MP 161LN
High-value desktop multifunctionality
Standard equipped to suit your exact needs
Whether you work in a small office or workgroup, your office needs are diverse yet precise. The Aficio™MP
161LN has exactly what it takes to meet them. Copying, printing, colour scanning and full networkability: this is a perfect match for everyone. The MP 161LN is highly reliable and user-friendly, providing standard duplexing, attractive paper handling and fast operation. Compact, convenient and cost-effective, these office partners are ready to optimise your specific workflow!
Fast copying and duplexing.
Easy document feeding.
Standard network printing.
Network TWAIN colour scanning.
Small footprint.
Your entire document flow covered
ALL AT THE TOUCH OF A BUTTON
With no time to waste, you need an office device that is easy to install, operate and maintain. Designed
with ease of use in mind, the MP 161LN offers:
Simple plug and play installation.
Full front accessibility.
A straightforward operation panel with LED light.
SOLID RELIABILITY
Equipment you can fully depend on is crucial in your fast-paced office. With the MP 161LN you can rest assured. Building on years of experience and technological innovation, these digital systems offer a whole new level of professionalism.
THE COMPACT ANSWER
Small footprint.
Space-efficient, compact design with handy internal output tray.
Fits anywhere in the office without intruding on valuable workspace.
SPEED AT YOUR FINGERTIPS
Instantly available, the MP 161LN is ready for business in less than 10 seconds. Your first copy or print exits the device in under 7.5 seconds. A continuous output speed of 16 ppm is guaranteed.
MP 161LN
CONVENIENT PAPER HANDLING
Able to handle any paper size from A6 up to A4, the MP 161LN not only tackles your everyday office tasks. It also takes care of the occasional special request. Larger print/copy jobs are quickly processed too. With a maximum paper capacity of 850 sheets, you need not worry about frequent refills. Further­more, the handy ARDF facilitates feeding of up to 50 sheets at once.
STANDARD DUPLEXING
Save paper and reduce your costs by copying and printing duplex. Standard included on the MP 161LN, the duplex function produces double-sided output at high speed. To save you time, the MP 161LN’s scanner can digitise both sides of an original in one go.
HANDY PRINTING AND COLOUR SCANNING
Low-cost printing.
Colour scanning by using the TWAIN driver.
Easy digitising of books and magazines: scan straight from the platen glass.
Standard network printing for efficient integration within the workgroup.
RICOH’S GREEN COMMITMENT
Like all Ricoh products, the Aficio™MP 161LN reflects Ricoh’s commitment to the environment. We use toxic-free materials, limit noise emission and produce toner with little energy. With their ultra-low power consumption and standard duplexing, our devices take environmental care even further.
MP 161LN
COPIER
Copying process: Laser beam scanning and electro-photographic printing Copy speed: 16 copies per minute Resolution: 600 dpi Multiple copy: Up to 99 Warm-up time: Less than 10 seconds First output speed: Less than 7.5 seconds Zoom: 50 - 200% (in 1% steps) Memory: Standard: 16 MB Paper input capacity: Standard: 1 x 250-sheet paper tray 1 x 100-sheet multi-bypass tray Maximum: 850 sheets Paper output capacity: Standard: 250 sheets (internal tray) Paper size: Standard tray: A5 - A4 Bypass tray: A61 - A4 Duplex tray: A4 Paper weight: Standard tray: 60 - 90 g/m² Bypass tray: 60 - 157 g/m² Duplex tray: 64 - 90 g/m² Dimensions (W x D x H): 485 x 450 x 371 mm Weight: Less than 24 kg Power source: 220 - 240 V, 50 - 60 Hz Power consumption: Operation: Less than 900 W Energy saver mode: Less than 25 W
PRINTER
Print speed: 16 prints per minute Printer language/resolution: Standard: DDST: 600 x 600 dpi Option: PCL5e, PCL6: 600 x 600 dpi Interface: Standard: USB 2.0 Ethernet 10 base-T/100 base-TX Memory: Standard: 80 MB Network protocol: TCP/IP, IPP Supported environments: Windows® 2000/XP/Server 2003/Server 2008/Vista
SCANNER
Resolution: Full colour: 600 dpi using the optional memory Black and white: 600 dpi Original size: A5 - A4 Bundled drivers: Network, TWAIN
CONSUMABLES
Toner: Black: 7,000 sheets Photo conductor unit
OPTIONS
Platen cover 50-sheet Auto Reverse Document Feeder 1 x 500-sheet paper tray 256 MB memory PCL option Counter interface unit
1
Manual input.
Ricoh has designed this product to meet EC ENERGY STAR guidelines for energy efficiency.
For availability of models, optional apparatus and software, please consult your local Ricoh supplier.
ISO9001: 2000 certified ISO14001 certified
All brand and/or product names are trademarks of their respective owners. Specifications and external appearance are subject to change without notice. The colour of the actual product may vary from the colour shown in the brochure. The images in this brochure are not real photographs and slight differences in detail might appear.
Copyright © 2009 Ricoh Europe PLC. All rights reserved. This brochure, its contents and/or layout may not be modified and/ or adapted, copied in part or in whole and/or incorporated into other works without the prior written permission of Ricoh Europe PLC.
