, this
places the controller into clock setting mode, in the
digital monitor the clock digits will flash, if this is the first
time the clock has been set the starting time will be AM
12:00.
Use the ‘Temperature’ or buttons to select the
desired time, holding these buttons down continuously
cycles the digits. When you get close to the time you
wish to set, press the button intermittently to avoid going
further than the desired time.
To return to normal mode press the 'Clock' button
once, if no buttons are pressed for a period of
approximately 60 seconds the controller will return to
normal mode.
The time is always displayed regardless
of whether the water controller is
turned ON or OFF.
The clock may need resetting if power
to the water heater unit is disrupted due
to a power failure or if the power is
switched off over a prolonged period.
ADJUSTING TEMPERATURE
Simply press the 'Temperature' or bu ttons u ntil the required
temperature is displayed on the digital monitor.
To operate the water heater, open any hot water tap. This will
automatically light the burner, providing hot water. The ‘In Use’
indicator will illuminate on all water controllers.
Once the hot water is running, if the set temperature is either too hot
or cold press the 'Temperature' or buttons until the desired
temperature is reached.
Whilst hot water outlets are open the set temperature may be lowered. However
it cannot then be raised above 43°C. In addition, transfer of 'priority' between
controllers is not possible. These are safety features.
CHECK WATER TEMPERATURE BEFORE USE.
A parent or carer should always check the temperature before a child is placed
in contact with hot water, see page 5.
Rinnai Australia 10 Operation Manual
DELUXE BATHROOM WATER CONTROLLERS
NOTE
NOTE
OPERATING THE SHOWER SAVER / BATH FILL FUNCTION
The 'Shower Saver / Bath Fill' function allows a preset
water volume and temperat ure to be selected and run
automatically.
Initial Settings
When a deluxe bathroom controller is first turned on, the
default shower / bath fill temperature is set to 40°C and
the shower / bath volume is set to 100 litres. The shower
/ bath volume can be lowered to a minimum of 30 litres
or raised to a maximum of 400 litres and the
temperature adjusted as desired.
Setting Shower / Bath Temperature and Volume
With the system on, select a Deluxe Bathroom water
controller and ensure that it currently has priority. If it
does not have priority press the ‘Transfer’ button
once and the ‘Transfer’ button will illuminate.
No voice prompts will be available if the
‘Voice OFF’ or ‘Sound OFF’ options are
selected. With ‘Sound OFF’ there will
also be no audible tones.
Press 'Shower Saver / Bath Fill' button once. The
'Shower Saver / Bath Fill' button will illuminate and a
voice prompt and tone will sound.
To select the desired delivery temperature use the
'Temperature' or buttons.
The selected temperature will be displayed on the digital monitor and will remain as the default
'Shower Saver / Bath Fill' temperature until it is changed or if the mains power is turned off for an
extended period.
To select the volume of water to be used in the shower / bath use the 'Water Volume' or
buttons. The selected volume is displayed in large digits to the right and will remain as the default
'Water Volume' until it is changed or if the mains power is turned off for an extended period.
The selected volume is also repeated in the form of a remaining volume counter below the
temperature and replaces the clock during 'Shower Saver / Bath Fill' operations.
When filling a bath for the first time, it is recommended that a low bath fill volume such as 60 litres or
lower be used. During any subsequent bath fills the volume can then be adjusted to suit your known
bath volume and or desired fill level.
Be careful not to overfill the bath, an average bath volume is 160 litres. It is
recommended that when filling a bath for the first time you should:
• Remain by the bath during the filling process.
• Use a low bath fill volume such as 60 litres or less.
When Smartstart® (page 15) is in operation, the Shower Saver / Bath Fill function
is unavailable while the water heater ‘In Use’ indicator is illuminated. Do not
press the Preheat button whilst Shower Saver / Bath Fill is in operation as the
programmed bath fill volume will not be met.
Using Shower Saver / Bath Fill
Press 'Shower Saver / Bath Fill' button once. The 'Shower Saver / Bath Fill' button will illuminate
and a voice prompt and tone will sound. During 'Shower Saver / Bath Fill' operations the 'Bath'
indicator will also be displayed in the Deluxe Kitchen water controller digital monitor (when fitted).
Rinnai Australia 11 Operation Manual
DELUXE BATHROOM WATER CONTROLLERS
HOTHOT
COLDCOLD
ON!ON!
HOTHOT
COLDCOLD
OFF!OFF!
CAUTION
NOTE
The voice prompt will say "The hot water system is
ready. Open the hot water tap”. Open the hot water tap
for the relevant shower or bath.
The ‘In Use’ indicator will illuminate on all Deluxe
water controllers and the shower will run or the bath will
start to fill.
To Stop Shower Saver / Bath Fill Operation
If you wish to stop the water flow whilst the Shower
Saver / Bath Fill function is in operation, simply press
the 'Shower Saver / Bath Fill' button.
The 'Shower Saver / Bath Fill' button will flash and the
voice prompt will say "Hot water is not available, Turn off
all hot water taps and push the 'Bath Fill' button". Follow
the voice prompt instructions.
When Shower Saver / Bath Fill Operations Finishes
Once the Shower Saver / Bath Fill operation finishes the
following events will occur:
1. The flow from the shower / bath hot water tap ceases.
2. The 'Shower Saver / Bath Fill' button will flash.
3. The Deluxe Kitchen water controller 'Bath' indicator
will flash.
4. A tone will sound.
5. The voice prompt will say "Bath fill is complete. Turn off the bath hot water tap and push the Bath
Fill button."
Follow the voice prompts instructions. Note that the water heater will not allow hot water to flow from
any fixture until the 'Shower Saver / Bath Fill' button has been pressed.
6. The 'Shower Saver / Bath Fill' button light on the Deluxe Bathroom water controller and the 'Bath'
indicator on the Deluxe Kitchen water controller monitor (when fitted) will go out.
CHECK WATER TEMPERATURE BEFORE USE.
A parent or carer should always check the temperature before a child is placed
in contact with hot water, see page 5.
NEVER LEAVE YOUNG CHILDREN UNATTENDED IN THE BATH.
When using the 'Shower saver / Bath fill' function, ALWAYS close the hot water
tap for the bath or shower after the flow has stopped.
Whilst hot water outlets are open the set temperature may be lowered. However
it cannot then be raised above 43°C. In addition transfer of 'priority' between
controllers is not possible. These are safety features.
USING MULTIPLE WATER CONTROLLERS
The water heater can be turned on and off at any water controller. If more than one water controller is
fitted press the ‘Transfer’ button to transfer priority to the desired controller.
COMBINING UNIVERSAL AND DELUXE WATER CONTROLLERS
Universal and Deluxe water controllers can be combined and will function as described in other
sections of the Water Heater Operation / Installation M anual. Refer to page 6 to confirm the maximum
number and combination of controllers that can be fitted to your water heater model.
Rinnai Australia 12 Operation Manual
DELUXE KITCHEN WATER CONTROLLERS
Used to switch the water heater on and
off. This button is illuminated when the
hot water heating system is on.
ON/OFF BUTTON
DIGITAL
MONITOR
Indicates that the water heater is in
operation and delivering hot water.
WATER HEATER
'In Use' INDICATOR
SPEAKER
When in Normal mode these
buttons are usedto select the water
temperature.
In 'Setup' mode these buttons are
used to adjust the voice prompt
volume and to set the clock.
UP AND DOWN BUTTONS
Used to swith the controller
between Normal, Voice or Clock
modes.
MODE BUTTON
Indicates the selected hot water
temperature.
WATER TEMPERATURE
INDICATOR
Indicates that the Shower Saver /
Bath Fill function is operating.
SHOWER SAVER /
BATH FILL INDICATOR
Used to start and stop the
Smartstart® preheat unit (when
fitted), See Smartstart® Operation
on page 15.
This buttonisilluminated when the
Smartstart® preheater (when fitted)
is activated.
PREHE AT BUTTON
12 Hour AM / PM clock display.
In the event of a fault, codes for
error messages will flash here.
CLOCK
Used to transfer control priority
between theWater Controllers. The
controlle r with priority has
command of the hot water delivery
temperature. This button is
illuminated when this controller
has priority.
TRANSFER BUTTON
NOTE
NOTE
ABOUT THE DELUXE KITCHEN WATER CONTROLLER (MC-100V)
TURNING ON THE CONTROLLER
If the controller is switched off (No digits other than the clock digits
displayed in the digital monitor) press the On/Off button once.
The On/Off and Transfer buttons illuminate to indicate that the hot
water unit will be ready to supply hot water once a hot water tap is
opened.
If more than one controller is fitted press the ‘Transfer’ button to
transfer priority to the desired controller.
SETTING THE SOUND OPTIONS
To set the sound options press the 'Mode' button once to place the controller into ‘Voice’ mode.
Use the or buttons to select the desired audible setting as follows:
Voice High, Med, Low or Off, sets the voice prompt volume but does not affect the audible tones.
Sound Off, mutes all voice prompts and audible tones.
To return to normal mode press the 'Mode' button once, if no buttons are pressed for a period of
approximately 10 seconds the controller will return to normal mode.
Rinnai Australia 13 Operation Manual
Only one MC-100V may be fitted to your water heater. Refer to page 6 to confirm
the maximum number and combination of controllers that can be fitted to your
Water Heater model.
The MC-100V controller is not water resistant, avoid direct exposure to water or
steam as these conditions may cause a malfunction.
Voice prompts only available when Deluxe Bathroom water controller(s) are
installed.
DELUXE KITCHEN WATER CONTROLLERS
NOTE
HOTHOT
COLDCOLD
ON!ON!
NOTE
CAUTION
SETTING THE CLOCK
The clock is a 12 hour AM/PM style display. To set the time press the 'Mode' button twice. This
places the controller into clock setting mode and in the digital monitor the word ‘Clock’ will be
displayed and the clock digits will flash. If this is the first time the clock has been set the starting time
will be AM 12:00.
Use the or buttons to select the desired time. Holding these buttons down continuously cycles
the digits. When you get close to the time yo u wish to set, press the button intermittently to avoid going
further than the desired time.
To return to normal mode press the 'Mode' button once. If no buttons are pressed for a period of
approximately 10 seconds the controller will return to normal mode.
The time is always displayed regardless of whether the water controller is turned
ON or OFF.
The clock may need resetting if power to the water heater unit is disrupted due
to a power failure or if the power is switched off over a prolonged period.
ADJUSTING TEMPERATURE
Simply press the 'hot water temp' or buttons until the
required temperature is displayed on the digital monitor.
To operate the water heater, open any hot water tap. This will
automatically light the burner, providing hot water. The ‘In Use’
indicator will illuminate on the water controller.
Once the hot water is running, if the set temperature is either too hot
or cold press the or buttons until the desired temperature is
reached.
Whilst hot water outlets are open the set temperature may be lowered. However
it cannot then be raised above 43°C. In addition transfer of 'priority' between
controllers is not possible. These are safety features.
CHECK WATER TEMPERATURE BEFORE USE.
A parent or carer should always check the temperature before a child is placed
in contact with hot water, see page 5.
Rinnai Australia 14 Operation Manual
SMARTSTART® PRE-HEAT OPERATION
DIGITAL
MONITOR
Indicatesthat'Smartstart®'
preheater isactivated*
PREHEAT INDICATOR
2
5
8
1
2 3
ON/OFF
BUTTON
4
CONTROLLER ON
INDICATOR
5
TEMPERATURE
BUTTONS
6
WATER HEATER
'IN USE' INDICATOR
7
TRANSFER
BUTTON
8
Usedto start andstop 'Smartstart®'
preheater.
PREHEAT BUTTON
1
1
6
2
8
2
1
8
5
4
4
6
3 3 47 75 3 7
6
38563
127
NOTE
ABOUT THE SMARTSTART® PREHEAT SYSTEM
Preheat Function
The “Preheat” function works in conjunction with various Rinnai water heater models and the
separately installed and optional Rinnai “Smartstart®” module.
When the “Preheat” function is activated and used in accordance with these in structions, water in the
pipework connected between the water heater and the hot water outlets in your house is warmed
before any outlets are opened. This results in water savings and added convenience.
The “Preheat” function is activated as follows:
1. Ensure that the hot water unit is on (temperature digits are displayed in the digital monitor ).
If more than one controller is fitted pre ss the ‘Transfer’ button to pass on priority to your
desired controller, the ‘Controller On’ indicator will illuminate to confirm that priority has been
assigned to this controller and that the hot water unit is ready to deliver hot water.
2. Select the desired temperature using the 'Temperature' buttons until the required
temperature is displayed in the digital monitor .
3. Press the ‘Preheat’ button once. The ‘Preheat’ indicator and the ‘In Use’ indicators
will illuminate, signifying that the preheat system has been activated.
4. Wait approximately two minutes before opening an outlet. This will allow the water in the
pipework to be warmed.
The waiting time may be longer or shorter than two minutes depending on your
particular installation configuration.
The “Preheat” function is cancelled 5 minutes after activation and the ‘Preheat’
indicator will go out. This is to conserve energy. To reactivate, simply repeat
steps 2-4 above.
* If the ‘Preheat’ button is pressed and the ‘Smartstart®’ preheat unit is not
installed, the ‘Preheat’ indicator will still light but there will be no “Preheat”
function. The ‘Preheat’ indicator will go out after a sho rt time and will not affect the
other functions of the water controller or water heater.
After using the Shower Saver / Bath Fill function wait 30 seconds before
activating the “Preheat” function. Attempting to use the “Preheat” function
earlier will result in voice prompts being repeated until the system is reset. The
system can be reset by pressing the ‘On /Off' button twice.
Other Controller Functions
Controller functions such as temperature control and transfer of priority between multiple controllers
is not affected by the operation of the preheat. Such functions are described in the applicable sections
of this manual.
Rinnai Australia 15 Operation Manual
TROUBLESHOOTING
NOTE
Your Rinnai Continuous Flow water heaters has a self diagnostic capability. If a fault occurs, an Error
Code will flash on the digital monitor or status monitor* if you have water controllers. This assists with
diagnosing the fault, and may enable you to overcome a problem without a service call. Please quote
the code displayed when enquiring about service. *Status Monitor available on INFINITY 26 Plus
(REU-VRM2630WD), HD250e and HD200e HD200i models only.
ERROR FAULT REMEDY
-
03
10 Air intake or flue blocked. Service Call.
11 No ignition / No gas supply.
12 Flame Failure / Low gas flow.
14 Remaining Flame Safety Device. Service Call.
16 Over Temperature Warning. Service Call.
32 Outgoing Water Temperature Sensor Faulty. Service Call.
33 Heat Exchanger Outlet Sensor Faulty. Service Call.
34 Combustion Air Temperature Sensor Faulty. Service Call.
52 Gas Modulating Valve Faulty. Service Call.
61 Combustion Fan Failure. Service Call.
65
71 Micro-processor Failure. Service Call.
Noticeable reduction in water flow. Inlet water filter needs to be cleaned. Service call.
Power interruption during Bath fill
(Water will not flow on power reinstatement).
Water Flow Control Faulty
(Does not stop flow properly).
Turn off all hot water taps. Press On/Off twice.
Check gas is turned on at water heater and gas meter
or cylinder.
Check gas is turned on at water heater
and gas meter or cylinder.
Check there are no obstructions to the flue outlet.
Service Call.
72 Micro-processor Failure. Service Call.
LC Scale build-up inside the heat exchanger. Service Call.
In all cases, you may be able to clear the Error Code simply by turning the hot water tap OFF, then ON again. If this does not clear the Error Code,
try pushing the On/Off button OFF, then ON again. If the Error Code still remains, contact Rinnai for advice.
Troubleshooting Without Controllers
If you have no water controllers and experience the following symptoms, carry out these suggestions.
If the symptom continues, contact Rinnai for advice.
FAULT REMEDY
The unit does not attempt to start at all.
The unit starts then shuts down immediately.
The unit starts then the water goes cold.
Check the power is on at the unit.
Check the isolation valves at the unit are open.
Check the power is still on.
Check the gas isolation valves at the
unit and the gas meter are fully open.
Open your hot water tap fully.
Check the power is still on.
Open your hot water tap further.
Faults caused by insufficient gas supply, insufficient water supply, gas quality,
water quality, installation errors or operation errors are not covered by the Rinnai
warranty. Refer to the warranty card for details.
Rinnai Australia 16 Operation Manual
Rinnai Australia 17 Operation Manual
Rinnai Australia 18 Operation Manual
INSTALLATION MANUAL
GENERAL INSTALLATION INSTRUCTIONS ..........................................................21
REGULATIONS .........................................................................................................................................21
APPLICABLE MODELS ............................................................................................................................21
APPLIANCE LOCATION ...........................................................................................................................21
PIPE SIZING .............................................................................................................................................22
WATER SUPPLY ......................................................................................................................................22
HOT WATER DELIVERY TEMPERATURE .............................................................................................. 22
WATER HEATER AND CONTROLLER INSTALLATION CONFIGURATIONS ........................................ 22
MOUNTING THE APPLIANCE ................................................................................................................. 22
SERVICE CONNECTION POINTS ........................................................................................................... 23
HORIZONTAL FLUE TERMINAL CLEARANCES (Extract from AS5601 - 2004) ..................................... 24
HORIZONTAL OBSTRUCTIONS .............................................................................................................. 24
MULTIPLE INSTALLATIONS OF EXTERNAL MODELS .......................................................................... 24
APPLIANCE AND WATER CONTROLLER DIMENSIONS ...................................................................... 25
COAXIAL FLUEING FOR INTERNAL MODELS ....................................................................................... 26
CONDENSATE DRAIN (REU-KM’ MODELS ONLY)................................................27
IMPORTANT CONSIDERATIONS FOR THE CONDENSATE DRAIN PIPE ............................................ 27
LENGTH AND CHANGES OF DIRECTION .............................................................................................. 27
INSTALLATION .........................................................................................................................................27
INTERCONNECTION OF CONDENSATE DRAIN LINES ........................................................................ 28
COMMON STACK DISCHARGE ..............................................................................................................28
TUNDISH DRAIN LINES ...........................................................................................................................28
AREAS SUBJECT TO FREEZING ............................................................................................................ 28
WATER CONTROLLER INSTALLATION.................................................................29
RINNAI WATER CONTROLLERS ............................................................................................................29
POSITIONING OF WATER CONTROLLERS ........................................................................................... 29
WATER CONTROLLER CABLES ............................................................................................................. 29
FITTING THE ‘UNIVERSAL’ WATER CONTROL (MC-91Q) .................................................................... 29
FITTING THE ‘DELUXE KITCHEN’ WATER CONTROLLER (MC-100V) ................................................ 31
FITTING THE ‘DELUXE BATHROOM’ WATER CONTROLLER (BC-100V) ............................................ 31
CONNECTING COMMUNICATION CABLES TO THE WATER HEATER ...............................................32
COMMISSIONING .....................................................................................................33
TESTING ...................................................................................................................................................33
GAS PRESSURE SETTING ..................................................................................................................... 33
COMMISSIONING CHECK LIST ..............................................................................................................33
ACCESSORIES ........................................................................................................35
PRODUCT RECORDS .............................................................................................35
CONTACT INFORMATION ......................................................................................36
Rinnai Australia 19 Installation Manual
Rinnai Australia 20 Installation Manual
GENERAL INSTALLATION INSTRUCTIONS
REGULATIONS
This appliance must be installed in accordance with:
• Current AS/NZS3000, AS/NZS3500 and AS5601
• Rinnai Installation Instructions
• Local regulations and municipal building codes
Installation, Service and Removal MUST BE by an Authorised Person only.
APPLICABLE MODELS
These Installation Instructions apply to the following Rinnai Continuous Flow Water heater models:
REU-VR3237WG
REU-VR2626WG
REU-VRM2630WD
REU-VR2632FFUG*
REU-VR2024WG
REU-VR1620WG
REU-VRM3237WC
REU-VRM2632WC
REU-VRM2632FFUC*
* Denotes an internal model.
REU-KM3237WD
REU-KM2635WD
REU-VR2426WB
REU-VR1620WB
APPLIANCE LOCATION
(External Models)
This appliance is designed for ‘Outdoor’ Installation only. As such, it must be located in an above
ground open air situation with natural ventilation, without stagnant areas, where gas leakage and
products of combustion are rapidly dispersed by wind and natural convection.
This appliance must be mounted on a vertical structure with the water and gas connections on the
underside pointing downwards. For appliances installed on elevated structures or under floors specific
requirements apply. Refer to AS5601 Section 5 for details.
This appliance must not be used as a domestic spa or swimming pool heater.
Location of the appliance flue terminal must be in accordance with Section 5 and Figure 5.3 of
AS5601. Figure 5.3 is reproduced in the ‘Horizontal Flue Terminal Clearances’ section of these
instructions. Note that AS5601-2004 was current at the time of printing but may have been
superseded. It is the installers’ responsibility to ensure current requirements are met.
(Internal Models)
This appliance is designed for ‘Indoor’ installation only. It may be installed ‘Outdoors’ in an enclosure
if the requirements of AS5601 Section 5 are satisfied. An enclosure is defined as a compartment,
enclosed area or partitioned off space primarily used for the installing of the appliance. If installed in
an enclosure, either Internally or Externally, the location should be ventilated to allow gas to dissipate
and provision must be made for the safe disposal of any leaking water to a visible location.
This appliance must be mounted on a vertical structure with the water and gas connections on the
underside pointing downwards. For appliances installed in roof spaces or elevated structures specific
requirements apply. Refer to AS5601 Section 5 for details.
This appliance must not be used as a domestic spa or swimming pool heater.
Rinnai internal models described in this manual must use the coaxial Rinnai FF flue components. The
use of non Rinnai FF flue components may result in a dangerous situation and violates regulations.
The maximum FF flue length is 9 metres with a maximum of three 90 degree bends. Horizontal (wall)
or vertical (roof) terminals are available. For detailed information refer to ‘FLUEING FOR INTERNAL
MODELS’ on page 26.
This appliance must be located so that the flue terminal exits the building at a suitable point.
If a horizontal (wall) terminal FFWALLTERM is used, the location must be in accordance with Section
5 and Figure 5.3 of AS5601. Figure 5.3 is reproduced under ‘HORIZONTAL FLUE TERMINAL
CLEARANCES’ on page 24 of this manual.
If a vertical (roof) terminal FFROOFCOWL is used, the location must be in accordance with Section
5 of AS5601 and the ‘FLUEING FOR INTERNAL MODELS’ on page 26.
AS5601-2004 was current at the time of printing but may have been superseded. It is
the installer’s responsibility to ensure current requirements are met.
NOTE
launaM noitallatsnI12ailartsuA ianniR
GENERAL INSTALLATION INSTRUCTIONS
(All Models)
This appliance must be placed as close as practicable to the most frequently used hot water outlet or
outlets to minimise the delay time for hot water delivery. For installations wher e the distance between
the water heater and the outlets is considerable, a flow and return system or the Rinnai Smartstart®
system can be used which minimise the waiting time for hot water delivery. Alternatively, multiple
appliances can be strategically placed to serve outlets with minimal delay t ime. Contact Rinnai for
further information.
An AC240V, 10 Amp, earthed power point must be provided adjacent to the appliance. For outdoor
installations this power point must be weather proof. It must be clear of the gas and water connection s
to the appliance and also the flue exhaust and water pressure relief valve. The power cord of the
appliance is 1.5 Metres long.
All appliances must be installed to ensure access can be gained without hazard or un due difficulty for
inspection, repair, renewal or operational purposes. Sufficient clearances shall allow access to, and
removal of, all serviceable components. Appliances should not be mounted higher than 3.5 metres
above the ground or floor level unless the customer can arrange permanent and safe access or can
provide another means of access, for example, by means of scissor or boom lifts acceptable to local
authorities.
PIPE SIZING
See Table 1 page 23 for appliance gas consumption. If the gas pipe sizing is insufficient the customer
will not get the full performance benefit. Gas pipe sizing must consider the gas input to this appliance
as well as all the other gas appliances in the premises. The gas meter and regulator must be specified
for this gas rate. An approved sizing chart such as the one in AS5601 should be used.
Water pipe sizing and layout should be performed in accordance with AS/NZS3500. All hot water pipework should be insulated to optimise performance and energy efficiency.
WATER SUPPLY
See Table 1, page 23 for applicable water pressures. Approved pressure limiting valves may be
required if the ‘Maximum’ rated water supply pressures in Ta ble 1 are exceeded. To achieve the rated
flow, the ‘Minimum’ water supply pressures in Table 1 must be supplied. The water heaters will
operate at lower pressures but will not achieve the rated flow. Contact Rinnai for ‘gravity fed’ or ‘low
pressure’ installations.
Water chemistry and impurity limits are detailed under ‘Warranty Conditions’. Most metropolitan water
supplies fall within the requirements. If you are unsure about your local water quality, contact your
water authority. If sludge or foreign matter is present in the water supply, a suitable filter or strainer
should be incorporated in the water supply to the water heater.
HOT WATER DELIVERY TEMPERATURE
Local regulations and or the requirements of AS/NZS 3500.4 must be considered regarding the
temperature limitations of hot water supplied to areas used primarily for personal hygiene. The
temperature of water to these areas may be limited to 50º C or less. To ensure these regulations and
or requirements are met the system MUST be installed in accordance with the 'Water Heater and
Controller Installation Configurations' Section of these instructions.
WATER HEATER AND CONTROLLER INSTALLATION CONFIGURATIONS
If the appliance is marked to state that it delivers water not exceeding 50°C, local regulations may
permit it's installation without a Temperature Limiting Device. Installations without a Temperature
Limiting Device are shown in Diagram 1 (page 23). If you are unsure about your local regulations
contact your regulating authority or Rinnai.
If the appliance is NOT marked to state that it delivers water not exceeding 50°C, or your local
regulations require installation with a Temperature Limiting Device then install the appliance in
accordance with Diagram 2 (page 23).
MOUNTING THE APPLIANCE
See Table 1, page 23 for individual appliance weights. The wall or structure on which the un its are to
be mounted must be capable of supporting these weights and the associated pipe-work.
Rinnai Australia 22 Installation Manual
GENERAL INSTALLATION INSTRUCTIONS
If the appliance is to deliver water primarily for the purposes of personal hygiene in an
IMPORTANT
Ensure that suitable fixing screws or bolts are used to secure the units to the wall, in accordance with
AS5601 section 5. Wooden plugs shall not be used.
The top bracket has a keyhole slot so that the appliance can be positioned by hanging it on one screw,
then the other screws can be secured.
early childhood centre, primary or secondary school, nursing home or a similar facility
for the care of young, aged, sick or disabled persons as defined in AS/NZ3500.4 a
Temperature Limiting Device (TLD), such as a Tempering Valve may be required even
if the appliance is set to 50º C or less.
For these types of applications contact Rinnai.
SERVICE CONNECTION POINTS
See Table 1 for individual appliance connection / fitting dimensions. Note that these dimensions are
NOT an indication of the pipe sizes required.
An Approved full flow isolation valve and disconnection union MUST be fitted to the cold water inlet.
A non return valve is not required unless required by local regulations.
Isolation Valves must not be fitted directly to the appliance.
If may be necessary to fit a temperature limiting device for delivery to areas used primarily for the
purposes of personal hygiene. Refer to the ‘Water Heater and Controllers Installation Configurations’
Section of this document.
Purge gas and cold water supply lines to remove air and swarf before final connection of the
appliance. Swarf in either the gas or water supplies may cause damage.
Gas
Model:
REU-VR3237WG 250 180 1000 29 R ¾ (20mm) R ¾ (20mm) R ¾ (20mm) -
REU-VRM3237WC 250 180 1000 29 R ¾ (20mm) R ¾ (20mm) R ¾ (20mm) -
REU-VR2626WG 199 200 1000 16 R ¾ (20mm) R ¾ (20mm) R ¾ (20mm) -
REU-VRM2630WD 199 190 1000 17 R ¾ (20mm) R ¾ (20mm) R ¾ (20mm) -
REU-VRM2632WC 199 140 1000 21 R ¾ (20mm) R ¾ (20mm) R ¾ (20mm) -
REU-VR2632FFUG 195 140 1000 21 R ¾ (20mm) R ¾ (20mm) R ¾ (20mm) -
REU-VRM2632FFUC 195 140 1000 21 R ¾ (20mm) R ¾ (20mm) R ¾ (20mm) -
REU-KM3237WD 211 250 1000 32 R ¾ (20mm) R ¾ (20mm) R ¾ (20mm) R ½ (15mm)
REU-KM2635WD 172 250 1000 29 R ¾ (20mm) R ¾ (20mm) R ¾ (20mm) R ½ (15mm)
REU-VR2426WB 188 200 1000 15 R ¾ (20mm) R ¾ (20mm) R ¾ (20mm) -
REU-VR2024WG 160 160 1000 15 R ¾ (20mm) R ¾ (20mm) R ¾ (20mm) -
REU-VR1620WG 125 120 1000 15 R ½ (15mm) R ½ (15mm) R ¾ (20mm) -
REU-VR1620WB 125 120 1000 15 R ½ (15mm) R ½ (15mm) R ¾ (20mm) -
Consumption
MJ/h
Water Supply kPa
Min. Max. Hot Cold Gas Condensate
Weight
kg
Fittings
Table 1.
launaM noitallatsnI32ailartsuA ianniR
GENERAL INSTALLATION INSTRUCTIONS
500mm
HORIZONTAL FLUE TERMINAL CLEARANCES (Extract from AS5601 - 2004)
HORIZONTAL OBSTRUCTIONS
AS5601-2004 ‘Gas Installations’ stipulates a minimum
horizontal clearance of 500 mm between a building
structure and obstruction facing the terminal. For Rinnai
external continuous flow water heaters such a building
structure must ‘obstruct’ th e full front cover height of the
appliance, or extend vertically above and below the front
cover. There must be no partial obstructions to the front
cover of the appliance or any other parts of the appliance
casing. This will avoid the appliance failing to operate
under windy conditions.
MULTIPLE INSTALLATIONS OF EXTERNAL MODELS
Dimension ‘h’ above does not apply when multiple Rinnai
external water heaters of the same model are installed on
the same vertical face with flue terminals at the same
height. Under these conditions appliances can abut each
other as shown. The total gas consumption of all
appliances applies when determining other clearances.
Rinnai Australia 24 Installation Manual
GENERAL INSTALLATION INSTRUCTIONS
APPLIANCE AND WATER CONTROLLER DIMENSIONS
A
C
D
B
M
I
G
J
H
F
K
E
N
FITTING DIAMETER
L
Dim' Description
REU-VR2626WG
REU-VR3237WG
REU-VRM3237WC
A 053053074htdiW
B 572~532491442htpeD
C 006035006tinU-thgieH
D Height - Including Brackets 644 571 641
E Hot Water outlet (from wall) 115 87 91 ~ 131
F Hot Water outlet (from centre) 61 105 110
G Cold Water inlet (from wall) 99 68 70 ~ 110
H Cold Water inlet (from centre) 52 10 27*
I
Gas Connection (from wall) 61 77 99 ~139
J Gas Connection (from centre) 110 83 89
K Condensate outlet (from wall) - - -
L Condensate outlet (from centre) - - -
Gas Connection Length (from base) 41 40 41
Cold Connection Length (from base) 51 50 51
M
Hot Connection Length (from base) 42 42 42
Condensate Connection Length (from base) - - - --- -
N
Condensate: Fitting Diameter - - -
* Please note that this measurement is to the left of the centre line.
355.6
202
503
571
87
105
68
10
77
83
-
40
50
42
20
20
20
-
REU-VRM2630WD
REU-VR2632FFUG
020202retemaiDgnittiF:saG
020202retemaiDgnittiF:dloC
020202retemaiDgnittiF:toH
REU-KM3237WD
REU-VRM2632FFUC
470
283
670
722
115
100
80
28
104
103
138
195
40
50
41
22
20
20
20
15
470
283
670
722
115
100
75
13
104
103
138
195
40
50
41
22
20
20
20
15
REU-VR2426WB
REU-KM2635WD
350
350
194
194
530
530
571
571
87
87
105
105
68
68
10
10
77
77
83
83
-
-
40
40
50
50
42
39
20
20
20
20
20
20
-
REU-VR1620WB
REU-VR1620WG
REU-VR2024WG
350
194
530
571
105
-
-
-
87
68
10
77
83
40
50
39
20
15
15
REU-VRM2632WC
350
251
600
636
96
110
75
27*
104
89
-
-
-
41
51
42
20
20
20
-
-
Dim' Description
PR
O
Q
O 821htdiW
P 021thgieH
Q 02htpeD
Distance between
R
mounting hole centres
90
120
20
83
MC-91
83
BC-100V
MC-100V
202
104
22
181
launaM noitallatsnI52ailartsuA ianniR
GENERAL INSTALLATION INSTRUCTIONS
OFFON
SW1
1 2345678
FFU (Internal) Models Only
Short Flue: Total flue
lentgh less than 1.5 metres
OFFON
SW2
12 3 4 56
OFFON
SW1
1 2345678
FFU (Internal) Models Only
Extended Flue: Total flue
length 1.5 metres or greater
OFFON
SW2
12 3 4 56
Flue Length Dip switch Settings
Dipswitches
SW1
Dipswitches
SW2
1
2
3
4
COAXIAL FLUEING FOR INTERNAL MODELS
Rinnai internal models described in this manual must use the coaxial Rinnai FF flue components. The
use of non Rinnai FF flue components may result in a dangerous situation and violates regulations.
The FF flue system must be installed in accordance with the ‘FF Flue Installation Manual’ which is
provided with the FF flue terminal components FFWALLTERM or FFROOFCOWL.
Installations can consist of both
horizontal and vertical runs to a
maximum length of 9 metres and
with a maximum of three 90°
bends.
If flue length exceeds 1.5m,
dipswitch 1 of SW1 is to be
switched to the 'OFF' position.
This increases the combustion
speed to overcome the additional
friction loses.
Basic methods of installation
There are four basic flue
installation methods available.
These are:
(1.) Direct Horizontal
(2.) Extended Horizontal
(3.) Vertical
(4.) Combination Vertical /
Horizontal
Multiple Terminal Installations
The terminal clearances stated in
AS5601 do not apply to the Rinnai
internal continuous flow water
heaters when they are installed
side by side.
AGA certification allows for a
horizontal separation of 160 mm
for roof terminals and 270 mm for
wall terminals.
Rinnai Australia 26 Installation Manual
CONDENSATE DRAIN (REU-KM’ MODELS ONLY)
NOTE
A
B
C
B
D
E
The INFINITY ENVIRO 32 (REU-KM323 7WD) and INFINITY ENVIRO 26 (REU-KM263 5WD) water
heaters generate condensate continuously at a rate of up to 5 litres per hour as a by-product of highly
efficient gas burner system. This condensate must be drained via a pipe to a suitable point of
discharge. Because the condensate is a by-product of gas combustion it is mildly acidic. For this
reason copper tube and fittings MUST NOT be used as it will corrode. Instead, Rinnai recommend
plastic pipes and fittings such as Unplasticised Polyvinyl Chloride (UPVC) or Polyethylene (PE) which
is commonly used for irrigation piping.
IMPORTANT CONSIDERATIONS FOR THE CONDENSATE DRAIN PIPE
The content of AS3500.4:2003 Section 5.12 ‘Temperature / Pressure Relief and
Expansion Control Valve Drain Lines’ has been used as a guide in preparing these
considerations.
Water heater drain outlet connection, ½” (20mm) BSP male.
PE ½” BSP (20mm) female to barbed irrigation system connector (13 – 19mm) or equivalent
plastic fitting.
Drain pipe and fittings to match item .
Continuous fall (of at least 2°) from water heater to discharge point. Lengths and bends in
accordance with ‘LENGTH AND CHANGES OF DIRECTION’ below.
Suitable points of discharge are deemed to be drains, sewers or pits. DO NOT discharge onto
electrical connections, earth stakes, copper pipes, concrete paths or into a pond.
LENGTH AND CHANGES OF DIRECTION
Maximum length and changes of direction
greater than 45 ° should be as follows:
Max changes of direction >45° 3 4 5 6
Lengths and changes of direction
Max length (Metres) 9 8 7 6
INSTALLATION
(a) The drain line MUST NOT discharge onto electrical connections, earth stakes, copper pipes,
concrete paths or into a pond.
(b) The point of discharge from each drain line shall be located so that the release of condensate
does not cause a nuisance, is readily discernible and incurs no risk of damage to the building.
In view of (a) and (b), suitable points of discharge are deemed to be drains, sewers or pits.
(c) There shall be no tap, valve or other restrictions in any line.
(d) Each line shall fall continuously from the valve to the approved point of discharge.
(e) Drain lines shall not discharge into a storage water heater safe tray.
(f) The end of the condensate drain line shall be:
(i) not lower than 200 mm or higher than 300 mm above an unpaved surface; or
(ii) not lower than 75 mm or higher than 300 mm above a gravel pit not less than 100 mm in
diameter in a paved surface.
Rinnai Australia 27 Installation Manual
CONDENSATE DRAIN (REU-KM’ MODELS ONLY)
(g) Where disch arging over a tu ndish or gully trap, dra in lines shall have an air gap of a size at least
twice the diameter of the drain line.
INTERCONNECTION OF CONDENSATE DRAIN LINES
Condensate drain lines from multiple water heaters may be joined together provided they conform
with the ‘INSTALLATION’ requirements on page 27.
COMMON STACK DISCHARGE
Where individual water heaters are installed in a multistorey building, th e condensate dr ain lines may
discharge into a common stack, subject to the following:
(a) The discharge from the common stack is to a tundish, having a discharge line, that is not less
than the size of the common stack, directly connected to a fixture trap, and installed in connection
with any adjacent soil or waste stack.
(b) The discharge point of the common stack is such that any discharge is readily visible and not
cause any nuisance.
(c) The common stack is vented by extending the pipe upwards, above the roof level.
TUNDISH DRAIN LINES
The drain line from any tundish shall be not less than DN 20 or less than one size larger than that of
the largest drain line discharging into the tundish. Tundish drain lines shall comply with the
‘INSTALLATION’ requirements on page 27.
AREAS SUBJECT TO FREEZING
In areas where water pipes are p rone to freezing, the drain pipe from any valve shall be insulated and
not exceed 300 mm in length. It shall discharge into a tundish through an air gap of not less than 75
mm and not more than 150 mm measured from the outlet of the drain pipe to the rim of the tundish.
Rinnai Australia 28 Installation Manual
WATER CONTROLLER INSTALLATION
NOTE
NOTE
NOTE
RINNAI WATER CONTROLLERS
Water controllers are available as an optional extra. Universal and Deluxe water controllers can be
used together and will function as described in the Operation Section of this manual. Please refer to
page 6 to confirm the maximum number and combination of water controllers that can be fitted.
Other manufacturers water controllers are NOT compatible with Rinnai water
heaters. Water controllers MUST NOT be used with any Solar Boost water heater .
Rinnai water controllers brought in from other countries are not compatible with
Rinnai appliances sold in Australia.
POSITIONING OF WATER CONTROLLERS
Water controllers must be installed in shaded and clean locations. They should be fitted out of reach
of children (suggested height from floor to be at least 1500 mm). BC-100V remote controllers are
water resistant, however, durability is improved when positioned outside the shower recess. All deluxe
remote controllers must be installed at least 400 mm above the highest part of a sink, basin or bath.
• Do not install remote controllers near a heat source, such as a cook top, stove
or oven. Heat, steam, smoke and hot oil may cause damage.
• Do not install remote controllers in direct sunlight.
• The MC-100V remote controller MUST NOT be installed in a bathroom.
• Do not install remote controllers outdoors unless protection from dust
ingress and sunlight are provided.
• Do not install remote controllers against a metal wall unless the wall is
earthed in accordance with AS/NZS3000.
• Water controllers MUST NOT be installed where chemicals such as benzine,
alcohol, turpentine or other similar chemicals are in use.
POSITIONING CONSIDERATIONS FOR THE MC-100V WATER CONTROLLER.
The MC-100V uses a Liquid Crystal Display (LCD) for the digital
monitor. Light reflections can make the LCD difficult to see at
direct eye level.
For best results when Installing the MC-100V mount the remote
controller lower than your eye-level to avoid these light
reflections.
WATER CONTROLLER CABLES
Water controllers operate at extra low voltage (12 Volts DC) which is supplied from the water heater.
Each Water controller comes supplied with 15 m of electrical cable. The appliance end of the cables
are fitted with spade terminals. Extension cabling is available from Rinnai.
Alternatively two core sheathed (double insulated) flex with minimum crosssectional area of 0.5 mm² may be used. Maximum individual cable runs should
not exceed 50 m.
FITTING THE ‘UNIVERSAL’ WATER CONTROL (MC-91Q)
1. Determine the most suitable position for the water controller.
2. Mark and drill 3 holes, locating the cable access as shown in Fig. 1.
3. When running cable through the access hole ensure the connector end of the cable is located
nearest to the controller (Fig.2).
4. Carefully remove face plate from the water controller, using a screw driver (Fig. 3).
5. Connect the cable to the water contr oller. Feed any excess cable lengths into the wall cavity to
avoid the pinching of cables between the wall and the controller.
6. Fix the water controller to the wall using the appropriate fixings as shown in Fig. 4.
Rinnai Australia 29 Installation Manual
WATER CONTROLLER INSTALLATION
Connector
Controller Cable
Face Plate
Face P late
Screw
Film
QUESTION
QUESTION
NOTE
7. Remove protective film from the water contr oller face as shown in Fig. 4 and replace face plate.
41.5
83
120
Securing
Screw
Outline of Water Control
90
Fig. 1
Ø20 Cable Access
Fig. 2 Fig. 3 Fig. 4
OPTIONAL PROGRAMMING FOR THE ‘UNIVERSAL’ WATER CONTROLLER (MC-91Q)
Are there four water controllers connected ?
IF NO: (You have three water controllers or fewer), go to Question 2.
IF YES: You will need to activate the fourth water controller as follows:
STEP 1: For the water controller in the KITCHEN ONLY, press and hold
the ‘Transfer’ and ‘On/Off’ buttons simultaneously (see Fig. 5)
until a ‘beep’ is heard (approximately 5 seconds).
STEP 2: Check that the display on ALL FO UR water controllers is lit and
displaying a temperature when ‘switched on’. If any ONE of the
controller displays two dashes (see Fig. 6) repeat STEP 1.
This completes the activation procedure for the fourth controller,
you may ignore Question 2.
Fig. 5
Fig. 6
Is the water heater marked to state it delivers water
not exceeding 50°C ?
IF YES: No further action required.
IF NO: You will need to program the kitchen controller to enable
selection of temperatures higher than 50°C.
STEP 1: For the controller in the KITCHEN ONLY, press and hold the
‘Transfer’ and ‘On/Off’ buttons simultaneously (Fig. 7) until a
‘beep’ is heard (approximately 5 seconds).
Fig. 7
STEP 2: When the controller fitted in the KITCHEN is switched On, it
should be possible to select temperatures higher than 50°C. If
not, repeat STEP 1.
If the water controller in the kitchen is replaced, repeat STEP 1 above for the
replacement controller.
If the water controller in the kitchen is swapped with another controller (for
example, the controller fitted in a bathroom), repeat STEP 1 for the controller
moved from the kitchen to the bathroom. Then perf orm STEP 1 for the contro ller
moved from bathroom to the kitchen.
Rinnai Australia 30 Installation Manual
WATER CONTROLLER INSTALLATION
181
202
Outline of Water Controller
104
Securing
Screw
Ø20 Cable Access
Connector
Controller Cable
Backing Seal
Remove film
to expose
self-adhesive
FITTING THE ‘DELUXE KITCHEN’ WATER CONTROLLER (MC-100V)
1. Determine the most suitable position for the water controller (see notes page 29).
2. Use the wall mounting bracket as a template to mark and drill 3
holes, locating the cable access as shown in Fig. 1.
3. Fix the mounting bracket to the wall using the appropriate fixings.
4. Run the cable through the hole in the wall.
128
5. Carefully remove face plate from the water controller, using a screw
driver (Fig. 2).
Screw Securing Points
Outline of Water Controller
Fig.1
6. Connect the cable to the water controller as shown in Fig 3. At this point cables from other
controllers (if fitted) may also be connected to th e screw terminals of the Kitchen water controller
(Fig. 4) eliminating the need for multiple cable runs directly to the water heater. Water controllers
are not polarity sensitive. Feed any excess cable lengths into the wall cavity to avoid the pinching
of cables between the wall and the controller.
7. Fasten the controller to the wall moun ting brac ke t as shown in Fig. 5. Avoid the over-tightening
of fixings as this may cause damage. Once secured replace the face plate.
Fig. 2 Fig. 3
Fig. 4 Fig. 5
FITTING THE ‘DELUXE BATHROOM’ WATER CONTROLLER (BC-100V)
1. Determine the most suitable position for the water controller (see notes page 29).
120
Ø20 Cable Access
2. Mark and drill 3 holes, locating the cable access as shown in Fig. 1.
3. When running a cable throug h the access hole ensure the conne ctor
end of the cable is located nearest to the controller (Fig. 2).
4. Affix the double sided self-adhesive seal to the back of the water
controller (Fig. 3).
5. Carefully remove the face plate from the water controller, do this by
Fig. 1
placing your thumbs on the front of the digital display and while
hooking your fingers behind top of plate and gently push as shown in
Fig. 4, DO NOT use a screwdriver as this may damage the controller.
6. Connect the cable to the water controller. Feed any excess cable
lengths into the wall cavity to avoid the pinching of cables between
the wall and the controller.
Fig. 2
7. Fix the controller to the wall using the appropriate fixings as shown in Fig. 5, avoid overtightening of fixings as this may cause damage. Once secured replace the face plate.
Rinnai Australia 31 Installation Manual
Fig. 3 Fig. 4 Fig. 5
WATER CONTROLLER INSTALLATION
CAUTION
A
B
C
D
E
A
A
B
A
C
E
D
B
'Ezi connect' cable connector for water heater models:
INFINITY 26, 26 Plus, 20, 16, V1500, V1200.
HD 200e (REU-VM2630WC).
'Ezi connect' cable connector f or water heater models:
INFINITY 32, 26i, EVIROSMART
HD 250e, 200e (REU-VRM2632WC), 200i
F
Three
Cables
Four
Cables
F F F
CONNECTING COMMUNICATION CABLES TO THE WATER HEATER
Communication cables connect the water heater to water controllers and operate at an extra low
voltage (12 Volts DC) which is supp lied from the water heater . Communication cables ar e supplied
with the water controllers (15m) and are fitted with spade ter minals for co nnection to water heater . Up
to two cables can be connected directly to the ‘Ezi connect’ cable connector at the water heater.
Extension cables are available from Rinnai. Alternatively, two core sheathed (double insulated) flex
with minimum cross sectional area of 0.5mm² may be used. Cable length s must not exceed 20 metres.
DO NOT attempt to connect cables to the 'Ezi connect' cable connector at the water
heater unless the electric power to the water heater is switched ‘off’ otherwise damage
to electrical components may occur.
To connect up to two cables to the 'Ezi connect' cable connector
1. Isolate the electric power supply by switching the power point off and removing the power plug of
the water heater from the electric power socket.
2. Remove the retaining screw of the 'Ezi connect' cable connector at the base of the appliance.
3. Swing the 'Ezi connect' cable conn ector door op en an d thread the cab le th rough the weathe r seal
of the cable access hole in the direction shown allowing sufficient cable length so that the
sheath of the cable can be secured with cable clamp supplied with the transceiver.
4. Loosen screw terminals and and connect the cable spade connectors to these terminals
and re-tighten. Polarity is not important, either wire colour can be connected to either terminal.
5. Return the 'Ezi connect' cable connector to the original position taking care not to damage cable
wires in the process and replace the retaining screw .
Connecting Three or Four Controllers
Repeat steps 1, 2 and 3 above.
To connect three or four cables, separate all the cabl es to be fitted into
pairs. Cut off the existing spade connectors from each pair and reterminate each pair into a new spade connector (available from your
local electrical component retailer) so that there are only two sets
of spade connectors (4 spade connectors in total) to be terminated.
Repeat steps 4 and 5 above.
Rinnai Australia 32 Installation Manual
COMMISSIONING
TESTING
1. Before final connection of the water heater purge gas, hot water and cold water supply lines.
Swarf in either the gas or water supplies may cause damage.
2. Turn on gas and cold water supplies.
3. Test for water leaks and gas escapes near the unit.
4. Isolate gas supply. Remove test point screw located on the gas inlet connection and attach
pressure gauge.
5. Turn the power 'on' at the power point socket and tu rn on gas.
6. If water controllers are fitted, turn ensure they are controller 'ON', select the maximum delivery
temperature and open ALL available hot water taps including the shower. If remote controllers
are not fitted, simply open all available hot water taps. (CAUTION: Ensure building occupants do
not have access to hot water outlets during this procedure.)
7. Operate ALL other gas appliances at their maximum gas r ate, in accordance with manufactur ers
instructions.
8. With all gas appliances in operation at maximum gas rate, the pressure should read between
1.13 - 3.0 kPa on Natural Gas. On LPG the pressure sh ould be 2 .75 - 3.0 kPa. If the pressure is
lower, the gas supply is inadequate and the appliance will not operate to specification. It is the
Installers responsibility to check the gas meter, service regulator and pipe work for correct
operation/sizing and rectify as required. Note that the gas regulator on the appliance is
electronically controlled and factory pre-set. Under normal circumstances it DOES NOT need
adjustment during installation.
9. Close hot water taps including the shower.
10. Inspect and clean the strainer located on the cold water inlet connection. This procedure may
need to be repeated to ensure the strainer remains clear, especially on new installations.
11. If water controllers are fitted, it is necessary to test their operation through the complete range of
functions (refer to the Operation sections of this manual).
12. Confirm the hot water delivery temperature(s) using a thermometer. If controllers are fitted,
ensure temperatures exceeding 50º C cannot be selected on bathroom or ensuite contr ollers.
13. After testing is completed, explain to the householder the functions and operation of the water
heater and temperature controllers (if fitted). Ensure the “PRODUCT RECORDS” on page 35 of
this manual is filled in and that the booklet is handed to the customer. Reminding the customer
to complete the Warranty Card and forward to Rinna i.
GAS PRESSURE SETTING
The regulator is electronically controlled and factory pre-set. Under normal circumstances it does not
require adjustment during installation.
Make adjustments only if the unit is not operating correctly and all other possible causes for incorrect
operation have been eliminated.
Instructions for Gas Pressure Setting are to be found in the instruction pocket located inside the
appliance front cover.
COMMISSIONING CHECK LIST
A commissioning check list is provided to enable the installer to step through the correct
commissioning procedure when installing a Rinnai Continuous Flow water heater.
The check list can also assist the installer to identify potential installation errors that may prevent the
appliance from operating correctly.
For your convenience a copy of the commissioning check list has been provided on the following
page.
Rinnai Australia 33 Installation Manual
COMMISSIONING
Rinnai Australia 34 Installation Manual
ACCESSORIES
Recess Box:
When installing an Rinnai Continuous Flow hot water heater in a new home or renovation, it is a great
idea to allow for a recess box to be included at the construction stage. These boxes allow you to
literally recess the appliance into the cavity of the wall saving precious space. In addition they virtually
hide your hot water system altogether. A semi recessed (approx. 70mm proud of the wall) model is
available for all water heater models. In additio n, a fully recessed (flush to the wall) model is available
for use with the INFINITY 32 and HD250e water hea ters. All boxes and covers are suitable for painting
to blend in with the exterior of your home.
Pipe Cover:
Pipe covers are recommended as the finishing touch to an Rinnai Continuous Flow hot water heater
installation. Basically the covers ar e designed to hide the plumbing pipework and valves. These are
particularly popular in installations where the unit is permanently visible to the occupants of the house.
The cover can be easily attached to the appliance and two pipe covers can be joined together for
longer pipework if necessary.
Security Cage:
The Rinnai cage is available t o protect the unit from theft and da m ag e if th e Rinn a i Co n tin uo us F low
hot water heater is located in an exposed area.
Security Bracket:
Prevent theft by securing your Rinnai Continuous Flow hot water heater with our custom security
bracket, easily installed it covers the lower mounting bracket of the appliance to create a ta mper proof
installation.
Rinnai Smartstart® Water Saver
How much water is wasted everyday in Australian households waiting for the shower to get hot?
Previously a smart house design with the hot water system installed close to bathro oms was the only
way to reduce this wastage. The new Rinnai Smartstart® water saver is designed specifically to
reduce the water wasted in hot water dead legs, the Rinnai Smartstart® is installed with a Rinnai
Continuous Flow water heater and a hot water ringmain to all ‘wet areas’ of the home.
Sideways Flue Diverter
Redirects flue products from Rinnai continuous flow water heaters installed on balconies patios or
similarly enclosed areas. This product is available for selected models only.
Contact Rinnai for further information about our accessory range and model suitability details.
PRODUCT RECORDS
Please take a moment to record the following information below for your own records .
Model No : REU- Serial No :
Your Retailer :
Address :
Contact Number: ( )
Purchase Date : / /
Your Installer :
Address :
Installers License No. :
Contact Number : ( )
Installation Date : / /
Certificate of Compliance No. :
Rinnai Australia 35 Operation/Installation Manual
CONTACT INFORMATION
Australia Pty. Ltd.
ABN 74 005 138 769
Head Office
10-11 Walker Street,
Braeside, Victoria 3195
P.O. Box 460
Tel: (03) 9271 6625
Fax: (03) 9271 6622
Rinnai has a Service and Spare Parts network with personnel who are fully trained
and equipped to give the best service on your Rinnai appliance. If your appliance
requires service, please call our Hot Water Service Line. Rinnai recommends that
this appliance be serviced every 3 years.
Internet: www.rinnai.com.au E-mail: enquiry@rinnai.com.au
National Help Lines
Sales & Service
Tel: 1300 555 545* Fax: 1300 555 655*
Spare Parts & Technical Info
Tel: 1300 366 388* Fax: 1300 300 141*
*Cost of a local call Higher from mobile or public phones.
Hot Water Service Line
Tel: 1800 000 340
U 2 8 7 - 2771X01 ( 0 0)
Printed in Japan 2009.10
90/80/52 1.1 eussI 110-90DST AR63
Loading...
